From simple to complex filtration, all ofthem require a profound analysis.To understand “WHY” and “WHAT” willmean having the most appropriate answerto “cost/quality” effectiveness.Bare in mind that filtration will alwayshave a cost that can be minor or major. Alldepends on the end result one wishes toobtain.Therefore it is very important to carefullyanalyse beforehand all the elementsinvolved that originate the need to filter.This will no doubt help achieve the mostadequate and correct solution for eachcase.The concern of contaminated liquids arevarious and have many aspects. Fromeveryday drinking water to industrial foodprocessing plants, health risk and economicloss make filtration an extremely importantfactor.Choosing a specific filtering solutionrather than another means having wellevaluated in advance important factors.These factors are:• Type of liquid to be processed• Particle size• Dirt loading capacity• Media permeability• Pressure drop• Chemical compatibility• Temperature resistanceOther factors:• Cost/Quality effectiveness• MaintenanceOver the years AQUA Srl has made researchdevelopment its main goal. Finding the bestsolution to the aspects of filtration can onlybe achieved through heavy investments intechnology and research. We are today ableto satisfy all the market needs andrequirements.Our new Cartridge Product Guide presentsa vast amount of filtering elements thatdefer in material used and sizes. A widerange of products, that along with ourFilter Product Guide, make us today a fullline manufacturer. All products are strictlymade in compliance to the Health &Security regulations.AQUA Srl exports its products in all the 5continents, to those customers that workin various applications and markets. Amust for those that emphasize filtrationa major role in their business activity.Our leading role today is not only topresent a wide range but also to be ableto suggest and determine together withour users the most appropriate solutionfor any application.3

SEDIMENTCARTRIDGESCARTRIDGESFR-N QUALITYCOMPARISON TESTUnder exact same workingconditions, AQUA Cartridgeclearly shows it’s very highefficient filtering capacityagainst the evident “breakdown”of the competitor.AQUA CARTRIDGEOur depth cartridges FR-N Series aredesigned to obtain a high efficiency andfiltration of various liquids having impurity.Using only 100% pure polypropylene theyare manufactured through state of the arttechnology. They are generally used inapplications that require extremely highquality filtration.During the manufacturing process, thepolypropylene is mixed with compressedhot air. Then it is stratified on a rigidpolypropylene core through a continuesand constant rotating movement. Thisprocess infuses and intersects thepolypropylene fibres amongst themselves.This creates the so called “Depth Cartridge”guaranteeing a uniform filtration alongall the surface of the cartridge.The Polypropylene fibres used are alwaysand only of first choice which processedat high temperatures welds them togethereliminating any possibility of losingparticles or residuals.PECULIAR CHARACTERISTICS:- High Depth Filtration- Constant filtration on all surface- High Yield- High resistance to compression- High Stability- Lower pressure drop- No residual or particle lossFILTER EFFICIENCY:The FR-N Cartridges are fully tested toachieve at least 95% filtration efficiency.This means that a 10 micron FR-N Cartridgewill filter 95% of particles having adiameter of 10 micron or more. Theextraordinary filtration capability of theFR-N cartridges is obtained thanks to itswide filtering surface and compactnesswhich is distributed along all the surfaceof the cartridge itself.The cartridges need the be changed whena loss in pressure drop is detected or inany case when the specific filteringapplication requires it.APPLICATIONS:The FR-N cartridges can be used as endlinefiltration or as pre-filtration.Applications:Water treatmentElectronic/NuclearBiotechnology/Fine chemicalsFood/BeverageCoatings/ResinsGeneral IndustrialPharmaceutical/CosmeticsBulk chemicals/PetrochemicalsGalvanicThe range vary from 1 to 90 micron andstandard lengths are 9”3/4 to 40”. Thecartridges are made up as one whole pieceno matter what length.AQUA CARTRIDGECOMPETITOR CARTRIDGEFLOW RATE (lt/h)MICRON1135510202030505090FRNFRN-BIGFRNFRNFRN-BIGFRNFRNFRN-BIGFRNFRNFRN-BIGFRN9“3/4800800110015001500200025002500260026002600270020“14001400200027002700360045004500460046004600480030“2000300038005000620065006500680040“26004000480064008000800080008000COMPETITOR CARTRIDGE5-2020-50BIG-DGBIG-DG1800270032004800FR-N linedepth cartridges4

FR-NTECHNICAL FEATURESRaw material:Core:Outer cage:End caps:O-Ring / Gasket:Length:Inner diameter:Outer diameter:Micron rating:Efficiency:Pressure:Max working pressure:Max diferential pressure:Temperature:Max working temperature:FR-N100% PP100% PP—DOE—5”-9”3/4-10”-20”-30”-40”28 mm63 mm1/3/5/10/20/30/50/9095%6 bar0,8 bar80°CNote: Max water flow rate at 20°C and diferential pressure 0,15 barMELT BLOWN CARTRIDGES series FR-NCOD MICRON LENGTH QUANTITYboxA4240090A4240100A4240110A4240120A4240130A4240140A4240150A4240160A4240250A4240260A4240270A4240280A4240290A4240300A4240310A4240320A4240330A4240340A4240350A4240360A4240370A4240380A4240390A4240400A4240410A4240420A4240430A4240440A4240450A4240460A4240470A4240480A4240490A4240500A4240510A4240520A4240530A4240540A4240550A4240560A4240570A4240580A4240590A4240600A4240610A4240620A4240630A42406401351020305090135102030509013510203050901351020305090135102030509013510203050905“5“5“5“5“5“5“5“9“3/49“3/49“3/49“3/49“3/49“3/49“3/49“3/410“10“10“10“10“10“10“10“20“20“20“20“20“20“20“20“30“30“30“30“30“30“30“30“40“40“40“40“40“40“40“40“14014014014014014014014060606060606060606060606060606060303030303030303015151515151515151515151515151515Kgbox10,9010,9010,9010,9010,9010,9012,0012,0010,510,512,0012,0012,0012,0014,0014,0012,0012,0012,0012,0012,0012,0014,0014,0012,7012,7012,7012,7012,7012,7014,0014,007,507,507,507,507,507,509,007,5011,0011,0011,0011,0011,0011,0014,5011,00VOLUMEpackage0,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0750,0610,0610,0610,0610,0610,0610,0610,0610,0760,0760,0760,0760,0760,0760,0760,0766

FR-NTECHNICAL FEATURESRaw material:Core:Outer cage:End caps:O-Ring / Gasket:Length:Inner diameter:Outer diameter:Micron rating:Efficiency:Pressure:Max working pressure:Max diferential pressure:Temperature:Max working temperature:FR-N KID—DOE—5”28 mm50 mm1/5/2095%6 bar0,8 bar80°CFR-N MINI—DOE—100 mm18 mm25 mm1/5/2095%6 bar0,8 bar80°FR-N MICRO100% PP—DOE—53 mm18 mm25 mm1/5/2095%6 bar0,8 bar80°CFR-N BIG—DOE—9”3/4-20“28 mm114 mm1/5/20/5095%6 bar0,8 bar80°CFR-N BIG (dual grad.)—DOE—9”3/4-20“28 mm120 mm5-20/20-5095%6 bar0,8 bar80°Note: Max water flow rate at 20°C and diferential pressure 0,15 barMELT BLOWN CARTRIDGES series FR-N AQUA KIDCOD MICRON LENGTH QUANTITYboxA424K010A424K020A424K030A424K040A424K050A424K060152015205“5“5“9“3/49“3/49“3/4225225225110110110Kgbox13,7013,7013,7012,512,512,5VOLUMEpackage0,0930,0930,0930,0930,0930,093MELT BLOWN CARTRIDGES series FR-N AQUA MINI and MICROCOD MICRON LENGTH QUANTITYboxA424M010A424M020A424M030A424M040A424M050A424M06015201520MINIMINIMINIMICROMICROMICRO200200200200200200Kgbox29,8029,8029,8021,8021,8021,80VOLUMEpackage0,0930,0930,0930,0930,0930,093MELT BLOWN CARTRIDGES series FR-N AQUA BIGCOD MICRON LENGTH QUANTITYboxA4270100A4270120A4270140A42701501520509”3/49”3/49”3/49”3/48888Kgbox4,504,504,504,50VOLUMEpackage0,0360,0360,0360,036A4270110A4270200A4270220A427023015205020”20”20”20”44443,603,603,603,600,0360,0360,0360,036A427012EA427014E5-2020-509”3/49”3/4884,506,000,0360,036A427020EA427022E5-2020-5020”20”443,605,000,0360,0367

FR-E linedepth cartridges8

FR-ETECHNICAL CHARACTERISTICSRaw MaterialLength range:Inner diameter:Outer Diameter:Micron Rating range:Efficiency:Max. working pressure:Max. differential pressure:Max. working temperature:100% Polypropylene9”3/4 – 20” – 30” – 40”28 mm.61 mm.5 / 20 / 5080%6 bar0,8 bar80°COur FR-E series, is a break through in technology granting an interesting option to our consolidated and outstanding FR-N series. Because of our met-blown fabricationand procedure, these FR-E series grant a true comprise for those applications that require a just Price/Quality performance ratio.During the manufacturing phase, and without the essence of the internal core, these cartridges grant a perfect and compact resistance of filtration.Although an economical comprise, the soul element of these cartridge allow an exceptional performance when compared to the standard abundance supplied bycompetitors:• Consistency• Faithful retention of contaminates• Well meaning to compression• Contained pressure lossThanks to the method of fabrication and experience gained with our exceptional FRN series, this series offer a mere absence of particle media loss.Vast chemical compatibility because made only with 100% pure polypropylene, insuring nearly infinite applicationsLaboratory tests show that this series are guaranteed to give at least 80% efficiency of stated particle size confirming its perfect price/quality ratio.MELT BLOWN CARTRIDGES series FR-ECOD DESCRIPTION MICRON LENGTH QUANTITYA2460270A2460280A2460290A2460310A2460430A2460440A2460450A2460470A2460510A2460520A2460530A2460550A2460590A2460600A2460610A2460630CART.PP MELT-BLOW 9“3/4 FR5nECART.PP MELT-BLOW 9“3/4 FR10nECART.PP MELT-BLOW 9“3/4 FR20nECART.PP MELT-BLOW 9“3/4 FR50nECART.PP MELT-BLOW 20 FR5nECART.PP MELT-BLOW 20 FR10nECART.PP MELT-BLOW 20 FR20nECART.PP MELT-BLOW 20 FR50nECART.PP MELT-BLOW 30 FR5nECART.PP MELT-BLOW 30 FR10nECART.PP MELT-BLOW 30 FR20nECART.PP MELT-BLOW 30 FR50nECART.PP MELT-BLOW 40 FR5nECART.PP MELT-BLOW 40 FR10nECART.PP MELT-BLOW 40 FR20nECART.PP MELT-BLOW 40 FR50nE51020505102050510205051020509“3/49“3/49“3/49“3/420“20“20“20“30“30“30“30“40“40“40“40“box60606060303030301515151515151515Kgbox999999996,756,756,756,759999VOLUMEpackage0,0750,0750,0750,0750,0750,0750,0750,0750,0610,0610,0610,0610,0760,0760,0760,0769

SEDIMENTCARTRIDGESOur Polypropylene wound cartridges arepart of the depth and deforming cartridgeseries.They are manufactured using only 100%pure non-toxic polypropylene yarn. Thisseries offers an excellent ratio betweencost/quality, even though usually referredto as “economic-type” they aremanufactured so as to guarantee a highnominal filtration level.In this series we have 2 main types ofWound PP CartridgesWound Cartridge Carded Wash– Oil residual 0,07%Because of its characteristics, this washcarded yarn is of superior quality. It ismanufactured using only first choice rawmaterials and during the process ofextrusion & twist it undergoes a washtreatment at very high temperatureseliminating oil residuals used beforehandof the manufacturing process itself. Toincrease its resistance, it is then cardedand no further oils are added thusguaranteeing a completely non-toxicnatural polypropylene yarn.The yarn’s appearance is uniform,homogenous and very strong. This willallow a very compact construction of thecartridge itself and through a precisepattern mounting, it will achieveremarkable increase in the filtration surface.Therefore as a consequence, an increasein cartridge life. All this to achieve a higherfiltration efficiency at an excellentcost/quality ratio.Wound Cartridge Open-end Wash– Oil residual 0,2%This yarn is manufactured using machinerythat allows a shorter production periodand therefore a more economically pricedproduct. The raw material used for thisproduct is exactly the same as the WashCarded type. The only difference is that itis not carded after the process of extrusion& twist but simple manufactured arounda BCF (by extrusion spun yarn) making itcompact and uniform. Although lesscompact than the carded one, it still yieldsa satisfying filtration performance at lowercosts. Amongst the inconveniences of thiscartridge is that at the beginning of useit creates a small amount of foam thatafter a short period will disappear. Even ifthe foam is non-toxic, in certainapplications it could cause minor problemsto the post-filtration unit. Therefore it isimportant to know were such cartridgewill be applied to avoid any inconvenience.The inside core of the filter is rigid and inPolypropylene which guarantees stability.The lengths range from 4” to 40” and themicron range from 1 to 100.FLOW RATE (lt/h)MICRON1135551010202020305050100100FAFA-BIGFAFAFA-BIGFA-LFHFAFA-BIGFAFA-BIGFA-LFHFAFAFA-BIGFAFA-BIGFA line9“3/43003005008008001000110011001700170020001800190019002000200020“60060010001600160022002200250025002600260026002800280030“90090015002400240033003300340034003500350035003600360040“12001200200032003200400040004000400040004000400040004000Applications:Water treatment, Electronic/Nuclear,Biotechnology/Fine chemicals,Food/Beverage, Coatings/Resins,General Industrial,Bulk chemicals/Petrochemicals,Galvanic.depth cartridges10

135102030501001351020305010013510203050100135102030501004“4“4“4“4“4“4“4“5“5“5“5“5“5“5“5“7“7“7“7“7“7“7“7“9“3/49“3/49“3/49“3/49“3/49“3/49“3/49“3/4180180180180180180180180144144144144144144144144108108108108108108108108727272727272727213,1012,6012,6011,7011,7011,7011,7011,7013,7013,3013,3013,1013,1013,1012,5012,5016,0016,0016,0014,3014,3014,3014,3014,3019,2014,9019,2014,9013,6013,6013,6013,600,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,07712222222222222222222222222222222221351020305010013510203050100135102030501001351020305010010“10“10“10“10“10“10“10“20“20“20“20“20“20“20“20“30“30“30“30“30“30“30“30“40“40“40“40“40“40“40“40“727272727272727236363636363636362020202020202020202020202020202019,6019,6015,3015,3013,5013,5013,5013,5016,3016,3014,4014,4013,2013,2013,2012,3013,3013,3012,0012,0010,6010,6010,6010,2019,1019,1017,8017,8017,0017,0017,0016,500,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0880,0880,0880,0880,0880,0880,0880,0881,1501,1501,1501,1501,1501,1501,1501,15022222222111111111111111111111111FAFAA4010010A4010020A4010030A4010040A4010050A4010060A4010070A4010080A4010090A4010100A4010110A4010120A4010130A4010140A4010150A4010160A4010170A4010180A4010190A4010200A4010210A4010220A4010230A4010240A4010250A4010260A4010270A4010280A4010290A4010300A4010310A4010320A4010330A4010340A4010350A4010360A4010370A4010380A4010390A4010400A4010410A4010420A4010430A4010440A4010450A4010460A4010470A4010480A4010490A4010500A4010510A4010520A4010530A4010540A4010550A4010560A4010570A4010580A4010590A4010600A4010610A4010620A4010630A4010640WOUND PP CARTRIDGES series FARaw material:Core:Outer cage:End caps:O-Ring / Gasket:Length:Inner diameter:Outer diameter:Micron rating:Efficiency:Pressure:Max working pressure:Max diferential pressure:Temperature:Max working temperature:FA100% PP100% PP—DOE—4”-5”-7”-9”3/4-10”-20”30”-40”28 mm61 mm1/3/5/10/20/30/50/10080%6 bar0,8 bar80°CCOD MICRON LENGTH QUANTITYboxVOLUMEpackageNote: Max water flow rate at 20°C and diferential pressure 0,15 barTECHNICAL FEATURESKgboxQUANTITYpackageCOD MICRON LENGTH QUANTITYboxVOLUMEpackageKgboxQUANTITYpackage

FATECHNICAL FEATURESRaw material:Core:Outer cage:End caps:O-Ring / Gasket:Length:Inner diameter:Outer diameter:Micron rating:Efficiency:Pressure:Max working pressure:Max diferential pressure:Temperature:Max working temperature:FA AQUA BIG—DOE—9“3/4-20“28 mm114 mm1/5/10/20/50/10080%6 bar0,8 bar80°CNote: Max water flow rate at 20° and diferential pressure 0,15 barFA AQUA KID100% PP—DOE—5“28 mm50 mm1/5/10/20/5080%6 bar0,8 bar80°FA-LFH (wound PP open end)—DOE—5“-7“-9“3/428 mm56 mm5/2070%6 bar0,8 bar80°WOUND PP CARTRIDGES series FA for 1”1/4-1”1/2 inlets/outletsCOD MICRON LENGTH QUANTITYA4011450A4011440A4010680QUANTITYpackage2225201007“7“7“box108108108Kgbox16,0014,3014,30VOLUMEpackage0,0770,0770,077A4010790A4010690A40114602225201009“3/49“3/49“3/472727214,9013,6013,600,0770,0770,077WOUND PP CARTRIDGES series FA AQUA KIDCOD MICRON LENGTH QUANTITYboxA4011360A4011390A4011420A4010720A4011430A4011830A4011840A4011850A4011860A4011870A4010780A4010650A4010770A4010660A4011400A4011200A4010900A4010700A4011410A4010710A4010890A4011140151020501510205015102050100151020501005”5”5”5”5”9”3/49”3/49”3/49”3/49”3/49“3/49“3/49“3/49“3/49“3/49“3/420“20“20“20“20“20“200200200200200110110110110110WOUND PP CARTRIDGES series FA AQUA BIGCOD MICRON LENGTH QUANTITYbox181818181818999999Kgbox13,9012,7012,7012,9012,9013,9012,7012,7012,9012,90Kgbox15,4014,6014,6014,6012,4012,4017,6016,7016,7016,7013,5013,50VOLUMEpackage0,0770,0770,0770,0770,0770,0770,0770,0770,0770,077VOLUMEpackage0,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,0770,077WOUND PP CARTRIDGES series FA-LFH - Ø 56 mm. (OPENEND YARN)COD MICRON LENGTH QUANTITYboxA4280980A4280940A4280990A4280950A4280750A42809205205205205“5“7“7“9“3/49“3/41441441081087272Kgbox12,2012,2013,0013,7012,6012,60VOLUMEpackage0,0770,0770,0770,0770,0770,07713

CARTRIDGESPLEATEDPleated cartridges represent a valid filteringsolution for diverse applications.Certified raw materials are used and haveparticular technical characteristics thatgive the cartridge reliability and resistance.An important factor of quality is themechanical resistance. In both cases ofPolyester or Cellulose cartridges, theresistance is given by using 100% pureendless fibres.After pleating, which takes into accountfixed parameters (pleats dimensions andquantity) that guarantee maximumefficiency, the element is mounted arounda polypropylene rigid core thus assuringstability. It is then all placed inside apolypropylene cage which both ends areclosed by end caps.The pleated cartridge allows a vast filteringsurface while the PP cage has symmetricslots along all the surface of the cage itselftherefore allowing the water to flowequally along all the sides of the cartridgeand avoiding the water penetrating justone specific area.This results in a longer life and majorefficiency.The Polyester cartridges, contrary toCellulose types, can be reused over andover again without loss of efficiency. It isobvious though that the life of thesecartridges depend on the workingconditions. Even though the maintenanceis frequent, It is recommended not to usesuch cartridges under extreme conditions.Due to the fact that bacteria willundoubtedly grow and nest within thefibre, simply washing a cartridge does notmean it will last forever.Therefore as all washable cartridges, it isrecommended to frequently change themin order to guarantee a safe filtration.Thanks to its compatibility with a vastnumbers of chemicals, polyester can beused also in specific applications whereother materials are not compatible withreagents and/or chemical solvents.Regarding the applications of Polyesterand Cellulose cartridges, these areparticularly adequate for use in potablewater because the raw materials used arecompatible.APPLICATIONSCELLULOSE:Water treatmentPharmaceutical/CosmeticsGalvanicPaint Industry – Ink Industry - EmulsionPOLYESTER:Water treatment,Electronic/NuclearBiotechnology/Fine chemicalsFood/BeverageCoatings/ResinsGeneral IndustrialPharmaceutical/CosmeticsBulk chemicals/PetrochemicalsFLOW RATE (lt/h)MICRON3151520205050PLCECE-BIGPLPL-BIGPLPL-BIG9“3/480018002100200023002500280020“1600340041003600430045004800CE-PL linesurface filtering14

CE AQUA PROTECHNICAL FEATURESRaw material:Core:Outer cage:End caps:O-Ring / Gasket:Length:Inner diameter:Outer diameter:Micron rating:Efficiency:Pressure:Max working pressure:Max diferential pressure:Temperature:Max working temperature:CE AQUA PROCELLULOSEPPPPDOE-PPPVC9”3/4-2028 mm70 mm1585%6 bar0,8 bar65°CNote: Max water flow rate at 20°C and diferential pressure 0,15 barCE AQUA PRO BIGCELLULOSEPPPPDOE-PPPVC9”3/4-2028 mm116 mm1585%6 bar0,8 bar65°PLEATED CELLULOSE CARTRIDGES series CE AQUA PROCOD MICRON LENGTH QUANTITYboxA4070080A407010015159“3/420“1515Kgbox4,308,42VOLUMEpackage0,0300,035PLEATED CELLULOSE CARTRIDGES series CE AQUA PRO BIGCOD MICRON LENGTH QUANTITYboxA4070090A407011015159“3/420“66Kgbox4,278,16VOLUMEpackage0,0300,03516

PL AQUA PROTECHNICAL FEATURES PL AQUA PRO PL AQUA PRO BIGRaw material:Core:Outer cage:End caps:O-Ring / Gasket:Length:Inner diameter:Outer diameter:Micron rating:Efficiency:Pressure:Max working pressure:Max diferential pressure:Temperature:Max working temperature:PESPPPPDOE-PPPVC9”3/4-2028 mm70 mm3/20/5095%6 bar0,8 bar80°CNote: Max water flow rate at 20°C and diferential pressure 0,15 barPESPPPPDOE-PPPVC9”3/4-2028 mm116 mm20/5095%6 bar0,8 bar80°CPLEATED POLYESTER CARTRIDGES series PL AQUA PROCOD MICRON LENGTH QUANTITYboxA4080230A4080240A4080140A4080160A4080150A408017033202050509“3/420“9“3/420“9“3/420“151515151515Kgbox4,709,074,709,074,709,07VOLUMEpackage0,0300,0350,0300,0350,0300,035PLEATED POLYESTER CARTRIDGES series PL AQUA PRO BIGCOD MICRON LENGTH QUANTITYboxA4080180A4080200A4080190A4080210202050509“3/420“9“3/420“6666Kgbox4,328,694,328,69VOLUMEpackage0,0300,0350,0300,03517

WASHABLE NETCARTRIDGESThe washable Net Cartridges are calledsurface cartridges and have a nondeformingstructure.The inside core is manufactured using TalcFilled Polypropylene and a nylon net iswelded.The homogenous Net has physical andmechanical characteristics. The squaremesh allows a uniform flow along all thesurface of the cartridge itself thusminimizes the possibility of clogging.Manufactured using monofilament fibresthat enable uniform openings It also allowsan accurate capacity of filtration whileavoiding pressure drop.Also thanks to Its smooth surface it is veryeasy to wash and non shedding.The washable net cartridges give a nominalfiltration with efficiency of 80%. Whenproperly utilized, they can be used overand over again maintaining a constantefficiency.The available lengths range from 5” to 20”and the microns range from a minimumof 80 micron upwards. All in complianceto EC regulations.THE WASHABLE NETCARTRIDGE IS IDEAL FOR:Suspended Solids, Sand, Slime, Rust.APPLICATIONS:Water treatment,General Industry,Agricultural,Water pumps and Domestic applications.FLOW RATE (lt/h)MICRON808080250250430250RLA 3/4” - 1”RLA 1”1/4RLRLA 3/4”-1”RLA 1”1/4RLA 1”1/4RL9“3/4350042003200450052006000420020“700084006400900010400120008400RL-RLA linesurface filtration18

RLA-RLTECHNICAL FEATURESRaw material:Core:Outer cage:End caps:O-Ring / Gasket:Length:Inner diameter:3/4” - 1”1”1/4 - 1”1/2Outer diameter:3/4” - 1”1”1/4 - 1”1/2Micron rating:Efficiency:Pressure:Max working pressure:Max diferential pressure:Temperature:Max working temperature:RLAPA-PPDOE-PPPVC5”-7”-9”3/4-20”27 mm40 mm65 mm65 mm80-250-43080%6 bar0,8 bar80°CRLPAPPPPDOE-PPPVC5”-9”3/426 mm-63 mm-80-25080%6 bar0,8 bar80°CNote: Max water flow rate at 20°C and diferential pressure 0,15 barWASHABLE NET CARTRIDGES series RLA for 3/4”-1” inlets/outletsCOD MICRON LENGTH QUANTITYboxA4030100A4030010A4030020A4030110A4030030A4030120A4030040A4030130802508025080250802505“5“7“7“9“3/4“9“3/4“20“20”144144909070703535Kgbox15,9015,9012,6012,6012,6012,6013,0013,00VOLUMEpackage0,0930,0930,0930,0930,0930,0930,0930,093WASHABLE NET CARTRIDGES series RLA for 1”1/4-1”1/2 inlets/outletsCOD MICRON LENGTH QUANTITYboxA4030050A4030140A4030060A4030150A4030160A4030070A4030170A4030180A4030080A4030190A40302002504308025043080250430802504305“5“7“7“7”9“3/49“3/49“3/420“20”20”144144909090707070353535Kgbox15,9015,9012,3012,3012,3012,6012,6012,6013,0013,0013,00VOLUMEpackage0,0930,0930,0930,0930,0930,0930,0930,0930,0930,0930,093WASHABLE NET CARTRIDGES series RLCOD MICRON HEIGHT QUANTITYboxA4040010A4040050802509”3/49”3/47070Kgbox13,2813,28VOLUMEpackage0,0930,09320

RLATECHNICAL FEATURES RLA KID RLA AQUA NET RLA MINI RLA MICRO DIFF. FILTRORaw material:Core:Outer cage:End caps:O-Ring / Gasket:Length:Inner diameter:3/4” - 1”1”1/4 - 1”1/2Outer diameter:3/4” - 1”1”1/4 - 1”1/2Micron rating:Efficiency:Pressure:Max working pressure:Max diferential pressure:Temperature:Max working temperature:PA-PPDOE-PPPVC5”27 mm-50 mm-8080%6 bar0,8 bar80°CPA-PPSOE-102 mm27 mm-42 mm-8080%6 bar0,8 bar80°CPA-PPSOE-97 mm18 mm-22 mm-8080%6 bar0,8 bar80°CPA-PPSOE-52 mm18 mm-22 mm-8080%6 bar0,8 bar80°CPA-PPSOE-59 mm20 mm-25 mm-8080%6 bar0,8 bar80°CNote: Max water flow rate at 20°C and diferential pressure 0,15 barWASHABLE NET CARTRIDGES series RLA AQUA KIDCOD MICRON LENGTH QUANTITYboxA4030090A4030230A403024080802505”9”3/49”3/4225225110Kgbox15,7815,7815,78VOLUMEpackage0,0930,0930,093WASHABLE NET CARTRIDGES series RLA AQUA NETCOD MICRON LENGTH QUANTITYboxA803R020KgboxVOLUMEpackage80 102 mm 200 4,40 0,093WASHABLE NET CARTRIDGES series RLA AQUA-MINI and AQUA-MICROCOD MICRON LENGTH QUANTITYboxA803R030A803R04080809752100100Kgbox2,982,18VOLUMEpackage0,0930,093WASHABLE NET CARTRIDGES LAVABILE series AQUA BIGCOD MICRON LENGTH QUANTITYboxA4030510A4030520A4030530A403054080250802509“3/49“3/420“20“6666Kgbox334,54,5VOLUMEpackage0,0350,0350,0350,035WASHABLE NET CARTRIDGES DIFFUSER Ø 20 mm.COD MICRON LENGTH QUANTITYboxKgboxVOLUMEpackageA6011320 80 59200 3,18 0,09321

STAINLESSSTEELCARTRIDGESStainless steel net cartridges are so-called“surface cartridges” with non deformingstructure.They are well indicated for difficultapplications such as filtering of corrosiveliquids or were high temperatures apply.They are available in the following versions.- Series AC; non-pleated stainless steelwith end caps in polypropylene- Series AC-HT; non-pleated stainless steelwith end caps in stainless steel- Series ACP; pleated stainless steel withend caps in stainless steelBecause of its structure, stainless steel hasno particle migration therefore especiallysuitable for those applications weredrinkable water is being processed.Being pleated, the ACP series grant a muchhigher surface of filtration in the amountof 4 times a standard AC version whichare non-pleated. Therefore they are moreefficient when high flow is required andwere a high percentage of contaminatedparticles are present in the liquid itself.The Stainless steel net has a specialstructure called REPS that thanks to itscharacteristics makes it very strong andof high filtering efficiency. All end capsare electrically welded and no resin orglues are used.Pleated stainless steel cartridges, seriesACP can withstand pressures of 6 barswithout deforming. In any case it is alwayssuggested not to exceed 3 bars.All stainless steel cartridges are washableand therefore can be used time and timeagain. It can be done by backwashing themor washed with special chemicals.APPLICATIONS:Water Treatment,Food and beverage, Oil, Alimentary, SyrupsGeneral Industries, Paint, resins,Bulk chemicals/Petrochemicals, polymer,fuel, lubricant,Sewage water.FLOW RATE (lt/h)MICRON80808080ACAC-HT 3/4”-1”AC-HT 1”1/4ACP9“3/4250025003200280020“5000500064005600AC-ACP linesurface filtration22

AC/AC-HT/ACPTECHNICAL FEATURESRaw material:Core:Outer cage:End caps:O-Ring / Gasket:Length:Inner diameter:3/4” - 1”1”1/4 - 1”1/2Outer diameter:3/4” - 1”1”1/4 - 1”1/2Micron rating:Efficiency:Pressure:Max working pressure:Max diferential pressure:Temperature:Max working temperature:ACSS AISI 304SS AISI 304-DOE-PPPVC5”-9”3/427 mm70 mm80 mm75%6 bar0,8 bar80°CAC-HTSS AISI 304SS AISI 304-DOE-INOXPVC9”3/4-20”26 mm37 mm62 mm62 mm8075%6 bar0,8 bar100°CACPSS AISI 304SS AISI 304-DOE-INOXPVC5”-9”3/4-20”26 mm55 mm8075%6 bar0,8 bar100°CNote: Max water flow rate at 20°C and diferential pressure 0,15 barNON-PLEATED STAINLESS STEEL CARTRIDGES serie ACwith end caps in polypropyleneCOD MICRON LENGTH QUANTITYboxA4050110A405013080805”9”3/43015Kgbox4,923,90VOLUMEpackage0,0300,030NON-PLEATED STAINLESS STEEL CARTRIDGES series AC-HTwith end caps in stainless steell for 3/4”-1” inlets/outletsCOD MICRON LENGTH QUANTITYboxA4050030A405004080809”3/420”1515Kgbox3,956,84VOLUMEpackage0,0300,035NON-PLEATED STAINLESS STEEL CARTRIDGES series AC-HTwith end caps in stainless steell for 1”1/4-1”1/2 inlets/outletsCOD MICRON LENGTH QUANTITYboxA4050080A405009080809”3/420”1515Kgbox3,956,84VOLUMEpackage0,0300,03524

REPLACEMENT CARTRIDGES FOR SELF CLEANING FILTERSseries EKO CLEAN 3/4”-1”-1”1/4COD MICRON LENGTH QUANTITYboxR8010080R80100709030series EKO CLEAN 1”1/2903072 mm72 mmCOD MICRON LENGTH QUANTITYboxR8010100R8010090137 mm137 mm1111Kgbox0,0870,087Kgbox0,1600,160VOLUMEpackage--VOLUMEpackage--series TOP CLEAN E AQUAMATIC 3/4”-1”-1”1/4COD MICRON LENGTH QUANTITYboxR8010120R8010110903072 mm72 mm11Kgbox0,1470,147VOLUMEpackage--series TOP CLEAN 1”1/2COD MICRON LENGTH QUANTITYboxR8010140R80101309030137 mm137 mm11Kgbox0,2500,250VOLUMEpackage--series AQUAMATIC 1”1/2COD MICRON LENGTH QUANTITYboxR8010120R8010110903072 mm72 mm11Kgbox0,1470,147VOLUMEpackage--MINIBRAVOCOD MICRON LENGTH QUANTITYboxR8010220Kgbox90 100 mm 1 - -VOLUMEpackageseries BRAVOMAX 1”1/2-2”COD MICRON LENGTH QUANTITYboxA8010460A8010560A8010510A8010450A8010440A8010500100150200series BRAVOMAX 2”1/2-3”100150200165 mm x 90165 mm x 90165 mm x 90COD MICRON LENGTH QUANTITYbox225 mm x 90225 mm x 90225 mm x 90111111Kgbox0,2980,2980,298Kgbox0,4000,4000,400VOLUMEpackage---VOLUMEpackage---25

activated carbonTECHNICAL FEATURESFilter media:Coconut shell granular activated carbon:Pre filter:Post filter:Core:Out cage:End caps:O-Ring / Gasket:Length:Inner diameter:Outer diameter:Micron rating:Pre filter micronPost filter micronEfficiency (pre and post filter):Pressure:Max working pressure:Max diferential pressure:Temperature:Max working temperature:RLA-CAG.A.C.PAPES-PPSOE-PPPVC5”-7”-9”3/427 mm65 mm802075%6 bar0,8 bar50°CCA-CABLUG.A.C.PESPES-PST/PPSOE-PSTPVC5”-7”-9”3/4-20”27 mm72 mm202075%6 bar0,8 bar50°CGACG.A.C.PPPP-PPDOE-PPPVC9”3/4-20”26 mm72 mm404095%6 bar0,8 bar50°CGAC-CCG.A.C. LAVATOPPPP-PPDOE-PPPVC9”3/4-20”26 mm72 mm5/405/4095%6 bar0,8 bar50°CGAC-CC-P GAC-BIGG.A.C. ADIC WASHED G.A.C.+ POLYPHOSPHATEPPPPPPPP--PPPPDOE-PP DOE-PPPVCPVC9”3/4-20” 9”3/4-20”26 mm 26 mm72 mm 120 mm404095%6 bar0,8 bar50°C404095%6 bar0,8 bar50°CNote: Max water flow rate at 20°C and diferential pressure 0,15 barWASHABLE NET CARTRIDGES WITH ACTIVE CARBON series RLA-CACOD MICRON LENGTH QUANTITYboxA4090010A4090020A40900308080805”7”9”3/4301515Kgbox7,655,216,62VOLUMEpackage0,0300,0300,030TRANSPARENT CANISTER series CVCOD MICRON LENGTH QUANTITYboxA4110010A4110020A4110030A4110040----5”7”9”3/420”100705025Kgbox12,9611,7011,0711,13VOLUMEpackage0,0930,0930,0930,093BLU CANISTER series CVCOD MICRON LENGTH QUANTITYboxA4110070A4110110A4110060A4110120----5”7”9”3/420”100705025Kgbox12,9611,7011,0711,13VOLUMEpackage0,0930,0930,0930,09328

activated carbonTECHNICAL FEATURESFilter media:Coconut shell granular activated carbon:Pre filter:Post filter:Core:Out cage:End caps:O-Ring / Gasket:Length:Inner diameter:Outer diameter:Micron rating:Pre filter micronPost filter micronEfficiency (pre and post filter):Pressure:Max working pressure:Max diferential pressure:Temperature:Max working temperature:GAC-BIG-CC FA-CAG.A.C. ADIC WASHED G.A.C.PPPP-PPDOE-PPPVC9”3/4-20”26 mm120 mm5/405/4095%6 bar0,8 bar50°CPPPES-PPDOE-PPPVC5”-7”-9”3/4-10”-20”30 mm70 mm20-80%6 bar0,8 bar50°CCE-CACELLULOSE IMPREGNATEDCARBON--PP-DOE-PPPVC5”-7”-9”3/4-20”27 mm70 mm5-85%6 bar0,8 bar50°CFRN-CA CTO-EG.A.C. ADIC WASHEDPPPPPP-DOE-5”-9”3/4-20”27 mm63 mm5/20-95%6 bar0,8 bar50°CCARBONBRIQUETTEPESPES--DOE-PPPVC9”3/4-20”26 mm72 mm10-95%6 bar0,8 bar50°CAQUASELECTG.A.C. ADIC WASHEDCELLULOSECELLULOSE-PSTDOE-PST--13 mm47 mm5585%6 bar0,8 bar50°CNote: Max water flow rate at 20°C and diferential pressure 0,15 barACTIVE CARBON CARTRIDGES series CA-POST20POST FILTER 20 MICRONCOD MICRON LENGTH QUANTITYboxA4120010A4120020A4120030A4120040202020205”7”9”3/420”30151515Kgbox7,405,718,2116,00VOLUMEpackage0,0300,0300,0300,035ACTIVE CARBON CARTRIDGESseries CA-POST20 BLU / POST FILTER 20 MICRONCOD MICRON LENGTH QUANTITYboxA4120050A4120060A4120070A4120080202020205”7”9”3/420”30151515Kgbox7,405,718,2116,00VOLUMEpackage0,0300,0300,0300,035ACTIVE CARBON CARTRIDGES series GAC-40CCCOCO SHELL GRANULAR-ACTIVATED CARBON / PRE-POST 40 MICRON FILTERCOD MICRON LENGTH QUANTITYboxA4120560A412057040409”3/420”1515Kgbox8,7518,37VOLUMEpackage0,0300,03529

ACTIVE CARBON CARTRIDGES series GAC/P-40CC / ACID WASHED COCO SHELLGRANULAR-ACTIVATED CARBON+POLYPHOSPHATES / PRE-POST 40 MICRON FILTERCOD MICRON LENGTH QUANTITYboxA4120580KgboxVOLUMEpackage40 9”3/4 15 8,80 0,030ACTIVE CARBON CARTRIDGES series GAC-40CC BIG / ACID WASHED COCO SHELLGRANULAR-ACTIVATED CARBON / PRE-POST 40 MICRON FILTERCOD MICRON LENGTH QUANTITYboxA4120620A412063040409”3/420”66Kgbox8,2816,02VOLUMEpackage0,0300,035ACTIVE CARBON CARTRIDGES series FA-CA / PRE-POST 20 MICRON FILTERCOCO SHELL GRANULAR-ACTIVATED CARBONCOD MICRON LENGTH QUANTITYboxA4210020A4210030A4210040A4210050A421006020202020205”7”9”3/410”20”3015151515Kgbox7,505,146,346,6014,20VOLUMEpackage0,0300,0300,0300,0300,035ACTIVE CARBON CARTRIDGES series FRN-CA / PRE-POST 40 MICRON FILTERCOCO SHELL / GRANULAR-ACTIVATED CARBONCOD MICRON LENGTH QUANTITYboxA4210530A4210540A4210550A4210510A4210500A42105205552020205”9”3/420”5”9”3/420”301515301515Kgbox4,203,917,684,203,907,70VOLUMEpackage0,0300,0300,0350,0300,0300,035CARBON BLOCK CARTRIDGES series CTO-ECOD MICRON LENGTH QUANTITYboxA4220050A422007010109”3/420”2516Kgbox1217,5VOLUMEpackage0,0420,06530

CARBON BLOCK CARTRIDGES series CTO-E for AQUA BIGCOD MICRON LENGTH QUANTITYboxA4220110A422012010109”3/420”126Kgbox1818VOLUMEpackage0,0530,053ACTIVE CARBON CARTRIDGES for AQUA-SELECT (2 pieces)COCO SHELL GRANULAR / ACTIVATED CARBONCOD MICRON LENGTH QUANTITY Kg VOLUMEboxbox packageA8090030 5 AQUA SELECT 24 3,96 0,085ALL CHLORINE REDUCTION DATA IS FOR 2 ppm FREE CHLORINE TO < 0,5 ppm. SOME DATA IS EXTRAPOLATED.MODEL LENGTH RECOMMENDEDFLOW RATECHLORINE REDUCTIONFLOW RATEMODEL LENGTH RECOMMENDEDFLOW RATECHLORINE REDUCTIONFLOW RATERLA-CARLA-CARLA-CACACACACA5”7”9”3/45”7”9”3/420”1,2 lpm a 0,1 bar1,9 lpm a 0,2 bar2,4 lpm a 0,3 bar1,8 lpm a 0,1 bar2,4 lpm a 0,2 bar3,6 lpm a 0,2 bar8 lpm a 1 bar6.200 a 1,2 lpm9.000 a 1,9 lpm12.400 a 2,4 lpm9.600 a 1,8 lpm14.400 a 2,4 lpm19.200 a 3,6 lpm38.400 a 8 lpmGAC-40 CC BIGGAC-40 CC BIGFA-CA PP20FA-CA PP20FA-CA PP20FA-CA PP20FA-CA PP209”3/420”5”7”9”3/410”20”8 lpm a 0,2 bar14 lpm a 0,4 bar1,4 lpm a 0,1 bar2,1 lpm a 0,2 bar2,6 lpm a 0,3 bar2,6 lpm a 0,3 bar5,2 lpm a 1 bar180.000 a 8 lpm360.000 a 14 lpm6.400 a 1,4 lpm9.200 a 2,1 lpm12.600 a 2,6 lpm12.600 a 2,6 lpm25.200 a 5,2 lpmGAC-40GAC-40GAC-5 CCGAC-5 CCGAC-40 CCGAC-40 CC9”3/420”9”3/420”9”3/420”3,6 lpm a 0,2 bar8 lpm a 1 bar3,8 lpm a 0,2 bar8 lpm a 1 bar3,8 lpm a 0,2 bar8 lpm a 1 bar19.200 a 3,6 lpm38.400 a 8 lpm28.400 a 3,8 lpm58.000 a 8 lpm28.400 a 3,8 lpm58.000 a 8 lpmCE-CACE-CACE-CACE-CAFRN-CAFRN-CAFRN-CA5”7”9”3/420”5”9”3/420”7 lpm a 0,3 bar12 lpm a 0,3 bar18 lpm a 0,4 bar24 lpm a 1 bar1 lpm a 0,1 bar2 lpm a 0,3 bar3,5 lpm a 1 bar8.500 a 1,8 lpm14.400 a 3 lpm24.400 a 4 lpm38.000 a 4 lpm4.200 a 1 lpm8.400 a 2 lpm16.800 a 3,5 lpmGAC/P-40 CC9”3/47 lpm a 0,3 bar18.900 a 7 lpmCTO-E9”3/44 lpm a 0,2 bar12.000 a 4 lpmGAC-40 BIGGAC-40 BIG9”3/420”8 lpm a 0,2 bar14 lpm a 0,4 bar48.000 a 8 lpm110.000 a 14 lpmAQUA SELECT2 lpm a 0,5 bar900 a 2 lpmGAC-5 CC BIGGAC-5 CC BIG9”3/420”8 lpm a 0,2 bar14 lpm a 0,4 bar180.000 a 8 lpm360.000 a 14 lpm31

POLYPHOSPHATECARTRIDGESAQUA Srl offers various polyphosphatecartridges that defer in sizes and withdefined characteristics.Polyphosphate salts are anti-scalingchemical agents. Therefore ideal for usewith hard calcareous water, and whereeliminating of scale and corrosion isrequired.A polyphosphate cartridge consists of aplastic canister filled with crystal salts ofdifferent mesh. The canisters can vary insize.Once the polyphosphate salt has dissolveda chemical reaction takes placewithholding the suspended particles. Thisprevents scaling and depositing of theparticles along pipelines or insidemechanical components, avoidinginefficiency.To be efficient, all polyphosphate cartridgerequire a determined time of watercontact. However, thanks to its fastdissolving effect this period is relativelyshort.Polyphosphate cartridges have a lowpressure drop.Usually they are used in industrialapplications. Standard regulations requirethat only minimal dosage is allowed whenapplied to drinking water. Therefore, inthese cases, it is necessary to have anaccurate and controlled dosageguaranteed by a dosing pump (AQUA-Mini & AQUA-Dos, see our Dosing SystemsProduct Guide)It is important to fully understand theuse of such cartridges so as to determinethe correct application.For applications and maintenance, pleaserefer to the data sheet indicated for eachmodel.IDEAL APPLICATIONS ARE:Inlet of heaters, Inlet of washing machines.FLOW RATE (lpm)MODEL HEIGHT RECOMMENDED FLOW RATERLA CPRLA CPRLA CPCPCPCPCP5”7”9”3/45”7”9”3/420”4 lpm6 lpm8 lpm6 lpm9 lpm12 lpm18 lpmRLA-CP linespecial cartridges32

RLA-CP/CPTECHNICAL FEATURESFilter media:Pre filter:Post filter:Core:Out cage:End caps:O-Ring / Gasket:Length:Inner diameter:Outer diameter:Micron rating:Pre filter micronPost filter micronEfficiency (pre and post filter):Pressure:Max working pressure:Max diferential pressure:Max Temperature:Max working temperature:RLA-CPFOOD GRADE POLYPHOSPHATEPAPES-PPSOE-PPPVC5”-7”-9”3/427 mm65 mm802075%6 bar0,8 bar38°CCPFOOD GRADE POLYPHOSPHATEPESPES-PSTSOE-PSTPVC5”-7”-9”3/4-20”27 mm72 mm202075%6 bar0,8 bar38°CNote: Max water flow rate at 20°C and differentiaal pressure 0,15 barWASHABLE NET CARTRIDGES WITH POLYPHOSPHATESseries RLA-CPCOD MICRON LENGTH QUANTITYboxA4100010A4100020A41000308080805”7”9”3/4301515Kgbox12,608,7412,50VOLUMEpackage0,0300,0300,030TRANSPARENT CANISTERseries CVCOD MICRON LENGTH QUANTITYboxA4110010A4110020A4110030A4110040----5”7”9”3/420”100705025Kgbox12,9611,7011,0711,13VOLUMEpackage0,0930,0930,0930,09334

BLU CANISTERseries CVCOD MICRON LENGTH QUANTITYboxA4110070A4110110A4110060A4110120----5”7”9”3/420”100705025Kgbox12,9611,7011,0711,13VOLUMEpackage0,0930,0930,0930,093CARTRIDGES WITH POLYPHOSPHATESseries CP / PRE-POST 20 MICRON FILTERCOD MICRON LENGTH QUANTITYboxA4130010A4130020A4130030A4130040202020205”7”9”3/420”30151515Kgbox14,0311,0616,1331,21VOLUMEpackage0,0300,0300,0300,035CARTRIDGES WITH POLYPHOSPHATESseries CP-BLU / PRE-POST 20 MICRON FILTERCOD MICRON LENGTH QUANTITYboxA4130050A4130060A4130070A4130080202020205”7”9”3/420”30151515Kgbox14,0311,0616,1331,21VOLUMEpackage0,0300,0300,0300,03535

SPECIALCARTRIDGESAQUA can supply the following models ofSpecial CartridgesQUARTZ CARTRIDGES;The QU series are filtering cartridges madewith siliceous sand (quartz). Very fine grainsare used which are bonded together by aepoxy component very resistant to water.The extremely compact mesh constructionguarantees a nominal filtration of 30microns with a filtering efficiency of 82%.This is a mechanical filter and it is usedfor eliminating or reducing suspended solidparticles or when there is turbid water.Quartz cartridges can be used several timesbut require a thorough clean from time totime. This can be done by submersing thecartridge into a 10% dilute solution ofhydrochloric acid for 4 to 10 hours andthen using compressed air on the surfacemaking sure the action is from external tointernal.Because of its structure It is suggested notto use these cartridges excessively as thefiltered particles will become more difficultto remove and consequently pressure dropwill jeopardize the efficiency and growthof bacteria will accrue.STERILIZING CARTRIDGES:Antibacterial Ceramic Cartridges aremechanical cartridges and not biological.During the filtration they sterilize becausea special fossil flour of diatom is used.These cartridges are very porous with veryfine mesh that can filter very finesuspended particles. This means alsobacteria will be filtered.It has to be clarified that these cartridgeswill act only as a barrier to bacteria downto a size of 0.5 micron.Changing of these cartridges depends onthe working conditions. In any case wesuggest not to use such cartridge for morethan 12 months.APPLICATIONS:Water TreatmentFLOW RATE (lph)MICRON300,40,40,5QUMXMCAAQUA SELECT9“3/412012060QU-ST linespecial cartridges36

specialTECHNICAL FEATURESRaw material:Filter media:Core:Outer cage:End caps:O-Ring / Gasket:Length:Inner diameter:Outer diameter:Micron rating:Efficiency:Pressure:Max working pressure:Max diferential pressure:Temperature:Max working temperature:QUQUARTZ--DOEPES5”-7”-9”3/428 mm55 mm3082%6 bar0,8 bar38°CMXSINTERED DIATOMACEOUS EARTH--DOE-240 mm1/4” x 30 mm52 mm0,499,9%6 bar0,8 bar38°CNote: Max water flow rate at 20°C and diferential pressure 0,15 barQUARTZ CARTRIDGES series QUCOD MICRON LENGTH QUANTITYboxA4160010A4160020A41600303030305”7”9”3/4181212Kgbox6,856,058,07VOLUMEpackage0,0280,0280,028STERILIZING CARTRIDGES D.O.E. series MXCOD MICRON LENGTH QUANTITY Kg VOLUMEboxbox packageA4180010 0,4 240 24 7,40 0,02838

specialTECHNICAL FEATURES MCA AQUA SELECTRaw material::Filter media:Core:Outer cage:End caps:O-Ring / Gasket:Length:Inner diameter:Outer diameter:Micron rating:Efficiency:Pressure:Max working pressure:Max diferential pressure:Temperature:Max working temperature:SINTERED DIATOMACEOUS EARTHG.A.C.--DOE-240 mm1/4” x 30 mm52 mm0,499,9%6 bar0,8 bar38°CSINTERED DIATOMACEOUS EARTH-ABS-DOE-72 mm13 mm50 mm0,599,9%6 bar0,8 bar38°CNote: Max water flow rate at 20°C and diferential pressure 0,15 barSTERILIZING CARTRIDGES D.O.E. series MCACOD MICRON LENGTH QUANTITYboxA4190010KgboxVOLUMEpackage0,4 240 24 9,80 0,028CERAMIC AND ACTIVE CARBON CARTRIDGES FOR AQUA SELECTCOD MICRON LENGTH QUANTITYboxA8090040KgboxVOLUMEpackage0,5 72 mm 50 6,50 0,02839

RESINCARTRIDGESCartridges with ionic exchange resin areused for eliminating ionic substance whichare present in water.According to the type of filter media used,they can by applied for treating water withcalcium and magnesium, reducing thepresence of iron and obtain de-mineralizedwater.All cartridges are assembled with a pre andpost filtration. This optimizes the efficiencyof the resin for water inbound andimproves the quality of the treated wateroutbound.Similar to the GAC cartridges, the Pre &post filters are made of melt blown whichis of the same technology used for ourFR-N cartridges. This technologyguarantees a very efficient filtering action.APPLICATIONS:Water TretmentGeneral IndustriesLaboratoryFLOW RATE (lpm)MODELRCRCRC-BIGRC-BIGR-DEMIR-DEMIR-DEMI BIGR-DEMI BIGFE-BIGlength9”3/420”9”3/420”9”3/420”9”3/420”20”recommendedflow rate2 lpm3 lpm4,5 lpm8 lpm1 lpm1,6 lpm2,5 lpm4,7 lpm24 lpmmin. total exchangecapacity,cation exchange resinion exchange resineq/lKgr/ft3 as CaCo3eq/lKgr/ft3 as CaCO3Na+Form1,941,5OH+Form1,021,9H + Form1,839,3resin linespecial cartridges40

esinTECHNICAL FEATURES RC RC-BIG R-DEMI R-DEMI BIG FE-BIGFilter media:Pre filter:Post filter:Core:Out cage:End caps:O-Ring / Gasket:Length:Inner diameter:Outer diameter:Micron rating:Pre filter micronPost filter micronEfficiency (pre and post filter):Pressure:Max working pressure:Max diferential pressure:Temperature:Max working temperature:CATION RESINPPPP-PPDOE-PPPVC9”3/4-20”26 mm72 mm5595%6 bar0,8 bar38°CCATION RESINPPPP-PPDOE-PPPVC9”3/4-20”26 mm120 mm5595%6 bar0,8 bar38°CMIX BED RESINPPPP-PPDOE-PPPVC9”3/4-20”26 mm72 mm5595%6 bar0,8 bar38°CMIX BED RESINPPPP-PPDOE-PPPVC9”3/4-20”26 mm120 mm5595%6 bar0,8 bar38°CSILICA CRYSTALSPPPP-PPDOE-PPPVC9”3/4-20”26 mm120 mm404095%6 bar0,8 bar3°CNote: Max water flow rate at 20°C and diferential pressure 0,15 barCATION EXCHANGE RESIN CARTRIDGESseries RC / PRE-POST 40 MICRON FILTERCOD MICRON LENGTH QUANTITYboxA4150010A4150040559”3/420”1515Kgbox11,3225,00VOLUMEpackage0,0300,035CATION EXCHANGE RESIN CARTRIDGESseries RC-BIG / PRE-POST 40 MICRON FILTERCOD MICRON LENGTH QUANTITYboxA4150050A4150060559”3/420”66Kgbox12,1328,50VOLUMEpackage0,0300,035IONIC EXCHANGE RESIN CARTRIDGEseries R-DEMI / PRE-POST 40 MICRON FILTERCOD MICRON LENGTH QUANTITYboxA4150070A4150080559”3/420”1515Kgbox11,3225,00VOLUMEpackage0,0300,03542

IONIC EXCHANGE RESIN CARTRIDGESseries R-DEMI-BIG / PRE-POST 40 MICRON FILTERCOD MICRON LENGTH QUANTITYboxA4150090A4150100559”3/420”66Kgbox12,1328,10VOLUMEpackage0,0300,035IRON REMOVAL CARTRIDGESseries FE / PRE-POST 40 MICRON FILTERCOD MICRON LENGTH QUANTITYboxA4150110KgboxVOLUMEpackage40 20” 6 28,10 0,035iron levelin water5 ppmAPPROXIMATE LIFE OF CARTRIDGEtotal ltwater used1000 lt day4 people60.00060 60 days500 lt day2 people120 120 days4 ppm83.00083 83 days166 166 days3 ppm105.000105 105 days210 210 days2 ppm158.000158 158 days316 316 days1 ppm310.000310 310 days620 620 days0,5 ppm620.000620 620 days1.240 1.240 daysNote (1): in order to use silica crystals, the following characteristics are required:- minimum water hardness of 5°Fr.- minimum 80 mg/l TDS (total dissolved solids)- back wash flow rate between 17 and 24 m3/hNote (2): high iron concentration inside the water may cause unpleasant taste and smell. In this case it’s addvisableto use an active carbon cartridge, series GAC-BIG-CC.43

4420304050102550802550401111123111112211111111111111111111111111113113323333332133131121221111111121111111112222332311212321111111211111111111111111111211332123221*111231111122111111111111111111111111111131131***2131*********1****************************1*A11231111122111111111111111111111111111131132*A23223*********1****************************1112112312*12113*11111111111211111112122112111113111131322111111111111111111111121111131211132321331222222*1*1*133223222132231211121*13213TEMPERATUREMINERAL ACIDHYDROCHLORIC ACIDCHROMIC ACIDHYDROFLUORIC ACIDPHOSPHORIC ACIDNITRIC ACIDSULPHURIC ACIDACQUA REGIAORGANIC ACIDACETIC ACIDBENZOIC ACIDBUTYRIC ACIDFORMIC ACIDLACTIC ACIDOLEIC ACIDOXALIC ACIDSALICYLIC ACIDSALTSSODIUM ACETATESODIUM BENZOATESODIUM BISULPATESODIUM BROMIDESODIUM CHYANIDALUMINIUM CHLORIDEAMMONIUM CHLORIDEBARIUM CHLORIDECALCIUM CHLORIDEFERRIC CHLORIDEMAGNESIUM CHLORIDESODIUM CHLORIDEZINC CHLORIDESODIUM NITRATEALUMINIUM SULPHATECOPPER SULPHATESODIUM SULPHATESODIUM SULPHIDEBASECALCIUM CARBONATEPOTASSIUM CARBONATESODIUM CARBONATEAMMONIUM HYDROXIDECALCIUM HYDROXYDEPOTASSIUM HYDROXYDESODIUM HYDROXYDEOXIDIZING AGENTSPERACET ACIDPOTASSIUM BICHROMATEBROMINESODIUM CHLORITEPOTASIUM CHLORITECHLORINE% CONCENTRATIONPOLYPROPYLENEPOLYAMIDEPOLYESTERPOLYPROPYLENE TFSANPOLYPROPYLENE GFABSVITONPVCAISI 304

455103020100901001004031211111221111232323212323323222321121231111111313333321111111113111111111212123311121131111112111121111111112111112111111121123111211111111131211111221111232323212323323222321121231111111*1********332333***33*3333333**333*1331*121211131211111221111232323212323223222321121231111111*2********33233****33*3333333**333*2**1*221111121111123333212113213311132211*23213112121111111*12113133332223333333*1*33333*3332213313111111132*2233112111123*112211111111111121111111113111FLUORINESODIUM HYPOCHLORITEOZONOPOTASSIUM PERMANGANATEHYDROGEN PEROXIDEIODINE SOLUTIONCALCIUM HYPOCLORITEORGANIC SOLVENTSAMYL ACETATEBUTYL ACETATEETHYL ACETATEACETONEAMYL ALCOHOLETHIL ALCOHOLMETHYL ALCOHOLBENZENECARBON BISULFIDECYCLOHEXANONECHLOROFORMETHIL CHLORIDEETHER BENZENEETHYL ETHERDIETHYLENE GLYCOLETHYLENE GLYCOLPROPYLENE GLYCOLMETHYL ETHYL KETONECARBON TETRACHLORIDETOLUENETRICHLOROETHYLENEXYLENEMISCELLANEOUSACETALDEHIDE IN WATERANILINEBENZALDEHYDE IN WATERCRESOLPHENOLFORMALDEHYDEGLYCERINENAPHTHANITROBENZENEMINERAL OILTRICRESYL PHOSPHATEBEERINKSOLIVE OILSEA WATERWINEWHISKEYMILKTEMPERATURE% CONCENTRATIONPOLYPROPYLENEPOLYAMIDEPOLYESTERPOLYPROPYLENE TFSANPOLYPROPYLENE GFABSVITONPVCAISI 304

CODEFRNCARTRIDGES SPARE PARTSFA CE PL RL RLA KID AC ACP CV CP CA GAC CTO FACA CECA RGASKET FORCARTRIDGES 3/4”-1”A6010210 GASKET 52x27x4•••••••••• ••••CARTRIDGES 1”1/4-1”1/2-2”A6010860 GASKET 52x40x4••A6012070 GASKET 50x31x3,5•MG020020 GASKET 53x28x8 S/AD•••MC030070 GASKET 21 D. 70x20 mm•••MC030260 GASKET 21 D. 52x20 mm•COUPLERSA6010190 UNIVERSAL GOUPLERS FOR CARTRIDGE• •••••••S4110160 CARTRIDGE GOUPLER CV••••A6050260 CARTRIDGE GOUPLER AQUA PRO••DIFFUSER TUBEA6010100 DIFFUSER TUBE 5”A6010110 DIFFUSER TUBE 7”A6010120 DIFFUSER TUBE 9”3/4A6010130 DIFFUSER TUBE 20”A6012080 DIFFUSER TUBE 9”3/4 BIGA6012090 DIFFUSER TUBE 20” BIGPG010060 O.RING TUBE STANDARDMG010480 O.RING TUBE AQUA BIGA6010140 DIFFUSER DISC STANDARDA6011370 DIFFUSER DISC AQUA KIDA6012100 DIFFUSER DISC AQUA BIGFILTER MEDIAMC010010 COCO SHELL GRANULAR-ACTIVATED CARBON 12X30 ACID WASHEDMC020030 POWDER POLYPHOSPHATE SALTSMC020010 FINE GRANULAR POLYPHOSPHATE SALTSMC030120 SOFTENER CATION RESIN (KG. 20)MC030160 MIX BED RESIN (KG. 20)MC030400 IRON REMOVER (Silica crystals) (KG. 22,7)KGKGKGLTLTLT25252525252846

WarrantyAll the articles produced by Aqua are under warranty for a period of one year from the date of purchase. Theterms of warranty require that:The article be used following the instructions printed by the manufacturer, Aqua.Installation and maintenance be carried out following the instructions of the manufacturer, Aqua.Goods under warranty be replaced only upon submission of faulty material and upon verification of the natureof the defect, which will be considered in light of technical data available from the data-base in the Aquaengineering department, where the results of daily product testing are recorded.Warranty be limited to replacement of the faulty part only, to the exclusion of any other claim by the customerfor direct or indirect damages caused by the product.The customer pay all labor and transport expenses necessary for replacement of the part covered by thewarranty.Any warranty on Aqua products be suspended upon failure to comply with the general regulations printedby the manufacturer, or failure to comply with the relevant European regulations in force.General Sales TermsAqua accepts only written orders and reserves the right to confirm all orders.Failure to comply with sales terms, including payment for the goods sold, will automatically result in thesuspension of any delivery underway or any previously accepted orders.The goods are sold FRANCO AQUA PLANT, meaning that the customer is authorized to collect the goods in theway deemed appropriate.In the absence of specific instructions, Aqua will dispatch the goods at their discretion.Aqua accepts no liability for the goods after they have left the Aqua warehouses, therefore whoever picks upthe goods will have to check to make sure the packages are in good condition and that there is the correctnumber of pieces, notwithstanding of the type of packing used.Aqua reserves the right to make changes in the technical specifications and prices of its products, withoutproviding advance notification.Any litigation that may arise will be judged by the Competent Court of Reggio Emilia, the applicable law andthe italian law.LEGENDPP PES PA= Polypropylene = Polyester = NylonPVC PST SS= Polyvinyl chloride = Polystyrene = Stainless steel
