Development and realization of a new

non-invasive method for tear film assessment

using a corneal topographer

Validation of new non-invasive

methods for tear film assessment

using a Keratograph

Imprint

Publisher:

OCULUS Optikgeräte GmbH

Postfach • 35549 Wetzlar • GERMANY

Tel. ++49-641-2005-0 • Fax +49-641-2005-295

E-Mail: export@oculus.de • www.oculus.de

Print:

Bernecker Mediagruppe, Melsungen

Layout:

Grips Design GmbH, Wetzlar



using a corneal topographer*

B. Sc. Doreen Wiedemann [1],[2]

A particularly suitable approach to tear film examination is found in methods that non-invasively analyze the optical

radiation reflected by the tear film [2]. For this purpose a grid is projected onto the cornea and the precorneal tear

film, respectively. The only non-invasive commercial device to date that is suitable for this, the Tearscope (Keeler),

is currently neither available nor being produced. Alternative methods will therefore gain significance in future. The

Keratograph is based on the same type of projection, qualifying it as as a non-contact, non-invasive method of inquiry.

To date the Keratograph has primarily been used for measuring corneal topography. The purpose of the present

study was to clarify to what extent it is also suited for tear film assessment and what modifications would be needed

in order to make both qualitative and quantitative tear film measurements. The device chosen for this purpose was

the Keratograph (Oculus), a modern, well-established model that is widely used in optometric and ophthalmic practices

in Germany. After suitable modification the device was used in a clinical trial for determining tear meniscus

height as well as non-invasive tear film break-up time. The newly developed method was also compared with selected

well-established tests of high practical relevance. These tests involved use of the Tearscope

(Keeler) for determining non-invasive tear film break-up time and a biomicroscope

equipped with a measuring eyepiece for determining the height of the tear meniscus.



using a Keratograph*

B. Sc. Doreen Wiedemann [1],[2] ; Dipl.-Ing. (FH) Martina Michel [1],[2] ;

Prof. Dipl.-Ing. (FH) Wolfgang Sickenberger, MS. Optom. (USA) [1],[2] ;

Dipl.-Ing. (FH) Sebastian Marx [1],[2]

The majority of established tear film examination methods to date are based on observation of induced tear film

reflections. Examples are the determination of tear meniscus height, assessment of interference phenomena, and

the observation of non-invasive tear film break-up time. One limitation common to all these methods is the

subjective nature of the observations made [1]. The fact that tear film data thus obtained contain indeterminable

distortions that limit comparability poses a serious obstacle to their interpretation. Standardisation may serve to

solve some such problems, but not to exclude them. In 2007 the Report of the Diagnostic Methodology Subcom-

mittee of the International Dry Eye Workshop (RDEWS) was published, containing recommendations for standardisation

in established tear film examination methods and clinical studies on dry eye disorders with a view to im-

proving comparability [2]. The members of the subcommittee are nonetheless agreed that it would be of great

importance to develop objective analysis methods that might supplement recommended test combinations for

examining the precorneal tear film. [3]. Such was the situation that motivated the

development of an automated, examinerindependent technique for detection of

non-invasive tear film break-up time.

[1] Fachhochschule Jena; [2] JENVIS Research Institute

* First publication in “Die Kontaktlinse”, issue 7 and 8/2010

weiterlesen auf

Seite 4

weiterlesen auf

Seite 16



using a corneal topographer


radiation reflected by the tear film [2]. For this purpose a grid is projected onto the cornea and the precorneal tearfilm,

respectively. The only non-invasive commercial device to date that is suitable for this, the Tearscope (Keeler), is

currently neither available nor being produced. Alternative methods will therefore gain significance in future. The

Keratograph is based on the same type of projection, qualifying it as as a non-contact, non-invasive method of inquiry.

To date the Keratograph has primarily been used for measuring corneal topography. The purpose of the present study

was to clarify to what extent it is also suited for tear film assessment and what modifications would be needed in

order to make both qualitative and quantitative tear film measurements. The device chosen for this purpose was the

Keratograph (Oculus), a modern, well-established model that is widely used in optometric and ophthalmic practices

in Germany. After suitable modification the device was used in a clinical trial for determining tear meniscus height

as well as non-invasive tear film break-up time. The newly developed method was also compared with selected

well-established tests of high practical relevance. These tests involved use of the Tearscope (Keeler) for determining

non-invasive tear film break-up time and a biomicroscope equipped with a measuring eyepiece for determining the

height of the tear meniscus.

1 Introduction


radiation reflected by the tear film [2]. For this purpose a grid is projected onto the cornea and the precorneal tear film,

respectively. The only non-invasive commercial device to date that is suitable for this, the Tearscope (Keeler), is currently

neither available nor being produced. Alternative methods will therefore gain significance in future. The Keratograph is

based on the same type of projection, qualifying it as as a non-contact, non-invasive method of inquiry. To date the

Keratograph has primarily been used for measuring corneal topography. The purpose of the present study was to clarify

to what extent it is also suited for tear film assessment and what modifications would be needed in order to make both

qualitative and quantitative tear film measurements. The device chosen for this purpose was the Keratograph (Oculus),

a modern, well-established model that is widely used in optometric and ophthalmic practices in Germany. After suitable

modification the device was used in a clinical trial for determining tear meniscus height as well as non-invasive tear film

break-up time. The newly developed method was also compared with selected well-established tests of high practical

relevance. These tests involved use of the Tearscope (Keeler) for determining non-invasive tear film break-up time and

a biomicroscope equipped with a measuring eyepiece for determining the height of the tear meniscus.

2 Tear Film Analysis Methods

Tear film analysis methods can be classified as either quantitative or qualitative or as either invasive or non-invasive.

Quantitative methods yield information on the amount of tear fluid produced per unit of time as well as on the tear

volume contained in the anterior eye segment. Tear film quantity depends on the production rate, distribution and drainage

of tear fluid. Qualitative methods of tear film analysis yield information on the stability and composition of the tear

film. These methods also give insights into the properties of the different tear fluid layers [3].

Optometric examination methods are termed invasive when they injure the integrity of the eye. These include, for example,

the application of fluorescein or the use of test strips which can come into direct contact with or irritate the eye [4]. The

following table gives an overview of the most important methods of tear film analysis.

– 4 –

Development and realization of a new non-invasive method for tear film assessment using a corneal topographer

Invasive Minimally Invasive Non-Invasive

Quantitative Schirmer‘s test I,

Schirmer‘s test II (Jones test),

dilution test

Qualitative BUT

(Break-Up Time)

Further Tests LWE

(Lid Wiper Epitheliopathy)

ULMS

(Upper Lid Margin Staining)

Table 1: Overview of the most important tear film analysis methods

Phenol red thread test

according to Kurihashi,

tear meniscus examination

with slit lamp

Tear meniscus examination

with Tearscope (Keeler)

Flow behavior NIBUT

(non-invasive break-up time),

interference test

LIPCOF

(lid parallel conjunctival folds)

DEQ

(dry eye questionnaire)

The present study was dedicated to the examination of the tear meniscus and tear-film break-up time by means of the

Keratograph. These methods are classified as non-invasive because the Keratograph neither comes into contact with the

eye nor impairs its physiology in the process [5]. However, caution should also be exercised with non-invasive methods

because swelling of the tear meniscus has been observed even under stable test conditions. These techniques therefore

merit classification in the grey area between non-invasive and minimally invasive [2].

3 Methods

3.1 Reference Methods

3.1.1 Tear meniscus height (TMH)

The tear meniscus was assessed using a slit lamp with weak diffuse illumination or reduced direct focal illumination. For

the latter a vertically or horizontally oriented light band of 0.5 to 1 mm width was used. Height measurements were performed

using a monocular adjustable measuring eyepiece (see Figure 1) calibrated for 10x magnification. The eyepiece was

equipped with a 10 mm graticule plate with 0.2 mm divisions. For larger magnification an appropriate scale factor must be

used, since the magnification scale in the focal plane is then no longer 1.0 [6]. Table 2 shows the scale divisions for different

magnifications and measuring eyepieces and the calculation of the scale factor.

Figure 1

1 graticule

2 length scale

3 Tabo angle scale

4 cover glass

5 measuring sphere

6 insertion connecting piece

– 5 –


interval (target) x magnification (target) = interval

magnification (actual) (actual)

– 6 –

Measuring eyepiece

10x

magnification (actual) interval (actual)

in mm


10x

interval (actual)

in mm


12x

interval (actual)

in mm

8x 0.125 0.250 0.300

10x 0.100* 0.200* 0.240

12x 0.083 0.167 0.200*

16x 0.063 0.125 0.150

20x 0.050 0.100 0.120

24x 0.041 0.083 0.100

32x 0.031 0.062 0.075

40x 0.025 0.050 0.060

* This value gives the scale division appropriate to the calibration of the magnification used. This is a necessary condition

in order for measuring scale and measured object to be of the same scale. The values take no account of devicespecific

measurement errors. [6]

Table 2: Relationship between scale division and magnification used

Disregard of the relationship between scale gradation and magnification can lead to significant errors in measuring the

tear meniscus.

3.1.2 Non-invasive tear film break-up time (NIBUT)

It is generally known and has been variously demonstrated that tear film break-up consists in a destabilization or loss

of integrity of the precorneal tear film. Non-invasive tear film break-up time was defined by Mengher et al. in 1985 as

follows: NIBUT is defined as the time in seconds between the last complete blink and the first perturbation of a grid

projected onto the surface of the cornea [7]. NIBUT is measured non-invasively and without application of fluorescein.

NIBUT measurement methods thus differ significantly from the invasive BUT method.

3.1.3 NIBUT measured with the Tearscope (Keeler)

The Tearscope (Keeler) is the only commercial device available for non-invasive tear film analysis. A cold light source is

used in general, the corneal microscope only serving for magnification. After 3 to 4 blinks the subject is asked to keep

his or her eyes open. From this moment on the reflected projection surface is observed closely. Irregularities in the

reflected image indicate places on the cornea where the tear film is losing stability or breaking up. If no grid is used,

the full Tearscope (Keeler) illumination source is employed, producing a white reflection surface. This method permits

continuous observation and identification of the type of tear film break-up, which may, for example, show as an areal

expanse or as stripes or spots.

Figure 2: Reflection image generated with the Tearscope (Keeler)


Due to the high contrast of the reflected image, distortions and disturbances can be observed very well in a dark-coloured

iris. Not so in the case of a light-coloured iris, where determination of tear film break-up time becomes more difficult and

less accurate. Similar difficulties can occur when the tear film has a thin or low-reflecting lipid layer [8]. Figure 3 shows

the poor contrast that results when these two factors coincide, illustrating the difference compared with the image obtained

of the dark-coloured eyes (Figure 2, centre).

Figure 3: Low-contrast reflection image resulting from a light-coloured iris in association with a low-reflecting lipid layer

3.2 Tear Film Analysis Using the Keratograph

3.2.1 Tear meniscus height (NIK TMH)

For the newly developed tear meniscus measurement method presented in this study, illumination was effected by means

of four IR diodes. These IR diodes were mounted on the Keratograph in vertical orientation and arranged in two pairs located

one above the other. The automatic red ring illumination otherwise used for corneal topography was deactivated.

This ensured a dark background for the examination. The diodes were covered up in turn to determine the influence of

each diode pair on the appearance of the reflected image and hence on measured tear meniscus height and the results

obtained were compared with each other. The following combinations were tested:

a) 3 images with both diode pairs;

b) 3 images with the upper diode pair;

c) 3 images with the lower diode pair.

Figure 4: Illumination conditions obtained with the Keratograph

The measurement was performed over a predefined width centered 2 mm nasally from the pupil center, since the height

of the tear meniscus varies along the length of the lower eyelid. Figure 5 shows the reflections occurring with NIK TMH

as compared with the reference method. The yellow arrows show the meniscus height.

– 7 –


Figure 5: TMH (top); NIK TMH (bottom)

3.2.2 Non-invasive tear film break-up time (NIK BUT).

An illuminated ring pattern was projected onto the cornea using the Keratograph. In this case the Placido disk consisted

of 22 rings. After three blinks the projected ring pattern was examined for signs of tear film break-up as described above.

Attention was given in particular to distortions and gaps in individual rings and the time such deviations from the original

ring pattern took to occur was measured.

Figure 6: Graphic representation of wave-like distortions; these were also interpreted as a tear film destabilization, i.e. break-up.

Figure 7: left: Ideal ring pattern; right: ring pattern with wave-like distortions

– 8 –

Development and realization of a new non-invasive method for tear fi lm assessment using a corneal topographer

Examinations were recorded on video. At the start of the recording the subject was asked to blink his or her eyes three

times and then to keep them open. The recording was discontinued at the next eye blink. This procedure was repeated

three times. Tear fi lm break-up time was measured according to the defi nition by Mengher et al. [7] both for the reference

method and for the newly developed method. Figure 8 summarizes the measurement procedure.

1. tear meniscus

measurement

1. tear meniscus

measurement

Figure 8: Overview of test procedure

General preparations

Information and informed consent

2. NIBUT

measurement

Examination using a slit lamp

30 minutes break

3. Examination of

anterior eye segment

Examination using the Keratograph

2. NIBUT

measurement

Statistical evaluation

3. Examination of

anterior eye segment

4. Documentation

of results


of results

– 9 –


3.3 Modifications on the Keratograph

Two software modifications were developed for the Keratograph to realize the measurements described above:





tear meniscus measurement program

tear film measurement program.

Figure 9: Menu of the new measurement program incorporated in the Keratograph (OCULUS) software

In single-shot mode the new software provides a measuring scale for determining tear meniscus height and a magnification

function to facilitate measurement of reflection height. The accuracy of the measurement depends on the magnification

function, being greater at higher than at lower magnification. A running digital clock is displayed in the top left-hand

corner during the video recording. The time was measured manually with a stopwatch, since an automatic eye blink trigger

function was not yet available at the time of the study.

Figure 10: Single-shot mode with measuring scale, magnification function and saving option

3.4 Subjects

– 10 –

Measuring scale

Magnification function

Save (including measured value)

A total of 34 subjects participated in the study, 16 (47%) female and 18 (53%) male. The subjects’ age ranged from 19

to 53 years with a mean value of 28.3 ± 7.2 years.

The newly developed method is designed for use in contact lens fitting as well as for detection of pathological alterations

of the eye in clinical screenings. The inclusion and exclusion criteria were determined on the basis of these designated

application areas, with no resulting exclusions. The only inclusion criterion was that test persons had to be of age. The

only exclusion criterion was the wearing of contact lenses within the last 24 hours preceding the examination. This was

to minimize short-term contact-lens-induced fluctuations in tear film parameters.

4. Results


4.1 Tear Meniscus Height

4.1.1 Tear meniscus height measurements using a slit lamp

In 22 out of the total of 34 subjects tear meniscus height was found to be lower, in four equal to and in eight greater than

0.2 mm. The Shapiro-Wilk Test showed the measured data to be normally distributed within each series of measurements.

(p=0.096). Figure 11 shows the frequency distribution within the classifi cation groups.

4.1.2 Tear meniscus height measurement using the Keratograph

Measurements of tear meniscus height using the Keratograph were considered separately for each of the three illumination

setups in order to determine the infl uence of each individual diode pair on refl ection height. As with the reference

measurements, all measurement series performed with the Keratograph were found to have produced normally distributed

data according to the Shapiro-Wilk test. Figure 11 shows the frequency distributions, along with the reference methods

(shown grey) for comparison.

Corneal microscope with measuring eyepiece

Keratograph (upper diode pair)

65%

71%

82%

76%

Figure 11: Percent distribution of results

Frequency distribution of tear meniscus height

n = 34

12%

6%

3%

Keratograph (both diode pairs)

Keratograph (lower diode pair)

9%

24%

24%

15%

TM < 0.20 mm TM = 0.20 mm TM > 0.20 mm

The differences between means were analyzed using the t-test for paired samples. The null hypothesis was that the differences

between means were entirely the product of chance.

T Test pair 1* pair 2** pair 3***

Paired differences (mean) 0.0035 0.0088 0.0144

Standard deviation 0.0372 0.365 0.0404

T value 0.553 1.410 2.081

p value (signifi cance, 2-tailed 0.584 0.168 0.045

Table 3: Differences between means and correlations (n=34)

*pair 1: Corneal microscope with measuring eyepiece vs.

Keratograph (both diode pairs)

**pair 2: Corneal microscope with measuring eyepiece vs.

Keratograph (upper diode pair)

***pair 3: Corneal microscope with measuring eyepiece vs.

Keratograph (lower diode pair)

15%

– 11 –


On considering the differences between the mean obtained with the reference method and the mean obtained with each

of the three Keratograph versions (Table 10), it becomes clear that the smallest deviation from the reference method

is achieved when both IR diode pairs are used. The p value for method pairs one and two indicates a signifi cance level

higher than α = 0.05. Therefore the null hypothesis cannot be rejected, meaning that the difference between the means

is possibly due to chance. For method pair three the null hypothesis is rejected, since the difference between the means is

signifi cant. The results show that using only the lower diode pair for illumination is not a suitable setup for tear meniscus

measurement.

4.2 Non-invasive tear fi lm break-up time

Not all of the 34 subjects showed tear fi lm break-up during measurement. Measurements that were terminated not by tear

fi lm break-up but by a blink were excluded, in keeping with the defi nition of Mengher et al. [7].

4.2.1 NIBUT measured using the Tearscope (Keeler)

This sample had a median of 8.2 seconds and a range from 4.5 seconds to 29.9. seconds. The Shapiro-Wilk test showed no

normal distribution (p=0.000). A statistical analysis was also performed of the horizontal width of the observed measurement

range. Tearscope (Keeler) measurements showed the width to range from 3.5 to 4.9 mm with a mean value of 4.2

±0.3 mm.

4.2.2 NIK BUT measured with the Keratograph

In 17 of 34 subjects, measurements were in compliance with the defi nition of Mengher et al.. In fi ve out of these 17 subjects

NIK BUT was shorter than 10 seconds, in 10 it ranged between 10 and 20 seconds and in two it was greater than 20

seconds. Neither of the two methods indicated a normal distribution of this sample. The median of the results obtained with

the Keratograph was 11.33 s, with a range from 5.70 s to 25.07 s.

The horizontal width of the measurement range was analyzed as with the reference method, giving a range from 8.25 to

10.46 mm and a mean of 9.37 ± 0.46 mm. The mean was rounded to 9.4 mm to facilitate a comparison of the two methods.

– 12 –

76%

29%

Figure 12: Distribution of results in per cent

Frequency distribution of tear fi lm break-up time

n = 17

Tearscope Keratograph

18%

59%

6%

12%

NIBUT < 10 10ss 10 10 ss ≤ < NIBUT < 20 20 ss NIBUT > ≥ 20 20s s


The median of the two methods differed by 2.5 s and the mean by 2.8 s. There was little deviation between the extremes

obtained with the two methods. The standard deviation was 5.0 s for the results obtained with the reference method and

5.24 s for those obtained with the Keratograph. Wilcoxon’s test was used to determine whether the differences found between

the two methods might be attributable to chance. This yielded a p-value of 0.049, indicating a significant difference

for α = 0.050 and hence rejection of the null hypothesis. Moreover, Spearman’s rank correlation coefficient was calculated

as 0.088, indicating no appreciable correlation between the measurement results of the two methods.

5 Discussion

5.1 Tear Meniscus Height

The reference method was performed with a measuring eyepiece mounted on the slit lamp. As already mentioned, this

method requires appropriate magnification for accurate results. Since it is not being applied to an inanimate object, it also

requires a certain degree of experience on the part of the examiner. The longer it takes the examiner to perform the measurement,

the greater the influence of reflex secretion provoked by the examination and hence the probability of obtaining

distorted results. This is where the advantage of the newly developed method lies. The use of IR diodes avoids exposure of

the subject to glare, thus markedly reducing the risk of reflex secretion. Moreover, the examination takes less time, since

only one shot of the tear meniscus is taken. When the measurement has been completed, the examiner can then take all

the time he needs for the evaluation. For this purpose the software of the Keratograph was modified to include a segment

magnification function and a measuring scale calibrated to the magnification being used. These modifications reduce the

influence of measurement errors that have caused problems in the past. In addition, the picture material can be automatically

incorporated in the patient file for later use in follow-up examinations.

5.2 Non-invasive Tear Film Break-Up Time

The illumination system of the Keratograph consists of 200 red LEDs with a wavelength of 653 nm. LEDs have the

advantage of emitting very little heat radiation, minimizing the danger of thermally induced alterations of the tear film.

The method of area illumination and projection differs from that of the Tearscope (Keeler) in the use of an additional grid.

However, the Tearscope (Keeler) provides only poor contrast in the case of light-coloured eyes associated with a low-

reflecting lipid layer, making it difficult to obtain accurate NIK-BUT measurements. Compared with the Tearscope (Keeler)

the newly developed method permits very good observation of tear film break-up phenomena under constant contrast

conditions, independent of eye colour or of interference effects related to the lipid layer. This provides ideal conditions

for discriminating between disorders of the tear film, caused for example by air bubbles or mucin threads, and tear film

break-up. The Keratograph provides a markedly larger field of observation so that peripheral tear break-ups are also

considered.

– 13 –


6 Conclusion and Outlook

Modern contact lens fitting as it is practised today would be unthinkable without the Keratograph. With around one in

three contact lens wearers complaining of dryness problems or dry eye symptoms there is a practical interest in obtaining

information on a person’s tear film quality and quantity when they have their corneal geometry measured in preparation

of contact lens fitting. The present newly developed method is suited for non-invasive assessment of tear meniscus height

as well as determination of non-invasive tear film break-up time. All results obtained with the method can be directly

incorporated in the patient file. The highest priority of future development work should be to facilitate the generation of

reproducible, objective data in the area of non-invasive tear film analysis. One important step towards this end will be to

develop automatic examiner-independent methods. The results obtained in this study, and the modifications performed

by the Oculus company on the Keratograph for this purpose - implemented in its TF Scan module - constitute important

steps in this direction. This new objective method has in the meantime been validated by the JENVIS Research Institute.

The validation included a comparison of NIK BUT with classical analysis methods, e.g. BUT, Schirmer‘s test, tear meniscus

height and the results of a personal dry eye questionnaire.

Figure 13: NIK-BUT validation study

Current plans to continue development work on the Keratograph will open the field for numerous follow-on studies. Future

development work on the TF Scan module could be aimed at an assessment of NIK DUT, i.e. non-invasive drying-up time.

The present study has prepared the ground for this new avenue of research.

– 14 –

Follow-on study

(n=101)

Validation



Classification

Tear film &

dry eye

Literature


[1] MARQUARDT, R.; LEMP, M. A.: Das trockene Auge in Klinik und Praxis.- 1. Aufl. - Heidelberg: Springer Verlag, 1991

[2] The Ocular Surface, Report of the International Dry Eye WorkShop (DEWS):

Methodologies to Diagnose and Monitor Dry Eye Disease: Report of the Diagnostic

Methodology Subcommittee of the International Dry Eye WorkShop, 2007

[3] SICKENBERGER, W.: Klassifikation von Spaltlampenbefunden. Großostheim:

Bezug über Ciba Vision Vertriebs GmbH, 2001

[4] MASTERS,B. R.: Noninvasive Diagnostic Techniques in Ophthalmology,Springer Verlag, 1990

[5] KLYCE, S. D.; DINGELDEIN, S.A.: Corneal Topography, aus: Noninvasive Diagnostic Techniques in Ophthalmology,

Springer Verlag, S. 61-77, 1990

[6] Augenuntersuchungen mit der Spaltlampe. Ophthalmologische Geräte von Carl Zeiss,

http://www.zeiss.com/C12567A10053133C/allBySubject/576876A46968B68AC125718600422005 (Stand 1.11.09)

[7] MENGHER, L. S.; PANDHER, K. S.; BRON, A. J.: Non-invasive tear film break-up time: sensitivity and specificity.

Acta Ophthalmologica, Vol.: 64: 441-444, 1986

[8] GUILLON, J.P.: Non-invasive tearscope plus routine for contact lens fitting. Contact Lens and Anterior Eye,

(Supplement) Vol.: 21: 31-40, 1998 Validation of new non-invasive methods for tear film assessment using

a Keratograph

Author:

Doreen Wiedemann, BSc, student of the Master Program in Optometry /Vision Science / Jena University of Applied Science,

collaborator of the JENVIS Research Institute, Jena

Email: wiedemann@jenvis-research.com

Advisor:

Prof. Dipl.-Ing. (FH) W. Sickenberger, MS. Optom. (USA), FH Jena

Dipl.-Ing. (FH) M. Michel, JENVIS Research Institute, Jena

– 15 –



using a Keratograph*

B. Sc. Doreen Wiedemann [1],[2] ; Dipl.-Ing. (FH) Martina Michel [1],[2] ;

Prof. Dipl.-Ing. (FH) Wolfgang Sickenberger, MS. Optom. (USA) [1],[2] ;

Dipl.-Ing. (FH) Sebastian Marx [1],[2]

[1] [2] Fachhochschule Jena; JENVIS Research Institute

* First – 16 publication – in “Die Kontaktlinse”, issue 8-2010



using a Keratograph

The majority of established tear film examination methods to date are based on observation of induced tear film

reflections. Examples are the determination of tear meniscus height, assessment of interference phenomena, and

the observation of non-invasive tear film break-up time. One limitation common to all these methods is the sub-

jective nature of the observations made [1]. The fact that tear film data thus obtained contain indeterminable distortions

that limit comparability poses a serious obstacle to their interpretation. Standardisation may serve to solve

some such problems, but not to exclude them. In 2007 the Report of the Diagnostic Methodology Subcommittee

of the International Dry Eye Workshop (RDEWS) was published, containing recommendations for standardisation

in established tear film examination methods and clinical studies on dry eye disorders with a view to improving

comparability [2]. The members of the subcommittee are nonetheless agreed that it would be of great importance

to develop objective analysis methods that might supplement recommended test combinations for examining the

precorneal tear film. [3]. Such was the situation that motivated the development of an automated, examiner-

independent technique for detection of non-invasive tear film break-up time.

1 Introduction

This study is based on the results of a development study entitled “Development and realization of a new non-invasive

method for tear film assessment using a corneal topographer” which was published in the 7-8/2010 issue of this journal.

The present follow-on study was dedicated to a validation of objective Non-Invasive Keratograph Break-Up Time

(NIK-BUT), the aim being to delimitate normal from critical values. For this purpose a test battery was set up conforming

to the RDEWS recommendations and covering the more established qualitative, quantitative and subjective tear film

analysis methods. A further aim, motivated by substantial controversy over the correlation of results, was to determine

comparability between the individual examination methods.

Follow-on study

(n=101)

Validation

Classification

Figure 1: Overview of methods considered in the present validation study

Tear film &

dry eye

– 17 –

Validation of new non-invasive methods for tear film assessment using a Keratograph

2 Materials and Methods


2.1.1 Tear meniscus height (TMH and NIK-TMH)

Tear meniscus height (TMH) was determined at reduced room lighting using a measuring eyepiece (10x, 0.2 mm scale division)

mounted on a slit lamp. A horizontal light band was projected onto the test subject’s face such that it approached

the lower eyelid from below, and the tear meniscus was measured three times over a defined central measuring range.

Tear meniscus height (NIK-TMH) was measured with the Keratograph using the same two measurement tools described in

the preceding article [5]. These were incorporated unchanged in the TF-Scan software, the only modification being the use

of horizontally arranged white diodes in place of the previous red ring illumination. This modification was made purely for

technical reasons related to the equipment. NIK-TMH was thus determined three times and the results were entered in a

documentation form.

2.1.2 Break-up time (BUT)

BUT was measured at mid-range magnification. Measurements were performed in a darkened room under direct focal illumination

with the blue and yellow filters interposed. The Dry Eye Test (DET) was performed for better reproducibility of the

amount of fluorescein applied. Subjects were asked to blink three times after receiving fluorescein and then keep their eyes

open. The time from the last blink until the first appearance of dark areas on the cornea was measured with a stopwatch.

This was done three times and the resulting arithmetic mean was calculated. Table 1 gives a classification of invasive tear

film break-up time.

Classification BUT (in s) Interpretation

Grade 0 ≥10 stable tear film

Grade 1 6-9 tear film stability critical

Grade 2 ≤ 5 dry eye disorder

Table 1: Classification of BUT

2.1.3 McMonnies DEQ

Test subjects completed the McMonnies’ Dry Eye Questionnaire (McMonnies DEQ) for a subjective assessment of tear film.

Answers were classified according to a scoring system with a total score range from 0 to 45 defining three grades of dryness.

Classification Total score Interpretation

Grade 0 0-9 no dry eye; asymptomatic

Grade 1 10-20 slightly dry; critical

Grade 2 >20 dry eye

Table 2: Classification according to the McMonnies DEQ

– 18 –


2.1.4 Schirmer test (without anaesthetic)

For the Schirmer test (without anaesthetic), a standardised 5 mm wide strip of filter paper was placed in the temporal

third of the lower fornix as an indicator and left there for five minutes with the test subject’s eyes open. After this time

the test strip was removed and the moistened length of strip was read in mm and entered in the documentation form.

Figure 2: Schirmer test in progress

Classification length (mm/5 min) Interpretation

Grade 0 ≥ 15 normal

Grade 1 6-14 slightly dry eye

Grade 2 ≤ 5 dry eye

Table 3: Classification according to the Schirmer test (without anaesthetic) [3][4]

2.2 NIK-BUT method

2.2.1 Technical modifications on the Keratograph

The TF-Scan software (Oculus) was reviewed in preparation of the validation study and modified in cooperation with the

Oculus company. This software permits automatic determination of tear film break-up time, providing a graphic representation

referred to as a Tear-Map, which shows the location and size the regions in question. The colour coding of the

Tear-Map was modified (see Figure 3). In addition to the “first break-up time” (NIKf-BUT) the software now also gives the

“average break-up time” (NIKav-BUT), i.e. the average of all tear film break-ups occurring over the entire cornea.

Figure 3: Modified colour scale of the tear map

red below 6s

orange / yellow from 6s (previously 9s) on

green from 12s (previously 16.5s) on

The time reading shown against white background below the colour scale in Figure 3 gives the time between the first

blink, which triggers the measurement, and the second blink, which terminates it.

– 19 –


2.2.2 NIK-BUT

After creating a test subject in the patient file the option „New measurement (NIBUT)“ was selected from the control bar

of the Keratograph. After the operator had centered the test subject’s eye a window appeared in the screen prompting

the operator to have the test subject blink twice. The second blink automatically triggered the video recording and measurement.

The measurement was terminated by either of two events: another blink or excessive blur or distortion of the

reflected image of the Placido rings, making continued detection impossible. After measurement completion the following

information was available for documentation: a video recording, a representation of tear film break-up over time including

its graphic depiction in a tear map, the first break-up time (NIKf-BUT) and the average break-up time (NIKav-BUT)

(see Figure 4).

Figure 4: Output after a NIK-BUT measurement: left: video; top right: progress of tear film break-up over time; bottom

right: Tear-Map and display of NIKf-BUT and NIKav-BUT.

– 20 –

Validation of new non-invasive methods for tear fi lm assessment using a Keratograph

Results for NIKf-BUT and NIKav-BUT were entered in the documentation form. This measurement was performed three

times per test subject. Figure 5 gives an overview of the test procedure.

1. NIK-TMH

measurement

1. TMH

measurement

General preparations

Information and informed consent

Examination using the Keratograph

2. NIK-BUT

measurement

2. BUT

measurement

Figure 5: Schematic overview of test procedure

Break

Examination using a slit lamp

McMonnies DEQ

3. Subjective assessment

of examination

3. Subjective assessment


Schirmer test (without anaesthetic)

1. Measurement (mm / 5 min) 2. Subjective assessment


Statistical evaluation


of results


of results

3. Documentation of results

– 21 –


2.3 Subjects

101 subjects participated in the validation study. Their age and sex distribution is shown in Table 4.

N 101

Mean age 41 ± 16 years

Min. age 18 years

Max. age 75 years

Mean age of females (n=57) 40 ± 16 years

Mean age of males (n=44) 40 ± 17 years

Table 4: Demographics

2.4 Statistical methods

The results obtained with the various methods were first analysed descriptively and tested for normal distribution using

the Shapiro-Wilk test. This led to rejection of the null hypothesis in each case, indicating absence of normal distribution

for every method used.

A cut-off value was determined for the boundary between normal and critical tear film quality in preparation of a classification

of Non-Invasive Keratograph Break-Up Time (first break-up time and average break-up time). This was done by

comparing the results of TMH, BUT, the McMonnies DEQ and Schirmer test with the corresponding NIK-BUT values using

ROC (receiver operating characteristic) curves. This analysis method is used for gaining information on the sensitivity

and specificity of diagnostic tests. It involves plotting sensitivity on the y-axis and 1 - specificity on the x-axis of a twodimensional

coordinate system. Significant deviation of the resulting curve from the diagonal reference line indicates

good discrimination by the test under consideration. The performance of the test is represented by the area under the

ROC curve, also referred to as AUC (Area Under Curve). AUC can range between ca. 0.5 and ca. 1.0, with high values

indicating a powerful test and low absolute values a test of low discriminatory power.

Discriminatory power AUC

Unacceptable 0.5 – 0.7

Acceptable 0.7 – 0.8

Very good 0.8 – 0.9

Excellent 0.9 – 1.0

Table 5: Interpretation of AUC values

For this type of statistical evaluation it is first necessary to map all objective and subjective results to either of two test

outcome levels. In the present study this information was obtained from the classification keys of the individual reference

tests (Table 6).

Discriminatory power Grade 0 Grade 1 Grade 2

0 (normal) x

1 (critical) x x

Table 6: Definition of the two test outcome levels

To determine the discriminatory power of the present newly developed method we analysed it firstly in comparison with

all the other tests and secondly in comparison with the tests with the highest sensitivity and specificity for dry eye, namely

with BUT and the McMonnies DEQ [1]. This appeared all the more appropriate as it is meaningful to combine objective and

subjective methods [6].

– 22 –

3 Measurement data and results


The purpose of the validation study was to establish a distinction between normal and critical NIK-BUT values. This is the

primary focus in the following presentation of results, which gives the results obtained with the individual methods only in

a brief overview.

3.1 Reference methods

3.1.1 Tear meniscus (TMH and NIK-TMH)

In 15 of the 101 test subjects NIK-TMH measurement yielded values below 0.2 mm, in 16 equal to and in 70 greater than

0.2 mm. TMH measurements deviated only slightly from this distribution.

69% 62%

Frequency distribution

n = 101

Grade 0 Grade 1 Grade 3

Figure 6: Frequency distribution of NIK-TMH and TMH across the three groups

Analysis of the relationship between the two methods yielded a correlation coefficient of 0.722 and a coefficient of determination

of 0.568. This is confirmation of our finding in the development study that NIK-TMH and TMH produce comparable

results, justifying their combined use for the present classification.

3.1.2 Break-up time

The results of invasive tear film break-up time (BUT) were likewise classified into three levels (see Figure 8). The entire

sample had an arithmetic mean of 7.53 ± 3.73 s, a median of 6.90 s, and a range from 2.10 s to 19.40 s.

26%

NIK-TMH TMH

16% 23%


n = 101

Figure 7: Frequency distribution of BUT across the three groups

BUT

15% 15%

37% 37%


– 23 –


3.1.3 McMonnies DEQ

In the McMonnies questionnaire the test subjects produced a mean overall score of 10.36 ± 6.83 and a median of 9.00. The

lowest overall score was 1 point and the highest was 28.

Figure 8: Frequency distribution for the McMonnies DEQ across the three groups

3.1.4 Schirmer test (without anaesthetic)

The results of the Schirmer test gave a mean of 18.58 ± 7.36 mm/5 min and a median of 22.00 mm/5 min for the entire

sample (n=101). The maximum, limited by the length of the test strip, was 25 mm/5 min and the minimum in this study

was 3 mm/5 min.

Figure 9: Frequency distribution of the results of the Schirmer test across the three groups

– 24 –

58%


n = 101

McMonnies DEQ

30%

12%


70%


n = 101

Schimer I - Test

19%

11%

Grade 0 Grade 1 Grade 3

3.2 Comparison of methods and statistical data


3.2.1 Frequency distributions for each of the reference methods

The results obtained for the 101 subjects with the five reference methods were in each case classified into three groups.

69% 62%

Figure 10: Synopsis of frequency distributions of results across the three groups

No confirmation of normal distribution was obtained when the results of all the reference methods were considered

together.

3.2.2 Correlation and comparability of reference methods

The outcomes obtained with the individual reference methods were examined for correlations using Spearman’s rank correlation

test. Strong and significant correlations were only found between NIK-TMH and TMH and between NIKf-BUT and NIKav-

BUT. Weak correlations were found between BUT and NIKf-BUT and between BUT and NIKav-BUT. No correlations were found

between any of the established reference methods. Table 7 gives the correlation coefficients for each method pair.

NIK-TMH NIKf-BUT NIKav-BUT TMH BUT McMonnies Schirmer test I

NIK-TMH 1,000 ,065 ,081 ,722(**) ,087 -,198(*) ,078

NIKf-BUT ,065 1,000 ,868(**) ,062 ,505(**) -,280(**) ,132

NIKav-BUT ,081 ,868(**) 1,000 ,070 ,454(**) -,246(*) ,090

TMH ,722(**) ,062 ,070 1,000 ,127 -,207(*) ,056

BUT ,087 ,505(**) ,454(**) ,127 1,000 -,182 ,258(**)

McMonnies -,198(*) -,280(**) -,246(*) -,207(*) -,182 1,000 -,182

Schirmer test I ,078 ,132 ,090 ,056 ,258(**) -,182 1,000

** The correlation is significant at a level of 0.01 (two-tailed)

* The correlation is significant at a level of 0.05 (two-tailed)


n = 101

NIK-TMH TMH BUT McMonnies DEQ Schimer I - Test

26%

58%

70%

16% 23%

37% 30%

19%

15% 15%


Table 7: Spearman’s nonparametric rank correlation coefficients for all reference methods studied (n = 101)

37%

12% 11%

– 25 –


The following diagrams illustrate the high degree of scatter and hence poor comparability of the results obtained with the

various reference methods. Each diagram shows the results obtained for the entire sample (n=101).

Figure 11: Representation of value pairs: Comparison of NIKav-BUT and NIKf-BUT with BUT and McMonnies DEQ (n=101)

The diagrams in Figure 11 show that there is no linear relationship or indeed any correlation between the results of the

method pairs chosen. The diagrams in Figure 12 show there to be a particularly large scatter among the data obtained for

BUT vs. Schirmer test.

Figure 12: Representation of value pairs: Comparison between BUT and TMH and between BUT and Schirmer test (n=101)

3.2.3 ROC curves

As already described, the output range of each tear film test was divided into an asymptomatic and a symptomatic subrange.

This was done to facilitate a comparison of NIK-BUT with a combination of subjective and objective tear film tests,

the McMonnies DEQ serving as a subjective and TMH, BUT and the Schirmer test as objective tests. Test subjects were

classified as symptomatic if altogether at least three out of four tear film tests yielded results classified as critical or dry

eye disorder (Grade 1 or 2). According to this combination of objective and subjective criteria, 82 of the total of 101 test

subjects were asymptomatic and 19 were assessed as symptomatic. The predictive values of NIKf-BUT and NIKav-BUT were

found to be significant (NIKf-BUT: AUC=0.679; p=0.016; NIKav-BUT: AUC=0.646; p=0.048).

Figure 13: ROC curves for NIKf-BUT and NIKav-BUT (n=101; reference methods: TMH, BUT, Schirmer test and McMonnies DEQ)

– 26 –

NIKav-BUT

TMH

25,0

20,0

15,0

10,0

5,0

0,0

BUT/NIKav-BUT

0,0 5,0 10,0 15,0 20,0 25,0

0,50

0,45

0,40

0,35

0,30

0,25

0,20

0,15

0,10

0,05

BUT

BUT/TMH

0,00

0,0 5,0 10,0 15,0 20,0 25,0

BUT

Sensitivity

1,0

,8

,5

,3

0,0

NIKav-BUT

Schimer-Test I

-5

25

20

15

10

0,0 ,3 ,5 ,8 1,0

1 - Specifity

5

McM. DEQ/NIKav-BUT

5 15 25 35 15

McMonnies DEQ

BUT/Schimer-Test I

0

0,0 5,0 10,0 15,0

BUT

20,0 25,0

Source of curve

Reference line

NIKav-BUT-MW

NIKf-BUT-MW


The value with the smallest difference between sensitivity and specificity represents the cut-off value. The smallest

difference between the two for NIKf-BUT was 0.01, giving a cut-off value of 9s, and for NIKav-BUT the smallest difference

was again 0.01, giving a cut-off value of 14s. Test subjects with lower NIK-BUT values should be considered as critical or

symptomatic.

Assessment of NIK-BUT on the basis of BUT and the McMonnies DEQ

NIK-BUT was then assessed on the basis of one objective and one subjective test, both of which were selected for having

the highest discriminatory power and performance with regard to dry eye within their class (BUT test and McMonnies DEQ

[1]), and the results of these two tear film tests were considered anew. Test subjects were classified as symptomatic when

the BUT test and the McMonnies DEQ both yielded values classifiable as critical or dry eye disorder (Grade 1 or 2). According

to this classification 61 of the 101 test subjects were asymptomatic and 40 were symptomatic, i.e. seen as critical or as

having dry eye disorder. When interpreted on the basis of these two tests NIK-BUT shows good and significant predictive

power (NIKf-BUT: AUC=0.750; p=0.000; NIKav-BUT: AUC=0.735; p=0.000).

Figure 14: ROC curves for NIKf-BUT and NIKav-BUT (n=101; reference methods: BUT and McMonnies DEQ)

Again the cut-off value was determined by finding the value giving the smallest difference between sensitivity and specificity.

The smallest difference was found to be 0.01, giving cut-off values of 14s for NIKav-BUT and 10s for NIKf-BUT. NIK-

BUT values below the cut-off value merit interpretation as critical.

Using the same two reference methods as an assessment basis an attempt was then made to distinguish between critical

and dry eye tear film. This time test subjects were classified as symptomatic if both the BUT test and the McMonnies DEQ

were indicative of Grade 2 dry eye disorder. 84 of 101 test subjects were found to be asymptomatic and 17 symptomatic

under this interpretation. With AUC values of 0.763 and 0.751, respectively, this test has good discriminatory power, but

our findings on it should be viewed as tentative because of the low number symptomatic cases (NIKf-BUT: AUC=0.763;

p=0.001; NIKav-BUT: AUC=0.751; p=0.001).

Sensitivity

Sensitivity

1,0

,8

,5

,3

0,0

1,0

,8

,5

,3

0,0

0,0 ,3 ,5 ,8 1,0

1 - Specifity

0,0 ,3 ,5 ,8 1,0



NIKav-BUT-MW

NIKf-BUT-MW



NIKav-BUT-MW

NIKf-BUT-MW

Figure 15: ROC curves for classification as Grade 2 dry eye disorder according to NIKf-BUT and NIKav-BUT (n=101;

reference methods: BUT and McMonnies DEQ)

– 27 –


The cut-off values for this test can be defined as 5s (NIKf-BUT) and 7s (NIKav-BUT). This gives the following three-level

classification for NIKf-BUT and NIKav-BUT:

Table 8: Classification of NIK-BUT results

Classification NIKf-BUT (in s) NIKav-BUT (in s) Interpretation

Grade 0 ≥10 ≥14 stable tear film

Grade 1 6-9 8-13 critical tear film

stability

Grade 2 ≤ 5 ≤ 7 dry eye disorder

Figure 16 gives the frequency distribution for this classification. Those for the reference methods have been calculated and

are shown on the basis of the established classification keys.

Figure 16: Frequency distribution for NIK-BUT, BUT and the McMonnies DEQ across the three groups

4 Discussion


The present study showed no correlation between established dry eye tests. For example, Spearman’s rank correlation coefficient

between the Schirmer test and the BUT test was 0.258. On the other hand, there have been studies showing a good and

significant correlation between these two tests when a local anaesthetic was used prior to the Schirmer test (n=44; Pearson’s

correlation coefficient 0.653; p=0.000 [7]. Findings on the reliability of the Schirmer test in terms of its ability to classify tear

film quantity have been contradictory and highly varied [8] whether performed with or without the use of an anaesthetic. By

comparison, the correlations of NIK-BUT with other established methods such as TMH or BUT are markedly higher.

Due to inconsistent findings on the relationships between different examination methods it has not been possible to date

to a define generally applicable gold standard for tear film analysis and classification. For a classification of tear film quality

and quantity it is therefore advisable to use not just one or two tests with an additional subjective questionnaire such

as the McMonnies DEQ. Numerous studies have sought to find optimal test combinations, some comprising both objective

and subjective tests.

– 28 –

60% 58%

NIK-BUTav

26%

58%


n = 101

NIK-BUTf BUT McMonnies

37%

33%

28% 30%

12% 9%

37%


12%


A further source of controversy is that the more established methods are operator-dependent, making it difficult to judge

their objectivity. With NIK-BUT, by contrast, non-invasive tear film break-up time is measured automatically and thus

objectively, without the operator influencing the outcome. Thus NIK-BUT circumvents two error sources involved in the

BUT method. The latter requires fluorescein application, which can distort outcomes by affecting the composition of the

tear film as well as through the difficulty of reproducible dosage. Mc Monnies DEQ and BUT have been suggested as a test

combination for diagnosis of dry eye disorder, having together the highest sensitivity and specificity. This was the motivation

for using these two methods for the determination of NIK-BUT cut-off values. The resulting classification is recommended

by the authors for assessing tear film quality by NIK-BUT.

4.2 NIK-BUT method

In the present study NIK-BUT was no longer determined manually as in the development study but automatically. This

eliminates any influence of the operator on individual measurement results, including the operator response time previously

contained in time measurements. Detection occurs with computer assistance, capturing even the smallest tear film

break-up. These factors have led to shorter break-up times than are measured manually. This was the reason for measuring

both the first and the average break-up time in the present validation study. The results thus obtained show that both are

suitable for assessing tear film quality and provide good and significant discriminatory power for distinguishing between

normal and critical tear film break-up times. The present study was performed on a modified version of the TF-Scan software

(Oculus) used in the development study. The modified version has lower rates of error resulting from pupillary response,

shadowing from the nose or eyelashes or additional reflections at the upper tear meniscus. Further improvements

relate to the colours used on the tear map and the adjusted classification of break-up times according to the cut-off values

found.

Some imprecision appears to remain in the central region. This can be seen in Figure 4 for example, which shows no breakup

time, or rather no tear film break-up, in the central region. This occurred several times, leading us to assume that the

altered contrast conditions have made detection against the dark pupil more difficult.

5 Conclusion and preview

The present validation study on NIK-BUT was successful in identifying significant cut-off values which permit discrimination

between normal and critical NIK-BUT values.

Measurement of NIK-BUT offers numerous advantages over conventional methods for both the examiner and the person

being examined. The procedure can be learnt quickly and easily, making it suitable both as a screening method and as an

objective, examiner-independent diagnostic test. The test outcome is presented in the form of an intuitively colour-coded

tear map, making communication easier and facilitating the customer’s or patient’s understanding, i.e. whether in a clinical

setting or in preparation of contact lens fitting. No auxiliary equipment is required, lowering the risk of skewed results

as well as costs.

The highest priority of further development work should be on extending the classification of NIK-BUT to permit a reliable

diagnosis of dry eye disorder. To this end the authors have already carried out a study in which patients with a diagnosis

of dry eye were examined with NIK-BUT. The tear map generated in the process allows to locate the break-up zones. This

can now serve as a basis to examine whether the location and size of the break-up zones can contribute to the diagnosis.

Another aspect of potential clinical interest might lie in using the method for examining the tear film after LASIK.

– 29 –


Literature

[1] The Ocular Surface, Report of the International Dry Eye WorkShop (DEWS):

Methodologies to Diagnose and Monitor Dry Eye Disease: Report of the Diagnostic

Methodology Subcommittee of the International Dry Eye WorkShop, 2007

[2] The Ocular Surface, Report of the International Dry Eye WorkShop (DEWS): Design and Conduct of Clinical Trials.:

Report of the Diagnostic Methodology Subcommittee of the International Dry Eye WorkShop, 2007

[3] The Ocular Surface, Report of the International Dry Eye WorkShop (DEWS): The Definition and Classification of

Dry Eye Disease, Report of the Diagnostic Methodology Subcommittee of the International Dry Eye WorkShop, 2007

[4] SICKENBERGER, W.: Klassifikation von Spaltlampenbefunden.3.Auflage, Großostheim: Ciba Vision Vertriebs GmbH, 2010

[5] Wiedemann, D.: Entwicklung und Erprobung neuer nichtinvasiver Untersuchungsmethoden des Tränenfilms mittels

Videokeratographen. Die Kontaktlinse, Nr.: 7-8, 2010

[6] Michel, M.: Diplomarbeit: Bestimmung des kontaktlinsenrelevanten okulären Trockenheitsgrades anhand validierter

und optimierter Patienten-Fragebögen und objektiven Tests.. Fachhochschule Jena, Fachbereich SciTec, Studiengang

Augenoptik, Erscheinungsjahr 2008

[7] ISREB, M.A.; GREINER, J.V.; KORB, D.R; GLONEK, T.; MODY, S.S; FINNEMORE, V.M.; REDDY, C.V.: Correlation of lipid layer

thickness measurements with fluorescein tear film break-up time and Schirmer’s test; Nature Publishing Group: Eye

(2003) Vol: 17: 79–83, 2003

[8] CHO P.; YAP M.: Schirmer-Test I – A Rewiev. Optometry and Vision Science, Vol. 70 No. 2, 152-156, 1993

Author:

Doreen Wiedemann, student of the master program in optometry and vision science at FH Jena

associate at the JENVIS Research Institute, Jena

Email: wiedemann@jenvis-research.com

– 30 –


– 31 –

WWW.OCULUS.DE

OCULUS is certifi ed by TÜV according to

DIN EN ISO 13485:2003/DIN EN ISO 9001:2000

OCULUS Optikgeräte GmbH

Postfach • 35549 Wetzlar • GERMANY

Tel. ++49-641-2005-0 • Fax ++49-641-2005-295

E-Mail: export@oculus.de • www.oculus.de

OCULUS Keratograph - Special Reprint [2981 KB]

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
