Model: PUHY-P168TSKMU-A
(Consists of One PUHY-P96TKMU-A, One PUHY-P72TKMU-A and One CMY-Y100CBK3 Twinning Kit)
Job Name:
Location:
Engineer Name: Contractor:
System No.:
OUTDOOR VRF HEAT PUMP SYSTEM FEATURES
• 3-phase, 208/230V
• Modular variable refrigerant flow (VRF) systems;
smaller capacity units can be piped together to form a single,
large-capacity two-pipe system
• Required Twinning Kit allows for easy field piping connection
• Selectable fan static, 0.12 or 0.24"WG external static pressure;
factory set to 0"WG
• Connects to CITY MULTI indoor units; controlled via
CITY MULTI Controls Network (CMCN)
• External finish: Pre-coated Galvanized-steel Sheets
• Operating Temperature Range
Cooling (Outdoor): 23° ~ 115°F (-5° ~ +46°C) DB
Heating (Outdoor): -4° ~ +60°F (-20° ~ +16°C) WB
Date:
PUHY-P96TKMU-A
PUHY-P72TKMU-A
OPTIONAL PARTS
□ Twinning Kit*.…………………………………...…….CMY-Y100CBK3
□ T-Branch Joint (≤ 72,000 Btu/h)………………..........CMY-Y102SS-G2
□ T-Branch Joint (≤ 144,000 Btu/h)……………….…....CMY-Y102LS-G2
□ T-Branch Joint (≤ 234,000 Btu/h)……………….........CMY-Y202S-G2
□ Header (4-Branch; ≤ 72,000 Btu/h)........………………CMY-Y104C-G
□ Header (8-Branch; ≤ 144,000 Btu/h)......………………CMY-Y108C-G
□ Header (10-Branch; ≤ 234,000 Btu/h)....………………CMY-Y1010C-G
* Twinning Kit is necessary to combine the refrigerant flows of the
modules and is sold separately.
Specifications System Module 1 Module 2
Unit Type PUHY-P168TSKMU-A PUHY-P96TKMU-A PUHY-P72TKMU-A
Nominal Cooling Capacity Btu/h 168,000 96,000 72,000
Nominal Heating Capacity Btu/h 188,000 108,000 80,000
External Dimensions (H x W x D) In. / mm Refer to Module Data
65 x 48-1/16 x 29-5/32 /
65 x 36-1/4 x 29-5/32 /
1,650 x 1,220 x 740
1,650 x 920 x 740
Net Weight Lbs. / kg 953 / 436 532 / 241 430 / 195
Electrical Power Requirements Voltage, Phase, Hertz Refer to Module Data** 208 / 230V, 3-phase, 60Hz**
Cooling Power Input kW 12.71
Heating Power Input kW 14.02
Refer to System Data
Cooling Current (208/230V) R.L.A. 39.1 / 35.4
Heating Current (208/230V) R.L.A. 43.2 / 39.1
Refer to System Data
Minimum Circuit Ampacity
(MCA)**
A Refer to Module Data** 34 / 31** 25 / 23**
Maximum Breaker Size** A Refer to Module Data** 40** 30**
Maximum Overcurrent Protection** A Refer to Module Data** 57 / 52** 42 / 38**
Piping Diameter
From Twinning Kit to Indoor Units Liquid (High Pressure) 5/8 / 15.88
Refer to System Data
(Brazed) (In. / mm)
Gas (Low Pressure) 1-1/8 / 28.58
From Modules to Twinning Kit Liquid (High Pressure)
3/8 / 9.52 3/8 / 9.52
Refer to Module Data
(Brazed) (In. / mm)
Gas (Low Pressure) 7/8 / 22.2 7/8 x 22.2
Indoor Unit
Total Capacity
50 to 130% of ODUs
Model / Quantity P06 ~ P96 / 2 to 36
Refer to System Data
Sound Pressure Levels dB(A) 61.0 58.0 58.0
Fan
Type x Quantity Propeller Fan x 1 Propeller Fan x 1
Refer to Module Data
Airflow Rate CFM 6,200 6,200
Direct-drive Inverter Motor Output kW 0.92 0.92
Compressor Operating Range 6% to 100% Refer to System Data
Compressor Type x Quantity
Inverter-driven Scroll Hermetic x 1 Inverter-driven Scroll Hermetic x 1
Compressor Motor Output kW Refer to Module Data
7.1 5.5
Compressor Crankcase Heater kW - -
Refrigerant
R410A
Refer to Module Data
Lubricant
MEL32
High-pressure Protection Device
601 psi / 4.15 MPa 601 psi / 4.15 MPa
Compressor / Fan Protection Device Refer to Module Data Overheat Protection / Thermal Switch Overheat Protection / Thermal Switch
Inverter Protection Device Overheat / Overcurrent Protection Overheat / Overcurrent Protection
Blue Fin Anti-corrosion Protection: Cellulose- and polyurethane-resin coating treatment applied to condenser coil that protects it from air contaminants;
≥1μm thick; Salt Spray Test Method - no unusual rust development to 480 hours.
** Each individual module requires a separate electrical connection. Reference electrical data for each individual module.

Module :
PUHY-P168TSKMU-A – DIMENSIONS
740(29-5/32)
1220(48-1/16)
30(1-3/16) 920(36-1/4)
Discharge air
Outdoor unit 1
Outdoor unit 2
Intake
air
Intake
air
Intake
air
Left view c
a
To indoor unit
Liquid Twinning pipe
d b
To indoor unit
Gas Twinning pipe
Front view
Twinning pipe connection size
Package unit name
f
PUHY-P168TSKMU-A(-BS)
1650(64-31/32)
e
PUHY-P168TSKMU-A(-BS)
PUHY-P96TKMU-A(-BS)
PUHY-P72TKMU-A(-BS)
CMY-Y100CBK3
ø15.88(5/8)
ø28.58(1-1/8)
Outdoor unit 1
Outdoor unit 2
Component unit name
Gas
d or f
Liquid
c or e
Unit model
Outdoor Twinning Kit(optional parts)
ø22.2(7/8)
ø22.2(7/8)
ø9.52(3/8)
ø9.52(3/8)
P72
P96
Twinning pipe~Outdoor unit
Gas
Liquid
Indoor unit~Twinning pipe
Unit : mm(in.)
Note 1.Connect the pipes as shown in the figure above. Refer to the table above for the pipe size.
2.Twinning pipes should not be tilted more than 15 degrees from the horizontal plane.
Be sure to see the Installation Manual for details of Twinning pipe installation.
3.The pipe section before the Twinning pipe (sections "a" and "b" in the figure) must have at least 500mm(19-11/16) of straight section
(*including the straight pipe that is supplied with the Twinning pipe).
4.Only use the Twinning pipe by Mitsubishi (optional parts).
a
b

Module :
PUHY-P96TKMU-A – DIMENSIONS
PUHY-P96TKMU-A(-BS)
Note1.Please refer to the next page for information
regarding necessary spacing around the
unit and foundation work.
2.At brazing of pipes, wrap the refrigerant service valve
with wet cloth and keep the temperature of
refrigerant service valve under 120°C(248°F).
740(29-5/32)
150(5-29/32)
Gas
Connecting pipe specifications
Diameter
Model Refrigerant pipe
Service valve
Liquid Gas Liquid
70
(23-5/8)
(2-25/32) =(5-29/32)X4
600=150×4
4X5-ø4.6(3/16) Hole
(Make hole at the plastic fan guard
for snow hood attachment)
19.5
(25/32)
1181(46-1/2)
1220(48-1/16)
19.5
(25/32)
ø22.2 Brazed ø9.52 ø28.58
(7/8) *2
(3/8) (1-1/8)
ø9.52 Brazed
(3/8) *1
(ø12.7 Brazed)
(1/2) *2 *3
Top view
Discharge air
PUHY-P96TKMU
303
(11-15/16)
*1 Expand the on-site piping and connect to the refrigerant service valve piping.
*2 Use the pipe joint(field supply) and connect to the refrigerant service valve piping.
*3 Furthest piping length (OU from IU) 90m(295ft)
Control box
> =
1650(64-31/32)
Intake
air
4
7
3
(5-17/32) (3-1/16)
150 × 94 Knockout hole
(5-29/32) (3-23/32)
ø62.7 or ø34.5 Knockout hole
(2-15/32) (1-3/8)
ø43.7 or ø22.2 Knockout hole
(1-3/4) (7/8)
ø65 Knockout hole
(2-9/16)
ø52 Knockout hole
(2-1/16)
ø34 Knockout hole
(1-11/32)
89 77
(3-17/32) (3-1/16)
(8-9/16)
217
222
(8-3/4)
20 20 75(2-31/32)
(13/16) (13/16)
586(23-3/32)
57
(9-29/32) 251 58(2-5/16)
(2-1/4)
(10-23/32) 272 140(5-17/32)
Left side view Front view
(6-25/32)
29.5
(1-3/16)
(4-25/32)
(5-3/4)
(7-23/32)
(26-13/16)
681(678~684)
(26-23/32~26-15/16)
(Mounting pitch)
(740)(29-5/32)
145
(5-23/32)
94 84
(3-23/32) (3-5/16)
(10-23/32)
(11-7/8)
(8-15/16)
Refrigerant service
valve
Refrigerant service
valve
29.5
(1-3/16)
57
(2-1/4)
(3-5/32) (Mounting pitch) (3-5/32)
Bottom view
Intake
air
1347(53-1/16)
Service
panel
Refrigerant service valve
1
Intake
air
Specifications
140 × 77 Knockout hole
Usage
NO.
Refrigerant service valve
Front through hole
For pipes
Bottom through hole
Front through hole
Front through hole
For wires
2X2-80(3-5/32)X35(1-13/32) Oval hole
Bottom through hole
Bottom through hole
2X2-14(9/16)X20(13/16) Oval hole
Front through hole
For transmission cables
150(5-29/32)
83(3-9/32)
272
301
227
5
2
6
80 1060(41-3/4)
54(2-5/32)
1
2
172
3
4
5
6
7
121
196
146
Unit : mm(in.)
80

Module :
PUHY-P72TKMU-A – DIMENSIONS
2. EXTERNAL DIMENSIONS
PUHY-P72TKMU-A(-BS)
2X5-ø4.6(3/16) Hole
(Make hole at the plastic fan guard
for snow hood attachment)
Note1.Please refer to the next page for information
regarding necessary spacing around the
unit and foundation work.
2.At brazing of pipes, wrap the refrigerant service valve
with wet cloth and keep the temperature of
refrigerant service valve under 120°C(248°F).
Connecting pipe specifications
Diameter
Service valve
Refrigerant pipe
Model
Gas
Liquid
Liquid Gas
ø28.58
(1-1/8)
ø9.52
(3/8)
PUHY-P72TKMU ø9.52 Brazed ø22.2 Brazed
(3/8) *1 (7/8) *2
*1 Expand the on-site piping and connect to the refrigerant service valve piping.
*2 Use the pipe joint(field supply) and connect to the refrigerant service valve piping.
Specifications
140 × 77 Knockout hole
Usage
(5-17/32) (3-1/16)
150 × 94 Knockout hole
(5-29/32) (3-23/32)
ø62.7 or ø34.5 Knockout hole
(2-15/32) (1-3/8)
ø43.7 or ø22.2 Knockout hole
(1-3/4) (7/8)
ø65 Knockout hole
(2-9/16)
ø52 Knockout hole
(2-1/16)
ø34 Knockout hole
(1-11/32)
Control box
NO.
(8-9/16)
217
89 77(3-1/16)
(3-17/32)
303
(11-15/16)
(2-25/32) =(5-29/32)X4
(23-5/8)
Intake
air
Discharge air
Intake
air
Intake
air
Service
panel
(2-5/32)
(6-25/32)
222
(8-3/4)
57
(2-1/4)
19.5
881(34-11/16) 19.5
(25/32) 920(36-1/4) (25/32)
20
20
(13/16) (13/16)
586(23-3/32)
Refrigerant service valve
Refrigerant service valve
57
(2-1/4)
(7-15/16)
(8-3/4)
222 150(5-29/32)
251 83
177 (3-9/32)
(7-23/32)
(5-3/4)
(4-25/32)
145(5-23/32)
94 84(3-5/16)
(3-23/32)
(26-13/16)
29.5
681(678~684)
29.5
(1-3/16) (26-23/32~26-15/16) (1-3/16)
(Mounting pitch)
(8-3/4)
(9-29/32)
(6-31/32)
6
Refrigerant service
valve
4
3
5
2
75
(2-31/32)
58(2-5/16)
140(5-17/32)
Refrigerant service
valve
(3-5/32) (Mounting pitch) (3-5/32)
Front through hole
1
For pipes
7
1
2X2-80(3-5/32)X35(1-13/32) Oval hole
2X2-14(9/16)X20(13/16) Oval hole
Bottom through hole
2
Front through hole
3
Front through hole
4
For wires
Bottom through hole
Bottom through hole
Front through hole
For transmission cables
740(29-5/32)
Top view
1347(53-1/16)
1650(64-31/32)
70
600=150X4
150(5-29/32)
Left side view
201
222
Front view
(740)(29-5/32)
80 760(29-15/16) 80
Bottom view
5
6
7
Unit : mm(in.)
54
146
196
121
172

Twinning Kit:
CMY-Y100CBK3
CMY-Y100CBK3
For Gas pipe:
For Liquid pipe:
Ref.: CMY_Y100VBK2_EXD_EUDB_SI
in.
1-1/8"
1-1/8"
Note 2 13-15/32"
19-29/32"
Pipe cover
(Dot-dashed part)
Local brazing
23-5/32"
7/8"
Distributer
1"
1"
7/8"
6-5/16"
5/8"
5/8"
7-7/32"
1/2"
Local brazing
Note 2
3-9/32"
Pipe cover
(Dot-dashed part)
9-1/2"
Distributer
1/2"
1/2"
1/2"
3-7/8"
7/8"
1/2" 3/8"
1-15/16"
(2 pcs.)
2-15/32"
(2 pcs.)
1-1/8"
5/8"
1/2"
1-15/16"
7/8" 3/4"
2-15/32"
(2 pcs.)
ID: Inner Diameter
OD: Outer Diameter
Note 1. Reference the attitude angle of the branch pipe below the fig.
Distributer
15
The angle of the branch pipe for high pressure is within 15 against the horizontal plane.
2. Use the attached pipe to braze the port-opening of the distributer.
3. Pipe diameter is indicated by inside diameter.
4. Only use the Twinning pipe by Mitsubishi (optional parts) .
Notes:
Mitsubishi Electric Air Conditioning & Refrigeration Systems Wo rks acquired ISO
based on a review of quality warranties for the production of refrigeration and air
conditioning equipment.
ISO Authorization System
The ISO 9000 series is a plant authorization system relating to quality warranties as
development, production, installation and auxiliary services" for products built at
an authorized plant.
Mitsubishi Electric Sales Canada Inc.
www.MitsubishiElectric.ca
Mitsubishi Electric Air Conditioning & Refrigeration Systems Works acquired environmental
The ISO 14000 series is a set of standards applying to environmental protection set by the
International Standard Organization (ISO).
Specifications are subject to change without notice.
SB_PUHY-P168TSKMU-A_201206a
