EDITORIAL
Looking ahead to new
opportunities
2012 saw thermal processing equipment manufacturers gaining
confidence while coping with the increasing complexities of
global markets. Companies have learned the lessons the recent
crisis has taught. In particular, the downward trends in steel and
automotive production called for continued efforts in 2012.
Even though orders kept dropping for a while, eventually the
struggle paid off. Wether tireless research and development, elaborate
market analyses, or tailored products and services for new
markets – manufacturers pulled out all the stops. Being a provider
of a key technology for a wide range of applications and markets, of
course, also had its part in overcoming the difficulties. The German
manufacturers of thermo processing equipment were able to increase
their exports by around 10 per cent in 2012 (January through
October) and they are expected to reach out to the two billion
Euro threshold which they last exceeded in 2008. Latest economic
indicators like the Purchasing Managers’ indexes of China, the United
States or the Eurozone point to a gain in stability and have incited
economic experts to raise their predictions for 2013.
Throughout the world, efforts are being stepped up to conserve
resources and reduce pollutant emissions. Energy consumption is
becoming a decisive factor in competition within manufacturing
industry. In this respect, thermal process technologies not just play
a key role in the production and processing of a wide range of
products or for the recovery of raw materials but notably in making
production and processes more efficient, sustainable and environmentally
friendly – for all application areas. Thanks to their expert
knowledge of many customers’ industrial sectors, manufacturers
act as competent advisors on process engineering decisions and
process selection and optimization. In order to support customers
in their efficiency and sustainability efforts manufacturers and the
VDMA Thermo Processing Association have developed ‘The Energy
Efficiency Manual for Thermo Processing Plants’, by now available
in four languages. On the European level the ‘Ecodesign for Energy
Related Products Directive’ (ErP) is well under way to be implemented
for industrial and laboratory furnaces and ovens. Right from the
start, CECOF – The European Committee of Industrial Furnace and
Heating Equipment Associations, has participated in the process as
one of the stakeholders. With its contribution CECOF aims at raising
the practicability of the new measures that the EU Commission
will issue for implementation, being convinced that any guideline
needs to take into account that most of the industrial furnaces are
built tailor-made for specific applications and individual customers.
While starting optimistically in a new year of opportunities heat
processing equipment providers are well aware that in the globalized
economic environment risks will change but not vanish.
Regardless of company size, confidence
has grown that the industry is well
prepared to tackle the challenges
lying ahead in 2013
and what is more, to open
up new horizons.
Dr. Timo Würz
Managing Director of Thermo Process Technology
within VDMA and General Secretary of CECOF
heat processing 1-2013
