PALLET WRAPPER
G1010

GÖWEIL
MASCHINENBAU GMBH
Since 1988, the GÖWEIL name has stood for the ultimate in quality in baling and bale wrapping technology.
Our other core areas include manufacturing bale opening and transport devices, high-lift buckets, and
knife sharpeners.
THE ULTIMATE IN MACHINE CONSTRUCTION
Professional solutions for farming and industry
Thanks to our extremely high export share, GÖWEIL machinery is known and used
not only in Europe, but all around the world.
The company originally specialized in agricultural machines, but now makes
equipment for industrial applications as well.
As a company, GÖWEIL is committed to four key values:
QUALITY.
All products are designed,
developed and produced exclusively at
the company’s locations in Kirchschlag
and Rainbach (Upper Austria).
EFFICIENCY.
We’re constantly developing and
improving our product range to offer
efficient, high-quality solutions in line
with your current needs.
KNOW-HOW.
Years of experience and close collaboration
between our construction and
production divisions are the key to our
smart and effective solutions.
SERVICE.
Even the best machines need maintenance.
Our service team is available
24 hours a day to help you with your
concerns.

OUR SOLUTIONS:
PALLET WRAPPER
G1010
HIGHLIGHTS 4 - 5
Advantages and unique features of the G1010 pallet wrapper
EQUIPMENT 6 - 7
Basic Model, Technical Data, Required
Connections, Additional Equipment and Attachments

G1010
HIGHLIGHTS
The G1010 pallet wrapper is the perfect machine for transporting, wrapping and loading pallet goods. One of the wrapper’s many uses is
in packing sod rolls. Its construction includes numerous elements from our proven round bale wrapping technology. There is also a wide
selection of loader attachments available for the pallet wrapper.
CONTROL UNIT
Fully automatic PROFI
program control
All work processes are fully
automatic
2
1
3
4
5

1
3
5
PICKUP AND TRANSPORT
With the G1010 pallet wrapper, you can transport, wrap and load full pallets,
all with a single vehicle. The pallets are picked up with ordinary forks.
During transport, the film cutting and wrapping system is folded up and
out of the way. The tines can be inserted all the way under the pallet,
until the pallet rests against the load backrest. As a result, the load is
very close to the tractor. And thanks to the side-positioned upper frame
section, the driver always has a clear view of the pallet.
4
HYDRAULICALLY ACTUATED FILM STRETCH
UNIT
One of this wrapper’s unique features is the hydraulically actuated film
stretch unit which moves 600 mm up and down during wrapping, enabling
it to completely wrap a 1350 mm-high pallet with a 750 mm-wide
film.
HYDRAULIC FOLDABLE FILM CUTTING AND
WRAPPING SYSTEM
FORKS
The G1010 pallet wrapper is fitted with the standard ISO 3B mount for the
forks. With its 1400 mm forks, picking up and transporting pallets is easy.
Other available options are 2200 mm forks or telescoping tines (1300 mm
long, extensible by 950 mm).
2
CONTROL UNIT
The wrapper is fitted with a user-friendly PROFI program control unit.
All work processes and functions can be controlled from the comfort of
the tractor cab. All work steps can be controlled either manually or fully
automatically.
The hydraulically actuated film cutting and wrapping system folds down
before wrapping starts. The pallet is lowered to the pallet stop, and wrapping
can begin. After the last turn in the wrapping process, the system
folds up, cuts the film off cleanly and secures it in place. The cutting and
wrapping system folds up and out of the way to make pallet transport
easier.
Telescoping fork tines

G1010
EQUIPMENT
The G1010 pallet wrapper combines three work processes in one machine: transport, wrapping and loading. This page provides an overview
of the basic model, technical specifications and additional options.
BASIC MODEL (no attachments)
Load Sensing
Can be used even on tractors with no load sensing pump
Single wrapping arm
Hydraulic foldable film cutting and wrapping system
Film monitoring unit
Stops wrapping process if film tears or runs out
Combined film stretching unit
For 500 mm and 750 mm film widths, the amount of overlap can also be configured
Hydraulically actuated film stretch unit
Height adjustment: 600 mm
Standard mount for the forks: ISO 3B
Forks - Length: 1400 mm
LED working lights
Fully automatic PROFI program control
All work steps can be triggered either manually or fully automatically.
TECHNICAL DATA // Basic model
Weight
Length
Width
Height
Maximum pallet size
Maximum pallet height
Oil requirements
Pallet weight
760 kg
2000 mm
1400 mm
2240 mm
1350 x 1350 mm
1700 mm
from 25 l/min at max. 190 bar
max. 2000 kg
AVAILABLE ATTACHMENTS (assembly not included)
Euro capture frame, three-point linkage, Cat. I and II
SMS, MX
Dieci/New Holland, Amkodor, Manitou, JCB Q-Fit, JCB Compact Tool Carrier, Weidemann
(hydraulic), Kramer, Schäffer up to 3550, Schäffer 3550T and up, Atlas, Claas
Scorpion, Zettelmeyer 602, Volvo BM, CAT 907H/Liebherr L507, Liebherr L514, Faresin,
Faucheux, Bobcat, Skit Steer, Fendt Cargo T955/Sennebogen
Other attachments upon request

1
IMAGE DESCRIPTIONS
1) The side-positioned upper frame section ensures a clear view of the palletized goods
2) The pallet is lowered to the pallet stop
3) Ideal for packing sod rolls
4) Pallets can be wrapped with net and film
5) Especially convenient for loading trailers
2 3
ADDITIONAL EQUIPMENT
Radio remote control
Required connection: 3-pole socket for electrical power supply to hand-held terminal
(12V/10A)
Forks - Length: 2200 mm
Telescoping fork tines – Length: 1300 mm long, extensible by 950 mm
Battery power cable, 5.3 meters / 2x6 mm² with 3-pole socket
Camera system
For improved monitoring of forks and film cutter
Required connection: 12-volt combination plug, DIN ISO 4165
Splash guard
Specifically for use with wheel loaders or telescopic handlers
4 5
REQUIRED CONNECTIONS
• One pressure connection and one depressurized return connection to supply the
wrapping machine
• Load Sensing connection (for LS operation)
• 3-pole socket for electrical power supply with direct feed to battery (12V/30A) -
cable cross section 2x6 mm²
