teaching - Earth Science Teachers' Association

teaching

EARTH

SCIENCES

Journal of the EARTH SCIENCE TEACHERS’ ASSOCIATION

Volume 27 ● Number 3, 2002 ● ISSN 0957-8005

www.esta-uk.org

th Science

ache

Earth Science

Activities and

Earthquakes

Response to the

Science and

inquiry into the

Kingston 2001

Book Reviews

Websearch

Browne

Teaching Earth Sciences: Guide for Authors

The Editor welcomes articles of any length and nature and on any topic related to

Earth science education from cradle to grave. Please inspect back copies of TES,

from Issue 26(3) onwards, to become familiar with the journal house-style.

Three paper copies of major articles are requested. Please use double line spacing

and A4 paper and please use SI units throughout, except where this is inappropriate

(in which case please include a conversion table). The first paragraph of each

major article should not have a subheading but should either introduce the reader

to the context of the article or should provide an overview to stimulate interest. This

is not an abstract in the formal sense. Subsequent paragraphs should be grouped

under sub-headings.

Text

Please also supply the full text on disk or as an email attachment: Microsoft Word

is the most convenient, but any widely-used wordprocessor is acceptable.

References

Please use the following examples as models

(1) Articles

Mayer, V. (1995) Using the Earth system for integrating the science curriculum.

Science Education, 79(4), pp. 375-391.

(2) Books

McPhee, J. (1986 ) Rising from the Plains. New York: Fraux, Giroux & Strauss.

(3) Chapters in books

Duschl, R.A. & Smith, M.J. (2001) Earth Science. In Jere Brophy (ed), Subject-

Specific Instructional Methods and Activities, Advances in Research on Teaching. Volume 8,

pp. 269-290. Amsterdam: Elsevier Science.

To Advertise in


EARTH

SCIENCES


EARTH

SCIENCES



Your President

Introduced

Martin Whiteley

Thinking Geology:

Activities to Develop

Thinking Ski ls in

Geology Teaching

Recovering the

Leaning Tower of Pisa

Demonstrations:

House of Commons

Technology Commi tee

Science Cu riculum for

14 - 19 year olds

Se ting up a local

group - West Wales

Geology Teachers’

Network

Highlights from the

post-16 ‘bring and

share’ session a the

ESTA Conference,

ESTA Conference

update

News and Resources

www.esta-uk.org



Telephone

Ian Ray

0161 486 0326


EARTH

SCIENCES

rth Science

chers’ Asso


Creationism and

Evolution:

Questions in the

Classroom

Institute of Biology

Chemistry on the

High Street

Peter Kenne t




Fossils and Time

Mike Tuke

Beyond Petroleum:

Business and

The Environment in

the 21st Century John

Using Foam Rubber in

an Aquarium To

Simulate Plate-

Tectonic And Glacial

Phenomena

John Wheeler

Dorset and East

Devon Coast:

World Heritage Site


Update

New ESTA Members

Websearch


(including ESTA AGM)

Figures

Prepared artwork must be of high quality and submitted on paper and disk. Handdrawn

and hand-labelled diagrams are not normally acceptable, although in some

circumstances this is appropriate. Each figure must be submitted as a separate file.

Photographs

Please submit colour or black-and-white photographs as originals. They are also

welcomed in digital form on disk or as email attachments: .jpeg format is to be preferred.

Please use one file for each photograph.

Copyright

There are no copyright restrictions on original material published in Teaching Earth

Sciences if it is required for use in the classroom or lecture room. Copyright material

reproduced in TES by permission of other publications rests with the original

publisher. Permission must be sought from the Editor to reproduce original material

from Teaching Earth Sciences in other publications and appropriate acknowledgement

must be given.

All articles submitted should be original unless indicted otherwise and should

contain the author’s full name, title and address (and email address where relevant).

They should be sent to the Editor,

Dr Roger Trend

School of Education

University of Exeter

Exeter EX1 2LU

UK

Tel 01392 264768

Email R.D.Trend@exeter.ac.uk

Editor

WHERE IS PEST

PEST is printed as the

centre 4 pages in

Teaching Earth Sciences.




TEACHING EARTH SCIENCES ● Volume 27 ● Number 3, 2002


EARTH

SCIENCES

Teaching Earth Sciences is published quarterly by

the Earth Science Teachers’ Association. ESTA

aims to encourage and support the teaching of

Earth Sciences, whether as a single subject or as

part of science or geography courses.

Full membership is £25.00; student and retired

membership £12.50.

Registered Charity No. 1005331

Editor

Dr. Roger Trend

School of Education


Exeter EX1 2LU

Tel: 01392 264768

Email: R.D.Trend@exeter.ac.uk

Advertising

Ian Ray

5 Gathill Close

Cheadle Hulme

Cheadle

Cheshire SK8 6SJ

Tel: 0161 486 0326

Reviews Editor

Dr. Denis Bates

Institute of Geography and Earth Sciences

University of Wales

Aberystwyth

Dyfed SY23 3DB

Tel: 01970 622639

Email: deb@aber.ac.uk

Council Officers

President


Barrisdale Limited

Bedford

Chairman

Geraint Owen

Department of Geography

University of Swansea

Singleton Park

Swansea SA2 8PP

Secretary

Dr. Dawn Windley

Thomas Rotherham College

Moorgate, Rotherham

South Yorkshire

Membership Secretary

Owain Thomas

PO Box 10, Narberth

Pembrokeshire SA67 7YE

Treasurer

Geoff Hunter

6 Harborne Road

Tackley, Kidlington

Oxon OX5 3BL

Contributions to future issues of Teaching Earth

Sciences will be welcomed and should be

addressed to the Editor.

Opinions and comments in this issue are the

personal views of the authors and do not

necessarily represent the views of the Association.

Designed by Character Design

Highridge, Wrigglebrook Lane, Kingsthorne

Hereford HR2 8AW

CONTENTS

66 Editorial

Roger Trend

68 Hydrogeology, Pollution and Cemeteries

Mike Lelliott

74 Mass Extinctions:

The Alternatives to “Deep Impact”

Rosalind V. White

78 Fossils Under the Microscope

Ian Wilkinson

85 The Stone Tapes:

Building Stones in the History of the City of

Nottingham

Graham Lott

89 Lost Worlds:

How Exceptional Fossils Reveal the Past

Mark Williams

94 From Flood to Drought and Back Again

Brian Waters

96 ESTA Conference 2003

97 Reviews

98 ESTA Diary

99 Websearch

101 News and Resources


EARTH

SCIENCES

Visit our website at www.esta-uk.org

Front cover:

Key Stage 2 children exploring the rock

shelves, National Stone Centre. Note

that hard hats are not required!

Photo Ian Thomas. See page 101.

Back cover:

The snout of the Porito Moreno glacier

and Lago Argentino in Patagonia,

southern Argentina.

Photo: Martin Whiteley

65 www.esta-uk.org


Editorial

Afew weeks ago the BBC broadcast a peak-time

television programme called something like

“Fifty Places You Must Visit before You Die”,

comprising the 50 most popular holiday locations

according to some kind of viewer survey. Of course, I

won’t bore or insult you by going through the usual

caveats, (unrepresentative sample, inconsistent selection

criteria etc.), but they are probably more relevant

here than with most other data sources! Nevertheless,

and remaining fully cognisant of the distinguishing

characteristics of sound academic enquiry, I have on

your behalf analysed the research data comprehensively,

rigorously, statistically and exhaustively (not to mention

exhaustingly). I have come up with some amazing

facts that should cheer the hearts of those who seek

after truth, including those committed to Earth science

I had to determine if Iceland was ranked at 44

because of its diverse and spectacular geological

phenomena or because of its unique and equally

spectacular socio-economic and cultural attractions.

Similarly, what attracted respondents to Hawaii:

the volcanoes or the surfing beaches

education. There is, however, one major weakness in

this academic investigation which might throw into

question the reliability of the findings. This weakness is

the fact that I, the objective and wholly impartial

researcher engaged in this study, have been unsuccessful

in my quest for research funds to allow me to investigate

at first hand each and every location. This

difficulty has prevented me from obtaining muchneeded

supportive data to facilitate triangulation, and is,

of course, a reflection of the very low esteem in which

such high-quality, esoteric, academic research of this

kind is generally held.

Method

The programme was watched, with a cup of coffee to

hand, or was it tea Pencil and paper also figured in the

data-collection instrument.

Results and Analysis

Taking the fifty locations in total, the Grand Canyon is

top, the Great Barrier Reef is second, South Island

New Zealand is fourth and Table Mountain is fifth. If

you really want to know the third most popular location,

please see the bottom of the next page where it is

printed small and inverted. Needless to say, many of

the world’s cities are in the list, such as Sydney at 8,

New York at 9, Venice at 18 and Paris at 27. Specific

buildings or historical settlements also figure large,

such as the Taj Mahal at 10, Machu Picchu at 14,

Angkor Wat at 29 and Abu Simbel at 48.

Each location was painstakingly analysed to determine

its relative Earth science content. This was a

major element in the research project because it

involved probing respondents’ minds in a systematic

way in order to expose their perceptions of the places.

This was particularly demanding because I had no

access whatsoever to the respondents... For example, I

had to determine if Iceland was ranked at 44 because

of its diverse and spectacular geological phenomena or

because of its unique and equally spectacular socioeconomic

and cultural attractions. Similarly, what

attracted respondents to Hawaii: the volcanoes or the

surfing beaches

For current readers the most significant “locale

group” (a norm-referenced multi-variate artefact developed

by my research team specifically for this project)

comprises those places which are perceived as being

attractive essentially because of their geological or geomorphological

features: examples include Grand

Canyon at 1, Great Barrier Reef at 2, South Island New

Zealand at 4, Table Mountain at 5, Lake Louise at 11,

Uluru at 12, Yosemite at 23, North Island New Zealand

at 25, Alaska at 28, Everest at 30 and the Matterhorn at

46. This group is labelled Downright Geological. A similar

locale group (Diluted Geology) comprises places similar

to these but with rather less domination by the

geology: Galapagos at 33 (don’t forget all that biology:

marine iguanas, finches, giant tortoises etc.) and Sri

Lanka (think of all those non-geological elephants, trees

and tea plantations) at 41 exemplify this category.

Another important Earth science locale group comprises

the Waterfalls, with no fewer than 4 on the list:

Niagara at 15, Victoria at 21, Iguacu at 26 and Angel at

47. A final Earth science grouping comprises historical

or cultural places which possess significant geological

elements, such as Petra at 16, Machu Picchu at 14, the

Great Wall of China at 20 and the Terracotta Army at 45.

This last group is labelled Building on Geology.

The following table summarises the data according

to locale group. Note that the four geology-related

groups contain 31 places, being 62% of the total. This is

more than half: an amazing and wholly-unexpected

finding which has clear implications for curriculum

Locale Group

Frequency

Urban Delights 13

Downright Geological 13

Building on Geology 10

Tropical Paradise 5

Waterfalls 4

Diluted Geology 4

Other (see bottom of next page) 1


66


planning not only across the sciences but also in business

& finance, travel, and leisure & tourism.

The above analysis treats each rank as of equal value,

but clearly a position of 3 is much better than one of 46.

The mean rank of all the Downright Geological places

(n=13) is 19.53 whereas that for Urban Delights

(n=13) is far higher, at 26.84. This is unequivocal evidence

that the world’s holiday-makers prefer visiting

geological sites than drab and boring cities such as Sydney,

Venice and Barcelona. Only the Other category has

a higher rank than all of the geological categories, a

wholly inexplicable and somewhat worrying finding.

Implications of the Findings

The implications of the results presented above are

clearly very significant for the Earth science education

community, and beyond, but it is not possible

here to examine them at the length and depth warranted:

such an analysis belongs in a high-status academic

journal read by 12 very clever people

worldwide rather than in TES which is read by many

hundreds of practitioners. Nevertheless, some tentative

conclusions are offered in all humility and the

following ones might be drawn from this analysis. I

present them as options to be considered.

1. We can learn nothing whatsoever from these data: far

more research is needed... and soon.

2. Earth science figures large in the perceptions of people

who both watch television and take overseas holidays.

We have no reliable data on such perceptions

among people who only engage in one of these two

activities. These subjects do not actually think of

themselves as being keen on geology, possibly

because of its perceived connections with anoraks, so

most are actually unaware of this Earth science orientation

in their perceptions. However, if they were

to become aware of it they would probably switch

their holidays to Paris, Venice and Rome, with obvious

implications for those places.

3. Earth science teachers should take over responsibility

for all courses in travel, leisure and tourism

and the balance of content within such courses

should be adjusted to match the expressed interests

of the punters.

4. Package tour operators should insist that all their

representatives are Earth science graduates and their

professional training within the tour company

should involve refresher courses every year to ensure

they are up-to-date (for example, do all current reps

know if birds really are descendants of dinosaurs).

5. Package tour representatives should be provided

with scripts prepared by true experts in the field. An

example follows: “Good afternoon, welcome to Majerife,

and I hope you had a good flight from Gatwick. My name

is Shelly and our coach driver today is Juan. We now have a

50-minute drive to your hotel complex, so just sit back and

relax. Make sure you go to the Welcome Meeting tomorrow

morning at 6.15 a.m. where we will be telling you all about

the local evidence for the Carnian-Norian extinction event,

the latest interpretation of the ultramafic xenoliths in the

alkali basalts which underlie the resort and, of course, the

classic overstep shown in the unconformity in the hills behind

your hotel. The meeting will finish by 3 p.m. so there will be

plenty of time for a swim in the pool... Quick ,if you look out

of the left side of the coach now you can see the quarry where

the well-exposed ophiolite sequence gives us terrific evidence

for the little-understood Tommotian collision...”

6. Authorities keen to attract new tourists to particular

locations should emphasise the geological features

and ignore cultural and historical factors. It is even

debatable if climatological and meteorological variables

(often referred to in popular literature as “the

weather”) should figure in their promotional material

since the evidence presented here suggests it is

totally irrelevant to the average holiday-maker

(Everest, Iceland, Alaska).

7. Earth science courses should be re-configured to

accommodate these findings. This may be done in

several ways. More full degree courses (or compulsory

modules) are needed with titles such as “With

Rocks In Mind: choosing your holiday destination

from an informed position” and “From Here to

Ibiza: hydrological, palaeontological and mineralogical

opportunities for all”.

Roger Trend

Answer. Walt Disney World

67 www.esta-uk.org


Hydrogeology, Pollution and Cemeteries

MIKE LELLIOTT

A large step forward towards water awareness was reached in August 2002 with the UN Secretary

General, Kofi Annan, identifying that “water is a fundamental resource for sustaining life and for

conserving the natural environment” (World Summit on Sustainable Development). A lack of

management in the evaluation, provision and use of water resources was identified as the basis

to water problems seen in many countries. Water resources have to be managed to provide

sufficient safe water for drinking, adequate sanitation facilities, food production, industry and

many other purposes; but not removing excessive water to effect the ecological functions of

wetlands and other ecosystems. Good management stems from a clear understanding of water

and the issues facing water. This article aims to increase understanding of water, and more

specifically “groundwater”, on two fronts; firstly, the origins and movement of water, and

secondly the pollution of water.

The Hydrological Cycle

Every year about 110 million million cubic metres of

water falls as precipitation on the land area of the

Earth (Price, 1996). If all the water in the atmosphere

were to fall as rain in one event it would produce an

average of about 25 mm of rainfall over the total surface

of the Earth. In an average year it is estimated that

1000 mm of rain falls over the entire surface of the

Earth, which means about 40 cycles of condensation

and rainfall over a period of a year. This equates to 1

cycle approximately every 10 days, which in the UK

climate is all too believable. If all this water is falling,

and there is no apparent loss of water from the

oceans, then it must be being recycled. This recycling

of water is explained by the water cycle, which is simply

a system of water transferral between stores, wellknown

to readers. The ocean is the largest store of

water, but water molecules may also spend periods of

time stored in ice caps, or in the pore spaces of rocks.

The exception to this is for very small water losses in

the upper atmosphere to hydrogen and oxygen, and

broken down by plants during photosynthesis to help

form carbohydrates.

A large amount of precipitation occurs over the

ocean, and consequently short circuits the water cycle.

Water precipitated over land may take several routes

through the remainder of the cycle. Some will be intercepted

by foliage, and held on the leaves of trees and

plants until it evaporates. Some will fall on impermeable

surfaces such as certain rocks or man made constructions

and can either collects in puddles and

evaporates, or run off into natural or artificial drainage

channels. The remainder of water falls directly on soil,

with movement largely controlled by the soil type and

condition, of which movement can be divided into

three broad groups (Price, 1996):

● Water evaporated directly or by transpiration from

vegetation (Evapotranspiration)

● Run over soil surface (overland flow) or in the near

surface soil (interflow) until it reaches a ditch or

stream

● Or may soak into deeper layers of soil and perhaps

into the underlying rock

If the soil is dry and rainfall is light, all water reaching

the ground will infiltrate into the soil and be held there

as films of moisture which surround individual soil

particles. This water is held in the soil until it is either

evaporated directly or taken up by plants. As each successive

layer of soil absorbs water, infiltration moves on

downward, through the unsaturated zone until the

infiltration reaches the water table and joins groundwater

in the saturated zone. The precipitation that

reaches the water table is termed recharge.

The maximum rate at which water can enter the soil

is called the infiltration capacity of the soil (Price,

1996). If the rain is exceptionally heavy, if the soil has a

low infiltration capacity, or if the ground is already saturated

then a situation can arise where the infiltration

capacity is exceeded. This results in overland flow.

Overland flow is relatively rare and can often flow over

short distances before sinking into soil elsewhere.

If rocks beneath the soil are impermeable, or if there

is contrasting permeability within the soil there will be

a tendency for interflow, where water moves laterally

through the unsaturated zone until arriving at streams

or drains.

Water that reaches the water table becomes groundwater.

So what is groundwater The simplest definition

is that groundwater is water contained in saturated soil

and rock material below the surface of the earth. This

groundwater then percolates slowly though the aquifer

at rates varying from metres per day to millimetres per

year (see Figure 1). The groundwater moves towards an

outlet, which is usually a point where the water table

intersects the ground surface, such as a river or spring


68


or induced by abstraction. These are collectively known

as discharge areas.

Groundwater moves from areas of high hydraulic

head to areas of low hydraulic head. Hydraulic head

comprises of two parameters – elevation and pressure.

At the water table pressure is zero, so elevation defines

hydraulic head, and consequently groundwater moves

from high to low elevation.

So we understand that groundwater moves from

recharge to discharge areas, or from high head to low

head. But how does the water move through the rock

The movement of groundwater through aquifers is due

to either permeability or fractures. The permeability of

a rock is simply how well the pore spaces, or porosity,

are connected. If a rock has a high permeability then

groundwater will flow. The movement of groundwater

through the gaps between grains of a rock is termed

intergranular flow and is the predominant flow

mechanism for sands and sandstone.

The second mechanism for groundwater movement

is via fractures. The chalk of the UK has a high

porosity of about 40%, but a low permeability, due to

the fine-grained nature of the matrix resulting in pore

throats of approximately 1µm. However, the chalk is

heavily fractured and these fractures can allow rapid

transport of groundwater. The fractures contribute to

approximately 1% of total porosity, but almost all the

groundwater yield.

Figure 1:

Groundwater residence time and discharge

(IPR/35-35c British Geological Survey © NERC. All rights reserved.)

Figure 2:

Groundwater usage distribution in the UK

(UK Groundwater Forum)

UK Groundwater Resources

In the UK 28% of our water supply is sourced from

groundwater. However, this usage depends on geographical

position (see Figure 2). In the south of

England up to 72% of water supply is from groundwater,

whereas in Scotland this is as low as 3%. This

high usage, unsurprisingly, coincides with the main

aquifers. The usage is also high in the south and east

due to a high population density reducing the potential

for reservoirs, and a lower rainfall than the northwest.

Approximately 55% of groundwater is

abstracted from the chalk (see Figure 2), and 26%

from the Permo – Triassic sandstones. The remaining

19% is sourced from Devonian sandstone, Carboniferous

and Permian limestone and Cretaceous

sandstone. The use of groundwater is likely to

increase further as population and usage increases

and therefore any contamination of the resource is of

major concern for the supply of high quality drinking

water.

Pollution

The majority of people have seen a polluted stream or

lake. Surface waters are readily vulnerable to pollution

and a contaminated river is visibly obvious. The awareness

of the ease of polluting surface waters, and its high

visibility and consequently priority to the general public,

has resulted in actions to protect them, and for the

water to be treated.

69 www.esta-uk.org


Figure 3:

Potentially

polluting activities

(UK Groundwater

Forum)

Groundwater may not be pure, but it is less vulnerable

to simple pollution as seen in rivers and lakes.

However, this leads to a misconception that groundwater

is invulnerable to pollution. Two factors, perhaps

above all others, have led to a false sense of security over

groundwater pollution. The first is the slow speeds of

typical groundwater movement. From the time a molecule

of water enters the ground as recharge to the time

it leaves the aquifer is rarely less than years, and may be

centuries or millennia (Price, 1996). The second factor

is the enormous capacity of most aquifers to adsorb and

dilute pollutants. This arises from the size and volumes

of water held in storage and from the efforts of dispersion

and adsorption as groundwater flows through the

aquifer by advection. This delays the contaminant

emergence from the ground and often dilutes sufficiently

for no detection. The contamination can then

continue until by the time it is discovered the total

quantity of pollutant in and moving through the aquifer

may be very large. Also the factor of “out of site out of

mind” applies, where any contamination that is not visible

is not seen as a major problem and results in a lower

public awareness of such issues. A consequence of the

groundwater being out of site is that any contamination

is hard to detect and monitor, and the task of cleaning

up a polluted aquifer is enormous.

With increasingly stricter standards required for

water quality and increasingly sensitive detection

equipment the release of contaminants can lead to a situation

where large volumes of groundwater are theoretically

unfit for human consumption. It is therefore

important to take a preventative rather than curative

approach to groundwater pollution.

There is a large range of human activities that can

result in pollution of groundwater. (see Figure 3). The

obvious examples are contamination due to hydrocarbons

(NAPL’s) such as leaky storage tanks at petrol stations

or oil and gas power stations or industrial storage

sites. Another common source of contamination is

from landfill and also septic tanks. All of the above

examples are point source types of pollution. There is

also diffuse source pollution, which can arise from

large areas of land during farming operations. A third

group of pollution arises from line sources, such as

railway sidings or roads where excessive pollutants such

as pesticides or salt are used.

As people’s awareness of pollution improves, and

regulations become stricter, many current practices are

identified as having the potential to pollute the environment.

One such practice is burial sites.

Cemeteries

There are many anecdotal references to cemeteries,

such as a higher incidence of typhoid fever among people

living near a cemetery in Berlin between 1863 and

1867 (Bouwer, 1978) or a “sweetish taste and infected

odour” of water from wells close to cemeteries in Paris,

especially in hot summers (Bouwer, 1978). There has

also been an historical prevalence of placing drinking

wells in close proximity to cemeteries or graveyards. A

quote from Holme (1896), states:

“It is a fact that many wells, conduits and pumps in

and around London were, and still are, in close proximity

to churchyards, or even within them”

“Another [pump] in St Georges [churchyard] was

used for drinking water until the Revd Harry Jones,

during a cholera scare, hung a large placard on it reading

‘dead men’s broth!’”

To understand the potential for pollution from

cemeteries we have to understand the processes that

generate the contaminants, however gruesome it may

appear. There are 5 stages of human body decomposition

recognised:

1. Fresh

2. Bloat

3. Active decay

4. Advanced decay

5. Dry skeletal remains


70


The decay process begins as early as half an hour after

death, with muscular flaccidity, desiccation (dull eyeballs)

and hypostasis (drainage of blood under gravity).

A human corpse normally decays totally within a period

of 10-12 years with over half of the contaminant

loading leached within the first year of decomposition.

This gives each human body an approximate contamination

life span of 10 years, depending on prevailing

conditions such as temperature, chemical conditions

surrounding material.

The degradation of a human body is analogous to a

landfill filled with putrescible waste, with a couple of

minor exceptions, and is principally controlled by

microbial decay. The principle outputs for a landfill

containing putrescible waste is summarised in Figure

4. Decomposition begins when aerobic bacteria get to

work. The action of these bacteria consumes the oxygen

that was incorporated in the waste and produces

carbon dioxide. This first stage of decomposition usually

takes from a few weeks to a few months (Phase I).

When the oxygen has been consumed, anaerobic bacteria

take over and produce more carbon dioxide and

fatty acids. Methane also begins to be produced. There

is large-scale settlement in Stages I and II. In Stage III

the fatty acids are themselves broken down to produce

more methane. Stage IV is an equilibrium phase

where the landfill or body acts as a natural bioreactor.

The characteristic feature of this stage is the generation

of relatively constant levels of methane and carbon

dioxide. This only ends when the putrescible

component source is exhausted (Stage V) and aerobic

conditions return. At the same time there is gas produced,

inorganic material contribute to the composition

of leachate.

The principal differences between a landfill and

decomposition of a human body are that the ratio of

Carbon to Nitrogen to Phosphorous (30:3:1) in a

human body provides a good balance between the principal

microbial nutrients. Landfills are generally deficient

in Phosphorous. Also, more importantly, the rate

of leachate production in a grave is far higher than in a

landfill. Modern landfills are designed with low permeability

clay caps to reduce the amount of precipitation

infiltrating into the landfill, which helps to reduce the

amount of leachate produced. Graves are not, and they

actually act as preferential channels for infiltration as

they are filled with disturbed material. Secondly a

human body contains nearly double the amount of

water found in an average landfill, also aiding to

leachate production. Therefore, human bodies decompose

more efficiently than putrescible waste in a landfill,

with the process generating leachate containing the

following main contaminants:

● Organic compounds

● Ammonical nitrogen and nitrate

● Principle mobile anions (Chloride and Sulphate in

particular)

● Alkali earth metals (NA, K, Ca, Mg, Fe etc)

● Pathogens (Staphylococcus aureus, Bacillus cereus,

Clostridium perfrigens)

● Viruses (Enteroviruses, Polioviruses, Echovirus,

Hepatitis A, Reovirus and Rotavirus)

Pollution Risk from Cemeteries

We have seen that bodies decompose and produce a

range of contaminants, but are these contaminants likely

to become a source of pollution Modern landfills

generally have a low risk of pollution because their pollution

potential is well recognised and suitable measures

are in place. As mentioned previously, modern

landfills have low permeability clay caps to reduce infiltration

(see Figure 5).

Landfills also have a clay liner at the base that is engineered

to a low permeability (10 -9 m/sec) and often a

Figure 4:

Organic and nonorganic

products

from a putrescible

waste landfill

Figure 5:

Modern

Landfill design

(UK Groundwater

Forum)

71 www.esta-uk.org


Figure 6:

Mechanisms for

dispersion in the

saturated zone

synthetic liner on top of even lower permeability. This

acts to contain all leachates, which can then be removed

if required. A down side to this is that it can hinder

decomposition, but it does reduce risk of a pollution

incident.

This type of precaution is not seen at cemetery sites,

yet there are over 200,000 burials per year (Young et al,

2001), which equates to 12,000 tonnes of decomposing

material (based on average body weight of 60kg). However,

if burials were so contaminating then there would

be widespread pollution as a result, and awareness

would be high, as seen with landfills. This lack of

awareness is either due to a lack of research in correlating

pollution incidences with cemeteries or that the

contaminants are attenuated. The attenuation of contaminants

has much to do with the environment in

which the burial occurs. As mentioned earlier a grave

acts as a conduit for infiltration, due to the presence of

disturbed infilled material. This infiltrated water then

can dissolve and react with the products of degradation

to produce the leachate. What happens next The

movement of leachate from the grave “cell” is primarily

determined by the surrounding strata and geology,

with 3 principle components of pathways from the

grave:

● The soil surrounding the burial

● The unsaturated zone of the underlying aquifer

(if present)

● The saturated zone of the aquifer (if present)

The principle characteristics of each pathway are:

1) Soil Pathways: Soils are often more complex in

terms of composition, chemistry and biological

activity than the underlying rocks or sediments from

which they are derived. They may be the site of

intense biochemical reactions, so that contaminants

may undergo change as they pass through them. Air

access to soils is generally good and likely to be aerobic,

unless waterlogged, and this encourages oxidation

of pollutants (i.e. Ammonia to nitrite and

nitrate). The physical processes of filtration, adsorption,

absorption and cation exchange are all important

attenuating processes.

2) Unsaturated zone pathways: These zones are generally

less chemically and biologically active than the

overlying soils. The rate of re-oxygenation from the

surface is lower than in soils and anoxic conditions

may develop. Nevertheless, chemical and biochemical

reactions may continue to immobilise pollutants,

whilst filtration, adsorption and cation exchange

may continue to immobilise pollutants and some

dissolved pollutants.

3) Saturated zone pathway: Once in the saturated zone

the contaminant begins to follow the regional

groundwater movement (depending on relative densities

of water and contaminant). The contaminant is

transported with the groundwater by advection. The

groundwater/contaminants are subject to dispersion

(see Figure 6), and is the principle cause for dilution

in the saturated zone. There are additional factors

such as chemical and biological reactions, or filtration

and diffusion.

From this we can see how important the unsaturated

and saturated zones are in attenuating the pollutants

from a burial and that the potential for a cemetery to

pollute is often largely dependent on the vulnerability

of the soil, unsaturated zone and groundwater (see

Figure 7). A thin sandy soil (little material for chemical

reactions), a thin unsaturated zone and highly fractured,

rapid transport aquifer would be highly

vulnerable to pollution; whereas a thick clayey/organic

rich soil, with thick unsaturated zone and deep

water table offers good protection of groundwater

from contamination.

The potential risk from many of the contaminants is

well documented, and their attenuation in aquifers is

relatively well known. However, the study of bacteria

and virus transport in aquifers is relatively new. Studies

have shown several microbial contaminants in the

groundwater associated with cemeteries. One of the

most significant was Staphylococcus aureus, and is a bacteria

commonly associated with human decomposition.

Other potentially harmful bacteria resulting from

human decay are Bacillus cereus and Clostridium perfrigens.

There are also a series of potentially harmful viruses

such as: Enteroviruses, Polioviruses, Echovirus,

Hepatitis A, Reovirus and Rotavirus.

Most enteric pathogens die within 2-3 months once

outside the human gut, however, under cold conditions

they could survive up to years. Enterovirus survival has

been reported to range from 25 to 170 days. There is,

however, a lack of research and consequently understanding,

into firstly the potentially harmful microbes

produced from decomposition, and secondly the


72


mobility and survival of these microbes in groundwater.

An understanding of these factors needs to be considered

before an assessment of the potential risk from

bacteria and viruses resulting from decomposition can

be made.

Conclusions

An increased awareness of water – from a resource perspective

and a pollution perspective – is critical for sustainable

development. Water is continuously recycled as

part of the water cycle, of which groundwater is just one

part. The movement of water through the ground

occurs by two mechanisms; firstly water moving

between grains of material, termed intergranular flow,

and secondly water moving along fractures, termed

fracture flow. In the UK there is a large dependency on

groundwater in southern England (72%), and a low

dependency in Scotland (3%). This is primarily due to

the location of the main water bearing units, or

aquifers, in southern and central England, but also

because of the high population density in southern

England reducing space available for reservoirs.

Groundwater can be polluted by a wide range of

activities, either from a small aerial area, point source;

from a large aerial area, diffuse source; or from a line

source. An increasing understanding of pollution has

helped identify many previously unthought-of potentially

polluting activities, one of which is cemeteries. A

human body decomposes in 10-12 years, depending on

prevailing conditions. For this period the human body

acts as a potential contaminant source, with ammonia,

organic compounds, bacteria and viruses being some of

the products. The surrounding soil, unsaturated zone

and saturated zone control the movement of these contaminants

with the lowering of contaminant concentrations,

or attenuation, largely occurring in the soil zone

due to complex composition and chemistry allowing

biochemical reactions, chemical reactions, filtration,

and adsorption. In the saturated zone, attenuation of

contaminants is principally controlled by dispersion

within the main groundwater flow. There are many

unknowns in contamination arising from cemeteries,

principally the presence and movement of bacteria and

viruses, and therefore continued research is required to

improve understanding and help towards the management

of the “fundamental resource for sustaining life

and for conserving the natural environment”.

Mike Lelliott

British Geological Survey

Keyworth

Nottingham

NG12 5GG

Tel. 0115 936 3206

mlell@bgs.ac.uk

Figure 7:

Vulnerability of

groundwater

(UK Groundwater Forum)

References

Price, Mike (1996) Introducing Groundwater. 2nd edition. Stanley Thornes

Ltd.

Ward, R.C & Robinson, M. (2000). Principles of Hydrology. 4th Edition.

McGraw-Hill.

Young, C.P., Blackmore, K.M., Reynolds, P & Leavens, A. (2001).

Pollution Potential of Cemeteries. R&D Project Record P2/024/1.

Young, C.P., Blackmore, K.M., Reynolds, P & Leavens, A. (2001).

Pollution Potential of Cemeteries. R&D Technical Report.

Holmes, B. (1896). The London Burial Grounds. T Fisher Unwin

Bouwer, H. (1978). Groundwater Hydrology. McGraw-Hill

73 www.esta-uk.org


Mass Extinctions:

The Alternatives to “Deep Impact”

ROSALIND V. WHITE

This article is based on a presentation given to an INSET meeting for Post-16 Geology teachers at

the ESTA Annual Course and Conference, Keyworth, September 2002.

“Earth’s biggest mass extinction 251 million years ago was triggered by a collision with a comet

or asteroid, US scientists say.” (BBC News website, 23 February 2001)

“A huge outpouring of molten rock 250 million years ago may have been the decisive factor in the

deaths of nearly all lifeforms on the Earth at that time.” (BBC News website, 6 June 2002)

Figure 1.

The five mass

extinctions of the

Phanerozoic (after

Sepkoski, 1984).

Confronted with openly conflicting headlines

such as this, how should teachers react One of

the main difficulties facing post-16 students is

the realisation that science is an active process that,

instead of giving “correct” answers, just yields a reasonable

theory that fits the evidence we have at any particular

time. This is especially true of topics on the AS/A2

syllabus that are also the focus of active research at university

level. Less-than-impartial media reporting of

new advances can add to the confusion. This article

gives an overview of the possible reasons for mass

extinctions at the Permo-Triassic and Cretaceous-Tertiary

boundaries, and outlines recent developments in

research on the Permo-Triassic extinction.

What is a mass extinction

It is important that students understand the distinctions

between death, extinction, and mass extinction. Death

is an issue affecting individuals, with a 100% probability

per organism. Extinction occurs for a particular

species when the death rate exceeds the birth rate for a

sufficiently long period. Extinctions happen all the

time: the vast majority of species that have ever inhabited

the Earth are now extinct. The rate at which species

replace one another due to factors such as competition

is known as “background extinction”.

At some times in geological history, the extinction

rate increases markedly above this background level,

and this is known as a “mass extinction”, defined as the

extinction of a significant proportion of the world’s

biota in a geologically insignificant period of time. Of

course, we can then argue about the meaning of the

word ‘insignificant’, but for the purposes of this article,

the term “mass extinction” is reserved specifically for

the five most significant events of the last 500 million

years (see Figure 1).

Causes of mass extinctions: killing mechanisms

Surprisingly, there are actually only a handful of ways to

die: by direct physical trauma; via poisoning; through

starvation; or by suffocation. It’s possible to reclassify

all sorts of other deaths into these categories, e.g., death

from old age could be as a result of being physically

unable to collect or eat food (starvation) or inability to

breathe (suffocation), and death from disease could

potentially kill by any of the four mechanisms. However,

to cause a mass extinction, we need to kill millions of

individuals (or stop them reproducing), all within a relatively

short period of time, so we need a mechanism

that can cause direct physical trauma, poisoning, suffocation

or starvation on a massive scale. Because of the

apparent need for a catastrophic driving force, much of

the recent research has focused on two scenarios: meteorite

impact, or massive scale volcanism.

The K-T impact

In 1980, Alvarez proposed that a meteorite impact was

responsible for the Cretaceous-Tertiary (K-T) mass

extinction. This proposal was based primarily on the

presence of elevated iridium concentrations (“iridium

anomalies”) in rocks at the K-T boundary. Iridium is a

siderophile (iron-loving) element that is very rare in

crustal rocks, but is much more abundant in certain

classes of meteorite. Over the subsequent two decades,

more evidence for an impact was amassed, including


74


tektites (once-molten droplets), shocked quartz,

stishovite and microdiamonds (high pressure minerals),

soot from wildfires, and exotic minerals (e.g.,

spinels). This data-gathering culminated in the discovery

of a ~180-km-diameter buried crater at Chicxulub,

located on the Yucatan Peninsula of Mexico. A crater

this large would have been caused by an impactor

roughly 10 km in diameter, and the impact would have

had devastating effects on life.

Impact Winter

What would have happened when the meteorite hit

The scenario painted is gloomy. A fireball scorched

everything in its path, and violent tsunami and widespread

wildfires occurred. There would have been a

lengthy period when sunlight was obscured by dust

particles, reducing temperatures, hindering photosynthesis

and resulting in breakdowns in the food chain.

The meteorite landed on (and vaporised) gypsum and

limestone, injecting sulphur dioxide and carbon dioxide

into the atmosphere. The sulphur dioxide resulted

in acid rain, and excess carbon dioxide contributed to

greenhouse warming.

At the present day, even though most geologists are

convinced that there was a meteorite impact at the K-T

boundary, and believe that its environmental effects

would have been severe, discussion continues about

what actually caused the K-T extinction. For example,

on 31 August 2002, the BBC News website reported

that “Cold was killing dinosaurs long before the asteroid

commonly thought to have been their downfall hit,

according to scientists.”

Flood basalt volcanism

The major thorn in the side of the impact theory is the

fact that a meteorite impact was not the only catastrophic

event to affect the Earth in Cretaceous-Tertiary

times. In India, a vast “flood basalt” volcanic province

called the Deccan Traps was being erupted. The current

consensus amongst geologists is that flood basalts are

the result of melt generation in mantle plumes: convective

upwellings of anomalously hot material in the

underlying mantle. Estimates of the original volume of

the Deccan Traps are in the range of 1 to 2 million cubic

kilometres, enough to cover the United Kingdom in a

layer of lava 4-8 km thick! Individual eruptions may

have lasted about a decade, with periods of quiescence

lasting for centuries or millennia between eruptions.

What was even more problematic for those advocating

a meteorite impact as the sole cause of the K-T

extinction was the observation that other mass extinctions

also seemed to be temporally linked with the

eruption of flood basalt provinces (see Figure 2). The

biggest mass extinction of all, the Permo-Triassic (P-Tr)

extinction, coincides exactly with the eruption of the

Siberian Traps, and work published in 2002 shows that

this province is twice as large as had previously been

thought. Another example is the Triassic-Jurassic (Tr-J)

extinction, which was contemporaneous with eruption

of the Central Atlantic Magmatic Province, 200 million

years ago.

Volcanic Winter

What would the Earth have been like during this massive

scale volcanism Dust and ash were thrown up into

the atmosphere, together with tiny aerosol droplets of

sulphuric acid derived from volcanic sulphur dioxide

gas. These particles obscured sunlight, possibly for

months or years on end, reducing temperatures and

hampering photosynthesis. The sulphuric aerosols ultimately

fell back to the ground as acid rain. Lava set fire

to vegetation, causing wildfires. Toxic fumes derived

from fluorine and chlorine resulted in local poisoning.

Carbon dioxide was injected into the atmosphere, contributing

to greenhouse warming on longer timescales.

And the worst of it is, just when things were recovering,

there would be another eruption, and it would all happen

again.

Volcanism or impact

As you can see, the effects of large volcanic eruptions

and meteorite impacts are potentially fairly similar.

This means that discussions of their environmental

effects, while interesting, are not a particularly good

way of deciding what actually caused the extinctions.

We are called upon to make judgements about whether

one serious event would be more serious than the

cumulative effects of lots of smaller events.

Unfortunately, because we are dealing with evidence

that is millions of years old, there are many pieces of the

jigsaw missing, and with the available data it’s impossible

for either side to prove their case. This resulted in an

uneasy stand-off, with volcano-theory supporters conceding

that, in the case of the K-T, the “impactors” had

a good case, but maintaining that the Deccan Traps

must surely have had some significant effect. They also

pointed out that the impact theory doesn’t seem very

good at accounting for the other extinctions, which

must, therefore, be volcanism-related. The impact-the-

Figure 2.

Timing of eruption

of flood basalt

provinces

compared to the

rate of extinctions.

The three largest

extinctions all

correlate with

flood basalt

activity, but the

lack of extinctions

associated with

other flood basalts

demonstrates that

flood basalts do

not, on their own,

necessarily cause

mass extinctions.

75 www.esta-uk.org


ory supporters, meanwhile, were busily searching for

evidence of impacts at other mass extinction horizons.

Impact at the P-Tr and Tr-J boundaries

In the mid-eighties, the first paper claiming to have

found an iridium anomaly at the P-Tr boundary was

published, but subsequent work found the anomalies

to be insignificant, or non-existent. More recently, in

February 2001, the British national newspapers proclaimed,

“Comet killed life before dinosaurs”, and the

debate about an impact at the end of the Permian

recommenced. The articles arose from reports of

fullerenes (carbon ‘buckyballs’) in P-Tr boundary sediments;

the fullerenes contain trapped noble gases

with isotopic ratios indicative of an extraterrestrial

source. These results are highly controversial:

attempts to replicate them have so far been unsuccessful,

and the experimental details of the original work

have also been questioned.

For the Tr-J extinction, early searches for iridium

If there really were large life-threatening impacts,

even if the craters themselves have been subducted or

destroyed by tectonism, the fallout would have been

global, and I’m sure we’ll see a steady stream of

supporting evidence published over the next few years

anomalies were negative. However, a paper published

in 2002 reports a small iridium anomaly, indicating that

a small bolide impact occurred at this time.

Likelihood of meteorite impacts

My personal view is that I remain to be convinced that

significant meteorite impacts occurred at these other two

extinction horizons. That isn’t to say I don’t believe it –

I am keeping an open mind! The key issue here (again)

is the meaning of the word ‘significant’. If there really

were large life-threatening impacts, even if the craters

themselves have been subducted or destroyed by tectonism,

the fallout would have been global, and I’m

sure we’ll see a steady stream of supporting evidence

published over the next few years. Then I’ll probably

believe it. The reason for my scepticism is that smaller

impacts happen fairly frequently, geologically speaking,

and discovery of their products in the relevant time

interval doesn’t prove anything about whether they

were large enough to cause extinctions.

Take, for example, the story of Manicouagan Crater

in Canada. It is 100 km in diameter, and was once considered

a very likely suspect for the Triassic-Jurassic

extinction, at 200 Ma. However, when the crater was

dated, it turned out that it was 14 million years older

than the extinction, so could not have been the cause.

And what’s more, there is no mass extinction at 214 Ma,

so impacts causing craters as large as 100 km across

don’t necessarily cause extinctions.

We don’t know exactly how often impacts of different

sizes occur. Geologists estimate impact frequencies by

counting craters of different sizes on parts of the Earth’s

surface unaffected by tectonism, and the results from

this agree fairly well with astronomers’ estimates

derived from counting bodies with Earth-crossing

orbits. However, the errors are large – something like a

factor of two. Nevertheless, as more craters and Earthcrossing

bodies are discovered, it seems that the original

1980 estimate of a 100-million-year repeat time for

a K-T-sized impact is an overestimate. Estimates of

impact frequency published within the last five years

yield a repeat time of only ~30 million years for a K-Tsized

impactor, and 100-km craters would form even

more frequently – every 10 million years or so.

Do meteorite impacts cause flood basalt volcanism

If claims for meteorite impacts at the P-Tr and Tr-J

boundaries turn out to be true, and each of the three

main extinctions correlate with both an impact and a

flood basalt, does that mean that flood basalts are also a

consequence of meteorite impacts After all, doesn’t it

seem rather unlikely that impacts and flood basalts

would coincide on three occasions if they were not

linked in some way Although this idea has been aired

in the media, it is only believed by a minority of geologists.

Originally proposed for the K-T impact and the

Deccan Traps, it does not adequately explain our observations:

the discovery of the iridium-rich layer between

lava flows of the Deccan Traps indicates that the lavas

started erupting well before the meteorite hit. Moreover,

the Deccan Traps were not at the impact site, and

contrary to some claims, they weren’t directly opposite

it either.

In fact, because both impacts and flood basalts are

more common than they are perceived to be, random

chance is capable of explaining away a few coincidences

between impacts and flood basalt volcanism. This

analysis is dependent on the size of impact chosen:

because smaller impacts are much more common, a

few coincidences between flood basalts and, say, 100-

km craters are entirely credible. If, however, evidence

comes to light that several flood basalts correlate with

200-km craters, I may have to reconsider my opinion!

“Meteorites vs. volcanoes” oversimplifies the story

Of course, in reality, it’s much more complicated than

choosing between impacts and volcanoes. At the P-Tr

boundary, for example, there’s evidence of other

adverse environmental conditions. Discovery of pyrite

in shallow water sediments demonstrates that the shallow

oceans were oxygen-deficient (anoxic) – in which

case, many organisms would have suffocated. This

oceanic anoxia was probably a consequence of global

warming, which reduced the pole-to-equator temperature

gradient and made ocean circulation sluggish. This

global warming may, in turn, have been caused by CO2

release from the Siberian Traps, or from an impact site.


76


Additionally, warmer ocean waters may have triggered

the catastrophic release of methane hydrate from

continental shelf sediments. Methane hydrate is a white

crystalline substance consisting of CH4 molecules

trapped in a structure of H2O ‘cages’. It is stable only

when temperatures are low and pressures are high, and

forms in sediments where decay of organic matter by

anaerobic bacteria results in high methane concentrations.

If released during an interval of global warming,

it contributes strongly to the positive feedback loop:

methane is a much more potent greenhouse gas than

carbon dioxide. Evidence supporting an interval of

methane hydrate release at the P-Tr boundary comes

from changes in the carbon isotope composition of

ocean water (see White, 2002 for further reading).

Conclusions

At least three of the major mass extinctions of the last

600 million years appear to be temporally correlated

with flood basalt volcanism, meteorite impact, or possibly

both. However, we should not confuse ‘correlation’

with ‘causation’. Correlation is easy to prove, but causation

very difficult. Flood basalts and meteorite

impacts are both much more common than mass

extinctions, implying that neither type of event routinely,

on its own, causes mass extinctions. Instead, it

seems that mass extinctions only occur when Earth is

attacked on more than one front, or when it is already

in a vulnerable state.

Catastrophic events such as meteorite impacts and

massive volcanism provide an attractive means of

explaining mass extinctions. We should be wary, however,

about assuming that catastrophic outcomes necessarily

require catastrophic stimuli. Because of positive

feedback loops in the Earth’s biological and climatic

systems, particularly those related to global warming,

small perturbations in conditions may become amplified,

and may potentially lead to catastrophic changes.

This is important, because humans are currently contributing

CO2 to the atmosphere at a rate that, in geological

terms, is unprecedented. If we continue at this

rate for a couple of thousand years, we will have exceeded

the entire CO2 budget of the Siberian Traps. That’s

quite a scary thought. Are we forcing the Earth into a

vulnerable condition, such that a meteorite impact, if

(or when) it occurs, will push us over the edge

Catastrophic events such as meteorite impacts and

massive volcanism provide an attractive means of

explaining mass extinctions. We should be wary,

however, about assuming that catastrophic outcomes

necessarily require catastrophic stimuli.

Further Reading

Alvarez, L. W., Alvarez, W., Asaro, F. & Michel, H. V.

(1980) Extraterrestrial cause for the Cretaceous

Tertiary extinction. Science 208, 1095-1108.

Becker, L., Poreda, R. J., Hunt, A. G., Bunch, T. E. &

Rampino, M. (2001) Impact event at the Permian-

Triassic boundary: Evidence from extraterrestrial

noble gases in fullerenes. Science 291, 1530-1533.

Hallam, A. & Wignall, P. B. (1997) Mass extinctions and

their aftermath. Oxford University Press.

Reichow, M., Saunders, A. D., White, R. V., Pringle,

M. A., Al’Mukhamedov, A., Medvedev, A. & Kirda,

N. P. (2002). 40 Ar/ 39 Ar dates from the West Siberian

Basin: Siberian Flood Basalt Province doubled.

Science 296, 1846-1849.

Sepkoski, J. J., Jr. (1984) A kinetic model of

Phanerozoic taxonomic diversity. III. Post-Paleozoic

families and mass extinctions. Paleobiology 10, 246-269.

White, R.V. (2002) Earth’s biggest ‘whodunnit’:

unravelling the clues in the case of the end-Permian

mass extinction. Phil. Trans. Royal Soc. London A

360, X-XX (in press). Copies available (pdf files) by e-

mailing the author.

A Powerpoint version of this presentation is

available on request by e-mailing the author.

Rosalind V. White

Royal Society Dorothy Hodgkin Research Fellow

Department of Geology

University of Leicester

University Road

Leicester

LE1 7RH

e-mail: rvw1@le.ac.uk

Telephone: 0116 252 3315

Fax: 0116 252 3918

77 www.esta-uk.org


Fossils Under the Microscope

IAN WILKINSON

Micropalaeontology is a subject that is not as widely taught as macropalaeontology - everybody

has heard of trilobites, brachiopods and corals, but how many know of the existence of acritarchs,

coccoliths or ostracods Although many organisms really are microscopic (a few microns in

length), I will stretch the term to include fossils up to about 1500 microns across. It is an

impossible task to describe all types of microfossils in the Earth’s rocks, but I give a taster of

some of the more common. Microfossils from five kingdoms (see Figure 1) are studied and

applied in finding solutions to geological problems in stratigraphy and palaeoecology. Although

microscopic, it is not beyond the scope of schools to find at least some of these fossils.

Figure 1.

The relationship

of common

microfossils to

kingdoms and cell

type. (Note that

some authors

prefer to use the

term Protoctista

rather than

Protista as the

latter has been

used primarily for

single celled

organisms.)

Plants

Spores

Pollen

Eukaryotes

Prokaryotes

Finding microfossils

Microfossils can easily be extracted from marine,

Mesozoic, Tertiary and Quaternary mudstones, siltstones

and finer sandstones, particularly softer ones

such as the Oxford Clay, Kimmeridge Clay, Gault and

Speeton Clay. Softer chalk can also be disaggregated to

liberate microfossils. However, a little care will be

required as chemicals are involved. Soak the sediment

in (flammable!) white spirit for half an hour then drain

it off through filter paper to be used again. Wash the

sample through a 75 micron (or smaller) sieve; add to

warm water with washing soda and bring the water to

the boil (care required!). Allow it to cool before washing

it again through the sieve. When dry, the residue can

Fungae

Spores

Fruiting Bodies

Protista

Acritarchs

Dinoflagellates

Coccolithophores

Radiolaria

Diatoms

Foraminifera

Algae

Monera

Bacteria

Animals

Conodonts

Ostracods

Chitinozoa

be viewed best through a binocular microscope. Cross

contamination of samples is a danger with microfossils

and all equipment must be thoroughly cleaned after

each sample. Ostracods, foraminifera, radiolaria and so

on will be found with low-powered binocular microscopes

at X10 or X20 magnifications. Other microfossils

are probably beyond the scope of the equipment

found in many schools as more specialised preparation,

including acids, is needed and then high magnification

microscopes are required.

Those schools some distance from suitable rocks

might try modern pond, lake, estuarine or coastal sediments,

where similar organisms can be found. Modern

sediments are the easier to deal with. Soak them in

warm water with teepol or washing soda, before washing

them on a 75 micron sieve to remove all the fine

muds. Allow to dry. Examine the washed sediment

through a binocular microscope at X10 or X20 magnification

to see foraminifera and ostracods, in marine

and estuarine sediments, or ostracods, diatoms and

charophytes in lake and pond sediments.

At the end of this article I give 14 separate summary

boxes to show the range of microfossils across all five

kingdoms.

Kingdom Monera

The history of life begins with the evolution of Kingdom

Monera, and stretches back almost to earliest of

Earth’s preserved rocks. Kingdom Monera is based on

the prokaryote cell. These lack membrane bounded

organelles (such as mitochondria and chloroplasts) and

a nucleus with chromosomes. Some may have a simple

flagella composed of the protein flagelin.

There is often debate whether putative microfossils

are actually mineral growths (remember the Martian

‘microfossils’). The oldest undoubted fossil bacteria is

from the 3,465 million year old Apex Chert from Australia,

but there is some dispute whether older ‘microfossils’

are truly biotic. Bacteria must have passed

through a phase of non-biological evolution before

evolving into chemautotrophs and later into the more

advanced photosynthesising organisms. The fact that


78


Banded Ironstones began to develop about 3,500Ma

indicates when photosynthesis had evolved.

Blue-green cyanobacteria (formerly known as bluegreen

algae) began to evolve a little later and by

3,000Ma were removing CaCO3 from seawater during

photosynthesis. Stromatolites, thin calcareous mats laid

down one on top of the other by blue green cyanobacteria

form domes, sometimes several metres in height

and 3,000 million years later living representatives are

doing exactly the same thing at Shark Bay in Australia!

The evolution from Prokaryotes to eukaryotes was

probably the most significant step in the evolution of

life. All living organisms (with the exception of Monera)

are based on the eukaryotic cell structure. Eukaryotes

are aerobic and so could only have evolved after

oxygen had built up in the atmosphere. They had a larger

cell than the prokaryotes, with a membrane-bounded

nucleus containing chromosomes of DNA and

RNA and proteins. The eukaryotic cell also contained

membrane-bounded organelles (such as mitochondria).

The composition of the flagella (undulipodia) is

complex, being composed of tubulin and other proteins.

It has been suggested that the eukaryote cell

evolved by the symbiotic relationship of a number of

different prokaryotic cells. So Kingdom Protista had

evolved.

Kingdom Protista

Exactly when eukaryotes evolved is questionable.

There is good fossil evidence of their existence 900-

1,000 million years ago and there is strong evidence that

they were probably around 1,500 million years ago.

However, recent geochemical study on 2,700 million

year old shales has found eukaryote lipids, which if correct,

pushes the origin of the eukaryotes even further

back in time.

The Kingdom Protista is difficult to define and it is

easiest to say what it is not, rather than what it is. They

are not animals because they do not develop from blastula

(a hollow sphere of cells formed from the cleavage

of an ovum). They are not plants as they do not develop

from an embryo (e.g. within a seed). They are not

fungi as they have undulipodia (flagella for locomotion)

and do not develop from spores. They are not Monera

as they have a eukaryote cell structure. In other words,

they have none of the characteristics of more advanced

eukaryotic kingdoms.

Kingdom Protista is perhaps the single most useful

kingdom in the micropalaeontologist’s armoury. Of

course, in the palaeontological record, only protistids

that secreted a skeleton or went through an encysting

stage were normally fossilised. There were a number of

encysting organisms, including acritarchs and dinoflagellates,

but other protists secreted a calcareous skeleton

(such as various forms of algae, including

coccoliths, and foraminifera) or a siliceous skeleton

(such as radiolaria and diatoms).

Protista are important tools in the more applied side

of palaeontology (biostratigraphy and palaeoenvironmental

reconstruction). Dinoflagellate cysts are particularly

useful in dating organic-rich rocks, in which they

are found in abundance, and they have been particularly

useful in hydrocarbons exploration. Coccoliths are

also useful for biostratigraphical studies, particularly

through the Mesozoic and into the Tertiary, while

acritarchs and foraminifera can be used throughout the

Palaeozoic and through to the Quaternary. The history

of Radiolaria extends back into the Palaeozoic, but they

are useful as biostratigraphical markers particularly in

the Late Jurassic and in the Tertiary.

Diatoms are useful in several respects. In some cases

huge numbers of diatoms were deposited to form a sedimentary

rock called a diatomite (with industrial applications

in, for example, sugar refining, toothpaste

manufacturing, as a mild abrasive and in paint production).

However, their scientific application is in environmental

reconstruction. Fresh water diatoms can be

useful in monitoring the acidification of lakes as certain

species are affected by pH. By logging the species present

in sediments of different ages, it is possible to see

the effects of industrial pollution.

Algae are frequently single celled, but there are many

instances where they are multicelled (seaweeds, for

example). The single celled algae are generally considered

to be protista, but the multicelled algae are sometimes

considered to be members of the plant kingdom.

Undoubtedly the earliest plants evolved from multicelled

algae, probably the ‘green algae’, the chlorophytes,

but the definition of the plant kingdom, must

preclude them.

Kingdom Plantae

The plant kingdom comprises multi-celled, sexually

reproducing eukaryotes that develop from an embryo

(e.g. within a seed). The cell contains photosynthetic

organelles called chloroplasts that contain chlorophyll,

and its walls are composed of cellulose and pectins.

With the appearance of the plant kingdom from their

algal forebears, so spores and pollen became common

microfossils. The earliest spores are Mid Ordovician in

age (465-470 million years old) and probably produced

by bryophytes. The earliest fossilised plants are vascular

types (e.g. Cooksonia), which evolved in the Late Silurian.

They rapidly diversified so that by the Carboniferous

the first tropical rain forests had developed.

One of the difficulties that need to be faced in

palaeontology is where different parts of a single organism

are given different names. This is seen in palaeobotany

where the stem, leaf, root and pollen or spores of

a single plant are given different names. Although the

stems and leaves of plants do not fall within the definition

of microfossils, the spores and pollen do.

Spores and pollen are important microfossils for dating

and correlating terrestrial, lacustrine and marginal

marine sediments and for providing palaeoenvironmental

information. An example of how pollen can be

79 www.esta-uk.org


used in palaeoenvironmental reconstruction comes

from Eemian (Pleistocene) lake sediments of southern

England. Pollen from sediment cores show that with

the retreat of the ice, cold birch forests with abundant

small herbs and shrubs were established. With continued

amelioration pine colonised southern England and

then as the climatic optimum approached, elm, oak,

alder and hazel pollen began to appear in the sediments.

Climatic deterioration then set in re-establishing first

the pine forests and then the birch.

Kingdom Fungi

This kingdom contains eukaryotic organisms that

reproduce by spores. Reproductive structures may be

microscopic or macroscopic (mushrooms for example).

Reproduction is mainly sexual, the hyphae fusing

together, but a few produce only asexual spores.

Whichever stratagem is used, the hyphal nuclei are haploid.

However, they lack flagella in all phases of their

life cycle. Fungi are aerobes and heterotrophs. They do

not ingest food, but excrete enzymes that break down

the food into molecules outside the organism, before

absorbing it.

Fossil spores and fruiting bodies of fungus have been

found in rocks as old as the Devonian, although they are

not widely studied and do not form an important element

in the biostratigrapher’s armoury. I mention them

here for completeness.

Kingdom Animalia

The animal kingdom comprises multicelled, eukaryotic

organisms. They are heterotrophic (obtaining energy

from organic compounds), diploid (cells with a nucleus

containing two sets of chromosomes) and anisogamous

(gametes of different morphology, ova and

sperm). The diploid zygote develops by mitosis and

forms an embryo resembling a hollow ball of cells

(blastula) before progressing to the foetus. There are

several microscopic members of the animal kingdom

that are found as microfossils.

Ostracods, for example, are small bivalved crustacea.

The origin of ostracods is obscure because the soft bodies

of some Cambrian ‘ostracods’ have occasionally

been preserved intact, and prove that they are neither

ostracods (as discussed by Mark Williams elsewhere in

this volume p.89) nor, in some cases, crustacea. They

have applications in biostratigraphy, but as different

species live in a wide variety of environments, they are

also useful in palaeoenvironmental reconstruction and

modeling. Ostracods (together with Foraminifera) have

been particularly useful in studying climate change.

Different taxa have differing requirements and this can

be used to model palaeoclimates. In addition, all species

take up oxygen when forming their carapace during life

and an oxygen isotope ‘finger print’ is left that can be

used in palaeoenvironmental studies.

In the Palaeozoic, it is not unusual to find organisms

of uncertain affinity. Chitinozoa, for example, are

extinct flask-shaped organisms that are said by some

palaeontologists to have been related to foraminifera,

others have suggested they are egg cases, and yet others

considered to be related to an unknown animal. In fact

nobody is certain what they are related to and they are

often placed into ‘incertae sedis’.

Another animal that has caused a great deal of scientific

debate regarding its relationships is the conodont.

These are found as small teeth-like structures in

Palaeozoic rocks. Although first described as long ago as

1856, it was not until 1983 that palaeontologists knew

what the conodont animal looked like. These small

teeth came from the mouth of an eel-like animal, possibly

a distant relation of the hag fish. However, one of

the fundamental problems in palaeontology is illustrated

here. Different species and genera of conodont have

been erected on the basis of the different morphologies

of their tooth-like structures. Only when the whole

animal was found did palaeontologists realise that different

genera and species of conodont were found

together in a single creature. A taxonomic can of worms

was opened-what should the animal be called What

genus should it be put in

Conclusion

Microscopic life began with the prokaryotic cell when

monera evolved early in the Earth’s history. From these

the eukaryotic cell evolved and with it the protista, a

kingdom that experimented with multicellular body

plans. Some protista show a relationship with plants

(e.g. algae and dinoflagellates) and others with animals

(e.g. foraminifera). It was from protista that the three

other eukaryotic kingdoms evolved, plants, animals and

fungi, all with microscopic representatives preserved as

fossils (see Figure 1). A brief description of some of the

more common types of microfossils are appended in a

series of boxes.

Microfossils are not only important from a taxonomic

and evolutionary context, but they have important

stratigraphical applications for mapping, surveying

and coal or hydrocarbons exploration, where an understanding

of correlation, tectonics, geometry and relationships

of rock units is required. Some groups of

microscopic taxa evolve rapidly, live for a short time

before becoming extinct. Biostratigraphical dating of

the geological record and the recognition of zones and

subzones provides the geologist with a tight temporal

control and a tool for correlating widely separated exposures

and boreholes. Different species have a variety of

environmental requirements so that microfossils are

also useful in the study of palaeoenvironments and

modeling aspects such as sea level change, climate

change and conditions during sediment accumulation.


80


Suggested Reading

Although the literature is full of detailed scientific

description, discussion and geological applications of

microfossils, there are few books outlining microfossils

in a general way. Those that have been written are

becoming a little elderly and may be difficult to obtain

outside a library, although a revision of Brasier’s book is

in progress.

Bignot, G. (1985) Elements of Micropalaeontology. 217pp.

London: Graham & Trotman.

Brasier, M.D. (1980) Microfossils. 193pp London:

George Allen & Unwin.

Haq, B.U. & Boersma, A.(1978) Introduction to Marine

Micropaleontology. 376pp. New York: Elsevier.

The following can be purchased through the BGS or any good bookshop.

Wilkinson, I.P. (1996) Fossil Focus: Ostracoda. Nottingham: BGS.

Wilkinson, I.P. (1997) Fossil Focus: Foraminifera. Nottingham: BGS.

Acknowledgements

I thank the following for assistance in illustrating this paper. Bacteria and

blue-green bacteria were drawn by Chris Wardle. Photographs were taken

by Mike Stephenson (pollen & spore), Jim Riding (dinoflagellate), Stewart

Molyneux (chitinozoan and acritarch), Nick Riley (calcareous algae) and

Mark Dean (conodont). Former members of staff of the BGS captured the

images of the radiolarian and diatom (Murray Hughes) and coccoliths

(Alan Medd). This paper is published with permission of the Director of

the British Geological Survey (N.E.R.C.)

Ian Wilkinson


Keyworth, Nottingham NG12 5GG

Summary Charts

Ostracoda

Kingdom: Animal

Chitinozoa

Kingdom: Animal()

Geological range:

(Cambrian) Ordovician

to Recent


Ordovician-Devonian

Late Jurassic ostracod

Ostracods are small crustacea that secrete a bi-valved,

calcareous carapace. The hinge line along the dorsal margin

may be a simple bar and groove or a series of teeth and

sockets. The animal opens and closes the carapace with

adductor muscles, the scars often being seen inside each

valve. The surface of the carapace may be smooth or

ornamented with punctation, reticulation, ribs and spines.

Most ostracods are less than 1500 microns, although the

largest is about 2.5 centimetres long. Ostracods are found in

all aquatic environments from the deep sea to coastal rock

pools, estuaries, ponds and lakes. They have even been

found in trees of tropical rain forests where a small pools form

in the leaves. Although they are not usually regarded as

terrestrial animals, one genus has been found amongst leaf

litter on wet, marshy ground. Fossil ostracods are particularly

useful when making palaeoenvironmental reconstructions.

I.P.Wilkinson (BGS)

An Ordovician chitinozoan

Chitinozoa are flask- or bottle-shaped organisms with a

vesicle and an aperture at the end of a neck. They are

sometimes found attached in chains. They may be smooth,

hispid, tuberculate or spiny. They are usually 150-300

microns long, but may be as small as 30 microns or as large

as 1500 microns. The walls are made of chitin-like material

and generally brown or black in colour. These extinct

organisms are found in marine Palaeozoic rocks (especially

shales and siltstones) and mainly those that accumulated in

shallow, well oxygenated conditions. It is not unusual to

find organisms of uncertain affinity in Palaeozoic deposits.

The Chitinozoa is an example of this. Some palaeontologists

believe that they were planktonic and probably zooplankton;

others have suggested that they were related to

foraminifera, and yet others consider them to be egg cases

of an unknown animal.


81 www.esta-uk.org


Bacteria

Kingdom: Monera

Blue green cyanobacteria

Kingdom: Monera


Archaean to Recent


Archaean to Recent

Precambrian bacteria

Kingdom Monera is based on the prokaryote cell (they lack

organelles, like mitochondria, and a nucleus with

chromosomes). The most primitive would have been

chemoautotrophs, adapted to the reducing conditions, but

photautotrophs soon evolved. Some of the oldest known

fossils were single cells less than 1 micron long, but others

formed chains of cells (filaments), like those from the Apex

Chert (3465Ma), or star-like arrangements e.g. Eoastrion

from the Gun Flint Chert (2000 Ma). Bacillus-like

Eobacterium are found in the Fig Tree Chert (3000Ma). These

organisms formed Banded Ironstone Formations (BIFs).

Oxygen given off by the bacteria caused ferrous iron in ocean

water to oxidise and precipitated as a red layer of iron onto

the sea floor. At times when oxygen was not being created,

grey cherts were precipitated instead. These layers built up

alternately to form BIFs.


Precambrian blue-green cyanobacteria

Blue green cyanobacteria are found as fossils in

Precambrian cherts, the oldest being from the 3400Ma old

Towers Formation (Australia). Other examples come from the

Fig Tree Chert and the Gun Flint Chert. These single-celled

organisms may occur as single cells or form a chain of cells

called a filament. Cells may be spheroidal, cylindrical or

irregular. They photosynthesised, giving off oxygen as a

waste product. In some places, vast numbers of blue green

cyanobacteria formed a mat on the sea bed and by 3000Ma

they were removing CaCO3 from the sea water during

photosynthesis. Precipitation of these carbonates produced

the first limestones. Mat upon mat were built up to form

domes and mounds of limestone called stromatolites. 3000

million years later they are still doing the same thing in

Shark Bay, Australia.


Acritarchs

Kingdom: Protista

Dinoflagellates



Precambrian to Pleistocene


Silurian, Late

Triassic to Recent

Early Ordovician acritarch

Acritarchs are amongst the earliest protists. The oldest

fossils are simple spherical cysts that first appear in shales

1900-1600 million years old. Acritarchs are diverse and most

abundant in rocks of Cambrian to Devonian age (c. 550 to 350

million years ago). The cyst, which is up to about 150

microns across, has a resistant wall that may be preserved as

a fossil. Their exact affinities are unknown, but it is likely that

many were marine phytoplankton, similar to dinoflagellates

and some Prasinophyceae. If so, the organisms responsible

for producing the cysts probably had a motile planktonic

stage that encysted as a result of environmental stress or as

part of their reproductive life cycle. Nothing is known of the

motile stage, probably because it was composed of an organic

compound like cellulose, which is less easily preserved.

Jurassic dinoflagellate

Dinoflagellates are single celled protistids. They are plantlike

in having cellulose in the walls and chlorophyll pigments

in the protoplasm, but animal-like having a motile phase with

whip-like flagella to provide propulsion through ocean

waters. The hard envelope (theca) comprises a number of

plates and contains the large nucleus and chromoplasts. Like

acritarchs, during periods of adverse environmental

conditions or after reproduction, they have a ‘resting stage’

when they encyst. But, unlike acritarchs, the plates of the

theca are retained in the cyst stage. Cysts, the only part that

is fossilized, are 20-150 microns across, and may be smooth

or ornamented with spines, ridges and granules. When

improved conditions returned, the dinoflagellate escapes

their cyst through a hole (archaeopyle) in the wall, made by

discarding one of the plates.




82


Coccolithophores


(Precambrian)

Late Triassic to Recent


Foraminifera


Cambrian to Recent


Jurassic coccoliths

Coccolithophores are chrysophytes, unicellular and

planktonic, with two flagella for locomotion. Of the c. 2000

species, all but four live in normal marine salinities (three live

in fresh waters and one in high salinities of the Dead Sea).

They require well oxygenated waters and live within the top

50m of the water column in order to photosynthesise.

Between 10 and 30 tiny (3 to 15 microns) calcareous plates

(coccoliths) envelope the organism in a cyst-like coccosphere.

On death, the coccosphere breaks up into coccoliths and, with

diagenesis, these often break up into component crystals.

Coccoliths and their debris comprise over 90% of the

Cretaceous chalk of Britain. Coccolithophores are important

in our environment today as they remove carbon dioxide, a

greenhouse gas, by trapping it in their calcareous (CaCO3)

skeletons on the ocean floor. They are sometimes so

abundant that they form a coccolith ooze.


Late Jurassic Foraminifer

Foraminifera are sometimes called ‘armoured amoeba’. The

amoeba-like cell engulfs a tiny shell (test) that may be

composed of calcite, aragonite or sand or silt grains cemented

together by a calcite or silica cement. The test may be a

single globular or tubular chamber; a string of chambers; a

coiled arrangement of chambers or a mixture of these. They

are often found fossilised. Most species are less than 1mm

across, but the largest of these single celled organisms was

over 10 cm in length. Foraminifera are confined to marine and

brackish waters and extend into estuaries and marshes, but

are not found in fresh water. Some are planktonic, while

others are benthonic. They have a complex reproductive

strategy so that alternating generations occur; an organism

which was the result of sexual reproduction, will in turn

reproduce asexually.


Radiolaria


Diatoms



Cambrian to Recent


Jurassic,

Cretaceous to Recent

Eocene radiolarian

Radiolaria are planktonic actinopods, heterotrophic protista

that secrete a skeleton of between 100 and 2000 microns.

The composition of the skeleton may be strontium sulphate or

opaline silica. The latter, which dominate the fossil record,

form two large groups. Spumularia, which evolved during the

Ordovician, are radially symmetrical, often spherical or

discoidal, with radial spines. Nassellaria, which developed at

the beginning of the Mesozoic, are elongate and axially

symmetrical, being elongate, ellipsoidal, discoidal or fusiform

and often spinose. They live in tropical marine waters

especially at depths of 100 to 500m. They remain buoyant in

the water by using fat globules; gas-filled vacuoles; long rigid,

thread-like axopods on spines; and by having perforated

skeletons to reduce weight. Reproduction is asexual.

Palaeogene diatom

Diatoms are autotrophic, unicellular algae. They occur in the

photic zone of oceans, estuaries, lakes and ponds. The part

that is fossilised is the opaline silica shell (or frustule),

which comprise two valves that fit together rather like a pillbox.

The frustule may be up to about 2mm across and some

forms are colonial, forming long chains. There are two large

groups of fossil diatoms: the radially symmetrical Centrales,

which evolved during the mid Cretaceous, and the more

elongate, bilaterally symmetrical Pennales which appeared

in the Eocene. They may occur in huge numbers on the

ocean floor to form an ooze. In some cases when huge

numbers of diatoms accumulated they formed a sedimentary

rock called a diatomite. One Miocene diatomite in America is

1000m thick and there are an estimated 6,000,000 frustules

per cubic centimeter!



83 www.esta-uk.org


Green Algae

(Chlorophyta)


Late Silurian to Recent


Pollen & Spores


Ordovician to Recent

Kingdom: Plant

Carboniferous calcareous algae

Chlorophytes are ‘Green Algae’, with chlorophyll in their

cells. Prasinophyceae have spherical cells, 100 to 700

microns across, and an organic wall with small plate-like

scales. Range: Cambrian to Recent. Chlorophycae have a

large central vacuole surrounded by protoplasm. They may

be unicellular or multicellular. Eosphaera is an example

from the Precambrian. Some (Dasycladales and Siphonales)

are spherical, cylindrical or branched and secrete a skeleton

of aragonite, which becomes calcite during fossilisation.

Charophycae are plant-like algae (‘stonewort’) that grow up

to 2m high. Amongst the branches are small (500-750

microns) male (antheridia) and female (oogonia) organs.

The former is rarely fossilised, but the latter is an ovoid

body, with a spiral ornament that may be found in lacustrine

and estuarine deposits.


Pollen (top) & Spore (bottom) from the Permian

Spores and pollen appeared when the plant kingdom evolved

from its algal origin in the Ordovician. Spores from primitive

plants (e.g. bryophytes, Cooksoni and Rhynia) were windblown

and, if they landed in suitably moist soils, grew into a

gametophyte plant, bearing both male and female cells. More

advanced plants (e.g. clubmosses and horse tails), which

evolved in the mid-Devonian, gave rise to microspores (20-50

microns), that grew into male gametophytes, and megaspores

(200-400 microns), that became female gametophytes.

During the Late Palaeozoic, plants living in drier areas

“imprisoned” the megaspore in a capsule where it developed

further, eventually dividing into a few cells. The single celled

microspores evolved into multicelled pollen grains (the male

gametophyte), which fertilised the encapsulated female.

Gymnosperms (e.g. seed-ferns, cycads and conifers) and

flower-bearing angiosperms reproduced in this way.


Spores & Fruiting bodies


Devonian to Recent

Kingdom: Fungi

Conodontophorida

Kingdom: Animal


Early Cambrian to late Triassic

Fruiting body (left) & spore (right) of Palaeogene fungi

Fungi are known to have evolved by the Devonian, although

their early history is relatively poorly known. Spores and

fruiting bodies have been found in the fossil record, but have

been little studied. They have little known biostratigraphical

or palaeoenvironmental value and have generally been

ignored by palaeontologists.

Platform (top) and compound (bottom) conodonts from the Carboniferous

Conodonts are small teeth-like structures, generally 100 to

2000 microns in length, but occasionally up to 5000 microns.

They are made of calcium phosphate. Conodonts may be a

simple, individual tooth, a compound ‘blade’ composed of a

series teeth or a row of teeth attached to a ledge-like

platform. They are found in Palaeozoic rocks, particularly

limestones. Although first described as long ago as 1856, it

was not until 1983 that palaeontologists new what the

conodont animal looked like. These teeth came from the

mouth of a eel-like fish, possibly a distant relation of the hag

fish. But here was a problem. Different species and genera of

conodonts had been erected for the different morphologies.

Only when the whole animal was found did paleontologists

realise that different genera and species were found together

in the mouth of a single individual.




84

Winter 2002 ● Issue 39

ENVIRONMENTAL

IMPACTS – 3

RIVERS

Published by the Earth Science Teachers’ Association Registered Charity No. 1005331

Introduction

This is the third in a series of PEST’s concerning Environmental Impacts (1 and 2 were from space

and from Volcanoes). This one concentrates on the environmental impact that rivers can have for a

variety of reasons.

Most of this relates to aspects of the Geography curriculum and covers knowledge and

understanding of patterns and processes (Ga 4); Knowledge and understanding of

environmental change and sustainable development (Ga5) and Breadth of Study – Themes (Ga

6, c, d, e,). It can be linked into a variety of topic work particularly when studying any aspects of

settlement and/or rivers.

Many people do not realize the positive and often underlying environmental impact of a river such

as the reasons for a settlement having been established where it is, but are more aware of the

negative aspects such as flooding, pollution, disease, subsidence and drought.

One point that is often forgotten is that flooding is natural and is the way a river copes with excess

water. The flood plain is the flat area around a river channel that becomes flooded.

This issue provides ideas of where and how to include the environmental impacts that rivers have

from both a positive and a negative view.

It includes information about the effects of rivers on its environment, how we make use of rivers

and the effect this has, also the effect rivers have on our activities and how we live.

WINTER 2002 ● Issue 39 ● ENVIRONMENTAL IMPACTS - 3: RIVERS

Accentuate the Positive !!!

Settlements

Settlements grew up beside rivers because: -

There was easy access to water which is vital to human life

There was fertile land

There was water to grow crops

There may have been a crossing point of the river

There may have been access by water to other settlements

There was easy access to water for industrial purposes

The above ideas can be used when investigating a “place” in geography.

All early settlements needed water to drink and thus were often near to a river or stream.

The flood plains around rivers, also called alluvial plains, were also fertile land, which enabled

settlers to grow crops, there was also water there to irrigate the crops.

If the river had a shallow area where it could be crossed, the area was likely to attract travellers

who might then also want to trade with the settlers.

If the river was navigable then travellers might stop off to trade, or it would be easy for the settlers

to visit other settlements to trade.

If the river were suitable it could be used for industrial purposes, in earlier days this could have

been a water mill, which could have provided flour for the settlement. In more recent times this

light have been in the form of using the water for cooling purposes at a power station or even

providing power in the form of Hydro electric power where the river flow was sufficient.

Eliminate the Negative

Flooding

When a river floods it is because there is too much water being carried within the river channel.

This may be due to excessive rainfall over a short period of time, or a sudden thaw of snow and ice

or even a burst dam.

Floodplains, narrow valleys and coastal areas are the most likely areas to be affected, with coastal

areas (particularly low lying ones) more at risk than inland ones.

As floodwater travels downstream it can become very dangerous depending on the amount of

water involved, the debris it collects and the area it is flowing through.

When a river bursts its banks in a rural area fields are flooded and often the only creatures at risk

are animals. However crops can also be damaged by the floodwater, as can communications, with

roads, railways and bridges being underwater and sometimes permanently damaged. Land can

remain waterlogged for long periods of time in some cases with farmers’ livelihoods being put at

risk. Where a flood is severe trees can be uprooted.


In urban areas there is often far more damage, towns can become flooded, houses and vehicles

damaged and lives can be at risk. Where a flood is severe buildings and vehicles can be washed

away and this debris cause even more damage.

Where a potential hazard from flooding is known river defences are sometimes built to prevent

floodwater reaching habited areas, but these do not always prevent flooding. Sometimes these

defences cause as many problems as they solve, such as the levees built on the Mississippi in the

USA. These are huge banks of earth on either side of the river, which were intended to contain the

river when it flooded. These were however not enough to contain the summer floods in 1993,

which followed an excessively wet summer.

Dams are also used to regulate river flow on those rivers prone to flooding such as Clywedog Dam

at Llandiloes on the River Severn. Flood defences in the UK are the responsibility of the

Environmental Agency.

Pollution

Pollution after flooding can be as a result of floodwaters being polluted by sewage and other

contaminated waste such as from industrial areas, plus fuel storage sites.

However another form of pollution can be caused when industrial waste is released into a river by

accident and causes pollution downstream, damaging wildlife and fish. Water is also taken from a

river to be used for industrial purposes.

Disease

Due to pollution that occurs as above disease can sometimes cause more loss of life than the

floods that preceded it. This is more often the case in underdeveloped areas where the water

supplies may become polluted and cause diseases such as dysentery.

Subsidence

In certain types of areas, particularly those underlain by limestone, subsidence is the result of

flooding. Landslides are also a hazard, and can be as dangerous as the flood water itself.

Drought

You may wonder why we have included this here, but drought can have just as dramatic effect on

the environment, and can greatly affect river flow. In areas where there is a lock of rain a river

becomes a vital source of water, however the drought itself can also cause the river volume to

decrease and can affect crops and health.


Activities

Making a Flood

Build a river, using an old slide or plastic gutter and a mixture of sand and gravel (see instructions

in PEST 16). Demonstrate normal flow then increase the volume of water flowing to show the

difference that a large amount of water makes to a river. Ask children to predict which areas will be

safe by placing plasticine blocks where they think houses will not be affected.

Field Work.

When studying rivers it is of course ideal to be able to visit a local on. Even a small stream can

provide a good source for research. Ideally visit it at different times during the year so that the

children can see the difference between a low volume summer river and a high volume winter river.

Photographic records are very useful to remind children of what they have seen previously and to

compare findings. Children can measure the depth and width of the river using metre sticks and

tape measure, as well as the rate of flow using a floating object, metre stick and a stop watch Care

should always be taken when doing work of this kind.

Planning a New Town or Village

Give the children a map of an appropriate area with a river, flood plain etc: and ask them to plan

where they would build a new town or village. They need to give reasons why they have placed it

where they have and why they have not sited it in other parts of the area.

Planning A Factory Site

Give the children a map of an appropriate area with a river, flood plain etc: You could use the same

one as in the previous activity, or you might like to use one with a town or village already on it. Ask

the children to plan where to site a new factory which will either have waste products which, after

treatment, could be discharged into the river or requires the use of water from the river. Remind

the children that they need to take into account other people or industries in the area, and the

effect the new industry might have on them.

Linking to Work on Ancient Egypt in History.

Whilst doing work on Ancient Egypt or just afterwards investigate the River Nile. Cover the fact that

in ancient times the natural flooding of the River Nile was used to aid irrigation of crops as well as

providing fertile land to grow them on. Although this also led to problems for the population.

Contrast this with the fact that in more recent times this flooding has been prevented following the

building of dams on the river, which has meant that life is easier, but has meant that water has not

been available in the same way for irrigation of crops and other means have had to be found.

COPYRIGHT

There is no copyright on original material published in

teaching Primary Earth Science if it is required for

teaching in the classroom. Copyright materials

reproduced by permission of other publications rests

with the original publishers.

To reproduce original material from P.E.S.T. in other

publications permission must be sought from the Earth

Science Primary working group via: Peter York, at the

address below.

This issue was devised and written by Niki Whitburn and

edited by Graham Kitts.

TO SUBSCRIBE TO: TEACHING PRIMARY EARTH SCIENCE

send £5.00 made payable to ESTA.

c/o Mr P York,

346 Middlewood Road North,

Oughtibridge,

Sheffield S35 0HF


The Stone Tapes: Building Stones in the

History of the City of Nottingham

GRAHAM LOTT

From my days as a newly qualified geologist I still have a strong memory of an old BBC TV drama

production called the Stone Tape. The main premise of the storyline was that the historic events

that had occurred within a particular house were recorded in the stones of its walls and that these

stories could, in the right circumstances, be ‘replayed’ in the present. To a great extent my

subsequent career in geology, like that of many other geologists, has been spent in trying to

understand the geological stories ‘recorded and told’ by such stones through studying their

mineralogy and physical characteristics. Many of the techniques I learned I then found could be

applied to the identification of the stones used in buildings and other structures. This has

allowed me to take the story of the stones one step further by integrating their geological story

with the history and origins of the buildings.

The City of Nottingham, like most other cities

in Britain, fortunately still has many such significant

stories to tell through its stone buildings,

despite the tribulations brought about by the sometimes

catastrophic redevelopments of the 1960’s, 70’s

and 80’s. Today, enlightened planners and architects

have realised that conserving rather than demolishing

historic buildings and landscapes has resulted in much

more attractive and friendly city centre environments.

Any study of building stones and their sources is

very much intertwined with the development of first

local, and later national transportation systems within

an area (Lott 2001; BGS 2000). Throughout its history

Nottingham has always taken full advantage of its position

on one of the country’s major waterways, the River

Trent. Its early development was very much reliant on

the wealth generated from this river traffic. The river

carried raw materials, like coal, lead, iron and stone,

items too heavy for the existing overland trackways and

embryonic road systems, from the mines and quarries

of Derbyshire and north Nottinghamshire to the

Humber estuary and beyond. Much of the building

material that was needed for such a rapidly expanding

city was imported using this river system which, from

the late 18th century, was considerably improved by a

series of local canal networks.

As is typical of many cities, much of the older

stonework is of local origin. The oldest stone buildings

still surviving are the medieval churches of St Peter and

St Mary. Though both have been much restored and

added to over the centuries, the recently cleaned spire and

surviving early stone fabric of St Peter’s, and the tower of

St Mary’s, are constructed of large blocks of fine-grained

sandstone from the local Triassic Sherwood Sandstone

Group. The original quarries are now lost in the suburban

developments of Sneinton and Gedling but they,

together with quarries at Castle Donnington and Weston

on Trent, sited just upstream on either side of the Trent,

supplied a considerable amount of stone to the city until

at least the late 18th century. Stone from these quarries is

particularly well displayed in the Shire Hall (1770) (Galleries

of Justice Museum), comprising large blocks of

greenish or reddish-grey, cross-bedded sandstone, pockmarked

by the erosion of the soft clay clasts that often

characterise these fluvial, Triassic sandstones.

The city is still dominated by its castle sitting high on

St Mary’s Church:

Local Triassic and

Carboniferous

Sandstones

Shire Hall:

Local Triassic

sandstone.

Mansfield Red

pilasters

85 www.esta-uk.org


the ridge of Triassic sandstone that divides the city.

This sandstone has, unfortunately, always proved to be

too poorly cemented to provide good building stone

and was more widely utilised in the creation of the

warren of man-made caves that underlie much of the

urban area (Charsley et al. 1990; Waltham 1996) and

which much later encouraged the construction of the

Nottingham via the Trent. This finer grained, sandy Permian

dolomitic limestone is now only found in a few surviving

buildings in the city. The Mansfield White variety,

with its characteristic green clay seams, can be seen in the

Nottingham Corn Exchange (1849-50) in Thurland

Street and in the old Chapel (1815) on George Street.

The more ferruginous Mansfield Red variety was much

St Andrew’s

Church:

Bulwell

Golden Stone

(Magnesian

Limestone),

Ancaster

Limestone quoins

and mouldings,

grey Lias

limestone arches

Wollaton Hall:

Ancaster Stone

many railway tunnels that cross-cut the city. Little

appears to remain of the stonework of the original

medieval castle, which figured so prominently in the

city’s early history. What does remain, however, suggests

that a considerable amount of local Permian

dolomitic limestone together with assorted Carboniferous

and Triassic sandstones, were used in its construction

(Drage 1990). The present italianate ‘castle’

(1674), built for the Duke of Newcastle was largely

destroyed by fire in 1831. Today’s castle, restored by T.

C. Hine (see above) survives as a Museum of Art and

is built of strongly cross-bedded Carboniferous sandstone

probably from nearby Derbyshire quarries, to the

west, around Trowell, Stanton or Little Eaton.

The most commonly seen stone within the city is the

local Permian magnesian or dolomitic limestone (Cadeby

Formation) from the Bulwell quarries (Bulwell Golden

Stone), now also engulfed within the city’s northern

suburbs. They provided stone for many Victorian industrial

buildings, numerous churches (St Andrew (1869-

71); Goldsmith St.) and schools (Nottingham High

School (1866-7); Arboretum St.). This distinctive,

coarsely crystalline, pale yellow-brown, dolomitic limestone

formed the basis of a major local industry from at

least the 16th century, but particularly flourished in the

19th century. Not well suited for carved work, Bulwell

Stone was often used as a wall stone together with pale

yellow, Middle Jurassic Lincolnshire Limestone for the

dressed quoins, window and door mouldings (All

Saint’s Church (1863-4); Raleigh Street)

In 1796 the Chesterfield Canal linked the Permian

magnesian limestone quarries of the Mansfield area with

sought after, both locally and nationally, for decorative

stonework and often found in the door and window

mouldings of larger houses and shop fronts.

The Roman Foss Dyke that links Lincoln to the

Trent provided the distant Ancaster quarries with

access to Nottingham and, just outside the city centre,

Wollaton Hall (1580-88), home of the coal magnate

Francis Willoughby. Designed by Robert Smythson it

was constructed largely of Ancaster Stone, together

with some finer grained, Cadeby Formation dolomitic

limestone, the former transported no doubt by using

this ancient waterway to reach first the Trent and then

Nottingham beyond.

The gradual replacement of local stone by varieties

imported from further afield, fuelled by the increasing

industrial development in the city, reached its climax

in the mid-late 19th century with the gradual establishment

of the local rail network. Quickly replacing

the canals as the best means for transporting heavy

goods, and driven by the demands of many innovative

Victorian architects, a wide range of new building

stones and other building materials began to appear in

the city. Most commonly, buildings of this period in

the city show an increasing use of Derbyshire Carboniferous

sandstones as in the solidly built old GPO

Buildings (1895; Queen’s St.) and former Bank

buildings (c.1872; Victoria St.), the latter mixing buff

coloured sandstone with oolitic and shelly, Middle

Jurassic, Lincolnshire Limestone.

Leaving aside the legends of Robin Hood, the city of

Nottingham is perhaps most-famed for its lace production.

The industry still survives and was, in it heyday,


86


housed close to the city centre in an area now known as

the Lace Market. There has been considerable thought to

the conservation of the numerous mill buildings that

survive in this area and perhaps the jewel in the crown is

the Adams Building (1855; now Clarendon College).

The power, wealth and occasionally benevolent

nature of some local Victorian mill owners in this

industry is showcased in this recently restored building.

T. C. Hine the architect designed an imposing

entrance-way of ornately carved, pale yellow oolitic

Lincolnshire Limestone (Ancaster Stone), with the

street levels faced with harder, coarse grained Carboniferous

sandstone from the Millstone Grit of Derbyshire.

Inside, Adams provided a chapel and school for his

workforce. The need for each mill owner to display his

success through commissioning such exceptional

buildings is clearly evident in the area.

Like most Victorian cities local architects have played

an important role in shaping the character of the city

through their buildings. Nottingham had two such

luminaries, Thomas C. Hine and Watson Fothergill.

Hine from the early part of the 19th Century dominated

the building contracts within the city. He often favoured

brick but invariably used local stone for the more decorative

parts of his designs, as in the Adams Building. As

architect to the Duke of Newcastle Estate which included

the castle, his influence is everywhere in the city. Watson

Fothergill dominated the city’s architecture over the

latter part of the century producing a far more flamboyant,

polychromatic, architectural style. Strongly influenced

by the gothic works of Burges and Street, many of

his multifaceted buildings still survive. He used Derbyshire

buff and grey Carboniferous sandstones, Mansfield

Red dolomitic limestone, Upper Jurassic Portland

Stone and a variety of Scottish granites in his Nottingham

Express 1876 (Upper Parliament St.) and former

National Westminster Bank 1877-82 (Thurland St.)

buildings, which both typify his style.

Better known nationally Augustus Welby Pugin,

jointly with Charles Barry architect of the Palace of

Westminster, was contracted to design the impressive,

but very much plainer, St Barnabas (1841-4), Nottingham’s

R. C. Cathedral. He used the local, greybrown

Stancliffe Darley Dale (Ashover Grit) sandstone

from Derbyshire.

Industrial progress, particularly at the breakneck

pace of the late 19th century was not without a price. As

elsewhere the effects of coal-fired pollution had soiled

and blackened many of the stone buildings in the city.

In order to counteract these effects some architects,

notably Alfred Waterhouse, began to use colourful

glazed terracotta blocks that were thought to be more

impervious to the pollutants. Waterhouse’s Prudential

building (1896; King St.) in red terracotta with his characteristic

animal casts and the bronzed Art Nouveau

style of the shop front (1904; High Street) are just two

of many such examples in the city.

Growing Victorian cities like Nottingham were

Adams Building:


with Carboniferous

Sandstone

Nottingham

Express Building:

Carboniferous

sandstone;

Mansfield Red

decoration

87 www.esta-uk.org


Arkwright

Building:


often conscious of their image and liked to portray not

only their industrial success through their buildings but

also their concerns for other aspects of everyday life

such as the educational well being of their population.

In 1881 the University College of Nottingham was

founded and a new prestigious building was constructed

in pseudo-gothic style (Arkwright Building (1888);

Shakespeare St.) of Ancaster Stone. Although the University

has subsequently moved to its present site outside

the city centre the buildings now form part of the new

city centre Nottingham Trent University campus.

The last substantial classical style stone building to

be constructed in the city was the new Council House

(1927-29). The architect (T.C. Howitt) used white,

oolitic Portland Stone to clad its immense iron framework.

Portland Stone, from Dorset, subsequently

became a common feature in many office buildings in

this and many other UK cities during this period. It was

also used in the new University Park buildings when

the supply of its chosen sandstone, Darley Dale, proved

unreliable and again in the Nottingham Trent University

Newton buildings in the 1950’s.

Today, the stories being told by the stones tell us yet

again how transport systems have further evolved. Blue

Pearl Larvikite and migmatite imported from Norway;

travertine limestones and marbles from Italy; granites

from India are all showcased in the city’s newer buildings

and shopping malls. However, fewer and fewer

stone buildings are being constructed of local stones.

An encouraging exception is the Crown Court (1985;

Canal St.) building constructed of pinkish, Carboniferous

Birchover Sandstone from Derbyshire. The focus

has now turned to preserving and utilising the built

heritage of the city. As part of this process it essential not

only in Nottingham, but elsewhere in the country, to

continue to record and interpret the ‘messages’ being

broadcast by our many surviving stone buildings, messages

which are still, unfortunately, often being ignored.

Some of these ‘stone tapes’ are in need of ‘re-recording’

to pass on to new audiences before either they are

irreparably damaged by inappropriate conservation

techniques (Kennet 2001) or wiped clean forever (Harris

1999). These ‘stone tapes’ form a major part of our

built heritage and can tell us far more than just their

geological history.

References

BGS (2000) Building Stone Resources of the United

Kingdom (BGS Map 1:1,000,000 Scale).

Charsley, T.J., Rathbone, P.A. and Lowe, D.J. (1990)

Nottingham: A geological background to planning and

development. British Geological Survey Technical

Report WA/90/1

Drage, C. (1990) Nottingham Castle. A Place Full Royal.

Published by Nottingham Civic Society and the

Thoroton Society of Nottinghamshire.

Harris, J. (1999) No Voice from the Hall - Early Memories

of a Country House Snooper. London: Joh Murrray.

Kennet, P. (2002) Chemistry in the High Street.

Teaching Earth Sciences,

27 (1), pp. 7-8.

Lott, G.K. and Cobbing, J. (1996) Nottingham.

Heritage in Stone. BGS Earthwise Publication.

Lott, G.K. (2001) Geology and building stones in the

East Midlands. Mercian Geologist, 15, pp. 97-122.

Waltham, T. (1996) Sandstone Caves of Nottingham.

East Midlands Geological Society.

Published with the permission of the Director, British

Geological Survey (NERC).

Graham Lott


Keyworth

Nottingham NG12 5GG


88


Lost worlds:

How Exceptional Fossils Reveal the Past

MARK WILLIAMS

Fossils constitute amazing evidence of lost worlds and this article provides four ‘snapshots’ of

how they contribute to major scientific debates in the biological and geological sciences. The

fossil ‘snapshots’ are: a half billion year old animal from Shropshire, fossilized in 3-dimensions

with its soft anatomy, that indicates the presence of modern animal body plans in the Cambrian;

small fossil crustaceans from the Ordovician of the American Midwest, which appear in Scotland,

indicating the ancient geographical disposition of the continents; fossil mouthparts from the

Moffat district, that identify predators in the Silurian marine abyss; and microfossil assemblages

from ancient marine deposits of the Pacific Ocean that identify tsunamis. Fossils provide

examples of the evolution of organisms and the biosphere from the Precambrian to the present.

They can determine the positions of ancient continents and help to reconstruct complex ancient

ecologies. Fossils can even be used to ‘fingerprint’ tsunami deposits and identify potential

geological hazards.

A half billion year old relative of crabs and lobsters

In the ancient rocks of Shropshire are tiny fossilized

marine animals only 0.3mm long, preserved with their

entire soft anatomy (see Figures 1 and 2). So fine is the

preservation that the animals even display the hairs on

their legs. This would be amazing if they were one million

years old. But in this case the fossils are from rocks

deposited over half a billion years ago.

The tiny fossils are bivalved crustaceans. Their head

appendages are arranged in the same manner as that of

modern crabs, lobsters and crayfish, with two pairs of

antennae at the front, mandibles and maxillae (see Figure

2). At over 511 million years old these are the

grandfather of all tempura!

The animals come from the Comley Limestones of

1a

Shropshire, part of the Lower Cambrian sequence of

rocks that were deposited in a shallow sea at the margin

of the early Palaeozoic marine Welsh Basin. They are

the oldest complete animals preserved in 3-dimensions

ever found. This kind of preservation is astonishing, as

most fossils preserve only the hard shell or skeletal tissues.

Coated in the mineral phosphate, the Shropshire

animals were virtually ‘mummified’ alive, or preserved

almost immediately after death. Either way, there was

no chance for the decay of soft anatomy.

The fossils are amazing in themselves, encased in

limestone they waited half a billion years to be released

from the rock by acid processing techniques in the laboratory.

But their wider evolutionary significance is

much greater, given that they occur in Lower Cambri-

1b

Figure 1:

A fossil crustacean

from the Lower

Cambrian of

Shropshire

preserved with its

soft-anatomy: a,

oblique lateral

view; b, ventral

view (see also Fig.

2). At more than

511 million years

old, this tiny

fossil, just 0.3mm

long, is the oldest

3-dimensionally

preserved

complete animal

ever found.

89 www.esta-uk.org


Figure 3:

The small arthropod Kunmingella from the Lower Cambrian

Chengjiang deposit of south China (about 520 million years old).

The flattened specimen, about 5mm long, is preserved with most

of its soft anatomy, including its head and body appendages.

Once thought to be an ostracod, the preserved soft-anatomy of

this animal indicates that it is not even a crustacean.

Figure 2:

The fossil

crustacean from

Shropshire

reconstructed in

ventral view (see

also Fig. 1b). Two

legs on the left

side of the animal

were lost during

life or damaged

after its death.

an rocks. It is in these rocks that shelly fossils first

appear in great numbers, as part of what is often

referred to as the ‘Cambrian explosion’ of life. The

Shropshire crustacean shows that complex animal body

plans and animal behaviour already existed in the early

Cambrian. That such complex animals existed at this

time, poses the question of when their less derived animal

ancestors began to evolve Was there a long evolutionary

‘fuse’ extending back into the Precambrian

The crustaceans from the Comley Limestones are

just one of many instances of soft-bodied animals preserved

in the Cambrian. Perhaps the most famous softbodied

fauna is that of the Middle Cambrian Burgess

Shale of British Columbia, Canada. But this fauna, like

that of the Lower Cambrian soft-bodied fauna at

Chengjiang, southern China (see Figure 3), is preserved

as flattened impressions. The great beauty of the

Shropshire find is that, preserved in 3-dimensions, the

animals look as though they were alive just yesterday!

Tiny Ordovician fossils from the American

Midwest found in Scotland!

In Oklahoma, in the American Midwest, there is a superb

sequence of marine sedimentary rocks deposited during

the Ordovician period, between about 500 and 440 million

years ago. These outcrop in the Arbuckle Mountains,

about 3-4 hours drive north of Dallas, Texas. The

Ordovician rocks of Oklahoma are highly fossiliferous,

bearing trilobites, brachiopods, corals, graptolites and

many other fossil marine invertebrates. Amongst these

are the tiny shells of ostracods (see Figure 4).

Figure 4:

The fossilized shell of the ostracod Steusloffina from the

Ordovician. The figured species occurs in Caradoc-age rocks

(about 450 million years old) of the Girvan district of Scotland,

and is also widely documented from North America. The fossil is

about 2mm long, with its anterior (head) end to the right.

Ostracods are small bivalved crustaceans that typically

are about 1 to 2mm long. Known from over 30,000

species, they occupy all modern aquatic environments

from peat bogs to the ocean depths. However, during

the Ordovician the range of environments they occupied

was limited to shallow to mid-shelf marine settings

where they occurred amongst the sea-bottom

dwelling marine benthos.

The global patterns of Ordovician ostracod distribution

can be used to map out the margins of ancient continents.

When these ancient continents were separated

by wide ocean barriers, ostracods were unable to

migrate and faunas became highly provincial. But when

continents drifted together, as a result of plate tectonic

movements, ostracods migrated from one continent to

another, and the faunas became cosmopolitan. By measuring

these changes it is possible to track the relative

position of ancient continents during the Ordovician.

In Oklahoma, the Ordovician ostracod faunas


90


belong to the Laurentia palaeocontinent (Figure 5), a

landmass that comprised most of modern North America,

but also Scotland, and which straddled the equator.

We know that Scotland was part of Laurentia because it

has the same Ordovician fossils as North America.

Indeed, ostracods from the American Midwest can

be found in Ordovician rocks at Girvan on the Ayrshire

coast! To the south of Laurentia, separated by

the intervening Iapetus (or Proto-Atlantic)

Ocean, lay the Baltica palaeocontinent, modern

Scandinavia. Further south was the Avalonia

microcontinent, formed from parts of

Europe, including England and Wales, and

parts of eastern North America, including

Nova Scotia and New Brunswick (see

Figure 5). Still further south was the

Gondwana supercontinent extending

to the South Pole, where, during

the late Ordovician, North Africa

was situated.

By looking at the Ordovician

ostracods from Oklahoma and

Scotland and comparing them to

those of England and Wales, the

relative palaeogeographical position

of the Avalonia and Laurentia palaeocontinents

can be tracked. In early late

Ordovician times, about 455 million years ago (see

Figure 5), the ostracods of England and Wales were

very different from those of Scotland or Oklahoma.

But, by latest Ordovician times, about 440 million

years ago, they shared numerous species in common,

indicating that there was free migration of ostracods

between these palaeocontinents. Together with other

palaeontological, geological and palaeomagnetic data,

this indicates that Avalonia had drifted north towards

Laurentia and that the intervening Iapetus Ocean had

narrowed and was about to close. Indeed, Scotland

was about to be joined to England and Wales for the

first time, about 440 to 430 million years ago.

Ostracods can be used for reconstructions of

Ordovician palaeogeography globally. Thus, the ostracod

faunas of the Argentine Precordillera are different

from those of the rest of South America until the late

Ordovician (see Figure 5). It was at this time, about 440

million years ago, that the Precordillera microcontinent,

which had split off from North America much

earlier during the Cambrian, finally docked with the

rest of South America.

Ostracod fossils may be diminutive in size, but their

distribution patterns can nonetheless have global significance

for reconstructions of ancient geography.

Figure 5:

Reconstruction of palaeogeography for the Caradoc Series of the Ordovician, about 450

million years ago. England and Wales lie on the Avalonia palaeocontinent south of the

equator, whilst Scotland is situated on the Laurentia palaeocontinent to the north.

Intervening is the Iapetus Ocean. As Avalonia drifted northwards towards Laurentia during

the late Ordovician, the ostracod faunas of the two continental areas became progressively

more cosmopolitan as widespread migration took place. Many species were common to

Laurentia and Avalonia by latest Ordovician times (about 440 million years ago).

Figure 6:

A rare conodont bedding plane assemblage from southern

Scotland. Several paired Elements (‘teeth’) are visible lying

adjacent to a lower Silurian graptolite (top of picture). The whole

conodont assemblage is about 1cm long. At about 435 million

years old, this is the oldest near complete vertebrate mouthpart

apparutus ever found in Scotland.

Ancient fossil mouthparts from the Silurian

marine abyss

At about 1cm long, a newly discovered conodont

mouthpart assemblage from the Silurian of southern

Scotland may not look very threatening (see Figure 6).

91 www.esta-uk.org


component of the marine plankton biomass in deeper

water settings of the early Palaeozoic. But if this is so,

surely something must have been eating them Despite

the millions of graptolites recovered, virtually none

show evidence of bite marks, mastication or occurrence

in coprolites (fossil dung).

The Scottish conodont mouthpart association

strongly suggests that predators were living with the

graptolites in the overlying water column. It indicates a

much more complex ancient ecology than could be

gleaned from the graptolite fossils alone. Given that

there is also evidence for fossilized marine worms in

the newly discovered association, which may also have

been predators, the fossil find from southern Scotland

provides much evidence for the existence of complex

ecosystems in the Silurian marine abyss.

Figure 7:

Foraminifera are unicellular eukaryotic organisms (Protists) that

construct a calcium carbonate or agglutinated shell. They range

through a vast array of different marine and brackish water

environments and are powerful indices of ecology. The specimens

shown are shallow marine forms from the Pacific region, and are

between 0.5 to 2mm in size.

Nevertheless, it provides evidence for predators in the

Silurian seas and, at around 435 million years old, is the

oldest near complete vertebrate mouthpart apparatus

ever found in Scotland.

Conodonts were early vertebrates with a somewhat

‘eel-like’ body-morphology. They possessed hard

mouthparts, rather like teeth, collectively arranged as a

kind of ‘jaw’. Most conodonts are known only from

these ‘teeth’, which typically became dissociated after

the animal’s death. Only very rarely are the ‘teeth’,

more correctly termed ‘conodont elements’, preserved

in association. Such finds are very important for interpreting

the way in which these animals were eating, and

also for meaningful taxonomic assessment of their close

biological affinities.

The Silurian rocks in which the conodont mouthparts

were found, are thought to have been deposited in

a deep sea setting. They comprise black, organic rich

mudstones, accumulated on the sea floor under anoxic

sea bottom conditions, probably in an ocean-facing

marine basin. Fossils in these rocks are mainly graptolites,

colonial marine organisms that produced a rigid

protein skeleton. These lived in the overlying water

column but sank to the sea bottom after death, to be

locked into the sediments. Millions of graptolite fossils

have been recovered in southern Scotland and from

similar rocks in the English Lake District, Wales and

worldwide. These animals evidently formed a huge

Small fossils make big waves in the Pacific Ocean

In the Pacific Ocean tsunamis strike with alarming regularity

and cause extensive damage and loss of life: in

the recent Papua New Guinea tsunami of 1998 over a

thousand people were killed.

Tsunamis are generated by large scale geological phenomena

such as earthquakes, or the movement of large

slumps of sediment on the continental shelf or slope, or

more rarely are caused by bolide impacts. The resulting

shock waves from these effects can generate “tidal waves”

of hundreds of metres, which are capable of picking up

rock boulders the size of houses and depositing them

onshore. Recognising the rock deposits formed by past

tsunami can help to determine their periodicity and causal

effects. In this way the potentially devastating effects of

future tsunamis can be identified before they occur.

Shell assemblages in recent and ancient sedimentary

deposits can provide a characteristic signature, a kind of

‘genetic-fingerprinting’ for tsunami. Such tsunamidiagnostic

assemblages have been recognised in ancient

rock deposits from the Pacific to the Mediterranean.

Thus, on the Polynesian islands of the Pacific, coastal

sedimentary rocks previously interpreted as beach

deposits, can be ‘fingerprinted’ as tsunami deposits by

their macrofaunal and microfaunal content. Such

deposits contain many shell fragments of typical marine

invertebrates such as bivalves and gastropods, together

with abundant foraminifera and ostracods. Foraminifera

are ‘large’ millimetre scale unicellular organisms which

produce a calcium carbonate or agglutinated shell, and

which include sea-bottom dwelling and planktonic

forms (see Figure 7; see also the article by Ian Wilkinson

in this volume, page 78).

The faunal signature of tsunami deposits in Polynesia

can be very distinctive. Ongoing work by British

Geological Survey scientists shows that the larger

invertebrate fauna are pummelled to fragments of less

than 1mm size. The microfauna are winnowed to

remove both the smaller (immature) sea-bottom

foraminifera, and the more buoyant planktonic

foraminifera. This leaves a ‘skewed’ assemblage of


92


robust, mature, sea-bottom forms, which are clearly

not representative of an original living population. As

the fauna are also transported onshore by the tsunami,

there is a landwards displacement of environment-specific,

often incompatible faunas, ripped-up from different

ecologies as the tsunami approaches shore. The

distinctive faunal assemblage that this produces, a winnowed,

pummelled, mixed fauna from different marine

communities, ‘fingerprints’ the high-energy milieu of

deposition and distinguishes the deposits as the product

of a tsunami.

Conclusions: the importance of fossils

Notwithstanding their immense value for the relative

dating and correlation of rock sequences, the ‘snapshots’

presented here indicate the wider geological and

biological applications of fossils. Fossils are the key evidence

for the processes of evolution viewed in the long,

geological time-frame and, when preserved with their

soft anatomy, provide immense detail about past global

biodiversity. The distributional patterns of fossils can be

used to track the positions of ancient continents, and to

reconstruct complex ancient ecosystems. Fossils can be

things of great aesthetic beauty, but have a much more

practical role when they ‘fingerprint’ geological hazards

such as tsunami.

References

The following references provide more detailed information

about the ‘Cambrian explosion’, ancient palaeogeography,

conodonts and tsunamis. For animations and

much more information about tsunamis visit the United

States National Ocean and Atmospheric Administration

website at: http://www.pmel.noaa.gov/tsunami/

http://www.pmel.noaa.gov/tsunami/

An excellent general guide to fossils is the book by

Richard Fortey given below.

Cocks, L.R.M. (2000) The early Palaeozoic Geography

of Europe. Journal of the Geological Society, London,

157, pp. 1-10.

Fortey, R. (2002) Fossils: The Key to the Past. Third Edition.

London: Natural History Museum

Keating, B.H., Waythomas, C.F. & Dawson, A.G. (2000)

Landslides and Tsunamis. Birkhäuser Verlag. Basel-

Boston-Berlin.

Purnell, M. A., Donoghue, P. C. J. & Aldridge, R. J. (2000)

Orientation and anatomical notation in conodonts.

Journal of Paleontology, 74, pp. 113-122.

Siveter, D.J., Williams, M. & Walossek, D. (2001)

A phosphatocopid crustacean with appendages from

the Lower Cambrian. Science, 293, pp. 479-481.

Dr Mark Williams FGS CGeol

British Geological Survey,

Keyworth,

Nottingham NG12 5GG

Email: mwilli@bgs.ac.uk

Acknowledgments

David Siveter and Mark Purnell of Leicester

University, Dieter Walossek of Ulm University,

Maxine Akhurst and James Floyd of BGS

Edinburgh, and Ian Wilkinson and Dave Tappin of

BGS Nottingham are collaborators on various

aspects of the work detailed here. The

reconstruction used in Figure 2 was drawn by

Dieter Walossek and Chris Wardle. The

reconstruction of Ordovician palaeogeography

used in Figure 5 is courtesy of Mike Bassett and

Leonid Popov of the National Museum of Wales.

The image of foraminifera used in Figure 7 is

courtesy of Ian Wilkinson. Thanks to Vicki Ward

of Abbot Beyne School, Burton-on-Trent, for

information about the A-Level Geology

curriculum. Many of the specimens figured here

are in the museum collection of the British

Geological Survey at Keyworth, Nottingham.

Images are available from the author by request.

This article is published with the permission of the

Director, British Geological Survey (N.E.R.C.).

93 www.esta-uk.org


From Flood to Drought and Back Again

BRIAN WATERS

This paper is based on some work that looked at the Potential Impacts of Climate Change in the

East Midlands on behalf of the East Midlands Sustainable Development Round Table (emsdOt)

and future climate scenarios in the West Midlands for the Environment Agency. These were two of

a number of regional and sectoral studies, some of which can be accessed through the web site

of the UK Climate Impact Programme (www.ukcip.org.uk).

Everyone must have heard by now of the changing

climate and its likely causes due to emissions of

greenhouse gases, especially carbon dioxide from

the combustion of fossil fuels. Several studies have

looked at the likely future climate scenarios based on

assumptions of future trends in carbon dioxide concentrations

in the atmosphere. In 1998 UKCIP published a

report for the UK (Hulme and Jenkins, 1998) and this

was the starting point for the East Midlands study.

One of the team involved in the study used a technique

of downscaling to produce scenarios for the East

Midlands of temperature and rainfall (East Midlands

Sustainable Development Round Table, 2000). The

Environment Agency commissioned similar work for

the West Midlands (Environment Agency, 2001a).

More recently, the scenarios for the whole of the UK

have been updated (Hulme et al, 2002) to produce

maps at a 50km scale giving similar information about

predicted scenarios for 2020, 2050 and 2080. The scenarios

show predictions for annual averages and seasonal

changes in temperature and rainfall for a range

from low to high future carbon dioxide emissions. All

the scenarios imply increases in emissions, just at different

rates. Picking one of these – the Medium High

Scenario – Table 1 shows how the predictions have

changed between 1998 and 2002 for the East Midlands.

Although there are differences in detail, the broad

picture looks the same:

● Increased average temperatures

● Hotter drier summers

● Warmer wetter winters

The changes look modest but an increase of 3ºC in

average temperature ought to be compared with a 5º

difference between average temperatures now and the

last ice age. In addition the studies are predicting:

● More extreme events such as periods of intense rainfall

and drought.

● Less frost and snow.

● Rising sea levels due to expansion of the sea and

melting of polar and glacial ice caps (compounded by

relative changes in land level due to geological events

in some locations such as the East Coast).

These changes will have profound effects and the purpose

of the impact studies is to look at these both in

terms of their local significance and across sectors such

as agriculture, wildlife, industry and health.

For the Environment Agency the impacts are also

significant. It regulates and manages water resources,

flood defence, water quality and fisheries along with air

and land quality.

Increasing temperatures and reduced summer rainfall

are expected to increase the demand for water for

domestic and commercial use. For example, people will

shower more and want to water their gardens, agriculture

will want to irrigate more and industry will require

more cooling water. There are already problems with

water supply in some areas where falling groundwater

levels due to over abstraction and low stream flows during

dry periods mean that restrictions are imposed on

abstractors most years. Changes in water availability

also affect wetlands and other water features which

have a consequential effect on wildlife. The Environment

Agency has recently published a series of Water

Resources Strategies (Environment Agency, 2001b)

which start to address these problems. Everyone is

Table 1 Changing Scenarios For East Midlands 2080-2100

The table shows how little the Medium-High scenarios for temperature and precipitation towards

the end of this century have changed with improvements in climate models used in 1998 and 2002.

UKCIP 1998 UKCIP 2002

Temperature Change o C Annual +2.8 to +3.2 +3.0 to +3.5

Summer +2.5 to +3.0 +3.0 to +4.0

Winter +3.0 to +3.5 +2.0 to +3.0

Precipitation % Change Annual +4 to +9 +0 to -10

Summer -15 to -30 -40 to -50

Winter +23 to +30 +20 to +30


94


familiar with the problems of drought in many third

world countries but the UK is likely to find itself in a

similar, if not so critical, position. Even so, the Water

Resources Strategies highlight that the annual effective

rainfall per head of population in parts of the UK is

already less than in countries such as Ethiopia.

The response has to include ensuring that new water

resources are made available but not before demand has

been reduced through improving water efficiency.

Much can be done to reduce demand by using waterefficient

appliances, reducing waste and leakage and

adopting trickle irrigation.

At the other extreme, intense storms at any time of

year can produce local flooding. Wetter winters are also

likely to increase the risk of more widespread flooding

as catchments become saturated and unable to absorb

heavier rainfall. Sea level rise also increases the risk of

coastal flooding. There have been several major floods

in the last five years affecting large parts of the country.

It is too early to say with confidence that these are due

to climate change as there are natural variations in climate

and flooding frequency anyway. However, they

are certainly indicative of the sort of events that can be

expected more frequently as this century progresses.

The responses to the increased risk of flooding

include building more defences along river banks and

coastal stretches, improving flood prediction tools and

warning systems and raising awareness among the population

at risk. Nearly 2 million properties are in areas at

some risk of flooding but many residents are unaware

because there has not been flooding in recent years. The

areas at risk are shown in indicative flood plain maps

which can be found on the Environment Agency’s web

site at www.environment-agency.gov.uk. Insurance companies

are naturally showing an interest as the damage

over the last few years has escalated. They are loading

premiums for property in flood risk areas and pressing

the Government to provide more money for flood

defence under threat of withdrawing cover.

There is little sense in producing more problems for

the future by building more properties in the flood

plains so the Environment Agency works closely with

local planning authorities to ensure that this does not

happen. Local flooding is also made worse by increased

rates of run off from developments such as paved areas

and roof drainage. The Environment Agency is keen to

promote sustainable drainage through techniques such

as porous pavements, soakaways and retention wetlands

to store the water underground or at least attenuate the

rate of run off.

The changes in temperature and water regime will

affect wildlife and there are many recorded instances of

alien species appearing, losses of some species and

extended growing seasons. New crops such as maize,

grapes and sunflowers are appearing. Some of these

changes could be beneficial, offering new markets for

farmers and a wider, or at least different, diversity of

wildlife. Decisions will have to be made about whether it

is sensible to try to preserve habitats against the climatic odds, or whether it

would be more sensible to go with nature and help species to adapt or move

to better areas.

Climate change will also impact on a wide range of other sectors. Health

risks from exotic diseases, damage to roads, rail and other infrastructure,

and loss of markets for some products but increases for others (example:

equipment for heating and air conditioning). Will working patterns become

more like those in southern Europe Will there be a renaissance in tourism

in the UK as the current popular resorts become unpleasantly hot These

are the sorts of questions addressed by the regional and sectoral studies.

Whichever of the climate scenarios proves eventually to be the one that

happens, they run close together in the early years and only diverge towards

the middle of this century. The outlook for the next 50 years or so is for an

annual average temperature rise of between 1 and 2 degrees. This is largely

unavoidable even if we cut our use of fossil fuels dramatically now. The best

that can be hoped for is that the Kyoto agreement is ratified and forms the

basis for future cuts of greenhouse gas emissions of up to 60% or more.

There are lots of opportunities to bring climate change issues into

schools. The UKCIP web site has many publications which can be a source

of information on local impact studies or specific to sectors such as health,

agriculture of wildlife. These could form the basis for a detailed look at the

potential impacts in the school catchment. In addition, looking at the

school’s use of energy for heating and lighting, local transport issues, water

use and flood risk all help to raise awareness of the difficulties in mitigation

and adaptation.

Dr Brian Waters, recently retired as Regional Water Manager for the Midlands

Region of the Environment Agency.

References

East Midlands Sustainable Development Round Table (2000) The Potential

Impacts of Climate Change in the east Midlands, Summary Report, available

from Environment Agency, 550 Streetsbrook Road, Solihull, B91 1QT

and at www.ukcip.org.uk

Environment Agency, (2001a) State of the Environment Report; West Midlands

Region, available from Environment Agency, 550 Streetsbrook Road,

Solihull, B91 1QT. A more detailed report “Climate Change in the West

Midlands” is available from the same address.

Environment Agency, (2001b), Water Resources for the Future: A Strategy for

England and Wales, March 2001. Available, along with Regional appendices,

from Environment Agency offices.

Hulme, M., Jenkins, G.J. (1998) Climate Scenarios for the UK: scientific

report. UKCIP Technical Report No. 1, Climatic Research Unit, Norwich, UK,

80pp.

Hulme, M., Jenkins, G.J., Lu, X., Turnpenny, J.R., Mitchell, T.D., Jones,

R.G., Lowe, J., Murphy, J.M., Hassell, D., Boorman, P., McDonald, R.,

and Hill, S. (2002); Climate Change Scenarios for the United Kingdom: The

UKCIP02 Scientific Report, Tyndall Centre for Climate Change Research,

School 0f Environmental Sciences, University of East Anglia, Norwich,

UK. 120pp. Available at www.ukcip.org.uk

95 www.esta-uk.org


ESTA Conference 2003:

“Earth Sciences in the 21st Century”

University of Manchester, 12th-14th September 2003

The next ESTA Course and Conference, hosted by the University of Manchester Department of Earth Sciences in

conjunction with the Manchester Museum, promises to be a most informative and enjoyable affair. Manchester

occupied much of our television viewing in the summer when the city hosted the 2002 Commonwealth Games,

and then gained (geological) fame again recently with a series of small (but certainly perceptible!) earthquakes. The

city of Manchester is enjoying a renaissance, and the centre is now a thriving village of loft apartments, striking

modern architecture, pleasant shopping areas, clubs and restaurants. Thanks to the Games, Manchester now has

some of the finest sports and leisure facilities in the country. The city is within easy reach of some of the finest

scenery and geological sites in the country: the Peak District, the Pennines, and the Cheshire Plain – destinations

of some of our Sunday field workshops.

The venue for the Friday and Saturday workshops, lectures and exhibitions will be the Department of Earth Sciences

laboratories and lecture rooms, as well as facilities in the Education Section of the Manchester Museum,

immediately opposite across Oxford Road. Coffee, tea and lunches will also be served here. The Museum has been

refurbished recently, and the geological galleries are a delight. Delegates will also see some of the new geochemical

laboratories in Earth Sciences.

Accommodation for delegates will be in comfortable en-suite rooms at Hulme Hall, just 10 minutes’ walk away

from the university and museum. Breakfast, evening meals, Conference Dinner, bar and Open Lectures will be

held at Hulme Hall. For those wishing to explore a little further, Hulme Hall is situated at the start of the ‘curry

mile’ – more than 50 neon-lit Asian restaurants in actually about half a mile.

Provisional Programme

Friday 12th September

INSET for local teachers and ESTA members, all day.

● Key Stages 1/2 –

● Key Stages 3/4 –

● Post-16 – Update for teachers of Geology at AS/A Level, largely led by Manchester staff.

● Higher Education

Saturday 13th September

The programme is yet to be arranged, but will consist largely of updating lectures and workshops. Whilst the majority

of these will be of interest to teachers of Geology to AS and A Level, much will be relevant to teachers of Earth Science

at all Key Stages. As well as some specific provision for Primary and lower Secondary teachers, attendance at the

full day will result in greater confidence through the acquisition of more background knowledge of the subject.

Sunday 14th September

● Fieldwork in the local region, with a choice of visits to be arranged.

Attendance is open to all with an interest in Earth science education, on a day visit, or a residential basis. (You do

not need to be an ESTA member). There will be Open Lectures on Saturday which will be free: there are fees for

other aspects of the conference, to cover refreshments and the usual overheads.

The convenor, Dr Paul Selden, will be pleased to supply further details and a booking form for the whole conference,

once these become available in the Spring of 2003.

For further information, contact the Conference Convenor: Dr Paul Selden, Dept of Earth Sciences, University

of Manchester, Manchester, M13 9PL. Tel: 0161 275 3296; email: Paul.Selden@man.ac.uk

Meanwhile, visit these websites:

http://www.man.ac.uk............................................University of Manchester

http://www.earth.man.ac.uk...................................Department of Earth Sciences (inc. a section on the recent earthquakes)

http://museum.man.ac.uk ......................................The Manchester Museum

http://www.man.ac.uk/conferences/hulme.html ....Hulme Hall

http://www.manchester.com...................................Virtual Manchester


96


Reviews

Geology and building stones in Wales (north) / Daereg a cherrig adeiladau yng

Nghymru (y gogledd); Geology and building stones in Wales (south) / Daereg a cherrig

adeiladau yng Nghymru (y de).

Graham Lott and Bill Barclay. Folded sheets 42x30cm;

British Geological Survey 2002, Keyworth, Nottingham NG123 5GG.

£1.95 each. ISBN 0-85272-423-3; 0-85272-422-5.

These two pamphlets are published

by the Geological Survey, but

produced in association with

CADW (Welsh Historical Monuments),

the National Museums and Galleries of

Wales and the Countryside Council for

Wales. They are printed on thin glazed

card, presumably for protection when

carried in the field. Each carries a

bilingual (Welsh and English) text:

Welsh on one side and English on the

other, but with a single set of

photographs, and an appropriate and

simplified geological map.

For each pamphlet, there is a brief

account of the geology of the region,

together with reference to the use of the

rocks in buildings (e.g. the purple

Caerbwdi sandstones of the Cambrian

for the building of St. David’s cathedral).

Illustrations, necessarily quite small, are

given of representative or important

buildings. These range from the

prehistoric huts at Din Lligwy, Anglesey,

and a terraced house in Pontypridd, to

castles and railway viaducts. In addition

to the use of Welsh stone (usually locally

sourced) there is also a section in each

pamphlet on Foreign stones. It is pointed

out that there are few good freestones in

Wales, and that easily worked stones have

been imported from a variety of foreign

sources, such as Bath and Portland

stones. These have principally been used

from the middle of the nineteenth

century, and also mainly for important

buildings, whether civic, religious or

commercial. Decorative stones are given

a paragraph in each pamphlet: again

there are not many Welsh stones that are

suitable, and so imported stones are

prevalent. Each pamphlet has a

geological column, listing not only the

geological periods, but also the principal

building stones found (the column in

English only). Finally, there is a list of

important geologists (all deceased) who

have worked in Wales, listed in order of

dates of birth, ranging from G. Owen

(1552-1613) and E. Lhuyd (1660-1613)

to R.M. Cummings (1926-1995).

The geological maps also show the

locations of the buildings illustrated, and

it is of interest that, with the exception of

the Old College Building in Aberystwyth

(incorrectly described as being of

Grinshill Stone – it is mainly of Cefn

Sandstone), no other buildings are

shown in Wales south of Harlech and

north of St. David,s. I would have liked

to see some illustration of , for example,

the houses of Dolgellau, constructed of

almost monolithic blocks of local

igneous rocks, or of the many uses of

greywackes in Mid Wales.

The authors and publishers are to be

congratulated on having produced

concise, informative and attractive

publications, widening our knowledge of

Welsh building stones from just the slate

industry, to take in rocks of all ages, and

in all situations. May we look forward to

seeing this series extended to cover areas

in the rest of Britain

Denis Bates

University of Wales,

Aberyswyth

97 www.esta-uk.org


Introduced









Technology Commi t e





Network



share’ se sion a the


update

B ok Reviews

Websearch



ache

Browne

Websearch


ESTA Diary

Reviews

JANUARY 2003

Friday 3rd - Sunday 5th January

ASE, University of Birmingham.

[Sat 4th is Earth Science day]

APRIL 2003

Wednesday 16th April

10:00 to 16:30 Mineral collecting and

conservation – hammering out a future

Harold Riley Suite, University of Salford

Wednesday 23rd - Friday 25th April

Geographical Association Annual

Conference

University of Derby

SEPTEMBER 2003

8th - 12th September

The BA Festival of Science 2003

University of Salford

Friday 12th - Sunday 14th September

ESTA Annual Conference

University of Manchester

SEPTEMBER 2004

6th - 10th September

The BA Festival of Science 2004


To Advertise in


EARTH

SCIENCES

Telephone

Ian Ray

0161 486 0326


EARTH

SCIENCES











Kingston 2 01



Discovering Geology: Fossil Focus, Graptolites.

Ian Wilkinson, Susan Rigby and Jan Zalasiewicz.

An Earthwise publication; folded sheet 42x30cm;

British Geological Survey 2001, Keyworth, Nottingham NG123 5GG.

ISBN 0-85-272390-3. £1.95.

This double-sided sheet, printed on

stout glazed card, follows the

format established in a number of

publications by the British Geological

Survey, packing a concise account of

graptolites into a minimum of space.

Colour is used both in the photographs

of individual graptolites, and also to great

effect in the diagrams.

The first panel deals with the

morphology of the graptolites, and with

their presumed modern relatives, the

hemichordates. A good cutaway diagram

of a Climacograptus shows the general

structure, together with a diagram of a

Didymograptus (described unfortunately

as a “tuning folk graptoloid”!). Though

this may be seen as a quibble, this latter

diagram seems too diagrammatic: the

two stipes appear to emerge from

opposite sides of the sicula, and the

sicula has a bulbous proximal end, rather

than tapering to an extended nema.

The second panel covers the range of

morphologies exhibited by the




EARTH

SCIENCES


chers’ A so



Evolution:


Cla sr om



High Str et

Peter Ke ne t




Fo sils and Time

Mike Tuke


Busine s and



Using Foam Ru ber in




Phenomena

John Wheeler


Devon Coast:



Update




planktonic graptoloids, and the habitats

in which they, and the sessile dendroids,

lived. I was interested to see that the

many branched form Cyrtograptus (c on

the diagram) is shown as living at abyssal

depths. However, this would mean that

most specimens would have come from

rocks interpreted as being oceanic: in

contrast many specimens come from

rocks which accumulated not on oceanic

crust, but on deeper areas within shelves

(such as the area around Builth Wells, in

Wales). It is still likely, though, that they

lived within deeper water than the

majority of other graptoloids.

A dramatic diagram shows the history

of graptolites, relating their diversity to

global events. This, together with the

text, also illustrates the enormous

potential that the graptoloids have as

global timekeepers, with a pinpoint

accuracy of only a few hundred thousand

years. Finally, a panel of “Graptolites

tales” deals with sex (all we can say is

that they probably did it); Charles

Lapworth; graptolites and roofing slates

(they can only rarely be found on your

roof); and what ate them (there is a

specimen of a crumpled-up graptolite

that may have been eaten: but we don’t

know who did). Two cartoons illustrate

this panel, as well as photographs.

As with the other publications in this

series, Graptolites tells a long story in

simple terms, with the aid of good

graphics. A surprising amount of detail is

given, which bears comparison with

coverage in the more basic textbooks.

Furthermore, it is better presented, and

also more up to date. It should certainly

be on the shelves alongside more

conventional texts, and students’

attention should be drawn to it.

Denis Bates

University of Wales,

Aberystwyth


98


Websearch

Walking with Beasts

Discovery Channel has launched a Walking with Beasts site,

which provides an opportunity to compare the approaches adopted

by the leading TV science channels in the US and the UK.

http://dsc.discovery.com/convergence/beasts/beasts.html

The BBC site is

www.bbc.co.uk/beasts

Coastal Environments

Coastline 2000

www.angliacampus.com/public/sec/geog/coastln/page02.php

Schemes of work

www.learn.co.uki/gleaming/secondary/topical/ks3/

coastalerosion/teachers/htm

www.angliacampus.com/tour/sec/geog/coastal/index.htm

Case study, Holderness coast

www.bennett.karoo.net/topics/coasts/html

Case study, Reculver

www.users.globalnet.co.uk/~drayner/recintro.htm

Case study, Droskyn Point, Perranporth, Cornwall

cil-www.oce.orst.edu:8080/pporth.html

All along the coastline

www.theukcoastalzone.com/regional.asp

National Geographic News: Archaeology & Paleontology

http://news.nationalgeographic.com/news/archaeology.html

Palaeontology in the News

http://www-geology.ucdavis.edu/~GEL3/paleonews.html

The Geological Society of America has re-posted its 1999 Geological

Time Scale at

geosociety.org/science/timescale/timescl.pdf

It can be printed from that site.

Glaciers and Ice

Monitoring Glacier Changes from Space

sdcd.gsfc.nasa.gov/GLACIER.BAY/hall.science.txt.html

Glacier and Ice Sheet Research Group

glacier.lowtem.hokudai.ac.jp/index-e.htm

Glaciological research

www.maths.ox.ac.uk/~fowler/research/glaciology.html

Glaciers and Glaciations - Ice Sheets and Glacial Lakes

vulcan.wr.usgs.gov/Glossary/Glaciers/framework.html

Landscape Evolution

CRC LEME:

Cooperative Research Center for Landscape Evolution and Mineral

Exploration

leme.anu.edu.au/

Numerical Models Of Landscape Evolution

adder.ocean.dal.ca/philippe/LEM_Numerical_models.html

Modeling Landscape Evolution

erode.evsc.virginia.edu/frlect/introduction/index.html

Oceans

FEMA Fact Sheet: Hurricanes

www.fema.gov/fema/hurricaf.html

Ocean Planet

seawifs.gsfc.nasa.gov/ocean-planet.html

USGS Center for Coastal Geology

stimpy.er.usgs.gov/

USGS Marine and Coastal Geology Program

marine.usgs.gov/

USGS Woods Hole Field Center

woodshole.er.usgs.gov/

NOAA VENTS Program

www.pmel.noaa.gov/vents/home.html

Exploration of Mid-Ocean Ridges

www.nerc.ac.uk/BRIDGE/


National Earthquake Information Center

wwwneic.cr.usgs.gov/

Caltech Seismological Laboratory

www.gps.caltech.edu/seismo/seismo.page.html

Tsunami

www.geophys.washington.edu/tsunami/intro.html

Seismology and Earthquake Information

www.geophys.washington.edu/SEIS/welcome.html

USGS: Latest Earthquake Information

quake.wr.usgs.gov/QUAKES/CURRENT/index.html

San Francisco Bay Area Earthquake Map

quake.wr.usgs.gov/recenteqs/Maps/SF_Bay.html

99 www.esta-uk.org




Introduced













Technology Commi t e





Network



share’ se sion a the


Kingston 2001


update

Book Reviews

Websearch



ache



achers’ Assoc



Cla sroom



High Street

Peter Kenne t




Fo sils and Time

Browne



Phenomena

John Wheeler


Devon Coast:



Update


Websearch




Websearch

Earth’s Interior


www.seismo.unr.edu/ftp/pub/louie/class/100/interior.html

Earth’s Interior & Plate Tectonics

www.solarviews.com/eng/earthint.htm


www.seismo.unr.edu/ftp/pub/louie/class/100/interior.html

Plate Tectonics

NGDC Marine Geology and Geophysics Division

www.ngdc.noaa.gov/mgg/mggd.html

Ocean Drilling Program

www-odp.tamu.edu/

Plate Motion Calculator

manbow.ori.u-tokyo.ac.jp/tamaki-html/plate_motion.html


volcano.und.nodak.edu/vwdocs/msh/ov/ovpt/ovpt.html

Structure and Tectonics Groups on the WWW

craton.geol.brocku.ca/guest/jurgen/SITES.HTM

Caribbean Geology & Tectonics Website

www.fiu.edu/orgs/caribgeol

Welcome to the World Stress Map (WSM)

www-wsm.physik.uni-karlsruhe.de

Plate Tectonics: History of an Idea


www.ucmp.berkeley.edu/geology/techist.html

This Dynamic Earth (USGS)

pubs-usgs-gov/publications/text/dynamic.html

Plate Tectonics: A whole new way of looking at your planet

www.platetectonics.com/index.html

Plate Tectonic Reconstructions at UTIG

www.ig.utexas.edu/research/projects/plates/plates.html

The Active Tectonics Web Server

www.muohio.edu/tectonics/ActiveTectonics.html

Earth Systems, Impacts

Climate Processes over the Oceans

eos.atmos.washington.edu/

Comet Observation Home Page

encke.jpl.nasa.gov

Climate Change

www.ucsusa.org/globalwarming/index.html

U.S. Census Bureau

www.census.gov/

New Posting Retiring Stay in touch with

Teaching Earth Sciences News and Activities

Subscribe to

Teaching Earth Sciences

Subscription rates

Full membership

Student and retired membership

£25.00 to UK addresses £12.50 to UK addresses

Subscriber Details

TITLE

NAME


EARTH

SCIENCES




EARTH

SCIENCES


Evolution:

ADDRESS



Mike Tuke


Busine s and



Using Foam Rubber in




TOWN/CITY

COUNTRY

E-MAIL ADDRESS

POST CODE/ZIP

Membership Secretary:

Owain Thomas

PO Box 10, Narberth

Pembrokeshire SA67 7YE

Teaching Earth Sciences - serving the Earth Science Education Community


100



Mineral Collecting and Conservation:

Hammering Out a Future

A one day conference to be held at the

Harold Riley Suite, University of Salford,

Wednesday 16th April 2003, 10:00 to 16:30

Mineral collecting is scientifically and

educationally important and a hobby enjoyed by

many. However, many mineral sites are finite and the

issue of sustainable collecting on mineral sites is

becoming increasingly important. Collecting is

fundamental to mineralogical research, and for

educational, commercial and aesthetic purposes, but

indiscriminate activity can deplete or destroy a

mineralogical site. This conference aims to discuss the

different aspects of mineral collecting and the best

way of conserving the available mineral resource for

future use by all interest groups.

This meeting aims to open a debate rather than

attempt to reach solutions and provides an

opportunity to share views and identify and discuss

issues. Speakers have been chosen to reflect a full

range of views on the issues surrounding mineral

collecting and include; the statutory conservation

bodies; professional, hobbyist and academic research

collectors; museums; landowners; and industrial

archaeologists. The conference will conclude with an

open debate and it is hoped that stimulating

discussion will follow.

The meeting will be co-convened by English

Nature, the Geological Society’s Geoconservation

Commission and the Russell Society. The conference

proceedings will be published by English Nature and

will be available shortly after the conference.

Delegates will also have a chance to express their own

views on mineral collecting and conservation in the

form of written statements, which will be included

with the proceedings volume and collected on the day

of the conference.

Further information from:

Jennifer Yau,

Environmental Impacts Team,

English Nature, Northminster House,

Peterborough, UK PE11UA

(01733 455504).

Do You Use Geological Sites – Have Your Say

We need your help so that we can help you. Many readers of

Teaching Earth Sciences use geological and geomorphological

sites as a teaching resource – these might include National Nature

reserves (NNRs), Sites of Special Scientific Interest (SSSIs), Regional

Important Geological/Geomorphological Sites (RIGS), show caves,

country parks, coastal, river and other natural sections, pits and

quarries.

If this includes you or your school or you manage such a site for

visits by school groups, then read on.

The National Stone Centre (NSC) has been asked by English

Nature to examine particularly the opportunities presented by the

National Curriculum for using geological sites. The brief also includes

a review of the use of geological sites for teaching Earth science and by

schools in general. The NSC is working closely with ESTA members

on this scheme. The time allowed for the project is very limited indeed

and so will only enable a scoping study to be carried out.

So we need as much help as you can give us.

Please let the NSC know which sites you use and how you use

them – with what groups – for what purpose – what curriculum area

and how often Do you use background material published by others

or produce you own customised material Do you experience access

problems to sites Ideally would you like to use geological sites more

frequently If so, what factors constrain use – cost, timetabling, staff

cover, insurance cover, distance, curriculum/specification limitations

If you wish we can e-mail these questions to you so that you can

respond by e-mail (see below).

The exercise may be a first step in helping English Nature to work

more closely with schools – to help you to use geological and

geomorphological sites. So your comments could have a positive

payback for you in time. If you can help, please respond, if possible

before 23 December 2002 to ian@nationalstonecentre.org.uk

Ian Thomas

Director, National Stone Centre

Porter Lane, Wirksworth, Derbyshire DE4 4LS

Tel + Fax: 01629 824833

GeoSciEd IV, Calgary, Canada, August 10-14, 2003

Details of this international conference are shown on the separate

advertisement (p.102) and much more information is available on the

highly-informative and regularly-updated website, www.geoscied.org. The

objective of the meeting is to support colleagues across the world who are

involved in Earth science education from elementary to university/college

levels and beyond, through a variety of presentations, workshops and field

visits. There will be opportunities to share expertise and experiences, for

personal development and for networking with other geoscience educators

from around the world. We do hope that ESTA and other readers of TES

will be able to attend the meeting and to contribute as well. The Calgary

Organising Committee hopes to support a limited number of attendees

from Developing Countries. Consult the web site for further details.

CK & RDT

101 www.esta-uk.org

GeoSci advert

to be dropped in by printers


102

THEMATIC TRAILS

GEOLOGY AND THE BUILDINGS OF OXFORD Paul Jenkins

A walk through the city of Oxford is likened to visiting an

open-air museum. Attention is drawn to the variety of

building materials both ancient and modern, used in the

fabric of the city. Discussion of their suitability, durability,

susceptibility to pollution and weathering, maintenance

and periodic replacement is raised.

44 pages, 22 illustrations, ISBN 0 948444 09 6 Thematic

Trails (1988) £2.40

GEOLOGY AT HARTLAND QUAY Chris Cornford & Alan Childs

In a short cliff-foot walk along the beach at Hartland

Quay, visitors are provided with a straightforward

explanation of the local rocks and their history.

Alternative pages provide a deeper commentary on

aspects of the geology and in particular provides

reference notes for examining the variety of structures

exhibited in this dramatic location.

40 pages, 47 illustrations, ISBN 0 948444 12 6 Thematic

Trails (1989) £2.40

THE CLIFFS OF HARTLAND QUAY Peter Keene

Interpreting the shapes of coastal landforms is introduced

as a method of understanding something of the

environmental history of this dramatic coastal landscape.

A short walk following the coastal path to the south of

Hartland Quay puts this strategy into practice.

40 pages, 24 illustrations, ISBN 0 948444 05 3

Thematic Trails (1990) £2.40

STRAWBERRY WATER TO MARSLAND MOUTH Peter Keene

A short cliff-top walk between the small but spectacular

coastal coombes of Welcome Mouth and Marsland

explains what beaches, streams and valley sides can

tell us of the history of this coastal landscape. 40

pages, 24 illustrations, ISBN 0 948444 06 1


VALLEY OF ROCKS; LYNTON Peter Keene & Brian Pearce

The drama of the valley is explored both by offering

explanation for the spectacular scenery and by recalling

its theatrical setting as seen through the eyes of those

who have visited the valley in the past.

44 pages, 35 illustrations, ISBN 0 948444 25 8


THE CLIFFS OF SAUNTON Peter Keene & Chris Cornford

I n a short cliff-foot walk along the beach at Saunton,

visitors are provided with an explanation for the local rocks

that make up the cliff and the shore. Alternative pages

provide a deeper commentary on aspects of the geology

and a chance on the return walk to reconstruct the more

recent history of this coast by a practical examination of the

cliff face. 44 pages, 30 illustrations, ISBN 0 948444 24 X

Thematic Trails (May 1993) £2.40

INTERPRETING PLEISTOCENE DEPOSITS Peter Keene

A field interpretation guide for beginners. A simple

teaching model using an adapted graphic log sheet. Of

wide general educational application, but designed for

use with the following trails: ‘Westward Ho! Coastal

Landscape Trail’, ‘Valley of Rocks, Lynton’, ‘The Cliffs of

Saunton’, ‘Strawberry Water to Marsland Mouth’, ‘Prawle

Peninsula Landscape Trail’ and ‘Burrator Dartmoor

Landform Trail’ 10 pages, 10 illustrations

Thematic Trails (1993 edition) £2.40

MENDIPS New Sites for Old;

a student’s guide to the geology of the east Mendips. This

guide gives a detailed description of 39 safe, accessible

sites chosen for their educational potential.

192 pages, 46 illustrations,

ISBN 086139 319 8 (NCC 1985) £2.50

MALVERN HILLS; a student’s guide to the geology of the

Malverns. D. W. Bullard (1989)

The booklet includes detailed description of 21 geological

sites of interest in the area.


ISBN 086139 548 4 (NCC) £2.25

WENLOCK EDGE; geology teaching trail M. J. Harley (1988)

Six sites suitable for educational fieldwork are described

and suitable exercises outlined.


ISBN 086139 403 8 (NCC) £1.50

BURRATOR, DARTMOOR LANDFORM TRAIL Peter Keene & Mike

Harley (1987)

An interactive circular 6 mile walk exploring the evolution

of tor and valley scenery on Dartmoor.


ISBN 086139 385 6 (NCC) £1.50

THE ICE AGE IN CWM IDWAL

The Ice Age invested Cwm Idwal with a landscape whose

combination of glaciological, geological and floristic

elements is unsurpassed in mountain Britain. Cwm Idwal

is readily accessible on good paths within a few minutes

walk of the modern A5 route through Snowdonia.


ISBN 0 9511175 4 8

Addison Landscape Publications (1988) £3.00

THE ICE AGE IN Y GLYDERAU AND NANT FFRANCON

Ice in the last main glaciation in Wales carved the glacial

highway of Nant Ffrancon through the heart of Snowdonia

so boldly as to ensure its place amongst the best known

natural landmarks in Britain. The phenomena is explained

in a way that is attractive to both specialist and visitor

alike. 30 pages, 20 illustrations,

ISBN 0 9511175 3 X

Addison Landscape Publications (1988) £3.00

LONDON. ILLUSTRATED GEOLOGICAL WALKS.

BOOK 1 (The City)

Adds to the well-known Pevsner accounts of the buildings

of the City of London by offering comment upon the rock

types used in familiar City streets. Maps set out the route

clearly. No previous knowledge of geology is assumed. 98

pages, 98 photographs, 14 maps,

ISBN 0 7073 0350 8

Geologists’ Association (1984) £4.95

LONDON. ILLUSTRATED GEOLOGICAL WALKS.

BOOK 2 (The West End)

A wide range of exotic rock types are found in the shop

fronts of Piccadilly, Tottenham Court Road and the office

blocks of Central London. Again no previous knowledge of

geology is assumed.

142 pages, 128 photos, 16 maps,

ISBN 0 7073 0416 4

Geologists’ Association (1985) £4.95

Some earlier items are still available - please enquire

ORDERS TO: Dave Williams, Corner Cottage, School Lane, Hartwell, Northampton, NN7 2HL E-mail: earthscience@macunlimited.net

Official orders will be invoiced. Cheques and postal orders should be made payable to ESTA. Order forms avaliable from the ESTA Website

103 www.esta-uk.org

Key Stage 3

Science of the Earth 11-14 Units have been devised to introduce Earth Science to pupils at Key

Stage 3 level as part of their National Curriculum studies in Science and Geography.

Each Unit occupies about one double period of teaching time and the Units are sold as 3-Unit

packs. Units that are available now are:-

GW: Groundwork - Introducing Earth Science

GW1 - Found in the Ground

GW2 - Be a Mineral Expert

GW3 - Be a Rock Detective

LP: Life from the Past - Introducing Fossils

LP1 - Remains to be seen

LP2 - A well-preserved specimen

LP3 - A fate worse than death - fossilization!

ME: Moulding Earth’s Surface - Weathering, Erosion

and Transportation

ME1 - Breaking up rocks

ME2 - Rain, rain and rain again

ME3 - Landshaping

PP: Power from the past: coal (a full colour poster is

available with this Unit for a p & p charge of

£1.15 (inc. VAT) please indicate if you do not

require this.

PP1 - Coal swamp

PP2 - Layers and seams

PP3 - ‘Unspoiling’ the countryside

HC: Hidden changes in the Earth: introduction to

metamorphism

HC1 - Overheated

HC2 - Under Pressure

HC3 - Under Heat and Pressure

M: Magma - introducing igneous processes

M1 - Lava in the lab.

M2 - Lava landscapes

M3 - Crystallising magma

SR: Secondhand rocks: Introducing sedimentary

processes

SR1 - In the stream

SR2 - Blowing hot and cold

SR3 - Sediment to rock, rock to sediment

BM: Bulk constructional minerals

BM1 - What is our town made of

BM2 - From source to site

BM3 - Dig it - or not

FW: Steps towards the rock face - introducing

fieldwork

FW1 - Thinking it through

FW2 - Rocks from the big screen

FW3 - Rock trail

ES: Earth’s surface features

ES1 - Patterns on the Earth

ES2 - Is the Earth cracking up

ES3 - Earth’s moving surface

E: Power source: oil and energy

E1 - Crisis in Kiama - which energy source now

E2 - Black gold - oil from the depths

E3 - Trap - oil and gas caught underground

WG: Water overground and underground

WG1 - Oasis on a desert island-the permeability

problem

WG2 - Out of sight, out of mind - waste disposal

and ground water pollution

WG3 - The dam that failed

SPECIAL REDUCED PRICE

£2.00 each (post free)

for Key Stage 3

A Teachers’ Guide to the

‘Science of the Earth’ Approach - £1.00

Key Stage 4

SoE1: Changes to the atmosphere

SoE2: Geological Changes - Earth’s Structure and Plate Tectonics

SoE3: Geological Changes - Rock Formation and Deformation

Investigating the Science of the Earth. Practical and investigative activities for Key Stage 4 and beyond.

Price £2.95(Per Unit)

ROUTEWAY – solving planning and technical problems of building a major road. A three-unit pack dealing with aspects

of planning and engineering geology and associated environmental problems. Science and

Geography courses at Key Stage 4. Also applicable to problem-solving modules in ‘A’ level or Vocational Science or

Geology courses.

Price: £4.95

Please note - to claim ESTA member prices on the above items, you must enclose a copy of this

advertisement or an ESTA order form, or simply mention your ESTA membership.




104

GRAIN SIZE SCALE

Laminated cards specially printed for ESTA

(6 x 9 cm credit card size). They show grains

from coarse sand down to silt.

30p each

20p each for 20 to 99 copies

100 copies or more £15

1000 copies £100

WORKING WITH ROCKS PACK:

Folder of Teacher notes and worksheets; Christina’s Story

- tale of a marble headstone; 16 postcards of building

stones - for town and graveyard trails.

KS1/2/3. £7.00

ROCK, MINERAL & FOSSIL KITS

1. ESTA MINERAL SAMPLES

Boxed set of ten minerals (haematite, magnetite,

galena, pyrite, mica, gypsum, calcite, halite, quartz &

feldspar), plus steel nail, copper coin, streak plate,

dropper botter & magnifier. Essential for use with

activities in PEST 9 - MINERALS (copy included).

Suitable for KS2/KS3. £15.00

2. DIVERSITY OF LIFE - FOSSIL REPLICAS SET

Boxed fossil replicas, selected to illustrate the

diversity of life over geological time (dinosaur tooth,

trilobite, ammonite, shark tooth, icthyosaur tooth,
