FOREWORD

Nuclear Energy’s Responsible,

Sustainable Future

© L.Godart/CEA

Welcome to this second issue of CEA NEWS, the international publication of the French

Atomic Energy Commission. CEA is committed to providing in-depth but wide ranging

coverage of its activities ands achievements. We hope that this issue conforms to this goal.

Since our last issue, momentous events have taken place in our country including the

election of a new administration and the establishment of a new government. One of the

new government’s priorities is a determined undertaking to expand the research effort in

our country and to reform the governance and operations of universities. We at CEA

welcome this development, which corresponds to our deeply held view that partnership

with a strong and reactive academic sector can only be of benefit to an institution such as

ours, that thrives on cross-fertilization with our domestic and international partners in

both the academic and industrial sectors. We are all the more convinced that our mission

is to contribute to the building of the knowledge-based, high-valued added economy that

must rest on a deliberate as well as unrelenting effort in both fundamental and applied

research. This, one might add, is also a key to nurturing the international partnerships that

we at CEA value as a core component of our strategy.

Mr. Olivier Caron

Director of International Relations

In the field of energy, which remains at the forefront

of our priorities, CEA is committed to partaking in

national and international efforts and undertakings

that will foster the responsible and sustainable drive

toward expanded recourse to nuclear energy. If we

are to offer humanity reliable and cost-effective access

to this energy source, it is of prime import that new

nuclear programmes – as well as mature or

expanding ones – adopt or continue to uphold the

highest safety and spent fuel management standards.

It is an economic requirement as well as a civic duty

and moral responsibility to see to it that nuclear

expansion does not result in the unwarranted

accumulation and dissemination of spent fuels. A

fundamental rethink of security and nonproliferation

tenets are in order to address this

challenge successfully. We in France pride ourselves

on having pioneered an approach to the fuel cycle

that is precisely geared toward rising up to the

magnitude of the issue. And we are glad to see that

our major international partners are now willing to

reengage on the closed fuel cycle issue. This is a

heartening testimony to the virtues of patient and

steadfast policy development, based on confidence in

science and an acute awareness of the need to engage

public opinion and policy-makers. On this optimistic

note, I invite you to enjoy agreeable and thoughtprovoking

reading while awaiting our next issue. ■


AroundTheWorld

Global Nuclear Energy Partnership – Joint statement

by France, China, Japan, USA and Russia

Representatives of five nations (France, China,

Japan, USA and Russia) and the International

Atomic Energy Agency (IAEA) were invited

by Samuel Bodman, US Secretary of Energy

to a Ministerial Conference on the Global

Nuclear Energy Partnership (GNEP) in

Washington on May 21, 2007. The French

delegation was led by Alain Bugat, Chairman

of the CEA. A joint statement was issued at

the end of the conference.

The GNEP is a US initiative to kick-start nuclear energy once

again. On a domestic level, it aims to close off the fuel cycle and

ensure large-scale reprocessing of spent fuel. Its international

aims are to prevent the spread of technology that has proliferation

potential, to seek partnerships with

countries wishing to access nuclear

energy and to increase its use. The

goal is to offer spent fuel reprocessing

and recycling solutions without

requiring domestic facilities to be

built. This will complement the

IAEA's efforts to fine-tune its preproduction

fuel service supply

guarantee mechanisms.

Research and development into advanced cycle technologies

and fast reactors to burn actinides is also a subject of consultation

and coordination as part of the Generation IV International

Forum (GIF), currently chaired by France.

© A. Gonin/CEA

SECURITY AND NON-PROFILERATION

CEA and IRSN at the ESARDA conference

The CEA and IRSN both took part in the 29 th conference of ESARDA, the European

Safeguards Research & Development Association from May 22 to 24 in Aix-en-Provence.

This association was established in 1969 and draws together research laboratories,

industrial operators, inspection bodies and government ministers from the member

states of the European Union. ESARDA's goal is to facilitate R&D cooperation between

the various players involved in nuclear material security controls.

Around three hundred experts in the field of nuclear security and non-proliferation met

for three days to review the control of nuclear materials in the European Union and

around the world.

Representatives of organizations such as the IAEA 1 , ABACC 2 and INMM 3 are regular

participants. Olli Heinonen, Deputy Director General of the IAEA, Roland Schenkel,

Director General of the Joint Research Centre (JCR – European Commission) and

Dominique Ristori, Deputy Director General of the Directorate-General for Energy

and Transport (DGTREN – European Commission) all spoke at the conference.

Olivier Caron, CEA Director of International Relations and France's governor on the

IAEA board, spoke about French policies in the areas of nuclear security and compliance

with international treaties. Emmanuel Sartorius, Senior Defence and Security Official

in charge of domestic control of nuclear materials, spoke about control issues in France.

Video tracking : A digital camera may be attached to the radiation monitor for video capture and identification.

1. IAEA: International Atomic Energy Agency, responsible for the NPT inspection provisions.

2. ABACC: Brazilian- Argentine Agency for Accounting and Control of nuclear materials (regional control agency).

3. INMM : Institute of Nuclear Materials Management (USA).

Two types of controls apply to nuclear

materials in Europe: first, security

controls as instituted by the Euratom

Treaty (effective since 1958), and second,

nuclear weapons non-proliferation

controls (NPT, effective since 1970). The

inspection provisions in both treaties

cover the full range of controls in order

to ensure that members comply with

nuclear proliferation restraints. The

association's work brings the field's

many experts and practitioners together

to discuss relevant general topics and

detailed issues that relate to particular

types of nuclear facilities. The

association also promotes discussion

with nuclear operators and researchers

to facilitate cooperation in the area of

international controls, thus ensuring that

treaties are applied as comprehensively

as possible and that new control

technologies continue to be developed.



A NEW FRANCO-CHINESE PARTICLE

PHYSICS LABORATORY

Alain Bugat, Chairman of the CEA,

Catherine Bréchignac, President of the

CNRS, Arnold Migus, Director General

of the CNRS and Lu Yongxiang,

President of the Chinese Academy

of Sciences, have inked an agreement

to set up a Franco-Chinese international

associate particle physics laboratory,

the France-China Particle Physics

Laboratory (FCPPL). This agreement

formalises a longstanding partnership

between France and China in this field,

officially recognising the joint work of

more than 250 researchers, engineers

and students from the two countries.

The France-China Particle Physics

Laboratory (FCPPL) has been set up

as part of a key strategy of the CNRS

IN2P3 organization (French national

institute for nuclear and particle

physics), consolidating its links with

various Asian countries over the last

two years. The institute works with

Japan, South Korea, Vietnam, and

particularly with China's rapidly

expanding research sector. Several

dozen scientists in France and China

are already collaborating to study

particle physics, astroparticles and

cosmology.

This agreement sets up a framework

for establishing a genuine Franco-

Chinese scientific community, with joint

management, a joint steering committee

and regular conferences. Many Chinese

researchers have already been hosted

by French laboratories, and the program

will also allow French researchers to

work in Chinese laboratories.

Bilateral cooperation between CEA and Slovenia:

Call for projects

A second call for projects has been issued under the agreement executed on

March 27, 2006 between the CEA and the Slovenian Minister for Higher Education,

Science and Technology. The topics selected for 2007 are the following: life sciences,

new energy technologies (fuel cells, biomass, etc.), new materials (catalytic materials,

nanomaterials, etc.), nuclear energy (material ageing, etc.) and lasers.

The goal of these one-year projects is to strengthen relations between the CEA

and Slovenian laboratories and to establish new joint ventures. This agreement

provides an official framework for the work already in progress with the Republic

of Slovenia. It shows the way to new areas for cooperation and strengthens

current partnerships by contributing to the structures of European bilateral

nuclear research in the context of the 7 th Framework Programme.

The projects to receive backing were chosen on July 10, 2007 as part of the

second Sterling Committee meeting that was held in Marcoule.

© P. Stroppa/CEA

P hysics

New scientific

interest group –

“Physics of the

two infinities”

Man has always sought to answer fundamental

questions on the origins and evolution of

the Universe. What is it made up of? What are

the basic laws that govern it? What is its future?

Pushing back the boundaries of knowledge

and technology in these areas requires deeper

investigation into phenomena occurring both

on an infinitely small scale (elementary particles

and quantum mechanics) and an infinitely

large scale (cosmology and general relativity).

These fascinating and closely related physics

fields are the focus of the scientific interest

group “Physics of the two infinities” (P2i) which

was officially launched on 30 March 2007 and

draws together 19 laboratories at the CNRS

(National Centre for Scientific Research), CEA

(Atomic Energy Commission), the Paris

Observatory and various higher education

bodies (Pierre and Marie Curie University

Paris 6), Paris Diderot University (Paris 7),

Paris-Sud University (Paris 11) and the École

Polytechnique.

P2i has set itself the goals of achieving

international recognition, increasing

coordination in research and boosting the

dynamism and resources of teams working in

subatomic physics and cosmology in the Paris

region. Particle physicists, nuclear physicists,

theorists and astrophysicists will pool their

equipment as part of the consortium. The aim

is also to promote

skill-sharing in order

to tackle the major

scientific challenges

laid down by

nature, such as the

exploration of dark

matter and dark

energy, which are

poorly understood,

but together account

for more than 95%

of the Universe's

energy density.

© CEA/Dapnia



© D.Marchand/CEA

Lu Yongxiang,

President of the Chinese

Academy of Sciences,

visits the CEA

During his trip to France, Lu

Yongxiang, President of the

Chinese Academy of Sciences 1

and Vice-Chairman of the People's

National Congress visited Saclay

on April 11, 2007. He was

received by Yves Caristan, Director

of Physical Sciences, André Syrota,

Director of Life Sciences and

Olivier Caron, Director of

International Relations, and was

shown the latest developments

in the CEA's work, witnessing at

first hand the dynamic working

environment at Saclay. Mr. Lu's

visit included Soleil, the

third generation synchrotron

inaugurated last December, and

NeuroSpin, the new intense-field

nuclear magnetic resonance

cerebral imaging (MRI) center.

He then had a meeting with

Bernard Bigot, High Commissioner

for Atomic Energy.

During the visit, CEA Chairman

Alain Bugat signed two agreements

on behalf of the CEA in the

presence of Zhao Jinjun, Chinese

Ambassador to France. The first

was an agreement to set up an

international associate laboratory

involving the CEA, CNRS and the

Chinese Academy of Sciences

focusing on high-energy physics,

and the second was an

amendment to the agreement

between the CEA and the Chinese

Academy of Sciences on cosupervision

of research projects.

Mr. Lu emphasized the importance

of the CEA's collaboration to the

Chinese Academy of Sciences, and

described it as strategic. He

suggested instituting a yearly forum

to promote exchange between

researchers from the two bodies.

1. The Chinese Academy of Sciences is

China's largest national research

organization, with 58,000 staff.

Start of

construction work

for Jules Horowitz

research reactor

Construction work on the Jules Horowitz research reactor

(JHR) was launched by François Loos, Minster for Industry,

on March 19, 2007. Other figures who attended the ceremony,

along with 500 other guests, included CEA Chairman Alain

Bugat, Philippe Pradel, CEA Director of Nuclear Energy,

Serge Durand, Director of the Cadarache research site and

representatives of French industrial partners such as EDF

and Areva.

The goal of the Jules Horowitz Reactor is to develop and test

new fuels and materials to be used in production reactors

now and in the future, with a particular focus on Generation IV.

In addition to the applications for power production, JHR

will supply 25% of Europe's requirements for radioelements

used in nuclear medicine and could contribute to the

production of high-performance silicon

for industrial and electronic

components. The reactor is due

for commissioning in 2014.

©CEA

S ynergies

New “Climate-Environment-Society” scientific interest group

The newly established “Climate-Environment-

Society” is a joint venture between the CNRS,

CEA, the École Polytechnique, University

of Versailles Saint-Quentin-en-Yvelines,

University Pierre and Marie Curie and

ADEME 1 . Its goal is to synergize experts’ skill

sets to study climate change and its

consequences for society and the environment.

It will create solid links between researchers in complementary disciplines

– climatology, ecology, medicine, economics and the social sciences –

and promote the emergence of a more precise description of the

interactions between climate change and future societal choices.

The work will focus on the coordinated

development of climate models, observation

systems and tools for effecting change on

the interfaces between climate and society.

With the support of the Minister for Higher

Education and Research and the Minister of

Ecology and Sustainable Development, the

research group will enjoy international stature,

attracting foreign researchers and organizing conferences and

communication campaigns.

http://gisclimat.ipsl.jussieu.fr/

1. The French Environment and Energy Management Agency

© P. Bazoge/ CEA



© DR

European Parliament:

Speech by Oliver Caron

on Nuclear Power

Olivier Caron, CEA Director of

International Relations and France's

governor on the IAEA Board was

invited to speak the European Energy

Forum 1 , a discussion group led by

British MEP Giles Chichester, former

Chairman of the European Parliament

ITRE Committee 2 .

Mr. Caron's speech focused on the

worldwide renewal of interest in

nuclear energy. He described the

world's current energy challenges

(securing supply, combating climate

change, remaining competitive) and

demonstrated the vital place of this

energy source. He highlighted the

encouraging fact that discussions are

underway within European

institutions to develop a

comprehensive energy policy across

the European Union.

After the speech, a discussion that

included the fifteen or so MEPs in

attendance (including representatives

of the EU’s new member states)

confirmed Parliament's interest in

energy issues, including nuclear

power in particular. There were

discussions between the Committee

and various MEPs on the question

of nuclear safety and the requirement

laid down during accession

negotiations that some power stations,

particularly in Bulgaria, be shut down.

The issue of waste was brought up

repeatedly. Mr. Caron took the

opportunity to explain that technical

solutions do exist and, referring to

the French process, showed that waste

processing is now an issue for political

decision-making.

1. More info:

http://www.europeanenergyforum.eu/

2. Industry, Telecoms, Research et Energy.

FRANCO-JAPANESE DISCUSSIONS ON STORAGE

The 5 th “information exchange” between EDF, CEA and CRIEPI (Japanese Central

Research Institute of Electric Power Industry) was held in the Tokyo suburb of Abiko.

Hervé Lagrave, high-level radwaste storage manager and Guillaume Ranc, expert in

concrete structures, presented the most recent results from the Department of Fuel

Cycle Technology on spent fuel storage, chiefly

focusing on heat and air flows within storage

facilities, the mechanical behavior of structures at

temperature and the confinement of containers during

accidents (earthquake or drop accident). These joint

ventures should all be validated at the Management

Committee meeting in September 2007. The trip also

provided an opportunity to visit the Abiko center’s laboratories, which are working on

seal testing, dynamic characterization of concrete and chloride source terms; the

Akagi site, looking at heating within concrete containers, metal container drop

accidents and the transmission and use of electricity; the JAPC spent fuel dry

storage facility and the Tokai-Daini Electricity museum.

© Champion/CEA

7 th European

Framework

Program for

Research and

Development

The 7 th Framework Program was officially launched

on December 22, 2006 and is the main research

funding instrument for the period 2007-2013. “Its

goal is to consolidate the European Research Area,”

points out Claude Ayache, Director for European

Affairs (CEA's International Relations Division),

“and it follows directly in the footsteps of the previous

framework program. There is a concerted focus on

a limited number of priorities, with coordination at

all levels, among researchers, institutions and State

research policies.The aim is not just to provide funding,

but to continue to structure research throughout

Europe research.” Nevertheless, new ambitions

are set out in the 7 th framework programme for

research and development, both in financial and

political terms. The budget is up by a yearly

average of 60% compared with the 6 th framework

program, with a total envelope of € 54.5 billion

over the period 2007-2013. There are new

challenges on the research side too. “The biggest

of the challenges,” says Mr. Ayache, “is setting up

the European Research Council. The aim is to promote

scientific excellence by funding very high-level research,

pushing back the boundaries of knowledge. Establishing

exploratory research as a major factor for future

competitiveness is a first within the European

Community. Other new aspects of the 7 th framework

program include a boost for industrial collaborations,

with new forms of public-private partnerships,

European Technology Partnerships and Joint

Technology Initiatives (JTIs). Finally, there are two

new research priorities, security and space.”

TWO NEW CEA COUNSELORS IN EUROPE:

- Alain Régent in London

- Claude Sainte-Catherine in Helsinki

Pierre-Yves Cordier replaces Dominique Ochem

after his four-year stint, in Tokyo

Please refer to the back cover for contact information.


NANOSCIENCES

UNDERSTANDING

Stimulated by the

race towards

miniaturization in

the microelectronics

industry, research

in Nanosciences is

conducted at two

departments within

the Physical

Sciences Division:

the Drecam 1 in

Saclay and the

DRFMC 2 in Grenoble.

This involves

disciplinary fields at

the crossroads of

Chemistry, Physics

and Biology.

Activities at Saclay

in the spotlight.

© C. Fuseau/CEA

NEW LAWS

OF PHYSICS

Scanning

Electron

Microscopy

(SEM) is

among the

tools

frequently

used in

nanoscience.

Trying to manipulate nano-objects,

understanding the behavior of finely

divided matter, exploring quantum

effects: these are some of the

challenges facing fundamental

research in nanosciences.

At the level of atoms and molecules,

there is a whole world to explore:

the nanoworld, christened thus in

reference to the nanometer, a

billionth of a meter. Observing

atoms and molecules individually

became possible at the start of the

1980s thanks to two inventions:

the scanning tunneling microscope

for materials that conduct electricity

and its derivative, the atomic force

microscope for insulating materials.

These instruments are used both

to observe surfaces and to

manipulate atoms or molecules.

Pooling the talents of chemists,

physicists and biologists has played

a decisive role in the creation of

electronic devices and innovative

materials.


© CEA

TOPICS TO EXPLORE

/// Nanostructured matter

/// Quantum effects

/// How are nano-objects designed?

/// Toxicity of nano-objects

/// MINATEC ®

THE ADVANTAGES OF

NANOSTRUCTURED MATTER

How do the properties of particles change when their dimensions

go from the micrometric to the nanometric scale?

Pilot

installation

of nanopowder

synthesis

using the inflow

pyrolysis

method.

Understanding the effect of size on the

physical or chemical properties of particles

is essential in nanosciences. The particles

can be separated out individually in a powder

state or bonded to solid materials. At the

frontier between science and technology,

researchers are shuttling back and forth

between synthesizing materials, conducting

experiments and performing numerical

simulations and interpretations.

A more radiation-resistant

ceramic

A ceramic is a material obtained by heat

treatment (sintering) from powders generally

of micrometric size. A team specializing in

laser pyrolysis has developed an original

technique for producing chemical composites

in powders of calibrated sizes. According to

recent experiments, ceramics made from

nanometric powders produced in a laboratory

are more resistant to radiation than traditional

ceramics. In both cases, it is possible to

see the grains, separated by grain boundaries,

at different scales. Under the effect of

radiation, defects appear in the crystalline

organization of the grains and tend to merge

until they hit an obstacle: the boundary. It

seems that, in nanostructured ceramics, the

SIZE GUIDE

0.1 nm atom

1 nm molecule

10 nm protein

100 nm DNA

appearance of radiation damage is delayed

because the web of particles is a thousand

times finer. From the “materials” point of

view, these ceramic nanopowders could

be used in the composition of composite

materials for the nuclear reactors of the future.

A larger active surface area

Another example of a divided (or

nanostructured) material is the platinum in

fuel cells. The chemical reactions that produce

the current in the fuel cell are accelerated

(or catalyzed) by this metal when the reagents

“meet”, coming into contact with it. The use

of fine platinum particles makes it possible

to reduce the quantity of metal required.

The size of these particles varies from a

few nanometers to tens of nanometers.

Researchers are proposing to replace them

with particles of a perfectly calibrated size.

A “coating” of organic molecules prevents

the particles from forming clusters and means

that the distance between metal cores can

be finely regulated by the choice of grafted

molecules. From the perspective of

application to fuel cells, the electrical

conductivity of these objects can be optimized

according to their size. The icing on the cake

is that combining these particles with carbon

nanotubes would make the catalysis sites

more accessible to the reagents and improve

efficiency even more.

1. Department of Research on Condensed Matter, Atoms and Molecules

2. Condensed Matter Fundamental Research Department.

A choice of colors

One particular property of semiconductors

is photoluminescence, which provides a

spectacular illustration of the size effect.

When they are lit, these materials give out

some of the energy they receive by emitting

light. The color (or energy) of this light is

determined by the chemical nature and size

of the semiconductor. If the specimen size

is reduced to a few nanometers, there is

constant variation in this color: the energy

of the emitted light increases as the size of

the object decreases. The behavior of the

nanocrystal, also known as a quantum dot,

seems to gradually approach that of an

isolated atom. In particular, silicon

nanocrystals, still produced by laser pyrolysis,

could act as in vivo tracers for the diagnosis

and treatment of diseases.


> PYROLYSIS: chemical decomposition

through the action of heat alone.


CEA NEWS 9 September 2007

© Artechnique/CEA

NANOSCIENCES

OBSERVING AND USING

QUANTUM EFFECTS

On the scale of atoms, electrons and photons, interactions

between these entities are governed by quantum physics.

This opens up new perspectives for nano-objects.

© F. Vigouroux/CEA


As one of the dimensions of a device

approaches the size of an atom, the quantum

effects inherent in microscopic physics appear.

They are apparent, most notably, through

discontinuous energy transfers, in “packets”

known as quanta. These phenomena, invisible

on a large scale, open up potentially very

interesting paths for exploration. This is why

researchers are making an effort to observe

and use quantum effects in reasonably “large”

experimental devices.

WHAT IS

A QUANTUM STATE?

Much more than a binary piece of

information, a “quantum state” is defined

as a set of several simultaneously possible

situations, each with a very specific

probability of occurrence. An experimental

measurement fixes the quantum state in a

single one of these situations. To evaluate

the probability attached to the situation, the

measurement has to be repeated a very

large number of times.

Playing with electron spin

Giant magnetoresistance (GMR) manifests

itself as an increase in electricity conduction

in an electronic device when a magnetic field

is applied to it. This effect is explained on

a quantum scale by electron spin, the

electron's intrinsic rotation.

The device consists of an assembly of two

layers of metal with different magnetisms,

separated by a very thin insulating layer

(of the order of a nanometer). In one of

the magnetic layers, the spin of the electrons

is fixed by the prior state of magnetization

of the material and in the other, it is subject

both to the coupling with the first layer and

to an external magnetic field. The degree

of resistance to the passage of current, which

acts as a sensor, depends on the electron spin

configuration in the layers it is crossing: there

is less resistance when the magnetizations

are aligned than when they are opposed.

GMR can be used to read (and write)

information in the first magnetic layer or

to measure a magnetic field.

Discovered in 1998, GMR is today used

on an industrial scale in the hard disks of

our computers. The property is also exploited

in highly sensitive sensors, one of which

should be able to detect magnetic fields as

tiny as those resulting from neuron activity.

Regulating the electron ballet

How do you describe the passage of an electric

current through a metal conductor? Imagine

a set of relays in which an atom (for instance

copper) “gives” one of its electrons to a

neighboring atom and “receives” another in

>>>

“

Our collaboration

with companies in

many sectors, and

these applications, are

nurturing the most

fundamental research

into magnetism.

”

© Artechnique/CEA

Myriam Pannetier-Lecœur

Physical Sciences

Division/Drecam/Saclay

Measurement

set devoted to

studying spinpolarized

currents in

magnetic

nanostructures.


Fundamental research

experiment on magnetism

based on giant

magnetoresistance

ELECTRONS

TO SEE THE NANOWORLD

MICROSCOPES THAT

CAN “SEE” ATOMS

AND MOLECULES

How do we “see” the atoms and molecules

in a solid individually? The “eye” of these

microscopes is a tip that scans the surface

to be analyzed by gliding over it at a fixed

height of the order of a few atom

diameters (a few tenths of a nanometer).

This distance is adjusted by very shortrange

interactions between the last atom

right on the tip and the surface.

Microscope resolution is limited by the diffraction

of light crossing the specimen. This becomes

even more of a problem as the wavelength of the

light increases. Hence the idea of replacing

photons with electrons, which have a shorter

wavelength. In transmission electron microscopy

(TEM), a flow of electrons is passed through the

specimen and detected to form the image.

Resolution can go below a nanometer.

Meanwhile, the scanning electron microscope

(SEM) uses secondary electrons emitted by the

specimen when it is bombarded with electrons,

on the same side as the source. This time the

resolution is of the order of a nanometer.

“

With the benefit of experience,

theoretical formalism has been pushed

out in favor of intuition and inventiveness.

© C. Dupont/CEA

Christian Glattli

Physical Sciences Division/Drecam/Saclay

”

© CEA-LEM

In the scanning tunneling microscope (STM)

this interaction, quantum in nature, is

manifested by a weak electric current that

flows between the atom on the tip and the

surface. This current rapidly increases as the

tip gets closer to the surface. In the atomic

force microscope (AFM), similar forces to

those that make atoms bond in a molecule

are at work between the atom on the tip and

the atoms on the surface. At even shorter

distances, forces of repulsion predominate

between the atomic nuclei. Subject to these

antagonistic forces, the atom spontaneously

tries to remain at a fixed distance.

In both cases, a computer records either

the current or the force, and keeps the tip

at a constant distance from the surface. The

relief “felt” by the tip can be reconstituted

in this way with resolution of less than a

nanometer, giving the user an atom-byatom

picture of the material being studied.

return. Under normal conditions, electrons

barely move more than about thirty nanometers

before experiencing a collision that “erases”

their quantum effects. To observe the effects,

it is necessary to reduce the number of

collisions or to thin out the electron population

and extend the free trajectory of the electrons.

This is why some researchers have chosen

to study the interface between two

semiconducting layers 1 , working at very low

temperatures to attenuate the thermal agitation

of the atoms. The electrons can therefore

spread out almost freely in a plane, typically

over about ten thousand nanometers. The

apparatus also has electrodes that control

the opening of a passage for the electrons, a

few hundred nanometers wide.

What is observed? As the passage opens, the

conductance of the system, i.e. its ability to

conduct current, increases in steps! These

steps correspond to the multiples of a

fundamental constant known as a conductance

quantum – another quantum effect! These

effects can also be seen in metals when two

electrodes are linked by just one or more

atoms. What is even more extraordinary is

that the phenomenon generates almost no

spurious background noise! These “new”

laws apply to nanocomponents such as carbon

nanotubes, which transmit four conductance

quanta – no more and no less…

1. Made from gallium arsenide (AsGa) and gallium arsenide

and aluminum (AsGaAl) respectively. The density of

moving electrons is governed by the dopant concentration.


NANOSCIENCES

HOW ARE NANO-OBJECTS DESIGNED?

The carbon nanotube, the material most emblematic of the nanosciences,

is “coated” with molecules to massively increase its powers.

The discovery of the carbon nanotube in

1991 opened up a vast field of study in

nanoelectronics. It is a long cylinder made

from one or more rolled up sheets of carbon.

The diameter of a carbon nanotube varies

from a few nanometers for single-sheet tubes

to about a hundred nanometers for those

made from multiple sheets. What are their

benefits? They are easily mass-produced

to the point of becoming a commercial

product. With a particular geometry, they

can be semiconductors. Being much more

stable than isolated molecules, they are easy

to connect to electrodes. In 1998, the first

transistor made with carbon nanotubes

appeared.

We will now look at some of the stages in

the fabrication of nano-objects from carbon

nanotubes.

be highly practical for many types of

manipulation. First it is necessary to “graft”

organic molecules onto the nanotube that

are capable of clinging to the nanotube's

carbon atoms on the one hand, and giving

it the required solubility properties on the

other. One technique is to render soluble

only the semiconductor nanotubes, so they

can be sifted out. Once they are in a solution,

the nanotubes can be diluted to obtain the

desired rate of deposit on a surface.

Molecular “coatings”:

endless creativity

It is now possible to “coat” the nanotubes,

which simply means depositing molecules

on their surface, attaching them solidly to

the carbon atoms, or even inserting them

inside the cylinders.

The “coating” can make it possible for the

nanotube to attach to a prepared surface, a

bit like Velcro ® . More generally, combining

nanotubes with molecules with specific

electronic and optical properties is at the

heart of research into molecular electronics.

Nanotubes and DNA

Some researchers are working on combining

nano-objects such as DNA strands with

carbon nanotubes to make T-shaped

structures similar to those of a transistor.

A kind of molecular Scotch ® tape needs to

be devised to bind the nanotube and DNA

together using real chemical bonds. In this

case, nanotubes are being used because of

their ability to be connected to electrodes.

DNA could also be used as a “pattern” to

guide the spontaneous assembly of carbon

nanotube structures, along the same lines

as biological processes.


Self-assembled carbon nanotubes on a surface of

functionalized silica, connected electronically via gold wires.

Preparing the bare nanotubes

The first challenge is sorting the bare

nanotubes, because they are a mixture of

metallic objects and semiconductors. The

second is that nanotubes are not soluble, so

in their ordinary state they cannot be

incorporated into a solvent, which would

© Motorola/CEA

FROM NANOTUBES

TO NANORINGS

It sometimes happens that the

unexpected texture of the

chemical “coatings” of nanotubes

inspires researchers, leading to

the creation of some surprising

nano-objects – nanorings, for

example! Observation of ring

structures under a transmission

electron microscope led them to

include reactive functions in the

initial coating to stiffen the rings

and detach them from the nanotube. These nanorings could carry anti-cancer molecules

to diseased cells. This drug vectorization project is being carried out by a team from

Divison of Life Sciences in partnership with Laboratoire Servier. Another application, with

a more fundamental aim, is to use the nanorings as a substitute cell membrane for

studying proteins in cells. These proteins degrade as soon as they are removed from

their environment.



Preparing

impermeability tests

for nanoparticles in

protection equipment

(masks and gloves), as

part of the European

Nanosafe2 project.

© F. Vigouroux/CEA

EVALUATING THE TOXICITY

OF NANO-OBJECTS

Several CEA laboratories are participating in national and

European programs to evaluate the risks from nanoparticles.

How is their impact on health and the environment measured?


> TRANSISTOR:

component that

performs the functions

of an amplifier,

modulator or

interrupter of

electrical current.

> DNA:

deoxyribonucleic acid,

an essential

component of

chromosomes, and the

physical carrier of

heredity.

On a small scale, matter divided into

nanoparticles has a larger surface area than

ordinary matter. This could exacerbate its

toxicity. Furthermore, nanoparticles have a

natural tendency to form groups of

micrometric size. Before a toxicological study

is carried out, it is necessary to know the

chemical nature of the particles, their structure

and the physical and chemical state of their

constituents. Finding out this information

requires specialist skills and highly specialized

analysis methods. When it comes to studying

nanoparticles in suspension in the air, there

is a particular problem: how can they be

isolated or distinguished from ordinary

atmospheric pollution?

What effect do they have on

animal cells and bacteria?

Various teams are trying to assess the toxicity

of nano-objects for humans using in vitro

animal cell models. The aim is to study the

biological effects on the organs they reach

following inhalation or ingestion (lungs, liver)

or following their passage through the body's

natural barriers (kidneys).

Two effects are being studied: the toxicity for

the whole cell on the one hand and for the

genes it contains on the other. Can

nanoparticles pass through the cell

membrane? Does the cell remain alive? Is its

genetic material affected?

Researchers are also interested in what

happens in the environment to nanoparticles

released by the decomposition of consumer

products which have components containing

them. The first targets to be looked at are

bacteria in the ground and water. Are the

nanoparticles trapped on the surface of the

bacterium? Do they go inside it? If so, what

happens to them? Do the bacteria put up

any resistance?

Toxicity and exposure

These toxicological studies do not yet take

account of the processes of exposure of cells

in the body, which is a more complex

environment than in vitro experiments

provide. Until the results of the full toxicology

study program are available, those working

in laboratories are avoiding contact with

nanoparticles by using containment methods

(air locks, filters, packaging of powders, etc.).


NANOSCIENCES

Jean-Philippe

Bourgoin

of the Physical Sciences

Division, director of

CEA’s cross-disciplinary

Nanosciences program

INTERVIEW

1. Minatec ® center was inaugurated in

June 2006

2. Scanning Electron Microscopy (SEM)

performed on a nanocharacterisation

platform

3. Atomic force microscope used for nano

and micro component imaging

4. Automatic parametric tester

to perform functional characterization on

microsystems

1

5. Holographic and analytical Titan

Transmission Electron Microscope (TEM)

used to characterize materials

6. Wafer to wafer assembly and

lithography cluster

7. Micro-traction station to study

microsystems

8. Programming the Endura 5500C

machine to apply metal coating

applications for Microsystems

9. Lithography area for microsystems

“ORGANIZING

WORK AND

SKILLS”


Why is such a program necessary?

It’s a question of making early research in our

fields – Information's Technologies, Health and

Energy – more visible. It’s also a question of

developing our partnerships most notably with

CNRS and the universities, of strengthening

the sectors in which we excel at fundamental

research and of developing their application

potential.

What fields are covered?

In addition to the work already in place on quantum

electronics, chemistry for nanoelectronics,

separation chemistry or spin electronics and

nanomagnetism, new research subjects are

emerging. We are interested in the behavior of

fluids in fuel cells and biochips and in thermal

exchanges in electronic components and

refrigerant fluids. Simulation of nano-objects,

materials and electronic

components is also playing

“

an increasing role, as are

particular aspects of nanocharacterization.

Finally, in

collaboration with crossdisciplinary

programs on health

technologies and materials, we

have grouped and expanded the

research launched by CEA since

2001 on the potential risks from

nanotechnologies.

Simulation

of nano-objects

is also playing

an increasing

role in health

technologies.

”

Sophie Astorg – Le journal de Saclay nr 36 – 2007, April

2

3 4


RESEARCH ON MICRO- AND

NANOTECHNOLOGIES HOLDS

PROMISE... WITH MINATEC ®

6 7

5

8

While Nanosciences are studied in both Saclay and Grenoble,

research into Nanotechnology is mainly conducted at the

Minatec ® labs in Grenoble.

Initiated by CEA-LETI 1 and INP 2

Grenoble, the Minatec ® center was

inaugurated in early June 2006. It's an

impressive site with 44,000 m 2 of new

buildings spread over roughly 20 acres

of land – becoming a major European

innovation and consulting center for

micro- and nanotechnologies demands

significant investment. “Grenoble's

nanoscience and nanotechnology center is

an extension of all the programs recently

implemented by public authorities for

research and its application,” declared

François Goulard, Minister Delegate for

higher education and research, during

his visit to the CEA's Grenoble center

on October 31 st , 2006.

The Minatec ® concept is unique in both

France and Europe. Why? Because it

brings students and teachers as well as

researchers and people from industry.

Minatec ® gives them the chance to

exchange ideas and work together at a

single location. As a result, “upstream”

research is undertaken by scientists in

the Physical Sciences Division, whereas

“downstream” projects tend to be handled

by researchers in the Technological

Research Division. Which is in keeping

with the race to miniaturize and the era

of the infinitely tiny, both well underway.

It is imperative to harness the most

fundamental properties of matter, push

back the limits of current technologies,

and map out new technologies within

a multidisciplinary framework. Minatec ®

will focus on major research themes such

as microelectronics, nanoscience applied

to biology or new materials, and software.

No less than 3,500 engineers, researchers,

and academics will strive to meet this

objective, using the most advanced

equipment and technological resources.

Nanomaterials have inspired high hopes

and should lead to all sorts of products

that are both competitive and

environmentally friendly. Being more

and more efficient means producing on

an ever smaller scale, with lower

costs and higher performance. We

immediately think of cell phones,

computers, and so forth, but the realworld

applications of this research are

far more numerous: in the automotive

industry, for healthcare, entertainment,

safety, etc.

1. Laboratoire d'électronique et de technologie

de l'information (electronics and information

technology laboratory).

2.Institut National Polytechnique (engineering

school).

> For more information:

http://www.minatec.com/minatec_uk/index.htm

Photos 1-4 & 6-9: © P. Stroppa/CEA

Photo 5: © C. Morel/CEA

9


WASTE – ADVANCED PARTITIONING

SOLUTIONS FOR

RADIOACTIVE WASTE

How can

radioactive waste

be sustainably

managed? The

CEA (French

Atomic Energy

Commission) has

been carrying out

in-depth research

under an Act dated

December 30,

1991 1 . Our report

focuses on the

three areas of

investigation and

their results.

1. This act, also referred to as the “Bataille Act”, was transposed into the

French Environment Code as Article L.542 in September 2000

Storage hall in the Saclay center. Each of the

100 shafts is ten meters deep, the highly irradiant

drums are transferred to the shafts in a shipping

cask and covered with a concrete plug.

TOPICS TO EXPLORE

/// Review of 15 years of research

/// Partitioning

/// 2006: the new law



Separating

actinides:

filtering operation

in a glove box in

the Atalante

facility.

© T. Foulon/CEA

In June 2005, ANDRA 2 and the

CEA each submitted a report

to the Ministry of Research

reviewing their work on longlived,

high level radioactive waste

management, to enable the

government to propose a bill that

includes the solutions put

forward for sustainable waste

management. Nearly 80% of

French electricity is currently

produced by nuclear power

plants, which ensures energy

independence, standing France

in good stead given oil

price rises and limited fossil

fuel supplies, and also

ensures low greenhouse gas

emissions. When France

opted for nuclear power in

the 1970s, it immediately

started research into waste

management. The 1991 Act

gave the research a boost

and focused on three

areas: partitioning and

transmutation, geological

disposal and conditioning

& storage. Research

is still ongoing, but

a large body of

results has already

been produced, showing the way

to potential solutions.

Let's take a look at three research

areas that have focused French

science on one major issue for

a number of years: the sustainable

management of radioactive material.

2. French National Agency for Radioactive Waste Management.

3. Spent fuel is processed in Cogema's La Hague plant.

Research focus 1:

Scientific demonstration

of partitioning and

transmutation (P&T)

For the last twenty years or so,

the French nuclear industry has

been recycling 3 95% of its spent

nuclear fuel, unburned uranium

and plutonium, which is used

for producing a new fuel cycle.

The remaining 5%, which is

waste, is immediately vitrified.

Of this waste, the only items

covered by the 1991 Act are longlived

high-level radioactive

elements (0.4% of the spent fuel).

Research Focus 1 is looking

into a way of separating the

most radioactive elements for

transmutation. The partitioning

research undertaken at the Atalante

facility at the CEA Valrhô center

(at Marcoule, near Avignon) has

demonstrated process feasibility

in the laboratory. A high-yield

transmutation process, where

long-lived radioactive elements

are bombarded with neutrons,

can be performed in fast breeder

reactors, as proven by the tests

run in the CEA's Phénix

experimental reactor at Marcoule.

However, partitioning and

transmutation is not industrially

feasible before 2040, and will

only be used for waste produced

after that time. The CNRS

(French National Centre for

>>>

Research

reactor Phenix

is dedicated to

waste

transmutation


150

The number of extracting molecules tested by

researchers during studies into minor actinide

partitioning.

A TALANTE:

T HE O NLY F ACILITY O F

I TS T YPE IN T HE W ORLD

The Atalante facility at Marcoule hosts highly specialized

laboratories for work on improving spent fuel

reprocessing procedures. It has been specially designed

for studies into the management of long-lived high-level

waste (HLW): design and testing of extraction molecules

and studies into advanced partitioning processes,

design and manufacturing of irradiation targets for

transmutation and long term behavioral studies into

waste in storage or repositories. The CEA is also

developing methods for reprocessing and recycling fuel

from the fast neutron energy production systems of the

future. This unique facility is staffed by more than

200 people. The commissioning of Atalante was

announced by the ASN College (French Nuclear Safety

Authority) on June 22, 2007. ASN carried out a safety

review at the same time.

Special Issue – Les Défis du CEA – 2005, July


> TRANSMUTATION: The process of transforming a longlived

radioactive element into an element with a shorter

half-life or a stable element.


© P. Stroppa/CEA


Scientific Research) is working

on another transmutation method,

using hybrid nuclear systems.


Towards reversible deep

geological disposal

ANDRA is working on the second

research focus proposed in the

1991 Act. It is looking at ultimate

disposal of radioactive waste in

deep geological repositories,

capable of ensuring long-term

containment several hundred

meters below the ground. ANDRA

(French National Agency for

Radioactive Waste Management)

is studying three rock types –

granite, salt and clay. It has set up

a field laboratory at Bure, in the

Meuse region, that has been

operational for several months. If

the research is successful and

political leaders make the relevant

decisions, a geological disposal

© P. Dumas/CEA

center should be built between

2020 and 2025. According to the

Parliamentary Office for the

Evaluation of Scientific and

Technological Choices, this is a

vital option, but one that must be

reversible. All nuclear-waste

producing countries have selected

this as an option. Likewise, experts

from the International Atomic

Energy Agency (IAEA), an UN

authority recommend deep

geological disposal, considering

it the safest current option.


Increasingly

high-quality storage

Long-lived high level radioactive

waste from spent fuel processing

is currently vitrified and stored

pending an ultimate solution, to

be determined by the

Government after a parliamentary

debate. Current storage technologies

and facilities have been much

higher-performing over the last

few years, improved through

work by the CEA under Research

Focus 3. New waste conditioning

matrices developed at the CEA

Marcoule center have brought

gains in terms of performance,

reduced volumes and increaseddurability

packages. The

Parliamentary Office has judged

France's currently operational

storage facilities, at the Cogema

plant at La Hague and the CEA

Cadarache center as highly

efficient and fit to be safely used

for another fifty years. The goal

is to have storage facilities with

a service life of 100 to 300 years.

Amélie Kroell - Les Défis du CEA Nr 106

2005, August

Evolving Vitrification

Prototype (AVP)

1991-2006,

a review of 15 years

of research into

advanced

partitioning

Under the “Bataille” Act, one of the

major focuses in the drive to reduce

the quantity and danger of long-lived

high-level nuclear waste is to partition

some long-lived radionuclides, either to

transmute them or to carry out specific

conditioning. After the 15 years of

research prescribed by lawmakers,

Christine Rostaing, “Advanced

Partitioning” Project Manager, reviews

the progress made in research in this

field over the period.


Most of the partitioning studies

have focused on six radionuclides:

• the minor actinides

(americium Am, curium Cm

and neptunium Np) which,

after plutonium, are the main

contributors to the long-term

radio-toxic inventory of spent

fuels,

• three fission products

(iodine I, cesium Cs and

technetium Tc) which were

selected due to their abundance

in spent fuel, the existence of

a long-lived isotope and their

potential long-term mobility

within a geological repository.

The procedure used

In order to perform minor actinide

partitioning, extraction with a

solvent was selected as the

The entire processing and conditioning chain for highlevel

radioactive waste was tested in Atalante: glove boxes

comprised of a test loop for liquid-liquid extraction processes,

a shielded process line on spent fuel and a selection of

shielded compartments designed to host confinement

matrices (glass, ceramic) and to study the long-term behavior

of high-level waste packages; complemented by the shielded

process line for experimentation, which confirmed the

technical feasibility of advanced partitioning.

reference procedure. This is a

proven technique in the chemical

industry and there is significant

data available from operational

use of the PUREX process at the

La Hague plant over several

decades. The strategy therefore

consisted of:

• firstly, adapting the PUREX

process to recover neptunium,

technetium and iodine.

• secondly, developing complementary

solvent-based extraction processes

(hence the expression “advanced

partitioning”) to separate out

americium, curium and cesium

from the high-level waste

produced by the PUREX process

currently vitrified.

A target date of 2006 was set and

the research was organized into

two broad phases, aiming to

demonstrate the scientific feasibility


(validating the basic concepts of

partitioning) by the end of 2001

and the technical feasibility (trials

and overall validation of the

processes) by 2005.

The initial exploration phase

was undertaken over a decade,

involving wide-ranging cooperative

ventures. It consisted of assessing

the various extraction systems,

chiefly targeting the trickiest stage

– separating the actinides from

the lanthanides. The second

demonstration phase, between

2002 and 2005, focused on the

processes deemed the most

promising.

A three-stage approach

It is not easy to recover and

separate the minor actinides

(americium and curium) within

>>>

PARTITIONING

BY LIQUID-

LIQUID

EXTRACTION

Liquid-liquid extraction

is a technique that

uses two immiscible

liquids, one aqueous

phase and one organic

phase. The elements to

be separated are all

dissolved in the

aqueous phase and a

special molecule,

referred to as the

“extracting” molecule,

is dissolved in the

organic phase. The role

of this molecule is to

capture the elements

required for separation

within the aqueous

phase and to take them

with it (extract them)

into the organic phase.

This molecule needs to

be both effective

(having a good affinity

with the elements to be

separated) and

selective (affinity only

with said elements).

One of the major

difficulties in designing

a liquid-liquid

extraction process is

selecting this

extracting molecule.

Special Issue

Les défis du CEA - 2005, July

> PUREX:

Purification by

refining extraction.

> LANTHANIDES:

fission products

from the lanthan

family, with similar

chemical properties

to actinides.



high-level waste (HLW). A number

of factors make this a complex

problem. The very similar chemical

properties of the actinides (at

oxidation degree III) and the

lanthanides (at oxidation

degree III), mean they are difficult

to separate; in addition, there is a

large variety of elements within

the solution, which is moreover

highly acidic. A three-stage

approach is required:

• Stage 1: the DIAMEX, which

consists of simultaneously

extracting the actinides and

lanthanides using a molecule

from the malonamide family;

• Stage 2: the SANEX process,

separating out the Am+Cm pair

from the lanthanide group;

• Stage 3: the Am/Cm partitioning

process, using diamides.

Review and outlook

Since 1991, research into

advanced partitioning has enabled

procedures to be developed for

selectively recovering americium

and curium from fission product

solutions derived from the PUREX

process (99.9% recovery rate,

which meets the stated goal). The

selected concepts were validated

before the end of the first phase

of research (end of 2001). During

the second phase (2002-2005),

the processes were successfully

tested. Firstly, the solvent

endurance was tested in the

irradiation loop. Subsequently

the demonstration tests were

successfully performed, in April

and November 2005 respectively,

in the Atalante shielded process

cell, a 1/500 replica of the

industrial technologies, using

approximately 15 kg of EDF fuel.

But over and above the scientific

results expected within the strict

framework of the law, it should

also be emphasized that this

period was useful for carrying

out numerous basic studies, for

instance into the extraction and

complexation mechanisms of

various extraction systems.

Doctoral and Post-Doc research

contributed greatly, along

with national (GdR PRACTIS and

PARIS), European (NEWPART,

PARTNEW, CALIXPART,

EUROPART, etc.) and

international collaborations

(Japan, Russia, USA, etc.). The

CEA and the Valrho center have

thus acquired new skills (e.g.

molecular modeling) and new

tools (see insert Future

challenges).

The program also provided an

opportunity to run a project from

start to finish, from designing the

extraction molecules to testing a

process on several kilograms of

spent fuel. The work has boosted

partitioning chemistry and

actinide chemistry enhancing

excellence within our teams ready

to meet future challenges.

Christine Rostaing,

“Advanced Partitioning” Project Manager

Rive droite Rive Gauche - 2006, May


FUTURE CHALLENGES

Given the decisions needed in 2006, our significant results opened up a range of possibilities

for processing spent fuel in Generation IV reactor-fuel cycle systems that recycle their own

waste. The choice was made to transmute actinides in FBRs 1 , these studies will need to be

continued and adapted, depending on the nature of the actinide compounds selected for

recycling. In Atalante, work is already under way in this area, with

the parallel development of partitioning and multiple actinide

conversion (integrated processing and re-manufacturing concept).

The preparation for the demonstration experiment on key processes


for this concept (access to the fissile compound; multiple actinide

dissolving, extraction and conversion process; forming the fissile

compound and re-manufacturing the fuel element), will use a fuel representative of a GFR 2 .

The research teams will gradually focus their efforts on these new goals, which will also

require developments in the Atalante facility.

Christine Rostaing, “Advanced Partitioning” Project Manager

1. FBR: Fast Breeder Reactor - 2. GFR: Gas-cooled Fast Reactor


© P. Stroppa/CEA

© P. Dumas/CEA

Top: Managing waste drums during

dismantling operations in the UP1 plant

in Marcoule.

Middle: Shielded compartments for

dry processes used to manufacture

(crushing, pressing, sintering and

cladding) fuels for studies, transmutation

targets and confinement matrices.

Bottom: Mock-up for long-term

storage in the ground below the CECER

(Centre of expertise in conditioning and

storage of radioactive material).

99%

This is the proportion of americium and curium

that the selected molecules and the process

developed in ATALANTE can partition out of the

solution sourced from reprocessed spent fuel.

NEW TEAMS FOR ICSM

The Marcoule Institute of Separative

Chemisty (ICSM), a mixed research unit

jointly run by the CNRS (40%), University

of Montpellier 2 (20%) and the CEA

(40%), is planning on an influx of around

a hundred researchers in 2010. In the

short term however, the first of these

newcomers need to be identified – these

will be the first teams to get into the

Institute’s new premises at the entrance

to the Marcoule site.

Non-permanent staff Given staff

turnover, 15 new researchers will be

selected every year. Three tender

processes were run, in September 2004,

June and September 2005. In each

tender, an innovative and realistic

scientific collaboration was proposed,

supervised either by the Montpellier

Chemistry cluster – the Universities of

Montpellier, the Montpellier-based

Grande Ecole ENSCM and CEA-ICSM – or

by another French university or CNRSrun

laboratory.

Permanent staff 50 applications were

received by the close of the 2006

recruitment campaign. 16 candidates

have been interviewed by the

Shortlisting Committee and 12 have been

selected: 3 from the University of

Montpellier 2, 3 from the CNRS and 6

from the CEA (including 3 external

recruits). After 4 campaigns, the staff

team should be complete.

In addition, European collaborations in

the Physical Chemistry of Actinides (with

the Institute for Transuranic Elements,

Karlsruhe) and Sonochemistry (with

Max Planck Institute) are being set up to

enable researchers to work in mixed

ICSM units hosted by foreign

laboratories, from Spring 2007.

These initiatives should all help bring

together the teams and enable them to

be immediately operational when the

ICSM laboratories open in March 2008.

Gilles Richard - Rive droite Rive gauche – 2006, November

The new

law is here

The final text 1 of the bill to succeed the “Bataille

Act” (dating from December 30, 1991) was

approved by the National Assembly on June 15,

2006, following its examination by the Senate.

This report focuses on “Program Law”

no. 2006-739 dated June 28, which is much

larger in scope than its predecessor, since it

pertains “to the sustainable management of

radioactive materials and waste.” In other words

it covers all the CEA’s waste-related activities -

research, management, decommissioning,

facility operation and communication.

The new law lays down the

principle that “sustainable

management of radioactive

materials and waste of any

description (…) is undertaken in

compliance with the protection

of human health, safety and the

environment”, and in Article 3,

stipulates that research and study

related to long-lived high or

intermediate level radioactive

waste is to be performed “in three

complementary areas”, resulting

for the most part from work carried

out at Marcoule over the last fifteen

years or more.

1. Research and study focusing on

partitioning and transmutation

of long-lived radioactive elements

“are to be undertaken in relation

to research carried out into new

generations of nuclear reactors

(…) and accelerator-driven

systems dedicated to waste

transmutation”. The stated goal

is to be have an appraisal of the

“industrial potential of these

processes” by 2012 and to “put a

prototype facility into operation

by December 31, 2020”.

2. With respect to deep geological

disposal, a goal has been set for

researchers and engineers, to

design a reversible repository

>>>

1. The Act was signed by the President of the Republic and 8 Government ministers: the Prime

Ministers and Ministers of the Interior, Defense, Foreign Affairs, Health, Economy, Finance &

Industry, Education & Research and Ecology.



300years

After this period, 90% of radioactive waste returns to a level of radioactivity

comparable with background radiation. This waste is disposed of in existing final

repositories managed by ANDRA.

Studying the

diffusion of

hydrogen

through concrete

in the top of shell

used for the

storage/disposal

of intermediatelevel,

long-lived

waste.

Laser-welding glove-box for

cladding containing pellets of study

fuel, transmutation targets and

confinement matrices.

and to focus on selecting a site.

The operating start date has

been set for 2025, ten years after

filing the permission application,

which will be investigated and

debated in depth.

3. The same date of 2015 (at the

latest) has been set for creating

new storage facilities or adapting

existing facilities, on the basis

of research and study into the


issues, in order to “meet the

needs, particularly in terms

of capacity and duration.”

These three research focuses were

already known, but a calendar has

now been set, and additional

details and provisions laid down:

• the partitioning and transmutation

process is clearly linked to

Generation IV systems,

• deep geological disposal must

be reversible for a duration of

“no less than one hundred years”,

• the role of ANDRA is broadening,

to include, for instance, cleaning

up of radioactive contamination

sites or coordinating research

and study to be carried out (or

commissioned) with respect to

deep geological disposal and

as well as storage,

• three new taxes have been

created, in addition to the

existing tax on Basic Nuclear

Installations: they will be used

to fund economic development

and the roll-out of technology

in the areas surrounding the

selected disposal site, and

research and study into storage

and deep geological disposal.

The sums allocated to this research

and the construction and operation

of the corresponding facilities will

be paid into funds accounted for

separately within ANDRA.

A broader scope

The new law is much broader

in scope than the previous Bataille

Act. In particular, it sets in place

a research and study program,

aimed at commissioning a graphite

and radium-bearing waste disposal

center by 2013, and provide three

“deliverables” by 2008: storage

solutions for tritiated waste (until

the radioactivity has decayed

enough to allow for ground-level

or shallow disposal), finalization

of disposal solutions for used

sealed sources (in existing or new

centers) and a long-term impact

assessment on uranium mine

tailing disposal sites (with a

reinforced radiological monitoring

plan for these sites).

Under the new law, the first ever

national radioactive materials and

waste management plan is to be

put in place by December 31,

2006. This type of plan is to be

drawn up every three years by the

Government, and assessed by the

Parliamentary Office for the

Evaluation of Scientific and

Technological Choices. It will

review the existing management

methods for radioactive materials

and waste, survey the foreseeable

requirements for storage or

disposal facilities, specify their

capacity and duration (in the case

of storage) and establish targets

to be met (with a calendar), for

radioactive waste items that

still have no final management

method. This plan must comply

with three major objectives:

1. reducing the quantity and

danger of the radioactive waste,

in particular by reprocessing

spent fuel and processing and

conditioning radioactive waste;

in this respect, owners of long-

>>>


Interview

PHILIPPE PRADEL

CEA Director of Nuclear Energy

“

Major breakthroughs have

been achieved in nuclear

waste management.

lived Intermediate Level Waste

(ILW) produced before 2015

must have it conditioned by

2030 at the latest,

2. use specially designed facilities

to store radioactive material

awaiting reprocessing and

ultimate radioactive waste

awaiting disposal,

3. use deep geological repositories

to dispose of ultimate radioactive

waste that cannot be disposed

of in ground or shallow

repositories, for nuclear safety

or radiological protection

reasons.

Information,

assessment and

international cooperation

Like the preceding law, the new

one outlaws the disposal of

foreign radioactive waste in

France, but specifies the reason

for this ban. The law provides for

intergovernmental agreements to

be published in the Journal Officiel

(official gazette), specifying a

framework under which foreign

fuels may be reprocessed in

France, and how long the related

waste will remain stored on French

soil. Operators running research

and reprocessing operations

involving foreign radioactive

”

substances will have to draw up

an annual inventory on this issue,

which will be made public, along

with the annual report form the

National Board for Research

Assessment. The board must

include “at least one international

expert” and its report must “review

research carried out abroad”. The

same requirements apply to the

national radioactive materials and

waste management plan. It will

have to summarize research and

projects carried out outside France.

The new law requires wider

communication to the general

public. One body that could be

involved in communication

is the High Commission for

Transparency and Information on

Nuclear Safety, established under

a different law dated June 13,

2006. This new body could

organize “periodical consultations

and debates on the sustainable

management of radioactive

materials and waste.” Likewise, a

National Board, distinct from the

aforementioned research board,

will assess operators' funding of

decommissioning and radioactive

material management expenses.

It will also issue a tri-annual report

to the general public.

Gilles Richard - Rive droite Rive gauche

2006, September



What is your appraisal of

CEA research over these

last fifteen years?

The 1991 law brought

research projects into the

spotlight, some of which

were already underway, and

encouraged domestic and

international cooperation.

I would like to emphasize

the lively exchanges

stemming from the

confrontation of scientific

ideas among various players

in research, industry and

operations. The full range of

possibilities has been

explored with our partners

[ed: in France, chiefly ANDRA

and the CNRS] and major

breakthroughs have been

achieved. We now have a

panel of solutions, which are

actually complementary, and

will feed a calm and

informed public debate. To

give you an example, we

have reduced the volume of

intermediate level

radioactive waste by a factor

of 10. Likewise, having

demonstrated the scientific

feasibility of actinide

partitioning [ed: some of the

most radioactive elements]

and the existing methods for

transmuting them in fast

reactors, there is potential

for further reductions in final

waste in the future.

What might be the

international knock-on

effect of the these

results?

There is now a massive

renewal of interest in

nuclear power, throughout

the world, particularly in Asia

[ed: China and India], linked

to growing energy needs

and the requirement of

limiting CO2 emissions.

France is one of the

technological leaders with its

spent fuel reprocessing &

recycling processes, but also

a leader in institutional

terms, with a coherent

system and multiple,

rigorous, independent

control mechanisms. We are

being watched by the rest of

the world and need to show

that reasonable, sustainable

solutions for nuclear waste

management exist. Japan is

building a plant similar to

Cogema’s La Hague facility

at Rokkasho Mura. The USA

and China are now looking

at our technological options

with interest.

Is there a synergy

between research into

waste management and

research into future

systems?

Yes there is, because

research into the nuclear

systems of the future

involves a goal of

sustainable development,

which implies reducing

releases and waste as much

as possible, and recycling to

maximize resources. That is

why people talk about

“systems” these days, a

term referring both to

reactors and the associated

fuel cycle. Within the

framework of the

Generation IV initiative,

drawing together Euratom

and 10 other countries, four

of the six technological

options selected for the

nuclear systems to be

deployed by 2030 are fast

breeder reactors, which will

enable these sustainable

development goals to be

met. France is heavily

involved in research on this

type of reactor, and

already has wideranging

expertise. ■

Interview with Claire Abou

Les défis du CEA – No. 106

© L. Godart/CEA

SCIENTIFIC HIGHLIGHTS

The dynamics of

THE EARTH’S MAGNETIC FIELD

reproduced in the laboratory

© Collaboration VKS/CEA

Over the geological ages, the Earth has

undergone several erratic reversals of its

magnetic field. The sun’s magnetic field is

reversed regularly every 22 years according to

its cycle. These magnetic dynamics, which are

still shrouded in mystery, play a role in our

planet’s exposure to cosmic rays.

The joint VKS experiment 1 (CEA 2 , CNRS, the Ecole

Normale Supérieure in Lyon 3 and the Ecole Normale

Supérieure in Paris 4 ) has, for the very first time,

observed magnetic field reversals in laboratory

conditions thanks to a highly turbulent flow of

liquid sodium. The experiments should help scientists

to understand more about cosmic magnetic field

reversals. The results are published in Europhysics

Letters, Volume 77, March 2007.

The Earth’s magnetic field is created by highly

disordered movements that churn up the liquid

iron core at the center of the Earth. This is known

as the “dynamo” effect. One of its most astonishing

characteristics, revealed by paleomagnetic research,

is that reversal of the magnetic poles is totally random.

They remain close to the Earth’s geographic poles

and flip between north and south about once every

100,000 years or so, although longer periods have

been found between reversals. On average, these

reversals last a few thousand years.

The cause and timescale of such reversals, together

with the geometry of the magnetic field during a

reversal, remain the subject of much debate.

The consequences may be considerable: during a

reversal, the magnetosphere that protects the Earth

from solar and cosmic radiation is significantly

weakened. Life on Earth, and human life in

particular, has survived this kind of situation in

the past (the last reversal occurred 700,000 years

ago), but a repeat would severely interfere with

our modern communications systems (satellites

and networks, etc.).

The researchers involved in the VKS experiment

have shown that the dynamo effect could be

reproduced in a laboratory experiment, using a

turbulent flow of liquid sodium produced by the

counter-rotation of two impellers inside a cylinder 5 :

with the two impellers rotating at the same speed,

a stationary magnetic field is spontaneously generated

once a certain threshold is exceeded. They have

now observed that when the impellers rotate at

different speeds, thus adding global rotation similar

to that of the planets and stars, the dynamo field

may vary over the course of time. Certain regimes

have uncannily similar characteristics to the behavior

of the Earth’s magnetic field.

The field flips from one state of polarity to its opposite

for irregular time periods, with the transition from

one polarity to the other lasting a very short duration.

- The periods during which the field is stable vary

in length, but always last longer than reversal time.

- Field excursions, periods during which the field

decays and then grows again with no polarity

change, can also be observed.

At other rotation speeds, the magnetic field may

periodically be reversed, rotating in space without

polarities canceling each other out, as is observed

in the case of the sun.

These experiments imply that it will now be possible

to conduct laboratory studies of phenomena that

have intrigued geophysicists and astrophysicists for

centuries.

Magnetic field (in gauss) measured in the experiment

in relation to time (in seconds). The sodium flow

is driven by two turbines with counter-rotating

impellers rotating at different speeds.

Delphine Kaczmarek – 2007, April

1. Von Karman (the physicist after whom the flow was

named). Sodium (the fluid used in these experiments).

2. CEA’s Condensed State Physics Department, Physical

Sciences Division, team headed by François Daviaud.

3. Physics Laboratory at the Ecole Normale Supérieure de

Lyon, (CNRS, ENS Lyon), team headed by Jean-

François Pinton.

4. Statistical Physics Laboratory (ENS Paris, CNRS,

University of Paris VI and Paris VII), team headed by

Stephan Fauve.

5. The VKS experiment took place at CEA/Cadarache, at

the Department of Nuclear Technology in the Nuclear

Energy Division. The results are presented in an article in

Physical Review Letter 98, 044502 (2007).

SOITEC-LETI COMPETENCY CENTER


Soitec, the world leader in silicon-on-insulator technology, is pooling its skills with

those of CEA/LETI* to set up the Nanosmart Center, a world-class center of excellence

in advanced materials for the microelectronics industry. Funded by A21, the French

agency for industrial innovation, the Nanosmart Center will develop new generations

of semiconductor materials for innovative applications, such as high-frequency telecom

components and power components for the automotive and audiovisual industries.

* LETI: Electronics and Information Technology Laboratory.

CEA Technologies No. 83 – November-December 2006


XEDIX: 100 TB OF DATA SCREENED

IN JUST A FEW SECONDS

Using Xedix, the native XML database developed by the CEA, it takes less than

a second to find a document in a 100 Tbyte base. A start-up called Xedix Tera

Solutions is being set up to market this unique product that has potential

applications in a wide range of areas, including multimedia, research,

telecommunications and avionics.

The CEA is producing for its own

requirements an ultra high-performance

information management system called

Xedix, which it is currently testing on a

100 TB database.

A world first. “The archives of the Institut

National de l'Audiovisuel (French National

Audiovisual Institute) only represent 85 to

90 TB of data,” comments Didier Courtaud.

“If we were to store all the events of a person's

life on a single electronic storage medium,

it would take up about 100 GB, in other words,

a thousand times less than the total storage

capacity of Xedix.” The tests are performed

using standard test cases made up of several

types of realistic data. They are expected

to confirm the good results from earlier

tests carried out in 2003 on one TB and

in 2005 on ten TB. “We think we'll be able

to obtain response times of less than a second

for most queries.”

An outstanding information storage and

indexing system is the key to this

performance. The system stores and

indexes all data in XML (Extended Markup

Language), a descriptive language that

is totally independent of desktop software

programs and their constant stream of

upgrades. Image or video files are stored

in the base and listed in XML as metadata

describing the subject, shooting date,

characters or any other information selected

by the database administrator.

What's more, the data indexing system is

smart. “Unlike conventional search engines,

Xedix identifies the tag in which the required

character string(s) is(are) located. This means

that the query can be made clearer by adding

as many criteria as necessary.” Queries can

be carried out using a conventional browser

or a customized interface developed in

the language of the user's choice (Java,

PHP, etc.). The tool has already been

validated on other applications during

collaborative work carried out in the

System@tic competitiveness cluster. A

start-up called Xedix Tera Solutions is

being set up to market it.

With a product like this, the future looks

bright for the budding firm. There are

clear signs of interest from many

sectors including archiving services and

multimedia libraries, the research

community (European projects, joint

research-industry projects) and the world

of scientific and technical information.

Xedix Tera Solutions also hopes to arouse

the interest of other sectors such as largescale

scientific instrument companies (that

generate vast amounts of data),

telecommunications, and industries that

produce great quantities of documentation,

like the automotive and pharmaceutical

industries.

CEA Technologies No. 85 – April 2007

© F. Rhodes/CEA

© Artechnique/CEA

REMOTE

RECHARGE

FOR YOUR

BATTERIES

The mini-battery developed by CEA-LITEN 1

research teams could make a great difference

in the lives of people with certain disabilities.

The remotely rechargeable battery, which

can be fitted inside the human body with

a number of other stand-alone devices, opens

the door to a new generation of medical

appliances, including muscle stimulators

for paralyzed hands or for hearing implants.

The long-familiar lithium battery used in

pacemakers is capable of supplying electrical

power over a period of many years.

However, as it cannot be recharged and its

lifetime is limited by its size, it can only be

used to power devices with very low energy

consumption. “Which brings us to the

rechargeable, lithium-ion mini-battery we have

developed as part of the European Healthy Aims

project, in association with our industrial partner,

Saft. The battery meets the specifications of

implant manufacturers like Cochlear Ltd. and

Finetech Medical,” explains Séverine

Jouanneau, a researcher at CEA-LITEN.

“Lightweight (2 g) and compact (1 cm 3 ), the

battery is only 5 mm thick, yet provides

maximum energy (50 mAh) and can be

recharged daily.” Recharging can be carried

out by induction through the skin during

the night using a device placed at the patient's

bedside. Another advantage is service life –

the battery can work for more than ten years

at a temperature of 37°C.

Vahé Ter Minassian - Les Défis du CEA No. 122 – March 2007

1. LITEN: Laboratory for Innovation in New Energy

Technologies and Nanomaterials



The HESS observatory team awarded the European

Descartes prize for its progress in

VERY HIGH-ENERGY GAMMA ASTRONOMY

© ESO/ANTO/UT1

On March 7, 2007, the French-German very

high-energy gamma ray observatory received

the 2006 Descartes prize. Since the year 2000,

this prize has been awarded annually to scientific

teams for their transnational research results.

It was awarded to the HESS team in recognition

of the quality of results concerning the “nonthermal

universe” or “violent universe” that

opened up a new field of astronomy. The HESS

observatory's results have been hailed as a world

first in gamma astronomy.

The observatory was mainly built by French

and German laboratories, later joined by teams

from other European and southern African

countries. In France, it brings together CNRS

(IN2P3 and INSU) 1 and CEA (DAPNIA 2 )

laboratories.

HESS (High Energy Stereoscopic System) is

the name given to four telescopes installed

on the Gamsberg plateau in Namibia. HESS is

primarily dedicated to observing the southern

skies that give access to most of the Milky Way.

HESS provides precious information about

some of the Universe’s most violent phenomena

by detecting very high-energy gamma rays,

using the light flashes they produce as they

interact with the Earth's

atmosphere (“Cherenkov

effect”). The HESS

experiment will soon be

enhanced by the installation

of a very large telescope - 28

meters in diameter - at the

center of the existing array

of four instruments. This new

phase of the experiment will

not only enhance sensitivity

but also overlap with the

energy range covered by

NASA's gamma astronomy

satellite, GLAST, which should

be launched in 2007. The

project, called Cherenkov

> GAMMA RAYS: Like visible light

or X-rays, gamma radiation is

made up of photons, but at much

higher energy levels. Visible light

has an energy of around one

electron volt (1 eV). X-rays are in

the range of one thousand to one

million eV. HESS detects very

high-energy gamma rays that can

reach a million million eV (or

1 tera-electron volt (1 TeV)).

There are few of these very highenergy

gamma rays. Even for a

relatively intense astrophysics

source, the flow of gamma

photons entering the atmosphere

is around one per month per

square meter.

Telescope Array or CTA, will increase sensitivity

tenfold and considerably add to available

information sources.

Delphine Kaczmarek – 2007, March

1. LLR École polytechnique (IN2P3/CNRS), LPNHE of the

Universités Paris VI and VII (IN2P3/CNRS), APC

(IN2P3/CNRS/Université Paris 7/CEA), LPTA Université

de Montpellier 2 (IN2P3/CNRS), LAPP Annecy le Vieux

(IN2P3/CNRS), CESR Toulouse (INSU/CNRS), LAOG

Grenoble (INSU/CNRS), LUTH Observatoire de Paris-

Meudon (INSU/CNRS).

2. DAPNIA, Research laboratory dedicated to the

fundamental laws of the Universe in the Physical Sciences

Division.

ATLAS, ACCELERATING DETECTION

The superconducting toroidal magnet of the Atlas experiment

has just been started up at the LHC facility 1 .

A 21,000 A current was injected into the eight coils of the

magnet to produce its magnetic field 2 . CEA-DAPNIA scientists,

who have been closely involved in the design and construction

of Atlas, took this opportunity to check all the magnet operating

parameters and performed a successful test on its muon

spectrometer. This instrument has already detected cosmic

muon tracks bent under the influence of the magnetic field.

These results are very encouraging for the research teams, who

are now waiting for the LHC – the world's largest proton collider

– to be commissioned at the end of the year, when they will

be able to record and analyze the first collision data, and answer

a number of basic questions in particle physics – such as “does

the Higgs boson exist?”.

1. Large Hadron Collider,

installed in a tunnel with a

circumference of 27 km,

built 100 m below the

ground at the CERN in

Geneva.

2. The Atlas magnet stores

1.1 GJ of magnetic energy,

enough to lift the Eiffel

Tower about ten meters off

the ground.

Aude Ganier – Les Défis du CEA n° 121 – February 2007

© Cern


FIRST COMPLETE SIMULATION OF

PET IMAGING SCAN

OF THE WHOLE HUMAN BODY

Interpreting data from positron emission tomography (PET) - medical

imaging scanning increasingly used in hospitals - is still a complex

task. With a view to optimizing its analysis and extracting the most

relevant physiological information, researchers are working on computer

simulation programs to enhance PET techniques. The programs are

currently held back by computing time limitations.

This problem spurred CEA-SHFJ 1 (Service

hospitalier Frédéric Joliot in Orsay near Paris) to

set up the GATE 2 simulation platform, which

models PET scans using the Tera 10 supercomputer

located at the CEA's DAM-Ile-de-France 3 centre

in Bruyères-le-Châtel near Paris. The ensuing

simulation made it possible to reproduce - in an

entirely realistic manner and in a very short time

- the distribution of a tracer used in PET for

diagnosing cancer. This first simulation result

means that, in the medium term, a more precise

use of data provided by the images can be envisaged

as well as personalized scans for patients.

These simulations are carried out using the

Monte-Carlo method, based on probability

theories. The analysis is hindered, however, by

the limitations of digital processing: for a standard

PET scan of the whole human body, a Monte-

Carlo simulation must process the emission of

several billion positrons and gamma photons,

which is the equivalent of 10,000 computing

hours, or 400 days of analysis on a standard PC.

To reduce this computing time, researchers

conducted a simulation on

the Tera 10 supercomputer.

After modeling the

patient's body, using data

from an actual scan,

researchers simulated the

injection of a tracer by

selecting a realistic activity of 264 megabecquerels

(MBq) and an acquisition time similar to that

required for a standard PET scan. This initial

simulation required less than three hours'

computing time using 7,000 processors. The

subsequent comparison of the actual scan and

its simulation showed almost identical tracer

distribution. From a quantitative point of view,

comparisons of the volume of a tumor located

under the patient’s left axilla indicated a difference

of 6%, which is considered very low for an initial

simulation. This result represents a first decisive

step towards the development of methods that

could be used to correct actual data from PET

scans and, in the long term, target the creation

of a patient specification for PET acquisition


See the comparison of images

obtained below:

• Left: PET image of an actual

‘whole body’ scan

• Right: the result obtained through

simulation on Tera 10

protocols and analysis. It also shows the benefits

of intensive computing in the life science field.

Stéphane Laveissière – 2007, April

1. The SHFJ is one of the 4 research platforms of the

French Institute for BioMedical Imaging (CEA-I 2 BM).

The others are NeuroSpin (Saclay), MIRCen

(Fontenay-aux-Roses) and C-INAPS (Caen).

2. GATE: Geant4 Application for Tomographic Emission

– Geant4 is an international simulation program

developed at CERN (Switzerland).

3. DAM: Military Applications Division.


THE PIANIST'S FLOWING TOUCH

Music lovers everywhere expect a digital piano to

provide a perfect reproduction of the touch offered

by a grand piano. But high-fidelity reproduction calls

for perfect control of parameters such as the mechanism's

resolution and bandwidth. CEA/LIST* took up this

challenge by joining forces with the Ecole Polytechnique's

Solid Mechanics Laboratory to develop a new sensory

interface technology based on the use of magnetorheological

or MR fluids. These fluids, made up of

microscopic metal particles suspended in a liquid

solvent, change viscosity under the influence of a

magnetic field.

The degree of change is proportional to the intensity

of the applied field, making it possible to simulate

the “perfect” touch, using a real-time control system

and a dynamic model of traditional keys. The

demonstrator developed by CEA/LIST has not only

lived up to expectations. It also offers something extra

– low cost! This makes it compatible with industrial

production of keyboards integrating the new keys.

Other potential applications include sensory interfaces

and the design of new types of brakes and active dampers

for motor vehicles.

Sylvie Guigon – Atouts Bio Nr 4 – 2007, March

* LIST : Laboratory for Integration of Systems and Technologies.

> RHEOLOGY: Branch of mechanics

concerned with the study of flows

in liquids and related deformation

phenomena.



© CEA/Inserm-GBF

ANTICANCER DRUGS TACKLE

SCHIZOPHRENIA

Since they created the first “model” schizophrenic

mouse in 2002, pharmacologists from the

CEA and INSERM have been making one

discovery after another, the reward! The

reward being an alternative to existing

schizophrenia therapies. They observed an

improvement in the animal's behavior after

administering the epithilone D molecule,

an anticancer drug. In their efforts to find a

remedy, they focused on neurons rather than

the neurotransmitters involved in the disease

and currently treated by antipsychotic drugs.

In 2002, researchers found a link between

schizophrenia and cell microtubules for

the first time ever. They observed behavior

disorders in the animal if they deactivated

Compared with those of the expression of a protein

a normal mouse (A), the

microtubules (shown in involved in microtubule

green) of the neurons of a function. These disorders

schizophrenic mouse are were reflected in a lack of

not stable (B) at 4 °C,

social interaction or maternal

except when epothilone D

is present (C).

feeling, hyperlocomotion or

spatial memory problems.

In order to treat this schizophrenia, they turned

to molecules used in cancer treatment that

are capable of stabilizing microtubules. They

opted for epothilone D, one of the few

molecules that can penetrate the brain.

Administered at very low doses to prevent its

blocking action on cells (a trait common to

all anticancer drugs), it proved highly effective

in restoring synaptic functions with no adverse

side effects. This molecule has now been

patented and will soon be studied in humans.

Aude Ganier - Les Défis du CEA No. 122 – March 2007

> NEUROTRANSMITTERS:

Molecules that transmit information

from one neuron to another during

connections known as synapses.

> MICROTUBULES: Fibers along which

various components are routed from

one point of the neuron to another.

A CLIMATIC UPHEAVAL

BROUGHT TO LIGHT

Between ten and three million years ago,

the tropical rain forests of East Africa

gradually gave way to savannah. What

brought about such a radical change

in the environment? Until recently,

paleoclimatologists thought the cause was

twofold: a drop in the CO2 level in the air

and cooler surface water in the Indian

Ocean. Today, a French team 1 , including

researchers from LSCE (Laboratory of

Climate and Environmental Sciences), a

joint CEA/CNRS/UVSQ laboratory 2 , has

discovered a third factor explaining this

change 3 : the upthrust of the East African

Rift System.

This extraordinary geological structure

saw a renewal in its activity 12 million

years ago. In response to tectonic activity,

the Earth's crust was raised before

collapsing in the center to create a

6,000 km long valley, bordered by hills,

plateaus and mountains ranging from

2,000 m to 5,000 m in height. A

phenomenon on such a scale as this must

have had an impact on the climate but

this impact on the climate, but had never

been quantified.

Turning the problem round

LSCE climatologists therefore teamed up

with paleontologists and geologists 4 to

simulate the possible impact of the

emergence of the East African Rift. “In fact,

we turned the problem round,” says Pierre

Sepulchre, a member of the LSCE climate

modeling team. “We asked ourselves what

would happen if the Rift didn't exist? We used

the climate model developed by the Dynamic

Meteorology Laboratory to perform two digital

simulations. The first considered geological

structures only 2,000 m high and the second

at areas with no relief.”

The result left no room for doubt: the

flatter the region, the higher the

precipitation. Compared with today's

figures, the average annual rainfall rose

by 15%for the first simulation and by 40%

for the second, “The lack of relief allows the

Indian monsoon to progress farther into the

continent in winter and causes a moistureladen

zonal flow between southern Sudan

and Ethiopia in summer,” explains Pierre

“

Transport of

moisture from east

to west or vice

versa depending

on the latitude

and season.

”

The emergency of the Rift contributed significantly

to the desiccation of East Africa, as can be seen in

these simulations of changes in moisture transport.

Sepulchre. This humidity results in heavy

rainfall that favors the development of

forests, as illustrated by vegetation models

based on climatic simulation. This goes

to show that the emergence of the East

African Rift really is a key factor in the

desiccation observed in East Africa during

this period.

Fabrice Demarthon

Les Défis du CEA No. 121 – February 2007

1. Paris Earth Physics Institute, European Institute

of the Sea in Brest, Human Paleontology

Laboratory of the University of Poitiers, LSCE.

2. University of Versailles-Saint-Quentin.

3. Science, vol. 313, 08.11.06, P. Sepulchre et al.;

research funded by the CNRS Eclipse

multidisciplinary program.

4. From the University of Poitiers, the Paris Earth

Physics Institute and the European Institute of

the Sea.



SUPERDOPED SILICON:

AN EXCELLENT CONDUCTOR

Superconducting silicon capable of conducting

electricity without the slightest resistance?

Microelectronics specialists would think it quite

a paradox!

Because that's exactly the material they use for its intrinsic

semiconducting powers to control the intensity and

direction of electric current. Yet a CNRS 1 /CEA 2 /University 3

collaboration has come up with these results using silicon

that has undergone chemical treatment at ambient pressure.

As its superconductivity is only apparent at very low

temperatures (- 272.8 °C) 4 , its use should be restricted

to fundamental research laboratories, for testing theories

on nanostructure superconductivity, for example.

This result is still quite a performance!

“In the 1980s, researchers managed to make silicon a

superconducting material by subjecting it to tremendous

compression, but its crystalline structure was changed in

the process,” recalls CEA researcher Christophe Marcenat.

So he and his colleagues opted for a chemical process in

which silicon was “doped” through the gradual addition

of boron, gradually increasing its conducting power.

Until then, this process had always come up against the

inability of silicon to absorb large amounts of boron. “To

get round this problem, we used laser pulses to heat a silicon

film in an atmosphere of gas containing boron,” explains

Etienne Busterrret, a CNRS researcher. “These pulses also

force boron atoms inside the molten material where they

bind during recrystallization.” So superconductive doped

silicon isn't such a paradox after all!

Claire Abou - Les Défis du CEA No. 121 – February 2007

Adjusting the laser beam used to obtain silicon samples with more boron doping than that obtained through the

usual silicon microelectronics methods.

> SEMICONDUCTIVITY:

Intermediate electrical

conductivity between

that of metals and

insulators.

1. Laboratory for the Study of the Electronic Properties of Solids,

Grenoble.

2. Condensed Matter Fundamental Research Department, Grenoble.

3. Condensed Matter and Nanostructure Physics Laboratory, University

of Lyon 1 and CNRS; Basic Electronics Institute, University of Paris-

Sud and CNRS.

4. Today's superconducting materials operate within the –273 °C to

–140°C temperature range.

© J. Boulmer/CNRS

200 MM MICROSYSTEMS LINE SEEKS DEVELOPMENT PROJECTS

CEA/LETI has invested in a 200 mm R&D line

dedicated to industrial partnerships in the microsystems

field for development, prototyping and preproduction.

It’s the ideal solution for creating new products faster

and at lower cost without investing too soon.

1,000 square meters of clean rooms, specific equipment

worth €20 million available 24/7, teams of researchers

and technicians boasting 20 years of experience in

microsystems. That, in a nutshell, is what LETI is offering

industrial firms in Grenoble wishing to develop

components on 200 mm silicon wafers. “The microsystems

industry is still very customized,” observes Bruno Mourey,

in charge of the project at LETI. Everyone creates their own line (above-

IC or stand-alone) for niche markets at the cost of heavy investment

and long development times.“The aim, therefore, is to use LETI resources

and expertise to work faster and at a lower cost.”

The solution is based on the 200 mm format, which is not only tomorrow's

microsystems standard, but also and above all, the current standard on

a vast number of microelectronic production lines.

Collaboration projects lasting two to four years will be proposed to


people in industry. This is the time it takes to develop

lines (or set of processes), build prototypes, carry out

preproduction runs and, if the partners wish, transfer

the technology to their own production site. The platform

is intended for two types of partners. First, silicon

founders seeking new markets for their 200 mm facilities.

Second, manufacturers or end users, who see the

microsystem as an opportunity for differentiation and

innovation and who need development work to be

treated confidentially.

In all, LETI plans on working with six to ten companies

keen to invest in mass markets in various sectors, such

as mobile telephony, consumer products, motor vehicles

or industrial electronics. It will operate the equipment alone to ensure

that there are no “leaks” between projects and will allow each partner

access to its line. It is the only line dedicated to 200 mm microsystems

in Europe. Platform users will also have access to LETI's microelectronics

R&D resources as well as its other areas of expertise – characterization,

design, testing and materials – grouped together at the Minatec cluster.

CEA Technologies No. 83 – December 2006



Annual Report

CEA 2006

(french or english

version)

ARC-NUCLEART IN THE

LAND OF THE MAYAS

For the first time since the Atelier de Restauration (Restoration Workshop)

was created in 1970, the Nucleart Method – resin impregnation and gamma

irradiation – has been used abroad.

“This Maya sculpture, discovered on the site

of Becan in Yucatan, is a unique

archeological object. It has also been

declared a national treasure,

so there was no question of it

leaving the country,”

explains Alejandra Alonso,

a restoration specialist at

the INAH, the Mexican

National Institute of

Anthropology and

History. The Nucleart

Method, developed at

the CEA center in

Grenoble, was chosen

for the renovation work.

“It seemed the most effective

way of halting any further

damage to this statuette, a dwarf only 20 cm

tall, whose body had suffered considerable

deterioration, with the wood flaking away

at the slightest touch.” It was therefore decided

that the first week of the mission 1 would

be given over to treatment, with the second

week set aside for three conferences on

preservation and restoration processes for

dry and waterlogged wooden objects.

The Mayan statuette was first impregnated

with liquid styrene-polyester resin. It was

then packed in a special container and

taken under police escort to the industrial

irradiator located at the heart of the National

Institute for Nuclear Investigation, 40 km

outside Mexico City. This gamma irradiator

induces radioactive polymerization which

hardens the resin in the wood. Khôi Tran,

an ARC-Nucleart chemical engineer, is

working on something of a special agent's

mission. “Alejandra Alonso Olvera called me

at the beginning of 2006, asking me to come

to Mexico City to restore a dry, wooden sculpture

from the Maya period. This had first been

Restoration at work

mentioned back in 2002.” Although

the INAH is a major preservation

and restoration center employing

some one hundred people,

including forty restorers, it has quite

modest technical resources.

The next thing to do was to prepare the

mission. Using Khôi Tran's diagrams and

photos, Alejandra was able to have

alterations made to a 40 l

pressure cooker made

in America. Other

adjustments had to be

made to the vacuum

pump, pressure gauges,

nitrogen cylinder, tubes

and fittings, irradiation

parameters, resin formulation – even the

power supply voltage (110 V in Mexico).

“But even after six months of preparation,

there were always surprises in store, like

the purple color of the impregnating resin.”

The irradiation treatment lasted 48 hours.

The consolidation of the sculpture was

satisfactory and the polychrome resisted

well, thereby minimizing the risk

of damage during exhibitions. “We

demonstrated that Nucleart technology can

be transferred, especially to emerging

countries,” stresses Khôi Tran. The process

is of particular interest in tropical

countries, where objects densified by

Nucleart will put up better resistance to

extreme variations in climate. For the

past year, Vietnamese archeologists have

called on ARC-Nucleart to preserve

waterlogged, wooden, archeological

objects on site.

Marc Jary – Le mensuel de Grenoble – October 2006

1. The mission is fully funded by the Mexican

authorities.

Organized every year by the CEA and the Association of French Mayors, the “Save the

Heritage” competition offers the five award-winning towns the chance to have their

works of art treated and restored by the ARC-Nucleart Laboratory at the CEA center

in Grenoble.

Les Défis du CEA No. 122 - March 2007

© DR

France-China Symposium

on Nuclear Energy

Regulations, Codes,

Standards and Qualification

Rostrum during the Vice-Minister's speech. From left to

right: the Vice-Minister, Cyril Pinel of the ASN, the French

Ambassador to China, the Chief Executive Officer of the Chinese

nuclear safety authority.

The CEA and the Chinese Safety Authority held

the first “France-China Symposium on Nuclear

Energy Regulations, Codes, Standards and

Qualification” in Beijing on June 4-6, 2007.

China has recently decided to speed up the

development of its nuclear program (10 reactors

in service and 17 at various stages of testing,

construction and licensing); a number of players

will be involved: government authorities and

regulators, utilities, design institutes and industry.

France has completed a highly successful program.

One of the keys to success is the implementation

of a comprehensive set of regulations, codes and

standards addressing such subjects as supplier

qualification, equipment certification, on-site

inspection, etc.

The symposium provided an opportunity to

compare current French and Chinese regulations

and allowed government agencies, utilities, design

institutes and people from industry to share their

experience.

Some 300 people took part (including more than

200 Chinese). There were contributions from various

representatives of French industry and the IRSN

and some Chinese institutes. The Symposium was

chaired by Mr. LI Ganjie – Vice-Minister of SEPA,

Administrator of NNSA and Mr. André-Claude

Lacoste – President of the ASN.

Using hydrogen to produce

energy – a traveling exhibition

The depletion of petroleum resources is forcing us

to consider other options, especially renewable

energy sources. Among the possibilities, hydrogen

offers numerous advantages. It can be easily



G8 Global Partnership

Activity report

2004-2005-2006

(french and english version.

Russian version available on

line http://www-pmg8.cea.fr)

> These brochures are

available upon

request in paper

format or on line :

www.cea.fr

EXHIBITIONS


produced from any primary energy source (solar,

wind, nuclear, etc.) and used in a “fuel cell” to

generate high yields of electricity and heat, with

water as its only waste product!

To raise awareness about this important technology,

the Palais de la Découverte, a science museum in

Paris, has created a traveling exhibition (first stop

in Berlin at the Technikmuseum, from May 24 th

to July 24 th , 2007, then on to the Visiatome before

the end of the year). The exhibition covers all the

steps studied at the CEA: production of electricity

using photovoltaic panels, production of hydrogen

by electrolysis, storage and retrieval of electrical

energy using fuel cells. To illustrate how the

research works, the exhibition uses prototypes

and laboratory equipment, including the Genepac

fuel cell, metal plates, graphite plates and

membranes, along with an educational pack about

fuel cells.

As part of its renovation project, the Palais de la

Découverte will present a stationary version of

this exhibition in Paris.

ICAPP 2007

International Congress on Advances in Nuclear Power

Plants - “Nuclear Renaissance at Work.” - May 13-

18, 2007 • Nice Acropolis, France

The CEA participated in the 2007 ICAPP

international conference on progress in nuclear

power plants, covering design, construction,

operation, and maintenance. This professional

gathering brought together the most important

international stakeholders in the electronuclear

industry around the theme of “nuclear renaissance”.

It was an occasion for the Nuclear Energy Division

of the CEA to present its research and development

milestones in several areas and to co-chair the

plenary session dedicated to nuclear systems of

the future. The papers presented by the CEA

addressed the following areas:

• Research to optimize existing industrial nuclear

facilities and development of third-generation

systems (optimization of fuels and plant life

spans, better procedures for spent fuel processing,

advanced methods of computer simulation, etc.)

• The CEA's commitment to the nuclear systems

of the future (strategy and planning for sodiumcooled

fast reactors, materials and fuel

innovations, and new options for the back end

of the fuel cycle and waste management)

Finally, this conference allowed several major

nuclear actors abroad (USA, Japan, Russia, China,

South Korea, etc.) to share their vision of the

nuclear renaissance.

Following the conference, the participants toured the

CEA's Marcoule and Cadarache centers.They visited

certain advanced facilities for nuclear research, such

as Atalante, a large laboratory dedicated to actinide

chemistry, and Tore Supra, a tokamak for fusion

energy studies.

The 20 th World Energy

Congress & Exhibition

is promoted by the World

Energy Council (WEC*)

This is the most authoritative international energy

meeting, to be held in Rome in the new “Nuova

Fiera” venue, November 11-15, 2007. Excellent

speakers and thousands of participants will come

from all over the world. Besides the World Energy

Council Members, the Congress will welcome

exhibitors from both energy producing and

consuming countries, institutions, international

organizations and energy industry representatives,

researchers and experts from all over the world,

and all those who are interested in energy and

development issues. During the four-day meeting,

participants will have the chance to visit an

interesting and important exhibition covering

20,000 m 2 at the “Nuova Fiera”. Companies

will have a great opportunity to present their

products and technological innovations for the

energy industry to an international and

distinguished audience.

*With several Member Committees in over 90 countries, WEC

aims to monitor the status of the energy industry and find

solutions fostering the economic development of both industrialized

and developing countries. It also promotes the sustainable supply

and usage of energy for the greatest benefit of all people.


Transducers 07

TRANSDUCERS has grown into the largest

multidisciplinary conference on microsensors,

microactuators, and microsystems, with typically

900 attendees from government and industry who

gather every two years to share information on

the latest advances in the field. This year, the

technical program consisted of parallel oral sessions

and poster presentations. Invited speakers

(including researchers from LETI, the CEA

laboratory of electronics and information

technology) gave insightful

overviews on key topics

during the plenary session

and throughout the

conference, which also

included short courses and

exhibitions.

TRANSDUCERS 07 was

held in Lyon, France,

2007, June 10-14

Visiatome

The Visiatome is located in Southern France in

Marcoule, not far from Nîmes. This scientific

cultural center was created to inform the public

and answer questions related to radioactivity and

its applications, the various sources of energy,

radioactive waste management, and the nuclear

industry in general.

The 600-m 2 site offers fun, interactive exhibitions

addressing all these questions. Educational sessions

are available to school groups, and scientific

activities are offered Wednesday afternoons,

Sundays, and during school vacations.

> Practical info

Visiatome - CEA Marcoule - BP 64172

30207 Bagnols-sur-Cèze cedex

www.visiatome.fr

To learn more: Tel: +33 (0)4 66 39 78 78

contact.info@visiatome.com

Reservations: Tel: +33 (0)4 66 39 78 78

Fax: +33 (0)4 66 39 78 30

reservation@visiatome.com
