*Opm. Projectsloten E 1.2 14-01-2003 10:51 Pagina 1

Project locks

lock & cylinder technology

NEMEF BV P.O. Box 13, 7300 AA Apeldoorn, The Netherlands

Telephone +31 55 312 84 00 Telefax +31 55 312 20 87 E-mail info@nemef.nl Internet www.nemef.nl

JTP Reclamebureau / 9999990377 februari 2003

lock & cylinder technology


*Opm. Projectsloten E 1.2 14-01-2003 13:57 Pagina 3

Lock & cylinder technology

NEMEF guarantees an extensive and continually

growing assortment of locks and builders’ hardware,

such as door locks, profile cylinders, multi-point locks

and access control. These quality products that leave

the NEMEF plant reach their customers quickly and

efficiently due to a hypermodern distribution centre.

NEMEF is working today on the standard for tomorrow

through innovative product development focused on

contemporary user convenience.

3


*Opm. Projectsloten E 1.2 14-01-2003 10:52 Pagina 5

Project locks

lock & cylinder technology

The proven utility of NEMEF

project locks

The project building business asks for reliable locks and

builders’ hardware, which fulfil the highest quality

demands and which are also easy to install. Especially

for internal doors, NEMEF has developed a wide range

of project locks, which are particularly suitable for

heavy and frequent usage.

The locks, which are specified as per DIN 18251 part 1, or

are manufactured according to the dimensions in this

standard, are divided into several series, each with their

own specific characteristics: the standard 1030 series

(Class II), the heavy-duty 1060 series (Class III) and the

extra heavy-duty 7000 series (Class III and IV), which are

all handed, and the simple 340 series, standard 6600

series and the extra heavy-duty 6100 series, which are

all reversible. All project locks are suitable for use

with NEMEF project furniture in brass, aluminium or

stainless steel. For this reason, NEMEF project locks

have already been used on a large scale for many

years. Therefore, NEMEF guarantees a technical longevity

on their project locks.

The heavy-duty follower spring, in the locks that are

Class III, are made from sintered spring steel so that

lever handles will not hang.

340 series

Mortice lock DIN 18251 – part 1

Lock functions

349 Sash lock/entrance lock

348 Dead lock

345 Latch

344 Bathroom/wc lock

Specifications

• Steel, grey lacquered case

• Lock dimensions according to DIN 18251 – part 1

• Centres 72 mm (bathroom/wc lock 78 mm)

•Backset 50/60 mm

•Front plate 24x235 mm stainless steel rounded or

square, 20x235 mm stainless steel rounded

24x235 mm brushed brass rounded or square

• Die-cast zinc-plated follower 8 mm

• Easily reversible latch bolt

•Packed per piece, including strike plate and screws

• Key action on latch bolt

• Die-cast nickel-plated latch and dead bolt

Advantages of NEMEF locks

• All locks in a series have the same lock case

dimensions. This means that all doors have the same

mortice cut-out irrespective of which lock function is

installed. Security lock versions are also available

with the same case dimensions.

• The interior parts are zinc-plated and wear-resistant

and therefore guarantee a long life.

• The locks are maintenance free due to thermally

stable lubrication.

• Latch and dead bolt are made of high quality material.

• The clamping follower, in the 1060 and 7000 series, is

bearing mounted and provides much more smoothness

and durability.

DIN Schedule

Main features DIN 18251 – part 1

after the tests the locks must still be operational

class 2 class 3 class 4

Lateral force on latch 3kN 3kN 5kN

Lateral force on dead bolt 4kN 6kN 10kN

Strength bolt detention - 2kN 4kN

Cycle test latch bolt - 200.000 200.000

Cycle test dead bolt - 50.000 50.000

Key action on latch bolt - 200.000 200.000

Lever force - 50Nm 50Nm

4

5


*Opm. Projectsloten E 1.2 14-01-2003 10:53 Pagina 7

Project locks

lock & cylinder technology

1030 series

1060 series

Lock functions

Lock functions

1039 Sash lock/entrance lock

1069 Sash lock / entrance lock

1036 Lever lock (with 1 key mounted on front plate)

1063 Dead lock

1034 Bathroom/wc lock

1065 Latch

1064 Bathroom/wc lock

Finish front plate

• White lacquered, rounded and square, with zinc-

Finish front plate

plated latch and dead bolt

• 18/20/24 x 235 mm: steel, bronze or silver

•Bronze lacquered, rounded and square, with zinc-

lacquered, rounded and square with die-cast

plated latch and dead bolt

zinc-plated latch and dead bolt

•Brass, rounded with nickel-plated latch and

• 20/24 x 235 mm: brushed brass, rounded and

dead bolts

square, with die-cast bright nickel-plated latch

and dead bolts

Specifications

• 20/24 x 235 mm: stainless steel, rounded and

• Steel lacquered lock case

square, with die-cast bright nickel-plated latch

• Lock is according to DIN 18251 part 1 – Class II

and dead bolt

• Centres 72 mm (bathroom/wc lock 78 mm)

• Backset 55 mm

Specifications

•Front plate 20 x 235 mm

• Steel zinc-plated lock case

Mortice Lock DIN 18251 – part 1, Class II

• Die-cast zinc-plated follower 8 mm

Heavy-duty mortice lock DIN 18251 – part 1, Class III

• Backset 50/60/65 mm

•With key action on latch bolt

• Centres 72 mm (bathroom/wc lock 78 mm)

84

• Handed

•2-pieced steel clamping follower 8 mm

20

3

55

•Packed per 25 pieces, without strike plate

•With key action on latch bolt

• Handed

56

Options

•Packed per piece, without strike plate

11,3

10

•Lacquered strike plate

30

= 38 =

8

•Brass strike plate

•Packed per piece

Option

•Blocking of the latch by key action on latch

• Silver lacquered front plate

235

8

50

20

21,5

153

• Plastic latch and dead bolt

30

72

10

6

7


*Opm. Projectsloten E 1.2 14-01-2003 10:53 Pagina 9

Project locks

lock & cylinder technology

7000 series * * * standard

7000 series * * * heavy-duty

Lock functions

Lock functions

700 Sash lock/entrance lock

710 Sash lock/entrance lock

702 Dead lock

712 Dead lock

703 Latch

713 Latch

704 Bathroom/wc lock

714 Bathroom/wc lock

715 Panic lock

Specifications

717 Hotel lock (backset 65 mm only)

•Zinc-plated lock case

718 X-ray lock (backset 40/80 mm only)

• Backset 55/60/65/70/80/100 mm

• Centres 72 mm (bathroom/wc lock 78 mm)

Specifications

• 2-pieced steel clamping follower 8/9 mm

•Zinc-plated lock case

•Plastic bearing when backset 55/60/65 mm is used

• Backset 55/60/65/70/80/100 mm

•Steel bearing when backset 70/80/100 mm is used

• Centres 72 mm (bathroom/wc lock 78 mm)

• Latch die-cast bright nickel-plated

• Latch sintered steel or brass

with noise reduction

• Dead bolt steel or brass

• Dead bolt die-cast brigth nickel-plated

• 2-pieced steel clamping follower 8/9 mm

•Front plate 20/24 x 235 mm rounded or square

• Steel bearing

•Finish of front plate: steel bronze lacquered,

• Latch bolt with noise reduction

stainless steel or polished brass

•Front plate stamped with ***

Extra heavy-duty mortice lock DIN 18251 - part 1, Class III

•Front plate stamped with ***

Extra heavy-duty mortice lock DIN 18251 - part 1, Class III

• Key action on latch bolt

•Packed per piece, without strike plate

• Handed

•Packed per piece, without strike plate

Options

•Front plate 20/24 x 235 mm: stainless steel or

• Steel bearing

polished brass lacquered, rounded or square

• Anti-friction latch bolt (finish depends on

front plate)

Only available with a minimum one of the

options listed below:

•Front plate silver lacquered

- Sintered steel nickel-plated anti-friction latch bolt

• Roller bolt lock

(for stainless steel finish)

- Brass polished anti-friction lach bolt

(for brass finish)

- Brass nickel-plated auxiliary latch (for ss finish)

- Brass polished auxiliary latch (for brass finish)

- Sintersteel nickel-plated anti-friction latch bolt and

brass nickel-plated auxiliary latch (for ss finish)

- Brass polished anti-friction latch bolt and auxiliary

latch (for brass finish)

- Latch blocking mechanism

8

9


*Opm. Projectsloten E 1.2 14-01-2003 10:54 Pagina 11

Project locks

lock & cylinder technology

7000 series * * * * standard

6600 series

Extra heavy-duty mortice lock DIN 18251 - part 1, Class IV

Lock functions

740 Sash lock / entrance lock

742 Dead lock

743 Latch

744 Bathroom/wc lock

746 Roller bolt lock

745 Panic lock

747 Hotel lock (backset 65 mm only)

748 X-ray lock (backset 40/80 mm only)

Specifications

• Zinc plated white lacquered lock case

• Backset 55/60/65/70/80/100 mm

• Centres 72 mm (bathroom/wc lock 78 mm)

• 2-pieced steel clamping follower 8/9 mm

• Steel bearing

•6 bushings per lock (except the x-ray lock)

• Latch with noise reduction

•Front plate

- Finishes brass polished lacquered in combination

with brass polished latch and/or dead bolt

- Stainless steel grinded in combination with steel

bright nickel-plated latch and/or dead bolt

•Key action on latch bolt

• Handed

•Packed per piece, without strike plate

Dimensions according to DIN 18251 – part 1 (Class III)

heavy-duty project lock non-handed

Lock functions

6602 Sash lock/entrance lock

6622 Dead lock

6632 Latch

6642 Bathroom/wc lock

Specifications

•Zinc-plated lock case

• Backset 60 mm

• Centres 72 mm (bathroom/wc lock 78 mm)

• Die-cast nickel plated bolts

• Steel clamping follower 8 mm

•Front plate 20/24 x 235 mm rounded or square,

lacquered or stainless steeel

• Key action on latch bolt

• Easily reversible latch bolt

•Packed per piece, including strike plate and screws

Options

• Hold back function on the latch

•For stainless steel finish

- Sinter steel nickel-plated anti-friction latch

- Brass nickel-plated auxiliary latch

- Sintersteel nickel-plated anti-friction latch and

brass nickel-plated auxiliary latch

•For brass finish

- Brass polished anti-friction latch

- Brass polished auxiliary latch

- Brass polished anti-friction latch and auxiliary latch

10

11


9

*Opm. Projectsloten E 1.2 14-01-2003 10:55 Pagina 13

Project locks

lock & cylinder technology

6100 series

Suitable strike plates

Lock functions

6109 Sash lock / entrance lock

6108 Dead bolt lock

40

340 series 1030 series

24

26

17

20

40

24

17

6105 Latch

6107 Night latch

6106 Night latch with hold back function

6104 Bathroom/wc lock

6102 Panic lock (in development)

Specifications

•Zinc-plated white lacquered lock case

170

9 76 76

46 37,5 36

15

4,5

12 5

5,75 (3x)

7 x90 (6x)

54

170

50 33 47

13

11

54

•Backset 60 mm

P344/349 (square and rounded)

P1036 (square and rounded)

•Centres 72 mm (bathroom/wc lock 78 mm)

•Sintersteel latch and dead bolt

40

24

•Forend 20 x 235 mm, square stainless steel

26

17

•2-pieced steel clamping follower 8 mm

•Extra heavy-duty counter spring

36

54

•Suitable for oval as well as euro profile cylinder

•Key action on latch bolt

170

15

Dimensions according to DIN 18251 – part 1 (Class III)

•Certified for 4 hours fire-resistant according to

extra heavy-duty project lock non-handed

BS 476 part 22, 1997, clause 8

20

3

60

88

•Easily reversible latch bolt

•Packed per piece, including strike plate, screws and

mounting instructions

P345 (square and rounded)

HP1036 (square and rounded)

12,4

53,2

11

24

31,7

= 38 =

8

235

9

50

34,8

21

10

= 36 =

21,5

71,1

165

11

= 50 =

90

4,9

6

P348 (square and rounded)

SK1036 (square and

rounded)

combination HP und SK

12

13


*Opm. Projectsloten E 1.2 14-01-2003 10:56 Pagina 15

Project locks

lock & cylinder technology

Suitable strike plates

Suitable strike plates

1060/7000 series 1060/7000 series

40

6600 series 24

6100 series

29

46,5

20

20

8

25

17

41,5

32

8

170

20

50 33 47

40

24

13

11

17

54

170

20

50

50 30

13

11

170

47 20

5,6

40

24

13

80 17

170

20

50

13

170

42 43,5 38

5,5

13

6 12 6

54

196

38

43,5

42

13

12

57

P6602 (square and rounded)

P6109 (square)

P7000 (square and

rounded)

HP7000 (square and

rounded)

P7003 for auxiliary latch

(square and rounded)

HP7003 (square and

rounded)

24

29

46,5

40

20

8

24

24

20

17

24

30

90

20

50

4,9 8,1

11

170

20 50

11

170

50 33 47

13

11

80

90

42

6 12 6

98

38

8 13

P7002 (square and

rounded)

24

40

HP7002 (square and

rounded)

1060 series

P7200 (square and rounded)

47

20

40

24

5,6 13

54 17

P6622 (square and rounded)

5,6

24

40

0

10

19

28

P6105 (square)

29

12

33,8

13

170

47

13

109,5

103

28

47

19

65

42

R

8

(2x)

84

93

103

5,25 (2x)

P7003 (square and rounded)

P1065 (square and rounded)

P6632 (square and rounded)

P6108 (square)

14

15

More magazines by this user
Similar magazines
