Presentation of existing <strong>SHOLS</strong><br />
system and future concepts for<br />
improved availability<br />
By<br />
<strong>Kongsberg</strong> <strong>Seatex</strong> AS<br />
Finn Otto Sanne<br />
Harlans Seminar 2007<br />
© KONGSBERG
Agenda<br />
1. Introduction<br />
2. The <strong>SHOLS</strong> system<br />
– SAP-90<br />
– The <strong>HMS</strong> <strong>100</strong> <strong>SHOLS</strong> system<br />
– Present installations<br />
3. Future concepts<br />
– Additional measurements<br />
– Landing Period Designator, LPD<br />
© KONGSBERG
Introduction - <strong>Kongsberg</strong> <strong>Seatex</strong><br />
• A company within the <strong>Kongsberg</strong> Maritime AS<br />
• Established in 1984, located in Trondheim with 90 employees<br />
• Product areas:<br />
– Surface Positioning Reference Systems (GPS/Glonass/Galileo)<br />
– Automatic Identification Systems (AIS)<br />
– Attitude sensors, like the motion sensor MRU and Seapath<br />
– Helideck Monitoring Systems (<strong>HMS</strong>)<br />
• We are the <strong>SHOLS</strong> system supplier to the Norwegian Navy<br />
© KONGSBERG
<strong>Kongsberg</strong> <strong>Seatex</strong><br />
<strong>HMS</strong> <strong>100</strong> <strong>SHOLS</strong><br />
(Ship Helicopter Operating Limits)<br />
A Computer Aided SAP-90<br />
© KONGSBERG
<strong>HMS</strong> <strong>100</strong> <strong>SHOLS</strong> - An electronic version of SAP-90<br />
© KONGSBERG
<strong>HMS</strong> <strong>100</strong> <strong>SHOLS</strong> – Electronic description of operations<br />
© KONGSBERG
<strong>HMS</strong> <strong>100</strong> <strong>SHOLS</strong> - Configuration of Operations & Procedures<br />
© KONGSBERG
<strong>HMS</strong> <strong>100</strong> <strong>SHOLS</strong> – Observed parameters<br />
Images: ForsvarsNett<br />
© KONGSBERG
<strong>HMS</strong> <strong>100</strong> <strong>SHOLS</strong> - System Description<br />
© KONGSBERG
<strong>HMS</strong> <strong>100</strong> <strong>SHOLS</strong> – Part locations<br />
Met sensors<br />
Bridge operator station<br />
Light panel<br />
MRU<br />
FDO display & waveoff<br />
© KONGSBERG
<strong>HMS</strong> <strong>100</strong> <strong>SHOLS</strong> - Processing<br />
SAP90B<br />
<strong>SHOLS</strong><br />
Data<br />
Motion Data<br />
Wind<br />
Limiter<br />
Motion<br />
Limiter<br />
MDM<br />
Limiter<br />
GO<br />
Met. Data<br />
NOGO<br />
Wind: Wind speed and direction<br />
Motion: SigmaRoll and SigmaPitch<br />
MDM: Max. Density Mass<br />
© KONGSBERG
<strong>HMS</strong> <strong>100</strong> <strong>SHOLS</strong> Processing - Diagrams<br />
300<br />
330<br />
Optimum daytime operational flight envelope for<br />
take-off and landing - Procedures<br />
0<br />
30<br />
Crossdeck facing port<br />
Relativ wind (port)<br />
Fore-aft<br />
Relativ wind (strb)<br />
Crossdeck facing strb<br />
60<br />
Ship Motion Limits<br />
+Heli-mass,<br />
temperature and<br />
airpressure<br />
Optimum daytime operational flight envelope for<br />
take-off and landing - MDM limits<br />
0<br />
270<br />
90<br />
Optimum daytime operational flight envelope for<br />
take-off and landing - Ship motion limits<br />
0<br />
330<br />
30<br />
Low wind<br />
High wind<br />
0 20 40 60<br />
330<br />
30<br />
Area A<br />
Area B<br />
Area C+D<br />
Area E<br />
300<br />
60<br />
240<br />
120<br />
300<br />
60<br />
210<br />
180<br />
150<br />
270<br />
90<br />
270<br />
0 20 40 60<br />
90<br />
0 20 40 60<br />
Procedures<br />
240<br />
120<br />
240<br />
120<br />
210<br />
150<br />
Relative wind<br />
210<br />
180<br />
150<br />
+Sigma Roll / Pitch<br />
180<br />
MDM Limits<br />
© KONGSBERG
<strong>HMS</strong> <strong>100</strong> <strong>SHOLS</strong> Operation - Detailed Presentation Window<br />
© KONGSBERG
<strong>HMS</strong> <strong>100</strong> <strong>SHOLS</strong> Operation - Start-up Procedure<br />
1. Select <strong>SHOLS</strong><br />
configuration day or night<br />
2. Enable logging and select<br />
Start in Run menu<br />
3. Input weight for the<br />
helicopter<br />
4. Select helicopter<br />
operation<br />
5. Select procedure for the<br />
selected operation<br />
6. Select wanted exterior<br />
light indication (Off, Red<br />
or Auto)<br />
© KONGSBERG
<strong>HMS</strong> <strong>100</strong> <strong>SHOLS</strong> Operation - Lights Panel Symbols<br />
DAY<br />
GO NOGO WAVE OFF<br />
NIGHT<br />
(NVG)<br />
© KONGSBERG
<strong>HMS</strong> <strong>100</strong> <strong>SHOLS</strong> Operation - Lights Panel<br />
• Dot-matrix panels<br />
• Symbolic representation<br />
• Flashing or steady<br />
• Light intensity rating:<br />
5500cd/m2<br />
• Adjustable intensity<br />
• Heating available<br />
• Dimension: 600X600X175 mm<br />
© KONGSBERG
<strong>HMS</strong> <strong>100</strong> <strong>SHOLS</strong> – Installations<br />
• All Coast Guard vessels in the<br />
Nordkapp class<br />
• The Coast Guard vessel Svalbard<br />
• All the new frigates in the<br />
Nansen class<br />
• Two of the coastal express<br />
vessels “Hurtigruten” for medical<br />
purposes<br />
© KONGSBERG
<strong>HMS</strong> <strong>100</strong> <strong>SHOLS</strong> – Main Goals<br />
• Automatic method to calculate whether the helideck motion is<br />
within the SAP-90 limits or not.<br />
• Go or NoGo for operations based on <strong>SHOLS</strong> calculations<br />
• Visual landing aid on the helideck<br />
• The complete helicopter operation can be compared to limits<br />
on all procedures simultaneously<br />
• Helicopter mission planning tool<br />
• Reduce the stress level for the crew and pilot during landing<br />
and take-off<br />
© KONGSBERG
Future concepts for improved<br />
availability:<br />
- Additional Measurements in <strong>SHOLS</strong><br />
- A Landing Period Designator<br />
© KONGSBERG
Future Concepts – Additional Measurements in <strong>SHOLS</strong><br />
• Heave and heave<br />
rate. Reduces the<br />
probability for hard<br />
landings due to limited<br />
capacity of the<br />
helicopter to follow the<br />
deck dynamics.<br />
• Measure horizontal<br />
accelerations.<br />
Reduce the probability<br />
to roll-over when<br />
standing on the deck.<br />
A Motion Severity<br />
Index (MSI) is under<br />
development.<br />
© KONGSBERG
Future Concepts – Landing Period Designator (LPD)<br />
• Measures position, velocity and<br />
acceleration and calculates an Energy<br />
Index- EI value<br />
• Determines the rate a ship can move<br />
because of its hydrodynamic forces<br />
against the hull and the dynamic<br />
characteristics of the matching<br />
helicopter<br />
• Determines the risetime in seconds for<br />
the accumulated energies in a ship to<br />
produce a motion from calm to a high<br />
risk condition (from green/very safe to<br />
red/danger)<br />
• The EI value is compared to a deck<br />
availability scale displayed to the user<br />
Green Deck<br />
Deck Stable<br />
(EI value 0-1.74)<br />
Green-Amber<br />
Deck Available<br />
Energy in Deck<br />
(EI value 1.74-4)<br />
Amber<br />
Deck Available<br />
Considerable Energy in Deck<br />
(EI value 4-10)<br />
Red Deck<br />
Deck Out-of Limits<br />
(EI value >10)<br />
Wave-Off<br />
© KONGSBERG
<strong>HMS</strong> <strong>100</strong> LPD<br />
• Tested by the US Navy<br />
since 1997 and also by<br />
the Royal Navy<br />
• Part of the US Navy<br />
Dynamic Interface<br />
program<br />
• The equipment is now<br />
in its final evaluation<br />
phase by the US Navy<br />
© KONGSBERG
