Oculus - Architectural Area Lighting

®

Precision Floodlighting

ARCHITECTURAL AREA LIGHTING


ENERGY EFFICIENCY

AAL's Oculus is designed to

use electrical energy in the

most efficient possible way. Its

reflectors are designed to direct

illumination with no stray light

which translates into wasted

energy. The result is more light

with less energy consumption.

LONGEVITY

AAL manufactures all its

products to have a life span as

long as the buildings or spaces

they illuminate. The primary

material used for all our products

is aluminum to resist corrosion

and the need for maintenance.

Aluminum will not need the

periodic refinishing required of

steel products that will eventually

rust and corrode. All our internal

parts and fasteners are made

of aluminum or stainless steel.

Lamp enclosures are kept dust

free and dry to prevent light

degradation and maintain a high

level of energy efficiency.

SUSTAINABILITY

AAL's products are developed

with recycling and resource

management in mind. We

recycle all incoming packaging

materials. Our products are

shipped in easy to recycle

packaging materials. Our

state-of-the-art finishing system

uses eco-friendly cleansing

and preparation chemicals.

Our powder coating process

eliminates the release of volatile

chemicals into the atmosphere.

AAL makes the Oculus, like all

AAL products, with renewable

materials such as aluminum and

stainless steel.

Contents

Table of

Design Excellence 8

Optical Systems 10

Mounting Flexibility 12

Oculus Nano 16

IDA Approved Dark-Sky

Friendly versions of these

luminaires are available.

Oculus Small 20

Oculus Large 24

TM

The Oculus ® is registered and protected by a patent granted by

the United States Patent Office. U.S. Patent D468,477

©2011 Architectural Area Lighting.

Printed on recycled paper.

2


design with

light

®

The Oculus ® elevates precision

floodlighting to a new level of

application flexibility and aesthetic

design to artistically illuminate

exterior and interior details

OCULUS ® FAMILY 3


®

Family of Luminaires

Highly

versatile,

controllable,

& precise

lighting system

®

LARGE

AAL CodeLink SM

4

OL spec sheet


®

®

SMALL

AAL CodeLink SM

NANO

OS spec sheet

AAL CodeLink SM

ON spec sheet

OCULUS ® FAMILY 5


6


Milwaukee Museum of Art

Calatrava Architects

Kahler Slater, Architect of Record

Ring & DuChateau Inc. Lighting Design

Oculus - Illuminating the “Wing”

®

OCULUS ® FAMILY 7


O

DESIGN EXCELLENCE

WATER RESISTANT BEZEL

• Eliminates water ponding even in the

straight up position

• No mineral stains on the glass from

standing water

Corrosion Resistant HOUSING

• Cast aluminum housing

with stainless steel hardware

• Super TGIC powder coat

finish with polymer

primer sealer for maximum

corrosion resistance

ONE-PIECE, MEMORY RETENTIVE

SILICONE GASKET

iP Rating of 66

• Molded silicone gaskets, ensure a

water tight and dust free operation

environment

Separate Lamp and Ballast

Housing

8

• Ballast runs cooler for longer life

• Allows for use of electronic metal

halide ballasts

• Can be ceiling mounted and semirecessed

in the wall

(not available with ONR)


105° tilt adjustment for aiming

Rotation is a full 360° with a cam stop

Internal accessories snap

on between the lens frame

and reflector, for the OSR

and OLR, and screw in for

the ONR.

Index marks on the OSR and

OLR lamp housing ensure the

correct position of the internal

accessories when relamping.

OCULUS ® FAMILY 9


O

OPTICAL SYSTEMS

Design

withlight

Three precision instruments designed to

address all floodlighting tasks.

Now you can truly design with

light. The adjustable reflector

beam on the small and large

Oculus ® models with parabolic reflector

allows on-site refinement of the light

pattern. You can adjust from a narrow

beam to a medium flood pattern with the

same luminaire. The Oculus Nano is also

field adjustable through lamp or reflector

changes. Snap (or screw in for ONR) in

a linear spread lens or diffusion lens for

even more beam patterns. Oculus ® gives

you the freedom to refine your lighting

design to changing field conditions without

replacing the fixture or reflector.

10


Refine

withlight

The Oculus Small and new Oculus Nano both feature high

efficiency, super bright white LED modules.

Oculus Small

• 30 LED (34.8 watt)

• 120 thru 277 volt

• Two color temperatures – warm white (3500K)

and bright white (5100K)

Oculus Nano

• 18 LED (22.2 watt)

• 120 thru 277 volt

• Two color temperatures – warm white (3500K)

and bright white (5100K)

• Suitable for 39 watt metal halide applications

The Oculus Nano is also available with a

Mini MasterColor ® option that features the long

life, high energy efficiency and crisp white light of

ceramic metal halide lamps with excellent color

quality, CRI=83

oCULUS

• High intensity axial beam optics

• Field adjustable beam pattern (OSR and OLR only)

• Round or elliptical beam shape with lenses

• Light Emitting Diodes (LED) optics (OSR and ONR)

• T6 and ED-17 metal halide optics

• Compact fluorescent optics

Uses:

• Highlight architectural features

• Ground, wall or ceiling mounting

• Graze surfaces

OCULUS ® FAMILY 11


O

OPTICAL SYSTEMS

Oculus Small & Large

uncontrolled arc tube

wasted light energy

baffle to minimize

uncontrolled beam

Oculus ®

Others

The Oculus ®

ADvantage

Other Horizontal

floodlights

The parabolic reflector with an axial lamp

orientation provides:

• A precise, parallel beam to direct the

light to where you want it.

• A concentrated beam for more center

beam punch and highlighting.

• Less stray, uncontrolled side light

reduces glare.

• Higher reflector efficiency means

more light output from the same

lamp wattage.

• Baffles used to attempt control of

stray light reduce the efficiency of the

fixture.

• The lower portion of the lamp lumens

are lost or redirected into the lamp

arc tube decreasing the

lamp life.

• Less beam control with an

uncontrolled, bare arc tube.

• Linear spread lens is difficult to aim

or adjust in a perpendicular direction

to the lamp.

External focusing

Final adjustment of the light to illuminate in

just the right way is easy. There is no need

to disassemble the Oculus ® to adjust the

beam pattern.

An adjustment screw on the exterior of the

fixture allows for easy, on site focusing for

a small tight beam to a larger spot pattern.

This also ensures the spread lens is in the

proper position when adjusting the beam.

12


One Reflector - Multiple BEAM Patterns

OLR 150PSMHT6

Large Oculus with

parabolic reflector

and 150 watt pulse

start T-6 ceramic

metal halide lamp.

The Oculus ® allows you to adjust to changing project conditions due to changes of

setbacks, fixture positions, and lighting levels. The parabolic reflector, with adjustable

focusing, provides variable beam patterns all in one fixture. For the Oculus Small and

Large, the reflector can achieve a 10° spot to a 78° wide flood distribution. The Oculus

Nano is field adjustable only through lamp or reflector changes.

Lamp in the low position c l e a r l e n s l i n e a r s p r e a d w i d e d i f f u s e d

193849

145387

98925

48462

23914

17936

11957

5979

9584

7188

4792

2396

nema beam class 2 3V x 4H 5

beam angle - 50% of max 9.1° 16V x 50H 48.2°

field angle - 10% of max 19.1° 32V x 65H 74.4°

peak candlepower 193,849 lumens 23,963 lumens 9593 lumens

Lamp in the high position c l e a r l e n s l i n e a r s p r e a d w i d e d i f f u s e d

34566

25925

17283

8642

28523

21392

14262

7131

11205

8404

5803

2801

nema beam class 3 3V x 4H 5

beam angle - 50% of max 23.6° 12V x 48H 48.1°

field angle - 10% of max 40° 32V x 68H 74.1°

peak candlepower 34,817 lumens 28,911 lumens 11,222 lumens

Oculus Nano 39R111 10° n a r r o w s p o t 24° m e d i u m f l o o d 40° w i d e f l o o d

Nano

nema beam class 2 3 4

beam angle - 50% of max 8.7° 21.4° 38°

field angle - 10% of max 18.5° 43.3° 59.1°

peak candlepower 35015 lumens 8534 lumens 3997 lumens

OCULUS ® FAMILY 13


O

MOUNTING FLEXIBILITY

OSR-SAH

14

The small and large Oculus ® can be semi-recessed in the

wall for a lower profile.


OLR

OCULUS ® FAMILY 15


O

MOUNTING FLEXIBILITY

(2) OLR

16


Top mounted pole adapters add accents to building

facades or highlights to objects. The focused light of an

Oculus ® can provide a better quality of light with a lower

quantity of fixtures. Save on fixtures and energy costs,

while reducing stray light and providing an improved

lighting design.

Side mount provides flexible mounting configurations.

(4) OLR

(4) OSR

OCULUS ® FAMILY 17


O

OCULUS NANO

ORDERING INFORMATION

®

NANO

The Oculus ® Nano is a highly versatile lighting

system. Available in 10° to 52° flood beam

angles that are field adjustable through lamp

or reflector changes. Also available in highly

efficient LED. Suited for wall, ceiling, pole or

stanchion mounting configurations.

AAL CodeLink SM

ON spec sheet

18


ORDER EXAMPLE

Fixture with Lamp/Ballast Options Color Mounting

ONR-39R111EB – 24 nln BLK nst

9” / 230mm

14.5” / 370mm

2.875” / 73mm

12.5” / 319mm

all

/ 188mm

ge

/ 239mm

18” / 459mm

2.75” / 70mm

9” / 230mm

2.875” / 73mm

12.5” / 319mm

2.75” / 70mm

small

12” / 306mm

7” / 179mm

large

16” / 408mm

8.75” / 223mm

1. Fixture

ON

Oculus Nano

The Oculus Nano is field adjustable only through lamp or

reflector changes.

9” / 230mm

2. Lamp/Ballast

small

7.375” / 188mm

3” / 77mm

large

12.5” / 319mm

9.375” / 239mm

3” / 77mm

ON-18LED-WW 18 light emitting diode array

small

(22.2 watt). Warm white

small

(3500K). 120 thru 277 volt.

12” / 306mm

ON-18LED-BW 18 light emitting diode array (21.1

12” / 306mm

9” / 230mm

watt). Bright white (5100K). 120 thru

9” / 230mm

9” / 230mm

14.5” / 370mm 277 volt.

2.875” / 73mm

2.875” / 73mm

ONR-39R111EB-10 39 watt electronic 3” / 77mm metal halide 120

7.375” / 188mm

7” / 179mm

thru 277 volt ballast. 10° narrow

spot beam angle.

ONR-39R111EB-24 39 watt electronic metal halide 120

large

thru 277 volt ballast. 24° medium

large

flood beam angle.

16” / 408mm

ONR-39R111EB-40 39 watt electronic metal halide 120

16” / 408mm

12.5” / 319mm

12.5” / 319mm

small thru 277 volt ballast. small 40° wide flood

beam angle.

18” / 459mm

small

small

2.75” / 70mm

2.75” / 70mm

ONR-70R111EB-10 70 watt electronic metal halide 120

9.375” / 239mm

3”

12”

/ 77mm

/ 306mm

9” / 230mm thru 8.75” 277 / 223mm volt ballast. 10° narrow

9” / 230mm

12” / 306mm

spot beam angle.

9” / 230mm

14.5” / 370mm

2.875” / 73mm

ONR-70R111EB-24 70 watt electronic metal halide 120

7.375” / 188mm

14.5” / 370mm3” / 77mm

7” / 179mm

thru 277 volt ballast. 24° medium

7.375” / 188mm

3” / 77mm

flood beam angle.

7” / 179mm

ONR-70R111EB-40 70 watt electronic metal halide 120

large thru 277 volt ballast. large 40° wide flood

beam large angle.

large

ONR-20MMC-16 20 watt electronic 16” / 408mm metal halide 120

12.5” / 319mm

12.5” / 319mm

or 277 volt only ballast. 16° spot

16” / 408mm

beam angle. 12.5” / 319mm

18” / 459mm

2.75” / 70mm

ONR-20MMC-30 20 watt electronic metal 9.375” / 239mm halide

18” / 459mm3” / 77mm

8.75” / 223mm

120 or 277 volt only ballast. 30°

9.375” / 239mm

3” / 77mm

medium

8.75” / 223mm

flood beam angle.

ONR-20MMC-52 20 watt electronic metal halide 120

or 277 volt only ballast. 52° wide

flood beam angle.

ONR-39MMC-16 39 watt electronic metal halide 120

thru 277 volt ballast. 16° spot beam

angle.

ONR-39MMC-30 39 watt electronic metal halide 120

thru 277 volt ballast. 30° medium

flood beam angle.

ONR-39MMC-52 39 watt electronic metal halide 120

thru 277 volt ballast. 52° wide flood

beam angle.

12.5” / 319mm

small

7.375” / 188mm

large

9.375” / 239mm

9” / 230mm

3. OPTIONS

9” / 230mm

2.875” / 73mm

12.5” / 319mm

2.875” / 73mm

12.5” / 319mm

2.75” / 70mm

2.75” / 70mm

Internal Options

The accessories mount internally between the

glass and reflector.

NLN Linear spread lens

NWA Wide angle spread lens

NRL Concentric ring louver

NHX Black hexcell louver

Only one internal option per fixture.

4. COLOR

NLN NWA NRL NHX

NCM

9” / 230mm

nah nfh

9” / 230mm

nrg

14.5” / 370mm

small

3” / 77mm

12” / 306mm

7.375” / 188mm

2.875” / 73mm

7” / 179mm

All standard and premium AAL colors available. For RAL and custom colors, please submit

a 4-digit RAL number or color chip for custom colors.

5. MOUNTING

large

16” / 408mm

NST 18" tall cast stanchion mount with a 3"/77mm O.D. post. Cast collar slips

12.5” / 319mm

12.5” / 319mm

over the post and is secured by 3 stainless steel set screws

NPS 4N Cast saddle mounts to the side of a 4"/100mm O.D. round pole

18” / 459mm

2.75” / 70mm

NTE Cast tenon mount slips over a 3"/77mm O.D. 9.375” / 239mm round post and secured with 3

3” / 77mm

stainless steel 8.75” set / 223mm screws

MOUNTING

External Options

The hoods are aluminum with stainless steel

hardware.

NCM Color filter holder*.

use a round glass filter*

NAH Angled hood shield

NFH Full hood shield

NRG Rock guard

MTW Cast twin arm and tenon slips over a 4"/100mm o.d. pole and secured with 6

stainless steel set screws. WT: 14 lbs EPA: .75

small

large

All ballasts are factory prewired,

except electronic.

NST NPS 4N NTE

OPTIONAL LAMPS

Lamp 39

CD

Lamp 70

CD

Phillips 39 watt T-6 ceramic,

cdM 39/T6/830

Phillips 70 watt T-6 ceramic,

cdM 70/T6/830

8.75” / 223mm

18” / 459mm

3” / 77mm

MTW

9.375” / 239mm

12.5” / 319mm

16” / 408mm

large large

8.70" 8.70”/

220mm

7” / 179mm

2.8” /

2.8"

71mm

71mm

3” / 77mm

Semi-Recess Wall Mounting

7.375” / 188mm

9.63"/245mm

14.5” / 370mm

9” / 230mm

7.5"/191mm

12” / 306mm

6.25"

159mm

small small

OCULUS ® FAMILY 19

2.75” / 7

12.5” / 319mm

7.25”/

184mm

2.875” / 7

9” / 230mm


O

OCULUS NANO

SPECIFICATIONS

HOUSING

The fixture housing is die cast aluminum. The front cover

is secured with four cap screws for relamping and internal

access. The front glass element is clear, tempered glass.

The front cover and electrical module are sealed with

memory retentive, extruded silicone gaskets. The lamp

module swivels 105 degrees by loosening one stainless steel

cap screw. Rotation is a full 360 degrees with a cam lock

stop, by loosening four set screws. All internal and external

hardware is stainless steel.

Optical Module

The R111 features a built in reflector composed of faceted

aluminum. The mini mastercolour features a high specular,

convex faceted round reflector made of aluminum. The LED

component features Ledil® optics, an optical grade PC with

high UV and temperature resistance. Internal accessories

are installed between the reflector and inside cover.

ELECTRICAL Module

The ballast is mounted directly onto the die-cast housing

and wired with a quick disconnect plug and removed by

loosening two screws. Electronic metal halide ballasts are

rated for -30°C starting, sound rating A. Sockets are pulse

rated porcelain, bi-pin, GX8.5 for R111 and PGJ5 for mini

mastercolour. Wired at the factory for 277 volts, unless

specified.

AAL CodeLink SM

ON spec sheet

FINISH

Fixture finish consists of a five stage pretreatment regimen with

a polymer primer sealer, oven dry off and top coated with a

thermoset super TGIC polyester powder coat finish. The finish

shall meet the AAMA 605.2 performance specification which

includes passing a 3000 hour salt spray test for corrosion

resistance.

Installation

The bottom of the ballast housing has a solid brass 1/2" NPT

nipple. The housing has four 0.300 inch knockouts for other

means of mounting.

EISA compliance

AAL is committed to complying with U.S. EISA requirements. All

applicable products manufactured for sale in the United States

after January 1, 2009, meet EISA requirements.

Certification

The fixture is listed with ETL for outdoor, wet location use,

UL1598 and Canadian CSA Std. C22.2 no.250. IP=66

Warranty

5 YEAR LED WARRANTY

Fixture is warranted for three years, or five years for LED

models. Ballast components carry the ballast manufacturer’s

limited warranty. Any unauthorized return, repair, replacement

or modification of the Product(s) shall void this warranty. This

warranty applies only to the use of the Product(s) as intended

by AAL and does not cover any misapplication or misuse

of said Product(s), or installation in hazardous or corrosive

environments. Contact AAL for complete warranty language,

exceptions, and limitations.

AAL reserves the right to change product specifications

without notice.

PERFORMANCE CHART

ONR Oculus NANO with reflector and 39 watt CDM R111 metal halide lamp

d i s t a n c e f r o m f i x t u r e

o d e g b e a m f i e l d n e m a 4' 6' 8' 10'

m o d e l c p a n g l e a n g l e e f f c l a s s a x i a l c i r c l e a x i a l c i r c l e a x i a l c i r c l e a x i a l c i r c l e

fc d i a. fc d i a. fc d i a. fc d i a.

ONR (10°) 35015 8.7 18.5 96.7 2 2188 8 978 13 547 17 350 21

ONR (24°) 8534 21.4 43.3 102 3 531 20 236 31 133 41 85 51

ONR (40°) 3997 38 59.1 101 4 250 35 111 53 63 70 28 105

20


3-ONR NPS 4N

OCULUS ® FAMILY 21


O

OCULUS SMALL

ORDERING INFORMATION

®

SMALL

AAL's Oculus ® Small is a highly versatile, controllable,

precision lighting system. The Oculus has a parabolic

reflector system and axial lamp orientation to allow for

control and efficiency. Beam spreads are offered from

10° spot to 78° wide flood distributions. Available with

highly efficient LED technology. Suited for wall, ceiling,

pole or stanchion mounting configurations.

AAL CodeLink SM

OS spec sheet

22


ORDER EXAMPLE

Fixture with Lamp/Ballast Options Color Mounting

OSR-70MHT6 SLN AWT MST

ll

small small

12” / 306mm

12” / 306mm

0mm

9” / 230mm

9” / 230mm 9” / 230mm

14.5” / 370mm

2.875” / 73mm

2.875” / 73mm

88mm

7.375” / 188mm

77mm

3” / 77mm

7” / 179mm

e

large large

16” / 408mm

16” / 408mm

19mm12.5” / 319mm

12.5” / 319mm 12.5” / 319mm

1. Fixture

OS

2. Lamp/Ballast

small

7.375” / 188mm

large

Oculus Small

Os-26CF

Compact fluorescent PL-T 26 watt

lamp. 120 thru 277 volt electronic

transformer.

Os-30LED-WW 30 light emitting diode array

(34.2 watt). Warm white

(3500K). 120 thru 277 volt.

Os-30LED-BW 30 light emitting diode array (34.8

watt). Bright white (5100K). 120

small

small

thru 277 volt.

OSR-39MHT6 39 watt metal halide 120/277 volt

12” / 306mm

ballast for T-6 lamp, parabolic

9” / 230mm

9” / 230mm

reflector.

9” / 230mm

OSR-39MHT6EB 14.5” / 370mm

39 watt metal halide electronic 120

2.875” / 73mm

7.375” / 188mm

2.875” / 73mm

3” / 77mm thru 277 volt ballast for T-6 lamp,

7” / 179mm

parabolic reflector.

OSR-70MHT6 70 watt metal halide 120/277/347

volt ballast for T-6 lamp, parabolic

large

large

reflector.

OSR-70MHT6EB 70 watt metal halide electronic 120

16” / 408mm

thru 277 volt ballast for T-6 lamp,

12.5” / 319mm

12.5” / 319mm

12.5” / 319mm

parabolic reflector.

3. OPTIONS

Internal Options

The accessories mount internally between the glass and

reflector.

SLN Linear spread lens

SWA Wide angle spread lens

SRL Concentric ring louver

SHX Black hexcell louver

Only one internal option per fixture.

External Options

The hoods are aluminum with stainless steel hardware.

SCM Color filter holder*.

use a round glass filter*

SAH Angled hood shield

SFH Full hood shield

SRG Rock guard

SLN SWA SRL SHX

18” / 459mm

2.75” / 70mm

small

39mm

9.375” / 239mm

77mm

3” / 77mm

8.75” / 223mm

9” / 230mm

6mm

9” / 230mm small

2.875” / 73mm

12” / 306mm 2.875” / 73mm

7.375” / 188mm

9” / 230mm

2.875” / 73mm

7.375” / 188mm

m

2.75” / 70mm

9.375” / 239mm

18” / 459mm

2.75” / 70mm

All ballasts 2.75” / small 70mm are factory prewired for 277 small volts, except

9.375” / 239mm

3” / 77mm

electronic. All ballasts are factory prewired. Lamps included.

8.75” / 223mm

All ballasts are EISA compliant

12” / 306mm

9” / 230mm

9” / 230mm

OPTIONAL LAMPS

2.875” / 73mm

Lamp 39

Phillips 39 watt T-6 ceramic,

7.375” / 188mm

3” / 77mm

CD

cdM 39/T6/830

7” / 179mm

Lamp 70

Phillips 70 watt T-6 ceramic,

CD

cdM 70/T6/830

14.5” / 370mm

SCM sah sfh srg

4. COLOR

All standard and premium AAL colors available.

For RAL and custom colors, please submit a 4-digit

RAL number or color chip for custom colors.

large

large

large

12.5” / 319mm

8mm

large

16” / 408mm

5. MOUNTING

m

m

16” / 408mm 12.5” / 319mm

2.75” / 70mm

12.5” / 319mm

2.75” / 70mm

2.75” / 70mm

9.375” / 239mm

9.375” / 239mm

18” / 459mm

MOUNTING

8.75” / 223mm

12.5” / 319mm

3” / 77mm

9.375” / 239mm

12.5” / 319mm

2.75” / 70mm

MST

MPS 4N

MTE

MTW

18" tall cast stanchion mount with a 3"/77mm O.D. post. Cast

collar slips over the post and is secured by 3 stainless steel

set screws

Cast saddle mounts to the side of a 4"/100mm O.D. round pole

Cast tenon mount slips over a 3"/77mm O.D. round post and

secured with 3 stainless steel set screws

Cast twin arm and tenon slips over a 4"/100mm o.d. pole and

secured with 6 stainless steel set screws. WT: 14 lbs EPA: .75

12.5” / 319mm

18” / 459mm

3” / 77mm

8.75” / 223mm

MST MPS 4N MTE MTW Semi-Recess Wall Mounting

16” / 408mm

12.5” / 319mm

2.75” / 70mm

9.375” / 239mm

large large

8.70" 8.70”/

220mm

7.25”/

184mm

7” / 179mm

2.8” /

2.8"

71mm

71mm

3” / 77mm

7.375” / 188mm

11.5"/292mm

14.5” / 370mm

9” / 230mm

9.25"/235mm

12” / 306mm

7.25"

184mm

small small

2.75” / 70mm

9” / 230mm

2.875” / 73mm

16” / 408mm

12.5” / 319mm

18” / 459mm

3” / 77mm

8.75” / 223mm

OCULUS ® FAMILY 23

9.375” / 239mm

12.5” / 319mm

large large

3” /


O

OCULUS SMALL

SPECIFICATIONS

HOUSING

The fixture housing is die cast aluminum. The front cover

is secured with four cap screws for relamping and internal

access. The front glass element is clear, tempered glass. The

front cover and electrical module are sealed with memory

retentive, molded silicone gaskets. The lamp module swivels

105 degrees by loosening two stainless steel cap screws.

Rotation is a full 360 degrees with a cam lock stop by

loosening three set screws. All internal and external hardware

is stainless steel.

Optical Module

The parabolic reflector is spun aluminum, polished and

anodized, and snaps into the front cover with three stainless

steel spring clips. The LED component features Ledil ® optics,

an optical grade PC with high UV and temperature resistance.

Internal accessories are installed between the reflector and

inside cover. The adjustable socket assembly is mounted to

the back of the lamp housing. The socket can be adjusted

from the exterior of the fixture by turning an adjustment screw.

ELECTRICAL Module

The ballast is mounted on a prewired plate with a quick

disconnect plug and removed by loosening two screws.

Electronic metal halide ballasts are rated for -30°C starting,

sound rating A. Sockets are pulse rated porcelain, bi-pin, G12

for T-6 metal halide lamps. Compact fluorescent sockets are

4 pin, GX24q-3,4 with an electronic ballast, -18°C starting.

Wired at the factory for 277 volts, unless specified.

AAL CodeLink SM

FINISH

Fixture finish consists of a five stage pretreatment regimen

with a polymer primer sealer, oven dry off and top coated

with a thermoset super TGIC polyester powder coat

finish. The finish shall meet the AAMA 605.2 performance

specification which includes passing a 3000 hour salt spray

test for corrosion resistance.

Installation

The bottom of the ballast housing has a solid brass

1/2" NPT nipple. The deep housings have two knockouts for

other means of mounting.

EISA compliance

AAL is committed to complying with U.S. EISA requirements.

All applicable products manufactured for sale in the United

States after January 1, 2009, meet EISA requirements.

Certification

The fixture is listed with ETL for outdoor, wet location use,

UL1598 and Canadian CSA Std. C22.2 no.250. IP=66

Warranty 5 YEAR LED WARRANTY

Fixture is warranted for three years, or five years for LED

models. Ballast components carry the ballast manufacturer’s

limited warranty. Any unauthorized return, repair, replacement

or modification of the Product(s) shall void this warranty. This

warranty applies only to the use of the Product(s) as intended

by AAL and does not cover any misapplication or misuse

of said Product(s), or installation in hazardous or corrosive

environments. Contact AAL for complete warranty language,

exceptions, and limitations.

AAL reserves the right to change product specifications

without notice.

PERFORMANCE CHART

OS spec sheet

OSR Oculus Small with reflector and 70 watt T-6 metal halide lamp

(L) = Lamp in low position, (H) = Lamp in high position

d i s t a n c e f r o m f i x t u r e

o d e g b e a m f i e l d n e m a 10' 20' 30' 40' 50'

m o d e l c p a n g l e a n g l e e f f c l a s s a x i a l c i r c l e a x i a l c i r c l e a x i a l c i r c l e a x i a l c i r c l e a x i a l c i r c l e

fc d i a. fc d i a. fc d i a. fc d i a. fc d i a.

OSR (L) 80,300 10.4 20.4 77.1 2 803 3.6 200 7.2 89 10.8 50 14.4 32 18.0

OSR (H) 9,010 43 59 76.2 4 90 11.3 22 22.6 10 33.9 5.6 45.2 3.6 56.5

OSR-SWA (L) 6,149 43 78 66.5 5 61 16.2 15 32.4 7 48.6 3.8 64.8 2.5 81.0

OSR-SWA (H) 4,715 45 102 70.6 6 47 24.7 12 49.4 5 74.1 3.0 98.8 1.9 123.5

OSR-SLN (L) 9,621 18V54H 34V66H 66.8 3V4H 96 6.1x13 24 12x26 11 18x39 6 24x52 3.9 31x65

OSR-SLN (H) 3,270 48V82H 94V118H 68.6 5V6H 32 22x33 8 43x67 4 64x100 2 86x133 1.3 107x167

24


OSR-MPS-4L

OCULUS ® FAMILY 25


O

OCULUS LARGE

ORDERING INFORMATION

®

LARGE

AAL's Oculus ® Large is a highly versatile, controllable,

precision lighting system. The Oculus has a parabolic

reflector system and axial lamp orientation to allow for

control and efficiency. Beam spreads are offered from

10° spot to 78° wide flood distributions. Suited for wall,

ceiling, pole or stanchion mounting configurations.

AAL CodeLink SM

OL spec sheet

26


ORDER EXAMPLE

Fixture with Lamp/Ballast Options Color Mounting

OLR-70MHT6t LLN AWT MST

l

m

mm

mm

9” / 230mm

14.5” / 370mm

2.875” / 73mm

mm12.5” / 319mm

mm

mm

9” / 230mm

m

18” / 459mm

2.75” / 70mm

2.875” / 73mm

2.5” / 319mm

m

small

7.375” / 188mm

large

2.75” / 70mm

12” / 306mm

9.375” / 239mm

small

12” / 306mm

7” / 179mm

large

16” / 408mm

8.75” / 223mm

9” / 230mm small

2.875” / 73mm

16” / 408mm 12.5” / 319mm

7.375” / 188mm

large

2.75” / 70mm

9.375” / 239mm

small

9” / 230mm

7.375” / 188mm

3” / 77mm

large

12.5” / 319mm

9.375” / 239mm

3” / 77mm

9” / 230mm

2.875” / 73mm

12.5” / 319mm

2.75” / 70mm

9” / 230mm

2.875” / 73mm

12.5” / 319mm

2.75” / 70mm

12” / 306mm

16” / 408mm

1. Fixture

OL

2. Lamp/Ballast

small

7.375” / 188mm

large

9.375” / 239mm

Oculus Large

OL-42CF

Compact fluorescent PL-T 42 watt lamp.

120 thru 277 volt electronic transformer.

OLR-70MH 70 watt metal halide magnetic

120/208/240/277 volt ballast. Use

medium base, ED-17 lamp

OLR-70MHEB 70 watt metal electronic 120 thru

277 volt ballast. Use medium

base, ED-17 lamp

OLR-70MHT6 small 70 watt metal halide 120/277/347

small

volt ballast. Use G12 base, T-6 lamp

OLR-70MHT6EB 70 watt metal halide electronic 120

12” / 306mm

9” / 230mm thru 277 volt ballast. Use G12 9” / 230mm base,

9” / 230mm

t-6 lamp

14.5” / 370mm

2.875” / 73mm

OLR-100MH 100 watt metal halide

7.375” / 188mm

2.875” / 73mm

3” / 77mm

120/208/240/277 volt ballast. Use

7” / 179mm

medium base, ED-17 lamp

OLR-100MHEB 100 watt metal electronic 120 thru

277 volt ballast. Use medium base,

ED

large

ed-17 lamp

large

OLR-150PSMH Pulse start 150 watt metal halide

120/208/240/277 16” / 408mm volt ballast. Use

12.5” / 319mm

medium base, ED-17 lamp12.5” / 319mm

12.5” / 319mm

OLR-150PSMHT6 Pulse start 150 watt metal halide

18” / 459mm

2.75” / 70mm

2.75” / 70mm

120/208/240/277 volt ballast. Use

9.375” / 239mm

3” / 77mm

g12 base, T-6 lamp

8.75” / 223mm

small

small

OLR-150MHEB 150 watt metal halide electronic 120

thru 277 volt ballast. Use medium

12” / 306mm

base, ED-17 lamp

9” / 230mm

9” / 230mm

OLR-150MHT6EB 150 watt metal halide electronic 120

thru 277 volt ballast. Use G12 base,

2.875” / 73mm

t-6 lamp

7.375” / 188mm

14.5” / 370mm

3” / 77mm

7” / 179mm

All ballasts are factory prewired for 277 volts, except electronic.

All ballasts are factory prewired. Lamps included. All ballasts

are EISA compliant

OPTIONAL LAMPS

16” / 408mm

Lamp 39 Phillips 39 watt T-6 ceramic,

12.5” / 319mm

12.5” / 319mm

CD

cdM 39/T6/830

Lamp 70 Phillips 70 watt T-6 ceramic,

2.75” / 70mm

9.375” / 239mm

CD

3” / 77mm

cdM 70/T6/830

18” / 459mm

MOUNTING

large

8.75” / 223mm

large

3. OPTIONS

Internal Options

The accessories mount internally between the glass and

reflector.

LLN Linear spread lens

LWA Wide angle spread lens

LRL Concentric ring louver

LHX Black hexcell louver

Only one internal option per fixture.

External Options

The hoods are aluminum with stainless steel hardware.

LCM Color filter holder*.

use a round glass filter*

LAH Angled hood shield

LFH Full hood shield

LRG Rock guard

LLN LWA LRL LHX

LCM lah lfh lrg

4. COLOR

All standard and premium AAL colors available.

For RAL and custom colors, please submit a 4-digit

RAL number or color chip for custom colors.

5. MOUNTING

MST

MPS 4L

MPS 5L

MTE

MTW

Cast stanchion mount with a 18"/460mm x 4"/100mm

o.d. aluminum pole. Cast collar slips over the pole and is

secured with 3 stainless steel set screws. EPA: 1.8

Cast saddle mounts to the side of a 4"/100mm o.d. pole.

Cast saddle mounts to the side of a 5"/127mm o.d. pole.

Cast tenon mount slips over a 4"/100mm o.d. pole and

secured with 3 stainless steel set screw.

Cast twin arm and tenon slips over a 4"/100mm o.d. pole and

secured with 6 stainless steel set screws.

12.5” / 319mm

18” / 459mm

3” / 77mm

8.75” / 223mm

MST MPS 4L/5L MTE MTW Semi-Recess Wall Mounting

16” / 408mm

12.5” / 319mm

2.75” / 70mm

9.375” / 239mm

large large

8.70" 8.70”/

220mm

7.25”/

184mm

7” / 179mm

2.8” /

2.8"

71mm

71mm

3” / 77mm

7.375” / 188mm

15.25"/387mm

14.5” / 370mm

9” / 230mm

12.75"/324mm

9” / 230mm

2.875” / 73mm

12” / 306mm

9.5"

241mm

OCULUS ® FAMILY 27

small small


O

OCULUS LARGE

SPECIFICATIONS

HOUSING

The fixture housing is die cast aluminum. The front cover

is secured with four cap screws for relamping and internal

access. The front glass element is clear, tempered glass. The

front cover and electrical module are sealed with memory

retentive, molded silicone gaskets. The lamp module swivels

105 degrees by loosening two stainless steel cap screws.

Rotation is a full 360 degrees with a cam lock stop by

loosening three set screws. All internal and external hardware

is stainless steel.

Optical Module

The parabolic reflector is spun aluminum, polished and

anodized, that snaps into the front cover with three stainless

steel spring clips. Internal accessories are installed between

the reflector and inside cover. The adjustable socket

assembly is mounted to the back of the lamp housing. The

socket can be adjusted from the exterior of the fixture by

turning an adjustment screw.

ELECTRICAL Module

The ballast is mounted on a prewired plate with a quick

disconnect plug and removed by loosening two captive

screws. Magnetic metal halide ballasts are high power factor,

rated for -30°C starting. Electronic metal halide ballasts are

rated for -30°C starting, sound rating A. Sockets are pulse

rated porcelain, bi-pin, G12 for T-6 lamps and medium base

for ED-17 metal halide. Compact fluorescent sockets are

4 pin, GX24q-3,4 with an electronic ballast, -18°C starting.

Wired at the factory for 277 volts, unless specified.

AAL CodeLink SM

FINISH

Fixture finish consists of a five stage pretreatment regimen

with a polymer primer sealer, oven dry off and top coated

with a thermoset super TGIC polyester powder coat

finish. The finish shall meet the AAMA 605.2 performance

specification which includes passing a 3000 hour salt spray

test for corrosion resistance.

Installation

The bottom of the ballast housing has a solid brass

1/2" NPT nipple. The housing has two knockouts for other

means of mounting.

EISA compliance

AAL is committed to complying with U.S. EISA requirements.

All applicable products manufactured for sale in the United

States after January 1, 2009, meet EISA requirements.

Certification

The fixture is listed with ETL for outdoor, wet location use,

UL1598 and Canadian CSA Std. C22.2 no.250. IP=66

Warranty

Fixture is warranted for three years. Ballast components

carry the ballast manufacturer’s limited warranty. Any

unauthorized return, repair, replacement or modification

of the Product(s) shall void this warranty. This warranty

applies only to the use of the Product(s) as intended by

AAL and does not cover any misapplication or misuse of

said Product(s), or installation in hazardous or corrosive

environments. Contact AAL for complete warranty language,

exceptions, and limitations.

AAL reserves the right to change product specifications

without notice.

PERFORMANCE CHART

OL spec sheet

OLR Oculus large with reflector and 150 watt T-6 pulse start metal halide lamp

(L) = Lamp in low position, (H) = Lamp in high position

d i s t a n c e f r o m f i x t u r e

o d e g b e a m f i e l d n e m a 20' 40' 60' 80' 100'

m o d e l c p a n g l e a n g l e e f f c l a s s a x i a l c i r c l e a x i a l c i r c l e a x i a l c i r c l e a x i a l c i r c l e a x i a l c i r c l e

fc d i a. fc d i a. fc d i a. fc d i a. fc d i a.

OLR (L) 193,849 9.1 19.1 63.1 2 484.6 6.7 121.2 13.5 53.8 20.2 30.3 26.9 19.4 33.6

OLR (H) 34,817 23.6 40 54.2 3 57.5 14.6 14.4 29.1 6.4 43.7 3.6 58.2 2.3 72.8

OLR-LWA (L) 8,822 48.2 74.4 52.1 5 22.1 30.4 5.5 60.8 2.5 91.2 1.4 121.6 0.9 151.9

OLR-LWA (H) 10,038 48.1 74.1 62 5 25.1 30.2 6.3 60.4 2.8 90.6 1.6 120.7 1 150.9

OLR-LLN (L) 23,963 16V50H 32V65H 51.7 3V4H 60 11x26 15 23x51 6.7 34x77 3.7 45x103 2.4 57x128

OLR-LLN (H) 28,911 12V48V 32V68H 59.8 3V4H 72 11x27 18 23x54 8 34x81 4.5 46x108 2.9 57x135

28


(4)OLR

OCULUS ® FAMILY 29


O

PHOTOMETRY

The data on the right is for the Large Oculus - OLR with the parabolic reflector

PHOTOMETRY

in the low and high lamp position. The values are in initial footcandles.

Discount values to account for light losses due to voltage, temperature and

atmospheric variations which affect light output. All testing performed by a

certified independent laboratory.

To calculate illuminance at a point, use the following equation.

E = I cos

D 2

D

Conversion factor

Lamp type Lumens OLR

70 MH, T-6 6600 .46

150 PSMH, T-6 14000 1.00

70 MH, ED-17 6200 .44

100 MH, ED-17 9300 .66

150 PSMH, ED-17 13000 .93

D


To substitute another lamp in the charts below,

multiply the chart values by the lamp conversion

factor on the right.

30


PHOTOMETRY

OLR-150T6 CLEAR LENS low lamp position

Polar Candela Curve

vertical plane 0 - 180°

distance from calculation grid=20'

1 square = 10 feet (3.1M)

outer ring = 10% field angle

inner ring = 50% beam angle

OLR-150T6 CLEAR LENS high lamp position

Polar Candela Curve

vertical plane 0 - 180°

Distance from calculation grid=20'

1 square = 10 feet (3.1M)

outer ring = 10% field angle

inner ring = 50% beam angle

193849

145387

98925

48462

193849

145387

98925

48462

47

48

17283

23 8642

47

58

193849

34566

40

145387

48

25925

7

98925

17283

OLR-150T6 48462 LWA flood low lamp position

OLR-150T6 LWA flood high lamp position

23 8642

Polar Candela Curve Distance from calculation grid=20' Polar Candela Curve Distance from calculation grid=20'

47

58

vertical plane 0 - 180° 1 square = 10 feet (3.1M)

vertical plane 0 - 180° 1 square = 10 feet (3.1M)

40

9584

outer ring = 10% field 1 angle

11205

outer ring = 10% field 2 angle

7

7188

inner ring = 50% beam angle

8404

inner ring = 50% beam angle

4792

2396

9584

7188

4792

2396

9584

7188

4792

2396

23

23

23

48

9

34566

25925

34566

25925

17283

23 8642

9

9

1

1

5803

2801

11205

8404

5803

2801

11205

8404

5803

2801

58

40

7

26

26

26

11

2

11

2

11

OLR-150T6 23914 LLN SPREAD LENS low lamp position

17936

3

Polar Candela 11957 Curve Distance from calculation grid=20'

21

vertical plane 5979 0 - 180° 1 square = 10 feet (3.1M)

outer ring = 42 10% field angle

23914

inner ring = 50% beam angle

17936

3

11957

21

5979

42

| 26 |

| 26 |

23914

17936

11957

5979

42

3

21

OLR-150T6 28523 LLN SPREAD LENS high lamp position

21392

3

Polar Candela 14262 Curve Distance from calculation grid=20'

vertical plane 71310 - 180° 1 square = 10 feet 29 (3.1M)

outer ring = 51 10% field angle

28523

inner ring = 50% beam angle

21392

3

14262

7131

28523

21392

A RCHITECTURAL AREA

14262

7131

A RCHITECTURAL AREA

51

51

29

LIGHTING

3

29

LIGHTING

| 26 |

A RCHITECTURAL AREA

LIGHTING

OCULUS ® FAMILY 31


®

Precision Floodlighting

(4) OLR

OCULUS | 25 |

Architectural Area Lighting, Division of Hubbell Lighting, Inc.

16555 East Gale Ave. | City of Industry | CA 91745

T 626.968.5666 | F 626.369.2695 | www.aal.net/aal/oculus1111.html

© 2011 Architectural Area Lighting | Design Patents Pending | Made in the USA | OCULUS 1111

More magazines by this user
Similar magazines
