Caravan Season 2010
all-inclusive-
de luxe | excellent | prestige | excelsior | la vitafittings

Caravanning made by Hobby
Caravans have been made in northern Germany
since 1967. Today, HOBBY is the global market
leader – the majority of caravans are made here.
Over the years, people’s holiday habits have
continuously changed. For our designers and
engineers, every year poses a new, exciting challenge
to capture the spirit of the times in terms
of technology and design, making sure that our
customers are what we want them to be: happy!
However, we have always been sure of one thing:
Every caravan has to be as individual as its owner.
We learned that 40 years ago when our founder,
Harald Striewski, built his own caravan for his
family.
At HOBBY, everyone should be able to find
their own personal caravan. That’s the philosophy
behind our brand portfolio and our wide range
of different layouts.
What bed should it be? Where will the children
sleep? Large kitchen, practical washroom?
A seating group area at the rear or the front?
Only you know what is important for you!
Find your dream vehicle and choose your own
personal design from our five model series featuring
34 different layout options. All-inclusive, of
course.
And if you cannot decide straight away – you can
get first-rate advice from your local HOBBY dealer.
HOBBY – your holiday escort.
3

CONTENTS
Living spaces
What Do YoU ValUe?
sleePing
bathroom cooking
liVing
Page 8 Page 14 Page 16 Page 20

Model series
in Which caraVan Do YoU feel best?
De lUXe eXcellent Prestige eXcelsior la Vita
Page 28 Page 32 Page 36 Page 40 Page 44
Overviews
50 Standard fi ttings
56 Optional extra
57 Awnings
58 „Standard fi ttings“ table
60 „Technical data“ table
62 Layouts
CONTENTS

LIVING SPACES
sleePing
Our choice of beds will convince
big and small. Whether it is a
Fixed bed or single beds, here
everyone sleeps well!
Page 8
bathroom
Large washroom, external washroom
or compact washroom –
Hobby has thought up practical
solutions with elegant design and
optimal lighting.
Page 14
cooking
Whether a compact kitchen block
or generous corner kitchen with
long work surfaces – choose your
favourites!
Page 16

liVing
Our living ideas for your caravan
respond to your demands for
more relaxation and leisure time.
Choose for yourself.
Page 20
Experience life – enjoy choice.
Uncompromising freedom. After a restful sleep, start the day relaxed.
Read whenever and wherever you want.
What are we eating today? Exotic recipes or traditional cuisine?
Plenty of space for all the essentials. We leave the non-essentials at home.
Feel safe, secure and comfortable on the road – in one of our 58 models,
which are sure to offer the perfect living space, whatever your needs. Single
bed or double bed, large washroom or compact washroom, circular, central or
side seating group – what is important to you?
See for yourself how your wishes and our solutions merge together to create a
Hobby caravan that matches your lifestyle exactly.
Whether De Luxe, Excellent, Prestige, Excelsior or La Vita – you will find your
personal living space here.
Which model will you choose? Your taste decides.
A holiday, just as you like it! We have the solution.
LIVING SPACES
7

SLEEPING
How do you enjoy sleeping?
la Vita bionda 4 5 5 U f
Fixed bed, crosswise
8
Enjoy the peace and quiet. Sleep very soundly. Wake up and
continue dreaming. Alone, together or with the whole family.
Our selection of beds is just as individual as you are. Do you
enjoy sleeping in comfortable Fixed beds or do you prefer
e Xc e l l e n t 5 4 0 U l
Single beds
practical, single beds? They all have one thing in common:
you will really relax and unwind in them. And that’s what
counts on a good holiday!
De lUXe 560 kmfe
Fixed bed, lengthwise

eXcelsior 650 Uff
Island bed
9
SLEEPING

SLEEPING
10
Prestige 720 Uml
Converted seating area

De lUXe 560 kmfe
Children‘s beds Teddy lamp
Sleeping options
Do you enjoy spending the nicest time of the year with your children?
Or do you enjoy having your grandchildren stop by for a visit? Our children’s bed
options will delight your young ones! Whether it is fixed beds or variable sleeping
options, a wide range of models and combinations provide just the right space for
family and friends.
Under bed storage
11
SLEEPING

SLEEPING
Adream, right down to the details
You will only discover many of the things that make sleeping in a Hobby caravan
more pleasant with time. Tidied away and decorated with a cover during the
day, cosy and comfortable at night – you’re on the right track here. Breathe in the
cool night air through the open roof light or enjoy the darkness of night, even when
the sun is already shining outside.
Thermo roof light Mini-Heki in bedroom
(model-specifi c)
12
Sleep well! Whenever and however you want.
Cover Pleated blind

eXcellent 540 Ul
Bed extension (Optional extra)
13
SLEEPING

BATHROOM
How do you like to shower?
P r e s t i g e 6 5 0 W f U
Rear washroom
14
The day begins in the washroom. What type of washroom do
you want on holiday? Large washroom, external washroom
or compact washroom – Hobby has thought up practical
solutions with elegant design and optimal lighting.
la Vita veneto 5 4 5 k m f
Washroom with separate shower
A cold shower in the morning? A hot shower in the evening?
Shower just the way you like it.
P r e s t i g e 7 2 0 U m l
Side washroom

De lUXe 560 kmfe
External washroom
15
BATHROOM

COOKING
What do you like to cook?
16
Delicious grilled fish or a juicy, succulent steak? Cook
whatever you want to.
Our kitchens offer all the space you need, and to ensure
everything stays exactly where it belongs, we now offer our
new kitchen central locking system.
Prestige 650 WfU
Large corner kitchen
This locks all drawers, so that your cooking utensils remain
securely stored during travel.
So when will your kitchen be earning its first star?
High-quality worktops with a stainless steel combination unit

la Vita bionda 4 5 5 U f
Small side kitchen
17
eXcellent 440 sf
Large side kitchen
COOKING

COOKING
P ractical ideas for great recipes!
For amateur cooks, everything that makes cooking enjoyable is available here!
From the optimal use of storage space for supplies on trips to technical aids such
as a three-ring hob or an optional oven. A large fridge with an ice compartment or
a more practical solution for weekend use? They all have one thing in common: the
kitchens are not just beautiful, they are also practical.
Pull-out storage baskets
18
112 litre fridge

eXcellent 540 Ufe
Kitchen with large fridge 175 litres
19
COOKING

LIVING
How do you like to live?
De lUXe 560 kmfe
Large side seating area
20
Sit down. Put your feet up. Read a good book. You’d rather
play games with the children? Or are friends coming over for
dinner? There’s enough room here!
Round, centre or side seating group? The heart of your
Hobby caravan is as individual as you are. Warm fabric or
eXcellent 410 sfe
Small side seating area
elegant, soft leather – what is important to you?
Our living ideas for your caravan respond to your demands
for more relaxation and leisure time. Choose for yourself.
Prestige 720 Uml
Small central seating area with TV cabinet
eXcelsior 650 Uff
Excelsior circular seating area

Prestige 560 Ufe
Circular seating area
21
LIVING

LIVING
Low wattage ceiling lights, indirect lighting
22

More light please!
The day goes and the evening arrives. To put your leisure time in the right light, we have
installed a modern lighting concept in all models. Unforgettable holiday evenings in an atmospheric
ambience with indirect lighting or an reading lamp – the right light for any time of day.
And when you want to go to sleep? Turn the lights off.
Corner shelving units with lighting Spots as additional lighting Ceiling lights above seating area
23
LIVING

LIVING
L iving details in a mobile design
Column rising table
(model-specifi c)
Caravan furniture should be beautiful – but above all functional! How practical
can a revolving table be? How quickly and securely can the column rising table be
adjusted? Our engineers and designers love good solutions. But one thing applies to
all of them: our living details must fit safely and reliably into the caravan environment.
People are the measure of all things. Whether they are big or small.
But they can both use the colouring board.
24
Rotating table Colouring board under children‘s bed
(model-specifi c)

Illuminated glass cabinet
25
LIVING

MODEL SERIES
D e lU X e
the youthful design with modern
technology and many different
layouts has the holiday solution
to suit every family.
Page 28
up to up to up to up to
e Xc e l l e n t
Prestige
e Xc e l s i o r
a relaxing experience – just as you
expect. Whether you want to enjoy a
weekend break or a six-week holiday.
Page 32
timelessly classic. Decades of experience
result in layouts and detail
solutions that cater to all holiday
requirements.
Page 36
soft fabric or warm leather on request?
Elegant wood design. You can feel your
own life style in every detail.
Page 40

l a V i ta
up to
the Hobby La Vita is our answer to
your needs. Excitingly different and
with a lively design.
Page 44
The Hobby caravan family
– as lovely as your holiday!
Do you like things to be modern? Or do you prefer things to be classic and stylish or luxurious? We
have the model series for all your wishes. Our Hobby caravan family is as varied as your own style.
Every model series has many different layout versions. You decide what is important to you!
Whether for two or for the whole family, for a day or six weeks – every Hobby caravan has its own
unique and strong personality. You will get lots of practical holiday solutions in all Hobby caravans.
But every model series has its own distinctive decor. Let yourself be fascinated and find your very
own caravan.
Your Hobby caravan. As individual as you are.
MODEL SERIES
27

DE LUXE
28
De Luxe
Simply beautiful
No rushing from one appointment to the next. A stopover in Rome? The sun decides whether
we continue driving or not. We have everything that we need on holiday with us. The HOBBY
De Luxe is practical and comfortable. The youthful design with modern technology and many
different layouts has the right holiday solution for every family – making caravanning simple.
Simply beautiful!
De lUXe 560 kmfe

29
DE LUXE

DE LUXE
De lUXe 490 Ul
30

400 sf
490 Ul
fabric
The de Luxe Series in summary
L: 590 cm B: 220 cm
G: 1.100 kg
L: 700 cm B: 230 cm
G: 1.350 kg
Blavand (Standard fi ttings)
440 sf
540 kmfe
L: 626 cm B: 230 cm
G: 1.200 kg
L: 755 cm B: 230 cm
G: 1.500 kg
fabric
455 Uf
540 Ul
Cairo (optional without surcharge)
L: 660 cm B: 230 cm
G: 1.300 kg
L: 738 cm B: 230 cm
G: 1.500 kg
460 lU
560 kmfe
L: 660 cm B: 230 cm
G: 1.300 kg
L: 762 cm B: 250 cm
G: 1.600 kg
Decor
Winchester Cherry / Cappuccino
460 Ufe
L: 660 cm B: 230 cm
G: 1.300 kg
31
DE LUXE

EXCELLENT
32

eXcellent 540 Ufe
Excellent
Better than good.
You know exactly you want. Every year, you look forward to spending your holiday in your
HOBBY Excellent. A relaxing experience – just as you expect. The HOBBY Excellent offers
your family the best concepts, whether you want to enjoy a weekend break or a six-week
holiday. Which of the 21 layouts is yours?
33
EXCELLENT

EXCELLENT
400 sf
460 Ufe
540 WlU
560 Ufe
720 Ukfe
fabric
Sydney
The Excellent Series in summary
L: 590 cm B: 220 cm
G: 1.100 kg
L: 660 cm B: 230 cm
G: 1.300 kg
L: 738 cm B: 230 cm
G: 1.500 kg
L: 757 cm B: 250 cm
G: 1.600 kg
L: 915 cm B: 250 cm
G: 2.000 kg
34
410 sfe
495 Ul
540 Ufe
560 Uff
L: 614 cm B: 230 cm
G: 1.200 kg
L: 709 cm B: 230 cm
G: 1.400 kg
L: 738 cm B: 230 cm
G: 1.500 kg
L: 762 cm B: 250 cm
G: 1.600 kg
440 sf
495 Ufe
540 Uff
560 kmfe
L: 626 cm B: 230 cm
G: 1.200 kg
L: 688 cm B: 230 cm
G: 1.400 kg
L: 738 cm B: 230 cm
G: 1.500 kg
L: 762 cm B: 250 cm
G: 1.600 kg
Decor
440 sfr
540 kmfe
545 kmf
560 WlU
Ariolo Birnbaum / Cappuccino
L: 626 cm B: 230 cm
G: 1.200 kg
L: 755 cm B: 230 cm
G: 1.500 kg
L: 753 cm B: 250 cm
G: 1.600 kg
L: 760 cm B: 250 cm
G: 1.600 kg
455 Uf
540 Ul
560 Ul
650 kmfe
L: 660 cm B: 230 cm
G: 1.300 kg
L: 738 cm B: 230 cm
G: 1.500 kg
L: 757 cm B: 250 cm
G: 1.600 kg
L: 843 cm B: 250 cm
G: 1.900 kg
Dekor
Musterdekor

eXcellent 410 sfe
35
EXCELLENT

PRESTIGE
36
Prestige
Why go without on holiday? You know what is important to you. In the Hobby Prestige, the harmony of
colours and shapes is timeless. Decades of experience result in layouts and detail solutions that cater
to all holiday requirements. Your Hobby Prestige is already a classic today.
What more do you want?
Timelessly classic.
Prestige 560 WlU

37
PRESTIGE

PRESTIGE
Prestige 720 Ukfe
38

The Prestige Series in summary
495 Ufe
560 Ufe
650 Umfe
L: 688 cm B: 230 cm
G: 1.500 kg
L: 757 cm B: 250 cm
G: 1.600 kg
L: 843 cm B: 250 cm
G: 1.900 kg
fabric
Havanna
540 Ul
560 WlU
650 kmfe
L: 738 cm B: 230 cm
G: 1.600 kg
L: 760 cm B: 250 cm
G: 1.600 kg
L: 843 cm B: 250 cm
G: 1.900 kg
540 WlU
610 Ul
720 Ukfe
L: 738 cm B: 230 cm
G: 1.600 kg
L: 810 cm B: 250 cm
G: 1.800 kg
L: 915 cm B: 250 cm
G: 2.000 kg
540 Ufe
650 kfU
720 Uml
L: 738 cm B: 230 cm
G: 1.600 kg
L: 848 cm B: 250 cm
G: 1.900 kg
L: 915 cm B: 250 cm
G: 2.000 kg
Decor
Winchester Cherry / Cappuccino
560 Ul
650 WfU
L: 757 cm B: 250 cm
G: 1.600 kg
L: 843 cm B: 250 cm
G: 1.900 kg
39
PRESTIGE

EXCELSIOR
40

eXcelsior 610 Ul
Fabric: Sahara
Excelsior
Warm leather on request or soft fabric? Elegant wood design. You sense your own lifestyle in
every detail. Generosity is a matter of course for you. Friendship and reliability are very important.
Our Hobby Excelsior is the perfect match for you.
Give your holiday a lifestyle. Yours.
Uniquely individual.
41
EXCELSIOR

EXCELSIOR
The Excelsior Series in summary
560 Ufe
L: 757 cm B: 250 cm
G: 1.600 kg
610 Ul
fabric leather
42
L: 829 cm B: 250 cm
G: 1.900 kg
Sahara Cream white
(special request)
650 Uff
L: 848 cm B: 250 cm
G: 1.900 kg
Decor
Pfaffenberger Mollebusch / Cappuccino

eXcelsior 650 Uff
Fabric: Sahara
43
EXCELSIOR

LA VITA
44
La Vita
Excitingly different.
Life is important to you. Beautiful design expresses your take on life. What caravan could be
a better fit for your lifestyle than our La Vita range? And particularly our latest development:
the La Vita veneto! Through its finely structured shell, silver design, sweeping windows and
alloy wheels, it exudes sporty style. Dynamic. Exciting. Different!
toP: la Vita bionda 560 kmfe
bottom: la Vita veneto 455 Uf
neW moDel
LA VITA veneto

45
LA VITA

LA VITA
la Vita bionda 460 Ufe
46

F eel great as standard
The dynamic exterior finish of the La Vita range is as individually styled as the personal, modern
interiors. Bright and welcoming in the La Vita bionda. Warm and cosy in the new La Vita veneto. Just
climb onboard, kick back, and feel great!
la Vita bionda 495 Ul
Fabric: Havanna
la Vita bionda 455 Uf
Fabric: Riga
47
LA VITA

LA VITA
The La Vita bionda in summary
400 sf
495 Ul
455 Uf
L: 590 cm B: 220 cm
G: 1.100 kg
L: 709 cm B: 230 cm
G: 1.400 kg
L: 660 cm B: 230 cm
G: 1.300 kg
440 sf
545 kmf
460 Ufe
L: 626 cm B: 230 cm
G: 1.200 kg
L: 753 cm B: 250 cm
G: 1.600 kg
The La Vita veneto in summary
fabric la Vita veneto
48
L: 660 cm B: 230 cm
G: 1.300 kg
455 Uf
560 kmfe
495 Ul
Decor la Vita veneto
Sydney Ariolo Birnbaum / Cappuccino
L: 660 cm B: 230 cm
G: 1.300 kg
L: 762 cm B: 250 cm
G: 1.600 kg
L: 709 cm B: 230 cm
G: 1.400 kg
460 Ufe
545 kmf
L: 660 cm B: 230 cm
G: 1.300 kg
L: 753 cm B: 250 cm
G: 1.600 kg
fabric la Vita bionda
Riga Ahorn / Mocca
Decor la Vita bionda

la Vita veneto 545 kmf
49

STANDARD FITTINGS
Lockable service fl ap 13-pin socket (Jäger system) Gas bottle locker THETFORD cassette toilet with electric fl ush
Split entrance door with integrated window,
storage areas and fl yscreen
50
Panoramic front window (model-specifi c)
All inclusive
All windows hinged

Don’t want to go without on your holiday? You don’t need to! Your caravan has everything you need for
a perfect holiday. A Hobby caravan is already fitted with all the extras that are needed for your chosen layout and
model series when it leaves the factory. All-inclusive, of course.
CEE-external socket 230 V
Panoramic side window (540 / 560 / 650 UFf)
Gas regulator with over-pressure
protection (DIN EN 12864)
Awning socket (230 V output, satellite and
TV connection) (model-specifi c)
Single key system for all locks
Integrated awning rail
STANDARD FITTINGS
Fixed fresh water tank with water level sensor
51

STANDARD FITTINGS
Torsion bar spring axle (Porsche system) with longitudinal member technology,
hot galvanized chassis
Wheel shock absorber
52
Anti-snaking coupling and over-run brake system
with automatic reversing device
Integrated trailer nose weight display
(model-specifi c)
Safety jockey wheel with crank handle
Drawbar cover
Tyre repair set (model-specifi c)

Tyre pressure shown on wheel arch cover
Front marker lights
Awning light
Aerodynamic manoeuvering handles
Rear lights with integrated fog lights
STANDARD FITTINGS
Wind-down legs (image shows heavy-load support, model-specifi c)
3rd brake light
53

STANDARD FITTINGS
Sprung mattresses for all L and F beds High-quality fi ttings Kitchen window combi-cassette with pleated fabric and fl yscreen
Rotating media unit, with connection for 15“ fl at screen TV and
LED lighting (model-specifi c)
54
Media sliding unit (model-specifi c)
Ball-bearing guided cutlery drawer

Panoramic thermo roof
light Midi-Heki
Central gas distributor in kitchen area
Mini-Heki thermo roof light in
sleeping (model-specifi c)
Operating panel for lighting system
and tank display
Wardrobe lighting (model-specifi c)
High-quality furniture fi ttings
STANDARD FITTINGS
Electronically regulated power supply
(example assembly)
Oval light above kitchen area, including additional spot lights
(model-specifi c)
55

OPTIONAL EXTRAS
Optional extras
1 2
3
4 5
1 2 3 4 5 6
56
Make a fully-equipped caravan even better. Is that possible? Using our special accessories,
you will find a range of options which allow you to individually adapt your
caravan to meet your specific needs.
Cover Cold-foam mattress Television bracket
Roll-out bed extension Oven Extractor hood
(model-specifi c)
6

1 3
2 4
We have been developing and producing the Nordland awnings for your caravan
for 38 years. Solid and precise quality, the tried-and-tested construction and the
harmonious design to match our Hobby models make these awnings the perfect
complement to your caravan.
1 tegernsee 2 lUgano 3 korfU 4 bUngaloW
awning: all-round roof
awning depth: 240 cm
steel poles: ø 25 mm
awning depth: 240 cm
steel poles: ø 25 mm
awning depth: 280 cm
steel poles: ø 32 mm
Designed by Nordland Zeltfabrik GmbH
sun roof: front wall can be retro-fitted
with mosquito window
awning depth: 240 cm
steel poles: ø 25 mm
awning: with veranda
awning depth: 240 cm
steel poles: ø 32 mm
57
VOORTENTEN
AWNINGS

STANDARD FITTINGS
Chassis & & Sicherheit Safety
Structure/ambience
Aufbau/Ambiente
Kitchen Küche
Bathroom Bad
• Standard fittings + Optional extras – not possible
1 Column rising table
400 SF
De lUXe eXcellent
Feuerverzinktes One-Piece-Chassis, gewichtsoptimiert • • • • • • – – – • • • • • • • • – – –
Feuerverzinktes Leichtbau-Chassis, gewichtsoptimiert – – – – – – • • • – – – – – – – – • • •
Feuerverzinktes Vollrahmen-Chassis – – – – – – – – – – – – – – – – – – – –
Sicherheits-Buglaufrad – – – – – – – – – – – – – – – – – – – –
Sicherheits-Buglaufrad mit integrierter Stützlastanzeige 0,6 kg • • • • • • • • • • • • • • • • • • • •
Ausdrehstützen • • • • • • – – – • • • • • • • • – – –
Schwerlaststützen 1,6 kg + + + + + + • • • + + + + + + + + • • •
Vorbereitung für Truma Mover • • • • • • • • • • • • • • • • • • • •
Reifenreparaturset 2,2 kg • • • • • • • • • • • • • • • • • • • •
Panorama-Bugfenster 1,5 kg – + + + – + – + – – – + + + – + – – + +
Panorama-Seitenfenster 0,5 kg – – – – – – – – – – – – – – – – – – – •
Unteres Kinderbett klappbar 2,0 kg – – – – – – • – • – – – – – – – – • – –
Dekokissen – – – – – – – – – – – – – – – – – – – –
Hochwertiger Teppichboden, herausnehmbar 7,0-10,5 kg + + + + + + + + + • • • • • • • • • • •
Metallhubtischgestell mit Drehtechnik – – • • • • – • • 1 Hot-dip galvanised one-piece-chassis, weight optimised
Hot-dip galvanised lightweight chassis, weight optimised
Hot-dip galvanised frame chassis
Safety jockey wheel with rotating crank
Safety jockey wheel with integrated trailer nose weight display, with rotating crank 0,6 kg
Wind down legs with hand crank
Heavy load support with hand crank 1,6 kg
Preparation for Truma Mover
Tyre repair set 2,2 kg
Panoramic front window 1,5 kg
Panoramic side windows 0,5 kg
Lower folding child bed 2,0 kg
Deco cushions
High-quality carpet, removable 7,0-10,5 kg
Metal rising table frame with wheeled feet
– – – – • • • • • • •
TV TV-Anrichte cupboard bzw. or TV TV-Fach cabinet
– – – • – – – – – – – – – – – – – – – –
Rotating TV / Bar: Drehbarer media unit TV-Schrank with connection mit Anschluss for 15“ flat für screen 15“ Flachbildfernseher TV and LED lighting und LED-Beleuchtung – – – – – – • – • – – – – – • • • • – –
Awning Vorzelt-Außensteckdose external socket (230 (230V-Ausgang, V output, satellite Sat- und and TV- TV Anschluss) connection) 0,4 kg + + + + + + + + + • • • • • • • • • • •
Circumferential Umlaufende Halogenlichtleiste halogen light strip im Bereich in the seating der Sitzgruppe unit area
– – – – – – – – – – – – – – – – – – – –
Corner Eckregale shelving mit integriertem with integrated Beleuchtungsträger lighting
– – • – • • – • • – – – – • • • • – • •
Wardrobe Kleiderschrankbeleuchtung lighting
– – – – – – – – – • • • • • • • • • • •
Thermo Thermo-Dachfenster roof light Midi-Heki Mini-Heki with im integrated Schlafraum sun mit and integriertem midge protection Verdunklungs- blind und Mückenschutzrollo – – – – • • • • • – • – – – • • • • • •
112-Liter-Kühlschrank 112-litre refrigerator with mit large großem freezer Gefrierfach compartment und Beleuchtung and lighting
• • • • • • • • • • • • – • • • • • • •
175-Liter-Kühlschrank 175-litre refrigerator with mit large großem freezer Gefrierfach compartment und Beleuchtung and lighting
– – – – – – – – – – – – • – – – – – – –
Licht-Oval Oval light above über Küchenbereich kitchen area, including inkl. Zusatzspots additional als spots Arbeitslicht as working lights
– – – – – – – – – – – – – – – – – – – –
Küchenleuchte Kitchen light inc. inkl. socket Steckdosen • • • • • • • • • • • • • • • • • • • •
THETFORD-Kassetten-Toilette THETFORD cassette toilet with mit electric elektrischer flush Spülung • • • • • • • • • • • • • • • • • • • •
THETFORD-Drehtoilette THETFORD rotating toilet mit with elektrischer electric flush Spülung – – – – – – – – – – – – – – – – – – – –
Frischwasser-Festtank Fixed fresh water tank mit with Wasserstandsensor, water level sensor, Volumen volume 25 25 l l • • • • • • – – – • • • • • • • • – – –
Frischwasser-Festtank Fixed fresh water tank mit with Wasserstandsensor, water sensor level, Volumen volume 50 50 l l 28 kg + + + + + + • • • + + + + + + + + • • •
Roof Dachhaube light-in im washroom Waschraum • • • • – • – • – • – • • • – • – – • •
Standard fittings all included Chassis & Safety
These features are included as standard
in ALL Hobby caravans
• Hot-dip galvanised torsion bar spring axle with
longitudinal member technology
• Wheel shock absorberr
• Anti-snaking coupling (single lever system) WINTERHOFF WS 3000
• 3rd brake light
• Over-run brake system with automatic reversing device
• Drawbar cover
• Chock
440 SF
455 UF
460 LU
460 UFe
490 UL
Structure/ambience
540 KMFe
540 UL
• High-quality upholstery (Prestige and Excelsion,
incl. deco cushions)
• Panoramic thermo roof light Midi-Heki with
integrated sun and midge protection blind
• THETFORD service flaps with central locking
• High-quality midge protection blind for entrance door
• Interior sprung mattresses for L and F beds
• Raising mechanism for slatted frame (F beds with gasspring
release lever)
560 KMFe
400 SF
410 SFe
440 SF
440 SFr
455 UF
460 UFe
495 UL
495 UFe
540 KMFe
540 UL
540 UFf
• Spots as additional lighting
• Awning light
• Integrated awning rail, both sides
• All windows hinged
• Indirect lighting
• Roof can be walked on
• Entry access step

540 UFe
540 WLU
545 KMF
eXcellent Prestige eXcelsior la Vita veneto la Vita bionda
560 UL
560 UFf
560 UFe
560 WLU
560 KMFe
650 KMFe
720 UKFe
495 UFe
540 UL
540 UFe
540 WLU
560 UL
560 UFe
560 WLU
610 UL
650 UMFe
650 KFU
– – – – – – – – – – – – – – – – – – – – – – – – – – – • • • – • • • • • – –
• • • • • • • • • – • • • • • • • • • • • • – – • • • – – – • – – – – – • •
– – – – – – – – – • – – – – – – – – – – – – • • – – – – – – – – – – – – – –
– – – – – – – – • • – – – – – – – • • • • • • • – • • – – – – – – – – – – –
• • • • • • • • – – • • • • • • • + + + + + + + • + + • • • • • • • • • • •
– – – – – – – – – – • – – – – – – – – – – – – – – – – • • • – • • • • • – –
• • • • • • • • • • + • • • • • • • • • • • • • • • • + + + • + + + + + • •
• – • • • • – • • • • • • – • • – • • • • – • • • • • • • • • • • • • • • •
• • • • • • • • + + • • • • • • • + + + + + + + • + + • • • • • • • • • • •
– • + + + – • – – – – + – • + – • + – • – • + – – + + + – + + – + + – + + –
– – – – • – – – – – – – – – – – – – – – – – – – – – • – – – – – – – – – – –
– – – – – – – • – – – – – – – – – – – • – – – – – – – – – – – – – – – – – •
– – – – – – – – – – • • • • • • • • • • • • • • • • • – – – – – – – – – – –
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • 1 • • • • • 1 • 1 • • • • • • • • • • • • 1 • • • • 1 • 1 • 1 • • • • 1 – – • • • • 1 • 1
– – – – – – – – – – – – – – – – – – • – – – • – – • • – – – – – – – – – – –
• • – – • • • • • • • • • • • • • • – • • • – • • – – – • • – – – – • • – •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
– – – – – – – – – – – – – – – – – – – – – – – – • • • – – – – – – – – – – –
• – – • • • – • • • • • • – • • – • • – • – • • • • • • • • – – – • • • – •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • – • • • – – – • • • •
– • – • • • • • • • • • – • • • • • • • • • – • • • • • • • – • • • • • – •
• – • – – – – – – – – – • – – – – – – – – – • – – – – – – – • – – – – – • –
– – – – – – – – – – • • • • • • • • • • • • • • • • • – – – – – – – – – – –
• • • • • • • • • • – – – – – – – – – – – – – – – – – • • • • • • • • • • •
• – – • • • – • • • • • • – • • – • • • • – • • • • • • • • – • • • • • – •
– • • – – – • – – – – – – • – – • – – – – • – – – – – – – – • – – – – – • –
– – – – – – – – – – • – – – – – – – – – – – – – – – – • • • – • • • • • – –
• • • • • • • • • • + • • • • • • • • • • • • • • • • + + + • + + + + + • •
– • – • • – • – – – – • – • • – • • – • – • • – – • • • – • – • • • – • – –
• Ceiling lights above the seating unit
• Raising mechanism for slatted frame
• Split entrance door with integrated
window and storage areas
• Combi-cassette with integrated midge
protection blind for all windows
Kitchen On-board technology
• Kitchen window combi-cassette with pleated
fabric, midge protection blind
• Stainless-steel combination with basin,
three-flame gas cooker and glass cover
• Ball-bearing guided cutlery drawer
• Fully extractable storage baskets, self-retracting
• Central locking kitchen storage
650 KMFe
650 WFU
720 UML
720 UKFe
• TRUMA gas only heating system with hot-air supply and
12-V blower
• TRUMA 240V electric only heating unit for hot water
supply in kitchen and bathroom (can be upgraded
• Operating panel for lighting system and tank display
• Gas regulator with over-pressure protection
(DIN EN 12 864) and hose line
560 UFe
610 UL
650 UFf
455 UF
460 UFe
495 UL
545 KMF
STANDARD FITTINGS
400 SF
440 SF
455 UF
59
460 UFe
495 UL
545 KMF
• Electronically regulated power supply
• Antenna socket with co-axial cable
• CEE-external socket 230V
• Central gas distributor in kitchen area
• Rollable waste water tank (22 l)
560 KMFe

TECHNICAL DATA
series Model
De lUXe
eXcellent
Prestige
eXcelsior
la Vita
veneto
la Vita
bionda
Overall length
incl. drawbar
cm
Body length
with/without
cylinder box in cm
Interior length
with/without
window bench in cm
Overall width/
interior width
cm
Overall height 1 /
Inside headroom
cm
Circumferential
dimension (awning)
cm
Technically permissible
gross weight 2
kg
Weight in
travel-ready state 3
kg
400 SF 590 470/411 441/405 220/207 259/195 845 1.100 968 1 132
440 SF 626 506/447 477/441 230/217 259/195 880 1.200 1.071 1 129
455 UF 660 540/481 511/475 230/217 260/195 914 1.300 1.098 1 202
460 LU 660 540/481 511/475 230/217 260/195 914 1.300 1.101 1 199
460 UFe 660 540/481 511/475 230/217 260/195 914 1.300 1.120 1 180
490 UL 700 580/520 550/514 230/217 260/195 955 1.350 1.186 1 164
540 KMFe 755 635/576 606/570 230/217 259/195 1.010 1.500 1.337 1 163
540 UL 738 618/559 589/553 230/217 259/195 993 1.500 1.278 1 222
560 KMFe 762 644/585 614/579 250/237 260/195 1.014 1.600 1.425 1 175
400 SF 590 470/411 441/405 220/207 259/195 845 1.100 971 1 129
410 SFe 614 495/435 465/429 230/217 259/195 868 1.200 1.050 1 150
440 SF 626 506/447 477/441 230/217 259/195 880 1.200 1.075 1 125
440 SFr 626 506/447 477/441 230/217 259/195 880 1.200 1.086 1 114
455 UF 660 540/481 511/475 230/217 260/195 914 1.300 1.100 1 200
460 UFe 660 540/481 511/475 230/217 260/195 914 1.300 1.130 1 170
495 UL 709 588/529 559/523 230/217 260/195 964 1.400 1.229 1 171
495 UFe 688 568/509 538/502 230/217 260/195 938 1.400 1.216 1 184
540 KMFe 755 635/576 606/570 230/217 259/195 1.010 1.500 1.348 1 152
540 UL 738 618/559 589/553 230/217 259/195 993 1.500 1.299 1 201
540 UFf 738 618/559 589/553 230/217 259/195 993 1.500 1.275 1 225
540 UFe 738 618/559 589/553 230/217 259/195 993 1.500 1.314 1 186
540 WLU 738 618/559 589/553 230/217 259/195 993 1.500 1.296 1 204
545 KMF 753 635/576 606/570 250/237 260/195 1.010 1.600 1.391 1 209
560 UL 757 639/580 609/574 250/237 260/195 1.014 1.600 1.392 1 208
560 UFf 762 644/585 614/579 250/237 260/195 1.018 1.600 1.383 1 217
560 UFe 757 639/580 609/574 250/237 260/195 1.014 1.600 1.397 1 203
560 WLU 760 642/583 612/577 250/237 260/195 1.018 1.600 1.439 1 161
560 KMFe 762 644/585 614/579 250/237 260/195 1.014 1.600 1.436 1 164
650 KMFe 843 725/666 695/660 250/237 256/195 1.095 1.900 1.587 2 313
720 UKFe 915 795/736 766/730 250/237 259/195 1.170 2.000 1.851 2 149
495 UFe 688 568/509 538/503 230/217 259/195 938 1.500 1.219 1 281
540 UL 738 618/559 589/553 230/217 259/195 993 1.600 1.323 1 277
540 UFe 738 618/559 589/553 230/217 259/195 993 1.600 1.316 1 284
540 WLU 738 618/559 589/553 230/217 259/195 993 1.600 1.311 1 289
560 UL 757 639/580 610/574 250/237 260/195 1.014 1.600 1.417 1 183
560 UFe 757 639/580 610/574 250/237 260/195 1.014 1.600 1.421 1 179
560 WLU 760 642/583 612/577 250/237 260/195 1.018 1.600 1.418 1 182
610 UL 810 692/632 662/626 250/237 256/195 1.052 1.800 1.611 2 189
650 UMFe 843 725/666 695/660 250/237 256/195 1.095 1.900 1.656 2 244
650 KFU 848 730/671 701/665 250/237 256/195 1.095 1.900 1.716 2 184
650 KMFe 843 725/666 695/660 250/237 256/195 1.095 1.900 1.666 2 234
650 WFU 843 725/666 695/660 250/237 256/195 1.095 1.900 1.631 2 269
720 UML 915 795/736 766/730 250/237 259/195 1.170 2.000 1.800 2 200
720 UKFe 915 795/736 766/730 250/237 259/195 1.170 2.000 1.866 2 134
560 UFe 757 639/580 609/574 250/237 260/195 1.014 1.600 1.448 1 152
610 UL 829 711/652 682/646 250/237 256/195 1.072 1.900 1.666 2 234
650 UFf 848 730/671 701/665 250/237 256/195 1.095 1.900 1.682 2 218
455 UF 660 540/481 511/475 230/217 260/195 914 1.300 1.108 1 192
460 UFe 660 540/481 511/475 230/217 260/195 914 1.300 1.137 1 163
495 UL 709 588/529 559/523 230/217 260/195 964 1.400 1.240 1 160
545 KMF 753 635/576 601/570 250/237 260/195 1.010 1.600 1.398 1 202
400 SF 590 470/410 441/405 220/207 259/195 845 1.100 980 1 120
440 SF 626 626/506 477/441 230/217 259/195 880 1.200 1.080 1 120
455 UF 660 540/481 511/475 230/217 260/195 914 1.300 1.103 1 197
460 UFe 660 540/481 511/475 230/217 260/195 914 1.300 1.132 1 168
495 UL 709 588/529 559/523 230/217 260/195 964 1.400 1.228 1 172
545 KMF 753 635/576 606/570 250/237 260/195 1.010 1.600 1.395 1 205
560 KMFe 762 644/585 614/579 250/237 260/195 1.014 1.600 1.441 1 159
Number
of axles
Load 4
kg

Weight capacity increase
possible against surcharge
kg
Load reduction to
(against surcharge)
kg
Lying-down area
front
cm
Lying-down area
Middle
cm
Lying-down area
rear
cm
Number of
lying places
Adults/children Model
1.350 – 197x132 - 188x135/127 3/1 400 SF
1.350 – 207x132 - 191x129/94 4 440 SF
1.350 1.250 207x132 - 195x147/126 4 455 UF
1.350 1.250 195x141/108 - 202x77; 182x77 4 460 LU
1.350 1.250 198x138/120 - 195x144/134 4 460 UFe
1.500 1.300 2x189x83 - 195x144/134 4 490 UL
1.600/1.700 1.450 198x138/117 188x96/86 188x70; 184x70 4/2 540 KMFe
1.600/1.700 1.450 2x192x83 - 195x147/145 4 540 UL
1.750 1.550 198x158/131 212x117 188x70; 184x70 4/2 560 KMFe
1.350 – 197x132 - 188x135/127 3/1 400 SF
1.350 1.150 198x138/120 - 219x130/93 2/2 410 SFe
1.350 – 207x132 - 191x129/94 4 440 SF
1.350 – 207x132 - 191x129/94 4 440 SFr
1.350 1.250 207x132 - 195x147/126 4 455 UF
1.350 1.250 198x138/120 - 195x134/130 4 460 UFe
1.500 1.350 189x83; 191x83 - 195x147/134 4 495 UL
1.500 1.350 198x138/120 - 195x138/131 4 495 UFe
1.600/1.700 1.450 198x138/117 188x96/86 188x70; 184x70 4/2 540 KMFe
1.600/1.700 1.450 2x192x83 - 195x147/145 4 540 UL
1.600/1.700 1.450 192x146 - 195x158/123 4 540 UFf
1.600/1.700 1.450 198x138/117 - 195x177/153 4 540 UFe
1.600/1.700 1.450 195x141/139 - 2x199x80 4 540 WLU
1.750 1.500 200x140/118 193x119/109 2x185x70 4/2 545 KMF
1.750 1.550 2x200x90 - 215x161/155 4 560 UL
1.750 1.500 192x156 - 215x158/130 4 560 UFf
1.750 1.550 198x157/131 - 215x192/185 4 560 UFe
1.750 1.550 215x138/131 - 198x86; 194x86 4 560 WLU
1.750 1.550 198x158/131 212x117 188x70; 184x70 4/2 560 KMFe
2.000 1.800 198x158/131 212x117 2x192x70; 162x139/92 5 650 KMFe
2.200 – 198x158/120 2x194x72; 182x83 215x157/148 4/3 720 UKFe
1.600 1.350 198x138/110 - 195x138/137 4 495 UFe
1.700 1.450 2x192x83 - 195x130 4 540 UL
1.700 1.450 198x138/117 - 195x179/149 4 540 UFe
1.700 1.450 195x146/137 - 2x199x80 4 540 WLU
1.750 1.550 2x200x90 - 215x142/136 4 560 UL
1.750 1.550 198x157/136 - 215x189/183 4 560 UFe
1.750 1.550 215x146/131 - 198x86; 194x86 4 560 WLU
2.000 1.700 2x200x90 - 215x197/179 4 610 UL
2.000 1.800 198x158/131 186x83 215x157/168 5 650 UMFe
2.000 1.800 215x160/135 202x138/118 188x70; 184x70 4/2 650 KFU
2.000 1.800 198x158/131 212x117 2x192x70; 162x139/92 4/2 650 KMFe
2.000 1.800 215x179/170 202x138/118 - 4 650 WFU
2.200 – 2x200x90 195x83 215x150/156 5 720 UML
2.200 – 198x158/120 2x194x72; 182x83 215x157/148 4/3 720 UKFe
1.750 1.550 198x157/136 - 217x176/167 4 560 UFe
2.000 1.800 2x200x90 - 217x176/167 4 610 UL
2.000 1.800 200x156 - 217x176/167 4 650 UFf
1.350 1.250 207x132 - 195x147/126 4 455 UF
1.350 1.250 198x139/120 - 195x134/130 4 460 UFe
1.500 1.350 189x83; 191x83 - 195x147/134 4 495 UL
1.750 1.500 200x140/118 193x119/109 2x185x70 4/2 545 KMF
1.350 – 197x132 - 188x135/127 3/1 400 SF
1.350 – 207x132 - 191x129/94 4 440 SF
1.350 1.250 207x132 - 195x147/126 4 455 UF
1.350 1.250 198x139/120 - 195x134/130 4 460 UFe
1.500 1.350 189x83; 191x83 - 195x147/134 4 495 UL
1.750 1.500 200x140/118 193x119/109 2x185x70 4/2 545 KMF
1.750 1.550 198x158/131 212x117 188x70; 184x70 4/2 560 KMFe
TECHNICAL DATA
The roof/wall thickness on all models is
31 mm, the floor thickness 40 mm.
Deviations of up to 5% are possible in
weight data due to the use of natural
materials. All dimensions are non-binding
and may be subject to minor changes. We
reserve the right to make modifications to
equipment and fittings. The water supply
system represents the latest technology
as of 10/2007 (directive 2002/72/EC).
1 Depending on the model and equipment
level, the unladen vehicle may be
up to 50 mm higher.
2 The technically permissible gross
weight must not be exceeded under any
circumstances.
3 The weight in the ready-to-travel state
includes the unladen weight of the
standard caravan plus the basic equipment.
The basic equipment is made up
of a completely full 11 kg aluminium
gas bottle, a 100 % filled fresh water
tank and if applicable a toilet flush
tank and cable drum. The basic equipment
weight for
models 400–495: 60.5 kg,
models 540–720: 85.5 kg,
WLU and KMF: 70.5 kg.
4 The loading corresponds to the
difference between the „technically
permissible gross weight“ and the
„ready-to-travel state“. This value
must take account of the values for
optional extras and personal items.
61

LAYOUTS
single beDs QUeen beDs
460 lU
De Luxe
L: 660 cm G: 1.300 kg
B: 230 cm
540 Ul
De Luxe, Excellent
L: 738 cm G: 1.500 kg
B: 230 cm
560 Ul
Excellent
L: 757 cm G: 1.600 kg
B: 250 cm
610 Ul
Prestige
L: 810 cm G: 1.800 kg
B: 250 cm
490 Ul
De Luxe
L: 700 cm G: 1.350 kg
B: 230 cm
540 Ul
Prestige
L: 738 cm G: 1.600 kg
B: 230 cm
560 Ul
Prestige
L: 757 cm G: 1.600 kg
B: 250 cm
610 Ul
Excelsior
L: 829 cm G: 1.900 kg
B: 250 cm
495 Ul
Excellent, La Vita bionda/veneto
L: 709 cm G: 1.400 kg
B: 230 cm
540 WlU
Excellent, Prestige
L: 738 cm G: 1.500/1.600 kg
B: 230 cm
560 WlU
Excellent, Prestige
L: 760 cm G: 1.600 kg
B: 250 cm
720 Uml
Prestige
L: 915 cm G: 2.000 kg
B: 250 cm
540 Uff
Excellent
L: 738 cm G: 1.500 kg
B: 230 cm
chilDren’s beDs
540 kmfe
De Luxe, Excellent
L: 755 cm G: 1.500 kg
B: 230 cm
650 kfU
Prestige
L: 848 cm G: 1.900 kg
B: 250 cm
560 Uff
Excellent
L: 762 cm G: 1.600 kg
B: 250 cm
545 kmf
Excellent, La Vita bionda/veneto
L: 753 cm G: 1.600 kg
B: 250 cm
650 kmfe
Excellent, Prestige
L: 843 cm G: 1.900 kg
B: 250 cm
650 Uff
Excelsior
L: 848 cm G: 1.900 kg
B: 250 cm
560 kmfe
De Luxe, Excellent, La Vita bionda
L: 762 cm G: 1.600 kg
B: 250 cm
720 Ukfe
Excellent, Prestige
L: 915 cm G: 2.000 kg
B: 250 cm

FIXED BEDS
400 SF
De Luxe, Excellent, La Vita bionda
L: 590 cm G: 1.100 kg
B: 220 cm
455 UF
De Luxe, Excellent, La Vita bionda/veneto
L: 660 cm G: 1.300 kg
B: 230 cm
495 UFe
Excellent, Prestige
L: 688 cm G: 1.400/1.500 kg
B: 230 cm
560 UFe
Excelsior
L: 757 cm G: 1.600 kg
B: 250 cm
410 SFe
Excellent
L: 614 cm G: 1.200 kg
B: 230 cm
460 UFe
De Luxe
L: 660 cm G: 1.300 kg
B: 230 cm
540 UFe
Excellent, Prestige
L: 738 cm G: 1.500/1.600 kg
B: 230 cm
650 UMFe
Prestige
L: 843 cm G: 1.900 kg
B: 250 cm
440 SF
De Luxe, Excellent, La Vita bionda
L: 626 cm G: 1.200 kg
B: 230 cm
460 UFe
Excellent, La Vita bionda/veneto
L: 660 cm G: 1.300 kg
B: 230 cm
560 UFe
Excellent, Prestige
L: 757 cm G: 1.600 kg
B: 250 cm
650 WFU
Prestige
L: 843 cm G: 1.900 kg
B: 250 cm
440 SFr
Excellent
L: 626 cm G: 1.200 kg
B: 230 cm
The figures are not to scale!
EXPLANATION OF SYMBOLS
Beds
Seating unit
Cabinet
Wardrobe
Kitchen
Refrigerator
Bathroom
Worktop/table
Floor
Window bench
Media unit
TV cabinet
L: Body length with cylinder box (cm)
B: Overall width (cm)
G: Technically permissible gross weight (kg)
Number of beds (children/adults)
large refrigerator (175 litres)
Tandem axle
DESIGN
463
LAYOUTS
F Fixed bed
K Children‘s bed
L Single bed
M Central seating unit
S Side seating unit
U Circular seating unit
W Washroom
f free-standing
e external bathroom
r large refrigerator (175 l)

GERMANY
ICELAND
DENMARK
NETHERLANDS
UNITED KINGDOM
BELGIUM
FRANCE
PORTUGAL
SPAIN
LUXEMBOURG
Hobby-Wohnwagenwerk
Ing. Harald Striewski GmbH
Harald-Striewski-Straße 15
D-24787 Fockbek/Rendsburg www.hobby-caravan.de
SWITZERLAND
ITALY
GREECE
BULGARIA
NOTE:
Dealer
NORWAY
FINLAND
SWEDEN
ESTONIA
RUSSIA
POLAND
CZECH REPUBLIC
HUNGARY
ROMANIA
AUSTRIA
SLOVENIA
JAPAN
the models featured in the brochure also currently have optional extras or decoration that are not part of the standard scope of delivery.
Deviations in terms of structure and colour compared to the featured furnishings are subject to change provided they have to do with the
nature of the materials used and are found in the trade. The same applies to technical changes to the vehicle provided the product quality
remains the same overall or is improved and the purpose of use is not impaired.
UK
Design & production: www.new-communication.de | Correct as of July 2009
