Separator’s Digest®

The Magazine of GEA Westfalia Separator Group Edition 3 | 2012

Insulin

Expanding markets and production

in the emerging nations

Petrochemical Additives

More stringent market requirements

PECTIN PRODUCTION

GEA Westfalia Separator Group | Separator’s Digest ® 2012 ACHEMA Special

Contents

Preface

3 Intelligent Solutions for Challenging Markets

Separator‘s News

4 Innovative Separator Concepts:

GEA Westfalia Separator directdrive ∞

5 Robust and Very Reliable

5 One Machine – Three Sizes

GEA Westfalia Separator Group

6 Production of Insulin

10 Petrochemical Additives

14 Boosting Yield and Efficiency

18 The Sun Continues to Shine

22 Valuable Protein from Stillage

26 Drainage Systems for Drilling Platforms

and Drilling Vessels

Lifestyle

30 Incredible Versatility

Imprint

Publisher:

GEA Westfalia Separator Group GmbH

Project management: Dr. Bertram Melzig-Thiel

Editors:

Dr. Bertram Melzig-Thiel (person responsible according

to German press law), Manfred Kaiser,

Lilian Schmalenstroer

Photography:

Michael Dannenmann, Tim Luhmann,

GEA Westfalia Separator Group GmbH archive,

iStock

Conception and Layout:

Kabutz Communication GmbH

Feldstraße 5 · 59423 Unna (Germany)

info@kabutz.de · www.kabutz.de

The product information included in this magazine is

solely for information purposes and is non-binding.

Binding information, in particular regarding performance

and suitability for specific applications, can only be

provided in response to a specific enquiry.

2


The number of proteins and enzymes which are

used for therapeutic or immunising purposes is

increasing at breakneck speed at the moment.

Those so-called bio-pharmaceuticals include

vaccines as well as insulin. These substances are

taking an increasing share in pharmaceutical

developments and markets. The trigger for the

heavy demand for insulin is the change in the

population structure, among other things.

Separators from GEA Westfalia Separator Group

take over the decisive function in the core process

in the manufacture of recombinant insulin.

Intelligent Solutions for

CHALLENGING MARKETS

In this issue of Separator’s Digest you will read more about the

solutions for the production of insulin in the new plant of

Gulf Pharmaceuticals Industries (Julphar) located in Ras al

Khaimah. With this new insulin factory Julphar will render

available this life-saving drug to many patients in the United

Arab Emirates and the Near East. In its capacity as bidder for

the complete solution, GEA was responsible for engineering,

supply, start-up and qualification of the entire systems used

to manufacture the extra-pure substances as well as several

process systems and purification plants.

Moreover, in this magazine we will present to you a new

possibility of isolating proteins from the residues of alcohol

distillation which being a valuable fodder protein attract new

markets for animal fodder. Moreover, we will explain how

further yield and profitability reserves can be used in the

production of pectin, and in addition we will explain how centrifugal

processing techniques provided by GEA Westfalia

Separator Group ensure highly efficient recovery of recyclable

materials in the wafer production for photovoltaic systems.

And finally we will go on board of drilling platforms and

drilling ships with you. For the treatment of drilling mud and

water on the drilling decks, GEA Westfalia Separator Group

has developed several graduated processes up to the recovery

of the valuable heavy mineral of barite.

Ever more complex tasks make one thing very clear: demanding

markets require innovative and individual solutions on the

highest level. For this reason, GEA Westfalia Separator Group

is using Achema 2012 as an ideal platform for the launch of

the new decanter generation ecoforce with summationdrive

as well as the separator series directdrive ∞ for the fields of

application in chemicals, pharmaceuticals, mineral processing

and renewable resources. Another exhibit is the steam-sterilizable

package unit with separator and the entire periphery on one

single frame. The size presented is especially suitable for

laboratory and pilot plants; the integrated separator is the only

unit worldwide which reaches a centrifugal acceleration

of 20,000 g.

We think about things for you and find intelligent solutions in

all fields of application. Please visit us at Achema 2012.

We will show you.

Markus Hüllmann

Segment President GEA Mechanical Equipment

3


Innovative

Separator

Concepts:

GEA Westfalia

Separator

directdrive

Robust separator with integrated

direct drive for chemicals,

pharmaceuticals and renewable

resources

The new series of separators with the integrated GEA Westfalia

Separator directdrive ∞ can be used in multiple areas of

application. This new drive concept offers advantages specifically

with its much reduced level of maintenance requirement and

the resultant higher level of availability.

GEA Westfalia Separator Group is presenting the directdrive ∞

at ACHEMA, and is for the first time showing the whole

spectrum of this series with integrated direct drive for

applications in chemicals, pharmaceuticals, mineral processing

and the field of renewable resources. Duties that are constantly

gaining in complexity make one thing quite clear: to be able to

serve these demanding markets successfully, customized

high-end solutions had to be developed. This diversity is

reflected in the wide range of design variants. By way of

example, the directdrive ∞ is based on a gastight design with

nitrogen blanketing, and is certified in compliance with the

ATEX directive for use in explosion-hazarded zones. The

models of the directdrive ∞ series have a fully automatic CIP

system; aseptic and closed processing, optimum cleaning and

reliable conformity with GMP requirements are also realized

for specific process techniques. The GEA Westfalia Separator

finetuner additionally enables optimum separation of the two

product phases. The separating zone can be adjusted to the

optimum working point while the machine is running.

Integrated direct drive –

efficient and service friendly

The direct route is generally the most efficient. This is also

applicable for the drive of a separator. If the energy used in

such solutions is transferred by way of a direct connection

from the motor to the bowl, energy losses are minimal. With

the directdrive ∞ , the motor is housed completely in the frame

of the separator. The bowl spindle serves simultaneously as

the motor shaft. The integrated direct drive can therefore also

be used in normal heights. There is consequently no separate

motor shaft, no motor bearing, no coupling – and thus also no

wear affecting these components. In addition, the component

is used in conjunction with standard robust asynchronous

motors which can be controlled with any normal frequency

converter. With these frequency converters, infinitely variable

speed regulation has been provided in a specified speed range

with the integrated direct drive.

The directdrive ∞ is thus very service-friendly. This is because

the direct drive does not need numerous sensitive components

such as bearings or belts: parts which do not exist do not have

to be maintained. At the same time, it is extremely compact,

which is the same as saying that it has a lower space requirement.

The bowl can be removed easily as a single part from

the frame, or the motor can be disassembled together with the

drive as a single entity, thus considerably reducing the downtimes

for maintenance work.

4


Robust and Very Reliable

New decanter family GEA Westfalia Separator ecoforce for maximum availability

With the new decanter platform ecoforce, GEA Westfalia

Separator Group has designed a series of multifunction

machines which guarantee maximum availability, high

throughput capacities and excellent separating efficiency. At

the same time, it meets the user’s desire for maximum

flexibility. The entire family of the new decanter generation

ecoforce is extremely robust and provides a unique combination

of excellent performance and low energy consumption. It can

be adjusted in an individual and optimum manner to meet

the needs of the specific application, and also enjoys the

benefits of user-friendly service for optimum availability.

Decanters from the ecoforce series are ideal for use in applications

in chemicals, pharmaceuticals, mineral processing

and the field of renewable resources. At ACHEMA 2012,

GEA Westfalia Separator Group is presenting a machine from

the new series in the mid-range performance segment – the

decanter type: ecoforce CF 6000.

High energy efficiency

All models of the new ecoforce generation will feature the

standardized GEA Westfalia Separator summationdrive. This

high-torque drive ensures that the process is reliably provided

with the optimum differential speed, thus guaranteeing

maximum performance and high separating efficiency. This

means that all shafts are provided only with the power which

is actually required, which means that the drive operates in a

particularly energy-efficient manner.

Reliable operation

Maximum availability of the systems is assured by the service

of the original manufacturer, which has been integrated

specifically for this decanter series: GEA Westfalia Separator

directcare. The aim of this new concept is to ensure that all

technical and financial advantages of the new ecoforce series

can be used completely and throughout the entire life cycle

and in a manner which is consistent with the customer’s needs

by ensuring that total cost of ownership can be calculated.

One machine – Three Sizes

Package unit for laboratory and pilot installations in the

pharmaceutical and biotechnology industry

GEA Westfalia Separator Group is presenting the PU CSC 1/5/8 package unit

for the pharmaceutical and biotechnology industry at ACHEMA. The package

unit with a separator and the entire peripheral products on a single frame

is particularly suitable for laboratory and pilot installations for the production,

for instance, of vaccines, insulin and antibodies. In total, three bowl sizes

for different throughput capacities are available. With the capacities 15 to

30 litres per hour, 100 to 200 litres per hour and 150 to 300 litres per hour, the

package unit can be adjusted in an optimum manner to the various fermenter

sizes in biotechnology. This is also the first time that a package unit has

been designed for micro fermenters. The entire package unit, including the

pipework system and the special valve nodes, are steam-sterilizable and

comply with GMP requirements.

5


Production

of Insulin

EXPANDING MARKETS

AND PRODUCTION IN THE

EMERGING NATIONS

Until a few years ago, the production of insulin was essentially in the hands of

three pharmaceutical companies with international operations. Together, they

covered up to 95 percent of the market. This situation has changed considerably

recently, in line with globalisation and the simultaneous upswing of emerging

countries. China, India, Brazil, the Middle East, Poland, Russia and the Ukraine are

the new countries involved in the production of insulin. In these regions, the

pharmaceutical industry is responding to rising demand for insulin and is producing

the active agent for diabetes sufferers at more favourable conditions.

Demand is strong particularly in these parts of the world: rising prosperity is being

accompanied by an increase in the prevalence of diabetes.

6


7


The WHO is expecting to see the

number of diabetes sufferers increase

from 220 million to 400 million

by the year 2030 in the eight

most affected countries.

In India, for instance, the number

of diabetes patients will rise to

approximately 80 million by 2030,

and the figure in China is

expected to more than double.

Diabetes

is rising

dramatically

Being overweight and a lack of exercise mean that diabetes is

becoming a global illness. Diabetes means that the human

body does not produce sufficient insulin, is unresponsive or

resistant to insulin. In its advanced stage, insulin is therefore

administered in the correct dose to the patient as a life-saving

measure. In general, the remaining life expectancy of patients

is reduced by approximately one third after the point at which

the illness is diagnosed. According to the fifth edition of the

Diabetes Atlas, the International Diabetes Federation (IDF)

expects to see a worldwide increase in the number of

sufferers from 36 million in 2011 to approximately 552 million

in 2030. IDF also estimates that approximately 183 million

sufferers are not even aware of their illness. 80 percent of

diabetes sufferers live in countries with low and medium

incomes. According to the World Health Organization (WHO)

3.2 million deaths annually are associated with diabetes.

The diabetes market leader Novo Nordisk from Denmark

accounts for an estimated more than 50 percent share of the

worldwide market for insulin. Together with the French

Sanofi-Aventis and the US manufacturer Eli Lilly, Novo

Nordisk controls around 80 percent of the market. Other

market players include newcomers and niche providers in the

emerging countries, such as the Indian pharmaceutical

manufacturer Biocon, the largest producer of insulin in Asia.

Wanbang Biopharma for instance is the largest producer of

insulin in its domestic market of China, accounting for almost

half of the overall market. Mainly for exports to Europe and

the USA, this Chinese producer now intends to build an

insulin factory which, in its initial stage, will be able to

produce around 130 million units annually.

Julphar due to commission a new

production facility in the Middle East

In the United Arab Emirates, a new insulin factory is to be

commissioned by Julphar (Gulf Pharmaceutical Industries) in

mid-2012; in the same way as many other production facilities

throughout the world, this facility will also be equipped

with mechanical separating technology from GEA Westfalia

Separator Group. As the largest producer of antibiotics delivered

in oral form and in injectable form in the Middle East,

Julphar produces its own brands and also operates as a subcontractor

for worldwide demand under GMP conditions.

The factories are also ISO-certified.

Julphar pioneered the production of insulin in the Middle East

and Africa. The company has been distributing insulin in

cooperation with a French manufacturer since 1998; at that

time, Julphar imported the insulin crystals. In 2006, Julphar

decided to manufacture the raw material for insulin itself.

This is a logical decision because, according to the International

Diabetes Federation (IDF), there are already an estimated 32.6

million diabetes sufferers in the region, and this figure is

expected to double by the year 2030. The diabetes rates in the

Middle East and North Africa are some of the highest in the

world.

8


a total of five separators in Ras Al Khaimah. A nozzle-type

separator CFA 65with GEA Westfalia Separator viscon ®

technology is used for separating the coli bacteria from the

fermentation broth; in this solution, the solids are continuously

discharged with a constant concentration. Following the

homogenisation stage, two self-cleaning separators of the

type CSE 80 separate the inclusion bodies from the cell

fractions and wash them. Following the precipitation of the

insulin crystals in the clean room, two chamber-type separators

BKA 28 are then used to separate the crystals and thus produce

concentrated insulin. Whereas the separators in the first

two stages were supplied as compact package units, the

chamber-type separators are stand-alone machines with the

corresponding valve blocks and control unit. After GEA Westfalia

Separator Group has provided intense training to the operating

personnel, operations in Ras Al Khaimah will start providing

product in mid-2012.

Core processes from

GEA Westfalia Separator Group

Julphar‘s new production facility in Ras Al Khaimah north of

Dubai is one of the most modern in the world for manufacturing

insulin crystals for human cosumption. It covers floor area

of 20,000 m 2 , including clean rooms of 5000 m 2 . Fifteen

kilometres of pipework have been installed. GEA Diesel was

responsible for the engineering, delivery, commissioning and

qualification of the entire systems for the production of

ultra-pure media as well as various process equipment and

cleaning installations. In addition, the delivery comprised all

necessary pipework and distribution systems for the production

processes. In Ras Al Khaimah, Julphar uses the technology of

recombinant DNA (r-DNA), by injecting the insulin gene into

a suitable carrier substance, in this case Escherichia coli. Its

genetic constitution is modified in such a way that it produces

the human hormone insulin. In various stages, the bacteria

then multiply in fermenters, and are subsequently recovered

and purified in separators. Separators thus constitute the core

processes in the production of insulin. Because GEA Westfalia

Separator Group is known as the worldwide technology leader

in the production of insulin, Julphar decided to use the knowhow

of the company from Oelde with centrifugal technology

in its new plant. GEA Westfalia Separator Group has installed

GEA Westfalia Separator hycon

as an alternative

As an alternative to the production of insulin from Escherichia

coli, other producers use yeast as the carrier substance. The

process is similar, but the valuable substance in this case is

not the solids, and instead is the clarified phase. In both

methods, the hycon machines can be used as an alternative to

the chamber-type separator after the crystallisation process.

hycon is a completely closed system which enables the

separating process to be carried out under clean room

conditions without contamination by the drive or motor.

Due to the principle of the suspended bowl, this twin-room

concept has the bowl with the hood and solids holding tank in

the clean room, whereas the drive units can be housed in a

separate room with a lower classification. The machine is

designed in such a way that the solids are automatically

discharged from the suspended separator into closed containers

installed below the separator. GEA Westfalia Separator Group

achieves very gentle product treatment which is appropriate

for the high value material by means of two features: the

hermetic feed and the gentle discharge at operating speed or

lower speed of the machine. Whereas chamber-type separators

are not sterilised and can only be cleaned manually, hycon

machines have fully automatic cleaning and, where necessary,

sterilisation by means of CIP and SIP. Demand for the

technologies of GEA Westfalia Separator Group for the

production of insulin is very strong, particularly in the new

markets of the emerging countries.

Thomas Homann

Senior Product Manager Biotechnology

Business Line Chemical / Pharmaceutical Technology

GEA Westfalia Separator Group, Oelde

Phone +49 2522 77-1541

thomas.homann@gea.com

9


How to combat more

stringent market requirements

with centrifugal separating

technology

10


Petrochemical

Additives

11


Lube oils and fuels only provide their full impact in

conjunction with specific additives which are designed

precisely to meet the requirements of a particular

application. Lube oil is for instance the engine oil

which reduces friction which would otherwise prevent

piston engines from functioning.

Selected additives improve the properties of such oil. Additives also provide

additional measurable benefit for fuels in combustion engines, for instance a

reduction in the volume of particulate emissions in diesel engines. The

petrochemical industry is therefore constantly carrying out research and

development for even more efficient additives.

Efficient separation of salts

and excess basic substance

Centrifugal separating technology is particularly suitable for industrial mass

production of these additives for lube oils and fuels. Organic solvents are used

as the carrier substance for the additives. In accordance with the fundamental

rules of chemistry, the fundamental substance must first be added to the

solvent in excess so that a desired reaction can take place. The excess reactant

is then removed from the solvent. Depending on the application and the

chemical formula involved, the added fundamental substance in the solvent is

present either in dissolved form or in the form of finely suspended particles.

These can be certain complexes which become attached to molecules, or they

can also be nanoparticles which provide specific lubricating properties.

The solvent also contains further undesired solids, in general salts precipitated

from the previous chemical reaction.

Decanters and separators from GEA Westfalia Separator Group are used for

reliably separating these salts and the excess fundamental substance, the

reactant, from the solvent with the valuable additive, irrespective of the specific

application. And because the use of solvents frequently involves substances

which form gas mixtures which tend to explode in the presence of oxygen, the

centrifuges are virtually always explosion-protected and are usually provided

with inert gas blanketing. The necessary solid-liquid separation, which is a

traditional clarifying task, is performed either with decanters or with selfcleaning

separators or, very frequently, in combination with both types of

centrifuges in a two-phase process in which a high solid content in the decanter

is first separated and the fine content is then clarified by a self-cleaning

disc-type separator.

A higher level of automation and

more efficient clarification

GEA Westfalia Separator Group is able to look back on decades of experience

in the market for additives for fuel and lube oils. Numerous installations have,

for instance, been operating for many years in the USA and the countries of

the former Soviet Union. In many cases, a replacement investment is now

necessary, involving a conversion to a new centrifuge generation. However,

centrifugal separating technology is also ideal as a substitute for or an addition

to existing facilities with static separators or filtration techniques. In the case of

static separators, it may, for example, make sense to use a self-cleaning separator

to subsequently clarify the upper clear discharge which contains residual

amounts of suspended solids and thus to optimize the efficiency of the overall

12


process. On the other hand, systems with filter installations

have the disadvantage of high operating costs due to personnel

and filter aid requirement.

Increased requirements

The requirements with regard to additives in lube oils and

fuels have also become more stringent in recent years. This

has much to do with more stringent environmental protection

requirements. There is therefore a demand for additives which

encourage better combustion of the fuel in order to generate

fewer emissions. Or additives which promote the long service

life of lube oil in order to use resources more efficiently as a

result of having to change oil less frequently. The separators

and decanters from GEA Westfalia Separator Group have

adapted to these developments. Today, TSE separators are

much more compact than was the case as recently as a few

years ago. Due to a reduction in the number of components,

they operate more efficiently while providing the same

performance, and can be adjusted precisely to the required

throughput volumes. Innovative drive concepts reduce the

energy input.

Precise adjustment

to the processes

GEA Westfalia Separator Group is also presenting the new generation of

ecoforce decanters for chemical operations for the first time at ACHEMA

2012. This new series enables operators to configure the machine to meet

their individual needs: low or high torque, obtuse or acute conical angles,

low or high differential speed as well as hot or normal operation.

A previously unknown flexibility enables the machines to be precisely

adjusted to the very different process conditions in the petrochemical

industry for the wide range of lube oil and fuel additives. In parallel with

this development, energy consumption in the new generation has also

been considerably reduced. Certain processes are also affected by

considerable wear. For this application, it is possible to use hard facing for

the centrifuge materials. The machines are also much easier to maintain;

this advantage is enhanced further by the integration of the service

concept GEA Westfalia Separator directcare and the monitoring system

wewatch ® . This increases availability, and maintenance tasks become

easier to calculate.

The challenges which are today facing manufacturers of additives for

lube oils and fuels thus find a suitable solution in centrifugal separating

technology incorporating the latest generation of separators and

decanters.

Sven Nitschke

Product Manager



Phone +49 2522 77-1983

sven.nitschke@gea.com

13


14


Boosting

Yield and

Efficiency

Additional separating

stages in the

production of pectin

15


Pectin is frequently an essential component,

and acts as a jellying, thickening or stabilisation

agent for marmalade, jam, fruit juices, dairy

products and confectionery, and is also used in

the pharmaceutical and cosmetic industries in

order to boost the viscosity and stability of gels

or creams.

The producers of pectin are able to utilise even more reserves in terms of yield and

efficiency. GEA Westfalia Separator Group has developed two side process stages

which, combined with manageable levels of investment, promise to provide significant

improvements in terms of efficiency.

Firstly, additional washing of the pectin in hydrolysis ensures

a higher yield. This process has already demonstrated its

worth in practice at a manufacturer of pectin in Italy. Secondly,

clarification of isopropanol in the precipitation of pectin

enables the expensive solvent to be recovered more efficiently.

A Czech producer has been using this solution for several

years, and has good experience with this elegant type of

making efficient use of resources.

Pectin – an essential element

in many foods

The annual global market for pectin in 2009 was approximately

42,000 tons, and is continuously expanding at a rate of

approximately three percent per annum. Approximately ten

manufacturers, mainly based in Europe, are involved with the

production of pectin. The Danish market leader alone produces

approximately 30 percent of the entire market. Although

pectin is found in almost every terrestrial plant, the raw

materials which are used are citrus peel from citrus juice

production (approximately 70 percent), apple peel (approximately

25 percent) and other fruit and vegetable residues (5 percent).

This is due to the fact that citrus peel contains approximately

30 percent pectin, apple pomace contains approximately

15 percent and thus guarantees a much higher yield than other

raw materials.

The raw material therefore comes mainly from South America,

and in particular Argentina, where the peel is dried and shipped.

Pectin is made by the producers in numerous factories around

the world. The polysaccharide pectin is generally approved for

virtually all foods, where it is also very much in demand. It is

frequently an essential component, and acts as a jellying,

thickening or stabilisation agent for marmalade, jam, fruit

juices, dairy products and confectionery, and is also used in

the pharmaceutical and cosmetic industries in order to boost

the viscosity and stability of gels or creams. In terms of

nutritional physiology, pectins are roughage for humans.

Additional washing stage in hydrolysis

Pectin is mainly produced in two stages, namely hydrolysis

and precipitation. In hydrolysis, all water-soluble substances

are extracted from the raw materials with hot and very acidic

water. This suspension is first clarified by a decanter, i.e. it is

separated into solids with dry matter of approximately twelve

percent and also into the liquid phase with the dissolved

pectin and less than two percent solids.

The liquid phase is further polished in a separator and a

subsequent filtration process. The solids from the decanter are

normally used as animal feed. But this is precisely where

there are further benefits which have not yet been utilised: by

means of an additional washing stage with hot water and a

dewatering process by means of a decanter, it is possible for

further valuable pectin to be recovered and thus the entire

yield to be increased.

16


Treating the isopropanol

during precipitation

In the second stage of pectin production, namely precipitation,

the pectin concentrate which has previously been twice

concentrated and membrane filtered is first precipitated with

80 percent isopropanol, and the pectin fibres are then

dewatered by a decanter. This process is repeated, but using

99 percent isopropanol. In the second subsequent dewatering

of the pectin fibres in a decanter the solids are discharged as

end product: pectin with a dry substance content of up to

37 percent, which is now dried further.

The solvent isopropanol which is used in both stages is

distilled in order to be recovered. However, the solvent still

contains so many solids that the distillation process is affected

and frequently has to be cleaned. It is protected by an

intermediate decanter which treats the isopropanol and

removes the solids which, depending on their quality, can

also be used as pectin end product. However, a more important

aspect in this case is the process of treating the expensive

isopropanol so that it can be recovered easily and efficiently.

Use hire decanters for testing the

procedures in the user’s own operation

In both cases, namely solids washing in hydrolysis and

isopropanol recovery after precipitation, the users are able to

employ the latest GEA Westfalia Separator ecoforce generation,

of course in gas-tight explosion-protected design for isopropanol

recovery. As the market leader among suppliers for pectin

production, GEA Westfalia Separator Group provides producers

with a unique opportunity of using hire decanters for testing

the two procedures over several months in their own operation

and thus to gain their own experience with the expected very

good results. Significant increases in yield are assured. As

is reliable after-sales service provided by GEA Westfalia

Separator Group.

Torsten Tusel

Product Manager



Phone +49 2522 77-1982

torsten.tusel@gea.com

42,000 t ANNUAL WORLD PECTIN MARKET IN 2009

3 % GROWTH PER ANNUM

70 % PECTIN FROM CITRUS PEEL

25 % PECTIN FROM APPLE PEEL

5 % PECTIN FROM OTHER FRUIT AND VEGETABLE RESIDUES

30 % PROPORTION OF PECTIN IN CITRUS PEEL

15 % PROPORTION OF PECTIN IN APPLE POMACE

17


18


Recovery of

RENEWABLE

RESOURCES in

wafer production

The

Sun

Continues

to Shine

19


The basis of photovoltaic technology are so-called wafers

which are produced by major companies in China, the USA

and Europe. Large quantities of consumables can be recycled

in the production of such wafers. Centrifugal process

technologies of GEA Westfalia Separator Group ensure selective

separation and highly efficient recovery of the recyclable

materials.

Wafers are square or round discs, with a thickness of

approximately 50 µm to one millimetre and a diameter of

between 150 and 450 cm; they are made from semiconductor

ingots. These ingots are cylindrical or cuboid bars which are

melted from silicon. Wafers are processed into solar cells in

several stages, and are used for making solar modules. Or they

are used as the base plate for electronic components in the

semiconductor industry.

Energy from

photovoltaic

installations –

this market is

booming

worldwide

Even if manufacturers of solar

cells are currently having to

contend with price erosion,

which is severe in certain areas,

demand will continue to rise.

China alone, with its new

five-year plan, will extend the

photovoltaic capacity which

had been installed by 2011

from 1.7 gigawatt to 15 to

20 gigawatt in 2015.

Wafer cutting with wire saws

The industry has developed various processes for cutting the

wafers. Wire saws are used in some applications, and

diamond saws have recently also been used. The process of

cutting wafers with wire saws is supported by a carrier medium

such as polyethylene glycol (PEG) or diethylene glycol (DEG)

and a cutting agent based on silicon carbide (SiC). Both

substances are relatively expensive. The process forms a

slurry, which is a sludge consisting of silicon waste, the silicon

carbide and the PEG. In order to ensure economic and

environmentally-friendly wafer production methods, it is very

important to ensure that the two materials SiC and PEG can

be recycled efficently.

Two-stage recycling of silicon carbide

With its Central Process Engineering Research Centre (Zentrale

Verfahrenstechnik – ZVT), GEA Westfalia Separator Group

has carried out intensive trials to determine how the efficiency

of this recycling process can be maximised. This has resulted

in a two-stage classification process. Using the characteristics

of different densities and particle sizes of the respective

components, centrifugal methods permit highly-selective

separation. In the first stage, a decanter centrifuge removes

the coarse silicon carbide from the slurry at a relatively low

g-force; this silicon carbide can then be mixed with new silicon

carbide and can thus be recycled. The separating limit for the

silicon carbide particles is approximately six µm.

A second decanter, which is connected in series, operates with

maximum available speed and removes the finer silicon

carbide and the silicon fines as waste products from the

polyethylene glycol carrier liquid. Approximately 80 percent of

the silicon carbide recovered from the first stage is used as the

starting point for new cutting agents; this means that, in reality,

only one fifth new silicon carbide has to be added on each

occasion. This is also applicable for the polyethylene glycol as the

carrier medium. Again, four fifths are used from recovered

PEG and one fifth fresh PEG is used for new carrier liquids.

20


Advantages of the system

compared with alternative methods

The same decanter type can be used for both stages; the speed

required in each case is set by means of a frequency converter.

This process which has been developed by GEA Westfalia

Separator Group has established an extremely good position

on the market. This is understandable, because operating

with decanters provides clear advantages compared with

alternative methods used, such as hydrocyclones or filter presses.

Due to the nature of the system involved, hydrocyclones are

not able to match the quality of the classification stage of the

second decanter stage; this means that it is not possible to

separate the silicon particles smaller than six µm from the

silicon fines and the PEG. The fact that this stage is less

precise has a direct impact on the quality of the process.

A further advantage of decanter technology is the lower total

cost of ownership. It is true that hydrocyclones are less

expensive in terms of the initial investment; however, they do

not have the service life of decanters and have to be replaced if

they are affected by wear.

Inline slurry processing

It does not matter which sawing method the wafer manufacturers

use; the solutions of GEA Westfalia Separator Group

are customised to meet the aim of attaining maximum

process qualities and recycling ratios of the valuable slurry

components. This is applicable for off-site concepts, when

wafer producers outsource slurry processing to external

providers, and also for inline processes in which the slurry

is treated and separated in the wafer factory itself. As a result

of the collapse in prices for wafers last year, more and more

wafer producers are now preferring inline processing. The

amortisation periods for such a changeover are generally less

than two years.

Tore Hartmann

Senior Application Manager Mineral Processing



Phone +49 2522 77-5684

tore.hartmann@gea.com

Compared with filter presses, compact decanters provide the

advantage of a much smaller space requirement. Compared

with the open operation of filter presses, centrifugal technology

is a closed system. Filter presses require filter agents with all

the associated disadvantages such as manual handling and

waste management. A further aspect is that filter presses

require start-up times of several hours for the classification

process in order to provide constant results, whereas decanters

are able to operate at full capacity within a few minutes.

Single-stage recovery process for cutting

with diamond saws

In addition to the process of cutting the wafers with wire

saws, which is currently used by industry in approximately

80 percent of all applications, a new method is now becoming

established, namely cutting with diamond saws. This method

operates at much higher speeds and with greater precision

and enables even thinner wafers to be cut, although it involves

higher costs. It is not a question of whether this technology

will be used more extensively; the question is how quickly

will this process take place.

Slurry is also encountered in this process; however, PEG is not

used as the carrier liquid. Instead, water with surface-active

substances is used. Accordingly, this slurry can be processed

in a single stage with a self-cleaning separator. The advantage

of this solution is to be seen in the use of maximum g-forces

for very efficient separation into pure silicon as the solids and

the carrier liquid as the liquid phase. Both materials can then

be recycled.

The sun will continue to shine on energy production by means

of photovoltaic solutions and will thus also continue to shine

on the wafer industry. Even if a slight shadow has been cast on

the price situation as a result of political factors. Recycling of

materials is beneficial for the photovoltaic industry and its

suppliers in economic and also ecological terms. GEA Westfalia

Separator Group is supporting them in this process.

21


Valuable

Protein from

Stillage

New procedure for

recovering valuable

substances from

alcohol distillation

residues

22


23


The concept of perpetual motion unfortunately does

not work. However, the new procedure of

GEA Westfalia Separator Group for treating stillage

from ethyl alcohol production does not fall far short

of meeting this concept. However, this is really only

an attractive additional effect. Of much greater

importance is the possibility of treating the distillation

residue in order to isolate proteins which, as valuable

animal feed protein, serve new animal feed markets

and which are suitable not only for ruminants, as is

the case with conventional stillage.

Alcohol can be made from raw materials which contain starch, e.g. corn, wheat

and rye, by grinding the starch and converting it into sugar by enzymatic

action; this is followed by a fermentation process, and the added yeast produces

alcohol. This alcohol is distilled into ethyl alcohol. The distillate residue which

is left over comprises all substances which cannot be fermented, such as fibres,

pentosanes, proteins and salts, the so-called stillage. This residue is a popular

and inexpensive feed for ruminants and cattle, goats or sheep. The fibre- and

protein-rich stillage is used particularly frequently for fattening bulls.

Conventional stillage under price pressure

Smaller distilleries sell the stillage untreated to farmers in the region, most of

whom collect the stillage themselves. However, for larger distilleries with a

production of approximately 60,000 litres of ethanol per day, the logistics of

the wet stillage becomes a critical problem because of the sheer volumes

involved. This is because, in the distillation process, approximately ten litres of

stillage are obtained for every litre of alcohol. In general, the stillage is then

dewatered with decanters and processed into animal feed which can be stored

and transported, using concentrators and driers (DDGS – Dried Distillers

Grain with Solubles). This means that distilleries now have to consider stillage

treatment as a separate branch of production in addition to the actual process

of producing alcohol: stillage management has a considerable influence on the

operating costs of a distillery. However, DDGS is having to face fierce competition,

which has recently also been exacerbated by bioethanol producers, and the

price of DDGS is not particularly attractive for the seller.

The situation is somewhat different if we can move away from this fiercely

competitive market of animal feed for ruminants. However, for this purpose,

it is necessary to remove the fibres which other animals such as pigs, poultry

or fish cannot digest. This means that distilleries are now able to approach an

entirely new market for selling their stillage which occurs every day.

Protein-enriched concentrate

Initial whisky distilleries are already running trials with a separator which

removes the proteins in the overflow of the decanter from the husks.

GEA Westfalia Separator Group has gone one step further, and has developed

a method which operates even more efficiently. This process does not use

concentration, and instead uses a three-stage procedure chain with a decanter,

24


membrane filtration and separator. This means that the stillage is broken down into three

fractions. The end product is a protein-reduced wet distillers grain which contains fibres

(WDG – Wet Distillers Grain), which is then dried to form DDG (Dried Distillers Grain) and is

suitable for ruminants. A second entirely new and major fraction from the centrifugal separation

process is a protein-enriched concentrate without fibres with a high nutritional value and a

wide range of potential applications in pig breeding and poultry breeding as well as fattening

fish. The prices of this protein concentrate are much better.

However, this is not the whole story. As a third fraction, the process obtains a substrate from

the membrane filtration installation with the clarified phase; this substrate can be used in

biogas installations for generating electrical and heat energy. Calculations show that the energy

obtained in this way is sufficient to power the entire protein recovery process described above.

In other words: the system does not require any external energy input. And the membrane

installation can also reduce the BOD and COD load in the effluent and might thus possibly also

enable the effluent to be discharged directly into the sewerage system.

No requirement for external energy input due to biogas

A particularly elegant aspect of the stillage process developed by GEA Westfalia

Separator Group is that existing conventional stillage treatments in the distilleries can easily be

retrofitted with membrane filtration and a separator. Using a by-product in the low-price segment,

distilleries in excess of a certain size are able to generate high-value protein products and

considerably boost their efficiency. And the operators are also able to gain an ecological image

with this process which does not require any input of external primary energy.

New and substantial fraction from

centrifugal separation is a proteinenriched

concentrate without

fibres, with high nutritional value

and a broad range of potential

applications in pig and poultry

breeding, and in fish farming.

This protein concentrate targets

significantly better pricing.

Burkhard Schiemann

Project Manager

Business Line Renewable Resources


Phone +49 2522 77-1530

burkhard.schiemann@gea.com

25


26


Drainage

Systems for

Drilling

Platforms and

Drilling Vessels

Additional

recovery of

barite possible

27


GEA Westfalia Separator Group has developed several graduated methods for

processing drilling mud and water on the drilling decks of drilling platforms and drilling

vessels; these range from a simple combination of decanter and separator, the upstream

installation of a skimmer tank right through to recovery of the valuable heavy mineral

barite. All three methods have already demonstrated their worth in the rough working

environment of drilling platforms.

Drilling platforms and drilling vessels pose particular

requirements with regard to the processing of bilgewater and

drilling mud. The platforms and the vessels are in principle

split in two. On the whole, it is necessary to treat water which

is equivalent to the bilgewater on normal vessels and which

can be treated by corresponding means. The tried-and-tested

BilgeMaster ® systems from GEA Westfalia Separator Group

are suitable for this purpose; they are currently being used in

hundreds of applications on all types of vessels.

Combination of decanter and

GEA Westfalia Separator BilgeMaster ®

The problem on the drilling deck is somewhat different. The

process of changing drill pipes results in large quantities of

drilling mud with a very high solids content on the deck.

Drainage water poses major challenges in terms of processing.

The composition of the drainage water varies considerably.

The oil content can vary between zero and five percent (by

volume), the water content can vary between 75 percent and

95 percent (by volume), and the solids content can be up to

20 percent (by volume). Erosive substances such as a high

corrosive salt content can also be included. Drilling water and

drilling muds on the drilling deck contain chemicals in

suspension and in solution, mud containing water, salt water,

rain water and formation water. The drilling muds also

contain sand, floating solids, stones and large particles.

Normal bilgewater processing systems are not suitable for this

purpose. In this case, a good solution is to use a combination

of an upstream decanter, which removes the coarse solids,

and a downstream BilgeMaster ® separator. It is of course selfevident

that this complete system has to be designed with

ATEX explosion protection. The combination of a decanter

and BilgeMaster ® has already demonstrated its worth. The

required MARPOL figure of fewer than 15 ppm oil in water is

attained reliably and consistently. Drilling companies have

already used this technology of GEA Westfalia Separator Group

on 17 occasions in the past two years for building new

platforms and drilling vessels or retrofitting the equipment.

28


Upstream skimmer tank

The experience gained with the combination system decanter /

BilgeMaster ® has been used by GEA Westfalia Separator Group

in conjunction with the drilling companies and shipyards in

order to further develop and improve the drainage system for

the drill decks. The use of an upstream skimmer tank was a

good solution for the preliminary separation of very large

particles such as stones and beverage cans as well as floating

solids. Four systems involving this combination of a skimmer

tank / decanter / BilgeMaster ® are already being used in hard

practical applications.

The drainage systems from GEA Westfalia Separator Group

were also part of a Samsung road show in the USA at which

the new Samsung drilling vessel was presented to interested

shipyards and drilling companies.

Recovery of barite with

classifying decanter

Special treatment is required for the heavy mineral barite

(barium sulphate), which has a minimum specific density of

4.20 g/cm 3 . The comparatively expensive barite is added to the

drilling mud on board in order to thicken the drilling mud.

This rare and valuable mineral would have to be disposed of

together with the dried drilling mud if it could not be

separately precipitated. However, it is far too precious. In order

to recover barite to be used again as an addition to the drilling

mud, GEA Westfalia Separator Group has developed the

possibility of installing a special classifying decanter upstream

of the separating decanter. This special decanter removes only

very heavy solids from the mud. A GEA Westfalia Separator

rigMaster CF 4000 from the new ecoforce decanter generation

is used for this application – with the inherent advantages

such as high strength, maximum availability, high throughput

capacities, excellent separating efficiency and low energy

consumption. The separation of barite is currently also being

used by two drilling companies.

The price pressure on shipyards for new projects is high.

All systems used on board drilling vessels and platforms are

to be automated as far as possible; they should also feature

user-friendly design in order to prevent the frequently

changing crew from having to face problems. This is achieved

by the drainage systems of GEA Westfalia Separator Group.

GEA Westfalia Separator Group also ensures high sustainability

by means of energy-saving measures. For instance, an

economiser which uses clean hot water to heat the cold water

in a heat exchanger counter flow arrangement is installed

upstream of the separator.

Thomas Perschke

Director

Business Line Oil & Gas


Phone +49 2522 77-2645

thomas.perschke@gea.com

5 ppm in sight

All of the three systems specified above

guarantee a purity of the waste water of max.

15 ppm oil content in water. In some regions of

the world, e.g. the Arctic, the Antarctic and off the

Norwegian, Danish and British coasts of the North Sea,

a purity of 5 ppm oil in water is required. GEA Westfalia

Separator Group is currently working on solutions for drilling

vessels and platforms which are used in these regions. On normal

vessels, it is already possible for bilgewater to be treated with only 5 ppm

by the BilgeMaster ® cleandesign system. GEA Westfalia Separator Group is

also working on configuring the complete systems to fit in containers so

that they can easily be retrofitted on existing platforms and drilling vessels.

29


How PET is

made from PTA

incredible

versatility

More than every third beverage in the world is consumed from PET

bottles. Precisely 38 percent of all packaged beverages in 2010

were filled in 422 billion PET packagings. According to Euromonitor,

446 billion PET packagings have already been used in 2011. By the

year 2015, market observers are predicting a further increase in the

packaging market to 1.31 trillion beverage packagings, with a

further increase in the share of PET to 42 percent.

Demand for PET packagings is accordingly increasing by more than five percent per annum.

Water and carbonated soft drinks alone account for approximately three quarters of the

consumption of PET packagings. A tremendous victory march, considering that the PET bottle

was first patented in 1973 by the chemist Nathaniel Wyeth. The main PET raw materials are

pure terephthalic acid (PTA) and monoethylene glycol (MEG). A polycondensation process is

used to trigger off a chemical reaction between the substances. This results in a polyester which

is crystallised and polymerised in order to achieve the desired product quality.

Mimicking nature

Chemists have taken the idea of polymerisation from nature. Proteins, cotton, wool and cellulose

are examples of polymers which occur naturally. These substances consist of very large

molecules (macro molecules) with units, described as monomers, which join together to form a

chain. Chemists have successfully copied the principle of combining small elements with

hydrocarbons. This synthetic polymerisation process is used in the production of many plastics

and other materials which are used in the production of everyday products such as bottles,

foam cushions, non-stick pans, toys and computer housings. The development of chemical

process engineering nowadays enables plastics to be produced cheaply and in large quantities.

30


Plastics and polymers, such as polyethylene, PVC, polypropylene and polystyrene,

are today estimated to account for 80 percent of the worldwide

production output of the chemical industry.

PTA (Purified Terephthalic Acid) which is necessary for PET production is a

colourless crystalline solid with an acid smell. Approximately 90 percent of

the annual production of terephtalic acid is used for the production of the

plastic polyethylene terephthalate (PET). Normally, PTA is used in the form of

a free-flowing powder in the production of saturated polyesters. Polyesters are

polymers with ester functions, and include the widely used polycarbonates (PC)

and particularly the technically important thermoplastic polyethylene (PET).

In addition to PET bottles, saturated polyesters are used in the production of

fibres for textiles and non-woven fabrics, transparencies, as a base material for

flexible printed circuit boards, films, tennis strings and fibre-reinforced

plastics. If every Chinese person were to buy one pair of new socks only once

every year, a complete PTA plant would be necessary for this purpose alone.

Up to 93 percent recycling of catalysts used

Terephthalic acid is produced by means of oxidation with the aid of p-xylol

catalysts. These catalysts are usually combinations of cobalt, manganese and

bromine. Acetic acid is used as a reaction solvent. Cobalt and manganese in

particular are valuable catalysts. This means that recycling is essential for

efficient operations under economic aspects and also in line with the principle

of making efficient use of resources. And this is precisely the point at which

the technology of GEA Westfalia Separator Group comes into play. Up to

93 percent of the catalysts cobalt and manganese which are used can be

recycled back into the process by means of centrifugal separation technology.

Depending on the process, either nozzle-type separators or decanters are

suitable for the recycling process. The disc-type separators, for instance the

type TDC 130 and TDC 160, are responsible for optimum clarification of the

suspension and also for concentrating the solids from one to two percent

(by weight) to four percent (by weight). Decanters on the other hand dewater

the solids with a process-related content from between 0.5 and 22 percent (by

weight) to 85 percent dry matter. Nozzle-type separators from GEA Westfalia

Separator Group have so far been used at PTA manufacturers in India, China,

Brazil, Portugal and Great Britain. An order for four nozzle-type separators has

recently been placed for a manufacturer in Eastern Asia. Decanters have so far

been used in China and Korea. So that the daily water or lemonade bottle can

be produced efficiently.

31

Rule the Liquids...

...extreme forces must be safely under control.

Our separators do a perfect job under the rough conditions

of the chemical and petrochemical industry.

GEA Westfalia Separator Group GmbH

Werner-Habig-Straße 1, 59302 Oelde, Deutschland

Phone: +49 2522 77-0, Fax: +49 2522 77-2488

www.gea.com

engineering for a better world

B_WS-12-05-0032 EN · Printed in Germany · Printed on chlorine-free paper

Westfalia ® , Westfalia Separator ® , Separator‘s Digest ® , BilgeMaster ® , viscon ® and wewatch ® are registered trademarks of GEA Mechanical Equipment GmbH.

CP-214-1-014

Separator's Digest 2012/3 - GEA Westfalia Separator Group

Transform your PDFs into Flipbooks and boost your revenue!

Separator's Digest 2012/3 - GEA Westfalia Separator Group

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
