MULTI-SERVICE SWITCHING & ROUTING SOLUTIONS

MULTI-SERVICE

SWITCHING & ROUTING

SOLUTIONS

PRODUCT GUIDE

Asynchronous Crosspoint Switching

Ethernet MACs

Ethernet Switching

Network Processors

Optical Switching

Packet and Cell Switching Fabrics

Traffic Management

Time Slot Interchange (TSI) Switching

Multi-Service Switching & Routings Solutions

Solutions Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Network Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

SECTION 1

SECTION 2

SECTION 3

SECTION 4

SECTION 5

SECTION 6

SECTION 7

SECTION 8

Asynchronous Crosspoint Switching Products . . . . . . . . . . . . . . . . . . . . .3

•Dual 2x2 2.7 Gb/s Asynchronous Crosspoint Switch (VSC830) . . . . . .3

•68x68 3.2 Gb/s Asynchronous Crosspoint Switch (VSC837) . . . . . . . . .3

•36x36 3.2 Gb/s Asynchronous Crosspoint Switch (VSC838) . . . . . . . . .4

•40x40 3.6 Gb/s Asynchronous Crosspoint Switch (VSC3138) . . . . . . . .4

•72x72 3.6 Gb/s Asynchronous Crosspoint Switch (VSC3139) . . . . . . . .5

•144x144 3.6 Gb/s Asynchronous Crosspoint Switch (VSC3140) . . . . . .5

•Crosspoint Switch System Applications . . . . . . . . . . . . . . . . . . . . . . . . . .6

Ethernet MAC Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

•1x10 Gb Ethernet MAC - Meigs I (VSC7320) . . . . . . . . . . . . . . . . . . . . . . .7

•10x1 Gb Ethernet MAC - Lansing (VSC7322) . . . . . . . . . . . . . . . . . . . . . . .7

•8x10/100 Ethernet MAC - OctalMAC (VSC2800) . . . . . . . . . . . . . . . . . . . .8

•Gigabit & 10 Gigabit Ethernet MAC Applications . . . . . . . . . . . . . . . . . .8

Ethernet Switching Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

•16x10/100/1000 Ethernet Switch - Heathrow-II (VSC7301) . . . . . . . . . . .9

•24x10/100/1000 Ethernet Switch - Stapleford (VSC7303) . . . . . . . . . . .10

•Heathrow II / Stapleford Comparison Chart . . . . . . . . . . . . . . . . . . . . . .11

Network Processor Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

•IQ2000 Programmable Network Processor (VSC2132) . . . . . . . . . . . . .12

•IQ2200 Programmable Network Processor (VSC2232) . . . . . . . . . . . . .13

•Vitesse NPU Developer’s Workbench (VSC2550) . . . . . . . . . . . . . . . . .14

Optical Switching Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

•8x8 All Optical Switch (VOS8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

•64x64 All Optical Switch (VOS64) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Packet and Cell Switching Fabric Products . . . . . . . . . . . . . . . . . . . . . . .17

•CrossStream E (VSC870/882) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

•GigaStream (VSC872/882) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

•TeraStream (VSC871/881) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

•Typical TeraStream Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Traffic Management Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

•OSCAR (VSC2401-25) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

•PaceMaker 2.5 (VSC2400-25) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

•Monitor 4.8 (VSC2450-00) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Time Slot Interchange (TSI) Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

•40 Gb/s STS-1 TSI IC (VSC9182) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

•64x64 STS-48/STM-16 TSI Switch (VSC9185) . . . . . . . . . . . . . . . . . . . . .21

•3024x3024 VT1.5 TSI Switch (VSC9187) . . . . . . . . . . . . . . . . . . . . . . . . . .22

•VT1.5 Pointer Processor/ Column Aligner (VSC9188) . . . . . . . . . . . . . .23

Sales Offices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

About Vitesse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Multi-Service Switching & Routing:

Solutions Overview

A fundamental shift is occuring in the way businesses leverage

networking and communications technology for their competitive

advantage. Recognition, awareness, and proactive steps to

meeting the diverse technology needs of the networking equipment

OEM have long been the focus of Vitesse.

While advances in communications technology have empowered our

industry, those very advances have led to tremendous confusion and

chaos in the marketplace. In the years ahead, we believe that the world

will look back at this time as the one when networking was really invented.

The products presented in this guide are the result of years of industry

focus and best-of-class engineering activities centered around delivering

highly integrated, maximum performance communication ICs. They have

been designed with the Routing and Switching OEM in mind and have

been optimized for interoperability and performance across the Vitesse

product family.

Multi-service systems are defined by Vitesse as common networking

equipment that are required to handle multiple traffic types, such as TDM

voice, ATM cells, and IP packets. In the access portion of the network

these are represented by equipment such as DSLAMs and IADs; in the

metro area network, edge routers and add/drop multiplexers; and within

the core of the network, multi-service switches and core routers. All

share some common requirements that Vitesse addresses through a

family of products. By outlining the high level system requirements of

these equipment types, we can demonstrate where Vitesse products find

their sockets.

We welcome you to explore the world of Vitesse...one Company...providing

solutions to today’s challenges in networking and communications.

Changing Requirements...

Multiple Solutions...

One Company.

OVERVIEW

1

Residential/

Enterprise

Mobile

Internet

via 3G RAN

Enterprise/Campus LAN

FR/ATM/Gb Ethernet

Switches/Routers VPN

Gateway

Residential/SOHO/

Enterprise via xDSL

Cable, Fiber,

Fixed Wireless

TEL.

PC

Access

CL5

Server Farms

Content Caches

Hosted Apps., etc.

PSTN

VoIP

Gateway

SS7

Access

Switch/Router

SoftSwitch

MSPPS, etc

Edge/Metro

Gb/Tb

Router

ATM/MPLS

GbE Switch

Metro Optical

Networks

Core

>200 DWDM

Optical Core

y

Optical

Switch

Tb Router/

Optical Switch

2

NETWORK DIAGRAM

Asynchronous Crosspoint Switching Products

Vitesse’s crosspoint switch family provides the broadest range of switch sizes from dual 2x2 to 144x144 matrices. Innovative features such as Input

Signal Activity Monitoring, Integrated Signal Equalization for deterministic jitter reduction, and small package form factors enable a wide variety

of different solutions such as SONET/SDH, Gigabit Ethernet, Fibre Channel, and HDTV standards.

VSC830

Dual 2x2 2.7 Gb/s Crosspoint Switch

The VSC830 was the industry’s first 2x2 asynchronous crosspoint switch

that supports FEC to 2.7 Gb/s per port. It is designed for critical signal

path control and buffering applications such as loopback, protection

switching and multi-channel backplane drivers/receivers. Signal path

delay is tightly matched between each output channel to eliminate the

need for delay path compensation when switching between signal

sources.

Features:

•50 Ω Source Terminated Output Driver and Programmable

Input Terminations

•PECL Compatible High-Speed I/O

•PECL/TTL Compatible Control Inputs

•Power-Down Mode for Unused Outputs

•Single 3.3 V Supply, 1 W (typ)

•Compact 10 mm x 10 mm 44-Pin PQFP Package

S1, S2

A1

Y1

VSC837

68x68 3.2 Gb/s Crosspoint Switch with Input Signal Activity

Monitoring

Supporting at data rates to 3.2 Gb/s, the VSC837 is a cost-effective member

of the industry’s broadest crosspoint switch family. In addition to

leading edge performance, the VSC837 provides enhanced flexibility with

multiple programming modes, user-selectable input and output termination

configurations, programmable output levels and Input Signal Activity

monitoring to allow in-system diagnostics. A new innovative feature

called Integrated Signal Equalization (ISE) is also included. ISE enhances

the output jitter performance of the VSC837 by compensating for input

jitter due to Inter Symbol Interference (ISI) generated by long, narrow PCB

traces.

Features:

•Input Signal Monitoring (ISA)

•Integrated Signal Equalization (ISE) for Deterministic Jitter Reduction

•Selectable On-Chip I/O Termination

•Hard and Soft Power-Down Modes for Unused Channels

•TTL/2.5 V CMOS Control I/O (3.3 V Tolerant)

•Non-Blocking Architecture with Broadcast and Multi-Cast Capabilities

•Single 2.5 V Supply

•High Performance 37.5 mm 480 TBGA Package

A0

2

2

Y0

A2

Y2

S1, S2

A1

Y1

A67

2

2

Y67

A2

Y2

P Control

ASYNCHRONOUS CROSSPOINT SWITCHING PRODUCTS

3

SECTION ONE

VSC838

3.2 Gb/s 36x36 Crosspoint Switch

Supporting data rates to 3.2 Gb/s, the VSC838 is a cost-effective member

of the industry’s broadest crosspoint switch family. In addition to

leading edge performance, the VSC838 provides enhanced flexibility with

multiple programming modes, user-selectable input and output termination

configurations, programmable output levels and Input Signal Activity

monitoring to allow in-system diagnostics. A new innovative feature

called Integrated Signal Equalization (ISE) is also included. ISE enhances

the output jitter performance of the VSC838 by compensating for input

jitter due to Inter Symbol Interference (ISI) generated by long, narrow PCB

traces.

Features:

•36x37 Switch Matrix

•3.2 Gb/s NRZ Data Bandwidth

•Integrated Signal Equalization (ISE) for Deterministic Jitter Reduction

•Input Signal Activity (ISA) for in System Diagnostics

•Programmable on Chip I/O Termination

•Single 2.5 V Supply

•6 W Typical Power (Low Drive Mode)

– High Performance 37.5mm, 480 TBGA Package

A0

A35

2

2

2

2

Y0

Y35

VSC3138

3.6 Gb/s 40x40 Asynchronous Crosspoint Switch

The VSC3138 is part of Vitesse’s latest crosspoint switch family designed

to carry asynchronous broadband data streams. The fully non-blocking

switch core is programmed through a multi-mode port interface that

allows random access programming of each input/output port. Each

high-speed output is a source-terminated fully differential switched current

driver for maximum signal integrity. Data inputs are self-biasing and

terminated on-die through 100 Ω resistors between true and complement,

facilitating AC-coupling to the switch inputs. Unused channels can

be powered down to allow efficient use of the switch in applications that

require only a subset of the channels. A secondary access port allows

asynchronous readback and configuration control to take place while the

primary programming port is in use.

Features:

•40 Input by 40 Output Crosspoint Switch


•Global and Per-Channel Programmable Input Signal Equalization (ISE)

•On-board PRBS Generator/Detector

•2.5 V / 3.3 V CMOS/TTL Control I/O

•Differential CML Data Output Driver with Programmable Drive Level

•Software Power-Down for Unused Channels

•Secondary Access Port for Configuration and Monitoring

•125 MHz Multi-Mode Program Port

•Multi-Cast and “Striping” Programming Modes

•On-Chip Input and Output Terminations

•Single 2.5 V Supply, 3.3 V Option for Control Port

•4.4 W Typical Power in Nominal Mode

•Integrated Temperature Sensor/Alarm

•High Performance BGA Package with PC Board Layout-Friendly Pinout

P Control

A0

2

2

Y0

A39

2

2

Y39

P Control


4

SECTION ONE

VSC3139





allows random access programming of each input/output port. Each highspeed

output is a source-terminated fully differential switched current

driver for maximum signal integrity. Data inputs are self-biasing and terminated

on-die through 100 Ω resistors between true and complement,

facilitating AC-coupling to the switch inputs. Unused channels can be

powered down to allow efficient use of the switch in applications that




Features:







•Software Power-Down for Unused Channels




•On-Chip Input and Output Terminations


•8 W/10 W Typical Power in Nominal/High-drive Mode

•Integrated Temperature Sensor/Alarm


A0

2

2

Y0

VSC3140





allows random access programming of each input/output port. Each highspeed

output is a source-terminated fully differential switched current

driver for maximum signal integrity. Data inputs are self-biasing and terminated

on-die through 100 Ω resistors between true and complement,

facilitating AC-coupling to the switch inputs. Unused channels can be

powered down to allow efficient use of the switch in applications that




Features:







•Software Power-down for Unused Channels




•On-chip Input and Output Terminations



A0

2

2

Y0

A71

2

2

Y71

A143

2

2

Y143

P Control

P Control


5

SECTION ONE

Using Vitesse Crosspoint Switches: Example Configurations

Rx

Tx

East

SFF

Rx

Tx

A1

A2

Y1

Y2

East Rx

VSC830

Y1

Y2

A1

A2

East Tx

Processing and

Conversion

Functions

Rx

Tx

West

SFF

Rx

Tx

A1 Y1

A2 Y2

VSC830

Y1 A1

Y2 A2

Control

West Rx

West Tx

Physical

Media

Interface

1x/2x

Fibre Channel

Receiver

1x/2x

Fibre Channel

Transmitter

P

Memory

Automatic Protection Switching (APS)

Line Cards

Physical

Media

Interface

1x/2x

Fibre Channel

Receiver

1x/2x

Fibre Channel

Transmitter

VSC837

VSC838

VSC3139

VSC3140

Physical

Media

Interface

1x/2x

Fibre

Channel

Receiver

1x/2x

Fibre

Channel

Transmitter

Backplane

Drivers

VSC7216

VSC7226

Backplane

Drivers

VSC7216

VSC7226

Controller Cards

VSC837

VSC838

VSC3139

VSC3140

Physical

Media

Interface

1x/2x

Fibre Channel

Receiver

1x/2x

Fibre Channel

Transmitter

Power

Supply

Memory

P

VSC837

VSC838

VSC3139

VSC3140

SAN – Switch Application

Power Supply Cards

SAN – Director Application


6

SECTION ONE

Ethernet MAC Family

Vitesse offers an array of superior MAC devices optimized for today's Ethernet customer. To fulfill customer applications ranging from switches and

uplinks to point-to-point embedded applications and server adapters, Vitesse offers Ethernet MAC devices with differentiating factors ranging from line

rate and port count to power and capacity. Today, this product family spans an impressive range from 10 Mb/s and 100 Mb/s to 10 Gigabits per second.

VSC7320 Meigs I

10 Gigabit Ethernet MAC

Features:

•10 Gigabit Ethernet Port with Non-Blocking Wire-Speed Performance

•1024 Kbit Ingress FIFO and 768 Kbit Egress FIFO

•10 Gb/s Operation via XGMII Interface

•CSIX-64 FPGA-Friendly Host Interface

•Advanced Aggregation/Trunking Based on SMAC/DMAC, MPLS and

Preamble Information

•Jumbo Frame Support

•RMON, 802.3 and SNMP Statistics

Targeted at high performance enterprise Ethernet LAN rack-based equipment,

VSC7320 provides 10 Gigabit connectivity for switch/router uplink

applications.

The VSC7320 provides access to one 10 Gigabit full-duplex Ethernet port

(XGMII) through a FPGA/ASIC-Friendly, fully standard-compliant, CSIX

host interface.

On-chip FIFOs capable of handling short-haul flow control are located

between the Ethernet port and the CSIX-64 interface, eliminating the

need for external memory.

The advanced and flexible link aggregation and trunking functionality in

Meigs-I (based on SMAC/DMAC and MPLS labels), allows the 10 GbE

port to behave like ten separate virtual 10/100/1000 Mb/s connections

on the CSIX host interface side.

A comprehensive set of statistics counters are built into VSC7320 and the

design takes into account the latest developments in emerging 10 Gigabit

standard.

Test features include cyclic replay of frames at a user-definable rate -

either generated by the external CPU or captured from incoming traffic.

XGMII

VSC7322 Lansing

10 Port Gigabit Ethernet MAC

Features:

•10 x 1 Gigabit Ethernet Ports with Non-Blocking Wire-Speed

Performance

•1024 Kbit Ingress FIFO and 1024 Kbit Egress FIFO

•Tri-Speed (10/100/1000 Mb/s) Operation via RGMII/RTBI Interface

•CSIX-64 FPGA-Friendly Host Interface

•Advanced Aggregation/Trunking Based on SMAC/DMAC, MPLS and

Preamble Information in Conjunction with VSC7320

•Jumbo Frame Support

•RMON, 802.3 and SNMP Statistics

Targeted at high performance enterprise Ethernet LAN rack-based equipment,

VSC7322 provides Gigabit line card connectivity for switch/router

applications integrating 10 ports for reduced cost.

VSC7322 is an advanced Ethernet MAC chip, allowing a system with a

standard CSIX-64 host interface access to 10 tri-speed (10/100/1000

Mb/s) Ethernet ports.

On-chip FIFOs capable of handling short-haul flow control are located

between the Ethernet port and the CSIX-64 interface, eliminating the

need for external memory.

VSC7322 can be used together with VSC7320 in a flexible port aggregation

or port trunking mode. The scheme can be based on MAC addresses

or MPLS tags.

These features allow a 10 GbE connection to behave like ten separate trispeed

connections, which make integration of 10 GbE into existing

designs simpler.

A comprehensive set of statistics counters supports the RMON 1,

IEEE802.3, and SNMP standards. Test features include cyclic replay of

frames at a user definable rate - either generated by the external CPU or

captured from incoming traffic.

10GbE MAC

RGMII/RTBI

FIFOs

Tri-speed MAC

10 x 1GbE

FIFOs

Dual

MIIM

CSIX-64

Statistics

CPU

Serial I/F

MIIM

CSIX-64

Statistics

CPU

Serial I/F

ETHERNET MAC PRODUCTS

7

SECTION TWO

VSC2800

Octal 10/100 Ethernet MAC for IQ2000 Family NPUs

The VSC2800 OctalMAC is a single chip high-speed packet concentrator

designed to communicate via the FOCUS16 Interface with Vitesse’s

IQ2000 Architecture. The OctalMAC combines high performance packet

transfer features, comprehensive packet-handing capabilities, and automated

statistics gathering for network management support. The

OctalMAC provides a cost effective solution with excellent performance

when used in conjunction with Vitesse’s IQ2000 family processors. The

integrated features of the OctalMAC offload the functions of the Network

Processor while simplifying the design and lowering overall design costs.

Vitesse’s OctalMAC allows the network processor to concentrate on providing

next-generation services such as DissServ and IPSec while delivering

wire-rate performance. The OctalMAC also reduces host processing

requirements by providing automated gathering of RMON and SNMP network

management statistics.

Features:

•8 10/100 Ethernet MAC Ports

•Communicates via the FOCUS16 Interface—a Compact 80 MHz,

16-Bit Dual Unidirectional Interface

•Burst-Oriented Data Streaming

•Standard MII or RMII Connections—Port Selectable

•Statistics Gathering in Hardware

•Jumbo Packet Support

•Control, Statistics and Data Provided over the FOCUS16 Interface

Gigabit and 10 Gigabit Ethernet MAC

Application Examples

CSIX-64

VSC7320

Meigs-1

O/E

10G Ethernet

Application using VSC7320 directly to CSIX switch fabric to create

10G switching connectivity

10x1G

VSC7322

Lansing-1

CSIX-64

VSC7320

Meigs-1

O/E

10G Ethernet

Chipset application using the VSC7320 and VSC7322 back-to-back to

aggregate 10 x 1G into 10G Ethernet

CSIX-64

VSC7322

Lansing-1

VSC7316

Quad PHY

VSC7316

Quad PHY

VSC7316

Quad PHY

10x1G

Application using the VSC7322 and VSC7216 quad Copper-PHYs to

create a gigabit switching line card

FOCUS interface

MII/RMII

Interface (x8)

FCS_TXD (15:0)

FCS_TX_CLK

FCS_TX_REQ

FCS_RXD (15:0)

FCS_RX_CLK

FCS_RX_RDY

FCS_RX_EXTCLK

FOCUS

Transmit

Controller

FOCUS

Receive

Controller

x8

x8

x8

x8

Transmit

FIFO

Transmit

Dataflow

Controller

Receive

Dataflow

Controller

Receive

FIFO

MAC

Control

Sublayer

10/100

Transmit

MAC

TX stats

10/100

Receive

MAC

RX stats

Mlln_TXD (3:0)

Mlln_TX_EN

Mlln_COL

Mlln_TX_CLK

RMll_CLK

Mlln_RXD (3:0)

Mlln_RX_DV

Mlln_RX_ER

Mlln_CRX

Mlln_TX_CLK

x8

x8

x8

JTAG (5)

Scan (2)

SYS_RST_N

JTAG,

Scan,

Reset

Aux Channel

Handler &

Chip Registers

SNMP/RMON

Statistics

Accumulator

Statistics

RAM

Serial

MII

Mgmt.

MDC

MDIO

ETHERNET MAC PRODUCTS

8

SECTION TWO

Ethernet Switching Family

Since developing some of the industry's first commercial Gigabit Ethernet devices over a decade ago, Vitesse has focused on solving the needs

of equipment manufacturers by delivering cost-effective, superior products that exploit the Company's broad system-level expertise and superior

device technologies.

The Vitesse family of Ethernet switching products are no exception to Vitesse's long history of delivering superior devices. In fact, our Ethernet

Switching products lead the industry in price/performance while delivering a robust feature set to the OEM.

Based on an internally developed, high-performance, scaleable architecture, Vitesse switching products are ideal for use in Enterprise, Access,

and Metro networking equipment.

Vitesse's Ethernet Switching product line is targeted at desktop/workgroup LAN connectivity that includes advanced tri-speed (10/100/1000

Mb/s) Ethernet technology.

VSC7301 Heathrow-II

16-Port Gigabit Ethernet Switch

The new 16-port Gigabit Ethernet Switch, Heathrow-II, is designed for

ease of integration and has a modular design that offers a wide range of

potential applications including tri-speed desktop switches, tri-speed

access/aggregation switches, and as backplane or control plane fabric.

This device provides a very high performance, flexible solution that meets

not only today's, but tomorrow’s challenges in networking and communication

technology without the time-to-market constraints, fixed-function

limitations, and short product life cycles usually associated with ASIC

technology. As such, the architecture of Heathrow-II is designed to take

advantage of emerging and future technologies; effectively allowing you

to “future-proof” your switching applications.

Features:

•16 Gigabit Ethernet Ports with Non-Blocking Wire-Speed Performance

•32 Gb/s Internal Switching Bandwidth, 24 Mp(packets)/s Forwarding Rate

•Tri-speed (10/100/1000 Mbit/s) Operation via MII/(R)GMII/(R)TBI

Interface

•4-Wire Low Cost Serial Microcontroller Interface for Unmanaged

Switches

•16-Bit Parallel CPU Interface for SNMP and Web-Based Management

•272 KB On-Chip Frame Buffer

•Programmable Classifier for QoS (Layer 4/Multi-Media)

Targeted at desktop/workgroup LAN connectivity, Heathrow-II offers new

levels of integration and performance for Gigabit Ethernet switch applications.

The Heathrow-II architecture enables both unmanaged and managed

designs using two different CPU interfaces.

protocols such as GxRP, STP, and IPMC. This makes Heathrow-II an ideal

choice for future switch applications.

Heathrow-II provides non-blocking, wire-speed Gigabit performance on

all ports. The switching engine with filtering/forwarding functions and

queuing capabilities eliminates any requirements for external memory

devices in the system design, enabling low cost, high-performance solutions.

The modular design eases integration and offers a wide range of potential

applications including tri-speed desktop switches, access/aggregation

switches, a plane back controller, or as control plane controller.

Additionally, the device is scalable making it possible to build a 16-port

switch using one chip, or a 24-port switch using two chips.

Rx

FIFO

Categorizer

Tx

FIFO

10/100/1000 MAC

Port Block

MII/(R)GMII/

(R)TBI

0 . . . 15

Rx

FIFO

Categorizer

Tx

FIFO

10/100/1000 MAC

Port Block

Frame Bus

MII/(R)GMII/

(R)TBI

Analyzer/Arbiter

CPU Interfaces

MII Management

Intefaces

Control/Status

Registers

PI

MIIM

SI

In addition to the inexpensive serial interface, Heathrow-II features a

high-bandwidth, 16-bit parallel interface to enable web-based or SNMP

management as well as allowing for CPU control over a range of routing

ETHERNET SWITCHING PRODUCTS

9

SECTION THREE

Applications

VSC7303


10

SECTION THREE

Stapleford—High Service 24-Port Gigabit Ethernet Switch

Standalone 16-Port Gigabit Ethernet Switch

This is how simple it is to build an unmanaged 16-port gigabit Ethernet

switch with Heathrow-II:

4-wire

Built using the same extensible technology as Heathrow-II, Stapleford

provides unparalleled price/feature/density in the Ethernet switching silicon

market today.

Features:

8051

Serial I/F VSC7301

Heathrow-II

24-port Single Chip Solution

GMII

•Wire-Speed, Non-Blocking Design

TBI

GMII

•Integrated 400 KB frame buffers (eliminates the need for external memory)

GMII

Automatic Address Learning

Quad Cu

Quad Cu

Quad Cu

Quad Cu

PHY

PHY

PHY

PHY

•Wire Speed

VSC7316 VSC7316 VSC7316 VSC7316

•8 K MAC address table

RMGII/TBI Interfaces Support 10/100/1000 Mb/s Operation

Jumbo Frame Support

The diagram shows a complete 16-port switch with 12 copper ports, and

•Configurable Up to 9 K Bytes

four optical ports that could be used for longer cabling, or uplink purposes.

In this example the low cost 8051 microcontroller is utilized. Typical

Per-Port Bandwidth Policing and Shaping

•Leaky Bucket Based

applications for such a system are Desktop Switches and Access

•0-1 Gb/s Linear Granularity

Switches.

Broadcast Storm Control

•Broadcast and Multi-Cast

Heathrow-II Control Plane Solution

Gigabit Ethernet is also well suited for controlling chassis-based systems.

This is how such a solution could be realized:

Flexible Control Interfaces

•Four-Wire Serial CPU Interface (unmanaged configuration)

•16-Bit parallel CPU Interface (managed configuration)

•MII Management (MIIM) Interface

Optional Control Port

Robust Quality of Service Support

16-bit

•Based on Layer 2-4 Information and IEEE 802.1p Tags

Parallel IF

CPU

VSC7301

Heathrow-II

•802.2 DSAP, UDP/TCP Port ID, 64 DSCPs per Port

IEEE Standard 802.3q VLAN and VMAN Support (Double Tags)

4x TBI

•Full 4K VLAN Table

•Priority-Based VMAN Labeling

Quad

Quad

Quad

Quad

SerDes

SerDes

SerDes

SerDes

VSC7216 VSC7216 VSC7216 VSC7216

Flexible Link Aggregation

•802.3ad

•2-12 Port Link Aggregation Groups (up to 16 ports per group)

Protocols Supported

•Spanning Tree (STP) and MSTP

The use of serial interconnects via the VSC7216 Quad SerDes makes signal

distribution across a chassis simple. The line cards could be fitted

•IGMP Snooping

with the VSC7212 single SerDes. Depending on the CPU used, an optional

Control Port (e.g., Ethernet or RS-232) can be implemented for remote, •LACP (802.3ad), EFM OAM

•GARP, GVRP, GMRP

out-of-band (and, therefore secure) management.

Applications with Stapleford

Comparing Heathrow-II and Stapleford

Quad

PHY

CPU

16-bit

CPU IF

RGMII / RTBI

Quad

PHY

Quad

PHY

VSC7303

Stapleford

Quad

PHY

24-port Tri-Speed GbE Switch Example

Quad

PHY

Managed and unmanaged desktop/workgroup switches

Layer 2 wire-speed non-blocking operation

Fully integrated designs with on-chip memories

Scalability for 16/24/32 GbE ports

Quad

PHY

Features Heathrow-II Stapleford

Number of 10/100/1000M 16 24

Onchip buffer 272 Kbytes 400 Kbytes

Architecture Non-Blocking Non-Blocking

wirespeed wirespeed

MAC interfaces R/G/MII, R/TBI RGMII, RTBI

MAC addresses 4K 8K

Policing/Shaping No Yes (per port)

Jumbo Pkt support No Yes (9Kbytes)

Link aggregation Yes (2 to 8 Port) Yes (2 to 12 Port)

SNMP, RMON stats Yes Yes

Flow control, STP, GxRP, Yes Yes

& IGMP

QoS (Layer 4 classification) Yes (2 Priorities) Yes (2 Priorities)

VMAN support (Double VLAN tag) No Yes

VLAN 4K 4K

Package 680 TBGA 680 TBGA

(40x40mm) (40x40mm)

Power dissipation 6 Watts TBD

Unmanaged solution 8 bit µC (e.g 8051) 8 bit µC (e.g 8051)

Managed solution e.g 8051 or CPU e.g 8051 or CPU


11

SECTION THREE

Network Processors

Change is afoot in the network hardware manufacturing marketplace as demands for very high-speed, service-enabled products eclipse those for

more traditional Layer 2/3 routing and switching offerings. The combination of hardware acceleration needs, direct support for IP services/features,

and demands for longer product life cycles with reduced time-to-market has given birth to the Programmable Network Processor.

Hardware vendors are in need of an "adjunct" processing solution that addresses both current and future challenges in network evolution; successfully

meeting these challenges through standard products is key to maintaining a competitive edge.

The IQ2x00 family of network processors enable innovation by providing a high-performance, flexible solution that meets today's challenges in networking

and communication technology without the time-to-market constraints, fixed function limitations, and short product life cycles associated

with ASIC technology.

IQ2000

Packet Inputs

Features:

•Four Integrated 200 MHz, Fully Programmable, Multi-Context Packet

Processing Engines

•Flexible, High Bandwidth I/O Interface Capability (from DS-0 to OC-48)

•High Performance, Patented Internal Architecture (50 Gb/s)

•Control Plane Processor Independence (native support for MIPS,

PowerPC, and other RISC implementations)

•Specialized Co-Processors for Lookup, Order Management, Multicast

Support, DMA Management, and Context Management

•Optimized Instruction Set for Network Operations

•Per Flow Queuing Support for Up to a Half-Million Flows

•Hardware Support for Quality (QoS) of Service Building Blocks

•Comprehensive Development Tools

•Next-Generation Service Acceleration: MPLS, DiffServ, IPSec,

Provisioning, AAA, Server Load Balancing, and More

IQ2000 Feature and Part Selection Guide

Host

Interface

Standard

CPU

CPU

A

Classification Engines

Order Management

Input Streaming Bus

CPU

B

CPU

C

Output Streaming Bus

Queue Management

Qos Engines

CPU

D

Lookup Bus

SRAM Bus

SRAM

Interface

Rambus

Memory

Controller

RDRAM

IQ2000 Part No.

FOCUS Port Configuration

VSC2100 VSC2102 VSC2132 FOCUS A FOCUS B FOCUS C FOCUS D

• • •

FOCUS 16 FOCUS 16 FOCUS 16 FOCUS 16

• • •

FOCUS 16 FOCUS 16 FOCUS 32

- • •

GigaMAC FOCUS 16 FOCUS 16 FOCUS 16

- • •

GigaMAC FOCUS 16

FOCUS 32

- • •

GigaMAC GigaMAC FOCUS 16 FOCUS 16

-

GigaMAC GigaMAC

FOCUS 32

• •

- - •

FOCUS 32

FOCUS 16 FOCUS 16

- - •

FOCUS 32

FOCUS 32

• = featured configuration - = featured not available

Packet Outputs

(provisioned and forwarded)

IQ2x00 Internal Diagram

Optional

SRAM

* FOCUS C & FOCUS D ports also serve as the CSIX-L1 Interface

NETWORK PROCESSOR PRODUCTS

12

SECTION FOUR

IQ2200

Features:

•Fully Firmware-Compatible and Pin-Compatible with IQ2000

•Double the IQ2000 Performance at Half the Power with Four Fully

Programmable, Multi-Context Packet Processing Engines

•Flexible, High Bandwidth I/O Interface Capability

•High Performance, Patented Internal Architecture (100 Gb/s)

•CSIX-L1 Fabric Interface

•Control Plane Processor Independence (native support for MIPS,

PowerPC, and other)

•RISC Implementations

•Specialized Co-Processors for Lookup, Order Management, Multi-Cast

Support, DMA

•Management and Context Management

•Optimized Instruction Set for Network Operations

•Per-Flow Queuing Support for up to a Half-Million Flows

•Hardware Support for Quality (QoS) of Service Building Blocks

•Comprehensive Development Tools

•Next Generation Service Acceleration: MPLS, DiffServ, IPSec,

Provisioning, AAA

•Server Load Balancing, and More

IQ2200 Feature and Part Selection Guide

IQ2200 Part No. FOCUS Port Configuration

VSC2200 VSC2201 VSC2232 FOCUS A

• • •

• • •

FOCUS 16 FOCAS 16 FOCUS 32

- • •

- • •

GigaMAC FOCAS 16

FOCUS 32

- • •

- • •

GigaMAC GigaMAC

FOCUS 32

- - •

FOCUS 32

- - •

FOCUS 32

FOCUS 32

• = featured configuration - = featured not available

FOCAS B FOCUS C FOCUS D

FOCAS 16 FOCAS 16 FOCAS 16 FOCAS 16

GigaMAC FOCAS 16 FOCAS 16 FOCAS 16

GigaMAC GigaMAC FOCAS 16 FOCAS 16

* FOCUS C & FOCUS D ports also serve as the CSIX-L1 Interface

FOCAS 16 FOCAS 16

Fabric Interface



CSIX/

FOCUS32

FOCUS32

IQ2200

VSC2232

Programmable

Network

Processor

Optical Interface

(up to OC-48)

CSIX/

FOCUS16/32

IQ2200

VSC2202

Programmable

Network

Processor

Gigabit

PHYs

Gigabit

PHYs

CSIX/

FOCUS16/32

FOCUS16

IQ2200

VSC2200

Programmable

Network

Processor

10/100

OC-3 to OC-12

Low Speed Aggregation

FOCUS16

A

g

g

r

e

g

a

t

i

o

n

N

e

t

w

o

r

k

DSL

ATM

DS3

POS

DS3

ATM

OC3

POS

OC3

ATM

OC12

POS

OC12

DS3

Framer

SAR/Framer

SAR/Framer

SAR/Framer

MUX

Data Path

Software

Network

Processor

IP

Control Path

Software

Standard

Processor

Frabric

IQ Family Application

Programmable

Network

Processor

Framer

Programmable

Network

Processor

OC48

POS

B

a

c

k

b

o

n

e

N

e

t

w

o

r

k

IQ2200 Internal Diagram


13

SECTION FOUR

Vitesse NPU Developer's Workbench

Delivering Performance and Flexibility

The Vitesse NPU Developer's workbench is a comprehensive engineering

environment that enables rapid OEM development of communications

systems solutions.

A combined hardware, development tools, and reference software offering,

the Developer's Workbench enables engineers to rapidly develop,

simulate, characterize, and optimize code for the IQ family of intelligent

network processors. This flexible facility provides a robust execution path

for system-level prototyping and greatly accelerates product time-to-market

and increases product time in market.

The Workbench is comprised of highly integrated elements, including:

•The Vitesse NPU Software Development Kit

•The Vitesse NPU MACRO Function Library

•The VISIONS Network Application Software Suite

•The Vitesse NPU Tool Kit of Specialty Networking Algorithms

•The IQ2000 Hardware Development System

•The IQ2200 Hardware Development System

Developers can choose individual elements or the entire offering

depending on their particular product or specialty application needs.

The Vitesse NPU Software Development Kit

The NPU Software Development Kit (SDK) brings together all the tools

and code sources needed to successfully develop applications for the

IQ2000 and IQ2200 families of intelligent network processors.

The SDK includes:

•IQ-C Optimizing Compiler—an open-source C/C++ optimizing

compiler for the IQ family of network processors. Based on a superset

of ANSI 'C', the compiler incorporates language extensions and a set

of specialty intrinsics (built-in functions that do not incur the overhead

of traditional function calls) that take advantage of the IQ-optimized

architecture and support all on-chip hardware acceleration features for

networking operations. To preserve customer investment in assembly

code, an in-line assembly capability is provided to maximize re-use.

•Red Hat GNUPro Tools—standards-based, open-source tools for the IQ

family of network processors. Includes assembler, linker, and binary

utilities.

•The Vitesse Debugger (VDB)—a visual source-level debugger that

supports IQ-based assembly programs and 'C' programs running under

the Vitesse simulation framework, on the Vitesse IQ2x00 family of

Hardware Development Systems, or customer hardware.

•IQ2x00 Simulation Framework (Simumatic)—an open, cycle-based,

data-accurate simulation framework for the IQ2x00 family of network

processors and peripheral devices.

•Simulation Models—comprehensive (end-to-end, not just CPU-centric)

simulation models of the IQ2000, IQ2200, OctalMAC, FOCUS CON-

NECT, and certain partner devices that run under the Simumatic

simulation framework.

•IQ-Traffic – a graphical utility for creating packet traffic to drive the

simulation framework.

•IQ-Audit – a graphical debugging utility for analysis and reporting of

chip buffer state.

•IQ-Sherlock –a graphical, rules-based expert system that analyzes

customer core files, OEM hardware configurations, Vitesse hardware

configurations, and simulation target configurations for common

development mistakes. Significantly reduces OEM debug time while

providing comprehensive advice on solving error conditions as well as

optimizing hardware/software configurations.

•IQ-Profile—a graphical performance profiler that helps developers

locate and correct inefficient NPU code. Supported in simulation, on

Vitesse hardware, and OEM hardware.

•IQ-Example—complete example implementations for Layer-2 and

Layer-3 packet forwarding designed to run on the Vitesse simulation

framework or on Vitesse hardware.


14

SECTION FOUR

The Vitesse NPU MACRO Function Library

The IQ2000 Hardware Development System (HDS)

The Vitesse MACRO function library is an extendable series of virtual

tomes designed to make packet processing easier for the developer.

These highly optimized routines may be referred to for learning purposes

or incorporated directly into OEM applications. Routines implemented in

the MACRO function library include the following:

•Packet Management

•Header Management

•Host Management

•Counter Management

•Queue Management

•Initialization

•Interrupts

•Exception Handling

Flash

PROM

optional

MIPs

Microprocess

or on

Daughter

32 or 64 bit

MIPS SYAD bus

Boot

PROM

RDRA

SRA

Debugger Connection

(Serial Port/10BT Port)

Network

Processor

Gigabit

PHY

Optics

Gigabit

PHY

Optics

FOCUS

Multi-Agent

option

OctalMAC

Network

Processor

OctalMAC

10/100 PHYs

Flash

PROM

RDRA

SRA

Boot

PROM

MIPs

Microprocess

or on

Daughter

32 or 64 bit

MIPS SYAD bus

EVB21002

The VISIONS Network Application Software Suite

Describing individual network processor capabilities in OEM networking

terms has been a difficult task for silicon vendors in the NPU space. The

VISIONS program provides integrated, real-world hardware and software

implementations for customer consumption (either for evaluation and

testing or for incorporation into their product offerings). The VISIONS

packages include specialty hardware, application notes, reference board

schematics, software specifications, code offerings, and independent

test metrics in the following areas:

•IPv4 Routing and Switching With IETF Differentiated Services,

Per-Flow Policing, and Network Address Translation

•IPv4 Routing and Switching With MPLS LER and LSR Functions

(including CR-LDP)

•IPv4 Routing and Switching With L2TP and IPSec VPN Support

The IQ2000 is the one of the hardware components of the Vitesse

Developer's Workbench. The HDS provides a high-performance environment

that enables rapid prototyping and architectural validation of OEM

networking applications. The IQ2000 HDS is powered by a pair of IQ2000

Intelligent Network Processors and comes configured at a 2 GbE x 16

10/100 Ethernet routing switch. Complete specifications or a demonstration

are available from your Vitesse sales associate.

The IQ2200 Hardware Development System

The IQ2200 Hardware Development System is on the cutting edge of

integrated design. Demonstrating the Vitesse PHY to Fabric story like no

other vendor, the IQ2200 HDS comes in a variety of configurations

depending on the evaluation requirements of the OEM. Complete specifications

or a demonstration can be arranged through your Vitesse sales

associate.


15

SECTION FOUR

Optical Switching Products

Enabling the “All-Optical” Network

The demand for the “all-optical” network has created an emerging segment of transport equipment that requires integrated circuits with new and

innovative architectures. Optical components and devices with performance monitoring and forward-error-correction (FEC) are needed for Dense

Wavelength Division Multiplexing (DWDM) transponders and optical cross-connects. For terabit routers, Vitesse has the most highly integrated,

lowest power, space efficient mappers, framers and packet/cell switching fabrics for clear channel data streams and the most efficient use of bandwidth

in the core network. Vitesse is also actively leading the way in creating devices that will support the requirements of emerging standards

in the optical transport network.

VOS8

All-Optical Switch Engine

VOS8 is an 8x8 all-optical non-blocking switch that enables cost-effective,

scalable network architectures in an efficiently packaged case.

Vitesse’s VOS8 is a bit-rate and format-independent switch with one of

the lowest insertion loss ratings (1dB typical) in the 8x8 switch category.

VOS8 incorporates unique real-time active optical alignment circuitry

(Versalign) to compensate for operating environment changes, such as

temperature, humidity and vibrations.

The VOS8 offers fast optical switching in less than 10 ms, necessary for

SONET protection applications. VOS8 also has a wide input signal

dynamic range from -16 dBm to +20 dBm.

As part of the VOS8s management and control capabilities, both data

and control/management functions are integrated into the same connector.

Features:

•All-Optical 8x8 Non-Blocking Switch

•Very Low Insertion Loss (

Packet & Cell Switching Fabric Products

Vitesse has been a pioneer in merchant silicon switch fabric solutions, releasing to production its first family of devices in 1999. Since then, we

have continued to provide customers with the highest performance fabric solutions with exceptional features and price. Vitesse is currently supplying

its third generation of switch fabric products and can provide fabric solutions for enterprise, access, metro and core equipment.

VSC870 & VSC882

CrossStream E Intelligent Switch Fabric

The CrossStream E chipset is a complete high performance synchronous

switch fabric solution composed of the VSC870—a scalable synchronous

serial transceiver, and the VSC882—a 16x16 serial crosspoint

switch. Together, the VSC870 transceiver and the VSC882 switch support

architectures of up to 16 OC-48 ports a with a fully redundant configuration.

The VSC870 transceiver and VSC882 switch are optimized for use in both

distributed-controlled packet-based switching systems (packet mode)

and centrally controlled cell-based switching systems (cell mode). The

VSC870 parallel interface supports automatic packet retransmission,

multicast with retransmission, and camp-on as well as supporting virtual

output queuing structures. The CrossStream E solution can switch either

self-routing, variable length packets or fixed length cells, making the

architecture ideal for applications using IP or ATM.

Features:

•Three Operational Modes: Packet, Cell, and Direct

•High Bandwidth Serial Links (2.125 Gb/s) Minimize Backplane

Complexity

•Word Synchronous Backplane Eliminates Lock Time After Switch

Reconfigurations

•Configurable for Self-Routing of Variable Length Packets or Centrally

Controlled Switching of Fixed Length Cells

•Packet Mode Supports Virtual Output Queues to Maximize Backplane

Utilization

•Packet Mode Supports Multicast with Automatic Recast

•Redundant Serial I/O in Transceiver Supports Redundant Switch Card

•Designed for Fault Isolation and Hot Swap

VSC872 & VSC882

GigaStream Intelligent Switch Fabric

The GigaStream chipset is a high performance, multi-protocol switch

fabric consisting of two integrated circuits: the GigaStream Queuing

Engine (VSC872) and the GigaStream Crossbar Switch (VSC882). Targeted

at both the access and metropolitan markets, GigaStream enables networking

equipment manufacturers to build routing and switching systems

capable of providing a maximum of 80 Gb/s of aggregate user bandwidth

with up to 320 Gb/s of highly available backplane bandwidth.

GigaStream provides support for sophisticated Quality of Service (QoS)

algorithms, distinct handling for both uni-cast and multi-cast traffic, as

well as multi-services.

Features:

•Highly-Integrated, Two-Chip Set

•Aggregate User Bandwidth of up to 80 Gb/s

•Single-Stage Aggregate Backplane Bandwidth of up to 320 Gb/s

•Maximum Port Configurations of Up to 32x32 OC-48 or 64x64 Gigabit

Ethernet

•Flexible N+1 and N+N “Active Redundancy Schemes”

•Integrated Queuing, Central Scheduling and Crossbar Switching

•Sophisticated QoS with Eight Priorities

•Advanced Uni-cast and Multi-Cast Support

•Field Proven, High-Speed 2.644 Gb/s Serial Link Technology

2 x GbE

2 x GbE

PHY

O/E

PHY

O/E

NPU/

TM

NPU/

TM

CSIX

CSIX

VSC872

Queuing

Engine

Primary

Switch Card

VSC882

Fabric

Switch

VSC882

Fabric

Switch

OC 48

OC 48

PHY

O/E

PHY

O/E

NPU/

TM

NPU/

TM

CSIX

CSIX

VSC872

Queuing

Engine

VSC882

Fabric

Switch

VSC882

Fabric

Switch

Typical GigaStream Configuration

Secondary

Switch Card

P ACKET & CELL SWITCHING FABRIC PRODUCTS

17

SECTION SIX

VSC871 & VSC881

TeraStream Intelligent Switch Fabric

The TeraStream product is a third generation Intelligent Switch Fabric

using Vitesse's proven high-speed serial link technology. This product

consists of the VSC871 Queuing Engine and the VSC881 Packet Exchange

Matrix, and supports aggregate user bandwidths of up to 160 Gb/s with

port speeds reaching 10 Gb/s.

The TeraStream chipset integrates advanced queuing and scheduling, a

synchronous serial crossbar, and multiple SerDes in a dual-chip fabric

architecture. Transmission between each line card and one or more

switch cards is conducted entirely in-band via the integrated SerDes. This

results in a high-performance, cost-effective switch fabric with a low

overall chip count to minimize power, design complexity and board space

requirements.

2 x GbE

OC-48

OC-48

2 x GbE

OC-192

CSIX

CSIX

CSIX

CSIX

CSIX

SPI-4.2

Line Card 1

VSC871

Queuing

Engine

VSC871

Queuing

Engine

The TeraStream Packet Exchange Matrix supports 32x32 high-speed, selfclocking

serial links, each operating at a maximum user data rate of 2.5

Gb/s. Multiple chips can be combined to increase the overall port bandwidths

to support dense system configurations such as 64x64 OC-48 and

Line Card N

16x16 OC-192. In addition, the TeraStream switch fabric protects the

Typical TeraStream Application

user’s line card investment with a seamless upgrade option to future

members of the TeraStream family of switch fabrics.

Features:

•Highly-Integrated, Two-Chip Set for Reduced Implementation Cost

•Integrated SerDes

•Single-Stage Aggregate User Bandwidth of Up to 160Gb/s

•2x backplane speedup

•Maximum Configurations of Up to 16x16 OC-192, 64x64 OC-48, or

Any Combination of OC-192/OC-48

•High Availability with Zero Loss of Traffic During Redundant

Switchover

•Field-Proven, High-Speed Serial Link (HSSL) Technology

P ACKET & CELL SWITCHING FABRIC PRODUCTS

18

SECTION SIX

Working

Switch Card

VSC881

Fabric

Switch

VSC881

Fabric

Switch

Protection

Switch Card

Traffic Management Products

VSC2400-30

PaceMaker

The PaceMaker device, with its state of the art Quality of Service (QoS)

features, supports full OC-48 data rate while delivering packet and cell

classification, policing, wire speed AAL5 SAR, a dual leaky bucket

shaper, and an optimum “Earliest Deadline First” (EDF) scheduler that

provides new capabilities in traffic management. The PaceMaker 3.0 also

supports an unrestricted number of multicast leaves, VC merging, and

label swapping.

Driven by the demand for enhanced services for the Internet infrastructure,

PaceMaker 3.0 was developed to provide new QoS and Class of

Service (CoS) capabilities to systems that make up the Internet infrastructure.

Based upon leading research into congestion management theory

and traffic modeling, PaceMaker 3.0 is the first device to address the

immediate problem of QoS for Internet users.

Control Memory

Packet Memory

VSC2401-30

OSCAR

The OC-48 Segmentation and Reassembly (OSCAR) device is a highly integrated

cell and packet processing engine that integrates two of the most

common functions found inside today’s high-speed networking equipment.

OSCAR supports a full OC-48 data rate while delivering packet and cell

classification and policing, as well as wire speed AAL5 SAR functions.

OSCAR delivers flexible policing and packet and cell conversion, according

to industry standards including ATM AAL5.

Features:

•Complete Interworking Capabilities: OSCAR provides complete packet

and cell interworking capabilities for multiservice applications

•AAL5 SAR: Unified Packet and Cell buffer and traffic management

architecture for integrated voice, video and data

Host PCI Interface

RDRAM Interface


Backpressure

Interface

UTOPIA/POS PHY

Interface

Traffic Classifier

Traffic Policer

Traffic

Manager

OC-48

AAL5

SAR

Traffic Shaper

Traffic Scheduler

Label Swapper

UTOPIA/POS PHY

Interface

SRAM Interface SRAM Interface SRAM Interface

Features:

Overview

•OC-48 Throughput

•Manages 256 K Output Queues

•1 M Buffer Shared Memory

Policer

•GCRA-Compliant Dual Leaky Bucket Policer

•Weighted Random Early Discard (WRED)

•Early Packet Discard/Partial Packet Discard

AAL5 SAR

•OC-48 AAL5 SAR Supporting 256 K Sessions

Traffic Management

•Dual Leaky Bucket Shaper

•Per-Session Output Queuing for up to 256 K Sessions

•EDF Scheduler Provides Guaranteed Delay and Rate Services

•Per-Port Backpressure

•Deficit Round Robin (DRR) Scheduler That Supports IP Precedence

Classes

•GFR Service for Cell/Frame/Packet Traffic

Statistics

•Per-Port and Per-Session Statistics Collection

•Statistics Collection for Billing and Monitoring

TRAFFIC MANAGEMENT PRODUCTS

19

SECTION SEVEN

VSC2450-00

Monitor 4.8

The Monitor 4.8 is a single chip device that provides a comprehensive set

of ATM Layer functions. It is a hardwired implementation of the ITU I.610

Operations, Administration, and Maintenance (OAM), I.630 Protection

Switching (PS) and I.371 GCRA Policing specifications and provides support

for 256 K bi-directional independent ATM VCs at an aggregate rate

of OC-48 full duplex.

The Monitor 4.8 provides full support for all 256 K connections for OAM

Fault Management processing (AIS/RDI/CC), Performance Management

(forward and backward cell generation) and ATM Layer Protection

Switching processing (1:1 and 1+1 configurations). A standard GCRA dual

leaky bucket policer (or GFR policer) with Partial Packet discard capability

for non-compliant AAL5 frames is also provided. The Monitor 4.8 maintains

a comprehensive set of per connection/per port statistics and provides

a standard 32-bit PCI CPU interface port for configuration, statistics

gathering and non-intrusive monitoring for any of the OAM/PS cell flows

by the host CPU.

Cell Control Memory

Features:

Overall

•Full Duplex OC-48 Operations, Administration, Maintenance

(OAM) and Protection Switching (PS) Processing

•Source/sink Operations for up to 256 K Bi-Directional Connections

Simultaneously

•Supports VP, VC, VP-to-VC, and VC-to-VP Switching

•Compliant with ITU I.610, I.371 and I.630 Recommendations

Operations, Administration, Maintenance (OAM)

•AIS, RDI, CC Cell Generation Timers

•AIS, RDI, CC Cell Receive Timers

•Performance Management (PM) Forward Monitoring Cell Generate and

Receive Processes

•Loopback Cell Processing

•PM Backward Reporting Cell Generation

•Activation/Deactivation Protocol State Machine

•All OAM Capabilities are Available on a Per-Connection Basis

Protection Switching

•Individual or Group Protection on a Per-Connection Basis

•1+1 and 1:1, Revertive/Non-revertive Architectures

•On-chip Global Priority Logic and APS Cell Generation Process

SRAM Interface

UTOPIA3

Interface

GRCA

Policer


OAM

Ingress

Processor

SRAM Interface

Protection

Switching

Protection

Switching

UTOPIA3

Interface

UTOPIA3

Interface

UTOPIA3

Interface

OAM

Ingress

Processor

Policer

•ITU I.371 Compliant

•Dual Leaky Bucket

•Guaranteed Frame Rate

•Partial Packet Discard for Nonconforming AAL5 Frames

Host PCI Interface


Cell Control Memory

TRAFFIC MANAGEMENT PRODUCTS

20

SECTION SEVEN

Time Slot Interchange (TSI) Switching Products

Vitesse’s Time Slot Interchange devices groom multiple SONET/SDH and PDH tributaries at the STS-1/VC-3 and VT/TU levels. They interface

directly to the Vitesse SONET/SDH and PDH framers, mappers, and pointer processors.

VSC9182

40 Gb/s STS-1 Time Slot Interchange

The VSC9182 is a 64x64 STS-12/STM-4 Time Slot Interchange Switch IC.

A single device provides 40 Gb/s of non-blocking STS-1 connectivity

(768x768 STS-1) with support for concatenated tributaries. All STS-

12/STM-4 inputs and outputs are differential serial signals running at 622

Mb/s for efficiency in switch card and system backplane design.

Backplane BER monitoring and deskew are integrated, and the connection

matrix can be hitlessly reconfigured.

Features:

•64x64 STS-12/STM-4 TSI Switch with Non-Blocking 768x768 STS-1

Switch Matrix

•Supports Both Multi-Cast and Broadcast

•Serial LVDS 622 Mb/s High-Speed Interface with PECL/CML

Compatibility and Retiming

•Integrated Clock Synthesis with a Choice of Two Reference

Frequencies

•LOS Detection, Input Parity Checking and Output Parity Insertion;

Scrambling and Descrambling

•Hitless Reconfiguration of TSI Mapping

SYNCP/N

FOSYNCP/N

RXD[63..0]+/-

SYSCLKP/N

Indexer

STS-12

Backplane

Input

Interfaces

(64)

CKBYP

Clock

Clock

Synthesis

PLL

CKSEL

PLOCK

Data

Control

RSTB

MODE8

PARITYON

SCRMBL

768x768 STS-1

Interconnection Matrix

and Storage

CPU

Interface

D[9:0]

A[10:0]

ALE

CSB

WRB

RDB

CONFIG

INTB

Control

Data

IDDQ1

IDDQ2

STS-12

Backplane

Output

Interfaces

(64)

Test

Interface

TDI

TCK

TMS

TRSTB

TDO

TXD

[63:0]+/

VSC9185

64x64 STS-48/STM-16 TSI Switch Fabric

The VSC9185 is a 64x64 Time Slot Interchange Switch IC supporting STS-

48/STM-16 and STS-12/STM-4 on every input and output independently.

A single device provides 160 G of non-blocking STS-1 connectivity

(3072x3072 STS-1) with support for concatenated tributaries. All inputs

and outputs are differential serial signals running at 2.488 Gb/s or 0.622

Gb/s for flexibility in switch card and system backplane design.

Backplane BER monitoring and deskew are integrated, and the service/protection

connection maps can be manually selected on an individual

output time slot basis or driven by in-band signaling for hardware protection

switching. Path AIS or UNEQ can be optionally inserted into all

3072 outgoing STS-1 tributaries. A standard asynchronous CPU interface

with event interrupts is also supported.

Features:

Interconnection Matrix

•Time and Space Switches any STS-(n) [n=1,3c,12c,48c,192c] Signal of

an Incoming STS-48 into Any Byte Position of Any STS-48 Output

•3072 x 3072 STS-1 Switch Matrix

•Single Stage Non-Blocking Structure of the Switch Allows for

Unrestricted Multi-Cast and Broadcast

•Programmable Service/Protection Map (with Shadow Memory) can

be Manually Selected on an Individual Output Time Slot Basis or

Driven by In-Band Signaling for Hardware Protection Switching

•New Connection Maps Take Effect on the Next Frame Boundary After

User Intervention or In-Band Reconfiguration Signal

Input Backplane Interface

•Serial 2.488 Gb/s and 0.622 Gb/s Differential CML STS-48/STM-16

and STS-12/STM-4 inputs

•Includes Optional Analog Equalization Circuitry for Deterministic Link

Jitter Reduction

•Receives 64 Serial Line Channels Frequency Synchronous and Frame

aligned to within +/-24 Time Slots for STS-48 frames, or +/-12 Time

Slots for STS-12 Frames

•Provides on-chip data recovery de-skewing functionality to Bit align,

Byte align, and Frame-align all incoming signals (within the above

tolerance) to the local clock

•Flags Out-of-Frame (OOF), Loss-of-Signal (LOS), Out-of-Alignment

(OOA), and Parity Errors

•Checks B1 Parity of Incoming Data Versus B1 Byte of Following Frame

•Accumulates received B1 errors over a provisionable sample period

with programmable threshold event

•Inserts Unequipped or AIS When channel is in OOF, LOS, or

Unprovisioned State and Inhibits Alarms

Continued on page 22

TIME SLOT INTERCHANGE SWITCHING PRODUCTS

21

SECTION EIGHT

VSC9185—64x64 STS-48/STM-16 TSI Switch Fabric

VSC9187

(continued from page 21)

•Optionally descrambles Incoming SONET data using one of two

Polynomials

•Monitors the received TOH bytes from a single row-column location

across all input channels

Output Backplane Interface

•Serial 2.488 Gb/s and 0.622 Gb/s Differential CML STS-48/STM-16 and

STS-12/STM-4 Outputs

•Optionally Pre-Emphasizes Electrical Signals for Deterministic Link

Jitter Reduction

•Optionally Inserts Byte-Interleaved Parity into B1 Byte of Following

Frame

•Originates In-Band Messages to Port Cards for Switching Purposes

•Optionally Scrambles Outgoing SONET Data Using One of Two

Polynomials

•Optionally inserts AIS or UNEQ on a Per-Channel, Per-Time Slot Basis

In-Band Signaling and Hardware Protection Switching

•Observes In-Band Alarm-Status (ASB) Bytes and Performs Hardware

Comparison

•Uses Result of Hardware Comparison to Drive Selection of

Service/Protection Connection Map

•Provides True Hardware Support for 1+1 Protection Switching

•Utilizes ASB Byte Generation Capabilities of VSC9186 10G Pointer

Processor and Frame Aligner

CPU Interface

•Generic Microprocessor (CPU) Interface Used for Device Configuration

and Status Checking

•16-Bit Data Bus and 16-Bit Address Bus

•Interrupt Output Pin to Signals Status Changes of Internal Alarms

•Flexible Interrupt Masking Features

•Eight Provisionable GPIO

Test Interface

•IEEE P1149.1 Test Access Port Controls External Boundary Scan

LEG_DI_S[5:0]

RefSyncl P/N

TEMPANODE

Sync

RefSyncO P/N

LEG_RCLK_S

Manager

TEMPCATHODE

TDM

MUX

LEG_RSYN_S

Auto

Protection

TSI_SW

Switch

9 x 622Mb/s

STS-12

Mode_622

STS_DI_[8:0] Serial

Backplane

ACC_Mode Input

Inputs

Data Interconnection

Output

Backplane

Data

(Service)

RxD[63:0]P/N

Matrix and

Backplane

Interfaces

TxD[63.0]P/N

Storage

Interfaces

(64)

(64)

RstN

IScE

LEG_DI_P[5:0]

TriStatE N

TDI

LEG_RCLK_P TDM

SysClkS P/N

TCK

MUX

LEG_RSYN_P

SysClkP P/N

Clock

CPU

Synthesis

JTAG TMS

TestClk1 P/N

Interface

PLL

TRSTN

TestClk2 P/N

TDO

9 x 622Mb/s

STS-12

STS_DI_[17:9] Serial

Backplane

Inputs

(Protection)


22

SECTION EIGHT

PIIByp

ClkSel[1:0]

PLock

D[15:0]

A[15:0]

GPIO[7:0]

Intrpt N

DIAck_Rdy N

CSN

CI_Mode[2:0]

CiClk

AS_ALE N

DS_WR N

RD_RW N

CICDI

CIRDO

PMTick

MemBIST

SHORT

The VSC9187 is a VT1.5 Time Slot Interchange (TSI) device. It provides

a fully non-blocking connect cross for 3024 VT1.5’s that are all frequency,

phase and column aligned in addition to a pre-grooming 2:1 UPSR

selection.

The device receives 9 x 622 Mb/s STS-12 working and protection backplane

inputs and performs all necessary functions to retime and align

these signals from the backplane. VT1.5 tributaries are then pre-selected

with a hardware 2:1 UPSR switch from the working and protection timeslot

with programmable holdover and pre-hold switch timers. The results

of the 2:1 hardware selection are then made available to an internal

3024x3024 VT1.5 non-blocking grooming switch, allowing a 5G UPSR

ring to be terminated. Alternatively, the nine protection STS-12 backplane

inputs can remain unused and the VSC9187 can act as a 5 G VT1.5

switch. Output STS-1 delay management following the crossconnect

allows the VSC9187 to be used in subtended switch applications with

large scale STS-1 crossconnects such as the VSC9182 40G STS-1 TSI.

Features:

• (5 G) Non-Blocking VT1.5 TSI, 6048x6048 (10 G) VT1.5 TSI with 2:1

UPSR Input Pre-Selection

•2 x 9 x 622 Mb/s STS-12 LVDS Backplane Inputs with Integrated

Retiming and Alignment

•Working and Protection 2 x 9 x 622 Mb/s STS-12 LVDS Outputs

•Supports 2:1 Hardware VT1.5 UPSR Selection When Used in

Conjunction With VSC9188 VT1.5 Pointer Processor and Column Aligner

•6 Service and 6 Protection STS-1-Like Serial 51.84 Mb/s Interfaces for

Local Drop Interfaces

•Integrated STS-1 Frame Delay Management on Output for Use in

Subtended STS-1 Switch Fabrics

•Compliant with SONET Requirements as Stated in ANSI T1.105 and

Bellcore GR-253-CORE

•Facillitates Hardware-Based UPSR Switching in Accordance with

Telcordia GR-1400-CORE

•Thermally-Enhanced 360 CCGA Package

•2.5 V / 1.8 V Power Supply; 0.18µm Technology

•IEEE P1149.1 Test Access Port

[8]

MUX

[7:0]

LASB Extraction

[8:0]

LASB

Low-Order Alarm Status Byte (LASB)

Inserted by VSC9188

(contains VTI.5 PM summary)

[17]

JTAG Interface

MUX

[16:9]

[17:9]

LASB

VT1.5 Hardware UPSR Selection

(Manual or LASB-based)

System Interface and PLL

3024 x 3024 VT1.5 TSI

HS-CLK LS-CLK SYNC M-SYNC

CLKREF

LASB Extraction

SYNCREF

STS-1 A1/A2 Output Delay Mgmt (H1/H2)

[8:0]

[8:0]

CPU Interface

TDM

DEMUX

GPO[7:0]

GPI[7:0]

INTB

RSTB

RDB

WRB

CSB

ALE

A[15:0]

D[7:0]

CPU_CLK

LEG_DO_S[5:0]

LEG_TCLK_S

LEG_TSYN_S

9 x 622Mb/s

STS-12

Serial STS_DO_[8:0]

Backplane

Inputs

(Service)

TDM

DEMUX

LEG_DO_P[5:0]

LEG_TCLK_P

LEG_TSYN_P

9 x 622Mb/s

STS-12

Serial STS_DO_[17:9]

Backplane

Outputs

(Protection)

VSC9188

The VSC9188 is a VT1.5 Pointer Processor and Column Aligner, which provides

column alignment and the VSC9188 is a VT1.5 Pointer Processor

and Column Aligner. The primary application for this device is to provide

column alignment and performance monitoring for VT1.5 payloads and

interface these tributaries to a large-scale VT1.5 crossconnect. The

VSC9188 receives four serial STS-12 622 Mb/s signals from a VSC9186

10 G Pointer Processor or VSC9182 STS-1 grooming crossconnect. These

signals are terminated at the path level, monitored at the VT1.5 level, and

column-aligned at the VT1.5 level in a deterministic fashion to a local

SYNC signal. GR-1400 UPSR performance information is aggregated and

placed in the VT overhead for use in the VT crossconnect. The four

processed serial STS-12 622 Mb/s signals are duplicated on working and

protection STS-12 622 Mb/s outputs for fan-out to protected VT fabrics.

Four serial STS-12 622 Mb/s signals are received from the switch and the

Path Overhead (POH) is reconstructed prior to transmission. Various loopback

and test modes are also available.

DL12I[3:0]

Line Side Backplane

Rx Direction

4x622Mb/s

STS-12

Serial

Backplane

Inputs

STS-1 Pointer

Interpreter

STS-1 Path

Overhead

Monitoring

M-SYNC

VT Pointer

Processor and

Column Aligner

VT1.5 Path

Overhead

Monitoring

FEBE & RDI

Alarm

Status

Byte

Insertion

Switch

Loopback

Switch Side Backplane

4x622Mb/s

STS-12

DL12O[3:0] Serial

Backplane

Outputs

4x622Mb/s

STS-12

Serial

Backplane

Inputs

DS12I[3:0]

STS-12 Line

Loopback

VT PP

Loopback

HS-CLK LS-CLK SYNC M-SYNC

JTAG Interface

System Interface and PLL

CPU Interface

TDO

TDI

TCK

TMS

TRSTB

CLKREF

SYNCREF

TRIST

PLLBYP

ISCEN

SHORT

RTSN

CIRDO

CICDI

RD_RWN

DS_WR

AS_ALE

CICLK

CI_MODE[1:0]

CS

DTACK_RDY

INTRPT

A[15:0]

D[7:0]

GPO[7:0]

GPI[7:0]

GR-1400 UPSR

Performance

Information

VSC9188

(2)

4x622Mb/s DS12O[3:0]

STS-12

Serial

Backplane

Outputs DS12O[3:0]

Tx Direction

Features:

•Bi-Directional 2.5G VT1.5 Pointer Processor, Path Terminator and

Column Aligner

•VT1.5 Pointer Processing on 4 x 336 VT1.5 Groups Within 4 x STS-12

Backplane Signals

•Path Termination and Generation of STS-1 Traffic

•4 x 622 Mb/s STS-12 LVDS Backplane Interface Inputs With

Integrated CDR and Realignment

•Two 4 x 622 Mb/s STS-12 LVDS Backplane Interface Outputs for

Working and Protection Fan-out

•Interfaces With VSC9186 10G Pointer Processor and VSC9187

3024 x 3024 VT1.5 TSI

•Generates In-Band VT Signaling of UPSR Performance Monitoring

Information for Hardware-based Protection Switching in VSC9187

3024 x 3024 VT1.5 TSI

•2.5 V/1.8 V Power Supply, 0.18µm Technology

•Compliant with SONET Requirements as Stated in ANSI T1.105 and


•Facilitates Hardware-Based UPSR Switching in Accordance with


•Provides JTAG TAP Controller Conforming to the IEEE 1149.1 Standard

•Thermally-Enhanced 552-pin CCGA Package Switch Side Backplane

STS-1 Path

Overhead

Insertion


23

SECTION EIGHT

Sales Offices

Vitesse corporate headquarters is located in Camarillo,

California, USA. Please contact any of our offices for additional

information or visit our website at www.vitesse.com.

Sales Headquarters

Vitesse

741 Calle Plano

Camarillo, CA 93012

TEL: (805) 388-3700

FAX: (805) 987-5896

Richard Riker, Vice President Sales & Marketing

Email: rriker@vitesse.com

Worldwide Channel & Partner Sales

Vitesse



TEL: (805) 388-3700

FAX: (805) 987-5896

Phil Richards, Vice President Channel & Partner Sales

Email: philr@vitesse.com

Customer Service

Vitesse



TEL: (805) 388-3700

FAX: (805) 987-5896

Cozy Darby, Director of Customer Service

Email: darby@vitesse.com

US National Sales Office

Vitesse

488 Schooley’s Mt. Road

Hasting’s Commons, Bldg. 1B

Hackettstown, NJ 07840

TEL: (908) 979-0990

FAX: (908) 979-0992

Mike Logan, Vice President of Sales

Email: logan@vitesse.com

Western Vitesse Sales Office

Vitesse

55 Vista Montana

San Jose, CA 95134

TEL: (408) 474-4070

FAX: (408) 888-7380

Burt Hadlock, Western Area Sales Director

Email: hadlock@vitesse.com

Southwest Regional Sales Office

Vitesse

5655 Lindero Canyon Road, Suite 521

Westlake Village, CA 91362

TEL: (818) 889-3145

FAX: (818) 889-3151

Ryan McCaskill, Field Sales Engineer

Email: ryanm@vitesse.com

North Central Regional Sales Office

Vitesse

2300 N. Barrington Road. Suite 400

Hoffman Estates, IL 60195

TEL: (847) 490-8425

FAX: (847) 884-9423

Mike Hansen, District Sales Manager

Email: mhansen@vitesse.com

Central Regional Sales Office

Vitesse

997 Hampshire Lane, Suite 200

Richardson, TX 75080

TEL: (972) 669-9797

FAX: (972) 669-2266

Jerry Quam, Regional Sales Manager

Email: quam@vitesse.com

Southeast & Mid-Atlantic Regional Sales Office

Vitesse

1000-G Perimeter Park Drive

Morrisville, NC 27560

TEL: (919) 465-2100

FAX: (919) 465-2171

Brian Thorpe, Regional Sales Manager

Email: briant@vitesse.com

Northeast Regional Sales Office

Vitesse

161 Worcester Road, Suite 401

Framingham, MA 01701

TEL: (508) 628-0501

FAX: (508) 628-0504

Shawn Fennelly, Regional Sales Manager

Email: shawnf@vitesse.com

International Sales Offices

Vitesse GmbH & Co. KG

Borussiastrasse 112

D-44149 Dortmund, Germany

TEL: +49-231-6560145

FAX: +49-231-6560199

Siegmar Hausberger, EMEA Sales Director

Email: siegmarh@vitesse.com

Vitesse A/S

Hoerkaer 16-18

DK-2730 Herlev, Denmark

TEL: +45-4485-5958

FAX: +45-4485-5909

Lars Haagh,

Northern European Sales Manager

Email: lha@vitesse.com

Vitesse GmbH

Altstadt 296

D-84028 Landshut, Germany

TEL: +49-871-966-3344

FAX: +49-871-966-3343

Hermann Helmbold,

Eastern European Sales Manager

Email: hermannh@vitesse.com

Asia-Pacific Vitesse Sales Office

39/F, Tower 1 Pacific Place

Queensway, Hong Kong

TEL: +852-2273-5132

FAX: +852-2273-5999

Mitchell Tang, Sales Director of Asia-Pacific

Email: mtang@vitesse.com

China Vitesse Sales Office

Room 9C, 9F, NEPTUNUS Bldg

Nan You Road, Nan Shen Qu

Shen Zhen 518054, P.R. China

TEL: +86-755-664-3119

FAX: +86-755-664-3117

Heng Zeng, District Sales Manager-China

Email: zeng@vitesse.com

Japan Vitesse Sales Office

Mitsugi Kotobuki-cho, Bldg 7F

1-1-3, Kotobuki-cho, Fuchu

Tokyo 185-0056 Japan

TEL: +81-42-336-6133

FAX: +81-42-354-1205

Yuzo Tsukui, Sales Director - Japan

Email: yuzo@vitesse.com

SALES OFFICES

24

Hiroshi Hayashida,

Regional Sales Manager-Japan

Email: hiroshi@vitesse.com

About Vitesse

Vitesse Semiconductor Corporation is a leading designer and supplier

of innovative, high-performance integrated circuits (ICs) and optical

modules used in next generation networking and optical communications

equipment. The Company's products address the needs of

Enterprise, Access, Metro, Core, and Optical Transport network equipment

manufacturers who demand a robust combination of high-speed,

high-service delivery and low-power dissipation in their products. In

concert with its broad communications product portfolio, Vitesse also

develops ICs for storage area networking and enclosure management.

Vitesse is headquartered in Camarillo, California, and operates two

fabrication facilities; one in Camarillo and one in Colorado Springs,

Colorado.

Company and product information is available by calling

1-800-VITESSE or on the web at www.vitesse.com.

Trademarks

Vitesse, ASIC-Friendly, FibreTimer, TimeStream and Snoop Loop are trademarks of Vitesse Semiconductor

Corporation. All other products or service names used in this publication are for identification purposes only,

and may be trademarks or registered trademarks of their respective companies. All other trademarks or registered

trademarks mentioned herein are the property of their respective holders.

©2002 Vitesse Semiconductor Corporation

Vitesse Semiconductor Corporation

741 Calle Plano, Camarillo, CA 93012

tel: 805.388.3700

fax: 805. 987.5896

www.vitesse.com

MULTI-SERVICE SWITCHING & ROUTING SOLUTIONS

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
