Operating instructions for condenser tumble dryer T 230 C

ContentsProblem solving guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23General problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23Check and fault indicator lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26To change the interior drum lamp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29Repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29PC indicator lamp (interface for service technicians). . . . . . . . . . . . . . . . . . . . 29Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30Front view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30Installation site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31Transporting the machine to its installation site . . . . . . . . . . . . . . . . . . . . . . . . 31Building under a continous worktop / in a row of kitchen units . . . . . . . . . . . . 31Replacing the lid. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31Levelling the machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32Room in which the dryer is located . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32Washer - dryer stack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32Before moving the machine again (e.g. when moving house) . . . . . . . . . . . . . 32External condensed water outlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33Setting up the drain hose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33Connection to a sink drain outlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34If you no longer wish to use an external condensed water outlet . . . . . . . . . . 34Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35Electrical connection U.K. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35Consumption data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37Programmable functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39Increased drying level in the COTTONS programmes . . . . . . . . . . . . . . . . . . . . . 39Increased drying level in the MINIMUM IRON programmes . . . . . . . . . . . . . . . . . 40Buzzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 413

Warning and Safety instructionsTo avoid the risk of accidents anddamage to the machine please readthese instructions carefully beforeusing it for the first time. Theycontain important information on itssafety, installation, use andmaintenance.Keep these instructions in a safeplace and ensure that new users arefamiliar with the content. Pass themon to any future owner of themachine.Correct useThe tumble dryer is only intendedfor drying fabrics which have beenwashed in a water solution, marked onthe manufacturer's care label as beingsuitable for tumble drying."Dry cleaning kits" for freshening upgarments in a tumble dryer areincreasingly available on the market. Ifusing, do so at your own risk, andfollow the instructions provided on thepackaging.Any other applications may bedangerous. The manufacturer is notliable for damage resulting fromimproper use or operation.Technical safetyBefore setting up the machine,check it for any externally visibledamage.Do not install or use a damagedmachine.Before connecting the machine,ensure that the connection data onthe data plate (voltage and connectedload) match the mains electricitysupply. If in any doubt, consult aqualified electrician.The electrical safety of thismachine can only be guaranteedwhen continuity is complete between itand an effective earthing system whichcomplies with local and nationalregulations. It is most important that thisbasic safety requirement is present andregularly tested, and where there is anydoubt the household wiring systemshould be inspected by a qualifiedelectrician. The manufacturer cannot beheld liable for the consequences of aninadequate earthing system (e.g.electric shock).Do not connect the appliance tothe mains electricity supply by anextension lead. Extension leads do notguarantee the required safety of theappliance (e.g. danger of overheating).4

The machine is built in accordancewith current safety requirements.Unauthorised repairs could result inunforeseen dangers for the user, forwhich the manufacturer cannot acceptliability. Repairs should only beundertaken by a Miele approvedtechnician.Ensure current is not supplied to themachine until after maintenance orrepair work has been carried out.Faulty components must only bereplaced by genuine Miele originalspare parts. Only when these parts arefitted can the safety standards of themachine be guaranteed.If the connection cable is faulty itmust only be replaced by a Mieleapproved service technician to protectthe user from danger.In countries where there are areaswhich may be subject to infestationby cockroaches or other vermin, payparticular attention to keeping themachine and its surroundings in aclean condition at all times. Anydamage which may be caused bycockroaches or other vermin will not becovered by the machine guarantee.Warning and Safety instructions5

Warning and Safety instructionsIn the event of a fault or forcleaning purposes, the machine isonly completely isolated from theelectiricty supply when:– it is switched off at the wall socketand the plug is withdrawn, or– it is switched off at the mains, or– the mains fuse is withdrawn.OperationThis equipment may only be usedin mobile installations such asships, caravans, aircraft etc. if a riskassessment of the installation has beencarried out by a suitably qualifiedengineer.The dryer must not be used withoutthe fluff filters in place or if the flufffilters are damaged in any way.The fluff filters must be thoroughlydried after cleaning. If they are stilldamp or wet when replaced there is arisk of faults occurring when themachine is used.The dryer must not be used withoutthe condenser unit in place.Do not install the machine in aroom where there is a risk of frostoccurring. At temperatures aroundfreezing point the machine may not beable to operate properly.There is a risk of damage if thecondensed water is allowed to freeze inthe pump, hoses and / or condensedwater container.The ambient room temperature shouldbe between +2°C and +35°C.If the water is drained externallythrough the drain hose instead ofbeing collected in the condensed watercontainer, make sure the drain hose issecurely attached if you hang it in asink or basin to avoid the hose slippingand the water causing damage.Condensed water is not drinkingwater. It can cause healthproblems in both people and animals.Always keep the area around themachine free of dust and fluff. Dustdrawn into the machine can, over time,cause blockages in the condenser unit.6

Warning and Safety instructionsDo not let anyone sit or lean on thedoor, as this can cause themachine to tip up.of:Always close the door after use.This way you will avoid the danger– children climbing onto or into thedryer or hiding things in it.– pets or other small animals climbinginto it.To prevent the risk of fire thefollowing textiles must not bedried in this machine:– fabrics which contain a largeproportion of rubber, foam rubber orrubber like materials.– items which contain padding orfillings (e.g. pillows, jackets).– items which have been treated withinflammable cleaning agents.– items which have been splashed withhair lacquer, hair spray, nail varnishremover or similar substances.– items which have been soiled withoils or residues containing grease(kitchen oils, cosmetics etc.).– items soiled with wax or otherchemicals (e.g. mops and floorcloths).– items which have not beenthoroughly cleaned and which arestill soiled with grease or oil, e.g.workwear. Such clothing may requirea heavy duty detergent to get themclean. If necessary consult thedetergent manufacturer for advice.Safety with childrenKeep children away from themachine at all times and supervisethem whilst you are using it. Thismachine is not a toy. To avoid the risk ofinjury, do not allow children to play onor near it or to play with its controls.Supervise its use by the elderly orinfirm.Using accessoriesAccessory parts may only be fittedwhen expressly approved by Miele.If non-Miele parts are used with thismachine, guarantee, performance andproduct liability claims may beinvalidated.Disposal of your old machineBefore discarding an old machine,switch it off at the wall socket andunplug it. Render the plug useless andcut off the cable directly behind themachine. This should be done by acompetent person.The manufacturer cannot be heldliable for damage caused by noncompliancewith these Warning andSafety instructions.7

Caring for the environmentDisposal of the packingmaterialThe transport and protective packinghas been selected from materials whichare environmentally friendly for disposaland can normally be recycled.Ensure that any plastic wrappings,bags etc. are disposed of safely andkept out of the reach of babies andyoung children. Danger of suffocation!Rather than just throwing thesematerials away, please ensure they areoffered for recycling.Disposal of your old applianceElectrical and electronic appliancesoften contain materials which, ifhandled or disposed of incorrectly,could be potentially hazardous tohuman health and to the environment.They are, however, essential for thecorrect functioning of your appliance.Please do not therefore dispose of yourappliance with your household waste.competent person. The plug must berendered useless and the cable cut offdirectly behind it to prevent misuse.See the "Warning and Safety" section ofthis booklet for further details.Energy saving tipsTo avoid unnecessarily long dryingtimes and high consumption of energy:– Make sure that your laundry isthoroughly spun before drying.The higher the spin, the greater thesavings that can be made in energyand time during drying.– Load according to the optimumamount of laundry recommended forthe programme being used (seeProgramme chart).Underloading is uneconomical.Overloading gives a poorer quality ofdrying and may cause unnecessarycreasing.– Make sure the room in which thedryer is located is well ventilated.– Make sure the fluff filters are cleanbefore using the dryer.– Check the condenser unit from timeto time and clean it when necessary.Please dispose of it at your localcommunity waste collection / recyclingcentre and ensure that it presents nodanger to children while being storedfor disposal.It should be unplugged or disconnectedfrom the mains electricity supply by a8

Control panela Programme selectorThe programme selector can beturned clockwise or anti-clockwise.b Programme sequence and checklampsc Start buttonPress the Start button to start aprogramme.The Start indicator lamp will flash assoon as a programme can bestarted. It lights up constantly oncethe programme has started.d I-On/0-Off buttonTo switch the machine on or off / tointerrupt a programme.The Anti-crease/Finish lamp will lightup as confirmation that the machinehas been switched on.e Door ButtonTo open the door / to cancel aprogramme.Pressing this button will open thedoor even when the machine isswitched off at the mains.If the machine is switched on at themains and the door is opened thedrum lighting will come on. It will goout a few minutes later to saveenergy.PC indicator lightThe indicator light marked PC is usedby Miele Service technicians as anoptical interface.9

Notes on laundry careWash care labelsBefore drying check the dryingsymbol on the wash care label.Significance of symbols:q Dry at normal temperaturer Dry at low temperaturesDo not tumble dryIf no symbol is featured, dry at yourown risk applying the followingprinciples:Cotton and minimum iron items shouldbe dried using the appropriateprogramme for the degree of dryingrequired. See programme chart.For delicates and fabrics with thefollowing wash care label r dry usingthe Low temperature option.Never overload the drum. Do notexceed the maximum recommendedloads given in the "Programmechart". Overloading can causeunnecessary wear and tear to thelaundry, give a disappointing dryingresult and cause more creasing.Do not put soaking wet items intothe tumble dryer. Spin themthoroughly after washing using theappropriate spin speed.Tips on dryingWoollens and wool blends tend tobecome matted and shrink if dried in atumble dryer. They can, however, bepartially dried using the Woollens handcare programme.Items filled with down.The fabric lining on these garmentsmay shrink depending on the quality.They can be partially dried using theSmoothing programme.Pure linen should only be machinedried if specified as suitable by themanufacturer on the wash care label,as the surface of the fabric mayotherwise "roughen". These items canbe partially dried using the Smoothingprogramme.Woven and loopknit materials (e.g.T-shirts, knitted garments) have atendency to shrink, depending on theirquality and this is made worse by overdrying.When purchasing thesegarments it is advisable to take theirshrinkage properties into account.Minimum iron fabrics and 100% cottonshirts or blouses tend to crease more,the larger the load being dried,particulary when the weave of thefabric is very fine. Reduce the load oruse the MINIMUM IRON - Hand ironprogramme with a max. load of 1 kg. Ifthis is unsatisfactory use the Specialcare "Smoothing" setting, then hang thegarments on a hanger to dry.Starched laundry can be dried in thetumble dryer. In order to achieve theusual finish, double the amount ofstarch should be used.New dark coloured garments should bedried separately from light colouredgarments to avoid the danger of coloursrunning.10

Programme chartProgrammes Fabric type Special notesCOTTONSDrying levelsNormal+Normal (2)Low temperatureHand iron (2)Machine ironSingle and multi-layeredfabrics, e.g. mixed load ofcotton fabrics (e.g.towelling, jerseywear).Load of similar cottonfabrics (jersey wear,flannelette sheets,towelling).For drying delicate fabricswith the symbol r (e.g.acrylic garments).Cotton or linen fabrics (e.g.table linen, bed linen,starched laundry etc.).Cotton or linen fabrics,including starched laundryfor machine ironing.(1) Weight of dry laundry(2) Note for test institutes:Programme setting for testing according to EN 61121 standardmaximum load:5 kg (1)-If laundry is still too damp,then:- finish drying using Timeddrying Warm air.- use the Normal+programme next time.Laundry is dried using theNormal programme, but at alower temperature.-The laundry should be rolledup to prevent it from dryingout before it can be ironed.11

Programme chartProgrammes Fabric type Special notesMINIMUM IRONDrying levelsNormal+Normal (2)Low temperatureHand ironMinimum iron items whichare made of synthetic orblended fabrics (e.g.pullovers, dresses, trousers)which are not driedadequately in the Normalprogramme.Minimum iron shirts, tablecloths etc. made of mixedfibres, e.g. cottons /synthetics.For drying delicate fabricswith the symbol r (e.g.acrylic garments).Minimum iron shirts, tablecloths etc. made of mixedfibres, e.g. cottons /synthetics, which are still tobe hand ironed.(1) Weight of dry laundry(2) Note for test institutes:Programme setting for testing according to EN 61121 standardmaximum load:2.5 kg (1)Spin minimum iron fabricsfor at least 30 seconds in thewashing machine beforedrying them.Spin minimum iron fabricsfor at least 30 seconds in thewashing machine beforedrying them.Laundry is dried using theNormal programme, but at alower temperature.Spin minimum iron fabricsfor at least 30 seconds in thewashing machine beforedrying them.Spin minimum iron fabricsfor at least 30 seconds in thewashing machine beforedrying them.For extra special care ofdelicate fabrics and toreduce creasing even more,reduce the load to 1 kg. Seealso "Special careprogrammes".12

Programme chartProgramme Fabric type Special notesSpecial care programmesWoollensmaximum load: 2 kg (1)hand careWoollen fabrics To refresh and fluff up woollengarments quickly. Remove garmentsimmediately at the end of theprogramme. Do not repeat.Woollen fabrics are not driedcompletely by this programme.Smoothing maximum load: 2.5 kg (1)Cottons and linen fabrics.Minimum iron items madeof cotton, blended fabricsor synthetics, e.g. cottontrousers, shirts.Smooths out creasing caused duringthe spin cycle in the washingmachine.Fabrics are not completely dried inthis programme.Remove garments immediately at theend of the programme and place ona line or hangers to dry.TIMED DRYING maximum load: 5 kg (1)Warm air Individual items-(e.g. bathing costumes,bath towels, tea-towels).Multi-layered fabric whoselayers have different dryingcharacteristics.Cool air Items which are to be airedonly.-13

How to dry correctlyA Prepare the laundry^ As far as possible, sort laundry for:- the type of fibre or weave,- the degree of dryness required,- similar size of items,- the moisture content afterspinning.This will help towards achieving aneven drying result.Fasten duvet covers etc. to preventsmall items from being rolled up insidethem.Do up zips, hooks and eyes etc.Tie fabric belts, apron strings.Sew in or remove underwiring frombras.Do not overload the drum.Overloading can cause unnecessarywear and tear to the laundry andgive a disappointing drying result.See the "Programme chart" formaximum recommended loads.^ Before closing the door check thatthe fluff filter is correctly positioned inthe door.Make sure there is no detergentdispenser ball etc. in with thelaundry, as this could melt anddamage the machine and thelaundry.B Load the drum and switchon the dryer^ Press the door button and open thedoor.^ Load the laundry loosely into thedrum.When closing the door make sureitems of laundry cannot be trappedby the door, as this will causedamage to the laundry.^ Shut the door either with a gentleswing or lean against it and push itshut.^ Switch the dryer on by pressing the"l-On/0-Off" button.14

How to dry correctlyC Select a programme^ Turn the programme selector to therequired programme.See "Consumption data" chart forprogramme durations.D Start the programme^ Press the Start button.The drying cycle begins.The drying stage reached is shown bythe sequence indicator lamps on theright hand side of the control panel.At the end of the drying phase acooling down phase commences tocool the laundry down. The Cool airindicator lights up.The required degree of dryness hasnow been reached.Low temperature^ For drying particularly delicatefabrics (care symbol r) e.g. acrylicsturn the programme selector to theLow temperature position.Because the temperature is reduced forthe Low temperature settings,programme durations will be increasedand laundry will take longer to dry.15

How to dry correctlySelecting a different programmeAs long as the cooling down phase orthe anti-crease phase has not beenreached it is possible to change aprogramme after it has started byturning the programme selector to adifferent programme position.Interrupting a programme^ Switch the machine off with theI-On/0-Off button.To continue drying:^ Switch the dryer on with theI-On/0-Off button.With COTTONS and MINIMUM IRONprogrammes the programme willcontinue unless the cooling down oranti-crease phase has been reached.With other programmes:^ Press the Start button.Adding or removing items,Do not touch the back of thedrum when adding or removingitems. The drum could be very hot -danger of burning.^ Open the door. Take out or add itemsas required.^ To continue drying close the doorand press Start.To cancel a programme^ Turn the programme selector toFinish or open the door .The programme has been successfullycancelled when only the Anti-crease/Finish indicator lamp is on.E At the end of a programmeAt the end of a programme the Anticrease/Finishlamp will come on in thesequence display and the buzzer willsound.The drum will continue to rotate atintervals to prevent laundry creasing, ifyou do not wish to remove it immediately.This anti-crease phase lasts for amaximum of 60 minutes, except withthe Woollens hand care programme.^ Press the Door button and open thedoor.^ Remove the laundry.Make sure that the drum is empty. Ifitems are left in the dryer, they couldbe damaged by overdrying whenthe dryer is next used.^ The condensed water containershould be emptied after every dryingcycle or as soon as the Empty outcontainer indicator lamp comes on.^ Clean the fluff filters.^ The condenser unit should becleaned on a regular basis (see"Cleaning and Care").^ Close the door.^ Switch the dryer off by pressing thel-On/0-Off.16

Cleaning and careEmptying the condensedwater containerThe condensed water will be collectedin the condensed water containerunless the machine has been fitted witha drain hose (see installation).The condensed water containershould be emptied after everydrying cycle or as soon as theEmpty out container indicator lampcomes on.The drying programme will beinterrupted if the maximum level of thecondensed water container is reached.The Empty out container indicator lampcomes on and the buzzer sounds.^ Open the shutter and empty out thewater.^ To replace the container hold it at aslight angle (as when removing it)and push it in gently until you feel itclick into position.^ Before starting a new programme,first switch the machine off and thenon again. The Empty out containerindicator lamp will go out.Condensed water should not beconsumed. It could lead to healthproblems for people and animals.^ Grip the container firmly with bothhands, as shown, and pull it outslightly towards the right-hand side.^ Hold the container with both handsand carry it in a horizontal position.Condensed water can be put tohousehold use (e.g. used in a steamiron or humidifier). To ensure that anyresidual particles of fluff in thecondensed water are removed beforeuse, pass it through a fine sieve orpaper filter first.17

Cleaning and careCleaning the fluff filtersThe fluff which is created by the dryingprocess is collected by the fluff filters inthe door and the door opening. Cleanthe filters after each drying programme.Cleaning them whilst dry^ Remove any fluff from the hollow partof the door holder. A cleaning brushis available as an optional extra fromyour Miele dealer or the Miele SpareParts Department.Tip: You can also use a vacuumcleaner.^ Once clean, push the filter back intothe door holder until it clicks intoposition. Ensure it is facing thecorrect way.^ Also clean the door seal (2) with adamp cloth.^ Open the door and pull the fluff filter(1) out of the door as illustrated.^ Use your fingers to remove the flufffrom the two fluff filters in the dooropening.^ Close the door.^ Use your fingers to remove the flufffrom the surface of the filter.18

Cleaning and careCleaning them with waterIf there is a great deal of compactedfluff on any of the filters, they can beremoved and cleaned under hotrunning water.^ To remove the fluff filter from the doorholder see previous page.^ Place the filters back in the dooropening (the left and right filters areidentical) with the finger holdersfacing upwards. See illustration.Cleaning the tumble dryerDisconnect the machine from themains electricity supply.^ Clean the housing and control panelwith a slightly damp cloth and a milddetergent or soapy water.^ The drum and other stainless steelparts can be cleaned with a suitableproprietary stainless steel cleanerfollowing the manufacturer'sinstructions.^ To remove the filters in the dooropening, grip the holder and pushupwards in the direction of the arrowto remove it.^ Rinse the filters under hot, runningwater.^ Then shake the filters until no morewater droplets are visible.^ Dry the filters thoroughly with care.,Do not replace them if they aredamp or wet. Damp or wet filterscould cause operational faults.Do not use solvents, abrasivecleaners, glass cleaners or allpurposecleaners. These coulddamage plastic sufaces and otherparts. The machine must never behosed down.^ Dry all parts with a soft cloth.^ A microfibre E-Cloth is available fromthe Miele UK Spare Parts Departmentwhich is suitable for cleaningsurfaces such as stainless steel,glass, plastic and chrome without theuse of chemicals. It can be washed300 times.^ Push the large filter back into thedoor holder until it clicks into position.Ensure it is facing the correct way.19

Cleaning and careCleaning the condenser unitDetergent residue, hair and fine flufffrom the dryer can get through the flufffilters and block the condenser unit.Dust from the room in which the dryer isinstalled can also get into thecondenser unit and cause a blockage.Check the condenser unit at leasttwice a year. If the dryer is usedfrequently then clean the condenserunit after approx. 100 drying cycles.Removing the condenser unit^ Turn the lever on the inner coverdownwards to the vertical position.^ Pull the cover forwards^ Then remove it by pulling itdiagonally upwards.^ Open the service panel by pressingthe two lower corners at the sametime (see illustration).The hooks at the side will prevent thepanel from falling off.^ Now the remove the panel by pullingit diagonally upwards.^ Then place it to one side.^ Turn the lever on the condenser unitto the vertical position.20

Cleaning and careIf you cannot see any fluff:^ Replace the condenser unit (seefollowing page).If you can see some fluff:^ Clean the condenser unit asdescribed below.^ Pull the condenser unit out of itshousing by the handle.Cleaning the condenser unit^ When rinsing the condenser unit,make sure you position it as shownin the next two illustrations.Checking the condenser unit^ Hold the condenser unit up to thelight as shown.^ Check to see if there is any fluffinside it.The arrows in the illustration aboveindicate where to look.^ Use a shower head or similar to rinsethe unit out as shown.21

Cleaning and careReplacing the condenser unit^ With the handle facing upwards,push the condenser unit back intoposition in its housing.^ Turn the lever down to the horizontalposition, making sure that the hookon the lever clicks into the groove.When replacing the inner cover aftercleaning, ensure that the rubber sealfits correctly into the groove.^ Then flush the unit through from thefront.^ Check the condenser unit again forany visible fluff and if necessary flushit through again until it has all gone.^ Remove any soiling still visible insidethe housing unit.^ Also make sure the rubber seals areclean.The rubber seals must not beremoved and must be free of kinks.^ Shake any excess water out of theunit until no more water droplets arevisible.^ Replace the cover making sure thehooks locate correctly. Hold it at anangle and push it gently downwards.^ Then turn the lever upwards into thehorizontal position to lock the cover.^ Replace the service panel and pressthe upper edge until it clicks intoposition.It is important to ensure that both thecondenser unit and the cover arecorrectly positioned and locked.Otherwise water may leak from themachine.22

Problem solving guideWith the help of the following notes minor faults in the performance of themachine, some of which may result from incorrect operation, can be put rightwithout contacting the Service Department.,Repair work to electrical equipment should only be carried out by a suitablyqualified person in accordance with local and national safety regulations.Repairs and other work by unqualified persons could be dangerous. Themanufacturer cannot be held liable for unauthorised work.General problemsProblem Possible cause RemedyThe tumble dryer fails tostart when switched on.Items made of syntheticfibres are charged withstatic electricity afterdrying.No obvious cause.Synthetic fibres tend toattract static charge.– Have you followed theswitch-on procedurecorrectly (see “How todry correctly”)?– Is the plug correctlyinserted in the socketand switched on?– Is the door closedproperly?– Has the fuse or circuitbreaker tripped?Static charge can bereduced by adding afabric conditioner to thefinal rinse in the washingmachine or a fabricconditioner sheet to theload in the dryer.23

Problem solving guideProblem Possible cause RemedyThere is a build upof fluff.The laundry is notsufficiently dry.The interior drumlighting does notcome on.Fluff is principally the resultof friction when garmentsare being worn andwashed. Machine dryinghardly causes any fluff toform and has beenestablished by researchinstitutes to have no effecton the lifetime of fabric.The load consisted ofdifferent fabrics.The lighting switched offautomatically.The lamp needs changing.Fluff is collected by the flufffilters and can be easilyremoved (see "Cleaningand Care").– Finish drying using"Timed drying - Warmair".– Select a more suitabledrying programme nexttime (see "Programmechart").The lighting only comes onwhen the door is opened ifthe dryer is switched on. Tosave energy the lightinggoes out after a while if thedoor is left open.Change the lamp asdescribed at the end of thissection.24

Problem solving guideProblem Possible cause RemedyThe drying processgoes on too long oreven switches off.Important: Before attempting to remedy one of thefollowing causes, switch the dryer off and switch on againto start the programme again.Ventilation to and from thedryer may be insufficient(e.g because it is installed ina small room). This hascaused the temperature inthe room to rise sharply.The fluff filters are cloggedup with fluff or were still wetwhen they were replaced.The laundry has not beenspun sufficiently.The tumble dryer has beenoverloaded.Metallic components, e.g.zips have prevented thedryer from registering thecorrect moisture level in thelaundry.Detergent residues, hair andfine fibres can block up thecondenser unit.The vents below the doorare blocked.Open a door or windowwhile the machine is inoperation for increased airflow.– Remove any fluff.– The fluff filters must becompletely dry.Make sure that your laundryis thoroughly spun athighest spin speed for thetype of fabric.Do not exceed the maximumload for the programmeselected.– Close zips and fasten anyhooks next time.If the problem occurs again,dry garments with long zipsusing "Timed drying - Warmair".Check the condenser unitfrom time to time and cleanit if necessary (see"Cleaning and Care").Remove any objects that areblocking the vents.25

Problem solving guideProblem Possible cause RemedyThe condenser unitservice panel will notshut.Water leaks from themachine after thecondenser unit hasbeen cleaned.The inner cover of thecondenser unit has notbeen locked properlyand/or the condenserunit has not beenpositioned correctly.Fluff has collected atthe bottom of thecondenser unit housing.Check and fault indicator lampsProblem Possible cause RemedyThe Empty outcontainer indicatorlamp comes on.The programme hasbeen interrupted, theindicator lamp forHand iron or Machineiron is flashing, andthe buzzer sounds.The condensed watercontainer is full or thereis kink in the drain hose.There is no obviouscause.– Ensure that the condenserunit is positioned correctlyand lock the cover.– Check the rubber seals.– Use a cloth to remove anyfluff from the inside of thecondenser unit housing.– Empty out the condensedwater container.– Check the drain hose.– Before starting a newprogramme, first switch thedryer off and then on again.– Switch off the dryer.– Then switch the dryer backon and start the programmeagain.If the programme stops againand an indicator lamp flashes,there is a fault. Contact theMiele Service Department.26

Problem solving guideProblem Possible cause RemedyThe programme hasstopped, the Anticrease/Finishlamp hascome on in thesequence display andthe buzzer is sounding.This is not a fault.The electronic unit hasrecognised that there isno laundry in the drumand cancelled theprogramme.Drying individualgarments or items whichare already dry can alsocause the programme tobe stopped.Use the "Timed drying -Warm air" programme todry individual items.Before changing aprogramme: Open andclose the drum door.27

Problem solving guideTo change the interior drum lampDisconnect the machine from themains electricity supply.^ Open the door.You will find the interior lamp cover atthe top of the drum aperture.The lamp specification andmaximum wattage is stated on thedata plate and on the lamp cover.^ Replace the lamp.^ To close the cover push it upwardsand press it on the left and right untilyou hear it click into position.,Ensure that it is fitted intoposition securely, as any moisturecould cause a short circuit.^ Insert a suitable tool, such as a widebladed screwdriver, under the sideedge of the lamp cover as illustrated.^ Apply a little pressure and whilstdoing so turn your wrist in thedirection of the arrow to open thecover.The cover will open downwards.The temperature resistant lamp shouldonly be ordered from your Miele dealeror the Miele Spare Parts Department.28

Problem solving guideAfter sales serviceRepairsIn the event of any faults which youcannot remedy yourself, please contact– your Miele Dealer or– The Miele Service Department (seeback cover for address).When contacting the ServiceDepartment, please quote the modeland serial number of your machine,both of which are shown on the dataplate situated on the right hand sidebelow the drum aperture.PC indicator lamp (interface forservice technicians)The indicator lamp marked PC on thefascia panel is the interface used bythe Miele service technicians duringservice work for testing purposes.Optional accessoriesOptional accessories for these dryersare available from your Miele Dealer orfrom the Miele Spare Parts Department.Please note that telephone calls maybe monitored and recorded toimprove our service.29

InstallationFront viewa Mains connection cableb Condensed water containerc Control paneld Doore Service panel for condenser unitf Four height-adjustable screw feetg External drainage options (e.g. viawash basin, wash basin drain outlet,or gully).30

InstallationInstallation site,Make sure the dryer door can beopened without hindrance afterinstallation.Transporting the machine to itsinstallation siteWhen moving the machine you canhold it by the lid where it protrudes tothe rear of the dryer.To manoeuvre the dryer out of itspacking case to its installation site youwill also need to hold it by the front feet.Building under a continous worktop /in a row of kitchen unitsThe dryer should not be installednext to a refrigerator or freezer. Thewarm air expelled from the rear ofthe dryer would increase thetemperature around therefrigerator's/freezer's heatexchanger causing the compressorto run continuously.If it is not possible to install the dryeranywhere else, then the refrigerator/freezer must be sealed off from thedryer.,A building under kit* is requiredwhich must be fitted by a suitablyqualified person.The machine lid is replaced by acoverplate. It is essential that thecoverplate is fitted to ensureelectrical safety.The building under kit is supplied withits own installation instructions.N.B. When built under running timesmay be longer.– The electrical socket must belocated in an accessible positionnear the machine.With niche heights of:– 840 mm, longer screw feet* arerequired.– 870/885 mm - 915/930 mm, one ortwo height adjustment frames* arerequired.* Available as an optional accessoryfrom your Miele dealer or the MieleSpare Parts Department.If you wish to push your machine undera worktop and there is space to do thiswithout removing the lid, the buildingunder kit is not necessary. Otherwisethe building under kit is essential.Replacing the lidIf the lid has been removed in order tofit a cover plate, ensure that, if the lid isreplaced, it fits securely into the rearholders. Otherwise, it is not properlysecure for transport.31

InstallationLevelling the machineThe machine must be perfectly level toensure safe and proper operation.Room in which the dryer is locatedAir taken in for use in the dryingprocess will be warm when it isexpelled from the rear of the dryer. Thisexpelled air heats up the air in theroom. It is therefore very important toensure that the room is adequatelyventilated, particularly if the dryer islocated in a small room. Otherwiserunning times and energy consumptioncould be increased.Washer - dryer stackThe tumble dryer can also becombined with a Miele washingmachine in a washer-dryer stack. To dothis the appropriate stacking kit* (WTV)to match your washing machine isrequired.* Available as an optional accessoryfrom your Miele dealer or the MieleSpare Parts Department.,Stacking kits must be fitted by asuitably qualified fitter.^ The screw feet can be adjusted tocompensate for any unevenness inthe floor.,The ventilation gaps in the plinthmust not be covered over as thiswould prevent a sufficient intake ofair.Before moving the machine again(e.g. when moving house)After each use a small quantity ofcondensed water will collect in the areaaround the pump. This water can runout if the machine is tipped up when itis being moved. It is a good idea to runthe Cool air programme forapproximately 1 minute before movingthe machine. Any remainingcondensed water will then be fed intothe condensed water container or outthrough the drain hose.32

InstallationExternal condensed wateroutletWhen drying is in progress, condensedwater is pumped into the condensedwater container through the drain hoseat the back of the dryer. Thecondensed water can also be drainedoff directly if the machine is installednear a sink, drain outlet etc. so thatthe condensed water container doesnot have to be emptied.The drain hose (approx. 2 m long) isstored in the dryer. It must be pulledout of the dryer to its full extent ifcondensed water is to be drainedexternally. Maximum delivery head:1 m.If it is not long enough, an extensionhose is available as an optionalaccessory through your dealer or fromthe Miele Spare Parts Dept.Setting up the drain hoseFrom the back of the dryer at the top:From the back of the dryer at thebottom:^ Unclip the drain hose from clip (3).^ Then pull the drain hose completelyout of the dryer towards the left (4)(See illustration). Important:,Do not let the drain hosebecome kinked, as this coulddamage it.,If you want to drain the water offinto a sink you will need to securethe hose carefully, e.g. by tying it toa tap to make sure it cannot slipduring use. Otherwise there is a riskof overflowing water which couldcause damage.Use the bow-shaped guide to preventthe drain hose from becoming kinked(see "Front view" illustration).^ Unclip the drain hose from clip (1).^ Then pull it off holder (2).33

InstallationConnection to a sink drain outletThe drain hose can be connecteddirectly to a sink drain outlet.If this nut has a flat disc sealing it youshould take the disc out first.Important: if this nut has a washer orseal in it this must not be removed!^ Attach the end of the hose to adapter1.^ Use a screwdriver to tighten hoseclip 3 up close to the nut.If you no longer wish to use anexternal condensed water outlet,Do not push the drain hoseback into the dryer. Doing this couldcause it to become kinked anddamaged in the dryer.^ Remove the following from the backof the dryer at the bottom:Adapter 1 and hose clip 3 behind it.^ Loop the drain hose up.^ Use a suitable cable tie to secure thelooped hose to the back of the dryer,or simply lay the looped hose behindthe dryer.^ Attach the open end of the drainhose back onto the holder at theback of the dryer at the top (seeholder 2 in "Pulling out the drainhose").^ Fit adapter 1 to the sink drain outletusing nut 2.34

Electrical connectionElectrical connection U.K.All electrical work should be carried outby a suitably qualified and competentperson, in strict accordance withnational and local safety regulations.Ensure power is not supplied to theappliance until after installation workhas been carried out.The appliance is supplied with a mainscable with moulded plug ready forconnection to a 230-240V mainssupply. The voltage and connectedload are given on the data plate.Please ensure these match thehousehold mains supply. The fuserating is quoted on the plug.Connection should be made via asuitable switched socket which is easilyaccessible after installation.For extra safety it is advisable to installa residual current device (RCD), with atrip current of 30 mA (in accordancewith DIN VDE 0664, VDE 0100 Section739).Do not connect via an extension lead.Extension leads do not guarantee therequired safety of the appliance (e.g.danger of overheating).Non-rewireable plugs BS 1363The fuse cover must be refitted whenchanging the fuse, and if the fuse coveris lost, the plug must not be used until asuitable replacement is obtained. Thecolour of the correct replacement coveris that of the coloured insert in the baseof the plug, or the colour that isembossed in words on the base of theplug (as applicable to the design ofplug fitted).Replacement fuses should be ASTAapproved to BS 1362 and have thecorrect rating. Replacement fuses andfuse covers may be purchased fromyour local electrical supplier.WARNING: THIS APPLIANCEMUST BE EARTHED35

Consumption dataProgramme Capacity Final spin speed(in a domesticwashing machine)ElectricityconsumptionDrying timeincl.coolingdown timekg rpm kWh MinutesCOTTONSNormal + 5.0 12001400160018002.802.652.402.3577746766Normal (1) 5.0 800 (70 % residual moisture) 3.40 92Normal 5.0 12001400160018002.652.552.252.20Hand iron (1) 5.0 800 (70 % residual moisture) 2.75 74Hand iron 5.0 1200140016001800Machine iron 5.0 1200140016001800MINIMUM IRON2.001.901.601.551.601.501.201.15Normal (1) 2.5 1000 (50 % residual moisture) 1.25 39Hand iron 2.5 1000 1.10 35Special careWoollens Hand care 2.0 - 0.20 4Smoothing 2.5 - 0.30 9(1) EN 61121 test programmeEN 61121 Standard testingBefore testing in accordance with EN 61121, dry a 3 kg load of cotton laundrywith 70% residual moisture as per the above standard using the Normal Cottonsprogramme without selecting any additional functions.Consumption data can vary from the nominal values given above dependingon the size of the load, types of textiles, residual moisture levels after spinning,fluctuations in the electricity supply and any additional options selected.74716463575347464744373636

Technical dataHeightHeight without lidWidthDepthDepth with door openWeightDrum volumeMaximum capacityCapacity of condensedwater containerLength of connection cableMaximum delivery headMaximum drain hose lengthVoltageRated loadFuse ratingLamp wattageEnergy consumptionTest certificates awarded85 cm (adjustable +0.7/- 0.7 cm)82 cm59.5 cm58 cm106 cm54 kg100 litres5 kg dry weightapprox. 3.5 litres1.60 m1 m3 msee data platesee data platesee data platesee data platesee "Consumption data"Radio/TV suppressed, VDE37

Programmable functionsfor changingstandard settings38

Programmable functionsIncreased drying level in theCOTTONS programmesThe machine is designed to dryusing as little energy as possible.However, if you require the laundry tobe drier, it is possible to reduce thefinal moisture level in the COTTONSprogrammes. Note that programmedurations will be longer if this optionis activated.The machine is supplied ex-works withthis option switched off. It can beactivated is wished.Follow steps A to G to programme andstore in memory.The programmable functions areactivated with the help of the Startbutton and the programme selector.Before you begin, first ensure that:– The tumble dryer is switched off.– The door is closed.– The programme selector is at Finish.A Press the Start button and keep itpressed in whilst carrying out stepsB to C.B Switch the dryer on with theI-On / 0-Off button.C Wait until the Start indicator lampcomes on . . .D . . . and then release the Start button.E Turn the programme selector to theCOTTONS Normal position.– If the Drying indicator lamp is not on,the increased drying level isdeactivated.– If the Drying indicator lamp isflashing, the increased drying level isactivated.F Pressing the Start button switchesbetween activating and deactivatingincreased drying.G Switch the machine off with theI-On / 0-Off button.The setting you have selected is nowstored in memory. You can change itagain at any time.To check:^ Carry out steps A to E.If the indicator lamp for Dryingflashes = Increased drying levelis switched onis not on = Increased drying levelis switched off^ Switch off the dryer.The check is complete.39

Programmable functionsIncreased drying level in theMINIMUM IRON programmesThe machine is designed to dryusing as little energy as possible.However, if you require the laundry tobe drier, it is possible to reduce thefinal moisture level in the MINIMUMIRON programmes. Note thatprogramme durations will be longer ifthis option is activated.The machine is supplied ex-works withthis option switched off. It can beactivated if wished.Follow steps A to G to programme andstore in memory.The programmable functions areactivated with the help of the Startbutton and the programme selector.Before you begin, first ensure that:– The tumble dryer is switched off.– The door is closed.– The programme selector is at Finish.A Press the Start button and keep itpressed in whilst carrying out stepsB to C.B Switch the dryer on with theI-On / 0-Off button.C Wait until the Start indicator lampcomes on . . .D . . . and then release the Start button.E Turn the programme selector to theCOTTONS Low Temperatureposition.– If the Drying indicator lamp is not on,the increased drying level isdeactivated.– If the Drying indicator lamp isflashing, the increased drying level isactivated.F Pressing the Start button switchesbetween activating and deactivatingincreased drying.G Switch the machine off with theI-On / 0-Off button.The setting you have selected is nowstored in memory. You can change itagain at any time.To check:^ Carry out steps A to E.If the indicator lamp for Dryingflashes = Increased drying levelis switched onis not on = Increased drying levelis switched off^ Switch off the dryer.The check is complete.40

Programmable functionsBuzzerAn audible tone sounds repeatedly atthe end of a programme.The buzzer is activated as standard exworks.It can be deactivated if wished.The buzzer will sound if there is a fault,even if it has been deactivated.Follow steps A to G to programme andstore in memory.The programmable functions areactivated with the help of the Startbutton and the programme selector.Before you begin, first ensure that:– The tumble dryer is switched off.– The door is closed.– The programme selector is at Finish.A Press the Start button and keep itpressed in whilst carrying out stepsB to C.B Switch the dryer on with theI-On / 0-Off button.C Wait until the Start indicator lampcomes on . . .D . . . and then release the Start button.E Turn the programme selector to theCOTTONS Hand iron position.– If the Drying lamp is flashing, thebuzzer is activated.– If the Drying lamp is not on, thebuzzer is deactivated.F Pressing the Start button switchesbetween activating and deactivatingthe buzzer.G Switch the machine off with theI-On / 0-Off button.The setting you have selected is nowstored in memory. You can change itagain at any time.To check:^ Carry out steps A to E.If the indicator lamp for Dryingflashes = The Buzzeris activatedis not on = The Buzzeris deactivated^ Switch off the dryer.The check is complete.41

Alteration rights reserved/0205M.-Nr. 05 993 020 / 03en-GB
