1.0 Material Acoustic Properties

Material

Logitudinal wave

Shear wave

Z Acoustic

mm/μs

mm/μs

Impedence

Acrylic resin

2.74

1.44

3.23

(Perspex)

Steel - SS 300

5.613

3.048

44.6

Series

Steel - SS 400

5.385

2.997

41.3

Series

Steel 1020

5.893

3.251

45.4

Steel 4340

5.842

3.251

45.6

http://www.ndtcalc.com/utvelocity.html

2.0 Ultrasonic Formula

http://www.ndt-ed.org/GeneralResources/Calculator/calculator.htm

Ultrasonic Formula

Ultrasonic Formula

α = Transducer radius

3.0 Properties of Acoustic Plane Wave

Wavelength, Frequency and Velocity

Among the properties of waves propagating in isotropic solid materials are

wavelength, frequency, and velocity. The wavelength is directly proportional

to the velocity of the wave and inversely proportional to the frequency of the

wave. This relationship is shown by the following equation.

4.0 The Speed of Sound

Hooke's Law, when used along with Newton's Second Law, can explain a few

things about the speed of sound. The speed of sound within a material is a

function of the properties of the material and is independent of the amplitude

of the sound wave. Newton's Second Law says that the force applied to a

particle will be balanced by the particle's mass and the acceleration of the the

particle. Mathematically, Newton's Second Law is written as F = ma. Hooke's

Law then says that this force will be balanced by a force in the opposite

direction that is dependent on the amount of displacement and the spring

constant (F = -kx). Therefore, since the applied force and the restoring force

are equal, ma = -kx can be written. The negative sign indicates that the force

is in the opposite direction.

F= ma = -kx

What properties of material affect its speed of sound?

Of course, sound does travel at different speeds in different materials. This is

because the (1) mass of the atomic particles and the (2) spring constants are

different for different materials. The mass of the particles is related to the

density of the material, and the spring constant is related to the elastic

constants of a material. The general relationship between the speed of sound

in a solid and its density and elastic constants is given by the following

equation:

V is the speed of sound

Eleatic constant

→ spring constants

Density

→ mass of the atomic particles

Where V is the speed of sound, C is the elastic constant, and p is the material

density. This equation may take a number of different forms depending on the

type of wave (longitudinal or shear) and which of the elastic constants that are

used. The typical elastic constants of a materials include:

• Young's Modulus, E: a proportionality constant between uniaxial stress

and strain.

• Poisson's Ratio, n: the ratio of radial strain to axial strain

• Bulk modulus, K: a measure of the incompressibility of a body subjected to

hydrostatic pressure.

• Shear Modulus, G: also called rigidity, a measure of a substance's

resistance to shear.

• Lame's Constants, l and m: material constants that are derived from

Young's Modulus and Poisson's Ratio.

E/N/G

5.0 Attenuation

The amplitude change of a decaying plane wave can be expressed as:

In this expression A o is the unattenuated amplitude of the propagating wave

at some location. The amplitude A is the reduced amplitude after the wave

has traveled a distance z from that initial location. The quantity α is the

attenuation coefficient of the wave traveling in the z-direction. The α

dimensions of are nepers/length, where a neper is a dimensionless

quantity. The term e is the exponential (or Napier's constant) which is equal

to approximately 2.71828.

http://www.ndt.net/article/v04n06/gin_ut2/gin_ut2.htm

Spreading/ Scattering/ adsorption (reflection is a form of scaterring)

Adsoprtion

Scaterring

Spreading

Scaterrring

Attenuation can be determined by evaluating the multiple backwall reflections

seen in a typical A-scan display like the one shown in the image at the bottom.

The number of decibels between two adjacent signals is measured and this

value is divided by the time interval between them. This calculation produces

a attenuation coefficient in decibels per unit time Ut. This value can be

converted to nepers/length by the following equation.

Where v is the velocity of sound in meters per

second and Ut is in decibels per second.

Amplitude at distance Z

Where v is the velocity of sound in meters per second and Ut is in decibels

per second (attenuation coefficient).

α is the attenuation coefficient of the wave traveling in the z-direction. The

α dimensions of are nepers/length (nepers constant).

Attenuation is generally proportional to the square of sound frequency.

Quoted values of attenuation are often given for a single frequency, or an

attenuation value averaged over many frequencies may be given. Also, the

actual value of the attenuation coefficient for a given material is highly

dependent on the way in which the material was manufactured. Thus, quoted

values of attenuation only give a rough indication of the attenuation and

should not be automatically trusted. Generally, a reliable value of attenuation

can only be obtained by determining the attenuation experimentally for the

particular material being used.

Attenuation ∝ Frequency 2 (f ) 2

Which U t ?

U 0 t , A 0 o

U 1 t , A 1 o , α 1

1 1

7.0 Acoustic Impedance

Sound travels through materials under the influence of sound pressure.

Because molecules or atoms of a solid are bound elastically to one

another, the excess pressure results in a wave propagating through the

solid.

The acoustic impedance (Z) of a material is defined as the product of its

density (p) and acoustic velocity (V).

Z = pV

Acoustic impedance is important in:

1. the determination of acoustic transmission and reflection at the boundary

of two materials having different acoustic impedances.

2. the design of ultrasonic transducers.

3. assessing absorption of sound in a medium.

The following applet can be used to calculate the acoustic impedance for any

material, so long as its density (p) and acoustic velocity (V) are known. The

applet also shows how a change in the impedance affects the amount of

acoustic energy that is reflected and transmitted. The values of the reflected

and transmitted energy are the fractional amounts of the total energy incident

on the interface. Note that the fractional amount of transmitted sound energy

plus the fractional amount of reflected sound energy equals one. The

calculation used to arrive at these values will be discussed on the next page.

http://www.ndt-ed.org/EducationResources/CommunityCollege/Ultrasonics/Physics/applet_2_6/applet_2_6.htm

Reflection/Transmission Energy as a function of Z

Reflection and Transmission Coefficients (Pressure)

• This difference in Z is commonly referred to as the impedance

mismatch.

• The value produced is known as the reflection coefficient. Multiplying

the reflection coefficient by 100 yields the amount of energy reflected as a

percentage of the original energy.

• the transmission coefficient is calculated by simply subtracting the

reflection coefficient from one.

Ipedence

mismatch

Reflection coefficient

Using the above applet, note that the energy reflected at a water-stainless

steel interface is 0.88 or 88%. The amount of energy transmitted into the

second material is 0.12 or 12%. The amount of reflection and transmission

energy in dB terms are -1.1 dB and -18.2 dB respectively. The negative sign

indicates that individually, the amount of reflected and transmitted energy is

smaller than the incident energy.

If reflection and transmission at interfaces is

followed through the component, only a small

percentage of the original energy makes it back

to the transducer, even when loss by attenuation

is ignored. For example, consider an immersion

inspection of a steel block. The sound energy

leaves the transducer, travels through the water,

encounters the front surface of the steel,

encounters the back surface of the steel and

reflects back through the front surface on its way

back to the transducer. At the water steel

interface (front surface), 12% of the energy is

transmitted. At the back surface, 88% of the

12% that made it through the front surface is

reflected. This is 10.6% of the intensity of the

initial incident wave. As the wave exits the part

back through the front surface, only 12% of 10.6

or 1.3% of the original energy is transmitted back

to the transducer.

Practice Makes Perfect

Following are the data:

Q1: What is the percentage of initial incident sound wave that will reflected

from the water/Aluminum interface when the sound first enter Aluminum?

R= (Z 1 -Z 2 ) 2 / (Z 1 +Z 2 ) 2 = (0.149-1.72) 2 /(0.149+1.72) 2

R= 0.707, Answer= 70.7%

Q2: What is the percentage of sound energy that will finally reenter the water

after reflected from the backwall of Aluminum? (Do not consider material

attenuation and other factors)

Answer: 6%

0.706 – initial Back wall

0.2934

0.207x 0.2934=0.0609

Second Backwall echo

0.2934x 0.706 =

0.207

8.0 Snell’s Law

Snell's Law holds true for shear waves as well as longitudinal waves and can

be written as follows

=

Where:

VL1 is the longitudinal wave velocity in material 1.

VL2 is the longitudinal wave velocity in material 2.

VS1 is the shear wave velocity in material 1.

VS2 is the shear wave velocity in material 2.

Snell’s Law

http://education-portal.com/academy/lesson/refraction-dispersion-definition-snells-law-index-of-refraction.html#lesson


5. For an ultrasonic beam with normal incidence, the reflection coefficient is

given by:

(a) [(Z 1 +Z 2 ) 2 ]/[(Z 1 -Z 2 ) 2 ]

(b) (Z 1 +Z 2 )/(Z 1 -Z 2 )

(c) [(4) (Z 1 )(Z 2 )]/[(Z 1 +Z 2 ) 2 ]

(d) [(Z 1 -Z 2 ) 2 ]/[Z 1 +Z 2 ) 2 ]

6. For an ultrasonic beam with normal incidence the transmission coefficient

is given by:

(a) [(Z 1 +Z 2 ) 2 ]/[(Z 1 -Z 2 ) 2 ]

(b) (Z 1 +Z 2 )/(Z 1 -Z 2 )

(c) [(4) (Z 1 )(Z 2 )]/[(Z 1 +Z 2 ) 2 ]

(d) [(Z 1 -Z 2 ) 2 ]/[Z 1 +Z 2 ) 2 ]

Practice Made Perfect

7. Snell's law is given by which of the following:

(a) (Sin A)/(Sin B) = VB/VA

(b) (Sin A)/(Sin B) = VA/VB

(c) (Sin A)/ VB = V(Sin B)/VA

(d) (Sin A)[VA] = (Sin B)[ VB]

8. Snell's law is used to calculate:

(a) Angle of beam divergence

(b) Angle of diffraction

(c) Angle of refraction

(d) None of the above


9. Calculate the refracted shear wave angle in steel [VS = 0.323cm/microsec]

for an incident longitudinal wave of 37.9 degrees in Plexiglas [VL = 0.267cm/

microsec]

(a) 26 degrees

(b) 45 degrees

(c) 48 degrees

(d) 64 degrees

10. Calculate the refracted shear wave angle in steel [VS = 0.323cm/microsec]

for an incident longitudinal wave of 45.7 degrees in Plexiglas [VL = 0.267cm/

microsec]


(b) 45.7 degrees


(d) 70 degrees


11. Calculate the refracted shear wave angle in aluminium [VS = 0.31cm/

microsec] for an incident longitudinal wave of 43.5 degrees in Plexiglas [VL =

0.267cm/microsec]




(d) 68 degrees

12. Calculate the refracted shear wave angle in aluminium [VS =

0.31cm/microsec] for an incident longitudinal wave of 53 degrees in Plexiglas

[VL = 0.267cm/microsec]




(d) 68 degrees

9.0 S/N Ratio

The following formula relates some of the variables affecting the signal-tonoise

ratio (S/N) of a defect:

FOM: Factor of merits at center frequency

The following formula relates some of the variables affecting the signal-tonoise

ratio (S/N) of a defect:

Sound Volume: Area x pulse length Δt

Material properties

Flaw geometry at center frequency:

Figure of merit FOM and

amplitudes responds

10. Near/ Far Fields

http://miac.unibas.ch/PMI/05-UltrasoundImaging.html

where α is the radius of the transducer and λ the wavelength.

For beam edges at null condition K=1.22

Modified Near Zone

T Perspex

Modified Z f

Example: Calculate the modified Near Zone for;

• 5 MHz shear wave transducer

• 10mm crystal

• 10 mm perspex wedge

Perspex L-wave: 2730 m/s

Steel S-wave: 3250 m/s

Steel L-wave: 5900 m/s

Modified NZ= (0.01 2 x f) / (4v) – 0.01(2730/3250)

=0.0300m

= 30mm

Apparent Near Zone distance

11.0 Focusing & Focal Length

http://www.olympus-ims.com/en/ndt-tutorials/flaw-detection/beam-characteristics/

The focal length F is determined by following equation;

Where:

F = Focal Length in water

R = Curvature of the focusing len

n = Ration of L-velocity of epoxy to L-velocity of water

12.0 Offset of Normal probe above circular object

θ 1

V 1

θ 1R

θ 2 V 2

Calculate the offset for following conditions:

Aluminum rod being examined is 6" diameter, what is the off set needed for (a)

45 refracted shear wave (b) Longitudinal wave to be generated?

(L-wave velocity for AL=6.3x10 5 cm/s, T-wave velocity for AL=3.1x10 5 cm/s,

Wave velocity in water=1.5X10 5 cm/s)

Question (a)

Question (b)

13.0 “Q” Factor

3dB down

14.0 Inverse Law and Inverse Square Law

For a small reflector where the size of reflector is smaller than the beam width,

the echoes intensity from the same reflector varies inversely to the square of

the distance.

5cm

7.5cm

75% FSH 33% FSH

Inverse Square Law

http://www.cyberphysics.co.uk/general_pages/inverse_square/inverse_square.htm

Inverse Law:

For large reflector, reflector greater than the beam width, e.g. backwall

echoes from the same reflector at different depth; the reflected signal

amplitude varies inversely with the distance.

10cm

7.5cm

DGS Distance Gain Sizing

Y-axis shows the

Gain

size of reflector is given as

a ratio between the size of

the disc and the size of

the crystal.

X-axis shows the Distance from the probe in # of Near Field

– Distance Gain Size is a method of setting sensitivity or assessing the signal

from an unknown reflector based on the theoretical response of a flatbottomed

hole reflector perpendicular to the beam axis. (DGS does not size

the flaw, but relate it with a equivalent reflector) The DGS system was

introduced by Krautkramer in 1958 and is referred to in German as AVG. A

schematic of a general DGS diagram is shown in the Figure. The Y-axis

shows the Gain and X-axis shows the Distance from the probe. In a general

DGS diagram the distance is shown in units of Near Field and the scale is

logarithmic to cover a wide range.

The blue curves plotted show how the amplitudes obtained from different

sizes of disc shaped reflector (equivalent to a FBH) decrease as the distance

between the probe and the reflector increases.

In the general diagram the size of reflector is given as a ratio between the

size of the disc and the size of the crystal. The red curve shows the response

of a backwall reflection. The ratio of the backwall to the crystal is infinity (∞).

Specific DGS curves for individual probes can be produced and so both the

distance axis and the reflector sizes can be in mm.

If the sensitivity for an inspection is specified to be a disc reflector of a given

size, the sensitivity can be set by putting the reflection from the backwall of a

calibration block or component to the stated %FSH. The gain to be added can

be then obtained by the difference on the Y-axis between the backwall curve

at the backwall range and the curve of the disc reflector of the given size at

the test range. If the ranges of the backwall and the disc reflector are different,

then attenuation shall be accounted for separately. Alternatively, the curves

can be used to find the size of the disc shaped reflector which would give the

same size echo as a response seen in the flaw detector screen.

20-4dB=16dB (deduced)

Δ Flaw =30-16=14dB

20dB

(measured)

Data:

Probe frequency: 5MHz

Diameter: 10mm compression probe

Plate thickness: 100mm steel

Defect depth: 60mm deep

Gain for flaw to FSH: 30dB

BWE at 100mm: 20dB

Example: If you has a signal at a certain depth, you can compare the signal of

the flaw to what the back wall echo (BWE) from the same depth and estimate

the FBH that would give such a signal at the same depth. The defect can then

be size according to a FBH equivalent.

Data:

Probe frequency: 5MHz

Diameter: 10mm compression probe

Plate thickness: 100mm steel

Defect depth: 60mm deep

Gain for flaw to FSH: 30dB

BWE at 100mm: 20dB

-------------------------------------------------------------------------

Near field: 21mm, flaw location= 3xNear Field

From the chart BWE at 60mm will be 20-4dB=16dB

Flaw signal Gain is 30dB-16dB= 14dB

Used the flaw signal Gain and locate the equivalent reflector size is between

0.4 to 0.48 of the probe diameter, say 0.44 x10mm = 4.4mm equivalent

reflector size.

http://www.olympus-ims.com/en/atlas/dgs/

More on DGS/AVG by Olympus

http://www.olympus-ims.com/en/ndt-tutorials/flaw-detection/dgs-avg/

DGS is a sizing technique that relates the amplitude of the echo from a

reflector to that of a flat bottom hole at the same depth or distance. This is

known as Equivalent Reflector Size or ERS. DGS is an acronym for Distance-

Gain-Size and is also known as AVG from its German name, Abstand

Verstarkung Grosse. Traditionally this technique involved manually

comparing echo amplitudes with printed curves, however contemporary

digital flaw detectors can draw the curves following a calibration routine and

automatically calculate the ERS of a gated peak. The generated curves are

derived from the calculated beam spreading pattern of a given transducer,

based on its frequency and element diameter using a single calibration point.

Material attenuation and coupling variation in the calibration block and test

specimen can be accounted for.

DGS is a primarily mathematical technique originally based on the ratio of a

circular probe’s calculated beam profile and measurable material properties

to circular disk reflectors. The technique has since been further applied to

square element and even dual element probes, although for the latter, curve

sets are empirically derived. It is always up to the user to determine how the

resultant DGS calculations relate to actual flaws in real test pieces.

An example of a typical DGS curve set is seen below. The uppermost curve

represents the relative amplitude of the echo from a flat plate reflector in

decibels, plotted at various distances from the transducer, and the curves

below represent the relative amplitude of echoes from progressively smaller

disk reflectors over the same distance scale.

As implemented in contemporary digital flaw detectors, DGS curves are

typically plotted based on a reference calibration off a known target such as a

backwall reflector or a flat bottom hole at a given depth. From that one

calibration point, an entire curve set can be drawn based on probe and

material characteristics. Rather than plotting the entire curve set, instruments

will typically display one curve based on a selected reflector size (registration

level) that can be adjusted by the user.

In the example below, the upper curve represents the DGS plot for a 2 mm

disk reflector at depths from 10 mm to 50 mm. The lower curve is a reference

that has been plotted 6 dB lower. In the screen at left (figure 1), the red gate

marks the reflection from a 2 mm diameter flat bottom hole at approximately

20 mm depth. Since this reflector equals the selected registration level, the

peak matches the curve at that depth. In the screen at right (Figure 2), a

different reflector at a depth of approximately 26 mm has been gated. Based

on its height and depth in relation to the curve the instrument calculated an

ERS of 1.5 mm.

Figure1:

Figure2:

15.0 Pulse Repetitive Frequency/Rate and Maximum

Testable Thickness

Clock interval = 1/PRR

Maximum testable length = ½ x Velocity x Clock interval

Note: The Clock interval has neglected the time occupied by each pulse.

16.0 Immersion Testing of Circular Rod

Q4-12

Answer:

First calculate the principle offset d; ϴ = Sin-1(1483/3250 xSin45)=18.8 °

d=R.Sin18.8= 0.323 (Assume R=1).

Wobbling ±10%; d’=0.355 ~ 0.290

d’=0.355, ϴ = Sin-1(0.355)=20.8 °

giving inspection Φ = Sin-1(3250/1483xSin20.8)=51, 13.3% above 45 °

d’=0.290, ϴ = Sin-1(0.290)=16.9 °

giving inspection Φ = Sin-1(3250/1483xSin16.9)=39.6, 12% below 45 °

Maximum ϴ

ϴ max = Sin -1 (ID/OD)

Addendum-02 Equations & Calculations

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
