An important step towards a reliable

energy supply in the future

The sun provides life on

our planet. As a source of

energy, it holds unimaginable

potential for supplying

energy in the future.

In view of the world‘s

climate and energy goals,

as well as the catastrophic

events surrounding nuclear

power plants, solar power

is increasingly gaining

importance. The industry is

now experiencing increased

demand for industrial-sized

plants, such as solar roof

systems atop commercial

buildings, following enormous

interest in the residential

construction sector.

Did you know …

... that such a system with an

output of 7.4 MW would

be capable of generating

approx. 7.3 million kWh of

energy every year, which

would correspond to the

annual requirements of

approx. 1,800 homes?

… that the largest photovoltaic

installation worldwide

generates a total output of

150MWp? It was launched

in Brandenburg (Germany)

in September 2011.

… that in Germany, since

2011 and for the first time

ever, there has been more

solar capacity connected

to the grid than energy

provided by nuclear power

plants? Germany continues

to be the largest photovoltaic

market, at the end of

2011, it had a total capacity

of approx. 20 GW installed.

Systems generating a total

output of 7500 MW have

been set up in 2011 alone.

... that renewable energies

would not make electricity

more expensive, but rather

have a restraining effect on

prices?

... that up until the end of

2011, the total photovoltaic

capacity installed around

the globe was 67 GW

and that 27 GW are being

added every year?

In the meantime, the

renewable energy industry

has become an astounding

economic factor, revitalising

the employment market and

creating numerous „green

jobs“.

The choice of the right components

for a PV system is of

fundamental importance. The

system will be in operation

for many years and all parts of

the system must satisfy the

highest standards. The appropriate

quality and longevity,

as well as warranties and Service

support are necessary in

order to guarantee long-term

success.

Here you can see the

industrial-size systems that

Eaton offers.

4

Leading the way

with safety …

Eaton ensures the

reliable availability

of renewable

energies – safe for

people and good for

the environment.

From solar module to

power grid

Solar power is becoming

increasingly more important

and safety plays a decisive

role. From the outset, it

pays to invest in the right

technology. Eaton delivers

all products needed to safely

transport energy from solar

panels to the power grid.

Reliable protection, separation

and control technology

provide for the safe operation

of photovoltaic systems,

using integrated or external

separation equipment for

automated and manual operation

and for both direct and

alternate currents (DC/AC).

Safety from the startt

Proper planning and design

are crucial to the safe and

reliable operation of a

photovoltaic plant, and ensure

trouble-free operation of all

switching, contacting, protection,

separation, insulation

and monitoring functions.

Through intensive cooperation

with system integrators,

manufacturers and switch

gear plant builders, Eaton

offers full peace of mind, right

from the start.

As one of the leading

global energy management

companies, Eaton guarantees

know-how, proximity and

the dynamics you need to

successfully complete your

project. Moreover, as a global

player and partner, Eaton

stands for high product

availability, outstanding quality

and exceptional service for

individual solutions.

It is this high level of

innovation combined with

environmentally proven

technology, that has

characterized the quality and

daily operational use of

Eaton products in the field

for many years.

Renewable energy is a part of the markets of the future.

Having Eaton as an experienced, reliable partner is a good thing:

• High-quality circuit breaker series, especially for photovoltaic use

• Reliable and fail-safe

• Eaton has been a global player and reliable partner for more than

100 years, with decades-long experience in energy distribution

5

AC components

Quality and safety on the AC current level: Eaton AC components.

Eaton also supplies everything on the AC level that you require for the safety and efficiency

of your photovoltaic installation. From the power inverter right up to the power grid, Eaton

components guarantee the best possible installation safety and assure reliable operation and

optimum power feed.

Grid-connected photovoltaic inverters

Eaton offers three-phase inverters for

10kW, 15kW and 20kW, compatible with

mono-crystalline and poly-crystalline

PV generators. They are absolutely

maintenance-free, work reliably and are

extremely easy to handle thanks to an

integrated LCD display. A maximum

power point tracker (MPPT) function

ensures optimized efficiency. The

I3GO series, featuring an IP65 degree

of protection, has been designed for

outdoor areas.

Protective switchgear such as MCBs,

RCBs and combined RCBOs

A new type of protective switchgear

equipped with integrated and patentregistered

digital technology adds even

more safety and reliability to photovoltaic

systems of the future. Digital RCBs

featuring a B+ characteristic are able to

identify fault currents in both the alternate

and direct current range, they warn

operators at a very early stage before

any damage can occur in the system,

and they meet all the requirements for

enhanced fire protection pursuant to

the relevant STANDARD. MCBs and

combined RCBOs complete our offering

for safe energy distribution.

Grid & systems

protection for up to

1000 kVA, ready-to-connect, with an

extremely low level l of own

consumption

For system sizes rangingn from 30 to

100kVA, 0kVA, Eaton has developed a compact,

ready-to-connect combination. It comes

in

a plastic enclosure, features an IP65 degree

of protection and meets the requirements

of the VDE-AR-N 4105 standard. The combination

includes two contactors switched

in series, actuated by a grid & systems protective

relay that comes prewired and

mounted inside an enclosure. The recently

developed grid & system protection is

installed between the power inverter and

the grid connection. It is easy to install and

fix in wall-mounting technology. The

DILMP contactor type used by Eaton is particularly

efficient thanks to an electronic

solenoid drive requiring a holding power of

only 2.1W. Eaton’s combined grid & systems

protection is available in four rating

classes.

6

AC components

Contactors DIL

The contactors DIL H safely

switch the power inverters

onto the grid. The innovative

construction design using

vacuum tubes reduces the

holding power by up to 96 %.

Accordingly, not only is the

heat development in the

control panel reduced, but

also the day-to-day operating

costs. Seven sizes cover the

power range up to 2600 A.

Eaton also offers 4-pole

contactors up to 800 A.

Circuit-breakers

NZM and IZM

The circuit-breaker series

NZM offers optimum installation

protection up to 1600 A

with four sizes. The air circuitbreaker

IZM, also with four

sizes, covers the power range

up to 6300 A. Both series are

characterised by their high

switching capacities and

comprehensive range of

accessories and provide a

solution for every application.

Eight sizes allow you to

cost-effectively engineer the

required dimensions and

ratings of the switch.

Control and

monitoring

Eaton panels are operating

and monitoring devices that

also can be used as control

devices. Modern touch

panels cater for clear, flexible

menu-guidance in every

desired language and allow

worldwide application

with just one hardware and

software solution. The optimum

solution is available for

every application with touch

panels from 3.5“ to 19“.

Medium-voltage systems

XIRIA

XIRIA ring main units protect

applications up to 24 kV. They

operate with a combination

comprised of circuit-breakers

and electronic relays and

feature high level of operational

safety and a compact

design. They are available in

three or four panel versions.

7

DC components

Quality and safety for the entire DC current requirements: Eaton DC components.

Power grid coupled photovoltaic systems feed the generated power directly into the electrical

grid without complex and costly intermediate storage. An installation of this kind mainly consists

on the DC end of solar modules, cables and different switchgear for operation, maintenance

and protection in the event of a fault. Eaton provides you with a complete product range

for protection, switching and isolation to safely and efficiently transport the solar energy from

the individual solar modules to the power inverter.

String circuit-breakers

PKZ-SOL

The fuseless alternative for

protection against short circuit

currents with the string circuitbreaker

PKZ-SOL. With their

variable trip range, they can

be optimally adjusted to the

actual short-circuit current of

a string. A thermal release

reacts at 1.05 … 1.3 fold

current, and the magnetic

release at 6-fold current.

Non-enclosed string circuitbreakers

are intended for

installation in customized

generator connection

enclosures.

DC switch disconnectors

Switch-disconnectors N…DC

in the special version for up

to 1500 V DC can be used on

1 or 2-poles. They comply

with the isolation properties

even for earthed IT networks.

Accessories, such as Bridge

kits, connection terminals and

door coupling rotary handles,

enable individual installation

in the most varied of distribution

systems. Auxiliary

switches, voltage releases

and remote operators facilitate

signalling and automation.

DC overvoltage protection

The surge arrester SPPT2PA

has been developed especially

for photovoltaic applications

and protects the installations

against transient overvoltages

that can be induced by indirect

lightning strikes. Eaton

provides versions for both

earthed and unearthed installations,

where spark gaps are

used to ensure galvanic isolation.

Naturally, the units are

available as prewired ready-touse

modules – just install and

they are ready to go.

CI insulated enclosures

The weather-proof CI enclosures

with the enhanced degree

of protection IP 65

are ideal for outdoor installation.

Thus, you can safely and

cost-effectively protect and

install your switchgear. The

modular design simplifies the

adaptation to different application

areas, such as generator

connection enclosures for

direct protection of several

strings in a field.

8

Content

DC-Disconnectors to 1500 V

Selection Information Page 10

Technical Data Page 14

DC-Disconnectors



Surge Protection



CS Wall-Mounted Sheet Steel



CI insulated enclosures



Photovoltaic inverters



Contactors DILM



Grid & systems protection



9

Photovoltaic - Switch-disconnectors

Switch-disconnectors for 1000/1500 V DC, 2 pole

• IEC/EN 60947-3

• Main switch characteristics including positive drive to IEC/EN 60204 and VDE 0113

• Isolating characteristics to IEC/EN 60947 and VDE 0660

• Busbar tag shroud to VDE0160 Part100

• Switch-disconnectors N can, in addition, be combined with voltage releases NZM...-XU, NZM...-XA

and auxiliary contacts as well as with remote operator NZM...-XR...

• For 2 pole switching, series connection of two poles each is required. See accessories bridge kits

• Standard equipment: Screw-type connection, frame terminal available as an option

• N2..: Can not be combined with early-make auxiliary contacts NZM-..XHIV or box terminal NZM2-4-XKC

at Ui > 1000 V DC

• For non-earthed networks > 1000 V DC the installation must be configured such that the likelihood of

a double earth fault is negligibly small

• Switches can not be combined with withdrawable units and/or connection on rear

Rated operational Short-circuit Screw 1000VDC 1500VDC Units per

current rated = protective connection Fixed mounted Fixed mounted package

uninterrupted device fuse Designation Designation

current gR-characteristic Article No. Article No.

I n = I u

A

A

wa_sg05309

160 200 S N2-4-160-S1-DC N2-4-160-S15-DC* 1 pcs.

127732 167688

200 200 S N2-4-200-S1-DC N2-4-200-S15-DC* 1 pcs.

127733 167689

250 315 S N2-4-250-S1-DC* N2-4-250-S15-DC* 1 pcs.

154940 167690

300 315 S N2-4-300-S1-DC* N2-4-300-S15-DC* 1 pcs.

168565 168566

*Estimated delivery date as of Oct. 2012

N3_3

320 500 S N3-4-320-S1-DC N3-4-320-S15-DC 1 pcs.

127734 166407

400 500 S N3-4-400-S1-DC N3-4-400-S15-DC 1 pcs.

142267 166408

500 500 S N3-4-500-S1-DC N3-4-500-S15-DC 1 pcs.

142268 166409

550 630 S N3-4-550-S1-DC* N3-4-550-S15-DC* 1 pcs.

168567 168568

*Estimated delivery date as of Oct. 2012

wa_sg04609

800 - S N4-4-800-S1-DC N4-4-800-S15-DC 1 pcs.

119890 166413

1000 - S N4-4-1000-S1-DC N4-4-1000-S15-DC 1 pcs.

119891 166414

1250 - S N4-4-1250-S1-DC N4-4-1250-S15-DC 1 pcs.

119886 166415

1400 - S N4-4-1400-S1-DC N4-4-1400-S15-DC 1 pcs.

119887 166416

1600 - S N4-4-1600-S1-DC N4-4-1600-S15-DC 1 pcs.

152552 166417

10


Bridge kits NZM...-XKV

• Model contains parts for upper or lower row of switchgear side for 4 pole switches N...-S1(S15)-DC that are

used as 2 pole switches for DC

• The links each connect two contacts in series

• Incoming unit and outgoer at bottom or top, user-definable

• N4-4-... ≥1250A at 65°C alternate connection at bottom through module plates NZM4-4

• Other derating values upon request.

2-pole

(+ and -)

on one side

Notes Rated opera- Protec- For use with Designation Units per

tional current tion Article No. package

I n

class

A

Incl. cover

190 at 70 0 C IP2X N2-4-...S1(S15)-DC NZM2-4-XKV2P 1 pcs.

200 at 65 0 C 131730

260 at 40 0 C

Incl. cooling unit 230 at 70 0 C IP2X N2-4-...S1(S15)-DC NZM2-4-XKV2P-K 1 pcs.

275 at 40 0 C 168591

400 at 70 0 C IP2X N3-320(400)-S1(S15)-DC NZM3-4-XKV2P 1 pcs.

450 at 40 0 C 131731

Incl. cooling unit 400 at 70 0 C IP1X N3-400(500)-S1(S15)-DC NZM3-4-XKV2P-K 1 pcs.

500 at 55 0 C IP2X 142271

1250 at 70 0 C IP2X N4-4-800-...S1(S15)-DC NZM4-4-XKV2P 1 pcs.

1400 at 40 0 C N4-4-1000-...S1(S15)-DC 119888

N4-4-1250-...S1(S15)-DC

N4-4-1400-...S1(S15)-DC

Incl. insulation plates and phase separator

190 at 70 0 C IP00 N2-4-...S1(S15)-DC NZM2-4-XKVI2P 1 pcs.

260 at 40 0 C 168586

Incl. cooling unit 260 at 70 0 C IP00 N2-4-...S1(S15)-DC NZM2-4-XKVI2P-K 1 pcs.

300 at 40 0 C 168587

400 at 70 0 C IP00 N3-400(500)-S1(S15)-DC NZM3-4-XKVI2P 1 pcs.

500 at 50 0 C 142269

Incl. cooling unit 500 at 65 0 C IP00 N3-500(550)-S1(S15)-DC NZM3-4-XKVI2P-K 1 pcs.

550 at 40 0 C 142270

Incl. cooling unit 1400 at 70 0 C IP00 N4-4-1400-S1(S15)-DC NZM4-4-XKV2P-K 1 pcs.

1500 at 65 0 C N4-4-1600-S1(S15)-DC 152553

1600 at 40 0 C

11



• Model contains parts for upper and lower row of switchgear side for 4 pole switches N...-S1(S15)-DC that are


• The links each connect two contacts in series




2-polig

(+ und -)

zweiseitig



I n

class

A

Incl. cover

190 at 70 0 C IP2X N2-4-...S1(S15)-DC NZM2-4-XKV2POU 1 pcs.

260 at 40 0 C 144070

Incl. cooling unit 230 at 70 0 C IP2X N2-4-...S1(S15)-DC NZM2-4-XKV2POU-K 1 pcs.

275 at 40 0 C 168588

400 at 70 0 C IP2X N3-320(400)-S1(S15)-DC NZM3-4-XKV2POU 1 pcs.

450 at 40 0 C 168589

Incl. cooling unit 400 at 70 0 C IP1X N3-400(500)-S1(S15)-DC NZM3-4-XKV2POU-K 1 pcs.

475 at 55 0 C 168590

475 at 40 0 C IP2X



260 at 40 0 C 168586


300 at 40 0 C 168587


475 at 40 0 C 142269

Incl. cooling unit 500 at 70 0 C IP00 N3-500(550)-S1(S15)-DC NZM3-4-XKVI2P-K 1 pcs.

525 at 40 0 C 142270

12



• Model contains parts for upper and lower row of switchgear side for 4 pole switches N...-S1(S15)-DC that are


• The links each connect one contact in series




1-polig

(+ und -)

zweiseitig



I n

class

A

Incl. cover

190 at 70 0 C IP2X N2-4-...S1(S15)-DC NZM2-4-XKV1P 1 pcs.

260 at 40 0 C 168591

Incl. cooling unit 230 at 70 0 C IP2X N2-4-...S1(S15)-DC NZM2-4-XKV1P-K 1 pcs.

275 at 40 0 C 168592

400 at 70 0 C IP2X N3-320(400)-S1(S15)-DC NZM3-4-XKV1P 1 pcs.

425 at 40 0 C 168593

Incl. cooling unit 400 at 70 0 C IP1X N3-400(500)-S1(S15)-DC NZM3-4-XKV1P-K 1 pcs.

475 at 55 0 C 168594

475 at 40 0 C IP2X



260 at 40 0 C 168595


300 at 40 0 C 168596


475 at 40 0 C 168597

Incl. cooling unit 490 at 70°C IP00 N3-500(550)-S1(S15)-DC NZM3-4-XKVI1P-K 1 pcs.

500 at 65°C 168598

525 at 40°C

13


Technical data

Switch-disconnectors 1000/1500 V DC N2-4-...-S1-DC N2-4-...-S15-DC N3-4-...-S1-DC

max. 300A max. 300A max. 550A

Rated operational voltage U e VDC 1000 1500 1000

Rated insulation voltage U i VDC 1000 1500 1000

Category of utilization DC-22A DC-22A DC-22A

Rated uninterrupted current with terminal jumpers

at 40 0 C I u A 300 300 550

at 65 0 C I u A 250 250 500

Rated operating current I e A 300 300 500

Rated short-time withstand current t = 1 s I cw kA 3,6 3,6 6,6

Rated conditional short-circuit current I q kA 15 - 15

With back-up fuse up to 1000 V A gR 315 - 630

Maximum operating frequency Ops/h 120 120 60

Lifespan

mechanical Operations 20000 20000 15000

(of which max. 50 %trip by N/U release)

electrical Operations 2500 2500 2000

For use in IT electrical power networks VDC 1000 - 1000

Lasttrennschalter 1000/1500 VDC N3-4-...-S15-DC N4-4-...-S1-DC N4-4-...-S15-DC

max. 550A max. 1600A max. 1600A

Rated operational voltage U e VDC 1500 1000 1500

Rated insulation voltage U i VDC 1500 1000 1500

Category of utilization DC-22A DC-22A DC-22A

Rated uninterrupted current with terminal jumpers

at 40 0 C I u A 550 1600 1600

at 65 0 C I u A 500 1500 1500

Rated operating current I e A 500 1500 1500

Rated short-time withstand current t = 1 s I cw kA 6,6 25 25

Rated conditional short-circuit current I q kA - - -

With back-up fuse up to 1000 V A gR - - -

Maximum operating frequencyit Ops/h 60 60 60

Lifespan

mechanical Operations 15000 10000 10000

(of which max. 50 %trip by N/U release)

electrical Operations 2000 500 500

For use in IT electrical power networks V DC - 1000 -

Notes: N...S1-DC can not be combined with withdrawable units and/or connection on rear.

N2...: Can not be combined with early-make auxiliary contacts NZM-...XHIV or box terminal.

14


Dimensions

Dimensions (mm)

Switch-disconnectors, 4 pole, N2-4

Jumper kit, NZM2-4-XKV...

À Blow out area, minimum clearance to other parts

Á Minimum clearance to adjacent parts

Switch-disconnectors, 4 pole, N3-4



Jumper kit, NZM3-4-XKV...

Jumper kit, NZM3-4-XKVI...

15


Dimensions

Switch-disconnectors, 4-polig, N4-4


< 690 V: 100mm

< 1500 V: 200mm


< 1000 V: 15mm

< 1500 V: 70mm


Jumper kit, NZM4-4-XKV2P

Jumper kit, NZM4-4-XKV2P-K

16

Photovoltaic - DC Disconnection

DC

DC switch-disconnector

DC switch-disconnector P-SOL 2-poles

• Rated operational voltage 1000 VDC

• Utilization category DC-21A

Rated op. current Ie Type designation Article No. Units per package

wa_sg05409, wa_sg04709

20A

30A

63A

P-SOL20 120934 1

P-SOL30 120935 1

P-SOL60 120936 1

Connection diagrams:

Unearthed system

PV array

Earthed system

PV inverter

DC switch-disconnector

DC switch-disconnector SOL 2-poles as pre-wired unit with protection

class II, degree of protection IP65


• Utilization category DC-21A

• Rated operational current Ie of 20, 30 or 63 A

• Several versions – plugs MC4 or cable glands available

• Versions for 2, 3 and 4 strings (INPUT) available

wa_sg00110

Ie INPUT OUTPUT Type designation Article No. Units per package

MC4 version

20A 2xMC4 1xMC4




SOL20/2MC4 120915 1

SOL20/4MC4 120916 1

SOL30/2MC4 120922 1

SOL30/4MC4 120923 1

Version with metric cable glands

20A 2xM12 1xM16

30A 2xM12 1xM16

SOL20/2MV 120919 1

SOL30/2MV 120926 1

SOL20/2MC4

SOL30/2MC4

SOL20/2MV

SOL30/2MV

SOL20/4MC4

SOL30/4MC4

17

Photovoltaic - DC String Protection

DC

DC string circuit-breaker

DC string circuit-breaker PKZ-SOL 2-poles


• Rated current In 4, 7, 12, 20, and 30 A

• For permissible string short-circuit currents Isc of 5 up to 22 A

Ie Isc Type designation Article No. Units per package

wa_sg05409

4A

1,6-3A

7A

2,6-5A

12A 5-9A

20A 9-15A

30A 15-22A

PKZ-SOL4 144069 1

PKZ-SOL7 144120 1

PKZ-SOL12 120937 1

PKZ-SOL20 120938 1

PKZ-SOL30 120939 1

Connection diagrams:


PV string


DC disconnection / PV inverter

18


DC

DC Switch-disconnector P-SOL

• Field of application:

DC-Disconnection in photovoltaic systems between

PV Array and Inverter to switch off the energy

• No polarity

• Any mounting position

• Spring work contacts

• Tested according to IEC/EN 60947-3, UL508

• Certificate TÜV-Rheinland

• Application acc. to IEC 60364-7-712 and IEC 62548

Connection diagram



Technical Data

P-SOL20 P-SOL30 P-SOL60

Electrical

Number of poles 2 2 2

Rated operational voltage U e 1000 VDC 1000 VDC 1000 VDC

Rated operational current I e 20 A 30 A 63 A

Rated short-circuit making capacity I cm 500 A 500 A 1500 A

Rated short-time withstand current 1sec. I cw 700 A 700 A 1500 A

Utilization category DC-21 A DC-21 A DC-21 A

Overvoltage category III III III

Rated impulse withstand voltage U imp 8 kV 8 kV 8 kV

Operating cycles electrical at U e and I e 1500 1500 1500

Internal resistance 6mΩ 5mΩ 3mΩ

Mechanical

Width 58 58 55

Height 93 93 140

Depth 76 76 160

Weight 265 g 265 g 920 g

Mounting quick fastening on DIN rail acc. to IEC/EN 60517 35 mm 35 mm 35 mm

Screw fastening

2xM4x18

Degree of protection IP20 IP20 IP20

Terminal capacity Flexible with end sleeve mm² 2x (1-6) 2x (1-6) 2x (1-35)

AWG 18-10 18-10 14-2

Tightening torque of terminal screws 1,7 Nm 1,7 Nm 3 Nm

Ambient temperature range -25°C to +60°C -25°C to +60°C -25°C to +60°C

Climatic resistance acc. to IEC 60068-2-78

Damp heat, constant

acc. to IEC 60068-2-30

Damp heat, cyclic

Pollution degree2 2 2

Operating cycles mechanical 100.000 100.000 100.000

Operating cycles mechanical per hour


DC

DC Switch-disconnector SOL as pre-wired unit


DC-Disconnection in photovoltaic systems between

PV Array and Inverter to switch off the energy

• Pre-wired unit ready for connection

• Lock-able in OFF-position with a padlock

• Any mounting position


• Tested according to IEC/EN 60947-3, UL508






SOL20

SOL30

Electrical

Number of poles 2 2

Rated operational voltage U e 1000 VDC 1000 VDC

Rated operational current I e 20 A 30 A

Rated short-circuit making capacity I cm 500 A 500 A

Rated short-time withstand current 1sec. I cw 700 A 700 A

Utilization category DC-21 A DC-21 A

Overvoltage category III III

Rated impulse withstand voltage U imp 8 kV 8 kV

Operating cycles electrical at U e and I e 1500 1500

Internal resistance 8mΩ 5mΩ

Mechanical

Weight 420 g 420 g

Degree of protection IP65 IP65

Ambient temperature range -25°C to +60°C -25°C to +60°C

Climatic resistance acc. to 60068-2-78


acc. to 60068-2-30


Pollution degree 3 3

Operating cycles mechanical 100.000 100.000


SOL20(30)

a

[mm]

MC4 234

MV 224

SOL20/2MC4

SOL30/2MC4

+ Strings

Input

- Strings

SOL20/2MV

SOL30/2MV

+ Strings

Input (M12)

- Strings

SOL20/4MC4

SOL30/4MC4

+ Strings

Input

- Strings

1 3 5

1 3 5

SOL20

SOL30

2 4 6

2 4 6

1 3 5

2 4 6

+ -

Output (M16)

+ -

Output

20


DC

DC-String Circuit Breaker PKZ-SOL


DC-Circuit breaker for string protection

in photovoltaic systems

• No polarity


• Tested according to IEC/EN 60947-2






PKZ-SOL4

PKZ-SOL7

PKZ-SOL12

PKZ-SOL20

PKZ-SOL30

Electrical

Number of poles 2

Rated operational voltage U e

900 VDC

Rated current I n

4 / 7 / 12 / 20 / 30 A

Thermal tripping characteristic

1.05 to 1.3 x I n

Electromagnetc tripping characteristic

6 x In

Rated ultimate short-circuit breaking capacity I cu

5 kA

Rated service short-circuit breaking capacity I cs

1.5 kA

Overvoltage category

III

Rated impulse withstand voltage U imp

8 kV

Operating cycles electrical at U e and I n 1500

Internal resistance

138 / 60 / 32 / 14 / 9 mΩ

Mechanical

Width 58

Height 93

Depth 76

Weight

265 g

Mounting quick fastening on DIN rail acc. to IEC/EN 60517 35 mm

Screw fastening

Degree of protection

IP20

Terminal capacity Flexible with end sleeve mm² 2x (1-6)

AWG 18-10

Tightening torque of terminal screws

1,7 Nm

Ambient temperature range

-25°C to +60°C

Climatic resistance acc. to IEC 60068-2-78


acc. to IEC 60068-2-30


Pollution degree 2

Operating cycles mechanical 100.000

Operating cycles mechanical per hour


DC

DC-String Circuit Breaker PKZ-SOL

Characteristic curve setting value - Short-circuit current

According to the design for IEC 62548-1, the tripping current for the circuit breaker must fall within a range of 1.4 to 2 times the value of the short-circuit current

of the PV modules, in order to protect the PV modules.

Since only the current values for the built-in overload tripping device can be plotted on the setting scale of the circuit breaker1), the correlation between the

tripping current for the safety device and the short-circuit current for the PV modules must be properly indicated for every point of the scale.

Tripping characteristic curve

String circuit breaker PKZ-SOL

35

Adjustment tool for string circuit breaker PKZ-SOL

tripping time

Setting Einstellwert value at the am Schutzschalter circuit breaker [A] [A]

30

25

20

15

10

5

PKZ-SOL12

PKZ-SOL7

PKZ-SOL20

PKZ-SOL30

PKZ-SOL4

0

0 5 10 15 20 25

Short-circuit Kurzschlussstrom current Solarmodul solar module [A] [A]

1) Norm IEC/EN 60947-2 (section 4.7.3) prohibits a direct specification

of the PV short-circuit current on the circuit breaker's setting scale,

whereby only the setting value for the response current may be

entered.


PKZ-SOL4

PKZ-SOL7

PKZ-SOL12

PKZ-SOL20

PKZ-SOL30

22

Photovoltaic - Surge Protection

AC

SPD-type T2 (Class C)

sg13309

Max. Cont. Op. Volt. U C I n (8/20)µs Type Designation Article No. Units per package

Plug-in surge arrester SPMT2PA, 1- to 4-pole

1pole 280VAC 1x20kA








1+1p – –

3+1p – –

SPMT2PA-280/1 131755 12 / 120

SPMT2PA-280/2 131756 1 / 60

SPMT2PA-280/3 131757 1 / 40

SPMT2PA-280/4 131758 1 / 30

SPMT2PA-335/1 131759 12 / 120

SPMT2PA-335/2 131760 1 / 60

SPMT2PA-335/3 131761 1 / 40

SPMT2PA-335/4 131762 1 / 30

SPMT2PA-1+NPE 131773 1 / 60

SPMT2PA-3+NPE 131774 1 / 30

SG13109

Inserts SPMT2PA for replacement

Insert 1-pole

Insert 280VAC

Insert 335VAC

Insert N-PE 260VAC

20kA

20kA

30kA

SPMT2PA-280 131778 4 / 120

SPMT2PA-335 131779 4 / 120

SPMT2PA-NPE 131783 4 / 120

Description Type designation Article No. Units per package

SG12809

Auxiliary Switch

for SPMT2PA ASAUXSC-SPM 131785 4 / 120

SG12909

Lead-through terminal for SPMT2PA

ASLTT-63 131784 12 / 120

23


AC

SPD-Type T2 (Class C), Plug-In Surge Arresters SPMT2PA


For the protection of photovoltaic systems against transient overvoltage

caused by indirect lightning stroke and switching operations.

• Test class II according to IEC 61643-1

• SPD-type T2 according to EN 61643-11

• Galvanic seperation in unearthed systems by means of a spark gap

• Types SPPT2PA-...-AX for remote message transmission of defective inserts



Inserts SPMT2PA -280 -335 -NPE

Electrical

SPD-type

Mechanical coding xT2 T3

xT2 T3 T2 y T3

Responding time < 25 ns < 25 ns < 100 ns

Voltage protection level at nominal discharge current / U oc < 1,4 kV < 1,6 kV < 1,5 kV

Voltage protection level at 5 kA (8/20) µs 1000 V 1200 V -

Maximum continuous operating voltage U c 280 VAC 335 VAC 260 VAC

Temporary overvoltage test value U T 350 VAC (5s) 415 VAC (5s) 12000 VAC (200ms)

Rated frequency 50/60 Hz 50/60 Hz 50/60 Hz

Open circuit voltage U oc 10 kV 10 kV 5 kV

Nominal discharge current (8/20) µs I n 20 kA 20 kA 40 kA

Charge Q at I n 0,57 As 0,57 As 1,14 As

Specific energy at I n 5,7 kJ/Ω 5,7 kJ/Ω 22,8 kJ/Ω

Maximum discharge current I max 40 kA 40 kA 60 kA

Follow current interrupt rating I fi – –

100 A eff

Permissible back-up fuse

Maximum short-circuit current


≤ 160 AgL

mMCT-C100

50 kA eff 20 kA eff

Mechanical

Frame size

45 mm

Device height

80 mm

Device width

17,5 mm per pole

Weight Base 1P, 1+1P, 2P, 3P, 3+1P, 4P

53/120/120/180/240/240 g

Weight Complete Devices 1P, 1+1P, 2P, 3P, 3+1P, 4P 110/201/220/330/412/440 g

Permitted ambient temperature

-40°C to +70°C

Degree of protection (built-in)

IP40

Upper and lower lift terminal capacity 4 - 25 mm 2

Upper and lower open mouthed terminals

for busbar thickness up to

1.5 mm

Tightening torque of terminal screws

2.4 - 3 Nm

Quick fastening on DIN rail according to IEC/EN 60715

Dimensions (mm) Application Examples SPMT2PA according to IEC 60364-5-53 Clause 534

SPMT2PA-280/4

SPMT2PA-3+NPE

SPMT2PA-

280/3

SPMT2PA-

1+NPE

ASLT

T-63

24


AC

SPD-type 2 (Class C), Surge Arresters SPMT2PA-1+NPE, SPMT2PA-3+NPE


For the protection of low voltage distribution systems against transient

overvoltage caused by indirect lightning stroke and switching operations.



• Auxiliary switch ASAUXSC-SPM for remote message transmission can be

mounted onto the device

• Suitable for busbar connection to EATON switchgear

• Type SPMT2PA-3+NPE:

consists of 1 base,

1 insert SPMT2PA-NPE and 3 inserts SPMT2PA-335

• Type SPMT2PA-1+NPE:

consists of 1 base,

1 insert SPMT2PA-NPE and 1 insert SPMT2PA-335


SPMT2PA-1+NPE

SPMT2PA-3+NPE

Electrical

SPD-type

T2 T3 T2 T3

Mechanical coding yx yxxx

Responding time L-N/N-PE/L-PE < 25ns/< 100ns/< 100ns < 25ns/< 100ns/< 100ns

Maximum continuous operating voltage U C L-N/N-PE 335VAC/260VAC 335VAC/260VAC

Temporary overvoltage test value U T (5 s) L-N 415 VAC 415 VAC

(200 ms) N-PE 1200 VAC 1200 VAC

Rated frequency 50/60 Hz 50/60 Hz

Nominal discharge current I n L-N/N-PE/L-PE 20 kA (8/20)µs 20 kA (8/20)µs

Voltage protection level U p at I n L-N/N-PE/L-PE ≤1600V/≤1500V/≤2050V ≤1600V/≤1500V/≤1900V

Maximum discharge current I max L-N/N-PE/L-PE 40 kA (8/20)µs 40 kA (8/20)µs

Follow current interrupt rating I fi N-PE 100 A r.m.s. 100 A r.m.s.

Permissible back-up fuse

≤ 160 AgL

mMCT-C100

Maximum short-circuit current

50 kA r.m.s. 20 kA r.m.s.


L1

L2

L3

x x x x

N

N

y

y

Mechanical

Mechanical coding of base yx yxxx

Frame size 45 mm 45 mm

Device height 80 mm 80 mm

Device width 35 mm 70 mm

Weight 201 g 412 g

Upper and lower lift terminal capacity 1 - 25 mm 2 1 - 25 mm 2

Open-mouthed terminals at both sides for busbar thickness up to 1.5 mm

1.5 mm

Tightening torque of terminal screws 2.4 - 3 Nm 2.4 - 3 Nm

Permitted ambient temperature -40°C to +70°C -40°C to +70°C

Mounting quick fastening on DIN rail IEC/EN 60715

Degree of protection (built-in) IP40 IP40


Application Examples

SPMT2PA-1+NPE SPMT2PA-3+NPE SPMT2PA-1+NPE SPMT2PA-3+NPE

SPMT2PA-NPE

SPMT2PA-335

SPMT2PA-NPE

SPMT2PA-335

25


DC

SPD-type T2 (Class C)

Max. Cont. Op. Volt. U C I n ( Type Designation Article No. Units per package

Plug-in Surge Arrester SPPT2PA for Photovoltaic application

SG11009

For earthed systems

600 V DC

1000 V DC

SPPT2PA-600-2PE 132663 1 / 60

SPPT2PA-1000-2PE 132664 1 / 60

with auxiliary switch

1000 V DC

SPPT2PA-1000-2PE-AX 132666 1 / 60

SG11309

For unearthed systems

600 V DC

1000 V DC

SPPT2PA-600-2+1PE 132661 1 / 40

SPPT2PA-1000-2+1PE 132662 1 / 40

with auxiliary switch

1000 V DC

SPPT2PA-1000-2+1PE-AX 132665 1 / 40

Inserts for replacement

600 V DC À

1000 V DC À

1100 V DC Á

SPPT2PA-600 132667 1

SPPT2PA-1000 132668 1

SPPT2PA-1100 132669 1

V OC

≤ U c

: Open circuit voltage of PV-Generator shall be equal or less than maximum

continuous operating voltage of Surge Protective Device (SPD) to prevent its

damage.

V OC . . . . . .Open circuit voltage of PV-Generator.

U C . . . . . . .Maximum continuous operating voltage of SPD.

Attention: Even at switched off DC-Disconnector system stays under high voltage!

Before mounting ensure de-energizing and check zero-potential.


SPPT2PA-600-2PE

SPPT2PA-1000-2PE(-AX)


SPPT2PA-600-2+1PE

SPPT2PA-1000-2+1PE(-AX)

L- L- L+

26


DC

SPD-type T2 (Class C), Plug-in Surge Arresters SPPT2PA-...-2PE







Connection diagrams

SPPT2PA-...-2PE


SPPT2PA-600-2PE

SPPT2PA-1000-2PE(-AX)

Electrical

Responding time ≤ 25 ns ≤ 25 ns

Maximum continuous operating voltage U C 600 V DC 1000 V DC

Rated frequency DC DC

Nominal discharge current I n 15 kA (8/20) µs 15 kA (8/20) µs

Voltage protection level U p ≤ 3 kV ≤ 5 kV

Residual voltage at 5 kA (8/20) µs ≤ 2.5 kV ≤ 4 kV

Maximum discharge current I max 30 kA (8/20) µs 30 kA (8/20) µs

Permissible back-up fuse – –

Maximum short-circuit current I sc 80 A 80 A

Residual current I PE ≤ 20 µA ≤ 20 µA

Mechanical


Device height 90 mm 90 mm (99 mm)

Device width 35.6 mm 35.6 mm

Weight 247 g 247 g (249 g)

Upper and lower lift terminal capacity

fine- / solid strand 4-25/4-35 mm 2 /AWG11-2 4-25/4-35 mm 2 /AWG11-2

Tightening torque of terminal screws 4.5 Nm 4.5 Nm

Permitted ambient temperature -40°C up to +80°C -40°C up to +80°C



Polution degree 2 2

Auxiliary switch

Electrical

Rated insulation voltage

Rated frequency

Switching contact

Minimum voltage per contact

Rated operational current

Min. admissible power

250 V

50/60 Hz

1 CO

5 V AC/DC

1.5 A / 250 V AC

1.5 A / 30 V DC

5 mA / 5 V

Mechanical

Terminal capacity

fine- / solid strand

Tightening torque

of terminal screws

1.5/1.5 mm 2 /AWG28-16

0.25 Nm


Application hints according to EN 50539-12

27


DC

SPD-type T2 (Class C), Plug-in Surge Arresters SPPT2PA-...-2+1PE






• Galvanic seperation in unearthed systems by means of a spark gap


Connection diagrams

SPPT2PA-...-2+1PE


SPPT2PA-600-2+1PE

SPPT2PA-1000-2+1PE(-AX)

Electrical

Responding time L+ -> L- / L -> PE ≤ 25 ns / ≤ 100 ns ≤ 25 ns / ≤ 100 ns

Maximum continuous operating voltage U C 600 V DC 1000 V DC

Rated frequency DC DC

Nominal discharge current I n 15 kA (8/20) µs 15 kA (8/20) µs

Voltage protection level U p L+ -> L- / L -> PE ≤ 3 kV / ≤ 3 kV ≤ 5 kV / ≤ 3 kV

Residual voltage at 5 kA (8/20) µs L+ -> L- / L -> PE ≤ 2.5 kV / ≤ 2 kV ≤ 4 kV / ≤ 2 kV

Maximum discharge current I max 30 kA (8/20) µs 30 kA (8/20) µs

Permissible back-up fuse – –

Maximum short-circuit current I sc 80 A 80 A

Residual current I PE ≤ 20 µA ≤ 20 µA

Mechanical


Device height 90 mm 90 mm (99 mm)

Device width 53.4 mm 53.4 mm

Weight 318 g 318 g (323 g)

Upper and lower lift terminal capacity

fine- / solid strand 4-25/4-35 mm 2 /AWG11-2 4-25/4-35 mm 2 /AWG11-2

Tightening torque of terminal screws 4.5 Nm 4.5 Nm

Permitted ambient temperature -40°C up to +80°C -40°C up to +80°C



Polution degree 2 2

Auxiliary switch

Electrical

Rated insulation voltage

Rated frequency

Switching contact

Minimum voltage per contact

Rated operational current

Min. admissible power

250 V

50/60 Hz

1 CO

5 V AC/DC

1.5 A / 250 V AC

1.5 A / 30 V DC

5 mA / 5 V

Mechanical

Terminal capacity

fine- / solid strand

Tightening torque

of terminal screws

1.5/1.5 mm 2 /AWG28-16

0.25 Nm


Application hints according to EN 50539-12

28

CS Wall-Mounted Sheet Steel Enclosures with Mounting Plate

CS Wall-Mounted Sheet Steel Enclosures with Mounting Plate, IP66

Dimensions (mm) Designation Article No. Units per package

Height A Width B Depth C

VT28910

VT21110

300 300 150 CS-33/150 111648 1 pcs.

300 300 200 CS-33/200 111649 1 pcs.

300 400 200 CS-34/200 111680 1 pcs.

400 300 150 CS-43/150 111681 1 pcs.

400 300 200 CS-43/200 111682 1 pcs.

400 400 150 CS-44/150 111683 1 pcs.

400 400 200 CS-44/200 111684 1 pcs.

400 600 200 CS-46/200 111685 1 pcs.

400 600 250 CS-46/250 111686 1 pcs.

400 600 300 CS-46/300 111687 1 pcs.

500 400 150 CS-54/150 111688 1 pcs.

500 400 200 CS-54/200 111689 1 pcs.

500 400 250 CS-54/250 111690 1 pcs.

500 500 250 CS-55/250 111691 1 pcs.

600 400 150 CS-64/150 111692 1 pcs.

600 400 200 CS-64/200 111693 1 pcs.

600 400 250 CS-64/250 111694 1 pcs.

600 500 150 CS-65/150 111695 1 pcs.

600 500 200 CS-65/200 111696 1 pcs.

600 500 250 CS-65/250 111697 1 pcs.

Universal Locks

Description Designation Article No. Units per package

VT12010

Identical locking, lock cy lin der LC-ZSBIT-CS 133104 1

with 2 keys

Ease-of-use Rotary Handle

VT12110


Retro-fitting set PHZ-A-ADD-ON 133106 1

Profile Half-Cylinder for Ease-of-use Handles


VT33610

Identical locking

Different locking

PHZ-E10/30-GS 138574 1

PHZ-E10/30-VS 138575 1

Material for Fixing on a Mast

Dimensions Enclosure Width (mm) Designation Article No. Units per package

VT33510

300

400

500

600

800

MAST-FIT-CS 140478 1

For more products, please refer to our Industry main catalogue

29

Technical Specifications


General information

Standards and regulations IEC/EN 60529, IEC 62262, IEC/EN 62208

RoHS

According to Directive 2002/95/EG of the European Parliament and Council

Climatic resistance Moist heat, constant according to IEC 60068-2-78,

Moist heat, periodic according to IEC 60068-2-30

Ambient temperature °C -40 to +70

Degree of protection

IP66

Degree of protection with ventilation panels

IP23

Set-up locations

Indoor/outdoor

Incorporation grid mm 25

Dissipated power loss

See separate table

Material

Material

Sheet steel

Surface finish

Structured powder-coating on Polyester base

Colour

RAL 7035, light grey

Surface

Slightly structured

Degree of gloss

Glossy

Body mm ≤ CS-65/...: 1.2; ≥ CS-66/...: 1.5

Mounting plate mm 2; as of height 800 x width 400mm: 3

Door mm ≤ CS-43/...: 1.0; ≤ CS-64/...: 1.2; ≤ CS-88/...: 1.5; ≤ CS-1212/...: 2.0

Bottom panel mm 1.5

Material properties

Mechanical

Shock-resistance rating IK09 according to EN 62262

Assembly weight - entire cabinet


Assembly weight - door


Assembly weight - mounting plate


Assembly weight - wall-mounting brackets


Description/Basic equipment

Type of construction

Folded and seam-welded, 2 M6 threaded bolts are included for protective

conductor

connection inside the enclosure

Rear panel

9 mm holes for wall-fixing

Side panels

No holes

Top panel

No holes

Bottom panel

No holes, foam sealant, removable for F3A-... flanges or for customized

solutions

Mounting plate

Basic equipment, sheet steel, sendzimir zinc-plated. 15 mm clearance to rear

panel. Mounted onto M8 copper thread-welding bolt. Therefore an additional

protective conductor connection is not compulsory.

Door

1 M6 thread-welding bolt for protective conductor connections in the door.

Where electrical operating material needs to be integrated in the

door, a consistent and permanent protective conductor connection

needs to be established by means of a protective conductor cable.

Please use the thread-welding bolts on the door and on the side

panel of the body as connecting points.

Door hinges

Right side, can be reversed on-site

Door opening angle ° 120

Locking system

Metal turnbuckle. standard lock. 3 mm two-way key-bit.

Locks Number See Ordering Section

Fixing on a mast

MAST-FIT-CS

30

Dimensions

Dimensions Enclosure

Dimensions Doors

Type a b c t1 t2 t3 t4

CS-33/150 300 300 150 112 232 80 200

CS-33/200 300 300 200 172 262 140 230

CS-34/200 300 400 200 172 332 140 300

CS-43/150 400 300 150 112 232 140 200

CS-43/200 400 300 200 172 262 140 230

CS-44/150 400 400 150 112 332 140 300

CS-44/200 400 400 200 172 332 140 300

CS-46/200 400 600 200 172 532 140 500

CS-46/250 400 600 250 172 532 140 500

CS-46/300 400 600 300 172 532 140 500

CS-54/150 500 400 150 112 332 80 300

CS-54/200 500 400 200 172 332 140 300

CS-54/250 500 400 250 172 332 140 300

CS-55/250 500 500 250 172 432 140 400

CS-64/150 600 400 150 112 332 80 300

CS-64/200 600 400 200 172 332 140 300

CS-64/250 600 400 250 172 332 140 300

CS-65/150 600 500 150 112 332 80 300

CS-65/200 600 500 200 172 432 140 400

CS-65/250 600 500 250 172 432 140 400

Enclosure Door

Height Width Height Width

250 200 248 197,5

300 200 298 197,5

300 300 298 297,5

300 400 298 397,5

400 300 398 297,5

400 400 398 397,5

400 600 398 597,5

500 400 498 397,5

500 500 498 497,5

600 400 598 397,5

600 500 598 497,5

Mounting Plates

MPP, MPL

Type Mounting Plate

Height Width

CS-33/150 270 250

CS-33/200 270 250

CS-34/200 270 350

CS-43/150 370 250

CS-43/200 370 250

CS-44/150 370 350

CS-44/200 370 350

CS-46/200 370 550

CS-46/250 370 550

CS-46/300 370 550

Type Mounting Plate

Height Width

CS-54/150 470 350

CS-54/200 470 350

CS-54/250 470 350

CS-55/250 470 450

CS-64/150 570 350

CS-64/200 570 350

CS-64/250 570 350

CS-65/150 570 450

CS-65/200 570 450

CS-65/250 570 450

a, b = Gehäusemaße

CS Wall-mounted Enclosure with door and blind flanges

31

CI Insulated Enclosures

Basic enclosures, IP65 (Apertures and Bases)

Lockable enclosure covers without openings

• Two or four lockable cover fasteners, diagonal with cylinder lock

• Cylindrical locks, uniformly locking

• Two diagonal lead-sealable cover locks. When also replacing all DV...-CI

with DVZ...-CI, the sealing function is not avaliable

• Equipment supplied: gasket, key

Dimensions Mounting For use Number Designation Units per

Width Height depth with Cylindrical Article No. package

mm mm mm locks

Tansparent cover RAL7032

0423_00329185.eps

187,5 250 125 U-CI23... 2 D125-CI23-RAL7032-DVZ 4

138526

250 150 U-CI23... 2 D150-CI23-RAL7032-DVZ 4

138527

375 250 125 U-CI43... 2 D125-CI43-RAL7032-DVZ 2

138528

150 U-CI43... 2 D150-CI43-RAL7032-DVZ 2

138529

200 U-CI43... 2 D200-CI43-RAL7032-DVZ 2

138530

375 125 U-CI44... 2 D125-CI44-RAL7032-DVZ 2

138531

150 U-CI44... 2 D150-CI44-RAL7032-DVZ 2

138532

200 U-CI44... 2 D200-CI44-RAL7032-DVZ 2

138533

250 U-CI44... 2 D250-CI44-RAL7032-DVZ 2

138534

500 200 U-CI45... 2 D200-CI45-RAL7032-DVZ 2

138535

750 200 U-CI48... 4 D200-CI48-RAL7032-DVZ 2

138536

750 250 U-CI48... 4 D250-CI48-RAL7032-DVZ 2

138537

Individual Enclosures Bases X

• Seitenwände glatt, ohne Vorprägungen

Dimensions Designation Article No. Units per package

Width

Height

mm

mm

187,5 250 U-CI23X 057909 1

375 250 U-CI43X 062655 1

375 375 U-CI44X 067401 1

375 500 U-CI45X 098470 1

Distribution board enclosure - Bases

• Sides closed, but with full area knockout

• Open top and bottom

Dimensions Designation Article No. Units per package

Width

Height

mm

mm

375 750 U-CI48 083880 1

A wider range of different enclosure covers, locking mechanisms

for the covers and any accessories you may need are presented in

our Industry main catalogue.

32



CI23... CI43... CI44... CI45... CI48...

General

Standards IEC/EN 60529

EN 50262

DIN 43656

DIN 43660

Climatic proofing Damp heat, constant, to IEC 60068-2-78

Damp heat, cyclic, to IEC 60068-2-30

Ambient temperature °C -40 at +80

Protection type

IP65

Radiated heat dissipation

next page


Material

Base

cover

Surface treatment

Color

Base

Cover

Glass-fibre reinforced polycarbonate

Non-reinforced polycarbonate

Corrosion-resistant

RAL 7032, pebble grey

Transparent, opaque or RAL 7032, pebble grey


Electrical

Creepage resistance to IEC 60112

Base

KB160, KC175

Cover

KB100, KC200

Surface treatment to IEC 60093 Ω x 10 13 > 1

Dielectric strength to IEC 60243-1 kV/mm 30

Thermal

Continuous thermal stability

Housing °C -40 – 120

Enclosure bolt °C 85

Sealing °C 80

Mechanical

IK code to EN 50102

Please enquire

Load bearing capacity kg/m 2 5 10 20 30 40

Chemical resistance

Resistant

Acids < 10 %, mineral oil, alcohol, petrol, grease, saline solution

Partially resistant Acids > 10 %

Non-resistant

Alkalis, paraffin

Atmospheric

Saline spray IEC 60068-2-11

UV resistance

Beneath protective canopy

Water absorption to DIN EN ISO 62 % 0.29

Flammability characteristics

Glow wire to VDE 0471 Part 2 °C 960

UL

Base

UL94V1

Cover

UL94V2

Halogen free

yes (lower section and cover)

33


Dimensions


Enclosures CI23...


225

250

147

177

25

162.5

187.5

25

t

27

92

27

92

225

250

147

177

25

350

375

25

t

27

92

27

92

84.5

t = 150/175 mm

272

t = 150/175/225 mm

114.5

302



350

375

272

302

25

25

27

350

92

375

t

27

92

475

500

25

147

177

350

375

25

27

92

t

t = 150/175/225/275 mm

t = 225 mm

27

92

272

302

272

302


725

272

302

27

92

25

750

375

272

302

t = 225/275 mm

350

375

25

t

27

92

34

Photovoltaic - Inverter

±

~

Three-phase PV-Inverter grid connected I3G2O

• Transformerless Design

• With MC4 compatible plugs

• Maximum efficiency ≥97.5%

• Euro efficiency ≥97%

• MPPT efficiency >99%

• Lead-free, RoHS complied

• Graphical LCD display

• RCMU (GFCI) embedded

• Works with monitoring software

• ENS meets VDE 0126-1-1

• 2 MPPT-tracker

• IP65, Outdoor

• Grid interface regulation according VDE-AR-N 4105, VDE 0126-1-1/A1 (Germany), ENEL

Guide 2012 (Italy), CEI 0-21, RD1663 (Spain), G83/1-1, G59 Issue 2 (UK) and BDEW(MVD)

sg00210

AC Output Type Designation Article No. Units per package

Outdoor series IP65

10 kW

15 kW

20 kW

I3G2O-10kW/2 167372 1

I3G2O-15kW/2 167373 1

I3G2O-20kW/2 167374 1

Explanactions:

MPP . . . . . . Maximum Power Point.

ENS . . . . . . Two independent main monitoring units with allocated all-pole switching devices.

GFCI . . . . . Ground Fault Current Interrupter.

RCMU . . . . Residual Current Monitoring Unit.

MC4 . . . . . . Multi Contact 4

35

Photovoltaic - Inverter

Three-phase PV-Inverter grid connected outdoors I3G2O


For use with mono- and polycrystalline PV-modules to build up a (light)

commercial photovoltaic system

• Transformerless design

• Maximum efficiency ≥97.5%

• ENS acc. to VDE 0126-1-1 integrated

• RCMU acc. to VDE 0126-1-1 integrated

• Application acc. to IEC 62109-1(2010), EN 62109-1:2011


I3G2O

±

~


I3G2O-10kW/2 I3G2O-15kW/2 I3G2O-20kW/2

Electrical

DC Max. DC power 10500 W 15750 W 21000 W

± Max. DC voltage 1000 VDC 1000 VDC 1000 VDC

~ MPP voltage range 350-850 VDC 400-850 VDC 450-850 VDC

Working voltage range 250-1000 VDC 250-1000 VDC 250-1000 VDC

Nominal DC voltage 720 VDC 720 VDC 720 VDC

Max. input current 16x2 ADC 20x2 ADC 23x2 ADC

MPP Tracker 2 2 2

±

AC Output power 10 kW / 10 kVA 15 kW / 15 kVA 20 kW / 20 kVA

Operating voltage 230/400 VAC ±20% 230/400 VAC ±20% 230/400 VAC ±20%

~ Operating frequency 50/60 Hz 50/60 Hz 50/60 Hz

Current THD < 3% < 3% < 3%

Nominal AC current 14.5 A 21.7 A 29 A

Max. AC current 16 A 24 A 30 A

SYSTEM Max. efficiency ≥ 97.5% ≥ 97.5% ≥ 97.5%

± Euro efficiency ≥ 97% ≥ 97% ≥ 97%

~ Stand-by power ≤ 1 W ≤ 1 W ≤ 1 W

Overvoltage category III III III

Degree of protection IP65 IP65 IP65

Operating temperature -20°C to +60°C -20°C to +60°C -20°C to +60°C

Humidity (condensing) 0-100% 0-100% 0-100%

Accustic noise level ≤ 55 dBA ≤ 55 dBA ≤ 55 dBA

Comm. interface

USB B type (RS485 optional)

Display

LCD / 128 x 64 pixels

Mechanical

W x H x D [mm] 548x565x297 548x565x297 548x565x297

T1 [mm] 636.2 636.2 636.2

Weight [kg]

Controlling & Switching


Basic devices up to 170 A

Conventional Can be combined AC operation DC operation

thermal with auxiliary Designation Designation

current I th = I e contact Article No. Article No.

open

AC-1 at 60 o C

I th =I e

A

0389_00178013_0

20 DILM32-XHI... DILM12-10(230V50HZ) DILM12-10(24VDC)

DILA-XHI(V).. 276830 276845

40 DILM32-XHI... DILM32-10(230V50HZ) DILM32-10(RDC24)

DILA-XHI(V).. 277260 277274

DILM32-XHI11-S

80 DILM150-XHI(V)... DILM65(230V50HZ) DILM65(RDC24)

DILM1000- 277894 277908

XHI(V)..

160 DILM150-XHI(V)... DILM150(RAC240) DILM150(RDC24)

DILM1000- 239588 239591

XHI(V)..

Contactors DILM, DILH

Comfort devices greater than 150 A

Conventional Designation Article No.

thermal

Article No.

current I th = I e

open

AC-1 at 60 o C

I th =I e

A

0389_00178013_0

315 DILM225A/22(RAC240) 139547

350 DILM300A/22(RA250) 139556

700 DILM500/22(RA250) 208213

1400 DILH1400/22(RAW250) 272441

37

Controlling & Switching


• IEC60947-4-1

• Contacts according to EN50012


DILM12 DILM32 DILM65 DILM150 DILM225 DILM300 DILM500 DILH1400

General

Lifespan, mechanical

AC operated Operations x10 6 10 10 10 10 10 10 7 5

DC operated Operations x10 6 10 10 10 10 10 10 7 5

Ambient temperature

open °C -25 - 60 -25 - 60 -25 - 60 -25 - 60 -25 - 60 -25 - 60 -25 - 60 -25 - 60

enclosed °C -25 - 40 -25 - 40 -25 - 40 -25 - 40 -25 - 40 -25 - 40 -25 - 40 -25 - 40

storage °C -40 - 80 -40 - 80 -40 - 80 -40 - 80 -40 - 80 -40 - 80 -40 - 80 -40 - 80

Magnet systems

Power consumption of the coil

in a cold state and 1.0 x U c

50HZ Pick-up VA 24 52 149 180 210 380 450 800

50Hz Sealing VA 3.4 7.1 16 3.1 2.6 4.3 4.3 7.5

DC operated Pick-up W 4.5 12 24 149 180 250 350 700

DC operated Sealing W 4.5 0.5 0.5 2.1 2.1 3.3 3.3 6.5

38

Grid & systems protection


Combined Grid & Systems Protection (IP 65 degree of protection)

Type designation NAS63-CI-1 NAS80-CI-1 NAS125-CI-1-K95 NAS160-CI-1-K95

Article No. 168106 168107 168110 168111

Rated output kVA 43 55 86 100

Rated operating voltage V 230/400 230/400 230/400 230/400

Rated current AC-1 A 63 80 125 160

Power consumption for Pick-up

Monitoring relay VA 5 5 5 5

2 contactors VA 90 90 360 360

Power consumption while Holding

Monitoring relay W 5 5 5 5

2 contactors VA/W 3/3 3/3 6,2/4,2 6,2/4,2

Own consumption kWh/a 70 70 98 98

Total breaking time (incl.

protective grid & systems) ms < 150 < 150 < 150 < 150

Ambient temperature °C -20 ... + 40 -20 ... + 40 -20 ... + 40 -20 ... + 40

Making time % ED 100 100 100

Max. cross section of connections Contactors Terminals

Feindrähtig mit Aderendhülse mm² 35 (Cu) 95 (Cu)

Mehrdrähtig mm² 50 (Cu) 95 (Cu)

Sektorleiter, eindrähtig mm² - 70 (AI)

Sektorleiter, mehrdrähtig mm² - 95 (Cu)

PE-Klemmen

Fine-wired with wire end mm² 50 (Cu) 95 (Cu)

Multi-wired mm² 50 (Cu) 95 (Cu)

Sector conductor, single-wired mm² - 70 (AI)

Sector conductor, multi-wired mm² - 95 (Cu)

PE terminals UFR1001E (made by ZIEHL) integrated UFR1001E (made by ZIEHL) integrated

Coupled switchgear

Style

4-pole contactors

Type designation DILMP63 (RAC240) DILMP80 (RAC240) DILMP125 (RAC240) DILMP160 (RAC240)

Article No. 167512 167513 109905 109915

Making capacity A 560 700 1120 1330

Breaking capacity A 400 500 800 950

Short-circuit protection A (gG) 125 160 250 250

Non-influenced

short-circuit current kA 100 100 100 100

Open time ms 45 45 40 40

< >

374

< >

150

>

>

565

940

<

<

>

175

>

<
