CAMFORGE Wellhead System Installation and ApplicationsSix-Well InstallationA six-well CAMFORGE installation job on a 24-well Gulf of Mexico platformwas completed in just 7 hours and 20 minutes. Similar six-well installationsusing welding had required several days to finish. With CAMFORGE, therewas no need to shut down production from adjacent wells.SD-25109CAMFORGE forging system for 20"CAMFORGE wellhead housing.Faster Installation TimesThe CAMFORGE wellhead housingcan be installed in a fraction of thetime required using the weldingprocess. To be more specific, thesetimes have been slashed to 1/5th to1/20th of that required by welding.Installation time for the 98th CAM-FORGE wellhead was an incredible40 minutes, including cutting thecasing. And there is no waiting onweather with CAMFORGE.Typical Installation TimesProcedure MinutesCut Casing 15Install Housing 10Cold Forge 25Hydro Test 10Total time 60SD-25107Conductor pipes cut, rough cut made on10-3/4” surface casing and landing basesinstalled. Ready for final mechanical cuton surface casing.There’s No Match forCAMFORGEThe CAMFORGE wellhead systemis the safe, flameless, economical,method for connecting wellheadhousings to casing. And it also hasapplications for the subsea pipelineindustry. It is ideal for installingcompact housings requiring orientationon close centers, as specifiedfor CSW .If you don’t want to fade the heatfor higher costs and other potentialproblems caused by the conventionalwelding process, call your localCameron representative to find outmore about the CAMFORGEWellhead.SD-25106Forging of surface casing to CAMFORGEwellhead housing and subsequent internalhydro test (which simulates actual wellconditions) complete. Ready for blowoutpreventer installation or capping.SD-25126Conductor Sharing Wellhead (CSW)camforged compact housings installed on9-5/8" surface casing in 30" conductor.CAMFORGE ApplicationsThe Conductor Sharing WellheadCSW system incorporates two ormore wellhead systems into asingle conductor. CAMFORGE isideal for attaching the compact housingin restricted space on platformswith adjacent producing wells.
