PHANTOM AMPLIFIERSIs bigger always better? No! For many years, if you wanted a big system, you needed bigproducts. Not anymore. Using state of the art SMT and Class D technologies, you can nowhave a system as big as you want, and still not sacrifice all your storage area. These new bigamps in a tiny chassis are available in 1, 2, 4 and 5 channel models to fit every application…AMPLIFIERSWe’re in a time where small is “in”. Smaller, more economicalvehicles are more and more desirable. But that doesn’t meanyou have to sacrifice big power for your system. The newiON amplifiers pack huge amounts of power into small chassisthanks to efficient full range Class D topology and SMT technology.Complimented with every possible preamp adjustment,the iON amplifiers leave nothing to be desired…Phantom Class D AmplifiersClass D Full Range SMT CircuitryDouble Sided Composite Epoxy PCB2-Ohm Stereo, 4-Ohm Bridged Multi-Channel1-Ohm Stable Class D MonoblockThree-Way Protection CircuitryDelayed On/Off CircuitTri-Mode Capable (2/4/5 ch. models)Variable 12dB High, Low, & Subsonic CrossoversBand-Pass Crossovers (4ch & 5ch.)Input Source Selector (4ch. & 5ch.)Variable 12dB 50Hz Bass Boost (1ch.)Dash Mounted Remote Gain Control (5ch. & 1 ch.)Direct Wire 8ga. Power & Speaker Terminals0ga Reducer Terminal IncludedPHANTOM P600.2 P900.4 P900.5 P1000.1iON i350.2 i320.4 i520.4 i540.5 i450.1 i650.1Channels 2 Ch. Class D 4 Ch. Class D 5cCh. Class D 1ch. Class DChannels 2 4 4 5 1 1RMS Power 4Ω 190 x 2 145 x 4 70 x 4 + 270 x 1 580RMS Power 4Ω 115 x 2 60 x 4 100 x 4 50 x 4 + 170 x 1 260 x 1 400 x 1RMS Power 2Ω 300 x 2 225 x 4 115 x 4 + 440 x 1 725RMS Power 2Ω 175 x 2 80 x 4 130 x 4 75 x 4 + 240 x 1 450 x 1 650 x 1RMS Power 4Ω Bridged 600 x 1 450 x 2 230 x 2 + 440 x 1 -RMS Power 4Ω Bridged 350 x 1 160 x 2 260 x 2 150 x 2 + 240 x 1 - -RMS Power 1Ω - - - 1,000RMS Power 1ΩRemote Gain Control - - - IncludedRemote Gain Control - - - Included Included IncludedDimensions:8.25” 10.625” 13.25” 13.25”Dimensions:5.50” 7.00” 9.25” 9.25” 8.00” 9.25”(6.50”w x 2”h)(5.375”w x 1.875”h)4 5

AMPLIFIERBlack Ice AmplifiersFull SMT Surface Mount TechnologyDouble Sided Composite Epoxy PCB2-Ohm Stereo, 4-Ohm Bridged Class A/B1-Ohm Stable Class D MonoblockBalanced Signal Input (requires BLT)Variable 12dB High, Low, & Subsonic FiltersBLACK ICE AMPLIFIERSPrecision Power is proud to introduce the newest generation of amplifiers, Black ICE. Overcompensated high headroom power supplies are capable of producing more than conventionalpower gain with 2 ohm loads. Selected models accept balanced signal for the purest sound.Additionally, double sided PCB’s with all surface mount technology enhance the quality of yourlistening experience.Band-Pass Crossovers (4ch & 5ch.)Input Source Selector (4ch. & 5ch.)Variable 12dB 45Hz Bass BoostVariable 0-180 0 Phase Control (1 ch.)Dash Mounted Remote Gain ControlDirect Wire Power & Speaker TerminalsBLT Balanced Line TransmitterComplimenting superior performance, a molded 1 piece gloss black aluminum surface and copper accentsgive Black ICE amplifiers the appearance their hidden technologies deserve.Wire Concealing End CapsMolded Gloss Black Acrylic TopThree-Way Protection CircuitryDelayed On/Off CircuitTri-Mode Capable (2/4/5 ch. models)BLACK ICE CLASS A/B BK120.2 BK210.2 BK340.2 BK340.4 BK520.4 BK800.4 BK580.5Channels 2 Ch. A/B 2 Ch. A/B 2 Ch. A/B 4 Ch. A/B 4 Ch. A/B 4 Ch. A/B 5 Ch. A/BRMS Power 4Ω 40 x 2 65 x 2 110 x 2 55 x 4 95 x 4 130 x 4 55 x 4 + 160 x 1RMS Power 2Ω 60 x 2 105 x 2 170 x 2 85 x 4 130 x 4 200 x 4 85 x 4 + 240 x 1RMS Power 4Ω Bridged 120 x 1 210 x 2 340 x 1 170 x 2 260 x 2 400 x 2 170 x 2 + 240 x 1Remote Gain Control - - - - - - IncludedDimensions:(8.25”w x 2”h)8.75” 9.50” 14.25” 12.25” 17.25” 21.00” 18.25”BLACK ICE CLASS D BK650.1D BK1300.1D BK1800.1DChannels 1 Ch. Class D 1 Ch. Class D 1 Ch. Class DRMS Power 4Ω 240 500 700RMS Power 2Ω 450 900 1,100RMS Power 1Ω 650 1,300 1,800Remote Gain Control Included Included IncludedDimensions:(8.25”w x 2”h)12.50” 17.00” 19.75”Remote Gain ControlInclude With Select Modelssedona AMPLIFIERSBack in the day, Sedona amplifiers stood for quality and durability with no sacrifice in sound reproduction.Today’s economy yields higher sales for lower cost products. The Sedona amps are greatquality with an entry level price point. But the features farexceed other entry level priced products on the market.High-pass low-pass, bandpass and subsoniccrossovers are capable of everything imaginablefrom 15Hz-5kHz. A bass boost and remotegain are also included on applicablemodels. Don’t settle for entrylevel products, outperform withSedona!Brushed Aluminum FinishClass A/B Full Range Monoblock Available12dB Variable High, Low, & Subsonic Crossovers6dB & 12dB 50Hz Bass Boost2 & 4 ch. Models Band-Pass Crossovers180 0 Phase Control for 5 Ch. & MonoblocksHigh Level or 200mV-6V Low Level InputDirect 4 ga. Power & 8 ga. Speaker TerminalsDash Mount Remote Gain Control IncludedRed Top Panel Accent LightingSEDONA CLASS A/B S200.2 S420.2 S580.2 S320.4 S580.4 S760.4 S580.5Channels 2 Ch. A/B 2 Ch. A/B 2 Ch. A/B 4 Ch. A/B 4 Ch. A/B 4 Ch. A/B 5 Ch. A/BRMS Power 4Ω 70 x 2 130 x 2 190 x 2 55 x 4 100 x 4 120 x 4 55 x 4 + 160 x 1RMS Power 2Ω 100 x 2 210 x 2 290 x 2 80 x 4 145 x 4 190 x 4 80 x 4 + 260 x 1RMS Power 4Ω Bridged 200 x 1 420 x 1 580 x 1 160 x 2 290 x 2 380 x 2 160 x 2 + 260 x 1Remote Gain Control - - - - - - -Dimensions:(9.50”w x 2.375”h)13.00” 19.00” 23.00” 17.00” 19.50” 23.00” 23.00”SEDONA MONOBLOCK S270.1 S550.1D S850.1D S1300.1D S2000.1DChannels 1 Ch. Class A/B 1 Ch. Class D 1 Ch. Class D 1 Ch. Class D 1 Ch. Class DRMS Power 4Ω 170 240 350 520 750RMS Power 2Ω 270 400 600 900 1,300RMS Power 1Ω * 550 850 1,300 2,000Remote Gain Control * Included Included Included IncludedDimensions:(9.50”w x 2.375”h)13.00” 11.75” 13.50” 16.00” 19.00”AMPLIFIER6 7

DEQ-8 Digital Signal ProcessorDEQ-8 is a unique DSP processor brought to you by the Product Development Team at PrecisionPower. A 24bit/96kHz digital audio processor allowing you full control of your system. With mobileaudio changing daily, we thought to our self’s what could we bring to the market that wouldmeet the needs of all vehicles, weather a factory system or the biggest baddest after marketsystems.With 6 channel high level inputs, DEQ-8 allows you to ingrate seamlessly with your factory radio.The system allows you full control of aftermarket speakers and amplifiers without replacing yourfactory head unit, and best of all you don’t loose any of your factory installed options. Synthesisallows you to fine tune your system with the easy to use program controlled by any laptop. Availableon both MAC and PC.With 8 channel outputs DEQ-8 allows you to create multipleplatforms. Weather a simple 2 way setup with subwoofersor a 4 way setup with multiple drivers. Synthesis delivers thehighest in audio quality without compromising your wallet.10,000w SPL Competition AmplifierNon-Regulated MOSFET PWM Power SupplyAll “N” Channel TO218 MOSFET TransistorsDual Internally Bridged Mono-blocksIdeal for 16V ApplicationsThree-Way Protection CircuitryDash Mount Remote Gain ControlDual 0 ga. Power Inputs, 4 ga. Speaker OutputsChannelsRMS @ 2Ω, 16V 3,700RMS @ 1Ω, 16V 6,100PDXPDX-10K1 ch. Class DRMS @ .5Ω, 16V 10,000Harmonic Distortion 1.00%AMPLIFIERAMPLIFIERFrequency Response15-150HzHardware172MHz -28/56bit DSP24bit ADC/DAC96kHz sample rate114db DR ADC converters114db DR DAC convertersBalanced OR Unbalanced RCA Inputs8V RCA Output/ Balanced31 Band Graphic EQ9 Band Parametric EQ4 Way crossoverTime AlignmentSoftware ControlUSB 2.0 interfacePlug&Play No driver requiredWinXP/Vista/7 & MAC CompatibleFirmware upgradable for future expansionVISIT PRECISIONPOWER.COM FOR MORE DETALS ABOUT DEQ-8Signal-to-Noise Ratio87dBDamping Factor > 350Signal Voltage200mV-7.6VPotential Current Draw 1,200ALow Pass FilterBass BoostSubsonic FilterRemote Gain Control24dB; 35-250Hz0-18dB; 40-120Hz24dB; 15-50HzYesDimensions 2.75” h x 12.625” w x 23.25L8 9

PHANTOM SUBWOOFERSPHANTOM SUBWOOFERSAcoustic engineers want 3 things out of a woofer: high SPL, low frequency response, and small air requirements.No woofer can be optimized for all 3, so some sacrifices always have to be be made if a woofer has avery specific design goal…Many vehicles do not have tons of airspace available for a big, bulky enclosure. Some vehicles, like somecrew-cab trucks have no space for a subwoofer. Until now… Phantom-13 is the shallowest woofer on the market!Coming in at a mere 2” of depth, they will fit comfortably behind rear crew-cab truck seats, under manyfront seats, or even in a friggin’ door with some custom fabrication! While other “shallow mount” subwoofersare available, they typically require traditional airspace. Phantom-13 is 13.25” in diameter and boasts a huge5” coil with inverted motor. Not only does it play well in ½ cubic foot (typical for most 8”-10” woofers), but itreproduces more lower frequency response than most 12” woofers with much larger enclosures.Our engineers were willing to sacrifice a couple of dB of efficiency to bring you a truly phenomenal, applicationspecific subwoofer. No more whining about not having a subwoofer available that will fit in virtually anyvehicle!Woven Fiberglass Composite ConeAll Phantom subwoofers use fiberglass stranding woventogether for ultimate strength and less elasticity. Aheavy soaking in epoxy combined with the sonic qualitiesof pulp paper backing proves itself worthy of anysystem.100% OFC 4-Layer Voice CoilPhantom subwoofers use generous 1.50” long, 2.5” diameter100% OFC Copper voice coils. A vented Aluminumformer extract and dissapate any heat build-up,resulting in improved power handling.Extended Excursion Polyurethane SurroundPolyurethane is a foam compound used in the manufactureof countless gasket and insulation products, knownfor its adhesive bonding properties. Phantom subwoofersutalize an extended excursion polyurethane surroundfor strength and flexiabiity during extreme movement.Back Plate & T-Yoke VentingHeat build-up is a leading cause of catastrophic wooferfailure. Venting built into the T-Yoke, back plate, andvoice coil extract and dissapate heat, ensuring Phantomsubwoofers keep their cool.Low Bass In No Space!Proprietary Cast Aluminum FrameInverted Motor AssemblyPP Coated Pressed Paper ConePolyurethane Surround2” Mounting Depth !!!5” Aluminum Former Voice CoilRequires only .75 ft Box!Semi-Circular Frame Venting12ga Direct Connect Wire TerminalsPolyurethane Mounting GasketPHANTOM-13RMS Power (watts) 200Efficiency (1w/1m dB)80.82dBVoice Coil Configuration 5.00” SVC 4ΩMounting Depth 2.00”Optimum Sealed ft 3 0.75Optimum Ported ft 3N/APHANTOM PH.10 PH.12 PH.15RMS Power (watts) 700 800 900Efficiency (1w/1m dB) 82.95dB 85.80dB 88.45dBVoice Coil Configuration 2.50” DVC 2Ω 2.50” DVC 2Ω 2.50” DVC 2ΩMounting Depth 5.875” 6.00” 6.875”Optimum Sealed ft 3 1.00 1.50 2.75Optimum Ported ft 3 1.50 2.25 2.7512 13

Black ICE SUBWOOFERSART collection SUBWOOFERSMany of today’s car audio products consist of a lot of custom tooled parts, all which cost extra money.The design goal for the SQ 8”was to engineer phenomenal audiophile-grade subwoofers that do notcost a fortune. If you’re looking for chrome or something really flashy, look somewhere else. If you’relooking perfect subwoofer performance, look no further. A.8SQ comes with a dual 4-ohm VC to wire apair to either class of amplifier.Art SQ SubwoofersNon-Pressed Paper ConeIMPP/Mica Composite Dust CapRubber Gasket4 Layer Voice CoilKapton VC FormerConex SpiderReinforced Foam SurroundVented Pole PieceCompression TerminalsART COLLECTION A.8SQRMS Power (watts) 180Efficiency (1w/1m dB)83dBVoice Coil Configuration 2.00” DVC 4ΩMounting Depth 4.00Optimum Sealed ft 3 0.60Optimum Ported ft 3 0.75sedona SUBWOOFERSClosed Cell Polyurethane SurroundA strong and flexible heat resistant compound, nitrilebutadiene rubber is used widely in automotive applications.Black Ice woofers utalize an extended excursionnbr surround for it’s strength and flexible properitiesduring extreme movement.Back Plate & T-Yoke VentingHeat build-up is a leading cause of catastrophic wooferfailure. Venting built into the T-Yoke, back plate, andvoice coil extract and dissapate heat, ensuring BlackIce woofers keep their cool.100% OFC 4-Layer Voice CoilBlack Ice woofers use generous 1.25” long, 2.00”diameter 100% OFC Copper voice coils. A ventedAluminum former extract and dissapate any heatbuild-up, resulting in im proved power handling.PHANTOM BI.104 BI.102 BI.124 BI.122 BI.154 BI.152RMS Power (watts) 450 450 500 500 550 550Efficiency (1w/1m dB) 87.10dB 88.0dB 90.20dB 91.20dB 86.60dB 87.7dBVoice Coil Configuration 2.00” DVC 4Ω 2.00” DVC 2Ω 2.00” DVC 4Ω 2.00” DVC 2Ω 2.00” DVC 4Ω 2.00” DVC 2ΩMounting Depth 5.375” 5.375” 5.75” 5.75” 6.50” 6.50”Optimum Sealed ft 3 1.00 1.00 1.75 1.75 2.50 2.50Optimum Ported ft 3 1.50 1.50 2.00 2.00 3.00 3.00Injection Molded Polypropylene ConeOvercast Stitched ConesNBR Rubber Surround2” SVC 4-Ohm Voice CoilEmbossed Dust CapFrame Voice Coil VentingVented T-Yoke & Back PlateSEDONA SN.8 SN.10 SN.12RMS Power (watts) 250 300 350Efficiency (1w/1m dB) 85.70dB 88.90dB 92.30dBVoice Coil Configuration 2.00” SVC 4Ω 2.00” SVC 4Ω 2.00” SVC 4ΩMounting Depth 4.00” 4.50” 5.375”Optimum Sealed ft 3 0.75 1.00 1.25Optimum Ported ft 3 1.00 1.50 1.7514 15

The PC components come in 2-way and 3-way models with all individual drivers using rare-earthNeodymium motors for high BL, light weight and compact size. Traditionally only tweeters use Neomotors, but we used Neo on the 2.5” midrange and 6.5” midbass as well making the drivers verystrong and compact. The 6.5” uses a Kevlar composite paper cone with laminated foam backing.Paper cones traditionally yield the most natural, uncolored sound reproduction possible. Weembedded Kevlar fibers into the paper for rigidity which reduces cone flexing and radiated distortion.The 2.5” midrange uses an aluminum cone for lightweight and strength while the tweeter usesa 20mm inverted aluminum diaphragm. The shallow depth of the midrange allows it to mount withthe tweeter on the dash, or in the A-pillar, for phenomenal staging, rather than being limited to usinga 4” midrange with the tweeter and being forced, in most cases, to fabricate kickpanel pods.COMPONENTSPOWERCLASS COMPONENTSPOWERCLASS PC2.65C PC3.65CSize & Configuration 6.5” 2-way 6.5” / 2.5” 3-wayPower Handling 90w 100wFrequency Response 60-20kHz 60-20kHzEfficiency (1w/1m dB) 87dB 87dBWoofer Mounting Depth 2.625” 2.625”2.5” Midrange• High Strength Neodymium Motor• Aluminum Cone• Aluminum Dust Cap• Low Resonance Polyphenylene Sulfide Basket• Conex Spider Inverted Butyl Rubber Surround• CCAW 1” Voice Coil• Aluminum VC Former with cooling ventsPHANTOM COMPONENTSWAIT! DO NOT let this little component sets fool you. Once a dust-bunny covered relic in the “uselesssample” bin at Precision Power headquarters, the new Phantom components took us all by surprise.It was originally thought to be a passive radiator, but to our amazement, these lil’ guys PACK APUNCH!!!COMPONENTSEven with only 1” mounting depth, the 6.5” woofer is capable of reproducing the lowest of lows andsnappiest kick bass with very little effort! An inverted neodymium motor structure allows a shallow andcompact profile frame. The cone and dust cap, ahemm..., is 1-piece IMPP with recesses molded intothe back side to receive the voice coil structure. This direct connection of cone to voice coil yieldsthe snappy reaction of a flat piston driver, virtually eliminating cone-radiated distortion. Very littlesuspension is necessary for this configuration, but what’s there snuggles up to the cone undersidein it’s own recess, and attaches directly to a recess in the frame for the motor. WTH you say? Thesuspension of conventional drivers attaches to the voice coil and can flex, bend, or warp with thesometimes violent acceleration of the voice coil. Since the suspension attaches to the fixed structureof the frame, the voice coil is less likely to loose control, keeping its linearity. BUT WAIT, THER’S MORE!!!The tweeter, damn, don’t get us started, is a smooth & crisp (yes that’s possible) 1.25” inverted dimpledAluminum dome diaphragm with phase plug. It’s ok..., read that again. The hochfrequenz responseof this tweeter is phenomenal. What you expect from luxurious component set at quadruplethe value. Even though the diaphragm is an unconventional 1.25”, the tweeter can be remove fromthe housing structure and installed in virturally any OEM tweeter location. Oh yeah, did we mentionthis tweeter sounds really good? It’s so killer, we also offer it to you as an add-on to replace your junkyfactory tweeter, you’re welcome...PHANTOMSize & ConfigurationShallow Mount High Efficiency Component SetLow Resonance Polycarbonate Frame6.5” MidbassOnly 1” Mounting Depth!• High Strength Neodymium Motor1-Piece Polypropylene Dome Cone• Kevlar Reinforced Paper Cone with Laminated Foam Backing20mm TweeterHigh Strength Neodymium Magnets• Solid Phase Plug• High Strength Neodymium Motor• Low Resonance Polyphenylene Sulfide Basket• Inverted and Dimpled Aluminum Diaphragm1.25” Aluminum Inverted Dome Tweeter• Conex Spider with Stitched Tinsel Leads• CCAW 20mm Voice CoilPassive 12dB Crossover Included• Butyl Rubber Surround• Kapton VC Former+/- 3dB Tweeter Attenuation Switch• CCAW 2” Voice CoilPTC Tweeter Protection16• Glass Fiber VC Former17Power HandlingFrequency ResponseEfficiency (1w/1m dB)PH2.65C6.5” 2-way80w60-20kHz94dBWoofer Mounting Depth 1.00”

ART COLLECTIONSize & ConfigurationPower HandlingFrequency ResponseEfficiency (1w/1m dB)ART collection COMPONENTSA2.65C6.5” 2-way130w70-20kHz86dBWoofer Mounting Depth 2.625”Convertible Component or CoaxialOptional Bi-Ampable OperationPressed Paper ConeButyl Rubber SurroundCONEX Spider SuspensionBlack ICE COMPONENTSIMPP Cone w/ Carbon Fiber Finish1” Kapton Voice CoilInverted Phase Plug1” Swivel Teteron Dome TweeterFlush or Surface Mounting12db Passive Crossover Included-3dB Tweeter AttenuationPTC Tweeter ProtectionBLACK ICESize & ConfigurationPower HandlingSystem ImpedanceFrequency ResponseEfficiency (1w/1m dB)BI.65C6.5” 2-way120w4-Ohm70-20kHz90dBWoofer Mounting Depth 2.50”Aluminum Phase Plug1” Silk Dome TweeterTweeter Flush Mount IncludedAluminum Phase Plug2-way Crossover IncludedPOWERCLASS FULL RANGEPC.52PC.572PC.652FULL RANGEInjection Molded Polypropylene ConeLow Resonance Polycarbonate Frame1” Aluminum Voice CoilButyl Rubber SurroundOptional Bi-Amp Operation1” Swivel Silk Dome TweeterPTC Tweeter ProtectionPassive Crossovers Includedsedona COMPONENTSZolon Coated Low Resonance BasketPolypropylene ConeButyl Rubber Surround1” Aluminum Voice CoilRubber Magnet Cover20oz. Ferrite Magnet1” Mylar TweeterSEDONASize & ConfigurationPower HandlingSystem ImpedanceFrequency ResponseEfficiency (1w/1m dB)S2.65C6.5” 2-way100w4-Ohm70-20kHz92dBPassive CrossoversIncluded18 19Woofer Mounting Depth 2.50”PC.692POWER CLASS PC.692 PC.652 PC.52 PC.572Size & Configuration 6” x 9” 2-way 6.5” 2-way 5.25” 2-way 5” x 7” 2-wayPower Handling 150w 120w 100w 120wSystem Impedance 4-Ohm 4-Ohm 4-Ohm 4-OhmFrequency Response 45-20kHz 65-20kHz 70-20kHz 55-20kHzEfficiency (1w/1m dB) 93dB 91dB 90dB 92dBWoofer Mounting Depth 4.25” 3.75” 3.00” 3.50”

FULL RANGEBI.402BI.694Black ICE FULL RANGEsedona FULL RANGES.693BI.502BLACK ICE SPEAKER BI.694 BI.653 BI.573 BI.502 BI.402Size & Configuration 6” x 9” 4-way 6.5” 4-way 5” x 7” 3-way 5.25” 3-way 4” 3-wayPower Handling 120w 90w 90w 75w 60wSystem Impedance 4-Ohm 4-Ohm 4-Ohm 4-Ohm 4-OhmFrequency Response 65-20kHz 65-20kHz 70-20kHz 80-20kHz 100-20kHzEfficiency (1w/1m dB) 89dB 89dB 89dB 88dB 88dBWoofer Mounting Depth 3.25” 2.25” 2.25” 2.25” 2.00”SEDONA SPEAKER S.693 S.653 S.52 S.42 S.573Size & Configuration 6” x 9” 3-way 6.5” 3-way 5.25” 2-way 4” 2-way 5” x 7” 3-wayPower Handling 80w 60w 50w 40w 60wSystem Impedance 4-Ohm 4-Ohm 4-Ohm 4-Ohm 4-OhmFrequency Response 50-20kH 80-20kHz 90-20kHz 100-20kHz 75-20kHzEfficiency (1w/1m dB) 90dB 89dB 87dB 85dB 89dBS.653BI.653BI.573IMPP Cone w/ Carbon Fiber Finish1.25” Mylar Midrange1” Mylar Tweeter1” Kapton Voice CoilButyl Rubber SurroundNomex Spider SuspensionQuick Disconnect Terminals3 ohm ImpedancePolypropylene ConeButyl Rubber Surround1” Aluminum Coil FormerMylar Midrange & TweeterSteel BasketSIGNAL PROCESSORSE.DZ1/2 DIN Dual Zone Equalizer• 2 Selectable Balanced RCA Inputs w/ Input Gain• Four 18dB Front Bands; 125Hz, 500Hz, 3.5kHz, 12kHz• Three 18dB Rear Bands; 50Hz, 600Hz, 6.3kHz• Independent Subwoofer Level Control• Selectable Subwoofer LPF; 32Hz, 64Hz, 125Hz• Up to 8V Front, Rear, & Subwoofer RCA Outputs• Fader Control• Red Backlit Control KnobsINT-5BOEM Integration w/ Bass Processor• 5 Channel Hi-Level Input• 4v-30v Input Sensitivity• Variable 30-80Hz Bass EQ• Variable 0-12dB Bass Boost• Variable Boost Q• Subwoofer Input Selector• 15-50Hz Subsonic FilterC.6F6 Farad Hybrid Power CapacitorC.10F10 Farad Hybrid Power Capacitor• 12-16 DCV Operation• Chrome Finish w/ Gloss Black Accents• Red Digital Voltage Display• Bolt Post for Any Gauge Ring TerminalsBP.8Bass Signal Processor• Variable 27-63Hz Bass EQ• Variable Boost Q• Boost Voltage Limitation Control• Selectable 35,50,80Hz Subsonic Filter• 10V Max Line Driver• Balanced Signal Inputs, Up To 15 Volts• Selectable Signal Grounding Mode• Selectable Ground Isolation• Dash Mount Remote Gain Control• THD: .003%• S/N Ratio: 130dBPROCESSORSCAPACITORSC.2F2 Farad Power CapacitorC.3F3 Farad Power Capacitor12-16 DCV Operation• Chrome Finish w/ Gloss Black Accents• Red Digital Voltage Display• Bolt Post for Any Gauge Ring TerminalsWoofer Mounting Depth 4.25” 3.125” 3.125” 2.875” 2.625”20 21

TweeterSPRO AUDIO MIDRANGEFlush, Surface, or Angle MountingAdjustable Eyeball DesignBuilt-in 12 dB In-Line CrossoverPeak Power HandlingDiaphrgam Size/MaterialImpedanceFrequency ResponseEfficiency (1w/1m dB)T.2100w1.00” Mylar4-Ohm2kHz-21kHz94dBMounting Depth 0.75”Peak Power HandlingDiaphrgam Size/MaterialImpedanceFrequency ResponseEfficiency (1w/1m dB)COMPRESSION TWEETERST.580w1.00” Aluminum4-Ohm15kHz-20kHz93dBMounting Depth 0.625”1.25” Aluminum Inverted Dome TweeterChassis Integrated Phase PlugHigh Strength Neodymium MagnetFlush or Surface Mounting Hardware Included12dB/Octave Passive Crossover IncludedPTC Tweeter Protection Switch2-WAY PRO AUDIO SPEAKER WITH COMPRESION TWEETER!MIDRANGEPM.654PM.658PM.804PM.808PM.104Size 6.50” 8.00” 10.00”Peak Power Handlin 170w 200w 350wImpedance 4-Ohm/8-Ohm 4-Ohm/8-Ohm 4-OhmFrequency Response 150-10kHz 120-8kHz 100-5kHzEfficiency (1w/1m dB) 96dB 97dB 98dBMounting Depth 2.75” 3.25” 4.25”2-WAY COAXIAL PM2.654 PM2.804 PM2.104Size 6.50” 8.00” 10.00”Peak Power Handlin 225w 300w 450wImpedance 4-Ohm 4-Ohm 4-OhmFrequency Response 150-8kHz 140-6kHz 85-4.5kHzEfficiency (1w/1m dB) 96dB 98dB 99dBMounting Depth 3.125” 3.50” 4.00”PT.2(pair)PT.4(pair)PRO2.XVRCrossover for all PM22-way Pro Audio Speakersw/ Compression TweeterNEODYMIUM PM654NX PM.804NXSize 6.50” 8.00”Peak Power Handlin 250w 350wImpedance 4-Ohm 4-OhmFrequency Response 180-10kHz 135-8kHzPT.52PT.54Efficiency (1w/1m dB) 97dB 98dBMounting Depth 2.75” 3.25”TWEETERS PT.2 PT.4 PT.5 PT.52 PT.54Peak Power Handling 90w 100w 100w 100w 100wDiaphrgam Size/Material 1.00” Titanium 1.00” Aluminum 1.75”Aluminum 2.00” Composite 2.00” CompositeImpedance 4-Ohm 4-Ohm 4-Ohm 4-Ohm 4-OhmFrequency Response 3kHz-20kHz 3kHz-20kHz 4kHz-20kHz 3kHz-20kHz 3kHz-20kHzEfficiency (1w/1m dB) 109dB 109dB 107dB 105dB 107dBPT.5 Mounting Depth 1.125” 1.50”-2.00” 2.50” 2.25” 3.25”22 23

SOURCE UNITSSOURCE UNITSPrecision Power INGENIX powered source units use a proprietary engine featuring 800 MHz CPU processor & WIN CE 6.0operating system. Commonly found in compact netbooks. Such lightning fast function processing has not been possible inan aftermarket automotive multimedia system, until now. INGENIX programming brings unique feature applications to yourfingertips.32GB SDHC & USB 2.0 ReaderGo ahead, take a second look....The primary menu of the INGENIX source units has an appealthat you might expect only from a computer. The LED backlight Full HD quality 800x480 screen resolution yields a crispimage. Drag any mode application icon from the slide menu atthe right side of the screen and drop it onto the desktop as ashortcut. Utilize the drop down widget menu for quick settingsaccess. The main menu background and brightness settingscan be set to change automatically at night. There’s even ascrolling marquee banner displaying your short message.Built-in GPS NavigationAll Ingenix powered source units come standard withGPS turn-by-turn navigation for USA & Canada (othercountries available). Set your destination and enjoytext-to-speech directions with lane guidance. Additionalfeatures include favorites list, programmable home destination,destination fuel estimates, multi-lingual, multigendervoices, speed limit warnings, and more. Mapsand POI data by TomTom.Digital Signal ProcessingDSP features include a digital 7-band equalizer w/ 9 factory presets & 2custom presets, real time analyzer, individual source level adjustment,variable subwoofer level control w/ low pass crossover, and sound stagingcontrols.Playback MP3, WAV, FLAC, & AC3 audio files, or MP4,WMV, DivX, & XviD video files from up to a 16GB SDHCcard or USB 2.0 mass storage device. Artwork transfersfrom enabled device, if available. INGENIX units willread files from a USB powered portable hard drive, up to250GB capacity.Bluetooth V2.1 + EDR ConnectivityStreaming Bluetooth Music (A2DP)Picture-in-PictureINGENIX is the first to bring the Picture-in-Picture function into the car. PIP allows uninterruptedvideo playback while simultaneouslyviewing the GPS navigation map in real time,as it happens. The picture can be re-sized andpositioned to 3 different ratios.Complete iPod Integration(requires IP-5C cable)Scroll through your iPhone, iPod Touch, Classic,or Nano to find your favorite tracks. Searchoptions include by Album, Artist, Genre, Playlist,or entire track list. Jump through lists byfirst alpha character scrolling.Bluetooth V2.1 with Enhanced Data Rate increasesdata transfer rates to 2.1 Mbit/s. Thislightning quick information transfer increasesclarity & virtually eliminates unwanted distortionduring calls and wireless MP3 audio playback.Most Bluetooth enabled Smartphoneswill transfer phone book contacts, view recentcall logs, and stream MP3 audio tracks.Pair your Bluetooth enabled cell phone, Smartphone,iPhone, or iPod Touch for wireless MP3payback. Use the touch screen controls for basicoperations.Multimedia File ManagerSort, view, play, move, or delete your multimedia& data files. No longer will you need acomputer on the go to manage your USB/SD/HDD Mass Storage devices.Speedometer & CompassAre larger wheels and tires throwing off yourADDITIONAL FEATURESspeedometer? Can’t figure which directionyou’re driving? Utilize the GPS based real-timeDual Zone for Rear Seat or Overhead EntertainmentAccepts Axxess OEM Steering Wheel Interfacespeedometer and directional compass to helpAdjustable Video Output Screen Ratio & Image PositioningJPG, BMP, & GIF Photo Browserout. Even set them as the screen saver forUtility Application w/ Memo Pad, Calculator, Calendar,Upload Custom Screen Saversconstant viewing.Car Maintenance, Texas Hold ‘em Poker, & World ClockRemote Control Sold Separately4V Front, Rear & Subwoofer Pre-amp OutputDigital & Analog TV Tuners AvailableFront Panel 3.5mm AUX A/V InputNTSC/PAL Video PlaybackA/V Input from Auxiliary Source50W x 4 MOSFET Speaker Outputs24Rear View Camera RCA Input w/ Trigger400NIT Panel Brightness25

SOURCE UNITSP-771NXDouble Din INGENIX AVN Source Unit w/Digital 7” LCD Touch ScreenGPS ON-BOARDPVI.265BiDouble DIN Multimedia Source Unit w/ Motorized 6.5" LCD720pSOURCE UNITSMulti-Region FM Frequency SteppingRemote Control Sold Separately800 x 480 Widescreen Resolution400NIT LED Backlight BrightnessMotorized 7” LCD w/ Preset Angle AdjustmentNoise Rejecting Copper Electroplated ChassisComplete Ingenix Operating SystemTomTom Turn-by-Turn GPS Navigation SystemPlayback from DVDR/RW or CDR/RW of MP3, MP4, & DivXPlayback From 32GB SD Card or USB of MP3, MP4, & DivXBluetooth V2.1+EDR Hands Free Calling from PhoneA2DP MP3 Audio Playback from Enabled DeviceComplete iPod Integration with IP-5CRCA A/V Input from Multiple Source IntegratonAUX A/V Input from Personal Media DevicesDual Zone for Rear Seat or Overhead DevicesAccepts Axxess Steering Wheel ModuleRear View Camera Input w/ Trigger5-Band Variable EQ w/ Presets, & Crossovers4V Pre-amp Front, Rear & Subwoofer Outputs52wx4 MOSFET Speaker OutputsMotorized Angle Adjustment 6.5” LCD Touch ScreenPlayback from DVDR/RW or CDR/RW of MP3, MP4, & DivXPlayback From 32GB SD Card or USB of MP3, MP4, & DivXBluetooth V2.0 Hands Free Calling from Enabled DeviceA2DP MP3 Audio Playback from Enabled DeviceComplete iPod Integration w/ Included CableAUX A/V Input for Personal Media DevicesID3 Tag Reading for Track & Artist InformationRear View Camera Input w/ Trigger4V Audio & Subwoofer RCA OutputFixed 80Hz Subwoofer Output52w x 4 MOSFET Speaker OutputsMulti-Region FM Frequency Stepping480x272 Widescreen Resolution500 NIT LED BrightnessPVI.170BiSingle Din Multimedia Source Unit w/ 7” Flip-Up LCD720pP-731NXSingle Din INGENIX AVN Source Unit w/Detachable Digital 7” LCD Touch ScreenMulti-Region FM Frequency SteppingRemote Control Sold Separately800 x 480 Widescreen Resolution400NIT LED Backlight BrightnessIP-5CFull Control iPod Cable forINGENIX Powered Source Units• Full Control of iPod Classic, iPhone, Nano, & iTouch• Charging of all Comaptible iPod Models• Scroll by Artists, Albums, Genres, or Playlists• Video Playback from Classic & iTouchGPS ON-BOARDMotorized 7” LCD w/ Preset Angle AdjustmentNoise Rejecting Copper Electroplated ChassisComplete Ingenix Operating SystemTomTom Turn-by-Turn GPS Navigation SystemPlayback from DVDR/RW or CDR/RW of MP3, MP4, & DivXPlayback From 32GB SD Card or USB of MP3, MP4, & DivXBluetooth V2.1+EDR Hands Free Calling from PhoneA2DP MP3 Audio Playback from Enabled DeviceComplete iPod Integration with IP-5CRCA A/V Input from Multiple Source IntegratonAUX A/V Input from Personal Media DevicesDual Zone for Rear Seat or Overhead DevicesAccepts Axxess Steering Wheel ModuleRear View Camera Input w/ Trigger5-Band Variable EQ w/ Presets, & Crossovers4V Pre-amp Front, Rear & Subwoofer Outputs52wx4 MOSFET Speaker OutputsREM-5Accessory Remote Controlfor Precision Power INGENIXSource UnitsMotorized Angle Adjustment 7" LCD Touch ScreenDetachable Theft Deterrent Front PanelPlayback from DVDR/RW or CDR/RW of MP3, MP4, & DivXPlayback From 32GB SD Card or USB of MP3, MP4, & DivXAUX A/V Input for Personal Media DevicesBluetooth V2.0 Hands Free Calling from Enabled DeviceA2DP MP3 Audio Playback from Enabled DeviceComplete iPod Integration w/ Included CableDual Zone for Rear Seat or Overhead EntertainmentProgramable Open or Closed Positioning After UseID3 Tag Reading for Track & Artist InformationRear View Camera Input w/ Trigger4V Audio & Subwoofer RCA Output52w x 4 MOSFET Speaker OutputsMulti-Region FM Frequency Stepping800 x 480 Widescreen Resolution400 NIT LED BrightnessPVI.134Single DIN DVD Multimedia Source Unit w/ Detachable 3.4” LCDPVI.134DRSingle DIN Digital Media Receiver w/ Detachable 3.4” LCDTheft Deterrent Detachable FaceplatePlayback of MP3, MP4, & DivX File Formats32GB SD & USB Readers for MP3, MP4, Divix PlaybackAUX Audio Input for Personal Media DevicesID3 Tag Reading for Track & Artist InformationAudio & Video RCA OutputsFixed Subwoofer RCA Output52w x 4 MOSFET Speaker OutputsMulti-Region FM Frequency Stepping720x420 Widescreen Resolution400 NIT LED Brightness26 27720p
