Technical Data - VELUX modulaire lichtstraten

Technical dataVELUX2Modular skylightPerformance areaTechnical valueProperty Standard Symbol and UnitRoof Windows & Skylights (EN 14351-1:2006+A1:2010)8H-20G1-33.2FLow EVariant 102-layer panePane variant8H-20G1-33.2FLSUN1Variant 113-layer pane8H-12G1-8HS-12G1-33.2FLow EVariant 16Resistance to wind load EN 12211 / EN 12210 Class C5Water tightness EN 12208 / EN 1027 Class E900Air permeability EN 12207 / EN 1026 Class 4Sound insulationEN ISO 717-1 /EN ISO 140-3Rw (C; Ctr) [dB] 35Thermal transmittance EN ISO 10077-2 Uw [W/(m²K)] 1,4 1,0Radiation – Solar factor EN 410 - 0,58 0,27 0,47Radiation – LighttransmittanceEN 410 - 0,77 0,48 0,68Resistance to snow load - IGU 8/20/33.2 8/12/8/12/33.2Reaction to fire EN 13501-1 Class B, s1-d2External fireperformanceEN 13501-5 / BS 476-3 Class Npd


Technical dataVELUX3Modular skylightPerformance areaTechnical valueProperty Standard Symbol and UnitNSHEV (Natural Heat and Smoke Exhaust Ventilators EN 12101-2:2003)8H-20G1-33.2FLow EVariant 102-layer panePane variant8H-20G1-33.2FLSUN1Variant 113-layer pane8H-12G1-8HS-12G1-33.2FLow EVariant 16Geometric area - Av [m 2 ] 0,462 - 1,436 depending on sizeAerodynamic areaEN 12101-2Annex BAa [m 2 ]0,19-0,65 depending on sizeAerodynamic valueEN 12101-2Annex BCv00,44 - 0,57 depending on sizeOpening speed(smoke vent.)EN 12101-2 [Sec] < 60Snow load (SL)Wind load (WL)Low ambienttemperature (T)EN 12101-2Annex EEN 12101-2Annex FEN 12101-2Annex ESL [N/m2] 750 N/m 2WL [N/m 2] 3000 N/m 2T [°C] T -15Reliability (RE)(Dual purpose)(smoke vent. + comfortvent.)EN 12101-2Annex CRE[No of opening]1000 + 10000Resistance to heat (B)EN 12101-2Annex CEN 13823ISO 11925-2B [°C]B300Reaction to fire forNSHEVMinimum installationheightEN 13501-1 Class B, s1-d2)60335-2-103 Height (m) 2.5 mOther relevant properties (discussed outside EN 14351-1:2006+A1:2010)Resistance to fire EN 13501-2 Class Npd


Technical dataVELUX4PanePerformance areaTechnical valueProperty Standard Symbol and Unit8H-20G1-33.2FLow EVariant 102-layer panePane variant8H-20G1-33.2FLSUN1Variant 113-layer pane8H-12G1-8HS-12G1-33.2FLow EVariant 16Reaction to fire EN 13501-1 Class Npd Npd NpdExternal fire performance EN 13501-5 Class Npd Npd NpdBullet resistance EN 1522 Class Npd Npd NpdExplosion resistance EN 13123-1 Class Npd Npd NpdBurglary resistance EN 356 Class Npd Npd NpdPendulum body impactresistanceResistance againstsudden temperaturechanges andtemperature differentialsWind, snow, permanentand imposed loadresistanceEN 12600 Class Npd Npd NpdENV 13420 [K] Npd Npd Npd- IGU 8/20/33.2 8/20/33.2 8/12/8/12/33.2Direct airborne soundinsulationEN ISO 717-1 /EN ISO 140-3Rw (C; Ctr) [dB] 42 (-3; -8) 41 (-3; -8) 40 (-3; -8)External fire performance EN 13501-5 / BS 476-3 Class Npd Npd NpdRain noise - ? Npd Npd NpdThermal transmittanceCentre-of-GlassEN ISO12567-2 Ug [W/(m²K)] 1.1 1,1 0,7Light transmittance EN 410 tV 0,77 0,48 0,68Light reflectance EN 410 rV (external) Npd Npd NpdUltraviolet transmittance EN 410 tUV Npd Npd NpdSolar directtransmittanceEN 410 te Npd Npd NpdSolar direct reflectance EN 410 re (external) Npd Npd NpdTotal solar energytransmittanceEN 410 g 0,58 0,27 0,47


Technical dataVELUX5FlashingMaterialMaterial thicknessAluminium1,0 mmSurface Front: Polyamide polyester lacquer Back: PVDF/ polyester lacquerColour Front: NCS standard colour: S 7500-N Back: UnspecifiedChain actuatorMaterialAluminium housing with steel chainDimensions 76 x 50 mm (W x D). L = 632WeightConnection cableChain strokeSpeedForce (pressure/traction)Locking forceTemperature condensationPower consumptionVoltageSwitch-on-durationOpen-circuit voltage4,3 kg50 mm grey silicone cable 3-core 0,34 mm 2 with fast on connector410–730 mm11,6 mm/s (full load)/full opening in 60 sek1300 N/500N3000 N-5°C to +74°C max. 90% relative humidity (not condensing)24 VDC19-32 VDCED max. 20 % (2 min per 10 min.)Max. 32 VDCCurrent consumption Max. 5 A.


Technical dataVELUX6Beam for 5 degree ridgeMaterialMaterial thicknessConstructionSurfaceSteel3 mmHollow beamPainted with white primer


Technical dataVELUX7Roller BlindSizesPlease refer to Product description for VELUX Modular Skylights. Can also be made to measure.Materials (Visible parts) Fabric PolyesterWireControl barTop pulley wheelsStainless steelAnodized aluminiumStainless steel (stone rumbled)Colours (cloth)InstallationCompabilityGrey, black and whitePlease see installation instructionAll VMS skylightsDimensions Product incl. packaging: 145 mm x 105 mm x 1.210 mm (W x H x L)Control systemPower consumptionConnectionIO home control0,4 A (awg.) / 24 VDelivered with motor cable for direct connection in the connection box in the window frameLight values* Grey: Reflection 20 %Transmission 10%Absorption 70 %* Tolerance +/-5Black: Reflection 20 %Transmission 10%Absorption 70 %White: Reflection 50 %Transmission 45%Absorption 5 %V-455265 © 2011 VELUX Group. ® VELUX og VELUX logo er registrerede varemærker anvendt under licens af VELUX Group.VELUX A/SModular SkylightÅdalsvej 99DK-2970 HørsholmTelephone: +45 45 16 40 00www.velux.com
