Expertise in assemblies
Development and quality assurance
Focus on precision
These sub-assemblies for vehicle automatic
transmissions were developed in close cooperation
with the customer.
Adherence to the tightest tolerances must be
guaranteed so that the components like armature
shafts (see above left) for electric motors
work perfectly.
Quality is our strength
The striving of our Company for quality is a firm part of our Company’s philosophy. Total quality
management, the responsible attitude of our highly motivated employees in the workplace and
constant research towards improvement have brought SCHERDEL’s stamping and bending
division the deserved success.
Stamping and bending technology
Suitable and economical solutions with
stampings and shaped components
Fully automatic assembly of components allows
large quantities and, therefore, an optimised cost
and product for our customers.
