EDITORIAL

Aluminium in the automotive industry:

A material with a promising future

The history of industrial aluminium production is as old as the

automobile. However, the path shared by the lightweight

metal and the product segment is still relatively recent. But there

are strong indications that this relationship will become even

closer. Aluminium is now the most important lightweight material

used in the automotive sector. And its development continues.

Vehicle manufacturing will offer good growth prospects

to aluminium in the future as well.

Lightweight, corrosion-resistant, and recyclable, without

any loss of quality – aluminium meets all the requirements of

a modern material for the implementation of modern mobility

concepts. The automobile manufacturing industry is increasingly

exploiting the flexible capabilities of lightweight aluminium. It

can be used in a wide variety of components and also enables

a variety of manufacturing processes. Since 1990, aluminium

content in cars has almost tripled, from 50 to 140 kg. And the

demand for innovative lightweight solutions continues to rise.

In the competition between construction materials, aluminium

has excellent prospects. The automotive industry and its

suppliers increasingly demand new applications for aluminium.

The times in which the lightweight metal was primarily used in

the luxury car segment have long since passed. More and more,

aluminium is being used for compact cars as well as mid-size

vehicles – in engines, the auto body, and chassis. In particular,

complex and highly stressed structural parts are proving to be

growth drivers for this material. As a result, the outlook is good:

Experts forecast that on average up to 180 kg of aluminium will

be installed per vehicle by 2020.

The requirements of car manufacturers and the highly specialized

supplier industry are also pushing the material and process

development of all things aluminium. We are regularly developing

new alloys with improved mechanical properties, including

stability, formability, and corrosion resistance. Aluminium recycling

is also of growing importance. In times of costly power

and dwindling reserves of raw materials, the materials cycle is

increasingly gaining value. The use of recycled aluminium also

leads to a significantly better carbon footprint. It not only reduces

the environmental impact of production process, but ensures a

higher-quality end product.

The intensive collaboration between materials specialists,

fabricators, and automobile manufacturers will open further

application areas and development potential for the lightweight

material aluminium. We live in the aluminium age. This “young”

metal has by no means reached the zenith of its development.

I'm looking forward to the Aluminium trade fair – see you in

October in Düsseldorf, Germany.

Thomas Reuther

Member of the Management Board

Trimet Aluminium SE

2-2014 heat processing

1
