Figure 1.3. Illustration of how integration of density logs (upper figure) can be used to estimate
overburden stress at depth (center figure) or overburden stress gradient (lower figure). Variability of
the density logs, as well as the fact that they are often not obtained over the total depth of interest,
leads to uncertainty in the calculated overburden (see text).
