GENERAL INFORMATIONINSTALLATION INSTRUCTIONSSYSTEM DESCRIPTION3

Stainless steel pipes for bridge drainageEN 10217-7/TC1 forms the general basis for the production of stainless steel pipes.STAINLESS STEEL PIPE SYSTEMMaterial according to ZTV-INGRegarding the design of pipes made of stainless steel, material 1.4571 must be selected according to DIN EN 10088 with aminimum wall thickness of 2mm.OpticsDue to the characteristics of stainless steel, no further coats are required.Roughness values - operationIdeal flow characteristics due to smooth internal surfaces (roughness value k (mm) < 0.05)InstallationLow weight and easy machinability ensure for a quick installation. The pipes are characterised by a constantouter diameter over the entire length. They can be cut at any position and mounted with Höllko connectors.The commercially available attachment systems can be used. No special protective paint coats are requiredThe contact of stainless steel with iron particles must be avoided. Suitable tools, cutting, and grinding devicesmust be used for processing purposes. Grinding dust from stainless steel cuts must be removed thoroughly as well.If the stainless steel processing instructions are followed, stainless steel is one of the most durable metal materials(see information centre stainless steel rust-free).Durability/maintenanceWithin the building and construction industry, stainless steel, material 1.4571, is used under normal atmospheric conditions.Due to air contaminations, an accumulation of deposits and contaminations on the metal surface occurs over time.If these contaminations are not washed away by the rainwater, an accumulation of pollutants resulting in optical impairmentswill occur over time. Stainless steel is durable, but requires regular care. The cleaning intervals depend on the degree ofcontamination, as well as the requirements regarding the optic. In order to thoroughly eliminate the contaminations,high-pressure water blasters are normally used.You will find further information on cleansing and care of stainless steel in the building and construction industryat www.edelstahl-rostfrei.de. (Sheet 965)Subject to technical changes - © with Höllko® 5

STAINLESS STEEL PIPE SYSTEMWeight tableOuter Ø/wall thickness 2/2.6mm 51/2.6 60.3/2.6 76.1/2 108/2 133/2 154/2 159/2 168.3/2 204/2 254/2 304/2Pipe weight empty kg/m 3.15 3.76 3.71 5.31 6.56 7.61 7.86 8.33 10.11 12.62 15.12Pipe weight filled kg/m 4.8 5.8 7.79 13.8 19.63 25.28 26.7 28.81 42.2 65.64 85.77Outer Ø/wall thickness 3mm 159/3 206/3 256/3 306/3 406/3 506/3 606/3Pipe weight empty kg/m 11.72 15.25 19.01 22.76 30.3 37.78 45.3Pipe weight filled kg/m 30.11 46.67 68.1 93.45 148.42 234 328Possible typesOur pipe systems are available in three types.VIEW (DESIGN: WITH SHORT PIPE FITTINGS)EXAMPLE TYPE 1DESIGN: WITH SHORT PIPE FITTINGS3 6 4 2 64 1 6 3 51 BRANCH 45°2 CLEANSING3 PIPE SUSPENSION4 PIPE SUSPENSION WITHOUTUPPER PIPE CLAMP5 STAINLESS STEEL PIPELINE6 CE-CONNECTORVIEW (DESIGN: PIPE FITTING WITH BRANCH AND CLEANSING OPENING)EXAMPLE TYPE 2DESIGN: PIPE FITTING WITH BRANCHAND CLEANSING OPENING32 13 512BRANCH 45°CLEANSING3PIPE SUSPENSION5STAINLESS STEEL PIPELINEVIEW (DESIGN: WITH SADDLE PIECES)EXAMPLE TYPE 3DESIGN: WITH SADDLE PIECES3 7 2 7 7 17 3 512357BRANCH SADDLE PIECE 45°CLEANSING SADDLE PIECEPIPE SUSPENSIONSTAINLESS STEEL PIPELINEBAND CLAMPAdvantages when using saddle pieces:Shorter delivery times, because of standard parts and pre-fabrication.Laying the longitudinal line is possible virtually without length adaptation, which means that there is hardly any waste.Anchor rails can normally be positioned at the same intervals end-to-end.Minimisation of the planning costs, because not all individual parts (moulded bodies) require a detailed drawing due toflexible saddle piece types. Dimensional differences (e.g. distances of the bridge gullies) can be accepted without concern,because the saddle piece with branch is positioned exactly at the location where it is required.Subsequent installation is possible without any problems.The installation of the longitudinal pipe is virtually possible without any length adaption.6Subject to technical changes - © with Höllko®

STAINLESS STEEL PIPE SYSTEMInstallation instructions for branch and cleansing saddle pieces, and cleansing covers.1.) Branch saddle piecea) The connecting pipe ND 150 is mounted close to the longitudinal pipe. The saddle pieceis initially positioned on the pipe. The final position of the saddle piece is marked.The oval pipe recess must also be marked on the pipe with a felt pen by reachinginto the branch nozzle from above.b) After having removed the saddle piece, the oval pipe recess is marked in accordance to paragraph a).This mark must be approx. 20 mm larger than the diameter of the incomingpipe (the mark of item a on all sides as shown in the drawing*).Continue with item d)*TOP VIEW (RECESS SADDLE PIECE 45°)20302.) Cleansing saddle piece and cleansing coverc) The recess for the cleansing saddle piece and the cleansing cover must be positioned at least 275mm(see drawing***) away from the edge of the branch saddle piece. This method preventsthe saddle pieces from overlapping. The size of the recess for thecleansing saddle piece and/or the cleansing cover can be found in the table below (see drawing**).3.) Branch, cleansing saddle piece, and cleansing coverd) The marked pipe recess can be cut with the help of a one-hand disc grinder with astainless steel cutting disc. The cutting disc must have a thickness of 1mm only.e) The cutting edges must then be deburred with a disc grinder equipped with a fan-shaped abrasive wheel(granularity 40 to 80).The cutting edge and possible stains caused by flying sparks must be cleansed thoroughly using abrasive fabric(granularity 100) up to the metal blank stainless steel surface. All grinding dust must be removed from the pipe.The protecting passive layer for stainless steel is formed automatically within approx. 14 days.f) At a distance of 2cm from the pipe recess, in the area of the sealing area, the stainless steel pipe has to be coveredwith a uniformly thick bead, width 10 - 20mm, with the adhesive, e.g. Sikaflex 11 FC.Please note the technical data sheet (processing temperature +5 degrees to +40 degrees celsius).(Cleansing cover is not attached with adhesive, item f is not applicable here)g) The saddle piece is positioned and aligned and the two related stainless steel band clampsare tightened uniformly until the half shell of the saddle piece has contact to the longitudinal pipe.Remaining sealing material must be removed thoroughly.h) Upon installation of the cleansing saddle piece, the screws of the covers has to be re-tightened.**PERSPECTIVE (RECESS OF THE CLEANSING SADDLE PIECE)***VIEW (DISTANCE BETWEEN THE SADDLES)Subject to technical changes - © with Höllko® 7

Stainless steel pipe systemSTAINLESS STEEL PIPESSubject to technical changes - © with Höllko® 9

LStainless steel pipe systemSECTIONLPipe (standard delivery dimensions)OD/wall thicknessND mm Length mm kg per pipe Item no.50 51/2.6 6000 18.9 ESR051-2.650 60.3/2.6 6000 22.56 ESR060.3-2.670 76.1/2 6000 22.26 ESR076.1-2100 108/2 6000 31.86 ESR108-2125 133/2 6000 39.36 ESR133-2150 154/2 6000 45.66 ESR154-2150 159/2 6000 47.16 ESR159-2150 168.3/2 6000 49.98 ESR168.3-2200 204/2 6000 60.66 ESR204-2200 206/3 6000 91.5 ESR206-3250 254/2 6000 75.72 ESR254-2250 256/3 6000 114.06 ESR256-3300 304/2 6000 90.72 ESR304-2300 306/3 6000 136.56 ESR306-3400 406/3 6000 181.8 ESR406-3500 506/3 6000 226.68 ESR506-3600 606/3 6000 271.8 ESR606-3Also available in the dimension specified below150 159/3 6000 70.32 ESR159-3Other dimensions upon requestSECTION15°RBend 15° (bend extended on both sides)ND OD/wall thickness mm R ≈ mm Length mm Item no.50 51/2 63.5 67 ESB051-2-15°50 60.3/2 76 70 ESB060.3-2-15°70 76.1/2 95 75 ESB076.1-2-15°100 108/2 142.5 137 ESB108-2-15°125 133/3 181 147 ESB133-3-15°150 154/2 225 159 ESB154-2-15°150 159/3 216 157 ESB159-3-15°150 168.3/2 229 160 ESB168.3-2-15°200 204/2 300 179 ESB204-2-15°200 206/3 300 179 ESB206-3-15°250 254/2 350 192 ESB254-2-15°300 306/3 400 205 ESB306-3-15°400 406/3 500 231 ESB406-3-15°500 506/3 600 257 ESB506-3-15°600 606/3 700 283 ESB606-3-15°10Subject to technical changes - © with Höllko®

Stainless steel pipe systemSECTIONL30°RBend 30° (bend extended on both sides up to DN 70)ND OD/wall thickness mm R ≈ mm Length mm Item no.50 51/2 63.5 83 ESB051-2-30°50 60.3/2 76 90 ESB060.3-2-30°70 76.1/2 95 100 ESB076.1-2-30°100 108/2 142.5 75 ESB108-2-30°125 133/3 181 95 ESB133-3-30°150 154/2 225 118 ESB154-2-30°150 159/3 216 113 ESB159-3-30°150 168.3/2 229 119 ESB168.3-2-30°200 204/2 300 157 ESB204-2-30°200 206/3 300 157 ESB206-3-30°250 254/2 350 183 ESB254-2-30°300 306/3 400 209 ESB306-3-30°400 406/3 500 261 ESB406-3-30°500 506/3 600 314 ESB506-3-30°600 606/3 700 366 ESB606-3-30°SECTIONLRBend 45° (bend extended on both sides up to DN 70)ND OD/wall thickness mm R ≈ mm Length mm Item no.50 51/2 63.5 100 ESB051-2-45°50 60.3/2 76 110 ESB060.3-2-45°70 76.1/2 95 125 ESB076.1-2-45°100 108/2 142.5 112 ESB108-2-45°125 133/3 181 142 ESB133-3-45°150 154/2 225 177 ESB154-2-45°150 159/3 216 170 ESB159-3-45°150 168.3/2 229 178 ESB168.3-2-45°200 204/2 300 236 ESB204-2-45°200 206/3 300 236 ESB206-3-45°250 254/2 350 275 ESB254-2-45°300 306/3 400 314 ESB306-3-45°400 406/3 500 393 ESB406-3-45°500 506/3 600 471 ESB506-3-45°600 606/3 700 550 ESB606-3-45°Subject to technical changes - © with Höllko® 11

Stainless steel pipe systemSECTIONLRBend 70° (bend extended on both sides up to DN 50)ND OD/wall thickness mm R ≈ mm Length mm Item no.50 51/2 63.5 128 ESB051-2-70°50 60.3/2 76 143 ESB060.3-2-70°70 76.1/2 95 117 ESB076.1-2-70°100 108/2 142.5 174 ESB108-2-70°125 133/3 181 221 ESB133-3-70°150 154/2 225 275 ESB154-2-70°150 159/3 216 264 ESB159-3-70°150 168.3/2 229 278 ESB168.3-2-70°200 204/2 300 367 ESB204-2-70°200 206/3 300 367 ESB206-3-70°250 254/2 350 428 ESB254-2-70°300 306/3 400 489 ESB306-3-70°400 406/3 500 611 ESB406-3-70°500 506/3 600 733 ESB506-3-70°600 606/3 700 855 ESB606-3-70°SECTIONLRBend 90° (bend not extended)ND OD/wall thickness mm R ≈ mm Length mm Item no.50 51/2 63.5 100 ESB051-2-90°50 60.3/2 76 119 ESB060.3-2-90°70 76.1/2 95 150 ESB076.1-2-90°100 108/2 142.5 224 ESB108-2-90°125 133/3 181 284 ESB133-3-90°150 154/2 225 353 ESB154-2-90°150 159/3 216 339 ESB159-3-90°150 168.3/2 229 358 ESB168.3-2-90°200 204/2 300 471 ESB204-2-90°200 206/3 300 471 ESB206-3-90°250 254/2 350 550 ESB254-2-90°300 306/3 400 628 ESB306-3-90°400 406/3 500 785 ESB406-3-90°500 506/3 600 942 ESB506-3-90°600 606/3 700 1100 ESB606-3-90°12Subject to technical changes - © with Höllko®

Stainless steel pipe systemSECTIONTOP VIEWLEnd capND OD/wall thickness mm Length mm Item no.50 51/2 50 ESED05150 60.3/2 50 ESED06070 76.1/2 50 ESED076100 108/2 80 ESED108125 133/3 80 ESED133150 154/2 80 ESED154150 159/3 80 ESED159150 168.3/2 80 ESED168200 204/2 80 ESED204200 206/3 80 ESED206250 254/2 80 ESED254300 304/2 80 ESED304300 306/3 80 ESED306400 406/3 80 ESED406500 506/3 80 ESED506600 606/3 80 ESED606Subject to technical changes - © with Höllko® 13

LATERAL VIEWOD1REAR VIEW14L2Ordering notes:120LL1When ordering, pleasestate the outside diameterof the longitudinal pipeODStainless steel pipe systemBranch saddle piece 45°, including band clamps and adhesiveND OD mm L1 mm L2 mm Length mm Item no.100 x 50 51 206 225 300 ESSA100-051GBS100 x 50 60.3 206 229 300 ESSA100-060GBS100 x 70 76.1 206 237 300 ESSA100-076GBS100 x 100 108 206 253 300 ESSA100-108GBS125 x 50 51 294 242 450 ESSA125-051GBS125 x 50 60.3 294 247 450 ESSA125-060GBS125 x 70 76.1 294 255 450 ESSA125-076GBS125 x 100 108 294 271 450 ESSA125-108GBS125 x 125 133 294 283 450 ESSA125-133GBS150 x 50 51 311 267 450 ESSA150-051GBS150 x 50 60.3 311 272 450 ESSA150-060GBS150 x 70 76.1 311 280 450 ESSA150-076GBS150 x 100 108 311 296 450 ESSA150-108GBS150 x 125 133 311 308 450 ESSA150-133GBS150 x 150 154 311 319 450 ESSA150-154GBS150 x 150 159 311 321 450 ESSA150-159GBS150 x 150 168.3 311 326 450 ESSA150-168GBS200 x 50 51 329 293 450 ESSA200-051GBS200 x 50 60.3 329 297 450 ESSA200-060GBS200 x 70 76.1 329 305 450 ESSA200-076GBS200 x 100 108 329 321 450 ESSA200-108GBS200 x 125 133 329 333 450 ESSA200-133GBS200 x 150 154 329 344 450 ESSA200-154GBS200 x 150 159 329 347 450 ESSA200-159GBS200 x 150 168.3 329 351 450 ESSA200-168GBS200 x 200 204 329 369 450 ESSA200-204GBS250 x 50 51 354 328 450 ESSA250-051GBS250 x 50 60.3 354 332 450 ESSA250-060GBS250 x 70 76.1 354 340 450 ESSA250-076GBS250 x 100 108 354 356 450 ESSA250-108GBS250 x 125 133 354 369 450 ESSA250-133GBS250 x 150 154 354 379 450 ESSA250-154GBS250 x 150 159 354 382 450 ESSA250-159GBS250 x 150 168.3 354 387 450 ESSA250-168GBS250 x 200 204 354 404 450 ESSA250-204GBS250 x 250 254 429 429 600 ESSA250-254GBS300 x 50 51 379 363 450 ESSA300-051GBS300 x 50 60.3 379 368 450 ESSA300-060GBS300 x 70 76.1 379 376 450 ESSA300-076GBS300 x 100 108 379 392 450 ESSA300-108GBS300 x 125 133 379 404 450 ESSA300-133GBS300 x 150 154 379 415 450 ESSA300-154GBS300 x 150 159 379 417 450 ESSA300-159GBSSubject to technical changes - © with Höllko®

Stainless steel pipe systemBranch saddle piece 45°, including band clamps and adhesiveND OD mm L1 mm L2 mm Length mm Item no.300 x 150 168.3 379 422 450 ESSA300-168GBS300 x 200 204 379 440 450 ESSA300-204GBS300 x 250 254 454 465 600 ESSA300-254GBS300 x 300 304 454 490 600 ESSA300-304GBS400 x 50 51 430 435 450 ESSA400-051GBS400 x 50 60.3 430 440 450 ESSA400-060GBS400 x 70 76.1 430 448 450 ESSA400-076GBS400 x 100 108 430 463 450 ESSA400-108GBS400 x 125 133 430 476 450 ESSA400-133GBS400 x 150 154 430 487 450 ESSA400-154GBS400 x 150 159 430 489 450 ESSA400-159GBS400 x 150 168.3 430 494 450 ESSA400-168GBS400 x 200 204 430 512 450 ESSA400-204GBS400 x 250 254 505 537 600 ESSA400-254GBS400 x 300 304 505 562 600 ESSA400-304GBS400 x 400 406 580 613 750 ESSA400-406GBS500 x 50 51 480 506 450 ESSA500-051GBS500 x 50 60.3 480 511 450 ESSA500-060GBS500 x 70 76.1 480 519 450 ESSA500-076GBS500 x 100 108 480 535 450 ESSA500-108GBS500 x 125 133 480 547 450 ESSA500-133GBS500 x 150 154 480 558 450 ESSA500-154GBS500 x 150 159 480 560 450 ESSA500-159GBS500 x 150 168.3 480 565 450 ESSA500-168GBS500 x 200 204 480 583 450 ESSA500-204GBS500 x 250 254 555 608 600 ESSA500-254GBS500 x 300 304 555 633 600 ESSA500-304GBS500 x 400 406 630 684 750 ESSA500-406GBS500 x 500 506 705 734 900 ESSA500-506GBS600 x 50 51 530 577 450 ESSA600-051GBS600 x 50 60.3 530 582 450 ESSA600-060GBS600 x 70 76.1 530 589 450 ESSA600-076GBS600 x 100 108 530 605 450 ESSA600-108GBS600 x 125 133 530 618 450 ESSA600-133GBS600 x 150 154 530 628 450 ESSA600-154GBS600 x 150 159 530 631 450 ESSA600-159GBS600 x 150 168.3 530 635 450 ESSA600-168GBS600 x 200 204 530 653 450 ESSA600-204GBS600 x 250 254 605 578 600 ESSA600-254GBS600 x 300 304 605 703 600 ESSA600-304GBS600 x 400 406 680 754 750 ESSA600-406GBS600 x 500 506 755 804 900 ESSA600-506GBS600 x 600 606 830 854 1050 ESSA600-606GBSSubject to technical changes - © with Höllko® 15

LATERAL VIEWOD1120REAR VIEWCOrdering notes:ODLL1When ordering, pleasestate the outside diameterof the longitudinal pipeStainless steel pipe systemBranch saddle piece 90°, including band clamps and adhesiveND OD mm C mm L1 mm Length mm Item no.100 x 50 51 176 150 300 ESSA100-051-90°GBS100 x 50 60.3 176 150 300 ESSA100-060-90°GBS100 x 70 76.1 176 150 300 ESSA100-076-90°GBS100 x 100 108 176 150 300 ESSA100-108-90°GBS125 x 50 51 189 225 450 ESSA125-051-90°GBS125 x 50 60.3 189 225 450 ESSA125-060-90°GBS125 x 70 76.1 189 225 450 ESSA125-076-90°GBS125 x 100 108 189 225 450 ESSA125-108-90°GBS125 x 125 133 189 225 450 ESSA125-133-90°GBS150 x 50 51 202 225 450 ESSA150-051-90°GBS150 x 50 60.3 202 225 450 ESSA150-060-90°GBS150 x 70 76.1 202 225 450 ESSA150-076-90°GBS150 x 100 108 202 225 450 ESSA150-108-90°GBS150 x 125 133 202 225 450 ESSA150-133-90°GBS150 x 150 154 202 225 450 ESSA150-154-90°GBS150 x 150 159 202 225 450 ESSA150-159-90°GBS150 x 150 168.3 202 225 450 ESSA150-168-90°GBS200 x 50 51 225 225 450 ESSA200-051-90°GBS200 x 50 60.3 225 225 450 ESSA200-060-90°GBS200 x 70 76.1 225 225 450 ESSA200-076-90°GBS200 x 100 108 225 225 450 ESSA200-108-90°GBS200 x 125 133 225 225 450 ESSA200-133-90°GBS200 x 150 154 225 225 450 ESSA200-154-90°GBS200 x 150 159 225 225 450 ESSA200-159-90°GBS200 x 150 168.3 225 225 450 ESSA200-168-90°GBS200 x 200 204 225 225 450 ESSA200-204-90°GBS250 x 50 51 249 225 450 ESSA250-051-90°GBS250 x 50 60.3 249 225 450 ESSA250-060-90°GBS250 x 70 76.1 249 225 450 ESSA250-076-90°GBS250 x 100 108 249 225 450 ESSA250-108-90°GBS250 x 125 133 249 225 450 ESSA250-133-90°GBS250 x 150 154 249 225 450 ESSA250-154-90°GBS250 x 150 159 249 225 450 ESSA250-159-90°GBS250 x 150 168.3 249 225 450 ESSA250-168-90°GBS250 x 200 204 249 225 450 ESSA250-204-90°GBS300 x 50 51 275 225 450 ESSA300-051-90°GBS300 x 50 60.3 275 225 450 ESSA300-060-90°GBS300 x 70 76.1 275 225 450 ESSA300-076-90°GBS300 x 100 108 275 225 450 ESSA300-108-90°GBS300 x 125 133 275 225 450 ESSA300-133-90°GBS300 x 150 154 275 225 450 ESSA300-154-90°GBS300 x 150 159 275 225 450 ESSA300-159-90°GBS16Subject to technical changes - © with Höllko®

Stainless steel pipe systemBranch saddle piece 90°, including band clamps and adhesiveND OD mm C mm L1 mm Length mm Item no.300 x 150 168.3 275 225 450 ESSA300-168-90°GBS300 x 200 204 275 225 450 ESSA300-204-90°GBS400 x 50 51 325 225 450 ESSA400-051-90°GBS400 x 50 60.3 325 225 450 ESSA400-060-90°GBS400 x 70 76.1 325 225 450 ESSA400-076-90°GBS400 x 100 108 325 225 450 ESSA400-108-90°GBS400 x 125 133 325 225 450 ESSA400-133-90°GBS400 x 150 154 325 225 450 ESSA400-154-90°GBS400 x 150 159 325 225 450 ESSA400-159-90°GBS400 x 150 168.3 325 225 450 ESSA400-168-90°GBS400 x 200 204 325 225 450 ESSA400-204-90°GBS500 x 50 51 375 225 450 ESSA500-051-90°GBS500 x 50 60.3 375 225 450 ESSA500-060-90°GBS500 x 70 76.1 375 225 450 ESSA500-076-90°GBS500 x 100 108 375 225 450 ESSA500-108-90°GBS500 x 125 133 375 225 450 ESSA500-133-90°GBS500 x 150 154 375 225 450 ESSA500-154-90°GBS500 x 150 159 375 225 450 ESSA500-159-90°GBS500 x 150 168.3 375 225 450 ESSA500-168-90°GBS500 x 200 204 375 225 450 ESSA500-204-90°GBS600 x 50 51 425 225 450 ESSA600-051-90°GBS600 x 50 60.3 425 225 450 ESSA600-060-90°GBS600 x 70 76.1 425 225 450 ESSA600-076-90°GBS600 x 100 108 425 225 450 ESSA600-108-90°GBS600 x 125 133 425 225 450 ESSA600-133-90°GBS600 x 150 154 425 225 450 ESSA600-154-90°GBS600 x 150 159 425 225 450 ESSA600-159-90°GBS600 x 150 168.3 425 225 450 ESSA600-168-90°GBS600 x 200 204 425 225 450 ESSA600-204-90°GBSSubject to technical changes - © with Höllko® 17

Stainless steel pipe systemLATERAL VIEWOD1COVER WITH RUBBER SEAL ANDSTAINLESS STEEL SCREW CONNECTIONSECTIONBL1LXCleansing saddle piece with rectangular cleansing opening,including band clamps and adhesiveND L1 mm B mm Length mm Item no.100 230 170 300 ESSARÖRE100GBS125 230 170 300 ESSARÖRE125GBS150 340 225 450 ESSARÖRE150GBS200 340 260 450 ESSARÖRE200GBS250 340 260 450 ESSARÖRE250GBS300 340 260 450 ESSARÖRE300GBS400 340 260 450 ESSARÖRE400GBS500 340 260 450 ESSARÖRE500GBS600 340 260 450 ESSARÖRE600GBSOrdering notes:DIM. X:UP TO ND200 = 40 MMOVER ND250 = 60 MMWhen ordering, pleasestate the outside diameterof the longitudinal pipeSikaflex adhesive 11 FC grey for saddle pieces made of GRP andstainless steelUnitItem no.CartridgeKLEBERSATTELLATERAL VIEWOD130SECTIONLCleansing cover with rubber seal, including band clampsND Length mm Item no.150 400 ESRDDN150GBS200 400 ESRDDN200GBS250 400 ESRDDN250GBS300 400 ESRDDN300GBS400 400 ESRDDN400GBS500 400 ESRDDN500GBS600 400 ESRDDN600GBSOrdering notes:When ordering, pleasestate the outside diameterof the longitudinal pipe18Subject to technical changes - © with Höllko®

Stainless steel pipe systemProduct description/tender specificationBand clamp with pivot bolts, material 1.4571 (A4)suitable for elastic pipe connectors, as well as stainless steel and GRP saddle piecesVIEWS25GBS band clampNDClampingrange(mm) Clamping parts Item no.100 110-125 1 GBSDN100A4125 136-150 2 GBSDN125A4150 155-185 2 GBSDN150A4200 205-235 2 GBSDN200A4250 256-286 2 GBSDN250A4300 305-343 2 GBSDN300A4400 408-446 2 GBSDN400A4500 505-555 3 GBSDN500A4600 605-655 3 GBSDN600A4Subject to technical changes - © with Höllko® 19

X1X1OD2OD2Stainless steel pipe systemProduct descriptionPipe fittings made of stainless steel, material 1.4571 (A4)maximum pipe length L = 6000mmThe pipe fittings are produced variably according to the customer's request.The pipe fittings shown in the drawings are examples,further designs are possible.45°OD1X2LPipe fittingPipe fitting with branch 45°Production according to customer's specification.When ordering, pleasespecify the following items:• Outside pipe diameters OD1, OD2• Angle XX°, if deviating• Dimensions X1, X2, and L45°OD1X2X3LPipe fittingPipe fitting with cleansing and branch 45°Production according to customer's specification.When ordering, pleasespecify the following items:• Outside pipe diameters OD1, OD2• Angle XX°, if deviating• Dimensions X1, X2, X3, and L20Subject to technical changes - © with Höllko®

X1OD2Stainless steel pipe systemOD345°45°OD1X2X3X4LPipe fittingPipe fitting with branch 90°, cleansing, and branch 45°Production according to customer's specification.When ordering, pleasespecify the following items:• Outside pipe diameters OD1, OD2, and OD3• Angle XX°, if deviating• Dimensions X1, X2, X3, X4, and LXX°OD1LPipe fittingPipe fitting with weld-on bendProduction according to customer's specification.When ordering, pleasespecify the following items:• Outside pipe diameter OD1• Angle XX°• Dimension LSubject to technical changes - © with Höllko® 21

Stainless steel pipe systemLATERAL VIEWBranch 45°ND (OD1xOD) OD mm L1 mm L2 mm Length mm Item no.50 x 50 51 130 188 200 ESAB051-051L2120OD50 x 50 60.3 130 193 200 ESAB060-06076 x 50 51 138 199 200 ESAB076-05176 x 50 60.3 138 204 200 ESAB076-06076 x 70 76.1 138 212 200 ESAB076-076OD1100 x 50 51 206 225 300 ESAB108-051100 x 50 60.3 206 229 300 ESAB108-060LL1100 x 70 76.1 206 237 300 ESAB108-076100 x 100 108 206 253 300 ESAB108-108125 x 50 51 294 242 450 ESAB133-051125 x 50 60.3 294 247 450 ESAB133-060REAR VIEW125 x 70 76 294 255 450 ESAB133-076125 x 100 108 294 271 450 ESAB133-108125 x 125 133 294 283 450 ESAB133-133150 x 50 51 302 254 450 ESAB154-051150 x 50 60.3 302 259 450 ESAB154-060150 x 76 76.1 302 267 450 ESAB154-076150 x 100 108 302 283 450 ESAB154-108150 x 125 133 302 295 450 ESAB154-133150 x 150 154 302 306 450 ESAB154-154150 x 50 51 311 267 450 ESAB159-051150 x 50 60.3 311 272 450 ESAB159-060150 x 76 76.1 311 280 450 ESAB159-076150 x 100 108 311 296 450 ESAB159-108150 x 125 133 311 308 450 ESAB159-133150 x 150 154 311 319 450 ESAB159-154150 x 150 159 311 321 450 ESAB159-159150 x 150 168.3 311 326 450 ESAB168-168200 x 50 51 329 293 450 ESAB204-051200 x 50 60.3 329 297 450 ESAB204-060200 x 70 76.1 329 305 450 ESAB204-076200 x 100 108 329 321 450 ESAB204-108200 x 125 133 329 333 450 ESAB204-133200 x 150 154 329 344 450 ESAB204-154200 x 150 159 329 347 450 ESAB204-159200 x 150 168.3 329 351 450 ESAB204-168200 x 200 204 329 369 450 ESAB204-204250 x 50 51 354 328 450 ESAB254-051250 x 50 60.3 354 332 450 ESAB254-060250 x 70 76.1 354 340 450 ESAB254-076250 x 100 108 354 356 450 ESAB254-108250 x 125 133 354 369 450 ESAB254-133250 x 150 154 354 379 450 ESAB254-154250 x 150 159 354 382 450 ESAB254-159250 x 150 168.3 354 387 450 ESAB254-168250 x 200 204 354 404 450 ESAB254-204250 x 250 254 429 429 600 ESAB254-254300 x 50 51 379 363 450 ESAB304-051300 x 50 60.3 379 368 450 ESAB304-06022Subject to technical changes - © with Höllko®

Stainless steel pipe systemBranch 45°ND (OD1xOD) OD mm L1 mm L2 mm Length mm Item no.300 x 70 76.1 379 376 450 ESAB304-076300 x 100 108 379 392 450 ESAB304-108300 x 125 133 379 404 450 ESAB304-133300 x 150 154 379 415 450 ESAB304-154300 x 150 159 379 417 450 ESAB304-159300 x 150 168.3 379 422 450 ESAB304-168300 x 200 204 379 440 450 ESAB304-204300 x 250 254 454 465 600 ESAB304-254300 x 300 304 454 490 600 ESAB304-304400 x 50 51 430 435 450 ESAB406-060400 x 50 60.3 430 440 450 ESAB406-076400 x 70 76.1 430 448 450 ESAB406-108400 x 100 108 430 463 450 ESAB406-133400 x 125 133 430 476 450 ESAB406-154400 x 150 154 430 487 450 ESAB406-159400 x 150 159 430 489 450 ESAB406-168400 x 150 168.3 430 494 450 ESAB406-204400 x 200 204 430 512 450 ESAB406-206400 x 250 254 505 537 600 ESAB406-254400 x 300 304 505 562 600 ESAB406-304400 x 400 406 580 613 750 ESAB406-406500 x 50 51 480 506 450 ESAB506-060500 x 50 60.3 480 511 450 ESAB506-076500 x 70 76.1 480 519 450 ESAB506-108500 x 100 108 480 535 450 ESAB506-133500 x 125 133 480 547 450 ESAB506-154500 x 150 154 480 558 450 ESAB506-159500 x 150 159 480 560 450 ESAB506-168500 x 150 168.3 480 565 450 ESAB506-204500 x 200 204 480 583 450 ESAB506-206500 x 250 254 555 608 600 ESAB506-254500 x 300 304 555 633 600 ESAB506-304500 x 400 406 630 684 750 ESAB506-406500 x 500 506 705 734 900 ESAB506-506600 x 50 51 530 577 450 ESAB600-060600 x 50 60.3 530 582 450 ESAB606-076600 x 70 76.1 530 589 450 ESAB606-108600 x 100 108 530 605 450 ESAB606-133600 x 125 133 530 618 450 ESAB606-154600 x 150 154 530 628 450 ESAB606-159600 x 150 159 530 631 450 ESAB606-168600 x 150 168.3 530 635 450 ESAB606-204600 x 200 204 530 653 450 ESAB606-206600 x 250 254 605 578 600 ESAB606-254600 x 300 304 605 703 600 ESAB606-304600 x 400 406 680 754 750 ESAB606-406600 x 500 506 755 804 900 ESAB606-506600 x 600 606 830 854 1050 ESAB606-606Subject to technical changes - © with Höllko® 23

Stainless steel pipe systemLATERAL VIEWCOVER WITH RUBBER SEAL ANDSTAINLESS STEEL SCREW CONNECTIONL1OD1SECTIONBDIM. X:UP TO ND200 = 40 MMOVER ND250 = 60 MMLXCleansing pipeND L1 mm B mm Length mm Item no.100 230 170 300 ESRR108125 230 170 300 ESRR133150 340 225 450 ESRR154150 340 225 450 ESRR159150 340 225 450 ESRR168200 340 260 450 ESRR204250 340 260 450 ESRR254300 340 260 450 ESRR304400 340 260 450 ESRR406500 340 260 450 ESRR506600 340 260 450 ESRR606SECTIONOD1TOP VIEWL1LL2OD2Transition pipe, sharp-edgedND L1 mm L2 mm Length mm Item no.100 x 050 50 50 100 ESRÜ060-108-S125 x 100 100 100 200 ESRÜ108-133-S150 x 050 50 50 100 ESRÜ060-154-S150 x 050 50 50 100 ESRÜ060-159-S150 x 050 50 50 100 ESRÜ060-168-S150 x 100 100 100 200 ESRÜ108-154-S150 x 100 100 100 200 ESRÜ108-159-S150 x 100 100 100 200 ESRÜ108-168-S150 x 125 100 100 200 ESRÜ133-154-S150 x 125 100 100 200 ESRÜ133-159-S150 x 125 100 100 200 ESRÜ133-168-S200 x 100 100 100 200 ESRÜ108-204-S200 x 125 100 100 200 ESRÜ133-204-S200 x 150 100 100 200 ESRÜ154-204-S200 x 150 100 100 200 ESRÜ159-204-S200 x 150 100 100 200 ESRÜ168-204-S250 x 200 100 100 200 ESRÜ204-254-S300 x 200 100 100 200 ESRÜ204-304-S300 x 250 100 100 200 ESRÜ254-304-S400 x 250 100 100 200 ESRÜ254-406-S400 x 300 100 100 200 ESRÜ304-406-S500 x 400 100 100 200 ESRÜ406-506-S600 x 400 100 100 200 ESRÜ406-606-S600 x 500 100 100 200 ESRÜ506-606-S24Subject to technical changes - © with Höllko®
