DESIGNER RADIATORS TECHNICAL 2011 - Thermic

D E S I G N E R R A D I A T O R S

T E C H N I C A L 2 0 1 1

EvERy INTERIOR HAS a SOul. THIS may be bOTH

fRESH CONTEmpORARy OR CLASSICAL but ALSO puRE

mINImALIST OR vINTAGE. EvERyONE CONTROLS THEIR

own HOmES OR wORk ENvIRONmENT DEpENDING

ON THEIR pERSONAL pREfERENCE. THERmIC RADIATORS

HAve a duRAbLE TImELESS but yET CONTEmpORARy

DESIGN THAT CAN mEET THESE CONfRONTATIONS

of STyLE. HIGH TECH pRODuCTS, DESIGNED fROm a

fuNCTIONAL TOTAL appROACH, CAN be mAINTAINED

fOR a LONG TIme bOTH IN NEw CONSTRuCTION

AND RENOvATION. INNOvATIve RADIATORS THAT

CAN be SEEN IN ANy bATHROOm, kITCHEN, HALL OR

LIvING ROOm.

A HOLDING wITH a fuLL RANGE of HEATING pRODuCTS

The Heating Company, founded in 2005, comprises the following radiator brands:

BRUGMAN / DURA / SupERIA / THERMIC / THOR / THERMIC

The Heating Company can offer you a broad range of well-known brands and top

quality products both for the lower and higher price classes: designer radiators,

bathroom radiators, steelplate radiators, floor heating and wall heating.

The Heating Company sells its products worldwide and the majority are sold in

Europe. The head office of The Heating Company is situated in Dilsen, Belgium.

The production sites are located in Tubbergen (Netherlands), Zedelgem (Belgium),

Dilsen (Belgium) and Legnica (Poland).

THERMIC bvba Factory (Belgium)

Kruishoefstraat 50

B-3650 Dilsen

T: +32(0)89/79 04 44

f: +32(0)89/79 05 55

@: marketing@thermic.be

www.thermic.nl

D E S I G N E R R A D I A T O R S

THERMIC company profile

Thermic is market leader in bathroom radiators and leading manufacturer of

designer radiators throughout Europe. Almost 78% of its production is being

exported to the most important European markets and other continents.

DESIGN

Quality and optimal heat emission are the basis of each design. A well thought

out contemporary design is essential for all Thermic radiators. Radiators are

explicitly present in the interior and are a part of the interior for a long time.

Hence the continuous search for the new development of a harmonic and

rhythmic whole. Products with a distinct design but that are not pushy. Products

that are young and contemporary and yet durable. The Thermic radiators

may be finished in an extensive range of RAL colours but also in trendy lightly

structured metallic colours or extra mat natural shades. Diverse national and

international design awards such as the Red Dot Design award, IF award,

Design Plus awards but also Designpreis Deutschland, Fnas d’or, the European

aluminium award an the Henry van de Velde public’s award are recognitions of

an intense design process.

Thermic stands for design.

Timeless character

A reserved neutral formation makes it possible to come to their own in any

interior: a pure minimalist space, a high-tech office, a cosy family room

or a classic historic building. Design that stands out for its sobriety, prepared to

meet any style confrontation. An absolute necessity for products

present in an interior for a long time. This design quality, besides their durable,

functional construction, is what make THERMIC radiators unique for

application in the bathroom, kitchen, hall and living room.

Quality

Thermic has the quality certificates ISO 9001 and ISO 14001 and gives a 10

year guarantee on all radiators. The radiators are finished with a cataforetic base

coating (as in the automotive industry) and an epoxy-polyester coating applied

electrostatically. Thermic radiators are designed to be seen and to give optimal

heat. The design and quality of the products are studied meticulously. Hanging,

connections, ventilators, weld seams, etc. are essential parts of the product that

require the necessary attention in the development of innovative radiators.

Thermic stands for quality.

Lacquer process

A catachrestic base lacquer (as used in the automobile industry) and a finish of

electrostatically applied epoxy-polyester coating guarantee a perfect

finish in various modern colours and structures (RAL-colours, metallic colours

(structure), natural colours (matt), texture colours).

Guarantee

THERMIC goods are guaranteed for 10 years against any leakages and for

10 years for the paintwork, when they are used in normal circumstances and

for a central heating system with hot water.

You only have a right on guarantee if you do not make any changes to the

radiator. THERMIC accessories (in combination with THERMIC radiators):

2 year guarantee.

Furthermore, THERMIC works in accordance with the ISO 9001-quality

standards, as well as with the ISO 14001-certificate that provides for

guarantees in the form of continuous quality, environmental and safety control

systems.

Innovation is the key to the success of THERMIC. We are constantly searching

for alternative materials, innovative designs and new production methods.

A good example is the new range of aluminium radiators that have recently

been included in the product range. The many awards collected with the new

offer, also confirm that innovation pays.

A second key to success is the commitment to continuous improvement

of existing products and processes. Only through continuous improvement

THERMIC can maintain its leading position in design and technology and meet

the needs of modern society.

EURO-NORM EN 442

75/65/20°C (ΔT50) means:

75°C supply temperature, 65°C return temperature and

20°C room temperature.

This is the EURO-standard to determine the heat output of a radiator.

90/70/20°C (ΔT60) means:



ΔT60 = ΔT50 x 1,27

55/45/20°C (ΔT30) means:



ΔT30 = ΔT50 x 0,51

Thermic cannot be held responsible for possible printing errors and modifications of the

programme.

4

THERMIC RADIATORS

Your order

On receipt of an order especially for non stock items, the orders are

immediately taken into production.

So the orders can neither be cancelled nor changed.

0,6

R0,6

0,6

R0,6

ATTENTION

Please indicate whether the order should be delivered complete.

Otherwise we will assume that part deliveries are permitted.

Prices 01/2011

All prices are exclusive VAT. The previous price lists are not valid anymore.

Small price variations may occur as prices have round up to the nearest euro.

Delivery terms

• For the stock radiators (RAL 9016, S600 or M301) we offer a maximum

delivery reliability of 5 working days.

• The other custom made radiators (non stock radiators) are in principle

available in 15-30 working days, dependent on the type of radiator.

The transport duration is not included in the delivery terms.

Colours

Full colour range see page 6-7

Taking back the radiators

In case of defects in raw materials or fabrication, recognized by THERMIC

bvba, THERMIC has the right to decide on repair or replacement.

The article has to be sent to us carriage paid, to the exclusion of all labour,

transport or relocation costs.

THERMIC isn’t obliged to any compensation, neither for damages on other

goods, nor for profits lost.

Replacement or repair of a radiator, doesn’t extend the guarantee period.

The manufacturer preserves the right to alter the technical data of its

products without prior notice.

Conditions for the return of undamaged radiators, which are still packaged:

1. The radiator type has to be part of the existing THERMIC programme.

2. The radiator must not be older than 6 months.

3. Stock radiators in the standard colour white (RAL 9016) or the standard

colour fine texture white (S600) (in the case of aluminium radiators and

Niva(Soft) radiators) or M301 are taken back at 70% (this means 30%

cancellation costs) of the net-value on the invoice, € 20 transport costs

are charged.

4. Radiators in another colour, but with the size and connections of the

stock radiators are taken back at 50% (this means 50% cancellation

costs) of the net-value on the invoice, € 20 transport costs are charged.

5. Non stock radiators, this means radiators with another size or

connection than the stock radiators, are NOT taken back, cancellation or

credit entry is not possible. Delayed deliveries do not mean that orders

can be annulled.

Luxury accessories are not taken back either!

ATTENTION

Radiators are only taken back after a preceding agreement in writing from

THERMIC. Don’t send the radiators spontaneously, but wait until a vehicle

collects the radiator with a THERMIC collection note.

On the reverse side of the label on the radiator, the production year is

mentioned. This label has to stay on the radiator. The guarantee period is not

valid if the label is removed.

Maintenance and installation instructions for

radiators

1. Do not use any aggressive, scouring, caustic substance on the radiator

(anti-lime products). avoid urine spots on the radiator too.

clean the radiator without using cleaning products (exception: stainless

steel radiators: a stainless steel cleaning product may be used).

2. It is not permitted to fit lacquered radiators in the following rooms (also

see the red zone above): above a bath with shower facility, in or near to

a shower, in a swimming pool (chlorine vapour) and in a sauna. Mounting

radiators above a bath with a device to take a shower, in a shower of

next to them is not allowed!

The radiator must not be exposed to water jets and/or soap residue

because water with soap residue is very corrosive.

3. The permeation of oxygen into the installation must

be prevented to avoid the internal corrosion of the

radiators. The design, assembly and operation of

the installation must take this into account.

We consequently recommend only using

our radiators in well-dimensioned enclosed

installations. The need for regular bleeding or

regularly adding water indicates defects in the

installation and requires technical intervention.

considering that practically all installations

comprise different metals (copper, steel, brass,

aluminium), corrosion as a result of electrolysis

must be prevented by using a protecting product.

PROTECT 1+1

Ref. nr. 12fh60111

Characteristics:

• ensures optimal protection of steel, cast iron, aluminium, copper,

copper alloys; does not damage synthetic piping and sealants.

• contains inhibitors that completely prevent galvanic corrosion

between metals with different potentials.

• contains dispergators and hardness stabilisers that prevent deposits

on the internal heating surfaces.

Use:

• The water must be neutral with a pH between 6 and 8.5.

• If the water in the installation should prove to be corrosive, the

guarantee shall lapse.

Dosage:

• 1% protector to the volume of water in the heating system (e.g. 1 litre

of protector for 100 litres of water).

The finish is permanent; a one-off dose is sufficient.

in the event of sub sequent additions of water, the concentration

must be checked.

our radiators are not guaranteed either, if they have been empty for

a certain period, if they are heated by industrial water, steam or water

containing chemical products or large quantities of acid. The quality of

the system water must comply with guideline VDI 2035-2.

4. The guarantee is only valid in case of rusted connections if the delivered

THERMIC radiator bleeding material and blind plugs have been

used.

5. Report immediately if a radiator has been damaged during transport.

This radiator must not be mounted. Transport damage of a mounted

radiator will not be accepted. A damaged radiator (for instance

scratches) must be sent back in the original packaging. .

6. Plugs and screws are not included. It is up to the installer to select, in

function of the wall construction and weight of the radiator, the correct

type and number of screws and plugs.

7. If the operator does not function well, you should not do anything.

Contact the internal service of the sales department.

8. Don't let you children climb on the radiator (a towel radiator is not a

ladder).

9. In case of a radiator with an electrical resistance, you only have a right on

guarantee if the resistance is combined with a THERMIC radiator.

10. You only have a right on guarantee if you do not make any changes to

the radiator.

11. If the product is changed (for any reason), THERMIC is entitled to deliver

equivalent though not identical parts or devices.

5

THERMIC COLOURS

Standard white: RAL 9016 / S600

RAL 9016/S600

Standard white

• RAL 9016 = Traffic white glossy

S600 = Traffic white (RAL 9016) fine texture

• S600 = standard for the aluminium radiators and collection Xtend (Soft)

RAL 9016 = standard for the other radiators

PRICE SUPPLEMENT COLOUR

• other THERMIC-colours: + 15%

• natural colours: + 15%

• metallic colours: + 15%

• M350 (stainless steel look): + 35%

The colours shown are only indicative.

ATTENTION:

Modifications in between are possible.

Please contact the headoffice to receive an actual update.

SANITARY COLOURS

0007 Jasmin 0008 Beige 0011 Edelweiss 0017 Taupe 0019 Pergamon 0023 Arania 0031 Classical

White

0033 Graphite

mat

RAL colours

RAL 1004

Golden Yellow

RAL 1013

Oyster White

RAL 1015

Light Ivory

RAL 2003

Pastel Orange

RAL 3002

Carmine Red

RAL 3003

Ruby Red

RAL 5002

Ultramarine Blue

RAL 7001

Silver Grey

RAL 7011

Iron Grey

RAL 7016

Anthracite Grey

RAL 7021

Black Grey

RAL 7030

Stone Grey

RAL 7035

Light Grey

RAL 8017

Chocolate Brown

RAL 9001

Cream

RAL 9002

Grey White

RAL 9003

Signal White

RAL 9005

Signal Black

RAL 9006

White Aluminium

RAL 9007

Grey Aluminium

RAL 9010

White

RAL 9016

Traffic White

6

THERMIC COLOURS

Natural colours

N500 Mist White N501 Mist Grey N502 Sand Light N503 Sand

N504 Platinum

Grey

N505 Dust Grey N506 Warm Grey N507 Grey-Brown

METALLIC Colours

M300 Black

January

M301 Anthracite

January

M302 Aluminium

Grey January

M303 Grey White

January

M304 Brown

January

Stainless Steel look

M350 Stainless

steel look*

* attention: M350 stainless steel look: loss of heat output up to 24%

7

THERMIC HOW TO ORDER

How to form the reference code ?

Composition

Reference

number

Width Height Connection** Colour Standard Finish*** = Reference code

Number of digits* 5 digits 4 digits 4 digits 4 digits 4 digits -00 2 digits 26 digits

Examples 12249 0500 0974 0018 9016 -00 00 122490500097400189016-0000

12254 0304 1800 0045 0302 -00 00 122540304180000450302-0000

* If needed add some zeros. Do not use any letters, ex. indicate the colour M302 as 0302, indicate the connection fully in digits.

** In case of a pure electrical radiator, please enter 0000 as connection. The regulation must be entered on the second line of the order form.

*** Finish:

Please use following 2 digits: Standard 00

Free-standing Hazel HZ2/Verso V-I/Havaro HP2-RO/HP2L1-RO 01

Grill bench PK 02

Thermostatic head integrated valve Veltis Horizontal/Havaro/Verena: white 03

Thermostatic head integrated valve Veltis horizontal/Havaro/Verena: chrome 04

Thermostatic head integrated valve Veltis Horizontal/Havaro/Verena: stainless steel 05

With fixed feet (Navaro) 06

Telescopic feet + lateral supports Verena VP2-ZB/Havaro HP2-RO/HP2L1-RO 07

Free-standing 1 foot Verena VP2-ZB 08

Free-standing 2 feet Verena VP2-ZB 09

ORDER FORM

Wholesaler:

installer:

Number Type Ref.nr. Width Height Connection Colour -00 Accessories

Price/piece €

excl. VAT

Total price €

excl. VAT

Stock radiator

1 -00

2 -00

3 -00

4 -00

5 -00

6 -00

7 -00

8 -00

9 -00

10 -00

11 -00

12 -00

13 -00

14 -00

15 -00

How to order accessories ?

When ordering accessories, please only indicate the number, the reference number (always 15 digits) and the price.

Number Ref.nr. Accessories Price/piece € excl. VAT Total price € excl. VAT

1

2

3

4

5

Customer wishes part deliveries

Customer doesn't wish part deliveries

8

Date: / /

Signature:

Attention: Please always check your order confirmation!!

ALUMINIUM

rADIATORs

steel

radiators

Technical

Alu-Zen COLLECTION Alu-Zen Vertical Alu-Zen 11

Bryce COLLECTION Bryce Vertical BV 15

* NEW * Canyon COLLECTION Canyon Vertical Canyon 19

Veltis COLLECTION Veltis Vertical Veltis V75 / Veltis V100 23

Veltis Horizontal

Veltis H100

Arche COLLECTION Arche Vertical VV / VH 29

Arche Plus Vertical VVL / VVR

Xtend COLLECTION XtenD Vertical lacQUered X1L1 / X2L1 37

XtenD Vertical StainleSS STeel

XtenD horizontal lacQUered

XtenD SofT Vertical

X1L1-I / X2L1-I

XH1L1 / XH2L1 / XH2L2

XS1L1 / XS2L1

Zana COLLECTION Zana Vertical ZV-1 / ZV-2 49

Zana Curved

Zana Horizontal

Zana half round

Zana with angle

Zana Bathroom

Zana Libra

ZV-R

ZH-1 / ZH-2

ZV-O

ZV-A

ZBD

Libra LU / Libra LD / Libra LL / Libra LR

Zana Multi Multi 1 / Multi 2

Zana Plinth

Plinth

C-Line COLLECTION Believe C-BE 77

C-RH

Taiyou

Sigma / Sigma-S

Bathroom COLLECTION Verso Lacquered V-S / VZ-S 87

Verso Stainless Steel

Verso Chrome

Tripla

Ponti

Hedria

Largo Lacquered

Largo Chrome

Hazel

C-RH

C-TA

C-SI

V-I / VZ-I

V-CHR / VZ-CHR

HKM / HKRM

HX

HDM / HDRM

HRM / HR2 / HRBM

HRM-C / HRBM-C

HZ / HZ2

Vengia Verena Havaro COLLECTION Vengia Vertical VPN1(-ZB) / VPN1L1-ZB / VPN2(-ZB) / VPNS1-ZB /

VPNS1L1-ZB

Verena Vertical

Havaro Horizontal

VP1-ZB / VP1L1-ZB / VP2-ZB

HP1-RO / HP1L1-RO / HP2-RO / HP2L1-RO / HP2L2-RO

PK COLLECTION PK PK1 / PK2 / PK3 / PK4 127

Navaro COLLECTION Navaro Vertical NVR1 / NVR2 / NVRSN 137

Navaro Horizontal

NHR1 / NHR2

VR COLLECTION VR Vertical VRV1-X / VRV2-X / VRVS1 / VRVS2 149

Vision COLLECTION Vision Vertical VRVK-V 157

Vision Horizontal

Vision Round

Vision half-round

Vision quarter-round

VRVK-H

VRVK-R

VRVK-O

VRVK-A

Toilet COLLECTION Veltis Horizontal Veltis H100 171

Electrical radiators COLLECTION

XtenD horizontal lacQUered





Mixed and pure electrical

radiators

Hedria

Largo

Tripla

Hazel

C-Line

Zana Bathroom

Zana Deco Bathroom

Verena

Xtend

E-Volve

E-PANEL

POSSIBLE CONNECTION SYSTEMS

Valves

Correction factors

Pressure Losses

Models of valve set combined

with radiators

XH1L1

ZH-1

HP1L1(-V)

VP1L1(-V)

NHR1

HD-EL / HDR-EL

HR-EL

HKR-EL

HZ-EL

C-RH-EL

ZBD-EL

ZBD-DECO-EL

VP1L1-ZB-EL

X1L1-EL

EV2-EL

EP-H FL / EP-H RIB / EP-V FL

One-pipe system / Two-pipe system /

One-point connection / Integrated valve /

Flow tube

109

173

193

Alu-Zen COLLECTION

Alu-Zen Alu-Zen Vertical 12

Accessories 14

Connections 14

Alu-Zen

11

Alu-Zen Vertical (Alu-Zen)

type

ref. nr.

12114

Alu-Zen

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

375 1600 1196 1504 1,30 17,40 1,30 - -

375 1800 1319 1662 1,31 19,40 1,40 - -

375 2000 1440 1814 1,31 21,40 1,50 - -

375 2200 1557 1962 1,31 23,25 1,75 - -

450 1600 1446 1822 1,31 21,07 1,53 - -

450 1800 1596 2011 1,31 23,49 1,68 - -

450 2000 1742 2195 1,31 25,92 1,83 - -

450 2200 1884 2373 1,31 28,20 2,07 - -

525 1600 1699 2140 1,31 24,73 1,77 - -

525 1800 1874 2361 1,31 27,58 1,97 - -

525 2000 2046 2578 1,31 30,43 2,17 - -

525 2200 2212 2787 1,31 33,15 2,38 - -

600 1600 1953 2460 1,31 28,40 2,00 - -

600 1800 2155 2715 1,31 31,68 2,25 - -

600 2000 2351 2962 1,31 34,95 2,50 - -

600 2200 2543 3204 1,31 38,10 2,70 - -

in conformity with EN442-1: radiators and convectors

stock radiators (S600)

type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

Alu-Zen 525 1800 0600 12114-01

525 2000 0600 12114-04

600 1800 0600 12114-03

600 2000 0600 12114-02

12

Alu-Zen

Centre between the connections 50

Centre between the brackets L-226

Alu-Zen Vertical (Alu-Zen)

Colours

• Standard colour S600 (fine texture white)

• Not available in M350 (stainless steel look)

• Extensive colour chart see p. 6-7

Special

• Composed out of vertical aluminium profiles

• Protection against internal corrosion: protecting product Protect 1+1

(see p. 5)

Alu-Zen

Brackets

• Wall brackets standard

Technical

• Aluminium radiators are manufactured by way of a patented press

process that goes into making a world class radiator.

• KTL priming coat, powder coating

• Standard operating pressure: 10 bar

• Maximum operating temperature: 110°C

Alu-Zen

return supply

ref. nr. 128210300000099

Fittings, see p. 204

Electrical (see chapter electrical radiators)

Pure electrical radiator prefilled

Pure electrical radiator to be filled

Mixed radiator

✘

✘

✘

Connection

One-point connection for one-pipe system

One-point connection for two-pipe system

Two-point connection for one-pipe system

(connection by way of the central connection) (see p. 194)

Two-point connection for two-pipe system

(standard) (see p. 194)

Integrated valve

• A standard automatic air vent is fitted on the top left hand side of the radiator

• Attention: The water should be PH neutral. Protect 1+1 or a similar product should be added to the

circuit (1 liter for 100 liters installation water).

Delivery terms Transport duration not included !

• Stock radiators in white (S600): 5 working days

• Non-stock radiators: 15 to 30 working days, dependent on the type of radiator

✘

✘

✔

✔

✘

113 L-226 113

123

116

16

23

H-123

100

H

1/2”

59

92

L

50

13

Alu-Zen Accessories

In option

ACCESSORIES COLOUR WIDTH RADIATOR REF.NR.

TOWEL RAIL

• Towel rail in aluminium

• h = 50 mm; b = 435, 510, 585, 660 mm; d = 46 mm; a = 42 mm

Alu-Zen

ALUMINIUM 375 mm 128323400000000

450 mm 128323500000000

525 mm 128323600000000

600 mm 128323700000000

d = distance front of the accessory up to front of the radiator

a = distance accessory up to the radiator

Alu-Zen Connections

Alu-Zen Vertical: Alu-Zen

MM

0066

MM

0066

• Attention: connecting the radiator can only be as shown by the connecting icons. For any other

connection method, we take no responsibility.

14

Bryce COLLECTION

BV Bryce Vertical 16



Bryce

15

Bryce Vertical (BV)

type

ref. nr.

12120

BV

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

409 1600 1079 1359 1,31 17,90 1,40 - -

409 1800 1188 1497 1,31 19,95 1,85 - -

409 2000 1295 1631 1,31 22,00 2,00 - -

409 2200 1402 1766 1,31 24,60 2,30 - -

512 1600 1326 1673 1,32 22,23 1,78 - -

512 1800 1460 1843 1,32 24,74 2,09 - -

512 2000 1592 2006 1,31 27,25 2,25 - -

512 2200 1723 2171 1,31 30,00 2,52 - -

615 1600 1569 1984 1,33 26,55 2,15 - -

615 1800 1727 2180 1,32 29,53 2,33 - -

615 2000 1883 2376 1,32 32,50 2,50 - -

615 2200 2038 2567 1,31 35,40 2,75 - -



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

BV 512 1800 0600 12120-01

512 2000 0600 12120-02

615 1800 0600 12120-03

615 2000 0600 12120-04

16

BV



Bryce Vertical (BV)

Colours




Special



(see p. 5)

• The Bryce is awarded with the Henry van de Velde label 2007, the

Product Design Award Hannover 2008, Design Plus Award - Material

Vision, Frankfurt 2007, the Red Dot Product Design Award 2008 and

nominated for the Designpreis 2009 and the European Aluminium

Award 2008.

BV

return

supply

Bryce

Brackets


ref. nr. 128210300000099


Technical










✘

✘

✘

Connection









• Attention: The water should be PH neutral. Protect 1+1 or a similar product should be added to the circuit

(1 liter for 100 liters installation water).




✘

✘

✔

✔

✘

L-80

78,5

H-76

H

28

76

75

1/2”

33

L

50

54

17

Bryce Accessories

In option

ACCESSORIES WIDTH TOWEL RAIL REF.NR.

BV

TOWEL RAIL IN

TRANSPARENT

GLASS

700 mm 128320200000000

900 mm 128320400000000

1200 mm 128320000000000

• Towel rail needs to be mounted to the wall.

• h = 70 mm; b = 700, 900, 1200 mm; d = 135 mm; a = 40 mm; glass thickness = 10 mm

BV

TOWEL RAIL

IN FROSTED

GLASS

700 mm 128320300000000

900 mm 128320500000000

1200 mm 128320100000000



d = distance front of the accessory up to front of the wall


Bryce Connections

Bryce Vertical: BV

MM

MM

0066 0066



18

Canyon COLLECTION

Canyon Canyon Vertical 20



Canyon

19

Canyon Vertical (Canyon)

type

ref. nr.

12206

Canyon

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

380 1600 1211 1526 1,31 19,70 1,35 5 -

380 1800 1338 1683 1,30 22,08 1,48 5 -

380 2000 1461 1834 1,29 24,45 1,60 5 -

380 2200 1581 1995 1,32 26,70 1,73 5 -

455 1600 1448 1827 1,32 23,65 1,62 6 -

455 1800 1600 2016 1,31 26,51 1,77 6 -

455 2000 1747 2197 1,30 29,37 1,92 6 -

455 2200 1891 2386 1,32 32,12 2,07 6 -

530 1600 1685 2130 1,33 27,60 1,88 7 -

530 1800 1862 2350 1,32 30,94 2,06 7 -

530 2000 2033 2561 1,31 34,28 2,23 7 -

530 2200 2200 2776 1,32 37,53 2,41 7 -

605 1600 1922 2434 1,34 31,55 2,15 8 -

605 1800 2123 2684 1,33 35,38 2,35 8 -

605 2000 2319 2932 1,33 39,20 2,55 8 -

605 2200 2509 3166 1,32 42,95 2,75 8 -

conform EN442-1: radiatoren en convectoren


type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

Canyon 530 1800 0600 12206-01

530 2000 0600 12206-03

605 1800 0600 12206-02

605 2000 0600 12206-04

20

Canyon



Canyon Vertical (Canyon)

Colours




Special



(see p. 5)

Canyon

Brackets


Technical






Canyon

return supply

ref. nr. 128210300000099






✘

✘

✘

Connection









• Attention: The water should be PH neutral. Protect 1+1 or a similar product should be added to the circuit

(1 liter for 100 liters installation water).




✘

✘

✔

✔

✘

107

115 L-230 115

23

H

H

H-124

74

30

77

40

74

L

50

21

Canyon Accessories

In option

ACCESSORIES COLOUR WIDTH RADIATOR REF.NR.

TOWEL RAIL


• h = 50 mm; b = 435, 510, 585, 660 mm; d = 47 mm; a = 43 mm

Canyon

ALUMINIUM 380 mm 128324400000000

ALUMINIUM 455 mm 128324500000000

ALUMINIUM 530 mm 128324600000000

ALUMINIUM 605 mm 128324700000000



Canyon Connections

Canyon Vertical: Canyon

MM

MM

0066 0066



22

Veltis COLLECTION

Veltis V75 / Veltis V100 Veltis Vertical 24

Veltis H100 Veltis Horizontal 26



Veltis

23

Veltis Vertical (Veltis V75, Veltis V100)

type

ref. nr.

12247

Veltis

V75

ref. nr.

12246

Veltis

V100

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

375 1600 1159 1460 1,31 16,50 1,38 5 -

375 1800 1281 1614 1,31 18,48 1,44 5 -

375 2000 1403 1767 1,31 20,45 1,50 5 -

375 2200 1502 1889 1,30 22,40 1,65 5 -

450 1600 1377 1750 1,36 19,57 1,57 6 -

450 1800 1518 1919 1,33 21,84 1,69 6 -

450 2000 1659 2090 1,31 24,12 1,82 6 -

450 2200 1765 2220 1,30 26,55 2,00 6 -

525 1600 1594 2040 1,40 22,63 1,76 7 -

525 1800 1755 2231 1,36 25,21 1,95 7 -

525 2000 1915 2413 1,31 27,78 2,13 7 -

525 2200 2027 2545 1,29 30,70 2,35 7 -

600 1600 1812 2336 1,44 25,70 1,95 8 -

600 1800 1991 2539 1,38 28,58 2,20 8 -

600 2000 2171 2740 1,32 31,45 2,45 8 -

600 2200 2289 2874 1,29 34,85 2,70 8 -

375 1600 1352 1700 1,30 18,85 1,25 5 -

375 1800 1490 1877 1,31 21,50 1,40 5 -

375 2000 1625 2044 1,30 23,30 1,60 5 -

375 2200 1757 2210 1,30 25,70 1,65 5 -

450 1600 1607 2021 1,30 22,38 1,48 6 -

450 1800 1771 2235 1,32 25,38 1,68 6 -

450 2000 1931 2433 1,31 27,75 1,95 6 -

450 2200 2088 2626 1,30 30,52 2,00 6 -

525 1600 1859 2342 1,31 25,92 1,72 7 -

525 1800 2049 2590 1,33 29,27 1,97 7 -

525 2000 2235 2816 1,31 32,20 2,30 7 -

525 2200 2417 3040 1,30 35,33 2,35 7 -

600 1600 2110 2658 1,31 29,45 1,95 8 -

600 1800 2326 2946 1,34 33,15 2,25 8 -

600 2000 2536 3195 1,31 36,65 2,65 8 -

600 2200 2742 3448 1,30 40,15 2,70 8 -



type

Veltis

V75

Veltis

V100

width

(L mm)

height

(H mm)

colour

short

ref. nr.

525 1800 0600 12247-01

600 2000 0600 12247-02

525 1800 0600 12246-01

600 2000 0600 12246-02

100

113

L-226

113

91

26

H-123

H

L-226

113 113

116

75

16

16

23

H-123

123

123

1/2” 1/2”

59

92

35

68

L

50

24

Veltis Vertical (Veltis V75, Veltis V100)

Types

• Vertical: Veltis V75 and Veltis V100 (depth)

Colours


• Not available in other colours

Veltis

Special



(see p. 5)

Veltis V75

Brackets


Technical










Connection









• Attention: The water should be PH neutral. Protect 1+1 or a similar product should be added to the

circuit (1 liter for 100 liters installation water).




✘

✘

✘

✘

✘

✔

✔

✘

Veltis V100

return supply

ref. nr. 128210300000099


Veltis V75 / Veltis V100


Centre between the brackets L-226

25

Veltis Horizontal (Veltis H100)

type

ref. nr.

12245

Veltis

H100

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

450 400 452 568 1,30 6,66 0,48 6 -

450 500 567 714 1,31 7,92 0,66 6 -

450 600 666 838 1,30 9,24 0,78 6 -

450 900 960 1207 1,30 13,14 0,96 6 -

450 1400 1391 1755 1,32 20,30 1,38 6 -

525 400 527 663 1,30 7,77 0,56 7 -

525 500 662 833 1,31 9,24 0,77 7 -

525 600 778 978 1,30 10,78 0,91 7 -

525 900 1120 1408 1,30 15,33 1,12 7 -

525 1400 1614 2037 1,32 23,70 1,57 7 -

600 500 756 952 1,31 10,56 0,88 8 -

600 600 889 1117 1,30 12,32 1,04 8 -

600 900 1280 1609 1,30 17,52 1,28 8 -

600 1400 1835 2316 1,32 27,10 1,75 8 -

675 400 678 852 1,30 9,99 0,72 9 -

675 500 851 1071 1,31 11,88 0,99 9 -

675 600 1000 1257 1,30 13,86 1,17 9 -

675 900 1440 1811 1,30 19,71 1,44 9 -

750 400 753 947 1,30 11,10 0,80 10 -

750 500 945 1191 1,31 13,20 1,10 10 -

750 600 1111 1397 1,30 15,40 1,30 10 -

750 900 1600 2012 1,30 21,90 1,60 10 -

825 400 828 1042 1,30 12,21 0,88 11 -

825 500 1040 1310 1,31 14,52 1,21 11 -

825 600 1222 1537 1,30 16,94 1,43 11 -

825 900 1760 2213 1,30 24,09 1,76 11 -

900 400 904 1136 1,30 13,32 0,96 12 -

900 500 1134 1429 1,31 15,84 1,32 12 -

900 600 1333 1676 1,30 18,48 1,56 12 -

900 900 1920 2414 1,30 26,28 1,92 12 -

975 400 979 1231 1,30 14,43 1,04 13 -

975 500 1229 1548 1,31 17,16 1,43 13 -

975 600 1444 1816 1,30 20,02 1,69 13 -

975 900 2080 2615 1,30 28,47 2,08 13 -

1050 400 1054 1326 1,30 15,54 1,12 14 -

1050 500 1323 1667 1,31 18,48 1,54 14 -

1050 600 1555 1956 1,30 21,56 1,82 14 -

1050 900 2240 2817 1,30 30,66 2,24 14 -

1125 400 1130 1420 1,30 16,65 1,20 15 -

1125 500 1418 1786 1,31 19,80 1,65 15 -

1125 600 1666 2095 1,30 23,10 1,95 15 -

1125 900 2400 3018 1,30 32,85 2,40 15 -

1200 500 1512 1905 1,31 21,12 1,76 16 -

1200 600 1777 2235 1,30 24,64 2,08 16 -

1200 900 2560 3219 1,30 35,04 2,56 16 -

1350 500 1701 2143 1,31 23,76 1,98 18 -

1350 600 1999 2514 1,30 27,72 2,34 18 -

1350 900 2880 3621 1,30 39,42 2,88 18 -

1500 400 1506 1894 1,30 22,20 1,60 20 -

1500 500 1890 2381 1,31 26,40 2,20 20 -

1500 600 2222 2794 1,30 30,80 2,60 20 -

1500 900 3200 4024 1,30 43,80 3,20 20 -

1650 400 1657 2083 1,30 24,42 1,76 22 -

1650 500 2079 2619 1,31 29,04 2,42 22 -

1650 600 2444 3073 1,30 33,88 2,86 22 -

1650 900 3519 4426 1,30 48,18 3,52 22 -

1800 400 1807 2273 1,30 26,64 1,92 24 -

1800 500 2268 2857 1,31 31,68 2,64 24 -

1800 600 2666 3352 1,30 36,96 3,12 24 -

1800 900 3839 4828 1,30 52,56 3,84 24 -

1950 500 2457 3095 1,31 34,32 2,86 26 -

1950 600 2888 3632 1,30 40,04 3,38 26 -

1950 900 4159 5231 1,30 56,94 4,16 26 -

2550 400 2560 3220 1,30 37,74 2,72 34 -

2850 400 2861 3598 1,30 42,18 3,04 38 -


26

Veltis H100

Height (H) 500 600 900 1400

Centre between the lateral connections 23/67 (R) 438,5 538,5 838,5 1338,5


Veltis Horizontal (Veltis H100)

Types

• Horizontal: Veltis H100 (depth)

Colours



Veltis

Special


• Protection against internal corrosion: protecting product Protect 1+1 (see p. 5)

• H100 also available as toilet radiator (450 x 400 mm and 450 x 500 mm)

Brackets


Technical










✘

✘

✘

Connection


✘


✘


✘


✔


Integrated valve (see p. 196)

✔


• Attention: The water should be PH neutral. Protect 1+1 or a similar product

should be added to the circuit (1 liter for 100 liters installation water).

Veltis H100


• 15 to 30 working days, dependent on the type of radiator

Veltis H100

Veltis H100 (integrated valve)

113

L-226

113

113

L-226

113

H-123 123

119

16

H

103

R

H-123 123

119

16

H

103

22,5

96,5

L

L

96,5

50

37,5

27

Veltis Accessories

In option

ACCESSORIES COLOUR REF.NR.

Veltis V75 / Veltis V100 / Veltis H100

HOOK O-RING

CHROME 128360400000099

• h = 22 mm; b = 22 mm; d = 42 mm


HOOK WITH A

WIDE GROOVE

CHROME 128340700000099

• h = 22 mm; b = 22 mm; d = 42 mm


TOWEL RAIL

CHROME 128323800000099

• h = 22 mm; b = 720 mm (easy adjustable); d = 75 mm; a = 56 mm



Veltis Connections

Veltis Vertical: Veltis V75 / Veltis V100

MM

0066

MM

0066



Veltis Horizontal: Veltis H100

integrated valve

6

8

0098

• Attention: the supply is always on the right side of the radiator!

3

6

3

6

3

6

3

6

2

7

2

7

2

7

2

7

2367

2367 2367

2367

3

6

3

6

3

6

3

6

2

7

2

7

2

7

2

7

2367 2367 2367 2367



28

Arche COLLECTION

VV / VH Arche Vertical 30

VVL / VVR Arche Plus Vertical 32



Arche

29

Arche Vertical (VV, VH)

type

ref. nr.

12117

VV

ref. nr.

12116

VH

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

470 1800 1050 1304 1,23 22,90 13,94 10 -

470 2000 1164 1449 1,24 25,36 15,42 10 -

470 2200 1279 1592 1,24 27,81 16,91 10 -

570 1800 1273 1581 1,23 27,78 16,90 12 -

570 2000 1412 1757 1,24 30,76 18,70 12 -

570 2200 1552 1931 1,24 33,73 20,50 12 -

670 1800 1496 1858 1,23 32,65 19,87 14 -

670 2000 1660 2065 1,24 36,15 21,98 14 -

670 2200 1824 2269 1,24 39,65 24,10 14 -

500 870 479 595 1,23 12,93 7,21 18 -

600 870 563 699 1,23 15,11 8,47 18 -

700 870 646 802 1,23 17,29 9,73 18 -

500 1170 632 786 1,24 17,16 9,84 24 -

600 1170 743 925 1,24 20,09 11,66 24 -

700 1170 853 1063 1,25 23,02 13,47 24 -

500 1470 786 980 1,25 21,38 12,47 30 -

600 1470 924 1154 1,26 25,06 14,84 30 -

700 1470 1060 1326 1,27 28,74 17,21 30 -

500 1670 889 1108 1,25 24,26 14,08 34 -

600 1670 1045 1305 1,26 28,43 16,78 34 -

700 1670 1199 1497 1,26 32,59 19,48 34 -

500 1870 993 1240 1,26 27,15 15,68 38 -

600 1870 1168 1456 1,25 31,79 18,71 38 -

700 1870 1339 1669 1,25 36,44 21,74 38 -


stock radiators (RAL 9016, M301)

type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

VV 470 1800 9016 12117-03

470 1800 0301 12117-01

570 1800 9016 12117-06

570 1800 0301 12117-04

VH 600 1870 9016 12116-04

600 1870 0301 12116-05

VV

Number of tubes (n) 10 12 14

Width (L) 470 570 670

Centre between the connections at the bottom 18 (R) 370 470 570

Centre between the brackets L-120 H-140

30

VH

Width (L) 500 600 700


Centre between the brackets L-140 H-120

Arche Vertical (VV, VH)

Tubes

• VV: Vertical, rectangular 45 x 20 mm

• VH: Horizontal, rectangular 45 x 20 mm

Colours

• Standard colour white RAL 9016


• Not available in S600 (fine texture white)


Arche

Special

• The Arche is awarded with the Design Plus Award 2005, Reddot

Design Award 2006, Silver Award Designpreis Deutschland 2006 and

nominated for the Henry van de Velde prize 2005.

VV

Brackets


Technical








Connection








✘

✘

✘

✘

✘

✔

✔

✘

VH

return

supply

ref. nr. 128210300000099



• Stock radiators in RAL 9016 and M301: 5 working days


VV

VH

L-140

L-120

75

70 H - 140

70

1/2”

75

17

52

H

50

R

L

H - 120 60

60

1/2”

17

52

H

R

L

50

31

Arche Plus Vertical (VVL, VVR)

type

ref. nr.

12118

VVL

ref. nr.

12119

VVR

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

470 1800 1050 1304 1,23 23,49 13,94 10 -

470 2000 1164 1449 1,24 25,95 15,42 10 -

470 2200 1279 1592 1,24 28,40 16,91 10 -

570 1800 1273 1581 1,23 28,44 16,90 12 -

570 2000 1412 1757 1,24 31,42 18,70 12 -

570 2200 1552 1931 1,24 34,40 20,50 12 -

670 1800 1496 1858 1,23 33,39 19,87 14 -

670 2000 1660 2065 1,24 36,89 21,98 14 -

670 2200 1824 2269 1,24 40,39 24,10 14 -

470 1800 1050 1304 1,23 23,49 13,94 10 -

470 2000 1164 1449 1,24 25,95 15,42 10 -

470 2200 1279 1592 1,24 28,40 16,91 10 -

570 1800 1273 1581 1,23 28,44 16,90 12 -

570 2000 1412 1757 1,24 31,42 18,70 12 -

570 2200 1552 1931 1,24 34,40 20,50 12 -

670 1800 1496 1858 1,23 33,39 19,87 14 -

670 2000 1660 2065 1,24 36,89 21,98 14 -

670 2200 1824 2269 1,24 40,39 24,10 14 -


32

VVL / VVR


Width (L) 470 570 670


Width towel rail (B) 335 385 435



Types

• VVR (towel bar right), VVL (towel bar left)

Tubes

• Vertical, rectangular 45 x 20 mm

Colours





Special

• Fixed towel bar, finished with the same powder coating as the radiator

• Attention: this towel bar does not heat!

Brackets


Technical








✘

✘

✘

VVR

return

supply

ref. nr. 128210300000099



Connection








✘

✘

✔

✔

✘



L-120

L-120

VVL

VVR

B

B

75

75

70 H-140

70

H

1100

70 H-140

70

H

1100

1/2”

50

1/2”

50

17

52

R

L

17

52

R

L

33

Arche Accessories

in optie

ACCESSORIES COLOUR WIDTH TOWEL RAIL REF.NR.

VV / VH

HOOK O-RING

CHROME 128360300000099

• h = 22 mm; b = 22 mm; d = 42 mm

VV / VH

HOOK WITH A

WIDE GROOVE

CHROME 128340500000099

• h = 22 mm; b = 22 mm; d = 42 mm

TOWEL RAIL IN

TRANSPARENT

GLASS

VV / VH

700 mm 128320200000000

900 mm 128320400000000

1200 mm 128320000000000



TOWEL RAIL IN

FROSTED GLASS

VV / VH

700 mm 128320300000000

900 mm 128320500000000

1200 mm 128320100000000



VV

CHROME 128321200000099

TOWEL RAIL



d = distance front of the accessory up to front of the wall (towel rail glass)


34

Arche Connections

Arche Vertical: VV/VH

Arche Plus Vertical: VVL/VVR

5

5

5

5

Arche

1 MM 8

1 MM 8

1 MM 8

1 MM 8

1188

1188 1188 1188



35

Xtend COLLECTION

X1L1 / X2L1 Xtend Vertical Lacquered 38

X1L1-I / X2L1-I Xtend Vertical Stainless steel 40

XH1L1 / XH2L1 / XH2L2 Xtend Horizontal Lacquered 42

XS1L1 / XS2L1 Xtend Soft Vertical 44

Xtend

Brackets 46



37

Xtend Vertical Lacquered (X1L1, X2L1)

type

ref. nr.

12191

X1L1

ref. nr.

12192

X2L1

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

420 1220 547 688 1,30 17,30 2,50 - -

420 1820 765 969 1,34 24,09 3,70 - -

420 2020 842 1074 1,38 26,46 4,08 - -

420 2220 919 1178 1,41 28,41 4,44 - -

520 1220 614 771 1,29 19,87 2,90 - -

520 1820 948 1201 1,34 29,83 4,59 - -

520 2020 1043 1330 1,38 32,75 5,05 - -

520 2220 1138 1459 1,41 35,17 5,49 - -

620 1220 680 852 1,28 22,43 3,30 - -

620 1820 1130 1431 1,34 35,56 5,47 - -

620 2020 1243 1585 1,38 39,05 6,03 - -

620 2220 1356 1739 1,41 41,94 6,55 - -

720 1820 1312 1662 1,34 41,30 6,35 - -

720 2020 1444 1842 1,38 45,35 7,00 - -

720 2220 1575 2019 1,41 48,70 7,60 - -

420 1220 891 1140 1,40 27,60 4,90 - -

420 1820 1203 1518 1,32 38,61 7,32 - -

420 2020 1297 1631 1,30 42,35 8,08 - -

420 2220 1391 1740 1,27 46,61 8,81 - -

520 1220 1013 1290 1,37 31,58 5,68 - -

520 1820 1489 1879 1,32 47,81 9,06 - -

520 2020 1606 2020 1,30 52,43 10,00 - -

520 2220 1723 2155 1,27 57,70 10,90 - -

620 1220 1136 1439 1,34 35,57 6,47 - -

620 1820 1776 2241 1,32 57,00 10,81 - -

620 2020 1915 2408 1,30 62,51 11,92 - -

620 2220 2054 2569 1,27 68,80 13,00 - -

720 1820 2062 2602 1,32 66,20 12,55 - -

720 2020 2224 2797 1,30 72,60 13,85 - -

720 2220 2385 2983 1,27 79,90 15,10 - -

* New *

height 1220 mm


stock radiators (S600, M301)

type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

X1L1 520 1220 0600 12191-14

520 1820 0600 12191-15

520 1820 0301 12191-16

520 2020 0600 12191-17

620 1820 0600 12191-12

620 1820 0301 12191-03

620 2020 0600 12191-13

X2L1 520 1820 0600 12192-28

520 2020 0600 12192-29

620 1220 0600 12192-37

620 1820 0600 12192-30

620 1820 0301 12192-12

620 2020 0600 12192-31

620 2020 0301 12192-17

720 2020 0600 12192-27

720 2020 0301 12192-22

X1L1

Width (L) 420 520 620 720

Centre between the connections at the bottom 18 (R) 200 300 400 500


38

X2L1

Width (L) 420 520 620 720



Xtend Vertical Lacquered (X1L1, X2L1)

Types

• Single (X1L1) and double (X2L1)

Colours




Xtend

Special

• The Xtend Vertical Lacquered is available with a lacquered front

plate (this means steel plate radiator + lacquered front plate).

X1L1

Brackets

• Wall brackets in the colour RAL 7016 (anthracite grey) standard. Also in

option available in the colour S600 (see p. 46).

Technical

• Electrically welded by means of resistance welding robots (invisible

weld seams)








Connection








✔

✘

✘

✘

✘

✔

✔

✘

X2L1

return

supply

ref. nr. 128210300000099



• Stock radiators in S600 and M301: 5 working days


X1L1

X2L1

L-108

L-218

L-108

L-218

80

119

H-241

28 60 68

H

1/2” 16

50

1/2” 55

50

42.5

50

R

L

89

R

L

28 60 68

H-241

H

39

Xtend Vertical Stainless steel (X1L1-I, X2L1-I)

type

ref. nr.

12256

X1L1-I

ref. nr.

12257

X2L1-I

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

520 1820 820 1031 1,30 30,25 4,50 - -

520 2020 890 1119 1,30 32,60 4,95 - -

620 1820 947 1191 1,30 35,50 4,40 - -

620 2020 987 1241 1,30 39,55 5,90 - -

520 1820 1321 1670 1,33 48,80 8,80 - -

520 2020 1440 1817 1,32 54,05 9,85 - -

620 1820 1588 2008 1,33 57,30 10,60 - -

620 2020 1685 2123 1,31 62,85 11,85 - -


stock radiators (stainless steel)

type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

X1L1-I 520 1820 9993 12256-01

X1L1-I

Width (L) 520 620

Centre between the connections at the bottom 18 (R) 300 400


40

X2L1-I

Width (L) 520 620



Xtend Vertical Stainless steel (X1L1-I, X2L1-I)

Types

• Single (X1L1-I) and double (X2L1-I)

Colours

• Stainless steel type 316L, matt brushed with grain 360

Xtend

Special

• The Xtend Vertical Stainless steel is available with a front plate in

stainless steel (this means steel plate radiator + front plate in stainless

steel).

• The Xtend Vertical Stainless steel is standard delivered with a

maintenance product for stainless steel.

• This maintenance product can not be delivered subsequently by

THERMIC.

X1L1-I

Brackets

• Wall brackets in the colour RAL 7016 (anthracite grey) standard. Also

in option available in the colour S600 (see p. 46).

Technical


weld seams)



X2L1-I

return supply





✘

✘

✘

ref. nr. 128210300009993


Connection








✘

✘

✔

✔

✘


• Stock radiators in stainless steel: 5 working days


X1L1-I

X2L1-I

L-108

L-218

L-108

L-218

80

119

H-241

28 60 68

H

1/2” 16

50

1/2” 55

50

42.5

50

R

L

89

R

L

28 60 68

H-241

H

41

Xtend Horizontal Lacquered (XH1L1, XH2L1, XH2L2)

type

ref. nr.

12193

XH1L1

ref. nr.

12194

XH2L1

ref. nr.

12195

XH2L2

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

520 450 301 376 1,26 7,50 1,19 - -

620 550 425 531 1,26 11,11 1,66 - -

620 650 490 613 1,27 13,28 1,92 - -

820 550 562 702 1,26 14,69 2,20 - -

820 650 649 812 1,27 17,56 2,53 - -

1020 550 699 873 1,26 18,28 2,73 - -

1020 650 807 1010 1,27 21,85 3,15 - -

1020 950 1124 1409 1,28 31,85 4,40 - -

1220 550 836 1044 1,26 21,86 3,27 - -

1220 650 965 1207 1,27 26,13 3,77 - -

1220 950 1344 1684 1,28 38,10 5,26 - -

620 550 611 766 1,28 17,25 3,27 - -

620 650 708 886 1,27 20,70 3,83 - -

820 550 809 1014 1,28 22,81 4,32 - -

820 650 936 1171 1,27 27,37 5,07 - -

1020 550 1006 1261 1,28 28,38 5,38 - -

1020 650 1165 1457 1,27 34,05 6,30 - -

1020 950 1630 2050 1,30 50,20 9,05 - -

1220 550 1203 1508 1,28 33,94 6,43 - -

1220 650 1393 1743 1,27 40,72 7,54 - -

1220 950 1950 2452 1,30 60,05 10,82 - -

1420 550 1400 1754 1,28 39,50 7,48 - -

1420 650 1622 2029 1,27 47,40 8,78 - -

1620 550 1597 2001 1,28 45,07 8,54 - -

1620 650 1850 2314 1,27 54,08 10,01 - -

678 550 804 1009 1,29 20,50 3,40 - -

678 650 941 1181 1,29 24,28 3,93 - -

878 550 1041 1307 1,29 26,55 4,40 - -

878 650 1219 1530 1,29 31,44 5,09 - -

1078 550 1279 1606 1,29 32,60 5,40 - -

1078 650 1496 1878 1,29 38,60 6,25 - -

1078 950 2027 2549 1,30 57,90 9,00 - -

1278 550 1516 1903 1,29 38,65 6,40 - -

1278 650 1774 2227 1,29 45,77 7,41 - -

1278 950 2403 3022 1,30 68,64 10,67 - -

1478 550 1753 2201 1,29 44,69 7,40 - -

1478 650 2051 2575 1,29 52,93 8,57 - -

1678 550 1990 2498 1,29 50,74 8,41 - -

1678 650 2329 2924 1,29 60,09 9,73 - -



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

XH1L1 520 450 0600 12193-01

XH2L1 1020 550 0600 12194-08

1020 650 0600 12194-23

XH2L2 1078 550 0600 12195-17

1078 650 0600 12195-22

XH1L1

Height (H) 450 550 650 950

Centre between the lateral connections 23/67 (R) 345 445 545 845


XH2L1

Height (H) 550 650 950

Centre between the lateral connections 23/67 (R) 445 545 845


42

XH2L2

Height (H) 550 650 950

Centre between the lateral connections 23/67 (R) 445 545 845


Xtend Horizontal Lacquered (XH1L1, XH2L1, XH2L2)

Types

• XH1L1, XH2L1, XH2L2

Colours




Xtend

Special

• The Xtend Horizontal Lacquered is available with 1

(XH1L1, XH2L1) or 2 rows (XH2L2) of steel fins at the back of

the tubes in order to increase the heat output.

• XH1L1 also available as toilet radiator (520 x 450 mm)

Brackets

• Wall brackets in the colour ral 7016 (anthracite grey) standard.

Also in option available in the colour S600 (see p. 46).

Technical

• Electrically welded by means of resistance welding robots

(invisible weld seams)








✘

✘

✘

Connection




(connection by way of the integrated valve) (see p. 194)



Integrated valve (see p. 196)

✘

✘

✔

✔

✔

XH1L1 / XH2L1

XH2L2

DelivERY terms Transport duration not included !



XH1L1 / XH2L1

XH2L2

L-178

L-120

L-200

L-258

95

128

58

75

58

H

37 R

68

1/2"

1/2"

L-20

L

3/4" 50 3/4

1/2"

1/2"

41

75

H

37 68

R

1/2"

1/2"

L-78

L

3/4

50

3/4

1/2"

1/2"

70

43

Xtend Soft Vertical (XS1L1, XS2L1)

type

ref. nr.

12197

XS1L1

ref. nr.

12198

XS2L1

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

440 1220 547 688 1,30 17,30 2,50 - -

440 1820 765 969 1,34 24,09 3,70 - -

440 2020 842 1074 1,38 26,46 4,08 - -

440 2220 919 1178 1,41 28,41 4,44 - -

540 1220 614 771 1,29 19,87 2,90 - -

540 1820 948 1201 1,34 29,83 4,59 - -

540 2020 1043 1330 1,38 32,75 5,05 - -

540 2220 1138 1459 1,41 35,17 5,49 - -

640 1220 680 852 1,28 22,43 3,30 - -

640 1820 1130 1431 1,34 35,56 5,47 - -

640 2020 1243 1585 1,38 39,05 6,03 - -

640 2220 1356 1739 1,41 41,94 6,55 - -

740 1820 1312 1662 1,34 41,30 6,35 - -

740 2020 1444 1842 1,38 45,35 7,00 - -

740 2220 1575 2019 1,41 48,70 7,60 - -

440 1220 891 1140 1,40 27,60 4,90 - -

440 1820 1203 1518 1,32 38,61 7,32 - -

440 2020 1297 1631 1,30 42,35 8,08 - -

440 2220 1391 1740 1,27 46,61 8,81 - -

540 1220 1013 1290 1,37 31,58 5,68 - -

540 1820 1489 1879 1,32 47,81 9,06 - -

540 2020 1606 2020 1,30 52,43 10,00 - -

540 2220 1723 2155 1,27 57,70 10,90 - -

640 1220 1136 1439 1,34 35,57 6,47 - -

640 1820 1776 2241 1,32 57,00 10,81 - -

640 2020 1915 2408 1,30 62,51 11,92 - -

640 2220 2054 2569 1,27 68,80 13,00 - -

740 1820 2062 2602 1,32 66,20 12,55 - -

740 2020 2224 2797 1,30 72,60 13,85 - -

740 2220 2385 2983 1,27 79,90 15,10 - -

* New *

height 1220 mm



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

XS1L1 540 1220 0600 12197-04

540 1820 0600 12197-01

540 2020 0600 12197-05

640 1820 0600 12197-02

640 2020 0600 12197-03

XS2L1 540 1820 0600 12198-01

540 2020 0600 12198-02

640 1220 0600 12198-07

640 1820 0600 12198-03

640 2020 0600 12198-04

740 2020 0600 12198-05

XS1L1

Width (L) 440 540 640 740



44

XS2L1

Width (L) 440 540 640 740



Xtend Soft Vertical (XS1L1, XS2L1)

Types

• Single (XS1L1) and double (XS2L1)

Colours




Special

• The Xtend Soft Vertical is available with a lacquered front plate

(this means steel plate radiator + lacquered front plate).

• With a flat front plate and rounded sides as a modern-day touch

Brackets

• Wall brackets in the colour RAL 7016 (anthracite grey) standard. Also

in option available in the colour S600 (see p. 46).

XS1L1

Xtend Soft

Technical


weld seams)




XS2L1

return supply





✘

✘

✘

ref. nr. 128210300000099


Connection








✘

✘

✔

✔

✘




XS1L1

L-238

XS2L1

L-238

80

42,5

119

81,5

28 60 68

H-241

1/2”

16

50

H

50

R

L

28 60 68

H-241

1/2”

55

89

H

R

L

50

45

Xtend Brackets

In option

Brackets HEIGHT RADIATOR COLOUR REF.NR.

X1L1 / X1L1-I / XS1L1

1820 mm S600 128710417000600

Wall bracket

2020 mm S600 128710419000600

2220 mm S600 128710421000600

X2L1 / X2L1-I / XS2L1

1820 mm S600 128710517000600

Wall bracket

2020 mm S600 128710519000600

2220 mm S600 128710521000600

XH1L1

450 mm S600 128710204000600

Wall bracket

550 mm S600 128710205000600

650 mm S600 128710206000600

950 mm S600 128710209000600

XH2L1 / XH2L2

550 mm S600 128710305000600

Wall bracket

650 mm S600 128710306000600

950 mm S600 128710309000600

46

Xtend Accessories

In option

ACCESSORIES WIDTH TOWEL RAIL COLOUR REF.NR.

TOWEL RAIL IN

TRANSPARENT

GLASS

X1L1 / X1L1-I

700 mm 128320200000000

900 mm 128320400000000

1200 mm 128320000000000

Xtend

• Towel rail needs to be mounted to the wall. h = 70 mm; b = 700, 900, 1200 mm; d = 135 mm; a = 45 mm; glass thickness = 10 mm

X1L1 / X1L1-I

700 mm 128320300000000

TOWEL RAIL IN

900 mm 128320500000000

FROSTED GLASS

1200 mm 128320100000000

• Towel rail needs to be mounted to the wall. h = 70 mm; b = 700, 900, 1200 mm; d = 135 mm; a = 45 mm; glass thickness = 10 mm

X1L1 / X1L1-I

440 mm CHROME 128321300000099

TOWEL RAIL

540 mm CHROME 128321400000099

640 mm CHROME 128321500000099

740 mm CHROME 128321600000099

• h = 25 mm; b = 440, 540, 640, 740 mm; d = 73 mm; a = 57 mm

X2L1 / X2L1-I

440 mm CHROME 128321800000099

TOWEL RAIL

540 mm CHROME 128321900000099

640 mm CHROME 128322000000099

740 mm CHROME 128322100000099

• h = 25 mm; b = 440, 540, 640, 740 mm; d = 73 mm; a = 57 mm

XH1L1 / XH2L1 / XH2L2

CHROME 128321700000099

TOWEL RAIL


TOWEL RAIL

X1L1 / X1L1-I / XS1L1

ALUMINIUM 128323900000000


• h = 55 mm; b = 326 mm; d = 57 mm; a = 51 mm

TOWEL RAIL

X2L1 / X2L1-I / XS2L1

ALUMINIUM 128324000000000


• h = 55 mm; b = 326 mm; d = 57 mm; a = 51 mm




47

Xtend Connections

Xtend Vertical Lacquered: X1L1/X2L1

Xtend Vertical Stainless steel: X1L1-I/X2L1-I

Xtend Soft Vertical: XS1L1/XS2L1

4 5

4 5

4 5

1 MM 8

1 MM 8

1 MM 8

1188 1188 1188

• Attention: MM with supply on the right (on this connection, there is a flow tube at the back).



Xtend Horizontal Lacquered: XH1L1/XH2L1/XH2L2

3

6

2

7

8

0098

3

6

3

6

3

6

3

6

2

7

2

7

2

7

2

7

0098

8

8

8

8

0098 0098 0098

3

6

3

6

3

6

3

6

2

7

2

7

2

7

2

7

8

8

8

8

0098 0098 0098 0098

• Thermostatic head only to use with connection on the valve (supply left, return right). Other connections,

eg. 23, take thermostatic head out of connection 6. Here the possibility to change the supply and the

return.



48

Zana COLLECTION

ZV-1 / ZV-2 Zana Vertical 50

ZV-R Zana Curved 53

ZH-1 / ZH-2 Zana Horizontal 55

ZV-O Zana half round 58

ZV-A Zana with angle 60

ZBD Zana Bathroom 62

Libra LU / Libra LD / Libra LL / Libra LR Zana Libra 64

Multi 1 / Multi 2 Zana Multi 67

Plinth Zana Plinth 70

Zana

Free-standing installation 72



49

Zana Vertical (ZV-1)

type

ref. nr.

12254

ZV-1

tubes

(n)

width

height (H mm)

(L mm)

1400 1600 1800 2000 2200 2400 2600 2800 3000

75/65/20 680 769 859 950 1042 1136 1231 1327 1426

90/70/20 848 959 1071 1184 1299 1416 1534 1655 1777

75/65/20 850 962 1074 1188 1303 1420 1539 1659 1782

90/70/20 1060 1199 1339 1481 1624 1770 1918 2068 2222

75/65/20 1020 1154 1289 1425 1563 1704 1846 1991 2139

90/70/20 1272 1439 1607 1777 1949 2124 2301 2482 2666

75/65/20 1190 1346 1504 1663 1824 1988 2154 2323 2495

90/70/20 1484 1678 1874 2073 2274 2478 2685 2896 3110

75/65/20 1360 1539 1719 1900 2085 2272 2462 2655 2852

90/70/20 1696 1918 2142 2369 2599 2832 3068 3309 3555

75/65/20 1531 1731 1933 2138 2345 2555 2769 2987 3208

90/70/20 1908 2158 2410 2665 2923 3185 3452 3723 3999

75/65/20 1701 1923 2148 2375 2606 2839 3077 3319 3564

90/70/20 2120 2398 2678 2961 3248 3539 3836 4137 4443

75/65/20 1871 2116 2363 2613 2866 3123 3385 3650 3921

90/70/20 2332 2637 2946 3257 3573 3893 4219 4550 4887

75/65/20 2041 2308 2578 2850 3127 3407 3692 3982 4277

90/70/20 2544 2877 3213 3553 3898 4247 4603 4964 5332

75/65/20 2211 2500 2793 3088 3388 3691 4000 4314 4634

90/70/20 2756 3117 3481 3849 4223 4601 4986 5378 5776

Watt/el. (75/65/20°C) 85,03 96,17 107,41 118,77 130,29 141,97 153,85 165,93 178,22

Weight, kg/el. 2,27 2,59 2,90 3,21 3,51 3,82 4,13 4,43 4,74

Water content, l/el. 1,03 1,18 1,33 1,46 1,59 1,72 1,85 1,98 2,11

n-exponent 1,27 1,27 1,28 1,28 1,28 1,29 1,29 1,29 1,29

8 304

10 384

12 464

14 544

16 624

18 704

20 784

22 864

24 944

26 1024



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

ZV-1 384 1800 9016 12254-08

384 1800 0301 12254-04

464 1800 9016 12254-09

464 1800 0301 12254-01

544 1800 9016 12254-18

544 1800 0301 12254-14

544 2000 9016 12254-19

544 2000 0301 12254-21

624 1800 9016 12254-25

624 1800 0301 12254-27

704 2000 9016 12254-31

704 2000 0301 12254-33

50

ZV-1 / ZV-2

Number of tubes (n) 8 10 12 14 16 18 20 22 24 26

Width (L) 304 384 464 544 624 704 784 864 944 1024

Centre between the connections at the bottom 18 (R1) 240 320 400 480 560 640 720 800 880 960

Height (H) 1400 1600 1800 2000 2200 2400 2600 2800 3000

Centre between the lateral connections 23/67 (R2) 1365 1565 1765 1965 2165 2365 2565 2765 2965


Zana Vertical (ZV-1, ZV-2)

Types

• One (ZV-1) or two rows (ZV-2)

Tubes


Zana

Collectors

• Horizontal, rear, round Ø 35 mm

Colours





ZV-1

Special

• ZV-1 also available as free-standing radiator

Brackets


Technical

• Electrically laser welded (invisible weld seams)




ZV-2

return

supply





✘

✘

✘

ref. nr. 128210300000099


Connection


(order as special radiator) (see p. 194)








✔

✔

✔

✔

✘




L-184

L-184

118

54

166

103

50

H-35

H-35

60

H

R2

1/2” 1/2”

19

54

60

68

103

50

R1

L

82

51

Zana Vertical (ZV-2)

type

ref. nr.

12255

ZV-2

tubes

(n)

width

height (H mm)

(L mm)

1400 1600 1800 2000 2200 2400 2600 2800 3000

75/65/20 1105 1242 1379 1515 1651 1788 1925 2062 2200

90/70/20 1377 1548 1719 1889 2059 2229 2399 2570 2742

75/65/20 1381 1553 1724 1894 2064 2235 2406 2577 2750

90/70/20 1721 1935 2148 2361 2573 2786 2999 3213 3427

75/65/20 1657 1863 2068 2273 2477 2682 2887 3093 3300

90/70/20 2066 2322 2578 2833 3088 3343 3599 3855 4113

75/65/20 1933 2174 2413 2651 2890 3129 3368 3608 3849

90/70/20 2410 2710 3008 3305 3603 3900 4198 4498 4798

75/65/20 2209 2484 2758 3030 3303 3576 3849 4124 4399

90/70/20 2754 3097 3437 3777 4117 4457 4798 5140 5484

75/65/20 2486 2795 3102 3409 3716 4023 4330 4639

90/70/20 3098 3484 3867 4249 4632 5014 5398 5783

75/65/20 2762 3105 3447 3788 4129 4470 4812

90/70/20 3443 3871 4297 4722 5146 5572 5998

75/65/20 3038 3416 3792 4167 4541

90/70/20 3787 4258 4727 5194 5661

75/65/20 3314 3726 4136 4545

90/70/20 4131 4645 5156 5666

75/65/20 3590 4037 4481

90/70/20 4475 5032 5586

Watt/el. (75/65/20°C) 138,09 155,26 172,35 189,39 206,43 223,48 240,58 257,73 274,96

Weight, kg/el. 4,40 5,02 5,64 6,25 6,85 7,46 8,06 8,67 9,27

Water content, l/el. 2,02 2,30 2,58 2,91 3,24 3,57 3,89 4,22 4,55

n-exponent 1,30 1,30 1,30 1,30 1,30 1,30 1,30 1,30 1,30

8 304

10 384

12 464

14 544

16 624

18 704

20 784

22 864

24 944

26 1024


stock radiators (RAL 9016)

type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

ZV-2 544 2000 9016 12255-01

704 2000 9016 12255-07

52

Zana Rond (ZV-R)

Tubes


Collectors


Zana

Colours





Special

• The vertical tubes of type ZV-R are slightly bent (10°).

ZV-R

return

supply

Brackets


ref. nr. 128210300000099


Technical









✘

✘

✘

Connection








✘

✘

✔

✔

✘



265

136

72

L

136

72

265

L

136

H-35

H

ZV-R

Number of tubes (n) 12 16

Width (L) 485 648


Centre between the brackets H-35

60

37

72

L

50

53

Zana Rond (ZV-R)

type

ref. nr.

12244

ZV-R

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

485 1600 1154 1444 1,27 31,08 14,16 12 -

485 1800 1289 1615 1,28 34,80 15,96 12 -

485 2000 1425 1786 1,28 38,52 17,52 12 -

485 2200 1563 1959 1,28 42,12 19,08 12 -

648 1600 1539 1925 1,27 41,44 18,88 16 -

648 1800 1719 2154 1,28 46,40 21,28 16 -

648 2000 1900 2381 1,28 51,36 23,36 16 -

648 2200 2085 2613 1,28 56,16 25,44 16 -


ZH-1 / ZH-2

Width (L) 704 784 864 944 1024 1104 1184 1264 1424 1584 1744 1904 2064 2224 2384 2544 2704 2864

Centre between the connections at the bottom 18 (R1) 640 720 800 880 960 1040 1120 1200 1360 1520 1680 1840 2000 2160 2320 2480 2640 2800

Height (H) 500 600 700

Centre between the lateral connections 23/67 (R2) 465 565 665


54

Zana Horizontal (ZH-1, ZH-2)

Types

• One (ZH-1) or two rows (ZH-2)

Tubes


• Attention: horizontal design, but always with vertical tubes !

Zana

Collectors


Colours





Special

• ZH-1 also available as toilet radiator (384 x 500 mm)

Brackets


Technical









✘

✘

✘

Connection









✔

✔

✘

✔

✘

ZH-1

return

supply

ref. nr. 128210100000099


ZH-2



L-184

L-184

54

118

103

166

H-35

H-35

H

R2

R1

L

55

Zana Horizontal (ZH-1)

type

ref. nr.

12252

ZH-1

tubes (n)

width

height (H mm)

(L mm)

500 600 700

10 384

75/65/20 347

90/70/20 432

18 704

75/65/20 624 728 831

90/70/20 778 908 1035

20 784

75/65/20 694 809 923

90/70/20 865 1009 1150

22 864

75/65/20 763 890 1015

90/70/20 951 1110 1265

24 944

75/65/20 832 971 1107

90/70/20 1038 1210 1380

26 1024

75/65/20 902 1052 1200

90/70/20 1124 1311 1495

28 1104

75/65/20 971 1133 1292

90/70/20 1210 1412 1610

30 1184

75/65/20 1040 1214 1384

90/70/20 1297 1513 1725

32 1264

75/65/20 1110 1295 1476

90/70/20 1383 1614 1840

36 1424

75/65/20 1248 1457 1661

90/70/20 1556 1816 2071

40 1584

75/65/20 1387 1618 1846

90/70/20 1729 2017 2301

44 1744

75/65/20 1526 1780 2030

90/70/20 1902 2219 2531

48 1904

75/65/20 1665 1942 2215

90/70/20 2075 2421 2761

52 2064

75/65/20 1803 2104 2399

90/70/20 2248 2623 2991

56 2224

75/65/20 1942 2266 2584

90/70/20 2421 2824 3221

60 2384

75/65/20 2081 2428 2768

90/70/20 2594 3026 3451

64 2544

75/65/20 2220 2589 2953

90/70/20 2767 3228 3681

68 2704

75/65/20 2358 2751 3138

90/70/20 2940 3430 3911

72 2864

75/65/20 2497 2913 3322

90/70/20 3113 3631 4141

Watt/el. (75/65/20°C) 34,68 40,46 46,14

Weight, kg/el. 0,90 1,05 1,20

Water content, l/el. 0,41 0,47 0,54

n-exponent 1,25 1,25 1,25


56

Zana Horizontal (ZH-2)

type

ref. nr.

12253

ZH-2

tubes

(n)

width

height (H mm)

(L mm)

500 600 700

75/65/20 1035 1205 1372

90/70/20 1290 1502 1711

75/65/20 1150 1339 1525

90/70/20 1433 1669 1901

75/65/20 1265 1473 1677

90/70/20 1576 1836 2091

75/65/20 1380 1607 1830

90/70/20 1720 2003 2281

75/65/20 1494 1741 1982

90/70/20 1863 2170 2471

75/65/20 1609 1875 2135

90/70/20 2006 2337 2661

75/65/20 1724 2009 2287

90/70/20 2150 2504 2851

75/65/20 1839 2143 2440

90/70/20 2293 2671 3041

75/65/20 2069 2411 2745

90/70/20 2579 3005 3421

75/65/20 2299 2678 3050

90/70/20 2866 3339 3801

75/65/20 2529 2946 3355

90/70/20 3153 3673 4182

75/65/20 2759 3214 3660

90/70/20 3439 4006 4562

75/65/20 2989 3482 3964

90/70/20 3726 4340 4942

75/65/20 3219 3750 4269

90/70/20 4012 4674 5322

75/65/20 3449 4018 4574

90/70/20 4299 5008 5702

75/65/20 3679 4285 4879

90/70/20 4586 5342 6082

75/65/20 3909 4553 5184

90/70/20 4872 5676 6462

75/65/20 4139 4821

90/70/20 5159 6010

Watt/el. (75/65/20°C) 57,48 66,96 76,24

Weight, kg/el. 1,69 1,98 2,28


n-exponent 1,28 1,28 1,28

18 704

20 784

22 864

24 944

26 1024

28 1104

30 1184

32 1264

36 1424

40 1584

44 1744

48 1904

52 2064

56 2224

60 2384

64 2544

68 2704

72 2864


Zana

57

Zana half-round (ZV-O)

type

ref. nr.

12242

ZV-O

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

393 1400 1294 1616 1,26 36,70 16,50 16 -

393 1800 1610 2010 1,26 45,40 23,45 16 -

393 2000 1758 2195 1,26 49,75 26,93 16 -

393 2200 1901 2374 1,26 54,10 30,40 16 -

473 1400 1684 2103 1,26 43,95 20,65 20 -

473 1800 2094 2606 1,24 55,35 26,15 20 -

473 2000 2287 2846 1,24 61,05 28,90 20 -

473 2200 2473 3072 1,23 66,75 31,65 20 -



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

ZV-O 393 1800 9016 12242-10

393 1800 0301 12242-08

160 160

R150

R190

H-35

H

H-35

H

ZV-O

Width (L) 393 473



64

214

R

L

64

253 R

L

58

Zana half-round (ZV-O)

Tubes


Collectors


Zana

Colours





Special

• Available in 2 versions: R150 and R190

Brackets


Technical









✘

✘

✘

Connection







✘

✘

✘

✔

✘

ZV-O

return

supply




ref. nr. 128210100000099


59

Zana quarter-round (ZV-A)

type

ref. nr.

12237

ZV-A

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

268 1200 588 734 1,26 15,60 7,10 8 -

268 1400 672 839 1,26 17,85 8,25 8 -

268 1800 840 1051 1,27 22,35 10,55 8 -

268 2000 923 1157 1,28 24,60 11,70 8 -

268 2200 1007 1262 1,28 26,85 12,85 8 -

322 1200 751 938 1,26 20,05 8,88 10 -

322 1400 857 1070 1,26 22,90 10,30 10 -

322 1800 1071 1335 1,25 28,60 13,15 10 -

322 2000 1177 1467 1,25 31,45 14,58 10 -

322 2200 1283 1599 1,25 34,30 16,00 10 -


134

54

179

83

R190

H

H-35

H

H-35

210

254

55

R150

58

60

ZV-A

Width (L) 268 322



R

L

R

L

Zana quarter-round (ZV-A)

Tubes


Collectors


Zana

Colours





Special

• Available in 2 versions: R150 and R190

ZV-A

return

supply

Brackets


Technical





ref. nr. 128210100000099






✘

✘

✘

Connection







✘

✘

✘

✔

✘



61

Zana Bathroom (ZBD)

type

ref. nr.

12248

ZBD

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

500 984 658 810 1,18 19,35 8,80 21 500

600 984 788 967 1,16 22,10 10,40 21 750

500 1504 976 1204 1,19 29,45 12,35 32 1000

600 1504 1151 1415 1,17 33,70 15,80 32 1250

500 1824 1189 1467 1,19 35,67 14,53 40 1250

600 1824 1383 1703 1,18 40,84 19,12 40 1500



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

ZBD 600 1504 9016 12248-01

600 1504 0301 12248-07

600 1824 9016 12248-02

600 1824 0301 12248-12

L-155

1/2" 1/2"

1/2" 1/2"

72

99-118

34-54

1/2"

1/2"

H-144

H = 984

H = 1504

H = 1824

ZBD

Width (L) 500 600



72

1/2"

R

L

1/2" 1/2"

R

1/2" 1/2"

R

1/2"

L

L

62

Zana Bathroom (ZBD)

Tubes

• Horizontal, rectangular 45 x 20 mm

Collectors

• Vertical, rear, round Ø 35 mm

Zana

Colours





Brackets


ZBD

return

supply

Technical





ref. nr. 128210100000099






✔

✔

✔

Connection







• For connection at the top 45, 54 a special flow tube has to be ordered separately, which needs to be

mounted in the return, see p. 197.




✘

✘

✘

✔

✘

63

Zana Libra (Libra LU, Libra LD, Libra LL, Libra LR)

type

ref. nr.

12241

Libra LU

ref. nr.

12238

Libra LD

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

384 900 738 920 1,25 18,70 8,40 10 -

384 1400 1032 1291 1,27 26,10 11,80 10 -

384 1800 1278 1602 1,28 31,90 13,60 10 -

464 900 886 1104 1,25 22,44 10,08 12 -

464 1400 1238 1549 1,27 31,32 14,16 12 -

464 1800 1534 1922 1,28 38,28 16,32 12 -

544 900 1034 1288 1,25 26,18 11,76 14 -

544 1400 1445 1807 1,27 36,54 16,52 14 -

544 1800 1789 2242 1,28 44,66 19,04 14 -

384 900 738 920 1,25 18,70 8,40 10 -

384 1400 1032 1291 1,27 26,10 11,80 10 -

384 1800 1278 1602 1,28 31,90 13,60 10 -

464 900 886 1104 1,25 22,44 10,08 12 -

464 1400 1238 1549 1,27 31,32 14,16 12 -

464 1800 1534 1922 1,28 38,28 16,32 12 -

544 900 1034 1288 1,25 26,18 11,76 14 -

544 1400 1445 1807 1,27 36,54 16,52 14 -

544 1800 1789 2242 1,28 44,66 19,04 14 -


77,5 L-155

77,5

34-54

L-144

H-144

99-119

353-373

99-119

34-54

H

77,5

L-155

77,5

1/2" 1/2"

353-373

77,5

H-155

77,5

34-54

353-373

77,5 H-155

77,5

34-54

99-119

H

R2

1/2" 1/2"

1/2" R1

1/2"

L

1-20

34-54

99-119

353-373

1-20

34-54

1/2" 1/2" 1/2" 1/2"

50

R1

L

64


Tubes


Collectors


Zana

Colours





Special

• 3 possibilities: Libra LU: angle on top, Libra LD: angle at the

bottom, Libra LL / Libra LR: angle left / right

Libra LD

Libra LU, Libra LD

return

supply

Brackets


Technical









Connection








✘

✘

✘

✘

✘

✔

✔

✘

ref. nr. 128210100000099


Libra LL, Libra LR

return

supply

ref. nr. 128210300000099




Libra LD

Width (L) 384 464 544

Centre between the connections at the bottom 18 (R1) 320 400 480

Height (H) 900 1400 1800



Libra LU

Width (L) 384 464 544


Height (H) 900 1400 1800



Libra LL

Width (L) 900 1400 1800


Height (H) 384 464 544

Centre between the lateral connections 67 (R2) 349 429 509


Libra LR

Width (L) 900 1400 1800


Height (H) 384 464 544

Centre between the lateral connections 23 (R2) 349 429 509


65


type

ref. nr.

12239

Libra LL

ref. nr.

12240

Libra LR

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

900 384 738 920 1,25 18,70 8,40 10 -

1400 384 1032 1291 1,27 26,10 11,80 10 -

1800 384 1278 1602 1,28 31,90 13,60 10 -

900 464 886 1104 1,25 22,44 10,08 12 -

1400 464 1238 1549 1,27 31,32 14,16 12 -

1800 464 1534 1922 1,28 38,28 16,32 12 -

900 544 1034 1288 1,25 26,18 11,76 14 -

1400 544 1445 1807 1,27 36,54 16,52 14 -

1800 544 1789 2242 1,28 44,66 19,04 14 -

900 384 738 920 1,25 18,70 8,40 10 -

1400 384 1032 1291 1,27 26,10 11,80 10 -

1800 384 1278 1602 1,28 31,90 13,60 10 -

900 464 886 1104 1,25 22,44 10,08 12 -

1400 464 1238 1549 1,27 31,32 14,16 12 -

1800 464 1534 1922 1,28 38,28 16,32 12 -

900 544 1034 1288 1,25 26,18 11,76 14 -

1400 544 1445 1807 1,27 36,54 16,52 14 -

1800 544 1789 2242 1,28 44,66 19,04 14 -


66

Zana Multi (Multi 1, Multi 2)

Types

• One (Multi 1) or two rows (Multi 2)

Tubes


Zana

Collectors


Colours





Special

• The Zana-Multi 1 consists of 1 row vertical tubes with an extra tube

on both sides.

Brackets


Technical









✘

✘

✘

Connection









✘

✘

✘

✔

✘

Multi 1 Multi 2

return

supply

ref. nr. 128210100000099


Zana Multi

Width (L) 464 544 624 704 784 864 944 1024 1104 1184 1264 1424 1584 1744 1904 2064 2224 2384 2544 2704

Centre between the connections at the bottom 18 (R1) 400 480 560 640 720 800 880 960 1040 1120 1200 1360 1520 1680 1840 2000 2160 2320 2480 2640

Height (H) 550 650 750


Centre between the brackets H-85 L-344

L-344

103

166

H-85

H

R2

103

R1

L

67

Zana Multi (Multi 1)

type

ref. nr.

12235

Multi 1

tubes

(n)

width

height (H mm)

(L mm)

550 650 750

75/65/20 520 592 664

90/70/20 647 738 828

75/65/20 606 691 775

90/70/20 754 862 966

75/65/20 693 790 886

90/70/20 862 985 1104

75/65/20 779 889 997

90/70/20 970 1108 1242

75/65/20 866 987 1107

90/70/20 1078 1231 1380

75/65/20 953 1086 1218

90/70/20 1185 1354 1518

75/65/20 1039 1185 1329

90/70/20 1293 1477 1656

75/65/20 1126 1284 1440

90/70/20 1401 1600 1795

75/65/20 1212 1382 1550

90/70/20 1509 1723 1933

75/65/20 1299 1481 1661

90/70/20 1616 1846 2071

75/65/20 1386 1580 1772

90/70/20 1724 1969 2209

75/65/20 1559 1777 1993

90/70/20 1940 2215 2485

75/65/20 1732 1975 2215

90/70/20 2155 2462 2761

75/65/20 1905 2172 2436

90/70/20 2371 2708 3037

75/65/20 2078 2370 2658

90/70/20 2586 2954 3313

75/65/20 2252 2567 2879

90/70/20 2802 3200 3589

75/65/20 2425 2765 3101

90/70/20 3017 3446 3865

75/65/20 2598 2962 3322

90/70/20 3233 3692 4141

75/65/20 2771 3160 3544

90/70/20 3448 3939 4417

75/65/20 2944 3357 3765

90/70/20 3664 4185 4693

75/65/20 3118 3555 3987

90/70/20 3879 4431 4969

Watt/el. (75/65/20°C) 43,30 49,37 55,37

Weight, kg/el. 1,08 1,23 1,37


n-exponent 1,24 1,25 1,25

12 464

14 544

16 624

18 704

20 784

22 864

24 944

26 1024

28 1104

30 1184

32 1264

36 1424

40 1584

44 1744

48 1904

52 2064

56 2224

60 2384

64 2544

68 2704

72 2864


68

Zana Multi (Multi 2)

type

ref. nr.

12236

Multi 2

tubes

(n)

width

height (H mm)

(L mm)

550 650 750

75/65/20 739 850 960

90/70/20 926 1066 1203

75/65/20 862 992 1120

90/70/20 1080 1243 1404

75/65/20 985 1134 1280

90/70/20 1235 1421 1605

75/65/20 1108 1276 1441

90/70/20 1389 1599 1805

75/65/20 1231 1417 1601

90/70/20 1543 1776 2006

75/65/20 1355 1559 1761

90/70/20 1698 1954 2206

75/65/20 1478 1701 1921

90/70/20 1852 2131 2407

75/65/20 1601 1843 2081

90/70/20 2006 2309 2608

75/65/20 1724 1984 2241

90/70/20 2160 2487 2808

75/65/20 1847 2126 2401

90/70/20 2315 2664 3009

75/65/20 1970 2268 2561

90/70/20 2469 2842 3209

75/65/20 2217 2551 2881

90/70/20 2778 3197 3610

75/65/20 2463 2835 3201

90/70/20 3086 3552 4012

75/65/20 2709 3118 3521

90/70/20 3395 3908 4413

75/65/20 2955 3402 3841

90/70/20 3704 4263 4814

75/65/20 3202 3685 4162

90/70/20 4012 4618 5215

75/65/20 3448 3969 4482

90/70/20 4321 4973 5616

75/65/20 3694 4252 4802

90/70/20 4630 5329 6017

75/65/20 3940 4536

90/70/20 4938 5684

75/65/20 4187 4819

90/70/20 5247 6039

75/65/20 4433

90/70/20 5556

Watt/el. (75/65/20°C) 61,57 70,87 80,03

Weight, kg/el. 1,83 2,11 2,39


n-exponent 1,28 1,28 1,28

12 464

14 544

16 624

18 704

20 784

22 864

24 944

26 1024

28 1104

30 1184

32 1264

36 1424

40 1584

44 1744

48 1904

52 2064

56 2224

60 2384

64 2544

68 2704

72 2864


Zana

69

Zana (Plinth)

type

ref. nr.

12243

Plinth

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

1000 254 462 574 1,23 13,21 4,86 4 -

1200 254 554 689 1,23 15,85 5,83 4 -

1400 254 647 804 1,23 18,49 6,80 4 -

1600 254 739 918 1,23 21,14 7,78 4 -

1800 254 832 1033 1,23 23,78 8,75 4 -

2000 254 924 1148 1,23 26,42 9,72 4 -

2200 254 1016 1263 1,23 29,06 10,69 4 -

2400 254 1109 1378 1,23 31,70 11,66 4 -

2600 254 1201 1492 1,23 34,35 12,64 4 -

2800 254 1294 1607 1,23 36,99 13,61 4 -

3000 254 1386 1722 1,23 39,63 14,58 4 -


128

L-35

254

82

1/2" 1/2"

R

L

70

Zana (Plinth)

Tubes


Collectors

• Vertical, round Ø 35 mm

Zana

Colours





Brackets


Technical









✘

✘

✘

Connection









✘

✘

✘

✔

✘

Plinth

return

supply

ref. nr. 128210100000099


Plinth

Width (L) 1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000

Centre between the connections at the bottom 18 (R) 927 1127 1327 1527 1727 1927 2127 2327 2527 2727 2927

71

Zana Free-standing installation

In option

Free-standing installation COLOUR REF.NR.

ZV-1

Free-standing

installation

RAL 9016 128100700009016

COLOUR

12810070000xxxx

• free-standing radiators in the colour RAL 9016 and Pergamon: 1 separate lateral support, 2 feet (H = 150

mm) and 2 rosets in the colour of the radiator.

• free-standing radiators in other colours: 1 separate lateral support, 2 feet (H = 150 mm) in the colour of

the radiator and 2 chrome plated rosets.

72

Zana Accessories

In option

ACCESSORIES WIDTH RADIATOR COLOUR REF.NR.

TOWEL RAIL

STRAIGHT

ZV / ZH / ZBD / LIBRA / MULTI

CHROME 128322800000099

Zana


ZV-R

TOWEL RAIL

CURVED

CHROME 128322900000099


ZV-O

Towel rail round

393 mm ALUMINIUM 128323200000000

473 mm ALUMINIUM 128323300000000

• Towel rail round ZV-O 393 mm; h = 40 mm; b = 518 mm; d = 65 mm ; a = 50 mm

• Towel rail round ZV-O 473 mm; h = 40 mm; b = 598 mm; d = 65 mm ; a = 50 mm

ZV-A

Towel rail round

268 mm ALUMINIUM 128323000000000

322 mm ALUMINIUM 128323100000000

• Towel rail round ZV-A 268 mm; h = 40 mm; b = 335 mm; d = 65 mm ; a = 50 mm

• Towel rail round ZV-A 322 mm; h = 40 mm; b = 386 mm; d = 65 mm ; a = 50 mm

ZV / ZV-R / ZH / ZV-O / ZV-A / ZBD / LIBRA / MULTI

HOOK O-RING

CHROME 128360300000099

• h = 22 mm; b = 22 mm; d = 42 mm

ZV / ZV-R / ZH / ZV-O / ZV-A / ZBD / LIBRA / MULTI

HOOK WITH A

WIDE GROOVE

CHROME 128340300000099

• h = 22 mm; b = 22 mm; d = 42 mm



73

Zana Connections

Zana Vertical: ZV-1/ZV-2 (stock)

Zana Horizontal: ZH-1/ZH-2

3

6

3

6

3

6

3

6

3

6

3

6

1 MM 8

1 MM 8

1 MM 8

1 MM 8

1 8

1 8

1188 1188 1188 1188

• Attention: connecting the radiator can only be as shown by the connecting

icons. For any other connection method, we take no responsibility.

3

0018 0018

6

3

6

3

6

3

6

Zana Vertical: ZV-1/ZV-2 (non stock)

2

7

2

7

2

7

2

7

3

6

3

6

3

6

3

6

0023 0023 0067 0067

3

6

3

6

3

6

3

6

1 8

1 8

MM

MM

2

7

2

7

2

7

2

7

0018 0018 0066 0066

0027 0027 0036 0036

3

6

3

6

3

6

3

6

3

6

3

6

3

6

3

6

2 7 2

7 2 7 2

7

0023 0023 0067 0067

2

7

2

7

2

7

2

7

4 5

4 5

0026 0026 0037 0037

3

6

3

6

4 5 4 5

2

7

2

7

2

7

2

7

0045 0045

3 6 3

6

0027 0027

3 6 3

6

2 7 2

7

0045 * 0045 *

2 7 2

7

0036 0036

2

7 2

7

0026 0026



* Not for toilet radiator ZH-1.

Zana half round: ZV-O / Zana with angle: ZV-A

3

6

3

6

2

7

2

7

5

5

0037 0037



Zana Curved: ZV-R

1 8

1 8

0018 0018



3

6

3

6

2 7 2

7

MM

MM

0066 0066



74


Zana Bathroom: zbd

4 5

4 5

4 5

4 5

Zana Libra: Libra lL

4 5

4 5

4 5

4 5

Zana

1 8

1 8

1 8

1 8

1

8

1 8

1 8

1 8

0018 0018 0018 0018



0018 0018

4

4

0045 0045

Zana Libra: Libra lu / Libra ld

6

6

7

7

1

1

3

6

3

6

3

6

3

6

0067 0067

1 8

1 8

MM

MM



0018 0018 0066 0066

Zana Libra: Libra lR

3

6

3

6

3

6

3

6

4

5

4 5

4 5

4 5

2 7 2

7 2 7 2

7

0023 0023 0067 0067

1

8

1 8

1 8

1 8

3 6 3

6 3 6 3

6

2

7

2

7

2 7 2

7

0018 0018

0045 0045

0027 0027 0036 0036

3

5

3

5

3 6 3

6

3

6

3

6

2

2

8

8

2

7 2

7

0026 0026 0037 0037



2

7

2

7

0023 0023



75


Zana Multi: multi 1 / multi 2

3

6

3

6

1 8

1 8

0018 0018

3

6

3

6

3

6

3

6

2

7

2

7

2

7

2

7

0023 0023 0067 0067

3

6

3

6

3

6

3

6

2

7

2

7

2

7

2

7

0027 0027 0036 0036

3

6

3

6

3

6

3

6

2

7

2

7

2

7

2

7

0026 0026 0037 0037



Zana Plinth: plintH

4

5

4 5

1

8

1 8

0018 0018



76

C-Line COLLECTION

C-BE Believe 78

C-RH C-RH 80

C-TA Taiyou 82

C-SI Sigma / Sigma-S 84

C-Line



77

C-Line Believe (C-BE)

type

ref. nr.

12129

C-BE

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

500 1212 932 1168 1,28 17,20 6,63 36 1000

600 1212 1092 1361 1,25 19,80 7,59 36 1000

400 1632 1018 1276 1,28 19,50 7,59 48 1000

500 1632 1237 1539 1,24 22,70 8,86 48 1250

600 1632 1457 1803 1,21 25,90 10,14 48 1500

600 2052 1758 2161 1,17 32,00 12,69 60 1500


78

C-BE

Width (L) 400 500 600

X 296,5 396,5 496,5


Centre between the brackets H-132

H-132

H-132

H

C-Line Believe (C-BE)

Tubes

• Horizontal, dynamically bent, round Ø 15 mm

Collectors

• Vertical, round Ø 35 mm, always 50 mm side by side

• By turning the radiator around his vertical axis, one can choose

whether the tubes are situated on the left or on the right side.

C-Line

Colours




C-BE

Special

• Also available as free-standing radiator

Brackets


Technical

• Welded by means of resistance welding robots (invisible weld

seams)




ref. nr. 128200100009016






✘

✔

✔

Connection


✘


✘

Two-point connection for one-pipe system (see p. 194) ✔


✔



✘





62

50

X

L

1/2” 1/2”

1/2” 1/2”

62

50

X

L

100-120

66

40-60

Ø35

1/2” 1/2”

H=1212

66

63

H=1632

H=2052

66

3/4"

40-60

47-67

1/2” 1/2”

50

L

1/2” 1/2”

50

L

1/2” 1/2”

50

L

66

62-82

70-90

79

C-Line C-RH (C-RH)

type

ref. nr.

12138

C-RH

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

400 792 470 588 1,27 9,00 3,20 22 500

500 792 582 719 1,20 10,60 3,90 22 500

600 792 693 846 1,13 12,20 4,60 22 500

400 1212 702 878 1,27 14,50 5,10 36 750

500 1212 869 1083 1,25 17,15 6,35 36 750

600 1212 1034 1278 1,20 19,80 7,60 36 1000

400 1632 955 1201 1,30 19,85 6,90 50 1000

500 1632 1181 1472 1,25 23,60 8,53 50 1250

600 1632 1406 1753 1,25 27,35 10,15 50 1500

400 2052 1236 1563 1,33 25,20 8,70 64 1250

500 2052 1529 1919 1,29 30,05 10,70 64 1500

600 2052 1820 2269 1,25 34,90 12,70 64 1500


80

C-RH

Width (L) 400 500 600

X 296,5 396,5 496,5



H-132

H

C-Line C-RH (C-RH)

Tubes


Collectors


• By turning the radiator around his vertical axis, one can choose

whether the tubes are situated on the left or on the right side.

C-Line

Colours




C-RH

Special

• Also available as free-standing radiator

Brackets


Technical


seams)




ref. nr. 128200100009016






✘

✔

✔

Connection


✘


✘


✔

(see p. 194)


✔



✘





62

50

X

L

1/2” 1/2”

1/2” 1/2”

62

50

X

L

1/2” 1/2”

40-60

66

100-120

H=2052

66 H- 132 66

63

3/4"

ø35

1/2” 1/2”

H=792

1/2” 1/2”

40-60

50

47-67

L

70-90

H=1212

1/2” 1/2”

50

L

H=1632

1/2” 1/2”

50

L

1/2” 1/2”

50

L

66

62-82

81

C-Line Taiyou (C-TA)

type

ref. nr.

12144

C-TA

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

1000 967 987 1217 1,19 21,00 8,55 38 750


82

C-TA

Width (L) 1000



H-117

H

C-Line Taiyou (C-TA)

Tubes


Collectors

• Vertical, round Ø 35 mm, always side by side

Colours





C-Line

Brackets


Technical

• Welded by means of resistance welding robots

(invisible weld seams)








✘

✔

✔

Connection




(see p. 194)




• For connection at the top 45, 54 a special flow tube has to be ordered separately, which

needs to be mounted in the return, see p. 197.



✘

✘

✔

✔

✘

C-TA

62

50

L

100-120

58,5

Ø35

1/2” 1/2”

ref. nr. 128200100009016


58,5

63

50

3/4"

1/2” 1/2”

50

40-60

47-67

70-90

83

C-Line Sigma / Sigma-S (C-SI)

type

ref. nr.

12142

C-SI

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

664 1717 1157 1460 1,32 20,60 8,40 68 1250


84

C-SI

Width (L) 664



C-Line Sigma / Sigma-S (C-SI)

Tubes


Collectors


Colours




Special

• Type Sigma-S is standard delivered with an integrated mirror

(width 160 mm). Ref. nr. 128510118000000

Brackets


C-SI

C-Line

Technical


seams)




ref. nr. 128200100009016






✘

✔

✔

Connection

One-point connection for one-pipe system ✘

One-point connection for two-pipe system ✘

Two-point connection for one-pipe system ✔

(see p. 194)

Two-point connection for two-pipe system ✔



✘

• For connection at the top 45, 54 a special flow tube has to be ordered

separately, which needs to be mounted in the return, see p. 197.



58,5

L

50

1/2" 1/2"

H-117

H = 1717

62

100-120

ø35

58,5

63

3/4"

40-60

47-67

70-90

1/2" 50

1/2"

85

C-Line Free-standing installation

In option


C-BE / C-RH

lateral support

RAL 9016 128100600009016

COLOUR 12810060000xxxx

M350 128100600000350

• The 2 lateral supports in the colour of the radiator are delivered.

C-Line Connections

C-Line: C-BE/C-RH/C-TA/C-SI

4 5

4 5

4 5

4 5

1 8

1 8

1 8

1 8

0018

0018 0018

0018



86

Bathroom COLLECTION

V-S / VZ-S Verso Lacquered 88

V-I / VZ-I Verso Stainless Steel 90

V-CHR / VZ-CHR Verso Chrome 92

HKM / HKRM Tripla 94

HX Ponti 96

HDM / HDRM Hedria 98

HRM / HR2 / HRBM Largo Lacquered 100

HRM-C / HRBM-C Largo Chrome 102

HZ / HZ2 Hazel 104

Bathroom




87

Bathroom Verso (V-S, VZ-S) Lacquered

type

ref. nr.

12123

V-S

ref. nr.

12126

VZ-S

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

450 744 356 444 1,25 6,45 2,55 21 300

500 744 389 487 1,27 6,87 2,67 21 300

600 744 455 574 1,32 7,70 2,90 21 300

750 744 552 704 1,38 8,95 3,25 21 500

450 1122 534 666 1,25 9,40 4,00 32 500

500 1122 585 729 1,25 10,07 4,18 32 500

600 1122 684 853 1,25 11,40 4,55 32 500

750 1122 828 1032 1,25 13,40 5,10 32 750

450 1338 638 800 1,28 11,38 4,76 40 500

500 1338 698 875 1,28 12,17 4,99 40 750

600 1338 816 1023 1,28 13,74 5,45 40 750

750 1338 989 1239 1,28 16,10 6,13 40 1000

450 1689 808 1020 1,32 14,60 6,00 50 750

500 1689 885 1113 1,30 15,58 6,30 50 1000

600 1689 1035 1297 1,28 17,55 6,90 50 1000

750 1689 1253 1562 1,25 20,50 7,80 50 1250

600 1959 1247 1571 1,31 20,65 8,20 60 1250

750 1959 1483 1849 1,25 24,40 9,20 60 1500

450 744 356 444 1,25 6,45 2,55 21 300

500 744 389 487 1,27 6,87 2,67 21 300

600 744 455 574 1,32 7,70 2,90 21 300

750 744 552 704 1,38 8,95 3,25 21 500

450 1122 534 666 1,25 9,40 4,00 32 500

500 1122 585 729 1,25 10,07 4,18 32 500

600 1122 684 853 1,25 11,40 4,55 32 500

750 1122 828 1032 1,25 13,40 5,10 32 750

450 1338 638 800 1,28 11,38 4,76 40 500

500 1338 698 875 1,28 12,17 4,99 40 750

600 1338 816 1023 1,28 13,74 5,45 40 750

750 1338 989 1239 1,28 16,10 6,13 40 1000

450 1689 808 1020 1,32 14,60 6,00 50 750

500 1689 885 1113 1,30 15,58 6,30 50 1000

600 1689 1035 1297 1,28 17,55 6,90 50 1000

750 1689 1253 1562 1,25 20,50 7,80 50 1250

600 1959 1247 1571 1,31 20,65 8,20 60 1250

750 1959 1483 1849 1,25 24,40 9,20 60 1500



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

V-S 600 1338 9016 12123-01

600 1689 9016 12123-02

FREE-STANDING V-S

Number of tubes (n) 21 32 40 50 60

H1 387 414 468 468 522

H2 270 594 702 1053 1215

V-S

Width (L) 450 500 600 750



88

VZ-S

Width (L) 446 496 595 744


Distance between wall and connection 1-8 (Z) 78-88 76-86 72-82 67-78


Bathroom Verso (V-S, VZ-S) Lacquered

Types

• Straight (V-S) and curved (VZ-S)

Tubes

• Horizontal, round Ø 15 mm

Collectors

• Vertical, semi-round Ø 42 mm

Colours




Special

• The horizontal tubes of type VZ-S are slightly bent (10°).

• V-S also available as free-standing radiator

Brackets


V-S

Bathroom

Technical





VZ-S

return

supply





✘

✔

✔

ref. nr. 128210300000099


Connection


(see p. 194)


(see p. 194)






• For connection at the bottom a flow tube is needed, this flow tube is standard delivered in the right

collector.




• Stock radiators in white (RAL 9016): 5 working days


✔

✔

✔

✔

✘

standard, folding chrome

plated drying and stacking

rack

10°

1/2"

L-140

1/2"

61,5

H-123

90

101-121

42

H-123 61,5

90

110-120

42

1/2"

H = 744

190 93 177 93 190

L-140

1/2"

H = 1122

217 93 204 93 204 93 217

1/2"

L-140

1/2"

H = 1338

271 93 258 93 258 93 271

1/2"

L-140

1/2"

H = 1689

271 93 258 93 258 93 258 93 271

1/2"

L-140

1/2"

H = 1959

325 93 312 93 312 93 312 93 325

H2

H1

60

H

61,5

1/2"

46-66

80-100

61,5

1/2"

Z

68-78

102-112

1/2"

50 1/2"

R

L

1/2"

50 1/2"

R

L

1/2"

50 1/2"

R

L

1/2"

50 1/2"

R

L

1/2"

50 1/2"

R

L

K=150

89

Bathroom Verso (V-I, VZ-I) Stainless Steel

type

ref. nr.

12122

V-I

ref. nr.

12125

VZ-I

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

450 744 259 322 1,24 5,85 2,70 21 -

600 744 334 417 1,26 6,90 3,05 21 300

450 1122 380 478 1,30 8,40 4,25 32 300

600 1122 490 616 1,30 10,00 4,78 32 500

450 1338 451 566 1,29 9,96 5,07 40 500

600 1338 581 731 1,30 11,96 5,78 40 500

750 1338 708 890 1,30 13,96 6,50 40 750

450 1689 571 716 1,28 12,50 6,40 50 500

600 1689 736 921 1,27 15,15 7,43 50 750

750 1689 896 1121 1,27 17,80 8,45 50 1000

450 744 259 322 1,24 5,85 2,70 21 -

600 744 334 417 1,26 6,90 3,05 21 300

450 1122 380 478 1,30 8,40 4,25 32 300

600 1122 490 616 1,30 10,00 4,78 32 500

450 1338 451 566 1,29 9,96 5,07 40 500

600 1338 581 731 1,30 11,96 5,78 40 500

750 1338 708 890 1,30 13,96 6,50 40 750

450 1689 571 716 1,28 12,50 6,40 50 500

600 1689 736 921 1,27 15,15 7,43 50 750

750 1689 896 1121 1,27 17,80 8,45 50 1000


stock radiators (stainless steel)

type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

V-I 600 1338 9993 12122-01

600 1689 9993 12122-02

FREE-STANDING V-I

Height (H) 744 1122 1338 1689

H2 540 918 1134 1485

V-I

Width (L) 450 600 750



90

VZ-I

Width (L) 446 595 744


Distance between wall and connection 1-8 (Z) 66,5-76,5 66,5-76,5 66,5-76,5

Distance between wall and middle of MM valve (M) 93-103 100-110 101-111

Distance between wall and front of the radiator (D) 101-111 107-117 108-118


Bathroom Verso (V-I, VZ-I) Stainless Steel

Types

• Straight (V-I) and curved (VZ-I)

Tubes


Collectors


Colours

• Stainless steel type 316L, matt brushed with grain 360

Special

• The horizontal tubes of type VZ-I are slightly bent (10°).

• V-I also available as free-standing radiator

• Standard with straight cover cap in stainless steel

Brackets


V-I

Bathroom

Technical




VZ-I

return

supply





✘

✔

✔

ref. nr. 128210300009993


Connection

One-point connection for one-pipe system (see p. 194)

One-point connection for two-pipe system (see p. 194)






• For connection at the bottom a flow tube is needed, this flow tube is standard delivered in the

right collector.

• For connection at the top 45, 54 a special flow tube has to be ordered separately, which needs to

be mounted in the return, see p. 197.


• Stock radiators in stainless steel: 5 working days


✔

✔

✔

✔

✘

10°

1/2"

1/2"

102

H-204

102

135

87,5

42

32-42

66,5-76,5

102 H-204

102

135

1/2" 1/2"

D

42

M

M-34

Z

H = 744

190 93 177 93 190

1/2"

1/2"

1/2"

H = 1122

217 93 204 93 204 93 217

1/2"

1/2"

H = 1338

271 93 258 93 258 93 271

1/2"

50 1/2"

1/2" 50 1/2"

1/2" 50 1/2"

1/2" 50 1/2"

R

R

R

R

L L L

L

1/2"

H = 1689

271 93 258 93 258 93 258 93 271

H2

H1= 252

45,5

H

K=150

91

Bathroom Verso (V-CHR, VZ-CHR) Chrome

type

ref. nr.

12121

V-CHR

ref. nr.

12124

VZ-CHR

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

450 744 235 293 1,25 6,95 2,60 21 -

600 744 311 388 1,26 8,35 2,95 21 300

450 1122 354 445 1,30 9,95 3,90 32 300

600 1122 468 589 1,30 12,05 4,48 32 500

450 1338 427 536 1,29 11,97 4,70 40 300

600 1338 565 711 1,30 14,47 5,39 40 500

750 1338 703 886 1,31 16,99 6,08 40 750

450 1689 556 697 1,28 15,25 6,00 50 500

600 1689 735 926 1,31 18,41 6,87 50 750

750 1689 915 1161 1,35 21,60 7,75 50 1000

450 744 235 293 1,25 6,95 2,60 21 -

600 744 311 388 1,26 8,35 2,95 21 300

450 1122 354 445 1,30 9,95 3,90 32 300

600 1122 468 589 1,30 12,05 4,48 32 500

450 1338 427 536 1,29 11,97 4,70 40 300

600 1338 565 711 1,30 14,47 5,39 40 500

750 1338 703 886 1,31 16,99 6,08 40 750

450 1689 556 697 1,28 15,25 6,00 50 500

600 1689 735 926 1,31 18,41 6,87 50 750

750 1689 915 1161 1,35 21,60 7,75 50 1000


stock radiators (chrome)

type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

V-CHR 600 1338 0099 12121-02

600 1689 0099 12121-03

VZ-CHR 600 1689 0099 12124-02

V-CHR

Width (L) 450 600 750



92

VZ-CHR

Width (L) 446 595 744


Distance between wall and connection 1-8 (Z) 78-88 72-82 68-78


Bathroom Verso (V-CHR, VZ-CHR) Chrome

Types

• Straight (V-CHR) and curved (VZ-CHR)

Tubes


Collectors


Colours

• Chrome plated radiators

V-CHR

Bathroom

Special

• The horizontal tubes of type VZ-CHR are slightly bent (10°).

• Standard with straight cover cap in chrome

Brackets


Technical








✘

✔

✔

VZ-CHR

return supply

ref. nr. 128210300000099


Connection








• For connection at the bottom a flow tube is needed, this flow tube is standard delivered in the

right collector.




• Stock radiators in chrome: 5 working days


✔

✔

✔

✔

✘



rack

10°

1/2"

L-140

1/2"

61,5 H-123

61,5

90

1/2"

101-121

42

46-66

61,5 H-123

61,5

90

1/2"

110-120

42

Z

68-78

H = 744

190 93 177 93 190

1/2"

1/2"

L-140

1/2"

H = 1122

217 93 204 93 204 93 217

1/2"

L-140

1/2"

H = 1338

271 93 258 93 258 93 271

1/2"

50 1/2"

1/2" 50 1/2"

1/2" 50 1/2"

1/2" 50 1/2"

R

R

R

R

L L L L

L-140

1/2"

H = 1689

271 93 258 93 258 93 258 93 271

80-100

102-112

93

Bathroom Tripla (HKM), HKRM)

type

ref. nr.

12174

HKM

ref. nr.

12176

HKRM

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

500 1010 530 663 1,27 10,35 5,30 21 500

600 1010 629 785 1,26 11,85 6,06 21 500

750 1010 775 964 1,24 14,08 7,18 21 750

900 1010 918 1140 1,23 16,30 8,30 21 1000

500 1406 716 896 1,27 13,90 7,20 29 750

600 1406 850 1063 1,27 15,80 8,31 29 750

750 1406 1047 1310 1,27 18,64 9,96 29 1000

900 1406 1240 1551 1,27 21,45 11,60 29 1250

500 1802 915 1145 1,27 17,65 9,30 37 1000

600 1802 1087 1357 1,26 19,97 10,67 37 1000

750 1802 1338 1671 1,26 23,42 12,72 37 1250

900 1802 1585 1976 1,25 26,85 14,75 37 1500

500 2022 1033 1292 1,27 19,80 10,55 42 1000

600 2022 1227 1535 1,27 22,56 12,06 42 1250

750 2022 1511 1887 1,26 26,67 14,31 42 1500

900 2022 1790 2231 1,25 30,75 16,55 42 1500

500 1010 530 663 1,27 10,35 5,30 21 500

600 1010 629 785 1,26 11,85 6,06 21 500

750 1010 775 964 1,24 14,08 7,18 21 750

900 1010 918 1140 1,23 16,30 8,30 21 1000

500 1406 716 896 1,27 13,90 7,20 29 750

600 1406 850 1063 1,27 15,80 8,31 29 750

750 1406 1047 1310 1,27 18,64 9,96 29 1000

900 1406 1240 1551 1,27 21,45 11,60 29 1250

500 1802 915 1145 1,27 17,65 9,30 37 1000

600 1802 1087 1357 1,26 19,97 10,67 37 1000

750 1802 1338 1671 1,26 23,42 12,72 37 1250

900 1802 1585 1976 1,25 26,85 14,75 37 1500

500 2022 1033 1292 1,27 19,80 10,55 42 1000

600 2022 1227 1535 1,27 22,56 12,06 42 1250

750 2022 1511 1887 1,26 26,67 14,31 42 1500

900 2022 1790 2231 1,25 30,75 16,55 42 1500



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

HKM 500 1406 9016 12174-03

500 1802 9016 12174-05

600 1010 9016 12174-02

600 1406 9016 12174-04

600 1802 9016 12174-06

HKRM 500 1406 9016 12176-02

500 1802 9016 12176-04

600 1406 9016 12176-03

600 1802 9016 12176-05

FREE-STANDING HKM

Height (H) 1010 1406 1802 2022

H2 836 1232 1628 1848

HKM

Width (L) 500 600 750 900



94

HKRM

Width (L) 496 596 745 893




Bathroom Tripla (HKM), HKRM)

Types

• Straight (HKM) and curved (HKRM)

Tubes


Collectors

• Vertical, triangular 56 x 34 mm

Colours




Special

• The horizontal tubes of type HKRM are slightly bent (10°).

• HKM also available as free-standing radiator

Brackets


Technical





HKM

HKRM

return supply

Bathroom





✔

✔

✔

ref. nr. 128210300000099


Connection








• For connection at the bottom a flow tube is needed, this flow tube is

standard delivered in the right collector.

• For connection at the top 45, 54 a special flow tube has to be ordered

separately, which needs to be mounted in the return, see p. 197.

✔

✔

✔

✔

✘



rack



• Non-stock radiators: 15 to 30 working days, dependent on the type of

radiator

10°

1/2"

L-150

1/2"

87 H-174

87

126

1/2"

97-117

34

46-66

80-100

87 H-174

87

126

114-124

34

1/2" Z

68-78

102-112

H = 1010

385 64 288 64 209

1/2"

1/2"

L-150

1/2"

H = 1406

429 64 332 64 244 64 209

1/2"

L-150

1/2"

H = 1802

473 64 332 64 288 64 244 64 209

1/2"

L-150

50 1/2"

1/2" 50 1/2"

1/2" 50 1/2"

1/2" 50 1/2"

R

R

R

R

L

L

L

L

1/2"

H = 2022

561 64 332 64 288 64 288 64 279

H2

H1 = 237

60

H

K=150

95

Bathroom Ponti (HX)

type

ref. nr.

12186

HX

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

500 1010 540 677 1,28 10,80 6,00 21 500

600 1010 632 792 1,28 12,16 6,80 21 500

750 1010 768 959 1,26 14,20 8,00 21 750

500 1406 745 934 1,28 14,75 8,40 29 750

600 1406 873 1092 1,27 16,63 9,50 29 750

750 1406 1060 1324 1,26 19,45 11,15 29 1000

500 1802 953 1194 1,28 19,00 10,90 37 1000

600 1802 1117 1392 1,25 21,32 12,14 37 1000

750 1802 1357 1680 1,21 24,80 14,00 37 1250

500 2022 1072 1341 1,27 21,40 12,20 42 1000

600 2022 1256 1571 1,27 24,02 13,78 42 1250

750 2022 1525 1911 1,28 27,95 16,15 42 1500



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

HX 500 1802 9016 12186-04

600 1406 9016 12186-03

600 1802 9016 12186-05

96

HX

Width (L) 500 600 750



Bathroom Ponti (HX)

Types

• Straight (HX)

Tubes

• Horizontal, round 24 mm

Collectors

• Vertical, rectangular, 56 x 34 mm

Colours





HX

return

supply

Bathroom

Brackets


ref. nr. 128210300000099


Technical









✘

✔

✔



rack

Connection


(see p. 194)


(see p. 194)







collector.






✔

✔

✔

✔

✘

L-150

1/2" 1/2"

H-174

97-117

34

H = 1010

385 64 288 64 209

L-150

1/2" 1/2"

H = 1406

429 64 332 64 244 64 209

L-150

1/2" 1/2"

H = 1802

473 64 332 64 288 64 244 64 209

L-150

1/2" 1/2"

H = 2022

561 64 332 64 288 64 288 64 279

126

1/2"

80-100

1/2" 50 1/2"

R

1/2" 50 1/2"

R

1/2" 50 1/2"

R

1/2" 50 1/2"

R

46-66

L

L

L

L

97

Bathroom Hedria (HDM, HDRM)

type

ref. nr.

12165

HDM

ref. nr.

12168

HDRM

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

500 702 391 490 1,28 7,50 3,10 20 300

600 702 464 581 1,28 8,55 3,50 20 500

700 702 535 672 1,29 9,60 3,90 20 500

800 702 606 762 1,30 10,65 4,30 20 500

900 702 677 853 1,31 11,70 4,70 20 500

500 1002 548 689 1,30 10,59 4,32 30 500

600 1002 650 819 1,31 12,09 4,91 30 500

700 1002 751 948 1,32 13,60 5,51 30 750

800 1002 851 1076 1,33 15,11 6,10 30 750

900 1002 950 1205 1,35 16,61 6,70 30 750

500 1392 744 934 1,29 14,60 5,90 40 750

600 1392 882 1109 1,30 16,70 6,75 40 1000

700 1392 1019 1284 1,31 18,80 7,60 40 1000

800 1392 1155 1458 1,32 20,90 8,45 40 1250

900 1392 1289 1630 1,33 23,00 9,30 40 1250

500 1782 931 1171 1,30 18,19 7,32 50 1000

600 1782 1103 1390 1,31 20,75 8,36 50 1250

700 1782 1274 1608 1,32 23,32 9,40 50 1250

800 1782 1444 1822 1,32 25,88 10,43 50 1500

900 1782 1612 2038 1,33 28,45 11,47 50 1500

500 2022 1041 1311 1,31 20,40 8,20 55 1000

600 2022 1234 1552 1,30 23,25 9,35 55 1250

700 2022 1425 1789 1,29 26,10 10,50 55 1500

800 2022 1614 2023 1,28 28,95 11,65 55 1500

900 2022 1802 2258 1,28 31,80 12,80 55 1500

500 702 391 490 1,28 7,50 3,10 20 300

600 702 464 581 1,28 8,55 3,50 20 500

700 702 535 672 1,29 9,60 3,90 20 500

800 702 606 762 1,30 10,65 4,30 20 500

900 702 677 853 1,31 11,70 4,70 20 500

500 1002 548 689 1,30 10,59 4,32 30 500

600 1002 650 819 1,31 12,09 4,91 30 500

700 1002 751 948 1,32 13,60 5,51 30 750

800 1002 851 1076 1,33 15,11 6,10 30 750

900 1002 950 1205 1,35 16,61 6,70 30 750

500 1392 744 934 1,29 14,60 5,90 40 750

600 1392 882 1109 1,30 16,70 6,75 40 1000

700 1392 1019 1284 1,31 18,80 7,60 40 1000

800 1392 1155 1458 1,32 20,90 8,45 40 1250

900 1392 1289 1630 1,33 23,00 9,30 40 1250

500 1782 931 1171 1,30 18,19 7,32 50 1000

600 1782 1103 1390 1,31 20,75 8,36 50 1250

700 1782 1274 1608 1,32 23,32 9,40 50 1250

800 1782 1444 1822 1,32 25,88 10,43 50 1500

900 1782 1612 2038 1,33 28,45 11,47 50 1500

500 2022 1041 1311 1,31 20,40 8,20 55 1000

600 2022 1234 1552 1,30 23,25 9,35 55 1250

700 2022 1425 1789 1,29 26,10 10,50 55 1500

800 2022 1614 2023 1,28 28,95 11,65 55 1500

900 2022 1802 2258 1,28 31,80 12,80 55 1500



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

HDM 500 702 9016 12165-01

500 1002 9016 12165-02

500 1392 9016 12165-04

500 1782 9016 12165-11

600 1002 9016 12165-03

600 1392 9016 12165-05

600 1782 9016 12165-07

600 2022 9016 12165-12

700 1392 9016 12165-06

700 1782 9016 12165-08

800 1782 9016 12165-09

800 2022 9016 12165-10

HDRM 600 1392 9016 12168-04

600 1782 9016 12168-06

98

FREE-STANDING HDM

Height (H) 702 1002 1392 1782 2022

H2 570 870 1260 1650 1890

HDM

Width (L) 500 600 700 800 900

Centre between the connections at the bottom 18 (R) 466 566 666 766 866


HDRM

Width (L) 496 595 694 793 893

Centre between the connections at the bottom 18 (R) 462 561 660 759 859

Distance between wall and connection 1-8 (Z) 79-89 76-86 74-84 72-82 71-81

Distance between wall and middle of MM valve (M) 102-112 102-112 102-112 108-118 110-120

Distance between wall and front of the radiator (D) 111-121 111-121 111-121 117-127 119-129


Bathroom Hedria (HDM, HDRM)

Types

• Straight (HDM) and curved (HDRM)

Tubes


Collectors

• Vertical, D-profile 34 x 34 mm

Colours




Special

• The horizontal tubes of type HDRM are slightly bent (10°).

• HDM also available as free-standing radiator

Brackets


Technical





HDM

HDRM

return supply

Bathroom





✔

✔

✔

ref. nr. 128210300000099


Connection


(see p. 194)


(see p. 194)







collector.






✔

✔

✔

✔

✘



rack

10°

L-120

1/2” 1/2”

L-120

1/2” 1/2”

L-120

1/2” 1/2”

60

66 H-132 66

103

1/2”

97-117

34

66 H-132 66

80-100

103

1/2”

D

34

Z

M

H-1=702

L-120

1/2” 1/2”

1/2” 1/2” 1/2” 1/2”

50

R

H=1002

L-120

1/2” 1/2”

1/2” 1/2” 1/2” 1/2”

50

R

H=1392

1/2” 1/2” 1/2” 1/2”

50

R

H=1782

1/2” 1/2” 1/2” 1/2”

50

R

H=2022

1/2” 1/2” 1/2” 1/2”

50

R

H1=216 H2

1/2” 1/2”

H

K=150

46-66 M-34

L

L

L

L

L

99

Bathroom Largo (HRM, HR2, HRBM) Lacquered

type

ref. nr.

12183

HRM

ref. nr.

12177

HR2

ref. nr.

12179

HRBM

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

500 682 402 498 1,21 7,60 3,60 17 300

600 682 481 595 1,21 8,65 4,11 17 500

750 682 601 745 1,22 10,24 4,88 17 500

850 682 680 843 1,22 11,30 5,40 17 500

500 1114 639 791 1,21 12,05 5,80 27 500

600 1114 766 948 1,21 13,73 6,60 27 750

750 1114 955 1182 1,21 16,25 7,80 27 1000

850 1114 1082 1339 1,21 17,95 8,60 27 1000

500 1726 968 1202 1,23 18,60 8,90 42 1000

600 1726 1159 1432 1,20 21,10 10,09 42 1250

750 1726 1447 1775 1,16 24,87 11,89 42 1500

850 1726 1639 2000 1,13 27,40 13,10 42 1500

500 2014 1149 1425 1,22 22,40 9,20 50 1250

600 2014 1345 1665 1,21 25,27 10,95 50 1500

750 2014 1640 2019 1,18 29,60 13,58 50 1500

850 2014 1838 2255 1,16 32,50 15,35 50 1500

500 1114 883 1099 1,24 20,10 10,56 27 750

600 1114 1064 1319 1,22 23,34 11,98 27 1000

750 1114 1338 1653 1,20 28,21 14,12 27 1250

850 1114 1522 1874 1,18 31,45 15,55 27 1500

500 2014 1500 1876 1,27 38,05 17,80 50 1500

600 2014 1809 2251 1,24 43,59 20,80 50 1500

750 2014 2275 2816 1,21 51,91 25,30 50 1500

850 2014 2586 3184 1,18 57,45 28,30 50 1500

500 682 402 498 1,21 7,60 3,60 17 300

600 682 481 595 1,21 8,65 4,11 17 500

750 682 601 745 1,22 10,24 4,88 17 500

850 682 680 843 1,22 11,30 5,40 17 500

500 1114 639 791 1,21 12,05 5,80 27 500

600 1114 766 948 1,21 13,73 6,60 27 750

750 1114 955 1182 1,21 16,25 7,80 27 1000

850 1114 1082 1339 1,21 17,95 8,60 27 1000

500 1726 968 1202 1,23 18,60 8,90 42 1000

600 1726 1159 1432 1,20 21,10 10,09 42 1250

750 1726 1447 1775 1,16 24,87 11,89 42 1500

850 1726 1639 2000 1,13 27,40 13,10 42 1500

500 2014 1149 1425 1,22 22,40 9,20 50 1250

600 2014 1345 1665 1,21 25,27 10,95 50 1500

750 2014 1640 2019 1,18 29,60 13,58 50 1500

850 2014 1838 2255 1,16 32,50 15,35 50 1500



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

HRM 500 1114 9016 12183-01

500 1726 9016 12183-03

600 1114 9016 12183-02

600 1726 9016 12183-04

750 2014 9016 12183-05

HRBM 600 1726 9016 12179-02

FREE-STANDING HRM / HR2


H 1114 1726 2014

H1 653 653 797

H2 432 864 864

HRM

Width (L) 500 600 750 850



100

HRBM

Width (L) 498 597 746 846




Bathroom Largo (HRM, HR2, HRBM) Lacquered

Types

• Straight (HRM), double row of tubes (HR2) and curved (HRBM)

Tubes


Collectors


Colours




Special

• The horizontal tubes of type HRBM are slightly bent (10°).

• Type HR2 consists of a double row of round tubes.

• HRM / HR2: also available as free-standing radiator

HRM

Bathroom

Brackets


Technical


seams)




HR2





✔

✔

✔

HRBM

return supply

Connection


(see p. 194)


(see p. 194)






• For connection at the bottom no flow tube is needed, this flow

tube will therefore not be delivered.

• For connection at the top 45, 54 a special flow tube has to be

ordered separately, which needs to be mounted in the return,

see p. 197.

• HR2 has no central connection.




✔

✔

✔

✔

✘

ref. nr. 128210300000099




rack

73

1/2"

10°

L-120

1/2"

71 H-142 71

114

95-115

ø35

71 H-142 71

114

113-123

ø35

71

H-142

71

150

ø35

H = 682

460 86 136

1/2"

L-120

1/2"

H = 1114

460 86 346 86 136

1/2"

L-120

1/2"

H = 1726

460 86 346 86 346 86 316

1/2"

L-120

1/2"

H = 2014

604 86 346 86 346 86 460

H1 H2

60

H

1/2"

55-70

1/2"

Z

103-112

1/2"

50 1/2"

R

1/2"

50 1/2"

R

1/2"

50 1/2"

R

1/2"

R

50 1/2"

K=150

46-61

68-78

L

L

L

L

80-95

102-112

101

Bathroom Largo (HRM-C, HRBM-C) Chrome

type

ref. nr.

12184

HRM-C

ref. nr.

12180

HRBM-C

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

600 862 336 417 1,23 8,95 3,95 15 300

600 1184 445 556 1,26 11,70 5,40 20 500

600 1736 666 826 1,22 17,35 7,40 30 750

600 862 336 417 1,23 8,95 3,95 15 300

600 1184 445 556 1,26 11,70 5,40 20 500

600 1736 666 826 1,22 17,35 7,40 30 750


stock radiators (chrome)

type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

HRM-C 600 1736 0099 12184-01

HRM-C

Width (L) 600

Centre between the connections at the bottom 18 (R) 560


102

HRBM-C

Width (L) 597

Centre between the connections at the bottom 18 (R) 550

Distance between wall and connection 1-8 (Z) 56-66


Bathroom Largo (HRM-C, HRBM-C) Chrome

Types

• Straight (HRM-C) and curved (HRBM-C)

Tubes


Collectors


Colours

• Chrome plated radiators

HRM-C

Bathroom

Special

• The horizontal tubes of type HRBM-C are slightly bent (10°).

Brackets


Technical


seams)







✘

✔

✔

HRBM-C

return supply

ref. nr. 128210300000099


Connection


(see p. 194)


(see p. 194)






• For connection at the bottom no flow tube is needed, this flow tube will therefore not be delivered.




• Stock radiators in chrome: 5 working days


✔

✔

✔

✔

✘



rack

10°

1/2"

L-120

1/2"

86 H-172

86

129

95-115

ø35

86 H-172

86

129

113-123

ø35

H = 862

212 116 206 116 212

1/2"

L-120

1/2"

H = 1184

212 116 206 116 206 116 212

1/2"

L-120

1/2"

H = 1736

258 116 252 116 252 116 252 116 258

1/2"

55-70

1/2"

Z

1/2"

R

50

1/2"

1/2"

R

50

1/2"

1/2"

R

50

1/2"

46-61

80-95

68-78

102-112

L

L

L

103

Bathroom Hazel (HZ, HZ2)

type

ref. nr.

12169

HZ

ref. nr.

12170

HZ2

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

450 850 387 480 1,22 10,90 3,10 12 300

450 1150 512 637 1,24 14,75 4,35 16 500

600 1150 652 807 1,21 17,50 5,10 16 500

450 1450 638 797 1,26 18,60 5,60 21 500

600 1450 812 1007 1,22 22,75 6,60 21 750

450 1810 790 988 1,27 23,40 7,00 27 750

600 1810 1006 1254 1,25 29,06 8,41 27 1000

700 1810 1145 1422 1,23 32,83 9,36 27 1250

800 1810 1281 1586 1,21 36,60 10,30 27 1250

800 2110 1490 1851 1,23 41,90 11,80 31 1500

600 1810 1440 1814 1,31 50,60 14,70 27 1500

800 1810 1838 2291 1,25 66,10 18,10 27 1500



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

HZ 600 1150 9016 12169-01

600 1450 9016 12169-03

600 1810 9016 12169-04

HZ

Width (L) 450 600 700 800



FREE-STANDING HZ2

Number of tubes (n) 27

H 1810

H1 664

H2 900

104

HZ2

Width (L) 600 800



Bathroom Hazel (HZ, HZ2)

Types

• HZ: 1 row of tubes

• HZ2: double row of tubes

Tubes

• Horizontal, flat-oval 57,5 x 10 mm

Collectors


Colours





Special

• HZ2 also available as free-standing radiator

HZ

Bathroom

Brackets


Technical


seams)








✔

✔

✔

HZ2

return

supply

ref. nr. 128210100000099


Connection


(see p. 194)


(see p. 194)





• For connection at the bottom no flow tube is needed, this flow tube will therefore not be delivered.



• HZ/HZ2 has no central connection.

✔

✔

✘

✔

✘




90 90

90 90

1/2"

1/2"

1/2"

1/2"

60

1/2"

1/2"

74 H -128 54

80 121

43,5

52

54

H -128

74

H = 850

1/2"

1/2"

54 95 1/2" R 1/2"

1/2" R 1/2"

L

L

H = 1150

1/2"

1/2"

H = 1450

1/2"

R 1/2"

L

H = 1810

1/2"

R 1/2"

L

H = 2110

1/2"

R 1/2"

L

H1 = 664 H2 = 900

H = 1810

K=147

105

Bathroom Free-standing installation

In option


V-S

Free-standing

installation

RAL 9016 128100300009016


M350 128100300000350

• free-standing radiators in the colour RAL 9016: 2 separate lateral supports, 2 feet (H = 150 mm) and 2

rosets in the colour RAL 9016.

• free-standing radiators in other colours: 2 separate lateral supports, 2 feet (H = 150 mm) in the colour of


V-I

Free-standing

installation

STAINLESS STEEL *

• free-standing radiators in stainless steel: 2 welded lateral supports, 1 feet (H = 150 mm) and 1 roset in

stainless steel.

* Please indicate code 01 for “Finish” when ordering (see “How to order” on page 8).

HKM

Free-standing

installation

RAL 9016 128100200009016


M350 128100200000350

• free-standing radiators in the colour RAL 9016: 2 separate lateral supports, 1 foot (H = 150 mm) and 1

roset in the colour RAL 9016.

• free-standing radiators in other colours: 2 separate lateral supports, 1 foot (H = 150 mm) in the colour of

the radiator and 1 chrome plated roset.

HDM

Free-standing

installation

RAL 9016 128100800009016


M350 128100800000350

• free-standing radiators in the colour RAL 9016: 2 separate lateral supports, 1 foot (H = 150 mm) and 1

roset in the colour RAL 9016.

• free-standing radiators in other colours: 2 separate lateral supports, 1 foot (H = 150 mm) in the colour of

the radiator and 1 chrome plated roset.

HRM

Free-standing

installation

RAL 9016 128100400009016


M350 128100400000350





HR2

Free-standing

installation

RAL 9016 128100500009016


M350 128100500000350





HZ2

Free-standing

installation

RAL 9016 *

COLOUR *






106

Bathroom Accessories

In option


DRYING- AND

STACKING RACK

STRAIGHT

• h = 15 mm; b = 350 mm; d = 94 mm; a = 45 mm

V-S / V-I / V-CHR

STAINLESS STEEL 128300500009993

Bathroom

V-S / V-I / V-CHR

DRYING- AND

STACKING RACK

CURVED

STAINLESS STEEL 128300600009993

• h = 15 mm; b = 338 mm; d = 94 mm; a = 45 mm

HZ / HZ2

TOWEL RAIL

CHROME 128322400000099

• h = 22 mm; b = 670 mm; d = 85 mm; a = 60 mm

HZ / HZ2

HOOK O-RING

CHROME 128360200000099

• h = 22 mm; b = 22 mm; d = 42 mm

HZ / HZ2

HOOK WITH A

WIDE GROOVE

CHROME 128340200000099

• h = 22 mm; b = 22 mm; d = 42 mm

HZ / HZ2

DRYING- AND

STACKING RACK

NARROW

CHROME 128300900000099

• h = 22 mm; b = 385 mm; d = 163 mm; a = 30 mm

HZ / HZ2

DRYING- AND

STACKING RACK

LARGE

CHROME 128301200000099

• h = 22 mm; b = 530 mm; d = 163 mm; a = 30 mm



107

Bathroom Connections

Verso Lacquered: V-S/VZ-S

Verso Stainless Steel: V-I/VZ-I

Verso Chrome: V-CHR/VZ-CHR

Tripla: HKM/HKRM

Ponti: HX

Hedria: HDM/HDRM

Largo Lacquered: HRM/HRBM

Largo Chrome: HRM-C/HRBM-C

4 5

4 5

4 5

4 5

1 MM 8

1 MM 8

1 MM 8

1 MM 8

1188 1188

1188 1188

4 5

4 5

1 MM 8

1 MM 8

1188 1188



Largo Lacquered: HR2

Hazel: HZ/HZ2

4 5

4 5

4 5

4 5

1 8

1 8

1 8

1 8

0018 0018 0018 0018



108

Vengia Verena Havaro COLLECTION

VPN1(-ZB) / vpN1L1-ZB / vpN2(-ZB) / vpNS1-ZB / vpNS1L1-ZB Vengia Vertical 110

VP1-ZB / VP1L1-ZB / VP2-ZB Verena Vertical 114

HP1-RO / HP1L1-RO / HP2-RO / HP2L1-RO / HP2L2-RO Havaro Horizontal 118

Free-STandinG inSTallation 124



Vengia Verena Havaro

109

Vengia Vertical (VPN1(-ZB), VPN1L1-ZB, VPN2(-ZB), VPNS1-ZB, VPNS1L1-ZB)

Types

• VPN1(-ZB) single row of tubes, VPN2(-ZB) double row of tubes

• VPNS1-ZB with integrated mirror, VPN1L1-ZB with steel fins in order to increase

the heat emission

Tubes

• Vertical, flat-oval 57,5 x 10 mm

Collectors


Colours





Special

• Type VPN1(-ZB) is also available with steel fins at the back of the flat-oval tubes

in order to increase the heat emission (VPN1L1-ZB).

• Type VPNS1-ZB is standard delivered with an integrated mirror (width 160 mm).

• Type VPN1L1-ZB and VPNS1-ZB are standard delivered with lateral coverings.

VPN1(-ZB)

VPN2(-ZB)

Brackets


Technical

• Welded by means of resistance welding robots (invisible weld seams)








✘

✘

✘

VPNS1-ZB

Connection










✔

✔

✔

✔

✘

ref. nr. 128200200009016





VPN1(-ZB) / VPN2(-ZB)

L-130

L-130

80

54

83

57

1/2"

1/2"

H-151

H-151

H

R2

VPN1(-ZB) / VPN2(-ZB) / VPN1L1-ZB

Number of tubes (n) 7 8 9 10 11 12 13 14 15

Width (L) 430 490 550 610 670 730 790 850 910

Centre between the connections at the bottom 18 (R1) 377 437 497 557 617 677 737 797 857

Height (H) 1400 1600 1800 2000 2200

Centre between the lateral connections 23/67 (R2) 1360 1560 1760 1960 2160


VPNS1-ZB

Number of tubes (n) 6 8

Width (L) 534 654

Centre between the connections at the bottom 18 (R1) 481 601

Height (H) 1800

Centre between the lateral connections 23/67 (R2) 1760


82

63

63 82

43,5 52

54

57

31

34

1/2"

R1

L

50 1/2"

20

110

Vengia Vertical (VPN1(-ZB))

type

ref. nr.

12218

VPN1

ref. nr.

12220

VPN1-ZB

tubes

(n)

width

(L mm)

7 430

8 490

9 550

10 610

11 670

12 730

13 790

14 850

15 910


height (H mm)

1400 1600 1800 2000 2200

75/65/20 588 670 752 834 916

90/70/20 741 845 949 1051 1152

75/65/20 671 765 860 954 1047

90/70/20 847 966 1085 1201 1317

75/65/20 755 861 967 1073 1178

90/70/20 953 1087 1221 1352 1481

75/65/20 839 957 1075 1192 1309

90/70/20 1059 1207 1356 1502 1646

75/65/20 923 1052 1182 1311 1440

90/70/20 1165 1328 1492 1652 1810

75/65/20 1007 1148 1290 1430 1570

90/70/20 1271 1449 1628 1802 1975

75/65/20 1091 1244 1397 1550 1701

90/70/20 1377 1570 1763 1952 2140

75/65/20 1175 1339 1505 1669 1832

90/70/20 1483 1690 1899 2102 2304

75/65/20 1259 1435 1612 1788 1963

90/70/20 1589 1811 2034 2253 2469

Watt/el. (75/65/20°C) 83,93 95,67 107,47 119,20 130,87

Weight, kg/el. 2,01 2,27 2,52 2,78 3,00

Water content, l/el. 0,64 0,72 0,79 0,87 0,95

n-exponent 1,32 1,32 1,32 1,31 1,30

Vengia


type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

VPN1-ZB 490 1800 9016 12220-02

VPNS1-ZB

L-130

VPN1L1-ZB

L-130

L-130

80

54

80

54

1/2" 1/2"

1/2"

1/2"

82

82

H-151

H

R2

H-151

H

63

R2

43,5

54

31

1/2" 50 1/2" 1/2" 1/2"

160

43,5

166

54

R1

L

31

R1

L

20

63

111

Vengia Vertical (VPN1L1-ZB, VPNS1-ZB, VPNS1L1-ZB)

type

ref. nr.

12219

VPN1L1-

ZB

tubes

(n)

width

height (H mm)

(L mm)

1400 1600 1800 2000 2200

75/65/20 799 901 1002 1100 1197

90/70/20 1014 1144 1276 1401 1522

75/65/20 913 1030 1145 1258 1369

90/70/20 1158 1308 1458 1602 1739

75/65/20 1027 1159 1288 1415 1540

90/70/20 1303 1471 1640 1802 1957

75/65/20 1141 1287 1431 1572 1711

90/70/20 1448 1635 1823 2002 2174

75/65/20 1255 1416 1574 1729 1882

90/70/20 1593 1798 2005 2202 2392

75/65/20 1370 1545 1718 1886 2053

90/70/20 1738 1962 2187 2403 2609

75/65/20 1484 1673 1861 2044 2224

90/70/20 1882 2125 2369 2603 2826

75/65/20 1598 1802 2004 2201 2395

90/70/20 2027 2289 2552 2803 3044

75/65/20 1712 1931 2147 2358 2566

90/70/20 2172 2452 2734 3003 3261

Watt/el. (75/65/20°C) 114,13 128,73 143,13 157,20 171,07

Weight, kg/el. 3,42 3,94 4,46 4,99 5,52


n-exponent 1,35 1,36 1,37 1,37 1,36

7 430

8 490

9 550

10 610

11 670

12 730

13 790

14 850

15 910



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

VPN1L1-

ZB

490 2000 9016 12219-03

610 2000 9016 12219-01

type

ref. nr.

12225

VPNS1-ZB

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

534 1800 645 814 1,32 22,70 4,70 6 -

654 1800 860 1085 1,32 27,70 6,30 8 -

ref. nr.

12224

VPNS1L1-

ZB

534 1800 859 1094 1,37 28,20 4,10 6 -

654 1800 1145 1458 1,37 35,10 5,50 8 -


112

Vengia Vertical (VPN2(-ZB))

type

ref. nr.

12221

VPN2

ref. nr.

12223

VPN2-ZB

tubes

(n)

width

(L mm)

7 430

8 490

9 550

10 610

11 670

12 730

13 790

14 850

15 910


height (H mm)

1400 1600 1800 2000 2200

75/65/20 894 1022 1155 1291 1433

90/70/20 1130 1292 1462 1635 1809

75/65/20 1021 1168 1319 1476 1638

90/70/20 1291 1477 1671 1869 2067

75/65/20 1149 1314 1484 1660 1843

90/70/20 1453 1661 1880 2103 2325

75/65/20 1277 1460 1649 1845 2047

90/70/20 1614 1846 2089 2336 2584

75/65/20 1404 1606 1814 2029 2252

90/70/20 1775 2030 2298 2570 2842

75/65/20 1532 1752 1979 2214 2457

90/70/20 1937 2215 2507 2804 3100

75/65/20 1660 1898 2144 2398 2661

90/70/20 2098 2400 2715 3037 3359

75/65/20 1787 2044 2309 2583 2866

90/70/20 2260 2584 2924 3271 3617

75/65/20 1915 2190 2474 2767 3071

90/70/20 2421 2769 3133 3504 3876

Watt/el. (75/65/20°C) 127,67 146,00 164,93 184,47 204,73

Weight, kg/el. 4,28 4,87 5,44 6,01 6,59


n-exponent 1,33 1,33 1,34 1,34 1,33

Vengia


type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

price

VPN2-ZB 490 1800 9016 12223-03 725

610 2000 9016 12223-01 944

113

Verena Vertical (VP1-ZB, VP1L1-ZB, VP2-ZB)

Types

• VP1-ZB single row of tubes, VP2-ZB double row of tubes, VP1L1-ZB with

steel fins

Tubes

• Vertical, flat-oval 70 x 10 mm

Collectors

• Horizontal, square, rear 34 x 34 mm

Colours





Special

• VP2-ZB also available as free-standing radiator

• As to type VP1L1-ZB, steel fins are welded at the back of the flat-oval tubes

in order to increase the heat emission.

• Standard delivered with 2 lateral coverings.

• VP1L1-ZB(-V) also available as toilet radiator (433 x 600 mm)

VP1-ZB

VP2-ZB

Brackets


Technical



• Standard operating pressure: 4 bar. Extra charge for higher service pressures

(10 bar): +10%.

• The delivery time of a radiator with a higher service pressure is 1 week extra.


VP1L1-ZB





✔

✘

✘

Connection









Integrated valve (order as special radiator) (see p. 196)

✔

✔

✔

✔

✔

ref. nr. 128200100009016





VP1-ZB

VP1L1-ZB

VP2-ZB

72,5 L - 145

72,5

72,5 L -145

72,5

72,5 L - 145

72,5

48

48

62

83,5 H - 152 68,5

50

81

83,5 H - 152 68,5

64

95

H

1/2”

1/2” 1

1/2” R1 1/2”

L

21,5

R2

21,5

R1

L

H

H

58,5

217

50

L

114

Verena Vertical (VP1-ZB)

type

ref. nr.

12215

VP1-ZB

tubes

(n)

width

height (H mm)

(L mm)

1200 1400 1600 1800 2000 2200 2400

75/65/20 300 351 401 449 495 539 581

90/70/20 381 445 507 568 626 683 736

75/65/20 400 468 534 598 659 718 774

90/70/20 508 593 676 757 835 910 982

75/65/20 500 585 668 748 824 898 968

90/70/20 635 742 845 946 1044 1138 1227

75/65/20 600 702 801 897 989 1077 1161

90/70/20 761 890 1014 1136 1252 1365 1473

75/65/20 700 819 935 1047 1154 1257 1355

90/70/20 888 1038 1183 1325 1461 1593 1718

75/65/20 800 936 1068 1196 1319 1436 1548

90/70/20 1015 1186 1352 1514 1670 1820 1964

75/65/20 899 1053 1202 1346 1484 1616 1742

90/70/20 1142 1335 1521 1703 1878 2048 2209

75/65/20 999 1170 1335 1495 1649 1795 1936

90/70/20 1269 1483 1690 1893 2087 2275 2455

75/65/20 1099 1287 1469 1645 1813 1975 2129

90/70/20 1396 1631 1859 2082 2296 2503 2700

75/65/20 1199 1404 1602 1794 1978 2154 2323

90/70/20 1523 1780 2028 2271 2505 2730 2945

75/65/20 1399 1638 1870 2093 2308 2514 2710

90/70/20 1777 2076 2366 2650 2922 3185 3436

Watt/el. (75/65/20°C) 99,94 117,00 133,54 149,51 164,85 179,54 193,55

Weight, kg/el. 2,62 3,00 3,38 3,75 4,12 4,48 4,84

Water content, l/el. 0,70 0,80 0,89 1,00 1,11 1,20 1,28

n-exponent 1,35 1,35 1,34 1,34 1,34 1,34 1,35

3 215

4 288

5 360

6 433

7 505

8 578

9 650

10 723

11 795

12 868

14 1013


Verena

VP1-ZB / VP2-ZB / VP1L1-ZB

Number of tubes (n) 3 4 5 6 7 8 9 10 11 12 14

Width (L) 215 288 360 433 505 578 650 723 795 868 1013

Centre between the connections at the bottom 18 (R1) 165 238 310 383 455 528 600 673 745 818 963

Height (H) 1200 1400 1600 1800 2000 2200 2400

Centre between the lateral connections 23/67 (R2) 1157 1357 1557 1757 1957 2157 2357


62

88-140 L

H

0

115

Verena Vertical (VP1L1-ZB)

type

ref. nr.

12213

VP1L1-ZB

tubes

(n)

width

height (H mm)

(L mm)

600 1200 1400 1600 1800 2000 2200 2400

75/65/20 421 480 538 594 649 702 754

90/70/20 534 610 683 754 823 890 954

75/65/20 562 640 717 792 865 936 1006

90/70/20 712 813 910 1005 1097 1186 1272

75/65/20 702 801 897 990 1081 1170 1257

90/70/20 891 1016 1138 1256 1372 1483 1590

75/65/20 403 842 961 1076 1188 1297 1404 1508

90/70/20 507 1069 1219 1365 1507 1646 1779 1908

75/65/20 983 1121 1255 1386 1513 1638 1760

90/70/20 1247 1422 1593 1758 1920 2076 2226

75/65/20 1123 1281 1434 1584 1730 1872 2011

90/70/20 1425 1626 1820 2010 2194 2372 2544

75/65/20 1264 1441 1614 1782 1946 2106 2263

90/70/20 1603 1829 2048 2261 2469 2669 2862

75/65/20 1404 1601 1793 1980 2162 2340 2514

90/70/20 1781 2032 2275 2512 2743 2965 3180

75/65/20 1544 1761 1972 2178 2378 2574 2765

90/70/20 1959 2235 2503 2763 3017 3262 3498

75/65/20 1685 1921 2152 2376 2594 2808 3017

90/70/20 2137 2438 2730 3014 3292 3558 3816

75/65/20 1966 2241 2510 2772 3027 3276 3520

90/70/20 2493 2845 3185 3517 3840 4151 4452

Watt/el. (75/65/20°C) 67,17 140,41 160,14 179,32 198,00 216,22 234,00 251,38

Weight, kg/el. 1,86 3,55 4,02 4,49 5,04 5,59 6,15 6,73

Water content, l/el. 0,40 0,68 0,77 0,87 0,96 1,05 1,15 1,25

n-exponent 1,30 1,35 1,35 1,35 1,35 1,35 1,34 1,33

3 215

4 288

5 360

6 433

7 505

8 578

9 650

10 723

11 795

12 868

14 1013



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

VP1L1-ZB 578 1800 9016 12213-01

578 2000 9016 12213-02

116

Verena Vertical (VP2-ZB)

type

ref. nr.

12217

VP2-ZB

tubes

(n)

width

height (H mm)

(L mm)

1200 1400 1600 1800 2000 2200 2400

75/65/20 445 518 586 649 705 756 801

90/70/20 562 655 743 822 893 957 1014

75/65/20 593 691 782 865 940 1008 1068

90/70/20 749 874 990 1096 1191 1277 1353

75/65/20 741 864 977 1081 1176 1260 1335

90/70/20 936 1092 1238 1370 1489 1596 1691

75/65/20 889 1036 1172 1297 1411 1512 1601

90/70/20 1123 1311 1486 1644 1787 1915 2029

75/65/20 1037 1209 1368 1513 1646 1764 1868

90/70/20 1310 1529 1733 1918 2084 2234 2367

75/65/20 1186 1382 1563 1730 1881 2016 2135

90/70/20 1498 1748 1981 2192 2382 2553 2705

75/65/20 1334 1554 1759 1946 2116 2268 2402

90/70/20 1685 1966 2228 2465 2680 2872 3043

75/65/20 1482 1727 1954 2162 2351 2520 2669

90/70/20 1872 2185 2476 2739 2978 3191 3381

75/65/20 1630 1900 2149 2378 2586 2772 2936

90/70/20 2059 2403 2724 3013 3275 3511 3719

75/65/20 1778 2072 2345 2594 2821 3024 3203

90/70/20 2246 2622 2971 3287 3573 3830 4058

75/65/20 2075 2418 2736 3027 3291 3528 3737

90/70/20 2621 3059 3467 3835 4169 4468 4734

Watt/el. (75/65/20°C) 148,17 172,67 195,40 216,22 235,08 251,95 267,87

Weight, kg/el. 4,52 5,21 5,90 6,60 7,29 7,80 8,13

Water content, l/el. 1,26 1,45 1,64 1,83 2,02 2,14 2,20

n-exponent 1,33 1,33 1,34 1,34 1,34 1,34 1,34

3 215

4 288

5 360

6 433

7 505

8 578

9 650

10 723

11 795

12 868

14 1013


Verena

117

Havaro Horizontal (HP1-RO, hp1L1-RO, hp2-RO, hp2L1-RO, hp2L2-RO)

Types

• HP1-RO single row of tubes, HP2-RO double row of tubes, HP1L1-RO, HP2L1-RO,

HP2L2-RO (1 or 2 rows of steel fins)

Tubes

• Horizontal, flat-oval 70 x 10 mm

Collectors

• Vertical, square, rear 34 x 34 mm

Colours





Special

• HP2-RO / HP2L1-RO also available as free-standing radiator

• As to type HL-RO, 1 or 2 steel fins are welded at the back of the flat-oval tubes in order to

increase the heat emission.

• HP1L1-RO(-V) also available as toilet radiator (500 x 360 mm)

• Standard with grill. If desired, also possible without grill.

Brackets


Technical



• Standard operating pressure: 4 bar. Extra charge for higher service pressures (10 bar):

+10%.







Connection

✘

✘

✘

HP1-RO

return

supply

HP2-RO

ref. nr. 128210100000099




✔






Integrated valve (order as special radiator) (see p. 196)

✔

✘

✔

✔

HP1-RO

HP1L1-RO

76 L-152

76

76 L-152

76

48

DelivERY terms Transport duration not included !


76 L-152

76

48

52

HP2-RO

76

L-152

76

81

65 min.

60

95

134

H-145

H-145

62

62

HP2L1-RO

76

L-152 76

HP2L2-RO

HP1-RO / HP2-RO /

HP1L1-RO HP2L1-RO

HP2L2-RO

25

65 min

60

min.

60

76

76

H

H

H-143

H

R2

R1

L

Retour

Aanvoer

50

L

50

80

min.

70

64

80

min.

70

102

min.

70

87

L

118

21,5

Havaro Horizontal (HP1-RO)

type

ref. nr.

12157

HP1-RO

width

(L mm)

500

600

700

800

900

1000

1100

1200

1400

1600

1800

2000

2200

2400

2600

2800

3000

tubes (n) / height (H mm)

4 5 6 7 8 9 10 11 12

288 360 433 505 578 650 723 795 868

75/65/20 167 205 243 281 320 358 398 438 480

90/70/20 208 255 302 350 398 446 496 546 598

75/65/20 200 245 291 337 383 430 478 526 575

90/70/20 250 305 362 419 478 535 595 655 718

75/65/20 234 286 340 393 447 501 557 613 671

90/70/20 291 356 423 489 557 624 694 764 837

75/65/20 267 327 388 449 511 573 637 701 767

90/70/20 333 407 483 559 637 714 794 874 957

75/65/20 301 368 437 505 575 644 716 788 863

90/70/20 374 458 544 629 716 803 893 983 1076

75/65/20 334 409 485 561 639 716 796 876 959

90/70/20 416 509 604 699 796 892 992 1092 1196

75/65/20 367 450 534 617 703 788 876 964 1055

90/70/20 458 560 664 769 876 981 1091 1201 1316

75/65/20 401 491 582 673 767 859 955 1051 1151

90/70/20 499 611 725 839 955 1070 1190 1310 1435

75/65/20 468 573 679 785 895 1002 1114 1226 1343

90/70/20 582 713 846 979 1114 1249 1389 1529 1674

75/65/20 534 654 776 898 1022 1146 1274 1402 1534

90/70/20 666 814 966 1118 1274 1427 1587 1747 1914

75/65/20 601 736 873 1010 1150 1289 1433 1577 1726

90/70/20 749 916 1087 1258 1433 1606 1786 1966 2153

75/65/20 668 818 970 1122 1278 1432 1592 1752 1918

90/70/20 832 1018 1208 1398 1592 1784 1984 2184 2392

75/65/20 735 900 1067 1234 1406 1575 1751 1927 2110

90/70/20 915 1120 1329 1538 1751 1962 2182 2402 2631

75/65/20 802 982 1164 1346 1534 1718 1910 2102 2302

90/70/20 998 1222 1450 1678 1910 2141 2381 2621 2870

75/65/20 868 1063 1261 1459 1661 1862 2070 2278 2493

90/70/20 1082 1323 1570 1817 2070 2319 2579 2839 3110

75/65/20 935 1145 1358 1571 1789 2005 2229 2453 2685

90/70/20 1165 1425 1691 1957 2229 2498 2778 3058 3349

75/65/20 1002 1227 1455 1683 1917 2148 2388 2628 2877

90/70/20 1248 1527 1812 2097 2388 2676 2976 3276 3588

Watt/m. (75/65/20°C) 334 409 485 561 639 716 796 876 960

Weight, kg/m. 7,78 9,87 12,07 14,23 16,43 18,60 20,62 22,60 24,60

Water content, l/m. 2,22 2,80 3,45 4,10 4,76 5,40 5,98 6,54 7,10

n-exponent 1,25 1,24 1,24 1,25 1,25 1,25 1,25 1,25 1,25


Havaro

HP1-RO / HP1L1-RO / HP2-RO / HP2L1-RO / HP2L2-RO

Width (L) 500 600 700 800 900 1000 1100 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000

Centre between the connections at the bottom 18 (R1) 457 557 657 757 857 957 1057 1157 1357 1557 1757 1957 2157 2357 2557 2757 2957

Height (H) 288 360 433 505 578 650 723 795 868

Centre between the lateral connections 23/67 (R2) 238 310 383 455 528 600 673 745 818


Centre between the brackets (HP2L2-RO) H-143

119

Havaro Horizontal (HP1L1-RO)

type

ref. nr.

12156

HP1L1-RO

width

(L mm)

500

600

700

800

900

1000

1100

1200

1400

1600

1800

2000

2200

2400

2600

2800

3000


4 5 6 7 8 9 10 11 12

288 360 433 505 578 650 723 795 868

75/65/20 272 322 370 415 459 501 541 580 618

90/70/20 340 403 463 520 576 629 680 729 777

75/65/20 326 386 444 498 551 601 649 695 741

90/70/20 408 483 556 624 691 754 816 875 933

75/65/20 381 451 518 581 643 701 757 811 865

90/70/20 476 564 649 728 806 880 952 1020 1088

75/65/20 435 515 592 664 734 801 866 927 988

90/70/20 544 644 741 832 921 1006 1088 1166 1244

75/65/20 490 580 666 747 826 901 974 1043 1112

90/70/20 612 725 834 936 1037 1131 1224 1312 1399

75/65/20 544 644 740 830 918 1001 1082 1159 1235

90/70/20 680 805 926 1040 1152 1257 1360 1458 1555

75/65/20 598 708 814 913 1010 1101 1190 1275 1359

90/70/20 748 886 1019 1144 1267 1383 1496 1604 1710

75/65/20 653 773 888 996 1102 1201 1298 1391 1482

90/70/20 816 967 1112 1248 1382 1508 1632 1749 1866

75/65/20 762 902 1036 1162 1285 1401 1515 1623 1729

90/70/20 952 1128 1297 1456 1612 1760 1904 2041 2176

75/65/20 870 1030 1184 1328 1469 1602 1731 1854 1976

90/70/20 1088 1289 1482 1664 1843 2011 2176 2332 2487

75/65/20 979 1159 1332 1494 1652 1802 1948 2086 2223

90/70/20 1224 1450 1668 1872 2073 2263 2448 2624 2798

75/65/20 1088 1288 1480 1660 1836 2002 2164 2318 2470

90/70/20 1360 1611 1853 2080 2303 2514 2720 2916 3109

75/65/20 1197 1417 1628 1826 2020 2202 2380 2550 2717

90/70/20 1496 1772 2038 2288 2534 2766 2992 3207 3420

75/65/20 1306 1546 1776 1992 2203 2402 2597 2782 2964

90/70/20 1632 1933 2224 2497 2764 3017 3264 3499 3731

75/65/20 1414 1674 1924 2158 2387 2603 2813 3013 3211

90/70/20 1768 2094 2409 2705 2994 3268 3536 3790 4042

75/65/20 1523 1803 2072 2324 2570 2803 3030 3245 3458

90/70/20 1904 2255 2594 2913 3225 3520 3808 4082 4353

75/65/20 1632 1932 2220 2490 2754 3003 3246 3477 3705

90/70/20 2040 2416 2779 3121 3455 3771 4080 4373 4664

Watt/m. (75/65/20°C) 544 644 740 830 918 1001 1082 1159 1235

Weight, kg/m. 11,02 14,00 16,64 19,25 21,89 24,50 27,21 29,89 32,60


n-exponent 1,26 1,27 1,27 1,28 1,29 1,29 1,30 1,30 1,31


88-140 L=2600-3000

88-140 L=1600-2400

H

100

H

M6 M6 M6 M6

100

M6 M6 M6

121 V V 121

121 121

120

L/2 L/2

Havaro Horizontal (HP2-RO)

type

ref. nr.

12163

HP2-RO

width

(L mm)

500

600

700

800

900

1000

1100

1200

1400

1600

1800

2000

2200

2400

2600

2800

3000


4 5 6 7 8 9 10 11 12

288 360 433 505 578 650 723 795 868

75/65/20 284 348 412 475 537 598 659 718 778

90/70/20 354 434 514 593 671 747 824 900 976

75/65/20 340 418 494 569 644 717 790 862 934

90/70/20 424 521 617 711 805 896 988 1079 1171

75/65/20 397 487 577 664 752 837 922 1005 1089

90/70/20 495 608 720 830 939 1045 1153 1259 1366

75/65/20 454 557 659 759 859 956 1054 1149 1245

90/70/20 566 694 822 948 1073 1194 1318 1439 1562

75/65/20 510 626 742 854 967 1076 1185 1292 1400

90/70/20 636 781 925 1067 1207 1344 1482 1619 1757

75/65/20 567 696 824 949 1074 1195 1317 1436 1556

90/70/20 707 868 1028 1185 1341 1493 1647 1799 1952

75/65/20 624 766 906 1044 1181 1315 1449 1580 1712

90/70/20 778 955 1131 1304 1475 1642 1812 1979 2147

75/65/20 680 835 989 1139 1289 1434 1580 1723 1867

90/70/20 848 1042 1234 1422 1609 1792 1976 2159 2342

75/65/20 794 974 1154 1329 1504 1673 1844 2010 2178

90/70/20 990 1215 1439 1659 1877 2090 2306 2519 2733

75/65/20 907 1114 1318 1518 1718 1912 2107 2298 2490

90/70/20 1131 1389 1645 1896 2146 2389 2635 2878 3123

75/65/20 1021 1253 1483 1708 1933 2151 2371 2585 2801

90/70/20 1273 1562 1850 2133 2414 2687 2965 3238 3514

75/65/20 1134 1392 1648 1898 2148 2390 2634 2872 3112

90/70/20 1414 1736 2056 2370 2682 2986 3294 3598 3904

75/65/20 1247 1531 1813 2088 2363 2629 2897 3159 3423

90/70/20 1555 1910 2262 2607 2950 3285 3623 3958 4294

75/65/20 1361 1670 1978 2278 2578 2868 3161 3446 3734

90/70/20 1697 2083 2467 2844 3218 3583 3953 4318 4685

75/65/20 1474 1810 2142 2467 2792 3107 3424 3734 4046

90/70/20 1838 2257 2673 3081 3487 3882 4282 4677 5075

75/65/20 1588 1949 2307 2657 3007 3346 3688 4021 4357

90/70/20 1980 2430 2878 3318 3755 4180 4612 5037 5466

75/65/20 1701 2088 2472 2847 3222 3585 3951 4308 4668

90/70/20 2121 2604 3084 3555 4023 4479 4941 5397 5856

Watt/m. (75/65/20°C) 567 696 824 949 1074 1195 1317 1436 1556

Weight, kg/m. 15,14 19,00 22,65 26,25 29,90 33,50 37,22 40,88 44,60


n-exponent 1,25 1,26 1,26 1,26 1,26 1,26 1,27 1,28 1,29


Havaro

88-140

L=500-1400

100

H

M6

121 V

121

M6

FREE-STANDING HP2-RO / HP2L1-RO

Width (L) 500 600 700 800 900 1000 1100 1200 1400 2600 2800 3000

Centre between the feet (V) 258 358 458 558 658 758 858 958 1158 777 827 877

121


type

ref. nr.

12160

HP2L1-RO

width

(L mm)

500

600

700

800

900

1000

1100

1200

1400

1600

1800

2000

2200

2400

2600

2800

3000


4 5 6 7 8 9 10 11 12

288 360 433 505 578 650 723 795 868

75/65/20 397 475 550 623 694 762 830 896 962

90/70/20 497 595 690 781 870 955 1040 1123 1205

75/65/20 476 569 660 747 832 914 996 1075 1154

90/70/20 597 714 828 937 1043 1146 1248 1347 1446

75/65/20 556 664 770 872 971 1067 1162 1254 1346

90/70/20 696 833 966 1093 1217 1337 1456 1572 1686

75/65/20 635 759 880 996 1110 1219 1328 1434 1538

90/70/20 796 952 1104 1249 1391 1528 1664 1796 1927

75/65/20 715 854 990 1121 1248 1372 1494 1613 1731

90/70/20 895 1071 1242 1405 1565 1719 1873 2021 2168

75/65/20 794 949 1100 1245 1387 1524 1660 1792 1923

90/70/20 995 1190 1380 1561 1739 1911 2081 2246 2409

75/65/20 873 1044 1210 1370 1526 1676 1826 1971 2115

90/70/20 1094 1309 1518 1717 1913 2102 2289 2470 2650

75/65/20 953 1139 1320 1494 1664 1829 1992 2150 2308

90/70/20 1194 1428 1655 1873 2087 2293 2497 2695 2891

75/65/20 1112 1329 1540 1743 1942 2134 2324 2509 2692

90/70/20 1393 1667 1931 2186 2435 2675 2913 3144 3373

75/65/20 1270 1518 1760 1992 2219 2438 2656 2867 3077

90/70/20 1592 1905 2207 2498 2782 3057 3329 3593 3855

75/65/20 1429 1708 1980 2241 2497 2743 2988 3226 3461

90/70/20 1791 2143 2483 2810 3130 3439 3745 4042 4337

75/65/20 1588 1898 2200 2490 2774 3048 3320 3584 3846

90/70/20 1990 2381 2759 3122 3478 3821 4161 4491 4819

75/65/20 1747 2088 2420 2739 3051 3353 3652 3942 4231

90/70/20 2189 2619 3035 3435 3826 4203 4577 4940 5300

75/65/20 1906 2278 2640 2988 3329 3658 3984 4301 4615

90/70/20 2388 2857 3311 3747 4174 4585 4993 5389 5782

75/65/20 2064 2467 2860 3237 3606 3962 4316 4659 5000

90/70/20 2587 3095 3587 4059 4522 4967 5410 5839 6264

75/65/20 2223 2657 3080 3486 3884 4267 4648 5018 5384

90/70/20 2786 3333 3863 4371 4869 5350 5826 6288 6746

75/65/20 2382 2847 3300 3735 4161 4572 4980 5376 5769

90/70/20 2985 3571 4139 4684 5217 5732 6242 6737 7228

Watt/m. (75/65/20°C) 794 949 1100 1245 1387 1524 1660 1792 1923

Weight, kg/m. 17,38 21,50 25,35 29,15 33,00 36,80 40,42 43,98 47,60


n-exponent 1,28 1,29 1,28 1,28 1,28 1,28 1,28 1,28 1,28


122


type

ref. nr.

12162

HP2L2-RO

width

(L mm)

500

600

700

800

900

1000

1100

1200

1400

1600

1800

2000

2200

2400

2600

2800

3000


4 5 6 7 8 9 10 11 12

288 360 433 505 578 650 723 795 868

75/65/20 488 584 675 761 843 921 996 1067 1137

90/70/20 612 734 849 956 1060 1158 1253 1342 1429

75/65/20 586 700 810 913 1012 1105 1195 1280 1364

90/70/20 734 881 1019 1148 1272 1389 1503 1610 1715

75/65/20 683 817 945 1065 1180 1289 1394 1494 1591

90/70/20 856 1027 1188 1339 1484 1621 1754 1879 2001

75/65/20 781 934 1080 1217 1349 1473 1594 1707 1818

90/70/20 978 1174 1358 1530 1696 1852 2004 2147 2287

75/65/20 878 1050 1215 1369 1517 1657 1793 1921 2046

90/70/20 1101 1321 1528 1721 1908 2084 2255 2415 2573

75/65/20 976 1167 1350 1521 1686 1841 1992 2134 2273

90/70/20 1223 1468 1698 1913 2120 2315 2505 2684 2858

75/65/20 1074 1284 1485 1673 1855 2025 2191 2347 2500

90/70/20 1345 1614 1868 2104 2332 2547 2756 2952 3144

75/65/20 1171 1400 1620 1825 2023 2209 2390 2561 2728

90/70/20 1468 1761 2037 2295 2544 2778 3006 3220 3430

75/65/20 1366 1634 1890 2129 2360 2577 2789 2988 3182

90/70/20 1712 2055 2377 2678 2968 3241 3507 3757 4002

75/65/20 1562 1867 2160 2434 2698 2946 3187 3414 3637

90/70/20 1957 2348 2716 3060 3392 3704 4008 4294 4574

75/65/20 1757 2101 2430 2738 3035 3314 3586 3841 4091

90/70/20 2202 2642 3056 3443 3816 4167 4509 4831 5145

75/65/20 1952 2334 2700 3042 3372 3682 3984 4268 4546

90/70/20 2446 2935 3395 3826 4241 4630 5010 5367 5717

75/65/20 2147 2567 2970 3346 3709 4050 4382 4695 5001

90/70/20 2691 3229 3735 4208 4665 5093 5511 5904 6289

75/65/20 2342 2801 3240 3650 4046 4418 4781 5122 5455

90/70/20 2935 3522 4075 4591 5089 5556 6012 6441 6860

75/65/20 2538 3034 3510 3955 4384 4787 5179 5548 5910

90/70/20 3180 3816 4414 4973 5513 6020 6513 6978 7432

75/65/20 2733 3268 3780 4259 4721 5155 5578 5975

90/70/20 3425 4109 4754 5356 5937 6483 7014 7514

75/65/20 2928 3501 4050 4563 5058 5523 5976

90/70/20 3669 4403 5093 5738 6361 6946 7515

Watt/m. (75/65/20°C) 976 1167 1350 1521 1686 1841 1992 2134 2273

Weight, kg/m. 22,14 27,60 32,35 37,05 41,80 46,50 51,19 55,81 60,50


n-exponent 1,28 1,30 1,30 1,30 1,30 1,30 1,30 1,30 1,30


Havaro

123

Vengia Verena Havaro Free-standing installation

In option

Free-standing installation width COLOUR REF.NR.

HP2-RO / HP2L1-RO

≤ 1400 mm

(2 feet, 1 lateral support)

RAL 9016 *

COLOUR *

telescopic foot

+ telescopic

lateral support

≤ 2400 mm


≤ 3000 mm


RAL 9016 *

COLOUR *

RAL 9016 *

COLOUR *

VP2-ZB


or

(1 foot, 2 lateral supports)

RAL 9016 *

COLOUR *

• attention: feet need to be ordered together with the radiator

VP2-ZB: 2 feet; HP2-RO/HP2L1-RO: L 500-1400 mm: 2 feet; 1600-2400 mm: 3 feet; 2600-3000 mm: 4 feet

* Havaro (foot (feet) + 1 lateral support): Please indicate code 01 for “Finish” when ordering (see “How to order” on page 8).

* Verena (1 foot + 2 lateral supports): Please indicate code 08 for “Finish” when ordering (see “How to order” on page 8).

* Verena (2 feet + 1 lateral support): Please indicate code 09 for “Finish” when ordering (see “How to order” on page 8).

HP2-RO / HP2L1-RO

≤ 1400 mm

(2 feet)

RAL 9016 *

COLOUR *

telescopic foot

+ standard wall

bracket

≤ 2400 mm

(3 feet)

≤ 3000 mm

(4 feet)

RAL 9016 *

COLOUR *

RAL 9016 *

COLOUR *

VP2-ZB

(2 feet) RAL 9016 *

COLOUR *

• attention: feet need to be ordered together with the radiator

VP2-ZB: 2 feet; HP2-RO/HP2L1-RO: L 500-1400 mm: 2 feet; 1600-2400 mm: 3 feet; 2600-3000 mm: 4 feet


124

Vengia Verena Havaro Accessories

In option


TOWEL RAIL

• h = 22 mm; b = 670 mm; d = 85 mm; a = 60 mm

HOOK O-RING

• h = 22 mm; b = 22 mm; d = 42 mm

HOOK WITH A

WIDE GROOVE

• h = 22 mm; b = 22 mm; d = 42 mm

VPN1(-ZB) / VPN2(-ZB) / VPN1L1-ZB / VPNS1-ZB

CHROME 128322400000099


HP1-RO / HP2-RO / HP1L1-RO / HP2L1-RO / HP2L2-RO

CHROME 128322300000099


CHROME 128360200000099



CHROME 128360000000099


CHROME 128340200000099



CHROME 128340000000099

Vengia Verena Havaro

VPN1(-ZB) / VPN2(-ZB) / VPN1L1-ZB

DRYING- AND

STACKING RACK

NARROW

CHROME 128300900000099



CHROME 128300700000099

• h = 22 mm; b = 385 mm; d = 163 mm; a = 30 mm


DRYING- AND

STACKING RACK

LARGE

CHROME 128301200000099



CHROME 128301000000099

• h = 22 mm; b = 530 mm; d = 163 mm; a = 30 mm



125

018

Vengia Verena Havaro Connections

Vengia: VPN1(-ZB) / VPN2(-ZB) / VPN1L1-ZB (stock)

Verena: VP1-ZB / VP2-ZB / VP1L1-ZB (non stock) continuation

3

6

3

6

3

6

3

6

5 5

3

3

3 6 3

6

1 8 mm 1 8 mm 1 8

mm

mm 1 8

7

7

8 8

1008 1008 1008 1008

• Attention: connecting the radiator can only be as shown by the connecting icons. for

any other connection method, we take no responsibility.

0037 0037 0036 0036

5

5

4

4

Vengia: VPN1(-ZB) / VPN2(-ZB) / VPN1L1-ZB / VPNS1L1-ZB / VPNS1-ZB

(non stock)

3

2

3

2

6

7

6

7

0023 0023 0067 0067

3

6

3

6

3

6

3

6

5

5 5

5

1 8

1 8

mm

mm

0018 0018 0099 0099

3

6 3

6 3

6 3

2 7 2

7 2 7 2

0023 0023 0067 0067

6

7

geïntegreerd

ventiel links

geïntegreerd

ventiel rechts

0019 0098 0099 0099



Havaro: hp1-ro / hp2-ro / hp1L1-ro / hp2L1-ro / hp2L2-ro

mm

mm

4 5

4 5

3

6

3

6

3

6

3

6

6

6

2

7

2

7

2

7

2

7

0045 0045 0027 0027

3 6 3

6

3 6 3

6

1

8

1 8

1 8

geïntegreerd

geïntegreerd

ventiel links

ventiel rechts

0019 0098 0018 0018

3

6

3

6

3

6

3

6

2 7 2

7

2

7 2

7

2

2

7

7

0036 0036

0026 0026

0023 0023 0067 0067

3

6 3

2

7 2

0037 0037

Verena: VP1L1-ZB (stock)

6

7

• Attention: connecting the radiator

can only be as shown by the

connecting icons. for any other

connection method, we take no

responsibility.

3

8

6

3

8

6

3 6 3

6

1 1

0038 0038 0016 0016

3 6 3

6

3

6

3

6

5

5

5

5

1 1

8

8

1 8

1 8

8

mm mm 1 mm 1 mm

8

0013 0013 0068 0068

1008 1008 1008 1008



Verena: VP1-ZB / VP2-ZB / VP1L1-ZB (non stock)

6

6

2 7 2

7

0027 0027

3

6 3

6

3 6 3

6

2 2

0026 0026

5

5

4 5

4 5

7

7

0037 0037

1 8

1 8

8

8



0018 0018 0045 0045

5 5

4

4

6

6

2 7 2

7

2

2

0027 0027 0026 0026



126

PK COLLECTION

PK1 / PK2 / PK3 / PK4 PK 128

PK

Brackets /

Free-standing installation

133




127

PK PK1 / PK2 / PK3 / PK4

Types

• PK1, PK2, PK3, PK4

Tubes


• Between the square tubes, a powerful convection heat exchanger is welded,

consisting of steel tubes of Ø 12 x 1 mm and rectangular fins of 0,4 mm.

Collectors

• 2 integrated steel collectors

Colours





Special

• PK is available in 4 heights (70, 140, 210 and 280 mm), in 5 depths (80-130-

180-230-280) and in 20 lengths (from 500 to 3900 mm).

• Type PK1, PK2 and PK3 are also available as bench plinth radiator (suspensions

from THERMIC, bench not delivered from THERMIC).

• An elegant covering grill is supplied as standard.

• Wall supports, telescopic floor brackets or column feet are available with price

supplement (are not included in the price).

• PK is available with designer WVO-screen of 1,5 mm steel plate. The WVOscreen

is supplied separately and can easily be mounted on the plinth radiator.

The WVO-screen reduces the heat loss through the window.

• PK4 also available as toilet radiator (500 x 280 mm)

Brackets

• To be ordered separately, not included in the price of the radiator

PK1

PK2

Technical

• Electrically laser welded



• Extra charge for higher service pressures (10 bar): +10%.







✘

✘

✘

PK3

PK4

Connection



✔



✔







• Non-stock radiators: 15 to 30 working days, dependent on the type

of radiator

✘

✔

✘

R2

20

Aansluiting 23 Aansluiting 22 / 77

= =

35

20 30 S 30

D S1

R1

L

50

S

Min 100

35

35

B

B

Min 100

Universele aansluiting = standaard

320

20

= =

141 y

±442

18

B

35

35

Min 100

H

128

PK PK1 (PK1/80, PK1/130, PK1/180, PK1/230, PK1/280)

type

ref. nr.

12201

PK1/80

ref. nr.

12260

PK1/130

ref. nr.

12264

PK1/180

ref. nr.

12268

PK1/230

ref. nr.

12272

PK1/280

width

depth (D mm)

(L mm)

80 130 180 230 280

500

75/65/20 203 312 422 523 630

90/70/20 258 397 535 666 801

600

75/65/20 243 374 506 627 756

90/70/20 309 476 641 799 961

700

75/65/20 284 437 590 732 882

90/70/20 361 556 748 932 1121

800

75/65/20 324 499 674 836 1008

90/70/20 412 635 855 1066 1282

900

75/65/20 365 562 759 941 1134

90/70/20 464 715 962 1199 1442

1000

75/65/20 405 624 843 1045 1260

90/70/20 515 794 1069 1332 1602

1100

75/65/20 446 686 927 1150 1386

90/70/20 567 873 1176 1465 1762

1200

75/65/20 486 749 1012 1254 1512

90/70/20 618 953 1283 1598 1922

1400

75/65/20 567 874 1180 1463 1764

90/70/20 721 1112 1497 1865 2243

1600

75/65/20 648 998 1349 1672 2016

90/70/20 824 1270 1710 2131 2563

1800

75/65/20 729 1123 1517 1881 2268

90/70/20 927 1429 1924 2398 2884

2000

75/65/20 810 1248 1686 2090 2520

90/70/20 1030 1588 2138 2664 3204

2200

75/65/20 891 1373 1855 2299 2772

90/70/20 1133 1747 2352 2930 3524

2400

75/65/20 972 1498 2023 2508 3024

90/70/20 1236 1906 2566 3197 3845

2600

75/65/20 1053 1622 2192 2717 3276

90/70/20 1339 2064 2779 3463 4165

2800

75/65/20 1134 1747 2360 2926 3528

90/70/20 1442 2223 2993 3730 4486

3000

75/65/20 1215 1872 2529 3135 3780

90/70/20 1545 2382 3207 3996 4806

3300

75/65/20 1337 2059 2782 3449 4158

90/70/20 1700 2620 3528 4396 5287

3600

75/65/20 1458 2246 3035 3762 4536

90/70/20 1854 2858 3848 4795 5767

3900

75/65/20 1580 2434 3288 4076 4914

90/70/20 2009 3097 4169 5195 6248

Watt/m. (75/65/20°C) 405 624 843 1045 1260

Weight, kg/m. 6,13 8,65 11,40 13,80 16,00

Water content, l/m. 1,31 1,75 2,10 2,40 2,80

n-exponent 1,36 1,36 1,35 1,38 1,36


PK

PK1 / PK2 / PK3 / PK4

Width (L) 500 600 700 800 900

1000 1100 1200 1400 1600

1800 2000 2200 2400 2600

2800 3000 3300 3600 3900

Centre between the connections at the bottom 18 (R1) 454 554 654 754 854

954 1054 1154 1354 1554

1754 1954 2154 2354 2554

2754 2954 3254 3554 3854

Centre between the lateral connections 23 (PK2, PK3, PK4) (R2) H-70

Depth (D) 80 130 180 230 280

S - 70 120 170 220

S1 60 85 110 135 160

Y PK1 211

Y PK2 141

Y PK3 71

Tablet L+200

129


type

ref. nr.

12202

PK2/80

ref. nr.

12261

PK2/130

ref. nr.

12265

PK2/180

ref. nr.

12269

PK2/230

ref. nr.

12273

PK2/280

width

depth (D mm)

(L mm)

80 130 180 230 280

500

75/65/20 304 442 611 756 953

90/70/20 386 562 777 962 1213

600

75/65/20 365 530 733 907 1143

90/70/20 463 674 932 1154 1456

700

75/65/20 426 619 855 1058 1334

90/70/20 540 786 1087 1347 1698

800

75/65/20 486 707 977 1209 1524

90/70/20 618 898 1242 1539 1941

900

75/65/20 547 796 1099 1360 1715

90/70/20 695 1011 1398 1732 2183

1000

75/65/20 608 884 1221 1511 1905

90/70/20 772 1123 1553 1924 2426

1100

75/65/20 669 972 1343 1662 2096

90/70/20 849 1235 1708 2116 2669

1200

75/65/20 730 1061 1465 1813 2286

90/70/20 926 1348 1864 2309 2911

1400

75/65/20 851 1238 1709 2115 2667

90/70/20 1081 1572 2174 2694 3396

1600

75/65/20 973 1414 1954 2418 3048

90/70/20 1235 1797 2485 3078 3882

1800

75/65/20 1094 1591 2198 2720 3429

90/70/20 1390 2021 2795 3463 4367

2000

75/65/20 1216 1768 2442 3022 3810

90/70/20 1544 2246 3106 3848 4852

2200

75/65/20 1338 1945 2686 3324 4191

90/70/20 1698 2471 3417 4233 5337

2400

75/65/20 1459 2122 2930 3626 4572

90/70/20 1853 2695 3727 4618 5822

2600

75/65/20 1581 2298 3175 3929 4953

90/70/20 2007 2920 4038 5002 6308

2800

75/65/20 1702 2475 3419 4231 5334

90/70/20 2162 3144 4348 5387 6793

3000

75/65/20 1824 2652 3663 4533 5715

90/70/20 2316 3369 4659 5772 7278

3300

75/65/20 2006 2917 4029 4986 6287

90/70/20 2548 3706 5125 6349 8006

3600

75/65/20 2189 3182 4396 5440 6858

90/70/20 2779 4043 5591 6926 8734

3900

75/65/20 2371 3448 4762 5893 7430

90/70/20 3011 4380 6057 7504 9461

Watt/m. (75/65/20°C) 608 884 1221 1511 1905

Weight, kg/m. 11,46 15,53 19,80 23,75 27,70


n-exponent 1,35 1,36 1,36 1,37 1,37



type

width

(L mm)

depth

(D mm)

colour

short

ref. nr.

PK2/130 800 130 9016 12261-01

1000 130 9016 12261-02

1200 130 9016 12261-03

1400 130 9016 12261-04

1600 130 9016 12261-05

2000 130 9016 12261-07

3000 130 9016 12261-10

PK2/180 1200 180 9016 12265-02

1600 180 9016 12265-04

2400 180 9016 12265-07

130


type

ref. nr.

12203

PK3/80

ref. nr.

12262

PK3/130

ref. nr.

12266

PK3/180

ref. nr.

12270

PK3/230

ref. nr.

12274

PK3/280

width

depth (D mm)

(L mm)

80 130 180 230 280

500

75/65/20 378 560 771 950 1176

90/70/20 480 711 982 1209 1500

600

75/65/20 454 672 925 1140 1411

90/70/20 575 853 1178 1450 1799

700

75/65/20 529 784 1079 1330 1646

90/70/20 671 995 1375 1692 2099

800

75/65/20 605 896 1233 1520 1881

90/70/20 767 1138 1571 1934 2399

900

75/65/20 680 1008 1387 1710 2116

90/70/20 863 1280 1768 2175 2699

1000

75/65/20 756 1120 1541 1900 2351

90/70/20 959 1422 1964 2417 2999

1100

75/65/20 832 1232 1695 2090 2586

90/70/20 1055 1564 2160 2659 3299

1200

75/65/20 907 1344 1849 2280 2821

90/70/20 1151 1706 2357 2900 3599

1400

75/65/20 1058 1568 2157 2660 3291

90/70/20 1343 1991 2750 3384 4199

1600

75/65/20 1210 1792 2466 3040 3762

90/70/20 1534 2275 3142 3867 4798

1800

75/65/20 1361 2016 2774 3420 4232

90/70/20 1726 2560 3535 4351 5398

2000

75/65/20 1512 2240 3082 3800 4702

90/70/20 1918 2844 3928 4834 5998

2200

75/65/20 1663 2464 3390 4180 5172

90/70/20 2110 3128 4321 5317 6598

2400

75/65/20 1814 2688 3698 4560 5642

90/70/20 2302 3413 4714 5801 7198

2600

75/65/20 1966 2912 4007 4940 6113

90/70/20 2493 3697 5106 6284 7797

2800

75/65/20 2117 3136 4315 5320 6583

90/70/20 2685 3982 5499 6768 8397

3000

75/65/20 2268 3360 4623 5700 7053

90/70/20 2877 4266 5892 7251 8997

3300

75/65/20 2495 3696 5085 6270 7758

90/70/20 3165 4693 6481 7976 9897

3600

75/65/20 2722 4032 5548 6840 8464

90/70/20 3452 5119 7070 8701 10796

3900

75/65/20 2948 4368 6010 7410

90/70/20 3740 5546 7660 9426

Watt/m. (75/65/20°C) 756 1120 1541 1900 2351

Weight, kg/m. 16,80 22,40 28,20 33,70 39,40


n-exponent 1,35 1,35 1,38 1,37 1,38


PK

131


type

ref. nr.

12204

PK4/80

ref. nr.

12263

PK4/130

ref. nr.

12267

PK4/180

ref. nr.

12271

PK4/230

ref. nr.

12275

PK4/280

width

depth (D mm)

(L mm)

80 130 180 230 280

500

75/65/20 435 678 919 1129 1335

90/70/20 551 866 1176 1444 1709

600

75/65/20 522 813 1103 1355 1602

90/70/20 661 1039 1411 1733 2050

700

75/65/20 609 949 1287 1581 1869

90/70/20 771 1212 1646 2022 2392

800

75/65/20 696 1084 1470 1806 2136

90/70/20 882 1385 1882 2310 2734

900

75/65/20 783 1220 1654 2032 2403

90/70/20 992 1558 2117 2599 3075

1000

75/65/20 870 1355 1838 2258 2670

90/70/20 1102 1731 2352 2888 3417

1100

75/65/20 957 1491 2022 2484 2937

90/70/20 1212 1904 2587 3177 3759

1200

75/65/20 1044 1626 2206 2710 3204

90/70/20 1322 2077 2822 3466 4100

1400

75/65/20 1218 1897 2573 3161 3738

90/70/20 1543 2423 3293 4043 4784

1600

75/65/20 1392 2168 2941 3613 4272

90/70/20 1763 2770 3763 4621 5467

1800

75/65/20 1566 2439 3308 4064 4806

90/70/20 1984 3116 4234 5198 6151

2000

75/65/20 1740 2710 3676 4516 5340

90/70/20 2204 3462 4704 5776 6834

2200

75/65/20 1914 2981 4044 4968 5874

90/70/20 2424 3808 5174 6354 7517

2400

75/65/20 2088 3252 4411 5419 6408

90/70/20 2645 4154 5645 6931 8201

2600

75/65/20 2262 3523 4779 5871 6942

90/70/20 2865 4501 6115 7509 8884

2800

75/65/20 2436 3794 5146 6322 7476

90/70/20 3086 4847 6586 8086 9568

3000

75/65/20 2610 4065 5514 6774

90/70/20 3306 5193 7056 8664

3300

75/65/20 2871 4472 6065 7451

90/70/20 3637 5712 7762 9530

3600

75/65/20 3132 4878 6617

90/70/20 3967 6232 8467

3900

75/65/20 3393 5285 7168

90/70/20 4298 6751 9173

Watt/m. (75/65/20°C) 870 1356 1838 2258 2670

Weight, kg/m. 22,14 29,28 36,60 43,66 51,10


n-exponent 1,34 1,39 1,40 1,40 1,40


132

PK Brackets / Free-standing installation

In option

Length in mm

number needed per

plinth

REF.NR.

PK/80

REF.NR.

PK/130

REF.NR.

PK/180

REF.NR.

PK/230

REF.NR.

PK/280

COLOUR

PK

Wall mounting

brackets*

500 - 1800: 2 128601200009016 128602200009016 128603200009016 128604200009016 128605200009016 RAL 9016

12860120000xxxx 12860220000xxxx 12860320000xxxx 12860420000xxxx 12860520000xxxx COLOUR

2000 - 2400: 3 128601300009016 128602300009016 128603300009016 128604300009016 128605300009016 RAL 9016


2600 - 3600: 4 128601400009016 128602400009016 128603400009016 128604400009016 128605400009016 RAL 9016


3900: 5 128601500009016 128602500009016 128603500009016 128604500009016 128605500009016 RAL 9016


When ordering the wall mounting brackets, please indicate the type (80-130-180-230-280) and the colour. Maximum width/bracket: for PK3: depth = 180 mm, for PK4:

depth = 130 mm.

* number needed per plinth:

PK1 PK2 PK3 PK4

in mm 80 130 180 230 280 80 130 180 230 280 80 130 180 80 130

up to 1800 mm 2 3 3 4 4 2 3 3 4 5 2 3 3 2 3

1900 - 2400 mm 2 3 3 4 4 2 3 3 4 6 2 3 3 3 3

2500 - 3600 mm 3 3 3 4 5 3 3 4 5 6 3 3 4 3 4

3700 - 3900 mm 3 3 3 4 5 3 3 4 5 6 3 4 4 3 4

Telescopic floor

brackets

500 - 1800: 2 128611200009016 128612200009016 128613200009016 128614200009016 128615200009016 RAL 9016


2000 - 2400: 3 128611300009016 128612300009016 128613300009016 128614300009016 128615300009016 RAL 9016


2600 - 3600: 4 128611400009016 128612400009016 128613400009016 128614400009016 128615400009016 RAL 9016


3900: 5 128611500009016 128612500009016 128613500009016 128614500009016 128615500009016 RAL 9016


When ordering the floor brackets, please indicate the type (80-130-180-230-280) and the colour. The feet are delivered standard with rosets. Max. height of the floor

brackets: 265 mm. Min. height of the floor brackets: 205 mm. The upper part of the foot consists of a rectangular foot of 40/25 mm, the lower part of a rectangular foot of

35/20 mm.

133

PK Free-standing installation

In option

Length in mm

number needed per plinth

REF.NR.

PK/80

REF.NR.

PK/130

REF.NR.

PK/180

REF.NR.

PK/230

REF.NR.

PK/280

Steel column feet

500 - 1800: 2 RAL 9016 128621200009016 128622200009016 128623200009016 128624200009016 128625200009016

COLOUR 12862120000xxxx 12862220000xxxx 12862320000xxxx 12862420000xxxx 12862520000xxxx

2000 - 2400: 3 RAL 9016 128621300009016 128622300009016 128623300009016 128624300009016 128625300009016


2600 - 3600: 4 RAL 9016 128621400009016 128622400009016 128623400009016 128624400009016 128625400009016


3900: 5 RAL 9016 128621500009016 128622500009016 128623500009016 128624500009016 128625500009016


Steel column feet enable to fix a thermostatic valve. The standard height of the feet is 150 mm. Possible for all connections except for connection 11 and 88.

Number of column feet needed = number of telescopic feet needed.

134

PK Accessories

In option

ACCESSORIES

REF.NR.

PK1

REF.NR.

PK2

REF.NR.

PK3

REF.NR.

PK4

COLOUR

PK

WVO-screen

1286301xxxx9016 1286302xxxx9016 1286303xxxx9016 1286304xxxx9016 RAL 9016

1286301xxxxxxxx 1286302xxxxxxxx 1286303xxxxxxxx 1286304xxxxxxxx COLOUR

The WVO-screen is delivered separately and can easily be mounted on the plinth radiator. The WVO-screen is included in the WVO-screen price.

Please indicate the length in the reference number when ordering (0500/0600/...).

ACCESSORIES

PLINTH

LENGTH

NUMBER OF

PIECES

REF.NR.

PK/80

REF.NR.

PK/130

REF.NR.

PK/180

REF.NR.

PK/230

REF.NR.

PK/280

Bench

Y

X

PK1

PK2

PK3

RAL 9016 500-1800 set 2x - 128642200009016 128643200009016 128644200009016 -

COLOUR - 12864220000xxxx 12864320000xxxx 12864420000xxxx -

RAL 9016 2000-2400 set 3x - 128642300009016 128643300009016 128644300009016 -


RAL 9016 2600-3600 set 4x - 128642400009016 128643400009016 128644400009016 -


RAL 9016 3900 set 5x - 128642500009016 128643500009016 128644500009016 -


RAL 9016 500-1800 set 2x - 128652200009016 128653200009016 128654200009016 -


RAL 9016 2000-2400 set 3x - 128652300009016 128653300009016 128654300009016 -


RAL 9016 2600-3600 set 4x - 128652400009016 128653400009016 128654400009016 -


RAL 9016 3900 set 5x - 128652500009016 128653500009016 128654500009016 -


RAL 9016 500-1800 set 2x - 128662200009016 128663200009016 128664200009016 -


RAL 9016 2000-2400 set 3x - 128662300009016 128663300009016 128664300009016 -


RAL 9016 2600-3600 set 4x - 128662400009016 128663400009016 128664400009016 -


RAL 9016 3900 set 5x - 128662500009016 128663500009016 128664500009016 -


The bench supports have to be ordered together with the plinth radiator. The bench parts are not sold separately.

A set consists of 1 steel column foot ‘X’ and 1 bench support ‘Y’. The wooden shelves for the bench are not available from THERMIC. The connections are the

same as the connections for steel column foot plinth radiators. A plinth radiator with a bench is available with WVO-screen. All models are supplied with a grill*.

* Please indicate code 02 for “Finish” when ordering (see “How to order” on page 8). Mounting accessories for benches are delivered together with the mounting

instructions with the positions of the wholes for the wooden bench.

X : 141 mm

Y : PK1 = 211 mm

PK2 = 141 mm

PK3 = 71 mm

Possible for the following plinth radiators:

type depth width

PK1-130 130 500-3900

PK1-180 180 500-3900

PK1-230 230 500-3900


PK2-130 130 500-3900

PK2-180 180 500-3900

PK2-230 230 500-3900


PK3-130 130 500-3900

PK3-180 180 500-3900

PK3-230 230 500-3900

135

PK Connections

PK: PK2 (stock)

3

6

3

6

2

7

2

7

1 8

1 8

9999 9999

3

6

3

6

3

6

3

6

2

7

2

7

2

7

2

7

1 8

1 8

1 8

1 8

9999 9999

9999 9999

3

6

3

6

3

6

3

6

2

7

2

7

2

7

2

7

1 8

1 8

1 8

1 8

9999 9999 9999 9999

• PK2 universal connection 6 x ½ (1, 2, 3, 6, 7, 8)

• Attention: two-pipe system: not possible for type PK2/80: 11, 88, 22, 77

• Attention: connecting the radiator can only be as shown by the connecting icons.

For any other connection method, we take no responsibility.

PK: PK1/PK2/PK3/PK4 (non stock)

6

6

1 8

1 8

0018 0018

3

6

3

6

3

6

3

6

2

2

7

7

0023 0023 0067 0067

3 6 3

6

3

6

3

6

2

2

7

7

0026 0026 0037 0037

6

6

2

7

2

7

0027 0027

• PK2, PK3, PK4 universal connection 6 x ½ (1, 2, 3, 6, 7, 8)

• PK1 universal connection 4 x ½ (1, 3, 6, 8)

• Attention: two-pipe system: - not possible for types PK1/80, PK2/80, PK3/80,

PK4/80: 11, 88, 22, 77 - not possible for type PK1: 23, 32, 67, 76



136

Navaro COLLECTION

NVR1 / NVR2 Navaro Vertical 138

NVRSN Navaro Vertical 141

NHR1 / NHR2 Navaro Horizontal 143

Navaro




137

Navaro Vertical (NVR1)

type

ref. nr.

12205

NVR1

tubes

(n)

width

height (H mm)

(L mm)

1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000

75/65/20 357 422 488 557 627 700 775 848 921 994 1067

90/70/20 447 530 615 704 791 881 973 1065 1156 1248 1339

75/65/20 476 563 651 742 836 933 1034 1131 1228 1325 1422

90/70/20 596 706 820 938 1055 1175 1297 1419 1541 1663 1785

75/65/20 596 704 814 928 1045 1166 1292 1413 1535 1656 1778

90/70/20 745 883 1025 1173 1319 1469 1622 1774 1927 2079 2232

75/65/20 715 844 977 1113 1254 1399 1550 1696 1842 1988 2133

90/70/20 894 1060 1230 1407 1582 1763 1946 2129 2312 2495 2678

75/65/20 834 985 1139 1299 1463 1633 1809 1979 2149 2319 2489

90/70/20 1043 1236 1435 1642 1846 2057 2271 2484 2697 2911 3125

75/65/20 953 1126 1302 1484 1672 1866 2067 2261 2456 2650 2844

90/70/20 1192 1413 1640 1876 2110 2350 2595 2839 3083 3327 3571

75/65/20 1072 1266 1465 1670 1881 2099 2325 2544 2763 2981 3200

90/70/20 1341 1590 1846 2111 2373 2644 2919 3194 3468 3743 4017

75/65/20 1191 1407 1628 1855 2090 2332 2584 2827 3070 3313 3556

90/70/20 1490 1766 2051 2345 2637 2938 3244 3549 3853 4159 4464

75/65/20 1310 1548 1791 2041 2299 2565 2842 3109 3377 3644 3911

90/70/20 1639 1943 2256 2580 2901 3232 3568 3903 4239 4574 4910

75/65/20 1429 1688 1953 2226 2508 2799 3101 3392 3684 3975 4267

90/70/20 1788 2119 2461 2814 3165 3526 3892 4258 4624 4990 5356

75/65/20 1548 1829 2116 2412 2716 3032 3359 3675 3990 4306 4622

90/70/20 1937 2296 2666 3049 3428 3819 4217 4613 5009 5406 5803

75/65/20 1667 1970 2279 2597 2925 3265 3617 3958 4297 4638 4978

90/70/20 2086 2473 2871 3283 3692 4113 4541 4968 5395 5822 6249

Watt/el. (75/65/20°C) 59,55 70,35 81,39 92,75 104,48 116,61 129,19 141,34 153,48 165,63 177,78

Weight, kg/el. 1,55 1,83 2,11 2,34 2,63 2,92 3,20 3,49 3,78 4,07 4,36

Water content, l/el. 0,44 0,50 0,57 0,63 0,72 0,80 0,89 0,97 1,05 1,14 1,22

n-exponent 1,27 1,29 1,31 1,33 1,32 1,31 1,29 1,29 1,29 1,29 1,29

6 270

8 360

10 450

12 540

14 630

16 720

18 810

20 900

22 990

24 1080

26 1170

28 1260



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

NVR1 450 2000 9016 12205-02

720 2000 9016 12205-07

225

225

35

127

54

35

176

103

1/2"

45

1/2"

50

63

H-40

H-40

63

H

R2

H+130

31

54

80

103

50

1/2" 1/2"

R1

L

20

77,5

R1

H=150

138

Navaro Vertical (NVR1, NVR2)

Types

• One (NVR1) or two rows (NVR2) of tubes

Tubes


Collectors


Navaro

Colours





NVR1

Special

• NVR1 / NVR2 also available as free-standing radiator

• Please indicate K-distance (distance floor / radiator) and B-distance

(distance radiator / ceiling) when ordering free-standing installation.

Brackets


NVR2

Technical



• Standard operating pressure: 4 bar. Extra charge for higher service

pressures (10 bar): +10%.

• The delivery time of a radiator with a higher service pressure is 1 week

extra.






✘

✘

✘

ref. nr. 128200200009016


Connection










✔

✔

✔

✔

✘




NVR1 / NVR2

Width (L) 270 360 450 540 630 720 810 900 990 1080 1170 1260

Centre between the connections at the bottom 18 (R1) 180 270 360 450 540 630 720 810 900 990 1080 1170

Height (H) 1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000

Centre between the lateral connections 23/67 (R2) 960 1160 1360 1560 1760 1960 2160 2360 2560 2760 2960


139

Navaro Vertical (NVR2)

type

ref. nr.

12208

NVR2

tubes

(n)

width

height (H mm)

(L mm)

1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000

75/65/20 603 705 808 911 1015 1121 1229 1335 1441 1547 1653

90/70/20 758 887 1016 1148 1277 1408 1543 1676 1809 1942 2075

75/65/20 804 940 1077 1214 1354 1495 1639 1780 1921 2063 2204

90/70/20 1011 1182 1354 1530 1702 1877 2057 2234 2412 2589 2767

75/65/20 1005 1175 1346 1518 1692 1869 2048 2225 2402 2578 2755

90/70/20 1263 1478 1693 1913 2128 2346 2571 2793 3015 3237 3459

75/65/20 1206 1410 1615 1822 2031 2242 2458 2670 2882 3094 3306

90/70/20 1516 1773 2031 2295 2553 2815 3085 3352 3618 3884 4150

75/65/20 1406 1645 1884 2125 2369 2616 2867 3115 3362 3610 3857

90/70/20 1769 2069 2370 2678 2979 3284 3600 3910 4221 4531 4842

75/65/20 1607 1880 2154 2429 2707 2990 3277 3560 3843 4125 4408

90/70/20 2021 2365 2708 3060 3405 3753 4114 4469 4824 5179 5534

75/65/20 1808 2115 2423 2733 3046 3364 3687 4005 4323 4641 4959

90/70/20 2274 2660 3047 3443 3830 4223 4628 5028 5427 5826 6225

75/65/20 2009 2350 2692 3036 3384 3737 4096 4450 4803 5157 5510

90/70/20 2527 2956 3385 3825 4256 4692 5142 5586 6030 6473 6917

75/65/20 2210 2585 2961 3340 3723 4111 4506 4895 5284

90/70/20 2779 3251 3724 4208 4681 5161 5657 6145 6633

75/65/20 2411 2820 3230 3643 4061 4485 4916

90/70/20 3032 3547 4062 4590 5107 5630 6171

75/65/20 2612 3056 3500 3947 4399 4859

90/70/20 3285 3843 4401 4973 5533 6099

75/65/20 2813 3291 3769 4251 4738

90/70/20 3538 4138 4740 5355 5958

Watt/el. (75/65/20°C) 100,46 117,52 134,60 151,81 169,21 186,87 204,82 222,49 240,16 257,83 275,50

Weight, kg/el. 2,94 3,50 4,05 4,61 5,15 5,70 6,25 6,80 7,35 7,89 8,44

Water content, l/el. 0,76 0,90 1,04 1,18 1,35 1,52 1,68 1,85 2,02 2,19 2,36

n-exponent 1,30 1,30 1,30 1,31 1,30 1,29 1,29 1,29 1,29 1,29 1,29

6 270

8 360

10 450

12 540

14 630

16 720

18 810

20 900

22 990

24 1080

26 1170

28 1260



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

NVR2 540 2000 9016 12208-02

720 2000 9016 12208-04

140

Navaro Vertical (NVRSN)

Types

• NVRSN: with integrated mirror

Tubes


Collectors


Navaro

Colours





NVRSN

Special

• Type NVRSN is standard delivered with an integrated mirror

(width 160 mm).

Brackets


ref. nr. 128200200009016


Technical



• Standard operating pressure: 4 bar. Extra charge for higher service pressures (10 bar): +10







✘

✘

✘

Connection










✔

✔

✔

✔

✘



225

35

127

54

1/2"

45

1/2"

H-40

H

R2

NVRSN


Width (L) 491 581 671





min. 70

63

31

54

1/2" 50 1/2"

160

176

R1

L

20

141

Navaro Vertical (NVRSN)

type

ref. nr.

12211

NVRSN

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

491 1800 872 1100 1,32 29,10 5,50 8 -

581 1800 1090 1376 1,32 34,40 6,90 10 -

671 1800 1308 1651 1,32 39,80 8,30 12 -


NHR1 / NHR2

Width (L) 540 630 720 810 900 990 1080 1170 1260 1440 1620 1800 1980 2160 2340 2520 2700 2880 3060

Centre between the connections at the bottom 18 (R1) 450 540 630 720 810 900 990 1080 1170 1350 1530 1710 1890 2070 2250 2430 2610 2790 2970

Height (H) 400 500 600 700 800 900

Centre between the lateral connections 23/67 (R2) 365 465 565 665 765 865


142

Navaro Horizontal (NHR1, NHR2)

Types

• One (NHR1) or two rows (NHR2) of tubes

Tubes


Collectors


Navaro

Colours





Special

• NHR1 / NHR2 also available as free-standing radiator

• Please indicate K-distance (distance floor / radiator) and B-distance

(distance radiator / ceiling) when ordering free-standing installation.

• NHR1 also available as toilet radiator (540 x 500 mm)

Brackets


Technical



• Standard operating pressure: 4 bar. Extra charge for higher service

pressures (10 bar): +10%.







Connection










✘

✘

✘

✔

✔

✔

✔

✘

NHR1

return

supply

ref. nr. 128210100000099


NHR2



225

91

225

147

H-40 35

127

54

35

H-40

176

103

H

1/2"

R2

45

1/2"

H+130

50

1/2"

63

31

54

63

80

103

20

1/2"

1/2" 1/2"

R1

L

1/2"

75

R1

K=150

143

Navaro Horizontal (NHR1)

type

ref. nr.

12276

NHR1

tubes

(n)

width

height (H mm)

(L mm)

400 500 600 700 800 900

75/65/20 330 396 460 523 587 651

90/70/20 409 490 571 651 732 813

75/65/20 385 461 536 611 685 759

90/70/20 477 572 666 760 854 948

75/65/20 440 527 613 698 783 868

90/70/20 545 654 762 868 976 1083

75/65/20 495 593 690 785 881 976

90/70/20 613 736 857 977 1098 1219

75/65/20 550 659 766 872 978 1084

90/70/20 681 817 952 1086 1220 1354

75/65/20 605 725 843 960 1076 1193

90/70/20 749 899 1047 1194 1342 1490

75/65/20 660 791 920 1047 1174 1301

90/70/20 817 981 1142 1303 1464 1625

75/65/20 716 857 996 1134 1272 1410

90/70/20 886 1063 1238 1411 1585 1760

75/65/20 771 923 1073 1221 1370 1518

90/70/20 954 1144 1333 1520 1707 1896

75/65/20 881 1055 1226 1396 1565 1735

90/70/20 1090 1308 1523 1737 1951 2167

75/65/20 991 1187 1380 1570 1761 1952

90/70/20 1226 1471 1714 1954 2195 2438

75/65/20 1101 1318 1533 1745 1957 2169

90/70/20 1362 1635 1904 2171 2439 2708

75/65/20 1211 1450 1686 1919 2152 2386

90/70/20 1499 1798 2094 2388 2683 2979

75/65/20 1321 1582 1839 2094 2348 2603

90/70/20 1635 1962 2285 2605 2927 3250

75/65/20 1431 1714 1993 2268 2544 2819

90/70/20 1771 2125 2475 2823 3171 3521

75/65/20 1541 1846 2146 2443 2740 3036

90/70/20 1907 2289 2666 3040 3415 3792

75/65/20 1651 1978 2299 2617 2935 3253

90/70/20 2044 2452 2856 3257 3659 4063

75/65/20 1761 2109 2452 2792 3131 3470

90/70/20 2180 2616 3046 3474 3903 4333

75/65/20 1871 2241 2606 2966 3327 3687

90/70/20 2316 2779 3237 3691 4147 4604

Watt/el. (75/65/20°C) 27,52 32,96 38,32 43,62 48,92 54,22

Weight, kg/el. 0,71 0,85 0,99 1,13 1,27 1,41

Water content, l/el. 0,22 0,25 0,29 0,33 0,37 0,40

n-exponent 1,21 1,22 1,23 1,24 1,25 1,26

12 540

14 630

16 720

18 810

20 900

22 990

24 1080

26 1170

28 1260

32 1440

36 1620

40 1800

44 1980

48 2160

52 2340

56 2520

60 2700

64 2880

68 3060


144

Navaro Horizontal (NHR2)

type

ref. nr.

12277

NHR2

tubes

(n)

width

height (H mm)

(L mm)

400 500 600 700 800 900

75/65/20 571 682 790 895 1000 1103

90/70/20 711 850 986 1120 1253 1385

75/65/20 667 796 921 1045 1166 1287

90/70/20 830 992 1151 1307 1461 1615

75/65/20 762 910 1053 1194 1333 1471

90/70/20 948 1134 1315 1494 1670 1846

75/65/20 857 1023 1185 1343 1499 1654

90/70/20 1067 1276 1479 1680 1879 2077

75/65/20 952 1137 1316 1492 1666 1838

90/70/20 1185 1417 1644 1867 2088 2308

75/65/20 1048 1251 1448 1642 1833 2022

90/70/20 1304 1559 1808 2054 2297 2538

75/65/20 1143 1364 1580 1791 1999 2206

90/70/20 1422 1701 1973 2240 2505 2769

75/65/20 1238 1478 1711 1940 2166 2390

90/70/20 1541 1843 2137 2427 2714 3000

75/65/20 1333 1592 1843 2089 2332 2573

90/70/20 1659 1984 2301 2614 2923 3231

75/65/20 1524 1819 2106 2388 2666 2941

90/70/20 1896 2268 2630 2987 3340 3692

75/65/20 1714 2047 2370 2686 2999 3309

90/70/20 2133 2551 2959 3361 3758 4154

75/65/20 1905 2274 2633 2985 3332 3676

90/70/20 2370 2835 3288 3734 4176 4615

75/65/20 2095 2501 2896 3283 3665 4044

90/70/20 2607 3118 3616 4107 4593 5077

75/65/20 2286 2729 3159 3582 3998 4412

90/70/20 2844 3402 3945 4481 5011 5538

75/65/20 2476 2956 3423 3880 4332 4779

90/70/20 3082 3685 4274 4854 5428 6000

75/65/20 2667 3184 3686 4179 4665 5147

90/70/20 3319 3969 4603 5228 5846 6461

75/65/20 2857 3411 3949 4477 4998

90/70/20 3556 4252 4931 5601 6263

75/65/20 3048 3638 4212 4776

90/70/20 3793 4536 5260 5974

75/65/20 3238 3866 4476 5074

90/70/20 4030 4819 5589 6348

Watt/el. (75/65/20°C) 47,62 56,85 65,82 74,62 83,30 91,91

Weight, kg/el. 1,21 1,50 1,79 2,08 2,37 2,65

Water content, l/el. 0,37 0,43 0,50 0,57 0,63 0,70

n-exponent 1,24 1,25 1,26 1,27 1,28 1,29

12 540

14 630

16 720

18 810

20 900

22 990

24 1080

26 1170

28 1260

32 1440

36 1620

40 1800

44 1980

48 2160

52 2340

56 2520

60 2700

64 2880

68 3060


Navaro

145

Navaro Free-standing installation

In option


NVR1 / NVR2 / NHR1 / NHR2

Free-standing

installation

RAL 9016 128100700009016

COLOUR

12810070000xxxx

• free-standing radiators in the colour RAL 9016 and Pergamon: 1 separate lateral support, 2 feet (H=150 mm) and 2 rosets in the colour of the

radiator.

• free-standing radiators in other colours: 1 separate lateral support, 2 feet (H=150 mm) in the colour of the radiator + 2 chrome plated rosets.

• Not for radiators ≥ 1800 mm


Telescopic

feet / ceiling

brackets

RAL 9016 128100900009016


• Telescopic feet: indicate distance floor-radiator (= K-measure).

• Telescopic ceiling brackets: indicate distance ceiling-radiator (= B-measure). Length: min. 151 mm, max. 225 mm.

NVR1 / NHR1

RAL 9016 *

COLOUR *

Fixed foot

NVR2 / NHR2

RAL 9016 *

COLOUR *

• The top of the foot is a part of the radiator = extended tube, 3rd tube on the left and on the right

number of tubes:

≤ 32: 2 feet

36-68: 4 feet

• price/foot


146

Navaro Accessories

In option


TOWEL RAIL

NVR1 / NVR2 / NVRSN / NHR1 /

NHR2

CHROME 128322200000099

Navaro

• h = 22 mm; b = 670 mm; d = 85 mm; a = 60 mm

HOOK O-RING


NHR2

CHROME 128360100000099

• h = 22 mm; b = 22 mm; d = 42 mm

HOOK WITH A

WIDE GROOVE


NHR2

CHROME 128340100000099

• h = 22 mm; b = 22 mm; d = 42 mm

DRYING- AND

STACKING RACK

NARROW


NHR2

CHROME 128300800000099

• h = 22 mm; b = 385 mm; d = 163 mm; a = 30 mm


DRYING- AND

STACKING RACK

LARGE

CHROME 128301100000099

• h = 22 mm; b = 530 mm; d = 163 mm; a = 30 mm



147

Navaro Connections

Navaro: NVR1 / NVR2 (stock)

3

6

3

6

3

6

3

6

1 mm 8

1 mm 8

1 mm 8

1 mm 8

1008 1008 1008 1008



Navaro: NVR1 / NVR2 / NVRSN / NHR1 / NHR2 (non stock)

3

6

3

6

3

6

3

6

1 8

1 8

mm

mm

0018 0018 0099 0099

3

6

3

6

3

6

3

6

2 7 2

7 2 7 2

7

0023 0023 0067 0067

4 5

4 5

3

6

3

6

2

7

2

7

2

7

2

7

0045 0045 0027 0027

3 6 3

6

3 6 3

6

2 7 2

7

2

7 2

7

0036 0036

0026 0026

3

6

3

6

2

7

2

7

0037 0037



148

VR COLLECTION

VRV1-X / VRV2-X VR Vertical 150

VRVS1 / VRVS2 VR Vertical 152

VR




149

VR Vertical (VRV1-X, VRV2-X)

type

ref. nr.

12226

VRV1-X

tubes

(n)

width

height (H mm)

(L mm)

1400 1600 1800 2000 2200

75/65/20 753 850 947 1043 1139

90/70/20 948 1071 1193 1307 1427

75/65/20 878 992 1105 1217 1328

90/70/20 1107 1250 1392 1525 1665

75/65/20 1004 1134 1263 1391 1518

90/70/20 1265 1428 1591 1743 1902

75/65/20 1129 1276 1421 1565 1708

90/70/20 1423 1607 1790 1961 2140

Watt/el. (75/65/20°C) 62,74 70,87 78,93 86,93 94,88

Weight, kg/el. 1,02 1,14 1,26 1,39 1,53


n-exponent 1,31 1,31 1,31 1,28 1,28

12 420

14 492

16 564

18 636

ref. nr.

12227

VRV2-X

12 420

75/65/20 1159 1299 1435 1568 1697

90/70/20 1460 1638 1815 1975 2138

14 492

75/65/20 1352 1516 1675 1829 1980

90/70/20 1704 1911 2117 2304 2494

16 564

75/65/20 1546 1732 1914 2091 2263

90/70/20 1947 2184 2420 2634 2851

18 636

75/65/20 1739 1949 2153 2352 2546

90/70/20 2191 2458 2722 2963 3207

Watt/el. (75/65/20°C) 96,60 108,26 119,61 130,66 141,43

Weight, kg/el. 1,91 2,15 2,40 2,67 2,95


n-exponent 1,31 1,32 1,33 1,31 1,31


168

168

35

92

54

35

92

54

1/2"

36

1/2"

50

1/2"

63

H=150

63

H-40

H-40

H

R2

H+130

20

1/2" 50 1/2" 1/2" 1/2"

54

31

54

31

R1

L

80

R1

150

VR Vertical (VRV1-X, VRV2-X)

Types

• One (VRV1-X) or two rows (VRV2-X) of tubes

VR

Tubes


Collectors


Colours





VRV1-X

Special

• VRV1-X / VRV2-X also available as free-standing radiator

Brackets


Technical





VRV2-X





Connection










✘

✘

✘

✔

✔

✔

✔

✘

ref. nr. 128200200009016




VRV1-X / VRV2-X

Number of tubes (n) 12 14 16 18

Width (L) 420 492 564 636

Centre between the connections at the bottom 18 (R1) 360 432 504 576

Height (H) 1400 1600 1800 2000 2200

Centre between the lateral connections 23/67 (R2) 1360 1560 1760 1960 2160


151

VR Vertical (VRVS1, VRVS2)

type

ref. nr.

12233

VRVS1

ref. nr.

12234

VRVS2

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

500 1800 789 994 1,31 20,14 6,00 10 -

572 1800 947 1193 1,31 22,66 7,20 12 -

644 1800 1105 1392 1,31 25,18 8,40 14 -

500 1800 1196 1512 1,33 31,54 11,30 10 -

572 1800 1435 1814 1,33 36,34 13,56 12 -

644 1800 1675 2118 1,33 41,14 15,82 14 -


168

168

35

92

54

35

92

54

1/2"

36

1/2"

H-40

H

63

H-40

63

R2

54

54

1/2" 50 1/2"

160

188

20

31

31

R1

L

152

VR Vertical (VRVS1, VRVS2)

Types

• One (VRVS1) or two rows (VRVS2) of tubes

VR

Tubes


Collectors


Colours





VRVS1

Special

• Type VRVS is standard delivered with an integrated mirror (width 160

mm).

Brackets


Technical



• Standard operating pressure: 10 bar.


VRVS2





Connection










✘

✘

✘

✔

✔

✔

✔

✘

ref. nr. 128200200009016




VRVS1 / VRVS2


Width (L) 500 572 644





153

VR Free-standing installation

In option


VRV1-X / VRV2-X

Free-standing

installation

RAL 9016 128100700009016

COLOUR

12810070000xxxx

• free-standing radiators in the colour RAL 9016 and Pergamon: 1 separate lateral support, 2 feet (H=150

mm) and 2 rosets in the colour of the radiator.

• free-standing radiators in other colours: 1 separate lateral support, 2 feet (H=150 mm) in the colour of the

radiator and 2 chrome plated rosets.

154

VR Accessories

In option


VRV1-X / VRV2-X / VRVS1 / VRVS2

VR

TOWEL RAIL

CHROME 128322700000099

• h = 22 mm; b = 670 mm; d = 85 mm; a = 60 mm



155

VR Connections

VR: VRV1-X / VRV2-X / VRVS1 / VRVS2

3

6

3

6

3

6

3

6

1 8

1 8

mm

mm

0018 0018 0099 0099

3

6

3

6

3

6

3

6

2 7 2

7 2 7 2

7

0023 0023 0067 0067

4 5

4 5

3

6

3

6

2

7

2

7

2

7

2

7

0045 0045 0027 0027

3 6 3

6

3 6 3

6

2 7 2

7

2

7 2

7

0036 0036

0026 0026

3

6

3

6

2

7

2

7

0037 0037



156

Vision COLLECTION

VRVK-V Vision Vertical 158

VRVK-H Vision Horizontal 160

VRVK-R Vision Round 162

VRVK-O Vision half-round 164

VRVK-A Vision quarter-round 166

Vision



157

Vision Vision Vertical (VRVK-V)

type

ref. nr.

12232

VRVK-V

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

332 1600 727 913 1,29 13,05 6,30 12 -

332 1800 811 1022 1,31 14,00 7,10 12 -

332 2000 895 1132 1,33 14,95 7,90 12 -

332 2200 979 1240 1,34 15,90 8,70 12 -

444 1600 974 1225 1,30 17,25 8,38 16 -

444 1800 1087 1367 1,30 18,85 9,33 16 -

444 2000 1199 1510 1,31 20,45 10,28 16 -

444 2200 1311 1655 1,32 22,05 11,23 16 -

500 1600 1098 1381 1,30 19,35 9,43 18 -

500 1800 1225 1541 1,30 21,28 10,45 18 -

500 2000 1352 1700 1,30 23,20 11,48 18 -

500 2200 1478 1862 1,31 25,12 12,50 18 -

668 1600 1469 1847 1,30 25,65 12,55 24 -

668 1800 1640 2059 1,29 28,55 13,80 24 -

668 2000 1809 2267 1,28 31,45 15,05 24 -

668 2200 1979 2480 1,28 34,35 16,30 24 -


L-164

72-90

36-54

1/2" 1/2"

50

28

1/2"

H-140

63

3/4”

31

H

R2

1/2"

H-130

1/2" 1/2" 1/2" 75 R1

50

R1

1/2"

K=150 H

54

L

158

Vision Vision Vertical (VRVK-V)

Tubes


Collectors


Vision

Colours





VRVK-V

Special

• VRVK-V also available as free-standing radiator

Brackets


Technical





ref. nr. 128200200009016






✘

✘

✘

Connection










✔

✔

✔

✔

✘



VRVK-V

Width (L) 332 444 500 668

Centre between the connections at the bottom 18 (R1) 280 392 448 616

Height (H) 1600 1800 2000 2200

Centre between the lateral connections 23/67 (R2) 1560 1760 1960 2160


159

Vision Vision Horizontal (VRVK-H)

type

ref. nr.

12229

VRVK-H

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

1600 332 798 984 1,19 13,05 6,30 12 -

1800 332 898 1108 1,19 14,00 7,10 12 -

2000 332 998 1231 1,19 14,95 7,90 12 -

2200 332 1098 1354 1,19 15,90 8,70 12 -

1600 444 1121 1392 1,23 17,25 8,38 16 -

1800 444 1262 1568 1,23 18,85 9,33 16 -

2000 444 1402 1741 1,23 20,45 10,28 16 -

2200 444 1542 1915 1,23 22,05 11,23 16 -

1600 500 1283 1599 1,25 19,35 9,43 18 -

1800 500 1444 1800 1,25 21,28 10,45 18 -

2000 500 1604 1999 1,25 23,20 11,48 18 -

2200 500 1764 2199 1,25 25,12 12,50 18 -

1600 668 1766 2213 1,28 25,65 12,55 24 -

1800 668 1987 2490 1,28 28,55 13,80 24 -

2000 668 2208 2767 1,28 31,45 15,05 24 -

2200 668 2429 3044 1,28 34,35 16,30 24 -


L-140

72-90

36-54

1/2” 1/2”

H-164

H

28

VRVK-H

Width (L) 1600 1800 2000 2200



160

Ø35

1/2” R

1/2”

L

Vision Vision Horizontal (VRVK-H)

Tubes


Collectors


Vision

Colours





Brackets


Technical









✘

✘

✘

Connection



✔



✔





✘

✔

✘

VRVK-H

return

supply



ref. nr. 128210100000099


161

Vision Vision Round (VRVK-R)

type

ref. nr.

12231

VRVK-R

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

450 1600 974 873 1,30 17,25 8,38 16 -

450 1800 1087 975 1,30 18,85 9,33 16 -

450 2000 1199 1074 1,31 20,45 10,28 16 -

450 2200 1311 1173 1,32 22,05 11,23 16 -

506 1600 1098 984 1,30 19,35 9,43 18 -

506 1800 1225 1098 1,30 21,28 10,45 18 -

506 2000 1352 1212 1,30 23,20 11,48 18 -

506 2200 1478 1324 1,31 25,12 12,50 18 -


265

72 72

38

46

109

39

109

1/2"

1/2"

H-40

H

H-40

H

H

45

L

265

50

50

28

L

162

VRVK-R

Width (L) 444 500



3/4” 3/4”

49 49

72 72

1/2" 1/2"

50

L

Vision Vision Round (VRVK-R)

Tubes


Collectors


Vision

Colours





VRVK-R

Special

• The vertical tubes of type VRVK-R are slightly bent (10°).

Brackets


Technical





ref. nr. 128200200009016






✘

✘

✘

Connection








✘

✘

✔

✔

✘



163

Vision Vision half-round (VRVK-O)

type

ref. nr.

12230

VRVK-O

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

337 1800 1383 1730 1,27 18,70 9,45 18 -

337 2000 1523 1905 1,27 21,25 10,55 18 -

337 2200 1649 2059 1,26 23,80 11,65 18 -

417 1800 1739 2164 1,24 23,50 11,30 22 -

417 2000 1900 2368 1,25 26,15 12,75 22 -

417 2200 1955 2441 1,26 28,80 14,20 22 -


160

160

R150

R190

H-40

H

H-40

H

VRVK-O

Width (L) 337 417



64

187

R

L

64

227

R

L

164

Vision Vision half-round (VRVK-O)

Tubes


Collectors


Vision

Colours





Special

• 2 designs possible, R150 and R190

VRVK-O

return

supply

Brackets


Technical





ref. nr. 128210100000099






✘

✘

✘

Connection







✘

✘

✘

✔

✘



165

Vision Vision quarter-round (VRVK-A)

type

ref. nr.

12228

VRVK-A

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr.

resistance

(Watt)

210 1800 625 782 1,27 8,70 4,30 8 -

210 2000 670 838 1,27 9,80 4,80 8 -

210 2200 702 880 1,28 10,90 5,30 8 -

270 1800 778 975 1,28 10,15 5,35 10 -

270 2000 848 1063 1,28 11,80 5,95 10 -

270 2200 911 1142 1,28 13,45 6,55 10 -


134

54

179

83

R15055

58

R190

H

H-40

H

H-40

182

226

VRVK-A

Width (L) 214 270



R

L

R

L

166

Vision Vision quarter-round (VRVK-A)

Tubes


Collectors


Vision

Colours





Special

• 2 designs possible, R150 and R190

VRVK-A

return

supply

Brackets


Technical





ref. nr. 128210100000099






✘

✘

✘

Connection







✘

✘

✘

✔

✘



167

Vision Accessories

In option


VRVK-V

TOWEL RAIL

STRAIGHT

CHROME 128322600000099


VRVK-R

TOWEL RAIL

CURVED

CHROME 128322500000099




168

Vision Connections

Vision Vertical: VRVK-V

3

6 3

6

3

6

3

6

Vision Round: VRVK-R

3

6 3

6

Vision

2 7 2

7

1 8

1 8

mm

mm

mm

mm

3

0018 0018 0099 0099

6 3

6 3

6 3

6

0099 0099



2 7 2

7 2 7 2

7

Vision half-round: VRVK-O / Vision quarter-round: VRVK-A

0023 0023 0067 0067

5

5

4 5

4 5

3

6

3

6

2

7

2

7

2

7

2

7

1 8

1 8

0045 0045 0027 0027

3 6 3

6

3 6 3

6

0018 0018



2 7 2

7

2

7 2

7

0036 0036

0026 0026

3

6

3

6

2

7

2

7

0037 0037



Vision Horizontal: VRVK-H

4 5

4 5

4 5

4 5

1 8

1 8

1 8

1 8

0018 0018 0045 0045



169

170

Lavatory COLLECTION

Veltis H100 Veltis Horizontal 172

XH1L1 Xtend Horizontal Lacquered 172

ZH-1 Zana Horizontal 172

HP1L1-RO(-V) Havaro Horizontal 172

VP1L1-ZB(-V) Verena Vertical 172

NHR1 Navaro Horizontal 172

Lavatory

171

Lavatory

type

width

(L mm)

height

(H mm)

75/65/20

(Watt)

90/70/20

(Watt)

n-exp.

weight

(kg)

water content

(l)

tubes

(n)

electr. resistance

(Watt)

Veltis Horizontal

ref. nr. 12245

Veltis H100

450 400 452 568 1,30 6,66 0,48 6 -

450 500 567 714 1,31 7,92 0,66 6 -

Xtend Horizontal Lacquered

ref. nr. 12193

XH1L1

520 450 301 376 1,26 7,50 1,19 - -


ref. nr.12252

ZH-1

384 500 347 432 1,25 9,00 4,10 10 -


ref. nr. 12156

HP1L1-RO(-v)

500 360 322 403 1,27 7,00 1,50 5 -


ref. nr. 12213

VP1L1-ZB(-v)

433 600 403 507 1,30 11,15 2,40 6 -


ref. nr. 12276

NHR1

540 500 396 490 1,22 10,20 3,00 12 -


* Standard colour S600 (fine texture white).

For more information see extended separate chapters of these collections.

172

Electrical radiators COLLECTION

Mixed radiators General 174

Pure electrical radiators General 178

HD-EL / HDR-EL Hedria 180

HR-EL Largo 181

HKR-EL Tripla 182

HZ-EL Hazel 183

C-RH-EL C-Line 184

ZBD-EL Zana Bathroom 185

ZBD-DECO-EL Zana Deco Bathroom 186

VP1L1-ZB-EL Verena 187

X1L1-EL Xtend 188

EV2-EL E-Volve 189

EP-H FL / EP-H RIB / EP-V FL E-PANEL 190

Electrical radiators


173

Electrical radiators Mixed and pure electrical radiators

Use environment for electrical radiators

THERMIC electrical radiators may be used in the bathroom in volumes 2 and 3 (see schedule below). After all, the radiators are Class II devices. This

means the radiators have and need no earthing.

Note

For safety reasons we advise against free-standing electrical or mixed radiators.

To calculate the consumption of an electrical radiator, all you need to

know is the radiator’s wattage.

Example:

1000 Watt radiator. This has an electrical capacity of 1kW.

The radiator therefore consumes 1kWh an hour. This applies, of course,

if the radiator is working at full capacity throughout the whole hour. This

is seldom the case in practice. After all, the radiator switches itself off

once it has reached the required temperature. If you know the price of

1kWh, you can now calculate what the radiator costs in electrical energy.

The electrical resistors are always mounted in the right-hand collector.

The controller should always be mounted at the bottom right.

GUARANTEE on electrical components: 2 years

This only applies when combined with a THERMIC radiator.

The guarantee is null and void in the event of wrong usage.

There are two kinds of electrical radiators:

• Mixed radiators (central heating (CH) or electrical functioning)

• Pure electrical radiators

174

Electrical radiators Mixed radiators

1. GENERAL

Mixed radiators are radiators that can be used individually for heating

via the central heating system or to heat electrically. These radiators are

highly suitable in spring and autumn when the central heating boiler is

usually not working. You can then choose to heat electrically. Ideal for

use in the bathroom.

The radiators listed below can be used as mixed radiators:

• C-Line C-RH

• C-Line C-TA

• C-Line C-BE

• C-Line C-SI

• Verso (V-S/VZ-S/V-I/VZ-I/V-CHR/VZ-CHR)

• Tripla (HKM/HKRM)

• Ponti (HX)

• Hedria (HDM/HDRM)

• Largo(-Chrome) (HRM/HR2/HRBM/HRM-C/HRBM-C)

• Hazel (HZ/HZ2)

• Zana Bathroom (ZBD)

If you choose to heat via the central heating system then the electrical

controller has to be switched off. If the electrical resistor is still heating

when the central heating system is working, this can damage the

electrical resistor.

If you choose to heat electrically (without using the central heating

system) then the thermostatic head must be closed. With a closed

radiator valve, however, free expansion to the central heating system’s

expansion tank via the return pipe must be ensured. The connection

possibility depends on the connection system and the width of the

radiator.

We differentiate between the following:

The width of the radiator is ≤ 600 mm:

Connection with standard stop valves

Note: The THERMIC range does not include stop valves and

thermostatic heads.

Connection with 1-8 designer valve set

Supply right and return left

The width of the radiator is greater than 600 mm:


For a two-pipe system with connection:

• 1-8: possible for all widths

• mm: the width of the radiator must be greater than 600 mm

• MM: the width of the radiator must be greater than 600 mm

For a one-pipe system with connection:

• mm: the width of the radiator must be greater than 600 mm

One-point connection:

• only possible in the left-hand collector

Note: If you use the mm valve, then the radiator can also be connected

to a one-pipe system.

Note: With a closed radiator valve, however, free expansion to the central

heating system’s expansion tank via the return pipe must be ensured (in the

summer).

2. POSSIBLE CONNECTIONS FOR MIXED RADIATORS

2.1. CONNECTING THE CH SYSTEM TO THE CENTRAL

CONNECTION (TWO-PIPE SYSTEM)

The radiators listed below can be connected to the central connection:





• Largo(-Chrome) (HRM/HRBM/HRM-C/HRBM-C)

2.2. CONNECTING THE CH SYSTEM TO THE 1-8 CONNECTION

(TWO-PIPE SYSTEM)

The radiators listed below can be connected via 1-8:









• Largo(-Chrome) (HRM/HR2/HRBM/HRM-C/HRBM-C)



175


3. RESISTORS FOR MIXED RADIATORS

Connection with 1-8 designer valve set

Supply right and return left

Note: The THERMIC range does not include valves.

T-piece

When using a T-piece, the connection dimensions are different.

Remember: if there is a flow tube, it has to be removed.

Ref. nr.: 12dv00002 Price: € 18

5

10

3.1. ST PTC RESISTOR (CLASS II)

Positive temperature coefficient

• Comprised of semiconductor elements

• Reacts according to the temperature and therefore automatically

regulates the heat production

• No thermostatic components that can wear out, fail or lead to

breakdowns

• Use environment: volume 2 or 3 of the bathroom (drawing p. 174)

• Mounted in the radiator on the underside

• Ø 12 mm

• Regulator or plug not provided

• Class IP64

Type

Emission

(Watts)

Ref. nr.

PTC 300 128410000000000

PTC 500 128410100000000

PTC 750 128410200000000

PTC 1000 128410300000000

PTC 1250 128410400000000

PTC 1500 128410500000000

26

40

Resistor lengths:

Note: If you make the connection with the 1-8 connection, the radiator

can only be connected to a two-pipe system.

Note: With a closed radiator valve, however, free expansion to the

central heating system’s expansion tank via the return pipe must be

ensured (in the summer).

2.3. ONE-POINT CONNECTION

9

One-point connection is possible only in the left-hand collector and with

the following models:





27

26

• PTC Resistor 300 W






: 450 mm

: 565 mm

: 795 mm

: 1025 mm

: 1205 mm

: 1385 mm

3.2. TB Thermoboost REGULATION WITH CLASSIC RESISTOR

• No time control

• Room temperature control

• No programmable daily programmes

• BOOST command: 1 hour

• Frost protection function


• IPX4 class II

• Thermostat (cable length: 1.2 m, no plug provided)

• Complete thermostat on radiator

Remember:

• TB controller connection (brown = phase, blue = neutral).

• Double insulated devices have no earthing.

176


Type

Emission

(Watts)

Ref. nr. (white)

TB 300 128420600009016

TB 500 128420700009016

TB 750 128420800009016

TB 1000 128420900009016

TB 1250 128421000009016

TB 1500 128421100009016

Type

Emission

(Watts)

Ref. nr. (grey)

TB 300 128420600009006

TB 500 128420700009006

TB 750 128420800009006

TB 1000 128420900009006

TB 1250 128421000009006

TB 1500 128421100009006

3.4. KIT TB-RF-L DELUXE RADIO FREQUENCY THERMOSTAT AND

RADIO FREQUENCY RECEIVER WITH CLASSIC RESISTOR

• Time control


• 9 programmes are pre-set

• 4 programmes can be freely programmed




• Receiver (cable length: 1.2 m, no plug provided)


• Thermostat: IP 30 class III

• Radio frequency communication between receiver and transmitter


3.3. Kit TB-RF-S STANDARD RADIO FREQUENCY THERMOSTAT

AND RADIO FREQUENCY RECEIVER WITH CLASSIC RESISTOR









• Thermostat: IP 30 class III


Remember:

• Receiver connection (brown = phase, blue = neutral)

• Double insulated devices have no earthing

• Each combination of thermostat and receiver (radio frequency) is

already coordinated

Type

Emission

(Watts)


Price

(white)

TB-RF-L 300 128421800009016 380

TB-RF-L 500 128421900009016 380

TB-RF-L 750 128422000009016 392

TB-RF-L 1000 128422100009016 404

TB-RF-L 1250 128422200009016 416

TB-RF-L 1500 128422300009016 428

Remember:

• Receiver connection (brown = phase, blue = neutral).



already coordinated.

Type

Emission

(Watts)


TB-RF-S 300 128421200009016

TB-RF-S 500 128421300009016

TB-RF-S 750 128421400009016

TB-RF-S 1000 128421500009016

TB-RF-S 1250 128421600009016

TB-RF-S 1500 128421700009016

Type

Emission

(Watts)


TB-RF-S 300 128421200009006

TB-RF-S 500 128421300009006

TB-RF-S 750 128421400009006

TB-RF-S 1000 128421500009006

TB-RF-S 1250 128421600009006

TB-RF-S 1500 128421700009006

Type

Emission

(Watts)


Price

(grey)

TB-RF-L 300 128421800009006 437

TB-RF-L 500 128421900009006 437

TB-RF-L 750 128422000009006 451

TB-RF-L 1000 128422100009006 465

TB-RF-L 1250 128422200009006 478

TB-RF-L 1500 128422300009006 492

For the TB / Kit TB-RF-S / Kit TB-RF-L controllers we use the same

resistor. Only the controllers from the THERMIC range can be mounted

on this resistor.


• Resistor 300 W






: 380 mm

: 515 mm

: 690 mm

: 865 mm

: 1040 mm

: 1220 mm

177

Electrical radiators Pure electrical radiators

1. GENERAL

Pure electrical radiators are radiators that can only heat electrically. They

cannot, therefore, be connected to a central heating system.

The radiator is filled with a fluid in the factory and fitted with an electrical

resistor in the right-hand collector.








: 380 mm

: 515 mm

: 690 mm

: 865 mm

: 1040 mm

: 1220 mm

Electrical radiators HOW TO ORDER

This is how to order a pure electrical radiator:

Step 1: Choose the model of radiator (see next pages).

Step 2: Choose the controller you would like for the radiator. You can

choose between the TB / Kit TB-RF-S / Kit TB-RF-L controllers in the

colours RAL 9016 (traffic white) or RAL 9006 (white aluminium), (see

page 179).

178

Electrical radiators Pure electrical radiators

1.1. TB SLIDEX REGULATION WITH CLASSIC RESISTOR








• Thermostat (cable length: 1.2 m, no plug provided)

• Complete thermostat on radiator

Remember:

• TB controller connection (brown = phase, blue = neutral).


1.3. KIT TB-RF-L DELUXE RADIO FREQUENCY THERMOSTAT AND

RADIO FREQUENCY RECEIVER WITH CLASSIC RESISTOR

• Time control


• 9 programmes are pre-set

• 4 programmes can be freely programmed

• BOOST commando: 1 hour





• Thermostat: IP 30 class III (only in RAL 9016)


Remember:



• Each combination of thermostat and receiver (radio-frequency) is



Colour

Ref. nr.

RAL 9016 128400400009016

RAL 9006 128400400009006

1.2. Kit TB-RF-S STANDARD RADIO FREQUENCY THERMOSTAT

AND RADIO FREQUENCY RECEIVER WITH CLASSIC RESISTOR









• Thermostat: IP 30 class III (only in RAL 9016)


Remember:





Colour

Ref. nr.

RAL 9016 128400100009016

RAL 9006 128400100009006

It is also possible to turn a central heating radiator into a pure electrical

radiator.

Remember: this is only possible with the following types:









• Largo(-chroom) (HRM/HR2/HRBM/HRM-C/HRBM-C)



You then order a resistor and controller (see section on mixed radiators

for reference numbers) and the fluid with which the radiator is filled,

namely DOWCAL 30%. You then fill the radiator with this fluid to a

maximum of 95%.

DOWCAL 30%

This fluid, which is based on ethanediol, contains corrosion-resistant

elements that provide anti-rust and frost protection up to -10°C.

Colour

Ref. nr.

RAL 9016 128400200009016

RAL 9006 128400200009006

Ref. nr.: 12dv00001 Price: € 5 / litre

E.g.: Radiator: 2.6 litres: 2.6 l x 0.95 = 2.47 litres of DOWCAL 30% are

required to fill the radiator.

179

Electrical radiators Hedria (HD-EL, HDR-EL)

Types

• Straight (HD-EL) and curved (HDR-EL)

Tubes


Collectors

• Vertical, D-profile 34 x 34 mm

Colours





HD-EL

Special

• The horizontal tubes of type HDR-EL are slightly bent (10°).

Brackets


Technical




HDR-EL



type

ref. nr.

12164

HD-EL

ref. nr.

12167

HDR-EL

width

(L mm)

height

(H mm)

weight

(kg)

tubes

(n)

electr.

resistance

(Watt)

500 916 13,70 18 500

500 1330 19,70 26 750

500 1790 26,30 35 1000

600 1882 31,20 37 1250

750 1882 32,20 37 1500

500 1330 19,70 26 750

500 1790 26,30 35 1000

600 1882 31,20 37 1250


HD-EL / HDR-EL

Centre between the brackets L-120 H-180 L-120 H-180

L-120

L-120

L-120

86-96

34

L-120

90

94-114

34

L-120

90

H = 1790

90

H-180

H = 916

H = 1882

H = 1882

H-180

H = 1330

50

90

91 - 101

50

99-119

L

L L L L

180

Electrical radiators Largo (HR-EL)

Types

• Straight (HR-EL)

Tubes


Collectors


Colours





Brackets


Technical




HR-EL




type

ref. nr.

12182

HR-EL

width

(L mm)

height

(H mm)

weight

(kg)

tubes

(n)

electr.

resistance

(Watt)

500 1322 19,50 26 750

500 1874 25,75 37 1000

600 1874 30,90 37 1250


HR-EL


L - 120 L - 120

Ø35

90 - 105

L - 120

86 H - 172

86

50

H = 1322

H = 1874

H = 1874

69 - 84

L L L

181

Electrical radiators Tripla (HKR-EL)

Tubes


Collectors

• Vertical, triangular 56 x 34 mm

Colours





HKR-EL

Special

• The horizontal tubes of type HKR-EL are slightly bent (10°).

Brackets


Technical






type

ref. nr.

12175

HKR-EL

width

(L mm)

height

(H mm)

weight

(kg)

tubes

(n)

electr.

resistance

(Watt)

500 1230 21,20 26 750

500 1758 28,60 37 1000

600 1758 34,30 37 1250


HKR-EL


L-150

L-150

L-150

87 H-174

87

34

H = 1230

H = 1758

H = 1758

50

94-104

L

L

L

182

Electrical radiators Hazel (HZ-EL)

Tubes

• Horizontal, flat-oval 57,5 x 10 mm

Collectors


Colours





Brackets


Technical






HZ-EL


type

ref. nr.

12173

HZ-EL

width

(L mm)

height

(H mm)

weight

(kg)

tubes

(n)

electr.

resistance

(Watt)

500 1205 22,20 18 750

500 1805 32,00 27 1000

600 1805 38,50 27 1250

700 1925 46,70 29 1500


HZ-EL


L-180

80

43,5

74 H -128

54

H = 1205

H = 1805

50

H = 1805

H = 1925

65 L L L

L

183

Electrical radiators C-Line (C-RH-EL)

Tubes


Collectors


Colours





C-RH-EL

Brackets


Technical






type

ref. nr.

12139

C-RH-EL

width

(L mm)

height

(H mm)

weight

(kg)

tubes

(n)

electr.

resistance

(Watt)

500 702 12,90 19 500

500 1332 25,50 38 1000

600 1392 31,60 40 1250

600 1632 37,90 48 1500


C-RH-EL


50

66 H-132 66

100-120

50

62

X

L

H=702

H=1332

H=1392

H=1632

70-90

L

L

L

L

92-112

184

Electrical radiators Zana Bathroom (ZBD-EL)

Tubes


Collectors


Colours





Brackets


Technical







ZBD-EL


type

ref. nr.

12251

ZBD-EL

width

(L mm)

height

(H mm)

weight

(kg)

tubes

(n)

electr.

resistance

(Watt)

500 984 28,30 21 750

500 1344 37,40 28 1000

500 1824 52,65 40 1250



type

width

(L mm)

height

(H mm)

colour

short

ref. nr.

ZBD-EL 500 984 9016 12251-01

500 1344 9016 12251-02

L-155

ZBD-EL


99-118

H-144 72

34-54

H=984

H=1344

72

H=1824

50

L L L

185

Electrical radiators Zana Deco Bathroom (ZBD-DECO-EL)

Tubes


Collectors


Colours





ZBD-DECO-EL

Special

• Radiator without spaces

Brackets


Technical






type

ref. nr.

12250

ZBD-

DECO-EL

width

(L mm)

height

(H mm)

weight

(kg)

tubes

(n)

electr.

resistance

(Watt)

500 1174 33,00 24 750

500 1474 40,50 30 1000

600 1674 46,00 34 1250


L-155

99-118

34-54

50

87

H-174 87

H

186

ZBD-DECO-EL


L

Electrical radiators Verena (VP1L1-ZB-EL)

Tubes

• Vertical, flat-oval 70 x 10 mm

Collectors

• Horizontal, square 34 x 34 mm

Colours





Brackets


Technical






VP1L1-ZB-EL


type

ref. nr.

12214

VP1L1-

ZB-EL

width

(L mm)

height

(H mm)

weight

(kg)

tubes

(n)

electr.

resistance

(Watt)

433 1200 26,85 6 750

433 1201 26,85 6 1000

505 1800 39,05 7 1250

578 1800 50,00 8 1500


72,5 L - 145

72,5

81

63

83,5

H -152 68,5

48

H

VP1L1-ZB-EL


62

L

187

Electrical radiators Xtend (X1L1-EL)

Colours




Special

• Lacquered front plate

Brackets


Technical



X1L1-EL



type

ref. nr.

12196

X1L1-EL

width

(L mm)

height

(H mm)

weight

(kg)

tubes

(n)

electr.

resistance

(Watt)

520 745 19,50 - 500

520 1105 33,00 - 750

620 1285 37,50 - 1000

620 1825 50,20 - 1250

720 1825 53,00 - 1500

Standard colour S600 (fine texture white).


100 L - 200 100

80,5

45

83,5

50

H-144,5

H

61

Centre between the brackets

X1L1-EL

L-200 H-144,5

54

L

188

Electrical radiators E-Volve (EV2-EL)

Tubes


Collectors


Electronic regulation

• The comfort of central heating: guarantees gentle heat and a stable

temperature

• A refined and sober design

• Fully integrated on the right side, protected by a translucid cover

• Child safety: lockable keyboard

• Using the “Mode” button you can set the radiator in relation to the

season and your needs

• Adjustment is easy: temperature from 10° to 30°C can be set by

0,5°C intervals

• Silent operation, perfect for bedrooms

• Active memory: saves adjusted settings in the event of a power-cut

• Anti-overheating safety: the radiators are equipped with a built-in

limiter thermostat


Colours


• Also available in RAL 9006 (aluminium white)


Brackets


Technical




EV2-EL



type

ref. nr.

12222

EV2-EL

width

(L mm)

height

(H mm)

weight

(kg)

tubes

(n)

electr.

resistance

(Watt)

660 600 27,70 10 500

840 600 35,10 13 750

1080 600 45,00 17 1000

1260 600 52,40 20 1250

1440 600 59,80 23 1500


L-180

52

85

EV2-EL


81 H-151

80

H

L

610

189

Electrical radiators E-Panel (EP-H FL, EP-H RIB, EP-V FL)

ASSORTIMENT

• A wide range of E-Panels is available, with capacities suited to each home.

There are three horizontal models, ranging from 750 W to 1500 W. Their height

is always 600 mm, their length varies from 500 mm to 1000 mm. There is also

a vertical model from 1500 W. The height is 1800 mm and the length 600 mm.

The radiators are available in white (RAL 9016), and you can choose between a

corrugated horizontal version and a flat horizontal version. A flat vertical version is

also available.

OPERATION

• Operation of the E-Panel is easy with two turning knobs to turn it on and off and

regulate the temperature. With this time-proportional control the radiator can be

set between 5°C and 30°C. The comfort temperature can easily be adapted by

turning the turning knob.

• Led indicator:

- Green: the radiator is not heating (the comfort temperature is set at a lower level

than the room temperature).

- Red: the radiator is heating.

- Green/red flashing: overheating.

Technical

• Power supply: 230VAC

• Insulation class II

• IPX1

• Selectable temperatures: from +5°C to +30°C

( *= 5°, I=10°, II=15°, III=20°, IV=26°, V=30°)

• Temperature control via chronoproportional on/off regulator

• Settings: ON and OFF

• Power cable (1.2 m): brown = phase, blue = neutral

• Temperature range: 0°C to 60°C

• Accuracy: < 0,5°C

• Standard: CE



EP-H FL

EP-H RIB

EP-V FL

type

ref. nr.

12149

EP-H FL

ref. nr.

12151

EP-H RIB

ref. nr.

12153

EP-V FL

width

(L mm)

height

(H mm)

weight

(kg)

tubes

(n)

electr.

resistance

(Watt)

500 600 19,27 - 750

800 600 30,83 - 1000

1000 600 38,54 - 1500

500 600 16,80 - 750

800 600 26,88 - 1000

1000 600 33,60 - 1500

600 1800 55,50 - 1500


350

99,5

22,5

H

L

74

1498

118

130 105

32

R4.5

106

33

405

48 352

17

R4.5

129

73

H

350

120

88

L

190

Electrical radiators Accessories

In option


Folding drying

and stacking

rack

• h = 8 mm; b = 450 mm; d = 168 mm; a = 41 mm

TOWEL RAIL

• h = 22 mm; b = 670 mm; d = 85 mm; a = 60 mm

HKR-EL

CHROME 128300300000099

EV2-EL / HZ-EL

CHROME 128322400000099

VP1L1-ZB-EL

CHROME 128322300000099



CHROME 128360200000099

HOOK O-RING

• h = 22 mm; b = 22 mm; d = 42 mm

VP1L1-ZB-EL

CHROME 128360000000099

ZBD-EL / ZBD-DECO-EL

CHROME 128360300000099


CHROME 128340200000099

HOOK WITH A

WIDE GROOVE

VP1L1-ZB-EL

CHROME 128340000000099


CHROME 128340300000099

• h = 22 mm; b = 22 mm; d = 42 mm


DRYING- AND

STACKING RACK

NARROW

CHROME 128300900000099

• h = 22 mm; b = 385 mm; d = 163 mm; a = 30 mm


DRYING- AND

STACKING RACK

LARGE

CHROME 128301200000099

• h = 22 mm; b = 530 mm; d = 163 mm; a = 30 mm



191

Electrical radiators Accessories

In option

ACCESSORIES WIDTH TOWEL RAIL COLOUR REF.NR.

X1L1-EL

TOWEL RAIL IN

TRANSPARENT

GLASS

128320400000000


• h = 70 mm; b = 900 mm; d = 135 mm; a = 45 mm; glass thickness = 10 mm

X1L1-EL

TOWEL RAIL IN

FROSTED GLASS

128320500000000


• h = 70 mm; b = 900 mm; d = 135 mm; a = 45 mm; glass thickness = 10 mm

X1L1-EL

TOWEL RAIL

540 mm CHROME 128324800000099

640 mm CHROME 128324200000099

740 mm CHROME 128324900000099

• h = 25 mm; b = 540, 640, 740 mm; d = 73 mm; a = 57 mm


TOWEL RAIL

CHROME 128322800000099


TOWEL RAIL

EP-V FL

ALUMINIUM 128324100000000

• h = 55 mm; b = 370 mm; d = 60 mm; a = 54 mm




192

TECHNICAL

TECHNICAL POSSIBLE CONNECTION SYSTEMS One-pipe system 194

Two-pipe system 194

One-point connection 194

Integrated valve 196

Flow tube 197

valves 197

Correction factors 200

Pressure Losses 201

Models of valve set combined with radiators 204


193

TECHNICAL POSSIBLE CONNECTION SYSTEMS

1. Possible connection systems

1. System with copper or plastic pipes

1.1. One-pipe system

Radiator Radiator Radiator

supply 75°C

Collector

Collector

return 65°C


This is the system most commonly used in contemporary home

construction.

You start with a collector, where every radiator has a separate supply

and return pipe.

supply

75°C

return 65°C

Boiler

2. System with steel pipes

A one-pipe system was often used in home construction in the 1970s

and 1980s.

It is a series circuit of radiators.

The return water from the previous radiator is the supply for the following

radiator. To ensure that the water temperature is high enough in the

following radiator, you need to use a valve with a bypass.

The bypass mixes the radiator's return water with hotter supply water,

so that the temperature of the water serving as supply for the following

radiator will be higher. A maximum of 50% of the hot supply water can

be mixed. We offer the mm valve set for a one-pipe system.

This has an adjustable bypass.

Boiler


supply 75°C 75°C 75°C

This system was commonly used in the 1980s.

return 65°C

In this system, two steel pipes are placed around the exterior walls of

the house.

One pipe is used for the supply water and the other for the return water.

Each radiator is connected to these pipes separately.

92

Note

front view

ø 3/4”

side view

ø 1/2”

109 23

rear view

The output of radiators is always indicated at 75/65/20°C.

As the supply temperature for the following radiators is lower (than

75°C), a correction factor is employed to define the correct output of the

radiator.

You can find this factor in the table of correction factors on page 200.

The full system, therefore, has to be calculated correctly so that there is

compensation for the heat loss.

1.2. Two-pipe system

There are two different systems:

63

1.3. One-point connection

Note: There are no valves suitable for a one-point connection in

the THERMIC range.

This connection can be used for the following radiators:

• Bathroom radiators

−−

Verso (V-S/VZ-S/V-I/VZ-I/V-CHR/VZ-CHR)

−−

Tripla (HKM/HKRM)

−−

Ponti (HX)

−−

Hedria (HDM/HDRM)

No extra charge

• Designer radiators

−−

Zana (ZV-1/ZV-2/ZH-1/ZH-2)

−−

Havaro (HP1-RO/HP1L1-RO/HP2-RO/HP2L1-RO/HP2L2-RO)

−−

PK (PK1/PK2/PK3/PK4)

−−

Verena (VP1-ZB/VP1L1-ZB/VP2-ZB)

−−

Vengia (VPN1(-ZB)/VPN2(-ZB)/VPN1L1-ZB/VPNS1-ZB)

−−

Navaro (NVR1/NVR2/NVRSN)

−−

VR (VRV1-X/VRV2-X)

−−

Vision (VRVK-V/VRVK-H)

Extra charge for one-point connection

1. With copper or plastic pipes

2. With steel pipes

The valves THERMIC sells are suitable for two-pipe systems.

194


Bathroom radiators

One-point connections can be used for a standard bathroom radiator.

With a one-point connection for a bathroom radiator, the flow tube fitted

in the factory needs to be removed before fitting the one-point valve.

Note: If there is no flow tube in the radiator, it cannot be connected via

a one-point valve.

The one-point valve needs to be fitted with a jet or injection pipe.

This should be a minimum of 2/3 of the height of the radiator.

The valve needs to be of a type where the supply water flows through

the jet or injection pipe and it can be fitted in either the left- or right-hand

collector, according to preference.

Designer radiators

One-point connections for designer radiators should be specified when

ordering.

• Radiators with a vertical collector (Havaro)

With a one-point connection, the diameter of the valve injection pipe

should be indicated when ordering (10, 11, 12… mm).

The one-point is also possible only with connection number 1 or 8.

The one-point valve needs to be fitted with a jet or injection pipe.

This should be a minimum of 2/3 of the height of the radiator.


A one-point connection can be used for both a one-pipe and a two-pipe

system.

The length of the jet pipe must be a minimum

of 2/3 of the height of the radiator.

• Plinth radiators (PK)

A one-point connection is possible in the following connection numbers:

2, 7, 1 and 8.

When fitting a one-point valve to the plinth radiator, make sure the jet

pipe reaches to a minimum of 10mm (x) past the partition "S".

S

x

air vent

One-point valve for a one-pipe system (not included in the THERMIC

range):

Supply water can be mixed directly with in the return via the bypass.

For a two-pipe system, the bypass system should be closed. The valve

is chiefly used for radiators with a horizontal collector.

x

S

air vent

This one-point valve has no bypass and is therefore unsuitable for a

one-pipe system. The valve is chiefly used for radiators with a vertical

collector.

195


• Radiators with a horizontal collector (Verena/Vengia/Navaro/VR)

With a one-point connection, the diameter of the valve jet pipe should

be indicated when ordering (10, 11, 12… mm). A one-point connection

is possible in the following connection numbers: 2 and 7.

When fitting one-point valves to radiators with horizontal collectors,

make sure that the jet pipe reaches to a minimum of 50 mm past the

middle of the radiator.

If the radiator with integrated valve is used in a one-pipe system, then

you need to use a bypass set.

This is not included in the THERMIC range but is available from

wholesalers.

Integrated valve for the HAVARO

Note: The partition with the cylindrical hole is always in the middle of the

lowest collector so that the jet pipe usually needs to be lengthened.

NAVARO/VR with one-point connection:

Integrated valve for the VERENA

VERENA/VENGIA with one-point connection:

The connections are 50 mm apart and have a 1/2" inner thread.

You can choose between:

1.4. Integrated valve

An integrated valve is available for the following radiators:

• VERENA (VP1-ZB/VP1L1-ZB/VP2-ZB)

• HAVARO (HP1-RO/HP1L1-RO/HP2-RO/HP2L1-RO/HP2L2-RO)

• XTEND horizontal (XH1L1/XH2L1/XH2L2)

• VELTIS horizontal (H100)

Extra charge integrated valve incl. designer thermostatic head

The radiator with integrated valve has been designed for a two-pipe

system and is equipped as standard with an insert on which the

thermostatic head can be fitted.

• Integrated valve on the left-hand side (thermostatic head also to

the left)

• Integrated valve on the right-hand side (thermostatic head also to

the right)

This must be clearly indicated when ordering.

Integrated valve for the XTEND horizontal

The NIVA horizontal is supplied with an integrated valve as standard

(always on the right side). The connections are 50 mm apart and

have a 3/4" outer thread (Euroconus). The supply should always be

connected to the 50-mm connection on the left side. The insert is fitted

in connection 6.

The designer thermostatic head is supplied with the radiator as

standard. You can choose between a white, chrome or stainless steel

designer thermostatic head:

White:

Please indicate code 03 for “Finish” when ordering (see "How to order"

on page 8).

196

Chrome:


on page 8).

Stainless steel:


on page 8).

If the colour is not mentioned, a white thermostatic head is delivered

for white radiators and a chrome

thermostatic head for coloured

radiators.

The insert can be pre-adjusted

exactly. The radiator with

integrated valve is already fitted in the factory.

To connect the radiator to the heating pipes you need a standard H

block. This is not included in the THERMIC range but is available from

wholesalers. The supply is always on the inside of the radiator.

Note:

If you don't want to connect the radiator via the integrated valve but via

another connection, then the insert has to be removed.

Then you will be able to change the supply and return.

The temperature is then controlled by a valve with thermostatic head, which

you need to buy (not in the THERMIC range).

Integrated valve for the VELTIS horizontal

The VELTIS horizontal is supplied on demand with an integrated valve

(always on the right side). The connections are 50 mm apart and have

a 1/2" inner thread. The supply should always be connected to the

50-mm connection on the right side. The insert will have to be fitted in

connection 6.

TECHNICAL SPECIFICATIONS FOR VALVES

1.5. Flow tube

When connecting 4-5 (= on the top) you need to place a special flow

tube at the top of the collector (in the return connection). In that case, the

lowest tube passes less heat on to the others.

Flow tube : The pre-mounted flow tube has to be removed.

Flow tube

(L)

Ref. nr.

600 DS01480001 HRM 17 / HRBM 17

680 DS01480002 HDM 20 / HDRM 20 / VERSO 21

740 DS01480003

HRM-C 15 / HRBM-C 15 / HZ 12 / C-RH 22 /

C-TA 38

940 DS01480005

HDM 30 / HDRM 30 / HKM 21 / HKRM 21 /

HX 21 / ZBD 21

1040 DS01480006 VERSO 32 / HRM 27 / HRBM 27 / HZ 16

1115 DS01480007 HRM-C 20 / HRBM-C 20 / C-BE 36 / C-RH 36

1260 DS01480009 VERSO 40

1330 DS01480010

HDM 40 / HDRM 40 / HKM 29 / HKRM 29 / HX 29 /

HZ 21 / ZBD 32

1530 DS01480011 VERSO 50 / C-BE 48 / C-RH 50

1665 DS01480012 HRM 42 / HRBM 42 / HRM-C 30 / HRBM-C 30 / C-SI 68

1720 DS01480013


HZ 27 / ZBD 40

1870 DS01480015 VERSO 60

1950 DS01480016


HRM 50 / HRBM 50 / HZ 31 / C-BE 60 / C-RH 64

Square:

Colour Ref. nr.

White 128210300009016

Pergamon 128210300000019

Chrome 128210300000099

Stainless steel 128210300009993

Straight:


Chrome 128210400000099

28.5

35

1/2” 50 1/2”

80

160

50

46

28.5

63.5

50

1/2” 1/2”

50

80

160

46


2. VALVES

MM designer valve set

SQUARE DESIGNER VALVE SET

STRAIGHT DESIGNER VALVE SET

Fittings for the MM designer valve set

• Fitting for copper pipe diameter 12 mm - without support cover

Ref. nr. 128220600000000;


Ref. nr. 128220700000000;

• Fitting for PEX pipe (with or without aluminium coating) 16 x 2 mm

Ref. nr. 128220400000000

MM designer valve set square / MM designer valve set straight

• Connection

The connection on the valve set comprises 2 x 1/2" inner thread. The

THERMIC designer valve set is supplied with an attractive designer

thermostatic head as standard. When using the THERMIC designer

valve set, the supply needs to be connected to the right of the valve (see

indication on valve). When using a flow tube, it should always be fitted to

the supply side. If you connect the supply to the left, the designer valve

will not work.

Copper without support

cover

PEX/multilayered

Pressure loss diagram for designer valve set

Solution: Fit a reverse header, but the pressure loss over the valve will be

greater (see diagram for reverse header p. 198). This is important for the

hydraulic balance.

• Pre-adjustment

Depending on the required pressure loss,

you can set the valve in accordance with

the diagram for the designer valve set

adjacent. The THERMIC designer valve set

is suitable for two-pipe systems (not onepoint

systems). The two connections can

be shut off entirely so you can wallpaper or

service the radiator without having to empty

Reverse header

Ref. nr.

128220300000000

the entire central heating system. To turn off the connection, it is best

to first fit the plastic cap, supplied as standard, on the valve on the

thermostatic head side and then shut it off. You can close off the return

with the socket screw on the underside of the valve.

197


Pressure loss diagram for reverse header

1/2"

1/2"

35

35

1/2"

46

30

35

35

1/2"

35

117

50

65

1/2"

1/2"

1-8 VALVE SET

Note:

The MM designer valve set can only be used for the central monobloc

connection (1MM8).

The valve can be used with the following types:

• Verso (V-S/VZ-S/V-CHR/VZ-CHR/V-I/VZ-I)




• Largo (-Chrome) (HRM/HRBM/HRM-C/HRBM-C)

• Zana (ZV-1/ZV-2/ZV-R)

• Xtend (X1L1/X2L1/X1L1-I/X2L1-I)

• Xtend SOFT (XS1L1/XS2L1)

• Bryce (BV)

• Veltis vertical (V75/V100)

• CANYON

• ARCHE (VV/VH)

• ARCHE PLUS (VVL/VVR)

• ALU-ZEN

Fittings for the 1-8 designer valve set


Ref. nr. 128220600000000;


Ref. nr. 128220700000000;

• Fitting for PEX pipe (with or without aluminium coating) 16 x 2 mm

Ref. nr. 128220400000000

Copper without support

cover

PEX/multilayered

Pressure loss diagrams for 1-8 designer valve set

1-8 designer valve set

1-8 designer valve set left


White 128210100009016

Chrome 128210100000099

1-8 designer valve set right

Ref. nr.

128210200009016

128210200000099

mm valve set

Remember : The thermostatic head has to be fitted in the return.

The 1-8 valve set can be used for radiators with the capacities in the

table below:

Ts - Tr Temperature regime Output

(Watts)

10 75 / 65 70 / 60 55 / 45 1300

15 80 / 65 70 / 55 60 / 45 1950

20 80 / 60 70 / 50 60 / 40 2600

Ts = Temperature supply / Tr = Temperature return

Can be used for both the new 1MM8 (1188) central monobloc

connection and the 1mm8 (1008) central connection. The connection

on the valve set comprises 2 x 3/4" outer thread. When you use the

THERMIC mm valve set you can exchange the supply and return. When

using a flow tube, it should always be fitted to the supply side.

• Pre-adjustment

Depending on the required pressure loss, you can adjust the valve in

accordance with the diagrams on page 199. The THERMIC mm valve

set can be used for one- and two-pipe systems.

198


For two-pipe systems: leave the bypass in the closed position. Adjust

pressure loss on the hexagonal nut with a scale division from 1 to 6.

For one-pipe systems: set the hexagonal nut to mark 6. Turn the bypass

back from closed position (factory setting) a number of rotations in

accordance with the diagram on page 199.

The supply and return pipes can be shut off entirely so you can

wallpaper or service the radiator without having to empty the entire

central heating system. A reverse header is not necessary.

When you use the THERMIC mm valve set, you can pre-adjust the

individual designer radiators according to the heat requirement. This

pre-adjustment (kv value) can also be adjusted when the system is

working until the heat distribution is optimally set. The kv value is

set on the hexagonal nut (using a hex key 13). You can choose from

the thermostatic head types below. THERMIC does not supply the

thermostatic head, however.

The following thermostatic heads that can be used are: Oventrop /

Honeywell / Comap / Heimeier / Danfoss / Junkers / Caleffi / Begetube

Remember: you need an M30 x 1.5 connection.

The mm valve has a rear connection 2 x 3/4" outer thread with manual

adjusting screw and protection cap.

The protection cap is available in the following colours:

• RAL 9016

• Pergamon 0019

• Chrome

• M350

• Other colours

Radiators in the colour RAL 0916

• Protection cap with straight underside

Ref. nr.: 128200100009016

Types: V(Z)-S / HK(R)M / HX / HD(R)M / HR(B)M / VERENA /

ZV(-R) / C-LINE

• Protection cap with curved underside

Ref. nr.: 128200200009016

Types: VR / VN / T / VRVK-V / VRVK-R

The mm valve with coloured protection cap should be ordered at the

same time as the radiator. With free-standing radiators the mm valve is

not aesthetically pleasing.

The following products are also available for the mm valve:

Knee coupling for thermostatic head

These can be ordered separately and make sure that the thermostatic

head faces forwards and not to the side. This is particularly advisable

with narrow radiators to guarantee they are well secured. This knee

coupling for the thermostatic head is only available in RAL 9016.

Ref. nr.: 128220100000000

90° curve

This can be used for bathroom radiators.

Use: Floor mounting (vertical), instead of wall mounting (horizontal)

Ref. nr.: 128220200000000

±54

±67

Pressure loss diagram:

Pre-adjusted two-pipe system

100000

1 2 3 4 5 6


Radiators in the colour Pergamon 0019


Ref. nr.: 128200100000019




Ref. nr.: 128200200000019

Types: VR / VPN / NVR / VRVK-V / VRVK-R

Radiators in other colours


Ref. nr.: 12820010000xxxx




Ref. nr.: 12820020000xxxx

Types: VR / VPN / NVR / VRVK-V / VRVK-R

Radiators in chrome


Ref. nr.: 128200100000099

Types: V(Z)-CHR / HR(B)M-C

Radiators in stainless steel


Ref. nr.: 128200100000350

Types: V(Z)-I

dp(Pa)

10000

1000

10 100

m (kg/h)

Pre-adjusted one-pipe system

dp(Pa)

100000

10000

1000

10 100

m (kg/h)

The hexagonal nut can be adjusted from 1 to 6 (standard = 6)

A= 50% radiator proportion or 2.5 rotations back from closed bypass

B= 45% radiator proportion or 3 rotations back from closed bypass

C= 40% radiator proportion or 4 rotations back from closed bypass

D= 35% radiator proportion or 5.5 rotations back from closed bypass

A B CD

1000

1000

199

TECHNICAL CORRECTION FACTORS

Starting hot water temperature 75/65/20°C

and n exponent: 1.3 (new Euro standard).

Example :

Required output: 1050 Watt

Room temperature: Ti = 22°C

Water regime: 70 / 50°C

In other words:

Ts= 70°C (supply) = 70°C

Tr = 50°C (return) = 50°C

Solution:

The correction factor = 0.70

Radiator type, for example

1050: 0.70 = 1,500 Watt

with regime 75/65/20 = ΔT50

(see tables for regime 75/65/20°C)

This will be type HKM 37/900

with 1,585 Watt output

Tr °C

35 40 45 50 55 60 65 70 75 80

Ts °C Ti °C Ti °C

16 0,91 0,97 1,04 1,11 1,17 1,24 1,31 1,38 1,45 1,52 16

18 0,86 0,92 0,99 1,05 1,12 1,19 1,25 1,32 1,39 1,46 18

90 20 0,81 0,87 0,94 1,00 1,07 1,13 1,20 1,27 1,34 1,41 20

22 0,76 0,82 0,88 0,95 1,01 1,08 1,15 1,21 1,28 1,35 22

24 0,71 0,77 0,83 0,90 0,96 1,03 1,09 1,16 1,23 1,29 24

16 0,85 0,91 0,97 1,04 1,11 1,17 1,24 1,31 1,38 16

18 0,80 0,86 0,92 0,99 1,05 1,12 1,19 1,25 1,32 18

85 20 0,75 0,81 0,87 0,94 1,00 1,07 1,13 1,20 1,27 20

22 0,70 0,76 0,82 0,88 0,95 1,01 1,08 1,15 1,21 22

24 0,65 0,71 0,77 0,83 0,90 0,96 1,03 1,09 1,16 24

16 0,78 0,85 0,91 0,97 1,04 1,11 1,17 1,24 16

18 0,74 0,80 0,86 0,92 0,99 1,05 1,12 1,19 18

80 20 0,69 0,75 0,81 0,87 0,94 1,00 1,07 1,13 20

22 0,64 0,70 0,76 0,82 0,88 0,95 1,01 1,08 22

24 0,59 0,65 0,71 0,77 0,83 0,90 0,96 1,03 24

16 0,72 0,78 0,85 0,91 0,97 1,04 1,11 16

18 0,68 0,74 0,80 0,86 0,92 0,99 1,05 18

75 20 0,63 0,69 0,75 0,81 0,87 0,94 1,00 20

22 0,58 0,64 0,70 0,76 0,82 0,88 0,95 22

24 0,54 0,59 0,65 0,71 0,77 0,83 0,90 24

16 0,66 0,72 0,78 0,85 0,91 0,97 16

18 0,62 0,68 0,74 0,80 0,86 0,92 18

70 20 0,57 0,63 0,69 0,75 0,81 0,87 20

22 0,53 0,58 0,64 0,70 0,76 0,82 22

24 0,48 0,54 0,59 0,65 0,71 0,77 24

16 0,61 0,66 0,72 0,78 0,85 16

18 0,56 0,62 0,68 0,74 0,80 18

65 20 0,51 0,57 0,63 0,69 0,75 20

22 0,47 0,53 0,58 0,64 0,70 22

24 0,43 0,48 0,54 0,59 0,65 24

16 0,55 0,61 0,66 0,72 16

18 0,50 0,56 0,62 0,68 18

60 20 0,46 0,51 0,57 0,63 20

22 0,42 0,47 0,53 0,58 22

24 0,37 0,43 0,48 0,54 24

16 0,49 0,55 0,61 16

18 0,45 0,50 0,56 18

55 20 0,41 0,46 0,51 20

22 0,36 0,42 0,47 22

24 0,32 0,37 0,43 24

16 0,44 0,49 16

18 0,40 0,45 18

50 20 0,35 0,41 20

22 0,31 0,36 22

24 0,27 0,32 24

16 0,39 16

18 0,34 18

45 20 0,30 20

22 0,26 22

24 0,23 24

200

TECHNICAL Pressure losses

HDM

HDRM

HKM

HKRM

HX

V-s

VZ-S

V-I

VZ-I

V-CHR

VZ-CHR

dp(Pa)

10000

1000

100

▲

10

C-LINE

ZANA ZBD

dp(Pa)

1000

▲

100

10

1

10 100

m (kg/h)

▲

1000


1

1 10

100 1000

m (kg/h)

▲

HRM

HRBM

HRM-C

HRBM-C

10000

1000

VENGIA

10000

VN1S

VN2S

VN1

100

▲

1000

VN2

dp(Pa)

10

1

1 10

100 1000

100

▲

m (kg/h)

▲

dp(Pa)

HR2

HZ2

1000

10

1 10

▲

100

100

▲

Flow/element (kg/h)

dp(Pa)

10

1

10 100

m (kg/h)

▲

1000

VR

ZANA

VISION

10000

VR1s

VR2s

VR1

1000

HZ

1000

VR2

100

▲

▲ 100

dp(Pa)

10

1

10 100

m (kg/h)

▲

1000

dp(Pa)

10

1 10

100


201


PK

SINGle

coNNECTIon

1 : P1/130-P2/180

2 : P1/180

3 : P1/230

4 : P1/280-P3/180

5 : P2/130

6 : P4/180

7 : P2/180

8 : P3/130

9 : P2/230

10 : P2/280

11 : P3/180-P4/130

12 : P3/230-P4/180

13 : P3/280

14 : P4/230

15 : P4/280

1000

100

10

▲

HavaRO

10000

1000

100

▲

H1S

H2S

H1

H2

dp(Pa)

1

10 00

1

2 3 5 7 9 11 15

4 6 8 10 12 14

13

m(kg/h)

1000

▲

dp(Pa)

10

1 10

▲


100

PK

oppoSITE

coNNECTIon

1000

VERENA

10000

V1S

V2S

V1

1 : P1/80

2 : P1/130

3 : P1/180

4 : P1/230

5 : P2/80

6 : P3/80

7 : P2/130

8 : P4/80

9 : P1/280-P3/130

10 : P2/180

11 : P2/230

12 : P3/180-P4/130

13 : P2/280

14 : P3/230-P4/180

15 : P3/280

16 : P4/230

17 : P4/280

dp(Pa)

100

10

▲

1

10 100

1000

1

2 3 5 7 9 11 15 17

4 6 8 10 14 16

12 13

m(kg/h)

▲

dp(Pa)

▲

1000

100

10

1 10

▲


100

V2

NavaRO

10000

1000

XTEND (soft)

T1s

T2s

T1

500

1000

200

T2

dp(Pa)

dp(Pa)

100

10

1 10


100

100

30 100 300

m (kg/h)

P = partition

In other words, two connections to the same collector

Example

Type T: nl.T1/45 900: two-pipe connection 18, 27, 36 45 or one-pipe connections, so

T1 S graph

ti = 20° c

supply temperature: 75°C

return temperature: 65°C

heat emission / element: 56,9 W

flow/element: m(kg/h) =

56,9W x 3600 s/h

4200J/kg K (75-65)K

= 4,9 kg/h

dp (Pa) = 400 Pa

202


100000

ARCHE

vv

Arche plus

vvl

vvr

10000

ARCHE

VH

100000

10000


1000

1000

100

100

10

1

10 100 1000

10

10 100 1000

m (kg/h)

m (kg/h)

BRYCE

bv

















203

TECHNICAL Models of valve set combined with radiators

R = RETURN

S = SUPPLY

R

8 1

S

R S R S S

1 8

R

Model

ALU-ZEN o o X X

Bryce (BV) o o X X

Canyon o o X X

VELTIS vertical (V75 / V100) o o X X

VELTIS horizontal (H100) X X X X

Arche vertical (VV / VH) o o o o

Arche PLUS Vertical (VVL / VVR) o o o o

XTEND Vertical (X1L1 / X2L1) o o o o

XTEND Vertical STAINLESS STEEL (X1L1-I / X2L1-I) o o o o

XTEND Horizontal (XH1L1 / XH2L1 / XH2L2) X X X X

ZANA Vertical / ROUND (ZV-1 / ZV-2 / ZV-R) o o o o

ZANA Half- & QUARTER-Round (ZV-A / ZV-O) X X o X

ZANA Horizontal (ZH-1 / ZH-2) X X o X

ZANA BATHROOM (ZBD) X X o X

ZANA LIBRA (LU / LD) o o o o

ZANA LIBRA (LL / LR) X X o X

ZANA MULTI X X o X

ZANA PLINTH X X o X

C-LINE (C-BE / C-RH / C-TA / C-SI) X X o o

VERSO (V / VZ) o o o o

TRIPLA (HKM / HKRM) o o o o

PONTI (HX) o o o o

HEDRIA (HDM / HDRM) o o o o

LARGO (-CHROME) (HRM / HRBM / HRM-C / HRBM-C) o o o o

LARGO (HR2) X X o o

HAZEL (HZ / HZ2) X X o X

VENGIA (VPN1(-ZB) / VPN2(-ZB) / VPNS1-ZB / VPNS1L1-ZB) X X o o*

VERENA (VP1-ZB / VP1L1-ZB / VP2-ZB) X X o o*

HAVARO (HP1-RO / HP1L1-RO / HP2-RO / HP2L1-RO / HP2L2-RO) X X o X

NAVARO Vertical (NVR1 / NVR2 / NVRSN) X X o o

NAVARO Horizontal (NHR1 / NHR2) X X o o

VR (VRV1-X / VRV2-X / VRVS1 / VRVS2) X X o o

Vision (VRVK-V / VRVK-R) X X o O

Vision (VRVK-H / VRVK-O / VRVK-A) X X o X

O = Option X = not possible!

* = mm connection is possible only with even number of pipes!

Type COLOUR REF. NR. FittingS REF. NR.

Square White 128210300009016

R A

For copper pipe 12 mm - without support cover 128220600000000

Pergamon 128210300000019 For copper pipe 15 mm - without support cover 128220700000000

Chrome 128210300000099 For PEX pipe (with or without aluminium coating) 16 x 2 mm 128220400000000

Stainless steel 128210300009993

straight Chrome 128210400000099

R A



For PEX pipe (with or without aluminium coating) 16 x 2 mm 128220400000000

1-8 Square LEFT White 128210100009016 R

8 1

A


Chrome 128210100000099 For copper pipe 15 mm - without support cover 128220700000000


1-8 Square RIGHT White 128210200009016 A

1 8

R


Chrome 128210200000099 For copper pipe 15 mm - without support cover 128220700000000

straight PROTECTION CAP White 128200100009016

Thermostatic head not supplied

Supply and return are interchangeable

Pergamon 128200100000019

Chrome 128200100000099

M350 128200100000350

Other colour *

12820010000xxxx

CURVED PROTECTION CAP White 128200200009016

Thermostatic head not supplied

Supply and return are interchangeable

Pergamon 128200200000019

Chrome -

Other colour *

12820020000xxxx


See chapter "Technical" for more technical information.

204

* Please indicate colour when ordering

205

206

THERMIC GENERAL TERMS OF SALE

1 Application 

The present general sales conditions apply to any sale or delivery of goods by The Heating

Company BVBA (hereinafter “THC”), to the exclusion of any general or specific conditions

communicated at any time by the buyer (hereinafter the "Buyer"). Any agreed derogation to

these general sales conditions will only apply to the specific sale for which such derogation

has been granted. By making any order, the Buyer acknowledges the present general sales

conditions and irrevocably agrees to be bound by them.

2 Offers and Order

2.1 THC’s offers are non-binding. THC will only be bound by an order upon its written

confirmation. 

2.2 All offers and acceptances of offers made by the Buyer, including verbal orders and

acceptances, are irrevocable.

3 Delivery 

3.1 All goods will be delivered to the buyer within the European Union DDU (ICC

Incoterms 2000). Unless specified otherwise, delivery outside of the European Union

will be DDP (ICC Incoterms 2000). 

3.2 The delivery times indicated are non-binding on THC, and are only given as an

estimate. THC is entitled to perform partial deliveries. 

3.3 No delay in delivery may lead to the cancellation of the sale or payment of damages

to the Buyer. Accordingly, the Buyer is not relieved of any obligation to accept or pay

for goods because of a delay in delivery. In case of non-delivery of goods, advances

that may have been paid by the Buyer will be reimbursed by THC, without any

additional interests or other compensation.

4 Retention of title 

4.1 The goods supplied by THC remain its exclusive property until payment of the price

in full by the Buyer. In case of non-payment upon the due date by the Buyer – and

without prejudice to THC’s rights under clause 8.6 – THC will automatically be entitled

to claim the goods back, ipso jure and at the Buyer’s expense.

4.2 If the Buyer resells the delivered goods before payment of the full price owed to THC,

the retention of title will apply to the price owed to the Buyer or, as the case may be,

the Buyer’s claim on its customer as a result of this sale will be pledged to THC as

security for the payment of the price owed to the latter. 

5 Complaints 

5.1 Unless otherwise provided in specific warranties offered by THC, any complaint

regarding a shortage, defect or non-conformity (jointly a “Defect”) of the delivered

goods is only valid if notified to THC in writing as soon as possible after delivery and

no later than:

• (i) three business days after delivery of the goods in respect of immediately

noticeable, visible Defects; and

• (ii) three business days after the date of discovery of the Defect, or the date on

which the Defect reasonably could have been discovered, in respect of all other

Defects, but in any event no later than three (3) months after delivery of the

defective goods.

5.2 Unless otherwise provided in specific warranties offered by THC, a complaint by the

Buyer pursuant to clause 5.1 will only be valid if:

• (i) he complaint is made within the periods set out in clause 5.1, after which the

Buyer is deemed to have waived all rights against THC in respect of a Defect of the

goods or the way that THC fulfilled its delivery obligations; and

• (ii) dthe delivered goods have remained in the same condition as at delivery; and

• (iii) he delivered goods have been used properly and in conformity with the agreed

or usual purpose; and

• (iv) the Buyer has fulfilled all its obligations towards THC.

5.3 No goods may be returned by the Buyer without THC’s prior express and written

consent.

6 Limited General Warranty 

6.1 In case of a timely and valid complaint for a wrongful delivery, THC shall at its option:

• (i) replace or repair the concerned goods at no cost; or

• (ii) supply equivalent goods; or

• (iii) credit the Buyer as far as is reasonable in whole or in part for the invoice value of

the goods concerned.

6.2 The general warranty set out in this clause 6, may be amended or complemented by

specific warranties offered by THC from time to time.

6.3 THC-products will materially conform to the technical specifications and features

provided for by the applicable catalogues and technical documentation. THC

guarantees delivery in accordance with the presented samples with explicit

reservation for small deviations in colour and in quality. Similarity in colour can only

be guaranteed with simultaneous orders. The measures and dimensions in the

catalogue and/or the price list are approximate. THC reserves the right to small

deviations as well to changes in form and view of a model.

7 Liability

7.1 THC’s liability towards the Buyer is limited to the fulfilment of the warranty set out in

clause 6. Consequently, THC is not liable for damage caused to the Buyer, except

for damage caused by THC’s own fraud or wilful misconduct. THC is under no

circumstances liable for loss of profits or production, environmental damage or any

other consequential or indirect damage, whatever the nature, suffered by the Buyer.

Moreover, THC is not liable for damage caused by its agents and sub-contractors

(including damage due to their fraud, wilful misconduct or gross negligence). 

7.2 THC is not liable for a delay in the performance of or a failure to perform its

obligations arising from any event beyond its normal control, including without

limitation, interruptions in production; difficulties in supply; shortages of raw material,

labour, energy or transport; or delays in transportation; strikes; lock-outs; work

interruptions; or any other collective labour disputes affecting either THC itself or its

suppliers, whether or not such events are foreseeable.

8 Price and payment 

8.1 The prices for goods are based on DDU (ICC Incoterms 2000) for delivery within

the European Union and, unless specified otherwise, DDP (ICC Incoterms 2000) for

delivery outside of the European Union and exclude VAT. All taxes or contributions, of

whatever nature, levied on the price or the goods, as well as transport or insurance

costs, as the case may be, need to be paid separately by the Buyer. 

8.2 Unless stated otherwise, invoices are payable within thirty (30) days after the invoice

date, without deduction or discount, in the currency as set out therein and if no

specification is made, in euro. The acceptance by THC of bills of exchange or other

payment instruments does not constitute a novation of debt. No ground, such as e.g.

the filing of a complaint regarding the delivered goods, entitles the Buyer to withhold

its payment. 

8.3 he Buyer relinquishes any right to set off (schuldvergelijking/ compensation de dettes/

Aufrechnung). THC, however, may set off any amounts owed to it by the Buyer

against any amounts THC owes the Buyer. 

8.4 Any sum remaining due after the date of payment shall, ipso jure and without notice,

produce an interest of one (1) per cent per month from the date of issuance of the

invoice, each month having commenced being regarded as a full month. 

8.5 In case of total or partial non-payment of an invoice upon due date, the Buyer shall,

ipso jure and without notice, owe an indemnity of ten (10) per cent of the amount

remaining due, with a minimum of EUR 125, and without prejudice to any other rights

or remedies of THC to obtain full compensation for the costs and damage incurred. 

8.6 HC is entitled, ipso jure and without notice or other formality, to postpone

performance of its obligations towards the Buyer under any agreement, to terminate

any agreement concluded with the Buyer with immediate effect, to claim immediate

payment of all outstanding claims (including those not yet due) or to refuse

performance except against cash payment, notwithstanding any prior agreement –

without prejudice to any other remedies which could be applied by THC – if:

• (i) an invoice is not fully paid upon its due date, or

• (ii) the Buyer does not fulfil any of its obligations under an agreement, or

• (iii) the Buyer becomes insolvent, bankrupt, files or has filed against it a petition in

bankruptcy, makes a proposal in relation to its insolvency under any bankruptcy

legislation, ceases to carry on all or a substantial part of its business, makes an

assignment for the benefit of its creditors, or if THC has good reasons to believe

that the Buyer becomes unable to pay its debts as they come due, or

• (iv) there is a direct or indirect change of control over the Buyer or Buyer transfers

all or substantially all its assets to a third party in any manner (including by merger,

(partial) split, transfer or contribution of universality or branch of activity).

8.7 Failure to take immediate action against any breach or default by the Buyer may

under no circumstances be construed as a waiver by THC of its right to act against

such breach or default at a later point in time.

9 Intellectual property 

The Buyer must not use or deal with any intellectual property rights (including, but not

limited to, trademarks, brands, logos or designs) owned or licensed by THC without THC’s

prior written consent. The Buyer shall not acquire any goodwill or any other right on THC’s

intellectual property rights, even if used for an extended period of time.

10 Governing law and disputes 

10.1 All relations between THC and the Buyer are governed by Belgian Law, to the

exclusion of (i) the provisions of the United Nations Convention on Contracts for the

International Sale of Goods and (ii) the rules on conflicts of laws. 

10.2 If the Buyer is established in a Member State of the European Union, any dispute

between THC and the Buyer shall be submitted to the exclusive jurisdiction of the

Courts of Tongeren (Belgium). If the Buyer is not established in a Member State of

the European Union, any dispute between THC and the Buyer shall be finally settled

under the CEPANI Rules of Arbitration by three arbitrators appointed in accordance

with the said rules. The seat of the arbitration shall be Brussels. The arbitration shall

be conducted in English. 

10.3 Notwithstanding the foregoing, THC will be entitled, at its sole discretion, to submit a

dispute to a jurisdiction located in the district or region where the Buyer maintains its

place of business.

207

D E S I G N E R R A D I A T O R S

DESIGNER RADIATORS TECHNICAL 2011 - Thermic

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
