POWER FLANGE

TERMINATION

PERFORMANCE SPECIFICATIONS:

Part Number:

RPT300-10

.100 (2.54)

.200 (5.08)

.300 (7.62)

.200 (5.08)

.100 (2.54)

.116 dia.

(2.94)

.160 (4.06)

max.

.062 (1.57)

Frequency: DC-4.0GHz

VSWR (Max): 1.10:1 DC to 1.5 GHz

1.35:1 1.5 to 4.0 GHz

.040 (1.02)

.030

(.76)

.125 (3.18)

min.

.003 (.076)

.110 (2.79)

10 Watts (1KW Peak)


.100 (2.54)

.200 (5.08)

.300 (7.62)

.200 (5.08)

.100 (2.54)

.116 dia.

(2.94)

.160 (4.06)

max.

.062 (1.57)

Part Number: RPT301-10



1.35:1 1.5 to 4.0 GHz

.040 (1.02)

.030

(.76)

.125 (3.18)

min.

.003 (.076)

.110 (2.79)



.200 (5.08)

.500 (12.70)

.300

(7.62)

.100 (2.54)

.100 (2.54)

.160 (4.06)

max.

.062 (1.57)




1.35:1 1.5 to 4.0 GHz

.125 (3.18)

min.

.040 (1.02)

.116 dia.

(2.94)

.003 (.076)

.110 (2.79)


Toll Free: 800.526.0704

Phone: 727.530.9555

RES-NET MICROWAVE

P.O. Box 18802 • Clearwater, FL 33762

1A

ELECTRO TECHNIK

POWER FLANGE

TERMINATION


.250 (6.35)

.062 (1.57)

.092 (2.34)

.250 (6.35)

.250 (6.35)

min.

.065 (1.65)

.003 (0.076)


Part Number: RPS100T



6 - 32

NC-2A THD.

.375 (9.52)


.032 wide x .035 deep slot

(.081) (.088)


.095 (2.41)

.060 (1.52)

.250

min. (6.35)

.125 (3.18)

.125 (3.18)

.105 (2.67)

±.01

.003 (.076)




1.15:1 1.0 to 2.0 GHz

.250

(6.35)

1.20:1 2.0 to 4.0 GHz

.515 (13.08)

.116 dia.

(2.94)

.250 (6.35)

.062 (1.57)

.180 (4.57)

max.


.250 (6.35)

.125 (3.18)

.116 dia.

(2.94)

.160 (4.06)

max.

.062 (1.57)





.515 (13.08)

1.15:1 1.0 to 2.0 GHz

.250 (6.35)

1.20:1 2.0 to 4.0 GHz

.250 (6.35)

min.

.003 (.076)

.060 (1.52)

.105 (2.67)





2A

www.electrotechnik.com


POWER FLANGE

TERMINATION

.515 (13.08)

.116 dia.

(2.94)

.250

min. (6.35)

.060 (1.52)

.095 (2.41)

.125 (3.18)

.125 (3.18)

.250

(6.35)

.250 (6.35)

.160 (4.06)

max.

.062 (1.57)

.003 (.076)

.105 (2.67)





1.15:1 1.0 to 2.0 GHz

1.20:1 2.0 to 4.0 GHz



.095 (2.41)

.060 (1.52)

.250

min. (6.35)

.125 (3.18)

.125 (3.18)

.105 (2.67)

max.

.003 (.076)




1.15:1 1.0 to 2.0 GHz

.250

(6.35)

1.20:1 2.0 to 4.0 GHz

.515 (13.08)

.116 dia.

(2.94)

.250 (6.35)

.062 (1.57)

.180 (4.57)

max.


.250 (6.35)

.515 (13.08)

.125 (3.18) .095 (2.41)

.250

(6.35)

.116 dia.

(2.94)

.060 (1.52)

.250 (6.35)

min.

.003 (.076) .130 (3.30)

.160 (4.06) max.





1.15:1 1.0 to 2.0 GHz

1.20:1 2.0 to 4.0 GHz


.062 (1.57)

Toll Free: 800.526.0704

Phone: 727.530.9555



3A

ELECTRO TECHNIK

POWER FLANGE

TERMINATION


.116 dia.

(2.94)

.515 (13.08)

.125 (3.18)

.125 (3.18)

.250(6.35)

.180 (4.75)

max.

.062 (1.57)





1.20:1 2.0 to 4.0 GHz

.250

min. (6.35) .060 (1.52)

.250 (6.35)

.003 (.076)

.130 (3.30)

.095 (2.41)



Part Number:

RPT800-40

.230

.800 (20.32)

.560 (14.22)

.350

(8.89)

min. (5.84) .040 (1.02)

.160 (4.06)

max.

.062 (1.57)

.115 (2.92)

.115 (2.92)



1.25:1 2.0 to 4.0 GHz

.130 dia.

(3.30)

.200 (5.08) min.

.003 (.076)

.125 (3.18)


.230

.800 (20.32) .160 (4.06)

.560 (14.22)

max.

.350

.115 (2.92) .062 (1.57)

(8.89)

.115 (2.92)





1.30:1 2.0 to 4.0 GHz

min. (5.84) .040 (1.02)

.130 dia.

(3.30)

.200 (5.08) min.

.003 (.076)

.125 (3.18)

50 Watts (600W Peak)




4A



POWER FLANGE

TERMINATION


.230 (5.84)

.975 (24.77)

.725 (18.42)

.350

(8.89)

.115 (2.92)

.180 (4.57)

max.

.087 (2.21)




1.25:1 2.0 to 4.0 GHz

.125 dia.

(3.18)

.125 (3.18) min.

.003 (.076)

.060 (1.52) .150 (3.81)



.230

.800 (20.32)

.560 (14.22)

.350

(8.89)

.160 (4.06)

max.

.062 (1.57)

.115 (2.92)

.115 (2.92)




1.25:1 2.0 to 4.0 GHz

min. (5.84) .040 (1.02)

.130 dia.

(3.30)

.200 (5.08) min.

.003 (.076)

.125 (3.18)



.820 (20.82)

.600 (15.24)

.235 (5.96)

max.

.062 (1.57)

Part Number:

Frequency:

RPT820-75

DC-1.5GHz

.127 (3.22)


.380 (9.65)

.127 (3.22)

.255

(6.47)

1.40:1 1.0 to 1.5 GHz

.156 dia.

(3.96)

.125 (3.18)

.250 (6.35)

.003

(.076)

.200

(5.08)


Toll Free: 800.526.0704

Phone: 727.530.9555



5A

ELECTRO TECHNIK

POWER FLANGE

TERMINATION


.375 (9.52)

.161 dia.

(4.08)

.870 (22.10)

.560

(14.22)

.370

(9.40)

.187(4.76)

.125 (3.17) min.

.120 (3.05)

.160 (4.06)

max.

.062 (1.57)

.003 (.076)

.108 (2.74)





1.35:1 1.0 to 1.5 GHz



.375 (9.52)

.870 (22.10)

.560

(14.22)

.370

(9.40)

.187 (4.75)

.160 (4.06)

max.

.062 (1.57)




1.35:1 1.0 to 1.5 GHz

.161 dia.

(4.08)

.125 (3.17) min.

.120 (3.05)

.003 (.076)

.108 (2.74)

100 Watts (1.2KW Peak)




6A



POWER FLANGE

TERMINATION

.230

.800 (20.32)

.560 (14.22)

.350

(8.89)

.160 (4.06)

max.

.062 (1.57)

.115 (2.92)

.115 (2.92)





min. (5.84) .120 (3.05)

.130 dia.

(3.30)

.200 (5.08) min.

.003 (.076)

.125 (3.18)



.375 (9.52)

.870 (22.10)

.560

(14.22)

.370

(9.40)

.187 (4.75)

.160 (4.06)

max.

.062 (1.57)




1.35:1 1.0 to 1.5 GHz

.161 dia.

(4.08)

.125 (3.18) min.

.120 (3.05)

.003 (.076)

.108 (2.74)



.975 (24.77)

.725 (18.42)

.375

(9.52)

.220 (5.59)

max.

.110 (2.79)


Frequency: DC to 3.0 GHz


.375 (9.52)

.187 (4.75)

1.30:1 DC to 3.0 GHz

.125 dia.

(3.18)

.125 (3.18) min.

.003 (.076)

.120 (3.05) .171 (4.34)


Toll Free: 800.526.0704

Phone: 727.530.9555



7A

ELECTRO TECHNIK

POWER FLANGE

TERMINATION



.975 (24.77)

.725 (18.42)

.375 (9.52)

.220 (5.59)

max.

.110 (2.79)




.375 (9.52)

.187 (4.75)

.125 dia.

(3.18)

.125 (3.18) min.

.003 (.076)

.120 (3.05) .171 (4.34)



.500

(12.70)

1.100 (27.94)

.800 (20.32)

.500

(12.70)

.250 (6.35)

max.

.125 (3.18)



VSWR (Max): 1.25:1 DC to 500 MHz

1.35:1 500 to 1 GHz

.170 dia.

(4.31)

.125 (3.18) min.

.250 (6.35)

.003 (.076)

.170 (4.31)


1.900 (48.26)

1.550 (39.37)

.750 (19.05)

.250 (6.35)

max.

.125 (3.18)



Frequency: DC-500MHz

VSWR (Max): 1.25:1 DC to 200 MHz

1.040

(26.42)

.500

(12.70)

1.50:1 200 to 500 MHz

.270

(6.86)

.170 dia.

(4.31)

.125 (3.18) min.

.250 (6.35)

.003 (.076)

.190 (4.83)





8A



POWER FLANGE

RESISTORS

.030

(.76)

.040 (1.02)

.100 (2.54)

.160 (4.06)

max.

.062 (1.57)


Part Number: RPR300-10


.200 (5.08)

.125 (3.18)

min.

.116 dia.

(2.94)

.200 (5.08)

.300 (7.62)

.003 (.076)

.110 (2.79)


.030

(.76)

.500 (12.70)

.040 (1.02)

.160 (4.06)

max.




.125 (3.17)

min.

.062 (1.57)

.200 (5.08)

.100 (2.54)

.300

(7.62)

.116 dia.

(2.94)

.003 (.076)

.110 (2.79)


Toll Free: 800.526.0704

Phone: 727.530.9555



9A

ELECTRO TECHNIK

POWER FLANGE



.250

(6.35)

.092 (2.34)

.015 (0.38)

.062 (1.57)

.250 (6.35)

.250 (6.35)

min.

.060 (1.52)

.003 (0.76)


Part Number: RPS100R


6 - 32

NC-2A THD.

.375 (9.52)

.032 wide x .035 deep slot

(.081) (.088)


.095 (2.41)

.060 (1.52)

.250

min. (6.35)

.125 (3.18)

.125 (3.18)

.105 (2.67)

max.

.003 (.076)




.250

(6.35)

.515 (13.08)

.116 dia.

(2.94)

.250 (6.35)

.062 (1.57)

.160 (4.06)





10A



POWER FLANGE


.800 (20.32)

.560 (14.22)

.115 (2.92)

.160 (4.06)

max.

.062 (1.57)




.230

.115 (2.92)

min. (5.84) .040 (1.02)

.130 dia.

(3.30)

.200 (5.08) min.

.003 (.076)

.108 (2.74)



.800 (20.32)

.560 (14.22)

.115 (2.92)

.160 (4.06)

max.

.062 (1.57)

Part Number:

Frequency:

RPR800-40

DC-4.0GHz

.230

.115 (2.92)

min. (5.84) .040 (1.02)

.130 dia.

(3.30)

.200 (5.08) min.

.003 (.076)

.108 (2.74)


Toll Free: 800.526.0704

Phone: 727.530.9555



11A

ELECTRO TECHNIK

POWER FLANGE



.800 (20.32)

.560 (14.22)

.115 (2.92)

.160 (4.06)

max.

.062 (1.57)




.230 (5.84)

.115 (2.92)

.130 dia.

(3.30)

.200 (5.08) max.

.040 (1.02)

.003 (.076)

.108 (2.74)


.800 (20.32)

.560 (14.22)

.115 (2.92)

.160 (4.06)

max.

.062 (1.57)




.230 (5.84)

.115 (2.92)

.130 dia.

(3.30)

.200 (5.08) max.

.040 (1.02)

.003 (.076)

.108 (2.78)





12A



POWER FLANGE


.820 (20.82)

.600 (15.24)

.235 (5.96)

max.

.062 (1.58)

.127 (3.23)




.380 (9.65)

.127 (3.23)

.255

(6.47)

.156 dia.

(3.92)

.125 (3.18) min.

.250 (6.35)

.003

(.076)

.200

(5.08)


.870 (22.10)

.560

(14.22)

.160 (4.06)

max.

.062 (1.52)




.375 (9.52)

.187(4.75)

.161 dia.

(4.08)

.125 (3.18) max.

.120 (3.05)

.003 (.076)

.108 (2.74)


Toll Free: 800.526.0704

Phone: 727.530.9555



13A

ELECTRO TECHNIK

POWER FLANGE



.800 (20.32)

.560 (14.22)

.160 (4.06)

max.

.062 (1.57)

.115 (2.92)




.230

.115 (2.92)

min. (5.84) .04 (1.02)

.130 dia.

(3.30)

.200 (5.08) min.

.003 (.076)

.108 (2.74)


.870 (22.10)

.560

(14.22)

.160 (4.06)

max.

.062 (1.57)




.375 (9.52)

.187 (4.75)

.161 dia.

(4.08)

.125 (3.17) min.

.120 (3.05)

.003 (.076)

.108 (2.74)





14A



POWER FLANGE


.870 (22.10)

.560

(14.22)

.160 (4.06)

max.

.062 (1.57)




.375 (9.52)

.187 (4.75)

.161 dia.

(4.08)

.125 (3.17) min.

.120 (3.05)

.003 (.076)

.108 (2.74)


.975 (24.77)

.725 (18.42)

.375 (9.52)

.220 (5.59)

max.

.110 (2.79)




.375 (9.52)

.187 (4.75)

.125 dia.

(3.17)

.125 (3.17) min.

.003 (.076)

.120 (3.05) .171 (4.34)


.975 (24.77)

.725 (18.42)

.375(9.52)

.220 (5.59)

max.

.110 (2.79)




.375 (9.52)

.187 (4.75)

.125 dia.

(3.17)

.125 (3.17) min.

.003 (.076)

.120 (3.05) .171 (4.34)


Toll Free: 800.526.0704

Phone: 727.530.9555



15A

ELECTRO TECHNIK

POWER FLANGE



1.100 (27.94)

.800 (20.32)

.250 (6.35)

max.

.125 (3.18)



Frequency: DC-.75GHz

.500

(12.70)

.250

(6.35)

.170 dia.

(4.31)

.125 (3.18) min.

.250 (6.35)

.003 (.076)

.170 (4.31)


1.900 (48.26)

1.550 (39.37)

.250 (6.35)

max.

.125 (3.18)



Frequency: DC- .50GHz

1.040

(26.42)

.500

(12.70)

.270

(6.86)

.170 dia.

(4.31)

.125 (3.18) min.

.003 (.076)

.250 (6.35)

.190 (4.83)





16A


COAXIAL TERMINATIONS

SMA TYPE CONNECTORS


SMA CONNECTORS:

PART FREQUENCY VSWR

NUMBER RANGE (max.)

RCX1SM DC to 12 GHz 1.25:1

.375 (9.52)

max.



RCX4SMG DC to 20 GHz 1.15:1

R-N

.312 (7.92)



RCX7SM DC to 26.5 GHz 1.35:1

For gold plated housing and nut add G after part number.

MALE TYPE

1 WATT (1 Kw peak)




.375 (9.52)

max.

RCX1SM2 DC to 12 GHz 1.25:1



R-N .312 (7.92)

RCX4SM2G DC to 20 GHz 1.15:1




MALE TYPE

2 WATTS (1 Kw peak)




.500 (12.70)

max.

RCX1SM2B DC to 12 GHz 1.25:1



.312 (7.92)

ref.

RCX4SM2BG DC to 20 GHz 1.15:1



RCX7SMB DC to 26.5 GHz 1.35:1


MALE TYPE 2 WATTS BALL & CHAIN

(1 Kw peak)




1B




BNC, TNC & "N" TYPE CONNECTORS

BNC CONNECTORS AVAILABLE WITH BALL & CHAIN:

PART CONNECTOR FREQUENCY VSWR

NUMBER TYPE RANGE (max.)

RCX6BM MALE DC to 2 GHz 1.10:1

1.70

(43.18)

RCX6BF FEMALE

RCX7BM MALE DC to 4 GHz 1.20:1

RCX7BF FEMALE

.565

(14.35)

.745

(18.92)

2 WATTS (1KW peak)

TNC CONNECTORS AVAILABLE WITH BALL & CHAIN:



1.70

(43.18)

RCX5TM MALE DC to 8 GHz 1.25:1

RCX5TF FEMALE

RCX6TM MALE DC to 4 GHz 1.15:1

.565

(14.35)

.745

(18.92)

RCX6TF

FEMALE


"N" TYPE CONNECTORS AVAILABLE WITH BALL & CHAIN:



RCX1NM MALE DC to 12 GHz 1.25:1

RCX1NF FEMALE


RCX3NF FEMALE


RCX5NF FEMALE


RCX6NF FEMALE

1.50 (38.10)

max.


.80 (20.32)

ref.

Toll Free: 800.526.0704

Phone: 727.530.9555



2B

ELECTRO TECHNIK

SMA COAXIAL

TERMINATIONS



PART CONNECTOR VSWR

NUMBER TYPE (max.)

RCX-SF5A SMA FEMALE DC to 4 GHz - 1.15:1

4 to 8 GHz - 1.25:1

RCX-SM5A SMA MALE 8 to 12 GHz - 1.30:1

.400

(10.16)

.515

(13.08)

.375

(9.52)

male

female

.500

(12.70)

typ.

RCX-SF5B SMA FEMALE DC to 8 GHz - 1.20:1

8 to 12 GHz - 1.25:1

RCX-SM5B SMA MALE 12 to 18 GHz - 1.30:1

RCX-SF5C SMA FEMALE DC to 8 GHz - 1.20:1

RCX-SM5C SMA MALE DC to 8 GHz - 1.20:1

RCX-SF5D SMA FEMALE DC to 4 GHz - 1.15:1

RCX-SM5D SMA MALE DC to 4 GHz - 1.15:1

.915 (23.24)

male

.775 (19.69)

female

SMA





RFT15SFA SMA FEMALE DC to 4 GHz - 1.15:1

4 to 8 GHz - 1.25:1

RFT15SMA SMA MALE 8 to 12 GHz - 1.30:1

2.10 (53.34)

male

2.00 (50.80)

female

RFT15SFB SMA FEMALE DC to 8 GHz - 1.20:1

8 to 12 GHz - 1.25:1

RFT15SMB SMA MALE 12 to 18 GHz - 1.30:1

RFT15SFC SMA FEMALE DC to 8 GHz - 1.20:1

1.33 (33.78)

dia.

RFT15SMC SMA MALE DC to 8 GHz - 1.20:1

RFT15SFD SMA FEMALE DC to 4 GHz - 1.15:1

RFT15SMD SMA MALE DC to 4 GHz - 1.15:1

.515 (13.08)

male

3.75 (9.52)

female





3B



SMA COAXIAL

TERMINATIONS




RFT25SFA SMA FEMALE DC to 4 GHz - 1.15:1

4 to 8 GHz - 1.25:1

RFT25SMA SMA MALE 8 to 12 GHz - 1.30:1

RFT25SFB SMA FEMALE DC to 8 GHz - 1.20:1

8 to 12 GHz - 1.25:1

RFT25SMB SMA MALE 12 to 18 GHz - 1.30:1





2.10 (53.34)

male

2.00 (50.80)

female

.515 (13.08)

male

3.75 (9.52)

female

1.33 (33.78)

dia.


1.63 (41.28)

dia.








RFT50SFE SMA FEMALE DC to 2 GHz - 1.10:1

RFT50SME SMA MALE DC to 2 GHz - 1.10:1

4.75 (120.65)

male

4.60 (116.84)

female

4.15 (105.41)


Toll Free: 800.526.0704

Phone: 727.530.9555



4B

ELECTRO TECHNIK

SMA COAXIAL

TERMINATIONS


.515 (13.08)

male

.375 (9.52)

female






RFT100SFE SMA FEMALE DC to 2 GHz - 1.10:1

RFT100SME SMA MALE DC to 2 GHz - 1.10:1


6.25

(158.75)

6.77 (171.93)

male

6.33 (168.40)

female

2.75 (69.85)

square




5B



TNC COAXIAL

TERMINATIONS




TNC

Connector

2.38 (60.45)

male

2.20 (55.88)

female

RFT10TFC TNC FEMALE DC to 8 GHz - 1.20:1

RFT10TMC TNC MALE DC to 8 GHz - 1.20:1

1.33 (33.78)

dia.

RFT10TFD TNC FEMALE DC to 4 GHz - 1.15:1

RFT10TMD TNC MALE DC to 4 GHz - 1.15:1

.900 (22.86)

male

.710 (18.03)

female






TNC

Connector

2.38 (60.45)

male

2.20 (55.88)

female



1.33 (33.78)

dia.


.900 (22.86)

male

.710 (18.03)

female


Toll Free: 800.526.0704

Phone: 727.530.9555



6B

ELECTRO TECHNIK

TNC COAXIAL

TERMINATIONS


2.38 (60.45)

male




2.20 (55.86)

female




1.33 (33.78)

dia.


.900 (22.86)

male


7.10 (18.03)

female

1.63 (41.28)

dia.




RFT50TFC FEMALE DC to 8 GHz - 1.20:1




5.05 (128.27)

male

4.86 (123.44)

female

4.15 (105.41)





7B



TNC COAXIAL

TERMINATIONS

.90 (22.86)

male

.71 (18.03)

female






RFT100TFE TNC FEMALE DC to 2 GHz - 1.10:1

RFT100TME TNC MALE DC to 2 GHz - 1.10:1

RFT100TFF TNC FEMALE DC to 1 GHz - 1.20:1

RFT100TMF TNC MALE DC to 1 GHz - 1.20:1

6.25

(158.75)

7.15 (181.61)

male

6.92 (175.77)

female


C L

2.75 (69.85)

square

Toll Free: 800.526.0704

Phone: 727.530.9555



8B

ELECTRO TECHNIK

BNC COAXIAL

TERMINATIONS





BNC

Connector

2.28 (57.91)

male

2.11 (53.59)

female

RFT10BFD BNC FEMALE DC to 4 GHz - 1.15:1

RFT10BMD BNC MALE DC to 4 GHz - 1.15:1

RFT10BFE BNC FEMALE DC to 2 GHz - 1.10:1

1.33 (33.78)

dia.

RFT10BME BNC MALE DC to 2 GHz - 1.10:1


.80 (20.32)

male

.63 (16.00)

female




BNC

Connector

2.28 (57.91)

male

2.11 (53.59)

female




1.33 (33.78)

dia.



.80 (20.32)

male

.63 (16.00)

female




9B



BNC COAXIAL

TERMINATIONS








RFT25BFF BNC FEMALE DC to 1 GHz - 1.10:1

RFT25BMF BNC MALE DC to 1 GHz - 1.10:1


BNC

Connector

2.28 (57.91)

male

2.11 (53.59)

female

.80 (20.32)

male

.63 (16.00)

female

1.33 (33.78)

dia.

1.63 (41.40)

dia.

BNC

Connector








4.95 (125.73)

male

4.78 (121.41)

female

4.15 (105.41)


Toll Free: 800.526.0704

Phone: 727.530.9555



10B

ELECTRO TECHNIK

BNC COAXIAL

TERMINATIONS


.80 (20.32)

male

.63 (16.00)

female

BNC

Connector








6.25

(158.75)

7.05 (179.07)

male

6.88 (174.75)

female


2.75 (69.85)

square




11B



"N" TYPE COAXIAL

TERMINATIONS




RFT10NFA "N" FEMALE DC to 4 GHz - 1.15:1

4 to 8 GHz - 1.25:1

RFT10NMA "N" MALE 8 to 12 GHz - 1.30:1

RFT10NFC "N" FEMALE DC to 8 GHz - 1.20:1

N

Connector

2.38 (60.45)

male

2.22 (56.38)

female

RFT10NMC "N" MALE DC to 8 GHz - 1.20:1

RFT10NFD "N" FEMALE DC to 4 GHz - 1.15:1

1.33 (33.78)

dia.

RFT10NMD "N" MALE DC to 4 GHz - 1.15:1

RFT10NFE "N" FEMALE DC to 2 GHz - 1.10:1

RFT10NME "N" MALE DC to 2 GHz - 1.10:1

.80 (20.32)

male

.74 (18.00)

female






4 to 8 GHz - 1.25:1



N

Connector

2.38 (60.45)

male

2.22 (56.39)

female



1.33 (33.78)

dia.




.80 (20.32)

male

.74 (18.00)

female


Toll Free: 800.526.0704

Phone: 727.530.9555



12B

ELECTRO TECHNIK

"N" TYPE COAXIAL

TERMINATIONS






4 to 8 GHz - 1.25:1



N

Connector

2.38 (60.45)

male

2.22 (56.39

female



1.33 (33.78)

dia.





.80 (20.32)

male

.74 (18.00)

female

1.63 (41.40)

dia.

N

Connector










4.95 (125.73)

male

4.89 (124.20)

female

4.15 (105.41)





13B



"N" TYPE


.80 (20.32)

male

.63 (16.00)

female

N

Connector








6.25

(158.75)

7.05 (179.07)

male

6.88 (174.75)

female


2.75 (69.85)

square

Toll Free: 800.526.0704

Phone: 727.530.9555



14B

ELECTRO TECHNIK


HIGH POWER



SMA CONNECTORS

PART CONNECTOR "X" VSWR


RCX-SF15A FEMALE .375 DC to 4 GHz - 1.15:1

4 to 8 GHz - 1.25:1

RCX-SM15A MALE .510 8 to 12 GHz - 1.30:1

.480 (12.19)

.240 (6.10)

X

.500 (12.70)

RCX-SF15B FEMALE .375 DC to 8 GHz - 1.25:1

8 to 12 GHz - 1.30:1

RCX-SM15B MALE .510 12 to 18 GHz - 1.35:1

1.00 (25.40)

.614 (15.60)

RCX-SF15C FEMALE .375

RCX-SM15C MALE .510

RCX-SF15D FEMALE .375

RCX-SM15D MALE .510

DC to 8 GHz - 1.25:1

DC to 4 GHz - 1.15:1

.193 (4.90)

.214 dia. (5.44)





.480 (12.19)

.240 (6.10)

X

.500 (12.70)



1.00 (25.40)

.614 (15.60)



.193 (4.90)

.214 dia. (5.44)






4 to 8 GHz - 1.25:1



8 to 12 GHz - 1.30:1


.600 (15.24)

.300 (7.62)

1.20

(30.48)

1.50

(38.10)

X

.500

(12.70)

.125

(3.18)

RCX-SF30C FEMALE .375

RCX-SM30C MALE .510

RCX-SF30D FEMALE .375

RCX-SM30D MALE .510

DC to 8 GHz - 1.30:1

DC to 4 GHz - 1.20:1

.150 (3.81) .166 dia.

(4.21)


.425

(10.80)

Toll Free: 800.526.0704

Phone: 727.530.9555



1C

ELECTRO TECHNIK

HIGH POWER



SMA CONNECTORS


.110 dia. (2.80)

PART POWER FREQUENCY VSWR

NUMBER (watts) RANGE (max.)

.90

(22.86)

RCX51SF DC to 2 GHz 1.15:1

50

RCX51SM 2 to 4 GHz 1.25:1

RCX52SF

RCX52SM

50 DC to 2 GHz 1.15:1

.387

(9.83)

.430

(10.92)

max.

.750 (19.05)

.500 (12.70)

.250

(6.35)

.115 (2.92)

.520 (13.21)





RCX50SF

50


1 to 2 GHz 1.15:1

RCX100SF 2 to 3 GHz 1.30:1

100

RCX100SM

.560

(14.22)

.630

(16.00)

max.

.090

(2.28)

.250

(6.35)

1.375

(34.92)

1.125

(28.57)

.960 (24.38)

.625

(15.88)

50 & 100 WATTS (5KW peak)

.125

(3.18)

.125 (3.18) .120 dia.

(3.05)

1.625 (41.28)





150 1 to 2 GHz 1.15:1

RCX150SM 2 to 3 GHz 1.30:1

.180

(4.57)

2.00

(50.80)

1.62

(41.14)

.875

(22.23)

.375

(9.53)


250 1 to 2 GHz 1.15:1

RCX250SM 2 to 3 GHz 1.30:1




2C

.250 (6.35)

.187 (4.75)

.562 (14.27)

.625 (15.87) max.

.215 dia.

(5.46)

150, 250 WATTS (5KW peak)



HIGH POWER


TNC CONNECTORS



RCX50TF

RCX50TM

RCX100TF

RCX100TM


50 DC to 3 GHz 1.25:1

100 DC to 3 GHz 1.25:1

.180

(4.57)

1.375

(34.92)

.375 (9.53)

.940 (23.87)

max.

1.125

(28.57)

.960 (24.38)

.625

(15.88)

.125

(3.18)

.120 dia.

(3.05)

.125

(3.18)

.845

(21.46)

male

.750

(19.05)

female

50 & 100 WATTS (5KW peak)




RCX150TF DC to 1 GHz 1.10:1

150 1 to 2 GHz 1.15:1

RCX150TM 2 to 3 GHz 1.30:1

RCX250TF DC to 1 GHz 1.10:1

250 1 to 2 GHz 1.15:1

RCX250TM 2 to 3 GHz 1.30:1

.180

(4.57)

2.00

(50.80)

.375 (9.53)

.812 (20.62)

1.62

(41.14)

1.625 (41.28)

.875

(22.23)

.215 dia.

(5.46)


.375

(9.53)

.845

(21.46)

male

.750

(19.05)

female

Toll Free: 800.526.0704

Phone: 727.530.9555



3C

ELECTRO TECHNIK

HIGH POWER



"N" CONNECTORS



RCX101NF

RCX101NM


100 DC to 2.4 GHz 1.25:1

1.06

(26.92)

1.13

(28.70)

.825

(20.95)

.152

(3.86)

1.13

(28.70)

6-32

.820

(20.83)

male

.740

(18.80)

female





RCX150NF DC to 1 GHz 1.10:1

150 1 to 2 GHz 1.15:1

RCX150NM 2 to 3 GHz 1.30:1


250 1 to 2 GHz 1.15:1

RCX250NM 2 to 3 GHz 1.30:1


500 1 to 2 GHz 1.15:1

RCX500NM 2 to 3 GHz 1.30:1

.180

(4.57)

2.00

(50.80)

.500 (12.70)

1.06 (26.92)

1.63

(41.40)

.187

(4.75)

1.63

(41.40)

.875

(22.23)

.215 dia.

(5.46)


.375 (9.52)

.820

(20.82)

male

.740

(18.80)

female




4C


STRIPLINE

FLANGE TERMINATIONS





.375

(9.53)

.250

(6.35)

.076 dia.

(1.93)

.050 (1.27)

DC to 4 GHz 1.15:1

RFT375-3 4 to 8 GHz 1.20:1

8 to 18 GHz 1.35:1

.250

(6.35)

.005

(0.13)

.250 dia.

(6.35)

1 WATTS

.50

(1.27)

.160

(4.06)

max.




.375

(9.53)

.250

(6.35)

.076 dia.

(1.93)

SMA pin

.050 (1.27)

RFT375-4 DC to 4 GHz 1.10:1

RFT375-5 DC to 8 GHz 1.20:1

RFT375-6 DC to 18 GHz 1.35:1

.250

(6.35)

.036

(.91)

.250 dia.

(6.35)

3 WATTS

.100

(2.54)

.160

(4.06)

max.




1D



STRIPLINE



PART FREQUENCY VSWR (max.)

NUMBER RANGE (GHz) DC-2 2-4 4-8 8-12 12-18

RFT502-10 DC to 2 1.10

.500

(12.70)

.340

(8.64)

.126 dia.

(3.20)

.175 (4.45)

max.

RFT504-10 DC to 4 1.10 1.10

RFT508-10 DC to 8 1.10 1.10 1.20

RFT512-10 DC to 12 1.10 1.10 1.20 1.30

RFT518-10 DC to 18 1.10 1.10 1.20 1.30 1.35

.250 (6.35)

.005

(.127)

.275 dia.

(6.99)

10 WATTS

.050

(1.27)

.100

(2.54)

.050

(1.27)




RFT 502-X DC to 2 1.10

.500

(12.70)

.340

(8.64)

.126 dia.

(3.20)

.050 (1.27)

RFT 504-X DC to 4 1.10 1.10

RFT 508-X DC to 8 1.10 1.10 1.20

RFT 518-X DC to 18 1.10 1.10 1.20 1.30 1.35

.250 (6.35)

“A”

.275 dia.

(6.99)

10 WATTS

.050

(1.27)

.050

(1.27)

.175

(4.45)

max.

MODEL "A"

NUMBER

RFT5XX-6 .028

RFT5XX-7 .032

HOW TO ORDER BY PART NUMBER:

The part number is a combination of model,

frequency range & contact type.

RFT5XX-8 .014

RFT5XX-9 .020

Example: RFT 518 6

MODEL NUMBER

FREQUENCY RANGE

CONTACT TYPE

Toll Free: 800.526.0704

Phone: 727.530.9555



2D

ELECTRO TECHNIK

STRIPLINE






RFT502-1 DC to 2 1.10

.500

(12.70)

.340

(8.64)

.104 dia.

(2.64)

.177 (4.50)

max.

RFT504-1 DC to 4 1.10 1.10

RFT508-1 DC to 8 1.10 1.10 1.15

RFT512-1 DC to 12 1.10 1.10 1.15 1.25

.250 (6.35)

.005

(0.13)

.275 dia.

(6.99)

RFT518-1 DC to 18 1.10 1.10 1.15 1.25 1.30

20 WATTS

.050

(1.27)

.100

(2.54)

.260

(6.60)

max.



NUMBER RANGE (GHz) DC-2 2-4 4-8 8-18

.500

(12.70)

.340

(8.64)

.104 dia.

(2.64)

.177 (4.50)

max.

RFT502-2 DC to 2 1.10

.250 (6.35)

RFT504-2 DC to 4 1.10 1.15

RFT508-2 DC to 8 1.10 1.15 1.20

RFT518-2 DC to 18 1.10 1.15 1.20 1.30

20 WATTS

.050

(1.27)

.028

(0.71)

.05

(0.13)

.050

(1.27)

.260

(6.60)

max.

.275 dia.

(6.99)



NUMBER RANGE (GHz) DC-2 2-4 4-8 8-18

RFT1002-2 DC to 2 1.10

RFT1004-2 DC to 4 1.10 1.15

RFT1008-2 DC to 8 1.10 1.15 1.20

1.000

(25.40) sq.

.718

(18.24)

.718

(18.24)

.125 dia.

(3.18)

.005

(0.13)

.078

(1.98)

.280 dia.

(7.11)

RFT1018-2 DC to 18 1.10 1.15 1.20 1.35

10 WATTS

.050

(1.27)

.100

(2.54)

.170 max.

(4.32)




3D



CYLINDRICAL

TERMINATIONS

GENERAL SPECIFICATIONS

FEATURES:

Designed for high frequency applications.

Space saver - compact sizes.

Time saver - easy to use.

IMPEDANCE: 50 Ohms.

FREQUENCY VSWR

RANGE (max.)

DC - 4 GHz 1.10:1

4 - 8 GHz 1.20:1

8 - 18 GHz 1.35:1

MECHANICAL TOLERANCE: ±.010 inch unless otherwise specified.

TEMPERATURE COEFFICIENT: ±100 PPM/°C.

TEMPERATURE CYCLING: Less than 0.25% change.

SHOCK & VIBRATION: Less than .10% change.

MOISTURE RESISTANCE: Less than 1% change when tested per

method 106 of MIL-STD-202.

LIFE TEST: Less than 1% change when tested for 1000 hours

full load at 100°C.

POWER RATING: Rated power is based on a

maximum flange temperature of 100°C derated

to 0 power at 150°C.

MATERIALS:

RESISTIVE ELEMENT: Proprietary film.

HOUSING: Copper, Nickel Plated.

SUBSTRATE: 3 Watt Alumina, 15 Watt Beryllium Oxide.

CONTACT: Beryllium Copper 1/2 hard Gold Plated.

.187

(4.75)

.050

(1.27)

.250

(6.35)

.100

(2.54)

.188

(4.78)

.005 (.13)

0.01

.254

R

.050

(1.27)

.188

(4.78)

SMA pin

.036

(.91)

.188

(4.78)

RCL3-1 3 WATTS


.260

(6.60)

.050

(1.27)

1/4 - 20

.250

(6.35)

SMA pin

.100

(2.54)

.250

(6.35)

.005 (.13)

0.10

.254

R

.050

(1.27)

.015 X .015

(.38)

.095

(2.41)

.036

(.91)

.178

(4.52)

RCL-15-1 15 WATTS


Toll Free: 800.526.0704

Phone: 727.530.9555



4D

ELECTRO TECHNIK

POWER COAXIAL TERMINATIONS

DC TO 2.4 GHz


RFT30NF

SPECIFICATIONS:

POWER: 30 Watts

Frequency Range:

VSWR:

Peak Power:

Nominal Size:

Weight:

DC to 2.4 GHz

1.10:1 - DC to 1.0 GHz

1.35:1 - 1.0 to 2.4 GHz

2 kW max.

(L,W,H) 3" x 21/2" x 21/4" max.

3/4 lbs. (.35 kg) max.

RFT60NF




VSWR:

Peak Power:

Nominal Size:

Weight:

DC to 2.4 GHz

1.10:1 - DC to 1.0 GHz

1.35:1 - 1.0 to 2.4 GHz

2 kW max.

(L,W,H) 3" x 21/2" x 21/4" max.

3/4 lbs. (.35 kg) max.

RFT100NF




VSWR:

Peak Power:

Nominal Size:

Weight:

DC to 2.4 GHz

1.10:1 - DC to 1.0 GHz

1.35:1 - 1.0 to 2.4 GHz

2 kW max.

(L,W,H) 63/4" x 41/4" x 41/4" max.

41/2 lbs. (2.04 kg) max.

RFT150NF




VSWR:

Peak Power:

Nominal Size:

Weight:

DC to 2.4 GHz

1.10:1 - DC to 1.0 GHz

1.35:1 - 1.0 to 2.4 GHz

2 kW max.

(L,W,H) 63/4" x 41/4" x 41/4" max.

41/2 lbs. (2.04 kg) max.




2E




DC TO 2.4 GHz

RFT250NF



VSWR:

Peak Power:

Nominal Size:

Weight:

DC to 2.4 GHz

1.15:1 - DC to 1.0 GHz

1.35:1 - 1.0 to 2.4 GHz

2 kW max.

(L,W,H) 10" x 41/8" x 41/8" max.

61/2 lbs. (2.95 kg) max.


RFT500NF



VSWR:

Peak Power:

Nominal Size:

Weight:

DC to 2.4 GHz

1.15:1 - DC to 1.0 GHz

1.35:1 - 1.0 to 2.4 GHz

2 kW max.

(L,W,H) 16" x 61/2" x 6" max.

15 lbs. (5.60 kg) max.


RFT1000NF



VSWR:

Peak Power:

Nominal Size:

Weight:

DC to 2.4 GHz

1.15:1 - DC to 1.0 GHz

1.35:1 - 1.0 to 2.4 GHz

2 kW max.

(L,W,H) 143/4" x 61/2" x 6" max.

16 lbs. (7.27 kg) max.


Toll Free: 800.526.0704

Phone: 727.530.9555



3E

ELECTRO TECHNIK


DC TO 500 MHz


RFT1500NF


6.50

6.500

(165.1)

6.500 6.50

(165.1)


VSWR:

Peak Power:

Nominal Size:

Weight:

DC to 500 MHz

1.25:1 - DC to 500 MHz

2 kW max.

(L,W,H) 221/4" x 61/2" x 61/2" max.

26 lbs. (11.79 kg) max.

22.25 max.

20.00

(565.15)

2.00 2.00

(50.8)

INPUT POWER: 1500 Watts

RFT2000NF

6.500

(165.1) max.


13.00 13.00 max.

(330.2)


VSWR:

Peak Power:

Nominal Size:

Weight:

DC to 500 MHz

1.25:1 - DC to 500 MHz

2 kW max.

(L,W,H) 141/4" x 13" x 61/2" max.

25 lbs. (11.34 kg) max.

14.25 max.

12.00 max.

(361.95)

2.00 2.00

(50.8)





4E



POWER COAXIAL ATTENUATORS

DC TO 2.4 GHz

RFA30NFFdB


RFA60NFFdB


RFA100NFFdB


RFA150NFFdB



Frequency Range: DC to 2.4 GHz

VSWR:

1.15:1 - DC to 1.0 GHz

1.35:1 - 1.0 to 2.4 GHz

Attenuation Value: 3 to 30 dB

Attenuation Accuracy: ±.30 dB or 3%

Peak Power: 2 kW max.

Nominal Size: (L,W,H) 3" x 21/2" x 21/4" max.

Weight:

3/4 lbs. (.35 kg) max.



VSWR:

1.15:1 - DC to 1.0 GHz

1.35:1 - 1.0 to 2.4 GHz




Nominal Size: (L,W,H) 3" x 21/2" x 21/4" max.

Weight:

3/4 lbs. (.35 kg) max.



VSWR:

1.15:1 - DC to 1.0 GHz

1.35:1 - 1.0 to 2.4 GHz




Nominal Size: (L,W,H) 71/2" x 41/4" x 41/4" max.

Weight:

4 lbs. (1.81 kg) max.



VSWR:

1.15:1 - DC to 1.0 GHz

1.35:1 - 1.0 to 2.4 GHz




Nominal Size: (L,W,H) 71/2" x 41/4" x 41/4" max.

Weight:

5 lbs. (2.27 kg) max.

Toll Free: 800.526.0704

Phone: 727.530.9555



5E

ELECTRO TECHNIK


DC TO 2.4 GHz


RFA250NFFdB


RFA500NFFdB




VSWR:

1.25:1 - DC to 1.0 GHz

1.35:1 - 1.0 to 2.4 GHz


Attenuation Accuracy: ±.30 dB or 3% DC to 1.0 GHz

±.75 dB or 5% 1.0 to 2.4 GHz


Nominal Size: (L,W,H) 101/2" x 41/8" x 41/8"

max.

Weight:

61/2 lbs. (2.95 kg) max.



VSWR:

1.25:1 - DC to 1.0 GHz

1.35:1 - 1.0 to 2.4 GHz



±.75 dB or 5% 1.0 to 2.4 GHz


Nominal Size: 14" x 61/2" x 6" max. (3-6 dB)

17" x 61/2" x 6" max. (7 dB & up)

Weight:

16 lbs. (7.26 kg) max.

RFA1000NFFdB



VSWR:

1.25:1 - DC to 1.0 GHz

1.35:1 - 1.0 to 2.4 GHz



±.75 dB or 5% 1.0 to 2.4 GHz


Nominal Size: 14" x 61/ 2" x 6" max.

Weight:

17 lbs. (7.70 kg) max.


(Fan note see section "E" cover sheet).




6E




DC TO 500 MHz

RFA1500NFFdB

output



DC to 500 MHz

6.500

6.500

(165.1)

input

VSWR:

Attenuation Value:

1.25:1 - DC to 500 MHz

3 to 30 dB


6.500

6.500

(165.1)


Nominal Size: (L,W,H) 221/4" x 61/2" x 61/2"

max.

Weight:

26 lbs. (11.79 kg) max.

22.25 max.

21.750 max.

(565.15)

2.00

2.00

(50.8)


output

RFA2000NFFdB

input

6.500

(165.1) max.

13.00 max.

(330.2)


Frequency Range: DC to 500 MHz

VSWR:

1.25:1 - DC to 500 MHz




Nominal Size: (L,W,H) 141/4" x 13" x 61/2" max.

Weight:

25 lbs. (11.34 kg) max.

14.25 max.

12.00 max.

(361.95)

2.00 2.00

(50.8)


Toll Free: 800.526.0704

Phone: 727.530.9555



7E

ELECTRO TECHNIK


PRECISION SMA

MINIATURE ATTENUATORS

GENERAL SPECIFICATIONS:


ACCURACY of ATTENUATION: 1 - 6 dB ±0.30 dB

7 - 20 dB ±0.50 dB

21 - 30 dB ±0.75 dB

INPUT POWER: The power is based on 25°C ambient temperature

derated to zero power at 125°.

OPERATING TEMPERATURE RANGE: -65°C to +125°C.

TEMPERATURE COEFFICIENT: 0.0001 dB/dB/°C.

CONNECTOR INTERFACE: Passivated Stainless Steel per MIL-C-39012.

CONNECTOR BODY: Passivated Stainless Steel.

MODEL FREQUENCY VSWR


RA2-2 DC-2 GHz 1.10:1

RA2-4 DC-4 GHz 1.15:1

RA2-8 DC-8 GHz 1.20:1

RA2-12 DC-12 GHz 1.25:1

RA2-18 DC-18 GHz 1.35:1

SMA jack

SMA plug

.280 ±.03

(9.14)



RA5-2 DC-2 GHz 1.10:1

RA5-4 DC-4 GHz 1.15:1

RA5-8 DC-8 GHz 1.20:1

1-12 dB .86 ±.02 (21.84)

13-30dB 1.02 ±.02 (25.90)


RA5-12 DC-12 GHz 1.25:1

RA5-18 DC-18 GHz 1.35:1

SMA jack

SMA plug


The part number is a combination of model, power,

frequency, connector type and attenuation value.

Example: RA 2 2 SFM dB

.280 ±.03

(9.14)

1-12 dB .86 ±.02 (21.84)

13-30dB 1.02 ±.02 (25.90)


.750 dia.

(19.05)

MODEL #

WATTAGE

FREQUENCY

RANGE

CONNECTOR

TYPE (male/female)

ATTENUATION

VALUE (dB)

Toll Free: 800.526.0704

Phone: 727.530.9555



1F

ELECTRO TECHNIK

TYPE "N"

ATTENUATORS




ACCURACY of ATTENUATION: DC - 2 GHz ±0.30 dB

DC - 4 GHz ±0.50 dB

DC - 6 GHz ±0.75 dB

INPUT POWER: 10 or 20 Watts. The power is based on 25°C

ambient temperature derated to zero power at 125°.

OPERATING TEMPERATURE RANGE: -65°C to +125°C.

TEMPERATURE COEFFICIENT: 0.0001 dB/dB/°C.

CONNECTOR INTERFACE: Meets the interface requirements of

MIL-C-39012.

HOUSING: Nickel Plated Brass.

ATTENUATION VALUES: 1 - 40dB

.790

(20.07)



N Male

Connector

RA10-2 DC-2 GHz 1.15:1

RA10-4 DC-4 GHz 1.25:1

RA10-6 DC-6 GHz 1.35:1

RES-NET

RA10 - 4NMF20

10WATTS 20 dB

N Female

Connector



RA20-2 DC-2 GHz 1.15:1

RA20-4 DC-4 GHz 1.25:1

RA20-6 DC-6 GHz 1.35:1

2.75 (69.85)

RA10

10WATTS (1KW peak)

N Male

Connector

2.75 (69.85)

N Female

Connector


The part number is a combination of model, power,

frequency, connector type and attenuation value.

1.50

(38.10)

.630 dia.

(16.00)

Example: RA 10 2 NMF dB

.770 (19.55)

RA20

20WATTS (1KW peak)

.770 (19.55)

MODEL #

WATTAGE

FREQUENCY

RANGE

CONNECTOR

TYPE (male/female)

ATTENUATION

VALUE (dB)




2F


POWER FLANGE

ATTENUATORS


PART NUMBER: RPA-20

FREQUENCY ATTENUATION VSWR

RANGE ACCURACY (dB) (max.)

dB DC-1GHz 1-2.5 GHz

.116 dia.

(2.94)

.515 (13.08)

.125 (3.18)

.125 (3.18)

.180 (4.75)

max.

.062 (1.57)

0 - 5 ±0.5 ±0.5

DC - 2.5 GHz 6 - 9 ±0.5 ±0.5

10 - 15 ±0.5 ±1.0

16 - 20 ±0.5 ±1.0

21- 30 ±1.0 ±3.0

1.15:1

DC to 1.0 GHz

1.35:1

1.0 to 2.5 GHz

.250

min. (6.35)

.060 (1.52)

.250 (6.35)

.250 (6.35)

.003 (.076)

.125 (3.18)

20 WATTS (200 watts peak)

0 to 30 dB





0 - 5 ±0.3 ±0.5

DC - 2.5 GHz 6 - 9 ±0.3 ±0.5

10 - 15 ±0.3 ±0.5

16 - 20 ±1 dB ±1dB

21 - 30 ±1.0 ±3.0


1.15:1

DC to 1.0 GHz

1.25:1

1.0 to 2.5 GHz

.130 dia.

(3.30)

.575 (14.60)

.250

min. (6.35) .060 (1.52)

.125 (3.18)

.115 (2.92)

.230 (5.84)

.250 (6.35)

min.

0 to 30 dB

.150 (3.81)

max.

.003 (.076)

.108 (2.74)





0 - 5 ±0.3 ±0.5

DC - 2.5 GHz 6 - 9 ±0.3 ±0.5

10 - 15 ±0.3 ±0.5

16 - 20 ±0.5 ±0.5

21 - 30 ±1.0 ±3.0

1.15:1

DC to 1.0 GHz

1.25:1

1.0 to 2.5 GHz

.130 dia.

(3.30)

.800 (20.32)

.550 (13.97)

.250

min. (6.35) .060 (1.52)

.125 (3.18)

.115 (2.92)

.230 (5.84)

.250 (6.35)

min.

.150 (3.81)

max.

.003 (.076)

.108 (2.74)


0 to 30 dB




1G



HIGH POWER

FLANGE ATTENUATORS




DC-1GHz 1-2 GHz

1.15:1

DC to 1.0 GHz

DC - 2 GHz ±0.3 ±0.5

1.25:1

1.0 to 2.0 GHz

.975 (24.77)

.725 (18.42)

.220 (5.59)

max.

.110 (2.79)

.187 (4.76)

.375 (9.52)


.250

min. (6.35) .060 (1.52)

.125 dia.

(3.17)

.003 (.076)

.171 (4.34)

1 to 20 dB




.250 (6.35)

.500 (12.70)

.150 (3.81)

min.

dB DC-1GHz 1-2 GHz 2-3 GHz

DC - 3 GHz 1 - 10 ±0.3 ±0.4 ±0.6

11 - 20 ±0.4 ±0.6 ±0.75

21 - 30 ±0.5 ±0.75 N/A

1.15:1

DC to 1.0 GHz

1.20:1

1.0 to 2.0 GHz

1.25:1

2 to 3.0 GHz

.680 (17.27)

.060 (1.52)

.125 dia.

(3.18)

.438

(11.13)


.190 (4.83)

.156 (3.96)

.003 (.076)

1 to 30 dB




dB DC-.5 GHz .5-1 GHz

1.000

(25.40)

.750 (19.05)

.375

(9.52)

.300 (7.62)

min.

DC - 1 GHz 1 - 10 ±0.3 ±0.5

11 - 20 ±0.3 ±0.75

1.15:1

DC to 1.0 GHz

.750

(19.05)

.120 (3.05)

21 - 30 ±0.3 ±1.0

.125 dia.

(3.18)


.250 (6.35)

.200 (5.08)

1 to 30 dB

.003 (.076)

Toll Free: 800.526.0704

Phone: 727.530.9555



2G

ELECTRO TECHNIK

POWER

COAXIAL ATTENUATORS


PART NUMBER: RPAX-25

.387

(9.83)



.125 dia. (3.18)

DC - 2 GHz ±0.3

DC-2GHz

1.15:1

DC to 2.0 GHz

1.30

(3.30)

.250

(6.35)

.500 (12.70)


When mounted to a heat sink maintaining case temp at 100°C max.

Connector SMA.

.430

(10.92)

max.

.520 (13.21)

.750 (19.05)

.115 (2.92)

1 to 20 dB

PART NUMBER: RPAX-50 / RPAX-100



DC-1GHz

DC - 1 GHz ±0.3

1.15:1

DC to 1.0 GHz

1.250

(31.75)

1.065

(27.05)

.990

(25.15)

1.850

(46.99)

max.

.500

(12.70)

50 / 100 WATTS (1000 watts peak)


Connector type SMA standard - type "N" available.

.130 (3.30)

.750

(19.05)

.125

(3.18)

1 to 40 dB

PART NUMBER: RPAX-250

5.500 (139.70)

nominal



dB DC-1 GHz 1-2.4 GHz

DC - 2.4 GHz 0.5 - 3 ±0.3 ±0.75

3 - 10 ±0.5 ±1.0

10 - 40 ±0.5 ±1.5

1.15:1

DC to 1.0 GHz

1.25:1

1.0 to 2.4 GHz

1.50

(38.10)

.500

(12.70)

1.500

(38.10)

1.500

(38.10)

.136 dia. thru

6 places

1.00

(25.40)

250 WATTS (2 KW peak)


Connector type "N" standard - SMA available.

4.000

(101.60)

1 to 40 dB

.250

(6.35)




3G


POWER CHIP

RESISTORS & TERMINATIONS



Performance to 18 GHz.

L

Highly reliable multilayer electrode construction.

Compatible with both flow soldering and reflow soldering.

Resistive

Area

W

Highly stable in auto placement surface mounting applications.

Reliability programs designed to customer requirements.

Proven designs for Microwave applications.

Terminal

A


T

STYLE T

STANDARD RESISTANCE RANGE: 5 ohms to 5,000 ohms.

Other values available.

TOLERANCE: ±1%, ±2%, ±5% and ±10%.

TEMPERATURE COEFFICIENT: ±100 PPM/°C. (-55°C to +125°C

with 25°C as reference). Other temperature coefficients available.

RESISTIVE ELEMENTS: Proprietary film.

SOLDERABLE TERMINALS: Electroplated Tin over Nickel.

SUBSTRATE: Beryllium Oxide.

TERMINAL STYLE:

T - Termination, one sided wraparound.

R - Resistor, Metallized backing.

W - Resistors, two sided wraparound.

T

T

.005

max.

STYLE R

STYLE Z

C

A

A

A

T

STYLE W

HIGH POWER BERYLLIUM OXIDE SUBSTRATE (BeO)

RPC W L T A MAXIMUM

TYPE (inches) (inches) (inches) (inches) (°C/Watt) POWER

±.005 ±.005 ±.005 ±.008

RPC50-50 .050 .050 .010 .012 1.46 5 watts

RPC50-100 .050 .100 .010 .017 1.57 10 watts

RPC75-150 .075 .150 .010 .020 1.18 15 watts

1. Thermal resistance in °C/W between film and mounting surface.

2. Maximum film temperature is 150°C.

3. Power ratings are based upon 100°C heat sink temperature.

4. "T" is substrate thickness, add 0.005 for terminal and film thickness.




1H



HIGH POWER CHIP


GENERAL INFORMATION:

When mounted on the appropriate heat sink,

these chips will provide high power dissipation.


DC Voltage (Maximum): E =1 √(AxB)

Resistive Tolerance: 1%, 2%, 5%, 10%

Terminals:

Tin over Nickel

Substrate:

Beryllium Oxide Ceramic

or Aluminum Nitride

Resistive: Element: Propriety Film

Environment:

Meets applicable portions

of MIL-PRF-55342

NOTES:

1. The "L" and "T" dimensions are for the substrate only and do not

include terminal thickness or optional tinning thickness.

2. Thermal Resistance (R0°) is measured in °C/W between resistive

film and mounting surface.

3. The CW power rating is based on maximum film temperature of

+150°C and with maximum heatsink temperature of +100°C.

Power is based on infinite and ideal heatsink. Type "W" and "Z"

termination style does not have full back plane metallization and

typically handles less power.


The part number is a combination of type, size, terminal style,

resistance value and tolerance.

A

Terminal

T

T

T

L

Resistive

Area

STYLE T

.005

max.

STYLE R

STYLE Z

C

B

B

B

W

Example: RPC 50-50 N T 50 - 1

TYPE

SIZE

N FOR ALUMINUM NITRIDE

TERMINAL STYLE

RESISTANCE VALUE

TOLERANCE %

T

STYLE W

B

RPC W L T A B C R0°C/W CW POWER

TYPE ±.005 ±.005 ±.005 ±.008 ±.010 ±.005 (max.) (max.)

(NOTE 1) (NOTE 1) (NOTE 2) (NOTE 2)

Beo ALN Beo ALN

100-200-4 .100 .200 .040 .100 .040 .040 .80 .55 67 46

230-350-4 .350 .230 .040 .187 .040 .040 .35 .24 150 104

250-250-4 .250 .250 .040 .187 .060 .040 .30 .21 169 117

250-250-6 .250 .250 .060 .187 .060 .040 .45 .31 112 78

250-375-4 .250 .375 .040 .220 .060 .060 .15 .11 250 225

250-375-1 .250 .375 .135 .220 .060 .060 .50 .35 108 75

375-375-4 .375 .375 .040 .250 .060 .060 .11 .08 306 212

500-500-4 .500 .500 .040 .375 .060 - .07 .05 510 353

1000-1000-6 1.000 1.000 .060 .412 .090 - .05 .03 700 485

Toll Free: 800.526.0704

Phone: 727.530.9555



2H

ELECTRO TECHNIK

LOW POWER CHIP

ATTENUATORS



DC to 10 GHz.

Temperature stable.

Reliability programs to customer requirements.

Custom sizes designed for special applications.

Compatible with flow and reflow soldering.

.125

(3.18)

.025

(0.63)

.150

(3.81)

.060

(1.52)

.015 min.

(.38)

Standard

Singleface

.015

(0.38)

ground

.125

(3.18)

.025

(0.63)

.150

(3.81)

.015 min.

(.38)

.060

(1.52)

.015

(0.38)

wraparound

ground

STYLE W

Ground Terminal

Wraparound



OPERATING TEMPERATURE: -55°C to +150°C. Exceeds

applicable requirements of MIL-E-5400 and MIL-PRF-55342.

ATTENUATION STABILITY: 0.0001 dB/DB/°C.

TEMPERATURE COEFFICIENT: ±100 PPM/°C. (-55°C to +125°C

with 25°C as reference). Other temperature coefficients available.

POWER RATING: The power rating is 1 Watt from 25°C to 85°C

derated linearly to zero at 150°C. The chip can be used at a higher

power level with adequate heat sinking.


TERMINALS: Platinum Silver or Tin over Nickel.

SUBSTRATE: 96% Alumina.

COVER: Epoxy or Alumina.

TABS: Beryllium Copper, Gold Plated.


(Test methods per MIL-PRF-55342)

TEST

Thermal Shock

Low Temperature Operation

Short Time Overload

High Temperature Exposure

Moisture Resistance

Life

Solderability

Termination Adhesion

REQUIREMENTS

±(.25% +0.05 ohm)

±(.25% +0.05 ohm)

±(.1% +0.005 ohm)

±(.5% +0.005 ohm)

±(.5% +0.05 ohm)

±(1% +0.05 ohm)

95% min. coverage

15 grams min.

.125

(3.18)

.025

(0.63)

.150

(3.81)

.060

(1.52)

.015 min.

(.38)

STYLE W3

3 Terminal

Wraparound

.015

(0.38)

wraparound

ground

.125 (3.18)

.150

(3.81)

.250

(6.35)

.060 (1.52) typ.

MICROSTRIP CONFIGURATION:

DC - 4 GHz DC - 10 GHz

dB ATTEN. VSWR ATTEN. VSWR

VALUE Sens. dB (max.) Sens. dB (max.)

1 to 6 ±0.5 1.25 ±0.5 1.35

7 to 9 ±0.5 1.25 ±0.5 1.35

10 to 12 ±0.75 1.25 ±1.0 1.35

13 to 14 ±0.75 1.25 ±0.5-2 1.35

15 to 16 ±1.0 1.25 ±0.5-3 1.35

17 to 18 ±1.0 1.25 ±0.5-3 1.35

19 to 20 ±1.0 1.25 ±0.5-4 1.35

1 WATT (200 Watts peak)

Part Number

RNCA

Db

.003

(.076)

.040

(1.02)

STYLE C

Tabs & Cover

Style




3H



HIGH POWER CHIP

ATTENUATORS



ATTENUATION VALUES: 1 dB to 20 dB.

POWER RATING: The power rating is from -65°C to 100°C, derated

linearly to zero at 150°C.

TEMPERATURE COEFFICIENT: ±100 PPM/°C maximum from -55°C to

+125°C.

ENVIRONMENTAL: Meets or exceeds the applicable requirements of

MIL-PRF-55342.

OPERATING TEMPERATURE: -65°C to +150°C.

ATTENUATION STABILITY: 0.0001 dB/dB/°C.

MECHANICAL TOLERANCE: ±.010 inch.

MATERIALS:


TERMINALS: Platinum Silver.

SUBSTRATE: Beryllium Oxide.

COVER: Epoxy or Alumina.

TABS: Beryllium Copper, Gold Plated.

.230

(5.84)

.150

(3.81)

.230

(5.84)

.350

(8.89)

.060

(1.52) .040

(1.01)

.042

(1.06)

ground

RPCA30 (30 WATTS)

.350(8.89) .092

.40 (2.34) max

(1.01)

.003

(0.076)

.043

(1.09)

RPCA30-XXC (30 WATTS)

.375

(9.53)

.040

(1.01)

.043

(1.09)

MICROSTRIP CONFIGURATION:

PART ATTENUATION ACCURACY (dB) VSWR

NUMBER & FREQUENCY (GHz) (max.)

dB DC-1GHz 1-2.5 GHz 2.5-4 GHz

RPCA30 1 - 5 ±0.3 ±0.5 ±0.5

6 - 9 ±0.3 ±0.5 ±0.7

10 - 15 ±0.4 ±0.5 ±1.0

16 - 20 ±0.5 ±0.6 ±1.0

20 - 30 ±0.75 ±1.0 N/A

dB DC-1GHz 0.5-1GHz

RPCA50 1 - 5 ±0.5 ±0.5

6 - 9 ±0.3 ±0.5

10 - 15 ±0.4 ±0.7

16 - 20 ±0.5 ±1.0

20 - 30 ±0.5 ±1.5

1.15 to DC

to 1.0 GHz

1.25 to 1.0

to 2.5 GHz

1.35 to 2.5

to 4.0 GHz

1.15 to DC

to 0.5 GHz

1.20 to 0.5

to 1.0 GHz

.060

(1.52)

.015

(.38)min.

.375

(9.53)

ground

RPCA50 (50 WATTS)

.250 min.

(6.35)

.003

(0.076)

.375

(9.53)

.092

(2.34)

RPCA50-XXC (50 WATTS)

Toll Free: 800.526.0704

Phone: 727.530.9555



4H

ELECTRO TECHNIK

COAXIAL ROD




RESISTANCE RANGE:10 ohms to 500 ohms.

other values available.

RESISTIVE TOLERANCE: ±1%, ±2%, ±5%.

TEMPERATURE COEFFICIENT: ±75 PPM/°C.

FREQUENCY RANGE: DC to 18 GHz.

For DC to 40 GHz consult factory.

TEMPERATURE RANGE: -65°C +175°C.

POWER RATING: Rated power is based on a

maximum surface temperature of +175°C.

MATERIALS:

TERMINALS: The solderable terminals are a

highly reliable multilayer of Tin over Nickel.

PROTECTIVE COATING: High temperature enamel.

CERAMIC: Low power rods are Alumina, high power

rods are Beryllium Oxide or Aluminum Nitride.

RESISTIVE ELEMENT: Metal film.

T

L

O.D.

ALUMINA ROD RESISTORS:

O.D. L T POWER

TYPE ±.003 ±.010 ±.015 WATTS

R40L115 .040 .115 .031 .050

R62L375 .062 .375 .047 .050

R125L250H .125 .250 .063 1.00

R125L406 .125 .406 .109 1.50

R125L500 .125 .500 .063 2.00

BERYLLIUM OXIDE ROD RESISTORS:


TYPE ±.003 ±.010 ±.015 WATTS

R40B115 .040 .115 .031 5.0

R60B120 .060 .120 .031 10.0

R62B187 .062 .187 .063 10.0

R62B375 .062 .375 .047 10.0

R125B500 .125 .500 .063 25.0

R250B750 .250 .750 .125 40.0

R375B750 .375 .750 .125 75.0

NEW

ALUMINUM NITRIDE ROD RESISTORS:


TYPE ±.003 ±.010 ±.015 WATTS

R40N115 .040 .115 .031 4.0

ALUMINA SHOULDERED ROD RESISTORS:

O.D. L T A B POWER

TYPE ±.002 ±.010 ±.015 ±.010 ±.015 WATTS

R125S500 .125 .500 .025 .064 .092 .050

R60N120 .060 .120 .031 8.0

R62N187 .062 .187 .063 8.0

R62N375 .062 .375 .047 8.0

T

A

R125N500 .125 .500 .063 20.0

R250N750 .250 .750 .125 31.0

R375N375 .375 .750 .125 59.0

NEW

L

B




5H



MICROWAVE CARBON

FILM ROD RESISTORS

Res-Net's high power carbon film rod resistors with ohmic

values from 25-100Ω and power ratings of 0.05 to 75 watts.

Contact our Sales Department for more information.

TERMINALS:

Terminals are nickel/tin plated.

SUBSTRATES:

Beryllium Oxide or Aluminum Oxide (alumina) ceramics

(L denotes aluminum oxide and B denotes beryllium oxide)

TEMPERATURE RANGE:

-55° to +200°C.

TEMPERATURE COEFFICIENT:

These rods exhibit a range of -200 to -300ppm/°C.

T

L

O.D.

LOAD LIFE:

The maximum change in resistance value is 1% when

operated at rated power, with appropriate heat sinking,

for 1000 hours.

POWER RATING:

The surface temperature should not exceed 200°C.

These resistors can handle full power at 70°C and are

then derated linearly to zero power at 200°C.

FREQUENCY RANGE:

DC to 26.5 GHz when using a properly designed cavity or

test fixture with proper heat sinking.

STANDARD RESISTANCE TOLERANCE:

A tolerance of 5% is standard but 2% and 1% tolerances

are available.


TYPE O.D. ±0.003 L ±0.010 T ±0.015 POWER WATTS

R40L115 0.040 0.115 0.031 0.050

R60L120 0.060 0.120 0.031 0.050

R62L187 0.062 0.187 0.063 0.050

R62L280 0.062 0.280 0.063 0.050

R62L375 0.062 0.375 0.047 0.050

R125L250H 0.125 0.250 0.063 1.000

R125L406 0.125 0.406 0.109 1.500

R125L500 0.125 0.500 0.063 2.000

R40B115 0.040 0.115 0.031 5.000

R60B120 0.060 0.120 0.031 10.00

R62B187 0.062 0.187 0.063 10.00

R62B375 0.062 0.375 0.047 10.00

R125B500 0.125 0.500 0.063 25.00

R250B750 0.250 0.750 0.125 40.00

R375B375 0.375 0.750 0.125 75.00

Toll Free: 800.526.0704

Phone: 727.530.9555



6H

ELECTRO TECHNIK

DISC RESISTORS


ELECTRICAL SPECIFICATIONS:

Resistance Range:

0.5-500 Ohms. For other values contact factory.

Standard Tolerance:

Resistance below 1.0 Ohms tolerance is ± 20% at 25 ºC

Resistance 1-50 Ohms tolerance is ± 10% at 25 ºC

Resistance above 50.0 Ohms tolerance is ± 5% at 25 ºC

Contact factory for other tolerance values.

Load Life: Expect maximum change in resistance to be

1% when operated at listed rating for 1000 hours.

Nominal Power:

Power rating depends on the dimension of the Disc.

See table below

Normal Frequency Range: DC to 1.0 GHz

Performance at higher frequency DC to 18 GHz depends

upon how the disc is mounted and associated mounting

configuration.

MECHANICAL SPECIFICATIONS:

Disc Material: Beryllium Oxide Ceramic.

Terminations:

T1

W

Proprietary Silver or Tin plated terminations on both

sides with a wrap around over Thick Film Conductor.

Temperature Range: -55°C to +150ºC

Temperature Coefficient:

Standard Temperature coefficient is

-100 to +100 PPM/ °C

T2

ID

OD


RES. NOMINAL OD ID W T1 T2

(OHMS) POWER (inches) (inches) (inches) (inches) (inches)

0.5 - 500 10W 0.372 - 0.380 0.131 - 0.139 0.030 - 0.036 1/32 1/32

0.5 - 500 5W 0.245 - 0.257 0.066 - 0.074 0.020 - 0.027 1/32 1/64




7H

RES-Net Microwave Catalog

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
