Circular structures and buildings associated with vernacular
farm architecture and folk engineering
Mauritz Naudé
Department of Architecture, Tshwane University of Technology
mauritz@nfi.museum
The rondavel has become a typical feature on farmsteads but it is not the only building with a circular
floor plan. Several other structures also have a circular floor plan. In Western architecture we have
become accustomed to the domination of the square and rectangle as spatial form giving element in
architecture in the West. Even though a circular building is not more complicated than the square or
rectangular counterparts, the construction of a cylindrical structure needs some special design and
construction precautions to prevent it from disintegrating and cracking in the long run. In some way we
perhaps negated the fact that the occurrence and use of the circular shape as solution for space problems
has been a strong element in South African folk architecture for centuries. The application and
use of the circle in vernacular architecture is not a measure to determine how civilized a community is
but rather an example of ‘contact architecture’ that was born from a need and combined with the local
building traditions. Over decades this shape was adopted to serve the spatial and aesthetic needs of an
individual or family. The construction of a circular building and structure relies on the construction
skills of the responsible craftsperson and has played a significant role in defining the character of South
African vernacular building typologies.
Key words: rondavel, circular shaped buildings, circular floor plans
Sirkelvormige strukture en geboue wat geassosieer word met volks plaasargitektuur en volksingenieurswerk
Die rondawel het ‘n tipiese element van plaaswerwe geword, maar dit is nie die enigste gebou wat ‘n
sirkelvormige grondplan het nie. Verskeie ander konstruksies se planvorm is aan die sirkel verwant.
In Westerse argitektuur het ons gewoond geraak aan die gebruik van die vierkant en die reghoek as
dominante planvorm om ruimtebenuttingsprobleme vir die ontwerp van geboue op te los. Alhoewel
die sirkelvormige plan nie meer ingwikkeld as die vierkantige plan is nie, benodig sirkelvorminge
konstruksies beide ontwerp-en konstruksievernuf om te verseker dat die struktuur nie oor die lang
termyn verswak en kraak nie. Die rondawel en ander sirkelvormige geboue en strukture het mettertyd
‘n belangrike rol in die geskiedenis van Suid-Afrikaanse volksargitektuur gespeel. Die gebruik van die
sirkelvormige grondplan in plaasargitektuur is egter nie ‘n barometer om vlakke van ‘beskaafdheid’
te bepaal nie, maar eerder ‘n voorbeeld van ‘kontakboukuns’. In sommige gevalle kon dit selfs om
estetiese redes verkies gewees het.
Sleutelwoorde: rondawels, sirkelvormige geboue, ronde planvorms
Contrary to what may seem to be a common perception that vernacular architecture on
the farms of white landowners in the northern part of South Africa is only represented
by rectangular or square floor plan buildings, structures with circular floor plans
were also common, such as the rondavel typology. However, circular floor plans are mostly
associated with engineering structures and not with residential buildings with the exception
of the ‘rondavel’. Rondavels and rondavel houses are common but in terms of using this form
giving formula as dwelling type it remains the exception rather than the rule. This may be the
reason why the circular floor plan has almost been negated and excluded from earlier vernacular
dwelling typologies and publications regarding early European vernacular architecture.
This study is part of an investigation into early vernacular dwelling typologies that have
existed among white pioneer settlers who moved into the area north of the Vaal River after
1840. The investigation takes as premise that both the circular and rectangular floor plans
entered the region and co-existed as vernacular architectural traditions among white farming
communities and early frontier settlers in the region. One assumption is that the circle was
part of the mental map and an archetype that was brought into the region when white settlers
arrived during the period 1840 to 1880. Concomitantly, the circle was a common spatial form
used by local indigenous peoples at the time and even long before white pioneers entered this
geographic area.
SAJAH, ISSN 0258-3542, volume 25, number 2, 2010: 1–28.

One assumption is based on the ‘form follows function’ principle: the circular floor plan
shape being the result of activities executed and dependant on a circular motion in order to be
productive and effective. However, the use of the circular shape as a floor plan for a dwelling
does not follow this logic. A second assumption is based on the principle of ‘form follows
tradition’: the circular floor plan for small dwellings, such as rondavels, was applied as a useful
type among early white settlers in the region north of the Vaal River during the frontier years
as they have been exposed to it sometime in their past or in the areas and districts from which
they originate. A third assumption is based on the ‘form follows local knowledge’ principle:
white settlers used the local black residents to erect rondavels based on their local know-how.
In this way no building plans had to be drafted and building specifications could be kept to the
minimum.
It is accepted that the small circular floor plan dwelling may have fitted into an evolution of
floor plans of the earliest pioneers and adventurers and these dwelling types served as temporary
shelters for either individuals or groups of individuals (individuals without their families). These
shelters can therefore not be considered ‘dwellings’ in the real sense of the word. At the same
time referring to the rondavel as a circular building type, it seems that this building was not
merely part of a phase in the history of early frontier settlement but it continued to be erected
well into the 20th century (1950s) and even became quite common on farmsteads long after the
pioneering phases of settlement (1840 to 1900) north of the Vaal River have past.
Most of the circular structures are also associated with activity areas where processes were
practiced and had to be accommodated either indoors, outdoors or in some kind of sheltered
space. However, this paper merely explores the occurrence of the various activity areas, buildings
and structures that have a circular origin, those that were practiced in a circular action or that
were constructed using the circle as basic form.
Motivation for the study
This study forms part of an investigation into the history and origins of the rondavel as a typical
form type in the history of both vernacular architecture and folk engineering in the northern part
of South Africa (the study does not cover the entire South Africa as the area is too vast). Most
of the examples mentioned and investigated are located in the northern part of South Africa.
The investigation into the origins and continuous use of the rondavel form type cannot be
considered to be merely a simple sequential timeline from some prototype that originated at a
particular geographic point, expanded around the globe and then continued into the 21st century.
One of the key questions remains why the circle is selected as suitable spatial form solution to
create floor plans for residential units as the rectangle and square have already proved to be a
practical solution.
The viewpoint of this paper is that the occurrence of the circle as a spatial design solution
to accommodate activities of a circular nature is logic and the applicability and practicality
of circular structures as containers have proved their validity as architectural and engineering
solutions.
It seems as if the circular floor plan has become commonly associated with the architecture
of the local and indigenous black people while the rectangular floor plan became associated
with the vernacular and designed architecture of Europeans. Closer scrutiny of the early rural
vernacular architecture and even later architecture on farmsteads in the region north of the Vaal
River suggests that both forms were rather common. Even though the circular form seems to
be impractical - at first glance - it has survived and even became a common solution solving
2

certain spatial problems in the architecture usually associated with farm architecture (not as an
engineering solution though).
The search for the origins of the circular floor plan and in particular the history of the
rondavel typology of the cone on cylinder inevitably resulted in a search for other buildings
and structures with a circular or similar (related) floor plan and this is the principal motivation
for this article. The preliminary investigation into the occurrence of the circle in the vernacular
architecture and early smaller folk structures in mostly rural traditions (especially farm building)
resulting in a division between buildings and structures; buildings being works with roofs and
structures being mostly engineering related construction works (those works without a roof).
A study of early farm engineering works has not been done to date and this study is also
not focused on this type of investigation. The creation of a category such as ‘vernacular’ farm
engineering is merely incidental, though essential for the discourse. This study is aimed at
determining some tradition or patterns in the typologies of floor plan types that can be associated
or classified as vernacular building types, form types or functional types.
Buildings and structures
Four broad categories of manmade spaces and construction works occur on farmsteads in order
to serve the needs of the productive farmer: (a) ‘buildings’ for the protection of people, produce
and equipment; (b)‘structures’ for manufacturing processes and utilitarian uses such as storage
and manufacturing; (c ) ‘infra structural elements’ and (d) ‘activity areas’. For the use of this
paper and logic of the discourse, the sequence is altered, starting with activity areas.
Circular construction
It is assumed that circular buildings and structures are the result of a very logical process based on
activities with a circular motion. This is only partially true for the construction of the vernacular
circular buildings on farms. This would have been a scientific approach to the erection of these
structures but in the early rural Transvaal, farmers were neither exposed to the disciplines and
domains of the agricultural sciences nor to civil engineering until the first agricultural colleges
were established. The thoughts generated and promoted at these institutions only reached the
farming community after the results of their research and experimentation were published – first
in scientific reports and later popularized in several agricultural journals.
It is uncertain what the impact of early agricultural publications such as Farming in South
Africa, Hulpboek vir Boere, Farmers Weekly and Landbou Weekblad had in promoting the
construction of circular buildings and structures. These publications were established between
1915 and 1920 – prior to the great depression. It can only be assumed that the recommendations
and suggestions indicated and set forward in the articles by professional individuals who were
linked to the various agricultural colleges and universities were not ignored by young and
dynamic farmers who wanted to expand their farming activities and profits by reassessment of
their farming paradigms and methods using contemporary and tested technology. It can also
be assumed that the circular buildings and structures already existed prior to the existence of
the publications. The information in the publications only confirmed and defined the potential
of and parameters for circular structures such as larger dams, water reservoirs and silos. Later
editions of these publications were also instrumental in the introduction of circular prefabricated
containers and the use of prefabricated materials such as corrugated iron that could be used for
the construction of large circular structures.
3

The functionality of the circular floor plan for any human activity reflects the presence
of some paradox. Most large circular activities on a farm occur and are practiced outside a
building. This leaves other activities such as storage and dwellings as spatial activities to be
defined within the circular confines of walls – such as silos and rondavels.
In terms of storage of fodder the circular building becomes a cylindrical storage facility. The
outward pressure on the walls increase as the cylinder is filled. This is where the circle becomes
very efficient as the pressure is distributed equally onto all the sides. The same principle is true
for using the cylindrical shape as a water reservoir.
In terms of the rondavel no such logic exists. Furniture is designed and constructed
according to fit the cube form and does not relate or fit smoothly into a circular or cylindrical
building. In this sense the rondavel is impractical and irrational.
The first motivation for the erection of a circular or cylindrical building would relate
directly to any circular activity that had to be executed within a defined and confined space,
some even indoors. When assessing the circular buildings on farmsteads it is found that few
activities inside circular buildings are of a circular nature and so are the furniture used in these
buildings.
Another circular building type that became common during the Anglo-Boer War was the
small circular fort. The logic of applying the circle is based on the 360 degree visibility along
the entire horizon. However, these buildings were not erected on farms and can therefore not be
considered part of the vernacular farm building typologies.
Activity areas
Identifying activities that are based on circular actions seems to be the most logical point of
departure when investigating the occurrence of circular buildings and structures. Few of these
activities can still be found on contemporary commercial farms. However, on farms where
traditional activities were practised or where activities were executed with manual labour, the
occurrence of areas of a circular shape is quite common. In this case activity areas relate to the
work place and the circular character of the floor or production area.
Wagon-builders smithy
Prior to prefabrication and mass production of iron products, later considered essential on a
farm and critical in the construction and maintenance of a wagon, blacksmith work was done by
the farmer and his workers. This activity was usually located near the waenhuis or sheds where
the farmer kept all vehicles. Smithing was done either on the ground but often a small hearth
was constructed (elevated area of about 600-700 mm high) on which a fire could be kindled.
The height of such a structure (hearth) was determined by the blacksmith as it served as a work
surface. Blacksmithing included the manufacturing of a variety of homemade tools and objects
that could be used in buildings (such as hinges, locks and window stays) and the construction
and maintenance of wagons and agricultural implements.
Compared to the area where general iron work is done on a farm, the shortening of wagon
tires had to be done outside a formal smithy (the building in which the hearth is located and
where the tools are stored). The area where wagon tires were finally laid over an existing (old)
or a new wheel (wooden structure) was done outside where the wheel was bolted to a rim and
mounted in the ground. To ensure that the work area was slightly elevated from the ground, it
was sometimes constructed with stone forming a small circular paved area (figure 1).
4

Figure 1
Circular paved stone area where a hot iron tire is placed over the wooden rim of a wagon wheel
(photograph: M. Naudé).
Threshing floor
Threshing of wheat is an old farming activity and the oldest example of a threshing floor being
preserved in South Africa is located directly adjacent to Mostert’s Mill in Mowbray, Cape Town
(figure 21). 1 Threshing floors and mills used to be constructed adjacent to each other as the one
activity merely precedes the other in the process of refining wheat to an edible product.
Figure 2
Reconstructed threshing floor at the Pioneer Museum site in Silverton, Pretoria
(photograph: M. Naudé).
Threshing floors used to be common on farms in regions where wheat farming is common. A
circular area was cleared of grass and bushes; the surface leveled, moistened and compacted
until it was hard enough for animals to walk on without destroying the surface. In its most
simple form it is an open-air activity that is practised during a certain time of the year (figure
2).
According to Küsel, 2 the threshing floor on the farm Lakenvlei (Belfast district, Mpumalanga
Province) is the best preserved example of such a structure in the entire region (formerly known
as the Transvaal). The farmstead has been redundant for more than 12 years and the buildings
and structures have slowly disintegrated due to vandalisation and loss of materials eventually
leading to structural failure of the buildings. 3
5

This is another typical folk activity that can only be defined as an activity area and not as a
‘structure’ as it consists of very little construction work. It is a clear example of an activity area
where ‘form follows function’ as threshing was done by training horses or donkeys to trample
over cut wheat along a circular trajectory. The circular shape of the structure is a direct result
of the movement of the animals. Horses are held together with a leash by a person in the centre
of the floor (or circle) while the animals move around him. Wheat is thrown on the hardened
surface and the hooves of the animals trample the thick layer of stems in order to separate the
grain from the chaff. However, in some parts of the country, threshing was also done indoors
and sites have been recorded in the northwestern part of the Northern Cape by researchers of the
National Cultural History Museum (now: Ditsong: National Museum of Cultural History). 4
Kneading thongs
In this case the activity of kneading thongs (Afrikaans: ‘riemebrei’) according to historic tradition
has no relation to any structure or architectural element but is merely an open air activity that
normally takes place under a tree. It is not a permanent activity and can be considered a dying
folk tradition.
In most cases the kneading of thongs using this method does not need the construction of
any structure as the thongs are merely suspended from a mature tree branch with a weight tied
to the bottom end of the bundle of raw thongs.
A pole is pushed in between the thongs and a winding action is started by a person walking
around the central axis. When tightly wound, the pole is pulled out and the thongs unwound
themselves. Due to the continuous circular strolling of the operator a large area with a circular
shape becomes visible.
Figure 3
Informal circular activity area created by the kneading of thongs – turning them around continuously
(photograph: M. Naudé).
Circular structures
Structures are usually those construction works that have no roof and could have been constructed
as an activity area or a storage facility. Usually these structures were erected to accommodate a
production process and as storage facility. In the case of the latter function the walls or sides of
the structure play a significant part in containing physical forces relating directly to the kind of
storage it was built for such as water or fodder.
6

Lime kilns
Lime kilns are also known to be circular in shape but even though little is known about the first
and oldest lime kilns in South Africa, an example of such a kiln was proclaimed a National
Monument (now referred to as a Provincial Heritage Site) in 1980. Two kilns are located on the
farms De la Rey and Jacobskraal, about 5 km outside the town of Yzerfontein (along the Cape
West Coast) (figure 4).
They are about 2.5 m high and were stacked with mussel shells and wood. A fire would be
made at the lower compartment of the kiln while the shells are placed on top of the wood. Air
was forced through the oven using billows. The final product would be ‘quicklime’ that was
collected from a pit at the bottom of the kiln. 5 This is a well-constructed structure and seems not
to be of a temporary type.
Figure 4
Lime kiln near Yzerfontein in the Western Cape Province where lime was manufactured from shells
(photograph: www.yserfontein.info/history/lime_kilns.html).
Detached outdoor oven
Figure 5
Low circular outdoor bake oven in the Waterberg
(photograph: Ditsong: National Museum of Cultural History, Pretoria).
Only in exceptional cases, an outdoor oven will have a circular floor plan but during the
pioneering years and especially while on trek, large ant heaps were used as (‘ready-made’)
bake ovens. Technically, it is not a manmade structure but merely the result of the ingenuity of
7

someone who exploited the latent potential of an ant heap that has become useless and offered
an appropriate void for this purpose. The ant heap only had to be cleared from the inside, a front
entrance and back draught-hole had to be created and the oven was ready to be used.
Research in the Waterberg has revealed evidence of a simple outdoor bake oven that was
constructed in a circular form in almost the same size and shape of an ant heap.
However, there is little relation between the outdoor oven and the development of the
rondavel. Hearths and fireplaces do not normally occur in rondavels and were not added to the
exterior walls. The development of the outdoor bake oven is closely associated to the occurrence
of the outdoor cooking area and the outdoor or detached kitchen – more often the semi-open
cooking screen.
Cooking screens
The cooking screen (Afrikaans: ‘kookskerm’) has become associated with the arid and semiarid
regions of South Africa. It is assumed that the cooking screen originated during the years
when people lived a relative nomadic lifestyle and food was prepared on an open fire on the
ground. A kitchen could not be located inside the tent or the ‘matjieshuis’ (reed hut) as these
semi-permanent abodes were too small. When a more permanent dwelling was erected, it was
either too small and the ‘kookskerm’ was preferably detached from the dwelling in fear that
sparks from the fire may light the thatch roofs or would add more heat to the interior of the
dwelling. The best solution was to keep the fire outside and create a small but functional facility
that could operate firstly as a detached kitchen but also as an informal place to socialize. 6
As a farmer would settle at his base or principal farm (Afrikaans: ‘blyplaas’), the ‘kookskerm’
remained a functional and practical solution for preparing food. These first dwellings remained
small and served only in the basic needs for privacy and accommodating the family’s essential
spatial needs for sleeping rather than serving other needs such as a bathroom, kitchen and toilet.
Whether the decision to retain this structure was the result of economic reasons (cheaper to
exclude such a luxury from the dwelling) is unlikely and tradition (a difficult habit to break)
may have been a more appropriate explanation. 7
It was located a short distance (within 30 m) from the dwelling and operated as an ‘instant’,
outdoor or detached kitchen. The ‘kookskerm’ is a circular or oval-shaped structure with a
single entrance, usually facing away from the direction of the prevailing winds, irrespective of
the location of the back door of the dwelling. Even in these circumstances and in such an almost
desolate natural landscape the dwelling had a front and back façade with the ‘kookskerm’ being
located in the backyard.
In regions where this structure is common, rain is an almost incidental occurrence and
an open fire in an area where food was prepared had almost no possibility to be washed out.
Direct sunlight, heat and wind were the only possible hazards to cope with when preparing
food outdoors8 . No real need for moving food preparation into the dwelling existed and secured
the survival of this household outdoor activity. Therefore, it remained an outdoor activity. It is
inevitable that when food was prepared on an open fire outside the dwelling that the longer the
same setting is used, some refinement to such an important activity area will result in several
changes and led to the introduction of appropriate additions that would at least protect the fire
against prevailing winds. 9
The standard way of preparing food was on an open fire in three-legged and flat base iron
pots. To retain a consistent source of heat, the flames had to be protected against winds and
breezes. The ‘kookskerm’ was erected mainly for this purpose – to keep the wind out. For the
same reason these screens were not high enclosed spaces and in some cases they were merely
8

etween 500 mm to 1 m high. However, the screen erected around this household activity also
had other purposes such as defining the space as if it was a separate annex to the dwelling. Often
the space included an outdoor bake oven, sometimes even more than one. Food preparation
consists of more than just leaving food on the fire or bread inside the oven. Additional space
had to be provided for the pre-preparation of some dishes while one or more individuals had
to tend to the fire, stirring and mixing food. The space had to be large enough to accommodate
one or more seats, a table to work on or even small wooden boxes in which kitchen utensils and
porcelain could be kept. Iron hooks and pokers were used to manipulate the fire and baking pans
inside the oven and ample working space had to be created inside the screen for this activity
without falling or tripping over the fire, hitting furniture or cooking utensils. 10
Figure 6
Circular cooking screen with low surrounding wall and a roof constructed with timber laths and patches
of roughly thatched vegetation, in front of a small rectangular dwelling
(photograph: Macdonald, W. 1913. The conquest of the desert, figure 2).
Figure 7
Field-cornet Snyman’s house in the Roggeveld, ca. 1810 with rondavel-type outbuilding (in the centre) that
probably served as a detached kitchen cum cooking screen
(drawing: Burchell’s Travels).
In some cases the cooking screen had a thatched or roughly covered roof supported by timber
poles suggesting the form of a primitive rondavel.
Wells
Wells are usually circular shafts excavated to reach fresh water. They seldom have rectangular
sides and to prevent the sides from caving in they need to be lined with stone, often smeared
with a layer of cement plastering. In areas where artesian water sources exist, such as the drier
parts of the country like the Kalahari and Namakwaland, the walls of these wells are lined with
chunks of calcrete without plastering. Examples of these wells occur along the Auob River in
9

the Northern Cape (Kalahari region). Here the water was scooped out of the well by allowing a
person to enter the well and lifting water from the water source with a bucket. Water was then
poured into a trough where animals would gather for drinking. The fresh water was protected by
a stone wall often an extension for the stone lining of the shaft inside. A small opening was left
into the surrounding wall to allow the person scooping the water to enter the well using stone
steps into the water.
Of particular interest is that the stone walling around the wells were not only constructed as
a lining to prevent the walls from caving inwards, but projected above the surrounding ground
surface in order to prevent animals and humans to fall into the well. An opening in this low
wall defined the entrance towards primitive steps constructed by large stone boulders. They
made it possible for the herder to enter into the well cavity. Poles were planted at the sides of
the entrance and a makeshift gate had to be opened before entering. The type of construction
relates to that of the rondavel but is different in that it is mostly subterranean (and more of a
makeshift nature).
The well on the farm Hartebeestpoort (Pretoria) is covered with a square timber structure
to prevent children and animals from falling in but has retained its circular shaft underneath the
timber structure. Winding of water with a bucket on a rope is also done from such a platform,
as the winder is mounted to this rectangular floor or ‘cap’. On the farm Kaalfontein (Rayton
district - Gauteng) the circular character of the well is exposed as the water is extracted with a
‘bakkies-pump’ that is fitted in the centre of the open shaft. The pump is driven by a donkey that
strolls around the structure and then drives the pump, hoisting water by way of a ‘chain’ with
tens of small scoops (Afrikaans: ‘bakkies’) mounted to the chain.
Figure 8
Circular well in the Kalahari, the retaining walls and small steps leading to the water, constructed with
chunks of calcrete (photograph: Ditsong: National Museum of Cultural History).
Dipping tanks
Dipping tanks on commercial farms are associated with cattle dipping and the structures
associated with this activity are elongated rectangles and not circular. Circular dipping tanks
were used for dipping stock and pigs (figure 10).
A unique aspect of these dipping tanks was the use of sandstone blocks that were shaped
(into a curve) to fit the circular shape of the final structure. More often, stone used for the
construction of a circular building was merely positioned in such a way that they fit the circular
10

floor plan using the building mortar to fill the triangular gap created by swiveling the square or
rectangular blocks to create a circular structure. In the case of rondavels, slabs or large bars of
stone (used for lintels and window sills) were shaped to fit the circular shape of the exterior of
the building and not the interior.
Figure 9
‘Bakkies pomp’ installed inside a well-type structure and operated by an animal strolling around a central
pivot (photograph: M. Naudé).
Figure 10
Sheep dip on the farm Berseba in the Steynsburg district northeastern Cape
(photograph: M. Naudé).
Dams and drinking troughs
The simplest dams constructed as reservoirs for cattle or stock farming are mere shallow dips in
the ground that have been covered with a layer of cement, which is periodically filled with water
from a well or pump. Examples of this type of ‘trough’ occur in the Kalahari and the remains
of some have been retained by SANParks in the Kgalakgadi National Park, when animals had
to drink water from the nearby well or pump that supplied water for reservoir. Due to the low
gradient of the slope of this structure, animals can walk into the water and drink without any
danger of drowning, slipping, getting stuck or causing damage to themselves. 11
Although dams or water reservoirs tend to be of any shape, the circular shape is the most
common. The shape is a direct result of the logic underlying its use as dams, in terms of the
11

outwards pressure (pushing forces) of water inside the dam. Dams are containers and need to
be designed with this in mind, especially as the quantity of the contents may change over time
depending on the seasonal drought conditions and level of the water, resulting in the altered
pressure on the walls. Dams can only be categorized as engineering structures.
Circular dams or reservoirs may occur in different sizes: from small drinking troughs to
large reservoirs with a diameter of 15 m (figure 11).
Figure 11
Small drinking trough for sheep on the farm Berseba (Steynsburg district) northeastern Cape
(photograph: M. Naudé). 12
Quite a unique structure not usually found or described in academic publications covering
vernacular engineering works, is the water furrow distributor dam (figure. 12). Water is brought
to the farmstead with a single wide furrow. Water then had to be distributed to other furrows
serving several areas such as orchards and gardens. The distributor dam is circular in shape and
consists of a central inlet furrow with several outlets depending where the water is needed for
irrigation. These distributor dams may have a hardened clay floor or may be constructed with
stone and lined with a cement floor.
Water is let through the appropriate sluice by lifting the small sliding sluice gate. They
were made of sheets of galvanized iron (often a flattened sheet of corrugated iron).
Figure 12
Circular ‘distributor’ dam where water from the principal water furrow is distributed into several
secondary furrows – Lydenburg district, Mpumalanga Province
(photograph: M. Naudé).
12

Kraals
The construction of circular ‘takkrale’ (a kraal constructed with branches) by the indigenous
peoples of South Africa is quite common and they can still be seen in the rural areas where
cattle farming are practiced (and ample wood is available). However, cattle or stock kraals have
been replaced with more formal gum-pole constructed structures.
The kraal at Donkerhoek (east of Pretoria) was constructed with sandstone and a sandand-lime
mortar with a thin topping of the same material along the top of the entire wall. This
prevented the top layer of stones to ‘open-up’ and break apart. It has an exceptionally wide
entrance – not common for a stock kraal.
Figure 13
Circular stock kraal in the Donkerhoek area (east of Pretoria). The wall is approximately 1,2 m high and
constructed with chunks of sandstone collected along the slopes of the surrounding ridge
(photograph: M. Naudé).
Most of these kraals suffer from the same symptoms of structural decay as other open circular
structures - they tend to widen at the top and cracks and structural problems occur along the
higher portions of the wall.
Wolwehokke
‘Wolwehokke’ (‘hyena traps’) are not common structures north of the Vaal River but was quite
common in the Karoo. The ‘wolwehok’ was designed to attract the ‘wolf’ or hyena into a
stone constructed structure by setting a trap with chunks of meat inside. It is also referred to
as a ‘wolwehuisie’ but this building has no association with ‘housing’ or with the ‘protection’
of animals or humans. It was normally constructed from stone 13 and used as a device to catch
nocturnal animals perceived to be predators such as jackal, aardwolf and other smaller species.
The animal was lured into the building and the trapdoor would be triggered as soon the bait
inside is moved or removed from its hook. The farmer would visit the site in the morning and
shoot the trapped animal through a hole at the top of the structure. 14
One of these structures was reconstructed by the former National Parks Board staff in
the Karoo National Park near Beaufort West. Another example was proclaimed a Provincial
Heritage Site in the Graaff-Reinet district.
13

Figure 14
A reconstructed ‘wolwehok’ with (vertical) sliding slate door and open at the top, in the Karoo National
Park (Beaufort West) (photograph: Ditsong: National Museum of Cultural History, Pretoria).
Pen or small kraal
In terms of structures dating to the Iron Age, small circular structures (without roofs) are easy
to identify and classify. Small circular structures with a diameter ranging from 2,5 to 4 m
without any entrances or openings in the walls are not uncommon occurrences in Early and
Later Iron Age sites. It has also been mentioned that some may have served as a foundation for
a granary. Granaries are usually elevated above the ground in order to insulate the floor from the
possibility of direct infestation by insects. The foundation would consist of a circular structure
constructed with stone with or without mortar. A significant aspect of these structures would be
that it forms a complete circle with no entrance or break in the circular walling. Timber beams
would be laid on top to form the floor and the remaining wall structure would consist of a timber
structure filled in with horizontal and vertical laths – sometimes also plastered with clay on the
interior and exterior. However, the same structure could be constructed without the circular
stone walling as the corner posts could have been planted directly into the ground and the floor
mounted at an elevated position above the ground. 15
Figure 15
Small pen on the farm Vaalekrans in the Steynsburg district, northeastern Cape (photograph: M. Naudé).
On historical sites these small circular structures are not that easy to contextualise. They are
often too small to be classified as a kraal and seldom have any traces of a roof structure. The
14

walls of these structures may either be plumb or are tapered towards the inside. Fieldwork has
not yet clearly secured a function for these structures other than keeping either small animals
or for keeping a small number of animals for a special reason. Young lambs, calves or pigs
(pigsties tend to be rectangular) were kept inside small circular structures. These structures may
have had well defined entrances with gates or in some cases had no entrance. 16
These are also not the remains of rondavels as rondavels tend to have larger diameters
and have been constructed with walls that are designed to be load bearing. In cases where the
rondavel roof has completely disappeared but the walls have remained intact, the top of the wall
has been refined by finishing it off with a final set of level stone layers in order to accommodate
the roof structure.
Still and fermentation tanks
Small fermentation tanks or subterranean pits serving various purposes were often constructed
on farms. If the farmer was a keen stiller of mampoer or witblits (moonshine), these pits were
either constructed with plastered brick walls or any other prefabricated containers. Otherwise,
pits were constructed by excavating holes in the ground and plastering the interior surfaces
with a layer or wash mixture of sand and lime. Subterranean pits were used for curing hides by
filling the pit with water and wattle or blue-gum (eucalyptus) tree bark. They were also used to
ferment fruit prior to the stilling process.
The still had to be heated from underneath as heat was an important element in the stilling
process. Surrounding the copper still with a layer of sundried bricks and wet clay would ensure
retaining of the heat inside. The makeshift clay brick solution was not a permanent structure and
had to be rebuilt after the stilling season.
Figure 16
Still located inside a circular makeshift brick structure with circular fermentation pits at the back – in
the Waterberg region, Limpopo Province (photograph: Ditsong: National Museum of Cultural History,
Pretoria).
These structures have little load bearing capabilities. In the case of the still the clay and brick
walling are removed when the still is cleaned and the fermentation pits only contain small
quantities of fruit.
15

Water reservoirs
Water reservoirs are small water containers usually located near the dwelling and as in the case
of the example on Hattingskraal (Winburg district in the Free Sate Province) (figure 17), placed
underneath the spout of the downpipe draining water from the roof of the building. In this case
the reservoir was constructed with bricks, plastered and whitewashed. Today it is more common
to find prefabricated galvanized iron tanks serving the same purpose.
Figure 17
Water reservoir constructed at the corner of the building to collect water draining from the roof - farm
Hattingskraal in the district of Winburg, Free State Province (photograph: M. Naudé).
Other water reservoirs were constructed in the same way as a dam wall of plastered brick
but projecting higher into the air. In the case of the example in the Kruger National Park, the
problems of mechanical or penetrating damp damage to the lower section of such a reservoir are
countered by buttressing the lower part with another wall either of brick but usually with stone
masonry. To prevent dust or any other material to end up in the water the top of the reservoir
was covered with a conical roof of galvanized sheet iron.
Figure 18
Small circular water reservoir with buttressed stone masonry wall around it in Skukuza, ca. 1932
(photograph: Pienaar, U. de V. 1990. Neem uit die verlede, p. 483).
16

Circular buildings
The circle as a spatial solution (and shape) for residential and storage needs is well-known
in the vernacular architecture of the local indigenous peoples in South Africa and among
traditional societies elsewhere in the world. It is a form type that occurs in all climatic and
botanical regions. It is even used as an architectural form by people such as the Eskimos. For
this reason the circular floor plan must be included into the typology of prototypes generally
used in vernacular architecture all over the world. It is used as both a temporary and permanent
solution for habitation, working and storage purposes.
Whether the circular prototype was identified and classified as a typical part of the South
African architectural vocabulary is not very clear. In terms of the various typologies that exist
among the local indigenous groups of South Africa it has been defined and accepted but it
seems to have been excluded from the vernacular architectural vocabulary of European or white
architectural history. In cases where South African or regional architecture was presented or
displayed the rectangle remained the prime prototype for representing early white vernacular
architecture and the circular floor plan typology was considered typical of indigenous black
vernacular architecture.
Gazebos
Gazebos usually consist of a roof supported by timber columns but with the sides either left
open or partially closed. Therefore it operates as a constructed ‘umbrella’ and shelter rather than
a formal building with a proper foundation and closed walls.
This building type not only occurs in the gardens of farmsteads or suburban properties but
also on farms and more official exclusive areas such as the Kruger National Park. Its function
is to protect people from the sun while allowing free movement of humans and breezes through
the created covered space underneath.
No research has been done on the occurrence of this building type in the vernacular
architecture in the northern part of South Africa. This may be because the building type is of
little architectural significance except when considered in some historical or cultural historical
context. In structure and form the gazebo has the same characteristics as the rondavel with
the exception that the sides were left open or were merely screened off with reeds or diagonal
cross slats. This allows the building to serve its purpose as a place of leisure and enjoyment of
a garden or as a private folk-type clubhouse next to a swimming pool, tennis court, or croquet
lawn. Gazebos were either square, rectangular or had a rondavel shape.
Figure 19
Reconstructed garden gazebo on the farm Zwartkoppies outside Pretoria
(photograph: M. Naudé).
17

Another popular gazebo type occurs in the Kruger National Park and this type is still erected in
other national parks as well. The thatched rondavel roof allows ample shelter to any number of
people and can be maintained and replaced using the local grass available. The building type is
also aesthetically sympathetic to the bush landscape and tends to disappear among the bushes
of the Lowveld and Bushveld.
Figure 20
Large open sided gazebo at the Pafuri tourist picnic area in the Kruger National Park
(photograph: M. Naudé).
Mills
Jan van Riebeeck had to provide most of the basic services during the early years at the Cape
including the grinding of wheat. For this reason, a so-called horse-mill was built. As they had no
horses the mill was worked by oxen. However, when the Khoi people stole all the oxen in 1659,
the miller, assisted by the Government, had to erect a wind driven mill. In the following century
several wind driven mills were erected, some of these were privately owned and Mostert’s Mill
in Mowbray (Cape Town) is the last remaining example of these. 17 This mill is of the type known
in the Netherlands as a ‘bovenkruier’ or ‘over-shot’ wheat mill. 18 Even though this building type
and associated engineering have proved to be successful over decades in the Netherlands, it did
not survive in South Africa and the tradition disappeared.
The entire tradition for wind powered mills was altered by the minimalist construction
of galvanized iron water mill structures. However, these mills were never exploited for the
generation of power to drive wheat mills.
It is constructed in the Dutch tradition of mill typologies and has a circular footprint.
According to Doreen Greig, Mostert’s Mill was built (ca. 1796) by Gysbert van Reenen, the
same man who erected the original house on the farm Welgelegen in 1757. Mosterts Mill and
the adjacent threshing floor were proclaimed a National Monument (now a Provincial Heritage
Site) in 1940. 19 This merely serves as evidence that some circular floor plans is not unique to
Africa or South Africa but originates from a typology that has its roots in Europe. It was not
the only mill with a wind driven milling machine in the Cape at the time but the only mill of
its kind that remained in the Boland. This building tradition never continued into the interior of
the country.
One of the smallest milling machines created for grinding purposes is the Norse Mill.
It is a small machine with a horizontal flywheel driven by the movement of water flowing
underneath the machine and the building. Flywheels may have diameter of between 1.5 m and
2.3 m. However, it is not the shape of the flywheel that determined the shape of the building
18

in which it was housed as the top part of the milling machine was usually square. These mills
could therefore be accommodated in a rectangular or a circular building.
Figure 21
Mostert’s Mill in Mowbray Cape Town. A circular threshing floor was reconstructed at the back, adjacent
to the mill (source: Oberholster 1972: 42).
Figure 22
Exploded drawing of a Norse Mill (machine) and all its parts indicating the use of the horizontal flywheel
(drawing: Ditsong: National Museum of Cultural History, Pretoria).
Figure 23
Lozenge-shaped building housing a Norse Mill on the farm Kaalfontein in the Cullinan district
(photograph: M. Naudé).
19

Silos
Silos are storage facilities and their shape does not necessarily have to be circular or cylindrical.
This is a relatively late development of the circular floor plan as it became a common phenomenon
on farms in the 20 th century when farmers learnt that they could collect fodder for winters and
could use this building cum container for this purpose. Silos seldom had roofs but the walls
had to be strong enough to contain the pressure of the fodder content inside. Silos are partly
subterranean with only the top two-thirds projecting above the ground. As the farmer’s needs
expanded a second silo was erected or the walls of an existing silo was merely added on top
Figure 24
Two redundant grain silos on the farm Zwartkoppies east of Pretoria. One of them was enlarged by
adding to the top. The second silo (right) was constructed using corrugated iron sheets as shuttering
(photograph: M. Naudé).
Figure 25
Ruins of two silos on the farm Garstfontein - Pretoria (photograph: M. Naudé).
Corrugated iron or sheet iron silos have been used for a long time by riveting, bolting and
welding flat sheets together to form a cylindrically-shaped container. The wall thickness depends
as much on the requirements to resist vertical forces and the effect of wind on an empty silo
as on the need to withstand the horizontal pressure of the fodder on the walls – from inside.
The solution is the use of corrugated iron but with the fluting running horizontally which is
stiff enough to resist wind forces. Such a silo also needs to be supported by vertical columns
spaced around the silo wall to resist the vertical (outward) forces. The result of such a structure
would be one of the most slender structures known to man with a slenderness ratio (ratio of the
biggest dimension (diameter or height) to the smallest [thickness]) that can reach as much as
20 000). 20
20

After becoming redundant, they are often covered with a roof and used as accommodation
as they normally have a diameter of about 5 m to 7 m, making them spacious enough to be used
as a residential unit.
Worker’s dwellings
One of the most common methods to identify and define a particular form type in a typology
is to trace a contemporary example back to its origin, but often these lines supposedly leading
towards the original archetype tend to become vague and eventually stop abruptly or disappear
into another form type. It is not the focus of this paper to do such a tracing exercise but the links
between the vernacular circular huts of indigenous peoples cannot be ignored as one of these
avenues towards a local origin.
The occurrence of the circular floor plan among the indigenous peoples of South and
southern Africa is well recorded as these people still use the circular floor plan today. They have
used it in the period prior to Europeans entering into South Africa and the building typology can
be traced back to the Iron Age and Late Stone Age.
However, tracing the origins of the rondavel on the farmsteads of European farmers has not
been done in such detail and this form type has not been investigated either by archaeologists or
architectural historians to the same extent as the occurrence of this form type among indigenous
peoples.
The cone on cylinder hut or rondavel has a documented history and some of the earlier
prototypes of the cone on cylinder still occur concurrently on farmsteads or in more traditional
villages. The circular floor plan has been replaced by the square and rectangle on farms where
black workers reside on a permanent basis. However, in some areas this change towards the
rectangle has not been completed and the circular floor plan is still used.
One of the first conclusions and perhaps most logical deductions, in terms of the origins of
the rondavel as a spatial solution for accommodation among white settlers, may be to consider
that the application of the circular floor plan was through acculturation as farm workers were
responsible for the construction of these circular buildings for their European ‘masters’.
Figure 26
Diagram indicating various basic hut types associated with sheltering by indigenous peoples (drawing: M.
Naudé - adapted from F. Frescura).
Grass mat dome structures of the Northwest and Namakwaland.
A well-known phenomenon in the region known as the Noordweste or Northwest and surrounding
regions such as the Hantam, Gordonia, the Kalahari, and Namakwaland, is the occurrence of
21

the circular domed dwellings of both the indigenous residents and later also the white settlers.
A dwelling type commonly referred to as the ‘grasmathuis’ or grass mat dwelling. In essence
this is a temporary dwelling type with no architectural elements secured on a foundation or
permanent structure linking the superstructure to the ground or to any subterranean base to
indicate any hint of permanence. They also have a simple floor plan: circular in shape with only
a single interior space – no subdivisions into several secondary or supporting rooms.
However, the key aspect is this building’s circular floor plan, its size and mobile structure.
It cannot be defined as a residence, neither as a house in terms of permanence or its size but still
served the purposes of its owners in most of their needs for shelter in terms of its transportability
and easy construction. Due to the material it was constructed from, it also had the ability to
counter the harsh climatic conditions of the regions where they were commonly used. The
existing surface of the ground or a hardened clay surface served as floor and the super structure
defined both the walls and roof. As the frame was covered with woven grass mats the material
allowed air to flow through the matting. It was cool during the day and protected its inhabitants
during the night. It had no need for windows and had only a single door (or merely an opening)
used as an entrance (and exit) and covered by a grass mat that was rolled up or down during
the day.
As a structure constructed with completely organic materials it would not have served its
purpose in areas that were more humid but in these areas (mentioned above) with almost no
rainfall during an average year, owners had no fear regarding building materials that would rot
and had to be replaced often.
Figure 27
Large dome-shaped timber frame hut covered with grass matting in the Namakwaland region
(photograph: Ditsong: National Museum of Cultural History, Pretoria).
Corbelled huts
A unique dwelling type in the drier parts of the former Cape Province is the corbel hut (Afrikaans:
‘korbeelhuis’). On many farms in the Carnavon Williston area corbelled huts also referred to
as ‘klip-rondawels’ (stone rondavels) are found. 21 This is the closest relative to the rondavel
hut type as it also has a circular floor plan, vertical walls to a certain height but the construction
of the roof differs completely from the roof types associated with the rondavel. Walls often
760 mm thick were built to a height of approximately 2 m before the next layers were slightly
tapered towards the top. Successive courses of flat stones were laid, overlapping inwards until it
was closed at the top with a large single flat slab. 22 The roof is merely an extension of the walls.
22

The roof structure is of a more complicated design as it was constructed exclusively from stone
and tapered into a conical dome towards the top and the centre of the building.
A major difference when compared with the rondavel is the exclusive use of stone for the
construction of the entire corbelled hut - the walls and roof form a single structure. According
to Maguire who has been extensively involved in the identification and mapping of corbelled
dwellings:
Stone for corbelled structures appears to have an optimum dimensional format, that is slabs that are approximately
3:1 in their length to width ration, but the size and shape of rock used in their construction is still being researched
as is the precise manner of their packing. Packing technique is easy to see in corbelled huts which have collapsed
due to structural failure. The reasons for such failure are also being studied. At this stage, it is possible to say that
blocks which are too square create structures which are unstable’. 23
Figure 28
Corbelled dwelling in Namakwaland (photograph: Ditsong: National Museum of Cultural History,
Pretoria).
Rondavels
Rondavels form the core of the investigation and as mentioned in the introduction, this article
merely highlights the occurrence of the circle as a spatial solution – one aspect of the investigation
into the origins and history of the rondavel. For this reason, rondavels will not be analysed in
detail in this article. Some general observations need to be highlighted though.
Rondavels remain significant vernacular building types in the entire classification and
variety of form types of vernacular farm architecture. In terms of farmyard layout and spatial
arrangement, rondavels can be clustered into two broad categories: (a) as separate buildings (or
annexes) to the main residence and (b) as form type defining or included into the floor plan and
spatial solution scheme of the main residence.
Where rondavels occur as annexes to the main farm residence they were used as a detached
kitchen, a milk room (where milk is separated), a meat room (where meat is prepared after
slaughtering of an animal), additional accommodation (sleeping facilities for visiting guests or
as detached rooms for the teenage boys) or as additional work space (either for the farmer – as
an office or for the housewife). Currently, rondavels are often used as space where farm workers
are trained or where housewives assist in the administration of the farming activities.
The occurrence of rondavel houses or rectangular dwellings with a single or more than one
rondavel (or circular room) attached to it is not the rule of thumb for early European vernacular
architecture but many examples exist – to the point that it can be considered as a significant
form type in the vernacular architecture of several regions.
23

Figure 29
Small rondavel constructed with blocks of dolerite and sandstone quoining around the window and as
window sill (photograph: Ditsong: National Museum of Cultural History, Pretoria).
In some cases circular dwellings and structures were designed, manufactured and marketed
as kits allowing farmers to order such a structure from a catalogue. Galvanised corrugated
iron is a popular material for these structures. Water reservoirs, containers such as silos and
even residential units such as rondavels were manufactured with this material and bought by
farmers and especially building or other contractors, either as housing, site offices or as storage
spaces.
Figure 30
Prefabricated rondavel constructed from corrugated iron on the farm Zwartkoppies, Pretoria
(photograph: M. Naudé).
Rondavel dwellings
There is general consensus that the single rondavel or the circular floor plan building is
impractical as a residence. The rondavel is also an impractical building type as a kitchen and
bathroom. One way to counter this impracticality is to either construct a ‘square-davel’ and to
cluster numerous rondavels or rondavel type buildings together in order to create a rondavel
house or to incorporate the circular building into another building with a rectangular floor plan.
The well-known 1920-1930s South African architect Gerard Moerdijk noted this in the various
articles he published in Die Boerevrou. Moerdijk promoted the design of an ‘Afrikaans’ dwelling
but did not reminisce neither did he explore the current tendencies of the Boer dwelling as they
existed in the landscape at the time. 24 Moerdijk never made any attempt to base his ideas of the
rondavel house on existing traditions that may have existed in rural Transvaal.
In the case of the so-called ‘guesthouse’ of Gustav Preller on the farm Pelindaba (figure
31), the rondavel units were clustered into a single residence but instead of adding rectangular
24

spaces, the connected areas in between the rondavels were used to serve as more ‘practical’
interior spaces – with more or less rectangular shapes.
Figure 31
Preller guest house on the farm Pelindaba near Hartebeestpoortdam west of Pretoria (photograph: M.
Naudé).
On the farm Koedoesrant, 25 two separate rondavels and a small rectangular cottage became
a single dwelling unit when they were connected with a large verandah. This indicates the
significance of the connecting passages, corridors, closed and open spaces in linking the various
circular spaces together. In this way new spaces are added, often with odd shapes and always of
varying sizes. These clusters do not have simple floor plans neither elementary roof structures
as conical thatched roofs had to be linked and often only linked via flat roofed concrete slabs
in between.
Figure 32
Rondavel dwelling with small gable building at the back, on the seasonal winter farm of the Bosman
family (photograph: Ditsong: National Museum of Cultural History, Pretoria).
In the case of the dwelling on the farm Rietvlei (Rayton district, Gauteng) the façade of the
original dwelling was flanked by two independent rondavels. When the dwelling had to be
enlarged the original core dwelling expanded towards the rondavels and they were eventually
linked to the main dwelling. Once again the space in between the rondavels and the rectangular
dwelling was covered to form a covered verandah (similar to the example on Koedoesrant). The
open façade of the verandah was later closed-off with a wall and windows to become a closed
stoep and another ‘room’.
The phenomenon of rondavel houses has not been investigated in detail yet and it falls
outside the scope of this paper to expand on the subject as these dwellings do not have a circular
floor plan after they have been altered and extended. The circle merely becomes a feature and
element of such a building.
25

Conclusion
The rondavel is a typical example of so-called ‘contact architecture’ – a term referring to the
(in this case, the relatively slow) translocation of a foreign building form from one cultural
group into the architectural vocabulary of another group. This paper does not focus on the use
of this spatial form as a solution to spatial problems focused on ‘dwelling’ and ‘living’ but
investigates this spatial form in a more general sense ( as an exploratory investigation) – also
from a vernacular point of view rather than a formal design angle. However, the occurrence of
the circular floor plan or spatial mental framework seems to be universal. The occurrence of the
circle as a form giving element in the construction of vernacular farm buildings and structures
seems to be quite common (especially in the northern part of South Africa) and is not a unique
engineering or architectural solution to serve the needs of early farmers and pioneer settlers in
the interior of South Africa. The rectangular floor plan remains the dominating form used by
early European settlers in the region for the construction for both residential units and other
building types typical of frontier settlement.
The vernacular use of the circle as a spatial and structural solution to create living, working
and storage space or as a method to create a building or structure with exceptional structural
capabilities have not been studied and recorded for academic or historical purposes yet, but this
phenomenon forms a well-defined niche in the study of vernacular architecture and engineering.
The decision to use the circle instead of the rectangle as spatial solution for a particular function
or use will always be based on functionality, but is often the result of finding a blend between
the needs of the landowner and the knowledge of the black workers responsible for construction
a circular building. It can be assumed that the occurrence of the circular phenomenon is not
necessarily a clinical decision in order to solve a spatial problem but based on the availability of
local knowledge of this building type (and the way it can be constructed) by the local indigenous
people. However, it is clear that not all circular buildings and structures were result of an activity
that is of a circular nature. Some structures such as rondavels are not circular because it makes
civil engineering sense, but were erected because the construction of this type of building was
an extension of a building typology known to the builders and acceptable to both landowners
and local builders.
The rondavel as dwelling type has a more extensive and perhaps more complex history and
was merely touched-on without a proper discourse as this topic cannot be thoroughly expanded
upon within the limits of this paper.
Notes
1. Oberholster, 1972: 42.
2. Interview with Dr U Küsel
(19 October 2009).
3. Interview with Dr U Küsel: The structure
is located among the trees on the way to
the cemetery and defined by a circular floor
surrounded by a single row of stones embedded
in the ground (6 March 2008).
4. Vd Waal-Braaksma Die Noordweste.
5. Internet: http://www.yzerfontein.info.history/
lime_kilns.html.
6. Vd Waal-Braaksma, 1986:104.
26
7. Vd Waal-Braaksma, 1986:104.
8. Vd Waal-Braaksma, 1986: 104.
9. Vd Waal-Braaksma, 1986: 104.
10. Vd Waal-Braaksma, 1986: 106.
11. The author visited several examples during an
investigation (for SANParks) of the remains of
farm the dwellings and structures of early white
farmers in the area along the Aoub River that
eventually became part of the Kalahari National
Park
(currently known as the Kgalakgadi
Transfrontier Park).

12. Farms in the Steynsburg district were visited
on several field trips between 2007 and 2009
as part of a research project by the Department
of Archaeology of the National Museum
in Bloemfontein (in collaboration with the
Department of Anthropology and Archaeology,
University of South Africa).
13. Maguire, 2008: 22.
14. Neethling, 1917: page unknown.
15. Personal comment: Dr J.A. van Schalkwyk
(Anthropologist, Ditsong: National Museum of
Cultural History) notes that he has never seen
the use of circular stone foundations mentioned
in the text but the use of timber columns at the
corner of a square granary seems to be the rule
of thumb for the construction of granaries (4
January 2010).
16. Personal comment: Dr J.A. van Schalkwyk has
observed several instances where pigs were
kept inside small circular stone structures in
indigenous African villages in the northern and
western parts of the Limpopo Province. Pigs
are considered dangerous animals and were
kept inside these structures. The structures
had no entrances or any openings that needed
to be secured or allowed the pigs to exist
accidentally. These pigs were fed on daily tit-
Works cited
De Clercq. H. 2002. The beloved ugly
duckling. SA Building (July).
Fisher, R.C., Le Roux, S & Maré, E. (eds.)
1998. Architecture of the Transvaal.
Pretoria: University of South Africa.
Fisher, R. C. & le Roux, S. (eds). 1989. Die
Afrikaanse woning – herdrukke uit:
Die Boerevrou (1919-1931). Pretoria:
Unibook.
Frescura, F. 1996. Vernacular architecture in
South Africa, a survey of historical and
current rural dwelling types and their
methods of construction. Johannesburg:
University of the Witwatersrand.
Greig, D.E. 1970. Herbert Baker in South
Africa. Johannesburg: Purnell.
Hartdegen, P. (Ed). 1988. Our building
heritage, an illustrated history. Cape
Town: Printpack Books.
Macdonald, W. 1913. The Conquest of the
Desert. London: T. Werner Laurie. Ltd.
27
bits and prevented them from browsing in the
neigbourhood eating human and animal faeces
(interview: 4 January 2010).
17. Oberholster, 1972: 42.
18. Oberholster, 1972: 43
19. Greig, 1970: 77.
20. De Clerq, 2002: no page numbers.
21. Oberholster, 1972:179.
22. Oberholster, 1972:180. In order to preserve these
unique buildings in South Africa’s vernacular
architecture, the former National Monuments
Council proclaimed five individual buildings at
different locations in the Karoo.
23. Maguire, 2008: 24.
24. Moerdijk 1920 and 1921: Die Boerevrou.
25. The author did not visit the farm. The
photograph was part of the collection of the
Bosman family (of the farm Roodepoort
- district of Middelburg) that was donated to
the National Cultural History Museum. The
history of the farm and this farmhouse has not
been recorded but a series of photographs taken
during the alterations gives some indication
of the sequence of changes leading up to the
dwelling’s character on the photograph.
Maguire, J. 2008. Building in stone in the
Karoo: possible explanations for the
restricted distribution of corbelled
houses. VASSA Journal (no.19).
Moerdijk G. 1920. Rondawelhuise. Die
Boerevrou (December).
Moerdijk, G. 1921. Rondawelhuise. Die
Boerevrou (December).
Naudé, M. 2007. A legacy of rondavels and
rondavel houses in the northern interior
of South Africa. South African Journal
of Art History (vol. 22).
Naudé, M. 2004. Oral evidence on the
construction of vernacular farm
dwellings in the Waterberg (Limpopo
Province). South African Journal of
Cultural History (vol. 18 no. 1).
Naudé, M. 2002. Erich Mayer’s depiction
of the vernacular hut and multiple hut
building tradition. South African Journal
of Art History (vol. 17).

Naudé, M. 2002. Oral evidence on
the Erasmus family and the farm
Randjesfontein (Midrand). Year Book
19. Africana Society of Pretoria.
Naudé, M. 2000. Vernacular stone buildings
and structures on farmsteads in the
southern districts of the Mpumalanga
Province. South African Journal of
Cultural History (vo.l 14 no. 2).
Naudé, M. 1994. Rondavels and rondavel
houses in the Transvaal. Year Book 12.
Africana Society of Pretoria.
Neethling, T. 1917. Die Wolfhuisie.
Huisgenoot (December).
Oberholster, J. J. 1972. The historical
monuments of South Africa.
Internet
http://www.flickr.com/photos/south-african-tourism/3918664733
Internet: http://www.yzerfontein.info/history/lime_kilns.html
28
Stellenbosch: Rembrandt van Rijn
Foundation for Culture.
Pienaar, U. de V. 1990. Neem uit die verlede.
Pretoria: Sigma Press
Radford, D. 1984. The detached kitchen:
its occurrence in South African
architecture. Restorica (October).
Van Der Merwe, H. 1986. Die tradisionele
wielmaakproses. Tydskrif vir Volkskunde
en Volkstaal (April).
Van der Waal-Braaksma, G. and Ferreira,
O.J.O. 1986. Die Noordweste. Die
stoflike kultuuruitinge van die streek se
bewoners. Johannesburg: Perskor.
Walton, J. 1998. Windpumps in South Africa.
Cape Town: Human & Rousseau.
Mauritz Naudé is a researcher at the Ditsong: National Museum of Cultural History (Pretoria). He holds a Masters
degree in Architecture (Conservation). His special field of interest is the conservation of architecture and the
built environment. Other interests include the study of vernacular architecture, indigenous building materials and
construction techniques. For the past 15 years he has been lecturing on a part-time basis at various universities and
has published various articles on folk building technology associated with different region north of the Vaal River.
Topics cover buildings such as rondavels, timber frame sheds and early farm dwellings in the Waterberg region
and the use of stonemasonry in the farm buildings of the southern districts of the Mpumalanga Province. More
recent publications explore the early industries of Pretoria and investigate engineering buildings and structures
associated with mining and other industries in the Gauteng region.
