Table of Contents<br />
1. Profiles<br />
1. Double Insulated Profile..............................................................................4<br />
1. Double Insulated ...............................................................................................5<br />
2. Windows & Grills...................................................................................................6<br />
3. Accessories.............................................................................................................8<br />
4. Color Palette.........................................................................................................12<br />
2. Single Steel Sheet Profile..........................................................................14<br />
1. B113 - Pastore- Steel.............................................................................................15<br />
2. B113 - Pastore Curved- Steel.........................................................................16<br />
3. B71 - Antitebesta 71 - Steel............................................................................17<br />
4. B95 - Antitebesta 95- Steel..................................................................................18<br />
5. B95 - Antitebesta 95- Aluminum......................................................................18<br />
6. Windows & Grills................................................................................................20<br />
7. Accessories...........................................................................................................22<br />
8. Color Palette.........................................................................................................26<br />
3. Double Steel Sheet Profile........................................................................28<br />
1. Double Steel Sheet .........................................................................................29<br />
2. Accessories...........................................................................................................<strong>30</strong><br />
3. Color Palette.......................................................................................................34<br />
2. Guides<br />
1. Guide “Omega” with Lip............................................................................36<br />
2. Guide “Omega”...........................................................................................37<br />
3. Guide “Omega”...........................................................................................38<br />
4. Side Support..............................................................................................39<br />
5. Side Mount.................................................................................................40<br />
6. Accessories.................................................................................................42<br />
7. Color Palette...............................................................................................44<br />
3. Shaft<br />
1. Shafts..........................................................................................................46<br />
2. Shaft end & Pivot.......................................................................................47<br />
4. & <br />
1. Front Frame................................................................................................48<br />
2. Two Side Box..............................................................................................49<br />
3. Three Side Box...........................................................................................50<br />
3
1.1. Double<br />
Insulated Profile<br />
» Special design<br />
for wide range of<br />
applications<br />
unique in the<br />
European market.<br />
» Silent Operation.<br />
» Made from one piece metal<br />
sheet.<br />
» <br />
» Excellent resistance to<br />
adverse conditions without<br />
additional expensive<br />
equipment.<br />
» High-performance of heat<br />
and sound insulation.<br />
» Unique quality due to<br />
powder coating, which<br />
confers high resistance in<br />
use.<br />
» Wide range of colors at the<br />
same price.<br />
» Ability to accomodate<br />
windows and ventilation<br />
grills.
CB1 - Double - Steel<br />
CB2 - Double - Aluminum<br />
1. Double Profile with Insulation - Specifications<br />
Profile<br />
Height/ Step - mm<br />
Pcs /m<br />
Thickness - mm<br />
Weight kg/m<br />
Maximum Production<br />
Length - Galvanized<br />
Maximum Production<br />
Length - Powder Coated 1<br />
Windload<br />
Safe Operation<br />
Operating Forces<br />
Min. Shaft Diameter<br />
Windows/ Ventilation Grills<br />
Polyurethane Density<br />
Sound Reduction 2<br />
Thermal Transmittance 3 CB1 - Steel<br />
1<strong>05</strong>/91<br />
11<br />
0,4<br />
1,<strong>05</strong><br />
12m<br />
12m<br />
<br />
<br />
<br />
Φ159<br />
~4pcs/ lm<br />
57kg/m 3 (±2kg/m 3 )<br />
R~21dB<br />
Up [W/(m 2 K)] 4,46<br />
CB2 - Aluminum<br />
1<strong>05</strong>/91<br />
11<br />
0,4<br />
0,45<br />
-<br />
m<br />
W:6000xH:6000 - Class 3<br />
<br />
<br />
Φ139<br />
~4pcs/ lm<br />
57kg/m 3 (±2kg/m 3 )<br />
R~21dB<br />
Up [W/(m 2 K)] 4,46<br />
<br />
1<br />
Color palette available after request<br />
2<br />
EN 717-1<br />
3<br />
EN 10077-2:2012<br />
5<br />
Certification according to :<br />
EN 13241-1:2003+A:201<br />
* Actual colors may differ
Windows<br />
& Grills<br />
Windows<br />
Double PLEXI GLASS<br />
(1<strong>30</strong>x60mm) windows option,<br />
for natural lighting.<br />
Weight: 0,049 kg/set<br />
Art. Code: W1<strong>30</strong>60<br />
Sealing Flange<br />
Sealing flange for double windows<br />
and ventilation grills<br />
Weight: 0,011 kg/pc<br />
Art. Code: F12<strong>05</strong>0<br />
Ventilation<br />
Grills<br />
Ventilation grills from double<br />
PLEXI GLASS (134x64mm)<br />
option, for natural ventilation.<br />
Weight: 0,042 kg/set<br />
Art. Code: VG1346
Aluminum Extrusion<br />
Profile<br />
Aluminium profile (for window<br />
placement)<br />
Weight: 1,0 Kg/m<br />
Length: 5,0 -5,5-6,0-6,5-7,0-10m<br />
(Natural, White, or Powder Coated))<br />
Art. Code: 4<strong>05</strong>02<br />
Windows<br />
PLEXI GLASS (150x60mm)<br />
windows on aluminum extrusion<br />
profile(4<strong>05</strong>02) option, for<br />
natural lighting.<br />
Weight: 0,024 kg/pc<br />
Art. Code: W15060<br />
Windows<br />
PLEXI GLASS ( 600x64mm) windows<br />
on aluminum extrusion<br />
profile(4<strong>05</strong>02) option, when<br />
additional natural lighting is<br />
required.<br />
Weight: 0,113 kg/pc<br />
Art. Code: W<br />
64<br />
600<br />
Perforated Grills<br />
Pefrorated Grills option. Metal<br />
plates with 3mm holes for natural<br />
ventilation, placed on an aluminum<br />
extrusion profile(4<strong>05</strong>02)<br />
Art. Code: <br />
7<br />
* Special product<br />
please contact us for construction
Plastic slide<br />
blockers for hooks<br />
Accessories<br />
Plastic slide blockers<br />
that are placed in both<br />
ends of every double<br />
profile of the shutter.<br />
Weight: 0,0<strong>30</strong>kg/pc<br />
* necessary when hooks<br />
are placed on the shutter<br />
Art. Code: TL12DH<br />
Plastic slide<br />
blocker<br />
Plastic slide blockers<br />
that are placed on both<br />
sides on every each<br />
other double profile of<br />
the shutter.<br />
Weight: 0,015kg/pc<br />
Art. Code: TL12D<br />
Plastic slide<br />
blockers for<br />
Aluminum<br />
extrusion profile<br />
Plastic slide blockers<br />
that are placed in both<br />
ends of every aluminum<br />
extrusion profile.<br />
Weight: 0,008 kg/pc<br />
Art. Code: TL12AL
Cover for<br />
Strut “V”<br />
Cover for strut “V” 1<strong>05</strong><br />
Weight: 0,016 kg/pc<br />
Art. Code: PC1<strong>05</strong><br />
Metal Strut “V”<br />
Metal strut from galvanized<br />
steel.<br />
Height: 1<strong>05</strong>mm<br />
Dimensions: 1<strong>05</strong>x1<strong>05</strong>x1mm<br />
Weight: 2kg/m<br />
Art. Code: V1<strong>05</strong><br />
“U” Profile<br />
Weight: 0,54kg/m<br />
Dimensions: 15x15x1,5mm<br />
Art. Code: BU15<br />
Bottom<br />
Aluminum<br />
Profile<br />
Bottom aluminum<br />
extrusion profile:<br />
- Up to 10m lengthnatural<br />
- Up to 9m lengthpowder<br />
coatedWeight:<br />
1,17kg/m Natural<br />
1,2kg/m PowdeCoated<br />
9<br />
Art. Code: 4<strong>05</strong>03
Support for big<br />
window<br />
It is placed in both sides<br />
of plexiglass big window<br />
Weight: 0,019 Kg/pc<br />
Art. Code: W50064S<br />
End Rubber<br />
(Standard)<br />
Bottom rubber<br />
Weight: 0,45 Kg/m<br />
Art. Code: TR376<br />
End Rubber<br />
for optosensor<br />
Bottom rubber for<br />
optosensor.<br />
Weight: 0,40kg/m<br />
Art. Code: TR400
Suspension<br />
Clip<br />
Suspension clip for<br />
winding shaft.<br />
Weight: 0,113 kg/pc<br />
Art. Code : SC<br />
Aluminum<br />
Hooks<br />
a) 26mm for the double<br />
profiles<br />
b) 55m for the bottom<br />
aluminum profile<br />
Weight: 0,08 kg/pc<br />
0,17kg/pc<br />
Art. Code a: 4<strong>05</strong><strong>05</strong>N<br />
b: 4<strong>05</strong><strong>05</strong>NB<br />
Plastic Slide for<br />
Alu hook 4<strong>05</strong><strong>05</strong><br />
Art. Code: PSH<br />
Inv. Code: 24.800.13.00139<br />
Aluminum Hook<br />
One Side 26mm<br />
Weight: 0,<strong>05</strong> kg/pc<br />
Art. Code: 4<strong>05</strong>19N<br />
Inv. Code: 24.700.70.00644<br />
Plastic End for Double<br />
Insulated Profile with<br />
Slide of Hook 4<strong>05</strong>19N<br />
Weight: 0,043 kg/pc<br />
Art. Code: TL12DH1<br />
Inv. Code: 24.800.13.00145<br />
11
Powder Coated<br />
Color Palette<br />
RAL - 1013 RAL - <strong>30</strong>00 RAL - 5010<br />
RAL - 60<strong>05</strong> RAL - 7015<br />
RAL - 8014<br />
RAL - 8017<br />
RAL - 9002 RAL - 9006<br />
RAL - 9007<br />
RAL - 9016<br />
Galvanized steel<br />
coated<br />
Transparent<br />
Prepainted<br />
RAL - 9002<br />
RAL - 9006<br />
RAL - 9016<br />
* Color palette is for reference only.<br />
Actual colors may differ.<br />
** More colors available on request
Plastificated in RAL tints<br />
RAL - 1013 RAL - <strong>30</strong>00 RAL - 5010<br />
RAL - 60<strong>05</strong> RAL - 7001<br />
RAL - 7015<br />
RAL - 8017 RAL - 9002 RAL - 9016<br />
Golden<br />
oak<br />
Dark<br />
oak<br />
*** Plastificated colors -except<br />
wood imitations- are delivered<br />
only on request and have a waiting<br />
period of one month.<br />
Galvanized Steel<br />
<br />
<br />
13
1.2. Single<br />
Profiles<br />
» Steel sheet profiles,<br />
hot galvanized.<br />
» Galvanized <br />
» Variety of designs<br />
» Wide range of RAL<br />
colors
B113 - Pastore - Steel<br />
1. B113 Pastore, Steel - Specifications<br />
Profile<br />
Blind<br />
Height/ Step - mm<br />
Pcs /m<br />
Thickness - mm<br />
Weight kg/m<br />
Maximum Production<br />
Length - Galvanized<br />
Maximum Production<br />
Length - Powder Coated 1<br />
Windload<br />
Safe Operation<br />
Operating Forces<br />
Min. Shaft Diameter<br />
Windows/ Ventilation Grills*<br />
128,5/113<br />
8,85<br />
0,8/1,0/1,2<br />
1,15/1,43/1,72<br />
12m<br />
9m<br />
W:10000x - Class <br />
<br />
<br />
Φ159<br />
5pcs/lm<br />
Perforated<br />
128,5/113<br />
8,85<br />
0,8/1,0<br />
0,99/1,22<br />
12m<br />
9m<br />
W:10000x - Class <br />
<br />
<br />
Φ159<br />
5pcs/lm<br />
113<br />
<br />
* Combined with B113 curved profile<br />
Color palette available after request<br />
155<br />
Certification according to :<br />
EN 13241-1:2003+A:201
B113 Curved - Steel<br />
2. B113 Curved, Steel - Specifications<br />
Profile<br />
Blind<br />
Height/ Step - mm<br />
Pcs /m<br />
Thickness - mm<br />
Weight kg/m<br />
Maximum Production<br />
Length - Galvanized<br />
Maximum Production<br />
Length - Powder Coated 1<br />
128,5/113<br />
8,85<br />
0,8/1,0/1,2<br />
1,15/1,43/1,72<br />
12m<br />
9m<br />
Perforated<br />
128,5/113<br />
8,85<br />
0,8/1,0<br />
0,99/1,22<br />
12m<br />
9m<br />
Windload<br />
Safe Operation<br />
Operating Forces<br />
Min. Shaft Diameter<br />
Windows/ Ventilation Grills<br />
W:10000x - Class<br />
<br />
<br />
Φ159<br />
5pcs/lm<br />
W:10000x - Class <br />
<br />
<br />
Φ159<br />
5pcs/lm<br />
<br />
Color palette available after request<br />
Certification according to :<br />
EN 13241-1:2003+A:201
B71- Antitebesta - Steel<br />
3. B71 Antitebesta, Steel - Specifications<br />
Profile<br />
Blind<br />
Height/ Step - mm<br />
Pcs /m<br />
Thickness - mm<br />
Weight kg/m<br />
Maximum Production<br />
Length - Galvanized<br />
Maximum Production<br />
Length - Powder Coated 1<br />
82,5/71<br />
14,08<br />
0,8/1,0/1,2<br />
0,85/1,06/1,28<br />
12m<br />
9m<br />
Perforated<br />
82,5/71<br />
14,08<br />
0,8/1,0<br />
0,67/0,83<br />
12m<br />
9m<br />
Windload<br />
Safe Operation<br />
Operating Forces<br />
Min. Shaft Diameter<br />
Windows/ Ventilation Grills*<br />
W:10000x - Class<br />
<br />
<br />
Φ159<br />
5pcs/lm<br />
W:10000x - Class <br />
<br />
<br />
Φ159<br />
5pcs/lm<br />
<br />
Combined with B113 curved profile<br />
Color palette available after request<br />
17<br />
Certification according to :<br />
EN 13241-1:2003+A:201
B95 - Antintebesta - Steel<br />
4. B95 Antintebesta, Steel - Specifications<br />
Profile<br />
Blind<br />
Height/ Step - mm<br />
Pcs /m<br />
Thickness - mm<br />
Weight kg/m<br />
Maximum Production<br />
Length - Galvanized<br />
Maximum Production<br />
Length - Powder Coated 1<br />
Windload<br />
Safe Operation<br />
Operating Forces<br />
Min. Shaft Diameter<br />
Windows/ Ventilation Grills*<br />
104/95<br />
10,52<br />
0,8/1,0/1,2<br />
0,98/1,23/1,48<br />
12m<br />
9m<br />
W:10000x Class <br />
<br />
<br />
<br />
Φ159<br />
5pcs/lm<br />
<br />
Perforated<br />
104/95<br />
10,52<br />
0,8/1,0<br />
0,76/0,94<br />
12m<br />
9m<br />
W:10000x - Class <br />
<br />
<br />
<br />
Φ159<br />
5pcs/lm<br />
<br />
<br />
* Combined with B113 curved profile<br />
Color palette available after request<br />
Certification according to :<br />
EN 13241-1:2003+A:201
B95 - Antintebesta - Aluminum<br />
5. B95 Antintebesta, Aluminum - Specifications<br />
Profile<br />
Blind<br />
Height/ Step - mm<br />
Pcs /m<br />
Thickness - mm<br />
Weight kg/m<br />
Maximum Production<br />
Length - Galvanized<br />
Maximum Production<br />
Length - Powder Coated 1<br />
104/95<br />
10,52<br />
1,0<br />
0,4<strong>05</strong><br />
12m<br />
9m<br />
Perforated<br />
104/95<br />
10,52<br />
1,0<br />
0,360<br />
12m<br />
9m<br />
Windload<br />
Safe Operation<br />
Operating Forces<br />
Min. Shaft Diameter<br />
Windows/ Ventilation Grills*<br />
W:0x Class 4<br />
<br />
<br />
Φ159<br />
5pcs/lm<br />
W:0x Class 4<br />
<br />
<br />
Φ159<br />
5pcs/lm<br />
<br />
Combined with B113 curved profile<br />
Color palette available after request<br />
Certification according to :<br />
EN 13241-1:2003+A:201<br />
19
Windows<br />
& Grills<br />
Windows<br />
PLEXI GLASS (128x56mm) windows,<br />
for natural lighting.<br />
They are placed only on B113<br />
Curved profile which in turn can<br />
be combined with any of the<br />
rest profiles.<br />
Weight: 0,016 kg/pc<br />
Art. Code: W12856<br />
Support for big<br />
window<br />
It is placed in both sides<br />
of plexiglass big<br />
window(600x64)<br />
Weight: 0,019 Kg/pc<br />
Art. Code: W50064S
Aluminum Extrusion<br />
Profile<br />
Aluminium profile (for window<br />
placement)<br />
Weight: 1,0 Kg/m<br />
Length: 5,0 -5,5-6,0-6,5-7,0-10m<br />
(Natural, White, or Powder Coated)<br />
Art. Code: 4<strong>05</strong>02<br />
Windows<br />
PLEXI GLASS (150x60mm)<br />
windows on aluminum extrusion<br />
profile(4<strong>05</strong>02) option, for<br />
natural lighting.<br />
Weight: 0,024kg/pc<br />
Art. Code: W15060<br />
Windows<br />
PLEXI GLASS ( 600x64mm) windows<br />
on aluminum extrusion<br />
profile(4<strong>05</strong>02) option, when<br />
additional natural lighting is<br />
required.<br />
Weight: 0,113/kg/pc<br />
Art. Code: W<br />
64<br />
600<br />
Perforated Grills<br />
Pefrorated Grills option. Metal<br />
plates with 3mm holes for natural<br />
ventilation, placed on an aluminum<br />
extrusion profile(4<strong>05</strong>02)<br />
Art. Code: <br />
21<br />
* Special product<br />
please contact us for construction
Plastic slide<br />
blockers for B113<br />
profile<br />
Accessories<br />
Plastic slide blockers<br />
that are placed in both<br />
ends of every other<br />
profile of the shutter.<br />
Weight: 0,012 kg/pc<br />
Art. Code: TL12P<br />
Plastic slide<br />
blockers for B113<br />
curved profile<br />
Plastic slide blockers<br />
that are placed on<br />
both sides on every<br />
other profile of the<br />
shutter.<br />
Weight: 0,014 kg/pc<br />
Art. Code: TL12PC<br />
Plastic slide<br />
blockers for<br />
B95 profile<br />
Plastic slide blockers<br />
that are placed in both<br />
ends of every other<br />
profile of the shutter.<br />
Weight: 0,014 kg/pc<br />
Art. Code: TL12AB
Plastic slide<br />
blockers for<br />
B71 profile<br />
Plastic slide blockers<br />
that are placed in both<br />
ends of every other<br />
profile of the shutter.<br />
Weight: 0,012 kg/pc<br />
Art. Code: TL12A<br />
Plastic slide<br />
blockers for<br />
Aluminum<br />
extrusion profile<br />
Plastic slide blockers<br />
that are placed in both<br />
ends of every aluminum<br />
extrusion profile.<br />
Weight: 0,008 kg/pc<br />
Code: <br />
Art. Code: TL12AL<br />
Cover for<br />
Strut “V”<br />
Cover for strut “V” 1<strong>05</strong><br />
Weight: 0,016 kg/pc<br />
Art. Code: PC1<strong>05</strong><br />
23
Suspension<br />
Clip<br />
Suspension clip for<br />
winding shaft.<br />
Weight: 0,113 kg/pc<br />
Art. Code : SC<br />
End Rubber<br />
(Standard)<br />
Bottom rubber<br />
Weight: 0,45 kg/pc<br />
Art. Code: TR376<br />
End Rubber<br />
for optosensor<br />
Bottom rubber for<br />
optosensor.<br />
Weight: 0,40kg/m<br />
Art. Code: TR400
Aluminum<br />
Hooks<br />
a) 26mm for the double<br />
profiles<br />
b) 55m for the bottom<br />
aluminum profile<br />
Weight: 0,08 kg/pc<br />
0,17kg/pc<br />
Art. Code a: 4<strong>05</strong><strong>05</strong>N<br />
b: 4<strong>05</strong><strong>05</strong>NB<br />
Plastic Slide for<br />
Alu hook 4<strong>05</strong><strong>05</strong><br />
Art. Code: PSH<br />
Inv. Code:<br />
24.800.13.00139<br />
Metal Strut “V”<br />
Metal strut from galvanized<br />
steel.<br />
Height: 1<strong>05</strong>mm<br />
Dimensions: 1<strong>05</strong>x1<strong>05</strong>x1mm<br />
Weight: 2kg/m<br />
Art. Code: V1<strong>05</strong><br />
“U” Profile<br />
Weight: 0,54kg/m<br />
Dimensions: 15x15x1,5mm<br />
Art. Code: BU15<br />
Bottom<br />
Aluminum<br />
Profile<br />
Bottom aluminum extrusion<br />
profile:<br />
- Up to 10m length<br />
Natural<br />
-Up to 9m length<br />
Powder Coated<br />
Weight:<br />
1,17kg/m Natural<br />
1,20kg/m Powder Coated<br />
25<br />
Art. Code: 4<strong>05</strong>03
Color<br />
Palette<br />
Color Palette<br />
Wide range of powder coating colours (AKZO NOBEL) with excellent<br />
resistance to outdoor conditions and excellent colour retention that<br />
meets the requirements of all major European architectural standards<br />
BS EN 12206:2004 PART I, QUALICOAT CLASS I and GSB.<br />
*Color palette is for reference only. Actual colors may differ.<br />
** More colors available on request.<br />
RAL-1013 RAL-1015 RAL-1021<br />
RAL-2004 RAL-<strong>30</strong>00 RAL-<strong>30</strong>04<br />
RAL-5002 RAL-5010 RAL-5012<br />
RAL-6001 RAL-60<strong>05</strong> RAL-6009
RAL-7001 RAL-7011 RAL-7015<br />
RAL-7035 RAL-7038 RAL-8003<br />
RAL-8014 RAL-8017 RAL-8024<br />
RAL-9002 RAL-90<strong>05</strong> RAL-9006<br />
RAL-9007<br />
RAL-9016<br />
Galvanized<br />
27
3. Double Steel<br />
Sheet Profile<br />
» Double Steel sheet<br />
profiles, hot<br />
galvanized.<br />
» Galvanized <br />
» Wide range of RAL<br />
colors
Double Steel<br />
Sheet Profile<br />
1. Double Steel sheet Profile - Specifications<br />
Profile<br />
Height/ Step - mm<br />
Pcs /m<br />
Thickness - mm<br />
Weight kg/m<br />
Maximum Production<br />
Length - Galvanized<br />
Maximum Production<br />
Length - Powder Coated 1<br />
Min. Shaft Diameter<br />
<br />
<br />
Operating Forces<br />
Blind<br />
129,7/113<br />
8,5<br />
0,8/ 1,0<br />
2,3/ 2,88<br />
12m<br />
9m<br />
Φ159<br />
W:7000 x 1338kg Class 3<br />
<br />
<br />
<br />
Color palette available after request<br />
Certification according to :<br />
EN 13241-1:2003+A:201<br />
29
Plastic Slide blocker<br />
<br />
Accessories<br />
Weight: 0,033 kg/pc<br />
<br />
Cover for<br />
Strut “V”<br />
Cover for strut “V” 1<strong>05</strong><br />
Weight: 0,016 kg/pc<br />
Art. Code: PC1<strong>05</strong><br />
Suspension<br />
Clip<br />
Suspension clip for<br />
winding shaft.<br />
Weight: 0,113 kg/pc<br />
Art. Code : SC
Aluminum<br />
Hooks<br />
a) 26mm for the double<br />
profiles<br />
b) 55m for the bottom<br />
aluminum profile<br />
Weight: 0,08kg/pc<br />
0,17kg/pc<br />
Art. Code a: 4<strong>05</strong><strong>05</strong>N<br />
b: 4<strong>05</strong><strong>05</strong>NB<br />
Plastic Slide for<br />
Alu hook 4<strong>05</strong><strong>05</strong><br />
Art. Code: PSH<br />
Inv. Code: 24.800.13.00139<br />
Metal Strut “V”<br />
Metal strut from galvanized<br />
steel.<br />
Height: 1<strong>05</strong>mm<br />
Dimensions: 1<strong>05</strong>x1<strong>05</strong>x1mm<br />
Weight:2kg/m<br />
Art. Code: V1<strong>05</strong><br />
Bottom Profile<br />
Weight: 1,7 kg/m<br />
Art. Code : BB40G<br />
31
End Rubber<br />
Weight: 0,5 kg/m<br />
Art. Code: G0011<br />
Tube for Bottom<br />
Profile<br />
Dimensions: <strong>30</strong>x20x1,5mm<br />
Weight: kg/m<br />
Art. Code: BB<strong>30</strong>20
33
Color<br />
Palette<br />
Color Palette<br />
Wide range of powder coating colours (AKZO NOBEL) with excellent<br />
resistance to outdoor conditions and excellent colour retention that<br />
meets the requirements of all major European architectural standards<br />
BS EN 12206:2004 PART I, QUALICOAT CLASS I and GSB.<br />
*Color palette is for reference only. Actual colors may differ.<br />
** More colors available on request.<br />
RAL-1013 RAL-1015 RAL-1021<br />
RAL-2004 RAL-<strong>30</strong>00 RAL-<strong>30</strong>04<br />
RAL-5002 RAL-5010 RAL-5012<br />
RAL-6001 RAL-60<strong>05</strong> RAL-6009
RAL-7001 RAL-7011 RAL-7015<br />
RAL-7035 RAL-7038 RAL-8003<br />
RAL-8014 RAL-8017 RAL-8024<br />
RAL-9002 RAL-90<strong>05</strong> RAL-9006<br />
RAL-9007<br />
RAL-9016<br />
Galvanized<br />
35
Guide “Ω” with lip<br />
2. Guides<br />
1. Guide “Omega” with lips - Specifications<br />
Art. Code<br />
Weight<br />
G<br />
4,7 kg /m<br />
G<br />
5,5 kg/m<br />
Dimensions<br />
Steel Thickness<br />
Material<br />
80x80mm<br />
2mm<br />
Galvanized Steel<br />
110x80mm<br />
2mm<br />
Galvanized Steel<br />
Maximum Length<br />
12m<br />
12m<br />
Hole Dimensions (Big/Small) 27mm/ 10mm<br />
27mm/ 10mm<br />
Hole Distance<br />
500mm<br />
500mm<br />
Other Options<br />
Powder Coated<br />
<br />
Powder Coated
Guide “Ω”<br />
2. Guide “Omega” - Specifications<br />
Art. Code<br />
G60G<br />
G80G<br />
Weight 2,5 kg /m 4 kg/m<br />
Dimensions<br />
Steel Thickness<br />
Material<br />
60x80mm<br />
1,5mm<br />
Galvanized Steel<br />
80x80mm<br />
2 mm<br />
Galvanized Steel<br />
Maximum Length 5m 5m<br />
Other Options Powder Coated Powder Coated<br />
Hole Dimensions (Big/Small) Not Provided<br />
Not Provided<br />
Hole Distance -<br />
-<br />
37
Guide “Ω”<br />
3. Guide “Omega” - Specifications<br />
Art. Code<br />
Weight<br />
G100G<br />
4,5 kg /m<br />
G120G<br />
5,6 kg/m<br />
Dimensions<br />
100x80mm<br />
120x80mm<br />
Steel Thickness<br />
Material<br />
2 mm<br />
Galvanized Steel<br />
2 mm<br />
Galvanized Steel<br />
Maximum Length 5m 5m<br />
Other Options Powder Coated Powder Coated<br />
Hole Dimensions (Big/Small)<br />
Hole Distance<br />
Not Provided<br />
-<br />
Not Provided<br />
-
Side Support<br />
4. Side Support - Specifications<br />
Art. Code<br />
FL40GIND<br />
FL45GIND<br />
FL50GIND<br />
FL55GIND<br />
Dimensions<br />
Steel Thickness<br />
Material<br />
400x400mm<br />
3mm<br />
Galvanized Steel<br />
450x450mm<br />
3mm<br />
Galvanized Steel<br />
500x500mm<br />
3mm<br />
Galvanized Steel<br />
Other Options Powder Coated Powder Coated Powder Coated<br />
550x550mm<br />
3mm<br />
Galvanized Steel<br />
Powder Coated<br />
Weight 8,2 kg/ pair 9,6 kg/ pair 11,8 kg/ pair 14,4 kg/pair<br />
Κωδικός: T238GP<br />
39
Side Mount<br />
5. Side Mount - Specifications<br />
Side Mount<br />
Weight: 15,4 kg/pc<br />
Lifting Capacity: 1400kg<br />
Art. Code: SUPB-GK
Side mount 17<br />
Weight: 9,6 kg/pc<br />
Lifting Capacity: 800kg<br />
Art. Code: SUPR17<br />
Side mount 15<br />
Weight: 5,3 kg/pc<br />
Lifting capacity: 500 kg<br />
Art. Code: SUPR15<br />
Κωδικός: T238GP<br />
41
Guide Support<br />
Accessories<br />
Support that is used to<br />
fix the guides onto the<br />
wall.<br />
Weight: 0,73 kg/pc<br />
Art. Code: SUPPORT-N<br />
Slide for Guide<br />
Slides that help the<br />
shutter roll into the<br />
guides as it descendes.<br />
Weight: 0,065 kg/pair<br />
Art. Code : IN11<br />
Guide Rubber<br />
Seal<br />
Rubber seal that is used<br />
with the “Omega with<br />
lips” guide.<br />
Weight: 0,215 kg/m<br />
Art. Code: 1085 - 450<br />
1085 - 500<br />
1085 - 550<br />
1085 - 6<br />
1085 - 700
Guide Rubber<br />
Seal<br />
Rubber seal that is<br />
used with the “Omega”<br />
guides.<br />
Weight: 0,42kg/m<br />
Art. Code: SP<br />
Top Sealing<br />
Brush<br />
Length: 3m<br />
Weight: 0,870 kg<br />
Art. Code: STAL<strong>30</strong>00<br />
43
Color<br />
Palette<br />
Color Palette<br />
Wide range of powder coating colours (AKZO NOBEL) with excellent<br />
resistance to outdoor conditions and excellent colour retention that<br />
meets the requirements of all major European architectural standards<br />
BS EN 12206:2004 PART I, QUALICOAT CLASS I and GSB.<br />
*Color palette is for reference only. Actual colors may differ.<br />
** More colors available on request.<br />
RAL-1013 RAL-1015 RAL-1021<br />
RAL-2004 RAL-<strong>30</strong>00 RAL-<strong>30</strong>04<br />
RAL-5002 RAL-5010 RAL-5012<br />
RAL-6001 RAL-60<strong>05</strong> RAL-6009
RAL-7001 RAL-7011 RAL-7015<br />
RAL-7035 RAL-7038 RAL-8003<br />
RAL-8014 RAL-8017 RAL-8024<br />
RAL-9002 RAL-90<strong>05</strong> RAL-9006<br />
RAL-9007<br />
RAL-9016<br />
Galvanized<br />
45
Industrial Shafts<br />
3. Shafts<br />
Shaft (in diameter Φ159- 4,0 mm). Also available in diameter<br />
Φ 133/193/220 according to the requirements of each case. They<br />
have flanged edges (both sides) which are welded into the shaft of<br />
the rolling shutter for extra support.<br />
Shaft<br />
BB-133<br />
BB-159<br />
BB-168<br />
BB-193<br />
BB-219<br />
Diameter<br />
Width<br />
Φ133<br />
4mm<br />
Φ159<br />
4mm<br />
Φ168<br />
4mm<br />
Φ193<br />
4 mm<br />
Φ219<br />
5-6mm<br />
Weight<br />
12,8 kg/m<br />
15,3 kg/m<br />
16,2 kg/m<br />
18,7 kg/m<br />
26,4 - 31,6 kg/m<br />
Suspension<br />
Clip<br />
Suspension clip for<br />
winding shaft.<br />
Art. Code : SC<br />
Weight: 0,113 kg/pc
Shaft end<br />
& Pivot<br />
W = Width<br />
L =Length<br />
47
Front Frame<br />
4. Box &<br />
Front Frame<br />
1. Front Frame - Specifications<br />
Art. Code<br />
FRAME 400<br />
FRAME 450<br />
FRAME 500<br />
Dimensions<br />
Steel Thickness<br />
Weight<br />
400x<strong>30</strong>mm<br />
1mm<br />
4 kg/m<br />
450x<strong>30</strong>mm<br />
1mm<br />
4,4 kg/m<br />
500x<strong>30</strong>mm<br />
1mm<br />
4,8 kg/m<br />
Material Galvanized Steel Galvanized Steel Galvanized Steel<br />
Other Options Powder Coated Powder Coated Powder Coated
Two Side Box<br />
2. Two Side Box - Specifications<br />
Art. Code<br />
BOX 400<br />
BOX 450<br />
BOX 500<br />
Dimensions<br />
Steel Thickness<br />
Weight<br />
400x400mm<br />
1mm<br />
7,2 kg/m<br />
450x450mm<br />
1mm<br />
8 kg/m<br />
500x500mm<br />
1mm<br />
8,8 kg/m<br />
Material Galvanized Steel Galvanized Steel Galvanized Steel<br />
Other Options Powder Coated Powder Coated Powder Coated<br />
49
Three Side Box<br />
3. Three Side Box - Specifications<br />
Art. Code<br />
BOX 400<br />
BOX 450<br />
BOX 500<br />
Dimensions<br />
Steel Thickness<br />
Weight<br />
400x400mm<br />
1mm<br />
10,5 kg/m<br />
450x450mm<br />
1mm<br />
11,5 kg/m<br />
500x500mm<br />
1mm<br />
12,8 kg/m<br />
Material Galvanized Steel Galvanized Steel Galvanized Steel<br />
Other Options Powder Coated Powder Coated Powder Coated
201
Change language
