YAMAHA YZF R6

(2008)

SLIP-ON & SLIP-ON MEGAPHONE EXHAUST SYSTEM

YAMAHA YZF R6 (2008) SLIP-ON & SLIP-ON MEGAPHONE EXHAUST SYSTEM

DESCRIPTION

For riders who do not want to make any major modifications to the Yamaha R6, the

Akrapovic Slip-On system is an excellent choice, giving a lot of results for a simple

installation. The Akrapovic Slip-On system is an outstanding combination of high

quality workmanship, performance, affordability and aesthetic enhancement. The

distinctive, street legal Slip-On HEXAGONAL muffler fits well in the original mounting

position and goes fantastically with the lines of the bike. For more race-oriented

riders we offer a completely open version - the Akrapovic Slip-On Megaphone.

We offer a complete exhaust system for the Yamaha YZF R6 2008, with an EVOLUTION

LINE tube set and a street legal SLIP-ON muffler.

Warning! In case of a combination with the EVOLUTION tube set, the SLIP-ON homologation

is not valid!

This combination is offered only for racing purposes and race track use, since EVOLUTION

OPEN or RACING OPEN complete exhaust systems exceed permitted noise emissions.

max. rear wheel power

HP / rpm

(measured on Dynojet ATV)

CONFIGURA-

TION

material

interference crossover

tubes

PERFORMANCE

stock AKRAPOVIC max. increased power

117.5 / 14900 119.1 / 14800 1.7 / 11800

CONFIGURATION

header tubes collector link pipe

- -

STAINLESS STEEL /

TITANIUM (megaphone)

tube shape - - cylindrical / cylindrical

- lambda sensor -

header tube inner sleeves - header tube flanges -

PERFORMANCE

Measurements of the Akrapovic SLIP-ON system on the YAMAHA YZF R6 (without

muffler insert):

header tubes - collector

connection

-

collector / header tube -

link pipe connection

SLEEVE JOINT+

SILICON SHIELDED

SPRING+METAL

CLAMP(SLIP-ON) \

SLEEVE JOINT + METAL

CLAMP (MEGAFON SLIP-

ON)

Power & Torque: the R6’s engine spins more freely with the Akrapovic Slip-On system,

which is reflected in the power and torque curves. The amount of increased power expands

as you go up the rpm range, so that at 14800 rpm the rear wheel puts out 119.1HP. Max.

increased power of 1.7 HP was measured at a screaming 11800 rpm.

link pipe - muffler

connection

muffler metal interior

Welded \ welded

STAINLESS STEEL /

TITANIUM (megaphone)

muffler

inlet cap /outlet cap

muffler outer sleeve

S.S. - Carb. \ Ti

Ti or carbon-fiber \ Ti

(megafon

muffler clamp CARBON-FIBER muffler bracket -

CONFIGURATION

muffler insert

EU YES heat shield -

US - catalytic converter -

The Akrapovic Slip-On for the R6 features a unique design. It is composed of an extremely

short cylindrical stainless steel link pipe, which is welded to the muffler. The connection with

the stock header assembly is a sleeve joint which is double secured with a metal clamp and

a silicon-shielded spring. The muffler inlet cap is made of stainless steel, the outlet cap is

carbon-fiber, and the outer sleeve is titanium. The muffler is attached to the frame with an

Akrapovic carbon-fiber clamp.

For race-oriented riders we have developed an open version of the Slip-On called the

Akrapovic Slip-On Megaphone. The performance characteristics of the Megaphone are

the same as the mentioned Slip-On, but it features a titanium link pipe whose outlet port is

flared to the characteristic shape, and also includes an installed noise damper. The Megaphone

is connected with the header assembly with a sleeve joint secured with a metal

clamp, and is attached to the frame using a metal bracket.

weight comparison

(kg)

noise

measurements

(dB / rpm)

possibility of periodic

service without removing

A.E.S.

stock

1.87

S.S. link pipe

stock

ADDITIONAL DATA

AKRAPOVIC

TITANIUM

link pipe

stock - S.S.

difference

stock - titanium

1.2 0.41 (megaphone) 0.67 0.67 (megaphone)

AKRAPOVIC

98 / 7250 98 / 7250

104 / 7250 (megaphone)

oil

YES

oil filter

YES

legal for street use

YES / NO (megaphone)

Technical specifications of Akrapovic exhaust systems and related products subject to change without notice.

Product code:

(109114) S-Y6SO7-ZC, (109113) S-Y6SO7-ZT Slip-on open

(109109) S-Y6SO7-HZC, (109108) S-Y6SO7-HZ Slip-on street legal

(105572) SM-Y6SO6T Megaphone system

Akrapovič d.d. 2008 all rights reserved


EXHAUST PHOTO

Product code:






BIKE PHOTO

Product code:






BIKE PHOTO

Product code:






EXHAUST PHOTO

Product code:






BIKE PHOTO

Product code:






BIKE PHOTO

Product code:






SHEMATIC

V-TUV080 NOISE REDUCTION INSERT

M-HZ01905C TITANIUM MUFFLER WITH CARBON FIBRE OUTER SLEEVE

M-HZ01905T TITANIUM MUFFLER

P-S2 SPRING

YAMAHA R6 Slip on,STREET LEGAL/ Model year:2008,

Product code: S-Y6SO7-HZC, S-Y6SO7-HZT

P-VST2AL STICKER

P-MCTZ11 CARBON FIBRE CLAMP FOR TITANIUM OUTER SLEEVE MUFFLER

P-MCCZ11 CARBON FIBRE CLAMP FOR CARBON FIBRE OUTER SLEEVE MUFFLER

P-HF182 FITTING PARTS-SET

Product code:






SHEMATIC


P-HF183 HANGING FITTING ASSEMBLY

LM-Y6SO6T LINK PIPE

YAMAHA R6,MEGAFON 2006-2008

PRODUCT CODE: SM-Y6SO6T

Product code:





.


SHEMATIC

EVOLUTION LINE tube set and a street legal SLIP-ON muffler.

P-57 INNER SLEEVE

Warning! In case of a combination with the EVOLUTION tube set,

the SLIP-ON homologation is not valid!

P-F11 FLANGE

Yamaha YZF R6, Complete exhaust system / EVOLUTION

LINE tube set with Street legal SLIP on Mufflers, Model year:2008

Product code: S-Y6RFT7TL-ZC/1

S-Y6RFT7TL-ZT/1


H-Y6RT7 HEADER TUBE

M-HZ01905T TITANIUM MUFFLER

M-HZ01905C TITANIUM MUFFLER WITH CARBON FIBRE OUTER SLEEVE

P-MCCZ11 CARBON MUFFLER CLAMP

FOR CARBON OUTER SLEEVE MUFFLER

P-MCTZ11 CARBON MUFFLER CLAMP

FOR TITANIUM OUTER SLEEVE MUFFLER

P-S2 SPRING

P-LBSB1 LAMBDA CONNECTOR BOLT

P-VST2AL STICKER

C-Y6RT6 COLLECTOR SET

P-HF182 FITTING PARTS

L-Y6R7TL/1 LINK PIPE

P-S1 SPRING

Product code:

S-Y6RFT7TL-ZC/1

S-Y6RFT7TL-ZT/1



DIAGRAM / CHART

STOCK EXHAUST

AKRAPOVIC SLIP-ON EXHAUST

120

110

60

100

55

90

80

50

WhlPwr

70

60

45

EngTrq

50

40

40

35

30

20

30

10

25

3000

4000

5000

6000

7000

8000

9000

10000

11000

12000

13000

14000

15000

16000

EngSpd RPM

Product code:
