2012 CATALOGUE

for a closer look log on to www.maxxis.co.uk

2 0 1 2 C A T A L O G U E

Lifetime

Guarantee

2


companyprofile

Founded in 1967, Maxxis has grown to become one of the largest and most

respected tyre manufacturers in the world. Building on its core beliefs of

working with its partners to deliver 100% Quality, 100% Trust and 100%

Service, Maxxis is now a world-class tyre manufacturer operating from state

of the art R&D and production facilities, producing in excess of 1,000,000

tyres and tubes per day, with a turnover exceeding $3.2 billion (2010).

2 0 1 2 C A T A L O G U E

lifetimeguarantee

Maxxis product has a pedigree born out of its strength in research and

development. A superior product at value for money prices, offering not only

a great margin opportunity, but peace of mind for customers in the shape of

a product guarantee – an unbeatable, comprehensive product proposition.

For terms of the guarantee visit

www.maxxis.co.uk/lifetime-guarantee

C A R

PRO R1 5

MAZ1 6

MAZ4S 7

i-PRO 7

M35 8

M36 8

MA510 9

MAPW 10

MAP1 11

MAV1 12

MAE1 13

MA501 13

MA651 13

UA603 13

MA307 14

MA701 14

MA702 14

MS300 15

MAT1 16

MA656 17

4 X 4

MARAUDER 2 MAS2 18

MARAUDER 1 MAS1 19

BRAVO HP600 22

BRAVO HT750 23

BRAVO HT770 23

BRAVO A/T 771 24

BRAVO MA751 25

BRAVO MA761 26

BUCKSHOT MT754 27

BIGHORN MT762 29

TREPADOR M8060 30

V A N / T R U C K

UE100 31

UE103 31

UE168 31

T A X I

DN851 31

A T V

WILDCAT 34

SUR TRAK 34

STREETMAXX 33

RUBICON 33

iRAZR 35

RAZR2 35

T U R F

C165 Kevlar® 36

C165 36

C190 37

C769 37

T R A I L E R

TRAILERMAXX CR966 32

C352 32

C824 32

C834 32

CR867 32

CR965 32

M8001 32

UE168 32

UN999 32

Lifetime

Guarantee

195/60 R15 88V

205/60 R16 92V

205/50 ZR16 91W XL

225/55 ZR16 99W XL

205/50 ZR17 93W XL

205/45 ZR17 88W XL

225/55 ZR17 101W XL

225/50 ZR17 98W XL

225/45 ZR17 94W XL

235/45 ZR17 97W XL

225/45 ZR18 95W XL

225/40 ZR18 92W XL

235/50 ZR18 101W XL

235/45 ZR18 98W XL

235/40 ZR18 95W XL

245/50 ZR18 104W XL

245/45 ZR18 100W XL

245/40 ZR18 97W XL

245/45 ZR19 102W XL

245/35 ZR19 93W XL

C A R PRO R1

2 0 1 2 C A T A L O G U E

• Special tread

compound improves wet grip

and reduces fuel consumption

•

technology delivers extended

tyre life

• Extra strength sidewall design

gives outstanding handling

and stability

• Optimised tread block and sipe

arrangement promotes reduced

tyre noise

5

6

• All-season UHP tyre with

aggressive unidirectional

tread design

• Excellent cornering and

handling from a high bead filler

and stiff shoulder blocks

• Advanced silica compound for

improving wet and dry traction

and rolling resistance giving

better mpg

• Specially designed high

rim protector

175/50 R13 76V XL

195/45 R15 78V

205/50 R15 89V XL

195/55 R16 91H XL

195/55 R16 91V XL

195/45 R16 84V XL

205/55 ZR16 91W

215/55 ZR16 97W XL

215/40 ZR16 86W XL

225/50 ZR16 96W XL

195/45 ZR17 85W XL

225/55 ZR17 102W XL

225/45 ZR17 94W XL

235/45 ZR17 97W XL

235/40 ZR17 94W XL

245/40 ZR17 95W XL

255/45 ZR17 102W XL

255/40 ZR17 98W XL

225/40 ZR18 92W XL

225/35 ZR18 87W XL

C A R MAZ1

2 0 1 2 C A T A L O G U E

235/50 ZR18 101W XL

235/40 ZR18 95W XL

245/45 ZR18 100W XL

255/45 ZR18 103W XL

255/35 ZR18 94W XL

215/35 ZR19 85Y XL

225/35 ZR19 88W XL

235/35 ZR19 91W XL

245/40 ZR19 98W XL

245/35 ZR19 93W XL

255/40 ZR19 100W XL

255/35 ZR19 96W XL

265/30 ZR19 93W XL

275/35 ZR19 100W XL

275/30 ZR19 96W XL

225/35 ZR20 90W XL

245/35 ZR20 95W XL

245/30 ZR20 95W XL

255/35 ZR20 97W XL

285/30 ZR20 95W

185/55 R16 83V MAZ4S

205/50 R16 91V XL MAZ4S

205/45 ZR16 87W XL MAZ4S

215/55 R16 97V XL MAZ4S

225/50 R16 96V XL MAZ4S

195/40 ZR17 81W MAZ4S

205/40 ZR17 84W XL MAZ4S

215/50 ZR17 95W XL MAZ4S

215/45 ZR17 91W XL MAZ4S

215/40 ZR17 87W XL MAZ4S

225/50 ZR17 98W XL MAZ4S

235/55 ZR17 103W MAZ4S

235/50 ZR17 100W MAZ4S

245/45 ZR17 99W XL MAZ4S

215/35 ZR18 84W XL MAZ4S

245/40 ZR18 97W XL MAZ4S

235/40 ZR19 96W XL i-PRO

255/55 ZR19 111W MAZ4S

245/40 ZR20 M+S 99W MAZ4S

275/30 ZR20 97W MAZ4S

C A R MAZ4S/i-PRO

2 0 1 2 C A T A L O G U E

285/50 R20 116V XL MAZ4S

265/35 ZR22 102W XL MAZ4S

285/35 R22 106V MAZ4S

• Unidirectional UHP all-season

tyre with a solid centre rib and

V-shaped aggressive

tread pattern

• Silica rich V-shaped

unidirectional tread pattern with

4 circumferential grooves gives

improved handling on dry and

wet roads

• Multiple snow-biting grooves

and optimal siping design for

great traction on snowy surfaces

• 5-pitch tread blocks and 2-in-1

groove designs minimise noise

for a quiet, comfortable ride

*image shown MAZ4S

7

8

• Unique asymmetrical tread

design combined with an

advanced silica rich compound

deliver an outstanding ultra high

performance summer tyre with

enhanced wet and dry grip

• Continuous outside reinforced

shoulder enhances cornering

stability and reduces noise level

• Optimised tread design with an

enhanced casing construction

gives great handling and a quiet,

comfortable ride

195/50 R15 82V M35

185/50 R16 85V M36

215/60 ZR16 99W XL M36

225/55 ZR16 99W XL M35

225/65 R17 102V M36

225/45 ZR18 95W XL M36

245/45 ZR19 102W XL M36

255/50 ZR19 107W XL M36

275/45 ZR19 108W XL M36

C A R M35/M36 *

2 0 1 2 C A T A L O G U E

*image shown M36

145/60 R13 66T MA510N

185/65 R14 86T MA510

175/65 R15 88H MA510N

185/60 R15 84H MA510

195/55 R15 85H MA510

225/55 R17 97V MA510

C A R MA510/N

2 0 1 2 C A T A L O G U E

• Central tread pattern is

designed with a high-stiff rib to

enhance high speed stability

• Multi-pitch tread delivers a

comfortable ride with low noise

• Large shoulder block design

increases the ground contact

patch to improve handling

performance and stability

• Four wide groove tread design

improves wet handling and

reduces hydroplaning

9

10

• Performance Winter Tyre delivering

the needs of today's high

performance vehicles

• Excellent ice and snow grip

delivered by the innovative

compound and unidirectional tread

• Quiet smooth ride with good

wet grip

• Superior water drainage and

snow removal

C A R /

W I N T E R

145/70 R12 69T

155/80 R13 83T XL

155/70 R13 75T

155/65 R13 73T

165/70 R13 83T XL

165/65 R13 77T

175/70 R13 82T

175/65 R13 80T

155/65 R14 79T

165/70 R14 85T XL

165/65 R14 83T XL

165/60 R14 79T XL

175/80 R14 88T

175/70 R14 84T

175/70 R14 88T XL

175/65 R14 82T

185/70 R14 88T

185/65 R14 86H

185/60 R14 82H

185/55 R14 80H

MAPW

2 0 1 2 C A T A L O G U E

145/65 R15 72T

165/65 R15 81T

175/65 R15 88T XL

175/60 R15 81T

175/55 R15 77T

185/65 R15 88H

185/60 R15 88T

185/55 R15 86H XL

195/65 R15 91H

195/60 R15 88H

195/55 R15 89H XL

195/50 R15 86H XL

205/70 R15 96T

205/65 R15 99H

205/60 R15 95H XL

195/55 R16 87H XL

205/60 R16 96H XL

205/55 R16 94V XL

205/45 R16 87H

215/65 R16 98H

215/60 R16 99H XL

215/55 R16 97H XL

225/55 R16 99H XL

205/50 R17 93V XL

215/50 R17 95H XL

215/45 R17 91V XL

225/50 R17 98H XL

225/45 R17 94V XL

225/40 R18 92V XL

155/65 R13 73T

165/65 R13 M+S 77H

175/70 R13 82H

165/65 R14 M+S 79H

165/60 R14 75H

175/65 R14 82H

185/70 R14 88H

185/65 R14 86H

185/60 R14 82H

195/70 R14 91H

195/65 R14 89H

195/60 R14 86H

135/70 R15 70T

145/65 R15 72T

155/60 R15 74T

165/65 R15 81T

175/65 R15 88T XL

175/60 R15 81H

175/60 R15 81V

175/55 R15 77T

C A R MAP1

2 0 1 2 C A T A L O G U E

185/65 R15 M+S 88H

185/60 R15 M+S 88H

185/55 R15 82V

195/65 R15 91H

195/65 R15 91T

195/60 R15 88H

195/55 R15 85V

205/65 R15 95H

205/60 R15 91H

205/60 R15 91V

205/55 R15 M+S 88V

215/65 R15 96H

195/55 R16 87V

205/55 R16 91V

215/60 R16 M+S 99H XL

225/60 R16 98V

225/55 R16 95V

235/60 R16 100H

235/60 R16 100V

• Outstanding steering response

and handling stability

• Excellent ride comfort with

reduced noise

• Aggressive tread design with

four circumferential grooves

delivers superior water

dispersion and wet traction

11

12

• High Performance All Season tyre

with double steel belted

construction for long life

and uniformity

• Ultra stiff bead filler and solid

centre rib provide excellent

cornering, acceleration

and handling

• Aggressive tread design delivers

excellent water dispensation

• Superior traction from the

specially formulated

tread compound

185/55 R14 80V

165/50 R15 72V

205/55 R16 91H

C A R MAV1

2 0 1 2 C A T A L O G U E

C A R

175/65 R13 80H UA603

175/65 R14 82T MA501N

175/60 R14 79H UA603

185/65 R15 92T UA603

185/55 R15 82H MA501N

195/65 R15 95T XL MAE1

195/65 R15 95H XL UA603

205/70 R15 96H UA603

205/65 R15 94V MA651

215/65 R15 100H XL UA603

215/60 R15 94H UA603

225/60 R15 96V UA603

205/65 R16 95H UA603

205/60 R16 92H UA603

215/60 R16 99V XL MA651

215/55 R16 93V MA651

215/55 R17 94V MA651

215/55 R17 98V XL MA651

UA603/MA651/

MA501/N/MAE1 *

2 0 1 2 C A T A L O G U E

• Performance all-season

radial tyre for use in all

weather conditions

• Advanced computer tread

design delivers excellent high

speed handling

• Low Profile design delivers

superior grip on both wet and

dry roads

• Smooth ride with outstanding

high speed noise level

*image shown UA603

13

14

• Computer optimised tread

design provides a smooth,

quiet ride with excellent

all-weather traction

• Advanced tread compound

delivers long life, with good

grip and braking

• High-strength polyester

casing delivers stability and

durability in all conditions

C A R

155/80 R12 77T MA701

145/80 R13 75T MA701

145/70 R13 71T MA701

155/80 R13 79T MA701

155/70 R13 75T MA701

165/80 R13 83T MA701

165/70 R13 79T MA701

175/70 R13 82T MA701

155/65 R14 75H MA701

165/80 R14 85S MA307

165/70 R14 81T MA701

165/70 R14 85T XL MA701

175/80 R14 88H MA701

175/80 R14 88T MA701

175/70 R14 84H MA701

175/70 R14 84T MA701

175/70 R14 88T XL MA701

185/70 R14 88T MA701

195/70 R14 91T MA701

135/80 R15 73T MA701

MA701/2/MA307 *

2 0 1 2 C A T A L O G U E

165/80 R15 87T MA701

205/65 R15 100T XL MA702

*image shown MA701

195/50 R16 88V XL

215/65 R16 98V

225/60 ZR16 98W

225/50 R17 98V XL

C A R MS300

2 0 1 2 C A T A L O G U E

• All season UHP providing a

unique balance of fuel economy

and a quiet, comfortable ride

• Unique tread pattern design

with four wide primary grooves

and three secondary grooves

plus cap-base construction for

ultimate wet traction and

ride comfort

• Computer-simulated pattern

pitch sequences and block

arrangement minimise impact

and tread noise for the ultimate

in ride comfort

15

16

• Premium touring tyre giving a

smooth ride

• Specially designed compound for

long life

• Multiple grooves for increased

water dissipation and wet

weather handling

• Computer designed tread pattern

delivers low noise

P215/60 R17 BSW M+S 96T

P225/60 R18 BSW M+S 100V

C A R MAT1

2 0 1 2 C A T A L O G U E

215/60 R17 BSW M+S 96H

215/60 R17 96V

225/60 R17 BSW M+S 99H

235/60 R17 BSW M+S 102H

C A R MA656

2 0 1 2 C A T A L O G U E

• All season design with

optimal performance in all


• Multi-block tread design gives

excellent dry and wet cornering

• Optimised tread compound

provides superior mileage with a

quiet, comfortable ride

• Four wide straight groove tread

design and multi-sipe blocks

provide excellent water dispersion

and increased snow traction

17

18

• Performance SUV/LT All Season

Tyre delivering the needs of

today's high performance vehicles

• Precise cornering and

handling stability

• Open shoulder design expels

water under wet conditions to

improve wet weather performance

• Unique tyre structure design

delivers a smooth ride and high

speed durability

225/75 R15 BSW 102H

245/70 R16 BSW 111H XL

265/70 R16 BSW 112H

235/65 R17 BSW 104V

255/65 R17 BSW 110H

265/65 R17 BSW 112H

275/55 R17 BSW 109V

235/60 R18 BSW M+S 107V XL

235/55 R18 BSW 104V

255/55 R18 BSW 109V XL

255/50 R19 BSW 107V XL

285/45 R19 BSW 111V XL

245/45 ZR20 BSW 99W

265/50 R20 BSW 112V XL

275/55 R20 BSW 117V XL

275/45 R20 BSW 111V XL

275/40 ZR20 BSW M+S 106W XL

295/45 R20 BSW 114V XL

295/40 R20 BSW 110V XL

305/45 R22 BSW 118V XL

4 X 4 MARAUDER 2

2 0 1 2 C A T A L O G U E

305/40 R22 BSW 114V XL

305/35 R24 BSW 114V XL

MAS2

225/70 R15 BSW 100H

235/75 R15 BSW 105H

255/60 R15 BSW 102H

265/70 R15 BSW 112S

265/50 R15 BSW 99H

215/70 R16 BSW 100H

215/65 R16 BSW 98H

225/70 R16 BSW 102H

235/70 R16 BSW 105H

255/70 R16 BSW 111H

255/65 R16 BSW 109H

225/55 R17 BSW 97H

255/60 R17 BSW 106H

265/60 R18 BSW 109H

285/60 R18 BSW 116H

285/50 R18 BSW 109H

4 X 4 MARAUDER 1

2 0 1 2 C A T A L O G U E

• All Season SUV/LT designed for

optimum performance in everyday use

• Unique tyre structure design delivers

a smooth ride and high

speed durability

• Unidirectional tread design provides

superior traction and handling

control in wet or snowy conditions

• Two polyester body plies absorb

road shock for a smooth and


MAS1

19

Quick Reference Guide – Cars

Rim Size

OD AR/Width 12 13 14 15 16 17 18 19 20 22

135 80

70

145 80

70

65

60

155 80

70

65

60

165 80

70

65

60

50

175 80

70

65

60

55

50

185 70

65

60

55

50

195 70

65

60

55

50

45

40

205 70

65

60

55

50

45

40

215 45

40

35

MA701

MAPW MA701

MA510N

MA701

MA701

MAPW

MA701

MAPW

MAP1 MA701

MAPW MAPW

MAP1

MAPW

MA701

MAP1

MAP1

MAPW

MAP1

MA701 MA307 MA701

MAP1 MAP1

MAPW MAPW

MAP1

MA701

MAPW

MAPW

MA701

MAPW

MA701

MAP1

MA701

MAPW MAPW

UA603

MAPW

MAZ1

MA701

MAPW

MA501N

MAP1

MAPW

MAV1

MA501N

MAP1

MAPW

UA603

MAP1

MAPW

MA701

MAP1

MAPW

MA510

MAP1

MAPW

MAP1

MAPW

MAV1

MAPW

MAP1

MAPW

UA603

MAP1

MAPW

MA510

MAP1

MAPW

MA501N

MAP1

MAPW

MAP1 MAP1

MA701

MAP1

MAE1

MAP1 MAP1

UA603

MAPW

ProR1

MAPW

MA510

MAP1

MAPW

MAZ1

DN851N

MAZ4S

M36

MAZ1

MAP1

MAPW

MA35

MAPW MS300

UA603

MAPW

MA651

MA702

MAP1

MAPW

MAP1

MAPW

MAZ1

UA603

UA603

ProR1

MAPW

MAP1 MAP1

MAV1

MAZ1

MAPW

MAZ1

MAZ4S

MAZ1 MAZ4S

ProR1 ProR1

MAPW

MAZ4S

MAPW

ProR1

MAZ4S

MAZ4S

MAPW

MAZ1 MAZ4S

MAZ4S

MAZ1

OD AR/Width 12 13 14 15 16 17 18 19 20 22

Rim Size

OD AR/Width 12 13 14 15 16 17 18 19 20 22

215 65

60

55

50

225 65

60

55

50

45

40

35

235 60

55

50

45

40

35

245 50

45

40

35

30

255 55

50

45

40

35

265 35

30

275 45

35

30

285 50

35

30

MAP1

UA603 MS300

MAPW

UA603

M36

MA651

MAP1

MAPW

MA651

MAZ4S

MAZ1

MAPW

M35

MAP1

ProR1

MAPW

MAZ1

MAZ4S

MA656

MAT1

MA651

MAZ4S

MAPW

M36

UA603 MAP1

MS300 MA656 MAT1

MAP1

MA510

MAZ1

ProR1

MAZ4S

MS300

ProR1

MAPW

MAZ1

ProR1

MAPW

MA656

MAZ4S

MAZ4S

MAZ1

M36

ProR1

MAZ1

ProR1

MAPW

MAZ1

ProR1 ProR1

MAZ1 MAZ1 MAZ1

MAZ1

ProR1

MAZ1

ProR1

ProR1

i-PRO

MAZ1

MAZ4S MAZ1

ProR1

M36

ProR1

MAZ1

MAZ4S

ProR1 MAZ1 MAZ4S

MAZ1 MAZ1

MAZ1

ProR1

MAZ4S

M36

MAZ1 MAZ1

MAZ1

MAZ1

MAZ1 MAZ1 MAZ1

MAZ1

M36

MAZ1

MAZ1 MAZ4S

MAZ1

OD AR/Width 12 13 14 15 16 17 18 19 20 22

Quick Reference Guide – Vans

MAZ4S

Rim Size

OD AR/Width 12 13 14 15 16

155

165 70

175

185

UE168 UE168

UE168

UE103

UE168

UE168 UE168

UE100 UE168N

OD AR/Width 12 13 14 15 16

MAZ4S

MAZ4S

Rim Size

OD AR/Width 12 13 14 15 16

185 75

195 70

65

60

205 75

65

215 75

70

65

60

225 75

70

65

235 65

UE168

UE103

UE168N

UE168N

Quick Reference Guide – 4x4

195 80

205 75

70

215 85

80

70

65

225 75

70

65

60

55

235 85

75

70

65

60

55

50

UE168N

UE103

UE103

UE168N

UE103

UE168N

UE103

UE103

UE168N

OD AR/Width 12 13 14 15 16

UE103

UE103

Rim Size

OD AR/Width 15 16 17 18 19 20 22 24

MA751

AT771

AT771

M8060

MA761

M8060

MA751

MA751

AT771

MAS2

AT771

MAS1

AT771

AT771

MAS1

MAS1

AT771

MT754

AT771

HT750

MAS1

AT771 HP600

AT771

AT771

MT754

AT771

M8060

MAS1

MT754

AT771

MAS1

AT771 MASUW

MAS1

HT770

HP600

HT770

AT771

MAS2

HP600

AT771 MAS2

MAS2

HP600

UE103

OD AR/Width 15 16 17 18 19 20 22 24

245 75

70

65

45

255 70

65

60

55

50

265 75

70

65

60

50

275 65

55

45

40

285 65

60

55

50

45

295 45

40

30 9.5

305 55

45

40

35

31 10.5

32 11.5

33 12.5

35 12.5

37 12.5

Rim Size

OD AR/Width 15 16 17 18 19 20 22 24

AT771

MT754

AT771

MAS2

AT771 AT771

MAS1

MAS1

AT771

MAS1

HT770

MAS1

AT771

M8060

MA761

MT754

MT762

AT771

M8060

MA761

MT754

MT762

MA761

MT754

MT762

AT771

M8060

MA761

MT754

MT762

AT771

M8060

MT754

MT762

AT771

MAS1

AT771

MT754

AT771

MAS2

AT771

AT771

AT771

AT771

MAS2

HT770

MAS1

AT771

MT754

AT771

MAS2

MAS2

M8060 M8060

MT762

AT771

AT771

MAS2

AT771

HT770

MAS1

AT771 AT771

M8060

AT771

MAS1

MAS1

MAS2

MAS2

MAS2

MAS2

AT771

MAS2

MAS2

MAS2

AT771

MAS2

MAS2

AT771

MAS2

MAS2

MAS2

OD AR/Width 15 16 17 18 19 20 22 24

22

• Multi-pitch design for a

smooth quiet ride

• Jointless spiral-wrapped full

nylon cap for added strength

and stability

• Stronger sidewall stiffness for

handling and corner stability

• Innovative tread compound

promotes outstanding wet/dry

traction and comfort

4 X 4 / S U V BRAVO

235/70 R17 BSW 111H XL

225/65 R18 BSW 103H

225/55 R18 BSW 98V

235/50 R18 BSW 101V XL

HP600

2 0 1 2 C A T A L O G U E

265/50 R15 99H HT770

225/70 R16 OWL M+S 103T HT750

235/75 R17 OWL M+S 109S HT770

235/70 R17 OWL M+S 111S HT770

255/60 R17 110T HT770

265/60 R18 OWL M+S 114H HT770

4 X 4 BRAVO *

HT770/HT750

2 0 1 2 C A T A L O G U E

• Specially designed premium all-season

tyre for modern SUVs and light trucks

• Advanced closed shoulder design and

multi-pitch tread block technology to

reduce road noise and provide a


• Reinforced casing design stabilises

vehicles under strong cross-winds

and also provides confidence under

braking, especially when

hauling or towing

• Excellent traction and handling on

wet and snowy road surfaces

*image shown HT770

23

24

• Modern tread pattern and

sidewall lug design offers

excellent all-terrain traction

• Stiff but comformable

carcass improves off-road

stability and handling

• Compound and pattern

design improve tread wear,

wet traction and

hydroplaning resistance

• Rim protector

30x9.5 R15LT OWL 104S 6PR

31x10.5 R15LT OWL 109S 6PR

33x12.5 R15LT 108S 6PR

35x12.5 R15LT 113Q 6PR

205/75 R15 OWL M+S 97T

205/70 R15 OWL M+S 96T

225/75 R15 M+S 102S

225/70 R15 M+S 100S

LT235/75 R15 OWL 104/101S 6PR

235/75 R15 OWL M+S 109S

255/70 R15 OWL M+S 108T

265/70 R15 M+S 112S

LT215/85 R16 115/112R 10PR

215/70 R16 OWL M+S 100T

225/75 R16 M+S 108S

LT225/75 R16 OWL 115/112Q 10PR

LT225/70 R16 OWL 102/99S 6PR

LT235/85 R16 120/116S 10PR

235/70 R16 OWL M+S 106T

235/60 R16 BSW M+S 104H

4 X 4 BRAVO A/T

771

2 0 1 2 C A T A L O G U E

245/75 R16 111S

LT245/75 R16 OWL 120/116Q 10PR

245/70 R16 OWL M+S 107T

255/70 R16 OWL M+S 111T

255/65 R16 OWL M+S 109T

265/75 R16 116T

LT265/75 R16 OWL 123/120Q 10PR

265/70 R16 OWL M+S 112T

LT265/70 R16 OWL 117/114S 8PR

LT225/75 R17 116/113Q 10PR

225/65 R17 OWL M+S 102T

225/60 R17 103T

235/65 R17 OWL M+S 104T

245/70 R17 M+S 110S

245/65 R17 OWL M+S 111S XL

255/70 R17 OWL M+S 112S

255/65 R17 BSW M+S 110H

265/70 R17 M+S 115S

LT265/70 R17 OWL 121/118R 10PR

265/65 R17 OWL M+S 112T

275/65 R17 OWL M+S 115T

255/60 R18 M+S 112H

255/55 R18 M+S 109H

265/65 R18 114S

275/65 R18 M+S 116S

LT275/65 R18 OWL 123/120S 10PR

LT285/65 R18 OWL 125/122R 10PR

275/55 R20 117T

LT285/55 R20 122/119S 10PR

LT305/55 R20 OWL 121/118S 10PR

195/80 R15 BSW M+S 96S

215/80 R15 RWL M+S 102Q

205 R16C BSW M+S 110/108Q 8PR

4 X 4 BRAVO

MA751

2 0 1 2 C A T A L O G U E

• Designed for all terrain (A/T) service

• Large tread block design provides

aggressive traction and rugged

off-road performance

• Premium rubber compound delivers

high mileage and superb handling

• Abrasion resistant sidewall adds

excellent durability and longer life

25

26

• Designed for all terrain (A/T) service

• Tread with stud pin hole for ice and

snow service

• Premium rubber compound delivers

excellent mileage and tread life

• Carcass with 3 plies (Triple Shield

Protector) for 8PR and 10PR tyres

30x9.5 R15LT OWL M+S 104S 6PR

31x10.5 R15LT OWL M+S 109S 6PR

32x11.5 R15LT OWL M+S 113S 6PR

33x12.5 R15LT OWL M+S 108S 6PR

205/70 R15C BSW M+S 106/104Q 8PR

4 X 4 BRAVO

MA761

2 0 1 2 C A T A L O G U E

30x9.5 R15LT OWL M+S 104Q 6PR

31x10.5 R15LT OWL M+S 109Q 6PR

32x11.5 R15LT OWL M+S 113Q 6PR

33x12.5 R15LT OWL M+S 108Q 6PR

35x12.5 R15LT OWL M+S 113Q 6PR

LT235/75 R15 OWL M+S 104/101Q 6PR

LT225/75 R16 OWL M+S 115/112Q 10PR

LT235/85 R16 OWL M+S 120/116N 10PR

LT245/75 R16 OWL M+S 120/116N 10PR

LT265/75 R16 OWL M+S 123/120M 10PR

LT265/70 R17 OWL M+S 119/116Q 8PR

4 X 4 BUCKSHOT

2 0 1 2 C A T A L O G U E

• Extremely aggressive 4x4

pattern designed for mud terrain

(M/T) service, pinned for studs

• Extra strong, durable casing

helps resist punctures

and abrasions

• Unique self-cleaning lugs for

maximum traction at all times

• Premium rubber compound

with tread siping delivers

maximum control in various


MT754

27

BIGHORN

a tough tyre that’s thick skinned

They say that beauty is only skin deep, but it’s what lies under the

surface which is the true beauty. The Maxxis Bighorn comes in 8

or 10 ply tyre with . The layers of ply prevent the rubber

stretching under pressure while the enhanced sidewall

construction helps resist punctures and delivers a really

durable performer ... More than meets the eye


Maxxis International UK Carr Road, Felixstowe, Suffolk, England IP11 3RX

BIGHORN

30x9.5 R15LT OWL M+S 104Q 6PR

31x10.5 R15LT OWL M+S 109Q 6PR

32x11.5 R15LT OWL M+S 113Q 6PR

33x12.5 R15LT RWL M+S 108Q 6PR

35x12.5 R15LT OWL M+S 113Q 6PR

35x12.5 R17LT OWL M+S 119Q 8PR

4 X 4 BIGHORN

MT762

2 0 1 2 C A T A L O G U E

• Radial 4x4 with a wide footprint

designed for mud terrain (M/T)

service, pinned for studs

• Extra large staggered shoulder

lugs for added traction in

uneven terrain

• Enhanced puncture resistance

from a strong and tough casing

• A smooth ride on the road, with

off-road grip when you need it

29

30

• Extreme Off-Road Specialist Tyre

• Unique tread element arrangement

ensures a uniform tread contact area

• Multi-stage staggered shoulder

pattern provides improved control

even on the most difficult off-road

and rocky terrain

• Nylon belt-reinforced tyre

construction improves puncture

resistance and prolongs tread life

30x9.50 R15LT BSW M+S 104Q 6PR

31x10.50 R15LT BSW M+S 109Q 6PR

33x12.5 R15LT 108Q 6PR

35x12.50 R15LT BSW M+S 113Q 6PR

205/70 R15C BSW M+S 104/102Q 6PR

LT235/75 R15 BSW M+S 104/101Q 6PR

35x12.50 R16LT BSW M+S 121Q 8PR

205 R16C BSW M+S 110/108Q 8PR

35x12.50 R17LT BSW M+S 119Q 8PR

37x12.50 R17LT BSW M+S 124Q 8PR

4 X 4 TREPADOR

M8060

2 0 1 2 C A T A L O G U E

V A N /

T R U C K

Black Cab - Taxi Tyre

175 R16C M+S 98/96Q 6PR DN851N

Van Tyres

155 R12C 88/86N 8PR UE168

155 R13C 91/89N 8PR UE168

165 R13LT M+S 94/92N 8PR UE168

175 R13C 97/95N 8PR UE168

185 R13C 100/98N 8PR UE100

165 R14C 97/95N 8PR UE168

165/70 R14C 89/87R 6PR UE103

175 R14C 99/98N 8PR UE168

195 R14C 106/104R 8PR UE168

185 R15C 103/102Q 8PR UE168N

195/70 R15C 104/102R 8PR UE103

205/65 R15C 102/100T 6PR UE103

215/70 R15C 109/107R 8PR UE168N

225/70 R15C 112/110R 8PR UE168N

185/75 R16C 104/102Q 8PR UE168N

195/65 R16C 104/102T 8PR UE103

195/60 R16C 99/97T 6PR UE103

UE103/UE168N/

DN851N/UE100 *

2 0 1 2 C A T A L O G U E

205/75 R16C 110/108R 8PR UE168N

205/75 R16C 113/111R 10PR UE168N

205/65 R16C 107/105T 8PR UE103

215/75 R16C 113/111R 8PR UE168N

215/65 R16C 109/107T 8PR UE103

215/60 R16C 103/101T 6PR UE103

225/75 R16C 116/114Q 8PR UE168N

225/65 R16C 112/110R 8PR UE103

235/65 R16C 115/113T 8PR UE103

• Commercial van tyre offers the

ideal balance of safety

and durability

• Deep rib tread design provides

excellent driving stability,

outstanding water drainage,

smooth ride comfort and low

noise level

• Premium tread compound

increases tread life by increasing

abrasion resistance

• High tensile strength steel-belted

construction reinforces

puncture resistance and extends

tyre life

*image shown UE103

31

32

• Commercial van tyre offers the

ideal balance of safety

and durability

• Deep rib tread design provides

excellent driving stability,

outstanding water drainage,

smooth ride comfort and low

noise level

• Premium tread compound

increases tread life by

increasing abrasion resistance

• High tensile strength steelbelted

construction reinforces

puncture resistance and

extends tyre life

T R A I L E R

16.5/650-8 72M C834

18.5/8.5-8 78M C834

600/9 C352

500/10 8PR C824

20.5/800-10 90M 8PR C834

145/R10 74N CR966

145/R10 82/84N CR966

195/50 B10 M8001

195/55 R10C 98P CR966

225/55 R10C 104/102N CR966

140/70 R12 86J UN999

155/70 R12C 104N UE168

185/60 R12C 104/101N CR966

195/60 R12 104/102N CR966

225/55 R12C 104/102N CR966

195/50 R13C 104N CR966

185/65 R14 93/91N CR965

185/R14 104/102N CR867

195/70 R14 96N CR966

TRAILERMAXX *

CR966/C352/C824/C834/CR867/CR965/

M8001/UE168/UN999

2 0 1 2 C A T A L O G U E

*image shown CR966

A T V STREETMAXX

A T V RUBICON

2 0 1 2 C A T A L O G U E

M983

• Specifically designed for road use

• Superb grip on tarmac with great braking

performance in both wet and dry conditions

• E-marked street legal quad tyres

• Speed index rating N (86mph/140kph)

C9272/3

165/70-10 (20/7-10) 27N C9272

175/70-10 (21/7-10) 42N C9272

19/7-8 20N C9272

185/88-12 (25/8-12) 40N C9272

19/8-8 24N C9273

215/50-9 (20/10-10) 50N C9273

225/40-10 (18/10-10) 32N C9273

255/60-10 (22/10-10) 55N C9273

270/60-12 (25/10-12) 50N C9273

25/1350-9 6PR

25/950-11 6PR

25/950-12 2PR

25/1250-12 2PR

• Oversize conversion tyres for ultimate

performance in arduous conditions while still

using standard rims

• Computer designed tread pattern delivers

maximum performance

• Wide self-cleaning hook and bar tread

design offers plenty of traction and power to

tackle the toughest mud and steepest hills

33

34

• Ideal for local authority and agricultural

machines where road use between sites

is necessary

• Aggressive style lugs for superior traction

• Large range of sizes available

• E-marked street legal

22/8-10 24J

22/11-10 35J

25/13-9 47J

22/11-8 36J

24/9-11 33J

24/8-12 28J

25/11-10 41J

25/10-12 38J

25/8-12 31J

24/8-11 29J

24/10-11 36J

22/11-9 36J

24/11-10 40J

25/12-10 44J

• Multi-directional tread design delivers excellent

traction in mud, snow and sand

• Dual traction lugs channel loose soil away from

the contact patch for optimum grip

• Outside shoulder lugs provide

aggressive side bite

• Durable nylon carcass improves

puncture resistance

• E-marked street legal

22/11-8 36J

22/11-9 36J

25/12-9 44J

22/11-10 35J

23/8-11 26J

24/9-11 33J

25/8-12 31J

25/10-12 38J

WILDCAT C828

A T V

22/7-11 20J

23/8-11 26J

25/12-9 44J

2 0 1 2 C A T A L O G U E

A T V SUR TRAK

24/8-11 29J

24/10-11 36J

24/8-12 28J

C9208

A T V iRAZR

M943/4

A T V RAZR2 M934

21/7 R10 iRAZR Radial M943

22/7-R10 iRAZR Radial M943



2 0 1 2 C A T A L O G U E

20/11-9 6PR RAZR 2 M934

22/11-9 6PR RAZR 2 M934

20/11-10 6PR RAZR 2 M934

22/11-10 6PR RAZR 2 M934

• Radial construction offers a smoother and

more controlled ride by reducing bump

steer and arm fatigue

• Radial construction also reduces the

sidewall tension, allowing a wider contact

patch with the terrain and better

braking performance

• Innovative tread pattern and flat profile

provides excellent braking and

steering response

• Designed for optimum performance in all

MX conditions

• The next generation of the ever popular Maxxis

Razr with a standard 6-ply rating for maximum

puncture resistance

• Aggressive tread pattern for enhanced

cornering ability

• Suitable for all types of cross

country terrain

• Increased lug depth offers increased skid and

traction control

35

36

• OE accredited

• Professional turf tyre developed specifically

for use with the latest technology

• Used by councils and groundscare

contractors, but equally suited to

domestic use

• Hard wearing tread compound offers high

levels of grip without being aggressive to turf

• Kevlar reinforced tread area provides greater

puncture resistance to minimise

machine downtime

• E-market street legal

T U R F

11/400-5 4PR C165 Kevlar

13/500-6 4PR C165

13/500-6 2PR C165

13/650-6 4PR C165

15/600-6 4PR C165

15/600-6 4PR C165 Kevlar

16/650-8 4PR C165S

16/650-8 4PR C165 Kevlar

18/850-8 4PR C165S

18/850-8 6PR C165S Kevlar + SWP

18/950-8 6PR C165S

20/800-8 4PR C165S

20/1000-8 4PR C165S

20/1000-8 6PR C165S Kevlar


20/800-10 4PR C165S Kevlar

20/1000-10 4PR C165S

20/1000-10 4PR C165S Kevlar

23/850-12 4PR C165S

23/1050-12 4PR C165S

C165 (Kevlar ® )

PROFESSIONAL

TURFMAXX C165

2 0 1 2 C A T A L O G U E

23/1050-12 4PR C769 Kevlar


24/850-12 4PR C165S

24/1300-12 6PR C165S

24/1300-12 4PR C165S Kevlar


24/850-14 4PR C165S

29/1200-15 4PR C165S

33/1250-15 4PR C165S

T U R F SMOOTH C190

T U R F C769

410/350-4 4PR C190

8/300-4 4PR C190

9/350-4 4PR C190

9/350-4 4PR C190 Kevlar

410/350-5 4PR C190

12/600-6 2PR C190

13/500-6 4PR C190

13/500-6 4PR C190 Kevlar

13/650-6 4PR C190

13/650-6 4PR C190 Kevlar

18/950-8 2PR C190

2 0 1 2 C A T A L O G U E

31/1350-15 8PR

• Dedicated design to minimise impact on

delicate greens and lawns

• KEVLAR® belted puncture resistant tread

area to minimise machine downtime

• Can also be used as a go kart slick tyre for

maximum grip on tarmac and

concrete surfaces

19/1050-8 4PR C190

20/10-8 4PR M190

20/10-10 4PR M190

• Premium quality grass mower tyre for use on top

quality turf such as golf courses and sports pitches

• The flat tread spreads the weight of the machine

evenly to minimise ground pressure

• Special round shouldered design won't mark the

turf when manoeuvring the machine

37

PRO R1

the secret to consistent grip level

Harnessing nano dispersement technology to combine silica

rich compounds with finely ground, consistently sized carbon

black particles, produces better distribution and bonding with

the rubber. The result is better grip, improved fuel economy

and extended life ... More than meets the eye


Maxxis International UK Carr Road, Felixstowe, Suffolk, England IP11 3RX

PRO R1

orangeengineering

The Maxxis Orange Engineering concept underpins all that we do. It is more than

the technical excellence behind our products, albeit this is impressive enough as

evidenced by the most advanced Research and Development Centres using the most

sophisticated state of the art equipment, in locations across three continents.

It also means the best in raw materials, working with only the most trusted, skilled

and reliable supply partners, having perhaps the industry’s most rigorous quality

control systems and of course a company culture where its employees take a pride

in their company and its products and accept nothing less than the best.

t3businessmodel

On a more defined level Maxxis has adopted a Business model which denotes three

dimensions as intrinsic to the Company’s success, namely 100% Quality, 100%

Service, 100% Trust.

100% Quality. Our products meet and we hope exceed our customers’ expectations.

They are manufactured to exacting standards which are replicated each and every

time such that our customers should expect zero defects.

100% Service. The company is geared to always provide what our customers want

when they want them. To achieve this, the supply and supplier network needs to

operate at optimum efficiency.

100% Trust. As long as the company is successful in achieving its goals of delivering

to its customers, staff and shareholders 100% Quality and 100% Service, then it

can reasonably expect to achieve 100% Trust. We believe our products speak for

themselves and that whether being used by a world class competitor in the sporting

arena or by a mum on the school run, everyone can trust Maxxis products to deliver.

39

2 0 1 2 C A T A L O G U E

Errors and Omissions: Whilst every effort has been made to ensure the accuracy of the information supplied

herein, Maxxis cannot be held responsible for any typographical errors, inaccuracies, or omissions.

Stapleton’s (Tyre Services) Ltd

Fourth Avenue, Letchworth

Garden City, Herts. SG6 2TT

www.stsproftlink.co.uk

phone or fax us..

Tel: +44 (0) 870 60 54321

Fax: +44 (0) 1462 488707

£2.99

email us..

email: sts@stapletons-tyres.co.uk

web: www.stapletons-tyres.co.uk

2012 CATALOGUE - Maxxis Tyres

Transform your PDFs into Flipbooks and boost your revenue!

2012 CATALOGUE - Maxxis Tyres

Transform your PDFs into Flipbooks and boost your revenue!

Delete template?

Save as template ?
