Getting Set Up and Started

Central Station

Controlling

Switching

Running

38

�

��

= Operating step(s) Märklin

= Operating step(s) DCC

Function Buttons

0 - 7

Function Symbols

8 - 15

Locomotive set up

for a shuttle train

inactive / active

Changing, Storing

of Data

Locomotive Menu

Switch to

keyboard

Switch to

layout


Switch to

memory

Switch to

setup

Switch to

control

Stylus

Sx

USB

Function Buttons

0 - 7

Function Symbols

8 - 15

60173

Locomotive Menu

Control Knob 2 Booster

Control Knob 1

Connections S 88 Feedback

6017 / 6015 Module

Stop - Emergency

Connections

Front of Unit

Direction Indicator

Stop

Locomotive Image

and Name; Locomotive

Menu

Direction Indicator

Locomotive Image

and Name; Locomotive

Menu

Back of Unit

Mobile Station Connections

Locomotive

Card

Stylus

Active Speaker

or Headphones

Network

PC

Output

Input

opt.

Aux

opt.

Booster

60174

Keyboard / Mouse

or USB Stick

B 0 B 0

B 0 B 0

prog

Track

power

Programming

Track

Power-supply

unit

Underside of Unit

Locomotive

Card

Getting Set Up and Started

Preparations

The following components are required to get started: � ��

Connections to the Layout � ��

60 VA power-supply unit, connecting cable between the power-supply unit and the Central Station,

connecting wires between the Central Station and the track layout, rolling stock and/or solenoid

accessories.

Connect the parts as shown in the following illustrations.

Connections to C Track or Connections to K Track or

The only possible connections are those shown!

1 Gauge feeder connection and/or

Connecting the power supply to the Central Station

and calibrating the touchscreen (Display) when

turning the Central Station on the fi rst time.

The maker fi eld near this text appears in different positions (5 times)

on the display. Please confi rm this symbol by touching it with the

stylus exactly in the middle.

The calibration procedure is ended after that and the locomotive

controller display will appear after a short time.

60

Aux

prog

B 0 B 0 B 0

B 0

power

0 B

0 B

0 B

Sx

� ��

USB

60173

60173

Aux

B 0 B 0

B 0 B 0

prog

B 0 B 0

Connections to the Programming Track

The programming track may not have any direct electrical contact with the layout, nor can it have

additional users (examples: lighting, turnout decoders, light track bumper, etc.) connected to it.

The programming track is required to read out, program, and process locomotive decoders.

C Track Programming Track or K Track Programming Track or 1 Gauge programming track and/or

0 B

B 0 B 0

power

0 B

0 B

power

��

��

39

� Page 39 =>

Select one of your locomotives

in the database.

This only works if the settings

done at the factory for the locomotive

have not been changed.

40

��

Registering mfx locomotive

mfx locomotive recognized

Selecting a Locomotive

�

�

Confi rm

selection.


Selecting and Running a Locomotive

Data from the mfx

locomotive completely

read in.

Confi rm

The mfx locomotive is ready to

run and can already be operated.

If it becomes necessary, we recommend

that the locomotive be

added to in the locomotive list as

shown starting on Page 47.

You can start immediately if one of these

locomotives is part of your roster:

(101 047-9 with address 1, BR 85 006 with

address 8) then continue as described

nearby under “Running a Locomotive“.

Or

Select a controller and continue

with the following steps.

Running a Locomotive Function switch

Selecting and Controlling Solenoid Accessories

Selecting Controlling

�

All accessory addresses

are available without

prior programming.

These addresses are arranged

in ascending order

and can be confi rmed with

the standard keyboard.

Loading the Basic Confi guration for DCC ��

Selecting a Locomotive

��

Or

You enter your locomotives as

described on page 47 under

“Programmable Locomotive“.


Selecting and Running a Locomotive

Do Reset_DCC. After that the basic confi

guration for the Central Station is set to

DCC. This facilitates entering locomotives

and turnouts.

You can start immediately if this locomotive or

a locomotive with address 3 belongs to your

motive power. Then continue as described

nearby under “Running a Locomotive“.

Running a Locomotive Function switch

Selecting and Controlling Solenoid Accessories

Selecting Controlling

��

2,048 addresses are available.

These are arranged

numerically in ascending

order and can be activated

from a standard keyboard.

We recommend that you

check the settings for the

type of decoder before

using it. => Page 56/3-5.1

41

Introduction

The fourth generation of Märklin multi-train control systems is now ready with this “Märklin Digital“.

The most important component is the Central Station, which is responsible for the generation of the

correct control data, which carries out the coordination of the components connected to it, and which

also offers an easy-to-use manageable operating surface. Trouble-free operation with this complex

system is only ensured when you use only tested Märklin system components. Märklin‘s manufacturer‘s

warranty therefore becomes invalid if you use any other make of product with the Central Station.

The operator is thereby responsible for damages arising from the use of other makes of products.

Adhere to the techniques and principles presented in this instruction manual when connecting your

layout to the Central Station. The use of other circuits can easily lead to damage to the electronic

components. It is therefore best if you refrain from “expensive“ experiments. The Central Station is

not a toy. Make sure that this device is also used by children only as a controller for a model railroad.

We hope you will have a lot of enjoyment using the Central Station with your model railroad layout.

With this Central Station you have a device that offers you extensive possibilities for controlling your

model railroad. We recommend that you work through the examples presented in this handbook.

You will thereby have a much greater level of reliability in using the Central Station.

Your Märklin Service Team

Notes for the Central Station

Do not expose the Central Station to moisture.

This Märklin product is not watertight. Malfunctions can occur if there is high humidity or if moisture

gets inside the housing. The corrosion of the internal mechanism and electronics can lead to irreparable

damages.

Do not expose the Central Station to shock.

If this controller is exposed to blows or strong vibrations, the result can be continuous malfunctions.

Do not expose the Central Station to extremes of temperature.

Sudden changes in temperature can cause moisture to condense inside the housing. In order to avoid

condensation buildup, you should keep the Central Station protected andl you should protect it during

transport before you change to a location with much higher or lower temperature.

Do not use force when operating the buttons and control knobs on the Central Station.

Do not use force when operating the buttons and control knobs on the Central Station.

Safekeeping

Do not keep the Central Station in locations where the following unfavorable conditions prevail:

High humidity or bad ventilation.

Temperatures over 50° Centigrade / 122° Fahrenheit (such temperatures can occur for example in direct

sunlight) or under -10° Centigrade / 14° Fahrenheit.

Humidity over 60%.

The humidity must not be greater then that for Central Europe.

Cleaning

Remove lint and dust with a soft, dry or slightly moist cloth. Never use alcohol, thinners or other

strong cleansers.

42

Technical Specifi cations

Power Output When Used with the 60061/60101 power-supply unit

Input voltage: min. 14 V= / max. 24 V ~

Load: Train operating track 3 amps / 5 amps

Programming track 1.0 amps

Maximum 5,0 amps

Please take note of the specifi cations in the Help function for this unit so that you can make

full use of the total possible load.

Display resolution: 800 x 480 Pixels with 16 Bit color depth

Possible Connections

Power-supply unit

Programming track

Mobile Station

Feeder track

Network: Ethernet

USB: for a mouse, keyboard, and/or memory stick

Booster: 6015, 6017, or 60174

Feedback Module: S 88

Aux: currently not used

Outlet: Connections for a Central Station (60213/60214/60215), the Terminal 60125 or from the Connect 6021

Input: Connections for a Central Station (60213/60214/60215) as an Auxiliary or Second Unit

SX-Bus: (Currently not used).

Headphones or active speakers (Currently not used).

Technical Note for the Central Station

Only standard, hooded USB sticks with an ferrite core may be plugged into the USB connection.

Digital Protocols:

The following digital protocols are supported:

Märklin Motorola, mfx, �

DCC adhering to NMRA/NEM standards. ��

Software:

Parts of the software for the Central Station are subject to the software license GPL.

You can get the source code for these software parts at no charge from Märklin, either as a CD or by

downloading a CD image from the Märklin home page.

More complete and updated information can be found on our Internet pages “www.maerklin.com“

If an error or defect should occur, do not open the Central Station. Send the defective unit to the Märklin

Service Department or to one of our service stations listed on our Internet page.

Opening this unit cancels any and all warranty claims. The individual and/or fi rm or customer responsible

for opening the Central Station bears the burden of proof and demonstration that opening the unit did not

cause the defect that has occurred and/or damages.

Control

��

43

Locomotives and powered units can be entered, run, and managed with the Control.

Selecting and Running

44

� ��

You can select from the last

30 locomotives used or you

can expand the selection.

The most frequently used

locomotives are available

for you to select in this list.

All of the locomotives taken by you

into the locomotive list are in this

list for you to select.

Now you can run the locomotive you have

selected with the control knob or by typing

in the desired speed on the screen.

The functions can be activated by pressing

on the button or by typing in the symbol.

Locomotive with an mfx Decoder

Registering and/or taking into the

locomotive list.

�

Place your locomotive with an mfx decoder on the programming track. This can also be done while

the layout is in operation. The locomotive registers itself as shown in the following illustrations. The

registration can be done with an icon and locomotive name as well as without. Additional processing

as described starting on Page 48 will be necessary depending on the registration.

mfx locomotive recognized.

Data from the mfx

locomotive completely

read in.

Confi rm.

The mfx locomotive is ready to run and

can already be operated.

If it becomes necessary, we recommend

that the locomotive be added to

the locomotive list as shown starting

on Page 48.

Entering:

New locomotive manually: Introduction and Preparation � Page 45

Locomotive with DIP Switches � � Page 46

Programmable Locomotive � Page 47

Select

Icon

Symbol

Selection for

the Display

on the

Mobile Station

Locomotive

Address

or

opens the

10 digit

keypad

� ��

Locomotive Description

Read Locomotive

Address

Read Status

Display

Opens Keypad

� ��

� ��

small or

large

Switch Settings

Decoder/Address

4 or 8 DIP Switches

Save Data

Cancel

without Saving

Online Help

Confi rm

and Save

Tip:

Basically, the decoders can be used in mixed operation. You can decide by address which protocol will be assigned to the latter and which protocol will be supported by the decoder.

0

Whenever you see this ? ,

the Help function is available

for you to use and will take

you through the operation

of the application you are

asking about.

45

46

Select icon.

Enter locomotive name: ex. Class 03.

3 x

Select an icon

that goes with

your locomotive.

Confi rm

selection.

With DIP Switches �

Programmable locomotive � Page 47

�

78

Check the settings for the

decoder.

If the locomotive is standing on the programming

track, you can read out the address for it.

or

enter a

decoder address.

3

You can do other settings that infl uence the

locomotive‘s running characteristics when

controlled with the Central Station. The settings

can be done in the fi elds with “-“ or “+“. In our

example: acceleration and braking delay (these

settings affect the Central Station‘s controllers

and are not supported by this type of decoder).

The speedometer setting is for the display on the

Central Station‘s screen and has no infl uence on

the maximum speed of the locomotive.

If all of the desired settings have

been done, then confi rm and save.

You can fi nd additional possible settings in the section “Confi guring a Locomotive“. Page 48

Programmable Locomotive:

Read or enter.

Place the locomotive on the

programming track!

� ��

� ��

�

oder

��

Selecting the decoder type.

The locomotive has been

taken into the locomotive list.

Reading the existing

decoder address.

Confi rm.

You can do other settings that infl uence the locomotive‘s running

characteristics when controlled with the Central Station. The

settings can be done in the fi elds with “-“ or “+“. In our example:

acceleration and braking delay as well as the speedometer.

Confi rm, or if changes have been

made, transfer them to the locomotive.

The locomotive is now entered. It can be added

to or changed as shown starting on Page 48.

47

48

Changing CVs (Parameters)

� ��

Confi guring a Locomotive

Adding to / changing symbols, functions, and settings. This function can be used for all types of

decoders. However, only those settings and functions available on the computer can be processed.

In the example of a locomotive with an mfx decoder we are showing you the multifaceted possibilities

for these settings.

The locomotive to be processed should

be called up on one of the two controllers.

Then go with this locomotive to

the confi guration mode as shown here.

In the confi guration mode there are additional icons available for the supplementary setup of the

locomotive.

!Please note that not every locomotive supports all functions and characteristics. Please refer

to the instructions that came with your locomotive. There you will fi nd information regarding what

functions and characteristics the locomotive‘s decoder supports.

Change Decoder

CVs

Add Shuttle

Train Route

Button for Resetting the

Locomotive Decoder

Function Symbols 8-15

Send data

to locomotive

Write data to

locomotive card

Function Symbols 0-7

Adding a Shuttle Train Route

Here, you have the possibility of

assigning a shuttle train route.

Deletion of the shuttle train route for this locomotive

You now have the possibility

of doing changes. For example,

adding an appropriate icon.

Select.

Confi rm.

Enter the contact from the

S 88 feedback module in the

fi eld to which it belongs and

set the maximum speed and

the waiting period.

Confi rm.

activated

Changing or Adding Function Symbols.

� ��

deactivated

Select a function symbol.

The shuttle train is now immediately

active; the locomotive

can now be used only for this.

The shuttle train is set up and

can be activated at anytime.

The locomotive can be used

universally.

select

You have the possibility of assigning

a type of function to the functions:

��

��

(ex. Telex couplers)

��

Select a function symbol,

example: duration function.

5

Select the

duration.

Changing CVs (Parameters)

� ��

Here, you have the possibility of changing

the CVs on certain locomotive decoders.

This is a far-reaching intervention

into the behavior of the decoder and

can lead to the decoder becoming

unusable when incorrect entries

are made.

Please use the instructions for your locomotive

and our extensive help resources

when doing this.

Check

The locomotive is reset

to factory default settings

if this is supported by the

decoder.

Confi rm

!Please note that not every locomotive supports all functions and characteristics. Please refer to the

instructions that came with your locomotive. There you will fi nd information regarding what functions

and characteristics the locomotive‘s decoder supports.

!

Note: Settings for the address (CV 1)

and the number of speed levels (CV 29)

should never be changed using the CV

table. There is a simple programming

maneuver for this on the confi guration

for the locomotive.

The locomotive data are

written to the locomotive

card.

49

Example: Function Mapping

Adding another function

50

confi rm or reject

The data are transferred

only for programmable or

mfx decoders. Decoders

with DIP switches are

only taken into the locomotive

list.

change

select

confi rm

1. Selecting a button 2. Selecting a symbol

selection

3. Adding a function

You can insert, change, or store other functions.

Data are transmitted and the confi guration

mode is closed.

4. Editing a selected function

You can change functions

or assign characteristics

to the functions (dim, blink,

etc.).

5. Storing changes

6. The new function can now be tested.

Functions when the locomotive is stopped or running

Example of an ABV parameter

The newly entered or

changed locomotives

are now ready to be run

with the Central Station.

Here you can set up a function that works when

the locomotive is stopped (S) or is running (F).

Steps 1-6 already explained above are used to

set this function up.

select

select

The CVs selected here are stored

directly in the decoder and directly

infl uence the locomotive's running

characteristics, example: the braking

and acceleration in the area

for a braking module.

Storing changes and

then continuing with

other CV settings or fi -

nishing the process with

the green check mark.

Important Note!

Carry out the function “Shutdown“ before turning the Central Station off, in order to ensure

that all data are saved. If you suddenly turn the Central Station off, you may lose data.

Programming On The Main (POM) ��

Programming On The Main (POM) is a special form of programming in which the locomotive is

programmed while it is running; i.e. the locomotive does not have to be standing on the programming

track and does not have to be stopped. POM must be supported by the decoder being used (see

decoder instructions) and even then only individual settings can be programmed with POM. You can

store and access CV tables specifi c to certain locomotives.

You cannot read out values from the decoder / locomotive with POM.

!

Note: Settings for the address (CV 1) and the

number of speed levels (CV 29) should never

be changed using the CV table. There is a

simple programming maneuver for this on the

confi guration for the locomotive.

Accept locomotive from Locomotive Card

� ��

You can accept locomotives from existing cards or write to a locomotive card.

Read:

Insert the locomotive card as shown into the card reader.

The data are taken into the locomotive list, and you can start.

!Make sure that the chip on the card is facing down.

!Make sure that the chip on the card is facing down.

Write: (only in the confi guration mode)

Insert the locomotive card as shown into the card reader.

Press the symbol. Locomotive data is written to the

locomotive card.

Locomotive data is being transferred to the locomotive card.

51

Entering an M.U. Consist

An m.u. (multiple unit) consists of at least 2 locomotives. You can however also have several

locomotives in a consist. The number of locomotives is limited by the current draw for users in

the power consumption area.

52

!Only locomotives similar to

one another in their running

characteristics should be

used in an m.u. consist.

� ��

Delete existing text.

Enter new name, ex. “Ore Train“.

Add the fi rst locomotive in the m.u. consist.

Go to the next locomotive.

Confi rm entry

Add the locomotive

to the

m.u. consist.

The motive power

consist has been

taken into the

locomotive list.

The m.u. consist is now available for use.

The 2nd controller can now be used for

another locomotive or m.u. consist.

You can process the m.u. consist with this

tool. Add or remove locomotives as in the

2nd step above.

Deleting a Locomotive or M.U. Consist

� ��

The motive power consist can

now be taken into the Control.

�

�

If you have not previously carried

out a data protection procedure

(backup), the data just deleted are

irretrievably lost and can be generated

only by entering and setting

them up again.

The locomotive or m.u. consist

is removed from the locomotive

list and is no longer available for

use. It must be entered again.

!Now and then you should generate a data backup in the menu “setup“. You should always do this

data backup after changes to data. You can then produce the old status from this backup and thereby

have your locomotive list available again.

� ��

Turning off the Central Station:

Go to the “Setup“ menu

before turning the Central

Station off. Select “Shutdown“

and confi rm the selection. The “Stop Button“ will light up

on the controller and the shutdown will begin. The Central Station

can be unplugged when the display goes off. The controller begins

to shut down. As soon as the door on the locomotive shed is

closed, the Central Station can be unplugged.

53

54

Keyboard

��

� ��

� ��

� ��

The Keyboard enables you to control and manage all turnouts, signals, turntables, and transfer tables; a total of 320 or 2,048 addresses are available for use.

Controlling Standard Turnouts and Signals

All addresses for the protocol being used are available immediately after the Central Station has

booted up and can be controlled using the standard control surface (see illustrations).

Tip: We recommend that you set up the solenoid accessories with the symbols and descriptions

that properly go with them in order to have better management of the accessories. See the next

section � Setting up Solenoid Accessories.

Controlling Turnouts and Signals.

The Keyboard has over 20 pages or 128 pages, each with 16 addresses. These addresses

are permanently assigned to the pages and cannot be shifted.

Changing Windows.

Controlling Multiple Position Turnouts and Signals.

oder

Turntable

Keyboard Window 15 is pre-assigned for the 7686 turntable. Please note that the turntable automatically

occupies the 15 following addresses.

You can delete this address assignment if you are not using a digital turntable and thereby free it up for

other solenoid accessories.

��

1

2

� ��

55

��

3

4

5

��

6

56

Selecting the Desired Address

5

�

�

Check the setting

for the turnout

decoder.

5.1

��

5.1

�

� ��

Any programming

of your DCC turnout

decoder must be

done according to the

instructions for that

decoder.

7

9

10

8

Enter a designation,

ex. DSS-9.

Confi rm entry

11

13

14

12

Set the switching duration: We recommend

a duration between 250 - 500 milliseconds.

Confi rm entry

Confi rm or

enter a new

accessory

(starting at

Step � 4)

Checking Accessory Function

15 15.1

If the turnouts/signals are connected to k 83 decoders (item nos. 6083 or 60830) and the turnout/signal

setting does not correspond to the display, then the blue wires for the connection in question must

be swapped.

! If the solenoid accessory does not operate despite the correct

address, please check the wires at the track connection.


Before you turn the Central Station off, perform

the function “Shutdown“ in order to ensure that

all data has been saved. Turning off the Central

Station suddenly may cause loss of the last data

to be changed.

Tip:

Basically, the addresses for the decoders can be used in mixed operation. You can decide by address

which protocol will be assigned to the latter and which protocol will be supported by the decoder.

You can thus use the Märklin professional quality color light signals in DCC operation also.

57

Programming Professional Quality Color Light Signals.

! No locomotives may be run during the programming procedure. Please note that the

programming procedure will be stopped if there are no entries made within 30 seconds.

Set up on your Keyboard beforehand the signals to be programmed as described in Steps 1-13.

Enter the switching time at 1,000 milliseconds for the programming procedure. Now click on this

symbol and confi rm the messages that come afterward.

Press the “Stop“ button in order to interrupt the current and connect the signal to the main track or

to the programming track. Make sure that the wire bracket (programming bracket) surrounded with

cardstock is clipped onto the underside of the decoder. Turn the current back on by pressing the

“Stop“ button again.

Changing signal aspects will now blink in the active programming mode. Now press the signal

image for the professional quality color light signal set up on the Keyboard on the Central Station.

76391 Hp1

76395

58

�

or

76371 Sh1

76392 Sh1

The programming is now complete for a signal with 2 aspects. The remainder of the process can be

found further down in the text.

�

With a signal with more than 2 aspects other signal aspects will alternately blink.

The individual steps for these signals can be found in examples further down in the text.

76394 Hp1/Sh1

�

�

76393 Hp1/Hp2

76397

If a distant signal is mounted on the mast of a home signal, this distant signal must now also be

programmed.

Now wait until only the

distant signal is blinking.

Then activate the home

Hp1

�

Hp1/Hp2

signal to which the distant

signal is assigned.

�

If the signal begins to switch between the signal aspects, the programming procedure is completed.

Now press the “Stop“ button. The programming bracket can now be removed. Then press “Stop“ again.

The Central Station is now ready to be operated again.

!Keep the programming bracket; it will be needed in the future for address changes.

��

Switch to the confi guration mode. Now, change the switching duration to 250 milliseconds (Step 12). This

is a long enough time for ordinary operation. Change to the operating mode and check to make sure all of

the functions of the signal just programmed are working correctly. If necessary, repeat the programming

procedure.

Hp2

�

�

�

�

�

Layout

��

59

Button

60

� ��

Setting up a Layout.

The Layout level of control on the Central Station simplifi es setting up and operating solenoid accessories and routes on a model railroad later on. After a Layout has been set up, turnouts, signals,

or routes can be activated by pressing on a symbol. Several Layout pages can be constructed in a Central Station.

We recommend that you set up the appropriate items on your keyboard before setting up the Layouts page.

Symbol:

Route

Symbol:

Go to the next page

Designation Field Keypad

Keypad

Save

Exit

without

Saving

Confi rm

and

Save

A complete description of the symbols is available in our Help function.

Symbols:

Track and Solenoid Accessories

Delete in Track Diagram

Information about the Solenoid

Accessory to be Used

Rotate the Symbol

Help Function

Symbol for

Contact (S 88)

Add a symbol.

Select and

add a new

symbol.

Select and mark

a symbol.

Select and confi rm a

turnout.

Ex. Three-way Turnout

238 from Route Exit N1.

Delete

symbol

Touch the symbol repeatedly

until its position corresponds

to the track plan.

Rotate

symbol

Information about

solenoid accessory

and change.

Select the symbol “Rotate“.

Place additional

symbols according to

the track plan.

Adding a Route:

In our example there is only

1 route available for use.

If several routes are available,

then the desired route can be

selected with the arrow button.

Confi rm selection.

The route has been added.

The signal has

been added.

Select signal from the

solenoid accessories

as before.

61

62

An S 88 contact has been

placed in the Layout.

Including this contact in the

track diagram also allows it

to be activated manually.

If the route is also to be operated by

means of an S 88 contact, the latter

can also be placed in the Layout.

Confi rm selection

Attach a name to the route

(Layout page) with the keypad

and then confi rm.

�

Controlling Accessories with the Layout.

�

Enter the name into the track diagram, example: Track 1

Confi rm and save completed

route.

After you have set up your Layout (track diagram) you can control individual solenoid accessories

or complete routes by touching the symbols. You can identify the status of particular solenoid

accessories from the track diagram.


Before you turn the Central Station off, perform the function “Shutdown“ in order to

ensure that all data has been saved. Data may be lost, when the Central Station is

suddenly turned off.

Memory

��

63

Setting up a Route. � ��

The “Memory“ part of the Central Station is used to set up and operate routes on a model railroad. Sixteen Memory windows are available for this function.

We recommend that you set up the appropriate items on your Memorys before setting up the Layouts page.

Routes are used so that you can activate several solenoid accessories with the press of a single button. With automatic controls

routes are combined with contacts on a model railroad layout in order to control certain processes on a model railroad automatically.

Examples of this are block controls and staging yard controls. More information about this can be found in the Help function.

64

Route Set Up Route Open

Route

Designation

Keypad

S 88

Contact

Save

Exit

without

Saving

Exit


Save

Display for

the Turnouts,

Signals, and

Routes Selected.

Manual and

Automatic Operation

or

Manual Operation.

Delete a selected

element.

Tip: Enter clear, short names;

divide your yard or station into

North-South or right-left for

example. These names can only

be used once.

Example:

Exit N1 = Exit North Track 1

Enter the name of the

route with the keypad.

Confi rm

Switch to the Keyboard.

Existing routes can be

integrated into a route.

Routes can be activated directly by

a train by means of an S 88 decoder.

To do this, the appropriate contact

output must be entered in the fi eld

for the S 88.

Add a solenoid accessory

to the route.

You can add the solenoid

accessories from different

keyboards to a route.

You do not have to adhere

to an obligatory sequence.

Unclear or in doubt?

Use the “?“, our help function.

End the setting up of the route and

save it or save with and design a new

route.

Controlling a Route.

Deleting a Route.

Start the route.

The route is now in the operation mode.

The route is now

in operation.

You can deactivate solenoid accessories

individually or you can deactivate the route

by deleting all of the elements and changing

the name to the basic setting (ex. A5).


Before you turn the Central Station off, perform the function “Shutdown“ in order

to ensure that all data has been saved. Data may be lost, when the Central Station

is suddenly turned off.

65

66

Setup

��

Setup allows you to adjust the reproduction of data, backup of data, update, reboot, shut down, calibrating, and settings for the Central Station.

Setup

� ��

Switch to the processing mode.

Possible Settings for the Central Station

This Central Station is activated

as the main controller.

This Central Station is being used

as a second or auxiliary controller.

The Central Station can be used

alone or in conjunction with several

Central Stations. When you are using

several Central Stations, one must be

used as the main controller and the

others may only be used as auxiliary

controllers.

After you have stored the setting in memory as a 2nd or auxiliary controller, you can determine

here whether the two controllers are supposed to be synchronized with the master Central Station.

You do this by calling up the menu “CS“ here. After you have determined whether synchronization

has to be done or not, store the setting again in memory.

If the Master/Slave connection is broken and the CS is deactivated as a 2nd or auxiliary controller,

the original data for the CS will be present again.

Sx

USB

60173

Aux

B 0 B 0

B 0 B 0

prog

Here, you can connect the Central

Station to a computer network.

More information about this

can be found with our help “?“.

power

2nd Central Station

60123 Slave cable (Not included with a Central Station).

Sx

USB

60173

Aux

B 0 B 0

B 0 B 0

The locomotive list must be set up again in the 2nd Central Station.

prog

power

1st Central Station

This menu can be used to adapt the Central

Station to your personal needs.

For example: speed indicator, status inquiry,

mouse pointer, function icon color, and

language.

67

Mobile Station 60652

After you have plugged the Mobile Station in,

it will register itself automatically. After the

registration procedure is over, locomotives

can be added to or removed from this Mobile

Station. Up to 10 locomotives can be assigned

to the Mobile Station.

Mobile Station 60653

See manual of the mobile station 60653


Information

about your


is displayed

here.

It is not possible

to make a manual

change.

68

save and process

further

exit without saving

save


exit

Information about Devices Connected

to the Central Station

Selection

You can get information about

current, voltage, and temperature

for the Booster or 2nd controller

that you have selected.

Information about a

60174 Booster

! The 6015/6017 Booster

cannot be displayed.

Information about

a Central Station

System Architecture

60061/60101

60213/60214/60215

60213/60214/60215

60061/60101

60061/60101

69

Wireless drive and control is possible with the iPod Touch ®, iPhone ® or iPad ® with a Memory => 32 GB and a wireless router.

How does this work? Get yourself the “Märklin Mobile Station” App (English abbreviation for application) in the App StoreSM and install this application on your controller.

Then connect your Central Station to your WLAN router.

70

LAN WLAN

Router

Apple, the Apple logo, iPhone and iPod touch are

trade marks of Apple Inc., registered in the U.S. and

other countries.

App Store is a service mark of Apple Inc.

Appendix:

Available Symbols

Blank

End light(s)

Interior lighting

Marker light(s)

Long distance headlight(s)

Sound

Pantograph

Smoke

Switching range

Telex coupler at both ends

Horn

Conductor‘s whistle

Bell

Raise/lower

Turn left

Turn right

Crane

Raise/lower crane boom

Acceleration/braking delay

Pump

Brake squealing

Relay steps

Generator

Operating sounds

Motor

Station announcement(s)

Coal being shoveled

Doors being closed

Doors being opened

Blower motor(s)


Fire box

Interior lighting

Table lamps Era IV

Table lamps Era III

Table lamps Era II

Grate being shaken

Rail joints sounds

Number board

Operating sounds

Destination sign

Front cab

Rear cab

Couplers engaging

Buffer impact

Train announcement(s)

Crane hook

Warning light

Cab lighting

Compressed air

Rear Telex coupler

Front Telex coupler

Rear pantograph

Front pantograph

Rear headlight(s)

Front headlight(s)

Raise


Running gear lights

Blowing out the cylinders

Magnet

Up

Down

Left

Right

instead of symbol
















71

Gebr. Märklin & Cie. GmbH

Stuttgarter Straße 55-57

73033 Göppingen

Deutschland

www.maerklin.com

169625/0211/Ha1Gm

Änderungen vorbehalten

© by Gebr. Märklin & Cie. GmbH

Getting Set Up and Started

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
