EDITORIAL

ITPS – The Key Event for

Thermo Process Technology

Within the frame of GMTN, the globally leading quartet of trade

fairs with the slogan ‘The Bright world of Metals’ and taking

place every four years in Düsseldorf, THERMPROCESS 2011 was an

outstanding event for the experts of the Thermal Processing Industry.

With a special focus on ‘Ecometals’ the industry also highlighted

new materials and new technologies for reduction of emissions and

consumption of energy whereby it has to be kept in mind that this

topic has already since long been in the spot light of competing

technologies.

Looking into the future we see that in the meantime the economical

environment for our customers in the material producing

industries is becoming more and more challenging. The markets

for equipment for thermal processing are regionally shifting. In

Europe the pressure for reduction of emissions and for fuel saving

is increasing further and energy prices are increasing. Efforts of

the European Union but also of governmental authorities in

other parts of the world are working on the preparation of new

regulations for our undoubtedly energy intense equipments. One

way to be exploited further is most probably to investigate in

more depth not only the individual step of a thermal process in

a whole production sequence for a material but into the whole

line of processes from the raw material to the final product. This

will require a close link between ourselves and our customers

and even their other suppliers.

It is therefore just the right time that CECOF, the European

Association of the Industry for Industrial Furnaces, in co-operation

with the Messe Düsseldorf as well as with Vulkan-Verlag – the

publisher of this journal heat processing - is launching the International

Thermo Process Summit 2013. More than any event before

this will be the place where the top expert of this industry will

discuss with the key customer industries as well as with representatives

of the political authorities the ways to find solutions

for our way into the future.

Dr. Hermann Stumpp

Chairman of the Association for

Thermal Process Technology

within VDMA

heat processing 4-2012

International Magazine for Industrial Furnaces,

NEWS Heat Treatment xxxx & Equipment


BRAND NEW

Already shopped

Know-how today?

The new web presence of hp


Vulkan-Verlag

2 heat processing 4-2012

xxxx

NEWS

4-2012 heat processing

3

TABLE OF CONTENTS 4-2012

8 38

HOT SHOTS

Gas carburising furnace in action

REPORTS

Energy-optimised heat treatment

Reports

Heat Treatment

by Dominik Schröder

37 Energy-optimised heat treatment

by Christian Sprung

41 Process routes for heat treatment, hardening and tempering of heavy plates

Induction Technology

by Günter Valder

51 Single-billet induction heaters meet the most exacting demands

Vacuum Technology

by Björn Eric Zieger

55 Purpose-directed hot zone and cooling-gas stream design of vacuum furnaces


4-2012 TABLE OF CONTENTS

42

REPORTS

35

Heat treatment of heavy plates

CECOF CORNER

New president: René Branders

Burner & Combustion

by Michael Angerstein

59 Infrared drying with porous burners in industrial environments

Research & Development

by Jörg Neumeyer, Holger Schülbe, Bernard Nacke

63 Hybrid processes in electrotechnology

News

10 Trade & Industry

20 Diary

23 Events

30 Personal

32 Book Review

Visit our websites:


www.heatprocessing-directory.com


5

TABLE OF CONTENTS 4-2012

52 24

REPORTS

Single-billet induction heating

NEWS

Aluminium shines with new records

CECOF Corner

34 Flashback CECOF General Assembly 2012

Companies Profile

100 KELLER HCW GmbH

Focus On

67 Edition 4: Paweł Wyrzykowski

“Energy efficiency is the biggest potential in Europe”

heatprocessing

Stay informed and follow us on Twitter

heat processing

@heatprocessing

heat processing is the international magazine for industrial furnaces,

heat treatment & equipment

Essen · http://www.heatprocessing-online.com


4-2012 TABLE OF CONTENTS

69

FOCUS ON

Edition 4: Paweł Wyrzykowski

Business Directory

78 I. Furnaces and plants for industrial

heat treatment processes

88 II. Components, equipment,

production and auxiliary materials

96 III. Consulting, design, service and

engineering

97 IV. Trade associations, institutes,

universities, organisations

98 V. Exhibition organizers, training

and education

Are you

playing it

safe?

FCU 500

For monitoring and

controlling central

safety functions in

multiple burner

systems on

industrial furnaces.

In accordance to

EN 746:2010.

COLUMN

1 Editorial

8 Hot Shots

76 Index of Advertisers

101 Imprint


Information about

the functional safety of

thermoprocessing equipment

can be found here:

www.k-sil.de

Elster GmbH

Postfach 2809

49018 Osnabrück

T +49 541 1214-0

F +49 541 1214-370

info@kromschroeder.com

www.kromschroeder.com

7

NEWS HOT SHOTS xxxx


xxxx

NEWS

Gas carburising furnace in action

Low-distortion heat treatment via removal of the component

from a gas carburising furnace and subsequent individual

hardening.

Source: AWT e.V.


9

NEWS

Trade & Industry

EMA Indutec to start up one of the

biggest induction hardening machines

Since the end of last year, one of the biggest

vertical induction hardening machines

has been operated with a power supply

of EMA Indutec GmbH. This is a vertical hardening

machine for shafts with a diameter

of up to 1.000 mm and a length of up to 8 m.

The machine was designed by a long-standing

customer of EMA - the subcontract

heat treatment shop Messrs. TermoIndüksiyon,

Istanbul, Turkey - produced and built

on their own. The aim for this investment

was to build a vertical, inductive heat treatment

machine with minimal distortion of

longitudinal shafts for wind energy systems

in the immediate vicinity of the manufacturer.

So far, the shafts had sometimes to be

transported to the United States back and

forth for an inductive heat treatment.

A converter of the EMA-type TIV-2D

3k800 was chosen as power supply covering

a frequency range of 1 to 3 kHz. With an

output power of up to 800 kW, this allows

a hardening depth of up to 15 mm (depending

on the material).

The adaptation of the AC-converter to the

provided inductors is carried out via a transformer

unit ensuring an operation of one- to

three-turn inductors without any problems.

In order to minimise the transmission losses

on this 8 m vertical travel distance, the inductors

are directly connected to the outputs of

EMA matching transformers moving vertically

along and mounted on a solid carrier.

The “high-voltage” connection between the

transformers and the power source is realised

via flexible coaxial cables of corresponding

length. The depicted “acceptance-shaft”

being hardened has a length of 8 m and a diameter

of 395 mm. The material was 42CrMo4

and the achieved hardening depth 10 mm.

EFD Induction opens new subsidiary in Brazil

EFD Induction’s worldwide network

expanded recently with the launch of its

Brazilian subsidiary. The new company - with

the formal name of EFD Induction Ltda. - is

based in the city of Sorocaba, about 60 km

from the metropolis of São Paulo.

“This is a milestone in our growth,” says

EFD Induction CEO Eivin Jørgensen. “We

have previously sold many systems throughout

Latin America. But having a subsidiary

in Brazil’s economic heartland means

we can offer better and faster support to

customers in the region.” The new subsidiary

is headed by Mr. Evandro Nishimuni,

a mechanical engineering graduate who

has previously worked in France and in the

Brazilian automotive industry. “EFD Induction

and Brazil have so much to offer each

other,” says Mr. Nishimuni. “There is growing

awareness throughout Brazil and the continent

that sustained economic growth can

only be maintained by investing in modern,

efficient and proven technologies such as

induction heating.”

Although the subsidiary is new, Brazil and

Latin America is no stranger to EFD Induction

products and services. For instance,

several of mobile Minac induction heating

systems are being used to braze hydroelectric

turbine stators at the Santo Antônio and

Jirau dams, key structures in a new hydroelectric

complex being constructed in Amazonia.

And Basso, the world-renowned valve

makers in Argentina, recently installed an

EFD Induction hardening system.

Mr. Evandro Nishmuni is however keen

to stress that most of the new company’s

business will most likely occur much closer

to home: “True, if Brazil is the engine of

South American economic growth, then the

state of São Paulo where we are located is its

dynamo. In fact this state alone is responsible

for a third of all Brazilian GDP. That gives

you some idea of just how economically

vibrant the region is.”



NEWS

Loesche wins order for supply of coal milling and drying system

Loesche has signed a contract with Doosan

Heavy Industries & Construction for

the supply of two Loesche coal mills type

LM 43.4D for the coal-based integrated

gasification combined cycle (IGCC) power

plant (1 x 300 MW, net) to be built in Taean,

South Korea.

The scope of supply comprises the complete

equipment from the raw coal feeding

system to the product bag filter, including

the Loesche grinding mills and Loesche hot

gas generators, flaps, fans, electrical drives,

and Loesche automation system.

The throughput of the Loesche four roller

grinding mill type LM 43.4D amounts to

95 t/h coal with additives (dry-base) based

on the fineness of 10 % residue on 90

microns sieve. In this case the Loesche coal

mill type LM 43.4D simultaneously grinds,

dries, and classifies a mixture of coal and

additives with more than 25 % moisture.

The mill main drive power rating amounts

to 1,600 kW. The required process heat is

provided by Loesche hot gas generators

type LF 36 with a maximum heat capacity of

25 MW per each mill. The hot gas generator is

operated with synthesis gas and natural gas.

Loesche’s expertise and experience in

the field of self-inert coal grinding plants

was, amongst other Loesche advantages,

one of the decisive reasons for Doosan to

select Loesche vertical roller mills for coal

grinding in the gasification industry. Selfinert

grinding plants, which are mainly operated

in the steel and iron industry, utilise

recirculated gases occurring in the installation

system itself. Up to now Loesche has

sold more than 60 coal mills for self-inert

coal grinding plants.

The IGCC technology is a high-efficiency

process whereby a synthetic gas consisting

primarily of hydrogen and carbon monoxide

is extracted from coal and used as

fuel to generate electricity. This gasification

technique is such an extremely advanced

technology that there are currently only

a few demonstration plants in operation

worldwide.

Complete delivery FOB North-sea port is

scheduled for May 2013 and commissioning

is scheduled for the first half of 2014.

High-efficiency quenching and tempering plants

based on comprehensive process expertise

LOI Thermprocess GmbH - Tenova Iron & Steel Division

Am Lichtbogen 29 - 45141 Essen / Germany

Phone +49 (0)201 1891.1 - Fax +49 (0)201 1891.321

info@loi-italimpianti.de - www.loi-italimpianti.com

12058-12 LOI Anz Grobblech Heat Processing 4-2012.indd 1 08.11.2012 9:38:07 Uhr


11

NEWS


Schmidt + Clemens to implement organisational realignment

The Schmidt + Clemens Group (S+C) with

its home base in Lindlar, Germany, has

consistently continued to implement the

organisational realignment it started at the

end of May 2012. The worldwide matrix organisation

aimed at, combined with a clear division-oriented

control and decision-making

structure at the home base, continues

to take shape. Apart from the merger of the

German companies S+C Extrusion Tooling

Solutions GmbH, S+C Märker GmbH and

Schmidt + Clemens GmbH + Co KG into a

single enterprise, planned for October 2012,

it has already been possible to complete

appointments to top management.

Besides the chairman of the board, Engineer

Jan Schmidt-Krayer, the managing

director for finance, Dr Henning Kreisel and

the managing director for marketing, Engineer

Thomas Hellige (recruited in-house), as

of September 1 st , 2012 it has been possible

to fill the newly created management position

for “Production and Engineering” with

Engineer Dominic Otte. Dominic Otte has

until now worked in responsible managerial

positions for a family-owned company with

worldwide operations in the airconditioning

sector and has many years of experience in

the field of international production.

“Our goal is continuous growth that is

profitable for everyone in the entire S+C

Group. And not only in existing markets but

in new ones as well and with innovative

products,” says management chairman

Jan Schmidt-Krayer. “The smaller business

divisions of extrusion tools and forged product

processing are precisely those that will

benefit the most from the new organisation.

That is where we want continuous further

development.”

The foundation for the old corporate

structure was laid 40 years ago and was

now no longer in tune with the times since

it could no longer keep pace with the corporate

group’s growth and with progressing

internationalisation.

Jan Schmidt-Krayer stresses in particular

that, with the restructuring measures, no jobs

are in jeopardy. On the contrary, the new corporate

organisation opens up new perspectives

in career development at S+C for some

employees. “I am really happy that our works

councils have welcomed this development

and I thank them for their support,” says Mr.

Schmidt-Krayer.

Seco/Warwick delivers

vacuum furnace to Spain

Seco/Warwick delivered and commissioned a two-chamber

vacuum furnace with oil-quench tank to a commercial

heat-treatment plant in Spain. The furnace is designated for

the heat treatment of aircraft landing-gear parts made chiefly

from materials such as 35NCD16, 4340M and 300M. The heating

chamber, which is 900 mm wide x 900 mm long x 1,200 mm

high, incorporates a diffusion pump with a capacity of 30,000 l/s.

In the quench chamber, right above the oil surface, there is a

gas-quench system operating within the pressure range up to

1.5 bar abs.

Linde to build Vietnam’s

largest air separation unit

T

he Linde Group has been awarded a long-term contract to

supply Vietnamese steel company POSCO SS-Vina (PSSV) with

industrial gases. The deal will see Linde construct the country’s

largest air separation unit (ASU) at the Phu My industrial park in

Ba Ria (Vung Tau province).

The new state-of-the-art ASU will be able to produce 35,000

normal m 3 of air gases per hour and is set to go on stream in 2014.

It will supply the new steelworks that PSSV is currently building

in Phu My with gaseous oxygen, nitrogen and argon. It will also

manufacture products for the regional market in southern Vietnam.


Powered by


NEWS

INTERNATIONAL

THERM

PROCESS

SUMMIT

Organized by

The Key Event

for Thermo Process Technology



09-10 July 2013

www.itps-online.com


13

NEWS


Aichelin forms new Brazilian subsidiary

Aichelin Holding GmbH formed a new

subsidiary in Brazil that started operations

in June 1 st . A-Sistemas Tratamentos Térmicos

Ltda. (A-STT) is located in Votorantim,

São Paulo, and will serve all existing and new

Aichelin customers in Central and South

America with state-of-the-art heat-treatment

technology. A-STT’s main focus will be

sales and local production of heat-treatment

equipment, process and safety consulting,

and after-sales service (including modernization

and spare parts for all Aichelin furnaces).

Prior to the formation of A-STT, Aichelin sold

all of its shares in Aichelin Brasil Ltda. and

terminated its license agreement covering

technology transfer for selling, manufacturing,

usage and service of Aichelin Group’s

heat-treatment products.

Ipsen shipped turbo treater to USA

Ipsen recently shipped a H3636 2-bar Turbo

Treater® furnace to a commercial heat-treatment

company located in the southeastern

U.S. The high-temperature furnace included

a 2-inch-thick carbon-composite/graphitefelt

hot zone with a nominal work zone of

24 inches x 24 inches x 36 inches and a gross

load capacity of 1,500 pounds, configured for

460 volts, 60 hertz, three phase. The furnace

was equipped with the user-friendly Compu-

Vac® supervisory control system as well as a

nitrogen and argon partial-pressure system.

Ruukki to initiate employer-employee negotiations

Ruukki is to initiate employer-employee

negotiations affecting Ruukki Metals and

the marketing and communications function.

These negotiations are part of Ruukki‘s

projects launched this year to improve the

company‘s competitiveness. It is estimated

there is a need for a total of 250 redundancies.

In addition to the efficiency improvement

programmes underway, studies are

being initiated to improve efficiency also in

corporate administration.

Ruukki Metals is to initiate employeremployee

negotiations concerning the

efficiency of its operations. The negotiations

affect most of Ruukki Metals’ production

organisation in Finland, which means a total

of around 3,500 persons. The Raahe Works

and Hämeenlinna Works are the largest units

affected by these negotiations. An estimated

maximum of 230 persons in all, of which

160 are workers and 70 salaried employees,

are affected by the need for redundancies. In

addition, employer-employee negotiations

concerning lay-offs of the entire personnel

will be initiated at the Kankaanpää and Pulkkila

sites in Finland.

Also employer-employee negotiations

will be initiated in the Marketing and

Communications function in pursuit of

improved operating efficiency. The negotiations

affect around 70 persons in Ruukki

countries. An estimated maximum of 20

people in all will be affected by the need

for redundancies.

The negotiations now being initiated are

part of Ruukki‘s projects launched this year

to improve the company‘s competitiveness.

The projects in the steel and construction

businesses seek to achieve a total permanent

annualised improvement of € 100 million

in earnings performance and profitable

business also when production is running

at 80 %, which is low for the steel industry.

„The flexibility and savings now being

sought are important for the competitiveness

of our business and we have worked

with the personnel to identify ways to

improve efficiency. In addition to improving

ways of working, our efficiency improvement

targets also regrettably require redundancies.

Our aim is to improve our long-term

competitiveness, which requires a permanently

lower cost level, in addition to the

challenges already referred to earlier. On top

of this, the Sulphur Directive, for example,

threatens to increase future transportation

costs within our steel production,“ explains

Olavi Huhtala, Executive Vice President of

Ruukki Metals.

The negotiations seek savings totalling

around € 10 million in annual costs and it is

estimated that the cost cuts will be achieved

in full during the second and third quarters

of 2013. Efforts will be made to carry out

some of the redundancies through retirement

and by deployment.

In addition to the efficiency improvement

programmes underway, studies will

be initiated to improve efficiency also in

corporate administration. The study affects

all administrative functions that serve the

whole of Ruukki or its divisions.



NEWS

ABP Induction receives order from China

For the third time ABP Induction receives

an order from FAW Foundry Group in

China. This time FAW orders 6 Twin-Power®

systems with 8 MW each and a total of twelve

IFM 7 furnaces (12 t capacity).

By signing this contract on August 7 th ,

2012, FAW #1 Chinas largest Automotive

Company, decided again for the successful

concept of ABP. The six Twin-Power® systems

will be used both to retrofit an existing

foundry and in a green field foundry which

will be the most modern one in the FAW

group in the future.

Each of the twelve IFM 7 medium frequency

furnaces will be equipped with the

newly developed ABP Eco Top-Hood for

fume-gas collection and de-dusting. Each

two of these furnaces will be operate according

to the ABP Twin-Power® principle with

one power supply. With this principle switching

times which have been common in

the past will be obsolete and superheating

of the melt will be avoided. Also the ABP

parallel converter technology proves the

innovation leader ship of ABP. Additionally

PRODAPT®-MD is integrated in every Twin-

Power® set. This melt processor designed

and engineered by ABP allows the convenient

control and supervision of the whole

system during operation.

Mr. Wei, GM of ABP China, is proud of

this order. This is already the third order

from the FAW group. This proves the ABP

Induction is very well appreciate from its

customers and that ABP holds its promises

100 %.

SCHMeTZ *RD pluS*

with intensified cooling

from the bottom

• Round graphite hot zone

• With intensified cooling from the bottom

• Most efficient and uniformest 360° all around nozzle cooling

• For large diecasting dies e.g. in automotive industry acc. to latest


NADCA standard

www.schmetz.de

15

We make the difference!

NEWS


Baosteel passed performance test of hot-metal production

One year following startup of the second

Corex module at the Chinese steelmaker

Baosteel in Shanghai, a successful performance

test has now proven the economy

efficiency of this alternative technology for

the production of hot metal. After the successful

performance test, on June 5, 2012,

also the Final Acceptance Certificate has

been signed by Baosteel.

“As opposed to the conventional blastfurnace

route, the Corex production costs

are substantially lower,” Dieter Siuka said

about the performance test. Mr. Siuka is

responsible worldwide for iron production

at Siemens Metals Technologies. Less

expensive and locally available raw materials

yield the same quality of hot metal as

higher-quality imports. Siuka expects that

the Corex route will now be further rolled

out as an alternative to conventional blast

furnace production, especially in markets

with increasing hot-metal production.

Following startup of the Corex plant in

March 2011, Baosteel and Siemens have

been working together over the past few

months to optimize operation of the plant,

which is designed for the production of 1.5

million t of hot metal per year. “All performance

parameters stipulated in the contract

were achieved or exceeded,” Siuka reported.

The performance test was completed in a

total of 170 h. The guaranteed production

rate of 175 t of hot metal per hour was achieved

in addition to a reduction in the specific

fuel rate from 950 kg to 870 kg/t of hot metal

based on local raw materials. Uniformly high

quality of the hot metal was achieved in

spite of the heavy fluctuation in the quality

of the raw materials. “The quality of the hot

metal produced in the Corex plant is comparable

to that found in the product of conventional

blast furnaces,” Siuka emphasized.

In light of the continuing depletion and

the high cost of high-quality raw materials,

and because of the environmental restrictions

placed on blast furnace operation

in numerous countries, the Corex-C-3000

route offers an environmentally compatible

and economically efficient alternative that

conserves resources. The successful performance

test is a “further milestone in commercialization

of the Corex production technology,”

Siuka emphasized, who expects

demand “particularly in markets with increasing

hot-metal production levels and where

raw materials are readily available.” Current

plans at Baosteel call for continued operation

of the Corex plant at high capacity.

The conventional blast furnace route

consists of the sintering plant, coke oven

plant and the blast furnace and produces

hot metal from agglomerated iron ore (sinter)

with the help of coke. In addition to high

investment costs, the disadvantages of this

route include the comparatively high emissions,

for example, of sulfur oxides (SO x ), nitrous

oxides (NO x ), dust and phenols. Liquid

hot metal produced in the Corex route is

melted directly from pellets and lump ore,

and non-coking coal is the primary source of

energy. In comparison with the conventional

route, the production costs and emissions

of the Corex route are lower because the

coking and sintering plants (systems with

the highest emissions) are not required. The

Corex gas can also be used as an energy

source to generate electricity or as a reducing

gas in a direct-reduction plant.


KNOWLEDGE


NEWS

for the FUTURE

Five Stein to supply two

vertical digital annealing

furnaces in China

Valin ArcelorMittal Automotive Co, Ltd. (VAMA), founded

in September 2010, is a joint-venture between

ArcelorMittal and the Chinese steelmaker Valin Group.

VAMA is focused on establishing itself as a premier quality

supplier of high-strength steels and value-added

products for China’s fast growing automotive market.

The new greenfield cold-rolling mill complex will be

installed in Loudi, Hunan province, for an annual production

capacity of 1.5 million t of steel strip and will

include a continuous automotive hot dip galvanizing

line and a continuous mixte annealing and aluminizing

line. Both of these lines will be equipped with Fives

Stein’s vertical Digital annealing furnaces and are scheduled

to start-up by mid-2014.

Fives Stein is engineering and supplying the complete

furnace and related automation systems, including

imported key process technologies from Europe and

all local manufacturing and supplies in China through

its local organization Fives Stein Shanghai which has

an experienced team of more than 100 employees.

Fives Stein’s vertical digital furnace technologies were

selected thanks to superior performances in high efficiency

digital heating sections and outstanding cooling

performances of the patented Flash Cooling® system.

A wide range of steel qualities can be processed in the

two lines, including mild, high-strength, low-alloyed,

IF, Dual-Phase, TRIP and bake-hardening (BH) grades.

In particular, the latest Advanced High-Strength

Steels (AHSS) can be processed in the line to respond

to the needs of the automotive industry to produce

lighter vehicles. Additional operation flexibility is also

provided for the mixte continuous annealing and aluminizing

Line through specific furnace features and

automation system giving VAMA the possibility to produce

uncoated as well as coated annealed strips in the

same line. The new high added-value coatings will be

the first introduced by VAMA in the Chinese market.

The international magazine

for industrial furnaces, heat

treatment and equipment

The technical journal for the entire field of industrial

furnace and heat treatment engineering, thermal

plants, systems and processes. The publication

delivers comprehensive information, in full technical

detail, on developments and solutions in thermal

process engineering for industrial applications.

Make up your mind on how to subscribe!

The printed volume suits the classic way of reading.

The e-paper issue offers the modern way of receiving

information on a computer, tablet pc or smart phone.

The printed volume + e-paper issue combine the best

of both worlds.

Available

as print volume

or as e-paper

heatprocessing

Stay informed and follow us on Twitter


heat processing

@heatprocessing

heat processing is the international magazine for industrial furnaces,

heat treatment & equipment

Essen · http://www.heatprocessing-online.com

For more information on

subscription details, please check


VULKAN-VERLAG GMBH


Scan to purchase

heat processing is published by Vulkan-Verlg GmbH, Huyssenallee 52-56, 45128 Essen

17

NEWS


ThyssenKrupp sells Tailored Blanks to WISCO

ThyssenKrupp AG has signed an agreement

with Wuhan Iron and Steel Corporation

(WISCO) for the sale of for its subsidiary

ThyssenKrupp Tailored Blanks, which produces

tailored steel blanks for the automotive

industry. The parties have agreed not to

disclose the purchase price. The sale is subject

to approval by the supervisory bodies

and the responsible regulatory authorities.

It is a further step in the optimisation of the

portfolio, which the Group announced on

May 13, 2011 in connection with its strategic

development programme. As part of the

portfolio optimization, the Group is divesting

businesses for which there are stronger

alternative strategic options. ThyssenKrupp

is proceeding fully according to plan, and

sale agreements have already been signed

or closed for around 95 % of the business

activities up for disposal.

ThyssenKrupp Tailored Blanks is an

important supplier of body systems to the

auto industry. Tailored products are made

of individual sheets of different steel grade,

thickness or finish, joined together by laser

welding. The blanks are designed from the

outset to meet the stresses in the parts in

which they will be used. This results in significant

weight and cost savings, for example

in the production of body parts.

Headquartered in Duisburg, Germany,

the global ThyssenKrupp Tailored Blanks

group has been producing tailored blanks

since 1985 and is the leading supplier in this

segment with a roughly 40 % global market

share. The company has 13 plants in Germany,

Sweden, Italy, Turkey, the USA, Mexico and

China. It employs around 950 people and

last year produced some 58 million parts

for automotive OEMs. Sales in the 2010/2011

fiscal year were approximately €700 million.

Wuhan Iron and Steel Corporation

(WISCO) started production in 1958, making

it one of China’s longest-standing steel

producers. The internationally successful

and fast-growing group headquartered in

Wuhan has more than 80,000 employees

and a capacity of around 40 million t. In

2011, WISCO achieved a turnover of around

€26 billion, produced nearly 34 million t and

was China’s fourth biggest steel producer. It

has subsidiaries and sales offices in over ten

countries, and is ranked 321 in the Fortune

500 ranking in 2012.

Can-Eng Furnaces announces startup of atmosphere roller

hearth reduction furnace

Can-Eng Furnaces International Limited

is pleased to announce the successful

start-up of an atmosphere roller hearth

reduction furnace at North American Hoganas

in Niagara Falls, New York. The unit, of

high temperature furnace construction, was

the first of its kind to be built in nearly 50

years. This electrically heated unit has the

capability of reducing iron oxide powder to

sponge iron in a 100 % hydrogen environment

flowing at high capacity.

In addition to the furnace, Can-Eng supplied

a H 2 recycle system, consisting of an

energy efficient heat recovery unit, spray

towers, and auxiliary equipment for the purposes

of decreasing the dewpoint of the

process hydrogen atmosphere. A Preheat

Furnace System was also supplied to heat

the recycled hydrogen to near process temperature.

The entire plant, measuring 200’

x 100’ x 50’ high, is arranged in a compact

footprint making use of the existing building

under truss space. The continuous roller

hearth furnace employed unique sealing

arrangements on the charge and discharge

openings as well as a special gasket system

on all rollers. The system came complete

with LEVEL II Automation software from

Can-Eng.



NEWS

Siemens to install slag

stopper systems on

converters in Belgium

ArcelorMittal Belgium NV has placed an order with Siemens

VAI Metals Technologies for the supply of two Simetal

Vaicon stoppers. The slag stopper systems will be installed

on two 300-ton LD converters at ArcelorMittal’s Gent works.

Reducing slag carry-over to a minimum will improve the

chemical composition and thus the quality of the steel. The

modernization project is scheduled for completion in the

first quarter of 2013.

At the company’s Gent works, ArcelorMittal operates LD

(BOF) converters, with a tapping weight of 300 t. In order

to almost completely prevent slag carry-over with the steel

towards the end of the tapping procedure, Siemens will equip

each of the converters with a Simetal Vaicon slag stopper

system. In this solution, the taphole is pneumatically sealed

with nitrogen gas. This non-contact technology ensures reliable

operation irrespective of possible taphole wear. The slag

stopper systems ordered by ArcelorMittal Gent can be operated

either in manual or automatic mode and will be able to

reduce the slag content in the liquid steel to levels lower than

4 kg/t, which will result in reduced rephosphorization and

resulfurization of the steel.

Cover

Induction solutions. Hard to beat!

SMS Elotherm

Elotherm is a worldwide technology leader and your reliable partner

for high performance induction machines and technologies.

With pioneering designs tempered by many decades of industrial

experience, SMS Elotherm designs and builds both individual

machines and complete systems for seamless integration into your

production line.

Induction heating and heat treatment lines

■

Induction heating of metals

for forging and rolling

■

Induction hardening and

quench & temper

■

Induction welding, annealing

and special technology for tubes

www.sms-elotherm.com

■

Continuous induction

strip heating

■

Induction kinetics

■

Laser technology

■

Global service

ArcelorMittal unveils new steel “Nature”

ArcelorMittal has launched a range of

organic coated steels that have eliminated

the need for the chemical Strontium

chromate (SrCrO 4 ). This chemical that has

been used by the construction industry in

coated steels for decades will be banned

in 2016 under the European REACH regulatory

framework (Registration, Evaluation,

Authorisation and Restriction of Chemical

Substances), which came into force on

June 1, 2007.

Long-standing research programmes

undertaken by ArcelorMittal Flat Carbon

Europe (FCE) in partnership with paint

suppliers have led to the development of

new corrosion-inhibiting pigments, such as

polyphosphates, silicates and ion-exchange

resins. These effective, neutral and durable

substitutes are the result of nearly 15 years

of research by ArcelorMittal.

ArcelorMittal has long led the way in

developing sustainable steel solutions for

the construction industry, and the Nature

range is the latest stage in that long tradition.

In 2011 alone, ArcelorMittal invested

$306 million in researching and developing

new steel products, solutions and processes

to support a low carbon world, demonstrating

the sustainable advantages available

through product innovation.

For many years, steel has been the responsible

choice for the construction industry.

Its natural advantages - strength and

flexibility - coupled with its infinite recyclability

mean that steel recovery within

the construction industry is as high as

85 %. Organic coated steel is widely used

in the building industry, in facades, roofing,

cappings, ceilings and lighting. In these different

applications, the coating ensures that

the product can withstand the effects of

weather and corrosives.


19

NEWS


DIARY

7-10 Jan. Tekno Tube Arabia

in Dubai, United Arab Emirates

www.tekno-arabia.com

16-19 Sept. IFEX 2013

in Kolkata, India

www.ifexindia.com

SMS Elotherm

receives order for

induction heater in Brazil

5-7 Feb. E-world energy & water 2013

in Essen, Germany

www.e-world-2013.com

8-12 April Hannover Messe 2013

in Hannover, Germany

Tel.: +49 (0)511/ 89-31127

www.hannovermesse.com

18-21 June Beijing Essen Welding & Cutting

in Shanghai, China

www.beijing-essen-welding-cutting.com

25-28 June Metallurgy-Litmash

in Moscow, Russia

www.metallurgy-tube-russia.com

9-10 July ITPS - International Thermo Process Summit

in Düsseldorf, Germany


17-19 Sept. Tube Southeast Asia

in Bangkok, Thailand

www.tube-southeastasia.com

17-19 Sept. wire Southeast Asia

in Bangkok, Thailand

www.wire-southeastasia.com

17-19 Sept. Hybrid Expo 2013

in Stuttgart, Germany

www.hybrid-expo.com

25-26 Sept. International Colloquium on Refractories

in Aachen, Germany

Tel.: +49 (0)2624/ 947-317

info@ecref.eu; www.feuerfest-kolloquium.de

1-3 Oct. Pipe & Tube 2013

Conference

in St. Petersburg, Russia

nfo@itatube.org

www.itatube.org

1-3 Oct. TUBOTECH 2013

in São Paulo, Brazil

www.tubotech-online.com

9-11 Oct. 69 th Heat Treatment Congress

in Wiesbaden, Germany

Tel.: +49 (0)421/ 522-9339

www.awt-online.org

I

n June 2012, the Brazilian Forjasul placed the order

for an EloForge induction heater for their Canoas

plant in Rio Grande do Sul. The SMS Elotherm

EloForge is a compact member of the modular

ForgeLine family of induction machines for

heating Forjasuls’s billets up to 51 mm. With the

nominal power of approx. 500 KW the systems

heats up to 1,250 kg steel billets per hour to the

required 1,250 °C.

SMS Elotherm has re-engineered their line of

induction heaters which resulted in a modular machine

system enabling the configuration of the induction

units depending on the production requirements.

Starting with the EloForge for billets with diameters

up to 100 mm the modular systems also allows for

high production lines for slabs up to 240 mm diameter

or even bar material of up to 360 mm OD.

“With this excellent reference for an EloForge

at Forjasul we have the possibility to showcase also

the compact model of Elotherm’s ForgeLine in

southern Brazil”, says Jose Machado, General Manager

of Elotherm’s Brazilian operations. “This latest

order ranges next to a high production billet heater

type EloForge L, which is placed at a world renown

supplier in Brazil”, so Mr. Machado.

Forjasul Canoas S.A. is part of the Tramontina

group and since 1959 pioneering in the field of

forged products for the high voltage transmission

lines, steel industry, shipyard and oil applicationsas

well as hand tool. Their products range from forged

hooks, forged electrical hardware to forged vises, an

exclusive Forjasul product on the Brasilian market.



NEWS

Otto Junker’s strip processing lines commenced

production in Shanghai

Chinalco Shanghai Copper Co. Ltd., a

company evolved out of the Shanghai

Non-ferrous Metals (Group) Co. Ltd., is

a Chinese enterprise with a long tradition

in the manufacture of copper and copperalloy

strip. As early as in the 1990s, Otto

Junker supplied the first strip processing

line comprising a strip flotation furnace to

this customer. In the context of Chinalco

Shanghai’s ambitious project of setting

leading standards in the manufacture of

copper products while simultaneously

expanding their strip processing capacity

from 70,000 to 120,000 t/year, Otto Junker

had recently delivered a state-of-the-art

annealing line built around a strip flotation

furnace, in addition to two strip cleaning

lines. The equipment successfully entered

production service in the summer of 2011.

While the technology and key components

were supplied by Otto Junker from

Germany, a substantial part of the systems

was built locally by Junker Shanghai, a

wholly owned enterprise of Otto Junker.

The strips are annealed continuously with

minimum tensile force at speeds up to 100

m/min, either in air or in a protective gas

atmosphere attaining a residual oxygen content

of as little as 10-22 bar partial pressure.

The protective atmosphere mixing plant,

which delivers a mix of disassociated ammonia

and nitrogen, was likewise supplied by

the German supplier.

Apart from its engineering leadership in

copper strip treatment technology which

Otto Junker has succeeded in maintaining

for many decades, the company’s

local presence yields decisive benefits.

Otto Junker’s sales office in Beijing and its

Shanghai manufacturing site with its service

base ensure a competent and timely

customer service, both in and after the

production launch stage. Chinalco Shanghai

not merely aims to enhance its high

product and service standards but is also

committed to international environmental

protection targets. In line with that policy,

e.g. a number of standards reflecting the

German Water Resources Act “WRA” requirements

were implemented.

Andritz Maerz to supply anode furnaces and converters

International technology Group Andritz has

received an order for supply of two anode

furnaces and four Peirce-Smith converters

for Kansanshi Mining Plc, a subsidiary of First

Quantum Minerals Ltd., Zambia. Start-up is

scheduled for 2014.

The scope of supply includes the latest

Andritz Maerz combustion and refining

systems, slag settling tanks, drive units and

control system, as well as the steel structures

for the furnaces and converters. With the furnaces

and converters, more than 300,000 t

of anode copper can be produced annually

from copper matte.

This order confirms the position of Andritz

Maerz as one of the globally leading suppliers

of fire refining furnaces and converters

for the copper industry.


21

NEWS

Events


Events

NEWS

ITPS - International Thermprocess Summit

for the first time in Duesseldorf

The No. 1 key event and B2B-forum for executives

and the top management is to be

held in the Düsseldorf Congress Centre (Germany)

from July 9 to 10 2013. The 2-day event

is organized by Messe Düsseldorf, VDMA,

CECOF and the magazine heat processing.

The four technology trade fairs GIFA,

METEC, THERMPROCESS and NEWCAST

caused a stir in the industry in June 2011.

With 79,000 visitors from 83 countries and

1,958 exhibitors, the four events provided

impressive confirmation of their position as

the leading trade fairs in their industry. As far

as the corporate exhibitors were concerned,

the good business done both during and after

the trade fairs was a particularly convincing

demonstration of the excellent position held

by the “Bright World of Metals, as the international

technology forum is often known as well.

It was primarily the experts from overseas,

especially those from India, who opened new

sales markets up for the THERMPROCESS exhibitors.

However, since the innovation cycles in

the industry are becoming increasingly short,

Messe Düsseldorf, VDMA (with the German

thermoprocess technology trade association,

Frankfurt), CECOF (European Committee

of Industrial Furnace and Heating Equipment

Associations, Frankfurt) and the trade magazine

“heat processing” published by Vulkan-

Verlag are initiating an International Thermprocess

Summit known as ITPS, a first-rate congress

for which the experts from the industry

are being invited to come to Düsseldorf.

The target group for the event will be

the CEOs and senior executives from the

relevant markets – such key industries as

metal production and processing, automotive

manufacturing, glass, ceramics,

cement, chemicals and petrochemicals.

Messe Düsseldorf Director Friedrich-Georg

Kehrer: “We have a very specific aim here,

which is to bring the users together with

the plant manufacturers and to offer them

a highly professional lecture programme

as well as time for technical discussions.”

Kehrer also points out that both sides will

enjoy tremendous additional benefits from

attending the ITPS as a result of the ideal

combination of networking and opportunities

to talk about technical issues with other

experts from the industry.

The ITPS programme reflects the pressing

issues of our time, with the focus on

sustainability, minimisation of resource

consumption and energy efficiency. These

are particularly tough challenges that the

representatives of the key industries have to

tackle today and in future. The topics include

the future of energy-intensive industries in

Europe, the current economic situation on

the market, technical development trends

in thermoprocess technology and the requirements

made by customers on the manufacturers

(the motto here: “Technological

innovation driven by the customer”).

Alongside the lecture programme, customers

who are interested can act as ITPS sponsors

and present their companies in the foyer

of the Congress Centre CCD South at Messe

Düsseldorf during the Summit. The sponsoring

arrangements are not limited exclusively

to the two days of the event; they also include

a website presence at www.itps-online.com.

The website also incorporates all the Internet

tools that exhibitors and visitors are familiar

with from THERMPROCESS. Admission to

the ITPS costs € 1,500, with a discount for

bookings that are made early: the sooner

the ticket is bought, the lower the price. For

further information please visit:



23

NEWS

Events

indometal 2013: Introducing new showcase

At the first edition of indometal 2013 -

international metal & steel trade fair for

southeast asia scheduled in Jakarta from 20

to 23 February 2013, the exhibition will introduce

a special showcase on machine tool

products, solutions and applications called

“indotools”. This new innovation and dedicated

platform on machine tools will feature

one main category - metal cutting machine

tools, alongside ten sub categories from drilling

machines to surface technology.

indotools is slated to be the bedrock of the

region’s machine tool industry and will offer

all the necessities and innovative solutions

to tooling challenges. Visitors can expect to

maximise the investment in their machinery

and equipment by finding up-to-date technology

that will allow for minimum setup and

machining time and the latest innovations in

metal cutting equipment including machining

centres, turning centres and a comprehensive

range of metal cutting technology.

Dedicated to bringing more business

opportunities directly to both trade exhibitors

and visitors, more effectively by bringing

technology closer to companies and

facilitating their innovation, “The indotools

showcase will extend the spectrum of offerings,

and will be a one-stop business and

sourcing platform for the metal, steel and

ALUMINIUM 2012 shines with new records

machine tool industries in Indonesia and the

region in one unique location,” says Beattrice

Ho, senior project manager.

Located in the exhibition area, the indotools

showcase will complement the seven

key categories which include metallurgy

technology, foundry machinery, equipment

and supplies, semi-finished and finished products,

thermo process technology, accessories

and components, metal cutting machine

tools, and tube manufacturing technology.

For further information please visit:

www.indometal.net

Exhibitor numbers up ten percent, exhibition

surface up 20 % and a visitor plus

of 23 %: for ALUMINIUM which was held in

Düsseldorf for the first time after its move

from the Ruhr to the Rhine, it was the perfect

premiere. With 961 exhibitors from 51 countries

(previous event: 872 from 47 countries)

and 21,300 visitors (17,200) the world’s largest

trade fair of the aluminium industry emphasised

its position as one of the most successful

industry fairs. The move from Essen

where ALUMINIUM had been held since 1997,

occupying 65,000 m² at the last event, had

become necessary to meet the current need

for exhibition space of 78,000 m².

“With the move to Düsseldorf

and the associated

increase in international

participation, ALUMINIUM

has completed its entry into

the first league of industry

fairs “, says Hans-Joachim

Erbel, CEO with organiser

Reed Exhibitions. 60 % of

the exhibitors and more

that half of the visitors came

from abroad; one third of

international visitors came

from countries outside

Europe - a mark of excellence

which demonstrates

that the reach and relevance of ALUMINIUM

continue to increase further. “ALUMINIUM

ideally fits into the ensemble of metal trade

fairs the Düsseldorf location is known for

the world over”, says Markus M. Jessberger,

Event Director of the lightweight construction

trade fair.

The increased internationality also proved

attractive for the entire industry, as

had been hoped during the preparatory

phase. In Germany, the Gesamtverband

der Aluminiumindustrie (GDA) expects

the current financial year as a whole to

remain almost stable, despite a slight drop

in production in the first half: “We do not

expect stagnation or recession “, says GDA

Executive Director Christian Wellner who

talked about an “impressive trade fair”. In

some parts of Europe, however, the drop

in production is felt in the order books,

according to Patrick de Schrynmakers, Secretary

General of the European Aluminium

Association. On the other hand, there are

strong impulses for growth coming from

countries and regions outside Europe. The

increase in the number of visitors from

these regions was particularly pronounced

at this year’s ALUMINIUM.

This is a market situation also reflected

in the business index which is compiled

by a market research organisation in connection

with ALUMINIUM: according to

this survey, currently a third of the companies

interviewed respectively expect

slight increases, a roughly stable development

or an economic downturn in the

industry. In the medium term, however,

more than 54 % of the companies expect

marked increases. Until 2030, the use of

aluminium in the automotive industry

alone is going to treble from today’s five

to then 15 million t.

The next ALUMINIUM, World Trade Fair

and Congress will take place from 7 to 9

October 2014 in Düsseldorf.


Events

NEWS

7 th International Foundry Forum was successful

hinking global – acting local, these

“Tare the investment consequences

for suppliers in consideration of the shift to

Asia on one side and the re-industrialisation

trends in the US as well as in Europe on

the other side” Gabriele Galante, President

of CEMAFON states. More than 240 CEOs

of the world’s leading foundries and their

suppliers from the mechanical engineering

and foundry chemical products industry discussed

with representatives of the main casting

purchasers about future expectations,

challenges and current industry trends at

the seventh International Foundry Forum

– where the CEOs meet – in Prague on

September 21 to 22, 2012. The IFF is jointly

organised by CAEF (The European Foundry

Association) and CEMAFON (The European

Foundry Equipment Suppliers Association).

Internationally leading management consultancies

dissected the investment situation

in the US, Asia and Europe. They determined

the factors important for individual

investment philosophies and came to the

conclusion that there is no investment oneway-street.

Strategically investment plans

cannot simply extrapolate former trends and

growth rates. The decision makers have to

be aware that in the wake of China and India

other nations, part of the so called “Next

Eleven”, are developing fast and these economies

are not all located in Asia. In addition

a new industrial rebuilding trend in the US

caused e.g. on the shale gas exploration is

visible. Furthermore the European Union has

announced a new eindustrialisation strategy.

On the other hand the requirements of

the customer industries are developing constantly

– whether through modified needs of

the market or political conditions: The truck

industry presented future motor concepts

and defined the forthcoming demand. Innovative

castings, multifunctionality and light

weight are the identified relevant contribution

to the energy and CO 2 efficient requirements!

In this context the truck industry

is acting as follower of the passenger cars

industry regarding these specific needs.

While casting requirements in aerospace

need highly specialised foundries for light

weight castings used in extreme conditions,

bionic is one of the upcoming trends. This

could be an advantage for the European

foundry industry: The traditional cooperative

industrial research between foundries,

customers and universities is the best basis

to fulfil these demands.

The off-highway industry, a long standing

customer, is balancing their purchasing

strategies to face the local content interests

of the different world regions. Under these

circumstances the old mantra “castings are

produced where castings are needed” is

still valid. On the other hand new customer

sections are generating. The casting needs

of tidal energy plants are gradually taking

shape. In a few years this could be a new

interesting demand especially for ferrous

and steel castings.

The second day of the conference was

again dedicated to the status and outlook

of the leading casting producing regions.

Speakers of South America, North America,

Japan, Russia, India, China and Europe,

representing more than 90 % of the global

casting production gave an interesting

insight of the major trends and challenges

of the world foundry industry.


25

NEWS

Events


Events

NEWS

HYBRID Expo staged for the first time in 2013 in Stuttgart

With HYBRID Expo, the world’s largest

trade show organiser Reed Exhibitions

further expands its materials trade fair portfolio.

HYBRID Expo, a trade fair for hybrid

materials, components and technology

will premiere next year

in Stuttgart (Germany).

“With HYBRID Expo we

offer the industry another

high-power trade

fair in the future market of

lightweight construction

which dovetails ideally

with the existing materials trade fairs”, says

Hans-Joachim Erbel, CEO of Reed Exhibitions

Deutschland GmbH.

Reed Exhibitions already organises

COMPOSITES EUROPE, European trade fair

for composite materials, and the ALUMINI-

UM world trade fair. With more than 1,300

exhibitors, these two fairs have become the

most successful and fastest-growing lightweight

construction trade fairs in Europe.

Meanwhile both events are also held successfully

in, among other places, Shanghai,

Mumbai, Dubai and Sao Paolo.

Hybrid materials – such as Glare, a glassfibre

reinforced aluminium especially developed

for aircraft construction – combine

several contrasting properties of materials

such as plastics, ceramics, composites and

metal and cumulatively exploit the combined

advantages of the respective materials.

Main users of hybrid components are

the automotive, aerospace and electronics

industries. “This is where the most significant

overlap is to be found with those sectors

already taking advantage of Composites

Europe and ALUMINIUM”, says Hans-Joachim

Erbel. Together, both fairs attract more than

20,000 trade visitors, 40 percent of whom

come from abroad.

Similar to both these fairs, HYBRID Expo

also focuses on the complete

production and value chain:

from materials research and

technology, to manufacturing

and processing methods,

machinery and plant, and

all the way to the finished

component. At the first HYB-

RID Expo event which will be held at the

Stuttgart Exhibition Centre from 17 to 19

September 2013 at the same time as COM-

POSITES EUROPE, Reed Exhibitions expects

150 exhibitors and 6,000 visitors. Altogether,

5,000 m² of exhibition space will be available

in Hall 2. For further information please visit:

www.hybrid-expo.com

Strong future subjects at E-world energy & water 2013

The 13 th E-world energy & water which

will take place at Messe Essen on February

5 to 7, 2013 will consistently place its faith

in pioneering subjects close to the market.

Questions relating to energy efficiency and

innovations will play a superordinate role in

this respect. For example, the megatrend

of “smart energy” will occupy its own fair

hall for the first time at the premier fair in

the energy and water industries. Around

70 exhibitors who will show their innovations

with regard to the main focal points of

intelligently controllable grids (smart grids),

meters (smart meters) or networked house

technology will be expected on an area of

3,000 m 2 in Hall 4.

“smart energy” is a branch of the economy

with a future: First introduced on

the occasion of E-world 2010, this complex

of subjects is encountering ever greater

interest as a source of impetus and innovation

motor for more energy efficiency.

Even now, the “smart energy” hall already

has a very good booking level - only a few

free places are still available. Until now, the

exhibitors will include companies such as

Thüga MeteringService, the IT service provider

Soptim, the energy data management

firm Enexoma, the grid operator Alliander or

Bosch Software Innovations. In the middle of

the exhibition area, a forum with specialist

lectures and podium discussions will offer

the opportunity to obtain comprehensive

information and to exchange experience.

As a supplement to the “smart energy”

section, the “Future of Mobility” special

show will indicate to the visitors how mobility

can be organised in such a way that it is

not only efficient and climate-friendly but

also safe and affordable. In the Galeria, exhibitors

will provide information about “new

mobility” such as bio fuels or electric vehicles

on three days of the fair. The popular

Segway course will once again be a part of

the special show. Further information visit:

www.e-world-2013.com


27

NEWS

Events

Clear Impulses generated by glasstec 2012

Trade visitors look to the future with optimism:

glasstec 2012 sent out clear signals

in an ambivalent economic climate. This was

the general tone expressed by the large

majority of the about 43,000 trade visitors.

Far more than half these specialists assess

the future economic climate in the sector as

positive. The response from the 1,162 exhibitors

at the world’s most important trade

fair in the glass sector also underline this

good mood.

Visitors from the fields of mechanical

engineering, industry, skilled trades,

architects/(facade) planners as well as the

solar sector all gave glasstec 2012 a ‘good

report’. Alongside the positive mood for

the future their ratings in terms of achieving

visiting goals and the quality of the

trade fair range were excellent. Both these

areas scored significantly over 90 %. With

that result glasstec underlines its status as

the world’s leading trade fair with a constantly

high number of international visitors

accounting for well over half of the

audience. Also continuing at the highest

level is the proportion of visitors from mid

to top management who account for over

two-thirds of glasstec attendees. What is

particularly striking is the significantly higher

willingness to invest amongst German

management.

“glasstec 2012 sent out a clear positive

signal for the sector in economic times that

are difficult to predict, and proved its quality

as a fair of innovations and the key meeting

point for the sector,” said Prof. Dr.-Ing.

Udo Ungeheuer, President of glasstec 2012

and Chairman of the Management Board

of Schott AG. “Exhibitors reported good

order activity amongst their customers. This

shows that glasstec came exactly at the right

time. This news does the sector good and

underlines the international importance of

the fair,” commented Hans Werner Reinhard,

Deputy Managing Director at Messe Düsseldorf.

The range of special shows was complemented

by the Skilled Trades Center “Zentrum

Handwerk” – impressively demonstrating

at its glass house the glass solutions

available from the skilled trades for and in

the house – and by the “glass art” exhibition.

Specially designed for auto glass specialists

was the “Autoglass Arena” with its international

auto glass contest and the German

championship plus its comprehensive, specialist

plenary meeting.

Aimed at architects, civil engineers and

related professions were the “engineered

transparency” conference with its technical

focus on glass construction technology

and the architects’ congress featuring

internationally renowned speakers. Already

a day ahead of the fair top-flight experts

from the glass and solar industry discussed

their interfacing markets at the conference

“Solar meets Glass – 3 rd Industry Summit for

Markets, Costs and Technology”. As early as

2013 Düsseldorf will already provide them

with further opportunity to discuss these

issues at the next edition of the conference

on 9 and 10 October. “With this platform we

wish to offer our customers the opportunity

to benefit from targeted specialist exchange

also in the ‘glasstec-free’ year. This means

despite the current economic climate new

sales opportunities can be opened up for

the glass industry in the medium term while

the solar industry can use the know-how of

the glass industry on its path to achieving

greater efficiency levels and lower production

costs,” explained Hans Werner Reinhard.

The next glasstec/solarpeq will be held in

October 2014.

Euro PM2012 - Basel hosts Europe’s PM event of the year

The historic riverside city of Basel hosted

this year’s Euro PM Congress organised

and sponsored by the European Powder

Metallurgy Association. A truly international

event it included delegates from some 40

countries. Although a more focussed event

in its areas of interest, its appeal meant that

it attracted nearly 200 oral and poster presentations

with over 600 attendees.

The event also included a sell-out exhibition

area with 74 stands covering companies

from all parts of the PM supply chain. Jonathan

Wroe, EPMA Executive Director said: “Basel has

proved an excellent and efficient venue for this

event with its focus on MIM, Hard Materials,

HIP and PM Applications. We would like to

thank the EPMA Swiss members, plus the technical

programme committee and delegates

for their support, which is much appreciated”.

During the Congress plenary session

EPMA President Mr Ingo Cremer presented

the EPMA Distinguished Service Award for

2012 to Dr Volker Arnhold formerly of GKN

Sinter Metals GmbH in Germany. In addition

EPMA Thesis awards were presented to

Dr. Catalina Jiménez from the Helmholz-

Centre, Berlin and Mr Bruno Marques who

was studying at Aveiro University in Portugal.

A full social programme included a welcome

reception and factory visits in addition

to the traditional Gala Dinner. This was held

at the elegant Stadtcasino, Basel in the heart

of the city and provided a suitable finale to

an enjoyable and productive event. Work is

already underway for Euro PM 2013 to be held

in Gothenburg, Sweden from the 15 to 18 September

2013. To receive further information

on this and other EPMA events please contact

the EPMA at:

www.epma.com


Events

NEWS

International Heat Treatment & Industrial Furnace Expo 2013

2013 is the glory 10 th year of the International

Heat Treatment & Industrial

Furnace Expo (HTIFE). In order to promote

the development and deepen interaction

within the industry, HTIFE 2013 will be held

at the China International Exhibition Center

on 16 to 18 October, with a new image, the

show will present to new and frequent customers

from home and abroad. HTIFE went

through a decade of trials, this year, is the

year to seek development and innovation.

Based on the previous exhibitions, HTIFE

will integrate industry resources and regional

advantages, improve service system,

strengthen the organization and operational

capability. This edition of exhibition area is

expected to increase by 20 % compared

with the last one, there will be hundreds of

exhibitors from Asia, Europe and Americas

join the event,enterprises and top-class

representatives would be invited to gather

in Beijing to further explore the future of the

thermal processing industry.

Founded in 2004, HTIFE always adhere to

the principle of resource sharing, win-win

benefit, the show displays various products

and devices while focuses on combination

of up and down stream industrial chain

to create a cooperative pattern for project

development, product sales, technical service

so as to deepen international cooperation

and exchange. The traditional thermal

processing industry usher in a broad development

prospects as the rapid progress

of new manufacturing industry like steel,

automobile, equipment manufacturing,

shipbuilding, aerospace in recent years.

Numerous enterprises take advantage of

this favorable opportunity to research and

develop new technologies according to

industry needs, to improve technologies

and product quality, accelerate the pace

of industrial upgrading. Based on domestic

market, the show follows the trend of the

markets, it has become a vital important

platform for trade and exchange among

thermal processing enterprises, and favored

by companies from applications sector.

Powered by

INTERNATIONAL

THERM

PROCESS

SUMMIT

Organized by

ITPS is a unique discussion platform for

international thermo process experts

worldwide!



Dr. Herman Stumpp

President of THERMPROCESS 2011

and Chief Technology Officer of

TENOVA Iron & Steel Group

29

NEWS

Personal

Otto Junker decides upon personnel restructuring

In June 2012, the Otto Junker Foundation,

owners of Otto Junker GmbH, appointed

Dr. Stefan Miskiewicz (President), Dr. Torsten

Bahke and Udo vom Berg new members

of the Board of Trustees. Dr. Ambros

Schindler was appointed a member of the

Foundation‘s Executive Board and of the

Supervisory Board of Otto Junker GmbH.

Otto Junker GmbH have restructured

their Managing Board in the course of their

strategic orientation. In its yesterday‘s meeting,

the Supervisory Board appointed Mr.

Markus D. Werner, former company CFO,

Chairman of the Managing Board with

immediate effect. Mr. Frank Donsbach (47),

Mr. Atilla Somuncu (52) and Dr. Elmar

Westhoff (45) were appointed new members

of the Managing Board. They head the

induction melting equipment, thermoprocessing

plant and high-grade steel foundry

divisions as COOs.

Mr. Markus D. Werner, new Chairman of

the Managing Board, states: „The reorganization

shall further strengthen the company‘s

value-oriented growth strategy. I appreciate

the trust shown in me and my colleagues

by the Executive Board and the Supervisory

Board. We are now facing the exciting challenge

of further strengthening our market

position and technological leadership, filling

our highly-motivated employees with

enthusiasm for our targets and pushing forward

the internationalization.“

Mr. Markus D. Werner supersedes Dr.

Hans Rinnhofer at the head of the company.

Dr. Rinnhofer took over as Chairman of the

Managing Board in August 2008 and was in

charge of the restructuring of the company

as a consequence of the worldwide financial

crisis. The Executive Board and the Supervisory

Board of Otto Junker GmbH wish to

thank him for his work and for the good

cooperation. Mr. Heinz Keweritsch (President

of the Supervisory Board): „We are greatly

indebted to Dr. Rinnhofer.“

Loesche announces Daniel Strohmeyer

to Head of PT

One year upon his leave,

Dr. Daniel Strohmeyer returns to the

Rhine area and has taken over the position

as Head of Process Technology (PT) at Loesche

GmbH starting September 2012.

With even more experience, with new

engagement and highly motivated Dr.

Daniel Strohmeyer re-joins Loesche

GmbH. The management, Dr. Thomas

Loesche and Dr. Joachim Kirchmann

as well as all members of the Loesche

team welcome the former sales manager

back in Duesseldorf.

Dr. Daniel Strohmeyer dedicates

himself to the challenges as head of Process

Technology (PT). Together with his team, the

40year old will initiate and lead F&E projects

to further develop the Loesche technology

and its proven and new applications in various

industries. The optimization of the mill

as well as of plant components with a focus

on the quality of the products produced

with vertical roller mills and on the overall

plant performance are further missions of

the PT department.

For his new activities, the Loesche team

wishes Dr. Strohmeyer all the best and is

looking forward to a successful cooperation.


Personal

NEWS

Bjørn Eldar Petersen is new CEO of EFD Induction

Bjørn Eldar Petersen, a Norwegian executive

with 20-plus years’ experience in

the global automotive industry, has been

appointed CEO of the EFD Induction Group.

Petersen takes over from Eivin Jørgensen,

who, as planned, has stepped down on his

60 th birthday.

“I’m honoured and flattered to be made

CEO of this great company,” said Petersen

from EFD Induction’s corporate headquarters

in Skien, Norway. “In fact, I was once a

satisfied customer of EFD Induction, back

when I was a manager at Kongsberg Automotive

plants in Hvittingfoss and Rollag,

Norway. So I’m already familiar with EFD

Induction, and how its products play key

roles in everything from Formula One cars

to wind turbines.”

A native of Oslo, Petersen earned

an MBA from the Norwegian School of

Management before being recruited by

Kongsberg Automotive, the multinational

manufacturer of driveline systems, power

electronics and other critical automotive

components. Before taking over at EFD

Induction, Petersen lived for more than

three years in China, where he headed

up Kongsberg Automotive’s Asian operations.

For EFD Induction board member Truls

Larsen, Petersen’s overseas experience and

executive role in Asia mesh perfectly with

the Group’s strategy. “EFD Induction is in the

process of becoming a seamlessly integrated

global player. It is a process that will no

doubt be supported by our new

CEO with his strong international

background and outlook.”

EFD Induction Group comprises

19 companies in Europe, Asia

and North and South America.

EFD Induction also has a significant

stake in an associated Canadian

company called Tekna Plasma

Systems.

“These are challenging times”,

comments Petersen. “The global

economic outlook is still uncertain.

But thanks in no small part

to the hard work of my predecessor,

EFD Induction is well

positioned to thrive in a tough

competitive environment. We

have technologies and solutions

that are proven to cut costs and

improve quality for our customers.

And we have the people,

the locations and the resources

to deliver those benefits to customers

around the world.”

A keen sportsman, Petersen enjoys literature

and music, and spending time with

his wife Tone and their three sons. Petersen

formally took over the role of CEO on

October 15.

Thilo Lutz to resume management position at

ThyssenKrupp Steel Europe

Dr. Jost A. Massenberg (56), longstanding

Chief Sales Officer of ThyssenKrupp

Steel Europe AG, is leaving the company

at his own request to take on a new professional

challenge. Effective March 1, 2013

Dr. Massenberg will become Chief Executive

Officer of Düsseldorf/Germany-based

Benteler Distribution International GmbH.

The Executive Board of ThyssenKrupp AG

thanks Dr. Massenberg for his commitment

and dedication to the company over the

past years.

He shall be succeeded on the Executive

Board of ThyssenKrupp Steel Europe AG by

Thilo Lutz (44), currently head of Auto Sales

at ThyssenKrupp Steel Europe AG. Thilo Lutz

is a mechanical engineer who has already

worked in various management positions

for companies of ThyssenKrupp AG for more

than seven years. Before joining the company

he spent many years with the Boston

Consulting Group as a project manager.

The personnel changes are subject to the

approval of the responsible supervisory bodies.


31

NEWS

Book Review

INFO

by Keith L. Richards

October 2012

CRC Press (London)

384 Pages, hardback

£ 82.00

ISBN: 978-1-4398-9275-6

www.crcpress.com

Design Engineer‘s Handbook

Student design engineers often require a

“cookbook” approach to solving certain

problems in mechanical engineering. With

this focus on providing simplified information

that is easy to retrieve, retired mechanical

design engineer Keith L. Richards has written

Design Engineer’s Handbook.

This book conveys the author’s insights

from his decades of experience in fields

ranging from machine tools to aerospace.

Sharing the vast knowledge and experience

that has served him well in his own career,

this book is specifically aimed at the student

design engineer who has left full- or parttime

academic studies and requires a handy

reference handbook to use in practice. Full

of material often left out of many academic

references, this book includes important indepth

coverage of key topics.

This guide has been written not to replace

established primary reference books

but to provide a secondary handbook

that gives student designers additional

guidance. Helping readers determine the

most efficiently designed and cost-effective

solutions to a variety of engineering

problems, this book offers a wealth of tables,

graphs, and detailed design examples

that will benefit new mechanical engineers

from all walks.

INFO

by Franz Beneke,

Bernhard Nacke,

Herbert Pfeifer

Volume 1: Fundamentals,

Processes, Calculations

2 nd Edition 2012

Vulkan-Verlag GmbH

(Essen)

700 pages, hardcover

with DVD (eBook)

€ 200.00

ISBN: 978-3-8027-2966-9

www.vulkan-verlag.de

Handbook of

Thermoprocessing Technologies

The Handbook of Thermoprocessing

Technologies provides a detailed

overview of the entire thermoprocessing

sector, structured on practical criteria, and

will be of particular assistance to students

of all relevant disciplines and to engineers

in this field. The first volume examines the

basic principles, procedures and processes

involved in thermoprocessing technology.

Content of the book: Introduction, Fundamentals

of materials engineering, Heat transfer,

Fuels and combustion, Electrothermal processes,

Energy balances and energy efficiency for

industrial furnaces, Thermoprocesses with gas

recirculation, Furnace atmospheres, Materials

for industrial furnace construction, Appendix.

INFO

by Müller-Steinhagen,

H. U. Zettler

PP Publico Publications

(Essen)

2 nd Edition (2011)

474 pages, numerous

tables, figures

€ 58.00

ISBN: 3-934736-20-3

www.pp-publico.de

Heat Exchanger Fouling

Mitigation and Cleaning Technologies

This handbook presents, now in the 2 nd completely

worked over and enlarged edition,

the most important technologies concerning

the reduction of fouling in heat exchangers

beginning with constructional disposition,

preventional measures and the appropriate

technologies of removal and cleaning.

The authors completely are experts of involved

companies and institutions from the european,

anglo-saxon and american industries. So

the handbook is an instructive advisor for engineers,

maintenance managers and their staff,

technical managers but also for students and

career changers forced to get a rapid overview.

32


Book Review

NEWS


33

CECOF CORNER

News from the European Committee of Industrial Furnace

and Heating Equipment Associations

Flashback CECOF General Assembly 2012

The 40 th General Assembly was held in Vienna (Austria) on

October 05, 2012, attended by delegates from Austria, Belgium,

France, Germany, Great Britain, Italy, Poland, Romania and Switzerland.

The associate members IHEA (US) and JIFMA (Japan) were

also represented.

The meeting focused on market and business trends as well as

the economic situation. In addition, standardisation and technical

issues were discussed.

For the first time, a political keynote was held by Dr. Paul Rübig,

Austrian Member of the European Parliament, covering the Energy

policy in the European Union and the actual situation concerning the

EuP Directive. His lecture and open comments during the discussion

really added value to the meeting and were highly appreciated by

the delegates.

Dr. Walter Böhme (OMV, Austria) gave a trend lecture on „The Role

of Oil and Gas in a Carbon Constraint World“. His lecture explains

that from 2008 to 2035 the European oil demand will have decreased.

However the European Gas demand will have grown by then.

Contrary to the European oil demand, the global oil demand will

grow. Business as usual (BAU) is no option for reducing the global

warming and CO 2 emission.

The „International ThermProcess Summit“, a new event for the

thermo processing industry, created by CECOF/VDMA together with

the partners Messe Düsseldorf and Vulkan Verlag, was presented by

Dr. Timo Würz and Mr. Stephan Schalm to the delegates and was

received with high interest. The congress is intended to fill the gap

between the THERMPROCESS exhibitions and addresses executives

from plant manufacturers and customers‘ sectors, offering a plattform

for information interchange as well as for meetings between

industry specialists.

NEW CECOF PRESIDENCY

Mike Debier resigned after twelve years from his position as President.

Thanking him for his long-standing devotion to CECOF, he

was in unison nominated Honorary President.

René Branders (49), General Manager of FIB Belgium, has been elected

unanimously as new CECOF President. His mandate will last

from 2012 to 2015.

The two Vice Presidents Dr. Karl Nolte (LOI Thermprocess) and

Catharina Lindgren (Sarlin Furnaces) were re-elected for the period

of 2012 to 2015.

Dr. Peter Schobesberger (Aichelin Holding) was elected as member

of the presidency, his mandate lasting from 2012-2015. Enrico

Marranini (Forni Industriali Bendotti) will be holding this position

until 2014, having been elected in 2011.

The next General Assembly will be held on September 20, 2013

in Antwerp (Belgium).

AUTHOR:

Annelie Heymann

CECOF General Secretariat

www.cecof.org

34


CECOF CORNER

News from the European Committee of Industrial Furnace

and Heating Equipment Associations

New CECOF President

René Branders

Date of birth: 29 September 1963

Married, 3 children

Languages: French, English, Dutch and

German

Studies:

• Graduated from the University of Brussels in chemical

engineering in 1986

Career:

• Involved in the wire industry since 1988

• General Manager of FIB since 1996

• Development of technologies related to fluidized bed,

including as main coordinator in the European 5th frame

program “JOULE”

• President of the consultative committee of SME’s of the

national technological federation of enterprises AGORIA

• Member of the national committee SME of the central

federation of the enterprises of Belgium FEB

• Vice President of the Chamber of Commerce of the Walloon

region (Brabant)

• President of the network of alumni at the school of

commerce ICHEC- Brussels

• Member of the board of the IWMA (International Wire &

Machinery Association)

• Expert at the ISO TC 244 – Work Group II

Powered by

INTERNATIONAL

THERM

PROCESS

SUMMIT

Organized by

The Key Event

for Thermo Process Technology



09-10 July 2013 www.itps-online.com

KNOWLEDGE

for the FUTURE

2

free trial

issues

as print or

as e-paper

The international magazine

for industrial furnaces,

heat treatment plants

and equipment

The technical journal for the entire fi eld of industrial

furnace and heat treatment engineering, thermal

plants, systems and processes. The publication

delivers comprehensive information, in full technical

detail, on developments and solutions in thermal

process engineering for industrial applications.

heat processing is published by Vulkan-Verlag GmbH, Huyssenallee 52-56, 45128 Essen Germany

Order now by fax: +49 (0)931 / 4170-492 or send in a letter

Yes, please send me two successive issues of heat processing as trial copies free of charge. If I do

not wish to subscribe, I will give notice within 14 days upon receipt of the second issue at the latest.

Otherwise I am prepared to read the magazine on a regular basis for at least one year (4 issues)

as a printed magazine at the annual price of

€ 166.00 plus shipping (€ 12.00 within Germany / € 14.00 outside of Germany).

as an e-paper magazine (PDF) at the annual price of € 166.00.

as a printed plus an e-paper magazine (PDF) at the annual price of

€ 227.80 (Germany) / € 229.80 (outside of Germany).

Special offer for students (proof of entitlement)

as a printed magazine at the annual price of

€ 83.00 plus shipping (€ 12.00 within Germany / € 14.00 outside of Germany).

as an e-paper magazine (PDF) at the annual price of € 83.00.

as a printed plus an e-paper magazine (PDF) at the annual price of

€ 119.90 (Germany) / € 121.90 (outside of Germany).

Reply / Antwort

Readers’ Service heat processing

P.O. Box 91 61

97091 Wurzburg

GERMANY

Company/Institution

First name, surname of recipient (department or person)

Street/P.O. Box, No.

Country, postalcode, town

Phone

E-Mail

Line of business

VULKAN-VERLAG GMBH


Fax



Date, signature

PAHEAT0412

Please note: According to German law this request may be withdrawn within 14 days after order date in writing at Readers’ Service heat processing, P.O. Box 91 61, 97091 Wurzburg, Germany.

After the first period the agreement can be terminated in writing with 2 months notice to the end of each year. In order to accomplish your request and for communication purposes your personal data are being

recorded and stored. It is approved that this data may also be used in commercial ways by mail, by phone, by fax, by email, none. This approval may be withdrawn at any time.


REPORTS

Energy-optimised heat treatment

by Dominik Schröder

Energy efficiency starts with plant engineering. Burner technology is a key factor. However, even optimum firing system

efficiency will only result in energy efficiency if the process and production are carefully harmonized with the plant and

plant capacity. Conversely, this means that a plant must be purchased specifically for the process and type of production

required. This article presents process optimization possibilities in steel and aluminium heat treatment and also focuses

on capacity utilization, the heating-up curve and dynamic structural transformation processes.

Anyone who has not already started to complain

about higher energy prices will certainly have ample

opportunity to do so in the future. Although no one

can make precise predictions concerning future price rises,

there is no reason to doubt that energy price increases will

outpace the rate of inflation. As a result, energy costs will

account for an ever greater share in total production costs.

For economical production, it will therefore be essential to

ensure that energy is used efficiently. This not only applies

to heat treatment processes in industrial furnaces but to all

sectors of industry and private consumers.

ENERGY-OPTIMIZED HEAT

TREATMENT PROCESS

Initially, energy-optimized heat treatment processes call

for the use of firing systems with optimized design. In

general, industrial users select a firing system with investments

which can be recouped during two or three years of

plant operation. This means that it is not always the most

energy-efficient firing system that is installed. For example,

complex regenerative systems are normally only used for

process temperatures above 1,000 °C. It would be beyond

the scope of this article to deal with this aspect. The firing

system is only a tool for the process, which consists of a

metallurgical structural transformation with the aim of

obtaining specified material properties.

AVOIDANCE OF UNNECESSARY

PROCESS STAGES

Following the austenitizing of steel or the solution annealing

of aluminium, the metal must be „frozen“ in the

solution-annealed condition by rapid cooling. For the hardening

of steel, rapid cooling is also required, producing

martensite, bainite or pearlite structures. Rapid cooling

(„quenching“) is followed by tempering or age hardening.

Especially in the case of the low-temperature tempering of

steels, it is necessary to check whether the quenching stage

cannot be interrupted in a controlled fashion at 250 °C

and the material cannot then be tempered using the residual

heat. The question to be answered is whether the steel is

given sufficient martensitic hardness by quenching to 250 °C.

In addition, it is necessary to consider whether simple

cooling as a tempering process is sufficient to meet the

specified tolerances on the mechanical properties of the

material. Fig. 1 shows the different procedures.

Although latent cooling during the tempering stage is

certainly acceptable because the tempering process is a

function of temperature and duration, „simple tempering“

during cooling can only be used if the material is not allowed

to cool in an uncontrolled way following quenching.

The temperature must not fall below the tempering temperature

required. This means that the material must be

transferred rapidly and heat losses must be avoided. Tem-

Fig. 1: Heat treatment with “separate” tempering (left) and tempering during cooling (right)


37

REPORTS


Fig. 2: Comparison of the specific surface losses of a furnace

plant charged to full and 50 % capacity

Fig. 3: Heating-up curve of a plate with a thickness of

20 mm in a continuous roller hearth furnace

pering may take place in a separate chamber or, in the case

of a continuous furnace plant, also in an insulated tunnel.

However, the tunnel must be closed to avoid heat loss.

CAPACITY UTILIZATION

The heat loss from the surface of any plant is a function of

the process temperature (Fig. 2). The plant must be heated

to the temperature required for the process irrespective of

whether it is charged to full capacity, 50 % capacity or is

even empty. The total surface loss remains constant. With

a plant charged to half capacity, the specific surface loss

is therefore double the figure for a plant operated at full

capacity. In order to save energy, this means that material

flow must be planned in such a way as to ensure that the

full capacity of the plant is always reached. Material and

temperature changes call for careful planning and must

be adapted to the possibilities of the plant.

Considerably more energy can be saved by effective

material flow planning than by further optimization of the

burner system.

AVOIDANCE OF UNNECESSARY

TEMPERATURE PEAKS

The energy which can be transferred is determined by the

surface area of the charge. If too much energy is available,

the excess energy is simply wasted and escapes with the

flue gas.

For example, let us assume that the charge in a continuous

furnace with a length of 80 m is to be heated to

the final temperature when it has passed the first 70 m

of the furnace length. In the first third of the furnace, the

charge has almost reached the target temperature. The

temperatures of the first furnace zones can be set to values

significantly below the target temperature without any

noticeable adverse effect on the performance of the furnace.

However, energy can be saved by reducing flue gas

losses (Fig. 3).

At a furnace temperature of 1,000 °C, a radiant tube can

reach a heat transfer rate of 25 kW/m², corresponding to a

heat output of 50 kW with a radiant tube surface area of

2 m². The efficiency of recuperator burners is typically 68 %.

The burners in the radiant tubes should therefore not be

set to a heat input of more than 73 kW.

PROCESS REVIEW

The purpose of a process review is to investigate whether

the mechanical properties required could be obtained

by a process requiring a lower energy input. For example,

the diagrams below show that different methods can be

used to obtain virtually the same results in the elevated

temperature age hardening of aluminium.

The left-hand graph in Fig. 4 shows mechanical properties

as a function of temperature. The graph on the right

shows the hardness which can be obtained as a function

of treatment time for various process temperatures. The

red mark indicates the mechanical properties which can

be obtained at a temperature of 170 °C with a process

duration of almost 7 hours. The green mark indicates the

mechanical properties with a temperature of 180 °C and

a duration of only 4.5 h. The mechanical properties which

can be obtained are virtually identical. By reducing the

process duration by more than 25 %, it would be possible

either to boost production by 20 % or to use a plant which

was 20 % smaller. Shorter process durations also reduce

time-dependent energy losses.

SELECTION OF THE RIGHT PLANT

The example of a heat treatment plant for aluminium coils

shows that furnaces must be used in a process-centred way.

In multiple-chamber furnaces, several coils are heat-treated

at the same time. In contrast, in a single-coil lifting hearth

furnace, only one coil is heat-treated, using a treatment program

adapted to the size and alloy of the coil. The left-hand

photograph in Fig. 5 shows a multiple-chamber furnace;



REPORTS

on the right, several single-coil lifting

hearth furnaces are installed

in a row.

Coils of the same size made

from the same alloy may be treated

either in single-coil lifting

hearth furnaces or in multiplechamber

furnaces. All the coils of

a batch are heat-treated using the

same program.

Nowadays, companies are

increasingly called upon to meet

individual customers‘ wishes. This

means that there may be significant

differences between the diameters,

widths and sheet thicknesses of coils. There are of

course also variations in the alloys used. If coils of different

sizes and alloys are to be treated together in a multiplechamber

furnace, the program must be selected for the

largest coil with the longest treatment time.

In contrast, single-coil lifting hearth furnaces allow

the operator to select the program that is best suited for

reaching the metallurgical properties specified for the individual

coil. This means that the storage capacity for coils

waiting to be heat-treated can be significantly reduced as

it is not necessary to wait for a group of coils with the same

size and alloy to be assembled for charging into a multiplechamber

furnace. If flexibility is needed for meeting customers‘

requirements, the highest quality standards can

only be reached using single-coil lifting hearth furnaces.

CONCLUSION

Energy saving starts with the selection of appropriate heating

systems. The main objective is for the process to meet

Fig. 4: Relationship between the mechanical properties of

the charge and process temperature and duration

the highest possible quality requirements. Frequently, the

main focus is still on economics at the expense of selecting

the most energy-efficient heating system.

However, effective energy optimization goes far beyond

the selection of the most energy-efficient heating system.

In fact, it starts with the selection of the right furnace plant,

the analysis of optimum process parameters and the operation

of the furnace. If these factors are taken into consideration,

it is possible to ensure energy-optimized heat treatment.

AUTHOR

Dr. Dominik Schröder

LOI Thermprocess GmbH

Essen, Germany

Tel.: +49 (0)201/ 1891-865

dominik.schroeder@loi-italimpianti.de

Fig. 5: Individual-chamber and multiple-chamber furnaces for the heat treatment of aluminium

coils (left: multiple-coil furnaces, right: individual-coil furn)


39

Handbook with

additional media

files and e-book

on DVD

Handbook of

Thermoprocessing Technologies

Volume 1: Fundamentals | Processes | Calculations

This Handbook provides a detailed overview of the entire

thermoprocessing sector, structured on practical criteria, and

will be of particular assistance to manufacturers and users of

thermoprocessing equipment.

In Europe thermoprocessing is the third largest energy consumption

sector with a very diversifi ed and complex structure. Therefore it is split

into a large number of subdivisions, each having a high importance for

the industrial economy. Accordingly we fi nd the application know-how

for the design and the execution of respective equipment represented

by a multitude of small but very specialized companies and their experts.

So this second edition is based on the contribution of many highly

experienced engineers working in this fi eld. The book’s main intention is

the presentation of practical thermal processing for the improvement of

materials and parts in industrial application. Additionally it offers a summary

of respective thermal and material science fundamentals. Further

it covers the basic fuel-related and electrical engineering knowledge and

design aspects, components and safety requirements for the necessary

heating installations.

Editors: F. Beneke, B. Nacke, H. Pfeifer

2 nd edition 2012, approx. 700 pages with additional media fi les and e-book

on DVD, hardcover

Vulkan-Verlag



Yes, I place a fi rm order for the technical book. Please send

___ copies of Handbook of Thermoprocessing Technologies 2 nd edition 2012 (ISBN: 978-3-8027-2966-9)

at the price of € 200,- (plus postage and packing)

___ copies of Handbook of Thermoprocessing Technologies 2 nd edition 2012 (ISBN: 978-3-8027-2966-9)

at the special price of € 180,- (plus postage and packing) for subscribers of heat processing

Company/institution

First name and surname of recipient

REPLY / ANTWORT

Vulkan Verlag GmbH

Versandbuchhandlung

Postfach 10 39 62

45039 Essen

GERMANY

Please note: According to German law this request may be withdrawn within 14 days after order date in writing

to Vulkan Verlag GmbH, Versandbuchhandlung, Postfach 10 39 62, 45039 Essen, Germany.

In order to accomplish your request and for communication purposes your personal data are being recorded and stored. It is approved that this data may also

be used in commercial ways by mail, by phone, by fax, by email, none. This approval may be withdrawn at any time.


Country, Postcode, Town

Phone

E-mail


✘


Fax

PAHTT12012


REPORTS

Process routes for heat

treatment, hardening and

tempering of heavy plates

by Christian Sprung

The great diversity of grades producible today in heavy-plate production requires a huge variety of different equipment

or in fact is only possible with that variety. To manufacture products with highest strength and ductility values,

optimized and high-performance heat treatment equipment is of particular importance. The article tries to give a

principal overview of the possible process routes and the corresponding plant technology. A special focus is put on

the different furnace types used for these purposes and a rough guideline is given on which criteria are decisive in

order to find the ideal solution.

The development of the most different kinds of

steel grades for heavy plate products, driven by

the enormous demand in this sector, has experienced

rapid progress in the last years. In this context,

both the variety of grades available today and the attainable

quality of the material properties, especially as

regards strength and toughness values as a function

of the alloying elements, has increased significantly.

Thus, high-strength and wear-resistant steel grades

are among the bestselling products in the heavy plate

sector. Under economic aspects, another driving factor

of course can be found in the possibility of achieving

a certain strength level using a lower amount of alloying

elements. Furthermore, a reduction of the carbon

content and the alloying elements usually leads to an

improvement in weldability.

Driven by this development, or rather hand-in-hand

with it, the plant technology required for these purposes

has significantly advanced as well. Today, operators can

choose from a wide range of plant technology options.

Taking into account the specific requirements and the

desired range of products, production sites can be provided

with the ideal equipment. Here, the broad range

of products from SMS Siemag AG offers the possibility to

compile an integrated tailor-made solution from one source

for every specific application.

TYPICAL PROCESS ROUTES IN

HEAVY PLATE PRODUCTION

In the production of heavy plate, two basic process routes

can be distinguished: conventional normal rolling and

temperature-controlled rolling. In the case of normal rolling,

the aim is to achieve the required product dimensions with

a minimum of rolling passes and at high output rates. By

contrast, in the process of temperature-controlled rolling,

deformation and temperature control are harmonized precisely

with each other. In the case of the so-called thermomechanical

(TM) rolling, the last passes are executed in the

non-recrystallizing temperature range of the austenite.

Fig. 1 [1] shows a diagram of the further diversifications

of these two process routes after hot rolling.

In the case of normal rolling, three different variants

can be distinguished following the deformation process:

firstly, simple cooling in air and cooling in air followed by

normalizing and cooling in air for a second time (N). Fig. 2

shows the process of discharging a uniformly heat-soaked

plate from a roller hearth furnace after normalizing.

Austenitizing annealing followed by high-pressure water

quenching (Q), represents a further process route. The combination

of both steps is referred to as conventional water

hardening or normal quenching. Following the quenchhardening

process, the final properties of the product can

be set exactly as required by means of temper annealing.


41

REPORTS


Water quenching followed by tempering allows the production

of materials that fulfill even the highest demands

as regards strength and toughness. This process route is

one possibility for the production of high-strength and

wear-resistant steel grades.

Plates can be quenched in two different types of quenching

units. One of them is the batch-operated so called

platen quench. If this quenching station is used, the plates

are stopped after their rapid discharge from the furnace

and clamped by means of clamping jaws. After clamping,

water is applied by means of nozzle pipes, which are arranged

above and below the plate.

In the case of a continuous quench, the plates pass

through the plant without being stopped (although stopping

the plates in a continuous quench is basically possible,

this does not correspond to the plant‘s normal mode of

operation). Therefore, in the case of continuous quenches, it

is possible to make use of different sections, i.e. one section

with maximum water spray density and thus maximum

cooling rates and one section with medium cooling rates.

Fig. 3 shows an example for a continuous quench. The

bottom right side of the figure shows a plate moving into

the intensive cooling section immediately after leaving the

furnace. The major advantage of the continuous quench

as compared to the platen quench is the possibility of

using individual stages with different cooling rates and the

associated implementation of a short section with a higher

cooling intensity. Furthermore, as soon as water is applied

in the case of a platen quench, differences in temperature

will occur between plate head and tail ends that due to the

plant‘s discontinuous operation cannot be entirely avoided.

On the other hand, platen quenches have the advantage

that due to the firm clamping, warping of the plate is largely

prevented. In the case of the continuous quench, this can

only be achieved by very sensitive adjustment of the local

amounts of water applied.

For both types of quenching machines, the actual quenching

process is characterized by very high dynamics. In

doing so, extreme cooling rates are implemented by means

of enormous amounts of water and special nozzle systems.

Monitored and controlled by the plant automation systems,

cooling must take place homogeneously across the entire

length and width of the plate, since even the smallest

variations in the cooling conditions may result in flatness

deviations and warped plates.

In the case of thermo-mechanical rolling, different rolling

strategies can be combined: rolling with subsequent

cooling in air, rolling immediately followed by accelerated

cooling (ACC) or rolling immediately followed by

high-pressure water quenching using a spray cooling

system. The latter is also referred to as „direct quenching“.

Since cooling always takes place immediately after the

rolling process, it makes sense to speak of in-line heat

treatment methods here.

Fig. 1: Schematic overview of the different process options in heavy-plate production

Fig. 2: Discharging of a plate from a



REPORTS

For ACC, plants with laminar cooling are typical. Here,

water is applied to the top and bottom surface of the plate

via a large number of U-pipes. In contrast, in the case of

spray cooling systems, pressurized water is applied by

means of special spray headers. Squeezer roll pairs are

arranged between the cooling headers. They guide the

strip, ensure the controlled application of water onto the

plate and at the same time protect the spray headers that

are installed close to the plate surface.

As regards design, a laminar cooling system is the

simpler solution. Furthermore, less energy is required for

its operation. On the other hand, spray cooling systems

necessarily achieve higher cooling rates. The cooling rates

achieved here are on a similar level as those achieved in

the continuous quenches described above.

Both cooling systems can be used on a stand-alone

basis. However in many cases both systems are combined.

The entry section is executed as a spray cooling

system, which is followed by the laminar cooling system.

Fig. 4 shows an example of such a combined system

arranged directly downstream of the rolling mill. On the

figure, the two different sections consisting of the spray

cooling system for high cooling rates and the laminar

cooling systems for the medium cooling rates can be

clearly distinguished.

The diagram in Fig. 5 summarizes the effects the different

cooling rates have on the final microstructure composition.

The variation „quenching and self tempering“ (QST)

is explained in the following section.

The decision on which of the different process routes

is applied for which final product depends on various

factors. Here, also the various operators pursuit different

concepts and strategies. Direct cooling after the rolling

process has the advantage that quenching is carried out

immediately without having to re-heat the plates, thus

making a significant contribution to reducing the energy

consumption. Furthermore, the microstructure subjected

to the transformation process here is the same that has

been set in a well-targeted manner during the preceding

rolling process. However, the direct connection of rolling

and quenching also involves some disadvantages. For

example, a certain distance must be covered by means

of roller tables between the rolling mill and the cooling

system. That is why with the final pass, especially thin plates

must be discharged from the rolling mill at high speeds of

approx. 150 m/min in order to reach the cooling system

in time (i.e. before the transformation sets in) and to avoid

that the difference in temperature between plate head and

tail end becomes excessive. In the case of „normal quenching“,

the quench can be arranged directly downstream

of the furnace. Thus, maximum speeds of approx. 60 m/

min are sufficient here. This difference becomes apparent

in the design of the plants and their reduced overall length.

Furthermore, during re-heating, the temperatures in the

roller hearth furnace after normalizing

Fig. 3: Continuous quench installed downstream of a hardening furnace;

bottom right side of the figure: plate moving into the intensive cooling

section of the quench


43

REPORTS


Fig. 4:

Combined cooling

plant comprising

a spray cooling

system and a

laminar cooling

system arranged

downstream of a

rolling mill

plate can be set very precisely and with a high degree of

uniformity. That is why in many heavy plate rolling mills,

equipment for both variants is available.

PROCESS MODELS FOR THE HEAT

TREATMENT OF HEAVY PLATE

In the case of the quenching methods described above,

it is also possible to quench only the subsurface zones of

the plate. Here, cooling is stopped in a controlled manner

before the core zones of the plate have reached the martensitic

transformation temperature. The remaining heat in

the core that will re-heat the near-surface zones after the

water cooling has been stopped then leads to a kind of

self-tempering or recovery (Fig. 5). Thus, separate temper

annealing is no longer required, which is desirable especially

as regards optimizing energy consumption. This process is

referred to as „quenching and self-tempering“ (QST).

This cooling variant requires a holistic understanding

of the process and thus an integrated process control of

the temperature curve, the forming process and the subsequent

quenching, respectively the processes of heating

and subsequent quenching. In order to reflect the complex

and to some extent highly dynamic processes, various

mathematical models are used and combined to form an

integrated approach. The motivation for this however does

not only lie in the mode of operation described above.

Also in the case of classical modes of operation, the various

requirements placed on precise process control already

necessitate the application of the respective models. Furthermore,

complex calculations must already be carried out

in advance to achieve an optimum design of the machine,

so that it is ensured that the respective requirements can

be met once the machine is in operation.

A plant‘s energy-efficient mode of operation, controlled

cooling of the plates, forecasting and setting of the

mechanical properties resp. the required microstructure

composition as well as compliance with the narrow flatness

tolerances serve as relevant reference variables for the

simulations and the derived plant control system. In this

context, the plate flatness is calculated „offline“, since an

„online“ calculation would involve an excessive amount of

time and resources required for computing.

Fig. 6 shows an example for the result of a plate flatness

simulation. In the case shown here, the extreme effects

of a head-to-tail temperature rundown in the area of the

plate head are simulated in connection with an otherwise

homogeneous discharge temperature distribution. From

the results obtained, suitable „countermeasures“ can be

derived for the process control of the quenching process.

ANNEALING PROCESSES IN

HEAVY-PLATE PRODUCTION

To be able to select the ideal furnace type for the possible

annealing processes in heavy-plate production, it is

of course necessary to first know the time-temperature

diagram of the respective annealing method.

The typical annealing processes used on heavy plate

after hot rolling are normalizing, hardening and tempering

as well as stress relief annealing in the case of carbon steels

and solution annealing in the case of high grade steels.

The purpose of normalizing is to develop a homogeneous,

fine-grained microstructure in the material. This



REPORTS

method is applied to rectify uneven and coarse microstructures.

In the case of hypoeutectoid steels, the normalizing

temperatures lie approx. 30 to 50 °C above Ac 3 , i.e. at

approx. 900 to 950 °C. In the case of hypereutectoid steels,

the temperatures lie approx. 30 to 50 °C above Ac 1 . The

heating phase is usually followed by a holding phase. In

any case, the material must be completely austenitized.

The hardening process has already been described in

the previous section. The target temperatures to be achieved

usually lie in a similar range as for the normalizing

process. In most cases, a holding phase is intended here as

well. Thus, from the furnace manufacturer‘s point of view,

it makes no difference whether normalizing or hardening

is applied.

The tempering process takes place at temperatures

between the room temperature and below Ac 1 . For lowand

medium-alloyed quenched and tempered steels, temperatures

of 200 to 680 °C are applied. The time for which

the material is held on this temperature depends on the

mechanical properties required. The aim of tempering lies

in the reduction of stresses in the material that have developed

during hardening as well as in setting the desired

technological properties such as tensile strength, yield

point, elongation and area reduction of fracture.

Stress relief annealing serves to reduce stresses in the

material at temperatures below Ac 1 . Common temperatures

for stress relief annealing lie between 450 and 650 °C.

If quenched and tempered material is to be subjected to

stress relief annealing, the required temperature must lie

approx. 30 to 50 °C below the last tempering temperature

in order to avoid any negative effects on strength.

Solution annealing is a heat treatment process which

is used for austenitic steel grades. The material is held at

temperatures of between approx. 1,000 °C and 1,100 °C

for 30 min and subsequently quenched in water. In this

way, carbide precipitations, delta ferrite or sigma phase are

dissolved, and the water quenching prevents the formation

of new precipitation.

SELECTION OF A SUITABLE FURNACE

TYPE FOR HIGH-TEMPERATURE

APPLICATIONS

The annealing methods described above and the resulting

temperature ranges to be covered by the furnace already

define important criteria for the selection of the suitable

furnace type. Furthermore, of course the geometry of the

plate to be treated, i.e. plate width, length and thickness,

as well as production data, i.e. the required capacity, product

range and typical batch sizes, determine the type of

furnace used.

For normalizing, in the case of high plate loads and

large plate widths, basically two furnace types can be used:

chamber furnaces and double walking beam furnaces. This

also applies for solution annealing at elevated temperatures

(if possible, also in combination with high plate loads). As

regards the parameter hearth load, i.e. the combination of

plate load and temperature, these furnaces have almost no

restrictions. In individual cases, also bogie hearth furnaces

are applied for similar sets of requirements.

Chamber furnaces are batch-operated furnaces with

a fixed hearth. These furnaces are characterized by their

high degree of flexibility and are thus typically used in the

Fig. 5: Schematic overview of the different cooling concepts

and their effects on the resulting microstructure

composition

Fig. 6: Simulation of the effects of non-uniform temperatures

on plate flatness during quenching


45

REPORTS


Fig. 7:

Roller hearth

furnace for

hardening and

normalizing

case of low capacity requirements and frequently changing

batches. Depending on the case of application, the hearth

can be subdivided such that heating of the plate bottoms

can be implemented at least in parts of the furnace. On the

longitudinal side, the furnaces are equipped with a large

door. Through this door, the plates are introduced into and

discharged from the furnace by means of a machine. For

plate transport to the furnace and away from the furnace, a

conventional roller table is installed along the longitudinal

side of the furnace.

Double walking beam furnaces are continuously operated

furnaces. That is why they are used for throughput

capacities that cannot be efficiently covered using batchtype

furnaces. In this type of furnace, the hearth consists of

two frame systems each comprising several furnace beams,

covering the entire length of the furnace. Both frame systems

move in an endless cycle consisting of an upward,

forward, downward and backward movement. Here, the

cycle of the two systems are slightly offset to each other.

That is why one part of the furnace beams always is in

contact with the plates, conveying them forwards. During

the conveying process, the plates themselves always are

on the same transport height. The described conveying

method of the double walking beam furnace provides for

a very gentle transport of the plates, since the plates are

in contact with the hearth across their entire surface. Furthermore,

there is no risk of scale sticking to the hearth of

a double walking beam furnace, since the hearth consists

of prefabricated ceramic parts.

For the quenching and tempering of plates, however,

the two furnace types described above are only suitable

to a limited extent. In the double walking beam furnace,

for example, it is not possible to move plates at different

speeds inside the furnace due to the continuous hearth.

Rapid discharging from the furnace, as it is required for the

quenching of thin plates, thus cannot be implemented. In

the batch-type furnace, the plate is exposed to air cooling

for a certain period of time before it reaches the quenching

station. For design reasons, this period of time cannot be

reduced as desired by increasing the discharging speed

of the handling machine. Furthermore, batch operation

necessarily involves temperature differences between the

plate head and tail ends at the beginning of the quenching

process. Thus, both furnace types can be used only if the

planned quenching processes are uncritical as regards time.

This only applies for thick plate or special steel.

A roller hearth furnace is not subject to these restrictions.

The strengths of a roller hearth furnace can thus be

found in variable speeds for the individual plates as well

as in high maximum speeds. That is why in plate rolling

mills, this type of furnace is the one used most frequently

for continuous heat treatment. Fig. 7 shows an example

for a roller hearth furnace. It has a length of 98 m and is

designed for plate widths of up to 3.5 m.

The furnace housing of the roller hearth furnace has the

shape of a long tunnel. The hearth itself consists of rollers

arranged transversely to the direction of transport. The

distance between the rollers must not exceed a maximum

dimension, as otherwise there would be a risk of the plates

„diving“ below one of the rollers. This maximum dimension

thus is determined by the bending behavior of the thinnest

plate at the highest possible temperature. The roller hearth

divides the furnace into a top and a bottom section and

thus provides the possibility of heating from both sides.

The hearth usually consists of high-alloy centrifugal cast

rollers and is the core component of roller hearth furnaces.

On the one hand, the rollers are a decisive factor as regards

the costs of such a furnace system, which again depend to



REPORTS

a large extent on the price fluctuations, especially for the

main constituents Cr and Ni. On the other hand, the rollers

may also impose restrictions on the system design. A sufficient

lifetime of the rollers can only be guaranteed if the

hearth load as a combination of temperature, plate load per

roller and bearing center distance (which again is directly

linked to the plate width) does not exceed certain limits.

For heating, basically two options are available: open

heating or indirect heating via radiant tube burners with

the furnace chamber being rendered inert using nitrogen.

The second option is preferably used where scaling of the

plates is to be kept as low as possible (even when using

nitrogen, it is not possible to generate an entirely oxidationfree

atmosphere, since the opening of the furnace doors

during the charging and discharging process as well as

the plates themselves lead to the introduction of moisture

into the furnace chamber, so that no sufficiently low dew

point values can be attained). Surface qualities showing

only a low degree of scaling are for example desirable for

the quenching process, since otherwise, the scale would

negatively affect the homogeneous cooling conditions

and heat transfer coefficients at the boundary layer between

water and plate. The diagram in Fig. 8 shows the

cross-section of a roller hearth furnace with radiant tubes.

For indirectly fired furnaces, however, significantly higher

investment costs and additional operational costs must be

expected due to the nitrogen consumption. The higher

investment costs result from the radiant tubes, the flame

tubes, the recuperator burner, the gas-tight doors and

attached roller bearing assemblies as well as the equipment

required for nitrogen injection. Furthermore, these

furnaces must be designed with an increased length, since

due to the rapid introduction and discharging of the plates

(the doors may only be opened for a short while to avoid

excessive ingress of oxygen and moisture), useful furnace

length is lost.

Furthermore, it must be considered that due to the

mode of operation described above, temporarily, large

sections of the furnace hearth are not occupied, which

necessarily leads to increased specific energy consumption.

(This issue of suboptimal hearth utilization also applies for

all other types of heating furnaces.) If a heat treatment

process has to cover several tasks, it thus must always be

checked whether it would be more cost-efficient to allocate

the individual types of heat treatments to different furnaces

instead of using a single large furnace with expensive

equipment for all tasks. This would be the case for example

if a large number of plates has to be normalized (no particular

requirements on the scaling behavior) and only a

smaller number of plates requires hardening.

In the case of indirect heating, the radiant tubes are

equipped with recuperator burners. In the case of furnaces

with an open firing system, however, it is recommended

to install high-velocity burners arranged transversely to

the flow of material which can be operated in an on/offmode.

Thanks to this cycle operation, good convection is

ensured on both sides, which is particularly important in

the case of low temperatures – e.g. during tempering – in

order to attain good temperature uniformity. In this way,

when normalizing carbon steels (i.e. target temperatures

of between 900 and 950 °C) and plate thicknesses

REPORTS


Fig. 9:

Combination of

hardening furnace

and tempering

furnace with the

pertaining roller

tables

exhaust gas leaves the furnace at lower temperatures. Thus,

if the temperature in the entry section is reduced, a system

with a state-of-the-art central recuperator can be operated

at the same gas consumption rates as an installation with

recuperator burners. The situation is different, however, if

the furnace is charged with preheated plates and thus the

target temperature can be defined as setpoint across the

entire length. Here, the gas consumption can be reduced

by using recuperator burners.

SELECTION OF A SUITABLE

FURNACE TYPE FOR LOW-

TEMPERATURE APPLICATIONS

When tempering plates, the roller hearth furnace with an

open heating system is under almost all circumstances

the best choice. At the lower temperatures, even high

specific hearth loads can be handled with a roller hearth.

Scale formation is no issue in this tempering temperature

range either, as a significant quantity of scale only begins

to form at higher temperatures. The exact temperature

pattern with highest degrees of uniformity in the plate can

easily be attained when heating the roller hearth furnace

from both sides.

If required, the open heating system can be extended

by a so-called exhaust gas jet. As a general rule, for tempering

a higher temperature uniformity is required than

for normalizing. On the other hand, the temperature level

on a whole and thus also the heat portions which enter

the material by heat radiation are lower than during normalizing.

For this reason, it is important to ensure a good

convection in the furnace. When a tempering furnace is

operated at operating points which are at the upper level

of its design values, i.e. at maximum temperature and maximum

throughput, a sufficient convection is ensured by the

frequent on/off-cycles of the burners. If the temperature

level in the furnace and the throughput are at the lower

level of the design parameters, an increase of convection is

recommended. For this purpose, parts of the exhaust gas

which have left the furnace and have passed the central

recuperator can be returned to the furnace and be injected

via nozzles. This has two effects: On the one hand, the

injected gases directly increase convection in the furnace

chamber; on the other hand, the activities of the heating

system are enhanced as the injected exhaust gas has a

lower temperature than the atmosphere in the furnace

chamber and must therefore be heated up again. The

resulting increased burner activity is in turn equivalent to

more convection. By means of this very simple system it is

possible to attain a temperature uniformity of within 3 °C

over the thickness for plate thicknesses


REPORTS

temporarily) they can normally not be used at all or only

with considerable expenditure for the materials used for

applications with temperatures >900 °C.

Whether both high-temperature and low-temperature

applications are realized with one furnace only decisively

depends on the product range and on the space conditions

in the production bay. As a general rule, a change between

high-temperature and low-temperature operation always

results in a loss of useful production time, as a furnace naturally

requires a certain time until the modified temperature

level has adjusted itself. Moreover, a temperature change

from low to high temperatures is always accompanied by an

energy loss as the refractory lining has to be heated up to the

required temperature. If high portions of high-temperature

and low-temperature applications are to be realized within

one product range, it is advisable to allocate these two tasks

to two furnaces. Fig. 9 shows an example for such an arrangement.

On the right side of the figure the hardening furnace

and on the left side the tempering furnace can be seen.

The figure does not show the quench, which is installed

downstream of the hardening furnace.

CONCLUSION

Today, where increasingly efficient plate materials are

developed, a growing variety of manufacturing processes

is available, the general requirements on the quality

of the final product are continuously rising and the focus

is increasingly laid on energy-efficient production, special

attention must be paid not only to the technical efficiency

of individual components but to the planning and layout of

the complete plant. The question which processes can be

performed best with which individual units and/or which

processes can be combined in one unit must be examined

in detail. There is no ready-made solution, as a multitude

of specific factors, such as product range, lot sizes, space

conditions, material flow, investment costs, maintenance

expenditure must be taken into account in each individual

case during the planning phase. An optimum and tailormade

solution can therefore vary considerably depending

on the respective task to be performed.

LITERATURE

[1] Streißelberger, A.; Schwinn, V.: Die Grobblechherstellung aus

verfahrenstechnischer Sicht. Stahl-Informations-Zentrum,

Dokumentation 570, 2001

[2] Heavy-plate production from the point of view of process

technology. Steel Information Center, Documentation 570,

2001

AUTHOR

Dr. Christian Sprung

SMS Siemag AG


christian.sprung@sms-siemag.com

Tel.: +49 (0)211/ 881-6724

Hotline Meet the team

Managing Editor: Dipl.-Ing. Stephan Schalm +49(0)201/82002-12 s.schalm@vulkan-verlag.de

Editorial Office: Annamaria Frömgen +49(0)201/82002-91 a.froemgen@vulkan-verlag.de

Editor: Silvija Subasic +49(0)201/82002-15 s.subasic@vulkan-verlag.de

Advertising Sales: Bettina Schwarzer-Hahn +49(0)201/82002-24 b.schwarzer-hahn@vulkan-verlag.de

Subscription: Martina Grimm +49(0)931/41704-13 mgrimm@datam-services.de

Hotline_184,5x35.indd 2 15.12.11 15:13


49

Arabia Essen 2013

Welding & Cutting

International Trade Fair Joining, Cutting, Surfacing

Supported by:

Tekno Arabia 2013

International Trade Fair for Industrial Machinery,

Sheet Metal, Metal working, Machine Tools & Die Moulds

Tube Arabia 2013

International Trade Fair for the

Tube & Pipe Industries

Supported by:

7 – 10 January

Dubai International Convention & Exhibition Centre,

Dubai, UAE

In co-operation with:

In conjunction with:

ARABPLAST 2013 and

COMPOSITE Arabia 2013

Messe Düsseldorf GmbH

P.O. Box 10 10 06

40001 Düsseldorf

Germany

Phone +49/211/45 60-77 93

Fax +49/211/45 60-77 40

RyfischD@messe-duesseldorf.de

www.messe-duesseldorf.de


REPORTS

Single-billet induction

heaters meet the most

exacting demands

by Günter Valder

Otto Junker GmbH offers both gas-fired heaters (GBE/ KombiGAS) and induction heaters (IBE) for reheating extrusion

billets. This paper presents the available range of induction-type billet heaters and their advantages. The description

is supplemented by a review of the handling systems employed from the billet or log feeding station to the point of

billet transfer to the extrusion press. Calculations of operating costs and CO 2 emissions are given for diverse materials

and key European countries, and some current reference projects are mentioned to round out this presentation.

In a heater of the type “Induction billet heater” (IBE), the

part responsible for heating the extrusion billet consists

of a water-cooled coil wound in multiple layers. The

shape of this coil is adapted as closely as possible to the

billet geometry for maximized efficiency, Fig. 1. Energy

is transferred as the magnetic field produced by the coil

induces a current in the aluminium billet and thereby

heats it. In a single-billet heater, more than 1,000 kW of

electric power can be transferred per m² of product surface,

irrespective of the billet surface condition (as-cast

skin / scalped).

As a result of these features, this heater is characterized

by high heat-up rates and comparatively low space requirements

for the heating unit, i.e., the coil. On the other hand,

the electric power supply and the indispensable cooling

system need additional space which must be taken into

account in layout planning. Temperature control quality

depends on the number of control zones; Otto Junker

warrants a reproducibility of the heating process to within

+/- 5K, Fig. 2. The temperature measurement carried out

for this purpose is performed in the 12:00 o’clock position;

this prevents the billet from moving upon application of

the thermocouples and ensures a defined contact configuration.

Wear of the thermocouple tips needs to be

addressed by maintenance personnel at regular intervals

of time. The company has significantly increased these

intervals by the so-called “blind heating” approach whereby

the thermocouples are applied only in the critical phases,

i.e., at the start and end of the heating cycle. All additional

information is calculated via a mathematical model coupled

to the IGBT frequency converter.

INDUCTION BILLET HEATER (IBE)

Since only a single billet is heated at a time and the high

power density mentioned earlier leads to short heating

times, the IBE system exhibits the highest flexibility among

all other known billet heaters. As virtually no heat is stored

in the system, temperature changes in either direction may

be effected at any time, and the minimum contract lot size

becomes „1“ from a heating point of view. Another major

advantage of an induction heater lies in its ability to apply

an axial temperature profile („taper“) to each billet. Induction

heaters of Otto Junker design achieve this goal, again,

with a reproducible temperature accuracy of +/-5K, Fig. 3.

Such taper heating is employed chiefly in direct aluminium

extruding applications. Direct extrusion means that

friction forces will be acting on the press container enclosing

the billet. The friction work needed to overcome these forces

is fully converted into heat, most of which goes into the

billet. Consequently, the billet temperature and hence, the

temperature of the extruded semi-finished product will rise

as extruding proceeds at a constant speed. However, since

the dimensional stability, surface quality and microstructural

properties of an extruded semi-finished product are

essentially a function of temperature, the aim is to keep the

temperature of the extruded product constant throughout

the process. In order to achieve this, either the extrusion

speed (and hence, press throughput) must be progressively


51

REPORTS


Fig. 1: Front view of a taper-heating plant built

to the point of billet transfer

into the extrusion press.

Always included in the basic

scope of supply is a product

tracking capability that supports

documentation and

archiving of all production

data (target & actual) so that

the requirements of modern

quality management will be

fulfilled.

At this point, special

mention should be made of

several devices which have

been enjoying brisk demand

of late and are often supplied

along with the billet

heater:

reduced or else it needs to be ensured that the billet already

exhibits an opposed temperature profile, the so-called taper,

beforehand. Today, tapers of up to 100 K per m of billet length

can be realized. It is state-of-the-art practice to calculate

the necessary taper with the aid of mathematical models

integrated into the extrusion press and to redefine it, from

one billet to the next, on the basis of measurement readings.

These calculations may even call for a non-linear taper, which

can likewise be produced with an induction heater.

The energy efficiency attained in the induction heating

process depends on the magnetic and electrical properties

of the material to be heated. The underlying physical

interrelationships are too complex to review in this context.

However, as an engineering “rule of thumb”, it may be stated

that the energy efficiency of an induction heater operating

at a constant frequency will be the better, the lower

the thermal conductivity of the charge material (Table 1).

The use of variable power and frequency IGBT (insulated

gate bipolar transistor) converters is now state-of-the-art.

Otto Junker, benefiting from synergy effects gained

in the manufacture of induction-heated coreless melting

furnaces, has been using a proprietary IGBT converter technology

that has proven its merits in over 100 installed systems

since 2004. Like the induction heater itself, every IGBT

converter cabin is built – without exception – at the Lammersdorf

factory and subjected to testing and adjustments

together with the induction heater before shipping so as

to reduce the commissioning effort at the customer’s site.

RANGE OF PRODUCTS

Naturally, apart from these billet heaters, Otto Junker

also supplies all billet handling equipment tailored to

on-site conditions, from the billet or log feeding station

■ Especially when processing aluminium logs, it has

remained a challenge to minimize the amount of scrap

produced by the sawing or cutting operation. By combining

a log welder with a cold saw, it is possible to

avoid the formation of scrap altogether, except for the

inevitable sawing swarf.

■ Before the welding operation, the log ends are moved

flush against each other and clamped in such a manner

that no air gap remains and zero radial offset is obtained,

if at all possible. In this way, air inclusions are avoided to

the maximum possible extent (Fig. 4).

At the customer’s request, test welds can be carried out

to make trial extrusions which can then be evaluated in

preparation of an investment decision.

The „narrow cut“ design (twin-blade cold saw) helps

to reduce losses in the form of low-value swarf substantially.

Due to the saw blade thickness of only around 3 to 4

mm, a very thin cut is obtained compared to conventional

single-blade saws. The two saw blades are mounted in a

common frame and can be individually adjusted so that

no undesirable steps will form on the sawn surface (Fig. 5).

Ideally, the logs supplied to the saw are taken from a vertical

log magazine (Fig. 6). Its log storage capacity, with a strict

separation between material grades, is much larger than that

of a horizontal magazine. Needless to say, logs withdrawn for

production may also be put back into storage, e.g., if a job is

to be aborted, and re-used at some later date. The requisite

software is developed and commissioned by our engineers.

OPERATING COSTS AND EMISSIONS

From the operator’s viewpoint, the only disadvantage

of an induction heater lies in the operating costs to be

factored into the payback calculation. These are higher



REPORTS

than for a system relying on fossil energy.

However, the drawback of higher

CO 2 emissions tends to be relevant only

at the national level as the specific electricity

mix of a given economy needs

to be considered here. For Germany as

an industrial location, it remains to be

seen how specific CO 2 emissions will

develop in the next few years in view

of the recently adopted phase-out of

nuclear power and the country’s shift

in focus towards regenerative energies

(Table 2).

As regards electricity prices, their

direction appears clear: regenerative

energy is currently more costly than

nuclear power, and fossil energy costs

can hardly be expected to come down

in the long run if only because of the

limitation of resources. This makes it

more difficult to justify the use of electrical

(instead of fossil) energy in extrusion

technology from an economic

viewpoint, to say nothing of the significant

operating cost drawbacks which

already emerge today when comparing

the German situation to countries with

similarly high labour costs (e.g., France

or Sweden), Table 3.

In calculating investment payback

periods it is therefore recommended to

consider not just the energy demand of

the induction heater per tonne of heated

aluminium but to relate this energy consumption

to the actual product output

obtained downstream of the extrusion

press. The higher yield will then justify

the use of an induction heater. Key arguments

in favor of the induction billet heater

include the following:

fewer quality defects through accurate,

reproducible temperature control, i.e.,

fewer rejects -low number of billets in

the system at any given time, i.e., if a job

is aborted, only one excess billet will be

heated (contrary to the situation with a

multi-billet heater).

CONCLUSION

The use of an induction heater based

on IGBT technology, whether as a standalone

unit or operating in series with a

fuel-fired preheater, provides significant

Billet temperature [°C]

Temperature [°C]

600

570

540

510

480

450

420

390

360

330

300

270

240

210

180

150

120

90

60

30

Sheathed thermocouple measurement on IBE

D billet = 380mm, L billet = 1500mm,

Heater target temp.: 530 °C, throughput: 7.35 billets / h

0

0 30 60 90 120 150 180 210 240 270 300 330 360 390 420 450 480 510 540 570 600

Kurve_IBE_OF_(E)

Time [s]

Fig. 2: Power-controlled heating of an aluminium billet to 530 °C

± 5K at a maximum temperature head of +20K

490

480

470

460

450

440

430

420

410

400

Measuring station control reading on IBE

D billet = 380mm, L billet = 1500mm,

Measuring station target temp.: 470 - 390 °C, throughput: 7.80 billets / h

Coil projection 50 mm

Kurve_Taperheating_IBE_OF(E)

Core TSP 1

Sheath TSP 1

Core TSP 2

Sheath TSP 2

Core TSP 3

Sheath TSP 3

Core TSP 4

Sheath TSP 4

Core TSP 5

Sheath TSP 5

Core TSP 6

Sheath TSP 6

Furnace target temp.

390

0 100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700

Coil length [mm]

Meas. station target temp. [°C] Max. tolerance [°C] Min. tolerance [°C] Billet 1

Billet 2 Billet 3 Billet 4 Billet 5

Billet 6 Billet 7 Billet 8 Billet 9

Billet 10 Billet 11

Billet length 1500 mm

Fig. 3: Result of the check-up measurement, conducted before the

aluminium extrusion press, of a linear taper set to 50 K/m

Table 1: Power consumption of an induction heater wirh multi-layer coil and IGBT frequency

converter

Specific energy consumption Aluminium Brass Copper

Final temperature without taper 480 °C 800 °C 950 °C

Specific enthalpy of charge

material

130 kWh/t Al

99 kWh/t Ms

113 kWh/t Cu

Power consumption of IBE ≈ 215 kWhel/t Al

≈ 152 kWhel/t Ms

≈ 202 kWhel/t Cu

Energy efficiency of IBE 60,5 % 65,1 % 55,9 %


53

REPORTS


Table 2: Comparison of CO 2 emissions based on national electricity mix

[Eurostat, 2007]

Table 3: Comparison of operating costs on the basis of

average electricity prices [Eurostat, 2009]

Specific CO 2

Specific operating

costs

Aluminium Brass Copper

emission

Aluminium Messing Kupfer

Sweden < 0,001 t CO2

/t Al

< 0,001 t CO2

/t Ms


REPORTS

Purpose-directed hot zone

and cooling-gas stream design

of vacuum furnaces

by Björn Eric Zieger

The heat-treatment processes of various components and loads have most different requirements reg. uniform components

cooling as well as for high quenching speed. Rectangular hot zone design with large scale gas through-streaming is

still and again for many standards and also for special loads recommendable. In this way gas through-streaming, which

corresponds to load plain, can even take place from various directions and with flow reversal. Round hot zones design

with nozzle cooling can offer, however, advantages through higher cooling capacity for hardening processes of large

size components.

The development and application of heat treatment

of metal tools and components has made significant

progress since the eighties, these days constituting

a fixed component of heat treatment in-house and on

sub-contracting.

Annealing processes, hardening, tempering, sub-zero

treatment, high temperature brazing and possibly thermochemical

processes can be reproducibly performed in

modern vacuum furnaces, fully automatically and without

supervision.

SINGLE CHAMBER VACUUM FURNACE

TYPES

Single chamber vacuum furnaces may basically be grouped

into three different types:

■ Chamber furnaces (horizontal, front loading design)

■ Bottom loader (vertical, with lifting platform)

■ Top loader (vertical shaft furnace).

Globally, the horizontal front loading vacuum chamber

furnace is the most commonly deployed furnace (Fig. 1). Its

main advantage lies in its high flexibility. This space-saving

design makes low demands on the location for installation.

BASIC VACUUM FURNACE DESIGN

Vacuum furnaces are electrically heated and designed

according to the “cold wall” system – i.e. with doublewalled

water-cooled furnace shell. This reduces the thermal

load on the metal furnace housing, since the no-load

losses are conducted to the cooling water in the jacket. The

generally cylindrical external housing may be of horizontal

or vertical design.

Inside the furnace there is the hot zone chamber with

insulated lining and heating elements as well as the rapid

cooling system with heat exchanger. The high performance

radial fan and electric motor are also installed inside the

chamber. On special furnaces the rapid cooling device may

also, however, be fitted externally.

The vacuum pumps, heating transformer and cabinet

are fitted outside the furnace.

HEATING SYSTEMS AND VERSIONS

Vacuum furnaces are predominantly heated with graphite

heaters operating at low voltage and high current. The

current enters the interior via vacuum- and pressure-tight

feed-throughs and lug bolts welded into the wall of the

vessel and then via insulating ceramic bushes into the hot

zone. The conductors are here solidly connected to the

heater in the hot zone.

It is important when heating up a vacuum furnace that

the load is heated uniformly to avoid distortions even in

the first phases of the heat treatment process. The practical

standard which has proven itself for most processes today

is single zone heaters. Multi-zone heaters are also found

for special applications. In addition to door and rear wall

heaters, these may also feature additional central heaters

or a combination of both (Fig. 2).


55

REPORTS


Fig. 1: Horizontal vacuum chamber furnace Type I

Fig. 2: Graphite insulated hot zone with central heaters

HOT ZONE

The hot zones of most heat treatment vacuum furnaces

are lined with graphite insulation. The hot zone may be

rectangular or round.

The heat treatment temperature for metal work pieces is

1,250 °C max., requiring a maximum temperature of 1,350 °C

to 1,400 °C for vacuum furnaces. Applications in the sintering

industry, however, may require temperatures of up to

1,600 °C. But even temperatures in excess of 2,000 °C are

achievable in vacuum furnaces.

All-metal hot zones are used for special applications

and requirements for carbon hydride-free atmospheres.

Several serial radiation shields made of molybdenum and /

or heat-resistant materials are used for insulation with these

heating elements. The application temperature determines

the number of radiation shields and their material. These

hot zones may be rectangular or round, as required (Fig. 3).

HIGH PRESSURE GAS QUENCHING

Depending on the requirements for the heat treatment

charge and materials, various cooling mechanisms are possible,

such as heating down by gradient, vacuum cooling

by temperature losses, gas cooling with static gas and high

pressure gas quenching.

REQUIRED COOLING RATE FOR HIGH

PRESSURE GAS QUENCHING

For high pressure gas quenching, the furnace is flooded

with protective gas (for steel hardening, usually nitrogen)

at a preselected pressure. A cooling fan unit comprising an

AC motor with fan streams cooling gas through the entire

load via open flaps or nozzles. The protective gas absorbs

the thermal energy of the charge, carrying it away to an

internal gas-water heat exchanger in the vacuum furnace

plant (Fig. 4).

The required cooling rate with high pressure gas quenching

in a vacuum furnace depends on many factors. The

quenching rate is determined not only by the preselected

pressure and properties of the quenching gas. The vacuum

furnace design has a significant effect on the quality of the

quenching procedure, e.g.:

■ Size of the hot zone

■ Size of the gas inlet apertures – should match the

dimensions of the useable volume, if possible

■ Cross sections for cooling gas flow

■ Gas volume flow – depends on motor output and fan

size

■ Gas-water heat exchanger – design and output

■ Cooling water supply – volume and temperature

■ Technical options such as multi-directional cooling and

all-round cooling.

This generally means that quenching with e.g. 6 bar in

vacuum furnace Type A cannot be compared with 6 bar

quenching in vacuum furnace Type B.

MULTI-DIRECTIONAL COOLING SYSTEMS

These days, different cooling systems provide for many

quenching options for a variety of components, to achieve

optimal results in terms of hardening and dimensional

stability.

The direction reversal through-flow principle has proven

itself in many typical vacuum furnace hardening processes.

Large inlet and outlet apertures that match the load

dimensions are required for high consistency of cooling.



REPORTS

These gas inlet and outlet apertures are fitted with special

gas distribution elements or nozzles.

The homogeneity of gas quenching may be improved

through programmable vertical and/or horizontal direction

reversal of the cooling gas stream. Vertical cooling gas

through-flow is recommended, among other, for hardening

of vertically arranged charges such as tool plates, drills,

valve pistons, etc. (Fig. 5).

Horizontal cooling gas through-flow is used typically

for cooling of plate heat exchanger loads, for instance.

This achieves fast and uniform cooling of the entire load

in all areas.

*2x2R* systems (Fig. 6) allow both reversal from horizontal

to vertical cooling within a cooling phase as well as

rotational cooling. The gas direction reversal may be controlled

by time or by temperature, depending on the requirements

of the material for heat treatment. Temperaturecontrolled

reversal of gas flow may be regulated by actual

temperature differences measured by thermocouples.

Quenching will be more even, with significantly reduced

distortion of components. This also achieves faster and

therefore more economical cooling of the load. The development

of the multi-directional *2R* and *2x2R* cooling

systems resulted in clearly reduced differences of temperature

within a load, as compared to single-directional

cooling. This significantly minimises component distortion.

NOZZLE COOLING SYSTEM

In vacuum furnaces with round hot zone, the cooling gas

stream is simultaneously distributed onto the surface of

the load 360° all-round before exiting at the back of the

heat exchanger (Fig. 7). In some furnace designs the gas

stream can be also forced to flow additionally through

nozzles in the front door area. A round hot zone with 360°

all-round radial nozzle cooling system has some advantage

for vacuum heat treatment processes such as hardening

of bulk charges or very large components, e.g. massive die

casting dies. The impinging cooling gas stream may be a

disadvantage in the case of several components arranged

one behind the other, or possibly upright arranged slim

components.

The achievable cooling rates in individual types of furnace

depend on factors as previously mentioned, such as

quenching pressure, quenching gas, rapid cooling system

design (cooling gas circulation motor, fan design, gas/water

heat exchanger), cooling water supply and furnace type.

Also the size of furnace has a significant effect on achievable

cooling speed of identical components. For identical

components shorter cooling times are reached with smaller

furnace sizes by trend.

For heat treatment of die casting dies, for instance, the

cooling rate is determined by comparison with measurements

on a test block (406 x 406 x 406 mm - 560 kg net)

Fig. 3:

Round molybdenum

insulated hot zone

Fig. 4: Basic layout of gas quenching in a vacuum furnace with rectangular

hot zone

Fig. 5:

Mass production of valve

pistons in the vacuum

furnace


57

REPORTS


in accordance with NADCA (North American Die Casting

Association) standard. The cooling rate is in this case determined

in the range 1,038 °C to 540 °C, using thermocouples

at defined positions on the test block surface and with a

prescribed minimum cooling rate > 30 K/min.

In this respect, the *RD* nozzle cooling system achieves

component cooling rates by far in excess of the NADCA

standard requirements and is therefore also capable of

comfortably meeting future requirements.

A corresponding vacuum hardening furnace of smaller

size 600 x 900 x 600 mm achieves with 10 bar (abs.) quenching

pressure some peak values clearly > 120 K/min at

some surface sides of the test block. A large size vacuum

furnace (1200 x 1500 x 1000 mm) exceeds the requirements

of NADCA even with an average value of 40 K/min for all

6 surface sides.

The new *RD PLUS* concept of nozzle cooling in a

vacuum furnace with round hot zone offers once more

optimized and more uniform cooling gas streaming. A

corresponding vacuum hardening furnace of size 900 x

1200 x 700 mm ( w x l x h) reaches an average value of 60

K/min for all 6 surface sides of the described test block with

10 bar (abs.) quenching pressure.

Increasing the quenching pressure from 10 bar to 13

bar (abs.) a further advance of approximately 15 % higher

cooling speed is to be expected.

Fig. 6: Multi-directional cooling system *2x2R*

CONCLUSION

The integration of vacuum heat treatment in small and

major series production demands high flexibility in terms

of plant technology. The relevant processes are rapidly

adaptable to other components. The fully automatic cycle

implements flawless and reproducible processes. Uniform

heat treatment of the entire load is assured by the use of

load thermocouples. High reproducibility reduces the cost

of testing to a minimum.

A universal solution comprising furnaces with rectangular

hot zone design and linear or possibly reversible cooling

gas through streaming is recommended for most typical

vacuum heat treatment processes.

A round hot zone design with nozzle cooling may be

advantageous for large size components to improve maximum

cooling rates. Today`s market demands are already

clearly exceeded in this respect.

AUTHOR

Fig. 7: Round hot zone of a vacuum furnace with *RD*

nozzle cooling system

Dipl.-Ing. Björn Eric Zieger

Schmetz GmbH

Menden, Germany

Tel.: +49 (0)2373/ 686-184

bjoern.zieger@schmetz.de



REPORTS

Infrared drying with porous

burners in industrial

environments

by Michael Angerstein

The use of gas infrared burners in general provides huge advantages in many drying and heating processes. Porous

burners, being the only short-wave gas infrared burners in the world, are quite special in this regard. The particular

features offered by porous burners will be addressed further down in this article.

They are ready for operation in just a matter of minutes,

meaning that the long heat-up phase needed

with many convection heaters is no longer necessary.

And yet, when using gas infrared burners, the heat transferred

is often so high that the drying phase can be much

shorter than with circulating air dryers, or higher drying

performance can be achieved with the same drying time.

OPERATING PRINCIPLE

Heat from infrared radiation is transmitted without any

kind of contact from the radiation source (the gas infrared

burner) to the recipient of the radiation. The dry air allows

100 % of this radiation to pass through.

Only when the infrared radiation meets a surface is

the radiated energy converted into heat. This operating

principle will be very familiar to anyone in a wintery environment

sensing the warming effect of the sun on their

skin. The highly efficient gas infrared radiant heaters used

for low-energy space heating work in a quite similar fashion.

Gas infrared burners used for drying in industrial environments

are burners that are operated using a combustion air

fan. This provides them among other things with better control

facilities and allows them to achieve the kind of reproducibility

in output that is required in industrial processes.

Fig. 1 is a schematic diagram showing an example

structure of a gas infrared unit. The individual burners are

lined up in a series to create any desired length. Two lines

of burners are usually joined to form a ‘twin row’. Single or

twin rows have ducts fitted on the sides, and this arrangement

then forms a single unit. It is possible to arrange any

number of these units behind one another.

Fig. 1 shows two of these twin rows as an example.

Please note that the burner is supplied with gas and combustion

air separately and is entirely independent from

the ambient air circulation system, which is also depicted.

Gas and combustion air are supplied to the burner and

burned there. The hot surfaces of the burner emit a very

even infrared radiation that is then used for drying or heating.

The hot gases from the combustion process and the

solvents evaporated in the drying process – usually steam

– are collected via the suction ducts.

OPTIMUM ENERGY USE

If the product to be dried permits, the heat energy from

the combustion process can be further exploited. In this

case, only part of the flow is discharged through the roof,

thus preventing the ambient air circulation system from

being saturated – for example with the vaporous solvent,

which is usually steam.

The discharged portion must have fresh air added to

it, which is achieved by means of a corresponding valve

control system. The largest part of the still-hot gases remain

in the ambient air circulation system and are blown via the

pressure-side ducts onto the product to be dried.

This means that, in addition to the radiated heat, there

is also convection, thus deriving the maximum possible

benefit from the energy.

HIGH LEVEL FLEXIBILITY

Gas infrared burners are large-surface burners, which

means that the radiation is emitted very evenly from the

entire radiating surface. By arranging burners as appropri-


59

REPORTS


Also of interest is the ability to balance out

certain variations in moisture content across

the width of the paper web. To achieve this,

the required number of burner rows are fitted

with a ‘profile correction’ system. This enables

each individual burner in the row to supply

varying output, based on the demands of

the moisture profile (Fig. 2).

The humidity is measured continuously

over the width of the web and the burner output

of each individual burner is automatically

modified so that the residual moisture beyond

the IR zone is as even as possible throughout

the width of the web.

Fig. 1: Construction in principle

ate, they can be adapted to the shape of the workpieces.

The ability to switch individual rows of burners on and off

provides a great deal of flexibility. Systems are also used in

practice that enable the radiation width to be modified.

By switching off unneeded burners – in the case of narrower

web widths, for example – this allows even more energy

to be saved and the already low operating costs to be

reduced even further by saving gas. Moreover, the surface

burners can be adjusted smoothly to any value between

at least 50 % and 100 % output. The porous burner can

even achieve values of between around 20 % and 100 %.

Large-surface products are particularly well-suited to

drying processes with gas infrared burners in principle. Indeed,

gas infrared burners are used very successfully to dry

coated paper web or coated steel strip, to quote examples.

The paper industry works with widths of up to 11

m running at speeds of more than 2000 m/min. While

medium-wave gas infrared burners have been in use for

decades to dry paper that has been coated on one or

both sides, the new type of porous burners have only

been in use since 2006.

Porous burners have more than proven their value in the

harsh arena of everyday practical use. Measurements have

confirmed that the high performance of the porous burner

(connected loads of up to 1,000 kW/m² possible) does not

impair the quality of the paper in any way. The much higher

supply of energy is used to the same extent for drying as

is the case with the much weaker medium-wave burners.

This means that in the paper industry – using the same

available space, meaning that no changes are made to

the route taken by the web when switching to a porous

burner system – the drying performance can be increased

many times over.

POROUS BURNERS FOR DRYING

COATED STEEL STRIPS

The use of porous burner to dry coated steel

strip is relatively new. The speeds that the strip

move at here are much lower than those of the paper

industry, but that does not mean that the task at hand is

any less complex, as shown by the following requirements

profile:

Strip width: 700 to 1750 mm

Strip thickness: 0.25 to 3.00 mm

Strip speed: 3 to 130 m/min

Coating: aqueous

Coating weight: 4 g/m² per side, wet

Strip supply temperature: 35 °C

Strip outlet temperature: min. 100 °C PMT (peak metal

temperature)

Direction of strip running: horizontal

Three twin rows are fitted with a total of 144 porous burners

for each line side. The heated width could be switched to

900, 1,200, 1,500 and 1,800 mm width levels.

Therefore, with strip of 700 mm in width, a heated width

of 900 mm was used, while with a strip width of 1750 mm, a

width of 1800 mm was used for using. The different heated

widths are shown in Fig. 3.

Output is regulated on the basis of the thickness of the

material, the speed and the coating material. The various

parameters and settings are stored in the PLC as a formula to

enable the dryer to enter the correct mode of operation automatically

when a stored formula is preselected. This means

that the correct width, the required output and the appropriate

number of burner rows are automatically activated.

Each twin row is fitted with a swivel joint that enables

it to be folded away 90° when no longer in use. The swivel



REPORTS

joint was fitted for two reasons:

1. The first is that in the event that the strip stops suddenly,

the rows can be folded away and operated in low-load

mode. This ensures that the strip does not overheat.

When the strip is moving again, production can be resumed

almost immediately.

2. Furthermore, in the interest of easier maintenance, where

strip is running at a height of over 2 m, platforms are

integrated into the dryers. This enables easy access to

the burners while they are folded away.

And replacing a burner is also very simple. Simply remove

the four screws on the rear side of the burner, then the new

burner and its mounting can be fitted. There is no need to

disconnect a gas hose, valve or similar to replace a burner.

In another case, there was a need to increase the output of

a dryer, because the circulating air dryer in use until then simply

did not provide enough drying performance, even though

the ambient air temperature was set as high as possible.

Fig. 2: Porous burner using profile correction system

Heated width 1:

1 2 3 4 5 6 7 8 9 10 11 12

Strip width: 650 to 1650 mm

Strip thickness: 0.3 to 3.00 mm

Strip speed: 150 m/min


900 mm

m

Coating: aqueous

Coating weight: 5 g/m² per side, wet

Direction of strip running: horizontal

Three twin rows are fitted with a total of 144 porous burners

for each line side. The heated width could be switched to

900, 1,200, 1,500 and 1,800 mm width levels. The length

here was limited to 5.5 m because the tension roller drive

station came directly after the dryer.

Whenever the strip was not sufficiently dried, not only

did it make the tension rollers dirty, which made complex

cleaning work necessary (thus also causing downtime),

but it also caused problems with the strip feed because

the still-wet strip was slipping on the rollers. As a result,

the insufficient drying performance of the circulating air

dryer had to be operated with a much reduced feed speed.

Additional, a supporting roller that ran in parallel had

to be fitted to the dryer supply point and automatically

moved away when the coater was coating the steel strip

in order to avoid disrupting the coating process. If the

coater is not in use, however, the roller is used to support

the uncoated strip.

The result – the strip slack can vary massively depending

on the mode of operation. An automated height adjuster

was therefore fitted for exactly this situation. Each twin

row (in addition to the properties of the aforementioned

dryer) is moved individually and automatically to achieve

the required distance to the surface of the strip.

This allows the system to be adapted in the best way

possible to the changing slack of the strip. In this case, it

1 2 3 4 5 6 7 8 9 10 11 12



1200 mm

1 2 3 4 5 6 7 8 9 10 11 12

1500 mm

1 2 3 4 5 6 7 8 9 10 11 12

1800 mm

Fig. 3: Active width adjustment

would be possible to leave out the swivel system. The

result – thanks to the porous burner – is a controlled drying

process in all operating modes.

AUTHOR

Dipl.-Ing. Michael Angerstein

GoGas Goch GmbH & Co. KG

Dortmund, Germany

Tel.: +49 (0)231/ 46505-87

michael.angerstein@gogas.com


61

The

Standard

Book

Handbook of

Aluminium Recycling

Fundamentals

Mechanical Preparation

Metallurgical Processing

Plant Design

The handbook guides the practitioner in the fi eld of production,

design or plant engineering in detail through the various tech nologies

involved in aluminium recycling. The book deals with aluminium

as a material and of its recovery from natural raw materials

sources, the various processes and procedures, melting and

casting plants, metal treatment facilities, provisions and equipment

for environmental and workforce safety, plant planning, operation

and control, and also remelting of aluminium. The reader is thus

provided with a detailed overview of the technology of aluminium

recycling.

Editor: Ch. Schmitz

1st edition 2006, 470 pages, hardcover

Vulkan-Verlag



Yes, I place a fi rm order for the technical book. Please send me

___ copies of the Handbook of Aluminium Recycling

1st edition 2006 – ISBN 978-3-8027-2936-6

at the price of € 88.00 (postage and packing extra)



REPLY / WERBEANTWORT




45039 Essen

GERMANY

Please note: According to German law this request may be withdrawn within 14 days after order date in writing to Vulkan Verlag GmbH, Versandbuchhandlung,

Postfach 10 39 62, 45039 Essen, Germany. In order to accomplish your request and for communication purposes your personal data are being recorded and

stored. It is approved that this data may also be used in commercial ways □ by mail, □ by phone, □ by fax, □ by e-mail, □ none. This approval

may be withdrawn at any time.


Country, postcode, town

Phone

E-mail


✘


Fax

PAHBAR2012


REPORTS

Hybrid processes in

electrotechnology

by Jörg Neumeyer, Holger Schülbe, Bernard Nacke

Processes out of the field of electrotechnology offer a large number of technological and ecological advantages for a

broad application area of industrial process heat. The large bandwidth of benefits possessed by electrothermal systems

can even be enlarged and adapted for other applications by means of rational and appropriate combination in the

context of so-called hybrid processes.

Industrial process heat makes up the third largest sector

of total German consumption of final energy, after

mechanical energy in the field of transport and domestic

space heating. An increasing percentage of the energy

required to generate process heat is now supplied using

electrothermal systems. The benefit of these methods

over conventional fuel-based technology can be found

in their universal usability, relatively simply handling and

use, high transmissible output density, superior efficiency,

and lower ecological impact. Electrical energy nowadays

continues mainly to be generated in power-generating

plants based on fuels such as coal and gas, but such largescale

facilities also include systems which keep pollutant

emissions low, such as flue-gas desulphurization and

dedusting installations. This large bandwidth of benefits

possessed by electrothermal systems can also be enlarged

and adapted for other applications by means of rational

and appropriate combination in the context of so-called

hybrid processes.

DIMENSIONING BY NUMERICAL

SIMULATION

The effects of electrothermal procedures onto the temperature

profile can be investigated previously by use

of numerical simulation. Thus it is possible to execute

cost-efficient parametric studies of different geometries,

generators and electric parameters. The simulation

allows the integral observation of the temperature

development at any location and at any time of the

process. It bases on FEM (finite-element-method) and is

accomplished electromagnetic and thermal coupled to

consider the temperature dependency of the material

parameters (Fig. 1).

BEAM WELDING AND INDUCTION

IN HYBRID PROCESSES

To join high-strength steels nowadays frequently laser

beam welding processes are applied. The strong focusing

of the laser beam leads to very high power densities in a

narrow area of the workpiece and to a distinctive deepweld

effect. Coincidental the high power densities are

causing very high temperature gradients in the welded

area. Again this temperature gradients end in a fast cooling

subsequent to the joining process and therefore to

an unacceptable hardness increase and brittleness of the

joint. The electromagnetic induction suits perfectly for

fast and controlled implementation of additional thermal

energy into the workpiece. Fig. 2 schematically shows the

experimental arrangement of a hybrid laser-induction-process

including a preparatory inductor and corresponding

measurement devices. The duration time of the inductor’s

effect can be calculated by use of the scanning velocity

and the length of the inductor. At the same time the electromagnetic

penetration depth can be influenced by the

frequency of the inductor’s current. Both the residence

time and the frequency determine the temperature profile

in the workpiece. The additional inserted thermal energy

on the one hand leads to smaller temperature gradients

subsequent to the joining process and on the other hand

reduces the necessary temperature range to the melting

point. Consequently a laser with less power respectively

the same laser at higher scanning velocity can be applied. If

inductor and laser are integrated in the same process head

both heat sources are moved with identical velocities: v Ind

= v Laser . Beside the version of a preheating inductor also a

subsequent induction system may be applied to generate

additional thermal energy after the joining process. Fig. 3


63

REPORTS


begin

Starting conditions

pos blank = 0

ϑ = f(x 1 ,y 1 ,z 1 )

v = ∆pos / ∆t

Geometrygeneration

p (x n , y n , z n )

harmonicanalysis

ρ = f(ϑ), µ = f(ϑ)

electromagnetic calculation

Joule heat distribution

Transient analysis(∆t)

λ = f(ϑ), c p = f(ϑ)

ϑ (x n , y n , z n )

pos blank = n · ∆pos ?

end

Thermal calculation

temperaturedistribution

yes

Fig. 1: Simulation sequence

Fig. 2: Hybrid laser-induction

no → n = n + 1

new position

pos blank = pos blank + ∆pos

Fig. 3: Induction support’s impact on the t 8/5 -time

temperature

distribution

ϑ (x n-1 , y n-1 , z n-1 )

shows calculation results of multiple simulations and

demonstrates the impacts of additional inductors onto

the t 8/5 -time – the cooling time between 800 and 500 °C –

that allows drawing conclusions about the hardness

increase of the microstructure. The heat generation by

the welding sources had been implemented by normally

distributed half ellipsoid sources [1].

A single laser beam process leads to a t 8/5 -time of only

2.3 s. The additional thermal energy of a preheating inductor

increases the t 8/5 -time to 9.8 s. Within the curves there

can be seen a temperature drop before initiation of the

laser beam over a time range of nearly two seconds. This

phenomenon can be ascribed to the safety distance between

inductor and laser source. There has to be a gap

between the point of impact of the laser beam and the

inductor of around 30 mm to prevent damage to the inductor.

The deployed scanning velocity of 1 m/min leads to

a period of 1.8 s for the safety time [2]. Compared to the

version with a preparatory inductor a following inductor

offers a t 8/5 -time of 12.1 s. Though in this connection it has

to be considered that the displayed temperature profile is

aimed at the part of the welded joint that is positioned at

the inductor overlooking surface. Hence this area resides in

the space of the electromagnetic penetration depth. The

already started heat conducting effects are leading to a greater

heat’s diffusion in the whole workpiece, whereby the

temperature at this point at the surface decreases and the

t8/5-time of the process with preheating is less. Regarding

the point at the seam root an opposite effect occurs. The

combination of both preheating and postheating inductors

and the necessary adjustment of the distance between

laser beam and post weld heating are able to achieve a

cooling time (t 8/5 -time) of 26.3 s.

Within a currently operated research project that is

funded by Forschungsvereinigung Stahlanwendung e.V.

(FOSTA) a process that includes a bifid beam source assisted

by induction heating is investigated. In opposite to the

exclusive application of a laser beam a hybrid process head

with a supplemental electric arc tube is implemented that

affords a common saturation of the same melting bath. The

additional charge by an arc tube leads to further enhancement

of the weldable sheet thickness and scanning

velocity and is able to provide fill material for infilling the

joint. This hybrid process head can be extended perfectly

by an inductive assistance. As you can see in Fig. 4 this

demonstrated treatment concerns a laser arc hybrid welding

process including an additional support by induction

heating. In contrast to the first displayed process (see Fig. 2)

the inductor is positioned perpendicular to the scanning

direction. A part of the laser energy is extracted to establish

a small seam weld that actualizes a mechanical and therefore

electrical bond of both sheets that have to be joined.

So the induced current in the workpiece is able to flow



REPORTS

and close across this joint. Fig. 5 shows the characteristic

of the current flows in the inductor and in the workpiece.

The current inside the workpiece flows along the sides

of the joint and generates “Joule Heat” in this area. In this

manner the whole material that is relevant for the welding

process can be preheated ideally. Afterwards follows the

closing hybrid process by laser and arc welding.

Beside the possibilities of combining different electrotechnologies

also whole processes may be teamed with

each other. An application that was developed with the

collaboration of the Institute of Electrotechnology and the

Laserzentrum Hannover e.V. permits the combination of an

inductive assisted laser welding process and a following

induction hardening process. An inductor with a gap for

the laser impact is supposed to preheat the material for the

welding (Fig. 6). After the welding process occurs a scan

hardening process of the remaining workpiece by usage of

the same inductor. Because for both process parts different

requirements to the electric parameters are demanded a

suitable control system has to be implemented. Also there’s

a supplementary quench integrated that cools down the

material rapidly after the induction heating to achieve the

necessary cooling rates and therefore the requested hardness.

The inductor’s width influences the power density

and by the rotation velocity respectively the scanning

velocity the heated breadth.

Fig. 4: Welding process FOSTA

COMBINATION OF CONVENTIONAL

PROCESSES AND ELECTROTECHNOLOGY

In spite of the large bandwidth of advantages of procedures

out of the field of electrotechnology conventional processes

furthermore have their right to exist. Especially in heating

and treating of workpieces with complex geometries

electrotechnologies reach their limitations. Conventional

gas- and oil-powered heating devices that merely warm

up by convection, conduction and radiation through the

surface afford only low heating rates. Furthermore they are

causing high thermal power losses and abet the appearance

of oxide scales. On the other hand there are advantages

of a simple design and a good possibility of temperature

maintenance. A proper combination of conventional

methods and the direct induction heating that enables

high power densities und high heating rates constitutes an

excellent potential to heat up complex geometries quickly

and homogeneously. The demonstrated process concerns

the heating of metal sheets made of high strength steel

for press hardening. The sheets possess a trapezium shape.

A sole warming by induction heating indeed affects high

heating rates but it also creates inadmissible temperature

inhomogeneity with a maximal difference of 360 K. The

following conventional heating affords a homogeneous

heating up to 900 °C in a relative short time period of only

Fig. 5: Principle – perpendicular

inductor

Fig. 6: Welding and

hardening

60 s (Fig. 7 [3]). Fig. 7: Hybrid process induction and conventional


65

REPORTS


CONCLUSION

Processes out of the field of electrotechnology offer a large

number of technological and ecological advantages for a

broad application area for industrial process heat. By coupling

of multiple methods in so-called hybrid processes the

particular advantages can utilized simultaneously. Also the

connection of conventional and electric heating processes

represents a good way to optimize existing procedures.

Hybrid processes expand and improve the possibilities and

the industrial application of electrotechnology.

LITERATURE

[1] Radaj, D.: Eigenspannungen und Verzug beim Schweißen –

Rechen- und Messverfahren. Fachbuchreihe Schweißtechnik

Band 143, Düsseldorf, 2002

AUTHORS

Dipl.-Ing. Jörg Neumeyer

Institute of Electrotechnology

Leibniz University of Hanover

Hanover, Germany

Tel.: +49 (0)511/ 762-3526

Dipl.-Ing. Holger Schülbe




Tel.: +49 (0)511/ 762-3928

[2] Meier, O.: Laserstrahlschweißen hochfester Stahlfeinbleche

mit prozessintegrierter induktiver Wärmebehandlung

Berichte aus dem Laserzentrum Hannover, Hannover, 2005

[3] Schülbe, H.; Jestremski, M.; Nacke, B.: Numerische Untersuchungen

induktiver Erwärmungsprozesse für das Presshärten, elektrowärme

international, Vol.: 69, Issue 3, 2011, page 283-288

Prof. Dr.-Ing. Bernard Nacke




Tel.: +49 (0)511/ 762-5533

KNOWLEDGE for the FUTURE

Handbook of Refractory Materials Design | Properties | Testing

This new edition has been completely revised, expanded and appears in a

compact format.

Readers obtain an extensive and detailed overview focusing on design, properties,

calculations, terminology and testing of refractory materials. With the great

amount of information this compact book is a necessity for professional working in

the refractory material or thermal process sectors.

Editors: G. Routschka / H. Wuthnow

4th edition 2012, 380 pages with additional information and

e-book on DVD, hardcover

Handbook

with additional

information

and entire e-book

on DVD

Vulkan-Verlag




___ copies of the Handbook of Refractory Materials plus DVD ROM.

4th edition 2012 – ISBN: 978-3-8027-3162-4





REPLY / ANTWORT




45039 Essen

Germany


Phone

E-mail

Fax



66

Postfach 10 39 62, 45039 Essen, Germany. In order to accomplish your request and for communication purposes your personal data are being

recorded and stored. It is approved that this data may also be used in commercial ways □ by mail, □ by phone, □ by fax, □ by e-mail, ✘

heat processing 4-2012

□ none. This approval may be withdrawn at any time.


PAHRM42012

Edition 4

FOCUS ON

“Energy efficiency is the

biggest potential in Europe”

Paweł Wyrzykowski is President of the Management Board at SECO/WARWICK Group

in Świebodzin, Poland. In this interview with heat processing he talks about the future

of the energy industry and technological challenges, revealing his own personal energysaving

achievement.

The energy mix of the future: Are you prepared to risk

a prediction?

Wyrzykowski: I am generally very positive and supportive

for the energy from renewable resources. There should be

enough potential in these renewable resources to constitute

a substantial energy supply for the earth’s population.

Although I think the efficient process of making this energy

useful will take some more time, as will the development

of efficient storage and transportation of it. Nevertheless

it is worth to work on it now with full speed.

The sun, wind, water, geothermics, etc.: Which regenerable

energy source do you consider to have the greatest

future?

Wyrzykowski: I think all of them have a lot of potential.

The one which I do not regard as a real renewable source

is the so called biomass, which uses wood residuals, and

sometimes even wood logs! This is not really very clever

to burn wood for gaining energy. First of all we release CO 2

to the atmosphere, and secondly we reduce valuable and

very healthy sources of raw materials for the production of

such goods as construction materials or furniture.

for some dozens of years, but I am also sure – not the prevailing

role forever. I support the attitude of Europe that we

do not want to take the dictate of oil and gas producers

for granted in the long run. Europe had been struggling

for solutions for decades, but only in the last years we can

see substantial progress thanks to renewable resources

and technologies harnessing them.

I would re-consider if we really have to give up the usage

of coal. I think also in the areas of its efficiency and the

environment protection we could achieve a substantial

progress when processing coal. It would however remain,

jointly with the renewable energy sources, our counterbalance

guarding our future income from being transferred

to OPEC or Russia for overpriced oil and gas. For the same

reason I support the nuclear energy. The future safety technologies

and all lessons learned must make it possible for

society to develop triple, or even quadruple safety systems,

which do not bear any real risks. I believe we can!

Which of the technologies currently emerging would

you invest in today on that basis?

Wyrzykowski: I think all of them will play a certain role,

but the importance of them will be different depending on

the natural conditions in each region. The question is the

economic and social cost of harnessing them. I am quite

sure in the long run the society will be quite successful in

some of the sources. I regard geothermic energy as the

underestimated one, but having a huge potential.

How do you assess the future ranking of fossil fuels such

as oil, coal and gas?

Wyrzykowski: I am sure they will be playing a major role


67

FOCUS ON Edition 4

The energy turnaround: What changes will be necessary

at the political (including the global political),

the social and the ecological level to enable us to talk

realistically of a “turnaround”?

Wyrzykowski: I am rather skeptical about the common global

political compromise in this respect. There are too many

differences, in terms of types and location of certain energy

resources, but also cultural, religious or climate differences.

We should struggle to have one common direction in the

EU, although also this seems not to

be easy. I believe at least to have an

integrated EU energy policy. This is

the pre-condition for searching the

global compromise.

There are at least two problems with renewable energy

sources: the lack of infrastructure, and the continuing

and persistent concentration of the established

channels on conventional forms of energy. Will this

change in the foreseeable future?

Wyrzykowski: The precautions to change this, has been

started by most of the governments already. However this will

take time, is costly and somehow there is an indication that

the end user, who will pay it in the end, need to have more

time, too, to adapt to costs and different usage behaviour.

Irrespective of the form of energy and the technology

used, many consider the term “energy-efficiency” to

be the key to the energy questions of the future. How

do you view this subject? What do you consider to be

the most important development in this field in the

heat-processing technology industry?

Wyrzykowski: Yes, I consider energy efficiency as the

biggest potential “energy source” in Europe. Starting from

much better insulation of buildings through many types

of industrial processes we should be able to save a lot of

energy. Our industry is highly exposed on this requirement.

There have been some inroads made in the recent years,

but the biggest work is still in front of us.

The use of energy in the heat treat industry depends on,

among other things, the size of the load that needs heated,

the heat losses (on housing and exhaust), the cooling

power and the process time. The load has been optimized

by weight reduction of components, better and more

accurate process treatment to improve safety measures

on functional parts and optimized jigging with low weight

fixtures. Our heat up simulation software and applied flow

models helped SECO/WARWICK a lot in achieving already

considerable savings here.

As a further step SECO/WARWICK’s new process technologies

for carburizing (PreNit-LPC®) and nitriding (ZeroFlow®)

reduced process time, exhaust losses and we are working on

more processes that optimize not only the energy use but

“We regularly convert

our innovations into

substantial new sales.”

also the functional properties of parts to minimize the specific

energy expense of each individual functional component.

What benefits do electrical process-heat routes offer

in your opinion?

Wyrzykowski: Electrical power on heating installations is

as most engineers in the process business learn early net

energy, as the exhaust losses of gas heated systems do not

need to be considered. It is clearly not as simple as this, but

with natural gas as a limited resource

and the distribution issues of natural

gas in some areas, electrical heated

systems have always been an alternative

to gas heated systems. The

benefit that electrical heating offers

is mainly its simplicity and the lack of heating gas exhaust

systems. As a matter of fact the control of electric heated

systems with a number of heating zones can be, as well

simplified. On another hand, with the development of the

technology to extract the shale gas, heating system based

on this medium may be very economical substitute of the

electrical heating.

In your opinion, how will energy consumption in industry,

commerce and domestic households change?

Wyrzykowski: As emphasized before I expect a significant

growth of energy efficiency. Secondly, the natural renewable

resources will gain ground. Thirdly, there may be a

shift of location of the heavy, energy consuming industry

to countries and regions which offer cheaper energy, irrespective

of its origin.

What role does your company currently play on the

energy market?

Wyrzykowski: As the furnace producer we do not consume

much energy ourselves, but we strongly influence

the energy consumption of our customers. That is why we

constantly search for new solutions in this respect.

What will be your company’s most important innovation

or project?

Wyrzykowski: In today’s business environment, factors

such as performance, energy efficiency, reliability are the

key contributors to success. It is very much likely it will not

change with time. SECO/WARWICK has always placed a

great emphasis on the development of the technologies

that deliver just that. Our low pressure carburizing technology,

with its newest addition PreNit® technology, allows

our customers to process parts at higher temperatures,

thanks to which the cycle time can be reduced, and still

without the risk of the grain grow. When applied with our

new generation three chamber furnaces (with oil or gas

quenching) it can reduce the cycle time by half.


Edition 4

FOCUS ON

Another example of the same philosophy is the ZeroFlow®

Nitriding technology. In this case the customers can benefit

from the reduced nitriding gas consumption. It is especially

important in view of the new regulations trying to reduce

the consumption of such gases ammonia.

The race to develop the furnaces with faster quenching rates

is on. SECO/WARWICK has developed a new high pressure

gas quench furnace, VPT type, whose quenching rate is

comparable to the rates reached in the oil quench systems.

What challenges do you see approaching you (economic,

technological, social, etc.)?

Wyrzykowski: We think the energy questions are very

up-to-date. The higher oil and gas prices the higher the

heat treatment cost will be. Those companies who will be

able to offer some comparative advantage will be winning

some ground.

How do the expansion of the EU and globalization affect

your company and its business?

Wyrzykowski: We definitely have some benefits from

the globalization process. Many of our regular customers

invite us to some new co-operation in new markets. In the

recent years we have made some good effort in enlarging

our geographical footprint from Europe and the U.S to

China, India and Russia.

How important is a trade name or a brand for the success

of products in the industrial sector?

Wyrzykowski: I really respect the brand approach also in

the industrial goods. The brand stands for the guarantee.

Not only for the mechanical or electrical product guarantee,

but also, or mainly – for the guarantee of a lean process

for our customers, and for delivering the customer some

competitive advantage through our innovations. These two

aspects are actually the core of SECO/WARWICK mission.

Have you been unable to pursue developments, or

able to pursue them only after a delay, or at reduced

speed, due to the lack of qualified personnel?

Wyrzykowski: We are generally happy with our innovations,

which regularly and in a visible magnitude are

converted into new sales. This is the main reason we are

growing rapidly, even despite the economic slow down.

Does a management team need greater media capabilities

in order to convince investors?

Wyrzykowski: We found a good balance between being

visible in the public and reflecting our real strengths, without

any exaggeration. As a stock listed company we are exposed

on some natural interest of the financial investors. We have

here a good feeling in meeting the main expectations.

What would you like to change in your company?

Wyrzykowski: At the end of October 2012 we announced

our new strategy. We will need some changes in organization

and communication to make the strategy work. The

biggest challenge is to create a good internal network

between all our subsidiaries and motivate their management

to reaching the highest standards within our group.

How important is expansion abroad

for your company?

Wyrzykowski: It is very important.

We are traditionally very

strong in Eastern Europe

and in the North America.

We successfully run

our factories in China and

India. We have a satisfactory

track record in Western

Europe, apart from Germany,

where we intend to

“We should struggle

to have one common

direction in the EU.”


69

FOCUS ON Edition 4

strengthen our position right now. We believe our technical

solutions are now on the level meeting many expectations

on this market. Our main plant in Świebodzin, Poland, is

only one driving hour away from Berlin, Germany.

How much does your company spend on investments

each year?

Wyrzykowski: We spend between 3 to 4 Mio. Euro

on operational investments, but we have been spending

much more on some capital investments. This we

would like to keep at least in the next two years in order

to strengthen our position in Asia and Brazil. Despite this

rapid development we have been able to avoid bank debts,

and we keep still a net cash position.

What has been/is your greatest energy-saving as a

private person?

Wyrzykowski: Recently, I changed my car for a model

which consumes 30 % less fuel. I and my family are trying

to pay attention also to many, sometimes little measures,

which help save energy.

How would you assess your dealings with employees?

Wyrzykowski: I try to do my best in having the high

respect for my colleagues. I think it is important to find

time for them and make sure their fields of responsibilities

are clearly defined. From my experience this is already a

lot, when employees avoid conflicts in their dealings and

know exactly what they are responsible for.

What moral values are of particular topicality for you?

Wyrzykowski: I think fairness and being straight to the

point are important values. You can create a good rapport

with your employees if you are really fair in evaluation of

their work. Being direct is also important, especially in

today’s world, where the speed of information has gained

a lot of importance. There is less and less time for reading

people’s mind, if they are not open enough.

Do you, or did you, have any people whom you regard

as examples to you?

Wyrzykowski: No, I am still waiting to meet somebody

who I could admire in his or her full picture. But, naturally

I’ve met some persons where I remember some traits I see

as a good target for myself.

How were you brought up and educated?

Wyrzykowski: I was born in Warszawa, Poland, and grew

up in the area of this city. I graduated from the Warsaw

School of Economics. Now I appreciate my first job very

much, which was in the banking business. I think it gives

a good backup and orientation in the world of business.

RESUME

Paweł Wyrzykowski

Date of birth: 3 rd of February 1969

Current job:

President of the Management Board, SECO/WARWICK Group

Studies:

Diploma in Faculty of Foreign Trade of the Warsaw School

of Economics in Poland

Career:

1992-1998: Creditanstalt group in Vienna (Austria) and Warsaw

(Poland)

1998-2001: Chief Financial Officer and member of the

Management Board of Pfleiderer Grajewo S.A.,

Poland

2003-2009: President of the company’s Management Board

of Pfleiderer Grajewo S.A. , Poland

2009-2011: Member of the Management Board of Pfleiderer

AG of Neumarkt, Germany

2012-now: President of the Management Board,

SECO/WARWICK Group


Edition 4

FOCUS ON

What is your motto for life?

Wyrzykowski: I do not have one and so far I do feel not

uncomfortable missing it.

In your opinion, what was the most important invention

of the 20 th century?

Wyrzykowski: Without being too academic, I respect

the mobile phone very much. I entered into my adult age

when the cell phone was not in place and remember how

different our life was.

When do you not think about your work?

Wyrzykowski: My family is generally a good counterbalance.

I have three kids ages 10 and below. When dealing

with them or taking care of them you really hardly can think

about anything else.

What is your own personal tip for the upcoming generations?

Wyrzykowski: I would not dare a tip for more generations

than only the next one. The speed of cultural and social

changes is simply too high. My tip for my kids is quite simple:

No invention will replace your mind (brain), so keep it

ready all the time.

What has shaped you in particular?

Wyrzykowski: I had a very hard and demanding study but

decided to go on with being a semi-professional footballer in

the same time. This combination helped a lot with many difficult

issues at the end of the day, like the team play, “staying

on the ground”, or good time management. Simultaneously

you had to pass all the exams coming up. I learned quite well

that you pass all your exams, if you take them one by one.

What can you absolutely not do without?

Wyrzykowski: I need some sport activity all the time. Due

to a serious injury in the past I am not able to play football

anymore, but now I try to go on with tennis and golf which

give me some balance against some stress in business.

What do you wish for the world?

Wyrzykowski: Keep being successful in “no next world

war”. Even looking at all your previous questions, where

some of them look really serious, we sometimes lose some

real relations. You asked about generations. For almost all our

preceding generations this stage we have had now would

not have been seen as taken for granted. We often forget this.

Thank you for this interview.


71

PRODUCTS & SERVICES

Inline Paint Section (IPS) started up for commercial production

The largest and fastest Inline Paint Section

(IPS), which is a full organic painting

production unit, integrated in a continuous

hot dip galvanizing line, has recently started

commercial production. This organic Inline

Paint Section consists of a pretreatment section

(either for chem-coatings or passivation

coatings application, followed by two organic

painting sections for two sided primer

coating and finish coating and is therefore

fully equivalent to a paint process section

of a continuous color coating line, exceptionally

it is integrated and linked to a before

ongoing galvanizing process. The production

speed of that line, is equivalent to the

max galvanizing process speed of 180 m/

min, with a production capacity of 80 t/h or

up to 500,000 t/a organic painted galvanized

steel coils. This is today the largest organic

painted coil production line, linked inline

with a galvanizing line.

The possible curing time within 5 s at a

max. speed of 180 m/min for applied coatings

with 25 μm layer thickness have been

proven already in successful production

batches for several colors (white, red and

brown) and from several different coating

manufacturers. The IPS is built in a “cubic”

tower of approx. 30 x 30 x 30 m³, containing

all process equipment, except the three

chamber RTO, which is positioned on the

ground floor next to the tower.

The adphosNIR® based “on demand” Inline

Paint Section can be applied and integrated

also horizontally in a galvanizing line, if needed.

Due to the possible compact designed

layout, the adphosNIR IPS is also possible to

be integrated in most existing CGLs / EGLs.

The possible resulting cost reductions of

an adphosNIR® IPS can add up to more than

70 €/t due to energy, media and operator

personal savings with additional resulting

benefits of production capacity increase

and reduced investment costs compared

to standalone CCLs, a total cost saving of

up to 100 €/t can be expected. adphos also

provides a free of charge analysis and evaluation

for your potential inline paint project.

adphos Thermal Processing GmbH (ATP)

www.adphos.de

Automatic gas burner control for

one-stage burners

Microprocessor-controlled automatic gas

burner control for intermittent and continuous

operation of one-stage atmospheric

burners or fanned burners, in particular for

industrial thermoprocessing equipment to

EN 746-2. The program sequence and times

can be customised by setting software parameters.

Two independent flame detectors:

Ionisation input, Gate input.

Extension module for Profibus/Modbus

communication are available. Additional

functions by extension modules are possible

as well. Version MPA 4111 (Plastic housing,

IP 42) is without a display, MPA 4112 (Plastic

housing, IP 54) has an integrated display.

The following accessories are flame detector,

Ignition transformers, parameterisation and

service box.

Karl Dungs GmbH & Co. KG

www.dungs.com

72



Furnace technology for different applications

Elino Industrie-Ofenbau GmbH has been

developing, designing, and manufacturing

continuous plants for more than 50

years: roller conveyor and paternoster furnaces

as well as chain conveyor furnaces, to

name but a few. More than 100 plants for

basic or very special requirements in the

field of aluminium processes, and 4,000

plants in other fields of application have

been delivered world-wide.

Cast components, e.g. cylinder heads,

engine bases, structural components as well

as axle suspensions, are also heat treated as it

is done with cold-formed aluminium sections

and machined components. A very accurate

temperature control during artificial aging

and solution annealing is absolutely vital.

Quenching processes after solution annealing

are implemented using water, polymer or air

depending on the customers’ requirements.

Elino can offer

various very new

designs for the processes

under ambient

air atmosphere

and for special gastight

designs with

process gases, e.g.

argon or nitrogen.

The continuous

furnaces made by

Elino are fully technically

developed,

are sound and allow

very long lifetimes.

We have always been focusing our activities

on the optimization of energy consumption.

Depending on the process conditions, heat

treatments of up to 1,000 °C can be carried

out. Product specific internal fittings in the

process chamber give ample scope for new

products.

Elino Industrie-Ofenbau GmbH

www.elino.de

Combustion multi-gas technology for the control of atmosphere

The direct heating of reactive products is

imposing a perfect control of the atmosphere.

On top of that, the composition of the

atmosphere has to remain constant for reasons

of quality. In order to do so, the principle

called “nozzle mix” consists in controlling the

mix made while the flame is developing, by

individually controlling the air flux and gas

flux in burners with separated air and gas.

Nozzle-mix burners have the major disadvantages

to create problems of constancy

of air/gas ratio. As nozzle-mix technology

means that the air and the gas are mixed at

the exit of the burner, the flame is quite long.

In the treatment of reactive products this

means that there is a risk that the flame can

come in contact with the heated product

especially if the air/gas ratio is not well under

control. Nozzle-mix burners are therefore

not suitable for compact heating chambers.

To tackle these limitations by focusing on

the ergonomy of the operators, the premix

technology is the alternative.

It consists in mixing prior to the burner

rack the combustion air with fuel-gas in a

dosing-mixer according to a predefined

ratio and to bring this “ready-mix” combustible

to the burners rack. Consequently,

contrary to the previous technique nozzle

mix the dosing is made well before the burner.

Thanks to a specific system of pressure

regulation, the quantity of gas admitted in

the mixer remains always proportional to

the quantity of combustion air injected in

the latter, according to the ratio predefined

by the operator. Consequently your combustion

efficiency remains always constant.

The premix combustion system allows

the same piping design and dosing-mixer

whatever the nature of gas. On top of that,

your working principle remains the same

what makes your maintenance aspects much

easier. As the system prepares a “ready-mix”

combustible, the celerity of the combustion

at the flame is independent from the flow

getting out of the burner: the flame remains

always inside the burner block.

This leads to non radiant flames with

high fumes velocity, no contact with your

product and considering compact chambers.

Premix combustion technology is used

already in many industrial heat treatment

applications. Premix combustion technology

can be considered for every application

where the control of atmosphere is concerned

or where a full stoichiometry is suitable.

At the heart of the FIB premix combustion

system is the CONSTAN® dosing-mixer that,

coupled with a zero governor, can guarantee

the stability of the air/gas ratio.

A control burner allows the operator to

see the quality of the flame from the outside

and evaluate the quality of the combustion

or measure the composition of the flame.

Other advantages of the Constan® dosing

mixers are: ability to feed a variable number

of burners; the pressure in the heating

chamber cannot affect the air fuel-gas ratio;

not sensitive to water, dust or other deposit

and very simple maintenance.

FIB BELGIUM S.A.

www.fib-combustion-solutions.be


73


Progress tracking from the engineering

phase up to the construction site

From the manufacturing phase up to the

construction site, the entire machinery,

e.g. roller mills for raw material or cement

plants, passes through numerous stations.

This is why order processes in plant engineering

and construction are often very

complex and require the co-operation and

interaction of several different departments.

If the close interaction between the production,

purchasing, sales, and project planning

departments does not flow smoothly, faulty

deliveries may result. These, in turn, may gravely

affect any type of construction projects

that are based on deadlines and time limits.

This problem can be counteracted by way

of a uniform, interdivisional execution of all

of the processes in SAP.

Intelligent add-ons broaden the project

management functions with important

components and facilitate the related tasks

thanks to a clear web interface. For more

than one year, Loesche GmbH has now

been making use of SAP across all divisions

combined with two additional tools made

by Milliarum in order to ensure the wellstructured

progress tracking of orders and

a simplified project scheduling.

Loesche GmbH

www.loesche.com

Tube furnace

combination for

carbonization of

fibers

Two step setting for operation at different

temperatures. (low temp. 5-zone

1,050 °C, high temp. 1-zone 1,600 °C, option

1,800 to 2,800 °C) and dwelling time with

gas feeding in located between.

New infrared thermometer with

thermocouple output

Conventional thermocouples may

encounter high abrasion resulting from

contacting measurement points and harsh

surroundings. The new infrared sensor optris

CS extends the lifetime of measuring fields

considerably due to its non-contact measuring

concept. Its standardized thermocouple

connection allows the use of already existing

measuring lines.

The innovative pyrometer covers a broad

temperature range between -40 °C and 1,030 °C.

Additionally there is a new LED display.

The electronic display unit

not only serves as a targeting

support for sensor alignment

but the LED

self-diagnosis

also displays

the

condition of the pyrometer (e.g. overheating

of sensor). Parallel to the new alarm output

on the device (open collector), a visual alarm

can be set through the LED. A temperature

code signal rounds off the innovative concept

of the optris CS. Its robust design makes it

dependable in ambient temperatures up to

85 °C without additional cooling.

In terms of reliability and connection

diversity the optris CS sets a new standard

in industrial infrared thermometers as it

allows for significant time and cost savings

for our customers. Besides the programmable

thermo element, 0-10 V and 0-5 V outputs,

there is the possibility to integrate the temperature

sensor into the license free optris

CompactConnect software via USB. Thus,

besides temperature monitoring a complete

parameterization of the sensor are possible.

Optris GmbH

www.optris.de

FRH-5-70/1000/1100

Tmax: 1,100 °C

Insert tube 1.4841, inside diameter: app.

40 mm, length: app. 1,800 mm

Heated length: app. 1,400 mm

Heating power: app. 7.2 kW

Gas feeding device for N 2 / Ar manually

FRH-70/500/1600

Tmax: 1,600 °C

Insert tube AlSint 99.7, inside diameter: app.

60 mm, length: app. 1,000 mm

Heated length: app. 500 mm

Heating power: app. 5.5 kW

Options: Gas feeding device for N 2 / Ar

manually, CFC-tube and temperature up

to 2,800 °C

Linn High Therm GmbH

www.linn.de

74



New flame safeguard for burner control

The new T600 Flame Safeguard from Eclipse offers the most

flexible, cost effective solution for burner control. T600 is a

single burner controller for use with direct or indirect-fired furnace

or oven applications that require global flame safety systems.

T600 Type 1 with no display, and T600 Type 2 with integrated

display. The following features are:

■ Features an advanced microprocessor to precisely control

gas burner start-up and operation.

■ Provides more of the features, options, and versatility users

need, including programming flexibility, scalability and

advanced diagnostics.

■ Program sequences and operating times can be customized

to provide exacting burner control in virtually any application.

■ Can control burners with either direct or pilot ignition and

models are available with or without an integrated display.

Eclipse, Inc.

www.eclipsenet.com

Highly configurable infrared camera platform

LumaSense Technologies, Inc. has introduced

a new line of highly configurable

thermal imaging cameras specifically designed

for use in harsh environments. The

MC320 line features uniquely configured

optics and detectors that

enable the cameras to be

tuned to specific infrared

wavelengths and optimal

performance to best suit

a particular application.

This flexibility means

the MC320 platform is

a cost-effective solution

for a wide range of

applications including

process control, predictive

maintenance, safety and critical vessel

monitoring.

Leveraging this integrated approach between

camera design, optics and detectors

coupled with LumaSense’s comprehensive

software will enable a wide variety of

turnkey solutions for various industries such

as energy, steel, glass, and refining, among

others.

The MC320 platform leverages tuned

VOx detectors to provide the most comprehensive

application specific wavelengths

and temperature ranges. Each model is optimized

to perform in the most demanding

industrial applications providing the best

sensitivity and image quality available in this

price range.

In addition LumaSense is capable to build

up a very efficient temperature monitoring

system by combining MC 320 Thermal Imaging

cameras economically with our Impac

range of pyrometers and tailor-made software,

which presents an excellent solution

for many applications during the production

and processing of metals.

LumaSense Technologies Inc.

www.lumasenseinc.com


75

INDEX OF ADVERTISERS

INDEX OF ADVERTISERS

Company

Page

4th International Cupola Conference 2012, Dresden, 63

Germany

Company

Page

AICHELIN Holding GmbH, Mödling, Austria Back Cover

ALUMINIUM

AICHELIN GmbH,

2012,

Mödling,

Düsseldorf,

Austria

Germany 32

Back Cover

ALUMINIUM CHINA 2012, Shanghai, People’s 21

Aluminium India 2013, Mumbai, India

Republic of China

ANDRITZ Aluminium Maerz Middle GmbH, East 2013, Düsseldorf, Dubai, Germany United Arab Emirates 13

22

26

ANKIROS 2012 / ANNOFER 2012 / TURKCAST 2012, 22

Istanbul, Arabia Essen Turkey 2013 / Tekno Arabia 2013 / Tube Arabia 2013,

Bloom Dubai, United Engineering Arab Emirates (Europa) GmbH, Düsseldorf, 11 50

Germany

Elster GmbH, Osnabrück, Germany

Elster GmbH, Osnabrück, Germany 07

7

indometal 2013, Jakarta, Indonesia 33

Company

Page

Euro PM2012, ‚Basel, Switzerland 88

FIB BELGIUM s.a., Tubize (Saintes), Belgium 15

HEAT TREATMENT 2012, Moscow, Russia

ITPS 2013, Düsseldorf, Germany

27

13, 23, 71

JASPER Gesellschaft für Energiewirtschaft Front Cover

und Kybernetik mbH, Geseke, Germany

LOI Thermprocess GmbH, Essen, Germany

LOI Thermprocess GmbH, Essen, Germany 61

11

SECO Schmetz / Warwick GmbH THERMAL Vakuumöfen, S.A., Menden, Swiebodzin, Germany Poland 35 15

Siemens AG, Rastatt, Germany 93

SECO/Warwick Europe S.A., Swiebodzin, Poland Inside Front Cover

SMS Elotherm GmbH, Remscheid, Inside Front Cover

Germany

SMS Elotherm GmbH, Remscheid, Germany

Uni-Geräte GmbH, Weeze, Germany

Front Cover, 19

25

Calendar 2013

Loose Insert

Business Directory 77-99




YOUR CONTACT TO THE

HEAT PROCESSING TEAM

Managing Editor:

Dipl.-Ing. Stephan Schalm

Phone: +49 201 82002 12

Fax: +49 201 82002 40

E-Mail: s.schalm@vulkan-verlag.de

Editorial Office:

Annamaria Frömgen

Phone: +49 201 82002 91

Fax: +49 201 82002 40

E-Mail: a.froemgen@vulkan-verlag.de

Advertising Sales:

Bettina Schwarzer-Hahn

Phone: +49 201 82002 24

Fax: +49 201 82002 40

E-Mail: b.schwarzer-hahn@vulkan-verlag.de

Advertising Administration:

Martina Mittermayer

Phone: +49 89 45051 471

Fax: +49 89 45051 300

E-Mail: mittermayer@oiv.de

Editorial Department:

Silvija Subasic

Phone: +49 201 82002 15

Fax: +49 201 82002 40

E-Mail: s.subasic@vulkan-verlag.de

www.heatprocessing-online.com

International Magazine for Industrial Furnaces



2012

Business Directory

I. Furnaces and plants for industrial

heat treatment processes ............................................................................................................................... 78

II.

III.

IV.

Components, equipment, production

and auxiliary materials .........................................................................................................................................88

Consulting, design, service

and engineering .........................................................................................................................................................96

Trade associations, institutes,

universities, organisations ............................................................................................................................... 97

V. Exhibition organizers,

training and education ......................................................................................................................................98

Contact:

Mrs Bettina Schwarzer-Hahn

Tel.: +49 (0)201 / 82002-24

Fax: +49 (0)201 / 82002-40

E-mail: b.schwarzer-hahn@vulkan-verlag.de

www.heatprocessing-directory.com


I. Furnaces and plants for industrial heat treatment processes

thermal production

Melting, Pouring, casting


4-2012 Business Directory


Heating

Powder metallurgy

More information available:



79



Heat treatment




81










83




cooling and Quenching




surface treatment

Joining

cleaning and drying




85



Joining




recycling

energy efficiency



KNOWLEDGE for the FUTURE

Handbook of Refractory Materials Design | Properties | Testing

This new edition has been completely revised, expanded and appears in a

compact format.

Readers obtain an extensive www.heatprocessing-online.com

and detailed overview focusing on design, properties,

calculations, terminology and testing of refractory materials. With the great

amount of information this compact book is a necessity for professional working in

the refractory material or thermal process sectors.


4th edition 2012, 380 pages with additional information and

e-book on DVD, hardcover

Handbook


information


on DVD

Vulkan-Verlag



BRAND NEW





Already shopped

Know-how today? REPLY / ANTWORT


The new web presence of hpVersandbuchhandlung

www.heatprocessing-online.com Postfach 10 39 62

45039 Essen

Germany





Phone

E-mail

Fax


Postfach Vulkan-Verlag

10 39 62, 45039 Essen, Germany. In order to accomplish your request and for communication purposes your personal data are being


recorded and stored. It is approved that this data may also be used in commercial ways □ by mail, □ by phone, □ by fax, □ by e-mail,

□ none. This approval may be withdrawn at any time.


✘


87

PAHRM42012


II. Components, equipment, production and auxiliary materials

Quenching equipment

Fittings

Burners

transport equipment







89



Burners Burner applications Burner equipment




Hardening accessories

Your contact to

HEAT PROCESSING


Tel. +49(0)201-82002-24

Fax +49(0)201-82002-40

b.schwarzer-hahn@vulkan-verlag.de




91



resistance heating

elements

inductors

Your contact to

HEAT PROCESSING


Tel. +49(0)201-82002-24

Fax +49(0)201-82002-40

b.schwarzer-hahn@vulkan-verlag.de




Gases

Measuring and automation


93



Measuring and automation

Power supply




refractories

cleaning and drying

equipment




95


III. Consulting, design, service and engineering


III. Consulting, design, service and engineering


IV. Trade associations, institutes, universities, organisations


97


V. Exhibition organizers, training and education

Hotline Meet the team

Managing Editor: Dipl.-Ing. Stephan Schalm +49(0)201/82002-12 s.schalm@vulkan-verlag.de

Editorial Office: Annamaria Frömgen +49(0)201/82002-91 a.froemgen@vulkan-verlag.de

Editor: Silvija Subasic +49(0)201/82002-15 s.subasic@vulkan-verlag.de

Advertising Sales: Bettina Schwarzer-Hahn +49(0)201/82002-24 b.schwarzer-hahn@vulkan-verlag.de

Subscription: Martina Grimm +49(0)931/41704-13 mgrimm@datam-services.de

Hotline_184,5x35.indd 2 15.12.11 15:13


Handbook


information


on DVD

Handbook of

Refractory Materials

Design | Properties | Testing

This new edition of the Handbook of Refractory Materials has been

completely revised, expanded and appears in a compact format.

Readers obtain an extensive and detailed overview focusing on design,

properties, calculations, terminology and testing of refractory materials

thus providing important information for your daily work. The appendix

was supplemented by following suggestions of readers. Consequently, the

handbook‘s usability was enhanced even further. With the great amount of

information this compact book is a necessity for professional working in the

refractory material or thermal process sectors. The e-book offers even more

fl exibility while travelling.


4th edition 2012, 380 pages with additional information and e-book

on DVD, hardcover

Vulkan-Verlag









REPLY / WERBEANTWORT




45039 Essen

GERMANY


Postfach 10 39 62, 45039 Essen, Germany. In order to accomplish your request and for communication purposes your personal data are being recorded and

stored. It is approved that this data may also be used in commercial ways □ by mail, □ by phone, □ by fax, □ by e-mail, □ none. This approval

may be withdrawn at any time.



Phone

E-mail


✘


Fax

PAHRM42012

COMPANIES PROFILE

KELLER HCW GMBH

KELLER HCW GMBH

COMPANY:

KELLER HCW GmbH

Division MSR Infrared Temperature Solutions

49479 Ibbenbüren

Germany

BOARD OF MANAGEMENT:

Dipl.-BW (FH) Karsten Biermann

Dipl.-Ing. Laurenz Averbeck

HISTORY:

The business which Carl Keller founded in 1894 is today a renowned

plant and machine manufacturer active on a global scale

with a focus on the heavy clay and building materials industry.

Beyond that, the KELLER name stands for intelligent solutions in

measurement instrumentation and automation. When their affiliate

Keller Spezialtechnik took over Pyro-Werk Hannover in 1967,

Keller entered the market segment of non-contact temperature

sensors. Following a 45-year business history and organizational

restructuring, this business unit changed its name in May 2011

to Division MSR Infrared Temperature Solutions (ITS). Through

continuous R&D initiatives and an innovative response to market

needs, Keller MSR ITS has become a global specialist in the field of

non-contact temperature measurement technology for industrial

applications.

GROUP:

Since 2006 Keller HCW GmbH is part of the French conglomerate

Groupe Legris Industries.

SHAREHOLDINGS:

Keller HCW GmbH and morando s.r.l.- an Italian company just as rich

in tradition - both belong to Keller Holding which is one of Groupe

Legris’ three divisions.

NUMBER OF STAFF:

Keller HCW GmbH: 350; Division MSR: 34

EXPORT QUOTA:

>50 %

PRODUCT RANGE:

With more than 250 different models, Keller’s wide range of instruments

covers nearly all industrial applications from -40 to +3,500 °C. Specially

engineered solutions for specific applications include measuring systems

for inductive heating equipment, for the iron and steel industry,

for molten metals, as well as for asphalt and concrete mixing plants.

PRODUCTION:

All products are designed, engineered and manufactured in Ibbenbüren,

Germany.

COMPETITIVE ADVANTAGES:

Keller’s expertise is backed by 45 years of experience in engineering

and manufacturing precision measuring instruments with a focus

on non-contact temperature measurement. Thanks to continuous

product innovations and specially engineered application solutions

in response to ever-changing market requirements, Keller MSR ITS

has established recognition as one of the leaders in its sector.

A worldwide sales network and service centers across the globe

ensure that Keller can provide customers with personal consultation

and on-site support.

With their comprehensive range of instruments and accessories,

Keller MSR ITS offers systems for standard applications as well as

highly specialized solutions.

SERVICE POTENTIALS:

Keller MSR ITS is headquartered in Germany and maintains service

centers in Brazil, China, France, India and Russia.

CERTIFICATIONS:

Since 1994: DIN EN ISO 9001:2008

INTERNET ADDRESS:

www.keller-msr.com

Contact:

Dipl.-Ing.

Albert Book

(Director)

Tel.: + 49 (0)5451/ 85320

albert.book@

keller-msr.de


4-2012 IMPRINT


Volume 10 · Issue 4 · November 2012

Official Publication

Editors

Advisory Board

Publishing House

Managing Editor

Editorial Office

Editorial Department

Advertising Sales

CECOF – European Committee of Industrial Furnace and Heating Equipment Associations

H. Berger, AICHELIN Ges.m.b.H., Mödling, Prof. Dr.-Ing. A. von Starck, Appointed Professor for Electric Heating at RWTH

Aachen, Dr. H. Stumpp, Chairman of the Association for Thermal Process Technology within VDMA, President of the

LOI Group and Chairman of the executive board LOI Thermprocess GmbH

Dr. H. Altena, Aichelin Ges.m.b.H., Prof. Dr.-Ing. E. Baake, Institute for Electrothermal Processes, Leibniz University of

Hanover, Dr.-Ing. F. Beneke, VDMA, Prof. Y. Blinov, St. Petersburg State Electrotechnical University “Leti“, Russia, Mike Debier,

President of CECOF, Dr.-Ing. F. Kühn, LOI Thermprocess GmbH, Dipl.-Ing. W. Liere-Netheler, Elster GmbH, H. Lochner,

EBNER Industrieofenbau GmbH, Prof. S. Lupi, University of Padova, Dept. of Electrical Eng., Italy, Prof. Dr.-Ing. H. Pfeifer,

RWTH Aachen, Dipl.-Phys. M. Rink, Ipsen International GmbH, Dipl.-Ing. St. Schalm, Vulkan-Verlag GmbH, M.Sc. S. Segerberg,

Heattec Värmebehandling AB, Sweden, Dr. A. Seitzer, SMS Elotherm GmbH, Dr.-Ing. P. Wendt, LOI Thermprocess GmbH,

Dr.-Ing. T. Würz, CECOF, Dr.-Ing. J. G. Wünning, WS Wärmeprozesstechnik GmbH

Vulkan-Verlag GmbH, Huyssenallee 52-56, 45128 Essen, Germany

P.O. Box 103962, 45039 Essen

Managing Directors: Carsten Augsburger, Jürgen Franke

Dipl.-Ing. Stephan Schalm, Vulkan-Verlag GmbH

Tel. + 49 (0) 201 82002-12, Fax: + 49 (0) 201 82002-40

E-Mail: s.schalm@vulkan-verlag.de

Annamaria Frömgen, Vulkan-Verlag GmbH

Tel. + 49 (0) 201 82002-91, Fax: + 49 (0) 201 82002-40

E-Mail: a.froemgen@vulkan-verlag.de

Silvija Subasic, Vulkan-Verlag GmbH

Tel. + 49 (0) 201 82002-15, Fax: + 49 (0) 201 82002-40

E-Mail: s.subasic@vulkan-verlag.de

Bettina Schwarzer-Hahn, Vulkan-Verlag GmbH

Tel. + 49 (0) 201 82002-24, Fax: + 49 (0) 201 82002-40

E-Mail: b.schwarzer-hahn@vulkan-verlag.de

Advertising

Martina Mittermayer, Vulkan-Verlag GmbH / Oldenbourg Industrieverlag GmbH

Administration Tel. + 49 (0) 89 45051-471, Fax: + 49 (0) 89 45051-300

E-Mail: mittermayer@oiv.de

Layout

Terms of subscription:

Nilofar Mokhtarzada, Vulkan-Verlag GmbH

heat processing is published four times a year.

Rates: Subscription (inside Germany): € 128,- + € 12,- shipping

Subscription (outside Germany): € 128,- + € 14,- shipping

Single copy (inside Germany): € 37,- + € 3,- shipping

Single copy (outside Germany): € 37,- + € 3,50 shipping

ePaper (as PDF): Subscription: € 128,- Single copy: € 37,-

Abo Plus (print + ePaper): Subscription (inside Germany): € 178,40

Subscription (outside Germany): € 180,40

Students: 50% reduction on normal subscription rate (proof of entitlement)

Orders may be placed at any time. Please address directly to our customer service or your local book shop. Subscriptions

continue for another year unless terminated in writing 2 months prior to the end of each year.

Subscriptions/

Leserservice heat processing . Postfach 91 61 . 97091 Würzburg

Single Copy Sales Tel. +49 (0) 931 / 4170-1616, Fax: +49 (0) 931 / 4170-492

E-Mail: leserservice@vulkan-verlag.de

Printed by

The magazine and all the contributions and illustrations contained therein are secured by copyright. With the exception

of the legally permitted instances, any utilisation without the express permission of the publisher will be punished at law.

The opinions contained in signed articles do not necessarily reflect the opinion of the publisher.

Druckerei Chmielorz GmbH

Ostring 13 · 65205 Wiesbaden-Nordenstadt

© 2003 Vulkan-Verlag GmbH

Huyssenallee 52-56 · 45128 Essen (Germany)

Telefon + 49 (0) 201 82002-0, Telefax + 49 (0) 201 82002-40

ISSN 1611-616X

Mitglied der Informationsgemeinschaft zur

Feststellung der Verbreitung von Werbeträgern e.V. (IVW)

ITPS –

International THERMPROCESS

Summit,

Düsseldorf,

July 09th – 10th, 2013

See you at ITPS!

Together one step ahead.

www.aichelin.com

HEAT PROCESSING Induction Solutions (Vorschau)

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
