EDITORIAL

Core and mold production

The state-of-the-art of our main topics – core and mold production – is now

considerably higher than it has ever been. The proven organic binder combinations

for producing molds and cores are still widely in use in foundries

around the world. But inorganic binding agents spread in light construction

and will sooner or later also be suitable for casting processes at higher temperatures

– a breakthrough that will change casting production worldwide. For one

thing is evident: environmental standards are steadily rising, as can be seen in

China, for example. In his article (from Page 12), our author Christian Appelt

from the foundry chemicals company ASK Chemicals explains the necessary

material properties and process requirements for inorganic core production.

In an interview, Amine Serghini from competitor Hüttenes Albertus talks about,

among other things, the inorganic market situation and comments on the direction

of development of his company, which is also exploiting organic binders.

Above all, however, Hüttenes Albertus is relying on its superior knowledge,

as the recent opening of both a Research & Development Center and a Competence

Center in northern Germany show (read more from P. 6).

We have also saved no effort regarding the topic of materials for core and mold

production: in our corporate report on the global player Imerys, that now owns

S&B (and thus its IKO Foundry Division), we examine the supplier of special

mineral-based products for the industry and its range for foundries (from P. 48)

The simulation of casting and solidification processes is widespread throughout

the sector. A group of scientists at the Ansbach University of Applied Sciences

in southern Germany has now been able to use a material flow simulator and

a thermodynamic model of the melting furnace to come up with interesting

conclusions to improve energy efficiency and productivity in die-casting foundries

(from P. 42). The project will continue – as will the reports on it in CP+T!

And, last but not least, two articles on zinc and plastic caster Föhl in Rudersberg

near Stuttgart, Germany (from P. 32) and die-casting machine producer Bühler

in Uzwil, Switzerland (from P. 38), offer interesting insights into highly efficient,

innovative and pioneering companies and processes.

Have a good read !

Robert Piterek

e-mail: robert.piterek@bdguss.de

Casting Plant & Technology 1 / 2018 3

---

FEATURES

INTERVIEW

Serghini, Amine

“We want to offer foundries innovative

and comprehensive solutions” 6

COREMAKING

Appelt, Christian

Material properties and process requirements for

inorganic core production 12

MELTING SHOP

Möldner, Tobias

Burner air preheating by means of a heat exchanger

Cover-Photo:

GTP Schäfer GmbH

Benzstraße 15

D-41515 Grevenbroich

Tel.: +49 2181 23394-0

Fax: +49 2181 23394-55

www.gtpschaefer.de

CASTING TECHNOLOGY

Dickinson, Brian; Midea, Tony; Adams, Andry

PRESSURE DIE CASTING

Piterek, Robert

Globalization in Swabian 32

6 32

Amine Serghini is Head of Global Sales and Marketing at

Hüttenes-Albertus. In an interview he speaks about inorganic

binders, e-mobility and 3-D-printing (Photo: HA)

The zinc and plastic caster Föhl, Rudersberg, Germany,

is preparing itself with innovations and productivity for the

future and also counts on China (Photos: A. Bednareck)

---

CASTING

1 | 2018

PLANT AND TECHNOLOGY

INTERNATIONAL

INDUSTRY 4.0

Buob, Adrian

Cell management for greater success 38

SIMULATION

Buswell, Andreas; Schlüter, Wolfgang; Henninger, Matthias; Müller, Stefan

Simulation of non-ferrous melting and die-casting plants

COMPANY

Vehreschild, Michael

Imerys - strong potential for synergies 48

COLUMNS

Editorial 3

News in brief 52

Brochures 64

Fairs and congresses/Ad index 66

Preview / Imprint 67

38

A central, optimized cell control creates the basis for productivity gains in die casting. For foundry machine manufacturer

Bühler, Uzwil, Switzerland, the development of the cell management system is an important step towards die casting foundries

becoming part of Industry 4.0 (Photos: Bühler)

---

INTERVIEW

”We want to offer foundries innovative

and comprehensive solutions”

Interview with Amine Serghini, member of the management team, Head of Global Sales and

Marketing at Hüttenes-Albertus (HA), Düsseldorf, Germany

Mr Serghini, you have opened a new

Research and Development (R&D)

Center in Hanover and the HA Center

of Competence (CoC) in Baddeckenstedt

(both Germany). What do both of

these investments mean for the company’s

strategic positioning?

Our R&D Center and CoC are two important

building blocks in fully implementing

our strategy. We want to get

even closer to our customers. We not only

want to sell products, but also offer the

foundry industry an innovative and comprehensive

solution, including services.

HA has added a competence centre

with foundry pilot plant to research

and development in Hanover. What

The CoC facilitates cooperation and allows

us to bring solutions to market

quickly and effectively. As a producer of

foundry chemicals, we are the link between

foundries, with their casting requirements,

and machine manufacturers,

with their technical possibilities. In

the past, customers often started by creating

a new production line design for their

new product in close collaboration with

the machine manufacturer. Only once

the new plant was ready did the foundry

approach HA to find the right chemical

products to produce the casting. This

was often too late to provide customers

with solutions tailored to their processes

or castings, which then still had to be

put into commission. As a result, valuable

time was lost. By working together with

the foundry, machine manufacturer and

other partners at an early stage in product

and process development, we aim to

reduce the time required for this phase.

different partners who are working on

the topic at the same time and not sequentially

as before. If necessary, institutes

and universities also team up

with the CoC. In our CoC (see box), we

can cast, shoot cores and build molds.

We can also fully test and optimize

new processes and products before

they are used. This helps us to develop

products for our customers faster and

in a more targeted manner until they

are ready for the market and to successfully

launch them in foundries.

Does this change the relationship between

products and services in your

strategy?

We still manufacture chemicals, but

services are becoming more and more

important. Let’s take the automotive

industry as an example. When introducing

new products, such as a new

cylinder head or a new engine block,

there is always a bottleneck in the prototype

phase. This is because you have

to use the engine foundry, which is already

operating at full capacity. Our

customers can carry out all of their

prototyping in our CoC. We have

every thing we need to produce cores

and molds, and to cast all metals. This

How does this work in practice?

The customer comes to the CoC with

his request and meets a consortium of

Example of a customer project in the HA Center of Competence: Production of prototypes

in inorganic core production (Photos: Hüttenes-Albertus)

6 Casting Plant & Technology 1 / 2018

---

HA Center of Competence (CoC)

The HA Center of Competence (CoC) has about 8,000 m 2 of pilot and industrial

facilities and replicates almost all of the stages of the foundry process.

Here, new ideas and solutions for nearly all mold and core production

processes can be tested in practice, and without disrupting the processes

of customers.

Moreover, a comprehensive machine park offers the opportunity to optimize

the interaction of foundry chemistry and machine technology.

To this end, HA cooperates with virtually all renowned manufacturers of

foundry plants. The machine park’s facilities include:

means that we are not only able to carry

out prototyping from core production

to casting, but also to provide other

services that can then be outsourced

by the foundry. We want to act as an

extension of the foundry and offer

every thing that a foundry, in the midst

of series production, would have difficulty

implementing internally.

As a chemicals manufacturer, will you

continue to focus on foundries in the

future?

Yes. We are 100 % focused on foundry

chemistry with worldwide distribution,

and in recent years, we have divested

some business areas outside our

core foundry business.

» melting and casting plants

» core shooting machines for Cold Box, inorganics and other core production

processes

» sand mixing plants for Cold Box and inorganic processes

» continuous mixers for the no-bake process

» coating area, including robotic handling

» drying oven with a range of special features

» extensive measuring technology

You are engaged in research and de-

organic

and organic binder systems.

What progress are you making?

The new research centre in Hanover will

significantly increase the degree of innovation

by bringing our researchers together.

In the past, R&D was divided into

two areas. All organic R&D took place in

Düsseldorf, while inorganic binder systems

and coatings were developed in

Hanover. In the future, we intend to significantly

increase the proportion of inorganic

products in our production. We

also aim to further reduce the volume of

organic content in our organic products

thereby increasing the volume of inorganic

content in return. Our aim is for

our researchers in organic and inorganic

chemistry to inspire each other.

Can you give me an example?

Years ago, we began to introduce more

and more inorganic content into organic

chemistry, for example with our

Sipurid Cold Box systems. In the future,

we intend to continue pursuing

this approach. HA’s strategy is to promote

the development of environmentally

friendly organic binders and not

to turn our back on organic products.

What proportion of turnover is accounted

for by inorganics?

Currently, inorganics continue to represent

about 8 % of total sales. Inorganics

are still in their infancy. But this is

the area that is growing fastest. Inorganics

will continue to grow to well

above 20 to 25% of our product portfolio

over the next few years.

When will inorganics for iron casting

arrive?

We are very close to a solution that we

will present to the market. The first

results for series production are very

promising. We think that we will be

ready to launch a product in 2019.

But you also sell organic binders with

inorganic content?

That’s right. We also integrate inorganic

components into the organic molecular

structure in order to improve environmental

behaviour and gain other

technical advantages.

Do organic binders have a future or

will they one day be substituted by

inorganic products?

Honestly, that is a difficult question to

answer. In principle, organic binders

have many advantages. The disadvantage

lies in their environmental impact.

That is why we are trying, both

now and in the future, to make these

products as environmentally compatible

as possible. We know that we will

never achieve zero emissions from organic

binders, but we can significantly

reduce them. If we manage to do

this, organic binders will continue to

have their place in the future. In addition,

as things stand today, completely

replacing organic materials with

inorganic materials, not only in Germany,

but globally, would be very difficult

given the limited supply of raw

materials alone. There are simply not

enough readily available materials to

completely convert to inorganics. We

Casting Plant & Technology 1 / 2018 7

---

INTERVIEW

want to maintain the efficiency of the

foundry industry, and need to keep

costs within reasonable bounds. We

can only do so by further developing

organic binders to incorporate more

inorganics.

Gladly. It is well known that the inorganic

binders used by core makers today

require heated tools. This results in

a negative energy balance when compared

to organic Cold Box processes.

If we succeed in making Cold Box systems

more environmentally compatible,

and it looks like we will, the Cold

Box process will be used for many years

to come. The Cold Box process definitely

has its advantages, especially in

the iron casting sector, and has become

well established in the automotive industry.

This is likely to remain the case

in the long term, unless regulations are

dramatically tightened.

Which process represents the greatest

threat to the Cold Box process?

Certainly, inorganics are among the

processes challenging Cold Box. When

I look at our sales figures, inorganics

have gained ground in the aluminium

sector compared to Cold Box. In

the iron sector, Cold Box dominates

and is still growing very strongly – every

year, purchase quantities have increased.

The Cold Box process is even

supplanting other organic core production

processes. For example, Cold

Box is increasingly replacing the shell

molding process. The same applies to

other processes: Even more voluminous

cores are more frequently shot

rather than pressed using the furan

resin method. In this respect, we see a

promising future for Cold Box.

Is e-mobility a relevant topic for you?

What impact will it have on you as a

foundry supplier?

When we talk about e-mobility, we are

talking about purely electric vehicles

and hybrid vehicles. Internal combustion

engines will continue to be used,

including in many Asian countries.

We assume that car sales will continue

to grow and that the share of internal

combustion engines, including hybrid

engines, will also increase until 2025.

Combustion engines will also change

in the future. The casting process is becoming

much more complicated due

to continuing efforts to reduce CO 2

and other pollutants.

An opportunity for casting?

This is both a challenge for foundries

and a great opportunity for the Cold

Box process. In the future, more complex,

filigree cores will be produced

and combined into packages – one of

the major strengths of the Cold Box

process. The way in which certain castings

are made will change and this will

require special binders.

So, Cold Box will remain an important

process for hybrid drives and internal

combustion engines ...

Absolutely. This is because cast iron

will always be an important part of

engines – whether it’s a turbocharger,

an engine block or a cylinder head.

These are all parts that continue to

be produced in sand casting. As the

castings become more complex, they

move from die casting to sand casting.

We see a clear trend here. With higher

complexity, castings are sometimes

easier to produce using the Cold Box

process. But Cold Box binders must fulfil

certain requirements. Both technically

and environmentally, the binders

must achieve a significantly better result

than today’s systems. We are currently

working intensively on both

challenges. In one to two years’ time,

we will offer market solutions that can

also meet these new conditions.

Does e-mobility place special demands

on foundry chemistry?

No, for the production of castings, this

depends solely on the processes used.

But in addition to powertrains, which

may become smaller because of e-mobility,

there are more and more die-cast

parts in car bodies and chassis. HA has

been serving these areas for some years

now, and here, too, we see opportunities

for high-performance, i.e. productivity-enhancing

and environmentally

friendly products.

How is the coating sector developing?

When will we see coating-free

castings?

In iron casting, efforts have been made

for years to eliminate the need for coatings.

In some cases, it is already possible

– depending on the metallurgy and

the geometry of the casting – but in

many cases casting is impossible without

coatings. In fact, the field of coating

is actually set to grow over the next

few years.

What are the drivers?

Just take new technologies like 3-D

printing for core production. 3-D

printing allows an enormous freedom

of geometry, but has the disadvantage

8 Casting Plant & Technology 1 / 2018

---

that compression is not of the same

standard as with a shot core. In order

to achieve the required surface quality,

a coating material is needed to smooth

out the unevenness that occurs during

printing. We are in the process of developing

coatings specifically designed

for 3-D printing, because not every

coating is suitable for this process. This

is a market with a future.

And in iron casting?

Coatings are still necessary in iron and

steel casting, even if inorganic material

is introduced. We have also succeeded

in modifying inorganic systems, which

are generally highly sensitive to water,

and coatings in such a way that they

can be applied without causing damage.

We are continuously working to

ensure that the binder systems and

matching coating materials harmonize

in order to prevent certain casting defects

in the iron and steel casting sector.

So, coatings are an important R&D

topic?

Yes, in fact we have expanded our resources

and increased the number of

researchers working on coatings. These

are scientists who focus exclusively on

developing coatings for the fields of inorganic

and 3-D printing. We are convinced

that coatings will continue to

represent a growing market in the future.

You have touched on additive production.

An engine plant that casts

more than one million engines a year

needs to produce cores economically.

Will 3-D printing ever be able to replace

core shooters?

Certainly not in the short or medium

term. Printing still takes far too long,

although the technology is advancing

in leaps and bounds. Over the last 5

years, speeds have increased fourfold.

And 3-D printing is getting faster all

the time. We already know that 3-D

printing allows maximum geometrical

freedom. In future, cores that cannot

be shot due to their geometry will

be produced using additive manufacturing

technologies, whereas simpler

cores will still be shot at low cost. We

fully expect both methods to be used

in combination. Core-making shops

will not only have 3-D printers or core

shooters – they will use both.

Are these developments being driven

by industry-led demands?

Certainly. In terms of 3-D printing, we

have also built up resources for the development

of new core printing additives.

After all, new processes require

new products. We also recognize the

pressure to innovate from the customer

side. Even today, it is possible

to print complete core packages with

20 cores, whereby it’s not always possible

to clearly distinguish between cores

YOUR PARTNER

FOR TURNKEY PROJECTS

in no-bake moulding shops for:

• moulding lines

• continuous mixers

• mechanical and thermal reclamations

• chromite separations

Smooth pneumatic conveying system for:

QUALITY

MADE IN GERMANY

Casting Plant & Technology 1 / 2018 9

FAT Förder- und Anlagentechnik GmbH www.f-a-t.de

---

INTERVIEW

and molds. Our customers are already

asking us how to advance this new

technology. Industry wants to use the

technology, but still sees certain limitations.

And what exactly is HA’s role in all

of this?

In our view, our task is to develop the

right products for the whole range of

metals in order to improve the field of

core printing. It is not only the printing,

it is also about the thermal stability

of printed cores during the complete

casting process, all the way through

to de-coring. It doesn’t help if I have

a beautifully printed core, but I can’t

get it out of the casting. After pouring

even the most delicate component, the

sand has to be removed from the tightest

corner. And this is one of the challenges

we are trying to solve.

Do you work closely with machine

manufacturers and foundries in additive

manufacturing?

We collaborate with universities and

other institutes, as well as with foundries

and machine manufacturers. Producers

of 3-D printers, such as Voxeljet

and ExOne, are among our customers.

We supply them with the appropriate

products and we also work together on

developing solutions for the foundry

industry.

Hüttenes-Albertus is a global company.

Where is the greatest demand?

HA has a very strong position in Europe

and is also very well established

in the United States. We certainly see

great potential for growth in Asia. China

is our fastest growing market, delivering

double-digit growth rates every

year. We also have a good footprint in

India, Turkey and Russia.

What is driving demand in China?

The automotive industry, together

with mechanical engineering, are

the key drivers of growth in the Chinese

foundry industry. When we talk

about hydraulic casting, we have 5 to

10 new customers in China every year.

Hydraulic casting is generally in steady

decline in Europe, except in certain,

special cases. The business of simple

castings has all moved to China, and

we are seeing more and more foundries

built there to satisfy this demand.

Do inorganic processes play a role in

China?

Inorganic processes play an increasingly

important role in China. Next year,

we will sell more inorganic products in

China than in Europe. China is experiencing

an enormous rate of growth.

It doesn’t take years and years to introduce

new regulations in China – they

are implemented quickly, within one

year. Some of our customers have already

been forced to switch to inorganic

processes to comply with new

environmental standards. In the field

of aluminium casting for the automotive

industry, for instance, more and

more new production lines are being

built – and they are all geared towards

inorganic processes in order to satisfy

more stringent environmental requirements.

However, the Cold Box process

is also gaining ground in China and is

increasingly replacing the shell molding

process that has so far dominated

there.

Do you also manufacture foundry

chemical products for local markets?

Like particularly high-quality offers designed

for the German market or the

automotive industry, and then simpler

products for the Asian market?

In the past, western European foundries

did require higher performance products

than Asian foundries. And I deliberately

say “performance” rather than

“quality”, because the quality of all our

products has to be just right. Nowadays,

we have customers in China who

have higher requirements and demand

even higher performing products than

our European customers, although

there are still customers who only require

lower performance products. Our

strategy is to always offer our customers

exactly the solution that meets their

needs and gives them added value, for

example in terms of increased efficiency.

For that reason, we do not manufacture

the same products everywhere. We

have market-specific products that we

only manufacture in China, for example,

for our customers there.

How will you generate growth in the

future? Organically, or via strategic

acquisitions?

HA’s growth over the last few years

has been achieved not only organically,

but also inorganically, via strategic

mergers and acquisitions. HA,

as a family-owned company, has had

a large number of joint ventures with

other family-owned companies worldwide.

Our philosophy has always been

to ultimately secure majority ownership

of these international joint ventures.

And we have succeeded in doing

so. In the last decade, for example,

we have achieved majority ownership

10 Casting Plant & Technology 1 / 2018

---

of joint ventures in Turkey, Spain, Korea

and Italy. The biggest challenge,

however, was to take control of the remaining

50 % of our joint venture in

the United States, which we managed

to do in May 2016. There will certainly

be more M&A projects in the future.

But a major part of our growth will also

be achieved organically.

With new products?

Through the introduction of new processes

and new high-performance

products for specific markets. As I mentioned

previously, we always focus on

the needs of our customers and develop

solutions to help them improve

processes and increase productivity.

We expect significant growth, particularly

in the Chinese market, but also

in the southeast Asian region, which

is also a region with a promising future

for us.

Next year is a GIFA year. Can we expect

anything new from HA at GIFA

2019?

Nothing revolutionary, but an evolution

with promising and innovative

solutions. We want to offer not only

individual products, but above all fully

integrated solutions for the foundry

industry. We will present at least two

new solutions that will have a positive

and lasting impact on the foundry industry.

Last question: Where is HA today, and

where will the company be 10 years

from now?

HA is already one of the leading foundry

chemical companies in the European

market. We also have a very strong

market position in North America. In

Asia, we still see enormous growth potential

in a number of foundry markets.

In some markets, the two letters

“HA” are not always as well-known

as we would like them to be. This will

certainly have changed 10 years from

now.

But one thing is certain: We are and

will remain a family-owned company.

Our owners will always stand firmly

behind the business. Our credo – HA

family – is far more than just a slogan.

Our employees and partners in the

global HA world live and experience

this every day. It is the foundation of

their motivation, and they work passionately

every day to help shape the

future and growth of our company.

The interview with Amine Serghini

was conducted by Gerd Krause,

Dusseldorf

www.huettenes-albertus.com/en

Pneumatic conveying

technology

For dry, free-flowing,

abrasive and abrasion

-sensitive material

Core sand preparation

technology

For organic and inorganic

processes, turn-key systems

including sand, binder

and additive dosing

and core sand distribution

Reclamation

technology

Reclamation systems for

no-bake sand and core sand,

CLUSTREG® for inorganically

bonded core sands

KLEIN Anlagenbau AG

Konrad-Adenauer-Straße 200 · 57572 Niederfischbach

Fon +49 2734 501 301 · Fax +49 2734 501 327

info@klein-ag.de · www.klein-ag.de

Casting Plant & Technology 1 / 2018 11

---

COREMAKING

Christian Appelt, ASK-Chemicals GmbH, Hilden

Material properties and process

requirements for inorganic core

production

The inorganic binder technology Inotec from ASK Chemicals has established itself over the past

10 years as a productive and alternative core manufacturing procedure in serial casting production

processes, especially in the segments of aluminium cylinder heads, crankcases and suspension

parts by low pressure die casting and gravity casting applications

This odourless and emission-free core

production is also characterized by

very low cleaning and maintenance efforts

for machines and tools. These ecological

advantages are strongly linked

to economic and technological benefits

as an increased permanent mold

availability leads to a general increase

in productivity and increased mechanical

component strength as permanent

mold temperatures are reduced. In order

to profitably deploy this technology

and its ecological, economic and

technological advantages, expertise

and specialized knowledge of materials

and processes are required.

“Inotec technology has established

itself as a productive core manufacturing

procedure for the serial production

of lightmetal castings by low-pressure

die casting and gravity casting applications”,

explains Dr. Christian Appelt,

Global Incubator Business Manager

Inorganics at ASK Chemicals, Hilden,

Germany.

The initial motivation for the introduction

of inorganic binder systems

into the foundry industry was themed

by “emission-free casting processes”

and is based on the absence of harmful

volatile compounds and emissions

during the core production, core storage

and casting processes, which ultimately

results in the elimination

of air treatment systems. The drastically

reduced cleaning and maintenance

effort for the permanent molds

is based on the inorganic nature of

Production of inorganic cores using Inotec technology at ASK Chemicals

the Inotec technology, since the formation

of condensates and pyrolysis

products during the casting processes

is not observed. The absence of these

condensates also allows a faster casting

solidification due to reduced permanent

mold temperatures, which in

turn contributes to the mechanical

strength of the metallurgical structures.

Thus, the ecological advantages

of this technology are in line with

economic and technological factors.

The Inotec technology is described

as a two-component binder system:

Component 1 forms the liquid Inotec

binder, which can be described as

a modified alkali silicate solution and

influences specific sand core properties

during the production (final

strength, flowability); Component

2 is the powdered Inotec promoter,

which is a mixture of synthetic and

natural raw materials based on a completely

inorganic product composition

( Figure 1).

Through the use of the Inotec promoter,

primarily mechanical and thermophysical

parameters of the sand

core are influenced during the production

process (immediate strength,

flowability), but in particular during

the casting processes, resulting in castings

of high dimensional accuracy and

best surface quality.

12 Casting Plant & Technology 1 / 2018

---

CASTING TECHNOLOGY

BEYOND TOMORROW

Are you

READY

to leave your

competitors behind?

Champion world-class tailor-made solutions ASK Chemicals

If you want to be on the podium in the future, you need to beat the competition. A reliable and strong partner will

help you in achieving this goal. We are always there for you, offering a comprehensive technical service that looks at

your entire production process. This opens up a whole world of new possibilities – from cost savings to increased

productivity.

ASK Chemicals experts look forward to hearing from you:

Phone: +49 211 71103-0

E-mail: info@ask-chemicals.com

www.ask-chemicals.com/beyondtomorrow

---

COREMAKING

Inotec binder system

with balanced viscosity

and particulate structure

of the promoter

The Inotec binder contains an active

solids content between 35 and 55 %

on the basis of an aqueous solution.

The macroscopic parameter “viscosity”

is thereby influenced by this active

solid content as well as by its adjusted

reactivity, whereby the viscosity

meets all requirements during the

mixing and core production processes,

e.g. wetting behaviour/coating of

the sand grain surface and flowability

at productive cycle times. The Inotec

promoter contains over 99.8 % solids.

The particulate, i.e. powdery, structure

of the promoter is essential to enable

the incorporation of network-forming

constituents and to act as filler for increasing

the flowability of the molding

mixture and increasing the sand core

packing density.

The core production is characterized

by a physical-chemical curing mechanism.

The introduction and supply

of thermal energy from heated steel

tools and dehumidified, heated compressed

air leads to the evaporation

of the free solvent water and simultaneously

initiates a chemical polycondensation

reaction with the formation

of a three-dimensional silicate

network which characterizes the actual

strength composite in the sand core

(Figure 2). Simultaneously, specific raw

materials of the Inotec promoter are

linked to the free, non-condensed, OH

Figure 1: Typical composition of an Inotec binder system

groups of the three-dimensional silicate

structure via a surface reaction and

can thus specifically influence the mechanical

and thermal properties of the

sand core. The binder bridge formed

after core production has a gel structure

and, depending on the cross-section

and volume of the sand core and

energy input during core manufacture,

contains a defined amount of residual

water. If this residual water is expelled

by further introducing thermal energy,

the binder bridge loses its binding gel

structure and embrittles, resulting in

sandy core surfaces and core fracture.

The material properties of the Inotec

technology thus define the process

windows and the technical prerequisites

for production: robust and

productive process flows can be effectively

ensured by suitable control and

quality assurance measures (Figure 3).

Process requirements: from

the incoming goods to the

deployment of the inorganically-bonded

sand cores in

the casting process

In addition to casting surface roughness

requirements, the silica sand

qualities commonly used for inorganic

core production have to fulfil specific

chemical and physical properties

(Table 1): a high chemical purity of

> 99 % SiO 2

ensures a high binder compatibility,

whereby impurities such as

clay or lime lead to reduced strength

properties of the sand cores; the particle

size and the fine-grain fraction

significantly alter the gas permeability

of the sand cores, so that cycle time

extensions or productivity losses occur

with fine silica sand qualities and

voluminous core geometries. Above

all, acidic silica sands with a pH value

Figure 2: Polycondensation reaction, schematic description of the sol-gel process and incorporation of network-forming components

of the Inotec promoter

14 Casting Plant & Technology 1 / 2018

---

Giesserei-Verlag Wörterbuch

Deutsch – Englisch / Englisch – Deutsch

1. Auflage · 1st Edition

ISBN 978-3-87260-186-5

39,00 €

PLASMA

METALL SCHMELZE

KÜHLER

DIN

RECOVERY

FORMANLAGE

GLÄTTEN

PIPE

CORE

MOULD

GUßEISEN

QUALITÄT

SUPPLY

FEUERFEST

ORE

PATTERN

KOKILLE

INDUSTRY ENERGY RECYCLING

WÄRME

TEMPERATURE

GUßBLOCK

OXIDANT

FOUNDRY KERNHERSTELLUNG

KERNEISEN

ZIRCON

WELDING

FERTIGUNG

Gießen | Casting

FOREHEARTH

Herausgeber:

Verein Deutscher Gießereifachleute e. V. (VDG)

2018 · 616 Seiten · 10,5 x 14,8 cm

Giesserei-Verlag

Wörterbuch · Dictionary

Deutsch – Englisch

Englisch – Deutsch

German – English

English – German

Das Giesserei-Verlag Wörterbuch ist die umfassend überarbeitete und aktualisierte Fassung

des seit der 1. Auflage 1971 im In- und Ausland bewährten und geschätzten “Giesserei-Wörterbuch“.

Erfasst ist der Fachwortschatz der gesamten Gießereitechnik in Wissenschaft und Praxis von Formstoffen,

Form- und Kernherstellung über Schmelzen und Gießen (einschließlich der Druckgießtechnik)

bis zu Rohgussnachbearbeitung, Qualitätssicherung und Gussverwendung.

Das Wörterbuch umfasst je Sprache rund 18.000 Eintragungen.

Giesserei-Verlag GmbH

Sohnstraße 65 · 40237 Düsseldorf · Tel.: +49 211 6707- 527 · Fax: +49 211 6707- 582

E-Mail: gabriele.wald@stahleisen.de · www.giesserei.eu

---

COREMAKING

Figure 3: a) Homogeneous distribution of the Inotec binder system in the molding mixture; b) binder bridge with gel structure;

c) destroyed binder bridge through dehydration and embrittlement

Figure 4: Temperature and moisture content curves of Inotec-bonded sand cores at low

humidity

Base mold material: Silica sand (96 – 97 % of the sand core)

Chemical Purity

content (

---

a cross-section and volume-dependent

strength development and volume-dependent

cycle times.

The storage stability of inorganic-bonded

sand cores is limited due to

the reversibility of the binder bridge formation

in the case of high temperatures

and high absolute humidity, so that

usually climate-controlled core storage

facilities are deployed. The equilibrium

between the temperature and humidity

(moisture content) of the sand core

and the ambient air is the driving force

of the moisture absorption (Figures 4

and 5). Here too, the selection of specific

Inotec binder systems can ensure sufficient

and stable storage stability even

at high absolutely humidity.

The filling of the liquid aluminium

melt during the casting process produces

a thermal energy input and causes an

equilibrium shift in the inorganic-bonded

sand core with the release of free residual

solvent water and chemically

bound water of the free Si-OH groups

of the 3-D silicate network. Therefore,

Figure 5: Temperature and moisture content curves of Inotec-bonded sand cores at

high humidity

the gas permeability of the sand cores

and the geometry and position of the

sand core in the permanent mold and

the orientation of the core prints ensure

a successful core gas venting.

Finally, the breadth of the process

window of inorganic core production

has been significantly reduced compared

to organic core production processes.

Suitable technical measures,

taking into account the Inotec material

properties, and specific control and

quality measures can accompany and

ensure stable and productive processes

of inorganic core production.

www.ask-chemicals.com

Competence in

Shot Blast Technology

We offer a complete service in surface preparation technology,

not just as machine designers and manufacturers.

Our emphasis is on providing reliable service on:

• Wear and Spare Parts

• Repair and (remote) maintenance

• Inspection and process advice

• Machine upgrades and performance

enhancement

• Upgraded used machines

AGTOS

Gesellschaft für technische Oberflächensysteme mbH

Gutenbergstraße 14 · D-48282 Emsdetten

Tel. +49(0)2572 96026-0 · info@agtos.de

www.agtos.com

151-11/13-4c-GB

Casting Plant & Technology 1 / 2018 17

---

MELTING SHOP

Tobias Möldner, Munich

Burner air preheating by means

reduces gas consumption

This furnace is the electrical version - without heat exchanger. For cost reasons,

however, the variant with heat exchanger is recommended (Photos: ZPF GmbH).

In 2016, the prototype of an optimized

aluminum smelting system was realized

as cooperative project between the

industrial and business communities,

funded by the German Federal Ministry

of Economics and Technology (BMWi).

The EDUSAL II project makes it possible

to determine the energy-saving potential

of the smelting process while at

the same time minimizing the resulting

smelting loss. In order to further reduce

the consumption values of such

a system and thus to increase both energy

efficiency and resource conservation,

the smelting furnace manufacturer,

ZPF GmbH, Siegelsbach, Germany,

has now extended its concept with additional

components: By incorporating

a so-called burner air preheating,

in which the warm exhaust gas volume

flow is passed through a pipe system to a

heat exchanger, the system operator has

more room for maneuver – with lower

pollutant emissions and lower gas consumption.

This new system can – with

appropriate adjustments – be used as a

retrofit kit for existing ZPF melting systems.

EDUSAL means energy efficiency

enhancement and melting process optimization

through the sensory detection

of melting material and melting range

of aluminum smelting furnaces.

“In last year’s project, numerous sustainable

improvements, that have optimized

the previous furnace system, were

achieved” says Sven-Olaf Sauke, head of

R & D at ZPF. “The main focus was on the

further development of the measurement

technology to a sensory detection of the

melting shaft, which means that in laboratory

operation both the position of the

residual material on the smelting link and

its quantity can be precisely determined.

In addition, a special evaluation algorithm

has been developed that has improved

the process to the point that an

increase in smelting efficiency of up to

15 % can be achieved.”

Another focus of the EDUSAL II system

was the testing of burner air preheating.

The idea of integrating a burner

air preheating, which efficiently uses

the heat flow of the system, has been

around for a long time. However, since

solutions with partly utopian characteristics

and promises are offered on the

market, an electrical preheating was initially

installed. This allows a very precise

energy and thus also profitability

balance of the measure. The characteristic

values obtained were used to design

a burner air preheating from the

exhaust gas stream of the smelting system.

“With this version, the already

18 Casting Plant & Technology 1 / 2018

---

heated exhaust gas flow is directed to a

heat exchanger via a suitable pipe system”,

continues Sauke.

The primary air side (hot gas side),

which is prefixed to the heat exchanger,

requires additional components: for

example, a control unit that directs the

exhaust gas flow to the heat exchanger

according to the requirement, and additional

measuring points that ensure

safe process management. In the event

of failure of the heat exchanger or any

of the components, the control unit

must direct the exhaust flow through a

bypass function, past the heat exchanger,

directly into the secondary system to

protect the heat exchanger and its components.

In the heat exchanger, the energy

is released to the secondary air side

(burner air) – the cooled exhaust gas is

discharged in the other system either

directly into the atmosphere or for preheating

the melting material in a corresponding

chamber.

The burner air fan conveys cold

burner air from the environment into

the heat exchanger, which is heated

there in the ZPF smelting systems

to about 200 °C. The pipe system after

the heat exchanger is insulated and

equipped with appropriate butterfly

valves, measuring instruments and displays.

An air collector installed directly

after the heat exchanger helps distribute

the heated medium evenly across

the piping to the entire burner system.

Thus, the flame temperature increases

significantly, resulting in a higher energy

input and lower gas consumption.

“In this way, not only are operating

and energy costs reduced, it also

allows for a careful handling of the

valuable resource of gas,” says Sauke.

“The efficiency of the entire system is

increased, and the pollutant emissions

are reduced.” This heat exchanger variant

is suitable for all ZPF gas-fired aluminum

smelting and heating furnaces,

which have a connected load of more

than 300 kW and a high smelting ratio

over the entire operating time of the

furnace. However, the specified limit

temperatures for the refractory lining

of the kilns must be strictly adhered to.

In burner air preheating by means of a heat exchanger, the warm exhaust gas volume

gas consumption

“Burner air preheating not only saves on

operating and energy costs, it also makes

it possible to use the valuable resource of

system will be increased, and pollutant

emissions will decrease,” explains Sven-

Olaf Sauke, head of R & D at ZPF

Burner air preheating by

means of heat exchanger as

ing

systems

The extension of the energy-efficient

burner air preheating with an integrated

heat exchanger can also be carried out

with an existing smelting system, but requires

some changes, according to Sauke:

“When upgrading existing ZPF systems,

in addition to the heat exchanger, a hot

gas withdrawal point, suitable piping

and temperature-resistant control and

butterfly valves must be integrated. The

adjustments with regard to the control

as well as the user interface must also be

observed. “All electrically operated components,

for example the control valves

and the measuring technology, are integrated

in the control and in the control

cabinet in order to simplify the operation

of the system.

All modifications and retrofits of

the system are done by ZPF directly

at the customer’s premises - before

this, a comprehensive inventory, consultative

discussions and an in-depth

conception will take place. In closing,

Sauke explains: “The need for pipes,

routes and insulation material must

be calculated on a project-specific basis.

The advantage of the developed

system lies in the fact that all components

are installed directly at the plant

and thus no further space requirement

arises in the smelting system. “In addition,

ZPF is working intensively on further

measures to improve the efficiency

of the aluminum smelting systems.

www.zpf-gmbh.de

Casting Plant & Technology 1 / 2018 19

---

CASTING TECHNOLOGY

(Photos and graphics: Foseco)

Brian Dickinson, Tony Midea, Andy Adams, Foseco Metallurgical, Inc., Cleveland, Ohio

-

The analysis uses industry standard filter

print designs as the baseline for the fluid

flow comparisons, and compares these

results to filter print designs that have

been altered for yield improvement. Industry

standard filter prints are defined

as those designed during the initial filter

development for iron castings. Some

of the key requirements for optimal results

were identified during the development,

incl. the following [1-4],[6-11].

» Maximize exposure of the filter inlet

face to ensure maximum total flow

» Maximize (four sided) support to ensure

that the inertial forces on the filter

from the iron flow do not surpass

the strength of the filter

» Minimize the possibility of iron

passing around (not through) the

filter by designing the support ledge

on the filter print outlet to match filter

tolerance dimensions

» Minimize turbulence by designing

the filter print volumes such that

the flow smoothly transitions from

inlet to outlet

These combined characteristics were

used to define the basis for standard filter

print design. Over the past 30 years,

these designs have been continually tested

and have slightly evolved through applications

and foundry evaluations. The

first simulations conducted in this study

were used to evaluate these standard designs.

Yield improvement is a high priority

for all foundries, and gating systems

are analyzed as carefully as all other

aspects of the casting process to reduce

weight. Alterations are sometimes

made to standard filter prints to reduce

weight without careful analysis of the

effect on the fluid flow properties on

the gating system.

20 Casting Plant & Technology 1 / 2018

---

Changes that adversely affect molten

metal fluid flow can result in increased

turbulence, non-uniform flow

and a reduction in filtration efficiency.

Several of these situations were also

evaluated in this study.

The results of this work include several

ideas on how to design filter prints

and runner systems that are applicable

to all iron filtration devices in the best

way.

Standard 75 mm x 75 mm x 22 mm

(2.95 x 2.95 x 0.866 inch) thick square

horizontal and vertical filter prints

were chosen as the baseline to begin

the analysis. Several modifications

were made to both types of filter prints

to evaluate the effect of these design

modifications on fluid dynamics.

All fluid flow analyses were conducted

using MAGMA 5 (Version 5.3.0.4)

with Solver 5. The mesh size for all simulations

was approximately 10 million

elements (700,000 metal cells). The

metal dataset represents ASTM A536-84

(80-55-06/GGG-60) grade ductile iron

poured at 1,400 °C (2,552 °F) into a sand

mold. The plate casting is approximately

305 x 610 x 76 mm (12 x 24 x 3 in) in

dimension and approximately 100 kg

(220 lb) in weight. Total pour weight

was approximately 110 kg (242 lb).

The filter was represented using

standard 10 ppi, foam filtration pressure

drop data for a 22 mm (0.866 in)

thick SEDEX filter [5]. In all cases, the

program was run using the “Automatic

Filling Control” feature. Specifically,

the program was forced to maintain

a pouring cup metal height of

70 % for all the simulations, thus ensuring

identical pouring conditions for

all versions simulated. Fill time was approximately

24 s for all configurations,

representing a flow rate of approximately

4.5 kg/s (10 lb/s).

The gating designs evaluated in this

report are representative of those in

use on industry standard, high pressure,

green sand, automated molding

equipment.

Standard Vertical Filter Print

Standard Horizontal Filter Print

Casting Plant & Technology 1 / 2018 21

---

CASTING TECHNOLOGY

The choke area was calculated using

Equation 1.

The top of the sprue was calculated

using Equation 2.

The sprue was tapered at a three-degree

angle to allow for mold stripping.

The runner system follows a ratio of

Sprue:Runner:Ingate of 1.0:1.1:1.2.

The baseline vertical filter print configuration

is shown in .

The baseline horizontal filter print

configuration is shown in .

All simulations were conducted on a

Dell Precision 7810 Tower workstation

utilizing 8 cores. CPU time for each

simulation was approximately 10 h.

Velocity at 10 % Filled

All fluid flow results shown are analytical

and based on the Navier-Stokes

flow equations. Flow predictions from

this first principal fluid dynamic approach

have been validated for several

decades in many industries and applications,

including molten metal applications.

The expectation is that the

comparative results shown should be

very meaningful and accurate. However,

foundry trials will be conducted

in future work to further validate the

conclusions presented in this paper.

The flow characteristics for a standard

vertical filter print are shown in .

The colors represent flow velocities. At

10 % filled, the flow is in a steady state

in and around the filter print. The color

scale goes from light blue (low velocity,

near 0.2 m/s (0.66 ft/s) to white (higher

velocity, near 2.0 m/s (6.6 ft/s). Flow

through the filter is approximately 0.3-

0.4 m/s (1-1.3 ft/s), and the flow before

the filter is laminar, and covers the entire

filter. Flow after the filter is uniform

and stable.

A cross section through the middle

of the filter print at this same time step

shows the fluid velocity and flow vectors

().

This image clearly shows the uniform

flow, and the utilization of the

entire filter face for both flow control

and filtration. This can be considered

a well-designed filter print and gating

system, and will serve as a baseline for

the vertical filter print section of this

study. In application, extreme changes

have sometimes been made to standard

filter prints to save weight, increase

yield and/or fit within pattern

plate restrictions. shows one

actual example.

While this design results in a 35 %

weight reduction to the filter print design

(0.9 kgs, 2 lbs), the flow characteristics

in the filter print and gating system

are adversely affected.

22 Casting Plant & Technology 1 / 2018

---

shows the flow characteristics at

the centerline of the filter print and ga t-

ing system at 6.5 % filled. (Note: The results

for all designs are compared to the

standard filter print design results. The

standard results are shown as the bottom

image in the comparative figures for the

vertical filter print examples.)

Because of the sharp angles of the

modified filter print inlet, the flow accelerates

into the center of the filter inlet

face, and begins to move through

the filter before completely filling up

the filter print inlet area. The flow

characteristics for the standard filter

print design show a more evenly distributed

flow pattern within the filter

print inlet and at the filter inlet face.

The high filter inlet face velocities of

the reduced filter print inlet area design

results in some very high filter exit

face velocities, as shown in .

Ideally, the filter should reduce flow

energy and turbulence by acting as a

flow discontinuity. However, this effect

is mitigated if only a small area of the

filter is being utilized. This is shown

clearly in Fig. 7, with the reduced area

filter print showing flow exiting the

filter at high velocity, while the standard

design shows the entire filter

filled with metal at very low velocity,

and minimal metal flow exiting the filter

itself at this time step.

In , this continues to be the

case even at steady state flow. Even at

steady state, the reduced area filter print

design is not allowing the entire filter

print inlet area to be used, and instead

is pushing the metal through the center

of the filter. This results in non-uniform

flow behind the filter, and the potential

for turbulence. Contrast this with

the uniform flow profile shown for the

standard filter print design, particularly

at the filter outlet face, the filter print

outlet and downstream in the runner.

Also, due to the steep angle of the

filter print outlet, the flow is launched

upward, thus adversely influencing the

stability of the flow downstream. This

can be seen more clearly in .

-

Casting Plant & Technology 1 / 2018 23

---

CASTING TECHNOLOGY

Fig. 9 shows a top view of a cross section

taken near the bottom of the runner

bar, just after the filter print. For

the reduced area filter print design,

note that the flow at both sides of the

runner bar are moving very slowly, and

most importantly, in the opposite direction

of the intended flow.

The upward thrust of the metal flow

due to the steep angle has created a

large, adverse eddy current driving the

flow slowly backwards. This situation

24 Casting Plant & Technology 1 / 2018

---

exists for the bottom third of this runner

bar. The standard filter print design

shows an area of slow flow near the bottom

of the runner on one side, but the

primary flow characteristics are much

more uniform in velocity and direction.

shows a side view of the

runner bar at the same time step, and

shows a clear difference between the

two designs, with the standard filter

print providing more uniform, controlled

metal flow to the casting. Reducing

the area of the filter print in this

fashion to slightly increase yield (0.9 kg,

2 lbs saved) has significant adverse effects

on the flow characteristics in the

filter print inlet, the filter inlet face, the

filter outlet face, the filter print outlet,

and in the downstream runner bar. This

type of alteration is not recommended

for best practice filter print design.

shows a configuration

with the area of the filter print outlet

modified to match the standard print

shown in Fig. 1, but the reduced filter

print inlet area is unchanged.

In this case, the issues in the filter

print inlet area and at the filter

inlet face remain the same as discussed

previously, but the flow after

the filter shows clear improvement. In

, note how similar the filter

outlet face and filter print outlet flow

profiles appear when comparing the

reduced filter print inlet area configuration

with the standard filter print.

The main difference between this

configuration and the standard filter

print is the dramatically higher flow

velocities at the filter inlet face for the

reduced area design, and the fact that

only a small portion of the filter is being

used. This is the same situation discussed

in the previous configuration,

but the yield argument is even more

clear this time.

Reducing the area of the filter print

inlet only saves 0.6 kg (1.3 lb), but adversely

affects the flow such that the

entire filter area is not being used to

efficiently filter inclusions from the

metal. Again, this small yield improvement

has a significant adverse effect on

the flow, and is not recommended in

practice.

shows a similar design with

the area reduced at the filter print outlet

only. Reducing the area of the filter

print outlet only will save just 0.3 kg

(0.66 lb), and result in very poor flow

exiting the filter print. The flow comparison

is shown in .

In this case, the flow in the filter

print inlet and at the filter inlet face

has the same beneficial characteristics

as that of the standard filter print.

However, the flow at the filter outlet

face, within the filter print outlet and

in the downstream runner bar exhibits

all of the same poor characteristics

shown in Fig. 7-10. A filter print design

that adversely affects the flow characteristics

and delivers minimal yield improvement

should not be considered as

practical.

shows the standard configuration

with an addition of a slag trap

before the filter. This change only adds

---

CASTING TECHNOLOGY

approximately 0.23 kg (0.5 lbs) to the

filter print design, but results in a positive

impact on the overall flow characteristics

of the filter print itself. The filter

print with a properly designed slag

trap displays all of the high quality

flow characteristics shown in the standard

filter print, with the added benefit

of better filter print inlet flow and

potentially better filtration efficiency.

shows how the trap begins

to work as soon as the metal reaches

the filter. Note that the bottom of the

filter print inlet has filled quickly, and

that the flow is washing the filter inlet

face and moving upwards into the

slag trap area.

At 8.5 % (), the flow is nearly

stabilized, and the slag trap is forcing

the initial metal into a beneficial

counter-clockwise eddy current, thus

potentially allowing inclusions to reverse

direction and slowly float upward

into the trap. The standard filter print

without the slag trap also has a small

area of beneficial eddy currents at the

top of the filter print inlet, but very little

space to trap and retain inclusions.

By 9 % filled ( ), the filter

print is fully flooded, including the

---

slag trap. There are still some small

beneficial eddy currents in the trap. By

10 % filled (), the filter print is

fully stabilized and any inclusions that

entered the slag trap will remain.

Adding a small area to trap slag in

the filter print inlet improves the flow

characteristics of the runner design

and the ability of the filter print to trap

inclusions. These are significant benefits

for a minimal reduction in yield.

For horizontal filter print designs,

some significant advantages to filtration

efficiency can be gained simply by

placing the filter at an angle relative to

the flow. shows a standard

horizontal filter print compared to an

angled filter print configuration.

The angled filter more readily accepts

the flow and provides a more

uniform flow pattern both within and

above the filter inlet face.

At 8.5 % filled ( ), the angled

filter print flow profile is fully established,

and uniform throughout. A

beneficial eddy current is visible within

the filter print inlet which enhan ces

the effectiveness of the slag trap. The

---

CASTING TECHNOLOGY

formation of the eddy current is a direct

result of the angled filter.

At 10 % filled (), both filter

prints are operating at steady state conditions,

and both produce a uniform

flow pattern. The angled design does

a better job of distributing and minimizing

the flow energy at the filter inlet

face and outlet face.

Another advantage of angling the

filter is to direct the flow across the filter

inlet face to potentially dislodge

any inclusions that may have become

trapped on the filter itself. These dislodged

inclusions could then get entrained

into the eddy current and be

mechanically moved into the slag

trap.

The velocities at the filter inlet face

are shown in top view in (To

create the image for the angled filter,

the clipping plane was rotated around

the y-axis to match the plane of the filter).

essentially shows a top

view of the flow profile at the filter inlet

face. For both cases the metal flow

is clearly moving across the filter inlet

face from one end to the other, but

more prominently in the angled filter

case, as seen in the right image. For

the angled filter, the flow is also moving

more quickly through the filter, as

shown in .

The images in Fig. 25 represent only

the filter geometry (no filter print or

gating), and the images are rotated for

comparative viewing and as such are

not in their normal orientation. The

left image represents the standard horizontally

oriented configuration while

the right image represents the angled

filter configuration. The filters have

been sectioned along the centerline,

and the scale has been adjusted (reduced)

to show the flow direction and

to delineate more clearly the velocity

differences.

From this view, the right image

shows the washing of the angled filter

inlet face, represented by the parallel

vectors on the filter inlet face and even

a few millimeters into the filter thickness

itself. By comparison, only two

small sections of the horizontal filter

(left image) show parallel flow at the

filter inlet face, and even then only on

the surface of the filter itself, not into

the filter thickness.

The benefits of the mechanical action

of moving inclusions from the fil-

28 Casting Plant & Technology 1 / 2018

---

Standard vs angled horizontal

ter inlet face to the slag trap are twofold.

This action allows the filter to

operate at maximum flow rate because

there are fewer particles trapped on the

surface of the filter restricting the metal

flow through the filter. In addition,

for metal containing significant slag

levels, this may also allow the filter to

operate at higher capacity than standard

filter print orientations because

of the opportunity to pass more metal

through the filter before ultimately

becoming blocked or caked with slag

or other inclusions.

Overall, placing the filter at an incline

relative to the metal stream is

beneficial to the filter flow rate capability

and filtration efficiency.

---

CASTING TECHNOLOGY

30 Casting Plant & Technology 1 / 2018

---

Alterations are sometimes made to

standard filter prints to improve yield

without careful analysis of the effect

on the fluid flow properties on the gating

system. This initial study evaluated

the effect of several filter print design

changes on the quality of metal flow in

the filter print, the runner system and

through the filter itself. In general, the

conclusions are as follows:

» Large reductions in filter print inlet

and outlet areas, and sharp angles

within the print itself adversely

alter the flow characteristics

resulting in non-uniform flow and

turbulence.Conclusion: Yield improvement

is minimal, not recommended.

» A slag trap designed prior to the

filter inlet face induces a counter-clockwise

eddy current that

washes the filter face and assists

with the trapping of inclusions.

Conclusion: Recommended

» In horizontal applications, angling

the filter relative to the metal stream

is beneficial to the filter flow rate capability

and filtration efficiency.

Conclusion: Recommended

Maximize

your profit

with 3D printed

cores & molds.

Our experts

will be pleased

to advise you!

This paper constitutes the initial, theoretical

study of various SEDEX filter

print designs and their effect on flow

characteristics. Future work is planned

to review additional design concepts

and to validate these configurations

with molten metal.

-

Daimlerstr. 22 • 86368 Gersthofen

+49 (0) 821 650 630

ExOne.com • europe@exone.com

---

PRESSURE DIE CASTING

Robert Piterek, German Foundry Association, Düsseldorf

Globalization in Swabian

60 years after Föhl was founded, looking back is much less interesting than looking ahead: the

zinc and plastic caster from Rudersberg near Stuttgart is preparing itself for the future with re-

nese

market

die-casting foundry”), the consolidation

of important processes, further

work on establishing a corporate culture,

and the professionalization of

further education and training.

Dr. Frank Kirkorowicz, Föhl’s President and CEO, at the Michelau die-casting plant.

(Photos: Andreas Bednareck)

In 1958, Germany’s economic miracle

was driving development, and the

die-casting process was still a comparably

new technology: Adolf Föhl,

then a toolmaker at pressure die-casting

machine producer Oskar Frech,

Schorndorf, Germany, recognized the

potential of this production process

and exploited his professional knowledge

to set up his own company –

Adolf Föhl GmbH + Co KG. An initial

injection molding plant rapidly became

a sizeable machine park in which

zinc die-casting machines soon played

the leading role. The marriage of Adolf

Föhl’s sister to Oskar Frech marked

the creation of a fruitful partnership

between the technology user and the

supplier, that has lasted to the present

day.

60 years after its founding in the late

1950s, Föhl is celebrating a decadal jubilee.

The Swabian foundry is now a

flourishing group of companies with

sales of 107 million euros and almost

700 employees in five works in Germany

and China. It is still a matter of

recognizing and exploiting potentials.

Because the caster from Swabia is currently

developing the company’s future

foundations. The program for the

coming years includes the launch of

newly developed technologies in Germany

and China, expansion of the

works in Michelau (which is already

considered “Europe’s most modern

Creating value by appreciating

value

As President and CEO, Dr. Frank Kirkorowicz

has been steering corporate

development since the mid-1990s. In

this he is supported by his Executive

Board colleagues Ulrich Schwab (Chief

Operating Officer) and Boris Langer

(Chief Financial Officer). Kirkorowicz,

who studied medicine in Heidelberg

and is the grandson-in-law of the company’s

founder, has led the firm through

highs and lows in recent decades, turning

it into an SME global player with the

construction of a Chinese works in Taicang

near Shanghai. With success: the

workforce has doubled, today’s sales of

more than 100 million euros are now

five times higher than in 1996, the year

he joined the company. “When I started

at Föhl I decided to expand the company

in such a way that it could rapidly

adapt to changing conditions,”

explains the former trauma surgeon

who gained the necessary know-how

for his current tasks at the respected St.

Galler Business School. In his opinion,

Föhl’s adaptability means, on the one

hand, a functioning corporate culture

under the motto ‘Creating value by appreciating

value’. “We see people holistically,

they must feel good and be able

to develop – then they can call up the

performance that we need,” according

to Kirkorowicz. A conviction that derives

from his medical past. On the other

hand, the father of three daughters

wants to maintain the company’s state-

32 Casting Plant & Technology 1 / 2018

---

of-the-art technology, building upon a

future-oriented innovation policy.

Focus on material and process

competence

Föhl is a Tier 2 automotive supplier and

produces, for example, plugs, ball sockets

for gas springs in cars, antennae components,

gear levers, and components

for belt restraints. Föhl also produces

components for the machine construction

and fittings sectors. The product

range – with about 1,100 different components

– is considerable. The weight of

the castings varies from a few grams to

about one-and-a-half kilograms. 90 %

of Föhl’s sales are now made with zinc

and 10 % with plastic. The batch size of

some components is an impressive 100

million units per year.

Kirkorowicz and the Föhl team skillfully

exploit their expertise in the two

material segments for the development

of hybrid components, e.g. zinc

antennae components recast in plastic.

Even though business with hybrid,

zinc and plastic components is

currently going well, the entrepreneur

is not resting on his laurels. Technological

changes such as Industry 4.0,

e-mobility and autonomous driving

push the company to develop further

The Mold Center in Rudersberg. The machine can mill and erode molds on the basis of

CAD data. Mechanical engineer Mirko Jordan (left) is one of eight designers at Föhl

innovations. Whereby Föhl is not developing

randomly, but is capitalizing

on its strengths: material and process

competences. Though the principle of

only developing resource-conserving

and energy-saving technologies also

applies.

Sprue-free casting

with hot runner technology

Hot-runner technology has attracted

considerable attention in the non-ferrous

metal sector: the parts are cast

with little or no sprue, as in a similar

process in injection molding. Where-

The Training Workshop: Föhl currently employs 37 trainees. With 430 employees in

Germany this represents almost 10 % of the workforce

A trainee practicing in the workshop

Casting Plant & Technology 1 / 2018 33

---

PRESSURE DIE CASTING

Ulrich Schwab (left), Dr. Frank Kirkowicz

and CP+T-Editor Robert Piterek (right)

during a works tour

High-tech hybrid component production in Haubersbronn. The casting is recast with

plastic and then closely inspected with the help of cameras and 3-D scanners

by several nozzles are used to inject the

liquid melt into the mold. This process

offers enormous advantages: little

or no sprue, less recycling material,

environmental benefits, less air in

the system and consequently higher-quality

castings, lower energy consumption,

and greater possibilities for

implementing complex geometries. In

economic terms, the increase in productivity

is a considerable advantage

because the lack of sprue creates space

in the mold so that more parts than

before can be poured with one shot.

This gave Kirkorowicz an idea: “This

also opens up the possibility of pouring

more parts in the same time on

existing machines,” he explains with

sweeping gestures, clearly enthusiastic.

Though he admits that the tools

for the process cost 30 - 40 % more.

Nevertheless, taken as a whole, the use

of the new technology could be good

for business – for which Kirkorowicz,

however, does not claim any exclusivity:

“The automotive industry wants

to purchase their products at competitive

prices. This is impossible if only

one supplier is using the technology.”

Fully automated tool

construction

Four of the five Föhl works are located

within ten kilometers of the company’s

Headquarters. Production continues

at Rudersberg itself, though space

Base for a car roof antenna: 1.2 million units are supplied every year

is limited. In addition, the Training

Workshop and the brand new Mold

Center (in which Föhl has invested

almost one million euros) are located

here. Casting tools for die-casting

plants are produced in the futuristic 6

x 6 m² temperature-controlled cell. A

robot uses a CAD data set to work on

the clamped molds with milling and

eroding tools, preparing them for the

manufacture of new products. 27-yearold

mechanical engineer Mirko Jordan

is one of eight designers at Föhl. He is

fascinated by the plant, which processes

graphite, steel and copper with an

accuracy of up to 3 μm. “I was lucky

because, straight after my training, I

got into CAM programming and I feel

really good here now,” says Jordan,

whose uncle also works at Föhl. The

plant, that measures and documents

every step with the help of a measuring

machine from Zeiss, is not just an important

step for Föhl in the direction

of Industry 4.0, but is also a motivation

for young people to start their careers

here. “Having in-house expertise

is crucial”, says Ulrich Schwab, “and

our young employees anyway want to

make the molds themselves”.

34 Casting Plant & Technology 1 / 2018

---

Perfect serial production: the zinc die-casting plants

in Michelau are arranged in several rows

The main entrance of the Föhl works in

Michelau: the railings on the bridge are

decorated with a variety of images, including

a galvanized dragon and a snake as a

symbol of molting and renewal

Training with social

responsibility

The Training Workshop run by Dierk

Göhringer is also located in Rudersberg.

37 trainees work here. Industrial

managers, industrial mechanics, electronics

engineers, process mechanics,

foundry mechanics (in pressure and

gravity die-casting), machine and plant

operators, tool mechanics, and specialists

in warehouse logistics are trained

here for their professional futures, as

well as several students who are doing

their Bachelor’s degrees at Föhl.

“The basic metal training is very similar

for all trainees during the first year

here. Then the trainees go to their various

specialist departments,” Göhringer

explains. Newcomers largely come

from Germany or have Turkish roots,

though recently a young man from Afghanistan

also started training as a machine

and plant operator. “We also had

an employee from Syria who was able

to communicate excellently after just

six months in Germany – we wanted

to keep him on, of course,” stresses Kirkorowicz,

who also feels a high level of

social responsibility towards refugees

and is committed to assisting their integration

in this way.

Connected plants for

large-scale production

Hot-chamber pressure die-casting

machines are used at the foundry in

Rudersberg, as at all the works. The

plants, with locking forces from 20

to 200 tonnes, all originate from machine

producer Oskar Frech, whose

works halls are only a few kilometers

from Föhl’s German works. There are

also highly productive plants in Rudersberg.

A socket, part of a car’s steering

wheel locking system, is being produced

in a fully automatic production

cell – a million of them are produced

every year. Three robots serve the entire

value-creation chain from cooling

and punching, through sprue melting,

to thread forming and blasting. “The

part used to go through three works

and is now finished within an area of

almost 60 m²,” explains Ulrich Schwab

proudly, and Kirkorowicz adds that,

“This is how the future of our foundry

must be, even for small batch numbers.”

This is because such highly automated

production is more economical

than any manual production, however

cheap it may be.

State-of-the-art high-tech is also to be

found in Haubersbronn, where the

plastic production is located. This is

also where the hybrid plant does its

work. Floor panels for several models

of Ford and the popular Mercedes

Sprinter are produced here in a refined

interplay of cameras, robots, 3-D scanners

and the injection molding machine.

The cycle time for four parts is

just 30 s, and 1.2 million floor panels

leave the works every year.

Transparency throughout

the process chain

The lion’s share of the 111 Föhl die-casting

plants worldwide, however, is located

in the Swabian caster’s newest German

die-casting works: the Michelau

Casting Plant & Technology 1 / 2018 35

---

Housings for Kärcher high-pressure cleaners are produced in this integrated casting cell

works that was opened in 1999, and

was visited by the then Federal Chancellor

Gerhard Schröder. The foundry

was constructed in response to a major

order from electronics producer

Philips for housing parts for CD players.

100 specially employed temporary

workers had to be discharged and 30 %

of sales were lost when the IT bubble

burst. “We needed ten years to get over

that crisis,” Kirkorowicz admits.

Business is now booming again in the

works – built on 250 piles for flood protection

and with oversized windows:

the familiar production noises engulf

the large and tidy production halls in

a busy soundscape. Production takes

place in two halls with several rows of

Frech die-casting machines. An automated

casting furnace moves around

between them, regularly filling the

machines with hot zinc melt at about

400 °C. The tool maintenance area is

accommodated in another hall where

the die-casting tools are, among other

things, cleaned in ultrasonic baths

and then dismantled. The great variety

of products is clearly visible in the production

halls: each machine spits out a

different casting and, at the back of the

hall, blasting units provide the necessary

processing. Hot-runner technology

is also already in use here, as is an

integrated production cell in which

the housings for Kärcher high-pressure

cleaners are produced. But capacity

has been exhausted 17 years after

construction of the Michelau foundry.

Expansion of the works is unavoidable.

Looking at the layout plan that has just

come out of the plotter, Ulrich Schwab

indicates the planned production enlargement:

the factory area will be doubled

in size. After the warehouse and

dispatch department has moved in,

more die-casting machines will probably

be installed in future – the expansion,

planned by Föhl personnel themselves,

should be completed by 2019.

Föhl has long been reliant on IT support

to ensure that high stocks do not

build up despite the many different products

and the millions of units – 5 million

per day worldwide. A new Enterprise Resource

Planning/Production Planning

System (ERP/PPS) recently started operation.

“If an excavator ripped up a cable

here, we would have to stop production

within three days because we would no

longer be able to maintain an overview,”

Kirkorowicz points out.

Green anti-corrosion coating

as an export hit?

The Asperglen logistics site accommodates

Föhl’s second large new development

with which the company intends

to establish itself worldwide: the

thin-film passivation or nano-coating

plant. This technology is revolutionary

because it can replace polluting metal-galvanizing

anti-corrosion coating

processes. Harmless silicon oxide dissolved

in liquid is used instead. “The

technology is sustainable; the recyclates

in the machine are vaporized

later. The rest can be sold to bioenergy

plants as cooling material,” explains

Kirkorowicz. Since mid-2017,

Föhl has used this ‘green technology’

for its own castings, such as rooftop antennae

components, to protect them

against corrosion. And in this case too,

Föhl plans to introduce the technology

on an open-market basis. Kirkorowicz

believes that there is enormous potential

for thin-wall passivation in China,

where environmental legislation is becoming

increasingly stringent – and is

also affecting galvanization there.

If one examines the growth figures of

the Föhl works in China (managed, by

the way, by Frank Kirkorowicz’s brother),

such a rollout does indeed appear

promising: the 15,000 m² works in

Tai cang with its 271 employees and

23 die-casting machines has achieved

fantastic growth figures for some years

now: growth rose to more than 30 % in

2017 from 8 % in 2015. Let the future

come – Föhl is prepared!

www.foehl.de

36 Casting Plant & Technology 1 / 2018

---

Demonstrate your expertise with professional reprints

Take advantage of the excellent reputation of CP+T

Casting, Plant and Technology International

Please contact us for further information

Gabriele Wald

Phone: +49 211 6707- 527

gabriele.wald@stahleisen.de

Giesserei-Verlag GmbH

Sohnstraße 65 · 40237 Düsseldorf, Germany · www.cpt-international.com

---

A central, optimized cell control creates the basis for productivity gains in die casting (Photos and graphics: Bühler)

Adrian Buob, Bühler AG, Uzwil

Cell management for greater success

Potential for optimization in die casting

Industry 4.0 – a buzzword currently on

the tip of everyone’s tongue. In some

branches of industry, the factories of

the future are already being tested; others

are more restrained. However, the

subject is being discussed all over – including

within the die-casting industry.

Die casting is in competition with

alternative manufacturing processes

and materials. In order to continue

manufacturing competitive die cast

parts, it is essential to keep working on

making the process more efficient. Cell

management plays an important role

in this regard, since there is still great

potential to be explored:

Having a central, optimized cell management

system makes it possible to

increase productivity in die casting

and to further develop the industry.

Networking is at the forefront of Industry

4.0: machines and products collect,

analyze and evaluate information,

while remaining in constant contact

with each other. This is also where the

exceptional potential for cell management

lies: the goal is that the die-casting

cell is ready for production quickly

after a standstill and that it optimizes

itself in the final expansion stage. This

results in sustained improvement of

uptime. After all, 47 % of the interruptions

in the production process are

currently caused by peripheral devices

(Figure 1). The problem generally lies

Figure 1: Nearly half of the interruptions of production during die casting are caused

by peripheral equipment. The data are subjected to an exemplary evaluation with the

help of the Bühler EventAnalyzer

in the inadequately developed communication

between the individual

subsystems. This is due to a lack of data

needed to inform the operator about

the cause and remedy for the problem.

A higher-level cell management system

would result in a clear improvement

at this point. However, further

development and setting of standards

are still required to create an intelligent,

self-optimizing cell.

Three steps towards an

intelligent die casting cell

For Bühler, Uzwil, Switzerland, the development

of the cell management system

is an important step towards die

casting foundries becoming part of Industry

4.0. The process of developing

an intelligent die casting cell can be divided

into three completed steps. They

build upon each other and can be continuously

expanded ().

The first step includes detecting and

correcting existing vulnerabilities within

the die-casting cell. A key criterion will

be the installation of a central head controller

– i.e. cell management. If an error

happens today, the operator has no other

choice than to walk around the cell

and find out where the problem lies. Frequently,

it becomes necessary to manual-

38 Casting Plant & Technology 1 / 2018

---

Bühler approaches the goal of intelligent production in three

development steps with a central cell control system

ly reset every single device within the cell

and to restart the process from the starting

position. The cell management system

relieves the operator by getting all of

the participating devices into home position

and automatically starting again.

This allows the operators to concentrate

on their primary duties.

In the second step, the goal is to attain

optimized production. The central

cell management system recognizes

deviating parameters and provides

tips for improving the process. In addition,

it can also suggest measures to be

taken to ensure that the die-casting cell

does not suddenly stop operating and a

proactive maintenance becomes possible.

A user-friendly visualization helps

the operator with the analysis of the

data and makes finding solutions easier.

Based on the interplay between the

machine, the operator and the process

experts, the die-casting process can be

more easily optimized, whereby the uptime

of the cell increases demonstrably.

The goal of the third step is to implement

intelligent production which

works fully-automatically and is able to

independently counteract errors and

loss of quality in a timely manner. This

is made possible by “Predictive Analytics”

which means that the control system,

based on algorithms, is able to

predict early on which parts have to

be serviced when. This knowledge allows

the control system to implement

targeted counter-measures. For example,

maintenance work is planned and

carried out at the ideal point in time.

Central control system acting

as the “brain of the cell”

“Currently we are working on executing

the first stage”, explained Laszlo

Jud, Head of Automation for Bühler

Die-Casting, Uzwil, Switzerland. During

the first step, the cell control system

is implemented and acts “as the

brain” of the die-casting cell, communicating

directly with the peripheral systems

such as the press and the marker

( Figure 3). It controls and monitors the

entire cell including all participants.

The cell control system is operated from

a central operating unit. The user interface

is web-based ensuring that it can

also be accessed from mobile terminals

through the network. Special attention

is paid to how user-friendly the system

is: instructions are clearly written, error

messages are precisely assigned to a

particular part of the machine and support

is provided for repairs. This ensures

that operating the machine is as easy as

possible. Furthermore, all relevant information

gained from the production

process is saved and the extensive tracing

of components is ensured.

Whenever the production process

is interrupted, the cell management

system provides additional significant

added value: for the first time, error

messages for all of the devices are bundled

centrally. The user not only receives

the information wherever there

is a problem, but also receives concrete

directions as to how to eliminate an error.

This ensures that the die-casting

cell is ready for operation faster after

a malfunction.

Ensuring traceability &

quality

Complete traceability is required particularly

for the automotive industry,

and is often associated with additional

costs. As a result of detailed production

data collection through cell management,

comprehensive documentation

is guaranteed for each manufactured

component.

Standardizing Interfaces

The successful implementation of a

cell management system also requires

standardization of interfaces and specification

of uniform data formatting

and transfer protocols. This is the only

way for components made by a wide

variety of manufacturers to work together

in a coordinated manner. The

interfaces that have been used up to

now can no longer meet current demands.

Just like many other companies,

Bühler relies on the IEC standard

that has been proven effective for communication

between machine control

systems and production management

systems (Figure 4).

Communication within the cell is

more challenging since a deterministic

signal exchange is absolutely essential.

Currently common interfaces

are Profinet and Ethernet/IP. However,

switching to a new communications

protocol takes time. “That is

why those of us participating in the

cell management project will be continuously

integrating all of the interfaces”,

explained Laszlo Jud. “We are

certainly convinced that the IEC standard

will soon have established itself as

the standard for communication within

the cell”.

Targeted data analysis at the

cell level as a factor for success

The tasks of analyzing data and interpreting

the processes must be performed

along the way of establishing a

cell management system. “We are currently

already able to record a great

Casting Plant & Technology 1 / 2018 39

---

INDUSTRY 4.0

amount of data from a die-casting machine.

However, expanding data collection

to all parts of the cell, how we interpret

these data, what conclusions we

draw from them and, finally, what measures

can be derived are all of great significance”,

explained Laszlo Jud. The information

gained has to be used in such

a way as to create the greatest possible

benefit for die casting foundries. One

possible use of the data is the predictive

maintenance of the cell that is made

possible by having reliable information

about the condition of the equipment.

This is a significant step on the way to a

digital future for die casting foundries:

errors that occur can be analyzed more

precisely and production can be optimized

accordingly. “Such a comprehensive

database combined with our experience

leads to highly promising results

for the benefit of our customers” according

to Mr. Jud. For one thing is clear: if

the production data are used correctly,

the uptime of a die casting cell will increase

significantly.

Cell management already

Already in 2018, the first cell control systems

from Bühler will be operating at

customers’ sites. “Starting with this first

step, we will be working together consistently

with our customers and partners

to continue developing and optimizing

the cell management system”, reports

Laszlo Jud. “In order for our customers

to benefit from cell management, we

all have to pull together.” Everything

is centered around the quality of the

manufactured parts, as well as around

productivity and uptime of the plant.

“This is where our years of experience

Figure 3: Die casting is currently hard at work creating a cell control system that monitors

and controls all of the machines and processes within a die-casting cell. It functions

as the “brain” of the cell

Figure 4: In cell management, the die-casting machine and the required peripheral devices

work together as equal partners and form a completed process step within the

entire value-added chain

with the die casting industry come into

play”, said Laszlo Jud with conviction.

www.buehlergroup.com

40 Casting Plant & Technology 1 / 2018

---

Casting Plant & Technology 1 / 2018 41

---

SIMULATION

Andreas Buswell, Wolfgang Schlüter, Matthias Henninger and Stefan Müller, University of Ansbach

Simulation of non-ferrous melting

and die-casting plants for energy

In order to stay competitive on the

world market a high level of automation

and energy efficiency is essential

for energy-intensive industries. The

impact of energy efficiency has increased

in Germany in particular as a

result of the energy transition and the

strengthening competition based on

globalization. In the non-ferrous melting

and die-casting industry for example

the energy consumption per ton of

good casting usually ranges between

2000 and 6000 kWh. Consequently,

the amount of energy costs generally

exceeds 25 % of gross value added.

Up to 60 % of this energy is needed

for the factory-internal melting process

of the aluminum, which usually

takes place in gas-fired secondary

aluminum melting furnaces. Thereby

problems are generally determined

by the lack of information on the production

fluctuations in the foundry

which are caused by the complex requirements

for liquid aluminum. Consequently

the furnaces are frequently

driven outside the ideal operating

range and energy is wasted. Obviously

the production process needs to be

optimized by appropriate intralogistic

control measures which lower the energy

consumption without impairing

productivity. Control strategies can be

evaluated with the help of a material

flow simulator which includes an ad-

Figure 1: Schematic structure of a melting and die-casting plant

Figure 2: Example of a melting furnace

with the four process stages

42 Casting Plant & Technology 1 / 2018

---

ditional function for the energy consumption

of the melting process.

Schematic structure of a melting

and die-casting plant

Constructing a simulation model requires

an understanding of the process

flow inside a typical melting and

die-casting plant (Figure 1). The delivery

of aluminum to the plant is carried

out in a liquid and a solid state. Whereas

the delivered liquid aluminum can

be processed directly, the solid aluminum

needs to be melted by using inhouse

melting furnaces. The melting

process is based on a 50 to 50 mixture

of solid aluminum shipments and recycled

process material, e.g. rejected

products or sprue material from the

die-casting process. Forklifts are used

for transporting liquid and solid aluminum

inside the plant.

Inside the die-casting machines the

liquid aluminum is pressed into the

desired shapes (products). Since the

die-casting machines act as the only

sinks for liquid aluminum, they determine

the demand for melted material

(pull system). The amount of produced

parts and the consumption of liquid

aluminum depend on the cycle time

as well as the shot weight of the current

product. Due to production fluctuations

and complex thermodynamic

processes within the melting furnaces,

it is almost impossible for the operation

manager in charge to optimize

the in-house melting process. Consequently,

the furnaces are usually operated

in a very unsteady way and this

leads to great fluctuations in the filling

levels. As a result the number of heating

and cooling processes increases.

These factors have a negative impact

on the specific energy consumption

(kWh/t) of the furnaces and therefore

the economic efficiency of the overall

process.

The process within the previously

examined melting furnaces can be divided

into four basic stages (Figure 2).

The solid aluminum is delivered to the

melting shaft by the charging system

(stage 1). Inside the shaft the aluminum

is heated up and melted by natural

gas-powered burners (stage 2).

Thereby hot flue gas is produced which

Figure 3:

Figure 4: Flue gas temperatures inside the melting furnace

flows around the aluminum and passes

on its own heat energy to the material.

The efficiency of the process

is determined by the amount of absorbed

heat energy of the aluminum.

The flue gas and the molten aluminum

leave the melting shaft and reach the

furnace’s holding area (furnace tub)

where the liquid metal is kept at a specified

temperature with the help of additional

burners (stage 3). In order to

withdraw molten aluminum at the discharge

socket, the whole furnace is tilted

to enable the material to flow into

the forklift’s container (stage 4).

Process analysis

An energy efficient functioning of

a melting furnace requires a steady

mode of operation at a high filling level

of the melting shaft. However, measurements

in reference plants have

shown that the filling levels inside

melting shafts are usually significantly

lower than the shaft’s maximum capacity

(Figure 3).

Low aluminum filling levels inside

the shaft reduce the heat exchange

which depends on the surface area as

well as the driving temperature gradient.

As a result, the thermodynamic

efficiency decreases whereas the furnace’s

specific energy consumption increases.

Therefore, a fluctuating operation

mode causes a negative effect on

the furnace’s performance. For example,

the specific energy consumption

of the examined furnace exceeds the

nominal value of the furnace manufacturer’s

specifications by 25 %. Additionally,

the measured melting rate of

3.68 t/h only reaches the lower end

of the specifications (3.5 – 4.5 t/h). Depending

on the operating point, the

thermodynamic efficiency ranges between

25 and 50 %.

Casting Plant & Technology 1 / 2018 43

---

SIMULATION

The flue gas’ outlet temperature is a

suitable parameter for rating the furnace’s

energy efficiency, since it represents

the result of the combined heat

transfer processes inside the furnace.

As a general rule, a higher efficiency is

obtained at a lower flue gas temperature.

Figure 4 depicts the chronological

course of flue gas temperatures at

the melting shaft’s exit (position A in

figure 2) as well as the furnace’s outlet

(position B).

The effect of the fluctuating filling

level on the flue gas temperature can

be seen at measurement position A.

Charging procedures lead to significant

drops of the measured temperature,

which are then followed by a steady

increase. However, the temperature of

the flue gas at the furnace’s outlet (position

B) which ranges between 850 °C

and 1,000 °C shows a more consistent

trend. Furthermore this illustrates that

the flue gas still contains a lot of heat

energy when leaving the furnace.

a

b

Figure 5:perature

inside the melting shaft

Figure 6: Aluminum mass inside a melting shaft with optimized charging strategy

Simulation model

In order to analyze different process

parameters, such as the die casting machine’s

demand for aluminum and its

effect on the melting furnaces, a simulation

model following the depiction

in figure 1 has been created. The

simulation is qualified for developing

new strategies for the in-plant aluminum

distribution or suitable operation

modes for the die-casting machines

and furnaces. Furthermore the simulation

tool offers the derivation of suitable

reactions for different problems,

such as an unexpected breakdown of a

melting furnace or delays in the delivery

of external melted aluminum. The

simulation allows in a risk-free and

cost-efficient virtual environment to

analyze procedures which would otherwise

have major impact on the operation,

e.g. the changing of charging

intervals of the melting furnaces or the

preheating of the raw materials.

The simulation consists of a material

flow model and an energy model,

representing the thermodynamic processes

inside the furnaces. The material

flow section comprises the transport

and processing of aluminum (see figure

1). In addition to the various components,

such as die-casting machines,

furnaces and forklifts, the model also

includes the control measures for the

entire process. In this context strategies

for distribution of liquid aluminum

to the die-casting machines as

well as the order of charging the melting

furnaces with solid material are implemented.

The link between the material flow

model and the energy model of the

furnace is realized by the processes af-

44 Casting Plant & Technology 1 / 2018

---

fecting the furnace, namely charging

and withdrawal of aluminum. The energy

model includes the combustion

of natural gas inside the burners, the

heat and mass transfer processes (conduction,

convection, radiation) and

the phase transition of aluminum.

The model allows analyzing different

demand situations and charging strategies

and their impact on the thermodynamic

processes. A precise calculation

would require flow simulations of

the furnace’s interior using a CFD tool.

However, this approach would lead to

extremely complex models and would

demand huge computational power,

especially for extended time periods.

Additionally, CFD simulations provide

low flexibility considering changing

boundary conditions. Therefore,

the developed simulation is based on

a simplified mathematical model consisting

of several ordinary differential

equations. The current model has been

refined by analyzing CFD simulations

of various steady cases. Because of the

conducted drastic simplifications the

validation of the model by using measured

data is crucial for the development

of a reliable simulation.

Validation

The results of the simulation can be

validated using a model that is specifically

configured to represent the

real-life plant. Parameters include the

implemented charging strategy for the

melting furnaces and the productions

schedule of the die-casting machines.

The validation data is based on measurements

inside the plant conducted

over the time period of a standard

working week which includes 17 shifts.

In terms of the analyzed week, the material

flow model shows a deviation of

1.4 % concerning the amount of produced

proper aluminum parts and a

deviation of 0.9 % regarding the overall

mass of aluminum used inside the

plant. These divergences can mainly be

traced back to unexpected breakdowns

of die-casting machines, which can be

statistically approximated, but not precisely

predicted. The accuracy of the

energy model can be proved by comparing

the chronological course of simulated

and measured data (Figure 5).

Figure 7: CFD simulation of the preheating of an aluminum package in a chamber

The charts show a high compliance

between the simulated and the measured

data within the analyzed time

frame. The flue gas temperature represents

an overall result of the thermodynamic

processes inside the furnaces.

The comparison of the simulated

and measured data of this parameter

shows the reliability of the simulation.

The remaining deviations might arise

from incomplete approximation of the

control algorithm governing the furnace’s

burners. During the simulated

week, the mass of melted aluminum

and the gas consumption deviated by

1.5 % respectively 0.5 % from the measured

data.

measures

The validation results illustrate that

the simulation model allows a precise

representation of the actual plant.

Based on the real-life configuration

various operational parameters can be

modified within the simulation model,

which determines the resulting effects

on the material flow and the thermodynamic

processes. The different

scenarios can be evaluated regarding

the key figures representing productivity,

production reliability and energy

efficiency. In the following, two measures

will be analyzed:

» Optimized aluminum charging

» Preheating of solid aluminum

(300 °C)

Optimized aluminum charging

Establishing a continuous operation of

the melting furnace at a constant high

aluminum filling level inside the melting

shaft is the aim of an optimized

charging strategy. Then the burners

are able to operate at their nominal

power which reduces the specific energy

consumption while maintaining a

high quality of the melted aluminum.

An adjusted charging strategy ensures

a filling level of 60 – 90 % of the melting

shaft’s capacity (Figure 6).

The high filling level leads to a large

heat transfer surface which enhances

the heat exchange and lowers the flue

Casting Plant & Technology 1 / 2018 45

---

SIMULATION

gas temperature at the shaft’s exit. In

combination with a constant burner

operation, these effects lead to an improvement

of the melting rate and the

specific energy consumption.

Preheating

The preheating of the solid material

inside heating chambers is a common

measure in industrial plants. The flue

gas’ waste heat is used to heat up the

air inside a chamber where raw aluminum

is stored.

Using CFD simulations the preheating

process inside the chamber can be

analyzed (Figure 7). The influence of

the inflow speed, the flue gas temperature

and the package geometry on the

required preheating time is displayed.

The CFD simulations demonstrate that

the warm-up period inside the chamber

can be reduced up to 22 % by improving

the arrangement of the mass package.

The integration of a preheating

chamber into the process sequence, in

particular during the charging of the

melting furnaces, is a problem not to

be underestimated.

However, the required time and the

energy consumption to melt the preheated

solid materials in the furnaces

decrease as a result of the preheating.

Figure 8:

Simulation results

The measurements inside the reference

plant reveal planned and unexpected

downtimes of 30 % of the die-casting

machines’ overall runtime. Under these

circumstances, the plant’s productivity

is solely limited by the die-casting machines.

Thus, the demand for aluminum

is constantly surpassed by the available

supply. In order to be able to analyze

the effects of the optimized aluminum

charging and the preheating of solid material,

downtimes have been reduced to

3 % in the simulation. This could be realized

by an improved maintenance concept

in the real plant. As a result, the supply

and demand for melted aluminum

are almost equally balanced.

The die-casting machines’ Overall

Equipment Effectiveness (OEE) is a suitable

key figure to describe a plant’s productivity.

On the other hand, downtimes

due to a lack of melted aluminum

Figure 9:

energy consumption

have impacts on the plant’s production

reliability.

Preheating of the solid aluminum

as well as an optimized charging strategy

increases the production reliability

(Figure 8). While the accumulated

downtimes due to aluminum shortage

initially make up 1.7 % of the analyzed

timeframe, they decrease to 0.3 % by

preheating, respectively 0 % due to an

optimized charging strategy. Additionally,

reducing these downtimes leads to

noticeable improvements of the plant’s

productivity. Optimized charging in

particular delivers OEE-values of over

90 %. Both measures do not only stabilize

the production, they also enable a

more energy efficient operation mode

of the melting furnaces (Figure 9).

Both measures show a positive effect

on the energy consumption.

While the energy consumption in

the initial configuration averages 910

kWh/t, preheating leads to a decrease

of 9 % (specific energy consumption:

825 kWh/t). The optimized charging

strategy even exceeds this improvement,

up to 20 % (specific energy consumption:

720 kWh/t).

The results illustrate that the previously

described measures are able to

optimize the plant’s operation itself,

as well as its energy efficiency. The improvements

in a real-life plant are likely

to be lowered by company standards

or thermal losses. However, the simulation

indicates that a purely intralogistical

measure (optimized charging)

46 Casting Plant & Technology 1 / 2018

---

can help to enhance productivity, production

reliability and energy efficiency

more effectively than any measures

taken at a cost-intensive preheating

chamber.

The described measures only reach

their full potential when combined

with a drastic reduction of die-casting

machine downtimes (3 %) or other

means of preventing an oversupply of

melted aluminum. This could include

reducing the amount of melted aluminum

deliveries or setting an furnace on

stand-by. Simulation results show that

the specific energy consumption can

be lowered by 10 % (reduced delivery)

respectively 12 % (furnace on standby)

without impairing production reliability.

Next steps

In the next phase of the project the previous

investigations will be carried out

within a further partner company. Subsequently,

the simulation model will

be adapted to this operation. Comparing

both simulations will enable to

determine the factors which have the

greatest influence on the simulated operating

sequence and the parameters

which can be neglected in the future.

The aim here is to realize a flexible simulation,

which can provide meaningful

results for a wide range of companies.

The provision of up-to-date process

data and key figures is a major challenge

in representing real operations

within a simulation. The state of automation

within the die casting industry

is still at a very low level compared

to other branches of industry, for example

the automotive industry. Therefore,

the acquisition and processing of

the relevant parameters are important

components in the project’s next

phase. However, the current results

have already proved that a step-by-step

introduction of Industry 4.0 measures

can contribute to an increase in productivity

in the melting and die casting

industries.

References:

www.cpt-international.com

Casting Plant & Technology 1 / 2018 47

---

COMPANY

Customer proximity was essential for Imerys during the acquisition of IKO, as shown at the Imerys’ GIFA booth (Photo: Imerys)

Michael Vehreschild, Kleve

Imerys – strong potential for synergies

The IKO brand, representing the green molding sand additives producer based in Germany, was

well known throughout the foundry industry. However, three years ago, IKO became “Imerys

Metalcasting Solutions”. The French group of companies Imerys, a world leader in mineralbased

specialty solutions for industry, acquired the Greek S&B Industrial Minerals S.A. in 2015

“The fast brand change was initially a

challenge, but quickly became a success,”

emphasizes Didier Legrand, the

Technical & Commercial Director for

Foundry Europe of Imerys Metalcasting.

A major benefit of the acquisition is

“the strong potential for synergies and

new investments”.

Some things have changed and, above

all, improved – which is instantly noticeable

upon entering the former IKO

plant in Marl, Germany. While walking

over the company area, red flags indicate

the loading of a truck. Securely

fixed storage shelves and the employees’

bright helmets should contribute to the

prevention of accidents. Furthermore, a

well-marked assembly point for emergencies

at the entrance sends immediately

a clear signal to the visitor: Safety

is very important here. This does not

mean that safety had not been of great

value before the acquisition. However,

the French company has “gone one step

further and transferred its corporate

safety concept to IKO/ S&B,” explains

Dr. Oleg Podobed, Application Technology

Manager – Foundry Germany.

IKO/S&B and Imerys complement

each other

However, safety is not the only subject

for added value. Another positive

effect of the acquisition is the greater

variety of potential solutions, because

“IKO/ S&B and Imerys complement

each other,” emphasizes Didier Legrand.

This is beneficial because, in addition

to the best possible performance

of Imerys’ products, “foundries must

speed up production and reduce costs,

while castings become increasingly

complex.” Customized blends of green

48 Casting Plant & Technology 1 / 2018

---

Imerys Metalcasting – a company with a long tradition

S&B Industrial Minerals was founded in 1934 and has a long tradition as a

supplier of foundry bentonites, using minerals from the renowned reserves

on the Greek island of Milos as well as from other mines worldwide. The

origin of IKO Industriekohle dates back to 1964. IKO Industriekohle and

Erbslöh Geisenheim merged in 1994 – S&B bought 50 % of the new company

with plants in Germany and France. S&B also acquired the remaining

50 % of IKO in 2001 and moved closer to the foundry customers in Europe,

supplying them with bentonites, lustrous carbon formers and other

selected raw materials, as well as customized technical services. The foundry

business expanded first into the Americas, Turkey and then to China,

India and Italy, by incorporating the expertise, technology and assets of

local foundry suppliers.

S&B/IKO has been part of Imerys, one of the world’s leading supplier of

mineral-based specialty solutions for industry, since 2015. Imerys, founded

in 1880, looks back at a long, successful and sustained history. The French

company, with headquarters in Paris, has about 18,500 employees worldwide

and generated more than 4 billion euros in sales in 2016. Imerys meets

ambitious criteria for responsible development, regarding social, environmental

or Corporate Governance.

Imerys Metallurgy Division, which emerged from S&B, encompasses the

world’s leading bentonite, perlite, bauxite and moler businesses with its

own high-quality deposits. Besides there is the Steel Casting Fluxes business

unit, serving continuous steel casting production. The Metallurgy Division

is mainly focussed on the foundry industry and its business segments. The

former IKO has been renamed into Imerys Metalcasting.

Imerys Metalcasting offers customized blends of green molding sand

additives as well as the technical expertise to the foundry industry. Having

a global focus, the company also serves international customer groups

through the extensive network of 14 metalcasting sites in Europe, North

America and Asia, according to the slogan: Think Global, Act Local. The

main customer group are foundries with automated molding plants. Another

application area for the Imerys products is the core shop using the

cold box process, where Imerys provides core sand additives, which are

needed to avoid veining and other core sand related casting defects.

Dr. Oleg Podobed, Application Technology

Manager – Foundry Germany. Safety plays

concept (Photo: MV)

molding sand additives based on bentonites,

lustrous carbon formers and

other selected high-quality raw materials

from Imerys Metalcasting contribute

to meet these challenges. Through

the combination with Imerys, S&B

gained access to the Imerys world of

minerals. S&B, which hold previously

only five industrial minerals, has over

30 Imerys industrial minerals at its disposal

now. “We use the larger portfolio

for the development of new, high-performing

products and blends,” explains

Didier Legrand. This is a boost

for further innovations. In 2016 more

than 90 new products were launched

within the Imerys Group worldwide,

whereas 110 new products have been

developed in 2017.

Supply reliability is ensured

Imerys Metalcasting benefits now

from a much larger network, because

the group is present on five continents

with 270 industrial facilities in more

than 50 countries. These include 14

production sites worldwide operating

for foundries in Europe, North America

and Asia. “This allows us today to

provide the right products at relatively

short notice. Furthermore, the delivery

security is increased,” according

to Didier Legrand. “In addition, market

fluctuations can be better absorbed because

we have our own mines.”

Focus on innovation

The trend towards weight reduction

in modern castings and increasing en-

Marl (Photo: Imerys)

Casting Plant & Technology 1 / 2018 49

---

COMPANY

Bentonite deposit on Milos (Photo: Imerys)

Milling installation (above) and modern

equipment in the laboratory (right) at

the Imerys plant in Marl (Photo: Imerys)
