Features:

The typical KF or NW assembly consists of two identical flanges, a center-ring, and an

aluminum clamp with a wingnut fastener frequently connect and disconnect without tools.

The vacuum seal is effected by uniform application of pressure by the clamp on 15° surface

of the flange.

The mating flange surfaces compress an O'ring ( held in place by metal centering ring ) to

generate a seal.

Specifications:

Blanks

: 304 S.S. (Other material available upon request)

Flanges


Fittings


Clamp

: Aluminum

O'ring material : Viton or NBR

Temperature Range : 150°C ( Viton ) 80°C ( NBR )

Vacuum Rate : 10-8 torr

Larger or special size available upon request


WING NUT

WASHER

EYE BOLT

HINGED CLAMP

O-RING

CENTERING RING

WELD FLANGE

WELD FLANGE

Hinged Clamp assemblies, detailed below, are the most commonly used method for making

KF-Flange vacuum seal connections. Assembly is simplified by the 360° rotatable flanges

and self-centering feature of the centering ring.

Pressure is applied uniformly around the 15° outer surface of both flanges by fingertightening

the single wingnut until the first metal-to-metal contact is made between the

spacing lips of the centering ring and the inner surface of the mating flanges. This

compresses the O'ring between the flanges and makes the vacuum seal.

1

-


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd

1

-




Application for KF Components

Applications for this system are as varied as the imagination can make them. Some

examples are:

1 Roughing and foreline plumbing for large vacuum system.

2 Small system.

3 System demanding frequent change.

4 System demanding frequent cleaning.

5 Experimental system in research laboratories.

6 Teaching laboratories.

Blank

Model No. Material A B C

Parts No.

KF10BS 304 S.S. 30 12.2 5 150101003

KF16BS 304 S.S. 30 17.2 5 150102003

KF25BS 304 S.S. 40 26.2 5 150103003

KF40BS 304 S.S. 55 41.2 5 150105003

KF50BS 304 S.S. 75 52.2 5 150106003

KF63BS 304 S.S. 87 70 12 150107003

KF80BS 304 S.S. 114 83 12 150108003

KF100BS 304 S.S. 134 102 12 150109003

KF160BS 304 S.S. 190 153 12 150112003

KF10BA Aluminum 30 12.2 5 150101001

KF16BA Aluminum 30 17.2 5 150102001

KF25BA Aluminum 40 26.2 5 150103001

KF40BA Aluminum 55 41.2 5 150105001

KF50BA Aluminum 75 52.2 5 150106001

KF63BA Aluminum 87 70 12 150107001

KF80BA Aluminum 114 83 12 150108001

KF100BA Aluminum 134 102 12 150109001

KF160BA Aluminum 190 153 12 150112001

øB

øA

2.5

C

Dimension in mm unless otherwise noted

-

1 1


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd




Bored Blank

Model No. Material A B C D Parts No.

KF10B12 304 S.S. 30 12.2 5 12.9 150201073

KF16B19 304 S.S. 30 17.2 5 19.3 150202093

KF25B25 304 S.S. 40 26.2 5 25.7 150203113

KF40B38 304 S.S. 55 41.2 5 38.4 150205133

KF50B51 304 S.S. 75 52.2 5 51 150206143

KF63B63 304 S.S. 87 70 12 63.7 150207153

KF80B76 304 S.S. 114 83 12 76.4 150208163

KF100B102 304 S.S. 134 102 12 101.8 150209183

KF160B153 304 S.S. 190 153 12 152.9 150212203



KF10WS 304 S.S. 30 12.2 16.5 13 150901073

KF16WS 304 S.S. 30 17.2 20.5 19.3 150902093

KF25WS 304 S.S. 40 26.2 29 25.7 150903113

KF40WS 304 S.S. 55 41.2 44.7 38.4 150905133

KF50WS 304 S.S. 75 52.2 57.4 51 150906143

KF63WS 304 S.S. 87 70 67.5 63.7 150907153

øD

øB

øA

øC

øD

øB

øA

2.5

12.7

C



KF80WS 304 S.S. 114 83 98 89.5 150908AM3

KF100WS 304 S.S. 134 102 118 114.5 150909AN3

KF160WS 304 S.S. 190 153 174 165.5 150912AQ3

Half Nipple (Short)

Model No. Available Area Material A B C Parts No.

KF10SHNSA U.S.A. 304 S.S. 30 12.7 12.7 150301073

KF16SHNSA U.S.A. 304 S.S. 30 19.05 12.7 150302093

KF25SHNSA U.S.A. 304 S.S. 40 25.4 12.7 150303113

KF40SHNSA U.S.A. 304 S.S. 55 38.1 19.1 150305133

KF50SHNSA U.S.A. 304 S.S. 75 50.8 19.1 150306143

KF10SHNSE Europe 304 S.S. 30 14 30 150501AB3

KF16SHNSE Europe 304 S.S. 30 20 30 150502AD3

KF25SHNSE Europe 304 S.S. 40 28 30 150503AE3

KF40SHNSE Europe 304 S.S. 55 45 30 150505AG3

KF50SHNSE Europe 304 S.S. 75 57 30 150506AJ3

KF25SHNSJ27 Japan 304 S.S. 40 27.2 20 150703AE3

KF40SHNSJ42 Japan 304 S.S. 55 42.7 20 150705AG3

KF50SHNSJ60 Japan 304 S.S. 75 60.5 20 150706AJ3

1 - 2 Dimension in mm unless otherwise noted Dimension in mm unless otherwise noted 1 - 3

øC

øD

øB

øA

øB

øA

20

C


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd




Half Nipple (Long)

Model No. Available Area Material A B C Parts No.

KF10LHNSA U.S.A. 304 S.S. 30 12.7 40 150401073

KF16LHNSA U.S.A. 304 S.S. 30 19.05 40 150402093

KF25LHNSA U.S.A. 304 S.S. 40 25.4 40 150403113

KF40LHNSA U.S.A. 304 S.S. 55 38.1 40 150405133

KF50LHNSA U.S.A. 304 S.S. 75 50.8 40 150406143

KF10LHNAA U.S.A. Aluminum 30 12.7 40 150401071





KF10LHNSE Europe 304 S.S. 30 14 70 150601AB3

KF16LHNSE Europe 304 S.S. 30 20 70 150602AD3

KF25LHNSE Europe 304 S.S. 40 28 70 150603AE3

KF40LHNSE Europe 304 S.S. 55 45 70 150605AG3

KF50LHNSE Europe 304 S.S. 75 57 70 150606AJ3

KF50LHNSJ Japan 304 S.S. 75 60.5 40 150806AJ3

øA

C

øB

Half Nipple (Short Japanese Type)

Model No. Available Area Material A B C D Parts No.

KF25SHNSJ34 Japan 304 S.S. 40 34 20 32 150703AF3

KF40SHNSJ48 Japan 304 S.S. 55 48.6 20 45 150705AH3

Half Nipple (Long Japanese Type)



øA

KF25LHNSJ Japan 304 S.S. 40 34 40 32 150803AF3

KF40LHNSJ Japan 304 S.S. 55 48.6 40 45 150805AH3

øD

øB

øD

øA

C

C

øB


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd



Clamp


Model No. Surface Treatment Material A B C Parts No.

KF16CLA Aluminum 61 45 16 21010511




KF16CLA-NP Nickel Plating Aluminum 61 45 16 21010521




Nail Clamp

Model No. Material Fits Size Bolt Quantity A Parts No.

KF-NCA Aluminum KF10 M6*20 3 43 2103A111





A

øA

B

C


Cap

Model No. Material Fits Flange Parts No.

KF10CAP Polyethylene KF10 5085DG

KF16CAP Polyethylene KF16 5085DG

KF25CAP Polyethylene KF25 5085DY

KF40CAP Polyethylene KF40 5085EJ

KF50CAP Polyethylene KF50 5085FD


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd

-

2





Features:

O’RING


OUTER RING

DOUBLE CLAW CLAMP

DOUBLE WALL CLAMP

ISO FLANGE

The components of ISO universal flange system are defined by the International Standards

Organization (ISO).

The construction of ISO flange series includes two smooth-faced sexless flanges clamped

together with a combination metal centering ring and elastomeric O-ring between them.

ISO components are reusable and changeable with other ISO dimension components of the

same size.


Blanks & Flanges : 304 S.S. (Other material available upon request)

Retainer Rings : 304 S.S. (Other material available upon request)

Centering Rings : 304 S.S. (Other material available upon request)

Outer Rings : Aluminum

Clamps

: Aluminum, Stainless steel, Steel plated

O'ring material : Viton or NBR

Temperature Range : 150°C ( Viton ) 80°C ( NBR )

Vacuum Rate : 10-8 torr



The system is versatile because of the many ways in which components can be

assembled.

1 Double Wall-Clamp or Double Claw Clamp

Illustrates the double wall (claw) clamp assembly to connect pairs of ISO flanges. Ease of use and

economic make this the most commonly used configuration.

2 Bolted Nonrotatable

DOUBLE WALL CLAMP

ISO FLANGE

DOUBLE CLAW CLAMP


O’RING

The two bolt flanges connected in the normal way.

BOLTED FLANGE

O’RING


OUTER RING

BOLTED FLANGE

-

2


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd

2

-





3 Single Wall Clamp

Single wall clamps are used to join an ISO flange to a tapped flange on a pump or gate valve.

ISO FLANGE

SINGLE WALL-CLAMP CENTERING RING

TAPPED

BOLTED FLANGE

4 Bolted Rotatable

O’RING

This fastening method allows the ISO flange to be rotated for ease of component alignment.

Additionally, a rotatable bolt ring can be used to fasten an ISO flange to a non-rotatable flange

using bolt.

ROTATABLE

BOLT RING

BOLTED FLANGE

O’RING


ISO FLANGE

SPLIT RETAINER RING

Applications for ISO Components

Applications for this system are as varied as the imagination can make them.

Some examples are:

1 Roughing and foreline plumbing for large vacuum systems.

2 High vacuum, high conductance, inter-connections.

3 Modular system which will be modified frequently.

4 System requiring frequent cleaning.

5 Experimental system in research laboratories.

2 -


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd

-

2 1


Blank





ISO63B 304 S.S. 95 70 12 90 152107003

ISO80B 304 S.S. 110 83 12 105 152108003

ISO100B 304 S.S. 130 102 12 125 152109003

ISO160B 304 S.S. 180 153 12 175 152112003

ISO200B 304 S.S. 240 213 12 235 152113003

ISO250B 304 S.S. 290 261 12 285 152114003

ISO320B 304 S.S. 370 318 17 365 152116003

ISO400B 304 S.S. 450 400 17 445 152118003

ISO500B 304 S.S. 550 501 17 545 152120003

Bored Blank

Model No. Material A B C D E Parts No.

ISO63B63 304 S.S. 95 70 12 90 63.7 152207153

ISO80B76 304 S.S. 110 83 12 105 76.4 152208163

ISO100B102 304 S.S. 130 102 12 125 101.8 152209183

ISO160B153 304 S.S. 180 153 12 175 152.9 152212203

ISO200B204 304 S.S. 240 213 12 235 203.7 152213213

ISO250B255 304 S.S. 290 261 12 285 254.5 152214223

ISO320B305 304 S.S. 370 318 17 365 305.3 152216233

ISO400B407 304 S.S. 450 400 17 445 406.9 152218253

ISO500B509 304 S.S. 550 501 17 545 508.8 152220273

øD

øB

øA

øD

øE

øB

øA

C

C

Bolted Flange

Model No. Material A B C D E *No. P.C.D. Parts No.

Bolted Flange-Tapped

P.C.D.

ISO63BF 304 S.S. 130 70 12 63.7 9*4 110 152307153

ISO80BF 304 S.S. 145 83 12 76.4 9*8 125 152308163

ISO100BF 304 S.S. 165 102 12 101.8 9*8 145 152309183

ISO160BF 304 S.S. 225 153 16 152.9 11*8 200 152312203

ISO200BF 304 S.S. 285 213 16 203.7 11*12 260 152313213

ISO250BF 304 S.S. 335 261 16 254.5 11*12 310 152314223

ISO320BF 304 S.S. 425 318 20 305.3 14*12 395 152316233

ISO400BF 304 S.S. 510 400 20 406.9 14*16 480 152318253

ISO500BF 304 S.S. 610 501 20 508.8 14*16 580 152320273

P.C.D.


ISO63BFTAP 304 S.S. 130 70 12 63.7 M8*4 110 152407153

ISO80BFTAP 304 S.S. 145 83 12 76.4 M8*8 125 152408163

ISO100BFTAP 304 S.S. 165 102 12 101.8 M8*8 145 152409183

ISO160BFTAP 304 S.S. 225 153 16 152.9 M10*8 200 152412203

ISO200BFTAP 304 S.S. 285 213 16 203.7 M10*12 260 152413213

ISO250BFTAP 304 S.S. 335 261 16 254.5 M10*12 310 152414223

ISO320BFTAP 304 S.S. 425 318 20 305.3 M12*12 395 152416233

ISO400BFTAP 304 S.S. 510 400 20 406.9 M12*16 480 152418253

ISO500BFTAP 304 S.S. 610 501 20 508.8 M12*16 580 152420273

øD

øB

øA

øD

øB

øA

øE

C

øE

C


-

2 2


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd

-

2 3




Rotatable Bolt Ring

Model No. Material A B C D *No. P.C.D. Parts No.

ISO63RBR 304 S.S. 130 98.5 12 9*4 110 152507073

ISO80RBR 304 S.S. 145 113.5 12 9*8 125 152508083

ISO100RBR 304 S.S. 165 133.5 12 9*8 145 152509093

ISO160RBR 304 S.S. 225 185.7 16 11*8 200 152512123

ISO200RBR 304 S.S. 285 245.7 16 11*12 260 152513133

ISO250RBR 304 S.S. 335 295.7 16 11*12 310 152514143

ISO320RBR 304 S.S. 425 375.8 20 14*12 395 152516163

ISO400RBR 304 S.S. 510 458.8 20 14*16 480 152518183

ISO500RBR 304 S.S. 610 558.8 20 14*16 580 152520203

ISO63RBR-NP Steel + Ni Plated 130 98.5 12 9*4 110 152507078










øB

P.C.D.

øA

øD

C

Half Nipple

Model No. Material A

B

C

Parts No.

ISO63HN 304 S.S. 95 63.5 100 152607153

ISO80HN 304 S.S. 110 76.2 100 152608163

ISO100HN 304 S.S. 130 101.6 100 152609183

ISO160HN 304 S.S. 180 152.4 100 152612203

ISO200HN 304 S.S. 240 203.2 100 152613213

ISO250HN 304 S.S. 290 254 100 152614223

ISO320HN 304 S.S. 370 304.8 100 152616233

ISO400HN 304 S.S. 450 406.4 100 152618253

ISO500HN 304 S.S. 550 508 100 152620273

øA

C

øB


-

2 4


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd

-

2 5





Split Retainer Ring

Model No. Material A Fit Flange Parts No.

ISO63SRR 304 S.S. 3 ISO63 20011041

ISO80SRR 304 S.S. 3 ISO80 20011141

ISO100SRR 304 S.S. 3 ISO100 20011241

ISO160SRR 304 S.S. 5 ISO160 20011541

ISO200SRR 304 S.S. 5 ISO200 20011641

ISO250SRR 304 S.S. 5 ISO250 20011741

ISO320SRR 304 S.S. 5 ISO320 20011941

ISO400SRR 304 S.S. 8 ISO400 20012141

ISO500SRR 304 S.S. 8 ISO500 20012341

ISO63SRR-NP Steel + Ni Plated 3 ISO63 200110A1









øA

Single Wall Clamp

Model No. Material A B C Fit Flange Parts No.

ISO63-100SWC304 304 S.S. M8 35 23

ISO63

ISO80

ISO100

ISO160

2121A241

ISO160-250SWC304 304 S.S. M10 35 23 ISO200

ISO250

ISO320

2121A441

ISO320-500SWC304 304 S.S. M12 50 30 ISO400

ISO500

2121A541

ISO63-100SWCA Aluminum M8 35 23.5

ISO063

ISO080

ISO100

ISO160

2121A211

ISO160-250SWCA Aluminum M10 35 23.5 ISO200

ISO250

ISO320

2121A411

ISO320-500SWCA Aluminum M12 50 30 ISO400

ISO500

2121A511

ISO63-100SWC-ZP Steel+ Zn Plated M8 35 23

ISO063

ISO080

ISO100

ISO160

2121A231

ISO160-250SWC-ZP Steel+ Zn Plated M10 35 23 ISO200

ISO250

ISO320

2121A431

ISO320-500SWC-ZP Steel+ Zn Plated M12 50 30 ISO400

ISO500

2121A531

C

A

B


-

2 6


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd

-

2 7





Double Wall Clamp

Model No. Material A B Quantity Fit Flange Parts No.

4 ISO63

ISO63-100DWCA Aluminum 45 M8 4 ISO80 2122A211

4 ISO100

4 ISO160


6 ISO250

8 ISO320


12 ISO500

B

A

Double Claw Clamp

Model No. Material A B Quantity Fit Flange Parts No.

4 ISO63

4 ISO80

ISO63-250DCC316 316 S.S. 61.5 M10 4 ISO100 2123A361

4 ISO160

6 ISO200

6 ISO250

8 ISO320

ISO320-500DCC316 316 S.S. 76 M12 8 ISO400 2123A561

12 ISO500

ISO630DCC316 316 S.S. 86 M12 12 ISO630 2123A661

4 ISO63

4 ISO80

ISO63-250DCC-ZP Steel + Zn Plated 61.5 M10 4 ISO100 2123A331

4 ISO160

6 ISO200

6 ISO250

8 ISO320

ISO320-500DCC-ZP Steel + Zn Plated 76 M12 8 ISO400 2123A531

12 ISO500

ISO630DCC-ZP Steel + Zn Plated 86 M12 12 ISO630 2123A631

A

B


-

2 8


-

2 10


ddddddddc

ddddddddc

ddc

ddc

ddc

ddc

ddc


ddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcddddddddcdddddddd

dddddddd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

cdd

cdd

cdd

cdd

cdd

cdd

cdddddddd

cdddddddd



dd

dd

dd

dd

dd

dd

dddddddd

dddddddd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd

dd




-

2 9

Cap


ISO63CAP Polyethylene ISO63 5085G9

ISO80CAP Polyethylene ISO80 5085GU

ISO100CAP Polyethylene ISO100 5085HJ

ISO160CAP Polyethylene ISO160 5085JR

ISO200CAP Polyethylene ISO200 5085KU

ISO250CAP Polyethylene ISO250 5085LE

ISO320CAP Polyethylene ISO320 5085QY

ISO400CAP Polyethylene ISO400 5085MT

ISO500CAP Polyethylene ISO500 5085ND


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd

-

3





Features:

KNIFE EDGE DETAIL

The high sealing effect and the low leak rates performance of CF flange connections is a

result of gasket material. When assembling the CF flange connect, the knife edge is pressed

into the flat copper gasket and force the seal material both axially as well as radially

outwards to the flange. The material is enclosed and cannot flow even at high bakeout

temperature. Due to this deformation of the seal such connections may sometimes stick

together. They can be easily separated with a special tool or screwdriver.

Offered in both rotatable and nonrotatable versions with through holes and tapped bolt

holes. Metric tapped holes and untapped holes flanges are identical products. UNC or UNF

or other tapped holes can be ordered as specials.


ROTATABLE CF FLANGE

INSERT

GASKET

NON-ROTATABLE

CF FLANGE

Blanks & Flanges : 304 S.S. (Other material available upon request)

Gaskets

: OFHC Copper or Viton

Bolt

: 304 S.S.

Temp. Range : -200°C ~ 450°C ( OFHC Copper )

Vacuum Range : 10-13 torr

Torque Rating : CF35 and smaller 220 kgf-cm

CF63 and larger 360 kgf-cm


PLATE NUT

Assembly:

The CF flange connection consists of two identical flanges with a flat gasket made of OFHC

copper, bolts, nuts. Because the applications are UHV environments, so the preparation work

is very important before installation. Surface cleaning guarantees the lowest possible

outgassing and leak rates.

Using clean lint free gloves, place pre-cleaned OFHC copper gasket against knife edge seal,

preferably the flange most likely to hold and support gasket from falling. With gasket in place

fit mating flange with desired bolt orientation; if flanges are fitted with leak test grooves, they

should aligned.

With flanges aligned, insert proper size bolt and hand tighten. Repeat this procedure with

remaining bolts. After hand tightening all bolts, support bolt and tighten nut using two

closed-end box wrenches. (washer are used on nut side)

-

3


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd

-

3




Applications for CF Components

CF flanges are suited for use in applications requiring a very clean environment,

ultrahigh vacuum conditions, high temperature or where critical or dangerous

materials must be contained or excluded. This include:

1 Difficult applications with corrosive radioactive, toxic or air sensitive materials.

2 Materials creation and processing such as molecular beam epitaxy.

3 Analytical instrumentation including Auger electron spectrometers and electron microscopes.

4 High energy physics installations such as accelerators and fusion devices.

Blank

Nonrotatable

Model No. Material A B C *No. P.C.D. Parts No.

CF16B 304L S.S. 33.8 7.5 4.4*6 26.9 154102004

CF35B 304L S.S. 69.5 12.7 6.7*6 58.7 154104004

CF63B 304 S.S. 113.6 18 8.4*8 92.1 154107003

CF100B 304 S.S. 151.6 20 8.4*16 130.3 154109003

CF150B 304 S.S. 202.5 22 8.4*16 181 154111003

CF200B 304 S.S. 253.2 24.7 8.4*24 231.8 154113003

CF250B 304 S.S. 336.5 28.5 10.3*30 306.5 154114003

CF300B 304 S.S. 355.6 28.5 10.3*30 325.7 154115003

CF350B 304 S.S. 419.1 28.5 10.3*36 388.9 154117003

CF16B-316 316 S.S. 33.8 7.5 4.4*6 26.9 154102005

CF35B-316 316 S.S. 69.5 12.7 6.7*6 58.7 154104005

CF63B-316 316 S.S. 113.6 18 8.4*8 92.1 154107005

CF100B-316 316 S.S. 151.6 20 8.4*16 130.3 154109005

CF150B-316 316 S.S. 202.5 22 8.4*16 181 154111005

CF200B-316 316 S.S. 253.2 24.7 8.4*24 231.8 154113005

CF250B-316 316 S.S. 336.5 28.5 10.3*30 306.5 154114005

CF300B-316 316 S.S. 355.6 28.5 10.3*30 325.7 154115005

CF350B-316 316 S.S. 419.1 28.5 10.3*36 388.9 154117005

øA

P.C.D.

øC

B


-

3 1


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd

-

3 2

Blank





Nonrotatable-Tapped Bolt Holes

øA

P.C.D.

øC

B

Blank

Rotatable



CF16BTAP 304L S.S. 33.8 7.5 M4*6 26.9 154202004

CR16B 304L S.S. 33.8 7.5 4.4*6 26.9 154302004

CF35BTAP 304L S.S. 69.5 12.7 M6*6 58.7 154204004

CR35B 304L S.S. 69.5 12.7 6.7*6 58.7 154304004

CF63BTAP 304 S.S. 113.6 18 M8*8 92.1 154207003

CR63B 304 S.S. 113.6 19 8.4*8 92.1 154307003

CF100BTAP 304 S.S. 151.6 20 M8*16 130.3 154209003

CR100B 304 S.S. 151.6 21.5 8.4*16 130.3 154309003

CF150BTAP 304 S.S. 202.5 22 M8*16 181 154211003

CR150B 304 S.S. 202.5 24 8.4*16 181 154311003

CF200BTAP 304 S.S. 253.2 24.7 M8*24 231.8 154213003

CR200B 304 S.S. 253.2 24.7 8.4*24 231.8 154313003

CF250BTAP 304 S.S. 336.5 28.5 M10*30 306.5 154214003

CR250B 304 S.S. 336.5 28.5 10.3*30 306.5 154314003

CF300BTAP 304 S.S. 355.6 28.5 M10*30 325.7 154215003

CR300B 304 S.S. 355.6 28.5 10.3*30 325.7 154315003

CF350BTAP 304 S.S. 419.1 28.5 M10*36 338.9 154217003

CR350B 304 S.S. 419.1 28.5 10.3*36 388.9 154317003

CF16BTAP-316 316 S.S. 33.8 7.5 M4*6 26.9 154202005

CF35BTAP-316 316 S.S. 69.5 12.7 M6*6 58.7 154204005

CF63BTAP-316 316 S.S. 113.6 18 M8*8 92.1 154207005

CF100BTAP-316 316 S.S. 151.6 20 M8*16 130.3 154209005

CF150BTAP-316 316 S.S. 202.5 22 M8*16 181 154211005

CF200BTAP-316 316 S.S. 253.2 24.7 M8*24 231.8 154213005

CF250BTAP-316 316 S.S. 336.5 28.5 M10*30 306.5 154214005

CF300BTAP-316 316 S.S. 355.6 28.5 M10*30 325.7 154215005

CF350BTAP-316 316 S.S. 419.1 28.5 M10*36 388.9 154217005

CR16B-316 316 S.S. 33.8 7.5 4.4*6 26.9 154302005

CR35B-316 316 S.S. 69.5 12.7 6.7*6 58.7 154304005

CR63B-316 316 S.S. 113.6 19 8.4*8 92.1 154307005

CR100B-316 316 S.S. 151.6 21.5 8.4*16 130.3 154309005

CR150B-316 316 S.S. 202.5 24 8.4*16 181 154311005

CR200B-316 316 S.S. 253.2 24.7 8.4*24 231.8 154313005

CR250B-316 316 S.S. 336.5 28.5 10.3*30 306.5 154314005

CR300B-316 316 S.S. 355.6 28.5 10.3*30 325.7 154315005

CR350B-316 316 S.S. 419.1 28.5 10.3*36 388.9 154317005

øA

P.C.D.

øC

B


-

3 3


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd

-

3 4

Blank




Rotatable-Tapped Bolt Holes Nonrotatable


CR16BTAP 304L S.S. 33.8 7.5 M4*6 26.9 154402004

CR35BTAP 304L S.S. 69.5 12.7 M6*6 58.7 154404004

CR63BTAP 304 S.S. 113.6 19 M8*8 92.1 154407003

CR100BTAP 304 S.S. 151.6 21.5 M8*16 130.3 154409003

CR150BTAP 304 S.S. 202.5 24 M8*16 181 154411003

CR200BTAP 304 S.S. 253.2 24.7 M8*24 231.8 154413003

CR250BTAP 304 S.S. 336.5 28.5 M10*30 306.5 154414003

CR300BTAP 304 S.S. 355.6 28.5 M10*30 325.7 154415003

CR350BTAP 304 S.S. 419.1 28.5 M10*36 388.9 154417003

CR16BTAP-316 316 S.S. 33.8 7.5 M4*6 26.9 154402005

CR35BTAP-316 316 S.S. 69.5 12.7 M6*6 58.7 154404005

CR63BTAP-316 316 S.S. 113.6 19 M8*8 92.1 154407005

CR100BTAP-316 316 S.S. 151.6 21.5 M8*16 130.3 154409005

CR150BTAP-316 316 S.S. 202.5 24 M8*16 181 154411005

CR200BTAP-316 316 S.S. 253.2 24.7 M8*24 231.8 154413005

CR250BTAP-316 316 S.S. 336.5 28.5 M10*30 306.5 154414005

CR300BTAP-316 316 S.S. 355.6 28.5 M10*30 325.7 154415005

CR350BTAP-316 316 S.S. 419.1 28.5 M10*36 388.9 154417005


øA

P.C.D.

øC

B



B

Parts No.


6-ø4.4

CF16B7 304L S.S. 6.5 5.5 154502044

CF16B12 304L S.S. 12.9 10.4 154502074

CF16B19 304L S.S. 19.3 16 154502094

CF16B7-316 316 S.S. 6.5 5.5 154502045

CF16B12-316 316 S.S. 12.9 10.4 154502075

CF16B19-316 316 S.S. 19.3 16 154502095


6-M4


B

Parts No.

CF16B7TAP 304L S.S. 6.5 5.5 154602044

CF16B12TAP 304L S.S. 12.9 10.4 154602074

CF16B19TAP 304L S.S. 19.3 16 154602094

CF16B7TAP-316 316 S.S. 6.5 5.5 154602045

CF16B12TAP-316 316 S.S. 12.9 10.4 154602075

CF16B19TAP-316 316 S.S. 19.3 16 154602095

P.C.D.26.9

P.C.D.26.9

7.5

7.5

øB

øB

øA

øA

ø33.8

ø33.8


-

3 5


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd

-

3 6





Nonrotatable


B

Parts No.

CF16B7N 304L S.S. 6.35 4.5 154902044

CF16B12N 304L S.S. 12.7 9.5 154902074

CF16B19N 304L S.S. 19.05 16 154902094




B

Parts No.

CF16B7TAPN 304L S.S. 6.35 4.5 155002044

CF16B12TAPN 304L S.S. 12.7 9.5 155002074

CF16B19TAPN 304L S.S. 19.05 16 155002094

CF16B7-316TAPN-316 316 S.S. 6.35 4.5 155002045

CF16B12-316TAPN-316 316 S.S. 12.7 9.5 155002075

CF16B19-316TAPN-316 316 S.S. 19.05 16 155002095


ø33.8

ø33.8

P.C.D.26.9

P.C.D.26.9

12.7

12.7

øB

øB

6-ø4.4

CF16B7N-316 316 S.S. 6.35 4.5 154902045

CF16B12N-316 316 S.S. 12.7 9.5 154902075

CF16B19N-316 316 S.S. 19.05 16 154902095

øA

6-M4

øA


Rotatable


B

Parts No.


Rotatable-Tapped Bolt Holes

6-ø4.4


B

Parts No.

ø33.8

P.C.D.26.9

ø33.8

P.C.D.26.9

12.7

12.7

øB

øA

CR16B7N 304L S.S. 6.35 4.5 155102044

CR16B12N 304L S.S. 12.7 9.5 155102074

CR16B19N 304L S.S. 19.05 16 155102094

CR16B7N-316 316 S.S. 6.35 4.5 155102045

CR16B12N-316 316 S.S. 12.7 9.5 155102075

CR16B19N-316 316 S.S. 19.05 16 155102095

6-M4

CR16B7TAPN 304L S.S. 6.35 4.5 155202044

CR16B12TAPN 304L S.S. 12.7 9.5 155202074

CR16B19TAPN 304L S.S. 19.05 16 155202094

CR16B7-316TAPN-316 316 S.S. 6.35 4.5 155202045

CR16B12-316TAPN-316 316 S.S. 12.7 9.5 155202075

CR16B19-316TAPN-316 316 S.S. 19.05 16 155202095

øB

øA


-

3 7


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd

-

3 8




Bored Blank

Nonrotatable


*No. D P.C.D. Parts No.

CF35B25 304L S.S. 69.5 12.7 6.7*6 25.6 58.7 154504114

CF35B38 304L S.S. 69.5 12.7 6.7*6 38.3 58.7 154504134

CF35B42 304L S.S. 69.5 12.7 6.7*6 42.9 58.7 154504AG4

CF63B51 304 S.S. 113.6 18 8.4*8 51.1 92.1 154507143

CF63B63 304 S.S. 113.6 18 8.4*8 63.7 92.1 154507153

CF100B102 304 S.S. 151.6 20 8.4*16 101.8 130.3 154509183

CF150B153 304 S.S. 202.5 22 8.4*20 153.1 181 154511203

CF200B204 304 S.S. 253.2 24.7 8.4*24 203.7 231.8 154513213

CF250B255 304 S.S. 336.5 28.5 10.3*30 254.5 306.5 154514223

CF300B305 304 S.S. 355.6 28.5 10.3*30 305.4 325.7 154515233

CF350B356 304 S.S. 419.1 28.5 10.3*36 356.1 388.9 154516243

CF35B25-316 316 S.S. 69.5 12.7 6.7*6 25.6 58.7 154504115

CF35B38-316 316 S.S. 69.5 12.7 6.7*6 38.3 58.7 154504135

CF35B42-316 316 S.S. 69.5 12.7 6.7*6 42.9 58.7 154504AG5

CF63B51-316 316 S.S. 113.6 18 8.4*8 51.1 92.1 154507145

CF63B63-316 316 S.S. 113.6 18 8.4*8 63.7 92.1 154507155

CF100B102-316 316 S.S. 151.6 20 8.4*16 101.8 130.3 154509185

CF150B153-316 316 S.S. 202.5 22 8.4*20 153.1 181 154511205

CF200B204-316 316 S.S. 253.2 24.7 8.4*24 203.7 231.8 154513215

CF250B255-316 316 S.S. 336.5 28.5 10.3*30 254.5 306.5 154514225

CF300B305-316 316 S.S. 355.6 28.5 10.3*30 305.4 325.7 154515235

CF350B356-316 316 S.S. 419.1 28.5 10.3*36 356.1 388.9 154516245


P.C.D.

øD

øA

øC

B

Bored Blank


P.C.D.

Model No. Material A B C *No. D P.C.D. Parts No.

CF35B25TAP 304L S.S. 69.5 12.7 M6*6 25.6 58.7 154604114

CF35B38TAP 304L S.S. 69.5 12.7 M6*6 38.3 58.7 154604134

CF35B42TAP 304L S.S. 69.5 12.7 M6*6 42.9 58.7 154604AG4

CF63B51TAP 304 S.S. 113.6 18 M8*8 51.1 92.1 154607143

CF63B63TAP 304 S.S. 113.6 18 M8*8 63.7 92.1 154607153

CF100B102TAP 304 S.S. 151.6 20 M8*16 101.8 130.3 154609183

CF150B153TAP 304 S.S. 202.5 22 M8*20 153.1 181 154611203

CF200B204TAP 304 S.S. 253.2 24.7 M8*24 203.7 231.8 154613213

CF250B255TAP 304 S.S. 336.5 28.5 M10*30 254.5 306.5 154614223

CF300B305TAP 304 S.S. 355.6 28.5 M10*30 305.4 325.7 154615233

CF350B356TAP 304 S.S. 419.1 28.5 M10*36 356.1 388.9 154616243

CF35B25TAP-316 316 S.S. 69.5 12.7 M6*6 25.6 58.7 154604115

CF35B38TAP-316 316 S.S. 69.5 12.7 M6*6 38.3 58.7 154604135

CF35B42TAP-316 316 S.S. 69.5 12.7 M6*6 42.9 58.7 154604AG5

CF63B51TAP-316 316 S.S. 113.6 18 M8*8 51.1 92.1 154607145

CF63B63TAP-316 316 S.S. 113.6 18 M8*8 63.7 92.1 154607155

CF100B102TAP-316 316 S.S. 151.6 20 M8*16 101.8 130.3 154609185

CF150B153TAP-316 316 S.S. 202.5 22 M8*20 153.1 181 154611205

CF200B204TAP-316 316 S.S. 253.2 24.7 M8*24 203.7 231.8 154613215

CF250B255TAP-316 316 S.S. 336.5 28.5 M10*30 254.5 306.5 154614225

CF300B305TAP-316 316 S.S. 355.6 28.5 M10*30 305.4 325.7 154615235

CF350B356TAP-316 316 S.S. 419.1 28.5 M10*36 356.1 388.9 154616245

øD

øA

øC

B


-

3 9


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd

-

3 10




Bored Blank

Rotatable

CR35B25 304L S.S. 69.5 12.7 6.7*6 25.6 58.7 154704114

CR35B38 304L S.S. 69.5 12.7 6.7*6 38.3 58.7 154704134

CR35B42 304L S.S. 69.5 12.7 6.7*6 42.9 58.7 154704AG4

CR63B51 304 S.S. 113.6 19 8.4*8 51.1 92.1 154707143

CR63B63 304 S.S. 113.6 19 8.4*8 63.7 92.1 154707153

CR100B102 304 S.S. 151.6 21.5 8.4*16 101.8 130.3 154709183

CR150B153 304 S.S. 202.5 24 8.4*20 153.1 181 154711203

CR200B204 304 S.S. 253.2 24.7 8.4*24 203.7 231.8 154713213

CR250B255 304 S.S. 336.5 28.5 10.3*30 254.5 306.5 154714223

CR300B305 304 S.S. 355.6 28.5 10.3*30 305.4 325.7 154715233

CR350B356 304 S.S. 419.1 28.5 10.3*36 356.1 388.9 154716243

CR35B25-316 316 S.S. 69.5 12.7 6.7*6 25.6 58.7 154704115

CR35B38-316 316 S.S. 69.5 12.7 6.7*6 38.3 58.7 154704135

CR35B42-316 316 S.S. 69.5 12.7 6.7*6 42.9 58.7 154704AG5

CR63B51-316 316 S.S. 113.6 19 8.4*8 51.1 92.1 154707145

CR63B63-316 316 S.S. 113.6 19 8.4*8 63.7 92.1 154707155

CR100B102-316 316 S.S. 151.6 21.5 8.4*16 101.8 130.3 154709185

CR150B153-316 316 S.S. 202.5 24 8.4*20 153.1 181 154711205

CR200B204-316 316 S.S. 253.2 24.7 8.4*24 203.7 231.8 154713215

CR250B255-316 316 S.S. 336.5 28.5 10.3*30 254.5 306.5 154714225

CR300B305-316 316 S.S. 355.6 28.5 10.3*30 305.4 325.7 154715235

CR350B356-316 316 S.S. 419.1 28.5 10.3*36 356.1 388.9 154716245


P.C.D.


øD

øA

øC

B

Bored Blank

Rotatable-Tapped Bolt Holes

P.C.D.


CR35B25TAP 304L S.S. 69.5 12.7 M6*6 25.6 58.7 154804114

CR35B38TAP 304L S.S. 69.5 12.7 M6*6 38.3 58.7 154804134

CR35B42TAP 304L S.S. 69.5 12.7 M6*6 42.9 58.7 154804AG4

CR63B51TAP 304 S.S. 113.6 19 M8*8 51.1 92.1 154807143

CR63B63TAP 304 S.S. 113.6 19 M8*8 63.7 92.1 154807153

CR100B102TAP 304 S.S. 151.6 21.5 M8*16 101.8 130.3 154809183

CR150B153TAP 304 S.S. 202.5 24 M8*20 153.1 181 154811203

CR200B204TAP 304 S.S. 253.2 24.7 M8*24 203.7 231.8 154813213

CR250B255TAP 304 S.S. 336.5 28.5 M10*30 254.5 306.5 154814223

CR300B305TAP 304 S.S. 355.6 28.5 M10*30 305.4 325.7 154815233

CR350B356TAP 304 S.S. 419.1 28.5 M10*36 356.1 388.9 154816243

CR35B25TAP-316 316 S.S. 69.5 12.7 M6*6 25.6 58.7 154804115

CR35B38TAP-316 316 S.S. 69.5 12.7 M6*6 38.3 58.7 154804135

CR35B42TAP-316 316 S.S. 69.5 12.7 M6*6 42.9 58.7 154804AG5

CR63B51TAP-316 316 S.S. 113.6 19 M8*8 51.1 92.1 154807145

CR63B63TAP-316 316 S.S. 113.6 19 M8*8 63.7 92.1 154807155

CR100B102TAP-316 316 S.S. 151.6 21.5 M8*16 101.8 130.3 154809185

CR150B153TAP-316 316 S.S. 202.5 24 M8*20 153.1 181 154811205

CR200B204TAP-316 316 S.S. 253.2 24.7 M8*24 203.7 231.8 154813215

CR250B255TAP-316 316 S.S. 336.5 28.5 M10*30 254.5 306.5 154814225

CR300B305TAP-316 316 S.S. 355.6 28.5 M10*30 305.4 325.7 154815235

CR350B356TAP-316 316 S.S. 419.1 28.5 M10*36 356.1 388.9 154816245

øD

øA

øC

B


-

3 11


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd

-

3 12





Reducing Flange

Model No. Material A B C D E F *No. G *No. Parts No.

CF35RF16 304 S.S. 69.5 12.7 15.8 26.9 58.7 6.7*6 M4*6 17480409052

CF63RF16 304 S.S. 113.6 18 15.8 26.9 92.1 8.4*8 M4*6 17480709052

CF63RF35 304 S.S. 113.6 18 38.1 58.7 92.1 8.4*8 M6*6 17480709082

CF100RF35 304 S.S. 151.6 20 38.1 58.7 130.3 8.4*16 M6*6 17480909082

CF100RF63 304 S.S. 151.6 20 63.5 92.1 130.3 8.4*16 M8*8 17480909132

CF150RF35 304 S.S. 202.5 22 38.1 58.7 181 8.4*20 M6*6 17481109082

CF150RF63 304 S.S. 202.5 22 63.5 92.1 181 8.4*20 M8*8 17481109132

CF150RF100 304 S.S. 202.5 22 101.6 130.3 181 8.4*20 M8*16 17481109152

CF200RF35 304 S.S. 253.2 24.7 38.1 58.7 231.8 8.4*24 M6*6 17481309082

CF200RF63 304 S.S. 253.2 24.7 63.5 92.1 231.8 8.4*24 M8*8 17481309132

CF200RF100 304 S.S. 253.2 24.7 101.6 130.3 231.8 8.4*24 M8*16 17481309152

CF200RF150 304 S.S. 253.2 24.7 152.4 181 231.8 8.4*24 M8*20 17481309172

CF250RF35 304 S.S. 336.5 28.5 38.1 58.7 306.5 10.3*30 M6*6 17481409082

CF250RF63 304 S.S. 336.5 28.5 63.5 92.1 306.5 10.3*30 M8*8 17481409132

CF250RF100 304 S.S. 336.5 28.5 101.6 130.3 306.5 10.3*30 M8*16 17481409152

CF250RF150 304 S.S. 336.5 28.5 152.4 181 306.5 10.3*30 M8*20 17481409172

CF250RF200 304 S.S. 336.5 28.5 203.2 231.8 306.5 10.3*30 M8*24 17481409192

øE

øD

øC

øA

øG

øF

B

Half Nipple

Nonrotatable


B

C

Parts No.

CF16HN 304 S.S. 33.8 38 19.05 155502093

CF35HN 304 S.S. 69.5 63 38.1 155504133

CF63HN 304 S.S. 113.6 105 63.5 155507153

CF100HN 304 S.S. 151.6 135 101.6 155509183

CF150HN 304 S.S. 202.5 167 152.4 155511203

CF200HN 304 S.S. 253.2 167 203.2 155513213

Half Nipple

Rotatable


B

C

Parts No.

CR16HN 304 S.S. 33.8 38 19.05 155702093

CR35HN 304 S.S. 69.5 63 38.1 155704133

CR63HN 304 S.S. 113.6 105 63.5 155707153

CR100HN 304 S.S. 151.6 135 101.6 155709183

CR150HN 304 S.S. 202.5 167 152.4 155711203

CR200HN 304 S.S. 253.2 167 203.2 155713213

øA

øA

B

B

øC

øC


-

3 13


ddddddddc




dd

dd


dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd dd dd

dd



dd

dd





















dd dd dd dd

dd dddddddd

dd

dd dd dd dd

dd dd dd dd

dddddddd

-

3 14





Plate Nut


A

CF16PN 304 S.S. 19.5 4 13.5 M4 21320541

CF35PN 304 S.S. 39.5 6 29.5 M6 21320741

CF63PN 304 S.S. 50.2 8 35.2 M8 21321041

Cap


CF16CAP Polyethylene CF16 5085EZ

CF35CAP Polyethylene CF35 5085GZ

CF63CAP Polyethylene CF63 5085H0

CF100CAP Polyethylene CF100 5085HY

CF150CAP Polyethylene CF150 5085HZ

CF200CAP Polyethylene CF200 5085LZ

CF250CAP Polyethylene CF250 5085LU

CF300CAP Polyethylene CF300 5085M4

CF350CAP Polyethylene CF350 5085ML

B

C

øD

Copper Gasket

Model No. Surface FixPack A B C Parts No.

Treatment Flange Quantity

CF16CG CF16 10 21 16 2 21310581

CF35CG CF35 10 48 37 2 21310781

CF63CG CF63 10 82 63 2 21311081

CF100CG CF100 10 120 101 2 21311281

CF150CG CF150 5 171 152 2 21311481

CF200CG CF200 5 222 203 2 21311681

CF250CG CF250 5 294 269 2 21311781

CF16SPCG Silver Plated CF16 10 21 16 2 21310591







C

øB

øA


-

3 15


709

TEL/ 06-2460296 FAX/ 06-2471701

HEAD QUARTERS



TEL/ +886-6-2460296 FAX/ +886-6-2471701


303

TEL/ 03-5973337 FAX/ 03-5973073




TEL/ +886-3-5973337 FAX/ +886-3-5973073

TEL/ +86-21-50460355

FAX/ +86-21-50460234




TEL/ +86-21-50460355

FAX/ +86-21-50460234



VACUUM 2002

SOLUTION

SECTION 4~5

FITTING SERIES

ADAPTOR SERIES


FITTING

SERIES

ADAPTOR

SERIES

CONTENTS




Corrosion Resistance Guide

KF Braided Flexible Hoses

KF Flexible Hoses

KF Compressible Bellows Connections

ISO Compressible Bellows Connections

ISO Compressible Hoses

CF Flexible Hoses-1 Flange Rotatable

CF Compressible Bellows Connections-1

Flange Rotatable

Conical Reducers

90 o Elbows

90 o Elbows with Tangents

45 o Elbows


Tees

4-Way Crosses

Unequal Tees

Unequal 4-Ways Crosses

KF 90 o Elbows

KF Tees

KF 4-Way Crosses

KF Unequal Tees

ISO Full Nipples

ISO 90 o Elbows

ISO Tees

ISO 4-Way Crosses

CF Nipples-Fixed

CF Nipples-1 Flange Rotatable

CF 90 o Elbows-Fixed

CF 90 o Elbows-Rotatable

CF Tees-Fixed

CF Tees-2 Flanges Rotatable

CF 4 Way Crosses-Fixed

CF 4-Way Crosses-2 Flange Rotatable

4 -

4 -

4 - 1

4 - 2

4 - 3

4 - 3

4 - 4

4 - 5

4 - 6

4 - 7

4 - 8

4 - 8

4 - 9

4 - 9

4 - 10

4 - 10

4 - 11

4 - 12

4 - 13

4 - 13

4 - 14

4 - 15

4 - 16

4 - 16

4 - 17

4 - 17

4 - 18

4 - 18

4 - 19

4 - 19

4 - 20

4 - 20

4 - 21

4 - 21


ADAPTOR SERIES


Explanation of ISO Pipe Thread

Thread Symbol List

ANSI-KF Tubulated Adaptor

ANSI-KF Tubulated Adaptor with O’Ring Groove

CF-ISO Tubulated Adaptor

CF-KF Tubulated Adaptor

ISO-KF Tubulated Adaptor

CF Reducing Adaptor-Fixed

CF Reducing Adaptor-Small Flange Rotatable

KF-VCR Male Adaptor

KF-VCR Female Adaptor

KF-Swagelok Adaptor

KF Rubber Hose Adaptor

KF Male Pipe Adaptor

KF Female Pipe Adaptor

KF Quick-Disconnect Adaptor

KF-KF Conical Reducing Adaptor

ISO-KF Conical Reducing Adaptor

ISO-ISO Conical Reducing Adaptor

5 -

5 -

5 -

5 - 1

5 - 1

5 - 2

5 - 2

5 - 3

5 - 4

5 - 4

5 - 5

5 - 5

5 - 6

5 - 6

5 - 7

5 - 8

5 - 9

5 - 10

5 - 10

5 - 11


4 -





Feature:

HTC tube fittings are convenient "building block" components. They offer great flexibility in

the design and construction of high and ultra-high vacuum system.

There are two type of bellows of HTC's products, or flexible metal hoses. "Flexible hoses"

have concertina walls made by pressurizing a thin-wall tube, they can be bent but not be

compressed. The other type is "Flexible bellows connections", this type can bent and

compressed. When possible, design the system so that the bellows make only a single bend

or curve. Multiple bends concentrate stress at minimum radius points, reducing life

expectancy during flexing or vibration. An elbow on one or both ends will usually eliminate

multiple bends. It is difficult to make a short bellows fit between parallel flange faces that are

not coaxial.


Flanges


Fittings


Flexible hoses

: 304 S.S.

Flexible bellows connections : 316Ti, 321 S.S., 316L S.S, 316 S.S., 304 S.S.

Htc tube fitting are made from welded pipe or tube.


Seamless pipe or tube are available upon request.

Applications:

Piping system.

Tube and Pipe O.D. Designator

Tube

Pipe

(ANSI B36.19)

Pipe

(JIS G3459)

IDF 3A ISO

DIN

(DIN11850)

Nom. Size O.D. Nom. Size O.D. Nom. Size O.D. Nom. Size O.D. Nom. Size O.D. Nom. Size O.D. Nom. Size O.D.

1/8

3/16

1/4

5/16

3/8

1/2

5/8

3/4

7/8

1

1 1/4

1 1/2

2

2 1/2

3

3 1/2

4

5

6

8

3.18

4.76

6.35

7.94

9.53

12.7

15.88

19.05

22.23

25.4

31.8

38.1

50.8

63.5

76.2

88.9

101.6

114.3

127

139.8

152.4

165.1

203.2

1/8

3/16

1/4

5/16

3/8

1/2

5/8

3/4

7/8

1

1 1/4

1 1/2

2

2 1/2

3

3 1/2

4

5

6

8

10.29

13.72

17.15

21.34

26.67

33.4

42.16

48.26

60.33

73.03

88.9

101.6

114.3

141.3

168.3

219.1

6A

8A

10A

15A

20A

25A

32A

40A

50A

65A

80A

90A

100A

125A

150A

200A

10.5

13.8

17.3

21.7

27.2

34

42.7

48.6

60.5

76.3

89.1

101.6

114.3

139.8

165.2

216.3

1

1 1/4

1 1/2

2

2 1/2

3

3 1/2

4

JIS G3459 : Stainless Steel Pipes (Sch10)

IDF : International Daily Federation

3A : 3-A Sanitary Standards (International Association of Milk, Food and Environment Sanitariums, U.S Public Health Service)

ISO : International Organization for Standardization

DIN : Deutsches Insitut fur Nonmung (Germany DIN 11850)

25.4

31.8

38.1

50.8

63.5

76.3

89.1

101.6

1

1 1/2

2

2 1/2

3

4

25.4

38.1

50.8

63.5

76.2

101.6

12

17.2

21.3

25

33.7

38

40

51

63.5

70

76.1

88.9

101.6

114.3

139.7

168.3

219.1

273

323.9

355.6

406.4

DN10

15

20

25

32

40

50

65

80

100

125

150

12

18

22

28

34

40

52

70

85

104

129

154

Connections of KF-series Fittings

Connections of ISO-series Fittings

Connections of CF-series Fittings

4

-

4

-




Corrosion Resistance Guide

Media Conveyed or Atmosphere Tempe AISl AISl Media Conveyed or Atmosphere

-rature type 304 type 316

Acetone

Acetyiene

Sulfur.Deoxide (Moist)

Sulfur.Deoxide (Dry)

Ethyl Alcohol

Methyl Alcohol

Ammonia R.T.

Ammonia Gas Hot

Sulfar (Dry)

Sulfar (Wet) R.T. * *

Sulfar (Molten)

Sulfar (Moist) R.T.

Ethylene Glvcol R.T.

Ethers R.T

Alminum Chloride

Iron Chloride

Magnesium Chloride

Chlorine (Dry)

Chlorine (Moist)

Hydrogen Peroxide R.T. *

Hydrogen Peroxide Boil *

Sea Water

Gasoline

Glycerin

Crude Oil

Ethyl Acetate

Oxygen

Carbon Tetrachloride (Dry)

Carbon Tetrachloride with water

Steam

Oxalic Acid (10%)

Mercury

Potassium Hydroxide (




KF Flexible Hoses

øA


B

Parts No.

KF16FX250 304 S.S. 30 250 40010550250AA

KF16FX500 304 S.S. 30 500 40010550500AA

KF16FX750 304 S.S. 30 750 40010550750AA

KF16FX1000 304 S.S. 30 1000 40010551000AA

KF25FX250 304 S.S. 40 250 40010560250AA

KF25FX500 304 S.S. 40 500 40010560500AA

KF25FX750 304 S.S. 40 750 40010560750AA

KF25FX1000 304 S.S. 40 1000 40010561000AA

KF40FX250 304 S.S. 55 250 40010570250AA

KF40FX500 304 S.S. 55 500 40010570500AA

KF40FX750 304 S.S. 55 750 40010570750AA

KF40FX1000 304 S.S. 55 1000 40010571000AA

KF50FX250 304 S.S. 75 250 40010580250AA

KF50FX500 304 S.S. 75 500 40010580500AA

KF50FX750 304 S.S. 75 750 40010580750AA

KF50FX1000 304 S.S. 75 1000 40010581000AA

B

KF Compressible Bellows Connections

C

Compressed length

Model No. Material

Excluding Bellows

A B C

Parts No.

KF10FXC100 304 S.S. 30 100 80 40310410100AA

KF16FXC100 304 S.S. 30 100 80 40310430100AA

KF25FXC100 304 S.S. 40 100 80 40310440100AA

KF40FXC100 304 S.S. 55 100 80 40310450100AA

KF50FXC100 304 S.S. 75 100 80 40310460100AA

ISO Compressible Bellows Connections


øA

øA

B

B

C




A B C

Parts No.

ISO63FXC140 304 S.S. 95 140 125 40310470140BB

ISO80FXC187 304 S.S. 110 187 160 40310480187BB

ISO100FXC187 304 S.S. 130 187 160 40310490187BB

ISO160FXC220 304 S.S. 180 220 200 40310500220BB




ISO Flexible Hoses

øA


B

Parts No.

ISO63FX250 304 S.S. 95 250 40010590250BB

ISO63FX500 304 S.S. 95 500 40010590500BB

ISO63FX750 304 S.S. 95 750 40010590750BB

ISO63FX1000 304 S.S. 95 1000 40010591000BB

ISO80FX250 304 S.S. 110 250 40010600250BB

ISO80FX500 304 S.S. 110 500 40010600500BB

ISO80FX750 304 S.S. 110 750 40010600750BB

ISO80FX1000 304 S.S. 110 1000 40010601000BB

ISO100FX250 304 S.S. 130 250 40010610250BB

ISO100FX500 304 S.S. 130 500 40010610500BB

ISO100FX750 304 S.S. 130 750 40010610750BB

ISO100FX1000 304 S.S. 130 1000 40010611000BB

B

CF Flexible Hoses-1 Flange Rotatable


B

Parts No.


øA

ROTATABLE

CF16FX250R 304 S.S. 33.8 250 40010550250FH

CF16FX500R 304 S.S. 33.8 500 40010550500FH

CF16FX750R 304 S.S. 33.8 750 40010550750FH

CF16FX1000R 304 S.S. 33.8 1000 40010551000FH

CF35FX250R 304 S.S. 69.5 250 40010570250FH

CF35FX500R 304 S.S. 69.5 500 40010570500FH

CF35FX750R 304 S.S. 69.5 750 40010570750FH

CF35FX1000R 304 S.S. 69.5 1000 40010571000FH

CF63FX250R 304 S.S. 113.6 250 40010590250FH

CF63FX500R 304 S.S. 113.6 500 40010590500FH

CF63FX750R 304 S.S. 113.6 750 40010590750FH

CF63FX1000R 304 S.S. 113.6 1000 40010591000FH

CF100FX250R 304 S.S. 151.6 250 40010610250FH

CF100FX500R 304 S.S. 151.6 500 40010610500FH

CF100FX750R 304 S.S. 151.6 750 40010610750FH

CF100FX1000R 304 S.S. 151.6 1000 40010611000FH

B




CF Compressible Bellows Connections-1 Flange Rotatable



A B C

Parts No.

CF16FXC150R 304 S.S. 33.8 150 130 40310430150FH

CF35FXC180R 304 S.S. 69.5 180 160 40310450180FH

CF63FXC210R 304 S.S. 113.6 210 190 40310470210FH

CF100FXC270R 304 S.S. 151.6 270 250 40310490270FH

CF150FXC300R 304 S.S. 202.5 300 280 40310500300FH

øA

ROTATABLE


B

C

Conical Reducers

Model No. Material A B C t

Parts No.

25-16CR 304 S.S. 35 25.4 19.05 1.5 16230030024

40-16CR 304 S.S. 60.3 38.1 19.05 1.65 16230050024

40-25CR 304 S.S. 60.3 38.1 25.4 1.65 16230050034

50-25CR 304 S.S. 60.3 50.8 25.4 1.65 16230060034

50-40CR 304 S.S. 60.3 50.8 38.1 1.65 16230060054

63-40CR 304 S.S. 60.3 63.5 38.1 1.65 16230070054

63-50CR 304 S.S. 60.3 63.5 50.8 1.65 16230070064

80-50CR 304 S.S. 92 76.2 50.8 1.65 16230080064

80-63CR 304 S.S. 92 76.2 63.5 1.65 16230080074

100-50CR 304 S.S. 92 101.6 50.8 2.5 16230090064

100-63CR 304 S.S. 92 101.6 63.5 2.5 16230090074

100-80CR 304 S.S. 92 101.6 76.2 2.5 16230090084

150-80CR 304 S.S. 152.4 152.4 76.2 3 16230110084

150-100CR 304 S.S. 152.4 152.4 101.6 3 16230110094


øB

t

A

øC

-

4 8





90 o Elbows

Model No. Material A B t

Parts No.

16EL90A 304 S.S. 28.6 19.05 1.65 16030020024

25EL90A 304 S.S. 38.1 25.4 1.65 16030030034

40EL90A 304 S.S. 57.2 38.1 1.65 16030050054

50EL90A 304 S.S. 76.2 50.8 1.65 16030060064

63EL90A 304 S.S. 95.2 63.5 1.65 16030070074

80EL90A 304 S.S. 114.3 76.2 1.65 16030080084

100EL90A 304 S.S. 152.4 101.6 2 16030090094

150EL90A 304 S.S. 228.6 152.4 2.7 16030110114


Model No. Material A B R t

Parts No.

16ELT90A 304 S.S. 34.5 19.05 28.6 1.65 16240020024

25ELT90A 304 S.S. 52.4 25.4 38.1 1.65 16240030034

40ELT90A 304 S.S. 74.6 38.1 57.2 1.65 16240050054

50ELT90A 304 S.S. 103.2 50.8 76.2 1.65 16240060064

63ELT90A 304 S.S. 131.8 63.5 95.3 1.65 16240070074

80ELT90A 304 S.S. 134.9 76.2 114.3 1.65 16240080084

100ELT90A 304 S.S. 211.1 101.6 152.4 2 16240090094

t

t

øB

øB

A

A

R

A

A

45 o Elbows

Model No. Material A H t

Parts No.

16EL45A 304 S.S. 19.05 8 1.65 16070020024

25EL45A 304 S.S. 25.4 15.9 1.65 16070030034

40EL45A 304 S.S. 38.1 23.8 1.65 16070050054

50EL45A 304 S.S. 50.8 31.8 1.65 16070060064

63EL45A 304 S.S. 63.5 39.7 1.65 16070070074

80EL45A 304 S.S. 76.2 47.6 1.65 16070080084

100EL45A 304 S.S. 101.6 63.5 2 16070090094


Model No. Material A B t

Parts No.

16ELT45A 304 S.S. 19.05 19.3 1.65 16250020024

25ELT45A 304 S.S. 25.4 30.2 1.65 16250030034

40ELT45A 304 S.S. 38.1 41.3 1.65 16250050054

50ELT45A 304 S.S. 50.8 58.7 1.65 16250060064

63ELT45A 304 S.S. 63.5 76.2 1.65 16250070074

80ELT45A 304 S.S. 76.2 93.7 1.65 16250080084

100ELT45A 304 S.S. 101.6 122.2 2 16250090094

t

B

t

B

H

øA

45 o

øA


-

4 9

-

4 10

Tees





Model No. Material A B C t

Parts No.

16TA 304 S.S. 34.5 19.05 69 1.65 16150020024

25TA 304 S.S. 47.6 25.4 95.2 1.65 16150030034

40TA 304 S.S. 57.2 38.1 114.3 1.65 16150050054

50TA 304 S.S. 76.2 50.8 152.4 1.65 16150060064

63TA 304 S.S. 76.2 63.5 152.4 1.65 16150070074

80TA 304 S.S. 82.5 76.2 165.1 1.65 16150080084

100TA 304 S.S. 98.4 101.6 196.8 2 16150090094

150TA 304 S.S. 127 152.4 254 2.7 16150110114

4-Way Crosses

Model No. Material A B C t Parts No.

16XA 304 S.S. 34.5 19.05 69 1.65 16190020024

25XA 304 S.S. 47.6 25.4 95.2 1.65 16190030034

40XA 304 S.S. 57.2 38.1 114.3 1.65 16190050054

50XA 304 S.S. 76.2 50.8 152.4 1.65 16190060064

63XA 304 S.S. 76.2 63.5 152.4 1.65 16190070074

80XA 304 S.S. 82.5 76.2 165.1 1.65 16190080084

100XA 304 S.S. 98.4 101.6 196.8 2 16190090094

150XA 304 S.S. 127 152.4 254 2.7 16190110114

t

t

øB

øB

C

C

A

A

øB

øB

A

A

C

Unequal Tees

Model No. Material A B C D E t Parts No.

25UT16A 304 S.S. 48.2 33.7 25.4 19.05 96.4 1.65 16170030024

40UT16A 304 S.S. 57.2 48.2 38.1 19.05 114.3 1.65 16170050024

40UT25A 304 S.S. 57.2 54 38.1 25.4 114.3 1.65 16170050034

50UT16A 304 S.S. 76.2 54.4 50.8 19.05 152.4 1.65 16170060024

50UT25A 304 S.S. 76.2 60.3 50.8 25.4 152.4 1.65 16170060034

50UT40A 304 S.S. 76.2 63.5 50.8 38.1 152.4 1.65 16170060054

80UT63A 304 S.S. 82.5 82.5 76.2 63.5 165 1.65 16170080074

100UT50A 304 S.S. 98.4 101.6 101.6 50.8 196.8 2 16170090064

100UT63A 304 S.S. 98.4 95.3 101.6 63.5 196.8 2 16170090074

100UT80A 304 S.S. 98.4 95.3 101.6 76.2 196.8 2 16170090084

150UT80A 304 S.S. 127 120.7 152.4 76.2 254 2.77 16170110084

150UT100A 304 S.S. 127 123.8 152.4 101.6 254 2.77 16170110094

E

øD

t

A

øC

B


-

4 11

-

4 12





Unequal 4-Ways Crosses

Model No. Material A B C D E F t Parts No.

25UX16A 304 S.S. 48.2 33.7 25.4 19.05 96.4 67.4 1.65 16210030024

40UX16A 304 S.S. 57.2 48.2 38.1 19.05 114.3 96.4 1.65 16210050024

40UX25A 304 S.S. 57.2 54 38.1 25.4 114.3 108 1.65 16210050034

50UX16A 304 S.S. 76.2 54.4 50.8 19.05 152.4 108.8 1.65 16210060024

50UX25A 304 S.S. 76.2 60.3 50.8 25.4 152.4 120.6 1.65 16210060034

50UX40A 304 S.S. 76.2 63.5 50.8 38.1 152.4 127 1.65 16210060054

80UX63A 304 S.S. 82.5 82.5 76.2 63.5 165 165 1.65 16210080074

100UX50A 304 S.S. 98.4 101.6 101.6 50.8 196.8 203.2 2 16210090064

100UX63A 304 S.S. 98.4 95.3 101.6 63.5 196.8 190.6 2 16210090074

100UX80A 304 S.S. 98.4 95.3 101.6 76.2 196.8 190.6 2 16210090084

150UX80A 304 S.S. 127 120.7 152.4 76.2 254 241.4 2.77 16210110084

150UX100A 304 S.S. 127 123.8 152.4 101.6 254 247.6 2.77 16210110094

øD

E

t

A

øC

B

F

KF 90 o Elbows

Model No. Available Area Material A B C R Parts No.

KF16EL90A USA 304 S.S. 38.3 19.05 30 28.6 16031021024

KF25EL90A USA 304 S.S. 56.2 25.4 40 38.1 16031031034

KF40EL90A USA 304 S.S. 78.4 38.1 55 57.2 16031051054

KF50EL90A USA 304 S.S. 107 50.8 75 76.2 16031061064

KF16EL90E Europe 304 S.S. 40 19.05 30 28.6 16041021024




KF Tees


KF16TA USA 304 S.S. 38.3 19.05 30 76.2 16151021024

KF25TA USA 304 S.S. 51.4 25.4 40 102.8 16151031034

KF40TA USA 304 S.S. 61 38.1 55 122 16151051054

KF50TA USA 304 S.S. 80 50.8 75 160 16151061064

KF16TE Europe 304 S.S. 40 19.05 30 80 16161021024

KF25TE Europe 304 S.S. 50 25.4 40 100 16161031034

KF40TE Europe 304 S.S. 65 38.1 55 130 16161051054

KF50TE Europe 304 S.S. 70 50.8 75 140 16161061064

øB

R

A

D

øC

øB

A

A

øC

A


-

4 13

-

4 14





KF 4-Way Crosses


KF16XA USA 304 S.S. 38.1 19.05 30 76.2 16191021024

KF25XA USA 304 S.S. 51.4 25.4 40 102.8 16191031034

KF40XA USA 304 S.S. 61 38.1 55 122 16191051054

KF50XA USA 304 S.S. 80 50.8 75 160 16191061064

KF16XE Europe 304 S.S. 40 19.05 30 80 16201021024

KF25XE Europe 304 S.S. 50 25.4 40 100 16201031034

KF40XE Europe 304 S.S. 65 38.1 55 130 16201051054

KF50XE Europe 304 S.S. 70 50.8 75 140 16201061064

D

øC

øB

A

A

KF Unequal Tees

øC

Model No. Available Area Material A B C D E F Parts No.

KF25UT16A USA 304 S.S. 52 37.5 40 30 25.4 19.05 16171031024

KF40UT16A USA 304 S.S. 61 52 55 30 38.1 19.05 16171051024

KF40UT25A USA 304 S.S. 61 57.8 55 40 38.1 25.4 16171051034

KF50UT16A USA 304 S.S. 80 58.2 75 30 50.8 19.05 16171061024

KF50UT25A USA 304 S.S. 80 64.1 75 40 50.8 25.4 16171061034

KF50UT40A USA 304 S.S. 80 67.3 75 55 50.8 38.1 16171061054

KF25UT16E Europe 304 S.S. 50 40 40 30 25.4 19.05 16181031024




KF50UT25 Europe 304 S.S. 70 65 75 40 50.8 25.4 16181061034


øF

øD

øE

A

B


-

4 15

-

4 16





ISO Full Nipples


Parts No.

ISO63N 304 S.S. 95 63.5 100 16012072074

ISO80N 304 S.S. 110 76.2 100 16012082084

ISO100N 304 S.S. 130 101.6 100 16012092094

ISO160N 304 S.S. 180 152.4 100 16012122124

ISO200N 304 S.S. 240 203.2 100 16012132134

ISO250N 304 S.S. 290 254 100 16012142144

ISO320N 304 S.S. 370 304.8 200 16012162164

ISO400N 304 S.S. 450 406.4 200 16012182184

ISO500N 304 S.S. 550 508 200 16012202204

ISO 90 o Elbows


Parts No.

ISO63EL90A 304 S.S. 138.4 63.5 95 16032072074

ISO80EL90A 304 S.S. 141.5 76.2 110 16032082084

ISO100EL90A 304 S.S. 217.7 101.6 130 16032092094

ISO160EL90A 304 S.S. 235.2 152.4 180 16032122124

øA

øB

øB

A

C

øC

A

ISO Tees


ISO63TA 304 S.S. 82.8 63.5 95 165.6 16152072074

ISO80TA 304 S.S. 89.15 76.2 110 178.3 16152082084

ISO100TA 304 S.S. 105 101.6 130 210 16152092094

ISO160TA 304 S.S. 133.6 152.4 180 267.2 16152122124

ISO 4-Way Crosses


ISO63XA 304 S.S. 82.8 63.5 95 165.6 16192072074

ISO80XA 304 S.S. 89.15 76.2 110 178.3 16192082084

ISO100XA 304 S.S. 105 101.6 130 210 16192092094

ISO160XA 304 S.S. 133.6 152.4 180 267.2 16192122124

D

øB

D

øB

øB

A

øB

A

øC

øC

A

A


-

4 17

-

4 18





CF Nipples-Fixed


Parts No.

CF16N 304 S.S. 33.8 76 19.05 16018028024

CF35N 304 S.S. 69.5 126 38.1 16018048044

CF63N 304 S.S. 113.6 210 63.5 16018078074

CF100N 304 S.S. 151.6 270 101.6 16018098094

CF150N 304 S.S. 202.5 334 152.4 16018118114

CF200N 304 S.S. 253.2 334 203.2 16018138134

CF Nipples-1 Flange Rotatable


Parts No.

øA

øA

øC

øC

B

B

ROTATABLE

CF16NR 304 S.S. 33.8 76 19.05 16016028024

CF35NR 304 S.S. 69.5 126 38.1 16016048044

CF63NR 304 S.S. 113.6 210 63.5 16016078074

CF100NR 304 S.S. 151.6 270 101.6 16016098094

CF150NR 304 S.S. 202.5 334 152.4 16016118114

CF200NR 304 S.S. 253.2 334 203.2 16016138134

CF 90 o Elbows-Fixed


Parts No.

CF16EL90 304 S.S. 37.5 19.05 33.8 16038028024

CF35EL90 304 S.S. 79.9 38.1 69.5 16038048044

CF63EL90 304 S.S. 141.3 63.5 113.6 16038078074

CF100EL90 304 S.S. 222.2 101.6 151.6 16038098094

CF150EL90 304 S.S. 241.3 152.4 202.5 16038118114

CF 90 o Elbows-Rotatable

ROTATABLE


Parts No.

øB

øB

A

A

øC

øC

A

ROTATABLE

CR16EL90 304 S.S. 42.7 19.05 33.8 16036026024

CR35EL90 304 S.S. 79.9 38.1 69.5 16036046044

CR63EL90 304 S.S. 141.3 63.5 113.6 16036076074

CR100EL90 304 S.S. 222.2 101.6 151.6 16036096094

CR150EL90 304 S.S. 241.3 152.4 202.5 16036116114

A


-

4 19

-

4 20





CF Tees-Fixed


CF16T 304 S.S. 37.5 19.05 33.8 75 16158028024

CF35T 304 S.S. 62.5 38.1 69.5 125 16158048044

CF63T 304 S.S. 85.7 63.5 113.6 171.4 16158078074

CF100T 304 S.S. 109.5 101.6 151.6 219 16158098094

CF150T 304 S.S. 139.7 152.4 202.5 279.4 16158118114

CF Tees-2 Flanges Rotatable

ROTATABLE


CR16T 304 S.S. 47.2 19.05 33.8 94.4 16156026024

CR35T 304 S.S. 62.5 38.1 69.5 125 16156046044

CR63T 304 S.S. 85.7 63.5 113.6 171.4 16156076074

CR100T 304 S.S. 109.5 101.6 151.6 219 16156096094

CR150T 304 S.S. 139.7 152.4 202.5 279.4 16156116114

D

øB

øB

A

øB

D

øB

A

øC

A

øC

A

CF 4 Way Crosses-Fixed


CF16X 304 S.S. 37.5 19.05 33.8 75 16198028024

CF35X 304 S.S. 62.5 38.1 69.5 125 16198048044

CF63X 304 S.S. 85.7 63.5 113.6 171.4 16198078074

CF100X 304 S.S. 109.5 101.6 151.6 219 16198098094

CF150X 304 S.S. 139.7 152.4 202.5 279.4 16198118114

CF 4-Way Crosses-2 Flange Rotatable

ROTATABLE


CR16X 304 S.S. 47.2 19.05 33.8 94.4 16196026024

CR35X 304 S.S. 62.5 38.1 69.5 125 16196046044

CR63X 304 S.S. 85.7 63.5 113.6 171.4 16196076074

CR100X 304 S.S. 109.5 101.6 151.6 219 16196096094

CR150X 304 S.S. 139.7 152.4 202.5 279.4 16196116114

D

øB

øB

D

øB

A

øB

A

øC

A

øC

A


-

4 21

5 -





Feature:

Adaptor flanges mate one type of flange system to another. They are available for all major

systems, such as ConFlat-compatible (CF), KF, ISO and ANSI. Unless stated otherwise, all

adaptors are stainless steel.

Most flange systems have been adapted to the ANSI flanges. This catalog lists only the most

popular, but we can provide almost unlimited variations and modifications to suit individual

requirements.


Flange : 304 S.S. (Other material available upon request)

Tube or Pipe : 304 S.S. (Other material available upon request)

Adaptor : 304 S.S.(Other material available upon request)


Applications:

Connection exchange.

Piping size variations and modifications to suit individual requirement.

KF female pipe adaptors are used to insert a PT (NPT) threaded pressure gauge or up-to-air

valve into a foreline. Often a KF tee is inserted into the foreline joint and the third port closed

with an adaptor.

KF male pipe adaptors are flanged stubs that terminate in threads ranging from 1/8" to 1".

Use Teflon tape for sealing threaded joint.

KF rubber hose adaptors are made from stainless steel with a flange at one end and a

rubber tubing adaptor at the other. The tubing adaptor is compatible with standard hose

bores.

KF quick-disconnect adaptor mates a KF flange with an O'ring quick coupling. The quick

couplings make a vacuum joint with any smooth-surfaced standard O.D. tube. Their most

common application is attaching tubulated ion or thermocouple gauges to a system.

Swagelok ® fittings provide a torque-free seal at all tubing connections and eliminate

hazardous leaks in instrumentation and process tubing.

VCR ® adaptors are used to connect a male or female VCR component to an existing flange

system. VCR’s seal by the compression of a gasket (usually copper) between two highly

polished beads on the surfaces of the VCR connectors.

5

-

5

-




Explanation of ISO Pipe Thread

The ISO 228/1 and 7/1 threads were created by the International Standard Organization to

standardize the nomenclature of several international pipe threads. The 228/1 is parallel

thread system where a pressure tight seal is not made on the thread. With the 228/1, the seal

is usually made metal-to-metal against the female port or with a gasket.

The 7/1 is a tapered system where a pressure tight seal is made on the thread.

The 7/1 looks similar to the NPT thread, except the 7/1 has a 55° inclined angle on the

threads. Also, number of threads per inch varies slightly.

Pipe Thread Symbol

Type Symbol

R (male)

Specification

Taper Rc JIS B 0203 (PT), DIN 2999, ISO 7/1, BS21 (BSPT)

Thread (female)

N ANSI/ASME B1.20.1 (NPT)

Parallel G JIS B0202 (PF), ISO 228/1, BS2779 (BSPP), DIN 3852 part 2

Thread U American Standard Unified Screw Thread

FINGER TIGHTENING

WRENCH TIGHTENING

NPT Thread E1 L1 L3 nominal L4

Thread size per inch mm Nominal mm threads mm mm

1/8 27 9.50 4.10 3 2.82 9.97

1/4 18 12.50 5.79 3 4.23 15.10

3/8 18 15.93 6.10 3 4.23 15.26

1/2 14 19.77 8.13 3 5.44 19.86

3/4 14 25.12 8.61 3 5.44 20.15

1 11.1/2 31.46 10.16 3 6.63 25.01

1.1/4 11.1/2 40.22 10.67 3 6.63 25.62

1.1/2 11.1/2 46.29 10.67 3 6.63 26.04

L1 L3 L 4

E 1

BSP TAPER

BSPP

b2

45 O

b1 a1

d4

d1

d1

45 O

E

45 O

S2

S1

BSP Taper

Threads d1 E d4 al S1 S2 b1 b2

BSPP BSPT Per nominal min max min min

Inch mm mm mm mm mm mm mm mm

1/8 1/8 28 9.73 3.97 15 1 9.53 7.14 8 5.5

1/4 1/4 19 13.16 6.05 19 1.5 14.28 9.40 12 8.5

3/8 3/8 19 16.66 6.35 23 2 14.28 9.40 12 8.5

1/2 1/2 14 20.95 8.16 27 2.5 19.05 14.28 14 10.5

3/4 3/4 14 26.44 9.2 33 2.5 19.05 15.88 16 13

1 1 11 33.25 10.39 40 2.5 23.80 18.24 18

1.1/4 1.1/4 11 41.91 12.7 50 2.5 24 19.84 20

1.1/2 1.1/2 11 47.80 12.7 56 2.5 25.4 22.23 22

BSPP

5 -

5

-




Thread Symbol List Thread Symbol List

Country Symbol Description Code No.

M Metric screw threads

JIS B 0205,

0207

S Miniature threads JIS B 0201

UNC Unified coarse threads JIS B 0206

UNF Unified fine threads JIS B 0208

Tr Metric trapezoidal threads JIS B 0216

TW 29° trapezoidal threads JIS B 0222

R Male taper pipe threads JIS B 0203

Rc Female taper pipe threads JIS B 0203

Rp Male taper pipe threads for female straight pipe threads JIS B 0203

Japan G Straight pipe threads JIS B 0202

PF Straight pipe threads not include in ISO JIS B 0202

PT Taper pipe threads not include in ISO JIS B 0203

PS Taper pipe threads not include in ISO JIS B 0203

CTC Thin wall cable pipe threads JIS B 0204

CTG Thick wall cable pipe threads JIS B 0204

BC Threads for automobile JIS B 0225

SM Threads for sewing machine JIS B 0226

E Threads for bulb JIS C 7709

TV Tire valve threads for automobile JIS D 4207

CTV Tire valve threads for bicycle JIS D 9422

M Metric screw threads ISO 261

S ISO miniature threads ISO R 1501

Tr ISO metric trapezoidal threads ISO 2902

UNC ISO inch coarse threads ISO 263

UNF ISO inch fine threads ISO 263

UNEF ISO inch extra-fine threads ISO 263

UN ISO inch threads ( constant pitch series ) ISO 263

UNJC Inch series UNJ threads for aircraft & aerospace ( coarse threads ) ISO 3161

UNJF Inch series UNJ threads for aircraft & aerospace ( fine threads ) ISO 3161

ISO UNJEF Inch series UNJ threads for aircraft & aerospace ( extra-fine threads ) ISO 3161

UNJ Inch series UNJ threads for aircraft & aerospace ( constant pitch series ) ISO 3161

MJ Metric threads for aircraft & aerospace ISO 5855

R Male taper pipe threads ISO 7/1

Rc Female taper pipe threads ISO 7/1

Rp Male taper pipe threads for female straight pipe threads ISO 7/1

G Straight pipe threads ISO 228/1

GL Threads for glass containers ISO R 1115

V Tire valve threads ISO 4570/1~3


UN Unified inch screw threads ANSI B 1.1

UNC/UNRC Unified coarse thread series ANSI B 1.1

UNF/UNRF Unified fine thread series ANSI B 1.1

UNEF/UNREF Unified extra-fine thread series ANSI B 1.1

4UN/4UNR Unified constant-pitch series with 4-threads ANSI B 1.1








UN/UNRS

Unified threads of special diameters, pitches and lengths of

engagement

ANSI B 1.1

NR American National thread with a 0.108p to 0.144p controlled root radius MIL-B-7838

Acme Acme screw threads ANSI B 1.5

Stub-Acme Stub Acme screw threads ANSI B 1.8

Butt Buttress inch screw threads ANSI B 1.9

UNM Unified miniature thread series ANSI B 1.10

NC5 Class 5 interference-fit thread ANSI B 1.12

NPT American Standard taper pipe threads for general use

ANSI/ASME

B 1.20.1

USA

NPTR American Standard taper pipe threads for railing joint

ANSI/ASME

B 1.20.1

NPTR American Standard taper pipe threads for railing joint

ANSI/ASME

B 1.20.1

NPSL

American Standard straight pipe threads for loose-fitting

mechanical joint with locknut

ANSI/ASME

B 1.20.1

NPSM

American Standard straight pipe threads for free-fitting

mechanical joint for fixtures

ANSI/ASME

B 1.20.1

NPSH

American Standard straight pipe threads for loose-fitting

mechanical joint for hose coupling

ANSI/ASME

B 1.20.1

NPTF Dryseal American Standard taper pipe threads

ANSI B

1.20.3,1.20.4

NPTF Dryseal American Standard taper pipe threads

ANSI B

1.20.3,1.20.4

PTF-SAE

SHORT

Dryseal SAE short taper threads

ANSI B

1.20.3,1.20.4

PTF-SPL

SHORT

Dryseal special short taper pipe threads

ANSI B

1.20.3,1.20.4

PTF-SPL

Dryseal special extra short taper pipe threads

EXTRA SHORT

ANSI B

1.20.3,1.20.4

SPL -PTF Dryseal special taper pipe threads

ANSI B

1.20.3,1.20.4

NPSI Dryseal American Standard intermediate internal

straight pipe threads

ANSI B

1.20.3,1.20.4

5 -

5

-




Thread Symbol List ANSI-KF Tubulated Adaptor


NPSF Dryseal American Standard fuel internal straight pipe threads

ANSI B

1.20.3,1.20.4

ANPT Aeronautical National Form taper pipe threads MIL-P-7105

NGO National gas outlet threads ANSI B 57.1

NGS National gas straight threads ANSI B 57.1

USA NGT National gas taper threads ANSI B 57.1

SGT Special gas taper threads ANSI B 57.1

NH Hose coupling and firehose coupling threads USAS B 2.4

NHR Hose coupling and firehose coupling threads USAS B 2.4

NPSH Hose coupling and firehose coupling threads USAS B 2.4

AMO American Standard microscope objective threads ANSI B 1.11

UNS Unified special series BS 1580

B.S.W. British Standard Whitworth coarse threads BS 84

BSF British Standard fine threads BS 84

BSP British standard pipe threads BS 21, 2779

B. A. B. A.- Screw threads BS 93, 1929

British Acme General purpose, Acme screw threads BS 1104

Buttress Buttress threads BS 1657

BSC Cycle threads BS 811

BSMO Microscope objective threads BS 3569

E Edison screw threads BS 5042

R. S. M.

Rolled sheet metal screw threads and threads for molded

plastics and die-cast materials

BS 2038

GL Glass containers thread DIN 168

S

Buttress thread

DIN 513,

2781, 20401

DIN 405,

Rd Kunckle thread

262, 264,

3182, 7273,

15403, 20400

DIN 168,

W Whitworth-gewinde

477, 6630,

4668, 49301

Germany KS, KT Screw seal for packages made of plastics DIN 6063

E Edison screw thread DIN 40400

Pg Steel conduit thread DIN 40430

Glasg Thread for cover glasses, porcelain and cast iron caps DIN 40450

Vg Automobile tire valve thread DIN 7756

Gf Thread for freezing pipes DIN 4930

Gg Thread for drill pipes

DIN 4941,

20314

HA Thread for bone screws and nuts DIN 58810

RMS Thread connection for microscope objectives DIN 58888

FG Bicycle threads DIN 79012


ASA4KA40 304 S.S. 108 55 42 38.1 15.8*4 79.4 17110501092

ASA4KA50 304 S.S. 108 75 42 50.8 15.8*4 79.4 17110501122

ASA5KA40 304 S.S. 127 55 42 38.1 15.8*4 98.4 17110601092

ASA5KA50 304 S.S. 127 75 42 50.8 15.8*4 98.4 17110601122

ASA7KA40 304 S.S. 190.5 55 42 38.1 19*4 228.6 17110701092

ASA7KA50 304 S.S. 190.5 75 42 50.8 19*4 228.6 17110701122

ANSI-KF Tubulated Adaptor with O’Ring Groove

Model No. Material A B C D E F *No. P.C.D. Parts No.

øA

øA

P.C.D.

P.C.D.

øE

øE

øD

12.7

C

øD

øF

12.7

C

ASA4OGKA40 304 S.S. 108 55 42 38.1 63.5 15.8*4 79.4 17120501092

ASA4OGKA50 304 S.S. 108 75 42 50.8 63.5 15.8*4 79.4 17120501122

ASA5OGKA40 304 S.S. 127 55 42 38.1 88.9 15.8*4 98.4 17120601092

ASA5OGKA50 304 S.S. 127 75 42 50.8 88.9 15.8*4 98.4 17120601122

ASA7OGKA40 304 S.S. 190.5 55 42 38.1 117.5 19*4 228.6 17120701092

ASA7OGKA50 304 S.S. 190.5 75 42 50.8 117.5 19*4 228.6 17120701122

øB

øB


-

5 1

-

5 2





CF-ISO Tubulated Adaptor


CF63S63A 304 S.S. 113.6 95 90 63.5 17080702132

CF100S63A 304 S.S. 151.6 95 90 63.5 17080902132

CF100S100A 304 S.S. 151.6 130 90 101.6 17080902152

ISO160C100A 304 S.S. 151.6 180 90 101.6 17021208172

CF150S63A 304 S.S. 202.5 95 90 63.5 17081102132

CF150S100A 304 S.S. 202.5 130 90 101.6 17081102152

ISO160C150A 304 S.S. 202.5 180 90 152.4 17021208172

øA

CF-KF Tubulated Adaptor


CF16K10A 304 S.S. 33.8 30 43 12.7 17080201032

CF16K16A 304 S.S. 33.8 30 43 19.05 17080201052

CF35K10A 304 S.S. 69.5 30 45.3 12.7 17080401032

CF35K16A 304 S.S. 69.5 30 45.3 19.05 17080401052

CF35K25A 304 S.S. 69.5 40 45.3 25.4 17080401072

KF40C35A 304 S.S. 69.5 55 45.3 38.1 17010508082

CF63K50A 304 S.S. 113.6 75 49.5 50.8 17080701122

øA

øD

C

øD

C

øB

øB

ISO-KF Tubulated Adaptor


ISO63KA25 304 S.S. 95 40 42 25.4 17020701072

ISO63KA40 304 S.S. 95 55 42 38.1 17020701092

ISO63KA50 304 S.S. 95 75 42 50.8 17020701122

ISO80KA40 304 S.S. 110 55 42 38.1 17020801092

ISO80KA50 304 S.S. 110 75 42 50.8 17020801122

ISO100KA40 304 S.S. 130 55 42 38.1 17020901092

ISO100KA50 304 S.S. 130 75 42 50.8 17020901122

øA

øD

C

øB


-

5 3

-

5 4





CF Reducing Adaptor-Fixed


CF35RA16 304 S.S. 69.5 33.8 76.2 19.05 17080408052

CF63RA16 304 S.S. 113.6 33.8 76.2 19.05 17080708052

CF63RA35 304 S.S. 113.6 69.5 76.2 38.1 17080708082

CF100RA35 304 S.S. 151.6 69.5 76.2 38.1 17080908082

CF100RA63 304 S.S. 151.6 113.6 76.2 63.5 17080908132

CF150RA35 304 S.S. 202.5 69.5 76.2 38.1 17081108082

CF150RA63 304 S.S. 202.5 113.6 76.2 63.5 17081108132

CF150RA100 304 S.S. 202.5 151.6 76.2 101.6 17081108152

CF Reducing Adaptor-Small Flange Rotatable

øA

øA

øD

øD

C

C

øB

ROTATABLE


CF35RA16R 304 S.S. 69.5 33.8 76.2 19.05 17080406052

CF63RA16R 304 S.S. 113.6 33.8 76.2 19.05 17080706052

CF63RA35R 304 S.S. 113.6 69.5 76.2 38.1 17080706082

CF100RA35R 304 S.S. 151.6 69.5 76.2 38.1 17080906082

CF100RA63R 304 S.S. 151.6 113.6 76.2 63.5 17080906132

CF150RA35R 304 S.S. 202.5 69.5 76.2 38.1 17081106082

CF150RA63R 304 S.S. 202.5 113.6 76.2 63.5 17081106132

CF150RA100R 304 S.S. 202.5 151.6 76.2 101.6 17081106152

øB

KF-VCR Male Adaptor

Model No. Material A B C VCR Parts No.

KF16MVCR6 304 S.S. 30 4.4 37 1/4" 17010216012

KF16MVCR13 304 S.S. 30 10.4 41.9 1/2" 17010216032

KF25MVCR6 304 S.S. 40 4.4 37 1/4" 17010316012

KF25MVCR13 304 S.S. 40 10.4 41.9 1/2" 17010316032

KF40MVCR6 304 S.S. 55 4.4 37 1/4" 17010516012

KF40MVCR13 304 S.S. 55 10.4 41.9 1/2" 17010516032

KF50MVCR6 304 S.S. 75 4.4 37 1/4" 17010616012

KF50MVCR13 304 S.S. 75 10.4 41.9 1/2" 17010616032

KF-VCR Female Adaptor

Model No. Material A B C VCR Parts No.

KF16FVCR6 304 S.S. 30 4.4 37 1/4" 17010217012

KF16FVCR13 304 S.S. 30 10.4 41.9 1/2" 17010217032

KF25FVCR6 304 S.S. 40 4.4 37 1/4" 17010317012

KF25FVCR13 304 S.S. 40 10.4 41.9 1/2" 17010317032

KF40FVCR6 304 S.S. 55 4.4 37 1/4" 17010517012

KF40FVCR13 304 S.S. 55 10.4 41.9 1/2" 17010517032

KF50FVCR6 304 S.S. 75 4.4 37 1/4" 17010617012

KF50FVCR13 304 S.S. 75 10.4 41.9 1/2" 17010617032

øA

øA

C

C

øB

øB


-

5 5

-

5 6





KF-Swagelok Adaptor

Model No. Material A B C Swagelok Parts No.

KF16SWA6 304 S.S. 30 4.8 36.6 1/4" 17010219012

KF16SWA13 304 S.S. 30 10.4 45 1/2" 17010219032

KF25SWA6 304 S.S. 40 4.4 36.6 1/4" 17010319012

KF25SWA13 304 S.S. 40 10.8 54.3 1/2" 17010319032

KF40SWA6 304 S.S. 55 4.4 36.6 1/4" 17010519012

KF40SWA13 304 S.S. 55 10.4 54.3 1/2" 17010519032

KF50SWA6 304 S.S. 75 4.8 36.6 1/4" 17010619012

KF50SWA13 304 S.S. 75 10.4 54.3 1/2" 17010619032

øA

KF Rubber Hose Adaptor

Model No. Material A B

Hose Size Parts No.

KF10RHA 304 S.S. 16 40 1/2" or 5/8" 17010118042

KF16RHA 304 S.S. 19.1 40 5/8" or 3/4" 17010218052

KF25RHA 304 S.S. 22.2 40 7/8" or 1" 17010318062

KF40RHA 304 S.S. 41.3 40 1 1/2" or 1 5/8" 17010518102

KF50RHA 304 S.S. 47.7 40 1 7/8" or 2" 17010618112

øB

B

C

øA

KF Male Pipe Adaptor

øA

Thread Type: PT

Model No. Material A B C D Tread Parts No.

KF16MPT3 304 S.S. 30 35 4.7 10 1/8"PT 17010212002

KF16MPT6 304 S.S. 30 35 7.1 14 1/4"PT 17010212012

KF25MPT3 304 S.S. 40 35 4.7 10 1/8"PT 17010312002

KF25MPT6 304 S.S. 40 35 7.1 14 1/4"PT 17010312012

KF25MPT13 304 S.S. 40 40 11.9 22 1/2"PT 17010312032

KF25MPT19 304 S.S. 40 40 15.9 27 3/4"PT 17010312052

KF40MPT6 304 S.S. 55 35 7.1 14 1/4"PT 17010512012

KF40MPT13 304 S.S. 55 40 11.9 22 1/2"PT 17010512032

KF40MPT19 304 S.S. 55 40 15.9 27 3/4"PT 17010512052

KF40MPT25 304 S.S. 55 45 22.2 36 1"PT 17010512072

KF50MPT6 304 S.S. 75 35 7.1 14 1/4"PT 17010612012

KF50MPT13 304 S.S. 75 40 11.9 22 1/2"PT 17010612032

KF50MPT19 304 S.S. 75 40 15.9 27 3/4"PT 17010612052

KF50MPT25 304 S.S. 75 45 22.2 36 1"PT 17010612072

Thread Type: NPT

Model No. Material A B C D Tread Parts No.

KF16MNPT3 304 S.S. 30 35 4.7 10 1/8"NPT 17010214002

KF16MNPT6 304 S.S. 30 35 7.1 14 1/4"NPT 17010214012

KF25MNPT3 304 S.S. 40 35 4.7 10 1/8"NPT 17010314002

KF25MNPT6 304 S.S. 40 35 7.1 14 1/4"NPT 17010314012

KF25MNPT13 304 S.S. 40 40 11.9 22 1/2"NPT 17010314032

KF25MNPT19 304 S.S. 40 40 15.9 27 3/4"NPT 17010314052

KF40MNPT6 304 S.S. 55 35 7.1 14 1/4"NPT 17010514012

KF40MNPT13 304 S.S. 55 40 11.9 22 1/2"NPT 17010514032

KF40MNPT19 304 S.S. 55 40 15.9 27 3/4"NPT 17010514052

KF40MNPT25 304 S.S. 55 45 22.2 36 1"NPT 17010514072

KF50MNPT6 304 S.S. 75 35 7.1 14 1/4"NPT 17010614012

KF50MNPT13 304 S.S. 75 40 11.9 22 1/2"NPT 17010614032

KF50MNPT19 304 S.S. 75 40 15.9 27 3/4"NPT 17010614052

KF50MNPT25 304 S.S. 75 45 22.2 36 1"NPT 17010614072

B

øC

D


-

5 7

-

5 8





KF Female Pipe Adaptor

Thread Type: PT

Model No. Material A B C Tread Parts No.

KF16FPT3 304 S.S. 19.05 25 17 1/8"PT 17010213002

KF25FPT3 304 S.S. 25.4 25 19 1/8"PT 17010313002

KF40FPT3 304 S.S. 38.1 25 32 1/8"PT 17010513002

KF50FPT3 304 S.S. 50.8 25 46 1/8"PT 17010613002

KF16FPT6 304 S.S. 19.05 25 17 1/4"PT 17010213012

KF25FPT6 304 S.S. 25.4 25 19 1/4"PT 17010313012

KF40FPT6 304 S.S. 38.1 25 32 1/4"PT 17010513012

KF50FPT6 304 S.S. 50.8 25 46 1/4"PT 17010613012

Thread Type: NPT

Model No. Material A B C Tread Parts No.

KF16FNPT3 304 S.S. 19.05 25 17 1/8"NPT 17010215002

KF25FNPT3 304 S.S. 25.4 25 19 1/8"NPT 17010315002

KF40FNPT3 304 S.S. 38.1 25 32 1/8"NPT 17010515002

KF50FNPT3 304 S.S. 50.8 25 46 1/8"NPT 17010615002

KF16FNPT6 304 S.S. 19.05 25 17 1/4"NPT 17010215012

KF25FNPT6 304 S.S. 25.4 25 19 1/4"NPT 17010315012

KF40FNPT6 304 S.S. 38.1 25 32 1/4"NPT 17010515012

KF50FNPT6 304 S.S. 50.8 25 46 1/4"NPT 17010615012

B

øA

C

KF Quick-Disconnect Adaptor

Model No. Material A B C Tube Size Parts No.

KF16QDA6 304 S.S. 6.5 33.4 30 1/4' 17010220012

KF16QDA12 304 S.S. 13 36.5 30 1/2" 17010220032

KF16QDA19 304 S.S. 19.4 44.5 30 3/4" 17010220052

KF25QDA12 304 S.S. 13 36.5 40 1/2" 17010320032

KF25QDA19 304 S.S. 19.3 44.5 40 3/4" 17010320052

KF25QDA25 304 S.S. 25.7 50.8 40 1" 17010320072

KF40QDA12 304 S.S. 13 36.5 55 1/2" 17010520032

KF40QDA19 304 S.S. 19.3 44.5 55 3/4" 17010520052

KF40QDA25 304 S.S. 25.7 50.8 55 1" 17010520072

KF40QDA38 304 S.S. 38.4 60.3 55 1 1/2" 17010520092

KF50QDA38 304 S.S. 38.4 60.3 75 1 1/2" 17010620092

KF50QDA50 304 S.S. 51 60.3 75 2" 17010620122

øA

B

øC


-

5 9

-

5 10





KF-KF Conical Reducing Adaptor


Parts No.

KF25RA16 304 S.S. 40 30 40 17210301052

KF40RA16 304 S.S. 55 30 40 17210501052

KF40RA25 304 S.S. 55 40 40 17210501072

KF50RA16 304 S.S. 75 30 40 17210601052

KF50RA25 304 S.S. 75 40 40 17210601072

KF50RA40 304 S.S. 75 55 40 17210601092

ISO-KF Conical Reducing Adaptor


Parts No.

ISO80KRA40 304 S.S. 110 55 63 17220801092

ISO100KRA40 304 S.S. 130 55 63 17220901092

ISO80KRA50 304 S.S. 110 75 63 17220801122

ISO100KRA50 304 S.S. 130 75 63 17220901122

øA

øA

C

C

øB

øB

ISO-ISO Conical Reducing Adaptor


Parts No.

ISO80RA63 304 S.S. 110 95 63 17220802132

ISO100RA63 304 S.S. 130 95 63 17220902132

ISO100RA80 304 S.S. 175 95 63 17221202132

ISO160RA63 304 S.S. 130 110 63 17220902142

øA

C

øB


-

5 11


709

TEL/ 06-2460296 FAX/ 06-2471701

HEAD QUARTERS



TEL/ +886-6-2460296 FAX/ +886-6-2471701


303

TEL/ 03-5973337 FAX/ 03-5973073




TEL/ +886-3-5973337 FAX/ +886-3-5973073

TEL/ +86-21-50460355

FAX/ +86-21-50460234




TEL/ +86-21-50460355

FAX/ +86-21-50460234



VACUUM 2002

SOLUTION

SECTION 6

VALVE SERIES


VALVE

SERIES

CONTENTS


VALVE SERIES


Ordering Information

ANGLE VALVE

Manually Operated with Bellows

Manually Operated without Bellows

Manually Operated Copper Seal Bonnet with Bellows

Pneumatically Actuated

Pneumatically Actuated with Bellows Attached Reed Sensor

Z-INLINE VALVE






Y-INLINE VALVE



Pneumatically Actuated with Bellows


BAKEABLE ALL-METAL VALVE

Bakeable All-Metal Valve

ALUMINUM VALVE

Manually Operated Angle Valve

Single Pneumatically- Actuated Angle Valve

Double Pneumatically- Actuated Angle Valve

BALL VALVE

Ball Valve

6 -

6 -

6 - 1

6 - 5

6 - 8

6 - 11

6 - 22

6 - 26

6 - 29

6 - 32

6 - 35

6 - 39

6 - 42

6 - 45

6 - 48

6 - 51

6 - 54

6 - 55

6 - 56

6 - 57

6 - 58


6 -

VALVE SERIES




Features:

HTC is pleased to offer vacuum valves designed and manufactured in Tainan, Taiwan,

R.O.C. These valves are the result of a long and careful development program designed to

insure product quality, reliability and value. Every effort has been made to provide a valve

family suited to the requirements of various users.

They will function reliably in applications ranging from semiconductor production system

with chemical and particulate contamination.

Long life operation.

Stainless steel welded bellows seal.

Manual and electropneumatic actuation or fail safe operators (closes in the event of air

pressure loss).

Bakeable to 200°C intermittently, Viton seal bonnet.

Compact size.

Simple and fast maintenance.

Simple control via solenoid valve with manual override.


Body :304 S.S. (Other material available upon request)

Poppet :304 S.S. (Other material available upon request)

Bellows :Welded AM-350 (option)

Solenoid :Option

Position indicator :Option

Seal :Viton O'ring

Leak rate :2x10-9 std.cc./second

Pressure range :1x10-9 torr to 760 torr Viton seal bonnet

Maximum¡ pressure before opening :1.2 Bar

Operating air pressure :4 ~ 6.5 kg/cm2 Cycles until service :16 to 50 ~ 1,000,000

(full orifice open) 63 to 150 ~ 500,000

200 to larger ~ application dependent

Bake-out limitation :150°C Viton seal bonnet


Application:

KF, ISO and ANSI port models are designed for high vacuum applications where vacuum

pressures approximate 10-9 torr and bake-out temperature do not exceed 150°C. The

standard international KF/ISO configurations and ANSI configurations are used in areas

requiring an easily mountable and demountable flange type seal.

CF port models are designed for ultra-high vacuum applications where the vacuum pressure

approximates 10-10 torr and bake-out temperatures do not exceed 200°C. These valves are

used in applications during an OFHC copper gasket rather the conventional Viton O'ring

because of higher bake-out temperatures, lower vacuum pressures, (minimal outgassing)

and reduced permeability. They are also commonly used in applications requiring a more

permanent seal.

Manually Operated Angle Valve:

WELDED BELLOWS

VALVE BODY

KF FLANGE

SHAFT

BOTTOM PORT

Pneumatically Actuated Angle-In-Line Valve:

PISTON

SPRING GUIDE

SPRING

POPPET SEAL

VALVE SEAT

HAND WHEEL

BONNET PLATE

BONNET SEAL

POPPET

SIDE PORT

AIR CYLINDER

6

-

6

-

VALVE SERIES



Ordering Information

VALVE 3000SERIES

(Table 1 )

DIMENSION

(Table 2 )

ACTUATOR

0 = manual

1 = pneumatic (spring to close)

2 = double pneumatic

3 = power

4 = pneumatic (spring to Open)

FLANGE TYPE

0 = Tube End

1 = KF

2 = CF

3 = CR

4 = ISO

5 = ANSI

SOLENOID VOLTAGE

0 = No Solenoid

1 = 24VDC

2 = 110VAC

3 = 220VAC

4 = 24VAC

BELLOWS

0 = No bellows

1 = Stainless corrugated bellows

2 = 304ss welded bellows

3 = 304Lss welded bellows

4 = 316ss welded bellows

5 = 316Lss welded bellows

6 = AM350ss welded bellows

7 = Inconel 625 welded bellows

8 = Inconel 718 welded bellows

BODY MATERIAL

1 = Stainless steel

2 = Aluminum

POSITION INDICATOR

0 = No reed sensor

1 = 1 reed sensor

2 = 2 reed sensor

3 = limit switch

Table 1. Valve 3000 Series:

VALVE U.S.A. Series code

VITON POPPET / BONNET SEAL 3001

Angle Valve

METAL POPPET / VITON BONNET SEAL 3002

3001

KALREZ POPPET / BONNET SEAL 3003

KALREZ POPPET / METAL BONNET SEAL 3004

3019

BAKEABLE ALL-METAL 3005

VITON POPPET / METAL BONNET SEAL 3006


Z-Inline Valve


3021



3039




Y-Inline Valve


3041



3059




Tee Valve


3061



3069




Straight-Through


3071



3089



6 -

6

-

VALVE SERIES



Table 1. Continuous Table 2. Dimension

Angle Valve

3101

3119

Z-Inline Valve

3121

3139

Y-Inline Valve

3141

3159

Tee Valve

3161

3169

Straight-Through

3171

3189

VALVE EUROPE Series code































Codes and Dimensions Description

01~99 TUBE 1A~9Z TUBE A1~Z9 PIPE AA~ZZ PIPE

(Fractional) (Metric) (ANSI) (JIS)

Code Dimension Code Dimension Code Dimension Code Dimension

01 1/16" 1A 2 A1 1/8" AA 6(1/8")

02 1/8" 1B 3 A2 1/4" AB 8(1/4")

03 3/16" 1C 4 A3 3/8" AC 10(3/8")

04 1/4" 1D 6 A4 1/2" AD 15(1/2")

05 5/16" 1E 8 A5 3/4" AE 20(3/4")

06 3/8" 1F 10 A6 1" AF 25(1")

07 1/2" 1G 12 A7 1-1/4" AG 32(1-1/4")

08 5/8" 1H 16 A8 1-1/2" AH 40(1-1/2")

09 3/4"(16) 1 J 20 A9 2" AJ 50(2")

10 7/8" 1K 22 B1 2-1/2" AK 65(2-1/2")

11 1"(25) 1L 25 B2 3" AL 80(3")

12 1-1/4" 1M B3 3-1/2" AM 90(3-1/2")

13 1-1/2"(40) 1N B4 4" AN 100(4")

14 2"(50) 1P B5 5" AP 125(5")

15 2-1/2"(63) 1Q B6 6" AQ 150(6")

16 3"(80) 1R B7 8" AR 200(8")

17 3-1/2" 1S B8 10" AS 250(10")

18 4"(100) 1T B9 12" AT 300(12")

19 5" 1U C1 AU

20 6"(160) 1V C2 AV

21 8"(200) 1W C3 AW

22 10"(250) 1X C4 AX

23 12" 1Y C5 AY

24 14" 1Z C6 AZ

25 16"

26 18"

27 20"

28 22"

29 24"

6 -

6

-

VALVE SERIES



Specifcations for No Port Flange Angle Valve

Characteristic Units AVB-TE16-P

Model No.

AVB-TE25-P AVB-TE40-P AVB-TE50-P

Conductance Liters/second 4 7 26 29

Seal Leak Rate Std cc/s

ANGLE VALVE




CF Flange

Figure 3

D

O.D.

ISO Flange Figure 4

D

O.D.

O.D.

A

O.D.

A

A

A

B

B

C

C


Available Area : U.S.A.

Port Connections : Tube End

Model No. O.D. A B C D Figure Parts No.

AVB-TE16-M 0.75 2.00 5.25 6.00 2.25 1 300109000016

AVB-TE25-M 1.00 1.88 4.97 5.70 2.25 1 300111000016

AVB-TE40-M 1.50 2.25 6.28 7.50 3.00 1 300113000016

AVB-TE50-M 2.00 3.25 7.99 9.76 3.50 1 300114000016

AVB-TE63-M 2.50 3.00 8.35 10.95 4.00 1 300115000016

AVB-TE80-M 3.00 3.25 8.67 11.02 4.50 1 300116000016

Port Connections : KF Flange


AVB-KF16-M 0.75 2.15 5.41 6.15 2.25 2 300109010016

AVB-KF25-M 1.00 2.03 5.12 5.85 2.25 2 300111010016

AVB-KF40-M 1.50 2.40 6.43 7.65 3.00 2 300113010016

AVB-KF50-M 2.00 3.40 8.14 9.91 3.50 2 300114010016

Port Connections : CF Rotatable Flange


AVB-CR16-M 0.75 2.50 5.75 6.50 2.25 3 300109030016

AVB-CR35-M 1.50 2.45 6.49 7.71 3.00 3 300113030016

AVB-CR63-M 2.50 3.38 8.72 11.32 4.00 3 300115030016

Port Connections : ISO Flange


AVB-ISO63-M 2.50 3.25 8.60 11.20 4.00 4 300115040016

AVB-ISO80-M 3.00 3.50 8.92 11.28 4.50 4 300116040016

Note : All dimensions shown on this page are in inch.


Polished 304 stainless steel body.

3/4~3 inch port ODs.

Self lubricating bronze nut.

Bakeable to 150°C.

Viton Seal Bonnet : 10-9 Torr vacuum rating KF, ISO and CF flange.

6 - 2 Dimension in mm unless otherwise noted Dimension in mm unless otherwise noted 6 - 3

ANGLE VALVE




Available Area : Europe



AVB-KF16-M-E 19.05 40 112.7 141.5 57.15 2 310109010016

AVB-KF25-M-E 25.4 50 128.4 147.2 57.15 2 310111010016

AVB-KF40-M-E 38.1 65 167.5 198.5 76.2 2 310113010016

AVB-KF50-M-E 50.8 70 190.5 235.5 88.9 2 310114010016



AVB-CR16-M-E 19.05 38 120.7 139.5 57.15 3 310109030016

AVB-CR35-M-E 38.1 63 170.8 201.8 76.2 3 310113030016

AVB-CR63-M-E 63.5 105 241 308.5 101.6 3 310115030016



AVB-ISO63-M-E 63.5 88 224 291.5 101.6 4 310115040016

AVB-ISO80-M-E 76.2 98 236 295.5 114.3 4 310116040016



19.05~76.2 mm port ODs.



Viton Seal Bonnet : 10-9 Torr vacuum rating KF, ISO and CF flange.


6 - 4 Dimension in mm unless otherwise noted

Dimension in mm unless otherwise noted 6 - 5

Tube End

Figure 5

KF Flange Figure 6

D

O.D.

D

O.D.

O.D.

A

O.D.

A

A

A

B

B

C

C

ANGLE VALVE







AV-TE16-M 0.75 2.00 6.24 6.92 2.25 5 300109000010

AV-TE25-M 1.00 1.88 6.17 6.85 2.25 5 300111000010

AV-TE40-M 1.50 2.25 7.33 8.44 3.00 5 300113000010

AV-TE50-M 2.00 3.25 9.62 11.2 3.50 5 300114000010



AV-KF16-M 0.75 2.15 6.39 7.07 2.25 6 300109010010

AV-KF25-M 1.00 2.03 6.32 7.00 2.25 6 300111010010

AV-KF40-M 1.50 2.40 7.48 8.59 3.00 6 300113010010

AV-KF50-M 2.00 3.40 9.77 11.35 3.50 6 300114010010







Viton Seal Bonnet : 10-9 Torr vacuum rating KF flange.





AV-KF16-M-E 19.05 40 147.7 165 57.15 6 310109010010

AV-KF25-M-E 25.4 50 159 176.3 57.15 6 310111010010

AV-KF40-M-E 38.1 65 194.7 222.2 76.2 6 310113010010

AV-KF50-M-E 50.8 70 232 272 88.9 6 310114010010


19.05~50.8 mm port ODs.



Viton Seal Bonnet : 10-9 Specifications:

Torr vacuum rating KF flange.


Dimension in mm unless otherwise noted 6 - 7

ANGLE VALVE



Manually Operated Copper Seal Bonnet with Bellows Manually Operated Copper Seal Bonnet with Bellows

Tube End

Figure 7


D

O.D.

D

O.D.

O.D.

A

O.D.

A

A

A

B

B

C

C



CF Flange

Figure 9

D

O.D.

O.D.

A

A

B

C

ANGLE VALVE







AVB-CU-TE16-M 0.75 2.00 5.20 5.98 2.75 7 300609000016

AVB-CU-TE25-M 1.00 1.88 4.96 5.74 2.75 7 300611000016

AVB-CU-TE40-M 1.50 2.25 6.48 7.70 3.37 7 300613000016

AVB-CU-TE50-M 2.00 3.25 7.99 9.76 4.47 7 300614000016

AVB-CU-TE63-M 2.50 3.00 8.35 11.01 4.47 7 300615000016



AVB-CU-KF16-M 0.75 2.15 5.24 6.01 2.75 8 300609010016

AVB-CU-KF25-M 1.00 2.03 5.11 5.89 2.75 8 300611010016

AVB-CU-KF40-M 1.50 2.40 6.62 7.85 3.37 8 300613010016

AVB-CU-KF50-M 2.00 3.40 8.14 9.91 4.47 8 300614010016

Port Connections : KF Rotatable Flange


AVB-CU-CR16-M 0.75 2.50 5.58 6.36 2.75 9 300609030016

AVB-CU-CR35-M 1.50 2.45 6.68 7.90 3.37 9 300613030016

AVB-CU-CR63-M 2.50 3.38 8.72 11.38 4.47 9 300615030016




3/4~2 1/2 inch port ODs.


Bakeable to 150°C. (200°C intermittently for CF flange port).

Metal Seal Bonnet : 10-9 Torr vacuum rating KF and approximate 10-10 Torr vacuum rating

CF flange.




Tube End

Figure 10

Tube End Figure 11

C

O.D.

C

O.D.

O.D.

A

O.D.

A

A

A

B

B

ANGLE VALVE



Pneumatically Actuated Pneumatically Actuated

KF Flange

Figure 12

CF Flange Figure 13

C

O.D.

C

O.D.

O.D.

A

O.D.

A

A

A

B

B



CF Flange

Figure 14

ISO Flange Figure 15

C

O.D.

C

O.D.

O.D.

A

O.D.

A

A

A

B

B

ANGLE VALVE





With bellows, air to open, spring to close.


Model No. O.D. A B C Figure Parts No.

AVB-TE16-P 0.75 2.00 6.03 2.25 10 300109100016

AVB-TE25-P 1.00 1.88 5.77 2.25 10 300111100016

AVB-TE40-P 1.50 2.25 7.53 3.00 10 300113100016

AVB-TE50-P 2.00 3.25 10.17 3.50 10 300114100016



AVB-KF16-P 0.75 2.15 6.18 2.25 12 300109110016

AVB-KF25-P 1.00 2.03 5.92 2.25 12 300111110016

AVB-KF40-P 1.50 2.40 7.68 3.00 12 300113110016

AVB-KF50-P 2.00 3.40 10.33 3.50 12 300114110016



AVB-CR16-P 0.75 2.50 6.35 2.25 13 300109130016

AVB-CR35-P 1.50 2.45 7.73 3.00 13 300113130016





4~6.5 kg/cm2 operating air pressure.


Viton Seal Bonnet : 10-9 Torr vacuum rating KF and CF flange.



With bellows, air to open, air to close.



AVB-TE16-P2 0.75 2.00 6.03 2.25 11 300109200016

AVB-TE25-P2 1.00 1.88 5.77 2.25 11 300111200016

AVB-TE40-P2 1.50 2.25 7.53 3.00 11 300113200016

AVB-TE50-P2 2.00 3.25 10.17 3.50 11 300114200016

AVB-TE63-P2 2.50 3.00 10.55 4.00 11 300115200016

AVB-TE80-P2 3.00 3.25 10.96 4.50 11 300116200016

AVB-TE100-P2 4.00 4.22 14.30 6.50 11 300118200016

AVB-TE160-P2 6.00 6.00 20.02 9.25 11 300120200016

AVB-TE200-P2 8.00 8.00 25.40 9.97 11 300121200016



AVB-CR63-P2 2.50 3.38 10.90 4.00 14 300115230016

AVB-CR100-P2 4.00 4.66 17.74 6.50 14 300118230016



AVB-ISO-63-P2 2.50 3.25 10.80 4.00 15 300115240016

AVB-ISO-80-P2 3.00 3.50 11.21 4.50 15 300116240016

AVB-ISO-100-P2 4.00 4.47 14.57 6.50 15 300118240016

AVB-ISO-160-P2 6.00 6.26 20.28 9.25 15 300120240016

AVB-ISO-200-P2 8.00 8.26 25.65 9.97 15 300121240016







Torr vacuum rating CF and ISO flange.



ANGLE VALVE





Without bellows, air to open, spring to close.



AV-TE16-P 0.75 2.00 6.03 2.25 10 300109100010

AV-TE25-P 1.00 1.88 5.77 2.25 10 300111100010

AV-TE40-P 1.50 2.25 7.53 3.00 10 300113100010

AV-TE50-P 2.00 3.25 10.17 3.50 10 300114100010



AV-KF16-P 0.75 2.15 6.18 2.25 12 300109110010

AV-KF25-P 1.00 2.03 5.92 2.25 12 300111110010

AV-KF40-P 1.50 2.40 7.68 3.00 12 300113110010

AV-KF50-P 2.00 3.40 10.33 3.50 12 300114110010



AV-CR16-P 0.75 2.50 6.35 2.25 13 300109130010

AV-CR35-P 1.50 2.45 7.73 3.00 13 300113130010










Without bellows, air to open, air to close.



AV-TE16-P2 0.75 2.00 6.03 2.25 11 300109200010

AV-TE25-P2 1.00 1.88 5.77 2.25 11 300111200010

AV-TE40-P2 1.50 2.25 7.53 3.00 11 300113200010

AV-TE50-P2 2.00 3.25 10.17 3.50 11 300114200010

AV-TE63-P2 2.50 3.00 10.55 4.00 11 300115200010

AV-TE80-P2 3.00 3.25 10.96 4.50 11 300116200010

AV-TE100-P2 4.00 4.22 14.30 6.50 11 300118200010

AV-TE160-P2 6.00 6.00 20.02 9.25 11 300120200010

AV-TE200-P2 8.00 8.00 25.40 9.97 11 300121200010



AV-CR63-P2 2.50 3.38 10.90 4.00 14 300115230010

AV-CR100-P2 4.00 4.66 17.74 6.50 14 300118230010



AV-ISO-63-P2 2.50 3.25 10.80 4.00 15 300115240010

AV-ISO-80-P2 3.00 3.50 11.21 4.50 15 300116240010

AV-ISO-100-P2 4.00 4.47 14.57 6.50 15 300118240010

AV-ISO-160-P2 6.00 6.26 20.28 9.25 15 300120240010

AV-ISO-200-P2 8.00 8.26 25.65 9.97 15 300121240010










ANGLE VALVE








AVB-KF16-P-E 19.05 40 142 57.15 12 310109110016

AVB-KF25-P-E 25.4 50 149 57.15 12 310111110016

AVB-KF40-P-E 38.1 65 199 76.2 12 310113110016

AVB-KF50-P-E 50.8 70 246 88.9 12 310114110016



AVB-CR16-P-E 19.05 38 140 57.15 13 310109130016

AVB-CR35-P-E 38.1 63 198 76.2 13 310113130016



19.05~50.8 mm port ODs.






With bellows, air to open, air to close.



AVB-CR63-P2-E 63.5 105 296 101.6 14 310115230016

AVB-CR100-P2-E 101.6 135 391 165.1 14 310118230016



AVB-ISO-63-P2-E 63.5 88 280 101.6 15 310115240016

AVB-ISO-80-P2-E 76.2 98 294 114.3 15 310116240016

AVB-ISO-100-P2-E 101.6 108 364.5 165.1 15 310118240016


63.5~101.6 mm port ODs.







ANGLE VALVE








AV-KF16-P-E 19.05 40 142 57.15 12 310109110010

AV-KF25-P-E 25.4 50 149 57.15 12 310111110010

AV-KF40-P-E 38.1 65 199 76.2 12 310113110010

AV-KF50-P-E 50.8 70 246 88.9 12 310114110010



AV-CR16-P-E 19.05 38 140 57.15 13 310109130010

AV-CR35-P-E 38.1 63 198 76.2 13 310113130010



19.05~50.8 mm port ODs.






Without bellows, air to open, air to close.



AV-CR63-P2-E 63.5 105 296 101.6 14 310115230010

AV-CR100-P2-E 101.6 135 391 165.1 14 310118230010



AV-ISO-63-P2-E 63.5 88 280 101.6 15 310115240010

AV-ISO-80-P2-E 76.2 98 294 114.3 15 310116240010

AV-ISO-100-P2-E 101.6 108 364.5 165.1 15 310118240010


63.5~101.6 mm port ODs.







ANGLE VALVE



Pneumatically Actuated with Bellows Attached Reed Sensor Pneumatically Actuated with Bellows Attached Reed Sensor

Tube End

Figure 16


C

O.D.

C

O.D.

O.D.

A

O.D.

A

A

A

B

B



CF Flange

Figure 18

C

O.D.

O.D.

A

A

B

ANGLE VALVE







AVBS-TE16-P 0.75 2.00 6.30 2.25 16 300109100216

AVBS-TE25-P 1.00 1.88 6.38 2.25 16 300111100216

AVBS-TE40-P 1.50 2.25 8.12 3.00 16 300113100216

AVBS-TE50-P 2.00 3.25 10.22 3.50 16 300114100216



AVBS-KF16-P 0.75 2.15 6.78 2.25 17 300109110216

AVBS-KF25-P 1.00 2.03 6.53 2.25 17 300111110216

AVBS-KF40-P 1.50 2.40 8.27 3.00 17 300113110216

AVBS-KF50-P 2.00 3.40 10.37 3.50 17 300114110216



AVBS-CR16-P 0.75 2.50 7.12 2.25 18 300109130216

AVBS-CR35-P 1.50 2.45 8.33 3.00 18 300113130216





3/4~2 inchs : air to open, spring to close. (normally close)


Sensor Specification : Voltage DC/AC 4~240V Amps : 5~40mA

Options Available : Air solenoid DC24V, AC24V, AC110V, AC220V.






AVBS-KF16-P-E 19.05 40 158 57.15 17 310109110216

AVBS-KF25-P-E 25.4 50 164.3 57.15 17 310111110216

AVBS-KF40-P-E 38.1 65 214 76.2 17 310113110216

AVBS-KF50-P-E 50.8 70 247 88.9 17 310114110216



AVBS-CR16-P-E 19.05 38 155.6 57.15 18 310109130216

AVBS-CR35-P-E 38.1 63 212 76.2 18 310113130216



19.05~50.8 mm port ODs.

3/4~2 inchs : air to open , spring to close. (Normally close)


Sensor Specification : Voltage DC/AC 4~240V Amps : 5~40mA

Options Available : Air solenoid DC24V ,AC24V, AC110V , AC220V.







Manually Operated with Bellows Manually Operated with Bellows

Tube End


B

B

Figure 19

O.D.

O.D.

A

A

F

F

O.D.

A

O.D.

A

C

C

D

D

E

E



CF Flange

B

Figure 21

O.D.

A

F

O.D.

A

C

D

E







Model No. O.D. A B C D E F Figure Parts No.

IVB-TE16-M 0.75 2.00 1.12 1.87 5.12 5.86 2.25 19 302109000016

IVB-TE25-M 1.00 1.88 1.37 2.25 5.33 6.08 2.25 19 302111000016

IVB-TE40-M 1.50 2.25 1.88 3.12 7.15 8.37 3.00 19 302113000016

IVB-TE50-M 2.00 3.25 2.62 4.12 8.86 10.63 3.50 19 302114000016



IVB-KF16-M 0.75 2.15 1.12 1.87 5.12 5.86 2.25 20 302109010016

IVB-KF25-M 1.00 2.03 1.37 2.25 5.33 6.08 2.25 20 302111010016

IVB-KF40-M 1.50 2.40 1.88 3.12 7.15 8.37 3.00 20 302113010016

IVB-KF50-M 2.00 3.40 2.62 4.12 8.86 10.63 3.50 20 302114010016



IVB-CR16-M 0.75 2.50 1.12 1.87 5.12 5.86 2.25 21 302109030016

IVB-CR35-M 1.50 2.45 1.88 3.12 7.15 8.37 3.00 21 302113030016











Tube End

Figure 22


B

B

O.D.

O.D.

A

A

F

F

O.D.

A

O.D.

A

C

C

D

D

E

E



CF Flange


Manually Operated without Bellows Manually Operated without Bellows


Figure 24

B

O.D.

A

F

O.D.

A

C

D

E



IV-TE16-M 0.75 2.00 1.12 1.87 6.11 6.79 2.25 22 302109000010

IV-TE25-M 1.00 1.88 1.37 2.25 6.54 7.22 2.25 22 302111000010

IV-TE40-M 1.50 2.25 1.88 3.12 8.20 9.31 3.00 22 302113000010

IV-TE50-M 2.00 3.25 2.62 4.12 10.49 12.07 3.50 22 302114000010



IV-KF16-M 0.75 2.15 1.12 1.87 6.11 6.79 2.25 23 302109010010

IV-KF25-M 1.00 2.03 1.37 2.25 6.54 7.22 2.25 23 302111010010

IV-KF40-M 1.50 2.40 1.88 3.12 8.20 9.31 3.00 23 302113010010

IV-KF50-M 2.00 3.40 2.62 4.12 10.49 12.07 3.50 23 302114010010



IV-CR16-M 0.75 2.50 1.12 1.87 6.11 6.79 2.25 24 302109030010

IV-CR35-M 1.50 2.45 1.88 3.12 8.20 9.31 3.00 24 302113030010














Tube End


B

B

Figure 25

O.D.

O.D.

A

A

F

F

O.D.

A

O.D.

A

C

C

D

D

E

E



CF Flange

B

Figure 27

O.D.

A

F

O.D.

A

C

D

E








IVB-CU-TE16-M 0.75 2.00 1.12 1.87 5.07 5.85 2.75 25 302609000016

IVB-CU-TE25-M 1.00 1.88 1.37 2.25 5.33 6.11 2.75 25 302611000016

IVB-CU-TE40-M 1.50 2.25 1.88 3.12 7.35 8.57 3.37 25 302613000016

IVB-CU-TE50-M 2.00 3.25 2.62 4.12 8.86 10.63 4.47 25 302614000016



IVB-CU-KF16-M 0.75 2.15 1.12 1.87 5.07 5.85 2.75 26 302609010016

IVB-CU-KF25-M 1.00 2.03 1.37 2.25 5.33 6.11 2.75 26 302611010016

IVB-CU-KF40-M 1.50 2.40 1.88 3.12 7.35 8.57 3.37 26 302613010016

IVB-CU-KF50-M 2.00 3.40 2.62 4.12 8.86 10.63 4.47 26 302614010016



IVB-CU-CR16-M 0.75 2.50 1.12 1.87 5.07 5.85 2.75 27 302609030016

IVB-CU-CR35-M 1.50 2.45 1.88 3.12 7.35 8.57 3.37 27 302613030016







Metal Seal Bonnet : 10-9 Torr vacuum rating KF and approximate 10-10 Torr vacuum rating





Tube End

Figure 28


B

B

O.D.

O.D.

E

A A

E

A A

O.D.

O.D.

C

C

D

D





CF Flange

B

Figure 30

O.D.

E

O.D.

A A

C

D





Model No. O.D. A B C D E Figure Parts No.

IVB-TE16-P 0.75 2.00 1.12 1.87 5.90 2.25 28 302109100016

IVB-TE25-P 1.00 1.88 1.37 2.25 6.14 2.25 28 302111100016

IVB-TE40-P 1.50 2.25 1.88 3.12 8.40 3.00 28 302113100016

IVB-TE50-P 2.00 3.25 2.62 4.12 11.04 3.50 28 302114100016



IVB-KF16-P 0.75 2.15 1.12 1.87 5.90 2.25 29 302109110016

IVB-KF25-P 1.00 2.03 1.37 2.25 6.14 2.25 29 302111110016

IVB-KF40-P 1.50 2.40 1.88 3.12 8.40 3.00 29 302113110016

IVB-KF50-P 2.00 3.40 2.62 4.12 11.04 3.50 29 302114110016



IVB-CR16-P 0.75 2.50 1.12 1.87 5.90 2.25 30 302109130016

IVB-CR35-P 1.50 2.45 1.88 3.12 8.40 3.00 30 302113130016


















IV-TE16-P 0.75 2.00 1.12 1.87 5.90 2.25 28 302109100010

IV-TE25-P 1.00 1.88 1.37 2.25 6.14 2.25 28 302111100010

IV-TE40-P 1.50 2.25 1.88 3.12 8.40 3.00 28 302113100010

IV-TE50-P 2.00 3.25 2.62 4.12 11.04 3.50 28 302114100010



IV-KF16-P 0.75 2.15 1.12 1.87 5.90 2.25 29 302109110010

IV-KF25-P 1.00 2.03 1.37 2.25 6.14 2.25 29 302111110010

IV-KF40-P 1.50 2.40 1.88 3.12 8.40 3.00 29 302113110010

IV-KF50-P 2.00 3.40 2.62 4.12 11.04 3.50 29 302114110010



IV-CR16-P 0.75 2.50 1.12 1.87 5.90 2.25 30 302109130010

IV-CR35-P 1.50 2.45 1.88 3.12 8.40 3.00 30 302113130010











Tube End

Figure 31


B

B

O.D.

O.D.

A

A

E

E

A

O.D.

O.D.

A

C

C

D

D





CF Flange Figure 33

B

O.D.

A

E

O.D.

A

C

D





IVBS-TE16-P 0.75 2.00 1.12 1.87 6.17 2.25 31 302109100216

IVBS-TE25-P 1.00 1.88 1.37 2.25 6.75 2.25 31 302111100216

IVBS-TE40-P 1.50 2.25 1.88 3.12 8.99 3.00 31 302113100216

IVBS-TE50-P 2.00 3.25 2.62 4.12 11.09 3.50 31 302114100216



IVBS-KF16-P 0.75 2.15 1.12 1.87 6.17 2.25 32 302109110016

IVBS-KF25-P 1.00 2.03 1.37 2.25 6.75 2.25 32 302111110016

IVBS-KF40-P 1.50 2.40 1.88 3.12 8.99 3.00 32 302113110016

IVBS-KF50-P 2.00 3.40 2.62 4.12 11.09 3.50 32 302114110016



IVBS-CR16-P 0.75 2.50 1.12 1.87 6.17 2.25 33 302109130216

IVBS-CR35-P 1.50 2.45 1.88 3.12 8.99 3.00 33 302113130216





3/4~2 inchs : air to open, spring to close. (Normally close)

4~6.5 kg/cm2 operating pressure.

Sensor Specification : Voltage DC/AC 4~240V Amps : 5~40 mA.

Option Available : Air Solenoid DC24V, AC24V, AC110V, AC220V.







Manually Operated with Bellows Manually Operated with Bellows

Tube End

Figure 34


A

A

O.D.

O.D.

D

B

D

B

C

C



CF Flange

Figure 36

A

O.D.

D

B

C








YVB-TE16-M 0.75 3.70 3.91 4.43 2.25 34 304109000016

YVB-TE25-M 1.00 3.90 3.82 4.34 2.25 34 304111000016

YVB-TE40-M 1.50 4.82 4.87 5.74 3.00 34 304113000016

YVB-TE50-M 2.00 6.70 5.30 6.55 3.50 34 304114000016



YVB-KF16-M 0.75 4.00 3.91 4.43 2.25 35 304109010016

YVB-KF25-M 1.00 4.20 3.82 4.34 2.25 35 304111010016

YVB-KF40-M 1.50 5.12 5.31 6.18 3.00 35 304113010016

YVB-KF50-M 2.00 7.00 5.30 6.55 3.50 35 304114010016



YVB-CR16-M 0.75 4.70 3.91 4.43 2.25 36 304109030016

YVB-CR35-M 1.50 5.24 5.31 6.55 3.00 36 304113030016











Tube End

Figure 37


A

A

O.D.

O.D.

B

B

D

C

D

C



CF Flange




Figure 39

A

O.D.

B

D

C



YVB-CU-TE16-M 0.75 3.70 3.88 4.76 2.75 37 304609000016

YVB-CU-TE25-M 1.00 3.90 3.92 4.44 2.75 37 304611000016

YVB-CU-TE40-M 1.50 4.82 5.01 5.87 3.37 37 304613000016

YVB-CU-TE50-M 2.00 6.70 5.30 6.55 4.47 37 304614000016



YVB-CU-KF16-M 0.75 4.00 3.88 4.76 2.75 38 304609010016

YVB-CU-KF25-M 1.00 4.20 3.92 4.44 2.75 38 304611010016

YVB-CU-KF40-M 1.50 5.12 5.01 5.87 3.37 38 304613010016

YVB-CU-KF50-M 2.00 7.00 5.30 6.55 4.47 38 304614010016



YVB-CU-CR16-M 0.75 4.70 3.88 4.76 2.75 39 304609030016

YVB-CU-CR35-M 1.50 5.24 5.01 5.87 3.37 39 304613030016






Metal Seal Bonnet : 10-9 Torr vacuum rating KF and approximate 10-10 Specifications:

Torr vacuum rating







Pneumatically Actuated with Bellows Pneumatically Actuated with Bellows

Tube End

Figure 40


A

A

O.D.

O.D.

C

C

B

B



CF Flange

Figure 42

A

O.D.

C

B




Pneumatically Actuated with Bellows




YVB-TE16-P 0.75 3.70 4.15 2.25 40 304109100016

YVB-TE25-P 1.00 3.90 4.09 2.25 40 304111100016

YVB-TE40-P 1.50 4.82 5.61 3.00 40 304113100016

YVB-TE50-P 2.00 6.70 7.15 3.50 40 304114100016

YVB-TE63-P 2.50 7.75 7.96 4.00 40 304115200016



YVB-KF16-P 0.75 4.00 4.15 2.25 41 304109110016

YVB-KF25-P 1.00 4.20 4.09 2.25 41 304111110016

YVB-KF40-P 1.50 5.12 5.61 3.00 41 304113110016

YVB-KF50-P 2.00 7.00 7.15 3.50 41 304114110016



YVB-CR16-P 0.75 4.70 4.15 2.25 42 304109130016

YVB-CR35-P 1.50 5.24 5.61 3.00 42 304113130016

YVB-CR63-P2 2.50 8.25 7.96 4.00 42 304115230016





3/4"~2 inchs : air to open, spring to close.

Over 2 inchs : air to open, air to close.







Tube End

Figure 43


A

A

O.D.

O.D.

B

B

C

C



CF Flange


Pneumatically Actuated with Bellows Attached Reed Sensor Pneumatically Actuated with Bellows Attached Reed Sensor


Figure 45

A

O.D.

B C



YVBS-TE16-P 0.75 3.70 4.74 2.25 43 304109100216

YVBS-TE25-P 1.00 3.90 4.67 2.25 43 304111100216

YVBS-TE40-P 1.50 4.82 6.16 3.00 43 304113100216

YVBS-TE50-P 2.00 6.70 7.78 3.50 43 304114100216



YVBS-KF16-P 0.75 4.00 4.74 2.25 44 304109110216

YVBS-KF25-P 1.00 4.20 4.67 2.25 44 304111110216

YVBS-KF40-P 1.50 5.12 6.16 3.00 44 304113110216

YVBS-KF50-P 2.00 7.00 7.78 3.50 44 304114110216



YVBS-CR16-P 0.75 4.70 4.74 2.25 45 304109130216

YVBS-CR35-P 1.50 5.24 6.16 3.00 45 304113130216





3/4"~2 inchs : air to open, spring to close. (Normally close)


Sensor Specification : Voltage DC/AC 4~240V Amps : 5~40 mA.

Option Available : Air Solenoid DC24V, AC24V, AC110V, AC220V.





BAKEABLE ALL-METAL VALVE


www.high-light.com.tw www.high-light.com.tw

Bakeable All-Metal Valve

Model No. O.D. A B C D Parts No.

AVBAK-CR16 19.05 38.1 122.2 133 38.1 300509030011

AVBAK-CR35 38.1 62.5 170 189 54 300511030011

Bakeability : 400˚C (open), 300˚C (close).

Pressure Range : Below 10-10 torr.

All stainless steel construction.

Bellows stem seal.

Leak Rate : 8.7 x 10-11 Pa.m3 Specifications:

/sec.

Closure Torque : CR16 First 150kg-cm, Maximum 250kg-cm.

CR35 First 300kg-cm, Maximum 600kg-cm.

Orientation : Any position.

D

O.D.

A

O.D.

A

B

C

D



Manually Operated Angle Valve

KF16,25 KF40,50

E

E

O.D.

A

O.D.

A

B

C

F

D

Model No. O.D. A B C D E F Parts No.

AVALWB-KF16-M 19.05 40 77 108 48 64 120 310109010026

AVALWB-KF25-M 25.4 50 99 130 56 80 148 310111010026

AVALWB-KF40-M 38.1 65 124 158 68 101 184 310113010026

AVALWB-KF50-M 50.8 70 131 168 78 111 207 310114010026

O.D.

A

O.D.

A

B

C

F


-

6 55




Single Pneumatically- Actuated Angle Valve

No Sensor

Model No. O.D. A B C D E Parts No.

AVALWB-KF16-P 19.05 40 68 109 48 64 310109110026

AVALWB-KF25-P 25.4 50 90 142 56 80 310111110026

AVALWB-KF40-P 38.1 65 112 191.3 68 101 310113110026

AVALWB-KF50-P 50.8 70 121 202.8 78 111 310114110026

Attached Reed Sensor

D


AVALWBS-KF16-P 19.05 40 68 109 48 64 310109110226

AVALWBS-KF25-P 25.4 50 90 142 56 80 310111110226

AVALWBS-KF40-P 38.1 65 112 191.3 68 101 310113110226

AVALWBS-KF50-P 50.8 70 121 202.8 78 111 310114110226

E

O.D.

A

O.D.

A

B

C

Double Pneumatically- Actuated Angle Valve




No Sensor

Attached Reed Sensor

D

AVALWB-KF16-P2 19.05 40 68 125 48 64 310109210026

AVALWB-KF25-P2 25.4 50 90 156 56 80 310111210026

AVALWB-KF40-P2 38.1 65 112 187 68 101 310113210026

AVALWB-KF50-P2 50.8 70 121 204 78 111 310114210026


AVALWBS-KF16-P2 19.05 40 68 125 48 64 310109210226

AVALWBS-KF25-P2 25.4 50 90 156 56 80 310111210226

AVALWBS-KF40-P2 38.1 65 112 187 68 101 310113210226

AVALWBS-KF50-P2 50.8 70 121 204 78 111 310114210226

O.D.

E

A

O.D.

A

B

C

Ball Valve

Model No. O.D. A

B C

Parts No.

KF16BV102 19.05 64 102 70 3201093101131

KF25BV107 25.4 70.4 107 83 3201113101131

KF40BV130 38.1 94 130 114.5 3201133101131

KF50BV178 50.8 138 178 130 3201143101131


BALL VALVE



1”

316

A

B

O.D.

C

BALL VALVE


709

TEL/ 06-2460296 FAX/ 06-2471701

HEAD QUARTERS



TEL/ +886-6-2460296 FAX/ +886-6-2471701


303

TEL/ 03-5973337 FAX/ 03-5973073




TEL/ +886-3-5973337 FAX/ +886-3-5973073

TEL/ +86-21-50460355

FAX/ +86-21-50460234




TEL/ +86-21-50460355

FAX/ +86-21-50460234



VACUUM 2002

SOLUTION

SECTION 7

CENTERING RING SERIES


CENTERING

RING

SERIES

CONTENTS


CENTERING RING SERIES


Temperature Range of Generic Elastomers

Relation Between O'ring Wire Diameter & Inside Diameter

AS568 DASH Number

Durometer Chart

O'ring Test Reports

KF Centering Ring

KF Centering Ring with O'Ring

KF Centering Ring, with Outer Ring & O'Ring

KF Centering Ring Adaptor, O'Ring

KF Meshed Centering Ring

KF Overpressure Ring

ISO Centering Ring

ISO Centering Ring with O'Ring

ISO Outer Ring Centering Ring, O'Ring

7 -

7 -

7 -

7 -

7 -

7 -

7 - 1

7 - 2

7 - 3

7 - 4

7 - 5

7 - 6

7 - 7

7 - 9

7 - 13






Features:

Viton O'ring bakeable to 200°C intermittently, sustained use to 150°C.

Vacuum seal of KF-series: O'ring compression by uniform pressure application around the

15° outer flange surface.

The vacuum seal of ISO-series is made by compressing the O'ring between the mating

flanges. This done by alternately wrench-tightening opposing pairs of clamps or bolts until

the first metal-to-metal contact is made between the inner surfaces of the flanges and the

spacing lips of the centering ring.


Centering Ring :304 S.S. (Other material available upon request)

O'ring :Viton (Other material available upon request)

Outer Ring :Aluminum

Mesh :304 S.S.

Temperature Range:150°C (Viton) 80°C (NBR)


Applications:

The O'ring is considered a universal sealing device.

Used as static, dynamic, radial or face seals.

Vacuum seal.

OUTER RING


O’RNG

Description:

Viton O'ring are normally used in vacuum service in place of NBR and silicone rubber.

Viton has a low porosity to most gases (except helium) and withstands high temperature (up

to 200°C) for short period. NBR O'ring are low cost, but their maximum operating

temperature (approx. 100°C) makes them unacceptable for many vacuum applications.

Silicone O'rings can withstand temperatures of 250°C for short periods, but silicone tends to

harden to prolonged high temperature service, sticking to the metal surfaces and making the

O'ring difficult to replaced. Silicone is also very porous to helium.

Comparison of Properties of Generic Elastomers

NOTE:

ELASTOMER TYPE (Polymer)

PROPERTIES FFKM FXM FKM EPDM NBRECO HNBRCR AU SI FSI

ABARSION RESISTANCE

ACID RESISTANCE

CHEMICAL RESISTANCE

COLD RESISTANCE

ELECTRICAL PROPERITES

FLAME RESISTANCE

HEAT RESISTANCE

IMPERMEABILITY

OIL RESISTANCE

OZONE RESISTANCE

SET RESISTANCE

TEAR RESISTANCE

TENSILE STRENGTH

WATER/STEAM RESISTANCE

WEATHER RESISTANCE

FFKM CHEMRAZ Perfluoroelastomer

FXM

®

FLUORAZ TFE/Propylene

FKM ®

FLUOROELASTOMER VF2/HPF (Viton )

EPDM ETHYLENE PROPYLENE

NBR NITRILE

ECO EPICHLOROHYDRIN

HNBR HYDROGENATED NITRILE

CR NEOPRENE

AU POLYURETHANE

SI SILICONE

FSI FLUOROSILICONE

- Poor - Fair - Good - Excellent

7 -

7

-

®




Temperature Range of Generic Elastomers

ELASTOMER TEMPERATURE RANGE

EPICHLOROHYDRIN - 20°C ~ 120°C

URETHANE - 40°C ~ 93°C

NEOPRENE - 54°C ~ 121°C

NITRILE - 54°C ~ 121°C

HYDROGENATED NITRILE - 5°C ~ 150°C

ETHYLENE PROPYLENE - 54°C ~ 150°C

FLUOROSILICONE - 40°C ~ 205°C

SILICONE - 114°C ~ 232°C

FKM FLUOROCARBON - 5°C ~ 204°C

FLUORAZ FLUOROCARBON 0°C ~ 260°C

CHEMRAZ PERFLUOROELASTOMER - 25°C ~ 260°C

Polyurethane (AU):

is a very tough, abrasion and wear-resistant elastoplastic material well suited for use as a

hydraulic rod or piston seal in heavy duty applications such as construction and lift

equipment. Most polyurethane compounds have a service temperature range from -40°C to

+93°C.

Neoprene (CR):

is a good general purpose polymer with a wide temperature range from -54°C to +121°C.

Neoprene exhibits moderate resistance to a broad range of fluids. These attributes account

for its wide use as a commercial seal material.

Nitrile (NBR):

is a popular polymer with excellent resistance to petroleum-based fluids, a good balance of

physical properties and a wide temperature range from-54°C to +121°C. Nitrile is the most

widely used polymer in the seal industry today, being the base polymer for most military

rubber specifications for fuel and oil-resistant MS and AN materials.

Hydrogenated Nitrile (HNBR):

is a newer polymer type similar to nitrile with improved high-temperature capabilities. Also

known as HSN(highly saturated nitrile), HNBR is capable of resisting temperatures up to

+150°C with excellent resistance to petroleum-based fluid. Available in a variety of

automotive rubber specification grades.

Ethylene Propylene (EPDM):

is widely specified as a seal material due to its excellent resistance to Skydrol and other

phosphate ester based hydraulic fluids. Ethylene propylene has a temperature range from

54°C to +150°C and is suitable for steam service to +204°C. EPDM materials are widely

used to seal automotive brake fluids and in aircraft hydraulic systems.

Silicone (SI):

as a glass this polymer exhibits exceptional heat and compression set resistance but relatively

poor tensile strength, tear and abrasion resistance. Silicones have the advantage of being

useful in wide temperature extremes. Specific Parker silicone compounds have exhibited

flexibility below -114°C, and some materials will resist temperatures up to +371°C for short

periods. The maximum recommended temperature for continuous service is +232°C.

Silicone is recommended for use in dry heat, high-aniline point oils and chlorinated diphenyls.

Fluorocarbon (FKM):

is the second most popular seal material after nitrile. Fluorocarbon polymers have widespectrum

chemical resistance and a very broad temperature range from -29°C to +204°C.

Properly formulated, some fluorocarbon materials have been known to seal temperatures as

high as +316°C for short periods. Some fluorocarbon compounds can be used in low

temperature static sealing applications to -54°C. FKM is widely used in aircraft, aerospace,

automotive and other applications requiring maximum resistance to deterioration by

environment and/or fluids.

Perfluoroelastomer (FFKM):

is a new class of seal material combining the chemical resistance of PTFE with the elastic

properties of fluorocarbon. The materials are an excellent choice for use in high-heat

applications where harsh chemical environments are present, as in semiconductor

processing equipment. FFKM has a temperature range from -25°C to +260°C.

Polyacrylate (ACM):

has outstanding resistance to petroleum-based fuels and oils. In addition, this material has

good resistance to oxidation, ozone and sunlight, with the ability to resist flex cracking. The

temperature range of polyacrylate materials is from -18°C to +150°C. ACM is widely used

in the automotive industry for automatic transmission and power steering service.

7 -

7

-

7

-



Butyl (IIR):


prior to the introduction of ethylene, butyl polymers were used to seal phosphate ester type

hydraulic fluids. Currently butyl finds its widest sealing application in vacuum systems

because of its very low gas permeation rates. The temperature range of butyl is -54°C to

+107°C.

Fluorosilicone (FMVQ):

combines the excellent temperature range of silicone with good resistance to petroleumbased

fuels and lubricants. Currently, the primary use of fluorosilicone materials is for seals

in aircraft fuel systems at temperatures up to +177°C and in applications where high heat

environments are combined with potential exposure to petroleum oils and/or hydrocarbon

fuels. High-strength fluorosilicone materials with better wear resistance have been

developed, and some of these also exhibit much improved resistance to compression set.

Polytetrafluoroethy lene (FTFE):

is a very stable polymer with extremely good resistance to almost all known chemicals as well

as a very wide temperature range from -268°C to over +288°C. PTFE may be fabricated in

its pure state or blended with various fillers to produce a material better suited for a

particular application. PTFE has very low friction and is widely used for piston seals and other

applications such as valve stem seals where resistance to temperature extremes and harsh

chemicals is required.

PEEK:

is an acronym for polyetheretherketone, a high-temperature-resistant plastic used for backups

and other sealing components where extrusion resistance, high-temperature capability

and a broad resistance to chemical environments is needed. Available in unmodified or

glass-fill formulations, PEEK has a long-term service temperature capability of +232°C.

Nylon:

is a generic name for a well-known family of plastics used widely in the sealing industry as

anti-extrusion devices. Nylon is resistant to a variety of petroleum and phosphate ester

hydraulic fluids. Nylon's temperature range is -55°C to +120°C.

Relation Between O'ring Wire Diameter & Inside Diameter

AS568

(001~475)

AS568

(901~932)

Wire diameter of O’Ring(mm)

Wire diameter of O’Ring(mm)

6.98

5.33

3.53

2.62

1.78

1.52

1.27

1.02

3.00

2.95

2.46

2.21

2.08

1.98

1.83

1.63

1.42

0

0 1.07 1.42 4.34 113.66

247.32 456.06 481.46 494.16

0.74 1.24 1.78 10.46 133.07

O’Ring I.D.(mm)

0

0 4.7 7.64 10.52 13.46 17.93 21.92 34.42 37.46

59.36

6.7 8.92 11.89 16.63 19.18

O’Ring I.D.(mm)

-

7




AS568 DASH Numbers

By Cross Section & Internal Diameter

ID 1/16 3/32 1/8 3/16 1/4

1/32 001*

3/64 002**

1/16 003 102

5/16 004

3/32 005 103

1/8 006 104

5/32 007 105

3/16 008 106 201

7/32 009 107

1/4 010 108 202

5/16 011 109 203

3/8 012 110 204

7/16 013 111 205 309

1/2 014 112 206 310

9/16 015 113 207 311

5/8 016 114 208 312

11/16 017 115 209 313

3/4 018 116 210 314

13/16 019 117 211 315

7/8 020 118 212 316

15/16 021 119 213 317

1 022 120 214 318

1-1/16 023 121 215 319

1-1/8 024 122 216 320

1-3/16 025 123 217 321

1-1/4 026 124 218 322

1-5/16 027 125 219 323

1-3/8 028 126 220 324

1-7/16 127 221

1-1/2 029 128 222 325

1-9/16 129

1-5/8 030 130 223 326

1-11/16 131

1-3/4 031 132 224 327

1-13/16 133

1-7/8 032 134 225 328

1-15/16 135

2 033 136 226 329

2-1/16 137

2-1/8 034 138 227 330

2-3/19 139

2-1/4 035 140 228 331

ID 1/16 3/32 1/8 3/16 1/4

2-5/16 141

2-3/8 036 142 229 332

2-7/16 143

2-1/2 037 144 230 333

2-9/16 145

2-3/8 038 146 231 334

2-11/16 147

2-1/4 039 149 232 335

2-13/16 149

2-7/8 040 150 233 336

3 041 151 234 337

3-1/8 235 338

3-1/4 042 152 236 339

3-3/8 237 340

3-1/2 043 153 238 341

3-5/8 239 342

3-3/4 044 154 240 343

3-7/8 241 344

4 045 155 242 345

4-1/8 243 346

4-1/4 046 156 244 347

4-3/8 245 348

4-1/2 047 157 246 349 425

4-5/8 247 350 426

4-3/4 048 158 248 351 427

4-7/8 249 352 428

5 049 159 250 353 429

5-1/8 251 354 430

5-1/4 050 160 252 355 431

5-3/8 253 356 432

5-1/2 161 254 357 433

5-5/8 255 358 434

5-3/4 162 256 359 435

5-7/8 257 360 436

6 163 258 361 437

6-1/4 164 259 362 438

6-1/2 165 260 363 439

6-3/4 166 261 364 440

7 167 262 365 441

7-1/4 168 263 366 442

7-1/2 169 264 367 443

7-3/4 170 265 368 444

By Cross Section & Internal Diameter

ID 1/16 3/32 1/8 3/16 1/4

8 171 266 369 445

8-1/4 172 267

8-1/2 173 268 370 446

8-3/4 174 269 371

9 175 270 372 447

9-1/4 176 271 373

9-1/2 177 272 374 448

9-3/4 178 273 375

10 274 376 449

10-1/4 377

10-1/2

10-3/4

275 378 450

11

11-1/4

276 379 451

11-1/2

11-3/4

277 380 452

12 278 381 453

12-1/2 454

13 279 382 455

13-1/2 456

14 280 383 457

14-1/2 458

15 281 384 459

15-1/2 460

16 282 385 461

16-1/2 462

17 283 386 463

17-1/2 464

18 284 387 465

18-1/2 466

19 388 467

19-1/2 468

20 389 469

21 390 470

22 391 471

23 392 472

24 393 473

25 394 474

26 395 475

*AS568-001 Nominal cross section = 1/32

**AS568-002 Nominal cross section = 3/64

7 -

7

-




Durometer Chart

The hardness of rubber compounds is measured by the Shore A durometer; the higher the

durometer number, the harder the compound. 70-durometer hardness should be used

wherever possible as it offers the best combination of properties for most o-ring applications.

Softer compounds stretch easier and seal better on rough surfaces. Harder compounds offer

greater abrasion resistance and resistance to extrusion. Extrusion must always be considered

when high pressures are used. The proper hardness may be selected from this chart by

matching the fluid pressure with maximum extrusion gap.

Fluid pressure

psi

Maximum gap

inches

O'ring Test Reports

7 -

7

-




KF Centering Ring


KF10CRS 304 S.S. 10 12 8 3.9 180003410

KF16CRS 304 S.S. 16 17 8 3.9 180005410

KF25CRS 304 S.S. 25 26 8 3.9 180006410

KF40CRS 304 S.S 40 41 8 3.9 180008410

KF50CRS 304 S.S. 50 52 8 3.9 180009410

KF10CRA Al 10 12 8 3.9 180003110

KF16CRA Al 16 17 8 3.9 180005110

KF25CRA Al 25 26 8 3.9 180006110

KF40CRA Al 40 41 8 3.9 180008110

KF50CRA Al 50 52 8 3.9 180009110

øB

D

C

øA

KF Centering Ring with O'Ring

Model No. C/R O’Ring O’Ring A B C D Parts No.

Material Material Size

KF10CRVS 304 S.S. Viton AS-310 10 12 8 3.9 180103411





KF10CRVA Al Viton AS-310 10 12 8 3.9 180103111





KF10CRNS 304 S.S. NBR AS-310 10 12 8 3.9 180303411





KF10CRNA Al NBR AS-310 10 12 8 3.9 180303111







øB

D

C

øA

O'Ring's color is brown, black is available upon request

-

7 3





KF Centering Ring, with Outer Ring & O'Ring

Model No. O/R C/R O’Ring O’Ring A B C Parts No.

Material Material Material Size

KF16OCRVS Al 304 S.S. Viton 5018 16 32.5 8 181105421



KF50OCRVS Al 304 S.S. Viton AS-330 50 77.5 8 181109421

KF16OCRV-316 Al 316 S.S. Viton 5018 16 32.5 8 181105621



KF50OCRV-316 Al 316 S.S. Viton AS-330 50 77.5 8 181109621

øA

C

øB

O'Ring's color is brown, black is available upon request

KF Centering Ring Adaptor, O’Ring

Model No. C/R O’Ring O’Ring A B C D E F Parts No.


KF10CR16VS 304 S.S. Viton AS-314 10 12 16 17 8 3.9 19011A411

KF20CR25VS 304 S.S. Viton AS-320 20 22 25 26 8 3.9 19011B411

KF32CR40VS 304 S.S. Viton AS-326 32 34 40 41 8 3.9 19011C411

KF10CR16VA Al Viton AS-314 10 12 16 17 8 3.9 19011A111

KF20CR25VA Al Viton AS-320 20 22 25 26 8 3.9 19011B111

KF32CR40VA Al Viton AS-326 32 34 40 41 8 3.9 19011C111

KF10CR16NS 304 S.S. NBR AS-314 10 12 16 17 8 3.9 19031A411

KF20CR25NS 304 S.S. NBR AS-320 20 22 25 26 8 3.9 19031B411

KF32CR40NS 304 S.S. NBR AS-326 32 34 40 41 8 3.9 19031C411

KF10CR16NA Al NBR AS-314 10 12 16 17 8 3.9 19031A111

KF20CR25NA Al NBR AS-320 20 22 25 26 8 3.9 19031B111

KF32CR40NA Al NBR AS-326 32 34 40 41 8 3.9 19031C111

øB

øA

F

E

øC

øD



-

7 4

-

7 5




KF Meshed Centering Ring

Model No. C/R O’Ring O’Ring Mesh/In2 A B C Parts No.


KF16M3CRVS 304 S.S. Viton AS-314 900 9.5 17 3.9 183105411

KF25M3CRVS 304 S.S. Viton AS-320 900 19 26 3.9 183106411



KF63M3CRVS 304 S.S. Viton AS-337 900 60.6 69.6 3.9 183110411




KF16M3CRNS 304 S.S. NBR AS-314 900 9.5 17 3.9 183305411

KF25M3CRNS 304 S.S. NBR AS-320 900 19 26 3.9 183306411



KF63M3CRNS 304 S.S. NBR AS-337 900 60.6 69.6 3.9 183310411





øB


C

øA

KF Overpressure Ring


Parts No.

KF10OPR 304 S.S. 23.5 28 3.7 20000341

KF16OPR 304 S.S. 30.12 31.75 3.7 20000541

KF25OPR 304 S.S. 38.86 40.4 3.7 20000641

KF40OPR 304 S.S 54 57.15 3.7 20000841

KF50OPR 304 S.S. 66.55 69.85 3.7 20000941

ISO80OPR 304 S.S. 100.2 106 3.9 20001141

øA

C

øB


-

7 6

-

7 7







ISO63CRSE 304 S.S. 68 70 8 3.9 191010420

ISO80CRSE 304 S.S. 81 83 8 3.9 191011420

ISO100CRSE 304 S.S. 100 102 8 3.9 191012420

ISO160CRSE 304 S.S 148 153 8 3.9 191015420

ISO200CRSE 304 S.S. 210 213 8 3.9 191016420

ISO250CRSE 304 S.S. 257.5 261 8 3.9 191017420

ISO320CRSE 304 S.S. 312 318 12 5.6 191019420

ISO400CRSE 304 S.S 394 400 12 5.6 191021420

ISO500CRSE 304 S.S. 494 501 12 5.6 191023420

ISO63CRAE Al 68 70 8 3.9 191010120

ISO80CRAE Al 81 83 8 3.9 191011120

ISO100CRAE Al 100 102 8 3.9 191012120

ISO160CRAE Al 148 153 8 3.9 191015120

ISO200CRAE Al 210 213 8 3.9 191016120

ISO250CRAE Al 257.5 261 8 3.9 191017120

ISO320CRAE Al 312 318 12 5.6 191019120

ISO400CRAE Al 394 400 12 5.6 191021120

ISO500CRAE Al 494 501 12 5.6 191023120


øB

D

C

øA




ISO63CRSA 304 S.S. 67 69.6 8 3.9 191010410

ISO80CRSA 304 S.S. 80 82.6 8 3.9 191011410

ISO100CRSA 304 S.S. 100 101.6 8 3.9 191012410

ISO160CRSA 304 S.S 150 152.6 8 3.9 191015410

ISO200CRSA 304 S.S. 210 212.6 8 3.9 191016410

ISO250CRSA 304 S.S. 257.5 260.4 8 3.9 191017410

ISO320CRSA 304 S.S. 312 318.3 12 5.6 191019410

ISO400CRSA 304 S.S 394 399.2 12 5.6 191021410

ISO500CRSA 304 S.S. 494 500.2 12 5.6 191023410

ISO63CRAA Al 67 69.6 8 3.9 191010110

ISO80CRAA Al 80 82.6 8 3.9 191011110

ISO100CRAA Al 100 101.6 8 3.9 191012110

ISO160CRAA Al 150 152.6 8 3.9 191015110

ISO200CRAA Al 210 212.6 8 3.9 191016110

ISO250CRAA Al 257.5 260.4 8 3.9 191017110

ISO320CRAA Al 312 318.3 12 5.6 191019110

ISO400CRAA Al 394 399.2 12 5.6 191021110

ISO500CRAA Al 494 500.2 12 5.6 191023110

øB

D

C

øA


-

7 8








ISO63CRVSE 304 S.S. Viton AS-336 68 70 8 3.9 191110421





ISO250CRVSE 304 S.S. Viton AS-377 257.5 261 8 3.9 191117421




ISO63CRVAE Al Viton AS-336 68 70 8 3.9 191110121





ISO250CRVAE Al Viton AS-377 257.5 261 8 3.9 191117121




øB

D

C

øA






ISO63CRNSE 304 S.S. NBR AS-336 68 70 8 3.9 191310421





ISO250CRNSE 304 S.S. NBR AS-377 257.5 261 8 3.9 191317421




ISO63CRNAE Al NBR AS-336 68 70 8 3.9 191310121





ISO250CRNAE Al NBR AS-377 257.5 261 8 3.9 191317121






øB

D

C

øA









ISO63CRVSA 304 S.S. Viton AS-336 67 69.5 8 3.9 191110411





ISO250CRVSA 304 S.S. Viton AS-377 257.5 260.4 8 3.9 191117411




ISO63CRVAA Al Viton AS-336 67 69.5 8 3.9 191110111





ISO250CRVAA Al Viton AS-377 257.5 260.4 8 3.9 191117111




øB

D

C

øA






ISO63CRNSA 304 S.S. NBR AS-336 67 69.5 8 3.9 191310411





ISO250CRNSA 304 S.S. NBR AS-377 257.5 260.4 8 3.9 191317411




ISO63CRNAA Al NBR AS-336 67 69.5 8 3.9 191310111





ISO250CRNAA Al NBR AS-377 257.5 260.4 8 3.9 191317111






øB

D

C

øA






D


Model No. O/R C/R O’Ring O’Ring A B C D E Parts No.


ISO63OCRVSE Al 304 S.S. Viton AS-336 68 70 8 3.9 94 192110421





ISO250OCRVSE Al 304 S.S. Viton AS-377 257.5 261 8 3.9 287 192117421




ISO63OCRVAE Al A1 Viton AS-336 68 70 8 3.9 94 192110121





ISO250OCRVAE Al A1 Viton AS-377 257.5 261 8 3.9 287 192117121




øE

C

øA

øB






ISO63OCRNSE Al 304 S.S. NBR AS-336 68 70 8 3.9 94 192310421





ISO250OCRNSE Al 304 S.S. NBR AS-377 257.5 261 8 3.9 287 192317421




ISO63OCRNAE Al Al NBR AS-336 68 70 8 3.9 94 192310121





ISO250OCRNAE Al Al NBR AS-377 257.5 261 8 3.9 287 192317121







øE

C

D

øA

øB

-

7 15








ISO63OCRVSA Al 304 S.S. Viton AS-336 67 69.5 8 3.9 94 192110411





ISO250OCRVSA Al 304 S.S. Viton AS-377 257.5 260.4 8 3.9 287 192117411




ISO63OCRVAA Al Al Viton AS-336 67 69.5 8 3.9 94 192110111





ISO250OCRVAA Al Al Viton AS-377 257.5 260.4 8 3.9 287 192117111





øE

C

D

øA

øB






ISO63OCRNSA Al 304 S.S. NBR AS-336 67 69.5 8 3.9 94 192310411





ISO250OCRNSA Al 304 S.S. NBR AS-377 257.5 260.4 8 3.9 287 192317411




ISO63OCRNAA Al Al NBR AS-336 67 69.5 8 3.9 94 192310111





ISO250OCRNAA Al Al NBR AS-377 257.5 260.4 8 3.9 287 192317111




øE

C

D

øA

øB



-

7 16


709

TEL/ 06-2460296 FAX/ 06-2471701

HEAD QUARTERS



TEL/ +886-6-2460296 FAX/ +886-6-2471701


303

TEL/ 03-5973337 FAX/ 03-5973073




TEL/ +886-3-5973337 FAX/ +886-3-5973073

TEL/ +86-21-50460355

FAX/ +86-21-50460234




TEL/ +86-21-50460355

FAX/ +86-21-50460234



VACUUM 2002

SOLUTION

SECTION 8~9

VACUUM PUMP & OTHERS

TECHNICAL INFORMATION


VACUUM

PUMP &

OTHERS

TECHNICAL

INFORMATION

CONTENTS



ANSI, JIS, DIN Flange

Special Order Products

Turbo Molecular Pump

Dry Vacuum Pumps

Cryo Pump

Others


TECHNICAL INFORMATION

Conversion Table

Temperature

Graphic Symbols for Important Components

Used in Vacuum Technology

Periodic Table of the Elements

Stainless Steel Specification Table

8 - 1

8 - 4

8 - 9

8 - 10

8 - 11

8 - 12

9 - 1

9 - 3

9 - 4

9 - 7

9 - 9


-

8 1





ANSI Flange (150 lb)

Model No. Nominal A B C D *No. P.C.D. Parts No.

ANSI150-350-050 1/2 3 1/2 7/16 0.88 5/8 * 4 2 3/8 156301A43

ANSI150-388-075 3/4 3 7/8 1/2 1.09 5/8 * 4 2 3/4 156302A53

ANSI150-425-100 1 4 1/4 9/16 1.36 5/8 * 4 3 1/8 156303A63

ANSI150-463-125 1 1/4 4 5/8 5/8 1.70 5/8 * 4 3 1/2 156323A73

ANSI150-500-150 1 1/2 5 11/16 1.95 5/8 * 4 3 7/8 156305A83

ANSI150-600-200 2 6 3/4 2.44 3/4 * 4 4 3/4 156306A93

ANSI150-700-250 2 1/2 7 7/8 2.94 3/4 * 8 5 1/2 156307B13

ANSI150-750-300 3 7 1/2 15/16 3.57 3/4 * 8 6 156308B23

ANSI150-850-350 3 1/2 8 1/2 15/16 4.07 3/4 * 8 7 156324B33

ANSI150-900-400 4 9 15/16 4.57 3/4 * 8 7 1/2 156309B43

ANSI150-1000-500 5 10 15/16 5.66 7/8 * 8 8 1/2 156310B53

ANSI150-1100-600 6 11 1 6.72 7/8 * 8 9 1/2 156311B63

ANSI150-1350-800 8 13 1/2 1 1/8 8.72 7/8 * 8 11 3/4 156313B73

øC

P.C.D.

øA


Material : 304 Stainless Steel.

øD

B


JIS Flange (5kg/cm 2 )


JIS5-075-010 10 75 9 17.8 12 * 4 55 157200AC3

JIS5-080-015 15 80 9 22.2 12 * 4 60 157201AD3

JIS5-085-020 20 85 10 27.7 12 * 4 65 157202AE3

JIS5-095-025 25 95 10 34.5 12 * 4 75 157203AF3

JIS5-115-032 32 115 12 43.2 15 * 4 90 157223AG3

JIS5-120-040 40 120 12 49.1 15 * 4 95 157205AH3

JIS5-130-050 50 130 14 61.1 15 * 4 105 157206AJ3

JIS5-155-065 65 155 14 77.1 15 * 4 130 157207AK3

JIS5-180-080 80 180 14 90.0 19 * 4 145 157208AL3

JIS5-190-090 90 190 14 102.6 19 * 4 155 157224AM3

JIS5-200-100 100 200 16 115.4 19 * 8 165 157209AN3

JIS5-235-125 125 235 16 141.2 19 * 8 200 157210AP3

JIS5-265-150 150 265 18 166.6 19 * 8 230 157211AQ3

JIS5-300-175 175 300 18 192.1 23 * 8 260 157225AU3

JIS5-320-200 200 320 20 218.0 23 * 8 280 157213AR3

JIS Flange (10kg/cm 2 )


JIS10-90-010 10 90 12 17.8 15 * 4 65 157400AC3

JIS10-95-015 15 95 12 22.2 15 * 4 70 157401AD3

JIS10-100-020 20 100 14 27.7 15 * 4 75 157402AE3

JIS10-125-025 25 125 14 34.5 19 * 4 90 157403AF3

JIS10-135-032 32 135 16 43.2 19 * 4 100 157423AG3

JIS10-140-040 40 140 16 49.1 19 * 4 105 157405AH3

JIS10-155-050 50 155 16 61.1 19 * 4 120 157406AJ3

JIS10-175-065 65 175 18 77.1 19 * 4 140 157407AK3

JIS10-185-080 80 185 18 90.0 19 * 4 150 157408AL3

JIS10-195-090 90 195 18 102.6 19 * 4 160 157424AM3

JIS10-210-100 100 210 18 115.4 19 * 8 175 157409AN3

JIS10-250-125 125 250 20 141.2 23 * 8 210 157410AP3

JIS10-280-150 150 280 22 166.6 23 * 8 240 157411AQ3

JIS10-305-175 175 305 22 192.1 23 * 8 265 157425AU3

JIS10-330-200 200 330 22 218.0 23 * 8 290 157413AR3

Note : All dimensions shown on this page are in mm.


-

8 2

-

8 3





DIN Flange (Nominal Pressure 6)


DIN6-075-010 10 75 12 22.4 11.5 * 4 50 158200A33

DIN6-080-015 15 80 12 27.7 11.5 * 4 55 158201A43

DIN6-090-020 20 90 14 34.5 11.5 * 4 65 158202A53

DIN6-100-025 25 100 14 43.2 11.5 * 4 75 158203A63

DIN6-120-032 32 120 16 49.5 14 * 4 90 158223A73

DIN6-130-040 40 130 16 62.0 14 * 4 100 158205A83

DIN6-140-050 50 140 16 74.7 14 * 4 110 158206A93

DIN6-160-065 65 160 16 90.7 14 * 4 130 158207B13

DIN6-190-080 80 190 18 103.4 18 * 4 150 158208B23

DIN6-210-100 100 210 18 116.1 18 * 4 170 158209B43

DIN6-240-125 125 240 20 143.8 18 * 8 200 158210B53

DIN6-265-150 150 265 20 170.7 18 * 8 225 158211B63

DIN6-320-200 200 320 22 221.5 18 * 8 280 158213B73

DIN Flange (Nominal Pressure 10)


DIN10-090-010 10 90 14 22.4 14 * 4 60 158400A33

DIN10-095-015 15 95 14 27.7 14 * 4 65 158401A43

DIN10-105-020 20 105 16 34.5 14 * 4 75 158402A53

DIN10-115-025 25 115 16 43.2 14 * 4 85 158403A63

DIN10-140-032 32 140 16 49.5 18 * 4 100 158423A73

DIN10-150-040 40 150 16 62.0 18 * 4 110 158405A83

DIN10-165-050 50 165 18 74.7 18 * 4 125 158406A93

DIN10-185-065 65 185 18 90.7 18 * 4 145 158407B13

DIN10-200-080 80 200 20 103.4 18 * 4 160 158408B23

DIN10-220-100 100 220 20 116.1 18 * 8 180 158409B43

DIN10-250-125 125 250 22 143.8 18 * 8 210 158410B53

DIN10-285-150 150 285 22 170.7 23 * 8 240 158411B63

DIN10-340-200 200 340 24 221.5 23 * 8 295 158413B73

Note : All dimensions shown on this page are in mm.



Stainless Chamber

Aluminum Chamber

-

8 4

-

8 5





Chamber

Chamber


Oil Mist Eliminator

Straight Through In-Line Valve

-

8 6

-

8 7





Molecular Sieve

Manual Operated Tee Valve


Pneumatic Actuated Tee Valve

Liquid Crystal Injection Chamber

-

8 8

-

8 9




Turbo Molecular Pump

HTC is an authorized agent and service center for SEIKO SEIKI turbo molecular pump.

For more than 5 years our service department has repaired most

models of turbo molecular pumps, satisfying the rigorous demands of

the semiconductor industry. Our extensive parts inventories, factorytrained

technicians and fully equipped, environmentally safe facilities

allow us to provide quality workmanship at fair price.

Dry Vacuum Pump

HTC is an authorized agent and service center for TAIKO dry pump.

Hum nity & Originality

Taiko has been aiming to have oil-free and clean dry vacuum with our

own vacuum technology cultivated for longer years.

The concept of twins screw rotors with specific profile made it possible

to have higher pumping efficiency at low rotation speed and to reduce

the number of assembling parts. It obviously resulted in high relibility

and easier maintenance.

It can operate under severe process conditions as etching and CVD for

the semiconductor industry. On the other hand, it can also operate for

wide range applications as fine chemical process of medicine, vacuum

packing process of food and so on.

Low speed screw rotation

based on the latest technology

-

8 10



www.high-ligh.com.tw

Cryo Pump

HTC is a service center for Cryopump.

HTC has a rapidly service team.

We have complete parts warehouse of cryo pump to insure

rapid, efficient and reliable service.

Our inventory of replacement parts includes repair kits and

related components for the major brands of cryo pump such as

AISIN, CTI etc.

Others

Welding Bellows Parts

Application:

We offer excellent welding bellows parts for semiconductor equipments such as CVD¡B

sputter¡Betcher and implanter etc.

Semiconductor Equipments

8 - 11 8 - 12

Accumulators

Actuators / Pistons

Aneroids

Bean Lines

Connectors

Couplings (Flexible)

Couplings

Expansion (Torque)

Dampening Devices Joints

Feed Throughs

Fluid Shock Absorbers

Fuel Drains

Gas Lines

Gate Valves

Kiss Seals

Leak Detectors

Lifters

Mechanical Shaft Seals

Orientors

Pressure Sensors

Pressure Switches

Pressure Transducers

Pumps / Compressors

Reservoirs

Shielding Devices

Slit Valves

Temperature Sensors

Valve Stem Seals

Vibration Dampeners

Volume Compensators

Wafer Compensators

X-Y-Z Manipulators

-

8 13



Others


HTC is authorized agent of VRC products

Gate Valves

Vacuum Gauge

VRC valves are accurate in the control of fluid flow and pressure and

the sequence of operation. Leakage between the valve element and

the valve seat is reduced to a negligible quantity by precisionmachined

surfaces, resulting in carefully controlled clearances.

For the last 10 years or so VRC has been working on Pirani and

Thermocouple gauge tube improvements.

Others

Ogawa (Hsiao Chuan) technology leak testing equipment

If compared to pressure difference type (pressurizing) leak tester, this tester won't be affected

by testing temperature and can measure for smaller leak rate.

It can be used for long-term without maintenance.

Available for high speed continuous testing.

As no need of air, the cost can be lowered down greatly.

Has obtained the special permit from Feng Tien Automobile Co.

-

8 14

-

8 15



Others


Continuous multi-function vacuum film plating equipment

A combination of vacuum film technology and roller turning technique, it is a continuous

equipment for polymerizing process with evaporating, splash plating, electro-bath, etc. for

ITO film, metallic foil, and fibre film.

Others

Vacuum exhaust, gas feeding system

Suitably applied for:

Function:

PDP, CCFL, FED, EL, etc.

panel exhaust, air feeding.

Precision of feeding air set pressure is upgraded (±1 torr).

Air feeding volume is efficient (to save the air).

System is composed of high welding technology and vacuum components

(feeding high purity air).

Upgrading to reach for vacuum.

High uniform distribution of temperature.

Sales Result:

Sharp, Mitsubishi, Toshiba, Matsushita, NEC, SASKYO, OPT, TEC, Hanli Photocell, Wang

Chen Electronic, etc.

-

8 16

-

9 1




Conversion Table

Pressure Force

kgf/cm 2 Pa mbar torr micron atm psi

N/m 2 mm Hg mtorr lb f/in 2

kgf/cm 2 1 9.8x10 4 9.8x10 2 7.36x10 2 7.36x10 5 9.68x10 -1 1.42x10 1

Pa 1.02x10 -5 1 1x10 -2 7.5x10 -3 7.5 9.87x10 -6 1.45x10 -4

mbar 1.02x10 -3 1x10 2 1 7.5x10 -1 7.5x10 2 9.87x10 -4 1.45x10 -2

torr 1.36x10 -3 1.33x10 2 1.33 1 1x10 3 1.32x10 -3 1.93x10 -2

micron 1.36x10 -6 1.33x10 -1 1.33x10 -3 1x10 -3 1 1.32x10 -6 1.93x10 -5

atm 1.03 1.01x10 5 1.01x10 3 7.6x10 2 7.6x10 5 1 1.47x10 1

psi 7.03x10-2 6.89x103 6.89x101 5.17x101 5.17x104 6.81x10-2 Example :

1

5x10-4Pa 5.1x10-9 5x10-4 5x10-6 3.75x10-6 3.75x10-3 4.94x10-9 7.25x10-8 Length

foot inch meter centimeter millimeter micron

ft in m cm mm um

foot 1 1.2x101 3.05x10-1 3.05x101 3.05x102 3.05x105 inch 8.33x10 -2 1 2.54x10 -2 2.54 2.54x10 1 2.54x10 4

meter 3.28 3.94x10 1 1 1x10 2 1x10 3 1x10 6

centimeter 3.28x10 -2 3.94x10 -1 1x10 -2 1 1x10 1 1x10 4

millimeter 3.28x10 -3 3.94x10 -2 1x10 -3 1x10 -1 1 1x10 3

micron 3.28x10 -6 3.94x10 -5 1x10 -6 1x10 -4 1x10 -3 1

Example :

2m 6.56 78.72 2 2x102 2x103 2x106 Weight

kg g oz lb

kg 1 1x103 3.53x101 2.21

g 1x10-3 1 3.53x10-2 2.21x10-3 oz 2.84x10 -2 2.84x10 1 1 6.25x10 -2

lb 4.54x10 -1 4.54x10 2 1.6x10 1 1

Example :

2kg 2 2x103 7.06X101 4.42

kgf N ozflbf kgf 1 9.81 3.53x101 2.21

N 1.02x10-1 1 3.6 2.25x10-1 oz f 2.83x10 -2 2.78x10 -1 1 6.25x10 -2

lb f 4.54x10 -1 4.45 1.6x10 1 1

Example :

10N 1.02 10 36 2.25

Torque

kgf-m N-m ozf-in lbf-ft kgf-m 1 9.81 1.38x103 7.23

N-m 1.02x10-1 1 1.41x102 7.38x10-1 oz f-in 7.25x10 -4 7.09x10 -3 1 5.21x10 -3

lb f-ft 1.38x10 -1 1.36 1.92x10 2 1

Example :

8 lbf-ft 1.104 10.88 1.54x103 8

gpm gps ltr/m ltr/s

gpm 1 1.67x10-2 3.79 6.31x10-2 Flow Rate

gps 6x101 1 2.27x102 3.79

ltr/m 2.64x10-1 4.4x10-3 1 1.67x10-2 ltr/s 1.59x10 1 2.64x10 -1 6x10 1 1

Example :

4gpm 4 6.68x10-2 1.52x101 2.52x10-1 Leak Rate

pa-ltr/s mbar-ltr/s torr-ltr/s std-cc/s

Pa-ltr/s 1 1x10-2 7.5x10-3 9.87x10-3 mbar-ltr/s 1x10 2 1 7.5x10 -1 9.87x10 -1

torr-ltr/s 1.33x102 1.33 1 1.32

std-cc/s 1.01x102 1.01 7.6x10-1 1

Example :

1x10-7 std-cc/s 1.01x10-5 1.01x10-7 7.6x10-8 1.x10-7 -

9 2

-

9 3




Temperature

°C °F

-73.3 -100 -148.0

-62.2 -80 -112.0

-51.1 -60 -76.0

-40.0 -40 -40.0

-28.9 -20 -4.0

-17.8 0 -32.0

-17.2 1 33.8

-16.7 2 35.6

-16.1 3 37.4

-15.6 4 39.2

-15.0 5 41.0

-14.4 6 42.8

-13.9 7 44.6

-13.3 8 46.4

-12.8 9 48.2

-12.2 10 50.0

-11.7 11 51.8

-11.1 12 53.6

-10.6 13 55.4

-10.0 14 57.2

-9.4 15 59.0

-8.9 16 60.8

-8.3 17 62.6

-7.8 18 64.4

-7.2 19 66.2

-6.7 20 68.0

-6.1 21 69.8

-5.6 22 71.6

-5.0 23 73.4

-4.4 24 75.2

-3.9 25 77.0

-3.3 26 78.8

-2.8 27 80.6

How to use:

°C °F

-2.2 28 82.4

-1.7 29 84.2

-1.1 30 86.0

-0.6 31 87.8

0 32 89.6

0.6 33 91.4

1.1 34 93.2

1.7 35 95.0

2.2 36 96.8

2.8 37 98.6

3.3 38 100.4

3.9 39 102.2

4.4 40 104.0

5.0 41 105.8

5.6 42 107.6

6.1 43 109.4

6.7 44 111.2

7.2 45 113.0

7.8 46 114.8

8.3 47 116.6

8.9 48 118.4

9.4 49 120.2

10.0 50 122.0

10.6 51 123.8

11.1 52 125.6

11.7 53 127.4

12.2 54 129.2

12.8 55 131.0

13.3 56 132.8

13.9 57 134.6

14.4 58 136.4

15.0 59 138.2

15.6 60 140.0

C=

5

(F-32) F=32+

9

C

9

5

°C °F °C °F

16.1 61 141.8 34.4 94 201.2

16.7 62 143.6 35.0 95 203.0

17.2 63 145.4 35.6 96 204.8

17.8 64 147.2 36.1 97 206.6

18.3 65 149.0 36.7 98 208.4

18.9 66 150.8 37.2 99 210.2

19.4 67 152.6 37.8 100 212

20.0 68 154.4 43.3 110 230

20.6 69 156.2 48.9 120 248

21.1 70 158.0 54.4 130 266

21.7 71 159.8 60.0 140 284

22.2 72 161.6 65.6 150 302

22.8 73 163.4 71.1 160 320

23.3 74 165.2 76.7 170 338

23.9 75 167.0 82.2 180 356

24.4 76 168.8 87.8 190 374

25.0 77 170.6 93.3 200 392

25.6 78 172.4 121.1 250 482

26.1 79 174.2 149 300 572

26.7 80 176.0 177 350 662

27.2 81 177.8 204 400 752

27.8 82 179.6 232 450 842

28.3 83 181.4 260 500 932

28.9 84 183.2 288 550 1022

29.4 85 185.0 316 600 1112

30.0 86 186.8 343 650 1202

30.6 87 188.6 371 700 1292

31.1 88 190.4 399 750 1382

31.7 89 192.2 427 800 1472

32.2 90 194.0 454 850 1562

32.8 91 195.8 482 900 1652

33.3 92 197.6 510 950 1742

33.9 93 199.4 538 1000 1832

For example, to convert 20°C into °F, find the number 20 in the center of the

first column. By referring the °F column on the right, it will be found that 20°C

equals 68.0°F.

To convert 20°F into °C, refer to the °C column on the left and it will be found

that 20°F equals -6.7°C.

Graphic Symbols for Important Components

Used in Vacuum Technology.

(Extract from DIN 28 401 Std. Spec.)

Vacuum Pumps

Cryo pump Diffusion pump Getter pump Piston vacuum

pump

Rotary plunger

vacuum pump

Radial flow

pump

Turbomolecular

pump

Accessories

Suptter-ion

pump

Rotary piston

vacuum pump

(e.g. trochoid pump)

Vacuum pump,

general

Baffle, general Cold trap,

general

Condensate trap

with heat

exchange

(e.g. cooled)

Filtering

apparatus,

general

Diaphragm

vacuum pump

Sliding vane

rotary vacuum

pump

Cold trap with

coolant reservoir

Gas filter,

general

Ejector vacuum

pump

Subimation

(evaporation)

pump

Roots vacuum

pump

Liquid ring

vacuum pump

Turbine vacuum

pump, general

Cooled baffle Condensate

trap, general

Sorption trap

-

9 4

-

9 5



Vacuum chamber


Vacuum Chamber

Isolating Devices

Butterfly valve Gate valve Isolating valve,

Straight-throught

valve

Right-angle

valve

Valve Actuation

Electric motor

operation

Weight-operated

Safety shutoff

valve

Electromagnetic

operation

Shut-off device,

general

Hydraulic or

pneumatic

operation

Non-return

valve

Stop-cock

Manual

operation

Right-angle

stop-cock

Three-way

stop-cock

Variable-leak

valve

Connections / Tubes

Branch-off point Change in the

cross-section of

a duct

Flange

connection

bolted

Threaded tube

connection

Gauges

Flange

connection

general

Vacuum gauge Vacuum gauge

control unit

General Symbol

Clamped flange

connection

Flexible

connection

(e.g. bellows,

flexible tubing)

Coooection

of ducts

Liner motion

leadthrough,

flange-mounted

Cross-over of two

ducts without

connection

Small flange

connection

Intersection of two ducts with connection

(Subject to international provision still to be agreed on, a contact point may be inserted for improved clearness)

General symbol for vacuum

(This symbol must be used only in the position shown)

Measurement of throughput

(This symbol must be used only in the position shown)

-

9 6

-

9 7




Periodic Table of the Elements

IA IIA IIIB IVB VB VIB VIIB VIII IB IIB IIIA IVA VA VIA VIIA INERT

GASES

1

H

1.00797

3

Li

6.939

11

Na

22.9898

19

K

39.102

37

Rb

85.47

55

Cs

132.905

87

Fr

(223)

4

Be

9.0122

12

Mg

24.312

20

Ca

40.08

38

Sr

87.62

56

Ba

137.34

88

Ra

(226)

21

Sc

44.956

39

Y

88.905

57

*La

138.91

89

‡Ac

(227)

22

Ti

47.90

40

Zr

91.22

72

Hf

178.49

104

Rf

(261)

23

V

50.942

41

Nb

92.906

73

Ta

180.948

105

Db

(262)

*

58 59 60

Ce Pr Nd

140.12 140.907 144.24

Lanthanide Series

‡Actinide Series

90

Th

232.038

91

Pa

(231)

92

U

238.03

24

Cr

51.996

42

Mo

95.94

74

W

183.85

106

Sg

(266)

61

Pm

(147)

93

Np

(237)

25

Mn

54.9380

43

Tc

(99)

75

Re

186.2

107

Bh

(262)

62

Sm

150.35

94

Pu

(242)

26

Fe

55.847

44

Ru

101.07

76

Os

190.2

108

Hs

(265)

63

Eu

151.96

95

Am

(243)

27

Co

58.9332

45

Rh

102.905

77

Ir

192.2

109

Mt

(266)

64

Gd

157.25

96

Cm

(247)

28

Ni

58.71

46

Pd

106.4

78

Pt

195.09

110

(271)

65

Tb

158.924

97

Bk

(247)

29

Cu

63.54

47

Ag

107.870

79

Au

196.967

111

(272)

66

Dy

162.50

98

Cf

(249)

Numbers in parenthesis are mass numbers of most stable or most common isotope.

Atomic weights corrected to conform to the 1963 values of the Commission on Atmoic Weights.

The group designations used here are the former Chemical Abstract Service numbers.

30

Zn

65.37

48

Cd

112.40

80

Hg

200.59

112

(277)

67

Ho

164.930

99

Es

(254)

5

B

10.811

13

Al

26.9815

31

Ga

69.72

49

In

114.82

81

Tl

204.37

68

Er

167.26

100

Fm

(253)

6

C

12.0112

14

Si

28.086

32

Ge

72.59

50

Sn

118.69

82

Pb

207.19

69

Tm

168.934

101

Md

(256)

7

N

14.0067

15

P

30.9738

33

As

74.9216

51

Sb

121.75

83

Bi

208.980

70

Yb

173.04

102

No

(256)

8

O

15.9994

16

S

32.064

34

Se

78.96

52

Te

127.60

84

Po

(210)

71

Lu

174.97

103

Lr

(257)

1

H

1.00797

9

F

18.9984

17

Cl

35.453

35

Br

79.909

53

I

126.904

85

At

(210)

2

He

4.0026

10

Ne

20.183

18

Ar

39.948

36

Kr

83.80

54

Xe

131.30

86

Rn

(222)

-

9 8

-

9 9





U.S.A. GERMANY GERMANY FRANCE JAPAN ITALY SWEDEN U.K. U.E. SPAIN RUSSIA

AISI DIN 17006 W.N. 17007 AFNOR JIS UNI SIS BSI EURONORM UNE GOST

201 SUS 201

301 X 12 CrNi 17 7 1.4310 Z 12 CN 17-07 SUS 301 X 12 CrNi 1707 23 31 301S21 X 12 CrNi 17 7 X 12 CrNi 17-07

302 X 5 CrNi 18 7 1.4319 Z 10 CN 18-09 SUS 302 X 10 CrNi 1809 23 31 302S25 X 10 CrNi 18 9 X 10 CrNi 18-09 12KH18N9

303 X 10 CrNiS18 9 1.4305 Z 10 CNF 18-09 SUS 303 X10 CrNiS 1809 23 46 303S21 X 10 CrNiS 18 9 X 10 CrNiS 18-09

303 Se Z 10 CNF 18-09 SUS 303 Se X10 CrNiS 1809 303S41 X 10 CrNiS 18-09 12KH18N10E

304

304 L

305

X 5 CrNi 18 10 1.4301

304S15

08KH18N10

Z 6 CN 18-09 SUS 304 X 5 CrNi 1810 23 32

X 6 CrNi 18 10 X 6 CrNi 19-10

X 5 CrNi 18 12 1.4303 304S16 06KH18N11

304 N SUS 304N1 X5 CrNiN 1810

304 H SUS F 304H X8 CrNi 1910 X6 CrNi 19-10

X 2 CrNi 18 11 1.4306 Z 2 CN 18-10 SUS 304L X 2 CrNi 1911 23 52 304S11 X 3 CrNi 18 10 X2 CrNi 19-10 03KH18N11

X 2 CrNiN 18 10 1.4311 Z 2 CN 18-10-Az SUS 304LN X 2 CrNiN 1811 23 71

Z 8 CN 18-12 SUS 305 X 8 CrNi 1812 23 33 305S19 X 8 CrNi 18 12 X8 CrNi 18-12

Z 6 CNU 18-10 SUS XM7 X 6 CrNiCu 18 10 4 Kd

309 X 15 CrNiS 20 12 1.4828 Z 15 CN 24-13 SUH 309 X 16 CrNi 2314 309S24 X 15 CrNi 23 13

309 S SUS 309S X 6 CrNi 2314 X 6 CrNi 22 13

310 X 12 CrNi 25 21 1.4845 SUH 310 X 22 CrNi 2520 310S24 20KH23N18

310S X 12 CrNi 25 20 1.4842 Z 12 CN 25-20 SUS 310S X 5 CrNi 2520 23 61 X 6 CrNi 25 20 10KH23N18

314 X 15 CrNiSi 25 20 1.4841 Z 12 CNS 25-20 X 16 CrNiSi 2520 X 15 CrNiSi 25 20 20KH25N20S2

316 X 5 CrNiMo 17 12 2 1.4401 Z 6 CND 17-11 SUS 316 X 5 CrNiMo 1712 23 47 316S31 X 6 CrNiMo 17 12 2 X 6 CrNiMo 17-12-03

316 X 5 CrNiMo 17 13 3 1.4436 Z 6 CND 17-12 SUS 316 X 5 CrNiMo 1713 23 43 316S33 X 6 CrNiMo 17 13 3 X 6 CrNiMo 17-12-03

316 F X 12 CrNiMoS 18 11 1.4427

316 N SUS 316N

316 H SUS F 316H X 8 CrNiMo 1712 X 5 CrNiMo 17-12

316 H X 8 CrNiMo 1713 X 6 CrNiMo 17-12-03

X 2 CrNiMo 17 13 2 1.4404 Z 2 CND 17-12 SUS 316L X 2 CrNiMo 1712 23 48 316S11 X 3 CrNiMo 17 12 2 X 2 CrNiMo 17-12-03 03KH17N14M2

X 2 CrNiMoN 17 12 2 1.4406 Z 2 CND 17-12-Az SUS 316LN X 2 CrNiMoN 1712

X 2 CrNiMo 18 14 3 1.4435 Z 2 CND 17-13 X 2 CrNiMo 1713 23 53 316S13 X 3 CrNiMo 17 13 3 X 2 CrNiMo 17-12-03 03KH16N15M3

X 2 CrNiMo 17 13 3 1.4429 Z 2 CND 17-13-Az X 2 CrNiMoN 1713 23 75

316 L X 6 CrNiMoTi 17 12 2 1.4571 Z 6 CNDT 17-12 X 6 CrNiMoTi 1712 23 50 320S31 X 6 CrNiMoTi 17 12 2 X 6 CrNiMoTi 17-12-03 08KH17N13M2T

10KH17N13M2T

X 10 CrNiMoTi 18 12 1.4573 X 6 CrNiMoTi 1713 320S33 X 6 CrNiMoTi 17 13 3 X 6 CrNiMoTi 17-12-03 08KH17N13M2T

10KH17N13M2T

X 6 CrNiMoNb 17 12 2 1.4580 Z 6 CNDNb 17-12 X 6 CrNiMoNb 1712 X 6 CrNiMoNb 17 12 2 08KH16N13M2B

X 10 CrNiMoNb 18 12 1.4583 X 6 CrNiMoNb 1713 X 6 CrNiMoNb 1713 3 09KH16N15M3B

317 SUS 317 X 5 CrNiMo 1815 23 66 317S16

317 L X 2 CrNiMo 18 16 4 1.4438 Z 2 CND 19-15 SUS 317L X 2 CrNiMo 1815 23 67 317S12 X 3 CrNiMo 18 16 4

317 L X 2 CrNiMo 18 16 4 1.4438 Z 2 CND 19-15 SUS 317L X 2 CrNiMo 1816 23 67 317S12 X 3 CrNiMo 18 16 4

330 X 12 CrNiSi 36 16 1.4864 Z 12NCS 35-16 SUH 330

321

X 6 CrNiTi 18 10 1.4541

X 12 CrNiTi 18 9 1.4878

Z 6 CNT 18-10 SUS 321 X 6 CrNiTi 1811 23 37 321S31 X 6 CrNiTi 18 10 X 6 CrNiTi 18-11 08KH18N10T

-

9 10

-

9 11





U.S.A. GERMANY GERMANY FRANCE JAPAN ITALY SWEDEN U.K. U.E. SPAIN RUSSIA

AISI DIN 17006 W.N. 17007 AFNOR JIS UNI SIS BSI EURONORM UNE GOST

321 H SUS 321H X 8 CrNiTi 1811 321S20 X 7 CrNiTi 18-11 12KH18N10T

329 X 8 CrNiMo 27 5 1.4460 SUS 329J1 23 24

347 X 6 CrNiNb 18 10 1.4550 Z 6 CNNb 18-10 SUS 347 X 6 CrNiNb 1811 23 38 347S31 X 6 CrNiNb 18 10 X 6 CrNiNb 18-11 08KH18N12B

347 H SUS F 347H X 8 CrNiNb 1811 X 7 CrNiNb 18-11

904 L

X 20 CrNiSi 25 4

1.4939

1.4821

Z 12 CNDV 12-02

UNS31803 X 2 CrNiMoN 22 5 1.4462

UNS32760 X 3 CrNiMoN 25 7 1.4501 Z 3 CND 25-06Az

X 6 Cr 13 1.4000

403 X 10 Cr 13 1.4006

405

409

X 15 Cr 13 1.4024

These are austenitic grades

These are ferritic grades

These are ferritic-austenitic grades (otherwise known as Duplex and Superduplex)

Z 12 C 13 SUS 403 X 12 Cr 13 23 02 403S17

X 10 Cr 13

X 12 Cr 13

X 6 CrAl 13 1.4002 Z 6 CA 13 SUS 405 X 6 CrAl 13 405S17 X 6 CrAl 13 X 6 CrAl 13

X 6 Cr 13 12Kh13

X 10 CrAl 7 1.4713 Z 8 CA 7 X 10 CrAl 7

X 10 CrAl 13 1.4724 X 10 CrAl 12 10Kh13SYu

X 10 CrAl 18 1.4742 X 10 CrSiAl 18 15Kh18SYu

X 6 CrTi 12 1.4512 Z 6 CT 12 SUH 409 X 6 CrTi 12

X 2 CrTi 12

409S19 X 5 CrTi 12

X 6 Cr 13 1.4000 Z 10 C13 SUS 410 X 12 Cr 13 23 02 410S21 X 12 Cr 13 X 12 Cr 13 12Kh13

410 X 10 Cr 13 1.4006 Z 12 C13

X 15 Cr 13 1.4024

410 S X 6 Cr 13 1.4000 Z 6 C 13 SUS 410S X 6 Cr 13 23 01 403S17 X 6 Cr 13 08Kh13

414

-

9 12

1


709

TEL/ 06-2460296 FAX/ 06-2471701

HEAD QUARTERS



TEL/ +886-6-2460296 FAX/ +886-6-2471701


303

TEL/ 03-5973337 FAX/ 03-5973073




TEL/ +886-3-5973337 FAX/ +886-3-5973073

TEL/ +86-21-50460355

FAX/ +86-21-50460234




TEL/ +86-21-50460355

FAX/ +86-21-50460234



VACUUM 2002

SOLUTION

SECTION 10

INDEX


CONTENTS

INDEX SECTION SECTION 10

INDEX

INDEX (Parts Number)

INDEX (Model Number)

10 - 1

10 - 13


-

10 1

INDEX




Parts No. Model No. Page

1501

150101001 KF10BA 1-1

150101003 KF10BS 1-1

150102001 KF16BA 1-1

150102003 KF16BS 1-1

150103001 KF25BA 1-1

150103003 KF25BS 1-1

150105001 KF40BA 1-1

150105003 KF40BS 1-1

150106001 KF50BA 1-1

150106003 KF50BS 1-1

150107001 KF63BA 1-1

150107003 KF63BS 1-1

150108001 KF80BA 1-1

150108003 KF80BS 1-1

150109001 KF100BA 1-1

150109003 KF100BS 1-1

150112001 KF160BA 1-1

150112003 KF160BS 1-1

1502

150201073 KF10B12 1-2

150202093 KF16B19 1-2

150203113 KF25B25 1-2

150205133 KF40B38 1-2

150206143 KF50B51 1-2

150207153 KF63B63 1-2

150208163 KF80B76 1-2

150209183 KF100B102 1-2

150212203 KF160B153 1-2

1503

150301073 KF10SHNSA 1-3

150302093 KF16SHNSA 1-3

150303113 KF25SHNSA 1-3

150305133 KF40SHNSA 1-3

150306143 KF50SHNSA 1-3

1504

150401071 KF10LHNAA 1-4

150401073 KF10LHNAA 1-4

150402091 KF16LHNAA 1-4

150402093 KF16LHNAA 1-4

150403111 KF25LHNAA 1-4

150403113 KF25LHNAA 1-4

150405131 KF40LHNAA 1-4


150405133 KF40LHNSA 1-4

150406141 KF50LHNSA 1-4

150406143 KF50LHNSA 1-4

1505

150501AB3 KF10SHNSE 1-3

150502AD3 KF16SHNSE 1-3

150503AE3 KF25SHNSE 1-3

150505AG3 KF40SHNSE 1-3

150506AJ3 KF50SHNSE 1-3

1506

150601AB3 KF10LHNSE 1-4

150602AD3 KF16LHNSE 1-4

150603AE3 KF25LHNSE 1-4

150605AG3 KF40LHNSE 1-4

150606AJ3 KF50LHNSE 1-4

1507

150703AE3 KF25SHNSJ34 1-3

150703AF3 KF25SHNSJ34 1-5

150705AG3 KF40SHNSJ42 1-3

150705AH3 KF40SHNSJ48 1-5

150706AJ3 KF50SHNSJ60 1-3

1508

150803AF3 KF25LHNSJ 1-5

150805AH3 KF40LHNSJ 1-5

150806AJ3 KF50LHNSJ 1-4

1509

150901073 KF10WS 1-2

150902093 KF16WS 1-2

150903113 KF25WS 1-2

150905113 KF40WS 1-2

150906143 KF50WS 1-2

150907153 KF63WS 1-2

150908AM3 KF80WS 1-3

150909AN3 KF100WS 1-3

150912AQ3 KF160WS 1-3

1521

152107003 ISO63B 2-1

152108003 ISO80B 2-1

152109003 ISO100B 2-1


152112003 ISO160B 2-1

152113003 ISO200B 2-1

152114003 ISO250B 2-1

152116003 ISO320B 2-1

152118003 ISO400B 2-1

152120003 ISO500B 2-1

1522

152207153 ISO63B63 2-1

152208163 ISO80B76 2-1

152209183 ISO100B102 2-1

152212203 ISO160B153 2-1

152213213 ISO200B204 2-1

152214223 ISO250B255 2-1

152216233 ISO320B305 2-1

152218253 ISO400B407 2-1

152220273 ISO500B509 2-1

1523

152307153 ISO63BF 2-2

152308163 ISO80BF 2-2

152309183 ISO100BF 2-2

152312203 ISO160BF 2-2

152313213 ISO200BF 2-2

152314223 ISO250BF 2-2

152316233 ISO320BF 2-2

152318253 ISO400BF 2-2

152320273 ISO500BF 2-2

1524

152407153 ISO63BFTAP 2-2

152408163 ISO80BFTAP 2-2

152409183 ISO100BFTAP 2-2

152412203 ISO160BFTAP 2-2

152413213 ISO200BFTAP 2-2

152414223 ISO250BFTAP 2-2

152416233 ISO320BFTAP 2-2

152418253 ISO400BFTAP 2-2

152420273 ISO500BFTAP 2-2

1525

152507073 ISO63RBR 2-3

152507078 ISO63RBR-NP 2-3

152508083 ISO80RBR 2-3

152508088 ISO80RBR-NP 2-3



152509093 ISO100RBR 2-3

152509098 ISO100RBR-NP 2-3

152512123 ISO160RBR 2-3

152512128 ISO160RBR-NP 2-3

152513133 ISO200RBR 2-3

152513138 ISO200RBR-NP 2-3

152514143 ISO250RBR 2-3

152514148 ISO250RBR-NP 2-3

152516163 ISO320RBR 2-3

152516168 ISO320RBR-NP 2-3

152518183 ISO400RBR 2-3

152518188 ISO400RBR-NP 2-3

152520203 ISO500RBR 2-3

152520208 ISO500RBR-NP 2-3

1526

152607153 ISO63HN 2-4

152608163 ISO80HN 2-4

152609183 ISO100HN 2-4

152612203 ISO160HN 2-4

152613213 ISO200HN 2-4

152614223 ISO250HN 2-4

152616233 ISO320HN 2-4

152618253 ISO400HN 2-4

152620273 ISO500HN 2-4

1541

154102004 CF16B 3-1

154102005 CF16B-316 3-1

154104004 CF35B 3-1

154104005 CF35B-316 3-1

154107003 CF63B 3-1

154107005 CF63B-316 3-1

154109003 CF100B 3-1

154109005 CF100B-316 3-1

154111003 CF150B 3-1

154111005 CF150B-316 3-1

154113003 CF200B 3-1

154113005 CF200B-316 3-1

154114003 CF250B 3-1

154114005 CF250B-316 3-1

154115003 CF300B 3-1

154115005 CF300B-316 3-1

154117003 CF350B 3-1

154117005 CF350B-316 3-1


1542

154202004 CF16BTAP 3-2

154202005 CF16BTAP-316 3-2

154204004 CF35BTAP 3-2

154204005 CF35BTAP-316 3-2

154207003 CF63BTAP 3-2

154207005 CF63BTAP-316 3-2

154209003 CF100BTAP 3-2

154209005 CF100BTAP-316 3-2

154211003 CF150BTAP 3-2

154211005 CF150BTAP-316 3-2

154213003 CF200BTAP 3-2

154213005 CF200BTAP-316 3-2

154214003 CF250BTAP 3-2

154214005 CF250BTAP-316 3-2

154215003 CF300BTAP 3-2

154215005 CF300BTAP-316 3-2

154217003 CF350BTAP 3-2

154217005 CF350BTAP-316 3-2

1543

154302004 CR16B 3-3

154302005 CR16B-316 3-3

154304004 CR35B 3-3

154304005 CR35B-316 3-3

154307003 CR63B 3-3

154307005 CR63B-316 3-3

154309003 CR100B 3-3

154309005 CR100B-316 3-3

154311003 CR150B 3-3

154311005 CR150B-316 3-3

154313003 CR200B 3-3

154313005 CR200B-316 3-3

154314003 CR250B 3-3

154314005 CR250B-316 3-3

154315003 CR300B 3-3

154315005 CR300B-316 3-3

154317003 CR350B 3-3

154317005 CR350B-316 3-3

1544

154402004 CR16BTAP 3-4

154402005 CR16BTAP-316 3-4

154404004 CR35BTAP 3-4

154404005 CR35BTAP-316 3-4


154407003 CR63BTAP 3-4

154407005 CR63BTAP-316 3-4

154409003 CR100BTAP 3-4

154409005 CR100BTAP-316 3-4

154411003 CR150BTAP 3-4

154411005 CR150BTAP-316 3-4

154413003 CR200BTAP 3-4

154413005 CR200BTAP-316 3-4

154414003 CR250BTAP 3-4

154414005 CR250BTAP-316 3-4

154415003 CR300BTAP 3-4

154415005 CR300BTAP-316 3-4

154417003 CR350BTAP 3-4

154417005 CR350BTAP-316 3-4

1545

154502044 CF16B7 3-5

154502045 CF16B7-316 3-5

154502074 CF16B12 3-5

154502075 CF16B12-316 3-5

154502094 CF16B19 3-5

154502095 CF16B19-316 3-5

154504114 CF35B25 3-8

154504115 CF35B25-316 3-8

154504134 CF35B38 3-8

154504135 CF35B38-316 3-8

154504AG4 CF35B42 3-8

154504AG5 CF35B42-316 3-8

154507143 CF63B51 3-8

154507145 CF63B51-316 3-8

154507153 CF63B63 3-8

154507155 CF63B63-316 3-8

154509183 CF100B102 3-8

154509185 CF100B102-316 3-8

154511203 CF150B153 3-8

154511205 CF150B153-316 3-8

154513213 CF200B204 3-8

154513215 CF200B204-316 3-8

154514223 CF250B255 3-8

154514225 CF250B255-316 3-8

154515233 CF300B305 3-8

154515235 CF300B305-316 3-8

154516243 CF350B356 3-8

154516245 CF350B356-316 3-8

-

10 2

-

10 3

INDEX





1546

154602044 CF16B7TAP 3-5

154602045 CF16B7TAP-316 3-5

154602074 CF16B12TAP 3-5

154602075 CF16B12TAP-316 3-5

154602094 CF16B19TAP 3-5

154602095 CF16B19TAP-316 3-5

154604114 CF35B25TAP 3-9

154604115 CF35B25TAP-316 3-9

154604134 CF35B38TAP 3-9

154604135 CF35B38TAP-316 3-9

154604AG4 CF35B42TAP 3-9

154604AG5 CF35B42TAP-316 3-9

154607143 CF63B51TAP 3-9

154607145 CF63B51TAP-316 3-9

154607153 CF63B63TAP 3-9

154607155 CF63B63TAP-316 3-9

154609183 CF100B102TAP 3-9

154609185 CF100B102TAP-316 3-9

154611203 CF150B153TAP 3-9

154611205 CF150B153TAP-316 3-9

154613213 CF200B204TAP 3-9

154613215 CF200B204TAP-316 3-9

154614223 CF250B255TAP 3-9

154614225 CF250B255TAP-316 3-9

154615233 CF300B305TAP 3-9

154615235 CF300B305TAP-316 3-9

154616243 CF350B356TAP 3-9

154616245 CF350B356TAP-316 3-9

1547

154704114 CR35B25 3-10

154704115 CR35B25-316 3-10

154704134 CR35B38 3-10

154704135 CR35B38-316 3-10

154704AG4 CR35B42 3-10

154704AG5 CR35B42-316 3-10

154707143 CR63B51 3-10

154707145 CR63B51-316 3-10

154707153 CR63B63 3-10

154707155 CR63B63-316 3-10

154709183 CR100B102 3-10

154709185 CR100B102-316 3-10

154711203 CR150B153 3-10

154711205 CR150B153-316 3-10


154713213 CR200B204 3-10

154713215 CR200B204-316 3-10

154714223 CR250B255 3-10

154714225 CR250B255-316 3-10

154715233 CR300B305 3-10

154715235 CR300B305-316 3-10

154716243 CR350B356 3-10

154716245 CR350B356-316 3-10

1548

154804114 CR35B25TAP 3-11

154804115 CR35B25TAP-316 3-11

154804134 CR35B38TAP 3-11

154804135 CR35B38TAP-316 3-11

154804AG4 CR35B42TAP 3-11

154804AG5 CR35B42TAP-316 3-11

154807143 CR63B51TAP 3-11

154807145 CR63B51TAP-316 3-11

154807153 CR63B63TAP 3-11

154807155 CR63B63TAP-316 3-11

154809183 CR100B102TAP 3-11

154809185 CR100B102TAP-316 3-11

154811203 CR150B153TAP 3-11

154811205 CR150B153TAP-316 3-11

154813213 CR200B204TAP 3-11

154813215 CR200B204TAP-316 3-11

154814223 CR250B255TAP 3-11

154814225 CR250B255TAP-316 3-11

154815233 CR300B305TAP 3-11

154815235 CR300B305TAP-316 3-11

154816243 CR350B356TAP 3-11

154816245 CR350B356TAP-316 3-11

1549

154902044 CF16B7N 3-6

154902045 CF16B7N-316 3-6

154902074 CF16B12N 3-6

154902075 CF16B12N-316 3-6

154902094 CF16B19N 3-6

154902095 CF16B19N-316 3-6

1550

155002044 CF16B7TAPN 3-6

155002045 CF16B7TAPN-316 3-6

155002074 CF16B12TAPN 3-6


155002075 CF16B12TAPN-316 3-6

155002094 CF16B19TAPN 3-6

155002095 CF16B19TAPN-316 3-6

1551

155102044 CR16B7N 3-7

155102045 CR16B7N-316 3-7

155102074 CR16B12N 3-7

155102075 CR16B12N-316 3-7

155102094 CR16B19N 3-7

155102095 CR16B19N-316 3-7

1552

155202044 CR16B7TAPN 3-7

155202045 CR16B7TAPN-316 3-7

155202074 CR16B12TAPN 3-7

155202075 CR16B12TAPN-316 3-7

155202094 CR16B19TAPN 3-7

155202095 CR16B19TAPN-316 3-7

155502093 CF16HN 3-13

155504133 CF35HN 3-13

155507153 CF63HN 3-13

155509183 CF100HN 3-13

155511203 CF150HN 3-13

1557

155702093 CR16HN 3-13

155704133 CR35HN 3-13

155707153 CR63HN 3-13

155709183 CR100HN 3-13

155711203 CR150HN 3-13

155713213 CR200HN 3-13

1563

156301A43 ANSI150-350-050 8-1

156302A53 ANSI150-388-075 8-1

156303A63 ANSI150-425-100 8-1

156305A83 ANSI150-500-150 8-1

156306A93 ANSI150-600-200 8-1

156307B13 ANSI150-700-250 8-1

156308B23 ANSI150-750-300 8-1

156309B43 ANSI150-900-400 8-1

156310B53 ANSI150-1000-500 8-1

156311B63 ANSI150-1100-600 8-1

156313B73 ANSI150-1350-800 8-1



156323A73 ANSI150-463-125 8-1

156324B33 ANSI150-850-350 8-1

1572

157200AC3 JIS5-075-010 8-2

157201AD3 JIS5-080-015 8-2

157202AE3 JIS5-085-020 8-2

157203AF3 JIS5-095-025 8-2

157205AH3 JIS5-120-040 8-2

157206AJ3 JIS5-130-050 8-2

157207AK3 JIS5-155-065 8-2

157208AL3 JIS5-180-080 8-2

157209AN3 JIS5-200-100 8-2

157210AP3 JIS5-235-125 8-2

157211AQ3 JIS5-265-150 8-2

157213AR3 JIS5-320-200 8-2

157223AG3 JIS5-115-032 8-2

157224AM3 JIS5-190-090 8-2

157225AU3 JIS5-300-175 8-2

1574

157400AC3 JIS10-090-010 8-2

157401AD3 JIS10-095-015 8-2

157402AE3 JIS10-100-020 8-2

157403AF3 JIS10-125-025 8-2

157405AH3 JIS10-140-040 8-2

157406AJ3 JIS10-155-050 8-2

157407AK3 JIS10-175-065 8-2

157408AL3 JIS10-185-080 8-2

157409AN3 JIS10-210-100 8-2

157410AP3 JIS10-250-125 8-2

157411AQ3 JIS10-280-150 8-2

157413AR3 JIS10-330-200 8-2

157423AG3 JIS10-135-032 8-2

157424AM3 JIS10-195-090 8-2

157425AU3 JIS10-305-175 8-2

1582

158200A33 DIN6-075-010 8-3

158201A43 DIN6-080-015 8-3

158202A53 DIN6-090-020 8-3

158203A63 DIN6-100-025 8-3

158205A83 DIN6-130-040 8-3

158206A93 DIN6-140-050 8-3

158207B13 DIN6-160-065 8-3


158208B23 DIN6-190-080 8-3

158209B43 DIN6-210-100 8-3

158210B53 DIN6-240-125 8-3

158211B63 DIN6-265-150 8-3

158213B73 DIN6-320-200 8-3

158223A73 DIN6-120-032 8-3

1584

158400A33 DIN10-090-010 8-3

158401A43 DIN10-095-010 8-3

158402A53 DIN10-105-015 8-3

158403A63 DIN10-115-020 8-3

158405A83 DIN10-150-032 8-3

158406A93 DIN10-165-040 8-3

158407B13 DIN10-185-065 8-3

158408B23 DIN10-200-080 8-3

158409B43 DIN10-220-100 8-3

158410B53 DIN10-250-125 8-3

158411B63 DIN10-285-150 8-3

158413B73 DIN10-340-200 8-3

158423A73 DIN10-140-025 8-3

1601

16012072074 ISO63N 4-16

16012082084 ISO80N 4-16

16012092094 ISO100N 4-16

16012122124 ISO160N 4-16

16012132134 ISO200N 4-16

16012142144 ISO250N 4-16

16012162164 ISO320N 4-16

16012182184 ISO400N 4-16

16012202204 ISO500N 4-16

16016028024 CF16NR 4-18

16016048044 CF35NR 4-18

16016078074 CF63NR 4-18

16016098094 CF100NR 4-18

16016118114 CF150NR 4-18

16016138134 CF200NR 4-18

16018028024 CF16N 4-18

16018048044 CF35N 4-18

16018078074 CF63N 4-18

16018098094 CF100N 4-18

16018118114 CF150N 4-18

16018138134 CF200N 4-18


1603

16030020024 16EL90A 4-8

16030030034 25EL90A 4-8

16030050054 40EL90A 4-8

16030060064 50EL90A 4-8

16030070074 63EL90A 4-8

16030080084 80EL90A 4-8

16030090094 100EL90A 4-8

16030110114 150EL90A 4-8

16031021024 KF16EL90A 4-13

16031031034 KF25EL90A 4-13

16031051054 KF40EL90A 4-13

16031061064 KF50EL90A 4-13

16032072074 ISO63EL90A 4-16

16032082084 ISO80EL90A 4-16

16032092094 ISO100EL90A 4-16

16032122124 ISO160EL90A 4-16

16036026024 CR16EL90 4-19

16036046044 CR35EL90 4-19

16036076074 CR63EL90 4-19

16036096094 CR100EL90 4-19

16036116114 CR150EL90 4-19

16038028024 CF16EL90 4-19

16038048044 CF35EL90 4-19

16038078074 CF63EL90 4-19

16038098094 CF100EL90 4-19

16038118114 CF150EL90 4-19

1604

16041021024 KF16EL90E 4-13

16041031034 KF25EL90E 4-13

16041051054 KF40EL90E 4-13

16041061064 KF50EL90E 4-13

1607

16070020024 16EL45A 4-9

16070030034 25EL45A 4-9

16070050054 40EL45A 4-9

16070060064 50EL45A 4-9

16070070074 63EL45A 4-9

16070080084 80EL45A 4-9

16070090094 100EL45A 4-9

1615

16150020024 16TA 4-10

-

10 4

-

10 5

INDEX





16150030034 25TA 4-10

16150050054 40TA 4-10

16150060064 50TA 4-10

16150070074 63TA 4-10

16150080084 80TA 4-10

16150090094 100TA 4-10

16150110114 150TA 4-10

16151021024 KF16TA 4-13

16151031034 KF25TA 4-13

16151051054 KF40TA 4-13

16151061064 KF50TA 4-13

16152072074 ISO63TA 4-17

16152082084 ISO80TA 4-17

16152092094 ISO100TA 4-17

16152122124 ISO160TA 4-17

16156026024 CR16T 4-20

16156046044 CR35T 4-20

16156076074 CR63T 4-20

16156096094 CR100T 4-20

16156116114 CR150T 4-20

16158028024 CF16T 4-20

16158048044 CF35T 4-20

16158078074 CF63T 4-20

16158098094 CF100T 4-20

16158118114 CF150T 4-20

1616

16161021024 KF16TE 4-13

16161031034 KF25TE 4-13

16161051054 KF40TE 4-13

16161061064 KF50TE 4-13

1617

16170030024 25UT16A 4-11

16170050024 40UT16A 4-11

16170050034 40UT25A 4-11

16170060024 50UT16A 4-11

16170060034 50UT25A 4-11

16170060054 50UT40A 4-11

16170080074 80UT63A 4-11

16170090064 100UT50A 4-11

16170090074 100UT63A 4-11

16170090084 100UT80A 4-11

16170110084 150UT80A 4-11

16170110094 150UT100A 4-11


16171031024 KF25UT16A 4-15

16171051024 KF40UT16A 4-15

16171051034 KF40UT25A 4-15

16171061024 KF50UT16A 4-15

16171061034 KF50UT25A 4-15

16171061054 KF50UT40A 4-15

1618

16181031024 KF25UT16E 4-15

16181051024 KF40UT16E 4-15

16181051034 KF40UT25E 4-15

16181061024 KF50UT16E 4-15

16181061034 KF50UT25E 4-15

16181061054 KF50UT40E 4-15

1619

16190020024 16XA 4-10

16190030034 25XA 4-10

16190050054 40XA 4-10

16190060064 50XA 4-10

16190070074 63XA 4-10

16190080084 80XA 4-10

16190090094 100XA 4-10

16190110114 150XA 4-10

16191021024 KF16XA 4-14

16191031034 KF25XA 4-14

16191051054 KF40XA 4-14

16191061064 KF50XA 4-14

16192072074 ISO63XA 4-17

16192082084 ISO80XA 4-17

16192092094 ISO100XA 4-17

16192122124 ISO160XA 4-17

16196026024 CR16X 4-21

16196046044 CR35X 4-21

16196076074 CR63X 4-21

16196096094 CR100X 4-21

16196116114 CR150X 4-21

16198028024 CF16X 4-21

16198048044 CF35X 4-21

16198078074 CF63X 4-21

16198098094 CF100X 4-21

16198118114 CF150X 4-21

1620

16201021024 KF16XE 4-14


16201031034 KF25XE 4-14

16201051054 KF40XE 4-14

16201061064 KF50XE 4-14

1621

16210030024 25UX16A 4-12

16210050024 40UX16A 4-12

16210050034 40UX25A 4-12

16210060024 50UX16A 4-12

16210060034 50UX25A 4-12

16210060054 50UX40A 4-12

16210080074 80UX63A 4-12

16210090064 100UX50A 4-12

16210090074 100UX63A 4-12

16210090084 100UX80A 4-12

16210110084 150UX80A 4-12

16210110094 150UX100A 4-12

1623

16230030024 25-16CR 4-7

16230050024 40-16CR 4-7

16230050034 40-25CR 4-7

16230060034 50-25CR 4-7

16230060054 50-40CR 4-7

16230070054 63-40CR 4-7

16230070064 63-50CR 4-7

16230080064 80-50CR 4-7

16230080074 80-63CR 4-7

16230090064 100-50CR 4-7

16230090074 100-63CR 4-7

16230090084 100-80CR 4-7

16230110084 150-80CR 4-7

16230110094 150-100CR 4-7

1624

16240020024 16ELT90A 4-8

16240030034 25ELT90A 4-8

16240050054 40ELT90A 4-8

16240060064 50ELT90A 4-8

16240070074 63ELT90A 4-8

16240080084 80ELT90A 4-8

16240090094 100ELT90A 4-8

1625

16250020024 16ELT45A 4-9



16250030034 25ELT45A 4-9

16250050054 40ELT45A 4-9

16250060064 50ELT45A 4-9

16250070074 63ELT45A 4-9

16250080084 80ELT45A 4-9

16250090094 100ELT45A 4-9

1701

17010118042 KF10RHA 5-6

17010212002 KF16MPT3 5-7

17010212012 KF16MPT6 5-7

17010213002 KF16FPT3 5-8

17010213012 KF16FPT6 5-8

17010214002 KF16MNPT3 5-7

17010214012 KF16MNPT6 5-7

17010215002 KF16FNPT3 5-8

17010215012 KF16FNPT6 5-8

17010216012 KF16MVCR6 5-5

17010216032 KF16MVCR13 5-5

17010217012 KF16FVCR6 5-5

17010217032 KF16FVCR13 5-5

17010218052 KF16RHA 5-6

17010219012 KF16SWA6 5-6

17010219032 KF16SWA13 5-6

17010220012 KF16QDA6 5-9

17010220032 KF16QDA12 5-9

17010220052 KF16QDA19 5-9

17010312002 KF25MPT3 5-7

17010312012 KF25MPT6 5-7

17010312032 KF25MPT13 5-7

17010312052 KF25MPT19 5-7

17010313002 KF25FPT3 5-8

17010313012 KF25FPT6 5-8

17010314002 KF25MNPT3 5-7

17010314012 KF25MNPT6 5-7

17010314032 KF25MNPT13 5-7

17010314052 KF25MNPT19 5-7

17010315002 KF25FNPT3 5-8

17010315012 KF25FNPT6 5-8

17010316012 KF25MVCR6 5-5

17010316032 KF25MVCR13 5-5

17010317012 KF25FVCR6 5-5

17010317032 KF25FVCR13 5-5

17010318062 KF25RHA 5-6

17010319012 KF25SWA6 5-6


17010319032 KF25SWA13 5-6

17010320032 KF25QDA12 5-9

17010320052 KF25QDA19 5-9

17010320072 KF25QDA25 5-9

17010508082 KF40C35A 5-2

17010512012 KF40MPT6 5-7

17010512032 KF40MPT13 5-7

17010512052 KF40MPT19 5-7

17010512072 KF40MPT25 5-7

17010513002 KF40FPT3 5-8

17010513012 KF40FPT6 5-8

17010514012 KF40MNPT6 5-7

17010514032 KF40MNPT13 5-7

17010514052 KF40MNPT19 5-7

17010514072 KF40MNPT25 5-7

17010515002 KF40FNPT3 5-8

17010515012 KF40FNPT6 5-8

17010516012 KF40MVCR6 5-5

17010516032 KF40MVCR13 5-5

17010517012 KF40FVCR6 5-5

17010517032 KF40FVCR13 5-5

17010518102 KF40RHA 5-6

17010519012 KF40SWA6 5-6

17010519032 KF40SWA13 5-6

17010520032 KF40QDA12 5-9

17010520052 KF40QDA19 5-9

17010520072 KF40QDA25 5-9

17010520092 KF40QDA38 5-9

17010612012 KF50MPT6 5-7

17010612032 KF50MPT13 5-7

17010612052 KF50MPT19 5-7

17010612072 KF50MPT25 5-7

17010613002 KF50FPT3 5-8

17010613012 KF50FPT6 5-8

17010614012 KF50MNPT6 5-7

17010614032 KF50MNPT13 5-7

17010614052 KF50MNPT19 5-7

17010614072 KF50MNPT25 5-7

17010615002 KF50FNPT3 5-8

17010615012 KF50FNPT6 5-8

17010616012 KF50MVCR6 5-5

17010616032 KF50MVCR13 5-5

17010617012 KF50FVCR6 5-5

17010617032 KF50FVCR13 5-5

17010618112 KF50RHA 5-6


17010619012 KF50SWA6 5-6

17010619032 KF50SWA13 5-6

17010620092 KF50QDA38 5-9

17010620122 KF50QDA50 5-9

1702

17020701072 ISO63KA25 5-3

17020701092 ISO63KA40 5-3

17020701122 ISO63KA50 5-3

17020801092 ISO80KA40 5-3

17020801122 ISO80KA50 5-3

17020901092 ISO100KA40 5-3

17020901122 ISO100KA50 5-3

17021208172 ISO160C100A 5-2

17021208172 ISO160C150A 5-2

1708

17080201032 CF16K10A 5-2

17080201052 CF16K16A 5-2

17080401032 CF35K10A 5-2

17080401052 CF35K16A 5-2

17080401072 CF35K25A 5-2

17080406052 CF35RA16R 5-4

17080408052 CF35RA16 5-4

17080701122 CF63K50A 5-2

17080702132 CF63S63A 5-2

17080706052 CF63RA16R 5-4

17080706082 CF63RA35R 5-4

17080708052 CF63RA16 5-4

17080708082 CF63RA35 5-4

17080902132 CF100S63A 5-2

17080902152 CF100S100A 5-2

17080906082 CF100RA35R 5-4

17080906132 CF100RA63R 5-4

17080908082 CF100RA35 5-4

17080908132 CF100RA63 5-4

17081102132 CF150S63A 5-2

17081102152 CF150S100A 5-2

17081106082 CF150RA35R 5-4

17081106132 CF150RA63R 5-4

17081106152 CF150RA100R 5-4

17081108082 CF150RA35 5-4

17081108132 CF150RA63 5-4

17081108152 CF150RA100 5-4

-

10 6

-

10 7

INDEX





1711

17110501092 ASA4KA40 5-1

17110501122 ASA4KA50 5-1

17110601092 ASA5KA40 5-1

17110601122 ASA5KA50 5-1

17110701092 ASA7KA40 5-1

17110701122 ASA7KA50 5-1

1712

17120501092 ASA40G40 5-1

17120501122 ASA4OG50 5-1

17120601092 ASA5OG40 5-1

17120601122 ASA5OG50 5-1

17120701092 ASA7OG40 5-1

17120701122 ASA7OG50 5-1

1721

17210301052 KF25RA16 5-10

17210501052 KF40RA16 5-10

17210501072 KF40RA25 5-10

17210601052 KF50RA16 5-10

17210601072 KF50RA25 5-10

17210601092 KF50RA40 5-10

1722

1722-0801092 ISO80KRA40 5-10

1722-0801122 ISO80KRA50 5-10

1722-0802132 ISO80RA63 5-11

1722-0901092 ISO100KRA40 5-10

1722-0901122 ISO100KRA50 5-10

1722-0902132 ISO100RA63 5-11

1722-0902142 ISO100RA80 5-11

1722-1202132 ISO160RA63 5-11

1748

1748-0406052 CF35RF16 3-12

1748-0706052 CF63RF16 3-12

1748-0706082 CF63RF35 3-12

1748-0906082 CF100RF35 3-12

1748-0906132 CF100RF63 3-12

1748-1106082 CF150RF35 3-12

1748-1106132 CF150RF63 3-12

1748-1106152 CF150RF100 3-12

1748-1306082 CF200RF35 3-12

1748-1306132 CF200RF63 3-12


1748-1306152 CF200RF100 3-12

1748-1306172 CF200RF150 3-12

1748-1406082 CF250RF35 3-12

1748-1406132 CF250RF63 3-12

1748-1406152 CF250RF100 3-12

1748-1406172 CF250RF150 3-12

1748-1406192 CF250RF200 3-12

1800

180003110 KF10CRA 7-1

180003410 KF10CRS 7-1

180005110 KF16CRA 7-1

180005410 KF16CRS 7-1

180006110 KF25CRA 7-1

180006410 KF25CRS 7-1

180008110 KF40CRA 7-1

180008410 KF40CRS 7-1

180009110 KF50CRA 7-1

180009410 KF50CRS 7-1

1801

180103111 KF10CRVA 7-2

180103411 KF10CRVS 7-2

180105111 KF16CRVA 7-2

180105411 KF16CRVS 7-2

180106111 KF25CRVA 7-2

180106411 KF25CRVS 7-2

180108111 KF40CRVA 7-2

180108411 KF40CRVS 7-2

180109111 KF50CRVA 7-2

180109411 KF50CRVS 7-2

1803

180303111 KF10CRNA 7-2

180303411 KF10CRNS 7-2

180305111 KF16CRNA 7-2

180305411 KF16CRNS 7-2

180306111 KF25CRNA 7-2

180306411 KF25CRNS 7-2

180308111 KF40CRNA 7-2

180308411 KF40CRNS 7-2

180309111 KF50CRNA 7-2

180309411 KF50CRNS 7-2

1811


181105421 KF16OCRVS 7-3

181105621 KF16OCRV-316 7-3

181106421 KF25OCRVS 7-3

181106621 KF25OCRV-316 7-3

181108421 KF40OCRVS 7-3

181108621 KF40OCRV-316 7-3

181109421 KF50OCRVS 7-3

181109621 KF50OCRV-316 7-3

1831

183105411 KF16M3CRVS 7-5

183106411 KF25M3CRVS 7-5

183108411 KF40M3CRVS 7-5

183109411 KF50M3CRVS 7-5

183110411 KF63M3CRVS 7-5

183111411 KF80M3CRVS 7-5

183112411 KF100M3CRVS 7-5

183115411 KF160M3CRVS 7-5

1833

183305411 KF16M3CRNS 7-5

183306411 KF25M3CRNS 7-5

183308411 KF40M3CRNS 7-5

183309411 KF50M3CRNS 7-5

183310411 KF63M3CRNS 7-5

183311411 KF80M3CRNS 7-5

183312411 KF100M3CRNS 7-5

183315411 KF160M3CRNS 7-5

1901

19011A111 KF10CR16VA 7-4

19011A411 KF10CR16VS 7-4

19011B111 KF20CR25VA 7-4

19011B411 KF20CR25VS 7-4

19011C111 KF32CR40VA 7-4

19011C411 KF32CR40VS 7-4

1903

19031A111 KF10CR16NA 7-4

19031A411 KF10CR16NS 7-4

19031B111 KF20CR25NA 7-4

19031B411 KF20CR25NS 7-4

19031C111 KF32CR40NA 7-4

19031C411 KF32CR40NS 7-4



1910

191010110 ISO63CRAA 7-8

191010120 ISO63CRAE 7-7

191010410 ISO63CRSA 7-8

191010420 ISO63CRSE 7-7

191011110 ISO80CRAA 7-8

191011120 ISO80CRAE 7-7

191011410 ISO80CRSA 7-8

191011420 ISO80CRSE 7-7

191012110 ISO100CRAA 7-8

191012120 ISO100CRAE 7-7

191012410 ISO100CRSA 7-8

191012420 ISO100CRSE 7-7

191015110 ISO160CRAA 7-8

191015120 ISO160CRAE 7-7

191015410 ISO160CRSA 7-8

191015420 ISO160CRSE 7-7

191016110 ISO200CRAA 7-8

191016120 ISO200CRAE 7-7

191016410 ISO200CRSA 7-8

191016420 ISO200CRSE 7-7

191017110 ISO250CRAA 7-8

191017120 ISO250CRAE 7-7

191017410 ISO250CRSA 7-8

191017420 ISO250CRSE 7-7

191019110 ISO320CRAA 7-8

191019120 ISO320CRAE 7-7

191019410 ISO320CRSA 7-8

191019420 ISO320CRSE 7-7

191021110 ISO400CRAA 7-8

191021120 ISO400CRAE 7-7

191021410 ISO400CRSA 7-8

191021420 ISO400CRSE 7-7

191023110 ISO500CRAA 7-8

191023120 ISO500CRAE 7-7

191023410 ISO500CRSA 7-8

191023420 ISO500CRSE 7-7

1911

191110111 ISO63CRVAA 7-11

1191110121 ISO63CRVAE 7-9

191110411 ISO63CRVSA 7-11

191110421 ISO63CRVSE 7-9

191111111 ISO80CRVAA 7-11

191111121 ISO80CRVAE 7-9


191111411 ISO80CRVSA 7-11

191111421 ISO80CRVSE 7-9

191112111 ISO100CRVAA 7-11

191112121 ISO100CRVAE 7-9

191112411 ISO100CRVSA 7-11

191112421 ISO100CRVSE 7-9

191115111 ISO160CRVAA 7-11

191115121 ISO160CRVAE 7-9

191115411 ISO160CRVSA 7-11

191115421 ISO160CRVSE 7-9

191116111 ISO200CRVAA 7-11

191116121 ISO200CRVAE 7-9

191116411 ISO200CRVSA 7-11

191116421 ISO200CRVSE 7-9

191117111 ISO250CRVAA 7-11

191117121 ISO250CRVAE 7-9

191117411 ISO250CRVSA 7-11

191117421 ISO250CRVSE 7-9

191119111 ISO320CRVAA 7-11

191119121 ISO320CRVAE 7-9

191119411 ISO320CRVSA 7-11

191119421 ISO320CRVSE 7-9

191121111 ISO400CRVAA 7-11

191121121 ISO400CRVAE 7-9

191121411 ISO400CRVSA 7-11

191121421 ISO400CRVSE 7-9

191123111 ISO500CRVAA 7-11

191123121 ISO500CRVAE 7-9

191123411 ISO500CRVSA 7-11

191123421 ISO500CRVSE 7-9

1913

191310111 ISO63CRNAA 7-12

191310121 ISO63CRNAE 7-10

191310411 ISO63CRNSA 7-12

191310421 ISO63CRNSE 7-10

191311111 ISO80CRNAA 7-12

191311121 ISO80CRNAE 7-10

191311411 ISO80CRNSA 7-12

191311421 ISO80CRNSE 7-10

191312111 ISO100CRNAA 7-12

191312121 ISO100CRNAE 7-10

191312411 ISO100CRNSA 7-12

191312421 ISO100CRNSE 7-10

191315111 ISO160CRNAA 7-12


191315121 ISO160CRNAE 7-10

191315411 ISO160CRNSA 7-12

191315421 ISO160CRNSE 7-10

191316111 ISO200CRNAA 7-12

191316121 ISO200CRNAE 7-10

191316411 ISO200CRNSA 7-12

191316421 ISO200CRNSE 7-10

191317111 ISO250CRNAA 7-12

191317121 ISO250CRNAE 7-10

191317411 ISO250CRNSA 7-12

191317421 ISO250CRNSE 7-10

191319111 ISO320CRNAA 7-12

191319121 ISO320CRNAE 7-10

191319411 ISO320CRNSA 7-12

191319421 ISO320CRNSE 7-10

191321111 ISO400CRNAA 7-12

191321121 ISO400CRNAE 7-10

191321411 ISO400CRNSA 7-12

191321421 ISO400CRNSE 7-10

191323111 ISO500CRNAE 7-10

191323111 ISO500CRNAA 7-12

191323411 ISO500CRNSA 7-12

191323421 ISO500CRNSE 7-10

1921

192110111 ISO63OCRVAA 7-15

192110121 ISO63OCRVAE 7-13

192110411 ISO63OCRVSA 7-15

192110421 ISO63OCRVSE 7-13

192111111 ISO80OCRVAA 7-15

192111121 ISO80OCRVAE 7-13

192111411 ISO80OCRVSA 7-15

192111421 ISO80OCRVSE 7-13

192112111 ISO100OCRVAA 7-15

192112121 ISO100OCRVAE 7-13

192112411 ISO100OCRVSA 7-15

192112421 ISO100OCRVSE 7-13

192115111 ISO160OCRVAA 7-15

192115121 ISO160OCRVAE 7-13

192115411 ISO160OCRVSA 7-15

192115421 ISO160OCRVSE 7-13

192116111 ISO200OCRVAA 7-15

192116121 ISO200OCRVAE 7-13

192116411 ISO200OCRVSA 7-15

192116421 ISO200OCRVSE 7-13

-

10 8

-

10 9

INDEX





192117111 ISO250OCRVAA 7-15

192117121 ISO250OCRVAE 7-13

192117411 ISO250OCRVSA 7-15

192117421 ISO250OCRVSE 7-13

192119111 ISO320OCRVAA 7-15

192119121 ISO320OCRVAE 7-13

192119411 ISO320OCRVSA 7-15

192119421 ISO320OCRVSE 7-13

192121111 ISO400OCRVAA 7-15

192121121 ISO400OCRVAE 7-13

192121411 ISO400OCRVSA 7-15

192121421 ISO400OCRVSE 7-13

192123111 ISO500OCRVAA 7-15

192123121 ISO500OCRVAE 7-13

192123411 ISO500OCRVSA 7-15

192123421 ISO500OCRVSE 7-13

1923

192310111 ISO63OCRNAA 7-16

192310121 ISO63OCRNAE 7-14

192310411 ISO63OCRNSA 7-16

192310421 ISO63OCRNSE 7-14

192311111 ISO80OCRNAA 7-16

192311121 ISO80OCRNAE 7-14

192311411 ISO80OCRNSA 7-16

192311421 ISO80OCRNSE 7-14

192312111 ISO100OCRNAA 7-16

192312121 ISO100OCRNAE 7-14

192312411 ISO100OCRNSA 7-16

192312421 ISO100OCRNSE 7-14

192315111 ISO160OCRNAA 7-16

192315121 ISO160OCRNAE 7-14

192315411 ISO160OCRNSA 7-16

192315421 ISO160OCRNSE 7-14

192316111 ISO200OCRNAA 7-16

192316121 ISO200OCRNAE 7-14

192316411 ISO200OCRNSA 7-16

192316421 ISO200OCRNSE 7-14

192317111 ISO250OCRNAA 7-16

192317121 ISO250OCRNAE 7-14

192317411 ISO250OCRNSA 7-16

192317421 ISO250OCRNSE 7-14

192319111 ISO320OCRNAA 7-16

192319121 ISO320OCRNAE 7-14

192319411 ISO320OCRNSA 7-16


192319421 ISO320OCRNSE 7-14

192321111 ISO400OCRNAA 7-16

192321121 ISO400OCRNAE 7-14

192321411 ISO400OCRNSA 7-16

192321421 ISO400OCRNSE 7-14

192323111 ISO500OCRNAA 7-16

192323121 ISO500OCRNAE 7-14

192323411 ISO500OCRNSA 7-16

192323421 ISO500OCRNSE 7-14

2000

20000341 KF10OPR 7-6

20000541 KF16OPR 7-6

20000641 KF25OPR 7-6

20000841 KF40OPR 7-6

20000941 KF50OPR 7-6

20001141 ISO80OPR 7-6

2001

20011041 ISO63SRR 2-5

200110A1 ISO63SRR-NP 2-5

20011141 ISO80SRR 2-5

200111A1 ISO80SRR-NP 2-5

20011241 ISO100SRR 2-5

200112A1 ISO100SRR-NP 2-5

20011541 ISO160SRR 2-5

200115A1 ISO160SRR-NP 2-5

20011641 ISO200SRR 2-5

200116A1 ISO200SRR-NP 2-5

20011741 ISO250SRR 2-5

200117A1 ISO250SRR-NP 2-5

20011941 ISO320SRR 2-5

200119A1 ISO320SRR-NP 2-5

20012141 ISO400SRR 2-5

200121A1 ISO400SRR-NP 2-5

20012341 ISO500SRR 2-5

200123A1 ISO500SRR-NP 2-5

2101

21010511 KF16CLA 1-6

21010521 KF16CLA-NP 1-6

21010611 KF25CLA 1-6

21010621 KF25CLA-NP 1-6

21010811 KF40CLA 1-6

21010821 KF40CLA-NP 1-6


21010911 KF50CLA 1-6

21010921 KF50CLA-NP 1-6

2103

2103A111 KF-NCA 1-6

2121

2121A211 ISO63-100SWCA 2-6

2121A231 ISO63-100SWC-ZP 2-6

2121A241 ISO63-100SWC304 2-6

2121A411 ISO160-250SWCA 2-6

2121A431 ISO160-250SWC-ZP 2-6

2121A441 ISO160-250SWC304 2-6

2121A511 ISO320-500SWCA 2-6

2121A531 ISO320-500SWC-ZP 2-6

2121A541 ISO320-500SWC304 2-6

2122

2122A211 ISO63-100DWCA 2-7

2122A411 ISO160-250DWCA 2-7

2122A511 ISO320-500DWCA 2-7

2123

2123A331 ISO63-250DCC-ZP 2-8

2123A361 ISO63-250DCC316 2-8

2123A531 ISO320-500DCC-ZP 2-8

2123A561 ISO320-500DCC316 2-8

2123A631 ISO630DCC-ZP 2-8

2123A661 ISO630DCC316 2-8

2131

21310581 CF16CG 3-15

21310591 CF16SPCG 3-15

21310781 CF35CG 3-15

21310791 CF35SPCG 3-15

21311081 CF63CG 3-15

21311091 CF63SPCG 3-15

21311281 CF100CG 3-15

21311291 CF100SPCG 3-15

21311481 CF150CG 3-15

21311491 CF150SPCG 3-15

21311681 CF200CG 3-15

21311691 CF200SPCG 3-15

21311781 CF250CG 3-15

21311791 CF250SPCG 3-15



2132

21320541 CF16PN 3-14

21320741 CF35PN 3-14

21321041 CF63PN 3-14

3001

300109000010 AV-TE16-M 6-6

300109000016 AVB-TE16-M 6-3

300109010010 AV-KF16-M 6-6

300109010016 AVB-KF16-M 6-3

300109030016 AVB-CR16-M 6-3

300109100010 AV-TE16-P 6-16

300109100016 AVB-TE16-P 6-14

300109100216 AVBS-TE16-P 6-24

300109110010 AV-KF16-P 6-16

300109110016 AVB-KF16-P 6-14

300109110216 AVBS-KF16-P 6-24

300109130010 AV-CR16-P 6-16

300109130016 AVB-CR16-P 6-14

300109130216 AVBS-CR16-P 6-24

300109200010 AV-TE16-P2 6-17

300109200016 AVB-TE16-P2 6-15

300111000010 AV-TE25-M 6-6

300111000016 AVB-TE25-M 6-3

300111010010 AV-KF25-M 6-6

300111010016 AVB-KF25-M 6-3

300111100010 AV-TE25-P 6-16

300111100016 AVB-TE25-P 6-14

300111100216 AVBS-TE25-P 6-24

300111110010 AV-KF25-P 6-16

300111110016 AVB-KF25-P 6-14

300111110216 AVBS-KF25-P 6-24

300116200010 AV-TE80-P2 6-17

300116200016 AVB-TE80-P2 6-15

300113000010 AV-TE40-M 6-6

300113000016 AVB-TE40-M 6-3

300113010010 AV-KF-M 6-6

300113010016 AVB-KF40-M 6-3

300113030016 AVB-CR35-M 6-3

300113100010 AV-TE40-P 6-16

300113100016 AVB-TE40-P 6-14

300113100216 AVBS-TE40-P 6-24

300113110010 AV-KF40-P 6-16

300113110016 AVB-KF40-P 6-14

300113110216 AVBS-KF40-P 6-24


300113130010 AV-CR35-P 6-16

300113130016 AVB-CR35-P 6-14

300113130216 AVBS-CR35-P 6-24

300113200010 AV-TE40-P2 6-17

300113200016 AVB-TE40-P2 6-15

300114000010 AV-TE50-M 6-6

300114000016 AVB-TE50-M 6-3

300114010010 AV-KF50-M 6-6

300114010016 AVB-KF50-M 6-3

300114100010 AV-TE50-P 6-16

300114100016 AVB-TE50-P 6-14

300114100216 AVBS-TE50-P 6-24

300114110010 AV-KF50-P 6-16

300114110016 AVB-KF50-P 6-14

300114110216 AVBS-KF50-P 6-24

300114200010 AV-TE50-P2 6-17

300114200016 AVB-TE50-P2 6-15

300115000016 AVB-TE63-M 6-3

300115030016 AVB-CR63-M 6-3

300115040016 AVB-ISO63-M 6-3

300115200010 AV-TE63-P2 6-17

300115200016 AVB-TE63-P2 6-15

300115230010 AV-CR63-P2 6-17

300115230016 AVB-CR63-P2 6-15

300115240010 AV-ISO63-P2 6-17

300115240016 AVB-ISO63-P2 6-15

300116000016 AVB-TE80-M 6-3

300116040016 AVB-ISO80-M 6-3

300116200010 AV-TE80-P2 6-17

300116200016 AVB-TE80-P2 6-15

300116240010 AV-ISO80-P2 6-17

300116240016 AVB-ISO80-P2 6-15

300118200010 AV-TE100-P2 6-17

300118200016 AVB-TE100-P2 6-15

300118230010 AV-CR100-P2 6-17

300118230016 AVB-CR100-P2 6-15

300118240010 AV-ISO100-P2 6-17

300118240016 AVB-ISO100-P2 6-15

300120200010 AV-TE160-P2 6-17

300120200016 AVB-TE160-P2 6-15

300120240010 AV-ISO160-P2 6-17

300120240016 AVB-ISO160-P2 6-15

300121200010 AV-TE200-P2 6-17

300121200016 AVB-TE200-P2 6-15

300121240010 AV-ISO200-P2 6-17


300121240016 AVB-ISO200-P2 6-15

3005

300509030011 AVBAK-CR16 6-54

300511030011 AVBAK-CR35 6-54

3006

300609000016 AVB-CU-TE16-M 6-10

300609010016 AVB-CU-KF16-M 6-10

300609030016 AVB-CU-CR16-M 6-10

300611000016 AVB-CU-TE25-M 6-10

300611010016 AVB-CU-KF25-M 6-10

300613000016 AVB-CU-TE40-M 6-10

300613010016 AVB-CU-KF40-M 6-10

300613030016 AVB-CU-CR35-M 6-10

300614000016 AVB-CU-TE50-M 6-10

300614010016 AVB-CU-KF50-M 6-10

300615000016 AVB-CU-TE63-M 6-10

300615030016 AVB-CU-CR63-M 6-10

3021

302109000010 IV-TE16-M 6-31

302109000016 IVB-TE16-M 6-28

302109010010 IV-KF16-M 6-31

302109010016 IVB-KF16-M 6-28

302109030010 IV-CR16-M 6-31

302109030016 IVB-CR16-M 6-28

302109100010 IV-TE16-P 6-38

302109100016 IVB-TE16-P 6-37

302109100216 IVBS-TE16-P 6-41

302109110010 IV-KF16-P 6-38

302109110016 IVB-KF16-P 6-37

302109110216 IVBS-KF16-P 6-41

302109130010 IV-CR16-P 6-38

302109130016 IVB-CR16-P 6-37

302109130216 IVBS-CR16-P 6-41

302111000010 IV-TE25-M 6-31

302111000016 IVB-TE25-M 6-28

302111010010 IV-KF25-M 6-31

302111010016 IVB-KF25-M 6-28

302111100010 IV-TE25-P 6-38

302111100016 IVB-TE25-P 6-37

302111100216 IVBS-TE25-P 6-41

302111110010 IV-KF25-P 6-38

302111110016 IVB-KF25-P 6-37

-

10 10

-

10 11

INDEX





302111110216 IVBS-KF25-P 6-41

302113000010 IV-TE40-M 6-31

302113000016 IVB-TE40-M 6-28

302113010010 IV-KF40-M 6-31

302113010016 IVB-KF40-M 6-28

302113030010 IV-CR35-M 6-31

302113030016 IVB-CR35-M 6-28

302113100010 IV-TE40-P 6-38

302113100016 IVB-TE40-P 6-37

302113100216 IVBS-TE40-P 6-41

302113110010 IV-KF40-P 6-38

302113110016 IVB-KF40-P 6-37

302113110216 IVBS-KF40-P 6-41

302113130010 IV-CR35-P 6-38

302113130016 IVB-CR35-P 6-37

302113130216 IVBS-CR35-P 6-41

302114000010 IV-TE50-M 6-31

302114000016 IVB-TE50-M 6-28

302114010010 IV-KF50-M 6-31

302114010016 IVB-KF50-M 6-28

302114100010 IV-TE50-P 6-38

302114100016 IVB-TE50-P 6-37

302114100216 IVBS-TE50-P 6-41

302114110010 IV-KF50-P 6-38

302114110016 IVB-KF50-P 6-37

302114110216 IVBS-KF50-P 6-41

3026

302609000016 IVB-CU-TE16-M 6-34

302609010016 IVB-CU-KF16-M 6-34

302609030016 IVB-CU-CR16-M 6-34

302611000016 IVB-CU-TE25-M 6-34

302611010016 IVB-CU-KF25-M 6-34

302613000016 IVB-CU-TE40-M 6-34

302613010016 IVB-CU-KF40-M 6-34

302613030016 IVB-CU-CR35-M 6-34

302614000016 IVB-CU-TE50-M 6-34

302614010016 IVB-CU-KF50-M 6-34

3041

304109000016 YVB-TE16-M 6-44

304109010016 YVB-KF16-M 6-44

304109030016 YVB-CR16-M 6-44

304109100016 YVB-TE16-P 6-50

304109100216 YVBS-TE16-P 6-53


304109110016 YVB-KF16-P 6-50

304109110216 YVBS-KF16-P 6-53

304109130016 YVB-CR16-P 6-50

304109130216 YVBS-CR16-P 6-53

304111000016 YVB-TE25-M 6-44

304111010016 YVB-KF25-M 6-44

304111100016 YVB-TE25-P 6-50

304111100216 YVBS-TE25-P 6-53

304111110016 YVB-KF25-P 6-50

304111110216 YVBS-KF25-P 6-53

304113000016 YVB-TE40-M 6-44

304113010016 YVB-KF40-M 6-44

304113030016 YVB-CR35-M 6-44

304113100016 YVB-TE40-P 6-50

304113100216 YVBS-TE40-P 6-53

304113110016 YVB-KF40-P 6-50

304113110216 YVBS-KF40-P 6-53

304113130016 YVB-CR35-P 6-50

304113130216 YVBS-CR35-P 6-53

304114000016 YVB-TE50-M 6-44

304114010016 YVB-KF50-M 6-44

304114100016 YVB-TE50-P 6-50

304114100216 YVBS-TE50-P 6-53

304114110016 YVB-KF50-P 6-50

304114110216 YVBS-KF50-P 6-53

304115200016 YVB-TE63-P2 6-50

304115230016 YVB-CR63-P2 6-50

3046

304609000016 YVB-CU-TE16-M 6-47

304609010016 YVB-CU-KF16-M 6-47

304609030016 YVB-CU-CR16-M 6-47

304611000016 YVB-CU-TE25-M 6-47

304611010016 YVB-CU-KF25-M 6-47

304613000016 YVB-CU-TE40-M 6-47

304613010016 YVB-CU-KF40-M 6-47

304614000016 YVB-CU-TE50-M 6-47

304614010016 YVB-CU-KF50-M 6-47

30463030016 YVB-CU-CR35-M 6-47

3101

310109010010 AV-KF16-M-E 6-7

310109010016 AVB-KF16-M-E 6-4

310109010026 AVALWB-KF16-M 6-55

310109030016 AVB-CR16-M-E 6-4


310109110010 AV-KF16-P-E 6-20

310109110016 AVB-KF16-P-E 6-18

310109110026 AVALWB-KF16-P 6-56

310109110216 AVBS-KF16-P-E 6-25

310109110226 AVALWBS-KF16-P 6-56

310109130010 AV-CR16-P-E 6-20

310109130016 AVB-CR16-P-E 6-18

310109130216 AVBS-CR16-P-E 6-25

310109210026 AVALWB-KF16-P2 6-57

310109210226 AVALWBS-KF16-P2 6-57

310111010010 AV-KF25-M-E 6-7

310111010016 AVB-KF25-M-E 6-4

310111010026 AVALWB-KF25-M 6-55

310111110010 AV-KF25-P-E 6-20

310111110016 AVB-KF25-P-E 6-18

310111110026 AVALWB-KF25-P 6-56

310111110216 AVBS-KF25-P-E 6-25

310111110226 AVALWBS-KF25-P 6-56

310111210026 AVALWB-KF25-P2 6-57

310111210226 AVALWBS-KF25-P2 6-57

310113010010 AV-KF40-M-E 6-7

310113010016 AVB-KF40-M-E 6-4

310113010026 AVALWB-KF40-M 6-55

310113030016 AVB-CR35-M-E 6-4

310113110010 AV-KF40-P-E 6-20

310113110016 AVB-KF40-P-E 6-18

310113110026 AVALWB-KF40-P 6-56

310113110216 AVBS-KF40-P-E 6-25

310113110226 AVALWBS-KF25-P 6-56

310113130010 AV-CR35-P-E 6-20

310113130016 AVB-CR35-P-E 6-18

310113130216 AVBS-CR35-P-E 6-25

310113210026 AVALWB-KF40-P2 6-57

310113210226 AVALWBS-KF40-P2 6-57

310114010010 AV-KF50-M-E 6-7

310114010016 AVB-KF50-M-E 6-4

310114010026 AVALWB-KF50-M 6-55

310114110010 AV-KF50-P-E 6-20

310114110016 AVB-KF50-P-E 6-18

310114110026 AVALWB-KF50-P 6-56

310114110216 AVBS-KF50-P-E 6-25

310114110226 AVALWBS-KF50-P 6-56

310114210026 AVALWB-KF50-P2 6-57

310114210226 AVALWBS-KF50-P2 6-57

310115030016 AVB-CR63-M-E 6-4



310115040016 AVB-ISO63-M-E 6-4

310115230010 AV-CR63-P2-E 6-21

310115230016 AVB-CR63-P2-E 6-19

310115240010 AV-ISO63-P2-E 6-21

310115240016 AVB-ISO63-P2-E 6-19

310116040016 AVB-ISO80-M-E 6-4

310116240010 AV-ISO80-P2-E 6-21

310116240016 AVB-ISO80-P2-E 6-19

310118230010 AV-CR100-P2-E 6-21

310118230016 AVB-CR100-P2-E 6-19

310118240010 AV-ISO100-P2-E 6-21

310118240016 AVB-ISO100-P2-E 6-19

4001

40010550250AAKF16FX250 4-2

40010550250FHCF16FX250R 4-5

40010550500AAKF16FX500 4-2

40010550500FHCF16FX500R 4-5

40010550750AAKF16FX750 4-2

40010550750FHCF16FX750R 4-5

40010551000AAKF16FX1000 4-2

40010551000FHCF16FX1000R 4-5

40010560250AAKF25FX250 4-2

40010560500AAKF25FX500 4-2

40010560750AAKF25FX750 4-2

40010561000AAKF25FX1000 4-2

40010570250AAKF40FX250 4-2

40010570250FHCF35FX250R 4-5

40010570500AAKF40FX500 4-2

40010570500FHCF35FX500R 4-5

40010570750AAKF40FX750 4-2

40010570750FHCF35FX750R 4-5

40010571000AAKF40FX1000 4-2

40010571000FHCF35FX1000R 4-5

40010580250AAKF50FX250 4-2

40010580500AAKF50FX500 4-2

40010580750AAKF50FX750 4-2

40010581000AAKF50FX1000 4-2

40010590250BB ISO63FX250 4-4

40010590250FHCF63FX250R 4-5

40010590500BB ISO63FX500 4-4

40010590500FHCF63FX500R 4-5

40010590750BB ISO63FX750 4-4

40010590750FHCF63FX750R 4-5

40010591000BB ISO63FX1000 4-4


40010591000FH CF63FX1000R 4-5

40010600250BB ISO80FX250 4-4

40010600500BB ISO80FX500 4-4

40010600750BB ISO80FX750 4-4

40010601000BB ISO80FX1000 4-4

40010610250BB ISO100FX250 4-4

40010610250FH CF100FX250R 4-5

40010610500BB ISO100FX500 4-4

40010610500FH CF100FX500R 4-5

40010610750BB ISO100FX750 4-4

40010610750FH CF100FX750R 4-5

40010611000BB ISO100FX1000 4-4

40010611000FH CF100FX1000R 4-5

4021

40210550250AA KF16BFX250 4-1

40210550500AA KF16BFX500 4-1

40210550750AA KF16BFX750 4-1

40210551000AA KF16BFX1000 4-1

40210560250AA KF25BFX250 4-1

40210560500AA KF25BFX500 4-1

40210560750AA KF25BFX750 4-1

40210561000AA KF25BFX1000 4-1

40210570250AA KF40BFX250 4-1

40210570500AA KF40BFX500 4-1

40210570750AA KF40BFX750 4-1

40210571000AA KF40BFX1000 4-1

40210580250AA KF50BFX250 4-1

40210580500AA KF50BFX500 4-1

40210580750AA KF50BFX750 4-1

40210581000AA KF50BFX1000 4-1

4031

40310410100AA KF10FXC100 4-3

40310430100AA KF16FXC100 4-3

40310430150FH CF16FXC150R 4-6

40310440100AA KF25FXC100 4-3

40310450100AA KF40FXC100 4-3

40310450180FH CF35FXC180R 4-6

40310460100AA KF50FXC100 4-3

40310470140BB ISO63FXC140 4-3

40310470210FH CF63FXC210R 4-6

40310480187BB ISO80FXC187 4-3

40310490187BB ISO100FXC187 4-3

40310490270FH CF100FXC270R 4-6


40310500220BB ISO160FXC220 4-3

40310500300FH CF150FXC300R 4-6

5085

5085DG KF10CAP 1-7

5085DG KF16CAP 1-7

5085DY KF25CAP 1-7

5085EJ KF40CAP 1-7

5085EZ CF16CAP 3-14

5085FD KF50CAP 1-7

5085G9 ISO63CAP 2-9

5085GU ISO80CAP 2-9

5085GZ CF35CAP 3-14

5085H0 CF63CAP 3-14

5085HJ ISO100CAP 2-9

5085HY CF100CAP 3-14

5085HZ CF150CAP 3-14

5085JR ISO160CAP 2-9

5085KU ISO200CAP 2-9

5085LE ISO250CAP 2-9

5085LU CF250CAP 3-14

5085LZ CF200CAP 3-14

5085M4 CF300CAP 3-14

5085ML CF350CAP 3-14

5085MT ISO400CAP 2-9

5085ND ISO500CAP 2-9

5085QY ISO320CAP 2-9

-

10 12

INDEX




Model No. Parts No. Page

Number

100-50CR 16230090064 4-07

100-63CR 16230090074 4-07

100-80CR 16230090084 4-07

100EL45A 16070090094 4-09

100EL90A 16030090094 4-08

100ELT45A 16250090094 4-09

100ELT90A 16240090094 4-08

100TA 16150090094 4-10

100UT50A 16170090064 4-11

100UT63A 16170090074 4-11

100UT80A 16170090084 4-11

100UX50A 16210090064 4-12

100UX63A 16210090074 4-12

100UX80A 16210090084 4-12

100XA 16190090094 4-10

150-100CR 16230110094 4-07

150-80CR 16230110084 4-07

150EL90A 16030110114 4-08

150TA 16150110114 4-10

150UT100A 16170110094 4-11

150UT80A 16170110084 4-11

150UX100A 16210110094 4-12

150UX80A 16210110084 4-12

150XA 16190110114 4-10

16EL45A 16070020024 4-09

16EL90A 16030020024 4-08

16ELT45A 16250020024 4-09

16ELT90A 16240020024 4-08

16TA 16150020024 4-10

16XA 16190020024 4-10

25-16CR 16230030024 4-07

25EL45A 16070030034 4-09

25EL90A 16030030034 4-08

25ELT45A 16250030034 4-09

25ELT90A 16240030034 4-08

25TA 16150030034 4-10

25UT16A 16170030024 4-11

25UX16A 16210030024 4-12

25XA 16190030034 4-10

40-16CR 16230050024 4-07

40-25CR 16230050034 4-07

40EL45A 16070050054 4-09

40EL90A 16030050054 4-08

40ELT45A 16250050054 4-09


40ELT90A 16240050054 4-08

40TA 16150050054 4-10

40UT16A 16170050024 4-11

40UT25A 16170050034 4-11

40UX16A 16210050024 4-12

40UX25A 16210050034 4-12

40XA 16190050054 4-10

50-25CR 16230060034 4-07

50-40CR 16230060054 4-07

50EL45A 16070060064 4-09

50EL90A 16030060064 4-08

50ELT45A 16250060064 4-09

50ELT90A 16240060064 4-08

50TA 16150060064 4-10

50UT16A 16170060024 4-11

50UT25A 16170060034 4-11

50UT40A 16170060054 4-11

50UX16A 16210060024 4-12

50UX25A 16210060034 4-12

50UX40A 16210060054 4-12

50XA 16190060064 4-10

63-40CR 16230070054 4-07

63-50CR 16230070064 4-07

63EL45A 16070070074 4-09

63EL90A 16030070074 4-08

63ELT45A 16250070074 4-09

63ELT90A 16240070074 4-08

63TA 16150070074 4-10

63XA 16190070074 4-10

80-50CR 16230080064 4-07

80-63CR 16230080074 4-07

80EL45A 16070080084 4-09

80EL90A 16030080084 4-08

80ELT45A 16250080084 4-09

80ELT90A 16240080084 4-08

80TA 16150080084 4-10

80UT63A 16170080074 4-11

80UX63A 16210080074 4-12

80XA 16190080084 4-10

A

ANSI150-1000-500 156310B53 8-01

ANSI150-1100-600 156311B63 8-01

ANSI150-1350-800 156313B73 8-01

ANSI150-350-050 156301A43 8-01


ANSI150-388-075 156302A53 8-01

ANSI150-425-100 156303A63 8-01

ANSI150-463-125 156323A73 8-01

ANSI150-500-150 156305A83 8-01

ANSI150-600-200 156306A93 8-01

ANSI150-700-250 156307B13 8-01

ANSI150-750-300 156308B23 8-01

ANSI150-850-350 156324B33 8-01

ANSI150-900-400 156309B43 8-01

ASA4KA40 17110501092 5-01

ASA4KA50 17110501122 5-01

ASA4OG40 17120501092 5-01

ASA4OG50 17120501122 5-01

ASA5KA40 17110601092 5-01

ASA5KA50 17110601122 5-01

ASA5OG40 17120601092 5-01

ASA5OG50 17120601122 5-01

ASA7KA40 17110701092 5-01

ASA7KA50 17110701122 5-01

ASA7OG40 17120701092 5-01

ASA7OG50 17120701122 5-01

AVALWB-KF16-M 310109010026 6-55

AVALWB-KF16-P 310109110026 6-56

AVALWB-KF16-P2 310109210026 6-57

AVALWB-KF25-M 310111010026 6-55

AVALWB-KF25-P 310111110026 6-56

AVALWB-KF25-P2 310111210026 6-57

AVALWB-KF40-M 310113010026 6-55

AVALWB-KF40-P 310113110026 6-56

AVALWB-KF40-P2 310113210026 6-57

AVALWB-KF50-M 310114010026 6-55

AVALWB-KF50-P 310114110026 6-56

AVALWB-KF50-P2 310114210026 6-57

AVALWBS-KF16-P 310109110226 6-56

AVALWBS-KF16-P2 310109210226 6-57

AVALWBS-KF25-P 310111110226 6-56

AVALWBS-KF25-P2 310111210226 6-57

AVALWBS-KF40-P 310113110226 6-56

AVALWBS-KF40-P2 310113210226 6-57

AVALWBS-KF50-P 310114110226 6-56

AVALWBS-KF50-P2 310114210226 6-57

AVB-CR100-P2 300118230016 6-15

AVB-CR100-P2-E 310118230016 6-19

AVB-CR16-M 300109030016 6-03

AVB-CR16-M-E 310109030016 6-04



AVB-CR16-P 300109130016 6-14

AVB-CR16-P-E 310109130016 6-18

AVB-CR35-M 300113030016 6-03

AVB-CR35-M-E 310113030016 6-04

AVB-CR35-P 300113130016 6-14

AVB-CR35-P-E 310113130016 6-18

AVB-CR63-M 300115030016 6-03

AVB-CR63-M-E 310115030016 6-04

AVB-CR63-P2 300115230016 6-15

AVB-CR63-P2-E 310115230016 6-19

AVB-CU-CR16-M 300609030016 6-10

AVB-CU-CR35-M 300613030016 6-10

AVB-CU-CR63-M 300615030016 6-10

AVB-CU-KF16-M 300609010016 6-10

AVB-CU-KF25-M 300611010016 6-10

AVB-CU-KF40-M 300613010016 6-10

AVB-CU-KF50-M 300614010016 6-10

AVB-CU-TE16-M 300609000016 6-10

AVB-CU-TE25-M 300611000016 6-10

AVB-CU-TE40-M 300613000016 6-10

AVB-CU-TE50-M 300614000016 6-10

AVB-CU-TE63-M 300615000016 6-10

AVB-ISO100-P2 300118240016 6-15

AVB-ISO100-P2-E 310118240016 6-19

AVB-ISO160-P2 300120240016 6-15

AVB-ISO200-P2 300121240016 6-15

AVB-ISO63-M 300115040016 6-03

AVB-ISO63-M-E 310115040016 6-04

AVB-ISO63-P2 300115240016 6-15

AVB-ISO63-P2-E 310115240016 6-19

AVB-ISO80-M 300116040016 6-03

AVB-ISO80-M-E 310116040016 6-04

AVB-ISO80-P2 300116240016 6-15

AVB-ISO80-P2-E 310116240016 6-19

AVB-KF16-M 300109010016 6-03

AVB-KF16-M-E 310109010016 6-04

AVB-KF16-P 300109110016 6-14

AVB-KF16-P-E 310109110016 6-18

AVB-KF25-M 300111010016 6-03

AVB-KF25-M-E 310111010016 6-04

AVB-KF25-P 300111110016 6-14

AVB-KF25-P-E 310111110016 6-18

AVB-KF40-M 300113010016 6-03

AVB-KF40-M-E 310113010016 6-04

AVB-KF40-P 300113110016 6-14


AVB-KF40-P-E 310113110016 6-18

AVB-KF50-M 300114010016 6-03

AVB-KF50-M-E 310114010016 6-04

AVB-KF50-P 300114110016 6-14

AVB-KF50-P-E 310114110016 6-18

AVBS-CR16-P 300109130216 6-24

AVBS-CR16-P-E 310109130216 6-25

AVBS-CR35-P 300113130216 6-24

AVBS-CR35-P-E 310113130216 6-25

AVBS-KF16-P 300109110216 6-24

AVBS-KF16-P-E 310109110216 6-25

AVBS-KF25-P 300111110216 6-24

AVBS-KF25-P-E 310111110216 6-25

AVBS-KF40-P 300113110216 6-24

AVBS-KF40-P-E 310113110216 6-25

AVBS-KF50-P 300114110216 6-24

AVBS-KF50-P-E 310114110216 6-25

AVBS-TE16-P 300109100216 6-24

AVBS-TE25-P 300111100216 6-24

AVBS-TE40-P 300113100216 6-24

AVBS-TE50-P 300114100216 6-24

AVB-TE100-P2 300118200016 6-15

AVB-TE160-P2 300120200016 6-15

AVB-TE16-M 300109000016 6-03

AVB-TE16-P 300109100016 6-14

AVB-TE16-P2 300109200016 6-15

AVB-TE200-P2 300121200016 6-15

AVB-TE25-M 300111000016 6-03

AVB-TE25-P 300111100016 6-14

AVB-TE25-P2 300111200016 6-15

AVB-TE40-M 300113000016 6-03

AVB-TE40-P 300113100016 6-14

AVB-TE40-P2 300113200016 6-15

AVB-TE50-M 300114000016 6-03

AVB-TE50-P 300114100016 6-14

AVB-TE50-P2 300114200016 6-15

AVB-TE63-M 300115000016 6-03

AVB-TE63-P2 300115200016 6-15

AVB-TE80-M 300116000016 6-03

AVB-TE80-P2 300116200016 6-15

AVBAK-CR16 300509030011 6-54

AVBAK-CR35 300511030011 6-54

AV-CR100-P2 300118230010 6-17

AV-CR100-P2-E 310118230010 6-21

AV-CR16-P 300109130010 6-16


AV-CR16-P-E 310109130010 6-20

AV-CR35-P 300113130010 6-16

AV-CR35-P-E 310113130010 6-20

AV-CR63-P2 300115230010 6-17

AV-CR63-P2-E 310115230010 6-21

AV-ISO100-P2 300118240010 6-17

AV-ISO100-P2-E 310118240010 6-21

AV-ISO160-P2 300120240010 6-17

AV-ISO200-P2 300121240010 6-17

AV-ISO63-P2 300115240010 6-17

AV-ISO63-P2-E 310115240010 6-21

AV-ISO80-P2 300116240010 6-17

AV-ISO80-P2-E 310116240010 6-21

AV-KF16-M 300109010010 6-06

AV-KF16-M-E 310109010010 6-07

AV-KF16-P 300109110010 6-16

AV-KF16-P-E 310109110010 6-20

AV-KF25-M 300111010010 6-06

AV-KF25-M-E 310111010010 6-07

AV-KF25-P 300111110010 6-16

AV-KF25-P-E 310111110010 6-20

AV-KF40-M 300113010010 6-06

AV-KF40-M-E 310113010010 6-07

AV-KF40-P 300113110010 6-16

AV-KF40-P-E 310113110010 6-20

AV-KF50-M 300114010010 6-06

AV-KF50-M-E 310114010010 6-07

AV-KF50-P 300114110010 6-16

AV-KF50-P-E 310114110010 6-20

AV-TE100-P2 300118200010 6-17

AV-TE160-P2 300120200010 6-17

AV-TE16-M 300109000010 6-06

AV-TE16-P 300109100010 6-16

AV-TE16-P2 300109200010 6-17

AV-TE200-P2 300121200010 6-17

AV-TE25-M 300111000010 6-06

AV-TE25-P 300111100010 6-16

AV-TE25-P2 300111200010 6-17

AV-TE40-M 300113000010 6-06

AV-TE40-P 300113100010 6-16

AV-TE40-P2 300113200010 6-17

AV-TE50-M 300114000010 6-06

AV-TE50-P 300114100010 6-16

AV-TE50-P2 300114200010 6-17

10 - 13 10 - 14

INDEX





AV-TE63-P2 300115200010 6-17

AV-TE80-P2 300116200010 6-17

C

CF100B 154109003 3-01

CF100B102 154509183 3-08

CF100B102-316 154509185 3-08

CF100B102TAP 154609183 3-09

CF100B102TAP-316 154609185 3-09

CF100B-316 154109005 3-01

CF100BTAP 154209003 3-02

CF100BTAP-316 154209005 3-02

CF100CAP 5085HY 3-14

CF100CG 21311281 3-15

CF100EL90 16038098094 4-19

CF100FX1000R 40010611000FH 4-05

CF100FX250R 40010610250FH 4-05

CF100FX500R 40010610500FH 4-05

CF100FX750R 40010610750FH 4-05

CF100FXC270R 40310490270FH 4-06

CF100HN 155509183 3-13

CF100N 16018098094 4-18

CF100NR 16016098094 4-18

ACF100RA35 17080908082 5-04

CF100RA35R 17080906082 5-04

CF100RA63 17080908132 5-04

CF100RA63R 17080906132 5-04

CF100RF35 17480906082 3-12

CF100RF63 17480906132 3-12

CF100S100A 17080902152 5-02

CF100S63A 17080902132 5-02

CF100SPCG 21311291 3-15

CF100T 16158098094 4-20

CF100X 16198098094 4-21

CF150B 154111003 3-01

CF150B153 154511203 3-08

CF150B153-316 154511205 3-08

CF150B153TAP 154611203 3-09

CF150B153TAP-316 154611205 3-09

CF150B-316 154111005 3-01

CF150BTAP 154211003 3-02

CF150BTAP-316 154211005 3-02

CF150CAP 5085HZ 3-14

CF150CG 21311481 3-15

CF150EL90 16038118114 4-19


CF150FXC300R 40310500300FH 4-06

CF150HN 155511203 3-13

CF150N 16018118114 4-18

CF150NR 16016118114 4-18

CF150RA100 17081108152 5-04

CF150RA100R 17081106152 5-04

CF150RA35 17081108082 5-04

CF150RA35R 17081106082 5-04

CF150RA63 17081108132 5-04

CF150RA63R 17081106132 5-04

CF150RF100 17481106152 3-12

CF150RF35 17481106082 3-12

CF150RF63 17481106132 3-12

CF150S100A 17081102152 5-02

CF150S63A 17081102132 5-02

CF150SPCG 21311491 3-15

CF150T 16158118114 4-20

CF150X 16198118114 4-21

CF1619TAP 154602094 3-05

CF16B 154102004 3-01

CF16B12 154502074 3-05

CF16B12-316 154502075 3-05

CF16B12N 154902074 3-06

CF16B12N-316 154902075 3-06

CF16B12TAP 154602074 3-05

CF16B12TAP-316 154602075 3-05

CF16B12TAPN 155002074 3-06

CF16B12TAPN-316 155002075 3-06

CF16B19 154502094 3-05

CF16B19-316 154502095 3-05

CF16B19N 154902094 3-06

CF16B19N-316 154902095 3-06

CF16B19TAP-316 154602095 3-05

CF16B19TAPN 155002094 3-06

CF16B19TAPN-316 155002095 3-06

CF16B-316 154102005 3-01

CF16B7 154502044 3-05

CF16B7-316 154502045 3-05

CF16B7N 154902044 3-06

CF16B7N-316 154902045 3-06

CF16B7TAP 154602044 3-05

CF16B7TAP-316 154602045 3-05

CF16B7TAPN 155002044 3-06

CF16B7TAPN-316 155002045 3-06

CF16BTAP 154202004 3-02


CF16BTAP-316 154202005 3-02

CF16CAP 5085EZ 3-14

CF16CG 21310581 3-15

CF16EL90 16038028024 4-19

CF16FX1000R 40010551000FH 4-05

CF16FX250R 40010550250FH 4-05

CF16FX500R 40010550500FH 4-05

CF16FX750R 40010550750FH 4-05

CF16FXC150R 40310430150FH 4-06

CF16HN 155502093 3-13

CF16K10A 17080201032 5-02

CF16K16A 17080201052 5-02

CF16N 16018028024 4-18

CF16NR 16016028024 4-18

CF16PN 21320541 3-14

CF16SPCG 21310591 3-15

CF16T 16158028024 4-20

CF16X 16198028024 4-21

CF200B 154113003 3-01

CF200B204 154513213 3-08

CF200B204-316 154513215 3-08

CF200B204TAP 154613213 3-09

CF200B204TAP-316 154613215 3-09

CF200B-316 154113005 3-01

CF200BTAP 154213003 3-02

CF200BTAP-316 154213005 3-02

CF200CAP 5085LZ 3-14

CF200CG 21311681 3-15

CF200HN 155513213 3-13

CF200N 16018138134 4-18

CF200NR 16016138134 4-18

CF200RF100 17481306152 3-12

CF200RF150 17481306172 3-12

CF200RF35 17481306082 3-12

CF200RF63 17481306132 3-12

CF200SPCG 21311691 3-15

CF250B 154114003 3-01

CF250B255 154514223 3-08

CF250B255-316 154514225 3-08

CF250B255TAP 154614223 3-09

CF250B255TAP-316 154614225 3-09

CF250B-316 154114005 3-01

CF250BTAP 154214003 3-02

CF250BTAP-316 154214005 3-02

CF250CAP 5085LU 3-14



CF250CG 21311781 3-15

CF250RF100 17481406152 3-12

CF250RF150 17481406172 3-12

CF250RF200 17481406192 3-12

CF250RF35 17481406082 3-12

CF250RF63 17481406132 3-12

CF250SPCG 21311791 3-15

CF300B 154115003 3-01

CF300B305 154515233 3-08

CF300B305-316 154515235 3-08

CF300B305TAP 154615233 3-09

CF300B305TAP-316 154615235 3-09

CF300B-316 154115005 3-01

CF300BTAP 154215003 3-02

CF300BTAP-316 154215005 3-02

CF300CAP 5085M4 3-14

CF350B 154117003 3-01

CF350B-316 154117005 3-01

CF350B356 154516243 3-08

CF350B356-316 154516245 3-08

CF350B356TAP 154616243 3-09

CF350B356TAP-316 154616245 3-09

CF350BTAP 154217003 3-02

ACF350BTAP-316 154217005 3-02

CF350CAP 5085ML 3-14

CF35B 154104004 3-01

CF35B25 154504114 3-08

CF35B25-316 154504115 3-08

CF35B25TAP 154604114 3-09

CF35B25TAP-316 154604115 3-09

CF35B-316 154104005 3-01

CF35B38 154504134 3-08

CF35B38-316 154504135 3-08

CF35B38TAP 154604134 3-09

CF35B38TAP-316 154604135 3-09

CF35B42 154504AG4 3-08

CF35B42-316 154504AG5 3-08

CF35B42TAP 154604AG4 3-09

CF35B42TAP-316 154604AG5 3-09

CF35BTAP 154204004 3-02

CF35BTAP-316 154204005 3-02

CF35CAP 5085GZ 3-14

CF35CG 21310781 3-15

CF35EL90 16038048044 4-19

CF35FX1000R 40010571000FH 4-05


CF35FX250R 40010570250FH 4-05

CF35FX500R 40010570500FH 4-05

CF35FX750R 40010570750FH 4-05

CF35FXC180R 40310450180FH 4-06

CF35HN 155504133 3-13

CF35K10A 17080401032 5-02

CF35K16A 17080401052 5-02

CF35K25A 17080401072 5-02

CF35N 16018048044 4-18

CF35NR 16016048044 4-18

CF35PN 21320741 3-14

CF35RA16 17080408052 5-04

CF35RA16R 17080406052 5-04

CF35RF16 17480406052 3-12

CF35SPCG 21310791 3-15

CF35T 16158048044 4-20

CF35X 16198048044 4-21

CF63B 154107003 3-01

CF63B-316 154107005 3-01

CF63B51 154507143 3-08

CF63B51-316 154507145 3-08

CF63B51TAP 154607143 3-09

CF63B51TAP-316 154607145 3-09

CF63B63 154507153 3-08

CF63B63-316 154507155 3-08

CF63B63TAP 154607153 3-09

CF63B63TAP-316 154607155 3-09

CF63BTAP 154207003 3-02

CF63BTAP-316 154207005 3-02

CF63CAP 5085H0 3-14

CF63CG 21311081 3-15

CF63EL90 16038078074 4-19

CF63FX1000R 40010591000FH 4-05

CF63FX250R 40010590250FH 4-05

CF63FX500R 40010590500FH 4-05

CF63FX750R 40010590750FH 4-05

CF63FXC210R 40310470210FH 4-06

CF63HN 155507153 3-13

CF63K50A 17080701122 5-02

CF63N 16018078074 4-18

CF63NR 16016078074 4-18

CF63PN 21321041 3-14

CF63RA16 17080708052 5-04

CF63RA16R 17080706052 5-04

CF63RA35 17080708082 5-04


CF63NR 16016078074 4-18

CF63PN 21321041 3-14

CF63RA16 17080708052 5-04

CF63RA16R 17080706052 5-04

CF63RA35 17080708082 5-04

CF63RA35R 17080706082 5-04

CF63RF16 17480706052 3-12

CF63RF35 17480706082 3-12

CF63S63A 17080702132 5-02

CF63SPCG 21311091 3-15

CF63T 16158078074 4-20

CF63X 16198078074 4-21

CR100B 154309003 3-03

CR10B12 154709183 3-10

CR100B102-316 154709185 3-10

CR100B102TAP 154809183 3-11

CR100B102TAP-316 154809185 3-11

CR100B-316 154309005 3-03

CR100BTAP 154409003 3-04

CR100BTAP-316 154409005 3-04

CR100EL90 16036096094 4-19

CR100HN 155709183 3-13

CR100T 16156096094 4-20

CR100X 16196096094 4-21

CR150B 154311003 3-03

CR150B153 154711203 3-10

CR150B153-316 154711205 3-10

CR150B153TAP 154811203 3-11

CR150B153TAP-316 154811205 3-11

CR150B-316 154311005 3-03

CR150BTAP 154411003 3-04

CR150BTAP-316 154411005 3-04

CR150EL90 16036116114 4-19

CR150HN 155711203 3-13

CR150T 16156116114 4-20

CR150X 16196116114 4-21

CR16B 154302004 3-03

CR16B12N 155102074 3-07

CR16B12N-316 155102075 3-07

CR16B12TAPN 155202074 3-07

CR16B12TAPN-316 155202075 3-07

CR16B19N 155102094 3-07

CR16B19N-316 155102095 3-07

CR16B19TAPN 155202094 3-07

CR16B19TAPN-316 155202095 3-07

10 - 15 10 - 16

INDEX





CR16B-316 154302005 3-03

CR16B7N 155102044 3-07

CR16B7N-316 155102045 3-07

CR16B7TAPN 155202044 3-07

CR16B7TAPN-316 155202045 3-07

CR16BTAP 154402004 3-04

CR16BTAP-316 154402005 3-04

CR16EL90 16036026024 4-19

CR16HN 155702093 3-13

CR16T 16156026024 4-20

CR16X 16196026024 4-21

CR200B 154313003 3-03

CR200B204-316 154713213 3-10

CR200B204-316 154713215 3-10

CR200B204TAP 154813213 3-11

CR200B204TAP-316 154813215 3-11

CR100B-316 154309005 3-03

CR100BTAP 154409003 3-04

CR100BTAP-316 154409005 3-04

CR200HN 155713213 3-13

CR250B 154314003 3-03

CR250B255 154714223 3-10

CR250B255-316 154714225 3-10

CR250B255TAP 154814223 3-11

CR250B255TAP-316 154814225 3-11

CR250B-316 154314005 3-03

CR250BTAP 154414003 3-04

CR250BTAP-316 154414005 3-04

CR300B 154315003 3-03

CR300B305 154715233 3-10

CR300B305-316 154715235 3-10

CR300B305TAP 154815233 3-11

CR300B305TAP-316 154815235 3-11

CR300B-316 154315005 3-03

CR300BTAP 154415003 3-04

CR300BTAP-316 154415005 3-04

CR350B 154317003 3-03

CR350B-316 154317005 3-03

CR350B356 154716243 3-10

CR350B356-316 154716245 3-10

CR350B356TAP 154816243 3-11

CR350B356TAP-316 154816245 3-11

CR350BTAP 154417003 3-04

CR350BTAP-316 154417005 3-04

CR35B 154304004 3-03


CR35B25 154704114 3-10

CR35B25-316 154704115 3-10

CR35B25TAP 154804114 3-11

CR35B25TAP-316 154804115 3-11

CR35B-316 154304005 3-03

CR35B38 154704134 3-10

CR35B38-316 154704135 3-10

CR35B38TAP 154804134 3-11

CR35B38TAP-316 154804135 3-11

CR35B42 154704AG4 3-10

CR35B42-316 154704AG5 3-10

CR35B42TAP 154804AG4 3-11

CR35B42TAP-316 154804AG5 3-11

CR35BTAP 154404004 3-04

CR35BTAP-316 154404005 3-04

CR35EL90 16036046044 4-19

CR35HN 155704133 3-13

CR35T 16156046044 4-20

CR35X 16196046044 4-21

CR63B 154307003 3-03

CR63B-316 154307005 3-03

CR63B51 154707143 3-10

CR63B51-316 154707145 3-10

CR63B51TAP 154807143 3-11

CR63B51TAP-316 154807145 3-11

CR63B63 154707153 3-10

CR63B63-316 154707155 3-10

CR63B63TAP 154807153 3-11

CR63B63TAP-316 154807155 3-11

CR63BTAP 154407003 3-04

CR63BTAP-316 154407005 3-04

CR63EL90 16036076074 4-19

CR63HN 155707153 3-13

CR63T 16156076074 4-20

CR63X 16196076074 4-21

D

DIN10-090-010 158400A33 8-03

DIN10-095-010 158401A43 8-03

DIN10-105-015 158402A53 8-03

DIN10-115-020 158403A63 8-03

DIN10-140-025 158423A73 8-03

DIN10-150-032 158405A83 8-03

DIN10-165-040 158406A93 8-03

DIN10-185-065 158407B13 8-03


DIN10-200-080 158408B23 8-03

DIN10-220-100 158409B43 8-03

DIN10-250-125 158410B53 8-03

DIN10-285-150 158411B63 8-03

DIN10-340-200 158413B73 8-03

DIN6-075-010 158200A33 8-03

DIN6-080-015 158201A43 8-03

DIN6-090-020 158202A53 8-03

DIN6-100-025 158203A63 8-03

DIN6-120-032 158223A73 8-03

DIN6-130-040 158205A83 8-03

DIN6-140-050 158206A93 8-03

DIN6-160-065 158207B13 8-03

DIN6-190-080 158208B23 8-03

DIN6-210-100 158209B43 8-03

DIN6-240-125 158210B53 8-03

DIN6-265-150 158211B63 8-03

DIN6-320-200 158213B73 8-03

I

IS0100B 152109003 2-01

IS0100B102 152209183 2-01

IS0100BF 152309183 2-02

IS0100BFTA 152409183 2-02

IS0160B 152112003 2-01

IS0160B153 152212203 2-01

IS0160BF 152312203 2-02

IS0160BFTAP 152412203 2-02

IS0200B 152113003 2-01

IS0200B204 152213213 2-01

IS0200BF 152313213 2-02

IS0200BFTAP 152413213 2-02

IS0250B 152114003 2-01

IS0250B255 152214223 2-01

IS0250BF 152314223 2-02

IS0250BFTAP 152414223 2-02

IS0320B 152116003 2-01

IS0320B305 152216233 2-01

IS0320BF 152316233 2-02

IS0320BFTAP 152416233 2-02

IS0400B 152118003 2-01

IS0400B407 152218253 2-01

IS0400BF 152318253 2-02

IS0400BFTA 152418253 2-02

IS0500B 152120003 2-01



IS0500B509 152220273 2-01

IS0500BF 152320273 2-02

IS0500BFTAP 152420273 2-02

IS063B 152107003 2-01

IS063B63 152207153 2-01

IS063BF 152307153 2-02

IS063BFTAP 152407153 2-02

IS080B 152108003 2-01

IS080B76 152208163 2-01

IS080BF 152308163 2-02

IS080BFATP 152408163 2-02

ISO100CAP 5085HJ 2-09

ISO100CRAA 191012110 7-08

ISO100CRAE 191012120 7-07

ISO100CRNAA 191312111 7-12

ISO100CRNAE 191312121 7-10

ISO100CRNSA 191312411 7-12

ISO100CRNSE 191312421 7-10

ISO100CRSA 191012410 7-08

ISO100CRSE 191012420 7-07

ISO100CRVAA 191112111 7-11

ISO100CRVAE 191112121 7-09

ISO100CRVSA 191112411 7-11

ISO100CRVSE 191112421 7-09

ISO100EL90A 16032092094 4-16

ISO100FX1000 40010611000BB 4-04

ISO100FX250 40010610250BB 4-04

ISO100FX500 40010610500BB 4-04

ISO100FX750 40010610750BB 4-04

ISO100FXC187 40310490187BB 4-03

ISO100HN 152609183 2-04

ISO100KA40 17020901092 5-03

ISO100KA50 17020901122 5-03

ISO100KRA40 17220901092 5-10

ISO100KRA50 17220901122 5-10

ISO100N 16012092094 4-16

ISO100OCRNAA 192312111 7-16

ISO100OCRNAE 192312121 7-14

ISO100OCRNSA 192312411 7-16

ISO100OCRNSE 192312421 7-14

ISO100OCRVAA 192112111 7-15

ISO100OCRVAE 192112121 7-13

ISO100OCRVSA 192112411 7-15

ISO100OCRVSE 192112421 7-13


ISO100RA63 17220902132 5-11

ISO100RA80 17220902142 5-11

ISO100RBR 152509093 2-03

ISO100RBR-NP 152509098 2-03

ISO100SRR 20011241 2-05

ISO100SRR-NP 200112A1 2-05

ISO100TA 16152092094 4-17

ISO100XA 16192092094 4-17

ISO160-250DWCA 2122A411 2-07

ISO160-250SWC304 2121A441 2-06

ISO160-250SWCA 2121A411 2-06

ISO160-250SWC-ZP 2121A431 2-06

ISO160C100A 17021208172 5-02

ISO160C150A 17021208172 5-02

ISO160CAP 5085JR 2-09

ISO160CRAA 191015110 7-08

ISO160CRAE 191015120 7-07

ISO160CRNAA 191315111 7-12

ISO160CRNAE 191315121 7-10

ISO160CRNSA 191315411 7-12

ISO160CRNSE 191315421 7-10

ISO160CRSA 191015410 7-08

ISO160CRSE 191015420 7-07

ISO160CRVAA 191115111 7-11

ISO160CRVAE 191115121 7-09

ISO160CRVSA 191115411 7-11

ISO160CRVSE 191115421 7-09

ISO160EL90A 16032122124 4-16

ISO160FXC220 40310500220BB 4-03

ISO160HN 152612203 2-04

ISO160N 16012122124 4-16

ISO160OCRNAA 192315111 7-16

ISO160OCRNAE 192315121 7-14

ISO160OCRNSE 192315421 7-I6

ISO160OCRVAA 192115111 7-14

160OCRNSA 192315411 7-16

ISO160OCRVAE 192115121 7-13

ISO160OCRVSA 192115411 7-15

ISO160OCRVSE 192115421 7-13

ISO160RA63 17221202132 5-11

ISO160RBR 152512123 2-03

ISO160RBR-NP 152512128 2-03

ISO160SRR 20011541 2-05

ISO160SRR-NP 200115A1 2-05


ISO160TA 16152122124 4-17

ISO160XA 16192122124 4-17

ISO200CAP 5085KU 2-09

ISO200CRAA 191016110 7-08

ISO200CRAE 191016120 7-07

ISO200CRNAA 191316111 7-12

ISO200CRNAE 191316121 7-10

ISO200CRNSA 191316411 7-12

ISO200CRNSE 191316421 7-10

ISO200CRSA 191016410 7-08

ISO200CRSE 191016420 7-07

ISO200CRVAA 191116111 7-11

ISO200CRVAE 191116121 7-09

ISO200CRVSA 191116411 7-11

ISO200CRVSE 191116421 7-09

ISO200HN 152613213 2-04

ISO200N 16012132134 4-16

ISO200OCRNAA 192316111 7-16

ISO200OCRNAE 192316121 7-14

ISO200OCRNSA 192316411 7-16

ISO200OCRNSE 192316421 7-14

ISO200OCRVAA 192116111 7-15

ISO200OCRVAE 192116121 7-13

ISO200OCRVSA 192116411 7-15

ISO200OCRVSE 192116421 7-13

ISO200RBR 152513133 2-03

ISO200RBR-NP 152513138 2-03

ISO200SRR 20011641 2-05

ISO200SRR-NP 200116A1 2-05

ISO250CAP 5085L 2-09

ISO250CRAA 191017110 7-08

ISO250CRAE 191017120 7-07

ISO250CRNAA 191317111 7-12

ISO250CRNAE 191317121 7-10

ISO250CRNSA 191317411 7-12

ISO250CRNSE 191317421 7-10

ISO250CRSA 191017410 7-08

ISO250CRSE 191017420 7-07

ISO250CRVAA 191117111 7-11

ISO250CRVAE 191117121 7-09

ISO250CRVSA 191117411 7-11

ISO250CRVSE 191117421 7-09

ISO250HN 152614223 2-04

ISO250N 16012142144 4-16

10 - 17 10 - 18

INDEX





ISO250OCRNAA 192317111 7-16

ISO250OCRNAE 192317121 7-14

ISO250OCRNSA 192317411 7-16

ISO250OCRNSE 192317421 7-14

ISO250OCRVAA 192117111 7-15

ISO250OCRVAE 192117121 7-13

ISO250OCRVSA 192117411 7-15

ISO250OCRVSE 192117421 7-13

ISO250RBR 152514143 2-03

ISO250RBR-NP 152514148 2-03

ISO250SRR 20011741 2-05

ISO250SRR-NP 200117A1 2-05

ISO320-500DCC316 2123A561 2-08

ISO320-500DCC-ZP 2123A531 2-08

ISO320-500DWCA 2122A511 2-07

ISO320-500SWC304 2121A541 2-06

ISO320-500SWCA 2121A511 2-06

ISO320-500SWC-ZP 2121A531 2-06

ISO320CAP 5085QY 2-09

ISO320CRAA 191019110 7-08

ISO320CRAE 191019120 7-07

ISO320CRNAA 191319111 7-12

ISO320CRNAE 191319121 7-10

ISO320CRNSA 191319411 7-12

ISO320CRNSE 191319421 7-10

ISO320CRSA 191019410 7-08

ISO320CRSE 191019420 7-07

ISO320CRVAA 191119111 7-11

ISO320CRVAE 191119121 7-09

ISO320CRVSA 191119411 7-11

ISO320CRVSE 191119421 7-09

ISO320HN 152616233 2-04

ISO320N 16012162164 4-16

ISO320OCRNAA 192319111 7-16

ISO320OCRNAE 192319121 7-14

ISO320OCRNSA 192319411 7-16

ISO320OCRNSE 192319421 7-14

ISO320OCRVAA 192119111 7-15

ISO320OCRVAE 192119121 7-13

ISO320OCRVSA 192119411 7-15

ISO320OCRVSE 192119421 7-13

ISO320RBR 152516163 2-03

ISO320RBR-NP 152516168 2-03

ISO320SRR 20011941 2-05

ISO320SRR-NP 200119A1 2-05


ISO400CAP 5085MT 2-09

ISO400CRAA 191021110 7-08

ISO400CRAE 191021120 7-07

ISO400CRNAA 191321111 7-12

ISO400CRNAE 191321121 7-10

ISO400CRNSA 191321411 7-12

ISO400CRNSE 191321421 7-10

ISO400CRSA 191021410 7-08

ISO400CRSE 191021420 7-07

ISO400CRVAA 191121111 7-11

ISO400CRVAE 191121121 7-09

ISO400CRVSA 191121411 7-11

ISO400CRVSE 191121421 7-09

ISO400HN 152618253 2-04

ISO400N 16012182184 4-16

ISO400OCRNAA 192321111 7-16

ISO400OCRNAE 192321121 7-14

ISO400OCRNSA 192321411 7-16

ISO400OCRNSE 192321421 7-14

ISO400OCRVAA 192121111 7-15

ISO400OCRVAE 192121121 7-13

ISO400OCRVSA 192121411 7-15

ISO400OCRVSE 192121421 7-13

ISO400RBR 152518183 2-03

ISO400RBR-NP 152518188 2-03

ISO400SRR 20012141 2-05

ISO400SRR-NP 200121A1 2-05

ISO500CAP 5085ND 2-09

ISO500CRAA 191023110 7-08

ISO500CRAE 191023120 7-07

ISO500CRNAA 191323111 7-12

ISO500CRNAE 191323111 7-10

ISO500CRNSA 191323411 7-12

ISO500CRNSE 191323421 7-10

ISO500CRSA 191023410 7-08

ISO500CRSE 191023420 7-07

ISO500CRVAA 191123111 7-11

ISO500CRVAE 191123121 7-09

ISO500CRVSA 191123411 7-11

ISO500CRVSE 191123421 7-09

ISO500HN 152620273 2-04

ISO500N 16012202204 4-16

ISO500OCRNAA 192323111 7-16

ISO500OCRNAE 192323121 7-14

ISO500OCRNSA 192323411 7-16


ISO500OCRNSE 192323421 7-14

ISO500OCRVAA 192123111 7-15

ISO500OCRVAE 192123121 7-13

ISO500OCRVSA 192123411 7-15

ISO500OCRVSE 192123421 7-13

ISO500RBR 152520203 2-03

ISO500RBR-NP 152520208 2-03

ISO500SRR 20012341 2-05

ISO500SRR-NP 200123A1 2-05

ISO630DCC316 2123A661 2-08

ISO630DCC-ZP 2123A631 2-08

ISO63-100DWCA 2122A211 2-07

ISO63-100SWC304 2121A241 2-06

ISO63-100SWCA 2121A211 2-06

ISO63-100SWC-ZP 2121A231 2-06

ISO63-250DCC316 2123A361 2-08

ISO63-250DCC-ZP 2123A331 2-08

ISO63CAP 5085G9 2-09

ISO63CRAA 191010110 7-08

ISO63CRAE 191010120 7-07

ISO63CRNAA 191310111 7-12

ISO63CRNAE 191310121 7-10

ISO63CRNSA 191310411 7-12

ISO63CRNSE 191310421 7-10

ISO63CRSA 191010410 7-08

ISO63CRSE 191010420 7-07

ISO63CRVAA 191110111 7-11

ISO63CRVAE 191110121 7-09

ISO63CRVSA 191110411 7-11

ISO63CRVSE 191110421 7-09

ISO63EL90A 16032072074 4-16

ISO63FX1000 40010591000BB 4-04

ISO63FX250 40010590250BB 4-04

ISO63FX500 40010590500BB 4-04

ISO63FX750 40010590750BB 4-04

ISO63FXC140 40310470140BB 4-03

ISO63HN 152607153 2-04

ISO63KA25 17020701072 5-03

ISO63KA40 17020701092 5-03

ISO63KA50 17020701122 5-03

ISO63N 16012072074 4-16

ISO63OCRNAA 192310111 7-16

ISO63OCRNAE 192310121 7-14

ISO63OCRNSA 192310411 7-16

ISO63OCRNSE 192310421 7-14



ISO63OCRVAA 192110111 7-15

ISO63OCRVAE 192110121 7-13

ISO63OCRVSA 192110411 7-15

ISO63OCRVSE 192110421 7-13

ISO63RBR 152507073 2-03

ISO63RBR-NP 152507078 2-03

ISO63SRR 20011041 2-05

ISO63SRR-NP 200110A1 2-05

ISO63TA 16152072074 4-17

ISO63XA 16192072074 4-17

ISO80CAP 5085GU 2-09

ISO80CRAA 191011110 7-08

ISO80CRAE 191011120 7-07

ISO80CRNAA 191311111 7-12

ISO80CRNAE 191311121 7-10

ISO80CRNSA 191311411 7-12

ISO80CRNSE 191311421 7-10

ISO80CRSA 191011410 7-08

ISO80CRSE 191011420 7-07

ISO80CRVAA 191111111 7-11

ISO80CRVAE 191111121 7-09

ISO80CRVSA 191111411 7-11

ISO80CRVSE 191111421 7-09

ISO80EL90A 16032082084 4-16

ISO80FX1000 40010601000BB 4-04

ISO80FX250 40010600250BB 4-04

ISO80FX500 40010600500BB 4-04

ISO80FX750 40010600750BB 4-04

ISO80FXC187 40310480187BB 4-03

ISO80HN 152608163 2-04

ISO80KA40 17020801092 5-03

ISO80KA50 17020801122 5-03

ISO80KRA40 17220801092 5-10

ISO80KRA50 17220801122 5-10

ISO80N 16012082084 4-16

ISO80OCRNAA 192311111 7-16

ISO80OCRNAE 192311121 7-14

ISO80OCRNSA 192311411 7-16

ISO80OCRNSE 192311421 7-14

ISO80OCRVAA 192111111 7-15

ISO80OCRVAE 192111121 7-13

ISO80OCRVSA 192111411 7-15

ISO80OCRVSE 192111421 7-13

ISO80OPR 20001141 7-06

ISO80RA63 17220802132 5-11


ISO80RBR 152508083 2-03

ISO80RBR-NP 152508088 2-03

ISO80SRR 20011141 2-05

ISO80SRR-NP 200111A1 2-05

ISO80TA 16152082084 4-17

ISO80XA 16192082084 4-17

IVB-CR16-M 302109030016 6-28

IVB-CR16-P 302109130016 6-37

IVB-CR35-M 302113030016 6-28

IVB-CR35-P 302113130016 6-37

IVB-CU-CR16-M 302609030016 6-34

IVB-CU-CR35-M 302613030016 6-34

IVB-CU-KF16-M 302609010016 6-34

IVB-CU-KF25-M 302611010016 6-34

IVB-CU-KF40-M 302613010016 6-34

IVB-CU-KF50-M 302614010016 6-34

IVB-CU-TE16-M 302609000016 6-34

IVB-CU-TE25-M 302611000016 6-34

IVB-CU-TE40-M 302613000016 6-34

IVB-CU-TE50-M 302614000016 6-34

IVB-KF16-M 302109010016 6-28

IVB-KF16-P 302109110016 6-37

IVB-KF25-M 302111010016 6-28

IVB-KF25-P 302111110016 6-37

IVB-KF40-M 302113010016 6-28

IVB-KF40-P 302113110016 6-37

IVB-KF50-M 302114010016 6-28

IVB-KF50-P 302114110016 6-37

IVBS-CR16-P 302109130216 6-41

IVBS-CR35-P 302113130216 6-41

IVBS-KF16-P 302109110216 6-41

IVBS-KF25-P 302111110216 6-41

IVBS-KF40-P 302113110216 6-41

IVBS-KF50-P 302114110216 6-41

IVBS-TE16-P 302109100216 6-41

IVBS-TE25-P 302111100216 6-41

IVBS-TE40-P 302113100216 6-41

IVBS-TE50-P 302114100216 6-41

IVB-TE16-M 302109000016 6-28

IVB-TE16-P 302109100016 6-37

IVB-TE25-M 302111000016 6-28

IVB-TE25-P 302111100016 6-37

IVB-TE40-M 302113000016 6-28

IVB-TE40-P 302113100016 6-37

IVB-TE50-M 302114000016 6-28


IVB-TE50-P 302114100016 6-37

IV-CR16-M 302109030010 6-31

IV-CR16-P 302109130010 6-38

IV-CR35-M 302113030010 6-31

IV-CR35-P 302113130010 6-38

IV-KF16-M 302109010010 6-31

IV-KF16-P 302109110010 6-38

IV-KF25-M 302111010010 6-31

IV-KF25-P 302111110010 6-38

IV-KF40-M 302113010010 6-31

IV-KF40-P 302113110010 6-38

IV-KF50-M 302114010010 6-31

IV-KF50-P 302114110010 6-38

IV-TE16-M 302109000010 6-31

IV-TE16-P 302109100010 6-38

IV-TE25-M 302111000010 6-31

IV-TE25-P 302111100010 6-38

IV-TE40-M 302113000010 6-31

IV-TE40-P 302113100010 6-38

IV-TE50-M 302114000010 6-31

IV-TE50-P 302114100010 6-38

JIS10-090-010 157400AC3 8-02

JIS10-095-015 157401AD3 8-02

JIS10-100-020 157402AE3 8-02

JIS10-125-025 157403AF3 8-02

JIS10-135-032 157423AG3 8-02

JIS10-140-040 157405AH3 8-02

JIS10-155-050 157406AJ3 8-02

JIS10-175-065 157407AK3 8-02

JIS10-185-080 157408AL3 8-02

JIS10-195-090 157424AM3 8-02

JIS10-210-100 157409AN3 8-02

JIS10-250-125 157410AP3 8-02

JIS10-280-150 157411AQ3 8-02

JIS10-305-175 157425AU3 8-02

JIS10-330-200 157413AR3 8-02

JIS5-075-010 157200AC3 8-02

JIS5-080-015 157201AD3 8-02

JIS5-085-020 157202AE3 8-02

JIS5-095-025 157203AF3 8-02

JIS5-115-032 157223AG3 8-02

JIS5-120-040 157205AH3 8-02

JIS5-130-050 157206AJ3 8-02

10 - 19 10 - 20

J

INDEX





JIS5-155-065 157207AK3 8-02

JIS5-180-080 157208AL2 8-02

JIS5-190-090 157224AM3 8-02

JIS5-200-100 157209AN3 8-02

JIS5-235-125 157210AP3 8-02

JIS5-265-150 157211AQ3 8-02

JIS5-300-175 157225AU3 8-02

JIS5-320-200 157213AR3 8-02

K

KF100B102 150209183 1-02

KF100BA 150109001 1-01

KF100BS 150109003 1-01

KF100M3CRNS 183312411 7-05

KF100M3CRVS 183112411 7-05

KF100WS 150909AN3 1-03

KF10B12 150201073 1-02

KF10BA 150101001 1-01

KF10BS 150101003 1-01

KF10CAP 5085DG 1-07

KF10CR16NA 19031A111 7-04

KF10CR16NS 19031A411 7-04

KF10CR16VA 19011A111 7-04

KF10CR16VS 19011A411 7-04

KF10CRA 180003110 7-01

KF10CRNA 180303111 7-02

KF10CRNS 180303411 7-02

KF10CRS 180003410 7-01

KF10CRVA 180103111 7-02

KF10CRVS 180103411 7-02

KF10FXC100 40310410100AA 4-03

KF10LHNAA 150401071 1-04

KF10LHNSA 150401073 1-04

KF10LHNSE 150601AB3 1-04

KF10OPR 20000341 7-06

KF10RHA 17010118042 5-06

KF10SHNSA 150301073 1-03

KF10SHNSE 150501AB3 1-03

KF10WS 150901073 1-02

KF160B153 150212203 1-02

KF160BA 150112001 1-01

KF160BS 150112003 1-01

KF160M3CRNS 183315411 7-05

KF160M3CRVS 183115411 7-05

KF160WS 150912AQ3 1-03


KF16B19 150202093 1-02

KF16BA 150102001 1-01

KF16BFX1000 40210551000AA 4-01

KF16BFX250 40210550250AA 4-01

KF16BFX500 40210550500AA 4-01

KF16BFX750 40210550750AA 4-01

KF16BS 150102003 1-01

KF16CAP 5085DG 1-07

KF16CLA 21010511 1-06

KF16CLA-NP 21010521-06

KF16CRA 180005110 7-01

KF16CRNA 180305111 7-02

KF16CRNS 180305411 7-02

KF16CRS 180005410 7-01

KF16CRVA 180105111 7-02

KF16CRVS 180105411 7-02

KF16EL90A 16031021024 4-13

KF16EL90E 16041021024 4-13

KF16FNPT3 17010215002 5-08

KF16FNPT6 17010215012 5-08

KF16FPT3 17010213002 5-08

KF16FPT6 17010213012 5-08

KF16FVCR13 17010217032 5-05

KF16FVCR6 17010217012 5-05

KF16FX1000 40010551000AA 4-02

KF16FX250 40010550250AA 4-02

KF16FX500 40010550500AA 4-02

KF16FX750 40010550750AA 4-02

KF16FXC100 40310430100AA 4-03

KF16LHNAA 150402091 1-04

KF16LHNSA 150402093 1-04

KF16LHNSE 150602AD3 1-04

KF16M3CRNS 183305411 7-05

KF16M3CRVS 183105411 7-05

KF16MNPT3 17010214002 5-07

KF16MNPT6 17010214012 5-07

KF16MPT3 17010212002 5-07

KF16MPT6 17010212012 5-07

KF16MVCR13 17010216032 5-05

KF16MVCR6 17010216012 5-05

KF16OCRV-316 181105621 7-03

KF16OCRVS 181105421 7-03

KF16OPR 20000541 7-06

KF16QDA12 17010220032 5-09

KF16QDA19 17010220052 5-09


KF16QDA6 17010220012 5-09

KF16RHA 17010218052 5-06

KF16SHNSA 150302093 1-03

KF16SHNSE 150502AD3 1-03

KF16SWA13 17010219032 5-06

KF16SWA6 17010219012 5-06

KF16TA 16151021024 4-13

KF16TE 16161021024 4-13

KF16WS 150902093 1-02

KF16XA 16191021024 4-14

KF16XE 16201021024 4-14

KF20CR25NA 19031B111 7-04

KF20CR25NS 19031B411 7-04

KF20CR25VA 19011B111 7-04

KF20CR25VS 19011B411 7-04

KF25B25 150203113 1-02

KF25BA 150103001 1-01

KF25BFX1000 40210561000AA 4-01

KF25BFX250 40210560250AA 4-01

KF25BFX500 40210560500AA 4-01

KF25BFX750 40210560750AA 4-01

KF25BS 150103003 1-01

KF25CAP 5085DY 1-07

KF25CLA 21010611 1-06

KF25CLA-NP 21010621 1-06

KF25CRA 180006110 7-01

KF25CRNA 180306111 7-02

KF25CRNS 180306411 7-02

KF25CRS 180006410 7-01

KF25CRVA 180106111 7-02

KF25CRVS 180106411 7-02

KF25EL90A 16031031034 4-13

KF25EL90E 16041031034 4-13

KF25FNPT3 17010315002 5-08

KF25FNPT6 17010315012 5-08

KF25FPT3 17010313002 5-08

KF25FPT6 17010313012 5-08

KF25FVCR13 17010317032 5-05

KF25FVCR6 17010317012 5-05

KF25FX1000 40010561000AA 4-02

KF25FX250 40010560250AA 4-02

KF25FX500 40010560500AA 4-02

KF25FX750 40010560750AA 4-02

KF25FXC100 40360440100AA 4-03

KF25LHNAA 150403111 1-04



KF25LHNSA 150403113 1-04

KF25LHNSE 150603AE3 1-04

KF25LHNSJ 150803AF3 1-05

KF25M3CRNS 183306411 7-05

KF25M3CRVS 183106411 7-05

KF25MNPT13 17010314032 5-07

KF25MNPT19 17010314052 5-07

KF25MNPT3 17010314002 5-07

KF25MNPT6 17010314012 5-07

KF25MPT13 17010312032 5-07

KF25MPT19 17010312052 5-07

KF25MPT3 17010312002 5-07

KF25MPT6 17010312012 5-07

KF25MVCR13 17010316032 5-05

KF25MVCR6 17010316012 5-05

KF25OCRV-316 181106621 7-03

KF25OCRVS 181106421 7-03

KF25OPR 20000641 7-06

KF25QDA12 17010320032 5-09

KF25QDA19 17010320052 5-09

KF25QDA25 17010320072 5-09

KF25RA16 17210301052 5-10

KF25RHA 17010318062 5-06

KF25SHNSA 150303113 1-03

KF25SHNSE 150503AE3 1-03

KF25SHNSJ34 150703AE3 1-03

KF25SHNSJ34 150703AF3 1-05

KF25SWA13 17010319032 5-06

KF25SWA6 17010319012 5-06

KF25TA 16151031034 4-13

KF25TE 16161031034 4-13

KF25UT16A 16171031024 4-15

KF25UT16E 16181031024 4-15

KF25WS 150903113 1-02

KF25XA 16191031034 4-14

KF25XE 16201031034 4-14

KF32CR40NA 19031C111 7-04

KF32CR40NS 19031C411 7-04

KF32CR40VA 19011C111 7-04

KF32CR40VS 19011C411 7-04

KF40B38 150205133 1-02

KF40BA 150105001 1-01

KF40BFX1000 40210571000AA 4-01

KF40BFX250 40210570250AA 4-01

KF40BFX500 40210570500AA 4-01


KF40BFX750 40210570750AA 4-01

KF40BS 150105003 1-01

KF40C35A 17010508082 5-02

KF40CAP 5085EJ 1-07

KF40CLA 21010811 1-06

KF40CLA-NP 21010821 1-06

KF40CRA 180008110 7-01

KF40CRNA 180308111 7-02

KF40CRNS 180308411 7-02

KF40CRS 180008410 7-01

KF40CRVA 180108111 7-02

KF40CRVS 180108411 7-02

KF40EL90A 16031051054 4-13

KF40EL90E 16041051054 4-13

KF40FNPT3 17010515002 5-08

KF40FNPT6 17010515012 5-08

KF40FPT3 17010513002 5-08

KF40FPT6 17010513012 5-08

KF40FVCR13 17010517032 5-05

KF40FVCR6 17010517012 5-05

KF40FX1000 40010571000AA 4-02

KF40FX250 40010570250AA 4-02

KF40FX500 40010570500AA 4-02

KF40FX750 40010570750AA 4-02

KF40FXC100 40310450100AA 4-03

KF40LHNAA 150405131 1-04

KF40LHNSA 150405133 1-04

KF40LHNSE 150605AG3 1-04

KF40LHNSJ 150805AH3 1-05

KF40M3CRNS 183308411 7-05

KF40M3CRVS 183108411 7-05

KF40MNPT13 17010514032 5-07

KF40MNPT19 17010514052 5-07

KF40MNPT25 17010514072 5-07

KF40MNPT6 17010514012 5-07

KF40MPT13 17010512032 5-07

KF40MPT19 17010512052 5-07

KF40MPT25 17010512072 5-07

KF40MPT6 17010512012 5-07

KF40MVCR13 17010516032 5-05

KF40MVCR6 17010516012 5-05

KF40OCRV-316 181108621 7-03

KF40OCRVS 181108421 7-03

KF40OPR 20000841 7-06

KF40QDA12 17010520032 5-09


KF40QDA19 17010520052 5-09

KF40QDA25 17010520072 5-09

KF40QDA38 17010520092 5-09

KF40RA16 17210501052 5-10

KF40RA25 17210501072 5-10

KF40RHA 17010518102 5-06

KF40SHNSA 150305133 1-03

KF40SHNSE 150505AG3 1-03

KF40SHNSJ42 150705AG3 1-03

KF40SHNSJ48 150705AH3 1-05

KF40SWA13 17010519032 5-06

KF40SWA6 17010519012 5-06

KF40TA 16151051054 4-13

KF40TE 16161051054 4-13

KF40UT16A 16171051024 4-15

KF40UT16E 16181051024 4-15

KF40UT25A 16171051034 4-15

KF40UT25E 16181051034 4-15

KF40WS 150905133 1-02

KF40XA 16191051054 4-14

KF40XE 16201051054 4-14

KF50B51 150206143 1-02

KF50BA 150106001 1-01

KF50BFX1000 40210581000AA 4-01

KF50BFX250 40210580250AA 4-01

KF50BFX500 40210580500AA 4-01

KF50BFX750 40210580750AA 4-01

KF50BS 150106003 1-01

KF50CAP 5085FD 1-07

KF50CLA 21010911 1-06

KF50CLA-NP 21010921 1-06

KF50CRA 180009110 7-01

KF50CRNA 180309111 7-02

KF50CRNS 180309411 7-02

KF50CRS 180009410 7-01

KF50CRVA 180109111 7-02

KF50CRVS 180109411 7-02

KF50EL90A 16031061064 4-13

KF50EL90E 16041061064 4-13

KF50FNPT3 17010615002 5-08

KF50FNPT6 17010615012 5-08

KF50FPT3 17010613002 5-08

KF50FPT6 17010613012 5-08

KF50FVCR13 17010617032 5-05

KF50FVCR6 17010617012 5-05

10 - 21 10 - 22

-

10 23

INDEX





KF50FX1000 40010581000AA 4-02

KF50FX250 40010580250AA 4-02

KF50FX500 40010580500AA 4-02

KF50FX750 40010580750AA 4-02

KF50FXC100 40310460100AA 4-03

KF50LHNAA 150406141 1-04

KF50LHNSA 150406143 1-04

KF50LHNSE 150606AJ3 1-04

KF50LHNSJ 150806AJ3 1-04

KF50M3CRNS 183309411 7-05

KF50M3CRVS 183109411 7-05

KF50MNPT13 17010614032 5-07

KF50MNPT19 17010614052 5-07

KF50MNPT25 17010614072 5-07

KF50MNPT6 17010614012 5-07

KF50MPT13 17010612032 5-07

KF50MPT19 17010612052 5-07

KF50MPT25 17010612072 5-07

KF50MPT6 17010612012 5-07

KF50MVCR13 17010616032 5-05

KF50MVCR6 17010616012 5-05

KF50OCRV-316 181109621 7-03

KF50OCRVS 181109421 7-03

KF50OPR 20000941 7-06

KF50QDA38 17010620092 5-09

KF50QDA50 17010620122 5-09

KF50RA16 17210601052 5-10

KF50RA25 17210601072 5-10

KF50RA40 17210601092 5-10

KF50RHA 17010618112 5-06

KF50SHNSA 150306143 1-03

KF50SHNSE 150506AJ3 1-03

KF50SHNSJ60 150706AJ3 1-03

KF50SWA13 17010619032 5-06

KF50SWA6 17010619012 5-06

KF50TA 16151061064 4-13

KF50TE 16161061064 4-13

KF50UT16A 16171061024 4-15

KF50UT16E 16181061024 4-15

KF50UT25A 16171061034 4-15

KF50UT25E 16181061034 4-15

KF50UT40A 16171061054 4-15

KF50UT40E 16181061054 4-15

KF50WS 150906143 1-02

KF50XA 16191061064 4-14

KF50XE 16201061064 4-14


KF63B63 150207153 1-02

KF63BA 150107001 1-01

KF63BS 150107003 1-01

KF63M3CRNS 183310411 7-05

KF63M3CRVS 183110411 7-05

KF63WS 150907153 1-02

KF80B76 150208163 1-02

KF80BA 150108001 1-01

KF80BS 150108003 1-01

KF80M3CRNS 183311411 7-05

KF80M3CRVS 183111411 7-05

KF80WS 150908AM3 1-03

KF-NCA 2103A111 1-06

Y

YVB-CR16-M 304109030016 6-44

YVB-CR16-P 304109130016 6-50

YVB-CR35-M 304113030016 6-44

YVB-CR35-P 304113130016 6-50

YVB-CR63-P2 304115230016 6-50

YVB-CU-CR16-M 304609030016 6-47

YVB-CU-CR35-M 304613030016 6-47

YVB-CU-KF16-M 304609010016 6-47

YVB-CU-KF25-M 304611010016 6-47

YVB-CU-KF40-M 304613010016 6-47

YVB-CU-KF50-M 304614010016 6-47

YVB-CU-TE16-M 304609000016 6-47

YVB-CU-TE25-M 304611000016 6-47

YVB-CU-TE40-M 304613000016 6-47

YVB-CU-TE50-M 304614000016 6-47

YVB-KF16-M 304109010016 6-44

YVB-KF16-P 304109110016 6-50

YVB-KF25-M 304111010016 6-44

YVB-KF25-P 304111110016 6-50

YVB-KF40-M 304113010016 6-44

YVB-KF40-P 304113110016 6-50

YVB-KF50-M 304114010016 6-44

YVB-KF50-P 304114110016 6-50

YVBS-CR16-P 304109130216 6-53

YVBS-CR35-P 304113130216 6-53

YVBS-KF16-P 304109110216 6-53

YVBS-KF25-P 304111110216 6-53

YVBS-KF40-P 304113110216 6-53

YVBS-KF50-P 304114110216 6-53

YVBS-TE16-P 304109100216 6-53

YVBS-TE25-P 304111100216 6-53


YVBS-TE40-P 304113100216 6-53

YVBS-TE50-P 304114100216 6-53

YVB-TE16-M 304109000016 6-44

YVB-TE16-P 304109100016 6-50

YVB-TE25-M 304111000016 6-44

YVB-TE25-P 304111100016 6-50

YVB-TE40-M 304113000016 6-44

YVB-TE40-P 304113100016 6-50

YVB-TE50-M 304114000016 6-44

YVB-TE50-P 304114100016 6-50

YVB-TE63-P2 304115200016 6-50

cf-flange series

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
