LUCIFER LIGHTING. mINImaL FIxTURES.

LEVER HOUSE

New York, NY

A retro/modern setting with warm

wood, mirrors, and black chairs is

enlivened by the small aperture,

sheer profile, recessed trims that

provide a strong contrast to the

conventional lighting in the honeycomb

ceiling panel.

Lighting: L’Observatoire International

Designer: Marc Newson

Fixture: DL11Z (p 20)

maxImaL

ImPaCT.®

4 AbOut the cOMpANY

5

OU DON’T NEED

IG LIGHTS TO

aKE a BIG ImPaCT.

At Lucifer Lighting, sophisticated design,

engineering innovation, and sustainable

light sources come together in architectural

fixtures that let your vision come to light.

All of our products—downlights, tracks, spots,

light strips, fiber optics, and landscape and path

lights—accept a variety of effects devices such

as lenses, louvers, kick reflectors, and filters.

Most also accept a variety of energy efficient

lamp sources and can be dimmed or controlled

by occupancy and photo sensors to reduce energy

consumption. We call it Tuneable ® Lighting.

Designers call it being able to produce the exact

results they want and need, with fixtures that

don’t call attention to themselves.

Lucifer means “bearer of light”, and it’s

what we do best—bring you the light you

need to design the environment you want.

6 7

JamES HOTEL

Chicago, IL

Subtle, no-glare lighting enhances

daylight by providing overall ambient

illumination and accents where needed,

such as over the reception desk and

seating areas.

Architecture: Yabu Pushelberg

Lighting: Isometrix Lighting + Design Ltd.

Fixture: DL2RZP (p 18)

8 INtRODuctION INtRODuctION 9

LEGaNCE IN DESIGN

ND ENGINEERING.

Downlights from Lucifer Lighting allow designers

to emphasize the effect, not the fixture. Small-scale

downlights and apertures, zero-sightlines, distinctive

finishes, and advanced engineering combine to create

the highest-quality, most unobtrusive fixtures available.

Our downlights perform beautifully whether you’re

designing light in art galleries or offices, residences

or retail settings, poolside or marine environments,

accessible or inaccessible ceilings, new construction

or remodeled interiors, restaurants, hotels, museums,

and more.

Lucifer Lighting has led the way in lighting for more

than 25 years with innovations and inventions that

have been copied, but never equaled.

be sure to check our website, luciferlighting.com,

for our Downlight Application Guide which provides

zero-sightline trade notes that can be incorporated

into drawings and electrical specifications.

HOUSING

APPLIQUé

SCREWS

TRIM

You’ll also find detailed photometry reports, the

most up-to-date product spec sheets, and complete

installation instructions.

ZERO-SIGHTLINE DOWNLIGHTS

Our zero-sightline trims install flush to the ceiling to

create a sleek finish without any visual distractions—just

a smooth surface punctuated with the beauty of pure

light. Because all parts are precision-engineered, with a

proper installation, there will be no ceiling cracking for

years and years.

We make flush-fit installation easy. Housings come

direct from the factory ready to accept the zero-sightline

kit. Simply frame in the housing, apply drywall, then

align the screw holes on the appliqué with those on the

rotatable collar on the housing, and secure. The rotatable

collar is a Lucifer innovation that makes it fast

and easy to align successive square trims in a ceiling—

the trim orientation can be rotated after the housing is

installed but before spackle is applied. After the appliqué

is spackled and painted, the downlight is installed.

Fixtures can also be specified without an appliqué so the

trim can overlap the ceiling.

ROTATABLE COLLAR

OPTIONAL ZERO-

SIGHTLINE KIT

GEaR-DRIVEN DOWNLIGHTS

We engineered the industry’s first dual-axis, gear-

driven downlights with 45º aim and superior center

beam optics.

Concealed internal gear trains create self-locking,

anti-skid, rotatable, and aimable two-axis adjustments.

All adjustment mechanisms are concealed by the

fixture faceplate, which is easily removed to provide

immediate access to the lampholder. Rotation and tilt

can be adjusted from inside the room, using just a

screwdriver, without removing the fixture or damaging

the ceiling, and while the light is on, so you can see the

effect while you’re creating it.

ZERO-SIGHTLINE DOWNLIGHT GEaR-DRIVEN DOWNLIGHT

In addition, an indexing key on the fixture precisely aligns

with the die-cast key slot in the appliqué to guarantee

the lampholder—and therefore, your lighting design—

stays in position after every relamping. Most fixtures can

accept up to three effects devices to control beam, color,

and glare. A black, baffle eliminates aperture glare.

KEYED FOR ALIGNMENT:

APPLIQUé KEY SLOT

FIXTURE KEY

ROUND OR SQUARE FACEPLATE IS

EASILY REMOVED FOR ADJUSTMENT

OF LAMPHOLDER ROTATION AND TILT

357º ROTATION 0º-45º TILT

10 INtRODuctION INtRODuctION 11

HE RIGHT LIGHT,

HE RIGHT EFFECTS

Lucifer Lighting is committed to excellence in interior

design and sustainability. By choosing the right light

source, fixture, and effects devices, you can create a

stunning setting that is also energy efficient.

MR AND LINE VOLTAGE HALOGEN

Halogen lamps are incandescent lights that use filaments

originally developed for the automotive industry.

Those in the MR (multifaceted reflector) configuration

are known for their precision and variably focused beam

that uses IR (infrared) technology to efficiently pack

light at 24 lumens per watt, offering higher wattage

performance at lower wattage consumption. Because

their color temperature is similar to sunlight, color,

texture, skin tones, fabrics, and food all look natural

under halogen lights. Special Halogen IR lamps contain

no mercury, are energy efficient, offer instant-on, and

are easily dimmable, making them a versatile choice.

EFFICIENCY COLOR TEMP 1 COLOR RENDITION 2 15-24 2,800-3,050 100 4,000-6,000

RATED LIFE

Lumens/Watt Degrees Kelvin CRI Hours

MR HID

High intensity discharge lamps are an arc source, often

referred to as metal halide. Usually thought of as very

high wattage, large area light sources, low wattage,

ceramic metal halide HID lamps offer an energy-efficient

alternative to standard incandescent light sources, with

similar color temperature and rendition. They are effective

in applications where instant-on, instant re-strike, or

dimming are not required, such as high-ceiling interiors,

retail stores, public spaces or residential exteriors where

the fixtures are operating on controls.

EFFICIENCY COLOR TEMP 1 COLOR RENDITION 2 50-53 3,000 81/92 12,000

RATED LIFE


1. Degrees Kelvin refers to the color of transmitted

light; lower Kelvin values denote a warmer perceived

light, and higher values a cooler, more bluish light.

2. cRI refers to how well color is rendered; a color

rendition index of 100 is considered optimal.

CHOOSING a LIGHT SOURCE

The lighting industry is at a welcome crossroads where

technological advancements are now able to support

environmental concerns by offering lamps that conserve

energy while providing the quality of illumination designers

demand. The following information will help you choose

the appropriate lamp for your Lucifer Lighting fixture.

LED

Light emitting diodes are solid state light sources that

are rapidly approaching the energy efficiency of CFLs.

Their small size brings them close to the optimal point

source and creates a range of opportunities for energy

efficient lighting design, especially for display and

accent lighting in lower ambient environments. LEDs

are also available in a wide range of white and discrete

colors, do not emit harmful IR (infrared) or UV (ultraviolet)

radiation, and do not contain mercury. LEDs are

currently not bright enough to supplant halogen lamps

for general illumination.

EFFICIENCY COLOR TEMP 1 COLOR RENDITION 2 7-37 2,700/4,200 70 50,000

RATED LIFE


CFL

Compact fluorescent lamps are an arc source that use

less power and have a longer life than incandescent

lamps, but their color temperature and rendition is not

as natural. Also, though they efficiently radiate diffuse

light over a broad area, they do not focus well, so are

not suited for accent lighting. While they are extremely

energy efficient, they do contain small amounts of

mercury which complicates disposal options and raises

questions about their environmental impact.

EFFICIENCY COLOR TEMP 1 COLOR RENDITION 2 54-60 2,700-4,100 82 12,000

RATED LIFE


As light sources are continually and rapidly evolving to

reflect technological advances and meet new needs, we

recommend you check with luciferlighting.com for the

latest information on available lamp sources.

CHOOSING a FIxTURE aDDING EFFECTS DEVICES

Most downlights are available with either round or

square faceplates. Many architects and designers find

round trims to be the most versatile and accommodating,

especially in irregularly shaped rooms, while

square trims can be especially effective in square or

rectangular spaces and when used in soffits to wash a

wall with light.

Fixed

To light a generalized area, such as a reception area,

office, corridor, or discrete area in a room, like a sofa

or dining table, fixed fixtures will provide crisp,

uniform illumination.

adjustable

Adjustable fixtures provide more focused illumination

to accent specific objects, such as a work of art, display

shelving, or interior furnishings. They are also useful in

interiors where furniture may be moved or its final

position is unknown.

Gear-Driven

If art, displays, or furnishings may change locations,

gear-driven, adjustable fixtures allow light to easily be

redirected. Gear-driven fixtures also allow you to

effectively position accent lights without moving the

finished trim in orientation to the ceiling.

Wallwash

A wallwash fixture will provide a soft and even wash

of light from where the wall meets the ceiling to where

it meets the floor, without scalloping. Wallwashing is

generally enhanced by using three or more fixtures.

Wet Location

Stainless steel fixtures are corrosion resistant, making

them appropriate for dry, damp, and wet exterior

locations, such as showers, baths, and under soffits

and eaves. Polymer fabricated trims are an excellent

alternative for use in harsh marine environments.

Effects devices are heat-treated glass lenses, color

filters, and black metal louvers and baffles. They allow

a designer to shape and control light to customize the

space, create added emphasis, or set a particular mood.

Clear lens (1)

Clear borosilicate glass lens for unlensed lamps;

conforms to NEC and NFPA codes.

Ultra-violet lens (2)

Made by Bausch and Lomb; blocks 99% of UV

radiation from light sources.

Spread lens (3)

Scatters and diffuses the light and is typically used

on rough and textured surfaces.

Linear spread lens (4)

Shapes the light into a vertical or horizontal

elongated form that is typically used to illuminate

columns or retail displays.

Soft focus lens (5)

Softens and spreads the light beam.

Honeycomb louver (6)

Minimizes glare and, if stacked closest to lamp

source, will also confine the beam.

Warm tone lens (7)

Adjusts color temperature of light to 2700 degrees

Kelvin, which enhances the depth of tones on surfaces

like wood panels.

Frosted lens (8)

Provides maximum beam diffusion and smoothes

out scallops.

LENSES

1 2 3 4 5 6 7 8

12 13

DUO RESTaURaNT, FOUR SEaSONS

aT maNDaLaY BaY, Honolulu, HI

These fixtures are resistant to the

corroding effects of wet weather and

salty air in this restaurant by the sea;

the stainless steel finish also reflects the

other shiny surfaces in the kitchen and

throughout the dining room.

Lighting: h.e. banks + associates

Fixture: DL21Z (p 21)

14 Z SERIES DOwNLIGhts 15

Z SERIES

OVERVIEW

The Z Series is the most diminutive downlight

fixture collection Lucifer Lighting offers. In addition

to small apertures, most fixtures have an outside

dimension of 4" or less and profiles of only 55/1000

of an inch, making them almost invisible against the

ceiling. Also, most trims can be installed flush to

the ceiling for zero-sightline applications. Precisely

machined torsion spring clips ensure secure

retention in ceilings that vary in thicknesses up

to 1", and allow the trim to be rotated from below.

Fixtures are listed for dry, damp, and wet locations.

The Z Series fixtures are compatible with the

following MR-16 style light sources: 20w to 75w low

voltage halogen, 20w and 39w HID ceramic metal

halide, 5w LED, and CCFL.

For export markets that require a special terminal

block on the downlights that will not be used with

housings, we recommend you refer to international

specification sheets for Z Series fixture construction.

Z SERIES aNTI-GLaRE

PROFESSIONaL BaFFLE

Most Z Series open aperture trims include a

distinctive, precision-engineered design feature,

the Professional Baffle. This black, die-cast

element covers the inside edge of the aperture

to ensure the aperture edge is non-reflective and

glare free when the fixture is illuminated.

FINISHES aND aCCESSORIES

Standard Z Series finishes are white and black with

a matte granulated powdercoat, industrial gray with a

glass bead blasted stainless steel finish, and polished

chrome. Select trims are available in brushed stainless

steel. Custom finishes are also available.

All Z Series fixtures come with a frosted lens. Standard

trims may accept multiple lenses or effects devices,

depending on lamp.

In areas of the ceiling where downlight fixtures may

be installed at a future date, for example, to illuminate

artwork when it changes position in a room, blankoff

plates (DLA-BOP-Z-RD round or DLA-BOP-Z-SQ

square) may be used. These blanks are appropriate

for both zero-sightline and trim flange overlay ceiling

conditions. Plates are easily removed using central

pinholes.

Fixture with professional baffle Fixture without professional baffle

PRIVaTE RESIDENCE

Modesto, CA

The art collector who owns this home

occasionally rearranges the collection.

Downlights with adjustable rotation and tilt

are simple to redirect when artwork is moved.

Keyed alignment between the downlight and

appliqué ensures correct placement of aimed

lamp during relamping.

Lighting: Randall Whitehead Lighting Design

Fixture: DL32DGZP (p 23)

16 Z SERIES DOwNLIGhts 17

CORPORaTE INTERIOR

Houston, TX

Diminutive downlights complement this

minimalist interior design. White finishes

accent the room’s perimeter, while chrome

finishes play up furniture details.

Lighting: Planning Design Research

Fixture: DL2RZP in chrome and white (p 18).

Series 2000 light strip also used.

Round Fixed

DL1Zp

Round adjustable Gear-Driven

DL2DGZp

1.75"

44mm

3.95" 100mm

1.75"

44mm

3.95" 100mm

3.13"

80mm

ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaT1ZP

Round, fixed downlight with deeply regressed lamp, and .055" thick trim flange

that is almost invisible against the ceiling. Optional zero-sightline appliqué can be

installed flush with the ceiling. 1.75" round aperture includes professional baffle.

Accepts up to 3 effects devices, depending on lamp.

4.00"

102mm

ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaT2DGZP

LAMPS

hAL, hID, LeD, ccFL

SPECIFICATION NOTES

ceiling mounted appliqué must be specified

separately for zero-sightline applications.

Lamp must be specified and ordered separately.

LAMPS






Round, hot aim, adjustable downlight with deeply regressed lamp, two axis, selflocking,

357° rotation, up to 45° of tilt in ceilings up to 5/8" thick, up to 15º of tilt in

ceilings up to 1" thick, and .055" thick trim flange that is almost invisible against

the ceiling. Optional zero-sightline appliqué can be installed flush with the ceiling.

1.75" round aperture includes professional baffle. Accepts up to 3 effects devices,

depending on lamp. patent pending.

enter an online quick product page reference

into our website search field to go directly to a

specific product page.

DL1Zp

DL2DGZp

18 Z SERIES DOwNLIGhts

Z SERIES DOwNLIGhts 19

DL2RZp DL6Zp

Round adjustable

DL2RZp


for detailed photometry reports, the most up-to-date

product spec sheets, and installation instructions.

1.75"

44mm

3.95" 100mm

1.75"

44mm

3.95" 100mm

3.13"

80mm

DL5Zp DL9Zp

Round Wallwash mirage ®

DL5Zp

ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaT2RZP

3.33"

85mm

Refer to online Downlight Application Guide for zerosightline

trade notes recommended for incorporation

in drawings and electrical specifications.

LAMPS






Round, adjustable downlight with deeply regressed lamp, up to 45° of manual tilt

that can be locked in any position from the room side, and .055" thick trim flange

that is almost invisible against the ceiling. Optional zero-sightline appliqué can be

installed flush with the ceiling. 1.75" round aperture includes professional baffle.



LAMPS






RECOMMENDED LAMP AND BEAM SPREAD

Ge 50w MR-16 Medium Flood eXK 30º

RECOMMENDED SPACING

15"-18" setback, 30" on center

Round, wallwash downlight with internal kick reflector with integral frosted lens

for uniform, glare-free wallwashing, and .055" thick trim flange that is almost

invisible against the ceiling. 1.75" round aperture includes professional baffle.

patented design. Accepts up to 2 effects devices, depending on lamp.


Wet Location

DL6Zp

Round Fixed Wet Location

DL9Zp

1.75"

44mm

4.38" 111mm

1.75"

44mm

4.38" 111mm

3.33"

85mm


3.13"

80mm

LAMPS



Listed for wet location.






Round, wallwash downlight with an internal kick reflector with sealed frosted lens

for uniform, glare-free wallwashing, and a .15" slight return, stainless steel flange

with integral silicone gasket. 1.75" round aperture includes professional baffle.

patented design. Accepts up to 2 effects devices, depending on lamp.


LAMPS





Round, fixed downlight with deeply regressed lamp, sealed frosted lens, and a

.15" slight return, stainless steel flange with integral silicone gasket. 1.75" round

aperture includes professional baffle. Optional clear sealed glass lens is also

available. Accepts up to 3 effects devices, depending on lamp.



specific product page.



DL11Z DL21Z

Round Fixed

DL11Z




1.75"

44mm

3.95" 100mm

1.75"

44mm

3.95" 100mm

2.30"

58mm

DL15Z DL21Zcp

Round Fixed Regressed Baffle

DL15Z

ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaT11Z

2.81"

71mm




LAMPS






Round, fixed downlight with .055" thick flange that is almost invisible against the

ceiling. Optional zero-sightline appliqué can be installed flush with the ceiling.

1.75" round, die-cast aperture lens holder allows for shallow lamp recess. May be

re-lamped from room side without removing trim from housing. Accepts up to 2

effects devices, depending on lamp.


LAMPS






Round, fixed downlight with .055" thick flange that is almost invisible against the

ceiling. Optional zero-sightline appliqué can be installed flush with the ceiling.

1.75" round aperture, deeply regressed black lens holder baffle is vertically

grooved for minimal glare. May be re-lamped from room side without removing

trim from housing. Accepts up to 2 effects devices, depending on lamp.

Round adjustable Naiad

Wet Location

DL21Z

Round adjustable Polymer Naiad

Wet Location

DL21Zcp

1.88"

48mm

4.38" 111mm

1.83"

46mm

4.34" 110mm

3.13"

80mm


3.13"

80mm

.25" 6mm

LAMPS



20w halogen flood bAb lamp for use in

showers and baths. 50w halogen lamp

best suited for porches and soffits outdoors.

Fixture rated for 50w max halogen lamp.

Listed for wet locations.


Round, adjustable downlight with integral silicone gasket with 45º of manual tilt

that can be locked in any position from above, and a .15" return, stainless steel

flange. standard frosted glass lens is sealed over the 1.88" round trim aperture

and listed for wet locations. Optional sealed clear glass lens is also available.

ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaT21ZCP


20w MR-16 Flood bAb 35º

LAMPS











Round, adjustable downlight with 45º of manual tilt that can be locked in any

position from above, and a .25" thick, composite, polymer flange with integral

silicone gasket. Frosted glass lens sealed over 1.83" round trim aperture is listed

for wet locations and includes professional baffle. Optional sealed clear glass

lens is also available.






DL23Z DL31Zp

Suspended Glass Star

DL23Z




1.25"

32mm

3.50" 89mm

5.88" 149mm

1.65"

42mm

4.25" 108mm

2.75"

70mm

DL24Z DL32DGZp

Square adjustable Naiad

Wet Location

DL24Z


3.13"

80mm




LAMPS



colored glass lens options:

blue DGL-B

Green DGL-G

pink DGL-P

Red DGL-R

Yellow DGL-Y


Round, fixed downlight with suspended, frosted, glass star with 1.25" round,

clear aperture retained with chrome stem buttons, and a .055" thick, chrome

trim flange. Optional lenses create colored, filtered light. Accepts up to 2



LAMPS











square, adjustable downlight with square .15" return, stainless steel flange with

integral silicone foam gasket, and 45º of manual tilt that can be locked in any

position from above. Frosted, glass lens sealed over 1.65" square trim aperture,

listed for wet locations. Optional sealed, clear glass lens is also available.

Square Fixed

DL31Zp

Square adjustable Gear-Driven

DL32DGZp

1.97"

50mm

4.00" 102mm

1.82"

46mm

4.00" 102mm

3.42"

87mm


4.00"

102mm

LAMPS






square, fixed downlight with square .055" thick trim flange that is almost

invisible against ceiling. Optional zero-sightline appliqué can be installed

flush with the ceiling. Includes square, deeply recessed, professional baffle.


ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaT32DGZP

LAMPS






square, hot aim, adjustable downlight with deeply regressed lamp, two axis,

self-locking, 357° rotation, up to 45° of tilt in ceilings up to 5/8" thick, up to 15°

of tilt in ceilings up to 1" thick, and square .055" thick trim flange that is almost

invisible against the ceiling. Optional zero-sightline appliqué can be installed

flush with the ceiling. 1.82" square aperture includes professional baffle.

Accepts up to 3 effects devices, depending on lamp. patent pending.






DL35Zp DL38Zp

Square Wallwash mirage ®

DL35Zp




1.97"

50mm

4.00" 102mm

1.97"

50mm

4.25" 108mm

3.42"

87mm

DL36Zp DL39Zp

Square Wallwash mirage ®

Wet Location

DL36Zp


3.42"

87mm




LAMPS






square, wallwash downlight with internal kick reflector with integral frosted

lens for uniform, glare-free wall washing, and square .055" thick trim flange

that is almost invisible against the ceiling. Optional zero-sightline appliqué can

be installed flush with the ceiling. 1.97" square aperture includes professional

baffle. Accepts up to 2 effects devices, depending on lamp.






LAMPS









square, wallwashing downlight with internal kick reflector with sealed frosted

lens for uniform, glare-free wall washing in wet locations, and square .15"

return, stainless steel flange with integral silicone gasket. 1.97" square aperture

includes professional baffle. Accepts up to 2 effects devices, depending on

lamp.

Square adjustable Dual-axis

DL38Zp

Square Fixed Wet Location

DL39Zp

1.82"

46mm

4.00" 102mm

1.97"

50mm

4.25" 108mm

3.48"

88mm


3.42"

87mm

LAMPS






square, adjustable downlight with deeply regressed lamp, 357° of rotation that

can be locked in any position from above, up to 45° of manual tilt in ceilings up

to 1" thick that can be locked in any position from the room side, and .055" thick

trim flange that is almost invisible against the ceiling. Optional zero-sightline

appliqué can be installed flush with the ceiling. 1.82" square aperture includes

professional baffle. Accepts up to 3 effects devices, depending on lamp.


LAMPS




showers and baths. 50w halogen lamp best

suited for porches and soffits outdoors.






square, fixed downlight with frosted glass lens and square .15" return, stainless

steel flange with integral silicone gasket. Optional sealed, clear, glass lens also

available. 1.97" square aperture includes professional baffle. Accepts up to 3







DL61Zp DL66Zp

Round Fixed Wide-aperture

DL61Zp




2.38"

60mm

3.95" 100mm

2.38"

60mm

3.95" 100mm

2.75"

70mm

DL65Zp DL69Zp

Round Wallwash Wide-aperture

DL65Zp


2.40"

61mm




LAMPS






Round, fixed downlight with die-cast, wide aperture interior baffle, deeply

regressed lamp, and .055" thick trim flange that is almost invisible against

the ceiling. Optional zero-sightline appliqué can be installed flush with the

ceiling. 2.38" round aperture includes professional baffle. Accepts up to 3



LAMPS









32"-36" setback, 36"-40" on center

Round, fixed wallwash downlight with angled, die-cast, wide aperture, interior

baffle, deeply regressed lamp, linear spread and frosted lenses. Features a

.055" thick trim flange that is almost invisible against the ceiling. Optional zerosightline

appliqué can be installed flush with the ceiling. 2.38" round aperture


lamp. patent pending.

Round Wallwash Wide-aperture

Wet Location

DL66Zp

Round Fixed Wide-aperture

Wet Location

DL69Zp

2.38"

60mm

4.38" 111mm

2.38"

60mm

4.38" 111mm

2.40"

61mm


2.75"

70mm

LAMPS





Round, fixed wallwash downlight with angled, die-cast, wide aperture, interior baffle,

sealed, linear spread and frosted glass lenses, and .15" return, stainless steel

flange with integral silicone gasket. 2.38" round aperture includes professional

baffle listed for wet locations. Accepts up to 2 effects devices, depending on lamp.

patent pending.





32"-36" setback, 36"-40" on center

LAMPS











Round, fixed downlight with die-cast, wide aperture, interior baffle, deeply

regressed lamp, sealed, frosted, glass lens, and .15" return, stainless steel

flange with integral silicone gasket. 2.38" round aperture includes professional

baffle listed for wet locations. Optional sealed, clear, glass lens also

available. Accepts up to 3 effects devices, depending on lamp.





Z SERIES AccessORIes 29

DL72Z

LAMPS

DLA-App-Z-RD-3 DLA-APP-Z-RD-3

DLA-App-Z-sQ-5 DLA-APP-Z-SQ-5

eDLA-App-Z-sQ-3

DLA-App-Z


EDLA-APP-Z-SQ-3

eDLA-App-Z

Gyro Tm

Dual-axis adjustable

DL72Z

1.35"

34mm

1.47"

37mm

3.95" 100mm

2.25"

57mm

.75" 19mm

Dh-NIc-sM2

LAMPS

eDL-ZF

eDL-ZO

eDL-XF

eDL

18.38" 467mm

hAL, LeD

EDL-ZF

EDL-ZO

EDL-ZF

Gemini Square modular

Dh-NIc-sM2





10.20"

259mm

17.20" 436mm

4.20"

107mm

9.20" 234mm

7.60"

193mm

5.13"

130mm








exposed, adjustable downlight with interlocking, circular, machined, aluminum

planes that can be manually adjusted in two axes and locked in position with an

allen-head wrench. May be configured with snoot towards roomside for glare

control or reversed allowing for wide light distribution. .055" thick trim face can

be installed with flange overlaying the ceiling plane or as zero-sightline with

optional appliqué. Accepts up to 3 effects devices, depending on lamp. patented

design.

ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaTNIC-Sm2


For zero-sightline applications only.

compatible trims: DL25Z Adjustable, DL31Zp

Fixed, DL35Zp wallwasher, DL38Zp Adjustable

All trims can be interchanged and are ideal

for retail applications where displays are being

changed and the lighting requirements must

adapt. consult factory as to availability of

custom finished trim divider.


Modular fixture, with two adjacent apertures for square trims, that will accept

any combination of DL25Z, DL31Zp, DL35Zp, and DL38Zp trims. housing

features integral, low voltage, electronic transformers that may be individually

circuited. Includes DLA-App-sM2 appliqué kit.

.74"

19mm

Ø 3.36"

85mm

8.00" 203mm

3.60" 91mm

Zero-Sightline appliqué Round

DLA-App-Z-RD

3.46" 88mm

3.62" 92mm

.070" 2mm

.77" 20mm

International Collar (Flange Overlay)

eDL-ZF

.74"

19mm

Ø 3.36"

85mm

6.50" 165mm

3.60" 91mm

Zero-Sightline appliqué Square

DLA-App-Z-sQ

Round and square appliqués are accessories that should be specified when a

downlight fixture is going to be installed flush to the ceiling for a zero-sightline.

Models DLa-aPP-Z-RD-3 and DLa-aPP-Z-SQ-3 are recommended for all

applications as they provide maximum structural reinforcement.

Models DLa-aPP-Z-RD-5 and DLa-aPP-Z-SQ-5 have a thinner profile and are

recommended for installations where the contractor prefers a thinner profile to

apply mudding. All models include a removable plaster plug that ensures flush

trim fit after mudding.

For Z series round or square, standard

flange overlay applications.

3.46" 88mm

.018" .5mm

3.82" 97mm .77" 20mm

International Collar (Zero-Sightline)

eDL-ZO

For Z series round, non-gear-driven,

zero-sightline applications.

International series downlight trims may

be installed without housings; a collar is

used instead to provide secure retention in

drywall and plaster ceilings

4.09”

104mm

.74"

19mm

Ø 3.36"

85mm

4.90" 124mm

8.00" 203mm

International Collar (Zero-Sightline)

eDLA-App-Z

4.33" 110mm

4.65" 118mm

.018" .5mm

For international gear-driven, zero-sightline

applications and other applications that

require a fine finish out. specify EDLa-aPP-

Z-RD for round trims and EDLa-aPP-Z-SQ

for square trims.

.77" 20mm

International Collar (Flange Overlay)

eDL-XF

For X series round or square, standard flange

overlay applications.

export trims are offered only in Z series and

the model number prefix changes to eDL.

For more information, please consult the

Lucifer Lighting website or export catalog.

30 31

HUNTINGTON LIBRaRY

San Marino, CA

With so many decorative objects, colors, and

textures, lighting must enhance the space

and integrate with the chandelier, without

distracting from the historic feeling in the

room or calling attention to itself. UV lenses

are used to protect the artwork and other

precious objects.

Lighting: Horton Lees Brogden Lighting Design

Fixture: DL2RZP (p 18)

32 x SERIES DOwNLIGhts 33

x SERIES

OVERVIEW

X Series fixtures feature small apertures and larger

trim diameters of about 5", which makes them

especially appropriate for remodel applications where

a larger trim may be required to access the housing

compartment components. Fixtures are listed for dry,

damp, and wet locations.

X series trims can be used in accessible and nonaccessible

ceilings and most are compatible with the

following MR-16 style light sources: 10w to 75w low

voltage halogen, 20w and 39w HID ceramic metal

halide, 5w LED, and CCFL lamps.

FINISHES aND aCCESSORIES

Standard X Series finishes are white and black with

a matte granulated powdercoat, industrial gray with a

glass bead blasted stainless steel finish, and polished

chrome. Select trims, including those for wet locations,

are available in brushed stainless steel. Custom finishes

are also available.

Most X Series fixtures come with a frosted lens and

accept up to three lenses or filters (depending on lamp)

to tune light and control glare.

PRIVaTE RESIDENCE

Palm Beach, FL

Diffuse light enhances an outdoor setting

at night. Fixtures are machined out of

special corrosion-resistant polymer with

reinforced stainless steel and include

sealed frosted lenses to last in harsh,

marine environments.

Lighting: I.D. Illumination Design

Fixture: DL21xCP (p 39)

34 x SERIES DOwNLIGhts

x SERIES DOwNLIGhts 35

DL1XM DL4XM

Round Fixed

DL1XM




1.88"

48mm

4.92" 125mm

1.88"

48mm

4.92" 125mm

3.13"

80mm

DL2RXM DL5XMp

Round adjustable

DL2RXM

ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaT1xm

3.13"

80mm

products with MM suffix feature larger diameter

trims to conceal miscut ceiling openings.

LAMPS



specify DL1xmm for a fixture with a 5.28" trim

plate, .055" thickness, and no return.

specify DL1x for a fixture with a 5.28" trim plate

and .15" thick return.


Round, fixed downlight with deeply regressed lamp, and a sheer, .055" thick

trim flange that is almost invisible against the ceiling. 1.88" round aperture.


ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaT2Rxm

LAMPS



specify DL2Rxmm for a fixture with a 5.28" trim


specify DL2Rx for a fixture with a 5.28" trim

plate and .15" thick return.


Round, adjustable downlight with deeply regressed lamp, up to 45º of tilt that

can be locked in any position from the room side, and a sheer, .055" thick trim

flange that is almost invisible against the ceiling. 1.88" round aperture. Accepts

up to 3 effects devices, depending on lamp.

Round Fixed Deep Cone

DL4XM


DL5XMp

2.84"

72mm

4.92" 125mm

1.75"

44mm

4.92" 125mm

4.10"

104mm


3.33"

85mm

LAMPS

hAL, hID




specify DL4x for a fixture with a 5.28" trim plate



RECOMMENDED BEAM SPREAD

MR-16 Medium Flood 30"

Round, fixed downlight with deeply regressed lamp, a sheer, .055" thick trim

flange that is almost invisible against the ceiling, a rolled-edge baffle to

eliminate aperture glare, and an aluminum reflector with a 2.84" aperture that

provides wide distribution and a 50º cut-off angle. standard reflector is clear

stippled (sR); reflectors are also available in specular clear (cR – shown in

photo), specular black (bR) and champagne (ch).

ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaT5xmP

LAMPS



specify DL5xmmP for a fixture with a 5.28" trim


specify DL5xP for a fixture with a 5.28" trim plate







Round, wallwash downlight with an internal kick reflector with integral

frosted lens for uniform, glare-free wallwashing and a sheer, .055" thick

trim flange that is almost invisible against the ceiling. 1.75" round aperture


lamp. patented design.






DL11XM DL13XM

Round Fixed

DL11XM

1.75"

44mm

4.92" 125mm

1.75"

44mm

2.62"

67mm

5.28" 134mm

2.30"

58mm

DL12X DL15XM

Square adjustable

DL12X





2.81"

71mm



LAMPS



specify DL11x for a fixture with a 5.28" trim



Round, fixed downlight with a sheer, .055" thick trim flange that is almost

invisible against the ceiling. 1.75" round, die-cast aperture lens holder provides

shallow lamp recess. can be relamped from room side without removing trim

from housing. Accepts up to 2 effects devices, depending on lamp.

ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaT12x

LAMPS




square, adjustable downlight with a square, .15" return flange and 30º of tilt.

1.75" round, die-cast aperture lens holder provides shallow lamp recess.

can be relamped from room side without removing trim from housing. Accepts

up to 2 effects devices, depending on lamp.

Round adjustable Topper

DL13XM

Round Fixed with Baffle

DL15XM

1.75"

44mm

4.92" 125mm

1.75"

44mm

4.92" 125mm

3.25"

83mm

3.20"

81mm


2.81"

71mm

LAMPS

hAL, LeD





Round, adjustable downlight with a sheer, .055" thick trim flange that is almost

invisible against the ceiling, and up to 70º of positively indexed tilt. 1.75" round,

die-cast aperture lens holder provides shallow lamp recess. can be relamped

from room side without removing trim from housing. Accepts up to 2 effects

devices, depending on lamp. Limited to low-voltage halogen or LeD lamps.


LAMPS






Round, fixed downlight with a sheer, .055" thick trim flange that is almost

invisible against the ceiling. 1.75" round aperture, deeply regressed lens holder

is vertically grooved for minimal glare. can be relamped from room side without

removing trim from housing. Accepts up to 2 effects devices, depending on

lamp.






DL18XM DL21Xcp

Round Fixed Luna

DL18XM




2.44" 62mm

4.92" 125mm

1.88"

48mm

5.28" 134mm

3.68"

94mm

4.37"

111mm

DL21X DL41XM

Round adjustable Naiad

Wet Location

DL21X


3.13"

80mm



LAMPS


Decorative, round, fixed downlight with a sheer, .055" chrome trim flange and

deeply regressed lamp. An aluminum, stippled reflector supports an etched glass

disk with a 2.44" diameter center aperture and chrome stem buttons. Accepts up

to 2 effects devices, depending on lamp.

ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaT21x



LAMPS











Round, adjustable downlight with a .15" return, stainless steel flange with

integral silicone gasket, and 45º of tilt that can be locked in any position from

above. A frosted glass lens is sealed over the 1.88" round trim aperture and

listed for wet locations. Optional sealed, clear, glass lens is also available.

Round adjustable Polymer

Naiad Wet Location

DL21Xcp

Round Deep Cone Basso

DL41XM

1.83"

46mm

5.45" 139mm

2.84"

72mm

4.93" 125mm

7.75"

197mm

3.13"

80mm

ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaT21xCP

LAMPS











Round, adjustable downlight with a .25", tapered, composite, polymer flange

with integral silicone gasket and 45º of tilt that can be locked in any position

from above. Includes professional baffle with frosted glass lens sealed over the

1.83" round trim aperture and listed for wet locations. Optional sealed, clear,

glass lens is also available.


LAMPS

hAL, hID







Round, fixed, par 20-style downlight with deeply regressed lamp, a .055" thick

trim flange that is almost invisible against the ceiling. An aluminum reflector

with a 2.84" aperture provides an exceptionally high cut-off angle. Includes a

rolled-edge baffle to eliminate aperture glare. standard reflector is stippled

(sR); reflectors are also available in specular clear (cR – shown in photo),

specular black (bR) and champagne (ch). Accepts up to 3 effects devices.






DL42XM DL51XM

DL43XM

Round 25º adjustable Deep

Cone Basso

DL42XM

Round 45º adjustable Deep

Cone Basso

DL43XM




2.84"

72mm

4.93" 125mm

2.84"

72mm

4.93" 125mm

0° to 25°

0° to 45°

7.75"

197mm


7.75"

197mm



LAMPS

hAL, hID







Round, adjustable, par 20-style downlight with deeply regressed lamp, a .055" thick

trim flange that is almost invisible against the ceiling, and 0º-25º of tilt that can be

locked in any position from the room side. 2.84" round aperture. Includes a rollededge

baffle to eliminate aperture glare. standard reflector is stippled (sR); reflectors

are also available in specular clear (cR – shown in photo), specular black (bR)

and champagne (ch). Accepts up to 3 effects devices.


LAMPS

hAL, hID







Round, adjustable, par 20-style downlight with deeply regressed lamp, a .055"

thick trim flange that is almost invisible against the ceiling, and 0º-45º of tilt that

can be locked in any position from the room side. 2.84" round aperture. Includes a

rolled-edge baffle to eliminate aperture glare. standard reflector is stippled (sR);

reflectors are also available in specular clear (cR – shown in photo), specular

black (bR) and champagne (ch). Accepts up to 3 effects devices.

Round Fixed Deep Cone CFL

DL51XM

3.70"

89mm

4.93" 125mm

7"

178mm


LAMPS

cFL 18w







EFFICIENCY NOTES

47% fixture efficiency with specular

clear Reflector.

Round, fixed, cFL-style downlight with deeply regressed lamp, a .055" thick

trim flange that is almost invisible against the ceiling. An aluminum reflector

with a 3.70" aperture provides an exceptionally high cut-off angle of 50º,

eliminating glare. Includes a rolled-edge baffle to eliminate aperture glare.

Reflectors available in stippled (sR), specular clear (cR – shown in photo),

specular black (bR) and champagne (ch).




42 SPECIaLTY DOwNLIGhts 43

SPECIaLTY

FIxTURES

OVERVIEW

Lucifer Lighting makes a variety of trims for

specialty applications. Visibly striking shapes,

contours, and materials are designed to bring

added glamour to the interior space. For making

a bold statement, consider the unique detailing

on these trims, including machined aluminum,

powder coated black gimbals, or a translucent

lens and skirt. The following trims require

specialty housings.

WILSON CORPORaTE HEaDQUaRTERS

Chicago, IL

Adjustable fixtures contribute to the architectural

statement by mimicking design

elements like graphics and furniture; the

light highlights interior decorating pieces,

no matter how they’re positioned.

Interiors: Gensler

Fixtures: DLJ2 (p 44)

44 SPECIaLTY DOwNLIGhts

SPECIaLTY DOwNLIGhts 45

DLJ1 Dh-NIc-LD

Java 1

DLJ1

1.75" 44mm

1.75" 44mm

6.25" 159mm

10.13" 257mm

6.25"

159mm

DLJ2 Dh-NIc-AK

Java 2

DLJ2




ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaTJ1

6.25"

159mm

LAMPS

hAL, LeD



Adjustable downlight frame encloses a 15/16" deep, black recess that contains

a black, spherical lamp holder with a black, regressed baffle. Lamp holder is

fully rotatable and tilts 25º in all directions; lamp retainer swivels and can be

relamped from the room without removing the trim from housing. Accepts up

to 2 effects, depending on lamp.

ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaTJ2

LAMPS

hAL, LeD



Dual, adjustable downlight frame enclosing a 15/16" deep, black recess that

contains two black, spherical lamp holders with black, regressed baffles.

Lamp holders are fully rotatable and tilt 25º in all directions; lamp retainers

swivel and can be relamped from the room without removing the trim from

housing. Accepts up to 2 effects devices, depending on lamp.

Lucid Tm

Dh-NIc-LD

Twin Rectangle

Dh-NIc-AK

Dh-NIc-AKL

4.5"

114mm

2.95"

75mm

11.50" 292mm

9.50" 241mm

14.10" 358mm

4.86"

124mm

1.8"

46mm

9.10"

231mm

8.25"

210mm

5.13"

130mm

10"

254mm

1.5" 38mm

1.00"

25mm

ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaTNIC-LD

5.75"

146mm

3"

76mm

LAMPS

hAL (37w Max), LeD, hID (consult factory)



Recommended for use with 37w IR lamp.


combination downlight and housing functions as an adjustable downlight.

Zero-sightline, translucent lens glows when lamp is illuminated and conceals

housing interior from view. For use in non-Ic accessible and non-accessible

ceilings. Adjustable appliqué system accommodates ceilings up to 1" thick.


ONLINe QuIcK pRODuct pAGe ReFeReNce: DLCaTNIC-aK

LAMPS

hAL (50w Max), LeD



DH-NIC-aK No perimeter border or lens

DH-NIC-aKS translucent perimeter border

DH-NIC-aKB bronze perimeter border

DH-NIC-aKL translucent perimeter border and

translucent lens

DH-NIC-aKBL bronze perimeter border and

translucent lens


combination downlight with housing and translucent perimeter border below

ceiling line; perimeter border also available in bronze finish. comes with twin,

integral, Mach-style lamp holders for adjustments in two axes: 45º of tilt in length

and 30º in width. For use in non-Ic accessible and non-accessible ceilings up to

1" thick. Available with optional translucent lens to conceal lampholders.





46 HOUSINGS 47

HOUSINGS

OVERVIEW

Housings are the metal compartments that contain

wiring, thermal sensors, and power supplies. These

components are framed in above the ceiling and

their use is a product safety requirement mandated

by the National Electric Code.

SPECIFYING a HOUSING

To correctly specify the appropriate housing, the

following factors must be considered:

Is this new construction or a remodel?

If the project is new, interior construction and/or

enclosed exteriors, is the insulation non-IC (at a 3"

setback) or IC (insulation contacting housing). Note:

NIC stands for non-insulated ceiling; IC stands for

insulated ceiling.

If the project is a remodel, the housing will be

installed in the existing ceiling through a new cutout

in the existing ceiling panel.

Is a specialty fixture specified?

If so, please refer to the specialty housing section.

What is the power supply?

While some lamps utilize mains voltage power

directly from the building service, most HAL, HID,

and CFL fixtures utilize a transformer or ballast to

power the light source. Lucifer Lighting offers

magnetic and electronic low voltage power supplies,

but suggests using electronic wherever possible

as they are energy efficient, quiet, lightweight,

easily accessible, and in most cases do not require

an interface with control systems.

Once these determinations have been made, refer

to pages 48-52 to select the correct housing for any

Lucifer Lighting downlight.

maRION OLIVER mCCaW HaLL

Seattle, WA

A large, decorative, glass chandelier

retains its position at center stage, even

as a series of downlights illuminate the

wall planes with warmer light. The linear

layout of downlights complements the

strong verticality of the architecture.

Architecture: LMN Architects

Interiors: Deborah Sussman

Lighting: Horton Lees Brogden Lighting Design

Fixture: DL5xmP (p 35)

48 HOUSINGS

HOUSINGS 49

CHOOSING THE

RIGHT HOUSING

Housings from Lucifer Lighting come in a variety

of ratings and fall into one of three categories:

Universal modular housings

for standard new construction.

Specialty housings and trims.

Housings for remodel applications.




Housings are distinguished by their accessibility,

small scale, superb heat management, and power

supply compatibilities.

Housings are rated for a range of applications

requiring IC, ASTM E283 Airtight, and Chicago

Plenum rated housings, as well as for installations

that do not require special ratings.

NIC

IC

CP

AT

Not rated for contact with insulation material.

Rated for contact with insulation material.

CCEA-Chicago Plenum rated.

Rated ASTM E283 Airtight.

UNIVERSaL HOUSINGS

FOR STaNDaRD NEW CONSTRUCTION

NIC IC

UNIVERSaL NIC HOUSINGS UNIVERSaL IC HOUSINGS

Recessed housing for use with recessed downlight trims

in non-Ic accessible and non-accessible ceilings up to 1"

thick. Maximum 75w MR-16, 39w hID, or 18w cFL lamp

usage. housing is fabricated to accept downlight trims

with minimal trim flange overlay over ceiling line. (Note:

Zero-sightline option available. Order appliqué separately.)

transformer compartment and all splice connections may

be serviced from room side. hID, cFL and par 20 lamp

versions come with extended top. the low profile housing is

the hAL version for use with MR-16 halogen lamp. hangar

bars are included with all versions and can be fitted to all

sides of the housing allowing installation in spaces as

narrow as 9".

1

2

3

3 2

3.7" 94mm (HAL)

5.04" 128mm (HID)

7" 177mm (CFL / Par 20)

1

6.3" 160mm

(Aperture Centerline)

12"

305mm

3.25"

83mm

6.3"

160mm

6.8"

172mm

SPECIFYING UNIVERSaL HOUSINGS

7"

177mm

CP

AT

10.9"

276mm

To find a spec sheet for universal modular housings for standard new construction,

create the appropriate model by following the logic outlined in the chart below.

Complete spec sheets are available online at luciferlighting.com.

DH IC IC, Airtight, xF X Series

CCEA

Flange Overlay

NIC Non-IC ZF Z Series

Flange Overlay

ZO Z Series

Zero-Sightline

Recessed housing for use with recessed downlight trims

in Ic accessible and non-accessible ceilings up to 1" thick.

Maximum 50w MR-16, 39w hID, or 18w cFL lamp usage.

housing is fabricated to accept downlight trims with minimal

trim flange overlay over ceiling line. (Note: Zero-sightline

option available. Order appliqué separately.) transformer

compartment and all splice connections may be serviced

from room side. the Ic housing is certified chicago plenum

and AstM e283 Airtight. hangar bars are included.

16.3"

413mm

7.2" 185mm

(Aperture Centerline)

HOUSING RaTING

SERIES

LIGHT SOURCE max WaTTS POWER SUPPLY (PRIMARY)

HaL Halogen Low Voltage

P20HaL Par 20 Halogen

mV Halogen Mains / Line Voltage

HID Metal Halide

P20HID Par 20 Metal Halide

LED Light Emitting Diode

CCFL Cold Cathode Fluorescent

CFL Compact Fluorescent

75 (NIC only)

50 (IC only)

75 (NIC), 50 (IC)

39

20

5

10

18

ExamPLE: DH-IC-ZO-HID-20-120E

120E 120v Electronic


120T 120v Torroidal (50w only)

120m 120v Magnetic

277m 277v Magnetic

REm Remote

120 120v Mains Voltage



REm Remote



UNI Universal

50 HOUSINGS

HOUSINGS 51

SPECIaLTY HOUSINGS

NIC

NIC

CP NIC CP

DH-NIC-JVC1

chicago plenum rated recessed housing for use in accessible

and non-accessible, non-insulated ceilings up to 1" thick,

complete with integral electronic transformer. Is also available

with magnetic 120v and 277v transformer. can be ordered for

use with remote transformer. transformer and all electrical

components serviceable from below. steel hanging bars and

brackets are also included.

DH-NIC-aK

6.50"

165mm

11.50" 292mm

9.50" 241mm

5.38"

137mm square

7.50"

191mm

5.13"

130mm

1.00"

25mm

combination downlight and housing with available translucent

perimeter border below ceiling line (also available in bronze

finish). housing comes with twin, integral Mach style lamp

holders for adjustments in two axes. Lampholders tilt 45° in

length axis and 30° in width axis. For use in non-Ic accessible

and non-accessible ceilings up to 1" thick. housing fabricated

to provide zero-sightline on ceiling plane and is available with

an optional translucent lens to conceal lampholders. patent

pending. See page 45 for border style and lens specifications.

2.95"

75mm

14.10" 358mm

4.86"

124mm

9.10"

231mm

10"

254mm

1.5" 38mm




5.75"

146mm

3"

76mm

DH-NIC-JVC2

chicago plenum rated recessed housing for use in accessible

and non-accessible, non-insulated ceilings up to 1" thick,

complete with twin integral electronic transformers. can be

ordered for use with remote transformer. transformers and

all electrical components serviceable from below. steel hanging

bars and brackets are also included.

NIC

7.50"

191mm

DH-NIC-LD

4.5"

114mm

18.38" 467mm

16.38" 416mm

11.50” 292mm

9.00"

229mm

9.50” 241mm

1.8"

46mm

5.38"

137mm

8.25”

210mm

6.50"

165mm

5.13”

130mm

5.13"

130mm

1.00”

25mm

1.00"

25mm

combination downlight and housing suitable as an

adjustable downlight. Fixture is only offered with a zero-sightline

translucent lens which glows when illuminated and which

conceals housing interior view. For use in non-Ic accessible

and non-accessible ceilings. housing is fabricated to provide

for zero-sightline only and is supplied with adjustable appliqué

system to accommodate ceilings up to 1" thick. It incorporates

a reinforcing zinc plated steel screen for applying joint compound

when used in a drywall or plaster ceiling. steel hanging

bars and brackets are also included. patent pending.

SPECIaLTY / REmODEL HOUSINGS

NIC CP

NIC

DH-NIC-Sm2 DH-NIC-TZ (LINEa)

Recessed housing for use in accessible and non-accessible,

non-Ic ceilings up to 1" thick, complete with twin integral

electronic transformers. can be ordered for use with remote

transformer. this housing accepts a combination of two square

trims which can be fixed (DL31Zp), adjustable (DL25Z or

DL38Zp) or wallwash (DL35Zp). All trims can be interchanged

and are ideal for retail applications where displays are being

changed and the lighting requirements must adapt. housing

is only offered in zero-sightline and is supplied with Model

DLA-App-sM2 appliqué kit. It incorporates a reinforcing zinc

plated steel screen for applying joint compound when used

in a drywall or plaster ceiling. transformers and all electrical

components serviceable from below. steel hanging bars and

brackets are also included.

For use with hAL and LeD only.

NIC

10.20"

259mm

18.38" 467mm

17.20" 436mm

9.20" 234mm

DH-NIC-Rm (REmODEL HOUSING)

4.20"

107mm

7.60"

193mm

5.13"

130mm

Recessed housing for use in existing, non-insulated construction,

complete with integral transformer. For use with X series

trims. can be ordered for use with remote transformer. splice

compartment and transformer assembly include adjustable leg

for support and balancing in ceiling. supplied with retractable

mounting clips to accommodate ceiling thickness of 1/2" to 1

1/4". splice compartment front is removable for easy access and

is mechanically secured by spring clips. splice compartment is

provided with five 5/8" knockouts.

For use with hAL only.

Recessed housing(s) for use in accessible and non-accessible

ceilings up to 1" thick with remote magnetic or electronic

transformer(s), or integral electronic transformer(s).

housings stand alone without framing accessory, or can

be positioned serially in optional accessory frame, which

makes them ideal for display applications. Round contoured

housing without accessory frame accommodates diverse

ceiling framing conditions. Framing construction ensures

consistently aligned on-center spacing of fixtures; trims

are interchangeable and can be circuited independently.

For use with 37w IRc halogen lamp. will accept any of the Z

series trims for zero-sightline or flange overlay applications.

transformer(s) and splice compartment(s) are serviceable

from below. steel hanging bars and brackets are included.

DH-NIC-TZO-1* For zero-sightline**, single unit

DH-NIC-TZF-1* For Flange Overlay, single unit

*Specify 1 for single unit, 2 for dual units,

or 3 for triple units

1

2

3

3.47"

88mm

12.5" 318mm (dual)

4.68"

119mm

5"

127mm

6.25" 159mm (single)

18.75" 476mm (triple)

6"

152mm

11.28" 287mm

2

4.50"

114mm

Inside Dia.

4.50"

114mm

Lip Dia.

3

6" 152mm

5.97"

152mm

1

Ø 3.36" 85mm

** For zero-sightline applications, specify appliqué DLA-App-Z-RD-t

for round trims, or appliqué DLA-App-Z-sQ-t for square trims.

52 HOUSINGS QuIcK ReFeReNce pRODuct cOMpAtIbILItY tAbLe

53

TRIM

Z SERIES

x-SERIES

JaVa SERIES

DL1ZP

DL2DGZP

DL2RZP

DL5ZP

DL6ZP

DL9ZP

DL11Z

DL15Z

DL21Z

DL21ZCP

DL23Z

DL24Z

DL25Z

DL31ZP

DL32DGZP

DL35ZP

DL36ZP

DL38ZP

DL39ZP

DL61ZP

DL65ZP

DL66ZP

DL69ZP

DL72Z

DL1XM

DL2RXM

DL4XM

DL5XMP

DL11XM

DL12X

DL13XM

DL15XM

DL18XM

DL21X

DL21XCP

DL41XM

DL42XM

DL43XM

DL51XM

DLJ1

DLJ2

HOUSING

DH-IC-ZO

DH-NIC-ZO

DH-IC-ZF

DH-NIC-ZF

DH-IC-XF

DH-NIC-XF

DH-NIC-RM

DH-NIC-JVC1

DH-NIC-JVC2

DH-NIC-SM2

DH-NIC-TZO

DH-NIC-TZF

LIGHT SOURCE

HALOGEN

HID

CFL

CCFL

LED

SEYFaRTH SHaW

Chicago, IL

A mixture of fixtures and mounting

techniques creates a variety of effects

that help define different seating areas and

accent the architecture. This is an AIA Gold

Award winning project.

Interiors: Gensler

Lighting: Mitchell B. Kohn Lighting Design

Fixtures: DL15xm (p 37), DLJ1 (p 44)

54 LAMp OptIONs 55

WaGamama RESTaURaNT

Boston, MA

The airy effect of the floating, overhead

panels is enhanced with deep cone downlights

that provide wide, uniform coverage

and compliment the chrome accents, from

trims, to mirrors and structural materials.

Crisp light, evenly diffused ensures food

appears fresh.

Lighting and Interiors: Gensler

Fixture: DL4x (p 35)

LIGHT SOURCE

WATTAGE

BEAM

SPREAD

COLOR

TEMP

LUCIFER

LIGHTING

PART NO.

mR-16 HaLOGEN 20W 10º 2900º 12-20-HL-SP

24º 2900º 12-20-HL-MF

40º 2900º 12-20-HL-FL

50W 15º 3050º 12-50-HR-SP

30º 3050º 12-50-HR-MF

40º 3050º 12-50-HR-FL

mR-16 IR HaLOGEN 37W 10º 3000º 12-37-HRIR-SP

25º 3000º 12-37-HRIR-MF

35º 3000º 12-37-HRIR-FL

60º 3000º 12-37-HRIR-WF

50W 10º 3000º 12-50-HRIR-SP

25º 3000º 12-50-HRIR-MF

35º 3000º 12-50-HRIR-FL

60º 3000º 12-50-HRIR-WF

mR-16 CERamIC 20W 12º 3000º 120-20-MH-SP

mETaL HaLIDE

25º 3000º 120-20-MH-MF

40º 3000º 120-20-MH-FL

39W 12º 3000º 120-39-MH-SP

25º 3000º 120-39-MH-MF

40º 3000º 120-39-MH-WF

mR-16 12v 5W 10º 2700º-3100º 12-5-LED-SP

2700ºK LED

25º 2700º-3100º 12-5-LED-MF

PaR 20 HaLOGEN 50W 25º 2900º 120-50-PAR20-FL

PaR 20 CERamIC

mETaL HaLIDE

35W 30º 2900º 120-35-MH-PAR20-FL

COmPaCT

FLUORESCENT

18W — 2700º-4100º 120-18-CF-27

Lucifer Lighting’s downlight fixtures have been

engineered to provide optimal results with the lamps

listed in this chart. All of these lamps can be ordered

directly from Lucifer Lighting and are available preinstalled

in the fixture, saving time and ensuring quality.

We have found that generic lamp sources frequently do

not meet our quality and performance standards.

The HID, CFL, and LED lamps listed in this chart are

energy code-compliant and fulfill ASHRAE standards for

LEED certification.

DISTANCE FROM

SOURCE (FT)

BEAM

DIAMETER (FT)

CENTER FOOT

CANDLES

3 0.4 610

6 0.7 196

9 1 93

12 1.2 54

15 1.6 37

10º BEAM SPREAD

3 1.1 481

6 1.4 229

9 2.1 111

12 2.8 64

15 3.4 42


3 1.1 568

6 1.3 289

9 1.9 150

12 2.4 90

15 3 59


3 1.1 601

6 1.3 322

9 1.8 171

12 2.3 104

15 2.8 68


3 0.7 888

6 1.3 245

9 1.8 114

12 2.3 86

15 2.8 45


3 0.7 1584

6 1.4 396

9 2.1 176

12 2.9 99

15 3.6 63


3 0.5 75

6 1 21

9 1.5 10

12 2 6

15 2.5 4


DISTANCE FROM

SOURCE (FT)

BEAM

DIAMETER (FT)





CENTER FOOT

CANDLES

3 0.7 409

6 1.3 105

9 1.9 48

12 2.5 28

15 3 19

3 1.6 243

6 3.1 68

9 4.6 31

12 6.1 18

15 7.7 11.6

3 1.3 394

6 2.6 122

9 3.8 54

12 5.1 31

15 6.4 20

3 1.4 472

6 2.5 148

9 3.7 69

12 4.9 40

15 6.3 25

3 1.4 318

6 2.7 82

9 3.9 38

12 5.2 22

15 6.3 15

DISTANCE FROM

SOURCE (FT)

BEAM

DIAMETER (FT)

25º BEAM SPREAD 40º BEAM SPREAD

3 1.6 561

6 3.3 140

9 4.9 62

12 6.6 35

15 8.2 22


3 1.2 23

6 2.4 6

9 3.7 3

12 4.9 2

15 6.1 1







CENTER FOOT

CANDLES

3 2 57

6 4 15

9 5.8 7

12 7.8 4

15 9 3

3 2 210

6 4 54

9 6.1 24

12 8.1 14

15 10.2 9

3 1.9 235

6 3.8 61

9 5.8 27

12 7.7 16

15 9.8 10

3 1.9 301

6 3.8 79

9 5.9 35

12 7.9 20

15 9.9 13

3 2.1 166

6 4.2 43

9 6 20

12 8 12

15 10.5 8

3 2.5 307

6 5 77

9 7.5 34

12 10 19

15 12.6 12

Lamp photometric tables are estimated using available manufacturer's bare lamp

data and assume standard reflectances of 80% ceiling, 50% walls and 20% floor.

check our website for detailed photometric reports. consult factory for complete

fixture photometrics.

The halogen IR lamps shown in this chart are also appropriate

for installations where energy codes and ASHRAE

permit low wattage halogen in special applications, such as

retail displays, art galleries, or task areas like receptions,

executive offices, or conference rooms.

Please be aware that HID light sources are not instant-on

or dimmable. We also recommend working with a lighting

consultant when specifying fixtures and lamps. The

International Association of Lighting Designers, IALD.org,

can assist in locating a trained lighting professional.

[ 101609]

DOWNLIGHTS

luciferlighting.com

At Lucifer Lighting, we are keenly aware of our responsibility to create

products that are both environmentally-friendly and high-quality. We have

a comprehensive environmental action plan in place that ensures our

products are manufactured in the most sustainable way possible. Here are

a few of the steps we have already taken:

Every one of our products can be controlled by occupancy and photo

sensors that reduce energy usage by automatically turning off lights when

they are not required.

Many of our fixtures use alternative, lower energy-consuming light sources

including fluorescent, metal halide, and Light Emitting Diodes (LEDs).

Our products are packaged in post-consumer recycled content.

This brochure was printed with low VOC, vegetable-based ink at Cenveo,

on Centura ® , an FSC-certified, 10% postconsumer recycled fiber paper from

Stora Enso, which has received the highest score on the Dow Jones

Sustainability index for seven consecutive years.

3750 Ih35 North

san Antonio, texas 78219 usA

[ph] +1 210 227 7329

[FAX] +1 210 227 4967

©2009 Lucifer Lighting Company

As part of its policy of continuous research and product

development, the company reserves the right to change

or withdraw specifications without prior notice.

DOWNLIGHTS - Lucifer Lighting

Transform your PDFs into Flipbooks and boost your revenue!

DOWNLIGHTS - Lucifer Lighting

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
