Accessories Cruiser - Suzuki

Accessories Cruiser
Intruder C1800 / Intruder C1500 / Intruder C800 / Intruder M1800R /
Intruder M1800R2 / Intruder M1500 / Intruder M800

Contents
Stylish, classical, easy-riding: Suzuki Cruisers are just
as unique as their riders. And they become even more
individual with original Suzuki accessories. In perfect
harmony with the look of the bike and of course, with
high-quality materials and workmanship.
P.4 Intruder C1800R
P.8 Intruder C1500
Intruder C800
P.10
Intruder M1800R
Intruder M1800R2
P.12 Intruder M1500
P.16
Intruder M800
P.22 Clothing / General
2 3

Intruder C1800R
1 Cruiser screen, set
Including lower wind deflectors.
Intruder C1800R, from model year 2008
4 5
1
P/N 99000-99074-65N

In the grand style: the right look
for your power cruiser
2 Accessory bar, set
Intruder C1800R,
from model year 2008
Chrome
P/N 99000-99074-63N
3 Sissy bar backrest 1
Intruder C1800R,
from model year 2008
Without rivets (not illustrated)
P/N 990A0-75059-SIE
With rivets
P/N 990A0-75069-SIE
4 Sissy bar mounting
kit 2
Intruder C1800R,
from model year 2008
Chrome
P/N 99000-99074-66N
2
3 4
5
6
1, 2
5 Rear carrier
Intruder C1800R,
from model year 2008
Chrome
P/N 990A0-75066-SIE
6 Brake fluid reservoir
cover
Intruder C1800R,
from model year 2008
Chrome
P/N 59600-10820-000
7
Note: Important information for riding with luggage!
Max. load of 2.3 kg each for saddlebags. Max. speed with
saddlebags: 130 km/h.
1 Only in combination with sissy bar mounting kit (pos. 4)
2 Only in combination with sissy bar backrest (pos. 3)
3 Only in combination with saddlebag support (pos. 9)
7 Saddlebag, set 3
Intruder C1800R, from model year 2008
Leather, with rivets
P/N 990A0-77024-SIE
8 Saddlebag, set 3
Intruder C1800R, from model year 2008
Leather, without rivets
P/N 990A0-77026-SIE
1, 2
9 Saddlebag support, set
Intruder C1800R, from model year 2008
Chrome
P/N 99000-99074-67N
10 Frame cover for
steering head, set
Intruder C1800R, from model year 2008
6 7
Chrome
P/N 47300-22820-000
8
9
10

Intruder C1500 / C800
11 12
11 Cruiser screen
Intruder C1500,
from model year 2007-2009
P/N 990D0-10F20-055
12 Cruiser screen
8 9
Intruder C800,
from model year 2007
P/N 990D0-41F20-055

13 14
17
13 Cruiser screen
(Illustration similar)
Intruder M1800R, from model year 2006
P/N 990D0-48G55-000
Intruder M1800R2, from model year 2008-2009
P/N 990D0-48G60-000
Intruder M1800R/2
16
14 Saddlebag, set 1
Intruder M1800R, from model year 2006
Intruder M1800R2, from model year 2008
Leather
P/N 990D0-48G00-000
15 Saddlebag support, set
Intruder M1800R, from model year 2006
Intruder M1800R2, from model year 2008
Chrome (not illustrated)
P/N 990D0-48G00-065
Note: Important information for riding
with luggage!
Max. load of 2 kg each for saddlebags.
Max. speed with saddlebags: 130 km/h.
16 Sissy bar, set
With leather backrest.
Intruder M1800R, from model year 2006
Intruder M1800R2, from model year 2008
Chrome
P/N 990D0-48G00-050
17 Adapter for navigation
bracket 2
Aluminium
P/N 990D0-48GNB-000
1 Only in combination with saddlebag support (pos. 15)
2 Navigation unit and specific bracket are not included
10 11

Intruder M1500
18 Cruiser screen
Intruder M1500, model year 2009
Long
P/N 99000-99074-77N
19 Cruiser screen
Intruder M1500, model year 2009
12 13
18
19
Short
P/N 99000-99074-78N

20
Take a seat and relax:
beautiful Accessories
for a beautiful Cruiser
20 Brake fluid reservoir cover
Intruder M1500, model year 2009
Chrome
P/N 59600-10820-000
21 Accessory bar, set
Intruder M1500, model year 2009
Chrome
P/N 99000-99074-79N
21
22 Sissy bar mounting kit 1
Intruder M1500, model year 2009
Chrome
P/N 99000-99074-81N
23 Sissy bar backrest 2
Intruder M1500, model year 2009
Without rivets
P/N 990A0-75059-SIE
With rivets (not illustrated)
P/N 990A0-75069-SIE
22
23
24
24 Rear carrier 3
(Illustration similar)
Intruder M1500, model year 2009
14
1 Only in combination with sissy bar backrest (pos. 23)
2 Only in combination with sissy bar mounting kit (pos. 22)
and rear carrier (pos. 24)
3 Only in combination with sissy bar mounting kit (pos. 22)
and sissy bar backrest (pos. 23)
15
Chrome
P/N 990A0-75066-SIE
25
25 Rear seat cover
Intruder M1500, model year 2009
Black
P/N 45500-40810-YAY
Red
P/N 45500-40810-YHL
Blue
P/N 45500-40810-YSF

Intruder M800
26 27
26 Cruiser screen
Intruder M800, from model year 2010
Long
P/N 99000-99074-83N
27 Cruiser screen
Intruder M800, from model year 2010
Short
P/N 99000-99074-84N
28 Cruiser screen
Intruder M800, from model year 2007-2009
16 17
28
P/N 990D0-39G00-055

29
Highway feeling with style –
and masses of chrome
29 Meter cover
Intruder M800,
from model year 2010
Mat black
P/N 99000-99013-K73
30 Accessory bar, set
Intruder M800,
from model year 2010
Chrome
P/N 990A0-75073-SIE
30
32
31 Radiator cover
Intruder M800, from model year 2010
Chrome
P/N 99000-99013-K74
32 Rear seat cover
Intruder M800, from model year 2010
Black
P/N 45500-39820-YAY
Grey
P/N 45500-39820-YHG
Orange
P/N 45500-39820-YME
33 Brake fluid reservoir
cover
Intruder M800, from model year 2010
18 19
31
Chrome
P/N 59600-10820-000
33

34
20
Unspoilt, authentic and
cool: cruiser-look comfort
34 Sissy bar backrest 1
Intruder M800, from model year 2010
Leather
P/N 990A0-75045-SIE
35 Sissy bar mount, set 2
Intruder M800, from model year 2010
Chrome
P/N 99000-99074-85N
1, 2
36 Rear carrier
Intruder M800, from model year 2010
Chrome
P/N 990A0-75066-SIE
35 37
Sissy bar, set
Incl. sissy bar mount
Intruder M800, from model year 2005-2009
Chrome (not illustrated)
P/N 990D0-39G50-000
36
Note: Important information for riding with luggage!
Max. load of 2.3 kg each for saddlebags. Max. speed with
saddlebags: 130 km/h.
1 Only in combination with sissy bar mount (pos. 35)
2 Only in combination with sissy bar backrest (pos. 34)
3 Only in combination with saddlebag support (pos. 39)
4 Only in combination with saddlebag plate (pos. 38) or
sissy bar mount (pos. 35)
38
39
37 Saddlebag, set 3
Intruder M800, from model year 2010
Leather
P/N 990A0-77032-SIE
38 Saddlebag plate, set 3
For saddlebag mounting without sissy bar.
Chrome
P/N 99000-99074-87N
39 Saddlebag support,
set 4
Intruder M800, from model year 2010
Chrome
P/N 99000-99074-86N

40
Authentic style:
outfits for
cruiser fans
1, 2
40 Cruiser helmet
The Suzuki Cruiser helmet, developed
in co-operation with HJC, has a
fibreglass Kevlar® multi-fibre outer
shell and features CoolMax® lining, an
ECE-22-05 seal of approval and a
convenient key lock. Integral and
system helmets do not fit for Shoei or
jet helmets.
Black, sizes: XS–XXL
P/N 990D0-HEITB-Size
41 42
1 For order articles with sizes please fill the three positions with zero.
For example: 990F0-STEX1-00L or 990F0-STEX1-0XL
2 while stocks last
41 Cruiser jacket 1
Universal with Airguard® 500D and two layers
throughout. CE-marked (EN1621-1 / EN1621-2)
shoulder, elbow and back protectors, this
double Dynax special, complete with 3M Scotch-
lite and same-coloured double stitching, offers
the outer shell you need for maximum safety –
and the inner lining, too! While Suzuki-branded
210 T Taffeta and a high-grade Z-Liner membrane
(100 % waterproof and breathable) provide
the basics for a comfortable ride, a twovent
front and rear air-control system and the
attached Lorica® neck warmer set you up,
whatever the weather. For a more individual fit,
elbow protectors can be adjusted into one of
two positions and stretch material along the inner
arm and side promises comfort, even on
long tours. Team this gem up with Suzuki’s
touring pants (990F0-STEX4-Size) by means of
the long connecting zipper, for a perfectly comfortable
ride – or use the short zipper to connect
other manufacturers‘ garments.
Black, sizes: XS–4XL
P/N 990F0-STEX1-Size
42 Cruiser pant 1
Similar to the touring jacket, the Suzuki
touring pants promise nothing but comfort
and safety. From the Airguard® 500D outer
shell, complete with adjustable Dynax-padded,
CE-marked (EN1621-1) knee protectors,
3M Scotchlite features, coloured double
stitching and an Alcantara © seat patch
for more grip, to the Suzuki-branded 210 T
Taffeta lining and high-grade Z-Liner membrane
(100 % waterproof and breathable), this
touring all-rounder truly leaves nothing to
be desired, come rain or shine. While the
two-vent front air-control system and the
stretch material across the groin and knees
let you balance out all climates, the special
long zipper lets you connect your touring
jacket – or jackets from other manufacturers
via the short zipper.
Black, sizes: XS–4XL
P/N 990F0-STEX4-Size
43
44
45
43 Cruiser gloves 1
Wrap safety around your little finger
– and the other four, too! Thanks
to their extra palm padding, preformed
fingers and excellent fit, these
genuine, lightweight leather touring
gloves with a mix of Airguard® 500D
and reflective Nyspan and a full polyester
lininqg, offer all the protection,
comfort and style you could ask for.
Black /Grey, sizes: XS–XXL
P/N 990F0-GLO80-Size
44 Kidney belt
Wind-breaking, stabilising and
breathable.
Black, sizes:
S (70–80 cm), M (80–90 cm),
L (90–100 cm), XL (100–110 cm)
P/N 990F0-SBELT-Size
45 Back protector
Keep your spine safe with this protective
shell.
For heights from 165 cm to 175 cm
P/N 990F0-PROTC-00L
For heights from 175 cm to 183 cm
P/N 990F0-PROTC-0XL
If you are looking for more
riding gear articles such as
helmets, kidney belts, protectors
or even touring
gloves, please take a look
at the new fashion & more
brochure.
46 Backpack
Conquer the great outdoors with this
sturdy all-rounder: from ergonomically
formed bottle holder to eyeletfitted
pockets for your mobile phone,
intercom or MP3 player, integrated
rain hood, helmet net and enough
space for your laptop, this practical
Suzuki backpack makes sure your stuff
stays dry and in one piece - whatever
adventure you may embark on.
Black / Grey, small
P/N 990F0-BACK0-001
47 Battery charger
Perfect battery maintenance and
care. Fully-automatic battery charger
with diagnosis function and overcharge
protection. 12 V, max. 0.6 A
P/N 990DO-OPTIM-3PL
48 First aid kit
Compulsory when travelling
Big, with safety vest
P/N 990D0-FIRST-KIT
49 First aid kit
Compulsory when travelling
Small, without safety vest
P/N 990D0-FIRST-AID
50 Oil filter
Chrome
P/N 16510-22H00-000
46
47
48 49
50
52
51
51 Oil filter cap
Chrome
P/N 09259-20014-000
52 Alarm system
Intruder M1800R,
model year 2006-2007
Alarm unit
P/N 990D0-ALARM-000
Installation kit
P/N 990D0-48G00-ALM
Intruder M1800R2 / M1800R,
from model year 2008
Alarm unit
P/N 990D0-ALARM-001
Installation kit
P/N 990D0-48G01-ALM
Intruder C1800, from model year 2008
Alarm unit
P/N 990D0-ALARM-001
Installation kit
P/N 990D0-22H00-ALM
Intruder M1500, all model years
Alarm unit
P/N 990D0-ALARM-001
Installation kit
P/N 990D0-40H00-ALM
Intruder M800, from model year 2010
Alarm unit
P/N 990D0-ALARM-001
Installation kit
P/N 990D0-39G00-ALM
22 23

24
Your Suzuki partner:
Get your catalogue now!
You want the perfect outfit, not only
for your bike, but for yourself as
well? No problem: order the special
clothing catalogue from your Suzuki
partner now.
Suzuki accessories are designed specifically for Suzuki vehicles
and are subject to the same quality standards as the vehicles
themselves. We would like to draw your specific attention to the
fact that only Suzuki original accessories are tested and approved
by Suzuki. The requirements they have to meet are set out in the
relevant manuals. Under certain circumstances, the installation
and/or usage of other accessory parts may therefore have a negative
impact on the characteristics of your vehicle as set out in
the design specifications, thereby impairing ride safety. Suzuki
cannot, under any circumstances, be made liable for damage occurring
from the use of any accessory that is not a Suzuki original
accessory.
Subject to engineering and design modifications. Please consult
the current price list for details of accessory prices.
Suzuki International Europe GmbH,
Suzuki Allee 7, 64625 Bensheim
Details of many more original accessories
and other extras can be found at:
www.suzuki.eu
09/09, 2k Karlsruhe, Printed in Germany.
