5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN

Tel: +81(6)6659-8201 Fax: +81(6)6659-8510

URL: www.m-system.co.jp

E-mail: info@m-system.co.jp

2009

Four-wire Signal Conditioners

Two-wire Signal Conditioners

Function Modules

Limit Alarms

Power Transducers

Remote I/O

PC Recorder

Paperless Recorders

Panel Meters

Lightning Surge Protectors

Electronic Actuators

Position Sensors

EC-Z906 Rev.6

January 2009

500365

ISO 9001 / ISO 14001 Certified

No matter what combination of process signal

I/O, power input and mounting configuration

you need, M-System can meet your requirements

when others can't. Just what you would expect

from the world's largest supplier of

high-performance interface solutions.

Count On Us for Quality & Reliability

Quality: M-System delivers more than 500,000 I/O units (300,000 units of signal conditioners) every year,

and we are very proud of our manufacturing and quality control process certified by ISO 9001.

Reliability: M-System does not easily stop manufacturing products once released in the market, unless we are

able to supply other products of equal or better quality to replace with, because we believe it is a very

important responsibility as a leading manufacturer in the world to continue to serve people who maintain the

performance of process control systems.

Count On Us for Fast & Precise Delivery Time

The standard manufacturing lead time for most M-System's signal

conditioners is 5 days. But more than quarter of the total shipments

are delivered in shorter lead time, and Quick Service Center expedites

more than 500 orders every month on the same day or the next day

after ordered. Do not worry too much about the standard delivery.

Just let us know 'When' you need a signal conditioner. Once a

delivery date is promised, you can of course count on us to deliver the

products precisely on time.

Meeting with Modern Industrial Trends

M-System offers an enormous selection of I/O products including signal conditioners, distributed network I/O,

paperless recorders, panel meters, surge suppressors and valve actuators. Not only that, we are continuously

working on meeting modern industrial trends for PROFIBUS, Modbus, Ethernet, DeviceNet, LONWORKS I/O,

MECHATROLINK devices. Working with openarchitecture

networks, these products easily

communicate to today's most popular HMI

software packages and DCS/PLCs.

Major product offerings of M-System are also

certified by various industrial standards such as CE

(EMC, LVD), UL & C-UL, ATEX (CENELEC) and FM.

Products Index

Page

Four-wire Signal Conditioners

6-24

Global English

www.m-system.com/english

hotline-intl@m-system.co.jp

Simplified Chinese

www.m-system.com/chinese

info-c@m-system.co.jp

Korean

www.m-system.com/korean


Select Your Language or Region

North America

(U. S. A., Canada & Mexico)

www.m-system.com/us

hotline-us@m-system.co.jp

Traditional Chinese

www.m-system.com/taiwan


• Mini-M Series Super-mini Transmitters

• Mini-MW Series Space-saving Dual Output Transmitters

• M6 Series Ultra-slim Transmitters

• M5/B5 Super-mini Terminal Block Transmitters

• W5 Terminal Block Dual Output Transmitters

• M3L Series PC Programmable Transmitters

• M3S Series Super-slim Transmitters

• Four-wire Fixed Range Isolators / DC mV, V, mA Input

• Four-wire Temperature Transmitters

• Frequency Transmitters

• Strain Gauge & Potentiometer Transmitters

• AC Input Transmitters

• Pneumatic Transducers

• Current Loop Supplies & DC Power Supplies

Two-wire Signal Conditioners

• B3 Series DIP-Switch Configurable Two-wire Transmitters

• Two-wire Fixed Range Transmitters

• Two-wire Universal Temperature Transmitter

• Two-wire Temperature Transmitters

25-28

PRODUCT KEY WORDS

Information on most popular

M-System products is included and

updated continuously on our web

site. For more information on the

products in this catalog including

detailed data sheet, look into the

keywords under PRODUCTS.

WORLD SALES CONTACTS

M-System has a worldwide network of sales

representatives. Access WORLD SALES

CONTACTS to find M-System’s local

representative in your area.


Limit Alarms

• M7E Series High-performance Dual / Quad Limit Alarms with LCD Display

• High-performance Dual / Quad Limit Alarms

• Analog Limit Alarms


29

30-32

33-34

• LT Series Power Transducers

• 53U Multi Power Monitor

Remote I/O

35-38

• R3 Series Multi-channel, Mixed Signal Remote I/O

• R5 Series Compact, Mixed Signal Remote I/O

• R7 Series Compact Remote I/O

SERVICES & SUPPORT,

LITERATURE

Technical and application

information is available in SERVICES

& SUPPORT section.

Device profiles and updates of

configurator software, demo version

tryouts are downloadable.

ON-LINE M-SYSTEM

SIGNAL CONDITIONERS DATA LIBRARY

M-System

Web Site

PC Recorder

• PC Recorder

• PC Recorder MSRPAC

• PC Recorder MSRpro

Paperless Recorders

• 73VR Paperless Recorder

Panel Meters

• Bargraph Indicators

• Digital Panel Meters

39-43

44-47

48-49

Specifications and instruction manuals for more than

1000 models are downloadable at On-Line M-System

Signal Conditioners DATA LIBRARY, updated weekly.

Search parameters include product function and model

number. CE, UL & C-UL are clearly indicated.


• Lightning Surge Protectors

• MD7 Series Ultra-Slim Lightning Surge Protectors

50-53

Electronic Actuators & Position Sensors 54-55

M2 Series Super-mini Transmitters

W2 Series Space-saving Dual Output Transmitters

M-System's M2 Series Signal Transmitters are designed to accept

a largest range of process signal inputs and provide a standard and

non-standard DC output.

The W2 Series Signal Splitters provide two isolated

output of independent ranges.

Both M2 and W2 use a compact-size, plug-in socket

base for quick installation or replacement of modules without

disturbing wiring

2000 Vac isolation

Standard DIN rail or surface mounting

Base socket included with modules

Selectable 100-240 Vac/24 Vdc power input

Selection of models by fixed range or PC programmable

CE marking and UL/C-UL Class 1 Div 2 approval

(selected models)

EXTERNAL DIMENSIONS mm (inch)

M2 Series

M2SN

M2XU

M2XUM

M2XV2

M2LV

70.5 (2.78)

MODEL

M2 Series

21.5

(.85)

10

(.39)

DC Inputs, Isolaters

84 (3.31)

114 (4.49)

DIN RAIL

35mm wide

[4 (.16)]

• When mounting, no extra space is needed between units.

89 (3.50)

53 (2.09)

W2 Series

23

(.91)

10

(.39)

MODEL

W2 Series

FUNCTION

M2 Series W2 Series

----

----

----

----

----

Input Loop Powered Isolator

Universal Transmitter (PC programmable)

Universal Transmitter

(PC-programmable; Modbus-RTU communication)

Signal Transmitter (PC programmable)

Signal Transmitter (field- and PC-configurable)

M2VS

M2VF

M2VF2

M2VV

W2VS

W2VF

----

----

84 (3.31)

114 (4.49)

DIN RAIL

35mm wide

[4 (.16)]


FUNCTION

M2 Series

W2 Series

Signal Transmitter

Signal Transmitter (high speed response)


(ultra-high speed response; isolated)

Voltage Divider

Temprature & Sensor Inputs

MODEL

M2 Series

M2XT2

M2TS

M2XR2

M2LR

M2RS

M2RR

M2XM2

M2LPM

M2MS

M2LCS

M2TG

M2AC

M2PA

M2PE

M2CA

M2CE

M2CEC

MODEL

M2 Series

M2D

M2D2

M2DYS

M2DY

M2DL

M2DNY

M2DYH

M2DU

MODEL

M2 Series

M2PV

MODEL

M2 Series

M2AVS

M2SED

W2 Series

----

W2TS

W2XR

----

W2RS

----

W2XM

----

W2MS

----

W2TG

W2AC

W2PA

W2PE

W2CA

W2CE

----

DC Supplies

M2AS

M2AS1

W2 Series

----

----

W2DYS

W2DY

----

W2DNY

W2DYH

----

W2 Series

W2PV

Limit Alarms

W2 Series

----

----

----

----

FUNCTION

Thermocouple Transmitter (PC programmable)

Thermocouple Transmitter

RTD Transmitter (PC programmable)

RTD Transmitter (field- and PC-configurable)

RTD Transmitter

Resistance/Resistance Converter

Potentiometer Transmitter (PC programmable)

Potentiometer Transmitter

(field- and PC-configurable)


Strain Gauge Transmitter

Tachogenerator Transmitter

AC Transmitter

PT Transmitter (average)

PT Transmitter (RMS, isolated)

CT Transmitter (average)

CT Transmitter (RMS)

AC Current Transmitter

(clamp-on current sensor)

FUNCTION

Pneumatic Transducers

Current Loop Supply (non-isolated)

Current Loop Supply (non-isolated)

Current Loop Supply (isolated)

Current Loop Supply

Current Loop Supply (square root output)


(with square root extractor; isolated)

Current Loop Supply (applicable to HART signal)

Current Loop Supply (10-50mA loop)

FUNCTION

P/I Transducer

FUNCTION

DC Alarm

DC Alarm (thumbwheel setpoint adjustments)

DC Alarm (thumbwheel setpoint adjustments;

DPDT output)

DC Alarm (thumbwheel setpoint adjustments;

single SPDT output)

Frequency I/O

MODEL

M2 Series

M2XPA3

M2XPA2

M2SP

M2XRP2

M2AP

M2PP

M2PRU

W2 Series

----

----

W2SP

FUNCTION

MODEL

FUNCTION

M2 Series W2 Series

M2ADS ---- Adder

M2SBS ---- Subtractor

M2MLS ---- Multiplier

M2DIS ---- Divider

M2REB ---- Ratio/Bias Transmitter (output bias)

M2RTS ---- Ratio/Bias Transmitter (input bias)

M2XF2 ---- Linearizer (PC programmable)

M2FL ---- Square Root Extractor

M2FLS ---- Square Root Extractor (isolated)

M2LMS ---- Limiter

M2UDS ---- Inverted Output Transmitter

M2CDS ---- Delay Buffer

M2CRS ---- Ramp Buffer

M2AMS ---- Track/Hold

M2PHS ---- Peak Hold

M2SES2 ---- High/Low Selector (with simple loop test output)

M2SES ---- High/Low Selector

MODEL

M2 Series

----

W2AP

W2PP

----


Installation Base

M2BS-16U0

M2BS-16U1

M2BS-16U2

M2BS-8U1

M2BS-8U2

M2BS2

M2BC

M2BD

W2 Series

----

----

----

----

----

----

----

----

Frequency Transmitter (PC programmable)

Frequency Transmitter (PC programmable)

Low Frequency Transmitter

Encoder Speed Transmitter

(PC programmable; built-in escitation)

DC/Frequency Converter

Pulse Isolator

Pulse Scaler (selectable range)

FUNCTION


(16 positions, Screw terminal block)


(16 positions, Fujitsu FCN type I/O connector)


(16 positions, Omron I/O connector)


(8 positions, Fujitsu FCN type I/O connector)


(8 positions, Omron I/O connector)


(for 61-UNIT series analog I/O modules)

Communication Controller

(Mitsubishi Control & Communication Link use)

Communication Controller (DeviceNet use)

6

7

M6 Series Ultra-slim Transmitters

Ultra-slim, Space saving, Low power consumption.

High performance transmitters with wide selection

of input and output ranges.

Selectable connection method - Euro terminal, Screw

terminal or Tension-Clamp.

Output load resistance 550Ω (at 4-20 mAdc)

The M6 Series is designed that ensuring low power

consumption. The front Power LED provided

Wide selection of models by fixed range or PC

programmable. User-friendly versatile programming

features provided

The status LED for PC programmable models


Optional fast response: Approx. 3.5 msec, voltage output

(M6xYV)

High-density mounting: 16 units (M6D) in a space of 9.5 cm (3.75”)

Euro terminal

M6D Series

5.9mm

(0.23”)

Screw terminal

M6N Series

7.5mm

(0.30”)

Tension-Clamp

M6S Series

5.9mm

(0.23”)

Optional installation base

Tension-Clamp Ultra-Slim Signal Conditioners M6S Series

• 5.9-mm (0.23”) wide ultra-slim design

• The spring terminal provides constant force, eliminating torque

management, maintenance-free for retightening

• High-density mounting

Spring Terminal

W5.9 x H94 x D102mm (0.23” x 3.70” x 4.02”)

Screw Terminal Ultra-Slim Signal Conditioners M6N Series


• Self-up screws prevents falling off a terminal


9.5cm

(3.75”) No.1

2

4

8

M6D EXTERNAL DIMENSIONS mm (inch)

8-M3 EURO TERMINAL

5 6 7 8

DIN RAIL HOOK

DIN RAIL

35mm wide

16

Power supplied to signal conditioners from the

power supply module (via the installation base).

Holding up to 48 modules of M6 Series using 6

installation bases.


(Model : M6xBS)

W7.5 x H102 x D102mm (0.30” x 4.02” x 4.02”)

Screw Terminal

Euro Terminal Ultra-Slim Signal Conditioners M6D Series


• Space saving Euro type terminal


94 (3.70)

35.4 (1.39)

Max.

48 modules

5.9 (.23)

1 2 3 4

102 (4.02)


Power supply module (Model : M6xPS1)

or

For redundant power supplies (Model : M6xPS2)

Euro Terminal

W5.9 x H94 x D102mm (0.23” x 3.70” x 4.02”)

8 9

M6 Series Ultra-slim Transmitters

ANALOG INPUT TYPE

Isolator

Product

Tension-Clamp type

Screw terminal type

Euro terminal type

Input / Output

Load resistance

Power input

Accuracy

Response time

(0-90%)


M6SSN-1, -2*

M6NSN-1, -2*

M6DSN-1, -2*

0-20 mAdc (4-20 mAdc) /

0-20 mAdc (4-20 mAdc)

Equivalent input

impedance:

250 Ω + Load resistance

(with 20 mA input)

0-600 Ω

----

± 0.1%

Approx. 20 mec.

Dielectric strength 1500 Vac@1 minute

(input to output)

CE marking Yes

* M6xSN-1: One Channel, M6xSN-2: Two Channels

Sensor and Pulse Input

Product




Input

DC current output


DC voltage output


Power input

Accuracy

Response time

(0-90%)

Dielectric strength

CE marking


M6SVS

M6NVS

M6DVS

Input range:

-30 to +30 Vdc

(Min. Span: 100 mVdc)

Current input:

Resistor incorporated

Output range: 0-20 mA

Min. Span: 1 mA

≤550 Ω at 4-20 mA

Output range:

0-1 V, 0-10 V, 0-5 V, 1-5 V,

-10 to +10 V, -5 to +5 V

DC voltage: 0-10 V

Min. Span: 1 V

≥5 kΩ at 1-5V

Isolator

M6SYV

M6NYV

M6DYV

4-20 mAdc / 4-20 mAdc

4-20 mAdc / 1-5 Vdc

1-5 Vdc / 4-20 mAdc

1-5 Vdc / 1-5 Vdc

-10 to +10 Vdc / -10 to +10 Vdc

DC current: ≤550 Ω at 4-20 mA

DC voltage: ≥20 kΩ at -10 to +10V

24 Vdc ± 10%

≤0.5 sec. standard;

Approx. 3.5 msec. optional with voltage output

Approx. 25 msec. optional with current output

2000 Vac@1 minute

(input to output to power to ground)


M6SDY

M6NDY

M6DDY

Input signal: 4-20 mAdc

Supply output:

24-30 V at no load

Current rating:

Max. 22mA

Shortcircuit protection

4-20 mA

0-10 V

0-5 V

1-5 V

24 Vdc ± 10%

± 0.1%

≤0.5 sec. standard;

≤100 msec.

Approx. 3.5 msec. optional

with voltage output

Approx. 25 msec. optional

with current output



Yes

Product

Dual Output Signal Transmitter

Tension-Clamp type M6SWVS

Screw terminal type M6NWVS

Euro terminal type M6DWVS

Input

Input range:

-30 to +30 Vdc

(Min. Span: 100 mVdc)

Current input:


Output 1 DC current output 0-20mA, 4-20mA

Load resistance ≤280 Ω

DC voltage output 0-5 Vdc, 1-5 Vdc

Load resistance ≥5 kΩ

Output 2

Same range availability as Output 1.

Power input 24 Vdc ± 10%

Accuracy

± 0.1%

Response time (0-90%) ≤0.5 sec. standard;

Approx. 3.5 msec. optional

Dielectric strength 2000 Vac@1 minute

(input to output 1 to output 2

to power to ground)


CT Transmitter

(clamp-on current sensor)

M6SCTC

M6NCTC

M6DCTC

Input range:

0-10 Aac to

0-600 Aac


Min. Span: 1 mA

± 0.5%

≤1 sec.

Dual Output Type

Clamp-on current sensor

(model: CLSB) optional.

Frequency Transmitter

M6SPA

M6NPA

M6DPA

Open collector

Mechanical contact

Voltage pulse (5 and 24 V)


(and 0-1 mA)

Min. span: 1 mA

Output range: 0-1 V, 0-10 V, 0-5 V, 1-5 V, -10 to +10 V,

-5 to +5 V


Min. Span: 1 V

± 0.1%

≤0.5 sec.

1-cycle input pulse or less

PC PROGRAMMABLE TYPE

Sensor Input

Product




Input

DC current output range


DC voltage

output range


Power input

Accuracy

Response time (0-90%)


CE marking

Limit Alarms

Product




Input

Alarm point

Relay rating

Power input

Set accuracy

Response time


Features

CE marking

Signal transmitter Thermocouple Transmitter RTD Transmitter Potentiometer Transmitter

M6SXV

M6NXV

M6DXV

2000 Vac@1 minute (input to output to power to ground)

Yes

M6SXT

M6NXT

M6DXT

(PR), K, E, J, T, B, R, S, N

M6SXR

M6NXR

M6DXR

Pt100

Pt50 Ω

Pt1000

Cu10 @25˚C

Current input range:

0-50 mAdc (Min. span: 2 mAdc)


Voltage input range:

-1000 to +1000 mVdc (Min. span: 100 mVdc)

-10 to +10 Vdc (Min. span: 1 Vdc)

0-20 mA (Min. span: 1 mA)

≤550 Ω at 4-20 mA

-10 to +10 V (Min. span: 1 V)

-5 to +5 V (Min. span: 0.5 V)

≥5 kΩ at 1-5 V

24 Vdc ± 10%

Varies with the type and input / output range. For details, see the specification sheet.

≤0.5 sec. ≤1 sec.

PC PROGRAMMABLE TYPE

DC Alarm

M6SXAS

M6NXAS

M6DXAS

Current input range:

0-50 mAdc

(Min. span: 2 mAdc)


Voltage input range:

-1000 to +1000 mVdc

(Min. span: 100 mVdc)

-10 to +10 Vdc

(Min. span: 1 Vdc)

Single (Hi/Lo selectable)

250 Vac @2A

30 Vdc @2A

24 Vdc ± 10%

± 0.05 %

≤ 0.2 sec.

(0 – 100% at 90% setpoint)


(input to output to power

to ground)

Failsafe operation input

type and range, alarm

setpoint, trip action

(High or Low)

power / alarm ON delay,

deadband, alarm test mode

Yes


Product




Input

Output range

Power input

Accuracy

Response time

(0-90%)


Functions

CE marking


M6SXF1

M6NXF1

M6DXF1

See M6xXV.

See M6xXV.

24 Vdc ± 10%

Varies with the type and input /

output range. For details,

see the specification sheet.

≤ 0.5 sec.

without any function setting



Filter / Lag

· Moving average output

· Dead time computing

· Delay buffer (first order lag)

· Lead time computing

· Ramp buffer

Linearization

· User’s table linearization

· Inverted output

· Square root extraction

(orifice, venturi)

· X 2 (Palmer-Bowlus flume,

Parshall flume)

· X 5/2 (triangular or v-notch weir)

· X 3/2 (rectangular weir)

Limiter

· High / Low limit

Yes

NEW

RELATED PRODUCTS

CE marking

Yes

Power Supply Modules

M6SXM

M6NXM

M6DXM

Input range:

0-100 Ω to 0-5000 Ω


Product Installation Base

Model No. M6SBS (M6S series), M6NBS

(M6N series), M6DBS (M6D series)

Installation Max. 48 modules (6 modules x 8 bases)

Product

Power Supply Module Power Supply Module

(dual redundant)

Tension-Clamp type M6SPS1 M6SPS2

Screw terminal type M6NPS1 M6NPS2

Euro terminal type M6DPS1 M6DPS2

Supply voltage 22-27 Vdc, ripple 10% p-p max.

2A (Total current consumed by signal

conditioners on the base must be 2A

or less.)

Dielectric strength 2000 Vac@1 minute (power to ground)


Blank Filler Modules

Product Blank Filler Module

Tension-Clamp type M6SDM

Screw terminal type M6NDM

Euro terminal type M6DDM

Used to fill blank solts on an

installation base

CE marking ----

10 11

M5/B5 Super-mini Terminal Block Transmitters

W5 Terminal Block Dual Output Transmitters

M-System's M5/B5/W5 Series Transmitters are designed to accept a

wide variety of process signal input and provide a standard and

non-standard DC output.

M5 Series B5 Series W5 Series

M5 Series Super-mini Terminal Block Signal Transmitters


94 (3.70)

3

(.12)

7.3 (.29)

1 2

3 4

5 6

7 8

25

(.98)

8–M3.5 SCREW

DIN RAIL

35mm wide

41 (1.61) [3.3 (.13)]


MODEL

M5SN

M5VS

M5MV

M5VF

M5TS

M5RS

M5MS

M5DY

M5PT

M5CT

M5CTC

M5PA

FUNCTION



Signal Transmitter (narrow span input)

Signal Transmitter (high speed response)





PT Transmitter

CT Transmitter

CT Transmitter (clamp-on current sensor)


B5 Series Super-mini Two-wire Terminal Block Signal Transmitters

Only 41 mm (1.61 in") deep modules can be installed anywhere, even behind the panel cover

The M5 Series features single channel four-wire models, while the B5 Series are two-wire models


7.3 (.29)


MODEL

B5SN

B5VS

FUNCTION



The W5 Series signal splitters provide two isolated DC outputs of independent ranges

Standard DIN rail mounting

1 2

3 4

DIN RAIL

35mm wide

B5TS

B5RS

B5MS




2000 Vac isolation (1500 Vac for M5 AC powered)

94 (3.70)

Selectable power input – 24 Vdc, 85-264 Vac (M5) ; 11-27 Vdc, 85-264 Vac, 110 Vdc (W5)

5 6

7 8

Space-saving

3

(.12)

25

(.98)

41 (1.61) [3.3 (.13)]

W5 Series Terminal Block Dual Output Signal Transmitters


7.4 (.29)


MODEL

W5VS

FUNCTION


W5FV

Signal Transmitter (field-configurble)

1

2

3

4

5

DIN RAIL

35mm wide

W5TS

W5RS



94 (3.70)

W5MS

W5DY



6

7

8

9 10 11

6 (.24)

W5LCS

W5PA

Strain Gauge Transmitter


M5/B5/W5 Series low profile form

factor fits into shallow cabinets

3

(.12)

45 (1.77) 41 (1.61) [3.3 (.13)]

6–M3 SCREW


12 13

M3L Series PC Programmable Transmitters

“ONE-STEP CAL” Programming Without Needing a PC is also available.

Easy and precise field configurable I/O ranges

Enhanced PC Configurator Software


18 mm (0.71”) thin profile DIN rail mounting

M-System’s M3L Series is a DIN rail mounted, universal input

transmitter with 1500 Vac isolation.

Ideal for Spare Parts Stock Reduction Programs, the M3L Series

supports two methods for configuring the unit. The unit’s DIP

switches/control buttons simplify in-field configuration without

using a PC. When identical multiple configurations are required,

save yourself some time downloading the setting from PC

software.

M3L Series is your safe bet when you are not sure of

your final I/O signals.

Typical applications include eliminating ground loops in

temperature measurement applications and providing an isolated MODEL FUNCTION

interface to data acquisition and control systems. M3LU Universal (DCmV, V, mA, T/C, RTD, Pot)

M3LV DC mV, V, mA input

M3LT Thermocouple input

M3LR RTD input

M3LM Potentiometer input

M3LPA Frequency input

M3LLC Strain gauge input

M3LDY Current loop supply


PC Configurator is packed with advanced features such as:

• Parameter setting are easily configured with a help of bargraphs on the screen.

• Trend graph monitoring is also possible.

• Fixed analog output can be set and provided for simulation when conducting a loop test.

• 128-point linearization and custom thermocouple/RTD tables

• Fine calibration

• Save configuration files

• Input filter

• Diagnostics

Sensor Information with Trend Graph

Analog Output Calibration

File Management (Compare)

PC Configuration

When you need to apply the same

setting to multiple transmitters,

downloading one setting from the PC is

convenient. The PC Configurator

Software is available to download at

M-System web site.

SPECIFICATIONS

Input type DC mV, V,mA Thermocouple RTD Pot/Resistance Frequency Strain Gauge Two-wire XMTR

Model No. M3LU

Model No. M3LV M3LT M3LR M3LM M3LPA M3LLC M3LDY

Selectable input 0-20 mA (PR), K, E, J, T Pt 100 - Pt 1000 Pot: 80-4000 Ω Open collector 0.0-1.0 mV/V 0-20 mA

±1V B, R, S, Ni 100, Ni 120, 90 – 20k Ω (M3LM) Mechanical contact 0.0-3.0 mV/V

±10V C (WRe 5-26) Ni 508.4 Resist: 10-4000 Ω Voltage pulse 0.0-10.0 mV/V

N, U, L Ni-Fe 604 Two-wire current 0.0-30.0 mV/V

P (Platinel II) Cu 10 @25ºC

P+50 Ω

RS-422 line driver

Max. 100 kHz

Excitation supply ---- 4 V , 8 V , 12 V 0.1 to 10.0 V 24-28 Vdc

Maximum current 20mA 30mA 22mA

Selectable output

0-20 mA (min. 1mA span) ±2.5V (min. 250mV span) ±10V (min. 1V span)

DC power input 10-32 Vdc 10-32 Vdc 10-32 Vdc 24 Vdc

AC power input 100-240 Vac (available only for M3LU) 100-240 Vac ---- ----

Accuracy * * ±0.2% *

Response time (0-90%) ≤0.2 sec. with the optimum synch filter (M3LU) * ≤10 msec. ≤1.0 sec.

Operating temperature

-25 to +65ºC (-13 to +149ºF)

Insulation resistance ≥100MΩ with 500 Vdc

Dielectric strength 1500 Vac @1 minute (input to output or power to ground) 500 Vac @1 minute (output to power)

Except AC powered M3LU: 2000 Vac @1 minute (input to output to power to ground)


Safety approval UL & C-UL (24 Vdc powered only)

*Depends upon the I/O types and ranges. Refer to the data sheet for the respective model for detail.

“ONE-STEP CAL” Configuration

Both input type & range and output type & range are totally independent to

each other, which makes the calibration easier and quicker than ever.

Simply by pushing the front control buttons, “ONE-STEP CAL”

programming is possible without requiring personnel to have any special

knowledge to do so.

LED

The front LED’s colors and flashing patterns

help you easily identify the transmitter’s

status and confirm the setup actions in each

step of Calibration Modes.

14 15

MODE Button

UP Button

DOWN Button

M3S Series Super-slim Transmitters

M3S Series including models available to select

universal AC/DC power input.

Super-space-saving 12mm (0.47") width

Universal AC/DC power input available

PC programmalble models available

DC input model with optional fast response time

12mm (0.47") slim profile DIN rail mounting.

Selectable 100-240 Vac/24-240 Vdc universal AC/DC power input.

Selection of models by fixed range or PC programmable.


• Parameter setting are easily configured on a PC screen.

• Trend graph - Input signal to the device can be monitored.

• Fixed analog output can be set and provided for simulation when conducting a loop test.

• 100-point linearization and 300-point custom thermocouple/RTD tables.

• Filter time constant.

• Fine calibration

• Save configuration files

Basic Setting View

Loop Test View

12mm (0.47”) wide


7 8

5 6

DINRAIL

35mm wide

106 (4.17)

62 (2.44)

Fine Adjustments View

Trend Graph View

1 2

3 4

Detachable terminal blocks.

12

(.47)

110.5 (4.35)



Input type DC mV, V, mA DC mV, V, mA DC mV, V, mA RTD Potentiometer

(Dual Output)

Model No. M3SYV M3SVS

M3SWVS M3SRS M3SMS

Input

DC current: DC current: DC current: Pt 100,

Potentiometer:

4-20 mA, 0-20 mA, resistor incorporated resistor incorporated Pt 50 Ω,

100 Ω – 10k Ω

±20 mA

4-20 mA, etc. 4-20 mA, etc. Ni 508.4 Ω

DC voltage:

0-10 V, 0-5 V,

1-5 V, ±10 V, ±5 V

DC voltage input range:

-300 to +300 V

(min. 3mV span)

DC current output 4-20 mA, 0-20 mA Output range: 0-20 mA

(min. 1mA span)

DC voltage:

-30 to +30 V


Load resistance ≤750 Ω

≤550 Ω at 4-20 mA ≤280 Ω

≤550 Ω at 4-20 mA

DC voltage output 0-10 V, 1-5 V,

±10 V

Output range:

-10 to +11 V


Load resistance ≥5k Ω at 1-5 V ≥5k Ω at 1-5 V ≥5k Ω

≥5k Ω at 1-5 V

Power input 24 Vdc 100-240 Vac, 24-240 Vdc

Accuracy ±0.1% ±0.2% ±0.1%

Response time

(0-90%)


Insulation resistance


CE marking

≤0.5 sec. ≤0.5 sec.

25 msec. optional

Output 1, 2:

4-20 mA, 0-20 mA

Output 1, 2:

0-5 V, 1-5 V

≤0.5 sec.

3.5 msec. optional

-10 to +55˚C (14 to 131˚F) (Min. -20˚C or -4˚F for M3SWVS and M3SDY)

≥100MΩ with 500 Vdc

2000 Vac @1 minute (input to output to power to ground)

Yes


(min. 1mA span)

Output range: -10 to +11 V


≤0.5 sec.


Two-wire XMTR

M3SDY

Input signal:

4-20 mAdc

Supply output:

24-28 Vdc

with no load

Current rating:

Max. 22 mAdc

4-20mA

≤550 Ω

0-10 V, 0-5 V,

1-5 V

≥5k Ω at 1-5 V

24 Vdc

±0.1%

≤100 msec.


Input type DC mV, V, mA Thermocouple RTD Potentiometer

Model No. M3SXV M3SXT M3SXR M3SXM

Input

DC current input range: (PR), K, E, J, T,

0-100 Ω to 0-5000 Ω

0-50 mA (min. 2mA span) B, R, S, N

DC voltage input range:

-1000 to +1000 mV


-10 to +10 V (min. 1V span)

Output range: 0-20 mA (min. 1mA span)

Pt 100,

Pt 50 Ω,

Pt 1000,

Cu 10 @25ºC


Load resistance 550 Ω at 4-20 mA

DC voltage output Output range: -10 to +10 V (min. 1V span) , -5 to +5 V (min. 0.5V span)

Load resistance 5 kΩ at 1-5 V

Power input 24 Vdc (100-240 Vac, 24-240 Vdc pending) 100-240 Vac, 24-240 Vdc

Accuracy *

Response time (0-90%) ≤0.5 sec. ≤1 sec.

Operating temperature -10 to +55˚C (14 to 131˚F)


Dielectric strength 2000 Vac @1 minute (input to output to power to ground)


*Depends upon the I/O types and ranges. Refer to the data sheet for the respective model for detail.

16 17

Four-wire Fixed Range Isolators / DC mV, V, mA Input

Four-wire Temperature Transmitters

Compact Plug-in Design

M2VS

M2VF

W2VS

W2VF


Series M2 / W2 Series M6 Series M5 / W5 Series

Single output model M2VS M2VF M6xVS

M5VS/M5MV

Dual output model W2VS W2VF M6xWVS

W5VS W5FV

DC voltage input -300 to +300 V -300 to +300 V -300 to +300 V -300 to +300 V

(Specific range of)

(±100mV/M5MV)

Minimum span 3mV 1V 100mV 100mV

(5mV/M5MV)

DC current input



Single output

Single output, ≤180 µsec. response

Two isolated outputs

Two isolated outputs, ≤180 µsec. response

• Wide selection of input and output ranges

• Optional 25 msec. response time selectable for M2VS and W2VS

• Two independent ranges can be specified with the signal splitter.

Ultra-slim, Space-saving

M6SVS

M6NVS

M6DVS

M2 Series

Single output, Tension-Clamp

Single output, Screw terminal

Single output, Euro terminal

Resistor attached to the input terminals.

4-20 mA, 0-10 mA, 10-50 mA, etc.

0-20 mA

e.g. 4-20 mA

M6SWVS

M6NWVS

M6DWVS

-10 to +20 mA

e.g. ±1mA

W2 Series


4-20 mA, 0-10 mA, etc.

0-20 mA

Low-profile, Low Cost Type

M5VS

M5MV

M5VF

W5VS

W5FV

M5VF

-30 to +30 V Field-selectable

0-60 mV, 0-100 mV,

1V


4-20 mA, 0-10 mA, 10-50 mA, etc.

0-20 mA

e.g. 4-20 mA

M5 Series

Single output

Single output, narrow span

Single output, ≤150 µsec. response


Two isolated outputs, field-selectable I/O

0-1 V, 0-5 V, 1-5 V,

0-10 V, ±5V, ±10V

Field-selectable

4-20 mA, 0-20 mA, 0-10 mA

Out 1: Field-selectable

4-20 mA, 0-20 mA

Min. span: 1mA (M6xVS)

4-20 mA, 0-20 mA

Minimum span 1mA 1mA Fixed (M6xWVS) 1mA Out 2: Fixed

W5 Series

• 41 mm (1.6”) deep


Two isolated outputs, Tension-Clamp

Two isolated outputs, Screw terminal

Two isolated outputs, Euro terminal

• 5.9 mm (.23”) wide for M6S Series and M6D Series, 7.5 mm (.30”) wide for M6N Series

• Optional fast response time selectable


M6 Series

Load resistance ≤750Ω at 4-20 mA ≤550Ω at 4-20 mA (M6xVS) ≤550Ω at 4-20 mA

≤550Ω at 4-20 mA

Load resistance, Out 2 ≤350Ω at 4-20 mA ≤280Ω (M6xWVS) ≤550Ω at 4-20 mA ≤550Ω at 4-20 mA



-10 to +12 V (+10V for Output 2)

e.g. 1-5 V, 0-10 V

0-10 V

Min. span: 1V (M6xVS)

0-5 V, 1-5 V

0-10 V (-10 to +12 V for W5VS)

e.g. 1-5 V, 0-10 V

Out 1: Field-selectable

0-10 V, 0-5 V, 1-5 V

±5V, ±10V

Minimum span 5mV

Fixed (M6xWVS) 1V (5mV for W5VS) Out 2: Fixed

Load resistance ≥5kΩ at 1-5 V ≥5kΩ at 1-5 V ≥500Ω at 1-5 V ≥500Ω at 1-5 V

Power input 24 Vdc or 100-240 Vac 24 Vdc 24 Vdc or 100-240 Vac

Accuracy ±0.1% ±0.1% ±0.1% ±0.1% ±0.1% ±0.1%

Response time ≤0.5 sec. ≤180 µsec. ≤0.5 sec.

≤0.5 sec. ≤150 µsec. ≤0.5 sec.

(0-90%)


3.5 msec. optional (25 msec.

for M6xVS Current output)

25 msec./≤1 msec.

Operating temperature -5 to +55ºC (23 to 131ºF) (Min. -20ºC or -44ºF for M6)


Dielectric strength 2000 Vac @1 minute (input to output to power to ground) 2000 Vac @1 minute (DC powered M5)

1500 Vac @1 minute (AC powered M5)

CE marking Yes Yes Yes (24 Vdc powered)

Safety approval UL & C-UL nonincendive ---- ----


M2TS Thermocouple input, Single output

W2TS Thermocouple input, Two isolated outputs

M2RS RTD input, Single output

W2RS RTD input, Two isolated outputs

W2XR RTD input, Two isolated outputs, PC programmable

• Linearization, burnout protection, cold junction compensation

(T/C input) standard

• Optional 25 msec. response time selectable



M6SXT

M6NXT

M6DXT

Thermocouple input, Tension-Clamp

Thermocouple input, Screw terminal

Thermocouple input, Euro terminal

M6SXR

M6NXR

M6DXR


M5TS Thermocouple input, Single output

W5TS Thermocouple input, Two isolated outputs

M5RS RTD input, Single output

W5RS RTD input, Two isolated outputs

• 41 mm (1.6”) deep

• Linearization, burnout protection, cold junction compensation




RTD input, Tension-Clamp

RTD input, Screw terminal

RTD input, Euro terminal

• 5.9 mm (.23”) wide for M6S Series and M6D Series

7.5 mm (.30”) wide for M6N Series

• Linearization, burnout protection, cold junction compensation (T/C input) standard

• PC programmable

M2 Series

M5 Series



Single output model M2TS M2RS M6xXT M6xXR

M5TS M5RS

Dual output model W2TS W2RS W5TS W5RS

Input T/C T/C T/C RTD

T/C RTD

DC current output 0-20 mA 0-20 mA 0-20 mA

(Specific range of) e.g. 4-20 mA e.g. 4-20 mA

Minimum span 1mA 1mA 1mA

Load resistance ≤750Ω at 4-20 mA ≤550Ω at 4-20 mA ≤550Ω at 4-20 mA

Load resistance, Out 2 ≤350Ω at 4-20 mA ---- ≤550Ω at 4-20 mA

DC voltage output -10 to +12 V (+10V for Output 2) -10 to +11 V (Min. span: 1V) 0-10 V (-10 to +12 V for W5)

(Specific range of) e.g. 1-5 V, 0-10 V -5 to +5 V (Min. span: 0.5V) e.g. 1-5 V, 0-10 V

Minimum span 5mV 1V (5mV for W5)

Load resistance ≥5kΩ at 1-5 V ≥5kΩ at 1-5 V ≥500Ω at 1-5 V


Accuracy ±0.4% ±0.2% Varies with the type and

input / output range.

For details, see the specification sheet.

K, E, J: ±0.1% FS or 0.2ºC ±0.2%

T, N: ±0.2% FS or 0.2ºC

B, R, S: ±0.3% FS

W2 Series

M6 Series

W5 Series

Response time (0-90%) ≤0.5 sec. standard; 25 msec. optional ≤0.5 sec. ≤0.5 sec. standard; 25 msec. optional

Operating temperature -5 to +55ºC (23 to 131ºF) -20 to +55ºC (-4 to 131ºF) -5 to +55ºC (23 to 131ºF)


Dielectric strength 2000 Vac @1 minute (input to output to power to ground) 2000 Vac @1 minute (DC powered M5)

1500 Vac @1 minute (AC powered M5)


Safety approval UL & C-UL nonincendive ----

----

18 19

Frequency Transmitters

Strain Gauge & Potentiometer Transmitters


M2XPA2 Frequency input, PC programmable

M2SP Frequency input, Single output

W2SP Frequency input, Two isolated outputs

• Converts the output from a pulse-type transducer into a DC signal

• Two independent ranges can be specified with the signal splitter

M2AP

W2AP

Single frequency output

Dual frequency output

• Provides a pulse rate output in proportion to DC input signal

• Pulse integration application

• Two independent ranges can be specified with the signal splitter

M2PP

W2PP

Single output pulse Isolator

Dual output pulse Isolator

• Galvanically isolates pulse rate signals

• Switches pulse transducer types

M2XRP2 Rotary encoder speed transmitter

• Converts a two-phase forward and

reverse rotation pulse signal with

90 degree phase difference into

a forward and reverse speed signal

• Scaling factor adjustable

M2PRU Pulse Scaler

• Converts pulse rate into convenient

engineering unit for display

on a totalizing counter or meter

• Scaling factor adjustable

M2 Series

W2 Series


M5PA Frequency input, Single output

W5PA Frequency input, Two isolated outputs

• 41 mm (1.6”) deep

• Converts the output from a pulse-type

transducer into a DC signal

YPD

M5PA

Standard Plug-in Design

JRQ2

W5PA

(For details, refer to Signal Conditioners Data Library at www.m-system.com)

YPD

WYPD

JRP2

JRQ2

Single output pulse isolator

Dual output pulse isolator

Rotary encoder speed transmitter

Rotary encoder position transmitter


Series

Single output model

M2 / W2 Series

M2XPA2

M2SP M2AP M2PP

M2PRU

Dual output model W2SP W2AP

W2PP

Input User-calibrated Dry contact 0-300 V, e.g. 1-5 V Open collector Open collector

(Open collector/ Voltage pulse Minimum span 1V Mechanical contact Mechanical contact

Mechanical contact/ Min. 50 Hz DC current with resistor, Voltage pulse Voltage pulse

Voltage pulse/RS-422/ Max. 10 kHz e.g. 4-20 mA Two-wire current

Two-wire current)

Sensor excitation User-calibrated 12 Vdc @30mA ---- 12 Vdc @30mA 12 or 24 Vdc @30mA

Output

4, 8 or 12 Vdc @5mA

User-calibrated DC current: 0-20 mA Open collector (1 kHz) Open collector Open collector

DC current: 0-20mA e.g. 4-20 mA / 750Ω Voltage pulse (1 kHz) Voltage pulse Voltage pulse

DC voltage:

Minimum span 1mA Mercury relay (30 Hz) Mercury relay (M2PP) AC/DC switch

-2.5 to +2.5V /

-10 to +10V


(10 V for Output 2)

e.g. 1-5 V / ≥5kΩ


Dry contact AC/DC

switch (W2PP)

Power input

Accuracy

24 Vdc or 100-240 Vac

----

±0.1% ±0.1% ---- ----

Response time (0-90%) ----

≤0.5 sec. at ≥500 Hz Approx. 3 sec. ---- ----




CE marking

Safety approval

-5 to +55°C (23 to 131°F)


2000 Vac @1 minute (input to output to power to ground)

Yes (except W2PP)

UL & C-UL nonincendive (UL/24 Vdc powered only for M2PP; except W2PP)

Field Configuration with Local Display,

Plug-in Type

MXLCF Strain gauge input

• ≤10 msec. response time

• Auto tare feature controlled by

PLC or DCS

Ultra-high Speed Response,

Remote Sensing, Plug-in Type

LCF Strain gauge input

• Six-wire bridge can be used to

compensate for lead resistance

variations due to temperature changes.

• ≤300 µsec. response (2 kHz, -3 dB)


M2LCS Strain gauge input

• Compatible with a bridge

type strain gauge

• Optional 25 msec. response

time selectable

M5MS W5MS


Series MX / M Series M2 / W2 Series M6 Series M5 / W5 Series

Single output model MXLCF LCF M2LCS M2MS M6xXM M5MS

Dual output model W2MS W5MS

Input

1.0mV/V, 3.0mV/V,

10.0mV/V, 30.0mV/V

Specific rating

up to 20 mV/V

Specific rating

up to 20 mV/V

100Ω min.

10kΩ max.

100Ω min.

5kΩ max.

100Ω min.

10kΩ max.

Excitation 0.1-12 V, 120 mA 2-10V, 120 mA 2-10V, 35 mA ---- ---- ----



Field-selectable:

0-20 mA

0-20 mA

e.g. 4-20 mA

0-20 mA

e.g. 4-20 mA

0-20 mA 0-20 mA

e.g. 4-20 mA

Minimum span ---- 1 mA 1 mA 1 mA 1 mA


Load resistance, Out 2



≤600Ω at 4-20 mA

----

Field-selectable:

±1V, ±10V

≤750Ω at 4-20 mA

----

-10 to +12 V

e.g. 1-5 V, 0-10 V


M2MS Potentiometer input,

Single output

W2MS Potentiometer input,


• 0.5V constant voltage excitation allows using

any resistance rating of 100 Ω to 10 kΩ

• Optional 25 msec. response

time selectable

M2MS

W2MS



M6SXM Potentiometer input,

Tension-Clamp

M6NXM Potentiometer input,


M6DXM Potentiometer input,

Euro terminal

• PC programmable


M5MS Potentiometer input,

Single output

W5MS Potentiometer input,


• 41 mm (1.6”) deep

• Optional 25 msec.

response time selectable

• Two independent ranges can be

specified with the signal splitter

≤750Ω at 4-20 mA

≤350Ω at 4-20 mA

-10 to +12 V (+10 V for Output 2)

e.g. 1-5 V, 0-10 V

≤550Ω at 4-20 mA

----

-10 to +11 V

(Min. span: 1V)

-5 to +5 V

(Min. span: 0.5V)

≤550Ω at 4-20 mA

≤550Ω at 4-20 mA

0-10 V (-10 to

+12 V for W5)

e.g. 1-5 V, 0-10 V

Minimum span ---- 5 mV 5 mV 1V (5mV for W5)

Load resistance ≥1kΩ, ≥10kΩ ≥5kΩ at 1-5 V ≥5kΩ at 1-5 V ≥5kΩ at 1-5 V ≥500Ω at 1-5 V

Power input

24 Vdc, 110 Vdc

or 100-240 Vac

100, 110, 120 Vac

200, 220, 240 Vac

24 Vdc or 100-240 Vac 24 Vdc

24 Vdc or

100-240 Vac

M6 Series

Accuracy ±0.2% ±0.1% ±0.1% *

±0.1%

Response time (0-90%) ≤10 msec. ≤300 µsec. ≤0.5 sec.; 25 msec. optional ≤1 sec. ≤0.5 sec.; 25 msec. optional

Operating temperature -5 to +55ºC (23 to 131ºF) (Max. 60ºC or 140ºF for LCF; Min. -20ºC or -4ºF for M6)


Dielectric strength 2000 Vac @1 minute (input to output to power to ground) 2000 Vac @1 min. (DC)

1500 Vac @1 min. (AC)

CE marking Yes Yes Yes Yes (24 Vdc powered)

Safety approval ---- UL & C-UL nonincendive ---- ----

*Varies with the type and input / output range. For details, see the specification sheet.

20 21

AC Input Transmitters

Pneumatic Transducers




M2PV Pneumatic input, Single output

W2PV Pneumatic input, Two isolated outputs

• Converts a standard pneumatic signal into a DC signal.


M2AC

W2AC

M2AC

AC input, Single output

AC input, Two isolated outputs

W2AC

• True RMS sensing


M2TG

W2TG

Tachogenerator input, Single output

Tachogenerator input, Two isolated outputs

• Tachometer input


M5PT

M5CT

PT (VT) input

CT input

• 41 mm (1.6”) deep

• True RMS sensing

Two-wire Pneumatic Transducer

BPV Pressure to current

• Monitor terminal (4-20 mA)

M2PV

W2PV

M2PE/M2PA

W2PE/W2PA

M2CE/M2CA

W2CE/W2CA

M2CE

W2CE

PT (VT) input, Single output

PT (VT) input, Two isolated outputs

CT input, Single output

CT input, Two isolated outputs

Two-wire Self-powered Pneumatic Transducer

HVPN Current to pressure

• Semiconductor pressure sensor in the feedback circuit

• No mounting position effect

• True RMS or average sensing



Series M2 / W2 Series M5 Series

Single output model M2AC M2TG M2PE / M2PA M2CE / M2CA M5PT M5CT

Dual output model W2AC W2TG W2PE / W2PA W2CE / W2CA

Input Specific range of Specific range of 0-110 Vac 0-1 Aac 0-110, 0-220 Vac 0-1 Aac

0-250 V or 0-1 A 0-250 V 0-150 Vac 0-5 Aac 0-150 Vac 0-5 Aac

DC current output 0-20 mA; Minimum span 1mA; e.g. 4-20 mA 0-20 mA; Min. 1mA span


e.g. 4-20 mA

Load resistance ≤750Ω at 4-20 mA (≤350Ω at 4-20 mA for Output 2) ≤550Ω at 4-20 mA

DC voltage output -10 to +12 V (+10V for Output 2) 0-12 V (10V for Output 2) 0-10 V; Min. 1V span

(Specific range of) e.g. 1-5 V, 0-10 V e.g. 1-5 V, 0-10 V e.g. 1-5 V, 0-10 V

Load resistance ≥5kΩ at 1-5 V ≥500Ω at 1-5 V

Power input 24 Vdc or 100-240 Vac 24 Vdc or 100-240 Vac

Accuracy ±0.4% ±0.4% ±0.4% ±0.3% ±0.3%

Response time (0-90%) ≤0.7 sec. ≤0.7 sec. ≤0.5 sec. ≤0.5 sec. ≤0.5 sec.



-5 to +55ºC (23 to 131ºF)


Dielectric strength 2000 Vac @1 minute (input to output to power to ground) 2000 Vac @1 minute (DC powered)

1500 Vac @1 minute (AC powered)

CE marking Yes ----

Yes (24 Vdc powered)

Safety approval UL & C-UL nonincendive ----


Series M2 / W2 Series B-UNIT Series H-UNIT Series

Single output model M2PV BPV HVPN

Dual output model W2PV

Input 19.6-98.1 kPa (0.2-1.0 kgf/cm 2 ) 19.6-98.1 kPa (0.2-1.0 kgf/cm 2 ) 4-20 mA

20-100 kPa (0.2-1.0 bar) 20-100 kPa (0.2-1.0 bar)

20.7-103.4 kPa (3-15 psig) 20.7-103.4 kPa (3-15 psig)

Output Specific range of 0-20 mA; Minimum span 1mA 4-20 mA 19.6-98.1 kPa (0.2-1.0 kgf/cm 2 )

e.g. 4-20 mA / ≤750Ω ≤600Ω 20-100 kPa (0.2-1.0 bar)

(≤350Ω at 4-20 mA for Output 2)

20.7-103.4 kPa (3-15 psig)

Max. air capacity ---- ---- 60 Nl/minute

Power input 24 Vdc or 100-240 Vac 15-28 Vdc Not required

Accuracy ±0.3% ±0.3% ±0.3%

Response time (0-90%) ≤0.5 sec. ≤0.5 sec. ≤3 sec.

Operating temperature -5 to +55ºC (23 to 131ºF) -10 to +60ºC (14 to 140ºF) -5 to +55ºC (23 to 131ºF)

Insulation resistance ≥100MΩ with 500 Vdc ---- ----

Dielectric strength 2000 Vac @1 minute (output to power to ground) ---- 1500 Vac @1 minute (input to housing)

CE marking

Yes

Safety approval UL & C-UL nonincendive ---- ----

22 23

Current Loop Supplies & DC Power Supplies


M2DYS

W2DYS

Single output


• Shortcircuit protection

• Monitor terminal (1-5 V)

• Two independent ranges can be specified with the signal

splitter.

M2DNY

W2DNY

Square root extractor, Single output

Square root extractor, Two isolated outputs


• Low-end cutout 4-8 %

• Monitor terminal (4-20 mA)


M6SDY

M6NDY

M6DDY


M5DY

W5DY

Single output


• 41 mm (1.6”) deep


• Monitor terminal (1-5 V)

• Two independent ranges can be specified with the signal

splitter.

DC Power Supply


MDC5 / MDC6 / MDC7

• Accepts 100-240 Vac and provides regulated 24 Vdc output

(60W / 120W / 240W)

• Maintenance forecast monitor function



Single output model M2DYS M2DNY M6xDY M5DY

Dual output model W2DYS W2DNY W5DY

Input 4-20 mA 4-20 mA 4-20 mA

Supply output 24-28 Vdc with no load 24-28 Vdc with no load 24-28 Vdc with no load

Current rating 22mA 22mA 22mA



0-20 mA; Min. 1mA span

e.g. 4-20 mA

4-20 mA 0-20 mA; Min. 1mA span

e.g. 4-20 mA

Load resistance ≤750Ω at 4-20 mA ---- ≤550Ω at 4-20 mA

Load resistance, Out 2 ≤350Ω at 4-20 mA ---- ----



0-12 V (10 V for Output 2); Min. 5mV span

e.g. 1-5 V, 0-10 V

0-10V, 0-5V, 1-5 V

0-10 V; Min. 1V span

e.g. 1-5 V, 0-10 V

Load resistance ≥5kΩ at 1-5 V ≥5kΩ at 1-5 V ≥500Ω at 1-5 V


Accuracy ±0.1% ±0.2% ±0.1% ±0.1%

Response time (0-90%) ≤0.5 sec.

≤0.1 msec.

≤0.5 sec. standard; 25 msec. optional

Operating temperature -5 to +55ºC (23 to 131ºF) -20 to +55ºC (-4 to 131ºF) -5 to +55ºC (23 to 131ºF)

Insulation resistance ≥100MΩ with 500 Vdc ≥100MΩ with 500 Vdc



Tension-Clamp


Euro terminal


M2 Series W2 Series M5DY W5DY

2000 Vac @1 minute


2000V AC @1 minute

(input or output to power to ground)

2000 Vac @1 minute (DC powered)

1500 Vac @1 minute (AC powered)


Safety approval UL & C-UL nonincendive

----

----

B3 Series

DIP-Switch Configurable Two-wire Transmitters

Input type and range selectable with the internal DIP switches and fine

calibration using the front potentiometers.

Wide supply voltage range 12-45 Vdc

Eliminates noise and prevents ground loops with 1500 Vac isolation between

input and output


M-System’s B3 Series are DIN rail mounted, input configurable

two-wire transmitters with 1500 Vac isolation between input and

output.

The input type & range are easily programmable with internal

DIP switches and front potentiometers, not needing any special

computer knowledge to program.

For example, after setting the internal SW1 and SW2 for

selecting an overall range, gain and offset, using a DC input

simulator as a reference, the B3FV could be adjusted to 0 to 10

V range by simply applying desired minimum and maximum

input levels and turning the respective front potentiometer.

Typical applications include eliminating ground loops in temperature,

flow and level measurement applications and providing

an isolated interface to data acquisition and control systems.

For the most basic isolation applications, the Model B3VS/2

dual channel isolator is an economical solution. The B3VS/2

houses two transmitters in the series’ standard enclosure,

accepting and providing independently isolated 4-20 mA

signals.


MODEL

B3HU

B3PU

B3FV

B3FT

B3FR

B3FP

B3VS/1

B3VS/2

FUNCTION

Universal temperature input, HART

Universal temperature input, PROFIBUS-PA

DC mV, V, mA input

Thermocouple input

RTD input

Frequency input

Single-channel 4-20 mA isolator

Dual-channel 4-20 mA isolator

Input type DC mV, V, mA Thermocouple RTD Frequency

Model No. B3FV B3FT B3FR B3FP

Selectable input -30 to +30 mA K, E, J, T, R, N Pt 100, Ni 120 Open collector, Voltage pulse

±100V Cu 10 @25ºC Two-wire current, Max. 100 kHz

Output 4-20 mA (600Ω at 24V)

Supply voltage 12-45 Vdc

Accuracy ±0.1% ±0.2% (K/J), ±0.3% (T/E/N) ±0.2% (±0.3% for Ni 120) ±0.1% typical

±0.4% (R) typical

Response time (0-90%) ≤0.5 sec. ≤0.5 sec. ≤0.5 sec. ≤0.5 sec. + pulse cycle

Operating temperature -40 to +85ºC (-40 to +185ºF)


Dielectric strength 2000 Vac @1 minute (input to output to ground)

CE marking


Yes

UL & C-UL

24 25

Æ

Æ

Two-wire Fixed Range Transmitters

Two-wire Universal Temperature Transmitters


M2SN-1 Input loop powered (self-powered), One channel

M2SN-2 Input loop powered (self-powered), Two channels

• No external power source required

• 4-20 mA or 10-50 mA input

M2SN-1


B5SN Input loop powered (self-powered)

Isolator

B5VS Output loop powered Isolator

B5TS Thermocouple input

B5RS RTD input

B5MS Potentiometer input

• 41 mm (1.6”) deep

• Linearization, burnout protection,

cold junction compensation



B5 Series

M2SN-2


Configuration

Input loop powered (Self-powered)

Series M2 Series B5 Series

Model No. M2SN B5SN

Input 4-20 mA, 10-50 mA 4-20 mA

Output 4-20 mA, 1-5 V 4-20 mA


Accuracy ±0.1%


50 to 350Ω with 4-20 mA input/output

15 msec., current output

≤0.5 sec., voltage output

Operating temperature -5 to +55ºC (23 to +131ºF) (Min. -20ºC or -4ºF for M6)



Thin-profile Type

B3VS/1 Output loop powered,

One channel

B3VS/2 Output loop powered,

Two channels

• 18 mm (.71”) wide

• Specific input range of ±100V;

current input with

the incorporated resistor


M6SSN -1, -2

M6NSN -1, -2

M6DSN -1, -2

Tension-Clamp


Euro terminal

• Inputloop powerd (self-powerd)

isolator

• One channel, Two channels


500 Vac @1 minute (input to output)

CE marking Yes Yes

Safety approval UL nonincendive ----

M6 Series

B3 Series

M6 Series

M6xSN

0-20 mA (4-20 mA)

0-20 mA (4-20 mA)

0 to 600Ω

20 msec.


(input to output)

Yes

----


Configuration Output loop powered

Series B3 Series B5 Series

Model No. B3VS B5VS B5TS B5RS B5MS

Input Specific range of -100 to +100 V Specific range of -30 to +30 V K, E, J, T, B, Pt100, Pt50, 100Ω min.

Min. 1V span Min. 100mV span R, S, N Ni508.4 10kΩ max.

4-20 mA, 0-10 mA, etc. 4-20 mA, 0-10 mA, etc.

Output 4-20 mA (600Ω at 24V)

Supply voltage 12-45 Vdc 12-28 Vdc

Accuracy ±0.1% ±0.1% ±0.1% (K/E/J) ±0.2% ±0.1%

±0.2% (T/N)

±0.3% (B/R/S)

Response time (0-90%) ≤0.1 sec. ≤0.5 sec., 25 msec. optional

Operating temperature -40 to +85ºC (-40 to +185ºF) -40 to +80ºC (-40 to +176ºF)


Dielectric strength 2000 Vac @1 minute (input to output to ground)

CE marking

Yes

Safety approval UL & C-UL ----

Field Mount Type

B6U-B HART, Intrinsically safe / explosion-proof - flameproof /

nonincendive

B6U HART, Intrinsically safe / nonincendive

Plug-in two-line LCD display

HART programmable

AMS software version 6.0 or higher

Stainless steel enclosure optional

ATEX Zone 0 approvals

FM Class I, II, III, Division 1 approvals

M-System’s Models B6U and B6U-B accept a wide variety of inputs including thermocouples and RTDs as well as mV, resistance and

potentiometer sensor types. This universal two-wire transmitter reduces component costs while meeting the requirements of hazardous

applications. They provide signal isolation to output a proportional 4-20 mA signal.

Both models have the HART capability which allows users a flexibility to program the modules either via hand-held communicator or via PC.

Input sensor type, temperature range and other items including HART properties are programmable. Additionally, users’ own temperature

calibration tables can be used. This feature makes the B6U and B6U-B the most universal temperature transmitters.

Optional highly legible LCD display indicates input signal in engineering unit and the transmitter status. The module is also used to configure

the transmitter and can be removed when not used.

The B6U designed for intrinsic safety and the B6U-B including the explosion-proof (flameproof) enclosure (NEMA 4X, IP65) are most suitable for

use in an explosive atmosphere in chemical and petrochemical industries. A pipe mounting bracket is optional for the B6U-B for easy installation.

DIN Rail Mount, Thin-profile Type

B3HU HART

B3PU PROFIBUS-PA

• 18 mm (.71”) wide

• AMS software version 6.0 or higher

• SIMATIC PDM

• ATEX Zone 0 approvals (B3HU)


Series B6 Series B3 Series

Model No. B6U B6U-B B3HU B3PU

Selectable input K, E, J, T, B, R, S, C, N, U, L, P, Pt 100 - Pt 1000, Ni 100, Ni 120, Ni 508.4, Ni-Fe 604, Cu 10 @25ºC

0 to 4000Ω, -50 to +1000 mV

Output 4-20 mA (500Ω at 24V) PROFIBUS-PA

Supply voltage 12-42 Vdc (up to 28V approved) 9-30 Vdc (up to 24V approved)

Accuracy

Depends upon the I/O types and ranges. Refer to the data sheet for the respective model for detail.

Response time (0-90%) ≤2 sec.

Operating temperature -40 to +85ºC (-40 to +185ºF)


Dielectric strength 1500 Vac @1 minute (input to output)

CE marking EMC / ATEX EMC / ATEX

EMC

Safety approval IS, nonincendive IS, EX, nonincendive IS ----

• Refer to data sheet of respective models for detailed specifications for use in classified locations.

26 27

Æ

Two-wire Temperature Transmitters


Head Mount Type (Programmable)

27HU

27U

27TS

27RS

27R

Field-mount Type

27HU-B

Universal input, HART / explosion-proof - flameproof

• HART programmable

• 4-digit LED indicator optional

• Stainless steel enclosure optional

• ATEX approvals

• FM Class I, II, III,

Division 1 approvals

OTHER TWO-WIRE TRANSMITTER & ACCESSORIES

6DV-B

Universal input, HART, Intrinsically safe

Universal input, Intrinsically safe

Thermocouple input, Intrinsically safe

RTD input, Intrinsically safe

RTD input, non-isolated, Intrinsically safe

• Function monitor LED optional (27R, 27RS)

• I/O range programming via PC Configurator

• HART programmable (27HU)

Convenient function

monitor LED!

4-digit Loop Powered Indicator, Intrinsically safe

Explosion-proof - flameproof, Field-mount

6DV 4-digit Loop Powered Indicator, Intrinsically safe

• 4-20 mA input powered


• Scaling & linearization selectable via the front control buttons

• Mountable on top of head-mount transmitter,

installed together in an outdoor enclosure

A3DYH Galvanic Isolator, HART

transmitter excitation supply

• Isolated intrinsically safe associated

apparatus - No need of grounding

• Isolates and relays HART signal

bidirectionally

Input

The PC configurator software is

available for download free of

charge on the M-System web site.

http://www.m-system.co.jp/

Head Mount Type (Fixed range)

26TS1 Thermocouple input

26RS RTD input

26R1 RTD input, non-isolated

26REX RTD input, non-isolated,

ATEX approved

• Suitable for DIN B type head

• Linearization, burnout protection,

cold junction compensation


• Optional 25 msec. response time

selectable for 26TS1 and 26RS

43AL-B

3 1/2 digit Loop Powered Indicator,




output

4-20 mAdc

MD6 Series Surge Protectors

• Directly mountable to the cable conduit

of two-wire transmitters and other field

devices in an outdoor enclosure

• Intrinsically safe / explosion-proof -

flameproof approvals

COP-H Bell202 Modem RS-232C interface

COP-HU Bell202 Modem USB interface

• Connects a HART transmitter to PC for

programming

USB or RS-232-C

Bell202 Modem

(model: COP-HU or COP-H)

24 Vdc

LOAD

Two-Input Arithmetic Function Modules

• Provides a DC signal proportional to the arithmetic function

of two inputs

M2ADS Addition

Output = Input 1 + Input 2 (Output, Input 1 & 2: 0-120 %)

M2SBS Subtraction

Output = Input 1 – Input 2 (Output, Input 1 & 2: 0-120 %)

M2MLS Multiplication

Output = Input 1 × Input 2 (Output, Input 1 & 2: 0-120 %)

M2DIS Division

Output = Input 1÷ Input 2

(Output, Input 1: 0-120 %, Input 2: 5-120 %)

High/Low Limiter

M2LMS

• Prevents DC output from going above or below preset values

• Limit range: -10.0 to +105%

Inverted Output

M2UDS

• DC output proportional to the inverted input

Filters

• Limits the rate-of-change of the output

M2CDS Delay Buffer

Time constant: 0.5-20 sec.

M2CRS Ramp Buffer

Rate-of-change: 0.5-40 sec.

Hold Function

• Holds the output signal once the command is received until reset

M2AMS Track/Hold

Output held at the command

M2PHS Peak/Valley Hold

Responds only to increasing or decreasing signals

High/Low Selector

M2SES

• Selects either higher or lower of two input signals

FUNCTION MODULES I/O CHARACTERISTICS

M2LMS

H

L

M2UDS

M2CDS

M2CRS

Ratio/Bias Modules

• Precise matching of DC control signals to final control elements

M2REB Output Bias

Xo = KXi + B (positive ratio)

Xo = KXi + B + 100% (negative ratio)

(K: 0.1 to 4.00 or -0.1 to -4.00, B: ±100%)

M2RTS Input Bias

Xo = K(Xi + B) (positive ratio)

Xo = K(Xi + B) + 100% (negative ratio)

(K: 0.1 to 4.00 or -0.1 to -4.00, B: ±100%)

Square Root Extractor

M2FLS

• Provides a DC signal proportional to the actual flow


Series

DC voltage input

Minimum span

DC current input


Minimum span



Minimum span


Power input





CE marking


M2AMS

HOLD

M2 Series

Specific range of -300 to +300 V

(±30 V for M2REB/M2RTS/M2LMS)

3mV (10mV for M2MLS/M2DIS;

100mV for M2REB/M2RTS; 1V for M2FLS; 1-5 V for M2SES)

Resistor attached to the input terminals.

4-20 mA, 0-10 mA, 10-50 mA, etc.

Specific range of 0-20 mA; e.g. 4-20 mA

1mA

≤750Ω at 4-20 mA

Specific range of -10 to +12 V; e.g. 1-5 V, 0-10 V

5mV

≥5kΩ at 1-5 V

24 Vdc or 100-240 Vac

≤0.5 sec.

-5 to +55ºC (23 to 131ºF)




Yes

UL & C-UL nonincendive

M2PHS

PEAK HOLD

INPUT

OUTPUT

28 29

M7E Series

High-performance Dual / Quad Limit Alarms with LCD Display

Limit Alarms

High-performance Dual / Quad Limit Alarms

Compact size: 29.5 mm wide

Front LCD display indicates process values and alarm trip conditions

Intuitive, easy programming just like operating a cell phone

PC Configurator is also available


M-System’s M7E Series is a 29.5-mm wide space-saving limit alarm.

A transreflective FSTN LCD display of 68 x 95 pixel size is provided on the

front panel, which is used to show process values and program the module.

With the clear, multi-line display’s help, programming using the front four

control buttons is as easy as that of your mobile phone.

The alarm module is plugged into a 11-pin relay socket and fixed firmly with

the knurled knob which can be pushed into the front panel.

You won’t need to consult the

instruction manual!

The LCD display will show you the parameters and selections

to guide you through the programming of the M7EASV.

Set Up Transmitter Input Calibration

Main contents list

LCD Mode

Information Mode

Alarm Test Mode

Parameter Lock

Setup menu

Alarm

Power ON Delay Timer

Alarm ON Delay Timer

Moving Average

Hysteresis

(deadband)

Latching

Fine Adjustment

Scaling

Alarm Value

Set L1...L4 in

engineering unit

Trip Operation

Select Hi / Lo

Coil at Alarm

Select Energize

/ De-energize

Time Setting

(0-99 sec.)

Time Setting

(0-999 sec.)

Number of Samples

Set L1...L4 in

engineering unit

Enable / Disable

Alarm setpoints in

enginerring unit value

Set 0%/100% range

Adjust 0%/100% input

Unit

Select unit

(A, mA, V, mV, W,

mW, %, ºC, ºF, Ω, Pa,

kPa, MPa, User Unit)

User Unit Setting

Decimal Point

Select decimal point

Set Scale

Set 0%/100% scale

Engineering

unit selections

User's unit

setting (e.g. N•m)

Contrast

adjustment

MODEL

M7EASV

M7EASDY

FUNCTION

DC mV, V, mA input

Current loop supply (4-20 mA input with

2-wire transmitter excitation)


Series

M7E Series

Model No. M7EASV M7EASDY

Input

0-50 mA, ±1V, ±10V:

Selectable range within

each input type

4-20 mA

Excitation: 24-28 Vdc wtih

no load, 22mA

Alarm points Dual or quad (Hi or Lo configurable for each input)

Relay contact Quad: 120 Vac, 30 Vdc @1A, 240 Vac @0.5A

Dual: 120 Vac, 30 Vdc @4A, 240 Vac @2A

DC power

24 Vdc

AC power

100-240 Vac

Set accuracy ± (0.1% of FS + 1 digit)

Response time


≤0.5 sec.

-5 to +55ºC (23 to 131ºF)


Dielectric strength 2000 Vac @1 minute


Setpoint adj. -9999 to 9999

Deadband 1 to 9999

Scaling

-9999 to 9999 (with engineering unit on display)

Display rate

150 msec.

Other features Failsafe operation, latching, power/alarm ON

delay, moving average filter, alarm test mode

CE marking

Yes

AS4 Series

• Engineering unit display

• Configurable input sensor type and range

• Dual or quad alarm trip

AS4V

AS4R

AS4M

AS4CT

Q


AS4V AS4T AS4LC KS2V

DC mV, V & mA input

RTD input

Potentiometer input

CT (AC current) input

SMOOTH PUMP OPERATION

AS4T

We are trying to control the level of liquid in a tank by staging four pumps that are

connected in parallel (see figure). However, the continuously changing liquid level

causes pumps to cycle ON and OFF sporadically around the setpoints. How can we solve this

problem?

You will need to set a deadband (hysteresis) for each pump’s control setpoint.

A With or dinary limit alarms, you might have to set two trip points for each pump to

accomplish this result. The AS4V can be field programmed to eliminate the unwanted pump

cycling, giving you consistant pump operations and control.

Series AS4 Series KS2 Series

INPUT

AS4V

L1

P1

L2 L3 L4

P2 P3 P4

Model No. AS4V AS4T AS4R AS4M AS4CT AS4LC KS2V KS2TR

Selectable

input

0-50 mA

±1V

±10V

100 to 10kΩ 0-1 Aac

0-5 Aac

0.0-3.0 mV/V

0.0-10.0 mV/V

0.0-30.0 mV/V

K, E, J, T

B, R, S

C (WRe 5-26)

N, U, L

P (Platinel II)


Pt 100

Pt 1000

Ni 508.4

Ni 100,

Cu 10

KS2V

KS2TR

1-5 V K, E, J, T

B, R, S

C (WRe 5-26)

N, PL2

Pt 100

Alarm points Dual or quad (Hi or Lo configurable for each input) Dual (Hi or Lo configurable)

Relay contact Quad: 120 Vac, 30 Vdc @1A, 240 Vac @0.5A

Dual: 120 Vac, 30 Vdc @5A, 240 Vac @2.5A

120 Vac, 30 Vdc @1A

240 Vac @0.5A

220 Vac @3A

30 Vdc @3A

DC power 24 Vdc, 110 Vdc 24 Vdc

AC power 100-240 Vac 100-240 Vac

Set accuracy ± (0.1% of FS + 1 digit) (0.2% for Cu 10, 0.3% for AS4CT) ±0.1% FS

Response time ≤0.5 sec. ≤1.5 sec. ≤0.5 sec. ≤0.7 sec. ≤1.5 sec. ----

Operating temperature -5 to +55ºC (23 to 131ºF) -10 to +50ºC (14 to 122ºF)

Insulation resistance ≥100MΩ with 500 Vdc ≥50MΩ with 500 Vdc

Dielectric 2000 Vac @1 minute (input to output to power to ground) 1500 Vac @1 minute

strength

(input to SET1/SET2 to power)

Setpoint adj. -1999 to 9999 -272 to 2416 -240 to 900 -1999 to 9999 -5 to +105%

Deadband 1 to 9999 0.0 to 2416 0 to 900 1 to 9999 0 to 102%

Scaling -1999 to 9999 -272 to 2416 -240 to 900 -1999 to 9999 -1999 to 9999

AS4LC

Strain gauge input

Read rate 100 msec. 0.5 sec.

Other Failsafe operation, latching, power/alarm ON delay, moving average filter, power-saving mode Failsafe, power/alarm ON

features


delay, First order lag filter

Yes

Safety approval UL & C-UL ---- UL & C-UL

KS2 Series

• 1/16 DIN panel cutout

• Front digital displays

• Dual alarm trip

DC voltage input

Temperature input

30 31

Limit Alarms

Analog Limit Alarms

LT Series Power Transducers

Plug-in Design


True RMS sensing

Surface or DIN rail mounting

M4 screw terminal

MSEF

ASD1

Conform to IEC 60688

Optional terminal cover

M2AVS

M2SED

Additional pulse rate output for

totalizing counter (Watt Transducer)

AYDV

KSED

MSEF

AYDV

ASD1

KSED

Front Control Button Adjustment, Dual Alarm

Potentiometer Adjustment, Dual Deviation Alarm

Thumbwheel Switch Adjustment, Dual Alarm

Thumbwheel Switch Adjustment, Dual Alarm

M2AVS

M2SED

M2AS

M2AS1

Potentiometer Adjustment, Dual Alarm

Thumbwheel Switch Adjustment, Dual Alarm, SPDT

Thumbwheel Switch Adjustment, Single Alarm, DPDT

Thumbwheel Switch Adjustment, Single Alarm, SPDT

AL Series

Direct Sensor Input, SPDT Alarm

• Input DC, T/C, RTD, Pot, Pulse,

AC, 2-wire Transmitter

• Output 120 Vac or 30 Vdc @1A;

240 Vac @0.5A

(For details, refer to Signal Conditioners Data

Library at www.m-system.com)



Series M-UNIT K-UNIT M2 Series

Model No. MSEF AYDV ASD1 KSED M2AVS M2SED M2AS / M2AS1

Input (specified

4-20 mA, 0-10 V, 0-5 V, 1-5 V

when ordering)

4-20 mA, 2-10 mA

1-5 mA, 0-10 V

0-5 V, 1-5 V

1-5 V, 4-20 mA

10-50 mA

(reference 1-5 V)

4-20 mA

0-10 V,

0-5 V, 1-5 V

Alarm points Dual (Hi/Lo selectable) Dual

(Hi/Lo selectable)

4-20 mA

0-10 V

0-5 V, 1-5 V

Dual (Hi/Lo)

Specific range

of -300 to +300

V

Dual


Dual (Hi/Lo)

Single


Relay contact SPDT SPDT SPDT N.O. SPDT DPDT / SPDT

Rated load 120 Vac @5A

240 Vac @2.5A

30 Vdc @5A

120 Vac @1A

240 Vac @0.5A

30 Vdc @1A

120 Vac @5A

240 Vac @2.5A

30 Vdc @5A

120 Vac @5A

240 Vac @2.5A

30 Vdc @5A

120 Vac @0.5A

240 Vac @0.5A

30 Vdc @0.5A

120 Vac @5A

240 Vac @2.5A

30 Vdc @5A

DC power input 12, 24 Vdc 12, 24, 48, 110 Vdc ---- ---- 24 Vdc

AC power input

100, 110, 115, 120 Vac

200, 220, 240 Vac

100-120 Vac

200-240 Vac

AE Series

Direct Sensor Input, SPDT plus

DC Transmitter Output

• Input DC, T/C, RTD, Pot, Pulse, AC,

2-wire Transmitter

• Output 120 Vac or 30 Vdc @1A;

240 Vac @0.5A

• Specific DC output range within -10 to +12 V or 0-20 mA

100-120 Vac

200-240 Vac

100-240 Vac

Set accuracy ±0.5% ±0.5% ±0.5% ±0.5% monitor ±0.5% ±0.5%

Response time ≤0.5 sec. ---- ≤0.7 sec. ≤0.5 sec. 0.5 ±0.2 sec. ≤0.5 sec.

Operating temperature -5 to +60ºC (23 to +140ºF) -5 to +55ºC (23 to 131ºF)


Dielectric strength 2000 Vac @1 minute (input to output to power to ground)

Setpoint adj. -10 to +110% -50 to +50% 0 to 99% 0 to 99% 0 to 100% 0 to 99%

Deadband 0.5 to 15% 0.2 ±0.1% 0.5, 1 to 14% 1% ≤0.5% 1±0.3% 1 to 99%

CE marking Yes ---- Yes Yes (24 Vdc) Yes Yes

Safety approval UL & C-UL ---- UL & C-UL ---- UL & C-UL ----

AC Current & Voltage Transducers

MODEL FUNCTION

LTCNE AC Current Transducer (self-powered)

LTCE

AC Current Transducer

LTCEC

AC Current Transducer (clamp-on current sensor)

LTPE

AC Voltage Transducer


MODEL FUNCTION

LTWT

Watt Transducer

LTWTN Watt Transducer (self-powered)

LTRP

Var Transducer

LTRPN

Var Transducer (self-powered)

LTPF/LTPFU Power Factor Transducer

LTPFN/LTPFUN Power Factor Transducer (self-powered)

LTPA/LTPAU Phase Angle Transducer

LTPAN/LTPAUN Phase Angle Transducer (self-powered)

LTHZ

Frequency Transducer

LTHZN Frequency Transducer (self-powered)

Multi Power Transducer

LSMT3

• Measures AC current, voltage, active/

reactive/apparent power and power factor

• AC/DC universal power input

• Conforms to IEC 688

• CE marking


Series

Configuration

LT Series

Three-phase/3- or 4-wire

Single-phase/2- or 3-wire

Clamp-on Current Sensor

VT input 100, 110, 115, 120, 190, 200, 210, 220,

230, 240, 380, 400, 415, 430, 440, 480 Vac,

100/200 Vac

CT input

1A, 2A, 5A

Frequency input (HZ) 45-55 Hz, 55-65 Hz, 45-65 Hz

DC current output Specific range of -10 to +20 mA; e.g. 4-20 mA

Minimum span 1mA

Load resistance ≤500Ω at 4-20 mA

DC voltage output Specific range of -10 to +12 V e.g. 1-5 V, 0-10 V

(negative output not available for VT/CT)


Load resistance ≥5kΩ at 1-5 V

Pulse output (WT) 2.777 Hz at 100% or customer specified pulse unit

Power input

24, 48 Vdc or 100-120, 200-240 Vac

Accuracy

±0.2 % for VT, CT, WT

Response time (0-90%) ≤1 sec. for VT, CT; ≤2 sec. for WT

Operating temperature -10 to +55ºC (14 to 131ºF)


Dielectric strength 2000 Vac @1 minute


Impulse withstand voltage 1.2/50 µsec. ±5kV

CE marking

Yes (except LTCNE / LTCEC)

32 33

53U Multi Power Monitor

Remote I/O

Single-phase/2-wire and 3-wire,

three-phase/3-wire, 4-wire systems

Three line measured value/bargraph

indicators plus energy count/info display

Programming lock to prevent unwanted

configuration changes

IP 50 front panel

Output options – Modbus, Ao, Do selectable

High accuracy (Option) NEW

M-System’s model 53U is a 96-mm-square Multi LCD Power Monitor mounted on a panel surface.

One model can be used for single-phase/2-wire and 3-wire, three-phase/3-wire and 4-wire systems. Users can freely choose and

program major variables in heavy-current power systems, such like AC voltage/current, active/reactive power, power factor, AC

frequency deviation, apparent power, active/reactive energy and up-to-the-31st harmonic distortions.

Measured variables also include the maximum/minimum/average values, in total of 500 types. Up to 1800 patterns of display

combinations are available.

All measured variables can be transmitted to the host PC via RS-485/Modbus RTU. Conversion factors, system configuration, interval

times are programmable using the front keys, or the PC Configurator Software locally or remotely. Measured values, counter values,

display mode, setting data are stored in the non-volatile memory at the power off.

An open collector output can be used for energy count pulse or limit alarm trip. Pulse rate for energy count can be specified. The

contact output can be simulated for testing the connected device.

External open collector input is typically used to reset energy count memory. The signal can be also monitored at the host system via

Modbus, so that the host can start/stop monitoring according to ON/OFF status of a load (e.g. motor running or not).

Enhanced PC Configurator Software with

Monitoring Function

Configuration window

Monitoring window

53U Monitoring & Logging Software

PC Recorder software is available

for use with the 53U.

NEW


Model No.

Configuration

VT input

CT input

Contact input

External interface

Accuracy





CE marking

53U

Three-phase/3- and 4-wire

Single-phase/2- and 3-wire

480 Vac

1A, 5A

24 Vdc or 110 Vdc

Modbus, Do x 1 points, Di x 1 points;

Modbus, Do x 3 points;

Do x 4 points;

Ao x 2 points, Do x 1 points, Di x 1 points;

Ao x 2 points, Do x 2 points;

Ao x 4 points;

voltage/current: ±0.3% (±0.2% optional)

power/power factor: ±0.5%

frequency: ±0.1%

energy/harmonic contents: ±1% (±0.5% for

energy optional)

Analog output: Accuracy of assigned measurand

or ±0.2%, whichever is greater.

≤2 sec.

-10 to +55ºC (14 to 131ºF)



(between power input to other field terminals)


(between other field terminals except power input)

Yes

Hot Swappable, Fully Isolated Remote I/O

Broad I/O Offering: Scalable and Flexible

Redundant Communications:

Reliable and Flexible

Redundant Power for High Reliability

M-System’s Remote I/O is designed to support DCS/PLC systems by expanding their I/O flexibility and capabilities in addition to

providing all full channel-to-channel isolation. The Remote I/O communicates directly to the PLC and DCS via industry standard

open-protocol networks.

M-System’s Remote I/O also can be used as stand-alone distributed I/O communicating with popular HMI software.

The Remote I/O can be located remotely in the field, or within an instrumentation cabinet such as test stands.

The flexibility and scalability of M-System’s Remote I/O supports future system upgrades with full isolation between

power-communication-I/O and between analog channels. Economical non-isolated analog modules are also selectable.

Isolated analog I/O modules provide high-performance signal conversion/conditioning and complete three-way plus

channel-to-channel isolation. This ensures you a highly dependable system.

Applications include: signal concentrator, data collection in flow and level monitoring, injection molding monitoring and control,

test stands and prototyping, glass furnace temperature control, assembly line discrete ON/OFF, paint booth environment reporting,

pharmaceutical processes.

Remote I/O Replacement

for PLC and DCS

Ethernet

Remote I/O Can Replace PLC

in PC-Based SCADA Systems

Gateway /

Protocol Converter

PLC/DCS

Open Field Network

Open Field Network (Modbus, etc)

R3 Series R5 Series

R1 Series

Ai/o, Di/o

R3 Series

Ai/o, Di/o

R5 Series

Ai/o, Di/o

M-System's Remote I/O is designed to support DCS/PLC

systems by expanding their I/O flexibility and capabilities in

addition to providing all full channel-to-channel isolation.

The Remote I/O communicates directly to the PLC and DCS

via industry standard open-protocol networks.

PC

R1 Series

Ai/o, Di/o

R3 Series

Ai/o, Di/o

R5 Series

Ai/o, Di/o

M-System’s Remote I/O can also be used as stand-alone distributed I/O

communicating with popular HMI software such as Citect, Intellution and

Wonderware. The Remote I/O can be located remotely in the field, or within

an instrumentation cabinet such as test stands.

PC

34 35

Remote I/O

R3 Series Multi-channel, Mixed Signal Remote I/O

Remote I/O

R5 Series Compact, Mixed Signal Remote I/O

Wide selection of I/O modules and network modules

• Great flexibilities in number and type of I/O signals: DC current/voltage, temperature, strain gauge, AC current/voltage, AC power, etc.

• Hot-swappable I/O modules and power supplies

• Dual redundant communication networks

• 1500 Vac isolation

• I/O modules with connector terminal available

Free combination of I/O modules, network modules and power modules.

• Single analog module can handle fully-isolated 2 points.

• Hot-swappable I/O modules

• Dual redundant communication networks and power supplies

• Space-saving DIN terminal block or heavy-duty screw terminal block selectable for I/O


NETWORK MODULES

Model Capacity Model Capacity

R3-NE1

R3-ND1

Modbus/TCP (Ethernet)

Analog 16 ch.

R3-NM1

R3-NP1

Modbus

R3-ND2

R3-ND3

R3-NC1

R3-NC2

R3-NC3

DeviceNet

CC-Link

Analog 32 ch.

Analog 64 ch.

Ver. 1; Analog 16 ch.

Ver. 1; Analog 32 ch.

Ver.2

R3-NL1

R3-NL2

R3-NF1

LONWORKS

T-Link

BASE

224 mm / 8.8 in. (8-position base)

PROFIBUS-DP

120 mm

4.7 in.

130 mm

5.1 in.

POWER MODULE(S)

I/O MODULES

NETWORK MODULE(S)

ANALOG INPUT MODULES

Input Model CH

Thermocouple R3-TS4 4 (isolated)

Input

R3-TS8 8 (isolated)

R3-RS4 4 (isolated)

RTD Input R3-RS8 8 (isolated)

R3-RS8A 8 (isolated)

DC Voltage

Input

DC Millivolt

Input

DC Current

Input

4-20mA Input

with Excitation

Potentiometer

Input

Strain Gauge Input

CT Input

AC Current Input

with Clamp-on

Current Sensor

Zero-phase

Current Input

AC Voltage Input

AC Power Input

AC Power Input

with Clamp-on


Multi Power Input

Multi Power Input

with Clamp-on


Pulse Input

Totalized Pulse

Input

Encoder Input

R3-SV4

R3-SV4B 4 (isolated)

R3-SV4C

R3-SV8

R3-SV8B 8 (isolated)

R3-SV8C

R3-SV8N 8 (non-isolated)

R3-SV16N 16 (non-isolated)

R3-SV4A 4 (isolated)

R3-SV8A 8 (isolated)

R3-SS4 4 (isolated)

R3-SS8 8 (isolated)

R3-SS8N 8 (non-isolated)

R3-SS16N 16 (non-isolated)

R3-DS4

R3-DS4A

4 (isolated)

R3-DS8N 8 (non-isolated)

R3-MS4 4 (isolated)

R3-MS8 8 (isolated)

R3-LC2 2 (isolated)

R3-CT4 4 (isolated)

R3-CT4A

R3-CT4B 4 (isolated)

R3-CT4C

R3-CT8A

R3-CT8B 8 (isolated)

R3-CT8C

R3-CZ4

R3-PT4

R3-WT4

R3-WT4A

R3-WT4B

R3-WT1

R3-WT1A

R3-WT1B

R3-PA4

R3-PA4A

R3-PA4B

R3-PA16

R3-PA2

4 (isolated)

4 (isolated)

4 (isolated)

4 (isolated)

1 system

1 system

4 (isolated)

4 (isolated)

16 (isolated)

2 (isolated)

ANALOG OUTPUT MODULES

Output Model CH

DC Voltage Output

R3-YV4 4 (isolated)

R3-YV8 8 (isolated)

DC Current Output R3-YS4 4 (isolated)

Pulse Output R3-PC16A 16

ALARM MODULES

Input Model CH

Thermocouple Input R3-AT4 4

RTD Input

R3-AR4 4

DC Voltage Input

R3-AV4 4

R3-AV8 8

DC Current Input

R3-AS4 4

R3-AS8 8

4-20mA Input


R3-AD4 4

DISCRETE MODULES

I/O

Dry Contact Input

Dry Contact Input

with External Exc.

AC Contact Input

Relay Output

Open Collector Output

Triac Output

BCD CODE MODULES

I/O Model CH

BCD Code Input

R3-BA32A 32

BCD Code Output R3-BC32A 32

POWER MODULES

Model

R3-PS1

R3-PS3

BASES

Model

R3-BS

R3-BSW

Model

R3-DA16

R3-DA16A

R3-DA32A

R3-DA64A

R3-DA16B

R3-DC16

R3-DC16A

R3-DC32A

R3-DC64A

R3-DC16B

Rating

20V 750mA

20V 2.0A (double width)

CH

16

16

32

64

16

16

16

32

64

16

Network

2 to 16 Positions

4 to 16 Positions, free I/O address

NETWORK MODULES

Model

Capacity

R5-NE1 Modbus/TCP (Ethernet)

R5-NM1 Modbus

R5-ND1

DeviceNet

Analog 16 ch.

R5-ND2

Analog 32 ch.

R5-NP1

PROFIBUS-DP

Analog 16 ch.

R5-NP2

Analog 32 ch.

R5-NC1

CC-Link

Analog 16 ch.

R5-NC2

Analog 32 ch.

R5-NF1 T-Link

231 mm / 9.1 in. (8 I/O modules)

BASE

POWER MODULE(S)

I/O MODULES

NETWORK MODULE(S)

90 mm

3.5 in.

90 mm

3.5 in.


Input

Thermocouple

Input

RTD Input

DC Voltage

Input

DC Current

Input

4-20mA Input


Potentiometer

Input

CT Input

AC Current Input

with Clamp-on


AC Voltage

Input

Totalized

Pulse Input

Model

CH

Euro Terminal Screw Terminal

R5-TS1

R5-TS2

R5T-TS1

R5T-TS2

1

2

R5-RS1 R5T-RS1 1

R5-RS2 R5T-RS2 2

R5-RSA1

1

R5-RSA2

2

R5-SV1 R5T-SV1 1

R5-SV2 R5T-SV2 2

R5-SS1 R5T-SS1 1

R5-SS2 R5T-SS2 2

R5-DS1 R5T-DS1 1

R5-DS2 R5T-DS2 2

R5-MS1

1

R5-MS2

2

R5T-CT1 1

R5T-CT2 2

R5T-CTA1 1

R5T-CTA2 2

R5T-CTB1 1

R5T-CTB2 2

R5T-PT1 1

R5T-PT2 2

R5-PA2 R5T-PA2 2


WITH RE-TRANSMITTED OUTPUT

Input

Thermocouple Input

RTD Input

DC Voltage Input

DC Current Input

4-20mA Input


Potentiometer Input

Model

R5-TS1A

R5-RS1A

R5-SV1A

R5-SS1A

R5-DS1A

R5-MS1A

CH

1

1

1

1

1

1

ANALOG OUTPUT MODULES

Output

DC Voltage

Output

4-20mA

Output

Totalized Pulse

Output

DISCRETE MODULES

I/O

POWER MODULES

Model

R5-PSR

R5-PSK

R5-PSL

BASES

Model

R5-BS04

R5-BS05*

R5-BS08

R5-BS09*

R5-BS16

R5-EX1

Model

CH


R5-YV1

R5-YV2

R5T-YV1

R5T-YV2

1

2

R5-YS1 R5T-YS1 1

R5-YS2 R5T-YS2 2

R5-PC2 R5T-PC2 2

Di 4 Points

Input R5-DA4 R5T-DA4 4

Di 16 Points

Input

Do 4 Points

Output

Do 16 Points

Output

Model

CH


R5-DA16 16

(Connector)

R5-DC4 R5T-DC4 4

R5-DC16

(Connector)

Rating

24Vdc

100–120Vac

200–240Vac

16

Capacity

4 I/O modules

5 I/O modules

8 I/O modules

9 I/O modules

16 I/O modules

Extender Power Module

Base

*Single Network Module

Input

Network

DC4-20mA

Re-Transmitted

Output

Mains 120/240 VAC

UPS 24 VDC

M3 screw terminal block is used for

I/O modules. The removable terminal

block is convenient for maintenance.

Network Module and Power Supply

Module in one housing.

One I/O module plus one Network Module

with power supply is the minimum unit:

Space-saving and economical solution.

The slanted I/O terminals are easily

accessible even with high-density wiring.

Re-Transmitted 4 to 20 mAdc output is

optional for local monitoring or recording

Add another power module for a backup

power source.

36 37

Remote I/O

R7 Series Compact Remote I/O

Economical all-in-one module for Modbus, CC-Link, DeviceNet,

LONWORKS and MECHATROLINK

• Palm-top size compact module can handle 4 analog input / 2 analog output or 8 /16 discrete signals.

• 8 or 16 discrete input/output module can be attached to the base module. Analog and discrete signals can be mixed.

• Simple setting


PC Recorder

Remote Data Acquisition Hardware and Software

PC Recorder Series

Log, Trend, Analyze and Profile Process

Signals with Your PC

Data Collection by PC Recorder Software

RS-485/RS-232C Communication Port

Modbus RTU Network

High Speed Sampling 50 ms / 8 ch

External Trigger Input

Remote Limit Alarming

Extension module

8 or 16 discrete input or output module can be attached to

the base module.

Analog and discrete signals can be mixed by combining a

discrete I/O module with an analog module.

1500 Vac isolation for analog modules

Fully isolated between I/O, network and power input.

Channel-to-channel isolation is also provided.

M-System’s R1M/R2M series is a high performance line of analog and discrete I/O modules. These modules feature individual

channel configuration of input types and ranges. Field I/O connects directly to the R1M modules and data is transmitted via the

Modbus RTU protocol over an RS-485 network. Additionally, the R1M/R2M provides an RS-232C port for portable host communications

to a PC.

The R1M/R2M series is designed for remote I/O and laboratory data acquisition applications. Applications include tank level

monitoring, flow monitoring, temperature profiling, discrete ON/OFF control and data logging. The Modbus RTU protocol enables

interfacing with popular HMI and SCADA software packages.

The R1M/R2M includes PC recorder software that easily replaces expensive traditional chart recorders. The PC recorder software is

fully featured enabling the logging, trending acquisition and analysis of application data. R1M/R2M hardware combined with PC

Recorder software provides a low cost industrial grade data acquisition system.

BASE MODULE

Network Modbus DeviceNet CC-Link

LONWORKS

MECHATROLINK

NEW

R1M-P4

Dry contact input, 16 points

NPN transistor output, 16 points

PNP transistor output, 16 points

Dry contact input, 8 points & NPN transistor output, 8 points

DC voltage / current input, 4 points

Thermocouple input, 4 points

RTD input, 4 poins

DC voltage output, 2 points

DC voltage output, 2 points (external power supply)

DC current output, 2 points

DC current output, 2 points (external power supply)

R7M-DA16

R7M-DC16A

R7M-DC16B

----

R7M-SV4

R7M-TS4

R7M-RS4

R7M-YV2

----

R7M-YS2

----

R7D-DA16

R7D-DC16A

R7D-DC16B

----

R7D-SV4

R7D-TS4

R7D-RS4

R7D-YV2

R7D-YV2A

R7D-YS2

R7D-YS2A

R7C-DA16

R7C-DC16A

R7C-DC16B

----

R7C-SV4

R7C-TS4

R7C-RS4

R7C-YV2

----

R7C-YS2

----

R7L-DA16

R7L-DC16A

R7L-DC16B

R7L-DAC16

R7L-SV4 NEW

R7L-TS4 NEW

R7L-RS4 NEW

R7L-YV2 NEW

----

R7L-YS2 NEW

----

R7ML-DA16 NEW

R7ML-DC16A NEW

R7ML-DC16B NEW

----

R7ML-SV4 NEW

R7ML-TS4 NEW

R7ML-RS4 NEW

R7ML-YV2 NEW

----

R7ML-YS2 NEW

----

R1M Series RS-485 I/O Modules

R1M-GH2 16-point DC/TC inputs

R1M-J3 8-point RTD/POT inputs

R1M-A1 32-point dry contact input

R1M-D1 32-point open collector output

R1M-P4 Totalized pulse input

R1M-GH2

R1M-A1

R1M-J3

R1M-D1

Model RZUS-U9 USB Bus-powered

12-point Universal Input Module

• 5 V (approx. 0.25 A) powered through the USB cable

• 12-point universal inputs independently configurable

for each input

• Supports 13 TC types, 12 RTD types, potentiometer

and ±12 Vdc inputs

• Easily expandable via RS-485

EXTENSION MODULE

Network Modbus DeviceNet CC-Link







R7M-EA8

R7M-EA16

R7M-EC8A

R7M-EC16A

R7M-EC8B

R7M-EC16B

R7D-EA8

R7D-EA16

R7D-EC8A

R7D-EC16A

R7D-EC8B

R7D-EC16B

R7C-EA8

R7C-EA16

R7C-EC8A

R7C-EC16A

R7C-EC8B

R7C-EC16B

LONWORKS

R7C-EA8 NEW

R7C-EA16 NEW

R7C-EC8A NEW

R7C-EC16A NEW

R7C-EC8B NEW

R7C-EC16B NEW

MECHATROLINK

R7ML-EA8 NEW

R7ML-EA16 NEW

R7ML-EC8A NEW

R7ML-EC16A NEW

R7ML-EC8B NEW

R7ML-EC16B NEW

Model R1MS RS-485 Fully Isolated

8-point DC/TC Input Module

R2M Series RS-232 Modules

R2M-2G3 8-point DC inputs

R2M-2H3 8-point TC inputs

Model RZMS-U9 RS-485 Isolated

12-point Universal Input Module

38 39

PC Recorder MSRPAC

Remote Data Acquisition Hardware and Software

MSRPAC PC Recorder Software Package

MSR128LV / MSR128LS - PC Recorder-Light

• Ideal for basic logging and trending purposes

• Maximum sampling rate of 50 ms for 8 channels, 500 ms to

1 minute for the total of 120 channels

The MSR128-Light is designed to operate on a PC of relatively

low performance, even a Windows 98 PC, though certain

functions of the MSR128 which require the PC’s high

performance, are not available.

The data used for the recorder is saved in CSV format allowing

easy export to other Windows programs such as Microsoft Excel.

Two models are available to run on low resolution screens.

MSR128LV for VGA (Screen area: 640 x 480 pixels)

MSR128LS for SVGA (Screen area: 800 x 600 pixels)

MSR128 - Full Featured PC Recorder Software

• Ideal for logging, trending and analyzing continuous process and batch applications.

• Up to 128 channels can be monitored simultaneously.

• Maximum sampling rate of 500 ms for 128 channels.

• High speed sampling 100 ms with R3 series TCP/IP module.

• Four network R1M modules can be polled with remote limit alarming.

The MSR128 works with all PC Recorder modules. The

MSR128 software polls data from the input module, plots

the value on the screen and stores it to the PC’s hard drive.

The data is polled, plotted and stored at a maximum rate

of 500 ms for 128 channels. Historical trends can be

recalled, edited and used to be printed as hard copies or

to be exported to spreadsheets for further analysis.

Data can be exported in CSV format to popular

spreadsheet software packages such as Microsoft Excel.

Data can be directly imported allowing the user to take full

advantage of spreadsheet software features.

SYSTEM CONFIGURATION EXAMPLES

Minimum Configuration

PC

RS-232C*

Expanded System via Modbus RTU (R7 + MSR)

MSRPAC

PC Recorder Software

Expanded System via Modbus RTU (53U + MSR)

Expanded System via Modbus RTU

RS-485 / Modbus RTU

R1M, R1MS, R2M or RZMS R1M-D1 R1M-A1 R1M-GH2

*USB port is usable by using an adaptor.

PC

MSRPAC


R7M

RS-232/RS-485 Converter

R2K-1

RS-485

R7M

*USB port is usable by using an adaptor.

MSRPAC


PC

RS-232C*

Expanded System via Ethernet

R3 Series

Expanded System via Ethernet (73VR + R7 + MSR)

PC

Paperless Recorder

(Models: 73VR3100)



MSRPAC


R7M

MSRPAC


Expanded System via Ethernet (53U + MSR)

PC

Ethernet

Ethernet



R7M

RS-485

R7M

PC

MSRPAC


PC

MSRPAC


Ethernet

RS-232/RS-485 Converter

R2K-1

Communication Adaptor

72EM2-M4

RS-485

RS-485

Multi Power Monitor

(Model: 53U)

53U 53U Multi Power Monitor

(Model: 53U)

53U

53U

40 41

PC Recorder MSRpro

MSRpro Client/Server System High Performance PC Recorder

Max. 2048 points

High speed 100 msec. mode up to 256 points

Active trend view to compare in real time past and present data overlapped on each other

Arithmetic and logic functions, including the ones performed between channels

Alarm history and data search functions

The MSRpro is a ‘paperless pen-type’ recording system for PC-based data acquisition and analysis. By communicating with I/O

modules that have a LAN card communication interface, the MSRpro reads in input signals and stores them in a hard disk as digital

data.

By sharing viewing and storing tasks by ‘Client’ and ‘Server,’ the MSRpro realizes the recording and operating functions of large

number of input signals in high speed.

M-System’s remote I/O modules, R3 Series, offers a wide variety of input signals including DC and AC signals, temperature,

potentiometer, strain gauge and others.

SYSTEM CONFIGURATION EXAMPLES

Expanded System via Ethernet (73VR + R7 + MSR)

Ethernet

Ethernet

R3 Series

MSRpro-Client /

Analyzer

R5 Series

Switching Hub





MSRpro-Server

MSRpro-Builder

Communication

Adaptor

72EM2-M4

RS-485

R7M R7M R7M

The MSRpro is a suite of three programs:

MSRpro-Server

MSRpro-Client/Analyzer


Collects and stores input measurement data

and executes arithmetic computation to it.

Used to view, analyze and print measurement data.

Creates and modifies configurations for either program.

R3 Series I/O

Analog Input

Contact Input

Contact Output

MSRpro-Server

Sample

Store

Compute

Personal Computer

Stored Data

MSRpro-Client/

Analyzer

(Data Views)

Trend Graph

Overview

Alarm History

Trend Retrieval

Expanded System via Ethernet (53U + MSR)

Ethernet

MSRpro-Client /Analyzer

MSRpro-Server


Trend View

Overview

Active Trend

Graphic

Communication

Adaptor

72EM2-M4

RS-485


(Model: 53U)

53U

53U

Power Monitoring System

MAX.4 (ClientPC)

Server PC


Analyzer

Client PC


Analyzer

MSRpro-Server


Ethernet

Ethernet

MSRpro-Server


Modbus/TCP Ethernet

Modbus RTU

RS-485

Communication

Adaptor

72EM2-M4

Communication

Adaptor

72EM2-M4

RS-485

Communication

Adaptor

72EM2-M4

RS-485

R3 Series

R1M

RZUS-U9


(Model: 53U)

53U

R7M

R7M

MAX.8 stations (incl.72EM2)

42 43

73VR Paperless Recorder

Replace paper chart recorders and save cost of supplies and maintenance.

Environmentally friendly data recording solution – no chart paper, pens and cartridges.

73VR Series offers 3 types to select in many applications.

Versatile data recording.

73VR1100 connects to remote I/O

Designed to utilize a wide variety of M-System's remote I/O devices.

• Best suited to record data transmitted from remote I/O

located remotely in the field, or inside an instrumentation or

control cabinet.

• Instead of using expensive sensor cables, reduce wiring runs

by using open field networks through remote I/O.

• I/O separated 73VR1100 provides the installation flexibility

which fits in the tight space of a control panel or machinery

chassis.

73VR1100

R3 Series

R7 Series

MULTICHANNEL REMOTE DATA ACQUISITION

REDUCE WIRING COST

73VR1100

Up to 128 points

73VR1100

Touch panel operation.

Selectable number of pens to display.

5.5-inch TFT color display with backlight.

In addition to the conventional white chart color,

blue-to-black gradating background color is selectable.

IP 65 front cover.

Remote I/O

Modbus RS-485

Max. 500 meters

Up to 15 remote I/O

Ethernet - Up to 2 stations

Remote I/O

Sensor Sensor Sensor Sensor

Trend View (horizontal)

Trend View (perpendicular)

Trend View (large digital display)

Overview


Number of input channels

Function pen points

Storing rate (high speed mode)

Storing rate (normal mode)

Input types

64, 128 (Function pen points are included in the above figures.)

32, 64

100 msec.

500 msec., 1, 2, 5, 10 seconds, 1minute, 10 minutes

Use R3 series I/O modules

(DC voltage, DC current, Thermocouple, RTD, AC voltage, AC current, Encoder, Totalized pulse)

Bargraph View (horizontal)

Bargraph View (perpendicular) Alarm History View Overview (large digital display)

Trigger input

Alarm/Run output

Weight

Display Display device

Display colors

Resolution

Max. 128 via remote I/O

Alarm x 1, Run x1; Alarm also available via remote output modules

1.7 kg (3.7 lbs)

5.5-inch TFT LCD

256

320 x 240 pixels

Ethernet

10BASE-T / 100BASE-TX automatically switched;

Conforms to IEEE802 (10BASE-T) or IEEE802.3 (100BASE-TX)

Degree of protection

IP65 (applicable to the front panel of with the cover closed when a single unit is

mounted according to the specified panel cutout)

CE marking

Yes

44 45

73VR Paperless Recorder

73VR2100 built-in universal input modules

Universal input – DC, Thermocouple, RTD

• Independent input type and range selectable for each channel.

• 100 msec. storing rate up to 6 point.

• 2, 4, 6, 8, 10 or 12 points.

• Real time trending and recording on the PC Recorder software

MSR via Ethernet.

73VR3100 selectable input modules

Flexible I/O capability using the R3 series modules.

Compatible with various open networks.

• Up to 4 R3 Series I/O modules can be selected (Max. 64 inputs).

• By replacing one of the I/O modules with Network Module for

the R3 Series, the 73VR3100 can directly communicate to major

PLC via DeviceNet, Modbus, Ethernet (Modbus/TCP),

PROFIBUS-DP, LONWORKS and CC-Link.

• 20 msec. storing rate with the combination of 8 analog and

8 discrete inputs.

• Real time trending and recording on the PC Recorder software

MSR via Ethernet.

QUICK SETUP

INPUT TYPE


touch panel screen

Network module

Selectable I/O modules

(max. 4)

DC VOLTAGE

Input resistance:

Input range:

900kΩ minimum

(Excluding the case in which, with range setting other than

±12V, ±6V or ±3V, a voltage exceeding ±1.3V is applied.)

±60mV, ±125mV, ±250mV, ±500mV, ±1000mV,

±3V, ±6V, ±12V

Open network module installed, using 73VR3100 as

remote I/O with local display and recording function.

PLC

CPU

Display & recording data input to a control system

Recorder Operator Panel Operator Panel

DC CURRENT

THERMOCOUPLE

4-20mA, use optional REM3-250 resistor module

Input range: (PR), K (CA), E (CRC), F (IC), T (CC), B (RH), R, S,

C (WRe 5-26), N, U, L, P (Platinel II)

Burnout sensing • Upscale: ≤130nA

• Downscale: ≤220nA

• No burnout: ≤10nA

Open Network

PLC

PLC

Open

Network

Intuitive “Help View” screen for easy user setup

and use.

RTD (3-wire)

Input range: Pt 100 (JIS ’89), Pt 100 (JIS ’97, IEC), Pt 200, Pt 300, Pt 400,

Pt 500, Pt 1000, Pt 50Ω (JIS ’81), JPt 100 (JIS ’89), Ni 100,

Ni 120, Ni 508.4Ω, Ni-Fe 604, Cu 10 @25°C

Allowable leadwire resistance: 20Ω per wire

Burnout sensing • Upscale or Downscale: ≤130nA

73VR3100

Input

Input

Input

Input

Input

Input

Isolator

Input

Input

Input

Input

73VR3100

Input

Input

Input

Input






Input types

Trigger input


Weight



Resolution

Ethernet


CE marking

2, 4, 6, 8, 10 or 12

12

100 msec.


Universal input (DC mV and voltage, thermocouple, 3-wire RTD)

Dry contact x 1

Relay contact x 1

2.4 kg (5.3 lbs)


256






Yes






Input types

Trigger input


Weight



Resolution

Ethernet


CE marking ----

4-64

16, 64

20 msec., 100 msec.


Use R3 series I/O modules

(DC voltage, DC current, Thermocouple, RTD, AC voltage, AC current, Encoder, Totalized pulse, Di/o)

Max. 64 (varies by input modules used)

Max. 32 (varies by input modules used)

2.3 kg (5.1 lbs) except I/O modules


256






46 47

Bargraph Indicators

Digital Panel Meters

Bargraph Indicator

DC input

• Red, Amber, Green, Blue

• Vertical or horizontal mounting

• Single/dual bargraphs

• IP 65 front panel cover

48NV

Panel cut size

Mounting direction

Bargraph LED

Bar color

Power input

CE marking

36 x 144 mm

Vertical / Horizontal

101 segments (two), 100 mm

Red, Amber, Green, Blue

100-240 Vac or 24 Vdc

Yes

Digital Panel Meters, LED Display Type

DC input, 4 1/2 digits


Thermocouple input, 4 digits

RTD input, 4 digits

Potentiometer input, 4 digits

Strain gauge input, 4 1/2 digits

AC current input, 4 1/2 digits

PT input, 4 1/2 digits

CT input, 4 1/2 digits

47LYV

47LV

47LT

47LR

47LM

47LLC

47LAC

47LPT

47LCT

NEW

Future Plan

NEW

NEW

NEW

Bargraph Indicating Alarm

DC input

48NAV

Transmitter output

48NAVA

2-wire transmitter excitation 48NAVD


48NAT

RTD input

48NAR


48NAM

• Red, Amber, Green, Blue or Multicolor LED

(red/orange/green)

• Vertical or horizontal mounting

• bargraph plus alarm output


Panel cut size

Mounting direction

Bargraph LED

Bar color

Power input

Alarm trip option

CE marking

36 x 144 mm

Vertical / Horizontal

101 segments, 100 mm

Red, Amber, Green, Blue, Multicolor


100-240 Vac or 24 Vdc

Dual or quad alarm

Yes

• 1/8 DIN size

• LED color selectable, Red, Orange, Green, Bluegreen, Blue, White

• Field-selectable input range

• IP66 front panel

Digital Panel Meters, LCD Display Type


47DV NEW

Thermocouple input, 5 1/2 digits 47DT NEW

RTD input, 5 1/2 digits

47DR NEW

Potentiometer input, 5 1/2 digits 47DM NEW

• 1/8 DIN size

• Red or Green LCD selectable (negative type LCD with LED backlight)

• Field-selectable input range

• IP66 front panel

Bargraph Indicating Alarm (with 4-digit digital meter)

DC input

48NDV


48NDVA

2-wire transmitter excitation 48NDVD


48NDT

RTD input

48NDR


48NDM

• Red, Amber, Green, Blue or Multicolor LED


• Vertical mounting

• bargraph, digital indicator plus alarm output


Panel cut size 36 x 144 mm

Mounting direction Vertical

Bargraph LED 101 segments, 100 mm

Bar color

Red, Amber, Green, Blue, Multicolor


Digital display digit 9999

LED height

8 mm (red)

Power input

Alarm trip option

100-240 Vac or 24 Vdc

Dual or quad alarm

CE marking

Yes

4-digit LED Loop Powered Indicator

4-digit Loop Powered Indicator, Intrinsically safe 6DV-B


4-digit Loop Powered Indicator, Intrinsically safe 6DV



• Scaling & linearization selectable via the front control buttons

3 1/2 digit LED Loop Powered Indicator

43 Series



BARGRAPH INDICATOR SPECIFICATIONS

Input type DC input


Model No.

Input

Excitation

supply option

Transmitter

output option

Specific range of

0-50 mAdc or

±10 Vdc

Specific range of

0-50 mAdc or

±10 Vdc

----

2-wire transmitter

excitation


RTD input

48NV

----

----

----

----

----

48NAV 48NAVA 48NAVD 48NAT 48NAR 48NAM

48NDV 48NDVA 48NDVD 48NDT 48NDR 48NDM

4-20mAdc Thermocouples;

K, E, J, T, B, R, S, N

2- or 3-wire RTDs;

Pt 100, Pt 50Ω,

Ni 508.4

---- 24-28 Vdc @22mA ---- ---- ----

---- 4-20 mA, 1-5 V and ----

---- ---- ----

other specific range

of 0-20 mA or ±10V


Potentiometer;

100Ω – 10kΩ

DIGITAL PANEL METER SPECIFICATIONS

Model No. 47LV 47DV 6DV / 6DV-B 43AL

Panel cut size 96 x 48 mm, 1/8 DIN 96 x 48 mm, 1/8 DIN ----

48 x 24 mm, 1/32 DIN

Display digit 19999 199999 9999

1999

Display height 16 mm (.63") Main display: 14.2 mm (.56")

8 mm (.30") 10.16 mm (.40")

Sub display: 5.5 mm (.22")

Display color Red / Orange / Green /

Bluegreen / Blue / White

Main display: Red and Green

Sub display: Yellow-green

Red

Red

Input ±10 V, ±5 V,

0-5 V, 1-5 V,

0-20 mA, 4-20 mA

DC voltage: ±5 V, 1-5 V, ±20 V, ±200 V

DC current: 0-20 mA, 4-20 mA,

±20 mA, ±200 mA

4-20 mAdc

4-20 mAdc

Power input 100-240 Vac or 24 Vdc Not required Not required

Output options Alarm Transmitter output, Alarm, RS-485, Modbus-RTU ----

----

CE marking ---- Yes

Yes

Safety approval ---- FM / ATEX UL

48 49


M-System Lightning Surge Protectors absorb only the lightning

surges with no interruption of the instrumentation signal

Protects sensor, signal and power lines

Can be removed and tested without

disconnecting wires

Superior protection and selection across

a wide range of applications including:

4-20 mA & pulse signal

Thermocouple

RTD

Potentiometer

Strain gauge

Frequency generating devices

Telemetering devices

RS-485 / RS-422

Ethernet, DeviceNet, PROFIBUS, LONWORKS

AC/DC Power supply lines (1 amp up to 30 amps)

Model MAKF One-Port Surge Protector For Power Supply Use

Designed to protect electronics equipment from induced lightning surges entering

through power supply cables

Connected in parallel between the power and ground lines regardless of load current

Varistor discharge element has a high speed response without follow current

No interruption of power supply even when the head element is removed:

easy maintenance and replacing

Degraded head element is automatically separated from the power lines to

prevent overheating, with a relay contact output to alert the failure status

Head-base connection is keyed so that only a head element of correct line

voltage can be mounted

Breaker Operation

3

Thermal Breaker (cross section)

The alarm output switch is turned on.

Connection Examples

Single-phase / 2-wire connection

Protected Device

G

Surge Current Flow (cross section)

Lightning Surge

M5 screw (spring loaded)

Metal Oxide

Varistor (MOV)

Model MDPA-24 Lightning Surge Protector with Life Monitor

Designed specifically for 4-20 mA and pulse signal

line including 4-wire/2-wire transmitters.

Battery powered life monitoring system includes

a ‘Test’ button with indicators alerting panel

inspectors of the surge protector’s ‘health.’

MDP-24-1

• 4-20 mA & pulse signals

• UL listed


CHK Check Button

ALM Indicator LED

CLOSE UP

BAT Indicator LED

LIFE IDENTICATION

ALT BAT

Replacement

No Need

Near

Immediately

Required

MA-100 / MA-200

• 120 Vac / 240 Vac power supply lines

• 2 amps

• Fuse provided for supplementar

protection


1

2

When the low temperature-melting

solder is melted by an abnormal high

temperature at the discharge element,

the lever mechanism is released by the

force of spring to separate the

discharge element from the circuit.

The green failure indicator turns to

black at the same time.

Cross-wiring

Grounding

Single-phase / 3-wire,

three-phase / 3-wire connection

Protected Device

G

Cross-wiring

Grounding

Model SHSP 8-Port Ethernet Switch with Surge Protector

Surge protector function for each port

Protects Ethernet devices from surges entering through LAN cables

Surge protector life monitor function with LED and contact output alarm

Data transfer rate can be fixed

Ground

MDM2A-24


• Life monitor

• Alarm output


MDM5E-A

• Designed specifically for Ethernet network

• Conforms both to 100BASE-TX / 10BASE-T

• LAN cable’s shield wire can be floating or

grounding by a shortcircuit bar.

• DIN rail mounting

MAA-100 / MAA-200

MAAC-100 / MAAC-200

• 120 Vac / 240 Vac power supply lines

• 5 amps

• Life monitor

• Surge counter function


MD6 Series


• Directly mountable to the cable

conduit of two-wire transmitters

and other field devices in an

outdoor enclosure


LAN PORT SPECIFICATIONS

Standards

Number of ports

Data transfer rate

IEEE 802.3, IEEE 802.3u, IEEE 802.3x

8; All ports support AUTO-MDIX*

10 Mbps (10 BASE-T),

100 Mbps (100 BASE-TX);

Supports Auto-Negotiation

Cable

Maximum segment length

Switching

Full duplex

10 BASE-T (STP cable, category 5)

100 BASE-TX (STP cable, category 5e)

100 meters

Store & Forward

PAUSE Frames

Flow control

Buffer

Half duplex Back pressure

64 KB

MAC address table 1024

* Automatically sensing cable type (straight-through or cross-over).

SURGE PROTECTOR PERFORMANCE

Compliant standard

Between ports

Port to G

FG (shield) to G

Voltage protection level

Port to FG or G

Between each port

FG to G

EN61000-4-5 level X

1kV (combination waveform)

10kV (combination waveform)**

15kV (combination waveform)***

160V min.

160V min.

160V min.

(with the shortcircuit bar removed)

** RJ-45 connector contact is out of the scope of this protection.

Using twisted-pair (STP) LAN cable is effective to reduce risk of fusing

contact.

*** With the shortcircuit bar

FRONT VIEW

LINK LED

100M LED

LAN Ports (x 8)

RJ45 Connector

Status

Device status LED

Protector

Surge Protector Life

Monitor LED

50 51

MD7 Series

Ultra-Slim Lightning Surge Protectors

High-density mounting with 7-mm wide modules

Excellent protection by multi-stage SPD

Max. discharge current 20 kA (8/20 µsec.)

Floating mode for the shield to avoid ground loops

DIN rail mounting / grounding

Loop disconnect fuse (option)

FM intrinsically safe (pending)

The MD7 Series is a new family of surge protectors offered from M-System,

specialist of signal conditioning who knows about a variety of electronic

devices interfacing field sensors and control rooms.

The MD7 surge protectors are multi-stage SPD, which, in addition to the

discharge element at the first stage, provide an extra protection by a series

resistance with diodes to limit current flow. The maximum discharge current

is up to 20 kA to further enhance its performance.

All MD7 products have an independent set of shield terminals, therefore it is possible to choose ‘Floating’ or ‘Grounding’ shield

terminal to suit users’ application needs. Floating mode is especially effective to prevent a ground loop.

The MD7 surge protectors are designed to earth ground through DIN rail, and by connecting the rail to the earth, they are

automatically grounded when they are mounted on it. No need of cross wiring.

Model MD7ST has an optional ‘Loop Disconnect Fuse’ function to conveniently separate the protected device from the power bus to

protect others when it has failed in shortcircuit mode.

95 (3.74)

7 (.28)

Wide adaptabillity:

4-pole terminals

8

6

5

4

Loop disconnect

fuse (MD7ST)

1 1

2

Power LED

3

7 (MD7DP)

Only 7 mm

wide

EASY COMMISSIONING

4

Easy wiring: Slanted terminals

5

2

6

8

3

7

98 (3.86)

DIN rail

mounting /

grounding

unit: mm (inch)

MODEL

MD7ST

MD7AST

MD72W

MD72WD

MD73W

MD7TC

MD7RB

MD7PM

MD7JS

MD7LC

MD7PL

MD74R

MD7PA

MD7LWA

MD7FB

MD7DP

MD7AP

APPLICATIONS

4-20 mA loop

4-20 mA loop, life monitor

2-wire transmitter loop

2-wire transmitter loop (2 channels)

3-wire transmitter loop

Thermocouple transmitter

RTD & RTD transmitter

Potentiometer & transmitter

Self-Synch & transmitter

Strain Gauge & transmitter

2-Point Pulse Signal

RS-422 / RS-485

PROFIBUS-PA

LONWORKS

FOUNDATION Fieldbus

DC power supply

AC power supply

NEW

The MD7 Series are designed for multi-point, ultra-high-density installation. DIN rail mounting/grounding and slanted terminal block

help installation and wiring work in such tight space.

When the DIN rail is grounded at single point, surge protectors mounted on it are automatically connected to the earth. There is no

need of cross-wiring individual module.

Thanks to the terminal blocks slightly slanted forward, access from the front side to the terminals is easy even after the protectors are

mounted on the rail.

NEW

Future Plan

Future Plan

HIGH PERFORMANCE

The multi-stage protection combining discharge elements at the

first stage and the series resistances and diodes ensures to limit

the current flow.

The maximum discharge current capacity is as high as 20 kA

for an impulse wave of 8/20 microseconds. The MD7 Series

are tested according to IEC 61643-21 standard to be suitable

for categories C1, C2 and D1. C1 category requires the surge

protector to withstand 300 times of average induced surges,

C2 to withstand 10 times of strong induced surges generated in

a harsh environment without electromagnetic shielding. D1

category is tested by two direct hits.

Ultra-slim Package, Unmatched Performance

SPECIFICATIONS - SURGE PROTECTORS FOR STANDARD SIGNAL LINE

Function 4-20 mA loop 2-wire 3-wire

Model No. MD7(A)ST-24 MD7(A)ST-60 MD72W-07 MD72W-16 MD72W-32 MD72W-55 MD73W

Max. continuous operating voltage (Uc) 30V 70V ±7V ±16V ±32V ±55V ±32V

Voltage protection level (Up) 60V max. 115V max. 20V max. 30V max. 50V max. 80V max. ±60V max.

Max. discharge current (Imax)

20 kA (8/20 µsec.), 1.0 kA (10/350 µsec.)

Test standard

IEC 61643-21, cagetories C1, C2 and D1

CE marking

Yes

Life monitor

Yes (MD7AST) ----

SPECIFICATIONS - SURGE PROTECTORS FOR SENSOR SIGNAL LINE

Function Thermocouple RTD Potentiometer Strain Gauge

Model No. MD7TC MD7RB MD7PM

MD7LC-1 MD7LC-0

Series resistance ---- With

Without

Max. continuous operating voltage (Uc) 7.5V ±3V 7.5V

Line side: ±0.2V Line side: ±0.2V

Exc. side: 15V Exc. side: 15V

Voltage protection level (Up) 25V max. ±25V max. 25V max.


Test standard

CE marking

Metal DIN rail adaptor

used for grounding

Loop disconnect fuse

(standard signal line)

20 kA (8/20 µsec.), 1.0 kA (10/350 µsec.)


Yes

SPECIFICATIONS - SURGE PROTECTORS FOR SENSOR, POWER SUPPLY LINE

Function

Model No.

Max. continuous operating voltage (Uc)

Voltage protection level (Up)

Self-Synch

MD7JS

±130V

±450V max.

Pulse signal (PNP)

MD7PL-P

-30V

-50V max.

Pulse signal (NPN)

MD7PL-N

+30V

+50V max.


20 kA (8/20 µsec.), 1.0 kA (10/350 µsec.)

Test standard


CE marking

Yes

Line side: ±40V max.

Exc. side: 50V max.

DC power supply

MD7DP-12

14V

±150V max.

Independent shield

terminal

Monitor LED

(power supply line)

Line side: ±15V max.

Exc. side: 30V max.

100 A (8/20 µsec.)

----

----

MD7DP-24

27V

±170V max.

SPECIFICATIONS - SURGE PROTECTORS FOR TRANSMISSION LINE

Function RS-422 / RS-485 PROFIBUS-PA LONWORKS FOUNDATION Fieldbus

Model No. MD74R MD7PA MD7LWA MD7FB

Max. continuous operating voltage (Uc) ±5V ±32V ±1.5V ±32V

Voltage protection level (Up) ±25V max. ±60V max. ±30V max. ±60V max.


20 kA (8/20 µsec.), 1.0 kA (10/350 µsec.)

Test standard


CE marking

Yes

52 53

Electronic Actuators & Position Sensors


SERVOTOP II Series

Failsafe Linear


Linear motion type PSN

for thrust 3000-5000 N

FEATURES

• Brushless angle sensor eliminates problems with mechanical

potentiometer feedback sensing

• 0.06 mm linear resolution for precise valve/damper positioning

• Opening/closing speed, split range and failsafe position

programmable in-field

• Internal temperature sensor to warm unit in cold climate or to

prevent motor burnout from overheating

• Forced-open/-closed contacts for remote or manual override

APPLICATIONS

• Chemical injection/mixing

• Fuel valve control

• Petrochemical and pharmaceutical flow controls

• Wastewater flow control

• HVAC damper positioning

• Food machines

Position Sensors

Brushless stepping motor

Enhances the durability and reliability of M-System’s

electronic actuators.

Unaffected by pressure fluctuations from the process

Line pressure fluctuations are absorbed by the screw shaft.

Sealing spring mechanism

M-System’s Model VOS2T and VOS2T-R are two-wire position transmitters incorporating a

brushless angle sensor as their key sensing component. They detect rotating angles of

pneumatic and electric actuators and send 4 to 20 mAdc signal proportional to the angles.

They are also widely used in monitoring and automating various mechanical systems.

FEATURES

• Lightweight & compact design

• High resolution

• Direct and reverse actions are selectable

in-field

• IP 66 diecast aluminum enclosure is

suitable for field applications

APPLICATIONS

Mini-Top Series

Linear & Rotary


Linear motion type MSP for thrust 700-2500 N

Rotary motion type MRP for torque 5-33 N·m

FEATURES

• High resolution positioning for better valve control

• Built-in feedback positioner and electronic limiter

• Brushless stepping motor assures long-life operation

• 1/1000 resolution

APPLICATIONS

• Pilot plants

• Chemical injection/mixing

• Tank valve control in brending machines

• Fuel valve control

• HVAC damper positioning

• Food machines

• Petrochemical, pharmaceutical,

wastewater flow controls

Built-in sealing spring retains the sealing pressure at the closed position.

• Position transmitter for pneumatic control valve or dampers

• Proportional control of an ON/OFF valve

• Position feedback for motor-driven systems or servo control systems

• Measuring roller position displacement in paper, cloth and other types of film feeders

• Upward/downward positioning for boarding bridges

• Rudder direction sensing

• Liquid level sensing in reservoir tanks

LINEAR MOTION TYPE

Model

Model (DeviceNet)

Model (CC-Link)

Max. stroke (mm)

Max. stroke (inch)

Max. thrust (N)

Max. thrust (lbs)

Resolution

Input signal

Position output

Motor

Position detection

Power input


Failsafe function

ROTARY MOTION TYPE

Model

Model (DeviceNet)

Model (CC-Link)

Max. angle

Max. torque (N·m)

Max. torque (ft·lbs)

Resolution

Input signal

Position output

Motor

Position detection

Power input


Model No.

Input angle

Mechanical angle

Stopper strength

Output action

Output signal


Supply voltage


Wiring conduit


Maximum vibration

Approx. weight

Linearity

MSP4

MSP5

MSP4D

MSP5D

MSP4C

MSP5C

15 mm

20 mm

0.59”

0.79”

700 N

700 N

157 lbs

157 lbs

1/1000

4-20 mA or 1-5 V

1-5 Vdc

Stepping motor

Potentiometer

24 Vdc, 100-120Vac, 200-240 Vac

IP55

----

MRP4

MRP5

MRP4D

MRP5D

MRP4C

MRP5C

90°, 180°

90°

5 N·m

10 N·m

3.69 ft·lbs

7.38 ft·lbs

1/1000

4-20 mA or 1-5 V

1-5 Vdc

Stepping motor

Potentiometer

24 Vdc, 100-120 Vac, 200-240 Vac

IP55

VOS2T

VOS2T-R

Linear Motion Type

Rotary Motion Type

-22.5 to +22.5° -45 to +45°

-27 to +27°

-55 to +55°

1.37 N·m (1.011 ft·lbs) with static load

Direct or Reverse

4-20 mAdc

0-600 Ω at 24 Vdc supply

15-28 Vdc

IP 66

G 1/2” female thread

-5 to +60°C (23 to 140°F)

2 G

550 g (1.2 lbs) without lever or cable

1.0% within the input angle

MSP6

PSN1

PSN3

CSP

MSP6D

----

----

----

MSP6C

----

----

----

40 mm

40 mm

60 mm

75 mm

1.57”

1.57”

2.36”

2.95”

2500 N

3000 N

5000 N

12000 N

562 lbs

674 lbs

1124 lbs

2697 lbs

0.04 mm

0.06 mm

Hysteresis 1 mm or less

4-20 Vdc

AC motor

Brushless angle sensor

Potentiometer

100 Vac, 110 Vac

200 Vac, 220 Vac

IP56

Optional

----

MRP6

CRP-0

CRP-1

CRP-2

MRP6D

----

----

----

MRP6C

----

----

----

90°, 180°

90°

33 N·m

68.6 N·m

196 N·m

588 N·m

24.3 ft·lbs

50.6 ft·lbs

144.7 ft·lbs 434.0 ft·lbs

0.45°

4-20 Vdc

AC motor

100 Vac, 110 Vac, 200 Vac, 220 Vac

Diecast aluminum enclosure

Direct/Reverse selector

Lever

Terminal block

Indicator

Direct drive shaft

Brushless angle sensor

Cable gland

54 55

Four-wire Signal Conditioners Two-wire Signal ... - M-System

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
