CAN A LINER
CHANGE
YOUR
BUSINESS
FOR GOOD?

Change your business for good
Can sustainability, savings and better product quality coexist?
How much extra profit would 10 % increase
in labelling productivity mean for your business?
What does 20% fewer reel changes mean in money?
All of those questions – and many more
– are answered on these pages.
Can you afford not to switch to
ProLiner PP30?
Is somebody willing to pay for your waste?
Who reaps the benefits of this ”thinnovation”?
ProLiner PP30 Benefits
• Improved productivity
• Fewer web breaks and
reduction of downtime
• Dense looking print effect
• Lower total applied cost
• Easy to recycle
2

Why is ProLiner PP30
a real game-changer in paper labelling?
As one of the leading companies UPM
Rafl atac has always considered its
responsibility to be quick and effi cient
in responding to the changing demands
in the market place. At the core of our
strategy across the businesses is product
renewal and innovation.
In the Paper Business we actively
seek solutions that support our customers’
and end-users’ business processes.
We have a strong commitment to the
sustainability initiatives which run in
parallel with our development and innovation
work. Guided by these principles,
we created the pioneering ProLiner PP30
liner solution.
Functionality and
sustainability combined
The development of ProLiner PP30 was
our response to the signals we received
from our customers. They sent us a clear
message with two key points: Firstly, to
fi nd solutions to improve the functional
aspects of label making. And secondly,
to fi nd a way to advance the development
of sustainable solutions in the
labelling business. ProLiner PP30 meets
both of these demands.
Filmic liners have been in the marketplace
for many years, but now we feel
that we have introduced a new solution
that will provide the standardized, high
volume paper business with a groundbreaking
functional and econo mical solution
in the area of fi lmic liners.
Benefits for the whole value chain
ProLiner PP30 has many benefi ts for
printers, packers and end-users. They
include features such as productivity
improvements, lower logistics costs and
recycling benefi ts, to mention a few.
We have good proof from companies
who have moved to ProLiner PP30 that
the benefi ts are tangible and feasible.
We invite you to visit our website at
www.upmraflatac.com/proliner where
you can discover the printing, packing,
logistics and recycling benefits
of ProLiner PP30. And while you’re
there, it pays to visit our Productivity
Calculator simulator that allows you to
explore the estimated savings you could
get by switching to ProLiner PP30.
The proof is already out there
The introduction of ProLiner PP30 took
place in Labelexpo Europe in the autumn
of 2009 and it was immediately received
with enthusiasm among the printers. We
already have signifi cant number of customers
developing this solution with their
customers and we see that this process
will continue to further strengthen in the
months to come. In the not so distant
future, we anticipate that ProLiner PP30
will become the de facto second industry
standard for the choice of liner in
standard paper business.
ProLiner PP30 is available on a wide
range of our most popular face materials.
It is available from the service terminals
throughout Asia Pacifi c local sales force
and marketing team will be glad to give
you additional information on the opportunities
ProLiner PP30 may provide. We
hope that you will take this opportu nity
for the change in the industry and join
the liner revolution in paper labelling
with ProLiner PP30!
ProLiner PP30 is the only cost-effective alternative for highvolume
paper faces, that will create extra raw material
capacity to improve the security of supply.
Nasuf Culha, Product Marketing Director, Asia Pacific
3

Why does
ProLiner PP30
give you a real
competitive
edge?
A common theme that we hear during
discussions with our customers is just how
competitive the market has become and
how they are planning to be competitive
in the years to come. Most customers want
a strong competitive advantage as they
look to deliver the perfect balance between
quality and costs. Traditionally low cost has
meant low quality, high costs higher quality
– the struggle these days is to try to deliver
enough quality for the demanded price.
Environmental issues are a must, but who
wants to pay more?
4

The innovative ProLiner PP30 will bring added value to
customers and help better position themselves among
competitors. Similar in Europe we strongly believe
customers in the Asia Pacific region will enjoy the many
benefits of ProLiner PP30.
Ma Changbao, Sales & Marketing Director, China
As with all industries there are leaders
and there are followers. Innovation is a
key characteristic of leading printers and
this innovation often carries rewards as
end-users select their preferred suppliers.
Technological leaps and game
changers are commonplace in younger
industries or niche areas, but what about
big volume pressure sensitive paper
labels?
Combining better quality, higher
productivity and easier recyclability
ProLiner PP30 is a real game changer in
labelling. It gives you a new alternative
to traditional glassine liners. It offers you
the sought-after combination of quality
benefi ts, lower total applied cost and
recyclability.
No fibre dust, excellent print
registration for a clear difference
In terms of print quality ProLiner PP30
is much cleaner on press than any paper
liner because it contains no fi bres,
which means no fi bre dust. Combining
this with the smoother adhesive layer
means not only more precise adhesive
side printing, but also a more dense
looking print effect. Added excellent
print registration and the improved
print quality compared to HG65 liner
is visible. Therefore ProLiner PP30 is the
new choice for quality minded printers.
Reduced downtime, better
productivity, lower total applied cost
Improved productivity and savings are
result of ProLiner PP30 fi lm coils being
around 20 per cent longer at the same
reel diameter than HG65 coils. It means
signifi cant reductions in downtime.
The thinner ProLiner PP30 means that
the reels can be up to as much as
6000 running metres long translating
into fewer reel changes, and to cost
savings. What’s more, the even thickness
means it is easy to die-cut. Because
ProLiner PP30 is about 20% lighter than
HG65, customers will save a roughly
corresponding percentage in their packaging
material, warehouse space and
transportation costs.
Mr Neil Fedorowycz, Director of
the Prime business segment at UPM
Rafl atac, emphasises, “Packaging and
printing machines are very expensive, so
lost time is lost money. ProLiner PP30 is
more robust than glassine, which means
fewer web breaks and a reduction of
downtime.” Furthermore, reduced risk of
web breaks means that the speed of dispensing
can often be increased, offering
even greater effi ciency. Depending on
the packed product, label design,
printing machine and labelling
line, the fi nancial benefi ts will vary.
However, according to our experience
in all cases the total applied
cost with ProLiner PP30 is lower.”
Productivity Calculator
shows the difference
To help customers get a more accurate
picture of the productivity gains
Productivity Calculator
can be found at
www.upmraflatac.com/pp30
5

ProLiner PP30 shall decisevly increase productivity at label
printing and application. Its positive recyling value is a great
relief to the industry
Shailesh Nema, Sales & Marketing Director, South Asia
they can achieve throughout the entire
chain with ProLiner PP30, UPM Rafl atac
has come up with an online Productivity
Calculator for Packers. This handy tool
allows clients to enter details of the
packing line process (such as labels per
reel, speed of applicator, time lost per
reel change, cost of downtime etc), and
see the difference it makes to switch
from HG65 to ProLiner PP30.
Mr Fedorowycz explains how this
process helps to highlight the benefi ts
of ProLiner PP30: “It is important for
the client to see the total cost of ProLiner
PP30 and glassine through the entire
process rather than simply looking at
the square metre price – because price
is not the total cost. For example, when
buying a car you don’t only think of the
purchase price but also how much fuel
it will consume, how long it will run,
service costs and resale value. Our sales
people are happy to explore the benefi
ts with each one of our customers.”
Recycling for profit
ProLiner PP30 is also the smart alternative
when it comes to recyclability, as
Mr Fedorowycz explains: “ProLiner
PP30 is easy and less energy-consuming
to recycle than a PET liner. There are
a greater number of PP recyclers across
Asia and many end-use areas for products
made of recycled PP.
ProLiner PP30 is the next
generation liner – available now!
Although fi lmic liners have been on
the market for a number of years for
premium applications such as beverage
and personal care labelling, they have
not, until now, been available as big
volume paper labels. This was mainly
owing to issues of price and economies
of scale. UPM Rafl atac’s recent investment
in new coating technology has allowed
it to develop a fi lmic liner that can
be used with volume paper products.
Right from the start most printers
and packers were of the opinion that
ProLiner PP30 had major benefi ts.
Mr Jon Lenck, Director of the VIP
business segment at UPM Rafl atac, comments
“We are now in the process of
introducing the benefi ts with our customers
along the whole chain, including
packers. We are already working on
signifi cant number of customer projects
and as you might expect, most of this
work is with the leading innovative
printers. We feel the interest in ProLiner
PP30 will increase signifi cantly over
the next year as growing numbers of
printers and packers become aware
of the productivity benefi ts it can bring
to their businesses.”
Mr Lenck concludes: “Our key target
for the next few years is to position
ProLiner PP30 in the market as the next
generation liner for standard paper
faces to compliment our glassine liners.”
6

What has our R&D
experienced
with ProLiner PP30?
THE OUTSIDE DIAMETER OF 6,000m ROLLS
0,925
0
Rafl acoat Plus
RH09
ProLiner PP30
1,016
Rafl acoat Plus
RH09
HG65
Although ProLiner PP30 is very thin
(30 microns) it provides a very robust
die-cutting platform for label converting.
The even thickness profi le combined with
stable release profi les makes label converting
easy. Naturally the converter has
to have die-cutting tools that are optimized
for this liner thickness. We have
witnessed real-life cases, where the
converter has been able to increase
the press speed remarkably compared
to using a standard paper liner. This
benefi t has been obvious in cases where
the label design is demanding when it
comes to matrix stripping. The result is improved
productivity of the printing press.
A signifi cant benefi t is also the more
dense printing result which is achieved
thanks to a smoother adhesive layer.
Lower weight, less roll
changes, register control
Handling rolls with ProLiner PP30 backing
is easier due to the lower weight of the
coil at the same length as with a paper
liner. When the standard diameter is
kept, the advantage is around 20 per
cent greater length, reducing the number
of roll changes in the press.
Another very important feature we
have seen in practise, is excellent register
control with ProLiner PP30. In the printing
press after changing the coil in the rewinder,
we have noted that ProLiner PP30 returns
to the set print register very quickly
compared to a paper liner. This cuts
down print waste dramatically.
Reduced web breaks in
demanding labelling conditions
As it is a fi lmic material, ProLiner PP30 is
inert to environmental changes (e.g. moisture
conditions), thus remaining constant in
all conditions. This feature reduces web
breaks during dispensing and thus minimizes
down time of the lines. This adds up to
improved effi ciency. It is also possible to increase
the line speed due to the decreased
risk of web breaks.
This provides clear benefi ts for example
in the Food application area, where labelling
conditions can be extremely demanding.
Labelling lines are often located in
conditions where excessive moisture, even
spraying water, can be a reality. Thanks
to its robustness ProLiner PP30 is a reliable
choice in tough conditions.
With ProLiner PP30’s unique and reliable properties, it’s
not surprising that it has already caught the attention of
customers and end users.
Junion Zhao, Product Manager, China
7

OBSERVATIONS AND LEARNINGS
FROM CONVERTING TEST RUNS
How does
ProLiner PP30 perform
in converting?
Since its launch we have gathered a lot
of experience from the convertability of
ProLiner PP30 in numerous tests. The following
are some observations from tests and
trials, which prove that ProLiner PP30 has
many advantages also in the converting
phase.
Easy to run on press
We compared ProLiner PP30 to Honey
Glassine 65 with Rafl acoat Plus on Gidue
press and Flint Group’s UV-fl exo colors.
It was surprising how easy ProLiner PP30
was to run on the press. We tried it out
with two different kinds of jobs: Firstly,
with a boot shaped label for detergent
bottle with 5 colors and an over-varnish.
Secondly, with relatively simple square
labels with 3 colors and an over-varnish.
In both cases we fi rst ran a Honey Glassine
65 and then changed to ProLiner PP30.
No issues with web tension on press
What did we notice? We didn’t have any
issues with web tension control. We ran the
materials fi rst at low speeds and then accelerated
the speed from 30 to 120m/min.
Then we made sudden stops but managed
easily to keep ProLiner PP30 coils in
good shape at the rewinder.
The maximum speeds were the
same as with the paper backing and
we even ran the boot shaped labels
with higher speeds than with the paper
backing equivalent. Waste matrix from
both constructions was taken at a 90
degree angle and with the same web
path confi guration. The run was smooth
with no matrix web breaks.
With the boot shaped label we ran
lower web tensions at the press rewinder
than with the paper backing due to
the shape of label layout on the die.
Higher web tension caused creases
near to the core of the converted coil,
which is something that simply has to
be taken into account when converting
with ProLiner PP30, as it is much thinner
than paper and not as stiff either.
Smooth adhesive layer,
no static electricity, no dust
One thing which was very noticeable,
was how smooth and mirror-like the
adhesive layer is. It gave a really good
impact on the printing effect.
What’s more, there was no static
electricity whilst converting to press.
This was quite interesting as the
relative humidity was only 30% when
the converting took place. However, it is
important not to lay the reel on the fl oor
after converting because of the tendency
of static electricity generating to a fi lmic
liner after it has been in contact with metal
rollers. An extremely positive observation
when trimcutting and coil rewinding,
was that there was no dust detected, and
especially no paper dust!
Web tension control important
An important thing to remember when
trimcutting ProLiner PP30 is that it has to
be done with good web tension control
and with fi lmic knives. There is a real difference
with PP and paper in this matter
and poor cutting can result in web breaks
on the applicator or even at the rewinder.
Web tension is important in generating
good label coils, we did not experience
any telescoping issues on label coils with
high speeds when running different labels
on the rewinder. Rewinding was as robust
as with paper backing coils.
Heavy thermal transfer printing –
which means loads of black color and
heat – didn’t cause any issues to ProLiner
PP30 either. All in all, ProLiner PP30
made a good impression on our
customer.
When compared to glassine liner, ProLiner PP30
provides a very smooth adhesive surface to achieve
better printing quality.
Sim-Bean Low, Product Manager, South East Asia
8

make
Can you
out of ProLiner PP30
money
waste?
One of the reasons we decided to develop
ProLiner PP30 for our high volume
paper products is that the used liner is
much easier to recycle than conventional
liner materials. This is due to the fact
that recycled PP is a widely traded
commodity with versatile application
possibilities, and it requires significantly
less energy to recycle than PET. This
means that used ProLiner PP30 has a
true market value when recycled.
Changing to ProLiner PP30 saves
money – and the environment. And you
can actually make money from its waste.
Often the best ideas are the simplest ideas.
ProLiner PP30: easy to convert, easy to recycle
and easy on the environment.
Joe D’Antini, Product Manager Oceania
9

What does
the customer – and
their customer
– have to say about
ProLiner PP30?
Meckelborg, Finland is a supplier of
both product marking equipment and
labelling materials, continually seeking
faster, more cost-effective and sustainable
solutions. Sales Director and head of
label production development Jarkko
Mäkelä points out that it has been easy
to move from a glassine backing to
ProLiner PP30 when there are so many
benefi ts for both parties – printer and
packer.
50% of Meckelborg’s label production
goes to big players in the beverage
and food industries – typical areas
where high-speed label dispensing and
moist conditions are the norm. In cases
like these, Jarkko Mäkelä says that using
paper-based liners has presented challenges
which undermine their effi ciency.
ProLiner PP30: Telling it like it is
Feedback from Meckelborg’s customers
shows that the robust new liner delivers
on its promise, enabling faster pack
production – because longer roll lengths
mean fewer roll changes – with far fewer
web breaks in dispensing.
Speaking of his company’s experience
after switching to ProLiner PP30,
Mäkelä takes a comprehensive view
that ‘small streams make a big river’:
Meckelborg benefi ts from 20% more
labels on the same size rolls even before
the labelstock enters the printing facilities
due to faster transport with less expense.
But more immediately noticeable
about ProLiner PP30 is the slick adhesive
surface giving a smoother run during
matrix-stripping for faster label production.
‘Pros’ that add up to change
As Jarkko Mäkelä says, the many combined
benefi ts for printer and end-user
all add up, making perfect sense to
leave glassine in the past. Meckelborg
has been witnessing a rising demand
for ProLiner PP30 also among smaller
packaging companies.
Another of the ‘pros’ is that packers
are nearly halving their liner waste.
Mäkelä calculates that at 40 million
labels a year, for instance, 30 tonnes
of incinerated glassine liner waste is a
costly burden – literally burning money!
With ProLiner PP30, packers are
recycling this valuable polypropylene
at no cost to themselves while demonstrating
a responsible attitude to the
environment.
Meckelborg has been using UPM
Rafl atac’s online Productivity Calculator
when discussing the benefi ts of ProLiner
PP30 with their customers.
The visual impact is
that of a higher quality
product – which it is.
Michel Tromp, Owner
of Clever Etiketten
10

It has been easy to move from a glassine backing
to ProLiner PP30 when there are so many benefits
for both parties – printer and packer.
Jarkko Mäkelä, Sales Director, Meckelborg
ProLiner PP30
ProLiner PP30 delivers quality down the line
Michel Tromp, owner of Clever Etiketten, the
Netherlands, says end-users are fi nding added
value with ProLiner PP30 in places he didn’t
expect: “They say our labels look great on
a clear film liner. The visual impact is that of
a higher quality product – which it is.”
“There’s visibly less pin-holing in our print
work without the dust we get from glassine
liners. As for our customers, they’re delighted
to have cleaner label rolls in their processes:
it’s something that helps secure the quality of
their food products.
“Ultimately, ProLiner PP30 makes life easier
for us and our customers: it delivers a quality
label product and runs great on-press – we only
had to buy new dies. And it’s more robust on
the dispensing line, which means labels can
be separated using higher force with less risk
of liner breakage.”
Clever ® Etiketten B.V. has been in business
for 20 years, runs fi ve conventional printing
presses, 4 die-cutting machines for non-printed
labels as well as digital presses. 45 people
work in shifts to supply a wide range of products
including self-adhesive labels, ticketing
solutions and fl exible packaging to a variety
of niche as well as mainstream markets.
PRODUCT RANGE
Product code EAN code Product name
TSRH09PP 8086551 RAFLACOAT PLUS RH 9 PROLINER PP30
02RH09PP 9027942 VELLUM TTR RH 9 PROLINER PP30
05RH09PP 9027393 RAFLAGLOSS RH 9 PROLINER PP30
HNRH09PP 198542 THERMAL TOP P 200 RH 9 PROLINER PP30
X7RH09PP 198535 THERMAL ECO 300 RH 9 PROLINER PP30
4YRH09PP 9027409 TRANSFER MATT RH 9 PROLINER PP30
03RH09PP 8104781 CASTGLOSS RH 9 PROLINER PP30
TECHNICAL SPECIFICATIONS
Properties Test method Units
Thickness ASTM D374 micron 30
Yield ASTM D 4321 m²/kg 36.6
Haze ASTM D 1003 % 2.5
Gloss 45 degrees ASTM D 2457 % 2.5
Tensile Strength at break ASTM D 882 MD N/mm2 170
TD N/mm2 300
Elongation at break ASTM D 882 MD % 150
TD 70
Thermal shrinkage ASTM D 2732 MD % 3
(120 °C, 5 min, in air) TD 1
Coeffi cient of friction ASTM D 1894 Film/fi lm 0.50
Film/metal 0.30
Surface tension ASTM D 2578 Dyne/cm O 38
1 -
11

www.upmraflatac.com
06/2011 AP 0016
