GL 205 / 215

FOR SEMI AUTOMATIC WRAPPING
STRETCH WRAPPER GL 205 / 215

Stretch Wrapper GL 205 / 215
Overview and dimensions
Air supply not needed
Option Top plate
Cyklop’s patented
with adjustable prestretch system up to 210%
Cyklop’s patented
with adjustable prestretch system up to 300%
GL 205 equipped with the option access ramp and GL 215 with both access ramp and top plate.
Dim (mm) A B C D E F G H I J K L
Standard 2670 1675 1020 2200 50 750 60 700 2670 550 1100 900
Option 2995 2000 1020 2600 50 750 60 700 3070 550 1100 1500
Weight, standard: 500 kg (Weight can vary depending on options). Crated dimensions: L2900 x H1050 x W1800 mm, weight: 650 kg.

Stretch Wrapper GL 205 / 215
Specification
GL 205 GL 215
Machine Table diam Ø1675 mm
Table speed
Up to 12 r.p.m adjustable
Soft start / stop
Electronically run
Bottom/top wrappings 1–3 1–6
Film carriage speed
Variable film overlapping top and bottom
Pre-stretch system
Pre-stretch ratio on
the Ecostretch unit
Stretch wrapping programs
Controller
Power Supply
Loading
Protection
Pallet Goods Max size (length x width)
Max. goods height incl. pallet:
Permitted load weight:
Stretch Film Core diameter
Outer diameter, max
Film width, max
Film thickness
Operating temperature:
C-mark (EN 60204)
GL 205: 1, 25, 45, 65, 90, 135, 170 or 210 % adjustable
GL 215: 30, 60, 80, 110, 145, 200, 250 or 300 % adjustable
4 standard, 2 options
Siemens PLC
3-phase 400 V+N+PE, 50 Hz
10 A
IP54
1200 x 1200 mm
2200 mm (standard machine)
Up to 1500 Kg
76 mm
250 mm
500 mm
15-35 my
5°C (40°F) to 35°C (95°F) for use in a dry, tempered area.
Selected options
Turntable diam Ø2000 mm,
for load up to 2000 kg
Extended mast (load height 2600 mm)
Access ramp
Top film cassette
1-phase 220V
Low temperature
Extra corrosion protection
GL 215 with option Tandem
GL 215 with option HS (Horse shoe turntable.)
GL 215 with option driven conveyor

Stretch Wrapper GL 205 / 215
Wraps 15-50 loads per day. Wraps irregular shaped loads. Uses forktruck/palletjack to load stretch wrapper. Operator
starts wrap cycle at machine. Operator manually cuts/attaches film.
The versatile Cyklop wrapper for a wide range of applications.The differences in the degree of automation of the
machines have been laid down based on many years of experience. Together with the equipment options and the many
possible settings they offer optimum adaptation to any requirements and thus provide the new stretch wrapper series
with a high level of cost-effectiveness.
These properties guarantee not only good load securement but also minimum material costs, i.e. low film consumption.
As opposed to the GL 205, with the GL 215 you have the possibility to regulate the application of tension (force of
applying the film to the product).
Easy to operate
The control system is easy to understand and
user-friendly.
Foldable mast and fork lifttruck voids are fitted
for easy in-transport and good mobility.
Film roll change fast and simple.
Automatic load height sensor.
Air supply not needed
Saves money
Pre-stretch ratio is adjustable up to 300%. Patent
approved system,
The chosen prestretch ratio stays constant, which
guarantees a consistent low film, consumption,
load after load.
Film carriage speed is individually adjustable to
minimize film overlap.
Motorized prestretch device (GL215) minimizes
film consumption and protects delicate goods.
Consistent packaging result
Flexible setting possibilities enable optimum
packaging for a variety of goods.
The film tension is automatically set which gives
an even cover around the goods.
Several standard programs are available, e g
with top sheet for protection against water.
4 programs are factory preset.
Key features:
Easy change of all program
parameters and settings.
Subject to Modification. Protectory notice persuant to ISO 16016 to be observed. © Copyright Cyklop GmbH, Cologne, Cyklop Teknik AB - PBE
961015EN - 2012
