<strong>Wolsey</strong> <strong>Product</strong> <strong>Range</strong>
F-Connector Aerial <strong>Range</strong><br />
• Strong, Rugged Construction<br />
• F-Connector Dipole Housing<br />
• Excellent F/B ratio and performance<br />
across the whole UHF band<br />
DG8<br />
QR10 RANGE<br />
QR12<br />
DG8 WF QR10 AF QR10 BF QR10 WF QR12 WF HG5 WF HG10 WF<br />
PART NO. (Boxed)<br />
PART NO. (Scan)<br />
GROUP<br />
ELEMENTS<br />
GAIN<br />
FRONT/BACK<br />
BEAMWIDTH<br />
WINDLOAD(N)<br />
WEIGHT (KG)<br />
SIZE (MM)<br />
BENCHMARK<br />
F CONNECTOR<br />
SCANTAINER<br />
108190 - - 108184 108155 108157 108158<br />
108191 108180 108181 108183 108156 108165 108166<br />
W A B W W W W<br />
8 10 10 10 12 32 52<br />
11 dBi 12 dBi 12 dBi 12 dBi 14 dBi 10-12 dBi 13-15 dBi<br />
>21dB >21dB >21dB >21dB >20-26dB 22dB 24dB<br />
±23° ±21° ±21° ±21° ±18° 32°H 35°V 32°H 35°V<br />
58 58 58 58 - 60 96<br />
0.51 1.00 0.98 0.98 1.25 1.45 1.63<br />
718x340 1173x420 997x420 997x420 1010x555 720x610 1220x610<br />
- Std 2 Std 2 Std 3 Std 3 Std 2 Std 2<br />
Yes Yes Yes Yes Yes Yes Yes<br />
200 50 120 120 75 60 50
HG Aerial <strong>Range</strong><br />
NEW TOOL FREE ASSEMBLY<br />
HG10 WF<br />
QUICK LOCK<br />
DIPOLE<br />
QUICK LOCK<br />
REFLECTOR<br />
HG5 WF
IR Pass Amplifiers<br />
• Distributes to multiple TV’s around the home<br />
• Allows control of Sky Digital receivers when<br />
used with <strong>Triax</strong> Digital Links<br />
• 4,6,8,12 and 16 way versions<br />
• Short circuit protection on each output<br />
• Power on LED<br />
• Screened housing<br />
• F Connectors<br />
• Easy to mount fixings<br />
• Mains powered<br />
• Boxed<br />
Part No. 334057 334054 334055 334064 334065<br />
<strong>Product</strong> F Conn F Conn F Conn F Conn F Conn<br />
No. Inputs 2<br />
No. Outputs 4 6 8 12 16<br />
Input Frequency <strong>Range</strong> (MHz)<br />
• VHF<br />
• UHF<br />
* EN 50083-3, 3 Tone Test at -60dB Interference.<br />
85-230<br />
470-862<br />
Output Frequency <strong>Range</strong> (MHz) 85-862<br />
Return Path Frequency <strong>Range</strong> (MHz) 5-30<br />
Forward Gain Typ. (dB)<br />
Return Path Gain (dB)<br />
10dB±2dB<br />
2.5dB<br />
Noise (dB)
Distribution Amplifiers<br />
• Allows distribution to multiple TV’s<br />
around the home<br />
• 1,2,4,6,8,12 + 16 way versions<br />
• F Connectors<br />
• Power on LED<br />
• Easy to mount fixings<br />
• Mains powered<br />
• Boxed<br />
Part No. 334031 334032 334034 334036 334038 334045 334046<br />
<strong>Product</strong> 1-Way 2-Way 4-Way 6 Way 8 Way 12-Way 16-Way<br />
No. Inputs 1 1 2 2 2 2 2<br />
No. Outputs 1 2 4 6 8 12 16<br />
Input Frequency <strong>Range</strong> (MHz)<br />
• Wideband<br />
• VHF<br />
• UHF<br />
85-862<br />
-<br />
-<br />
85-862<br />
-<br />
-<br />
Output Frequency <strong>Range</strong> (MHz) 85-862<br />
Gain Control (dB) 0-10<br />
Noise (dB)
Launch Amplifiers<br />
• <strong>Range</strong> of Multiband Amplifiers<br />
• Switchable Gain on Amethyst<br />
• Variable Gain Control 0-20dB on All Inputs<br />
• Switchable Filtering Control<br />
• Masthead Line Power with short circuit protection<br />
• SMPS Amethyst<br />
• Test -30dB<br />
• Earth Bonding Point<br />
Mercury<br />
Part No. 371001<br />
Frequency range<br />
88-862MHz<br />
Gain & Flatness<br />
34 dB ± 1 dB<br />
Attenuation <strong>Range</strong><br />
0~20 dB<br />
Rejection at 790MHz and 862MHz -18 dB<br />
Slope Control<br />
0~15 dB<br />
Max. Noise Figure<br />
5dB<br />
Max. Output Level ( DIN45004B )<br />
117 dBμV<br />
Return Loss<br />
10dB(QC)/12dB(TYP.)<br />
Switch for 790MHz & 862MHz<br />
Yes<br />
Power Supply Unit (Internal) Thermal Fuse on Primary winding<br />
230VAC/50Hz/5W<br />
Power Supply Indicator light<br />
Blue LED<br />
Connectors according to IEC169-24 input F-female<br />
output<br />
Test -30dB Port<br />
Nominal impedance input and output<br />
On/Off Power Output For Preamplifier (With Short Circuit Protection)<br />
Power Output For Preamplifier Overload Indicator light<br />
Equipment approval<br />
F-female<br />
Yes<br />
75Ω<br />
12VDC 0.1A Max.<br />
Green:Normal<br />
Orange:Fault<br />
CE/RoHS/WEEE<br />
Topaz<br />
Part No. 371002<br />
Frequency range<br />
88-862MHz<br />
Gain & Flatness FM (88-108MHz) 30 dB ± 1 dB<br />
Attenuation <strong>Range</strong><br />
DAB (217-230MHz)<br />
UHF (470-862MHz)<br />
30 dB ± 1 dB<br />
34 dB ± 2 dB<br />
0~20 dB<br />
Rejection at 380MHz from 470MHz -35 dB<br />
at 790MHz to 862MHz<br />
at 108MHz to 217MHz<br />
-18 dB<br />
-35 dB<br />
Max. Noise Figure FM+DAB 6 dB<br />
Max. Output Level ( DIN45004B )<br />
Return Loss<br />
Switch for 790MHz & 862MHz<br />
UHF<br />
Power Supply Unit (Internal) Thermal Fuse on Primary winding<br />
Power Supply Indicator light<br />
On/Off Power Output For Preamplifier (With Short Circuit<br />
Protection)<br />
Power Output For Preamplifier Overload Indicator light<br />
UHF<br />
4 dB<br />
115 dBμV<br />
10dB(QC)/12dB(TYP.)<br />
YES<br />
230VAC/50Hz/8.5W<br />
Blue LED<br />
12VDC 0.1A Max.<br />
Green:Normal<br />
Orange:Fault<br />
Connectors according to IEC169-24 input F-female<br />
Test -30dB Port<br />
Nominal impedance input and output<br />
Equipment approval<br />
output<br />
F-female<br />
YES<br />
75Ω<br />
CE/RoHS/WEEE
Ruby<br />
Part No. 371003<br />
Frequency range<br />
88-862MHz<br />
Gain & Flatness FM (88-108MHz) 30 dB ± 1 dB<br />
Attenuation <strong>Range</strong><br />
DAB (217-230MHz)<br />
UHF1 (470-862MHz)<br />
UHF2 (470-862MHz)<br />
30 dB ± 1 dB<br />
34 dB ± 2 dB<br />
34 dB ± 2 dB<br />
0~20 dB<br />
Rejection at 380MHz from 470MHZ -35 dB<br />
at 790MHz to 862MHz<br />
at 108MHz to 217MHz<br />
-18 dB<br />
-35 dB<br />
Max. Noise Figure FM+DAB 6 dB<br />
Max. Output Level ( DIN45004B )<br />
Return Loss<br />
Switch for 790MHz & 862MHz<br />
UHF<br />
Power Supply Unit (Internal) Thermal Fuse on Primary winding<br />
Power Supply Indicator light<br />
6 dB<br />
115 dBμV<br />
10dB(QC)/12dB(TYP.)<br />
YES<br />
230VAC/50Hz/9W<br />
Blue LED<br />
On/Off Power Output For Preamplifier (With Short Circuit Protection) UHF1 12VDC 0.1A Max.<br />
Power Output For Preamplifier Overload Indicator light<br />
Green:Normal<br />
Orange:Fault<br />
Connectors according to IEC169-24 input F-female<br />
Test -30dB Port<br />
Nominal impedance input and output<br />
Equipment approval<br />
output<br />
F-female<br />
YES<br />
75Ω<br />
CE/RoHS/WEEE<br />
Amethyst<br />
Part No. 371000<br />
Frequency range<br />
88-862MHz<br />
Gain & Flatness FM (88-108MHz) 40 dB ± 1 dB<br />
Attenuation <strong>Range</strong> for ALL inputs<br />
0dB / -10dB Output Switch<br />
DAB (217-230MHz)<br />
UHF1 (470-862MHz)<br />
UHF2 (470-862MHz)<br />
UHF3 (470-862MHz)<br />
40 dB ± 1 dB<br />
47 dB ± 2 dB<br />
47 dB ± 2 dB<br />
47 dB ± 2 dB<br />
0~20 dB<br />
Rejection at 380MHz from 470MHz -35 dB<br />
at 790MHz to 862MHz<br />
at 108MHz to 217MHz<br />
YES<br />
-18 dB<br />
-35 dB<br />
Max. Noise Figure FM+DAB 6 dB<br />
Max. Output Level (DIN45004B ) FM+DAB 118 dBμV<br />
Return Loss<br />
Switch for 790MHz & 862MHz<br />
Power Supply Unit (Internal) SMPS<br />
Power Supply Indicator light<br />
UHF<br />
UHF<br />
6 dB<br />
121 dBμV<br />
10dB(QC)/12dB(TYP.)<br />
YES<br />
230VAC/50Hz/9.5W<br />
Blue LED<br />
On/Off Power Output For Preamplifier (With Short Circuit Protection) UHF1 12VDC 0.1A Max.<br />
Power Output For Preamplifier Overload Indicator light<br />
Green:Normal<br />
Orange:Fault<br />
Connectors according to IEC169-24 input F-female<br />
Test -30dB Port<br />
Nominal impedance input and output<br />
Equipment approval<br />
output<br />
F-female<br />
YES<br />
75Ω<br />
CE/RoHS/WEEE
Masthead Amplifier Kits<br />
• F-Connector Masthead Amplifiers<br />
and Power Supply Kit<br />
• Weatherproof housing<br />
• Fully screened enclosure<br />
• 2 + 4 Way Splitters available<br />
Part No. 370553 370692 370693 370557 370555 370554 370558 370556<br />
<strong>Product</strong> WFAV25 WFAV110 WFAV210 WFAV410 WFAV225 WFAV425 WFAV610 WFAV622<br />
Input <strong>Range</strong> (Channel) 21-68<br />
Typical Gain (dB) 25 10 10 10 25 25 10 22<br />
Variable Gain 10-25 0-10 0-10 0-10 10-25 10-25 0-10 12-22<br />
Max. Output (dBuV)* 102 94 90 85 97 4x85 83 83<br />
Noise (dB)
