For you, the owner of a new White Sewing Machine,
we wish many years of success and enjoyment in sewing
for yourself, your family and home. Your success is
assured because your new White makes your sewing
almost effortless with its many improved seweasy
features.
To aid you in obtaining the greatest achievement
from your machine, we have prepared this book on its
use and care. A thorough understanding of your White
will reward you with the many years of satisfactory
service that have been built into it.
WHITE SEWING MACHINE CORPORATION
CLEVELAND 11, OHIO

INDEX
Name of Each Part. 1
Principal Features 2
How to Regulate the Stitch Length 4
Manual Operation 5
Chart on Changing Patterns 6
How to Sew Automatically with
How to Change Appearance of
Page
Decorator Discs 7
Automatic Designs 8. 9
How to Embroider with a Hoop 10
How to Use Attachments ID
Narrow Hemmer 10
2 Quilting Guide 11
3 Seam Gauge 12
1 Sewing on Buttons 13
5 Making Buttonholes 14. 15
II
How to Wind the Bobbin
How to Remove and Replace Bobbin Case
How to Thread the Bobbin Case
I
I
How to Remove the Shuttle
How to Insert the Needle
How to Thread the Machine 21
Preparing to Sew 2
Removing the Work 2
How to Adjust Thread Tensions 2
How to Use the Automatic Darner 2:
I)rop Feed Adjustment 2
Built-in Light
Needle-Thread-Fabric.stitching Guide 2
Check Up for Smooth Sewing 2
Oiling and Cleaning 21
Pa

Name of Each Part
I
I
(Fig. 1)
(*) Arm spool pin
2 Thread guide (upper)
) Thread tension regulator
Thread take up spring
® Thread guide (middle, lower
( Needle clamp screw
( Presser foot
® Presser bar
Thread guide
Needle thread guide
Automatic bobbin winder
iz Hand wheel
ia Bobbin winding tension disc
i Drop feed regulator push button t pe
is Stitch length regulating knob
is Push button for reverse stitch
r Stitch length indicator
is Zigzag stitch lock knob
is Zigzag stitch indicator
g Zigzag stitch regulating knob
(1)
j) Cover plate
d Needle plate
Lamp
Lamp switch
Face plate
s Thread take-up lever
Automatic darner
Thread cutter
hj Zigzag disc chamber

. .
—
(Fig. 3) tion, and must also turn freely when the decorator discs are used.
The stitch width is set at 0 for straight sewing.
— REGULATING
Principal Features
I. Stitch length regulation. The length of the stitch is
controlled by a dial located on the right of the arm.
Turn it right to shorten the stitch and left to lengthen.
The correct stitch length is shown by numbers in the plastic
window just above the dial. Near zero is the shortest stitch,
5 the longest. To sew in reverse, just push the button marked
R in the center of the dial. When the button is released the
machine will automatically sew forward again.
zJGzA(; STITCH ZIGZAG STITCH
INDICATOR LOCK KNOB
\
PUSH BUTTON
FOR REVERSE
STITCH LENGTH
KI
2. Stitch width regulation. To set the width of the stitch
at the size required, turn the zigzag stitch button lock
shown in Fig 3 until pointer on the indicator stops at the
width selected.
The regulating knob Fig :3 controls the width in manual opera
I
PUSH BUTTON
3. Decorator discs for automatic sewing. Select one of
7;
(Fig. 4
12 discs and insert in the disc chamber to do embroidery
designs automatically.

4.
Built-in light. The lamp bulb is located inside the
face plate to direct illumination on the sewing area.
is turned on and off by the switch shown
in
Fig
5.
It
GTH
G KNOB
stitch
lock
the
pera
used.
5.
Automatic darner. By turning clockwise the burled
nut shown in Fig
6,
pressure
is
released from the foot
that fabric can be moved freely for darning and mend
ing. For lighter than normal pressure, push the cap down
part way.
so
(Fig. 6)
e of
idery
(3.
Automatic bobbin winder. The bobbin winder is
engaged by pressing the lever marked “Push”. When the
bobbin is fully wound the winding stops automatically.
(3)

How to Regulate the Stitch Length
//
PUSH BUTTON POP PEVPSE
lig. 8)
The stitch length is regulated simply b turning the knob shown in
Fig 8. To lengthen the stitch turn knob to left, to shorten, return
to right. Refer to chart below for approximate number of stitches
per inch obtained at various settings.
1. To sew forward. Turn knob until marker on stitch indi
cator points to figure corresponding to the number of stitches
per inch required for the work you are doing.
2. To sew backward Push the button “Re in the center of
the stitch length knob and the machine will sew the same
length stitch in reverse. When the button is released the
machine automatically returns to forward stitching. This
backtacking” ‘ocks the seams and eliminates tying of
threads.
Stitch Length Chart
Figures in the dial
Number of stitches
per inch
No feed
ing
2 3 4
32 lt 11 8

Manual Operation
C A B
‘
The winged knob A” shown in Fig 9 is used to vary the
stitch width while you are doing machine embroidery manually.
If you do not set the lock “B”, Fig 9 you can swing the
needle freely between 0 and 4 widths.
(Fig. 9)
The stitch width required for operations such as monogramming
and making buttonholes is set by turning the zigzag stitch
lock “B” until the red pointer appears under the stitch width
most suitable on the indicator Fig “C” 9. Turn the knob in
the direction indicated by the red arrow widen to the stitch.
Return to zero for straight stitching.
When the stitch width is locked at any figure less than 1, the
knob “A” can be moved freely between that width and 4.
(Fig. 10)
(5)

tJ
C
C)
C
CC
-c
-C)
-c
C-)
0,
C
b.c
C
CC
-c C-)
-C
C)
(a
0
C
b.c
C
C)
CC
b.c
CC Nb.c
N
-C)
C
CC
b.c
CC
Cl)
C
Cl)
C
C—
C)
CC
C-
Cl)
-C CC

How to Sew Automatically with Decorator Discs
1. To insert discs in the disc chamber Fig 12 first turn the
zigzag stitch lock “Be back to zero. This will allow the knob
“A” to move freely.
(Fig. 11)
2. Press the button in front of the disc chamber and the cover
will pop up. Turn the knob “A” until width 4 appears in indi
cator, and hold it there while inserting the disc Fig 13. Place
the disc on the spindle, turning it until the notch on the under
side of the disc fits over the small pin on the spindle base.
DISC
(Fig. 12
3. Close the disc chamber cover and let knob “A” return to
o position. To change pattern, turn “A” to 4, remove disc
and insert another.
(Fig. 13) PUSH BUTTON
(7)

I
—
0
C,,
k)
C,,
tC —
C,,
‘%)
0
(_y
1
-J 14
H
CD
O
cr
CD
C
C
C
C 0
CD
C
C
CD
0
C
CD
C
C
C
CD 0
C-
CD
CD
0
C
0
C
0
0
0
(D
0
0
0
0
0
C
0
3
0
0
t\) I
V IM44 —
— •4fIII\
0
0
\A”V\
rt
C-
CD
C-
CD
0
C
C
C
C,,
C.,
0
H
C-
CD
CD
C
C-

a 0
4I
N)
a Cr,
—
N)
a crn,, wwwwWWWWVy\
— vrfvvr—rvr--vr-Ar o
0
(I,
0
-
N)
0 Cr,
-
-J
-
N)
0 C
-
-
N)
CD CD
0
t:r t g
CD CD
C —
— CD
C C
CDCD
—
CD
9 -
<
o
CD
C CD r
—
CD C
CD-.
D 0
— -I
CD r
- z
D
I
CD 0
C — t
—
CD
0
0
— CD
. .
0
- CD
CD

Fig. 173
How to Use Attachments
How to Embroider with a Hoop
It is easy to follow a stamped design or to work free hand
when embroidering or monogramming. (See Figs 16 and l7.(
Release the pressure from the foot by turning the burled nut
on the automatic darner in the direction of the arrow, or
clockwise. Push the drop feed button down so that “E”
appears between the two buttons. Stretch the fabric in an
embroidery hoop, and place under the needle after removing
the presser foot. Set the stitch width at the size you prefer
and lower the presser bar lifter. Then operate the machine
at a rather high speed while moving the hoop slowly with
both hands. Work carefully and be sure to keep fingers out
of the path of the needle.
4/
.
, , A
‘Fig. 16
12345:6789
(Fig. 18A)
1. Narrow hemmer. With the needle in its highest position
replace regular presser foot with narrow hemmer Fig 18 A.
For a plain narrow hem, make a I 8 inch double fold for about
two inches along edge of fabric. Hold each end of the two-inch
fold, slip underneath hemmer. Bring fold up into the scroll of
hemmer, draw forward to end and fasten with point of needle.
Lower presser bar lifter. Gently pull ends of thread as you
start stitching.
Guide material slightly to right, and it will automatically take
a double turn through scroll.
(‘ 10 )

Fig. 18 C,
Lace Trimmed hem
To attach lace to hem, insert lace in the slot next to
needle. Sew hem as above, guiding lace under needle
and hem into scroll Fig 18 B
Lace Edge with Invisible Stitching
Hold lace I 8 inch from raw edge on right side of
fabric. Insert both in scroll as for plain narrow bern.
Let hem roll over and sew in lace. Press lace out flat
along edge with hem turned up. For a little fullness
in lace, feed it freely under scroll.
French Seam
(Fig. 38 B
With right sides together, place top piece of material
1 8 inch inside edge of lower piece.
Insert in hemmer scroll, allowing hem to roll over and
sew in top fabric, making French seam Fig 18 C.
Flat Felled Seam
Open out French seam and insert rolled edge in scroll
of hemmer. Edgestitch to lay seam flat.
2. Quilting Guide. This guide for making par
allel rows of stitching is attached by placing the pron
ged holder between the presser foot and the presser
foot clamp screw Fig 113 .
Adjust
the curved bar to
press lightly on the fabric. By letting the guide ride
on the first stitching line, successive rows will be an
equal distance apart. When the bar is attached so
that the curved part is to the right of the needle, it
may also serve as a seam width guide.
I
(Fig. 19)
(11)

(Fig. 20)
3. Seam Gauge. Fasten gauge with screw provided in one
of threaded holes in the machine bed next to the needle plate.
Adjust to the seam width preferred by sliding the slot of the
gauge along the screw before tightening. Guide fabric so
edge just touches flat surface on seam gauge. See Fig 20.
(12 )

4. Sewing on Buttons. Exchange the regular presser foot for the one provided to sew
on buttons. See Fig 21. Drop the feed to “E position. Place button and fabric under
presser foot. Determine the width of the stitch needed to enter each hole of the button by
turning the hand wheel slowly toward you as you adjust the zigzag regulating knob. Then
lock at that width. Take six or seven stitches to fasten the button securely. Then turn the
knob to 0 and take two or three more stitches in one hole to lock the threads. Repeat the
procedure when sewing on four-hole buttons.
Snaps and hooks may be stitched on in the same manner.
O
—F
çFg. 21
(13 )

. 1td.h,mg 1)ULwnm)its. 1wpId*,A LIic icguaa pLsci ijuL
with the buttonhole foot which is equipped with a measurement
gauge (Fig 22. Set the stitch length near 0 for a very short
stitch. The width of the stitch should be set at 2 or slightly
under for a daintier buttonhole. If a heavier buttonhole is
required, cord may be strung through the hole in the foot.
Mark the desired length of buttonhole on the fabric or set the
gauge so that the distance between the curved marker and the
needle is equal to that of the buttonhole. Sew the first side
of the buttonhole, stopping the machine with the needle in the
material at right side of stitching.
Drop the feed to “Eu position and turn zigzag knob to No 4
width. Take about five or six stitches to make a bar tack.
Stop the machine with the needle out of the fabric, but leave
the presser foot down. Raise the feed to “N” and return
stitch width to 2 or original setting.
Proceed to stitch the second side of the buttonhole. When
you have reached the end of the first row of stitching, stop
the machine again with the needle out of the fabric,
(Fig. 22)
Lift the presser foot, and using the needle as a pivot, turn the
fabric end for end or 180 degrees (see Fig 23). Before lowering
the presser foot make sure that the first row of stitching is
lined up straight. Lower presser foot and turn wheel by hand
just enough to raise needle out of fabric.
(14 )

Leave the presser foot down, drop the feed to “E”, turn Zigzag knob to No.- width, and take five
or six stitches to close the buttonhole. Stop the machine with the needle out of the fabric, but do not
raise the foot.
Return stitch width to () and take two or three stitches, which will fasten the bar threads and prevent
ravelling.
Cut the buttonhole opening with the seam ripper, being careful not to cut the stitching.
If you plan to make buttonholes on sheer or soft material, place tarlatan or paper, which can be torn
away after stitching, under the fabric. And it is always wise to make several buttonholes on scraps
of fabric before working on the garment.
I” FE(Fig.
23)
EF
A

How to Wind the Bobbin
L ,,,
IN
iT
- - -. —
(Fig. 24)
Good No Good No Good
(Fig. 25)
Turn the clutch nut in the center of the
hand wheel toward you to disengage
the sewing mechanism. Place a spool of
thread on the spool pin, and slip the
thread through the upper arm thread
guide and across to the tension disc as
shown in Fig 24.
Insert thread through a hle on edge of
bobbin and place bobbin on spindle of
winder. Be sure that the notch in the
bobbin fits over the small pin on the
spindle. Press down on lever marked
“push” and set machine in motion.
When the bobbin is fully wound, the
action of the winder stops automatically.
Remove from spindle and cut off loose
thread end.
If the bobbin winds unevenly see Fig
25, adjust the bobbin winding tension
disc to the right or left by loosening
the screw holding it to the bed of the
machine. Then tighten.
Before starting to sew again, tighten
clutch nut by turning it away from von.
(16 )

How to Remove and Replace Bobbin Case
Raise the needle bar to its highest position and
lift up the hinged cover plate. Grasp the
bobbin case by the latch and pull out see Fig
26.
When the latch is closed, the bobbin falls out
of the case readily.
çFig. 26)
To replace, hold case by latch and place it on spindle
in center of shuttle race. Press firmly before closing
latch, making certain that the tongue of the case
fits into notch on the upper edge of the race cover.
( 17

• :.•
How to Thread the Bobbin Case
Refer to Figs 27, 28 and 29 to familiarize yourself with the procedure.
Hold the bobbin case in your left hand with the tongue pointing up.
Guide the thread end through the slot on the side of the case and
thread will be rotating counterclockwise.
(Fig. 29
Fig. 2L
Let about two inches of thread hang free from
the bobbin, and insert bobbin into case, so that
(Fig, 28)
under the tension spring until it enters the small notch on the edge
of the spring.
( 18 )

How to Remove the Shuttle
(Fig. 30)
When thread becomes tangled
in
the hook and shuttle race it
necessary to take the under thread mechanism apart and clean it.
Raise the needle bar to its highest position and tilt the head back.
Remove the bobbin case. Push the screws on either side of the race
cover to the outside and the cover can be removed easily. See Fig
30.
Lift the hook out.
Brush away all thread and lint from the race, hook and race cover.
Then, holding hook by the center pin, place it in race so that it fits
firmly against driver.
Fit cover over pins on each side of the race, with the notch at the
top. Pull latch screws back over side openings of the cover.
is
How to Insert the Needle
Turn hand wheel toward you to raise needle bar to its highest point.
Loosen needle clamp screw and insert needle with its flat side to the
right or toward the screw. Push needle up as far as it will go, and
tighten screw securely with screw driver.
Always use the type of needle recommended by the supplier of your
machine. Test on
a
flat surface to be sure it
is
not bent Fig
31
(Fig. 31)
( 19

How to Thread the Machine
Place a spool of thread on spool pin and raise the
take-up lever to its highest point. Refer to Fig :12.
Pull thread through slot of upper thread guide
down through tension discs 2
up into thread check spring :3
under the thread retainer 1
up into the middle thread guide 0)
and on up into the eye of the take-up lever 6 from
Return thread through middle thread guide 7
down through lower guide $
and into needle bar thread guide 9
—I
right to left.
(Fig. 32
I
Thread needle from left to right, pulling about four
inches of thread through needle.
20)

How to Use the Automatic Darner
To release the pressure from the presser foot so the material can be
moved freely for darning and mending, turn burled nut “B’, Fig $0 in
direction of arrow, or clockwise, and darner “A”pops up.
To return pressure to normal, push darner “A” all the way down again.
For a slighter pressure when sewing thin materials, push darner only part
way down. Test for correct position on a scrap of fabric.
Drop Feed Adjustment
The height of the feed dogs can be adjusted to suit the fabric or type of
work being done. Push the button on the left Fig 41 to “S” position to
(Fig. 40)
sew on thin materials, or all the way down to “E” position for darning or
embroidering with a hoop. Push button on the right to return feed to
“N” or normal.
Consult the following chart to determine the position of the drop feed
buttons and darner for various types of sewing.
Type of Sewing 1)rop Teed Darner Position
Sewing thin material S (SiIk Partially down
Darning, embroidery with hoop E (Embroidery) All the way up
(Fig. 41)
Sewing thick material N (Normal) Completely down
( 23 )

Built—in Light. To turn on the light located inside the face plate, turn
the switch to the right. When it is necessary to replace the bulb, open the hinged
face plate Fig 42;, unscrew bulb and insert a new one.
Needle-Thread-Fabrk-Stitching Guide
1))
Sheer. voile, lawn, 14 80
Very sheer -chiffon, 16 100
batiste, lace, organdy, 00 to to
ninon, net, marquisette, etc 20 150
Heavy Duty
A
50 A
Fabric
Machine
Needle Stitches
No per Inch
Cotton
Thread
Extremely heavy. 6 10
Silk
Mercerized or
Thread Nylon
tarpaulin, sacking 4 to to
canvas, duck, etc 8 30
Heavy -
upholstery
8 30
fabric, ticking, 3 to to
Heavy Duty
Heavy l)uty
(Fig. 42)
denim, leatherette, etc 10 40
Medium heavy -
40
drapery fabric, velveteen, 2 to to
suiting, felt, terry, etc 12 60
Medium. broadcloth,
percale, gingham, linen,
chintz, taffeta, sheer
wool, shantung, etc
12 60
1 tO to
14 80
50
dimity, crepe, 0 to to
handkerchief linen, 16 100
plastic film, etc
(Plastic film
50 A
( 24

Check Up for Smooth Sewing
Although your sewing machine is designed for maximum efficiency, should any of the following difficulties occur
they can be remedied with minor adjustments,
Upper Thread Breaks.
Be sure needle is inserted properly.
Check on correct way to thread machine.
Use correct needle size for thread.
Do not have upper tension too tight.
Lower Thread Breaks
Check correct method of threading bobbin case.
Be sure lower tension is not too tight.
Needle Breaks
Do not tug or pull on the fabric while sewing as this will bend and eventually break the needle.
Skipped Stitches
Stitches Loop
Do not use a blunt or bent needle.
Insert needle correctly.
Use correct needle size for thread.
Be sure pressure on foot is sufficient when sewing heavy fabrics.
Make sure tensions are properly balanced and that machine is threaded correctly.
Machine Binds
Clean thread, dust and lint from hook, shuttle and race. If condition continues, it may be that the machine
is gummy with oil. Apply kerosene to oil holes, run rapidly for a while, and wipe dry. Then lubricate
again with fine sewing machine oil.
( 25

Oiling and Cleaning
Before starting to oil the upper part of the machine, turn hand wheel
until take-up is at its lowest point. Apply a drop of oil to points
indicated by arrows in Figs 43, 44 and 45.
(Fig. 43)
To reach the areas requiring oil on the underside
of the machine (Fig 44( tilt the head back on
its hinges.
How frequently the machine is used determines the oiling
requirements. Moderate use calls for only an occasional
oiling. After applying the oil, run the machine at high
speed so that all parts will be penetrated by the oil.
(Fig 44)
(Fig. 45)
( 26
