<strong>2018</strong><br />
PRODUCT CATALOG
Personal Attention<br />
Accurate <strong>Dental</strong> Solutions<br />
Precision<br />
Down to the Smallest Detail<br />
Wide Range of <strong>Dental</strong> Solutions<br />
Engineered for a Lifetime<br />
Global Partners
Table of Contents<br />
Company Profile 2-4<br />
<strong>Implants</strong><br />
<strong>Implants</strong> Index 6-7<br />
Tuff 8-9<br />
Tuff Pro 10-11<br />
Tuff TT 12-13<br />
Onyx 14-15<br />
Cortical 16-17<br />
PteryCore 18<br />
PteryFit 19<br />
Pterygoid <strong>Implants</strong> Tools 21<br />
Zygomatic 22-25<br />
MBI & MBI NC 26-27<br />
Mono 28-29<br />
Packaging 30<br />
Prosthetics<br />
Prosthetic Workflow 32-33<br />
Accessories<br />
Healing Caps 34<br />
Open & Closed Tray Transfers 35<br />
Snap-On Transfer 36<br />
Clip-On Transfer 37<br />
Cement Retained Restorations<br />
Temporary Abutments 38-39<br />
Straight Abutments 40-41<br />
Angulated Abutments 42-43<br />
Titanium Base Zirconia Abutments 44<br />
Castable Abutments 45<br />
CAD/CAM Components 46-47<br />
Screw Retained Restorations<br />
Multi-Unit - Straight & Angulated 50<br />
Multi-Unit Components 52-53<br />
Multi-Unit Protocol 54-55<br />
Esthetic Screw Abutment 56<br />
Removable Restorations<br />
Vari-Connect 58<br />
Vari-Connect Components 59<br />
Ball Attachment 60<br />
Flat Attachment 61<br />
Instruments<br />
Drills Workflow 64<br />
Drills 65-68<br />
Drivers 69-71<br />
Tools 72-73<br />
Kits 74-76<br />
Index 77-82<br />
/ 1 /
Company Profile<br />
<strong>Noris</strong> <strong>Medical</strong> provides the medical market with a wide range of solutions.<br />
The company is directed by experienced physicians and professional<br />
engineers focusing on development, design and production of innovative<br />
products for the medical field. Within this framework, <strong>Noris</strong> <strong>Medical</strong> is<br />
focused on original products and systems for dental applications.<br />
The synergetic activity of <strong>Noris</strong> <strong>Medical</strong> team results in advanced products<br />
and outstanding systems that help dentists and patients alike.<br />
Each new product and system developed is supplied with comprehensive<br />
peripheral tooling needed for its successful implementation.<br />
<strong>Noris</strong> <strong>Medical</strong> offers responsive customer support and ongoing professional<br />
training courses to the global community of dental surgeons and technicians.<br />
With decades of collective professional experience, <strong>Noris</strong> <strong>Medical</strong> strives<br />
to provide the dental implantation market with the highest quality products<br />
and systems based on sound engineering principles and excellent<br />
manufacturing practices.<br />
/ 2 / <strong>Implants</strong>
<strong>Noris</strong> <strong>Medical</strong> improves the lives of dentists<br />
and patients around the world with the<br />
leading technology in dental implant systems.<br />
/ 3 /
Standards<br />
<strong>Noris</strong> <strong>Medical</strong> invests significant resources in creating an environment for the design and manufacture of its dental<br />
products. Keeping patient safety at the forefront throughout the process, <strong>Noris</strong> <strong>Medical</strong> complies with international<br />
standards for manufacturing and quality. The entire manufacturing process is monitored and recorded for total<br />
process traceability. All facilities are subjected to strict inspection procedures.<br />
• <strong>Product</strong>s carry the CE mark and meet the European <strong>Medical</strong> Device Directive (93/42/EEC).<br />
• <strong>Product</strong>s received the FDA Clearance Premarket Notification (510k) (K140440).<br />
• Meticulous quality control system is in compliance with EN ISO 13485:2012 and FDA QSR 21 CFR Part 820.<br />
• Facilities are subject to routine audits by international auditors.<br />
• Class 10,000 Clean Room for production.<br />
Materials & Surface Treatment<br />
Titanium alloys are known for their superior<br />
biocompatibility and tensile strength. Therefore, all <strong>Noris</strong><br />
<strong>Medical</strong> <strong>Dental</strong> <strong>Implants</strong> and Prosthetic Components<br />
are produced from Titanium Alloy Ti6Al4V (Grade 5).<br />
Macroscopic and microscopic properties of <strong>Dental</strong><br />
Implant surfaces play a major role in their osseous<br />
healing process. Roughened implant surfaces provide<br />
increased retention strength. The topography, down to<br />
the micrometer, affects the attachment and growth<br />
of bone cells.<br />
<strong>Noris</strong> <strong>Medical</strong> applies RBM (Resorbable Blast Media)<br />
technique in order to induce the sub-micro topography.<br />
The material used for RBM process is Calcium Phosphate,<br />
which is a highly resorbable and biocompatible material.<br />
Usage of Calcium Phosphate as the blasting material also<br />
eliminates the need of using strong acids for the removal<br />
of blasting material remnants.<br />
Implant surfaces that have been RBM treated are<br />
considered to be more osteoconductive. Research<br />
showed higher percentage of bone to implant contact<br />
around RBM treated implants. This finding could be<br />
especially useful in severe clinical conditions like poor<br />
bone quality and in cases of early or immediate loading.<br />
References<br />
McCrcken M. <strong>Dental</strong> implant material: Commercially pure titanium and titanium alloys. J Prosthod 1999; 8:40-43.<br />
Schwartz Z, Raz P, Zhao G, Barak Y, Tauber M, Yao H, Boyan BD. Effect of micrometer-scale roughness of the surface of Ti6Al4V pedicle<br />
screws in vitro and in vivo. J Bone Joint Surg Am. 2008; 90:2485-98.<br />
Piattelli A, Manzon L, Scarano A, Paolantonio M, Piattelli M. Histologic and histomorphometric analysis of the bone response to machined<br />
and sandblasted titanium implants: An experimental study in rabbits. Int J Oral Maxillofac <strong>Implants</strong>. 1998;13:805–810.<br />
Piattelli M, Scarano A, Quaranto M, Petrone G, Piattelli A. bone response in rabbit to machined and RBM titanium implants. J Dent Res.<br />
1999;78:1126.<br />
Piattelli M, Scarano A, Paolantonio M, Iezzi G, Petrone G, Piattelli A. Bone response to machined and resorbable blast material titanium<br />
implants: an experimental study in rabbits. J Oral Implantol. 2002;28;2-8.<br />
/ 4 / <strong>Implants</strong>
<strong>Implants</strong><br />
/ 5 /
Internal Hex. <strong>Implants</strong> Index<br />
Pages 8-9 Pages 10-11 Pages 12-13 Pages 14-15 Pages 16-17 Pages 18 Pages 19 Pages 22-25<br />
Tuff Tuff Pro Tuff TT Onyx Cortical PteryCore PteryFit Zygomatic<br />
Internal Hex. Drivers<br />
NMHX2640 NMHX2620 NMHX2615 NMHX2610 NMHX2607 NMHX1015 NMHX1014<br />
Driver<br />
2.42mm<br />
Motor Mount<br />
2.42mm<br />
Implant Sterile Blister<br />
Information<br />
Sticker<br />
Tube<br />
Casing<br />
Implant<br />
Implant<br />
Holder<br />
Cover<br />
Screw<br />
/ 6 / <strong>Implants</strong>
One Piece <strong>Implants</strong> Index<br />
Pages 26-27 Pages 26-27 Pages 28-29<br />
MBI MBI NC Mono<br />
MBI Drivers<br />
Mono Drivers<br />
NM-X2415 NM-X1520 NM-X1018 NM-X1019 NM-X1620<br />
Driver<br />
Motor Mount<br />
Driver<br />
Driver<br />
Motor Mount<br />
1.7mm<br />
1.7mm<br />
2.15mm<br />
2.15mm<br />
2.15mm<br />
/ 7 /
Tuff<br />
L2<br />
2<br />
D<br />
With their three thread zones, Tuff implants have<br />
been uniquely designed according to the anatomy of<br />
the bone structure. The lower V-shape thread zone<br />
enables self-tapping. The middle zone square type<br />
thread is used for compressing cancellous bone and<br />
helping achieve maximum BIC. The micro thread on<br />
the upper zone adds stability and prevents crestal<br />
bone loss.<br />
2.42<br />
Implant Tuff<br />
3.75<br />
Material: Titanium (Ti6Al4V ELI)<br />
Treatment: RBM<br />
Available in two neck textures versions:<br />
Machined surface or RBM treated surface.<br />
L<br />
D1<br />
D<br />
1200-<br />
Drilling Speed (RPM)<br />
1500 1200 900- 500-<br />
700<br />
500-<br />
700<br />
400-<br />
700<br />
400-<br />
700<br />
400-<br />
600<br />
400-<br />
600<br />
400-<br />
600<br />
400-<br />
600<br />
300-<br />
500<br />
300-<br />
500<br />
200-<br />
500<br />
Drill Diameter md ø2.0 ø2.8 ø2.8 ø3.2 ø3.2 ø3.65 ø3.65 ø4.2 ø4.2 ø5.2 ø5.2 ø5-6<br />
? ? ? ?<br />
? ?<br />
Drill Sequence*<br />
Bone type D1, D2<br />
6<br />
10<br />
16<br />
ø3.3 ø3.3 ø3.3 ø3.75 ø3.75 ø4.2 ø4.2 ø5.0 ø5.0 ø6.0 ø6.0<br />
? Torque Too high Further Drilling Sequence Insert Implant<br />
Drilling Speed (RPM)<br />
1200-<br />
1500<br />
900-<br />
1200<br />
500-<br />
700<br />
400-<br />
700<br />
400-<br />
600<br />
400-<br />
600<br />
300-<br />
500<br />
Drill Diameter md ø2.0 ø2.8 ø3.2 ø3.65 ø4.2 ø5.2<br />
Drill Sequence*<br />
Bone type D3, D4<br />
6<br />
10<br />
16<br />
ø3.3 ø3.75 ø4.2 ø5.0 ø6.0<br />
* The proposed procedure is only a recommendation and should not replace the doctor's judgment.<br />
The implants may be placed in immediate function when good primary stability (above 35 Ncm) has been achieved and with appropriate occlusal loading.<br />
* Implant Carrier removal After the osteotomy preparation, the implant should be inserted with the aid of the implant carrier.<br />
The implant should be initially stabilized by a few threads and then the carrier should be removed. Farther insertion of the implant will be done with appropriate tool.<br />
* Implant hexagon During implant insertion, the hexagon of the implant, should be located with a straight part of the hexagon toward the angulation needed, in order<br />
to provide adequate rehabilitation.<br />
/ 8 / <strong>Implants</strong>
<strong>Implants</strong> Ø D (mm) Ø D1 (mm) L (mm) RBM Treated Neck Machined Neck<br />
8 NM-F3308 NMSF3308<br />
10 NM-F3310 NMSF3310<br />
3.3 2.6<br />
3.75 3.1<br />
4.2 3.5<br />
5.0 4.5<br />
6.0 5.2<br />
11.5 NM-F3311 NMSF3311<br />
13 NM-F3313 NMSF3313<br />
16 NM-F3316 NMSF3316<br />
6 NM-F3706 NMSF3706<br />
8 NM-F3708 NMSF3708<br />
10 NM-F3710 NMSF3710<br />
11.5 NM-F3711 NMSF3711<br />
13 NM-F3713 NMSF3713<br />
16 NM-F3716 NMSF3716<br />
18 NM-F3718 NMSF3718<br />
6 NM-F4206 NMSF4206<br />
8 NM-F4208 NMSF4208<br />
10 NM-F4210 NMSF4210<br />
11.5 NM-F4211 NMSF4211<br />
13 NM-F4213 NMSF4213<br />
16 NM-F4216 NMSF4216<br />
18 NM-F4218 NMSF4218<br />
20 NM-F4220 NMSF4220<br />
22 NM-F4222 NMSF4222<br />
25 NM-F4225 NMSF4225<br />
6 NM-F5006 NMSF5006<br />
8 NM-F5008 NMSF5008<br />
10 NM-F5010 NMSF5010<br />
11.5 NM-F5011 NMSF5011<br />
13 NM-F5013 NMSF5013<br />
16 NM-F5016 NMSF5016<br />
6 NM-F6006 NMSF6006<br />
8 NM-F6008 NMSF6008<br />
10 NM-F6010 NMSF6010<br />
11.5 NM-F6011 NMSF6011<br />
13 NM-F6013 NMSF6013<br />
16 NM-F6016 NMSF6016<br />
Cover Screw Included with all implants NM-S5023<br />
/ 9 /<br />
Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff
Tuff Pro<br />
Tuff Pro implants have been uniquely designed to<br />
match the anatomy of the bone structure. The lower<br />
V-shape thread zone enables self-tapping. The middle<br />
zone square type thread is used for compressing<br />
cancellous bone and helping achieve maximum BIC.<br />
The smooth “Neck” surface at the top helps in<br />
eliminating the adherence of Perio-Pathogens, thus<br />
reducing the chances of an inflammatory process<br />
to develop around the neck area. The RBM treated<br />
surface increases the BIC.<br />
Material: Titanium (Ti6Al4V ELI)<br />
Treatment: RBM<br />
L<br />
2<br />
2.42<br />
3.75<br />
D1<br />
D<br />
1200-<br />
Drilling Speed (RPM)<br />
1500 1200 900- 500-<br />
700<br />
500-<br />
700<br />
400-<br />
700<br />
400-<br />
700<br />
400-<br />
600<br />
400-<br />
600<br />
400-<br />
600<br />
400-<br />
600<br />
NMAFXXXX-Tuff<br />
300-<br />
500<br />
300-<br />
500<br />
Drill Diameter md ø2.0 ø2.8 ø2.8 ø3.2 ø3.2 ø3.65 ø3.65 ø4.2 ø4.2 ø5.2 ø5.2<br />
? ? ? ?<br />
?<br />
Drill Sequence*<br />
Bone type D1, D2<br />
6<br />
10<br />
16<br />
ø3.3 ø3.3 ø3.3 ø3.75 ø3.75 ø4.2 ø4.2 ø5.0 ø5.0<br />
? Torque Too high Further Drilling Sequence Insert Implant<br />
Drilling Speed (RPM)<br />
1200-<br />
1500<br />
900-<br />
1200<br />
500-<br />
700<br />
400-<br />
700<br />
400-<br />
600<br />
400-<br />
600<br />
Drill Diameter md ø2.0 ø2.8 ø3.2 ø3.65 ø4.2<br />
Drill Sequence*<br />
Bone type D3, D4<br />
6<br />
10<br />
16<br />
ø3.3 ø3.75 ø4.2 ø5.0<br />
* The proposed procedure is only a recommendation and should not replace the doctor's judgment.<br />
The implants may be placed in immediate function when good primary stability (above 35 Ncm) has been achieved and with appropriate occlusal loading.<br />
* Implant Carrier removal After the osteotomy preparation, the implant should be inserted with the aid of the implant carrier.<br />
The implant should be initially stabilized by a few threads and then the carrier should be removed. Farther insertion of the implant will be done with appropriate tool.<br />
* Implant hexagon During implant insertion, the hexagon of the implant, should be located with a straight part of the hexagon toward the angulation needed, in order<br />
to provide adequate rehabilitation.<br />
/ 10 / <strong>Implants</strong>
<strong>Implants</strong> Ø D (mm) Ø D1 (mm) L (mm) Item<br />
10 NMAF3310<br />
3.3 2.6<br />
3.75 3.1<br />
4.2 3.5<br />
5.0 4.5<br />
Cover Screw Included with all implants<br />
11.5 NMAF3311<br />
13 NMAF3313<br />
16 NMAF3316<br />
10 NMAF3710<br />
11.5 NMAF3711<br />
13 NMAF3713<br />
16 NMAF3716<br />
10 NMAF4210<br />
11.5 NMAF4211<br />
13 NMAF4213<br />
16 NMAF4216<br />
10 NMAF5010<br />
11.5 NMAF5011<br />
13 NMAF5013<br />
16 NMAF5016<br />
NM-S5023<br />
/ 11 /<br />
Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff
Tuff TT<br />
L2<br />
2<br />
D<br />
Tuff TT <strong>Implants</strong> share the same three-thread zone<br />
concept as Tuff implants. The taper top converging<br />
coronal shape allows platform switch technology to<br />
prevent crestal bone loss.<br />
Material: Titanium (Ti6Al4V ELI)<br />
Treatment: RBM<br />
2.42<br />
Implant Tuff TT<br />
3.75<br />
L<br />
D1<br />
D<br />
Drilling Speed (RPM)<br />
1200-<br />
1500<br />
900-<br />
1200<br />
500-<br />
700 400-700<br />
400-<br />
600<br />
400-<br />
600<br />
400-<br />
600<br />
300-<br />
500<br />
300-<br />
500<br />
200-<br />
500<br />
Drill Diameter md ø2.0 ø2.8 ø3.2 ø3.65 ø4.2 ø5-6 ø5.2 ø5-6 ø5-6<br />
? ? ?<br />
Drill Sequence*<br />
Bone type D1, D2<br />
6<br />
10<br />
16<br />
? Torque Too high Further Drilling Sequence Insert Implant<br />
ø4.2 ø4.2 ø5.0 ø6.0 ø6.0<br />
Drilling Speed (RPM)<br />
1200-<br />
1500<br />
900-<br />
1200<br />
500-<br />
700 400-700<br />
400-<br />
600<br />
400-<br />
600<br />
300-<br />
500<br />
Drill Diameter md ø2.0 ø2.8 ø3.2 ø3.65 ø4.2 ø5.2<br />
Drill Sequence*<br />
Bone type D3, D4<br />
6<br />
10<br />
16<br />
ø4.2 ø5.0 ø6.0<br />
* The proposed procedure is only a recommendation and should not replace the doctor's judgment.<br />
The implants may be placed in immediate function when good primary stability (above 35 Ncm) has been achieved and with appropriate occlusal loading.<br />
* Implant Carrier removal After the osteotomy preparation, the implant should be inserted with the aid of the implant carrier.<br />
The implant should be initially stabilized by a few threads and then the carrier should be removed. Farther insertion of the implant will be done with appropriate tool.<br />
* Implant hexagon During implant insertion, the hexagon of the implant, should be located with a straight part of the hexagon toward the angulation needed, in order<br />
to provide adequate rehabilitation.<br />
/ 12 / <strong>Implants</strong>
implants Ø D (mm) Ø D1 (mm) L (mm) Item<br />
6 NM-F4306<br />
8 NM-F4308<br />
10 NM-F4310<br />
4.2 3.5<br />
5.0 4.2<br />
6.0 5.0<br />
Cover Screw Included with all implants<br />
11.5 NM-F4311<br />
13 NM-F4313<br />
16 NM-F4316<br />
18 NM-F4318<br />
20 NM-F4320<br />
6 NM-F5106<br />
8 NM-F5108<br />
10 NM-F5110<br />
11.5 NM-F5111<br />
13 NM-F5113<br />
16 NM-F5116<br />
6 NM-F6106<br />
8 NM-F6108<br />
10 NM-F6110<br />
11.5 NM-F6111<br />
13 NM-F6113<br />
NM-S5023<br />
/ 13 /<br />
Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff
Onyx<br />
L2<br />
2<br />
D<br />
Onyx implants are specially designed for treatments<br />
involving placement in type I and type II bone.<br />
Material: Titanium (Ti6Al4V ELI)<br />
Treatment: RBM<br />
2.42<br />
Implant Onyx<br />
3.75<br />
L<br />
D1<br />
D<br />
Drilling Speed (RPM)<br />
1200-<br />
1500<br />
900-<br />
1200<br />
500-<br />
700 400-700<br />
200-<br />
500<br />
400-<br />
600<br />
200-<br />
500<br />
400-<br />
600<br />
200-<br />
500<br />
300-<br />
500<br />
200-<br />
500<br />
Drill Diameter md ø2.0 ø2.8 ø3.2 ø3.75 ø3.65 ø3.75 ø4.2 ø5-6 ø5.2 ø5-6<br />
Drill Sequence*<br />
Bone type D1, D2<br />
6<br />
10<br />
16<br />
ø3.3 ø3.75 ø4.2 ø5.0 ø6.0<br />
Drilling Speed (RPM)<br />
1200-<br />
1500<br />
900-<br />
1200<br />
500-<br />
700 400-700<br />
400-<br />
600<br />
400-<br />
600<br />
300-<br />
500<br />
Drill Diameter md ø2.0 ø2.8 ø3.2 ø3.65 ø4.2 ø5.2<br />
Drill Sequence*<br />
Bone type D3, D4<br />
6<br />
10<br />
16<br />
ø3.3 ø3.75 ø4.2 ø5.0 ø6.0<br />
* The proposed procedure is only a recommendation and should not replace the doctor's judgment.<br />
The implants may be placed in immediate function when good primary stability (above 35 Ncm) has been achieved and with appropriate occlusal loading.<br />
* Implant Carrier removal After the osteotomy preparation, the implant should be inserted with the aid of the implant carrier.<br />
The implant should be initially stabilized by a few threads and then the carrier should be removed. Farther insertion of the implant will be done with appropriate tool.<br />
* Implant hexagon During implant insertion, the hexagon of the implant, should be located with a straight part of the hexagon toward the angulation needed, in order<br />
to provide adequate rehabilitation.<br />
/ 14 / <strong>Implants</strong>
<strong>Implants</strong> Ø D (mm) Ø D1 (mm) L (mm) Item<br />
8 NM-G3308<br />
10 NM-G3310<br />
3.3 2.4<br />
3.75 2.8<br />
4.2 3.2<br />
5.0 4.0<br />
6.0 5.0<br />
Cover Screw Included with all implants<br />
11.5 NM-G3311<br />
13 NM-G3313<br />
16 NM-G3316<br />
6 NM-G3706<br />
8 NM-G3708<br />
10 NM-G3710<br />
11.5 NM-G3711<br />
13 NM-G3713<br />
16 NM-G3716<br />
6 NM-G4206<br />
8 NM-G4208<br />
10 NM-G4210<br />
11.5 NM-G4211<br />
13 NM-G4213<br />
16 NM-G4216<br />
6 NM-G5006<br />
8 NM-G5008<br />
10 NM-G5010<br />
11.5 NM-G5011<br />
13 NM-G5013<br />
16 NM-G5016<br />
6 NM-G6006<br />
8 NM-G6008<br />
10 NM-G6010<br />
11.5 NM-G6011<br />
13 NM-G6013<br />
NM-S5023<br />
/ 15 /<br />
Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff
Cortical<br />
Cortical<br />
4<br />
Cortical implants provide good stability for immediate<br />
loading. Its sharp, deep threads provide extremely<br />
strong retention for primary implant stability.<br />
The threads’ location gives stability in the cortical<br />
bone. The Cortical system can be used in extraction<br />
sites for immediate implantation. Cortical is available<br />
in different sizes to suit any implantation site.<br />
L1<br />
4<br />
3.75<br />
L<br />
2.42<br />
4<br />
3.75<br />
Cortical<br />
2<br />
Material: Titanium (Ti6Al4V ELI)<br />
Treatment: RBM<br />
L2<br />
L1<br />
4<br />
1.6<br />
D<br />
L<br />
L2<br />
1.6<br />
D<br />
Drilling Speed (RPM)<br />
1200-<br />
1500<br />
900-<br />
1200<br />
500-<br />
700<br />
200-<br />
500 400-700<br />
200-<br />
500<br />
Drill Diameter md ø2.0 ø2.8 ø3.2 ø3.2 ø3.65<br />
? ?<br />
Drill Sequence*<br />
Bone type D1, D2<br />
6<br />
10<br />
16<br />
ø4.0 ø4.0 ø5.0 ø5.0 ø6.0<br />
? Torque Too high Further Drilling Sequence Insert Implant<br />
Drilling Speed (RPM)<br />
1200-<br />
1500<br />
900-<br />
1200<br />
500-<br />
700<br />
Drill Diameter md ø2.0 ø2.8<br />
Drill Sequence*<br />
Bone type D3, D4<br />
6<br />
10<br />
16<br />
ø4.0 ø5.0 ø6.0<br />
* The proposed procedure is only a recommendation and should not replace the doctor's judgment.<br />
The implants may be placed in immediate function when good primary stability (above 35 Ncm) has been achieved and with appropriate occlusal loading.<br />
* Implant Carrier removal After the osteotomy preparation, the implant should be inserted with the aid of the implant carrier.<br />
The implant should be initially stabilized by a few threads and then the carrier should be removed. Farther insertion of the implant will be done with appropriate tool.<br />
* Implant hexagon During implant insertion, the hexagon of the implant, should be located with a straight part of the hexagon toward the angulation needed, in order<br />
to provide adequate rehabilitation.<br />
/ 16 / <strong>Implants</strong>
<strong>Implants</strong> Ø D (mm) L (mm) L1 (mm) L2 (mm) Item<br />
10 4.5 5.5 NM-M4010<br />
11.5 4.7 6.8 NM-M4011<br />
4.0<br />
5.0<br />
6.0<br />
13 5 8 NM-M4013<br />
16 6 10 NM-M4016<br />
18 7 11 NM-M4018<br />
20 7.5 12.5 NM-M4020<br />
8 4.1 3.9 NM-M5008<br />
10 4.5 5.5 NM-M5010<br />
11.5 4.7 6.8 NM-M5011<br />
13 5 8 NM-M5013<br />
16 6 10 NM-M5016<br />
8 4.1 3.9 NM-M6008<br />
10 4.5 5.5 NM-M6010<br />
11.5 4.7 6.8 NM-M6011<br />
13 5 8 NM-M6013<br />
Cover Screw Included with all implants NM-S5023<br />
/ 17 /<br />
Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff
PteryCore<br />
PteryCore implants are installed in the posterior region of<br />
the atrophic Maxilla and located in the Pterygomaxillary<br />
region. Their Sharp, deep threads provide extremely strong<br />
retention for primary implant stability. As such they provide<br />
good stability for Immediate Loading procedures.<br />
2.42<br />
4.2<br />
3.75<br />
PteryCore <strong>Implants</strong> are designed to have a smooth<br />
surface at their “Neck”, followed by RBM treated surface<br />
underneath.<br />
The smooth “Neck” surface at the top helps in eliminating<br />
the adherence of Perio-Pathogens, thus reducing the<br />
chances of an inflammatory process to develop around the<br />
neck area. The RBM treated surface increases the BIC.<br />
L1<br />
L2<br />
4<br />
L<br />
Material: Titanium (Ti6Al4V ELI)<br />
Treatment: RBM<br />
1.7<br />
4.2<br />
Cortical-Preticore<br />
<strong>Implants</strong> Ø D (mm) L (mm) L1 (mm) L2 (mm) Item<br />
18 7 11 NM-M4218<br />
4.2<br />
20 7 13 NM-M4220<br />
22.5 7 15.5 NM-M4222<br />
25 7 18 NM-M4225<br />
Cover Screw Included with all implants<br />
NM-S5023<br />
/ 18 / <strong>Implants</strong>
PteryFit<br />
PteryFit implants are installed in the posterior<br />
region of the atrophic Maxilla and are located in the<br />
Pterygomaxillary region.<br />
PteryFit implants have been uniquely designed to match<br />
the anatomy of the bone structure. The lower V-shaped<br />
thread zone enables self-tapping. The middle zone<br />
square type thread is used for compressing cancellous<br />
bone and help achieving maximum BIC.<br />
The smooth “Neck” surface at the top helps in<br />
eliminating the adherence of Perio-Pathogens,<br />
thus reducing the chances of an inflammatory<br />
process to develop around the neck area.<br />
The RBM treated surface increases the BIC.<br />
Material: Titanium (Ti6Al4V ELI)<br />
Treatment: RBM<br />
<strong>Implants</strong> Ø D (mm) Ø D1 (mm) L (mm) Item<br />
4.2 2.5<br />
Cover Screw Included with all implants<br />
18 NMAF4218<br />
20 NMAF4220<br />
22 NMAF4222<br />
25 NMAF4225<br />
NM-S5023<br />
L<br />
5<br />
2.42<br />
3.75<br />
D1<br />
D<br />
NMAF42XX<br />
/ 19 /<br />
Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff
20 / <strong>Implants</strong><br />
Pterygoid <strong>Implants</strong> for<br />
Posterior Maxilla Rehabilitation
16<br />
18<br />
20<br />
22<br />
25<br />
16<br />
18<br />
20<br />
22<br />
25<br />
Pterygoid <strong>Implants</strong> Tools<br />
Osteotomes<br />
Ø D (mm)<br />
Item<br />
2.0 NM-X3001<br />
3.0 NM-X3002<br />
Long Drills<br />
Ø D (mm)<br />
Depth Groove<br />
(mm)<br />
16<br />
18<br />
20<br />
22<br />
25<br />
Item<br />
2.3 NM-D7423<br />
2.8 NM-D7428<br />
3.2 NM-D7432<br />
3.65 NM-D7436<br />
11.5<br />
Depth Groove<br />
(mm)<br />
13<br />
15<br />
18<br />
20<br />
22<br />
25<br />
Color Code<br />
Laser Mark<br />
3.2<br />
/ 21 /<br />
Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff
L<br />
L<br />
Zygomatic<br />
3.75<br />
2.42<br />
The Zygomatic Implant is designed to provide a<br />
solution for cases of atrophic maxilla. The shape<br />
of the Zygomatic Implant consists of sharp threads<br />
at the apical part for maximum retention to the<br />
Zygomatic bone. The implant has 2.42mm internal<br />
hex. connection, which enable simple and easy<br />
restoration. The Zygomatic Implant is available in<br />
a variety of lengths, from 30mm to 60mm.<br />
3.75<br />
2.42<br />
Material: Titanium (Ti6Al4V ELI)<br />
Treatment: RBM<br />
12.5<br />
D1<br />
D<br />
12.5<br />
D1<br />
D<br />
<strong>Implants</strong> Ø D (mm) Ø D1 (mm) L (mm) Item<br />
30 NM-F4430<br />
32.5 NM-F4432<br />
35 NM-F4435<br />
37.5 NM-F4437<br />
40 NM-F4440<br />
42.5 NM-F4442<br />
4.2 3.5<br />
45 NM-F4445<br />
47.5 NM-F4447<br />
50 NM-F4450<br />
52.5 NM-F4452<br />
55 NM-F4455<br />
57.5 NM-F4457<br />
60 NM-F4460<br />
Cover Screw Included with all implants<br />
NM-S5023<br />
/ 22 / <strong>Implants</strong>
Drill Sequence<br />
60<br />
55<br />
50<br />
45<br />
40<br />
35<br />
30<br />
16<br />
8<br />
4<br />
0<br />
Bone<br />
Type<br />
1<br />
60<br />
55<br />
50<br />
45<br />
40<br />
35<br />
ø4.2<br />
ø3<br />
ø2.5<br />
ø2<br />
2<br />
60<br />
55<br />
50<br />
45<br />
40<br />
35<br />
ø4.2<br />
ø3<br />
ø2.8<br />
3<br />
60<br />
55<br />
50<br />
45<br />
40<br />
35<br />
ø4.2<br />
ø3.2<br />
ø2.8<br />
3<br />
60<br />
55<br />
50<br />
45<br />
40<br />
35<br />
1 2 3 3<br />
ø4.2<br />
ø3.2<br />
ø2.8<br />
D4 D3 D2 D1<br />
/ 23 /<br />
Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff
Zygomatic<br />
Zygomatic Surgical Kit NM-X2118<br />
Step Drill for Zygoma, ø2.0, L 60mm<br />
Step Drill for Zygoma, ø2.8, L 60mm<br />
Step Drill for Zygoma, ø3.2, L 60mm<br />
Step Drill for Zygoma, ø2.0, L 80mm<br />
Step Drill for Zygoma, ø2.8, L 80mm<br />
Step Drill for Zygoma, ø3.2, L 80mm<br />
Diamond Burr, ø4.2mm, L 30mm, Fine<br />
Diamond Burr, ø4.2mm, L 30mm, Medium<br />
Diamond Burr, ø4.2mm, L 30mm, Coarse<br />
Depth Probe 35mm to 57.5mm<br />
Motor Mount 2.4mm, L 28mm<br />
Driver Hex 2.4mm, L 20mm<br />
Hand driver Star-Hex1.25, L 14.0mm, SS<br />
NM-D7020<br />
NM-D7028<br />
NM-D7032<br />
NM-D7120<br />
NM-D7128<br />
NM-D7132<br />
NM-D7201<br />
NM-D7202<br />
NM-D7203<br />
NM-X1028<br />
NMHX1015<br />
NMHX2620<br />
NM-X7007<br />
/ 24 / <strong>Implants</strong>
Zygomatic Step Drills<br />
0 D (mm) L (mm) Drill No. Item<br />
2.0<br />
2.8<br />
3.2<br />
40<br />
0 D (mm) L (mm) Item<br />
4.2 30<br />
Fine Grit<br />
Depth Probe NM-X1028<br />
1<br />
Zygomatic Burs for Groove Preparation<br />
Medium Grit<br />
Coarse Grit<br />
35 40 45 50 55 60<br />
Drilling Depth (mm)<br />
NM-D7520<br />
60 NM-D7020<br />
80 NM-D7120<br />
40<br />
2<br />
NM-D7528<br />
60 NM-D7028<br />
80 NM-D7128<br />
40<br />
3<br />
L<br />
NM-D7532<br />
60 NM-D7032<br />
80 NM-D7132<br />
NM-D7201<br />
NM-D7202<br />
NM-D7203<br />
/ 25 /<br />
Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff
MBI / MBI NC<br />
MBI & MBI NC are One-Piece, self-tapping<br />
<strong>Implants</strong>, with integrated ball attachment,<br />
for single-stage implantation to stabilize<br />
a tissue-supported denture. Designed<br />
for placement in a very narrow ridge.<br />
MBI & MBI NC features a unique thread<br />
for immediate insertion. The implants can<br />
be placed in all types of bone and can be<br />
subjected to immediate load.<br />
4<br />
H<br />
Material: Titanium (Ti6Al4V ELI)<br />
Treatment: RBM<br />
L<br />
1.7<br />
1.8<br />
4.2<br />
1.7<br />
1.8<br />
L<br />
L1<br />
D1<br />
D<br />
D<br />
Mini Ball Implant<br />
Drilling Speed (RPM)<br />
1200-<br />
1500<br />
1200-<br />
1500 900-1200<br />
Implant MBI-NMTV<br />
Drill Diameter ø1.2 ø1.5 ø2.0<br />
Drill Sequence*<br />
Bone type D1, D2<br />
6<br />
10<br />
16<br />
ø2.0 ø2.4 ø2.9<br />
Drilling Speed (RPM)<br />
1200-<br />
1500<br />
1200-<br />
1500<br />
1200-<br />
1500<br />
1200-<br />
1500<br />
Drill Diameter ø1.2 ø1.2 ø1.5 ø1.5<br />
Drill Sequence*<br />
Bone type D3, D4<br />
6<br />
10<br />
16<br />
ø2.0 ø2.4 ø2.9<br />
* The proposed procedure is only a recommendation and should not replace the doctor's judgment.<br />
MBI Torque Recommendations: Do not exceed 45 Ncm during implant placement.<br />
The implants may be placed in immediate function when good primary stability (above 35 Ncm) has been achieved and with appropriate occlusal loading.<br />
/ 26 / <strong>Implants</strong>
MBI<br />
<strong>Implants</strong> Ø D (mm) Ø D1 (mm) neck (H) (mm) L (mm) Item<br />
10 NM-V2010<br />
2.0 1.0 2.5<br />
2.4 1.5 2.5<br />
2.9 1.9 2.5<br />
MBI NC (Non Collar)<br />
<strong>Implants</strong> Ø D (mm) Ø D1 (mm) neck (H) (mm) L (mm) Item<br />
10 NMTV2010<br />
2.0 1.0 0<br />
2.4 1.5 0<br />
2.9 1.9 0<br />
MBI & MBI NC Components<br />
ø 4.3<br />
ø 3.4<br />
2.8<br />
2.3<br />
13 NM-V2013<br />
16 NM-V2016<br />
18 NM-V<strong>2018</strong><br />
10 NM-V2410<br />
13 NM-V2413<br />
16 NM-V2416<br />
18 NM-V2418<br />
10 NM-V2910<br />
13 NM-V2913<br />
16 NM-V2916<br />
18 NM-V2918<br />
13 NMTV2013<br />
16 NMTV2016<br />
18 NMTV<strong>2018</strong><br />
10 NMTV2410<br />
13 NMTV2413<br />
16 NMTV2416<br />
18 NMTV2418<br />
10 NMTV2910<br />
13 NMTV2913<br />
16 NMTV2916<br />
18 NMTV2918<br />
NM-T3201 NM-T3202 NM-T3203<br />
Metal Cap Extra Soft Nylon Cap Soft Nylon Cap<br />
NM-D2312 NM-D2315 NM-X1520 NM-X2415 NM-T6124 NM-T4410<br />
Drill<br />
Drill<br />
Motor Mount<br />
Driver<br />
Analog<br />
Transfer<br />
Ø 1.2mm<br />
Ø 1.5mm<br />
1.7mm<br />
1.7mm<br />
/ 27 /<br />
Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff
Mono<br />
L<br />
D1<br />
D<br />
Mono implants are specifically indicated for replacing<br />
maxillary lateral incisors and mandibular central and<br />
lateral incisors.<br />
The implants are cleared for immediate, non-occlusal<br />
provisionalization in single-tooth restorations.<br />
Multiple-unit restorations should be splinted together.<br />
In appropriate clinical conditions MONO <strong>Implants</strong><br />
may be loaded immediately.<br />
Material: Titanium (Ti6Al4V ELI)<br />
Treatment: RBM<br />
ONE-PIECE IMPLANT<br />
L 3 6.5<br />
2.15<br />
D2<br />
D1<br />
D<br />
2.15<br />
Drilling Speed (RPM)<br />
1200-<br />
1500<br />
1200-<br />
1500<br />
200-<br />
500<br />
900-<br />
1200<br />
200-<br />
500<br />
500-<br />
700<br />
200-<br />
500 400-700<br />
200-<br />
500<br />
Drill Diameter md ø1.5 ø2.0 ø2.0 ø2.8 ø2.8 ø3.2 ø3.2 ø3.65<br />
Drill Sequence*<br />
Bone type D1, D2<br />
6<br />
10<br />
16<br />
ø3.0 ø3.3 ø3.75 ø4.2 ø5.0<br />
Drilling Speed (RPM)<br />
1200-<br />
1500<br />
1200-<br />
1500<br />
200-<br />
500<br />
900-<br />
1200<br />
500-<br />
700<br />
500-<br />
700<br />
Drill Diameter md ø1.5 ø2.0 ø2.0 ø2.8 ø3.2<br />
Drill Sequence*<br />
Bone type D3, D4<br />
6<br />
10<br />
16<br />
ø3.0 ø3.3 ø3.75 ø4.2 ø5.0<br />
* The proposed procedure is only a recommendation and should not replace the doctor's judgment.<br />
The implants may be placed in immediate function when good primary stability (above 35 Ncm) has been achieved and with appropriate occlusal loading.<br />
/ 28 / <strong>Implants</strong>
Mono<br />
<strong>Implants</strong> Ø D (mm) ø D1 (mm) ø D2 (mm) L (mm) Item<br />
Bendable Mono<br />
Mono Components<br />
6<br />
10<br />
NM-D2315 NM-X1620 NM-X1018 NM-X1019 NM-X1720 NM-T6202 NM-T4420<br />
Drill<br />
Ø 1.5mm<br />
3.0 1.7 2.0<br />
3.3 2.0 2.0<br />
3.75 2.4 2.5<br />
4.2 2.9 2.8<br />
5.0 3.7 2.8<br />
Motor Mount<br />
2.15mm<br />
Driver<br />
2.15mm<br />
Driver<br />
2.15mm<br />
20<br />
10 NM-V3010<br />
11.5 NM-V3011<br />
13 NM-V3013<br />
16 NM-V3016<br />
10 NM-V3310<br />
11.5 NM-V3311<br />
13 NM-V3313<br />
16 NM-V3316<br />
10 NM-V3710<br />
11.5 NM-V3711<br />
13 NM-V3713<br />
16 NM-V3716<br />
10 NM-V4210<br />
11.5 NM-V4211<br />
13 NM-V4213<br />
16 NM-V4216<br />
18 NM-V4218<br />
10 NM-V5010<br />
11.5 NM-V5011<br />
13 NM-V5013<br />
<strong>Implants</strong> Ø D (mm) ø D1 (mm) ø D2 (mm) L (mm) Item<br />
3.75 2.4 1.8<br />
4.2 2.9 1.8<br />
11.5 NMBV3711<br />
13 NMBV3713<br />
16 NMBV3716<br />
11.5 NMBV4211<br />
13 NMBV4213<br />
16 NMBV4216<br />
Driver<br />
2.15mm<br />
Analog<br />
Transfer<br />
/ 29 /<br />
Mono MBI & MBI NC Zygomatic PteryFit PteryCore Cortical Onyx Tuff TT Tuff Pro Tuff
Packaging<br />
Implant Label<br />
Use by date<br />
Sterile package unless opened<br />
or damaged<br />
Sterilized using irradiation<br />
Do not re-use<br />
Do not resterilize<br />
Prosthetic Label<br />
Consult accompanying<br />
documents<br />
Caution: Federal law restricts this<br />
device to sale by or on the order of<br />
a licensed healthcare practitioner<br />
CEpartner4U<br />
Esdoornlaan 13, 3951 db Maarn,<br />
The Netherlands<br />
www.cepartner4u.eu<br />
/ 30 / <strong>Implants</strong>
Prosthetics<br />
/ 31 /
Prosthetic Workflow<br />
Pages 34 Page 35-37<br />
Healing Cap<br />
Impression Components<br />
Snap-On Transfer<br />
Clip-On Tray Transfer<br />
or<br />
Open Tray Transfer<br />
Closed Tray Transfer<br />
or<br />
Analog<br />
Prosthetic Components Drivers<br />
NM-X1207 NM-X1210 NM-X1215 NM-X1006 NM-X1007 NM-X1011 NM-X1008 NM-X1009 NM-X1010<br />
Driver<br />
1.25mm<br />
Hand Driver<br />
1.25mm<br />
Motor Mount<br />
1.25mm<br />
/ 32 / Prosthetics
Page 38-45 Page 46-47 Page 50-56<br />
Page 58-61<br />
Cement Retained<br />
Restorations<br />
CAD/CAM<br />
Screw Retained<br />
Restorations<br />
Removable<br />
Restorations<br />
Temporary Abutment<br />
Scan Bodies<br />
Straight Multi-Unit<br />
Ball Vari-Connect<br />
or<br />
or<br />
or<br />
Straight Abutment<br />
Titanium Base<br />
Angulated Multi-Unit<br />
Flat Vari-Connect<br />
or<br />
or<br />
or<br />
Angulated Abutment<br />
or<br />
Esthetic Screw<br />
Abutment<br />
Ball Attachment<br />
or<br />
Zirconia Abutment<br />
Flat Attachment<br />
or<br />
Castable Abutment<br />
Multi-Unit & Vari-Connect Drivers<br />
NM-X1016 NM-X1017 NM-X7006 NM-X7007 NM-X7011 NM-X7008 NM-X7009 NM-X7010<br />
Driver<br />
2.0mm<br />
Hand Driver<br />
1.25mm<br />
Motor Mount<br />
1.25mm<br />
/ 33 /
Healing Caps<br />
Healing caps prepare the site for the superstructure<br />
insertion and “shapes” the soft tissue surrounding the<br />
implant. Selecting the correct healing cap depends on<br />
the thickness of the mucosa. Wide healing caps are used<br />
for soft-tissue contouring of molars and premolars.<br />
Recommendation: Hand-tighten using a 1.25 mm hex.<br />
driver or a motor mount with a force of 10 Ncm.<br />
Material: Titanium (Ti6Al4V ELI)<br />
L<br />
Healing Cap<br />
3.750<br />
D<br />
1.28<br />
L (mm) Ø 3.8 (mm) Ø 4.6 (mm) Ø 5.5 (mm) Ø 6.3 (mm)<br />
2<br />
NM-H3802 NM-H4602 NM-H5502 -<br />
3<br />
NM-H3803 NM-H4603 NM-H5503 NM-H6303<br />
4<br />
NM-H3804 NM-H4604 NM-H5504 NM-H6304<br />
5<br />
NM-H3805 NM-H4605 NM-H5505 NM-H6305<br />
6<br />
NM-H3806 NM-H4606 NM-H5506 NM-H6306<br />
7<br />
NM-H3807 NM-H4607 NM-H5507 NM-H6307<br />
/ 34 / Prosthetics
Open & Closed Tray Transfers<br />
Transfers are designed for impressions using<br />
the open-tray technique when the retentions are<br />
sharp, and for the closed-tray technique when<br />
the retentions are round. The body of the transfer<br />
is made of stainless steel; the screws are made<br />
of titanium alloy.<br />
L<br />
Transfer T40XX<br />
Accessories<br />
Material: Stainless Steel<br />
2.42<br />
3.75<br />
D<br />
Open Tray Transfer<br />
Transfer Ø D (mm) L (mm)<br />
NM-T4008<br />
4.75 8<br />
Closed Tray Transfer<br />
Transfer Ø D (mm) L (mm)<br />
NM-T3601<br />
4.75 8<br />
Cement Retained<br />
Restorations<br />
NM-S1610<br />
Screw 16mm<br />
Included with all<br />
transfers above &<br />
available separately<br />
NM-S1307<br />
Screw 13mm<br />
Included with all<br />
transfers above &<br />
available separately<br />
NM-T4203<br />
NM-T4201<br />
3.85 12<br />
4.3 12<br />
NM-T3507<br />
NM-T3511<br />
3.85 12<br />
4.5 12<br />
Screw Retained<br />
Restorations<br />
NM-T4012<br />
4.75 12<br />
NM-S1610<br />
Screw 16mm<br />
Included with all<br />
transfers above &<br />
available separately<br />
NM-S2418<br />
Screw 24mm<br />
Included with all<br />
transfers above &<br />
available separately<br />
Non-Hexed Transfer<br />
Transfer Ø D (mm) L (mm)<br />
NM-T4204<br />
NM-S2418<br />
3.85 12<br />
Screw 24mm<br />
Included with all<br />
transfers above &<br />
available separately<br />
/ 35 /<br />
Removable<br />
Restorations
Snap-On Transfer<br />
The Snap-On Transfer is made of titanium alloy<br />
TI-6AL-4V and designed for impressions using the<br />
closed-tray technique, in conjunction with the cap<br />
T4402. The cap remains in the impression tray after<br />
it is removed from the mouth. It is also possible to<br />
use this type of transfer as esthetic abutments.<br />
33%<br />
Long Cap for transfer<br />
8<br />
Transfer T380X<br />
Material: Titanium (Ti6Al4V ELI)<br />
L<br />
L<br />
D<br />
2.42<br />
3.75<br />
D<br />
Plastic Cap for Snap-On Transfer<br />
Transfer Ø D (mm) L1 (mm)<br />
Cap Ø D (mm) L (mm)<br />
4.8 2<br />
4.8 11<br />
NM-T3802<br />
NM-T4402<br />
4.8 3<br />
NM-T3803<br />
4.8 4<br />
NM-T3804<br />
4.8 5<br />
NM-T3805<br />
4.8 6<br />
NM-T3806<br />
NM-S8324<br />
Included with all<br />
abutments<br />
above & available<br />
separately<br />
/ 36 / Prosthetics
Clip-On Transfer<br />
A clip-on connection transfer for impressions without<br />
a screw has a hexagonal lock to ensure a tight fit. It is<br />
especially effective with molars and premolars, where<br />
there is a lack of space, and where working with a<br />
driver is difficult. It is sufficient to use this transfer for<br />
all types of impressions as the lack of screws saves<br />
significant amount of time.<br />
Material: Stainless Steel<br />
L<br />
Transfer T34XX<br />
2.42<br />
Accessories<br />
3.75<br />
D<br />
Transfer Ø D (mm) L (mm)<br />
4.7 9<br />
Cement Retained<br />
Restorations<br />
NM-T3409<br />
NM-T3413<br />
Analog<br />
4.7 13<br />
Screw Retained<br />
Restorations<br />
Analog<br />
3.75<br />
2.43<br />
Analog Ø D (mm) L (mm)<br />
4 12.7<br />
L<br />
NM-T6004<br />
NM-T6005<br />
5 12.7<br />
The analog is made of stainless steel and is used<br />
in the preparation of laboratory models.<br />
Material: Stainless Steel<br />
D<br />
Removable<br />
Restorations<br />
/ 37 /
Temporary Abutments<br />
PEEK (polyetheretherketone) is a high-grade<br />
thermoplastic polymer which is certified for<br />
medical use. PEEK is characterized by a superior<br />
combination of strength, elasticity and resilience.<br />
PEEK is one of the most chemically resistant<br />
materials, Biocompatible and esthetic with low<br />
electrical conductivity. PEEK polymer is well suited<br />
for use in the oral cavity.<br />
Material: PEEK<br />
L<br />
2<br />
L1<br />
Abutment Anatomic<br />
A46XX<br />
2.42<br />
3.750<br />
D<br />
Technical Data:<br />
• Can be sterilized without changing the mechanical properties or biocompatibility violations.<br />
• Does not create artifacts in X-ray irradiation procedures, magnetic resonance imaging (MRI), and computed<br />
tomography (CT).<br />
• Has high compressive strength.<br />
• Possesses excellent mechanical properties such as stiffness and strength.<br />
• Has proven biocompatibility for both hard and soft tissue.<br />
• Does not contain metal additives to prevent ion exchange in the mouth.<br />
• Is a natural color, a superior esthetic advantage.<br />
Straight L (mm) Angulated 15° Angulated 25° L (mm) L1 (mm)<br />
9 9.5 1<br />
NM-C6001 NM-C5001 NM-C5201<br />
10 10.5 2<br />
NM-C6002 NM-C5002 NM-C5202<br />
11 11.5 3<br />
NM-C6003 NM-C5003 NM-C5203<br />
/ 38 / Prosthetics
Temporary Abutments<br />
The titanium Temporary Abutments are<br />
designed with deep retention grooves,<br />
for the acrylic prosthesis to hold to.<br />
The abutments are available hexed and<br />
non-hexed.<br />
L<br />
Straight Soulder A5001<br />
3.2<br />
Accessories<br />
Material: Titanium (Ti6Al4V ELI)<br />
L1<br />
Hexed Non-Hexed Short Non-Hexed L (mm) L1 (mm) Ø D (mm)<br />
2.42<br />
3.75<br />
D<br />
9.5 1.7 4.4<br />
Cement Retained<br />
Restorations<br />
NM-A5001 NM-A5002 -<br />
NM-A5101 - NM-A5102<br />
Included with all abutments above & available separately<br />
NM-S8324<br />
9.5 1.7 3.8<br />
Removable<br />
Restorations<br />
Screw Retained<br />
Restorations<br />
/ 39 /
Straight Abutments<br />
A wide variety of titanium straight abutments are<br />
available for use in different situations. These<br />
abutments remain stable, even when their wall<br />
thickness is reduced to 0.1 mm. They are used in the<br />
fabrication of cement-retained restorations, single<br />
crowns or bridges.<br />
Recommendation: Tighten the screw at a torque<br />
between 25 to 30 Ncm.<br />
Material: Titanium (Ti6Al4V ELI)<br />
L<br />
2<br />
L1<br />
Abutment Anatomic<br />
A46XX<br />
2.42<br />
3.750<br />
D<br />
Anatomic Ø D (mm) L (mm) L1 (mm)<br />
Shoulder Ø D (mm) L (mm) L1 (mm)<br />
NM-A4601<br />
5.2 9 1<br />
NM-A4801<br />
4.5 8.5 1<br />
NM-A4602<br />
5.2 10 2<br />
NM-A4802<br />
4.5 9.5 2<br />
NM-A4603<br />
5.2 11 3<br />
NM-A4803<br />
4.5 10.5 3<br />
NM-A4604<br />
5.2 12 4<br />
NM-A4804<br />
4.5 11.5 4<br />
NM-S8324<br />
Included with all abutments<br />
& available separately<br />
NM-C1005<br />
Available separately<br />
/ 40 / Prosthetics
Standard Ø D (mm) L (mm)<br />
NM-A5908<br />
4.5 8.5<br />
Standard Ø D (mm) L (mm)<br />
NM-A5601<br />
4.5 8.5<br />
Accessories<br />
NM-A5909<br />
4.5 9.5<br />
NM-A5602<br />
4.5 10.5<br />
NM-A5911<br />
4.5 11.5<br />
4.5 12.5<br />
Narrow Ø D (mm) L (mm)<br />
NM-A6006<br />
3.8 6<br />
3.8 8<br />
Cement Retained<br />
Restorations<br />
NM-A5912<br />
NM-A6008<br />
Shoulder, Narrow Ø D (mm) L (mm) L1 (mm)<br />
Mega Ø D (mm) L (mm)<br />
NM-A5300<br />
NM-A5301<br />
3.75 8.5 0.5<br />
3.75 8.5 1.5<br />
NM-A5515<br />
9 15<br />
Screw Retained<br />
Restorations<br />
3.75 8.5 2.5<br />
NM-A5302<br />
Wide Ø D (mm) L (mm)<br />
Mega, Co-Cr Ø D (mm) L (mm)<br />
NM-A5709<br />
5.5 9<br />
5.5 11<br />
15 15<br />
Removable<br />
Restorations<br />
NM-A5711<br />
NM-A5516<br />
/ 41 /
Angulated Abutments<br />
Angulated abutments are used when a change to<br />
the axis of the implant is required. Normally used<br />
for constructing cement-retained single crowns or<br />
bridges. The abutments are available with angles<br />
of 15° and 25° degrees.<br />
Recommendation: Tighten the screw at a torque<br />
between 25 to 30 Ncm.<br />
L<br />
Angular Abutment Anatomic 15<br />
A24XX<br />
L1<br />
15°<br />
Material: Titanium (Ti6Al4V ELI)<br />
2<br />
2.42<br />
3.75<br />
D<br />
Anatomic<br />
Angulated 15° Angulated 25° Ø D (mm) L (mm) L1 (mm)<br />
5.4 9.5 1<br />
NM-A2401<br />
NM-A2601<br />
5.4 10.5 2<br />
NM-A2402<br />
NM-A2602<br />
5.4 11.5 3<br />
NM-A2403<br />
NM-A2603<br />
5.4 12.5 4<br />
NM-A2404<br />
NM-A2604<br />
/ 42 / Prosthetics
Standard<br />
Angulated 15° Angulated 25° Ø D (mm) L (mm)<br />
4.5 9<br />
Narrow<br />
Angulated 15° Angulated 25° Ø D (mm) L (mm)<br />
4 9<br />
Accessories<br />
NM-A3209<br />
NM-A3409<br />
NM-A3609<br />
NM-A3809<br />
4.5 11<br />
NM-A3211<br />
NM-A3411<br />
Narrow Top<br />
Angulated 15° Angulated 25° L (mm)<br />
9<br />
Included with all abutments<br />
& available separately<br />
NM-A2809<br />
NM-A3009<br />
NM-S8324<br />
Removable<br />
Restorations<br />
Screw Retained<br />
Restorations<br />
Cement Retained<br />
Restorations<br />
/ 43 /
Titanium Base Zirconia Abutments<br />
Zirconia is an esthetic alternative material for the<br />
traditional titanium abutments. The abutments are<br />
available as fully cast zirconia or with a titanium<br />
base in a wide variety of shapes and sizes.<br />
L<br />
Angular Abutment Anatomic 15<br />
A24XX<br />
15°<br />
Material: Zirconium<br />
2<br />
L1<br />
2.42<br />
3.75<br />
D<br />
Anatomic<br />
Straight L (mm) L1 (mm) Angulated 15° Angulated 25° L (mm) L1 (mm)<br />
8.5 0.5 9 0.5<br />
NM-Z5600 NM-Z3400 NM-Z3600<br />
9 1 9.5 1<br />
NM-Z5601 NM-Z3401 NM-Z3601<br />
10 2 10.5 2<br />
NM-Z5602 NM-Z3402 NM-Z3602<br />
11 3 11.5 3<br />
NM-Z5603 NM-Z3403 NM-Z3603<br />
Titanium<br />
Base<br />
for Zirconia<br />
NM-S1001<br />
NM-Z1001<br />
/ 44 / Prosthetics
Castable Abutments<br />
Plastic Castable Abutments are intended for use<br />
by the technician for simple casting of custom-made<br />
abutments for constructing the prosthetic restoration.<br />
Plastic Castable Abutments on Titanium Bases<br />
enable the dental laboratory to cast on an accurate<br />
Titanium base. The machined Titanium base provides<br />
an accurate fit to the implant.<br />
L<br />
Angular Abutment Anatomic 15<br />
A24XX<br />
L1<br />
15°<br />
Accessories<br />
Material: Delrin<br />
2<br />
2.42<br />
3.75<br />
D<br />
Straight L (mm) Angulated 15° Angulated 25° L (mm) L1 (mm)<br />
9 9.5 1<br />
NM-C4001 NM-C3001 NM-C3201<br />
Cement Retained<br />
Restorations<br />
10 10.5 2<br />
NM-C4002 NM-C3002 NM-C3202<br />
11 11.5 3<br />
NM-C4003 NM-C3003 NM-C3203<br />
Hexed Non-Hexed L (mm) Ø D (mm) Angulated 15° L (mm) Ø D (mm)<br />
8.5 4.5 8.5 4.5<br />
Screw Retained<br />
Restorations<br />
NM-C2004 NM-C2003 NM-C2005<br />
10.5 3.25<br />
NM-C1002<br />
NM-C1001<br />
Titanium Base Co-Cr Base L (mm) Ø D (mm)<br />
NM-C2001 NM-C2002<br />
10.5 4.5<br />
NM-S8324<br />
Included with all<br />
abutments & available<br />
separately<br />
Removable<br />
Restorations<br />
/ 45 /
CAD/CAM Components<br />
The CAD/CAM components are especially designed<br />
for CAD/CAM fabrication of individual abutments.<br />
Recommendation:<br />
Tighten the screw NM-S8324 at a torque between 25 to 30 Ncm.<br />
Tighten the screw NM-S7102 at a torque of 15 Ncm.<br />
Material: Titanium (Ti6Al4V ELI) & PEEK<br />
Scan for downloading<br />
CAD/CAM library<br />
Scan Bodies Ø D (mm) L (mm)<br />
4.0 7<br />
NM-C9007<br />
L<br />
4.5<br />
4.0 10<br />
NM-C9010<br />
2.42<br />
3.75<br />
D<br />
4.0 13<br />
NM-C9013<br />
Single Unit Titanium Base Ø D (mm) L (mm)<br />
NM-C2201<br />
L<br />
4.8 4.5<br />
NM-C2201<br />
2.42<br />
3.75<br />
D<br />
Multiple Units Titanium Base Ø D (mm) L (mm)<br />
Flat Platform Base for CAD/CAM<br />
NM-C2202<br />
4.8 4.5<br />
2.42<br />
3.75<br />
D<br />
L<br />
NM-S8324<br />
Included with all abutments<br />
& available separately<br />
/ 46 / Prosthetics
Multi-Unit Scan Bodies Ø D (mm) L (mm)<br />
4.9 7<br />
Accessories<br />
NM-C9107<br />
D1<br />
4.9 10<br />
L<br />
NM-C9110<br />
D<br />
4.9 13<br />
NM-C9113<br />
Multi-Unit Titanium Base Ø D (mm) L (mm)<br />
4.9 4.5<br />
L<br />
Cement Retained<br />
Restorations<br />
D<br />
NM-C7124<br />
Included with all abutments<br />
NM-S7102<br />
Individual Blank for Milling Ø D (mm) L (mm)<br />
8<br />
M5<br />
Screw Retained<br />
Restorations<br />
10 26<br />
L<br />
NM-A5517<br />
NM-S8324<br />
Included with all abutments<br />
& available separately<br />
3.75<br />
D<br />
2.42<br />
Removable<br />
Restorations<br />
/ 47 /
IMMEDIATE<br />
LOADING<br />
A NEW SMILE<br />
IN ONE DAY<br />
/ 48 / Prosthetics
Multi-Unit<br />
/ 49 /
Multi-Unit | Straight & Angulated<br />
The Multi-Unit system provides a<br />
solution for screw-retained prostheses<br />
even on complicated-to-restore implants<br />
(for example, multiple tilted implants).<br />
The Multi-Unit system comprises a<br />
full range of sizes for both the upper<br />
and lower jaws. Straight, 17°, 30°, 45°,<br />
52° and 60° adaptors, in a variety of<br />
heights, connects to a wide range of<br />
complementary products.<br />
L1<br />
Multi Unit Abutment<br />
A710X<br />
2.0<br />
L1<br />
Multi Unit Base<br />
A711X<br />
a<br />
Material: Titanium (Ti6Al4V ELI)<br />
3.75<br />
4.9<br />
2.42<br />
3.75<br />
Straight<br />
L (mm)<br />
Angulated<br />
17 °<br />
Angulated<br />
30°<br />
Angulated<br />
45°<br />
Angulated<br />
52°<br />
Angulated<br />
60°<br />
L (mm)<br />
1<br />
NM-A7101<br />
2<br />
2<br />
NM-A7102<br />
NM-A7112<br />
3<br />
3<br />
NM-A7103<br />
NM-A7113<br />
NM-A7133<br />
4<br />
4<br />
NM-A7104<br />
NM-A7134<br />
NM-A7144<br />
5<br />
5<br />
NM-A7105<br />
NM-A7152<br />
NM-A7160<br />
NM-X7100<br />
Included with all multi-unit bases<br />
Included with all<br />
multi-unit bases<br />
NM-S7101<br />
NM-X7101<br />
Recommendation: Tighten the<br />
base at a torque of 25 Ncm.<br />
Recommendation: Tighten the screw at a torque of 20 Ncm.<br />
/ 50 / Prosthetics
Multi-Unit System<br />
60°<br />
52°<br />
45°<br />
30°<br />
17°<br />
0°<br />
Entire <strong>Product</strong> Line<br />
for Immediate Loading<br />
Removable<br />
Restorations<br />
Screw Retained<br />
Restorations<br />
Cement Retained<br />
Restorations<br />
Accessories<br />
/ 51 /
Multi-Unit Components<br />
Healing Cap<br />
Abutments<br />
Passive Fit Castable<br />
Abutment Kit<br />
Screw<br />
NM-S7102<br />
Screw*<br />
NM-S7102<br />
Screw*<br />
NM-S7102<br />
Healing Cap<br />
Ø 4.9mm H 4.3mm<br />
NM-H7101<br />
Ø 3.3 mm<br />
Universal Abutment<br />
Ø 4.9mm H 12mm<br />
NM-T7121<br />
Universal Abutment<br />
Ø 4.9mm H 12mm<br />
NM-T7121<br />
Transfers & Analog<br />
Screw<br />
L 13mm<br />
NM-S7111<br />
Open Tray<br />
Ø 4.9mm H 11mm<br />
Ø 3.8 mm<br />
Screw*<br />
NM-S7102<br />
Wide Universal<br />
Abutment<br />
Ø 4.9mm H 12mm<br />
NM-T7123<br />
Castable Sleeve<br />
Ø 4.9mm H 10.5mm<br />
NM-C7120<br />
Castable Sleeve<br />
Positioner<br />
Ø 4.9mm H 10mm<br />
NM-T7122<br />
NM-T7111<br />
Screw*<br />
NM-S7102<br />
The Passive Fit Castable Abutment<br />
Kit consists of three parts aimed for<br />
the fabrications of accurate metal<br />
reinforced prostheses.<br />
Plastic Cap<br />
Ø 4.9mm H 11mm<br />
NM-T4402<br />
Screw<br />
Castable Abutment<br />
Ø 4.9mm H 12mm<br />
NM-C7121<br />
The Castable Sleeve Positioner is<br />
used for locating the Castable Sleeve<br />
on the plaster model, ensuring passive<br />
fit of the fabricated metal cast when<br />
cemented to the Titanium Abutments.<br />
NM-S7102<br />
* Recommendation: Tighten the screw<br />
at a torque of 15 Ncm.<br />
* Recommendation: Tighten the screw at a<br />
torque of 15 Ncm.<br />
Closed Tray<br />
Ø 4.9mm H 8mm<br />
2 mm<br />
NM-T7102<br />
Titanium Base<br />
Scan Bodies<br />
Screw*<br />
Ø 4.9mm H 7mm<br />
Analog<br />
Ø 4.9mm<br />
NM-S7102<br />
NM-C9107<br />
NM-T7151<br />
Ø 4.9mm H 4.5mm<br />
Ø 4.9mm H 10mm<br />
NM-C7124<br />
NM-C9110<br />
* Recommendation: Tighten the screw<br />
at a torque of 15 Ncm.<br />
Ø 4.9mm H 13mm<br />
NM-C9113<br />
/ 52 / Prosthetics
Multi-Unit Drivers<br />
Straight Multi-Unit Drivers<br />
Star Hex. Drivers<br />
Accessories<br />
Short Driver<br />
2.0mm L 6mm<br />
NM-X1016<br />
Short Driver<br />
1.25mm L 7mm<br />
NM-X7006<br />
Long Driver<br />
2.0mm L 10mm<br />
NM-X1017<br />
Straight Multi-Unit<br />
Motor Mounts<br />
Short Motor Mount<br />
2.0mm L 20mm<br />
NM-X1120<br />
Long Driver<br />
1.25mm L 14mm<br />
NM-X7007<br />
Long Driver<br />
1.25mm L 20mm<br />
NM-X7011<br />
Cement Retained<br />
Restorations<br />
Long Motor Mount<br />
2.0mm L 25mm<br />
NM-X1125<br />
Star Hex. Motor Mounts<br />
Motor Mount<br />
1.25mm L 20mm<br />
NM-X7008<br />
Motor Mount<br />
1.25mm L 25mm<br />
NM-X7009<br />
Motor Mount<br />
1.25mm L 35mm<br />
NM-X7010<br />
Removable<br />
Restorations<br />
Screw Retained<br />
Restorations<br />
/ 53 /
Multi-Unit Protocol<br />
Assembly of a Straight<br />
Multi-Unit Base<br />
Assembly of Angled<br />
Multi-Unit Base<br />
Healing Cap Assembly<br />
1<br />
Adjust the straight<br />
Multi-Unit Base to<br />
the implant by using<br />
the plastic handle.<br />
1<br />
use the Angulated<br />
Guide Pin to choose<br />
the right correction<br />
angle.<br />
2<br />
Remove the handle.<br />
2<br />
Adjust the Multi-Unit<br />
base to the<br />
appropriate angle.<br />
Use the handle as an<br />
indicator for the final<br />
screw emergence.<br />
Impression<br />
Choose the desired<br />
impression technique:<br />
For closed tray<br />
choose Snap-On-<br />
Transfer.<br />
3<br />
3<br />
Tighten the base<br />
at 25 Ncm, with<br />
a 2.0mm Straight<br />
Multi-Unit Driver.<br />
Tighten the<br />
base at 20 Ncm,<br />
with a 1.25mm<br />
Hex Driver or<br />
a Star Driver.<br />
or<br />
For open tray<br />
technique choose<br />
conventional<br />
Transfer.<br />
4<br />
Remove the handle<br />
by unscrewing it out.<br />
/ 54 / Prosthetics
Immediate Loading<br />
(Fabrication of the temporary bridge)<br />
Laboratory Phase<br />
Passive Fit Castable<br />
Abutment Kit<br />
1 1<br />
Assemble the<br />
Titanium Sleeve on<br />
the Multi-Unit base<br />
and tighten the<br />
screw at 15 Ncm.<br />
2<br />
Mount the Plastic<br />
Sleeve on the<br />
Multi-Unit analog<br />
and tighten with the<br />
screw.<br />
2<br />
The Passive Fit Castable<br />
Abutment Kit consists of<br />
three parts aimed for the<br />
fabrication of accurate metal<br />
reinforced prostheses.<br />
The uniquely designed<br />
Castable Sleeve Positioner<br />
is used for locating the<br />
Castable Sleeve on the<br />
plaster model, ensuring<br />
passive fit of the fabricated<br />
metal cast when cemented<br />
to the Titanium Abutments.<br />
Attach the preprepared<br />
provisional<br />
acrylic prosthesis<br />
Splint the sleeves.<br />
3<br />
Carve the Sleeves to<br />
the desired shape.<br />
4<br />
Invest and cast the<br />
metal frame of the<br />
prosthesis.<br />
/ 55 /
Esthetic Screw Abutments<br />
Esthetic Screw Abutment is designed for the screw<br />
retained rehabilitation process on single or multiple units.<br />
NM-E10XX<br />
The height of the abutment is selected according to the<br />
thickness of the mucosa.<br />
The Esthetic Screw Abutment base is supplied with<br />
an appropriate screw adjusted to the height of the<br />
abutment together with a plastic sleeve for casting.<br />
2.1<br />
L<br />
Sleeves are available with or without internal hex.<br />
Material: Titanium (Ti6Al4V ELI)<br />
2.42<br />
3.75<br />
4.7<br />
Base<br />
L (mm)<br />
Screw<br />
L (mm)<br />
0.5<br />
10.5<br />
NM-E1005<br />
NM-S1002<br />
1.5<br />
11.5<br />
NM-E1015<br />
NM-S1102<br />
2.5<br />
12.5<br />
NM-E1025<br />
NM-S1202<br />
Hexed Non-Hexed L (mm)<br />
12<br />
NM-C1015<br />
NM-C1007<br />
/ 56 / Prosthetics
Vari-Connect<br />
/ 57 /
Vari-Connect<br />
The Vari-Connect system presents a complete solution for removable prostheses on tilted implants. It provides<br />
all the required equipment for removable prostheses, both on ball attachments and flat attachments, covering<br />
a wide range of possible situations. Straight, 17°, 30° and 45° adaptors are available. Complementary products<br />
are fixed to the adaptors by the adaptor thread.<br />
Material: Titanium (Ti6Al4V ELI)<br />
Multi Unit Base<br />
A72XX<br />
Ax<br />
L<br />
2.42<br />
3.75<br />
Angulated 17 ° Angulated 30° Angulated 45° L (mm)<br />
2<br />
NM-A7212 - -<br />
3<br />
NM-A7213 NM-A7233 -<br />
4<br />
- NM-A7234 NM-A7244<br />
Included with all vari-connect bases<br />
NM-S7101<br />
NM-X7101<br />
Recommendation: Tighten the screw at a torque of 30 Ncm.<br />
/ 58 / Prosthetics
Vari-Connect Components<br />
Healing Cap<br />
Ball-Connect<br />
Flat-Connect<br />
Accessories<br />
Screw<br />
NM-S7102<br />
Ball-Connect<br />
Ø 4.9mm, H 2mm<br />
NM-T7262<br />
Flat-Connect<br />
Ø 4.9mm, H 3mm<br />
NM-T7273<br />
Healing Cap<br />
Ø 4.9mm H 4.3mm<br />
Ball-Connect<br />
Ø 4.9mm, H 3mm<br />
Flat-Connect<br />
Ø 4.9mm, H 4mm<br />
NM-H7101<br />
NM-T7263<br />
NM-T7274<br />
Transfers & Analog<br />
Screw<br />
L 13mm<br />
NM-S7111<br />
Open Tray<br />
Ø 4.9mm H 11mm<br />
NM-T7111<br />
Plastic Cap<br />
Ø 4.9mm H 11mm<br />
NM-T4402<br />
Screw<br />
NM-S7102<br />
Ball-Connect<br />
Ø 4.9mm, H 4mm<br />
NM-T7264<br />
Metal Cap<br />
Ø 5mm, H 3.2mm<br />
NM-T3001<br />
Nylon Extra Soft Cap<br />
NM-T3002<br />
Nylon Soft Cap<br />
NM-T3003<br />
Nylon Standard Cap<br />
NM-T3004<br />
Metal Cap<br />
Ø 5.5mm, H 2.3mm<br />
NM-T3010<br />
Extra Soft Nylon Cap<br />
NM-T3015<br />
Soft Nylon Cap<br />
NM-T3016<br />
Standard Nylon Cap<br />
NM-T3017<br />
High Retention<br />
Nylon Cap<br />
NM-T3018<br />
Laboratory Cap<br />
NM-T3019<br />
Sealing Disc<br />
NM-T1824<br />
Available as Set NM-T3099<br />
Cement Retained<br />
Restorations<br />
Screw Retained<br />
Restorations<br />
Closed Tray<br />
Ø 4.9mm H 8mm<br />
Star Hex. Drivers<br />
Star Hex. Motor Mounts<br />
2mm<br />
NM-T7102<br />
Short Driver<br />
1.25mm L 7mm<br />
Motor Mount<br />
1.25mm L 20mm<br />
NM-X7006<br />
NM-X7008<br />
Analog<br />
Ø 4.9mm<br />
Long Driver<br />
1.25mm L 14mm<br />
Motor Mount<br />
1.25mm L 25mm<br />
NM-T7251<br />
NM-X7007<br />
Long Driver<br />
1.25mm L 20mm<br />
NM-X7011<br />
NM-X7009<br />
Motor Mount<br />
1.25mm L 35mm<br />
NM-X7010<br />
Removable<br />
Restorations<br />
/ 59 /
Ball Attachment<br />
The ball attachment superstructure is intended to<br />
secure a removable prosthesis. The attachment is<br />
used in conjunction with a stainless steel cap and an<br />
intermediate Nylone insert.<br />
Material: Titanium (Ti6Al4V ELI)<br />
L<br />
Ball Attachment<br />
2.5<br />
1.28<br />
3.75<br />
Ball Attachment<br />
L (mm)<br />
Ball Attachment<br />
L (mm)<br />
0.5<br />
4<br />
NM-T1200<br />
NM-T1204<br />
1<br />
5<br />
NM-T1201<br />
NM-T1205<br />
2<br />
6<br />
NM-T1202<br />
NM-T1206<br />
3<br />
NM-T1203<br />
Caps for 2.5mm Ball Attachment<br />
Metal Extr Soft Nylon Soft Nylon Standard Nylon<br />
ø 5<br />
3.2<br />
NM-T3001 NM-T3002 NM-T3003 NM-T3004<br />
/ 60 / Prosthetics
2.1<br />
Flat Attachment<br />
L 2<br />
The flat attachment superstructure is<br />
intended to secure a removable prosthesis.<br />
The attachment is used in conjunction with<br />
a stainless steel cap and an intermediate<br />
Nylone insert.<br />
2<br />
L<br />
Flat Attachment<br />
2.1<br />
3.75<br />
1.52<br />
Accessories<br />
Material: Titanium (Ti6Al4V ELI)<br />
3.75<br />
Flat Attachment<br />
L (mm)<br />
0.5<br />
Flat Attachment<br />
1.52<br />
L (mm)<br />
3<br />
Cement Retained<br />
Restorations<br />
NM-T1100<br />
NM-T1103<br />
1<br />
4<br />
NM-T1101<br />
NM-T1102<br />
2<br />
NM-T1104<br />
NM-T1105<br />
5<br />
Screw Retained<br />
Restorations<br />
Set NM-T3099<br />
Caps for Flat Attachment<br />
Metal<br />
Extra Soft<br />
Nylon<br />
Soft Nylon<br />
Standard<br />
Nylon<br />
High<br />
Retention<br />
Nylon<br />
Laboratory<br />
Sealing Disc<br />
NM-T3010 NM-T3015 NM-T3016 NM-T3017 NM-T3018 NM-T3019 NM-T1824<br />
Removable<br />
Restorations<br />
/ 61 /
Instruments<br />
/ 63 /
Drills Workflow<br />
Material: Stainless Steel<br />
Page 65<br />
Page 66<br />
Page 67<br />
Page 68<br />
Standard / Short<br />
Long<br />
Conical<br />
Complementary<br />
Drilling Tools<br />
Drills Color Code<br />
Ø 2.0<br />
Laser Mark<br />
Ø 2.8<br />
Ø 3.2<br />
Color Code<br />
Ø 3.65<br />
Ø 4.2<br />
Ø 5.2<br />
16<br />
13<br />
11.5<br />
10<br />
8<br />
6<br />
Depth Groove (mm)<br />
/ 64 / Instruments
Drills<br />
Drills<br />
Standard Drills<br />
Ø D (mm)<br />
External Irrigation<br />
2.0 NM-D1220<br />
2.5 NM-D1225<br />
2.8 NM-D1228<br />
3.2 NM-D1232<br />
Drivers<br />
3.65 NM-D1236<br />
4.2 NM-D1242<br />
5.2 NM-D1252<br />
Short Drills<br />
Ø D (mm) External Irrigation<br />
Tools<br />
2.0 NM-D1420<br />
2.8 NM-D1428<br />
3.2 NM-D1432<br />
3.65 NM-D1436<br />
4.2 NM-D1442<br />
5.2 NM-D1452<br />
Kits<br />
/ 65 /
Drills<br />
Long Drills<br />
Ø D (mm)<br />
Item<br />
2.3 NM-D7423<br />
2.8 NM-D7428<br />
3.2 NM-D7432<br />
3.65 NM-D7436<br />
Drills Color Code<br />
3.2<br />
Laser Mark<br />
Color Code<br />
Ø 2.3<br />
Ø 2.8<br />
Ø 3.2<br />
Ø 3.65<br />
25<br />
22<br />
20<br />
18<br />
15<br />
13<br />
11.5<br />
Depth Groove (mm)<br />
/ 66 / Instruments
Drills<br />
Conical Drills<br />
Ø D1-D2 (mm)<br />
External Irrigation<br />
1.8-2.4 NM-D3018<br />
2.0-3.2 NM-D3020<br />
2.5-3.7 NM-D3025<br />
2.7-4.0 NM-D3027<br />
Drivers<br />
2.7-4.5 NM-D3028<br />
3.1-5.5 NM-D3031<br />
Drills Color Code<br />
Ø 18.-24<br />
Laser Mark<br />
Tools<br />
Ø 2.0-3.2<br />
Ø 2.5-3.7<br />
Ø 2.7-4.0<br />
Ø 2.7-4.5<br />
Ø 3.1-5.5<br />
Color Code<br />
D2<br />
16<br />
13<br />
11.5<br />
10<br />
8<br />
6<br />
D1<br />
Depth Groove (mm)<br />
Kits<br />
Drills<br />
/ 67 /
Drills<br />
Countersink Drills<br />
Ø D (mm)<br />
Item<br />
3.8-4.2 NM-D1034<br />
5.0-6.0 NM-D1056<br />
Marking Drill<br />
Ø D (mm)<br />
Item<br />
1.9 NM-D3410<br />
Trephine Drills<br />
Ø D (mm)<br />
Item<br />
3.0-4.0 NM-D2030<br />
4.0-5.0 NM-D2040<br />
5.0-6.0 NM-D2050<br />
Extension Drill<br />
Ø D (mm)<br />
Item<br />
- NM-D3412<br />
/ 68 / Instruments
Drivers for <strong>Implants</strong><br />
Drivers<br />
Length (mm)<br />
2.42mm<br />
Item<br />
Drills<br />
7 NMHX2607<br />
10 NMHX2610<br />
15 NMHX2615<br />
20 NMHX2620<br />
40 NMHX2640<br />
One Piece Drivers<br />
Length (mm) D (mm) Item<br />
Drivers<br />
10 1.7 NM-X2415<br />
6 2.15 NM-X1018<br />
10 2.15 NM-X1019<br />
20 2.15 NM-X1720<br />
One Piece Motor Mounts<br />
Length (mm) D (mm) Item<br />
20 1.7 NM-X1520<br />
Tools<br />
20 2.15 NM-X1620<br />
Motor Mounts<br />
Length (mm)<br />
2.42mm<br />
Item<br />
20 NMHX1014<br />
28 NMHX1015<br />
Hand Wrench<br />
Length (mm)<br />
6.35mm<br />
Item<br />
Kits<br />
- NM-X1022<br />
/ 69 /
Drivers for Prosthetic<br />
Drivers<br />
1.25mm<br />
Length (mm)<br />
Item<br />
7 NM-X1207<br />
10 NM-X1210<br />
15 NM-X1215<br />
Hand Drivers<br />
1.25mm<br />
Length (mm)<br />
Item<br />
7 NM-X1006<br />
14 NM-X1007<br />
20 NM-X1011<br />
Motor Mounts<br />
1.25mm<br />
Length (mm)<br />
Item<br />
20 NM-X1008<br />
25 NM-X1009<br />
35 NM-X1010<br />
/ 70 / Instruments
Drivers for Multi-Unit & Vari-Connect<br />
Drills<br />
Straight Multi-Unit Drivers<br />
Length (mm)<br />
Item<br />
2.0mm<br />
6 NM-X1016<br />
10 NM-X1017<br />
Straight Multi-Unit Motor Mounts<br />
2.0mm<br />
Length (mm)<br />
Item<br />
20 NM-X1120<br />
25 NM-X1125<br />
Drivers<br />
Star Hex. Drivers<br />
Length (mm)<br />
1.25mm<br />
Item<br />
7 NM-X7006<br />
14 NM-X7007<br />
20 NM-X7011<br />
Star Hex. Ratchet Drivers<br />
Length (mm)<br />
1.25mm<br />
Item<br />
Tools<br />
7 NM-X7307<br />
10 NM-X7310<br />
15 NM-X7315<br />
Star Hex. Motor Mounts<br />
Length (mm)<br />
1.25mm<br />
Item<br />
20 NM-X7008<br />
Kits<br />
25 NM-X7009<br />
35 NM-X7010<br />
/ 71 /
Tools<br />
Material: Stainless Steel<br />
Hand Tools<br />
Item<br />
Ratchet<br />
NM-X1020<br />
Torque Ratchet<br />
NM-X1021<br />
Surgical Screw Driver<br />
NM-X1023<br />
Contra-Angle Torque<br />
Control HandPiece<br />
NM-X1030<br />
Depth Probe<br />
Item<br />
NM-X1025<br />
Gingival Height (mm)<br />
7<br />
6<br />
5<br />
4<br />
3<br />
2<br />
1<br />
0<br />
6<br />
8<br />
10<br />
11.5<br />
13<br />
16<br />
Osteotomy Depth (mm)<br />
/ 72 / Instruments
Angulated Guide Pin Internal Hex. 2.42mm<br />
Angle<br />
Item<br />
17° NM-X1402<br />
Drills<br />
30° NM-X1404<br />
45° NM-X1405<br />
52° NM-X1406<br />
60° NM-X1407<br />
Drivers<br />
Straight Guide Pin Ø2.0mm<br />
Length (mm)<br />
Item<br />
10 NM-X1026<br />
16 NM-X1027<br />
Angulated Guide Pin Ø2.0 mm<br />
Angle Length (mm) Item<br />
17° 10 NM-X1302<br />
Tools<br />
17° 16 NM-X1312<br />
30° 10 NM-X1304<br />
30° 16 NM-X1314<br />
45° 10 NM-X1305<br />
Kits<br />
45° 16 NM-X1315<br />
/ 73 /
Premium Surgical Kit Box<br />
Kit NM-X2111 Contains:<br />
Kit NM-X2112 (Conical Drills) Contains:<br />
Drill, ø2.0mm NM-D1220 Drill, ø1.8-2.4mm NM-D3018<br />
Drill, ø2.8mm NM-D1228 Drill, ø2.0-3.2mm NM-D3020<br />
Drill, ø3.2mm NM-D1232 Drill, ø2.5-3.7mm NM-D3025<br />
Drill, ø3.65mm NM-D1236 Drill, ø2.7-4.0mm NM-D3027<br />
Drill, ø4.2mm NM-D1242 Drill, ø2.7-4.5mm NM-D3028<br />
Drill, ø5.2mm NM-D1252 Drill, ø3.1-5.5mm NM-D3031<br />
Both Kits Contain:<br />
Countersink, ø3.8-4.2mm NM-D1034 Motor Mount 1.25, L 20mm NM-X1008<br />
Countersink, ø5.0-6.0mm NM-D1056 Motor Mount 2.42, L 20mm NMHX1014<br />
Marking Drill NM-D3410 Motor Mount 2.42, L 28mm NMHX1015<br />
Drill Extension NM-D3412 Torque Ratchet NM-X1021<br />
Driver 1.25mm, L 7mm NM-X1207 Guide Pin, L 10mm - 2 Pcs. NM-X1026<br />
Driver 1.25mm, L 15mm NM-X1215 Guide Pin, L 16mm - 2 Pcs. NM-X1027<br />
Driver 2.42mm, L 7mm NMHX2607 Depth Probe NM-X1025<br />
Driver 2.42mm, L 15mm NMHX2615 Hand Driver 1.25, L 14mm NM-X1007<br />
/ 74 / Instruments
Mini Surgical Kit Box<br />
Drivers<br />
Drills<br />
Kit NM-X2211 Contains:<br />
Drill, Countersink, ø3.8-4.2mm<br />
NM-D1034<br />
Driver 1.25mm, L 15mm<br />
NM-X1215<br />
Drill, ø2.0mm<br />
NM-D1220<br />
Driver 2.42mm, L 15mm<br />
NMHX2615<br />
Drill, ø2.8mm<br />
Drill, ø3.2mm<br />
NM-D1228<br />
NM-D1232<br />
Motor Mount 1.25, L 20mm<br />
Motor Mount 2.42, L 28mm<br />
NM-X1008<br />
NMHX1015<br />
Tools<br />
Drill, ø3.65mm<br />
NM-D1236<br />
Ratchet<br />
NM-X1020<br />
Drill, ø4.2mm<br />
NM-D1242<br />
Guide Pin, L 10mm<br />
NM-X1026<br />
Marking Drill<br />
NM-D3410<br />
Guide Pin, L 16mm<br />
NM-X1027<br />
Kit NM-X2210 (Torque Ratchet) Contains:<br />
Drill, Countersink, ø3.8-4.2mm<br />
NM-D1034<br />
Driver 1.25mm, L 15mm<br />
NM-X1215<br />
Drill, ø2.0mm<br />
NM-D1220<br />
Driver 2.42mm, L 15mm<br />
NMHX2615<br />
Drill, ø2.8mm<br />
NM-D1228<br />
Motor Mount 1.25, L 22mm<br />
NM-X1008<br />
Drill, ø3.2mm<br />
Drill, ø3.65mm<br />
NM-D1232<br />
NM-D1236<br />
Motor Mount 2.42, L 28mm<br />
Torque Ratchet<br />
NMHX1015<br />
NM-X1021<br />
Kits<br />
Drill, ø4.2mm<br />
NM-D1242<br />
Guide Pin, L 10mm<br />
NM-X1026<br />
Marking Drill<br />
NM-D3410<br />
Guide Pin, L 16mm<br />
NM-X1027<br />
/ 75 /
Drills Kit with Stoppers<br />
15 Drills Set<br />
Kit NM-X2216 Contains:<br />
35 Drills Set<br />
Kit NM-X2212 Contains:<br />
Drills diameters:<br />
ø2.0mm, ø2.8mm, ø3.2mm<br />
Each drill diameter has the following lengths:<br />
6mm, 8mm, 10mm, 11.5mm, 13mm<br />
Drills diameters:<br />
ø2.0mm, ø2.5mm, ø2.8mm, ø3.2mm, ø3.65mm,<br />
ø4.2mm, ø5.2mm<br />
Each drill diameter has the following lengths:<br />
6mm, 8mm, 10mm, 11.5mm, 13mm<br />
Drills <strong>Catalog</strong> No.:<br />
L (mm)<br />
Ø D (mm)<br />
2.0 2.5 2.8 3.2 3.65 4.3 5.2<br />
6 NM-D6006 NM-D6106 NM-D6206 NM-D6306 NM-D6406 NM-D6506 NM-D6606<br />
8 NM-D6008 NM-D6108 NM-D6208 NM-D6308 NM-D6408 NM-D6508 NM-D6608<br />
10 NM-D6010 NM-D6110 NM-D6210 NM-D6310 NM-D6410 NM-D6510 NM-D6610<br />
11.5 NM-D6011 NM-D6111 NM-D6211 NM-D6311 NM-D6411 NM-D6511 NM-D6611<br />
13 NM-D6013 NM-D6113 NM-D6213 NM-D6313 NM-D6413 NM-D6513 NM-D6613<br />
/ 76 / Instruments
Index<br />
NM-A Description Page<br />
NM-A2401 Angulated Anatomic Abutment, 15°, ø5.4mm, L9.5mm, SH1.0mm, Ti 42<br />
NM-A2402 Angulated Anatomic Abutment, 15°, ø5.4mm, L10.5mm, SH2.0mm, Ti. 42<br />
NM-A2403 Angulated Anatomic Abutment, 15°, ø5.4mm, L11.5mm, SH3.0mm, Ti. 42<br />
NM-A2404 Angulated Anatomic Abutment, 15°, ø5.4mm, L12.5mm, SH4.0mm, Ti. 42<br />
NM-A2601 Angulated Anatomic Abutment, 25°, ø5.4mm, L9.5mm, SH1.0mm, Ti. 42<br />
NM-A2602 Angulated Anatomic Abutment, 25°, ø5.4mm, L10.5mm, SH2.0mm, Ti. 42<br />
NM-A2603 Angulated Anatomic Abutment, 15°, ø5.4mm, L11.5mm, SH3.mm, Ti. 42<br />
NM-A2604 Angulated Anatomic Abutment, 15°, ø5.4mm, L12.5mm, SH4.0mm, Ti. 42<br />
NM-A2809 Angulated Abutment - Narrow Top, 15°, L9mm, Ti. 43<br />
NM-A3009 Angulated Abutment - Narrow Top, 25°, L9mm, Ti 43<br />
NM-A3209 Angulated Anatomic Abutment, 15°, ø4.5mm, L9.5mm, Ti. 43<br />
NM-A3211 Angulated Abutment, 15°, ø4.5mm, L11mm, Ti. 43<br />
NM-A3409 Angulated Abutment, 25°, ø4.5mm, L9mm, Ti. 43<br />
NM-A3411 Angulated Abutment, 25°, ø4.5mm, L11mm, Ti. 43<br />
NM-A3609 Angulated Narrow Abutment, 15˚, ø4.0mm, L9.0mm, Ti. 43<br />
NM-A3809 Angulated Narrow Abutment, 25˚, ø4.0mm, L9.0mm, Ti. 43<br />
NM-A4601 Straight Anatomic Abutment, ø5.2mm, L9mm, SH1.0mm,Ti. 40<br />
NM-A4602 Straight Anatomic Abutment, ø5.2mm, L10mm, SH2.0mm, Ti. 40<br />
NM-A4603 Straight Anatomic Abutment, ø5.2mm, L11mm, SH3.0mm, Ti. 40<br />
NM-A4604 Straight Anatomic Abutment, ø5.2mm, L12mm, SH4.0mm, Ti. 40<br />
NM-A4801 Straight Shoulder Abutment, ø4.5mm, L8.5mm, SH1.0mm, Ti. 40<br />
NM-A4802 Straight Shoulder Abutment, ø4.5mm, L9.5mm, SH2.0mm, Ti. 40<br />
NM-A4803 Straight Shoulder Abutment, ø4.5mm, L10.5mm, SH3.0mm, Ti. 40<br />
NM-A4804 Straight Shoulder Abutment, ø4.5mm,L11.5mm, SH4.0mm, Ti. 40<br />
NM-A5001 Temp. Abutment, Hexed, ø4.4mm, L 9.5mm, Ti. 39<br />
NM-A5002 Temp. Abutment, Non-Hexed, ø4.4mm, L9.5mm, SH1.7mm, Ti. 39<br />
NM-A5101 Temp. Abutment, Hexed, ø3.8mm, L9.5mm, SH1.7mm, Ti. 39<br />
NM-A5102 Temp. Abutment, Short Non Hexed, ø3.8mm, L9.5mm, SH1.0mm, Ti. 39<br />
NM-A5300 Straight Narrow Shoulder Abutment, ø3.75mm, L8.5mm, SH0.5mm, Ti. 41<br />
NM-A5301 Straight Narrow Shoulder Abutment, ø3.75mm, L8.5mm, SH1.5mm, Ti. 41<br />
NM-A5302 Straight Narrow Shoulder Abutment, ø3.75mm, L8.5mm, SH2.5mm, Ti. 41<br />
NM-A5515 Straight Mega Abutment, ø9.0, L15.0mm, Ti. 41<br />
NM-A5516 Straight Mega Abutment, ø15.0, L15.0mm, Co-Cr. 41<br />
NM-A5517 Individual Blank for Milling, ø10.0, L26.0mm, Ti. 47<br />
NM-A5601 Straight Abutment, ø4.5mm, L8.5mm, Ti. 41<br />
NM-A5602 Straight Abutment, ø4.5mm, L10.5mm, Ti. 41<br />
NM-A5709 Straight Wide Abutment, ø5.5mm, L9mm, Ti. 41<br />
NM-A5711 Straight Wide Abutment, ø5.5mm, L11mm, Ti. 41<br />
NM-A5908 Straight Abutment, ø4.5mm, L8.5mm, Ti. 41<br />
NM-A5909 Straight Abutment, ø4.5mm, L9.5mm, Ti. 41<br />
NM-A5911 Straight Abutment, ø4.5mm, L11.5mm, Ti. 41<br />
NM-A5912 Straight Abutment, ø4.5mm, L12.5mm, Ti. 41<br />
NM-A6006 Straight Narrow Abutment, ø3.8mm, L6mm, Ti. 41<br />
NM-A6008 Straight Narrow Abutment, ø3.8mm, L8mm, Ti. 41<br />
NM-A7101 Multi Unit Abutment, Straight, SH1.0mm, Ti. 50<br />
NM-A7102 Multi Unit Abutment, Straight, SH2.0mm, Ti. 50<br />
NM-A7103 Multi Unit Abutment, Straight, SH3.0mm, Ti. 50<br />
NM-A7104 Multi Unit Abutment, Straight, SH4.0mm, Ti. 50<br />
NM-A7105 Multi Unit Abutment, Straight, SH5.0mm, Ti. 50<br />
NM-A7112 Multi Unit Abutment, 17˚, SH2.0mm, Ti. 50<br />
NM-A7113 Multi Unit Abutment, 17˚, SH3.0mm, Ti. 50<br />
NM-A7133 Multi Unit Abutment, 30˚, SH3.0mm, Ti. 50<br />
NM-A7134 Multi Unit Abutment, 30˚, SH4.0mm, Ti. 50<br />
NM-A7144 Multi Unit Abutment, 45˚, SH4.0mm, Ti. 50<br />
NM-A7152 Multi Unit Abutment, 52˚, SH5.0mm, Ti. 50<br />
NM-A7160 Multi Unit Abutment, 60˚, SH5.0mm, Ti. 50<br />
NM-A7212 Vari Connect Abutment, 17˚, SH2.0mm, Ti. 58<br />
NM-A7213 Vari Connect Abutment, 17˚, SH3.0mm, Ti. 58<br />
NM-A7233 Vari Connect Abutment, 30˚, SH3.0mm, Ti. 58<br />
NM-A7234 Vari Connect Abutment, 30˚, SH4.0mm, Ti. 58<br />
NM-A7244 Vari Connect Abutment, 45˚, SH4.0mm, Ti. 58<br />
NM-C Description Page<br />
NM-C1001 Castable Abutment, Non-Hexed, ø3.25mm, L10.5mm, Delrin 45<br />
NM-C1002 Castable Abutment, Hexed, ø3.25mm, L10.5mm, Delrin 45<br />
NM-C1005 Castable Cap for Straight Shoulder Abutment, Plastic 40<br />
NM-C1007 Esthetic Screw Abutment, Non-Hexed, L12mm, Ti. 56<br />
NM-C1015 Esthetic Screw Abutment, Hexed, L12mm, Ti. 56<br />
NM-C2001 Titanium Base Castable Abutment, Hexed, ø4.5mm, L10.5mm, Delrin 45<br />
NM-C2002 Co-Cr Base Castable Abutment, Hexed, ø4.5mm, L10.5mm, Delrin 45<br />
NM-C2003 Castable Abutment, Non-Hexed, ø4.5mm, L8.5mm, Delrin 45<br />
NM-C2004 Castable Abutment, Hexed, ø4.5mm, L8.5mm, Delrin 45<br />
NM-C2005 Castable Angulated Abutment, 15°, ø4.5mm, L8.5mm, Delrin 45<br />
NM-C2201 CAD/CAM Abutment, Single Unit, ø4.8mm, L4.5mm, Ti. 46<br />
NM-C2202 CAD/CAM Abutment, Multiple Unit, ø4.8mm, L4.5mm, Ti. 46<br />
NM-C3001 Angualted Castable Abutment, 15°, L9.5mm, SH1.0mm, Delrin 45<br />
NM-C3002 Angualted Castable Abutment, 15°, L10.5mm, SH2.0mm, Delrin 45<br />
NM-C3003 Angualted Castable Abutment, 15°, L11.5mm, SH3.0mm, Delrin 45<br />
NM-C3201 Angualted Castable Abutment, 25°, L9.5mm, SH1.0mm, Delrin 45<br />
NM-C3202 Angualted Castable Abutment, 25°, L10.5mm, SH2.0mm, Delrin 45<br />
NM-C3203 Angualted Castable Abutment, 25°, L11.5mm, SH3.0mm, Delrin 45<br />
NM-C4001 Castable Abutment, L9mm, SH1.0mm, Delrin 45<br />
NM-C4002 Castable Abutment, L10mm, SH1.0mm, Delrin 45<br />
NM-C4003 Castable Abutment, L11mm, SH1.0mm, Delrin 45<br />
NM-C5001 Temp. Angulated Abutment, 15°, L9.5mm, SH1.0mm Peek 38<br />
NM-C5002 Temp. Angulated Abutment, 15°, L10.5mm, SH2.0mm Peek 38<br />
NM-C5003 Temp. Angulated Abutment, 15°, L11.5mm, SH31.0mm Peek 38<br />
NM-C5201 Temp. Angulated Abutment, 25°, L9.5mm, SH1.0mm Peek 38<br />
NM-C5202 Temp. Angulated Abutment, 25°, L10.5mm, SH2.0mm Peek 38<br />
NM-C5203 Temp. Angulated Abutment, 25°, L11.5mm, SH31.0mm Peek 38<br />
NM-C6001 Temp. Abutment, L9.0mm, SH1.0mm Peek 38<br />
NM-C6002 Temp. Abutment, L10.0mm, SH2.0mm Peek 38<br />
NM-C6003 Temp. Abutment, L11.0mm, SH3.0mm Peek 38<br />
NM-C7120 Castable Sleeve for Multi Unit, ø4.8mm, L10.5mm, Delrin 52<br />
NM-C7121 Universal Abutment for Multi Unit, ø4.9mm, L12.0mm, Delrin 52<br />
NM-C7124 Multi-Unit Titanium Base, ø4.9mm, L4.5mm, Ti. 47, 52<br />
NM-C9007 Scan Body for CAD/CAM, ø4.0mm, L7mm, Ti.&Peek 46<br />
NM-C9010 Scan Body for CAD/CAM, ø4.0mm, L10mm, Ti.&Peek 46<br />
NM-C9013 Scan Body for CAD/CAM, ø4.0mm, L13mm, Ti.&Peek 46<br />
NM-C9107 Multi-Unit Scan Body, ø4.9mm, L7mm, Ti.&Peek 47, 52<br />
NM-C9110 Multi-Unit Scan Body, ø4.9mm, L10mm, Ti.&Peek 47, 52<br />
NM-C9113 Multi-Unit Scan Body, ø4.9mm, L13mm, Ti.&Peek 47, 52<br />
/ 77 /
Index<br />
NM-D Description Page<br />
NM-D1034 Countersink Drill, ø3.8-4.2mm, SS. 68, 74, 75<br />
NM-D1056 Countersink Drill, ø5.0-6.0mm, SS. 68, 74<br />
NM-D1220 Standard Drill, ø2mm, SS. 65, 74, 75<br />
NM-D1225 Standard Drill, ø2.5mm, SS. 65<br />
NM-D1228 Standard Drill, ø2.8mm, SS. 65, 74, 75<br />
NM-D1232 Standard Drill, ø3.2mm, SS. 65, 74, 75<br />
NM-D1236 Standard Drill, ø3.65mm, SS. 65, 74, 75<br />
NM-D1242 Standard Drill, ø4.2mm, SS. 65, 74, 75<br />
NM-D1252 Standard Drill, ø5.2mm, SS. 65, 74<br />
NM-D1420 Short Drill, ø2mm, SS. 65<br />
NM-D1428 Short Drill, ø2.8mm, SS. 65<br />
NM-D1432 Short Drill, ø3.2mm, SS. 65<br />
NM-D1436 Short Drill, ø3.65mm, SS. 65<br />
NM-D1442 Short Drill, ø4.2mm, SS. 65<br />
NM-D1452 Short Drill, ø5.2mm, SS. 65<br />
NM-D2030 Trephine Drill, ø3.0-4.0mm, SS. 68<br />
NM-D2040 Trephine Drill, ø4.0-5.0mm, SS. 68<br />
NM-D2050 Trephine Drill, ø5.0-6.0mm, SS. 68<br />
NM-D2312 Drill, ø1.2mm, L16.0mm, SS. 27<br />
NM-D2315 Drill, ø1.5mm, L16.0mm, SS. 27, 29<br />
NM-D3018 Conical Drill, ø1.8-2.4mm, SS. 67, 74<br />
NM-D3020 Conical Drill, ø2.0-3.2mm, SS. 67, 74<br />
NM-D3025 Conical Drill, ø2.5-3.7mm, SS. 67, 74<br />
NM-D3027 Conical Drill, ø2.7-4.0mm, SS. 67, 74<br />
NM-D3028 Conical Drill, ø2.7-4.5mm, SS. 67, 74<br />
NM-D3031 Conical Drill, ø3.1-5.5mm, SS. 67, 74<br />
NM-D3410 Marking Drill, ø1.9mm, SS. 68, 74, 75<br />
NM-D3412 Extension Drill, SS. 68, 74<br />
NM-D6006 Stop Drill, ø2.0mm, L6.0mm, SS. 76<br />
NM-D6008 Stop Drill, ø2.0mm, L8.0mm, SS. 76<br />
NM-D6010 Stop Drill, ø2.0mm, L10.0mm, SS. 76<br />
NM-D6011 Stop Drill, ø2.0mm, L11.5mm, SS. 76<br />
NM-D6013 Stop Drill, ø2.0mm, L13.0mm, SS. 76<br />
NM-D6106 Stop Drill, ø2.5mm, L6.0mm, SS. 76<br />
NM-D6108 Stop Drill, ø2.5mm, L8.0mm, SS. 76<br />
NM-D6110 Stop Drill, ø2.5mm, L10.0mm, SS. 76<br />
NM-D6111 Stop Drill, ø2.5mm, L11.5mm, SS. 76<br />
NM-D6113 Stop Drill, ø2.5mm, L13.0mm, SS. 76<br />
NM-D6206 Stop Drill, ø2.8mm, L6.0mm, SS. 76<br />
NM-D6208 Stop Drill, ø2.8mm, L8.0mm, SS. 76<br />
NM-D6210 Stop Drill, ø2.8mm, L10.0mm, SS. 76<br />
NM-D6211 Stop Drill, ø2.8mm, L11.5mm, SS. 76<br />
NM-D6213 Stop Drill, ø2.8mm, L13.0mm, SS. 76<br />
NM-D6306 Stop Drill, ø3.2mm, L6.0mm, SS. 76<br />
NM-D6308 Stop Drill, ø3.2mm, L8.0mm, SS. 76<br />
NM-D6310 Stop Drill, ø3.2mm, L10.0mm, SS. 76<br />
NM-D6311 Stop Drill, ø3.2mm, L11.5mm, SS. 76<br />
NM-D6313 Stop Drill, ø3.2mm, L13.0mm, SS. 76<br />
NM-D6406 Stop Drill, ø3.65mm, L6.0mm, SS. 76<br />
NM-D6408 Stop Drill, ø3.65mm, L8.0mm, SS. 76<br />
NM-D6410 Stop Drill, ø3.65mm, L10.0mm, SS. 76<br />
NM-D6411 Stop Drill, ø3.65mm, L11.5mm, SS. 76<br />
NM-D6413 Stop Drill, ø3.65mm, L13.0mm, SS. 76<br />
NM-D6506 Stop Drill, ø4.3mm, L6.0mm, SS. 76<br />
NM-D6508 Stop Drill, ø4.3mm, L8.0mm, SS. 76<br />
NM-D6510 Stop Drill, ø4.3mm, L10.0mm, SS. 76<br />
NM-D6511 Stop Drill, ø4.3mm, L11.5mm, SS. 76<br />
NM-D6513 Stop Drill, ø4.3mm, L13.0mm, SS. 76<br />
NM-D6606 Stop Drill, ø5.2mm, L6.0mm, SS. 76<br />
NM-D6608 Stop Drill, ø5.2mm, L8.0mm, SS. 76<br />
NM-D6610 Stop Drill, ø5.2mm, L10.0mm, SS. 76<br />
NM-D6611 Stop Drill, ø5.2mm, L11.5mm, SS. 76<br />
NM-D6613 Stop Drill, ø5.2mm, L13.0mm, SS. 76<br />
NM-D7020 Step Drill for Zigoma, ø2.0mm, L60.0mm, SS. 24, 25<br />
NM-D7028 Step Drill for Zigoma, ø2.8mm, L60.0mm, SS. 24, 25<br />
NM-D7032 Step Drill for Zigoma, ø3.2mm, L60.0mm, SS. 24, 25<br />
NM-D7120 Step Drill for Zigoma, ø2.0mm, L80.0mm, SS. 24, 25<br />
NM-D7128 Step Drill for Zigoma, ø2.8mm, L80.0mm, SS. 24, 25<br />
NM-D7132 Step Drill for Zigoma, ø3.2mm, L80.0mm, SS. 24, 25<br />
NM-D7201 Dimond Burr, ø4.2mm, L30.0mm, Fine, Red 24, 25<br />
NM-D7202 Dimond Burr, ø4.2mm, L30.0mm, Medium, Black 24, 25<br />
NM-D7203 Dimond Burr, ø4.2mm, L30.0mm, Coarse, Blue 24, 25<br />
NM-D7423 Long Drill, ø2.3mm, SS. 21, 66<br />
NM-D7428 Long Drill, ø2.8mm, SS. 21, 66<br />
NM-D7432 Long Drill, ø3.2mm, SS. 21, 66<br />
NM-D7436 Long Drill, ø3.65mm, SS. 21, 66<br />
NM-D7520 Step Drill for Zygoma, ø2.0mm, L40mm, SS. 25<br />
NM-D7528 Step Drill for Zygoma, ø2.8mm, L40mm, SS. 25<br />
NM-D7532 Step Drill for Zygoma, ø3.2mm, L40mm, SS. 25<br />
NM-E Description Page<br />
NM-E1005 Esthetic Screw Abutment, Base, SH0.5mm, Ti. 56<br />
NM-E1015 Esthetic Screw Abutment, Base, SH1.5mm, Ti. 56<br />
NM-E1025 Esthetic Screw Abutment, Base, SH2.5mm, Ti. 56<br />
NM-F Description Page<br />
NM-F3308 Tuff Implant, ø3.3mm, L8.0mm, Ti. 9<br />
NM-F3310 Tuff Implant, ø3.3mm, L10.0mm, Ti. 9<br />
NM-F3311 Tuff Implant, ø3.3mm, L11.5mm, Ti. 9<br />
NM-F3313 Tuff Implant, ø3.3mm, L13.0mm, Ti. 9<br />
NM-F3316 Tuff Implant, ø3.3mm, L16.0mm, Ti. 9<br />
NM-F3706 Tuff Implant, ø3.75mm, L6.0mm, Ti. 9<br />
NM-F3708 Tuff Implant, ø3.75mm, L8.0mm, Ti. 9<br />
NM-F3710 Tuff Implant, ø3.75mm, L10.0mm, Ti. 9<br />
NM-F3711 Tuff Implant, ø3.75mm, L11.5mm, Ti. 9<br />
NM-F3713 Tuff Implant, ø3.75mm, L13.0mm, Ti. 9<br />
NM-F3716 Tuff Implant, ø3.75mm, L16.0mm, Ti. 9<br />
NM-F3718 Tuff Implant, ø3.75mm, L18.0mm, Ti. 9<br />
NM-F4206 Tuff Implant, ø4.2mm, L6.0mm, Ti. 9<br />
NM-F4208 Tuff Implant, ø4.2mm, L8.0mm, Ti. 9<br />
NM-F4210 Tuff Implant, ø4.2mm, L10.0mm, Ti. 9<br />
NM-F4211 Tuff Implant, ø4.2mm, L11.5mm, Ti. 9<br />
NM-F4213 Tuff Implant, ø4.2mm, L13.0mm, Ti. 9<br />
NM-F4216 Tuff Implant, ø4.2mm, L16.0mm, Ti. 9<br />
NM-F4218 Tuff Implant, ø4.2mm, L18.0mm, Ti. 9<br />
/ 78 / Index
NM-F4220 Tuff Implant, ø4.2mm, L20.0mm, Ti. 9<br />
NM-F4222 Tuff Implant, ø4.2mm, L22.0mm, Ti. 9<br />
NM-F4225 Tuff Implant, ø4.2mm, L25.0mm, Ti. 9<br />
NM-F4306 Tuff TT Implant, ø4.2mm, L6.0mm, Ti. 13<br />
NM-F4308 Tuff TT Implant, ø4.2mm, L8.0mm, Ti. 13<br />
NM-F4310 Tuff TT Implant, ø4.2mm, L10.0mm, Ti. 13<br />
NM-F4311 Tuff TT Implant, ø4.2mm, L11.5mm, Ti. 13<br />
NM-F4313 Tuff TT Implant, ø4.2mm, L13.0mm, Ti. 13<br />
NM-F4316 Tuff TT Implant, ø4.2mm, L16.0mm, Ti. 13<br />
NM-F4318 Tuff TT Implant, ø4.2mm, L18.0mm, Ti. 13<br />
NM-F4320 Tuff TT Implant, ø4.2mm, L20.0mm, Ti. 13<br />
NM-F4430 Zygomatic Implant, ø4.2mm, L30mm, Ti. 22<br />
NM-F4432 Zygomatic Implant, ø4.2mm, L32.5mm, Ti. 22<br />
NM-F4435 Zygomatic Implant, ø4.2mm, L35mm, Ti. 22<br />
NM-F4437 Zygomatic Implant, ø4.2mm, L37.5mm, Ti. 22<br />
NM-F4440 Zygomatic Implant, ø4.2mm, L40mm, Ti. 22<br />
NM-F4442 Zygomatic Implant, ø4.2mm, L42.5mm, Ti. 22<br />
NM-F4445 Zygomatic Implant, ø4.2mm, L45mm, Ti. 22<br />
NM-F4447 Zygomatic Implant, ø4.2mm, L47.5mm, Ti. 22<br />
NM-F4450 Zygomatic Implant, ø4.2mm, L50mm, Ti. 22<br />
NM-F4452 Zygomatic Implant, ø4.2mm, L52.5mm, Ti. 22<br />
NM-F4455 Zygomatic Implant, ø4.2mm, L55mm, Ti. 22<br />
NM-F4457 Zygomatic Implant, ø4.2mm, L57.5mm, Ti. 22<br />
NM-F4460 Zygomatic Implant, ø4.2mm, L60mm, Ti. 22<br />
NM-F5006 Tuff Implant, ø5.0mm, L6.0mm, Ti. 9<br />
NM-F5008 Tuff Implant, ø5.0mm, L8.0mm, Ti. 9<br />
NM-F5010 Tuff Implant, ø5.0mm, L10.0mm, Ti. 9<br />
NM-F5011 Tuff Implant, ø5.0mm, L11.5mm, Ti. 9<br />
NM-F5013 Tuff Implant, ø5.0mm, L13.0mm, Ti. 9<br />
NM-F5016 Tuff Implant, ø5.0mm, L16.0mm, Ti. 9<br />
NM-F5106 Tuff TT Implant, ø5.0mm, L6.0mm, Ti. 13<br />
NM-F5108 Tuff TT Implant, ø5.0mm, L8.0mm, Ti. 13<br />
NM-F5110 Tuff TT Implant, ø5.0mm, L10.0mm, Ti. 13<br />
NM-F5111 Tuff TT Implant, ø5.0mm, L11.5mm, Ti. 13<br />
NM-F5113 Tuff TT Implant, ø5.0mm, L13.0mm, Ti. 13<br />
NM-F5116 Tuff TT Implant, ø5.0mm, L16.0mm, Ti. 13<br />
NM-F6006 Tuff Implant, ø6.0mm, L6.0mm, Ti. 9<br />
NM-F6008 Tuff Implant, ø6.0mm, L8.0mm, Ti. 9<br />
NM-F6010 Tuff Implant, ø6.0mm, L10.0mm, Ti. 9<br />
NM-F6011 Tuff Implant, ø6.0mm, L11.5mm, Ti. 9<br />
NM-F6013 Tuff Implant, ø6.0mm, L13.0mm, Ti. 9<br />
NM-F6016 Tuff Implant, ø6.0mm, L16.0mm, Ti. 9<br />
NM-F6106 Tuff TT Implant, ø6.0mm, L6.0mm, Ti. 13<br />
NM-F6108 Tuff TT Implant, ø6.0mm, L8.0mm, Ti. 13<br />
NM-F6110 Tuff TT Implant, ø6.0mm, L10.0mm, Ti. 13<br />
NM-F6111 Tuff TT Implant, ø6.0mm, L11.5mm, Ti. 13<br />
NM-F6113 Tuff TT Implant, ø6.0mm, L13.0mm, Ti. 13<br />
NM-G Description Page<br />
NM-G3308 Onyx Implant, ø3.3mm, L8mm, Ti. 15<br />
NM-G3310 Onyx Implant, ø3.3mm, L10mm, Ti. 15<br />
NM-G3311 Onyx Implant, ø3.3mm, L11.5mm, Ti. 15<br />
NM-G3313 Onyx Implant, ø3.3mm, L13mm, Ti. 15<br />
NM-G3316 Onyx Implant, ø3.3mm, L16mm, Ti. 15<br />
NM-G3706 Onyx Implant, ø3.75mm, L6mm, Ti. 15<br />
NM-G3708 Onyx Implant, ø3.75mm, L8mm, Ti. 15<br />
NM-G3710 Onyx Implant, ø3.75mm, L10mm, Ti. 15<br />
NM-G3711 Onyx Implant, ø3.75mm, L11.5mm, Ti. 15<br />
NM-G3713 Onyx Implant, ø3.75mm, L13mm, Ti. 15<br />
NM-G3716 Onyx Implant, ø3.75mm, L16mm, Ti. 15<br />
NM-G4206 Onyx Implant, ø4.2mm, L6mm, Ti. 15<br />
NM-G4208 Onyx Implant, ø4.2mm, L8mm, Ti. 15<br />
NM-G4210 Onyx Implant, ø4.2mm, L10mm, Ti. 15<br />
NM-G4211 Onyx Implant, ø4.2mm, L11.5mm, Ti. 15<br />
NM-G4213 Onyx Implant, ø4.2mm, L13mm, Ti. 15<br />
NM-G4216 Onyx Implant, ø4.2mm, L16mm, Ti. 15<br />
NM-G5006 Onyx Implant, ø5.0mm, L6mm, Ti. 15<br />
NM-G5008 Onyx Implant, ø5.0mm, L8mm, Ti. 15<br />
NM-G5010 Onyx Implant, ø5.0mm, L10mm, Ti. 15<br />
NM-G5011 Onyx Implant, ø5.0mm, L11.5mm, Ti. 15<br />
NM-G5013 Onyx Implant, ø5.0mm, L13mm, Ti. 15<br />
NM-G5016 Onyx Implant, ø5.0mm, L16mm, Ti. 15<br />
NM-G6006 Onyx Implant, ø6.0mm, L6mm, Ti. 15<br />
NM-G6008 Onyx Implant, ø6.0mm, L8mm, Ti. 15<br />
NM-G6010 Onyx Implant, ø6.0mm, L10mm, Ti. 15<br />
NM-G6011 Onyx Implant, ø6.0mm, L11.5mm, Ti. 15<br />
NM-G6013 Onyx Implant, ø6.0mm, L13mm, Ti. 15<br />
NM-H Description Page<br />
NM-H3802 Healing Cap, ø3.8mm, L2mm, Ti. 34<br />
NM-H3803 Healing Cap, ø3.8mm, L3mm, Ti. 34<br />
NM-H3804 Healing Cap, ø3.8mm, L4mm, Ti. 34<br />
NM-H3805 Healing Cap, ø3.8mm, L5mm, Ti. 34<br />
NM-H3806 Healing Cap, ø3.8mm, L6mm, Ti. 34<br />
NM-H3807 Healing Cap, ø3.8mm, L7mm, Ti. 34<br />
NM-H4602 Healing Cap, ø4.6mm, L2mm, Ti. 34<br />
NM-H4603 Healing Cap, ø4.6mm, L3mm, Ti. 34<br />
NM-H4604 Healing Cap, ø4.6mm, L4mm, Ti. 34<br />
NM-H4605 Healing Cap, ø4.6mm, L5mm, Ti. 34<br />
NM-H4606 Healing Cap, ø4.6mm, L6mm, Ti. 34<br />
NM-H4607 Healing Cap, ø4.6mm, L7mm, Ti. 34<br />
NM-H5502 Healing Cap, ø5.5mm, L2mm, Ti. 34<br />
NM-H5503 Healing Cap, ø5.5mm, L3mm, Ti. 34<br />
NM-H5504 Healing Cap, ø5.5mm, L4mm, Ti. 34<br />
NM-H5505 Healing Cap, ø5.5mm, L5mm, Ti. 34<br />
NM-H5506 Healing Cap, ø5.5mm, L6mm, Ti. 34<br />
NM-H5507 Healing Cap, ø5.5mm, L7mm, Ti. 34<br />
NM-H6303 Healing Cap, ø6.3mm, L3mm, Ti. 34<br />
NM-H6304 Healing Cap, ø6.3mm, L4mm, Ti. 34<br />
NM-H6305 Healing Cap, ø6.3mm, L5mm, Ti. 34<br />
NM-H6306 Healing Cap, ø6.3mm, L6mm, Ti. 34<br />
NM-H6307 Healing Cap, ø6.3mm, L7mm, Ti. 34<br />
NM-H7101 Healing Cap for Multi Unit, ø4.8, L4.5mm, Ti. 52, 59<br />
NM-M Description Page<br />
NM-M4010 Cortical Implant, ø4.0mm, L10mm, Ti. 17<br />
/ 79 /
Index<br />
NM-M4011 Cortical Implant, ø4.0mm, L11.5mm, Ti. 17<br />
NM-M4013 Cortical Implant, ø4.0mm, L13mm, Ti. 17<br />
NM-M4016 Cortical Implant, ø4.0mm, L16mm, Ti. 17<br />
NM-M4018 Cortical Implant, ø4.0mm, L18mm, Ti. 17<br />
NM-M4020 Cortical Implant, ø4.0mm, L20mm, Ti. 17<br />
NM-M4218 PteryCore Implant, ø4.2mm, L18mm, Ti. 18<br />
NM-M4220 PteryCore Implant, ø4.2mm, L20mm, Ti. 18<br />
NM-M4222 PteryCore Implant, ø4.2mm, L22.5mm, Ti. 18<br />
NM-M4225 PteryCore Implant, ø4.2mm, L25mm, Ti. 18<br />
NM-M5008 Cortical Implant, ø5.0mm, L8mm, Ti. 17<br />
NM-M5010 Cortical Implant, ø5.0mm, L10mm, Ti. 17<br />
NM-M5011 Cortical Implant, ø5.0mm, L11.5mm, Ti. 17<br />
NM-M5013 Cortical Implant, ø5.0mm, L13mm, Ti. 17<br />
NM-M5016 Cortical Implant, ø5.0mm, L16mm, Ti. 17<br />
NM-M6008 Cortical Implant, ø6.0mm, L8mm, Ti. 17<br />
NM-M6010 Cortical Implant, ø6.0mm, L10mm, Ti. 17<br />
NM-M6011 Cortical Implant, ø6.0mm, L11.5mm, Ti. 17<br />
NM-M6013 Cortical Implant, ø6.0mm, L13mm, Ti. 17<br />
NM-S Description Page<br />
NM-S1001 Screw for Zirconia Abutment Base, Ti. 44<br />
NM-S1002 Esthetic Screw Abutment, L10.5mm, Ti. 56<br />
NM-S1102 Esthetic Screw Abutment, L11.5mm, Ti. 56<br />
NM-S1202 Esthetic Screw Abutment, L12.5mm, Ti. 56<br />
NM-S1307 Screw for Transfer, L13.0mm, Ti. 35<br />
NM-S1610 Screw for Transfer, L16.0mm, Ti. 35<br />
NM-S2418 Screw for Transfer, Open Tray, L24.0mm, Ti. 35<br />
NM-S5023 Cover Screw 9, 11, 13, 15, 17, 18, 19, 22<br />
NM-S7101 Screw for Multi Unit Abutment, Ti. 50, 58<br />
NM-S7102 Screw for Multi Unit Components, Ti. 46, 47, 52, 59<br />
NM-S7111 Screw for Multi Unit Transfer, Open Tray, Ti. 52, 59<br />
NM-S8324 Screw for Abutment, Ti. 36, 39, 40, 43, 45, 46, 47<br />
NM-T Description Page<br />
NM-T1100 Flat Attachment, SH0.5mm, Ti. 61<br />
NM-T1101 Flat Attachment, SH1mm, Ti. 61<br />
NM-T1102 Flat Attachment, SH2mm, Ti. 61<br />
NM-T1103 Flat Attachment, SH3mm, Ti. 61<br />
NM-T1104 Flat Attachment, SH4mm, Ti. 61<br />
NM-T1105 Flat Attachment, SH5mm, Ti. 61<br />
NM-T1200 Ball Attachment, SH0.5mm, Ti. 60<br />
NM-T1201 Ball Attachment, SH1mm, Ti. 60<br />
NM-T1202 Ball Attachment, SH2mm, Ti. 60<br />
NM-T1203 Ball Attachment, SH3mm, Ti. 60<br />
NM-T1204 Ball Attachment, SH4mm, Ti. 60<br />
NM-T1205 Ball Attachment, SH5mm, Ti. 60<br />
NM-T1206 Ball Attachment, SH6mm, Ti. 60<br />
NM-T1824 Sealing Disc 59, 61<br />
NM-T3001 Metal Cap, ø5.0mm, L3.2mm 59, 60<br />
NM-T3002 Nylon Extra Soft Cap 59, 60<br />
NM-T3003 Nylon Soft Cap 59, 60<br />
NM-T3004 Nylon Standart Cap 59, 60<br />
NM-T3010 Metal Cap for Flat Attachment, ø5.5, L2.3.0mm, SS. 59, 61<br />
NM-T3015 Cap Insert for Flat Attachment, Extra Soft, Nylon. 59, 61<br />
NM-T3016 Cap Insert for Flat Attachment, Soft, Nylon. 59, 61<br />
NM-T3017 Cap Insert for Flat Attachment, Standard, Nylon. 59, 61<br />
NM-T3018 Cap Insert for Flat Attachment, Hard, Nylon. 59, 61<br />
NM-T3019 Cap Insert for Flat Attachment, Laboratory. 59, 61<br />
NM-T3099 Caps for Flat Attachment Kit 61<br />
NM-T3201 Metal Cap for ø1.8mm Ball Attachment, ø4.3mm, L2.8mm, SS. 27<br />
NM-T3202 Cap Insert for ø1.8mm Ball Attachment, Extra Soft, Yellow, Nylon 27<br />
NM-T3203 Cap Insert for ø1.8mm Ball Attachment, Soft, Pink, Nylon 27<br />
NM-T3409 Clip-On Transfer, ø4.7mm, L9mm, SS. 37<br />
NM-T3413 Clip-On Transfer, ø4.7mm, L13mm, SS. 37<br />
NM-T3507 Transfer for Closed Tray, ø3.85mm, L12.0mm, SS. 35<br />
NM-T3511 Transfer for Closed Tray, ø4.5mm, L12.0mm, SS. 35<br />
NM-T3601 Transfer for Closed Tray, ø4.75mm, L8.0mm, SS. 35<br />
NM-T3802 Ball Transfer, SH2.0mm, Ti. 36<br />
NM-T3803 Ball Transfer, SH3.0mm, Ti. 36<br />
NM-T3804 Ball Transfer, SH4.0mm, Ti. 36<br />
NM-T3805 Ball Transfer, SH5.0mm, Ti. 36<br />
NM-T3806 Ball Transfer, SH6.0mm, Ti. 36<br />
NM-T4008 Transfer for Open Tray, ø4.75mm, L8.0mm, SS. 35<br />
NM-T4012 Transfer for Open Tray, ø4.75mm, L12.0mm, SS. 35<br />
NM-T4201 Transfer for Open Tray, ø4.3mm, L12.0mm, SS. 35<br />
NM-T4203 Transfer for Open Tray, ø3.85mm, L12.0mm, SS. 35<br />
NM-T4204 Transfer for Open Tray, ø3.85mm, L12.0mm, Non Hex, SS. 35<br />
NM-T4402 Plastic Cap for Snap-On Transfer, ø4.8mm, L11mm, Ti. 36, 52, 59<br />
NM-T4410 Snap On Transfer for MBI, Derlin 27<br />
NM-T4420 Snap On Transfer for MONO, Derlin 29<br />
NM-T6004 Analog, ø4.0mm, L12.7mm, SS. 37<br />
NM-T6005 Analog, ø5.0mm, L12.7mm, SS. 37<br />
NM-T6124 Analog for MBI, SS. 27<br />
NM-T6202 Analog for Mono, SS. 29<br />
NM-T7102 Snap On Transfer for Multi Unit, Closed Tray, ø4.9mm, L8.0mm, Ti. 52, 59<br />
NM-T7111 Transfer for Multi Unit, Open Tray, ø4.9mm, L11.0mm, SS. 52, 59<br />
NM-T7121 Universal Abutment for Multi Unit, ø4.9mm, L12.0mm,Ti. 52<br />
NM-T7122 Castable Sleeve Positioner, Multi Unit, ø4.8mm, L10mm, Ti. 52<br />
NM-T7123 Universal Abutment for Multi Unit, ø4.8mm, L12mm, Ti. 52<br />
NM-T7151 Analog for Multi Unit, ø4.8mm, SS. 52<br />
NM-T7251 Analog for Vari Connect, ø4.9mm, SS. 59<br />
NM-T7262 Ball Attachment for Vari Connect, ø4.8mm, L2.0mm, Ti. 59<br />
NM-T7263 Ball Attachment for Vari Connect, ø4.8mm, L3.0mm, Ti. 59<br />
NM-T7264 Ball Attachment for Vari Connect, ø4.8mm, L4.0mm, Ti. 59<br />
NM-T7273 Fall Attachment for Vari Connect, ø4.8mm, L3.0mm, Ti. 59<br />
NM-T7274 Flat Attachment for Vari Connect, ø4.8mm, L4.0mm, Ti. 59<br />
NM-V Description Page<br />
NM-V2010 MBI Implant, ø2.0mm, L10mm, Ti. 27<br />
NM-V2013 MBI Implant, ø2.0mm, L13mm, Ti. 27<br />
NM-V2016 MBI Implant, ø2.0mm, L16mm, Ti. 27<br />
NM-V<strong>2018</strong> MBI Implant, ø2.0mm, L18mm, Ti. 27<br />
NM-V2410 MBI Implant, ø2.4mm, L10mm, Ti. 27<br />
NM-V2413 MBI Implant, ø2.4mm, L13mm, Ti. 27<br />
NM-V2416 MBI Implant, ø2.4mm, L16mm, Ti. 27<br />
NM-V2418 MBI Implant, ø2.4mm, L18mm, Ti. 27<br />
/ 80 / Index
NM-V2910 MBI Implant, ø2.9mm, L10mm, Ti. 27<br />
NM-V2913 MBI Implant, ø2.9mm, L13mm, Ti. 27<br />
NM-V2916 MBI Implant, ø2.9mm, L16mm, Ti. 27<br />
NM-V2918 MBI Implant, ø2.9mm, L18mm, Ti. 27<br />
NM-V3010 Mono Implant, ø3.0mm, L10mm, Ti. 29<br />
NM-V3011 Mono Implant, ø3.0mm, L11.5mm, Ti. 29<br />
NM-V3013 Mono Implant, ø3.0mm, L13mm, Ti. 29<br />
NM-V3016 Mono Implant, ø3.0mm, L16mm, Ti. 29<br />
NM-V3310 Mono Implant, ø3.3mm, L10mm, Ti. 29<br />
NM-V3311 Mono Implant, ø3.3mm, L11.5mm, Ti. 29<br />
NM-V3313 Mono Implant, ø3.3mm, L13mm, Ti. 29<br />
NM-V3316 Mono Implant, ø3.3mm, L16mm, Ti. 29<br />
NM-V3710 Mono Implant, ø3.75mm, L10mm, Ti. 29<br />
NM-V3711 Mono Implant, ø3.75mm, L11.5mm, Ti. 29<br />
NM-V3713 Mono Implant, ø3.75mm, L13mm, Ti. 29<br />
NM-V3716 Mono Implant, ø3.75mm, L16mm, Ti. 29<br />
NM-V4210 Mono Implant, ø4.2mm, L10mm, Ti. 29<br />
NM-V4211 Mono Implant, ø4.2mm, L11.5mm, Ti. 29<br />
NM-V4213 Mono Implant, ø4.2mm, L13mm, Ti. 29<br />
NM-V4216 Mono Implant, ø4.2mm, L16mm, Ti. 29<br />
NM-V4218 Mono Implant, ø4.2mm, L18mm, Ti. 29<br />
NM-V5010 Mono Implant, ø5.0mm, L10mm, Ti. 29<br />
NM-V5011 Mono Implant, ø5.0mm, L11.5mm, Ti. 29<br />
NM-V5013 Mono Implant, ø5.0mm, L13mm, Ti. 29<br />
NM-X Description Page<br />
NM-X1006 Hand driver Hex 1.25mm, L7.0mm, SS. 32, 70<br />
NM-X1007 Hand driver Hex 1.25mm, L14.0mm, SS. 32, 70, 74<br />
NM-X1008 Motor Mount Hex 1.25mm, L20.0mm, SS. 32, 70, 74, 75<br />
NM-X1009 Motor Mount Hex 1.25mm, L25.0mm, SS. 32, 70<br />
NM-X1010 Motor Mount Hex 1.25mm, L35.0mm, SS. 32, 70<br />
NM-X1011 Hand driver Hex 1.25mm, L20.0mm, SS. 32, 70<br />
NM-X1016 Straight Multi-Unit Driver, Int. Hex 2.0mm, L6mm, SS. 33, 53, 71<br />
NM-X1017 Straight Multi-Unit Driver, Int. Hex 2.0mm, L10mm, SS. 33, 53, 71<br />
NM-X1018 Driver, Int. Sqr 2.15mm, L6mm, SS. 7, 29, 69<br />
NM-X1019 Driver, Int. Sqr 2.15mm, L10mm, SS. 7, 27, 29, 69<br />
NM-X1020 Ratchet, SS. 72, 75<br />
NM-X1021 Torque Ratchet, SS. 72, 74, 75<br />
NM-X1022 Hand Wrench, Hex 6.35mm, SS. 69<br />
NM-X1023 Surgical Screw Driver, SS. 72<br />
NM-X1025 Depth Probe, SS. 72, 74<br />
NM-X1026 Straight Guide Pin ø2.0mm, L10mm, SS. 73, 74, 75<br />
NM-X1027 Straight Guide Pin ø2.0mm, L16mm, SS. 73, 74, 75<br />
NM-X1028 Depth Probe 35mm-57.5mm 24, 25<br />
NM-X1030 Contra Angle Torque Control HandPiece, SS. 72<br />
NM-X1120 Straight Multi-Unit Motor, Int. Hex 2.0mm, L20mm, SS. 53, 71<br />
NM-X1125 Straight Multi-Unit Motor, Int. Hex 2.0mm, L25mm, SS. 53, 71<br />
NM-X1207 Driver Hex 1.25mm, L7.0mm, SS. 32, 70, 74<br />
NM-X1210 Driver Hex 1.25mm, L10.0mm, SS. 32, 70<br />
NM-X1215 Driver Hex 1.25mm, L15.0mm, SS. 32, 70, 74, 75<br />
NM-X1302 Angulated Guide Pin 17˚, L10.0mm, Ti. 73<br />
NM-X1304 Angulated Guide Pin 30˚, L10.0mm, Ti. 73<br />
NM-X1305 Angulated Guide Pin 45˚, L10.0mm, Ti. 73<br />
NM-X1312 Angulated Guide Pin 17˚, L16.0mm, Ti. 73<br />
NM-X1314 Angulated Guide Pin 30˚, L16.0mm, Ti. 73<br />
NM-X1315 Angulated Guide Pin 45˚, L16.0mm, Ti. 73<br />
NM-X1402 Angulated Guide Pin Int. Hex. 2.42mm, 17°, SS. 73<br />
NM-X1404 Angulated Guide Pin Int. Hex. 2.42mm, 30°, SS. 73<br />
NM-X1405 Angulated Guide Pin Int. Hex. 2.42mm, 45°, SS. 73<br />
NM-X1406 Angulated Guide Pin Int. Hex. 2.42mm, 52°, SS. 73<br />
NM-X1407 Angulated Guide Pin Int. Hex. 2.42mm, 60°, SS. 73<br />
NM-X1520 Motor Mount Int. Sqr. 1.7mm, SS. 7, 27, 69<br />
NM-X1620 Motor Mount Int. Sqr. 2.15mm, SS. 7, 29, 69<br />
NM-X1720 Driver, Int. Sqr 2.15mm, L20mm, SS. 29, 69<br />
NM-X2111 Premium Surgical Kit Box 74<br />
NM-X2112 Premium Surgical Kit Box Including Conical Drills 74<br />
NM-X2118 Zygomatic Surgical Kit 24<br />
NM-X2210 Mini Surgical Kit Box with Torque Ratchet 75<br />
NM-X2211 Mini Surgical Kit Box 75<br />
NM-X2212 35 Pcs. Stop Drill Set. 76<br />
NM-X2216 15 Pcs. Stop Drill Set. 76<br />
NM-X2415 One Piece Driver, Int. Sqr 1.7mm, L10mm, SS. 7, 27, 69<br />
NM-X3001 Osteotome, ø2.0mm, SS. 21<br />
NM-X3002 Osteotome, ø3.0mm, SS. 21<br />
NM-X7006 Driver Star-Hex 1.25mm, L7.0mm, SS. 33, 53, 59, 71<br />
NM-X7007 Driver Star-Hex 1.25mm, L14.0mm, SS. 24, 33, 53, 59, 71<br />
NM-X7008 Motor Mount, Star-Hex 1.25mm, L20.0mm, SS. 33, 53, 59, 71<br />
NM-X7009 Motor Mount, Star-Hex 1.25mm, L25.0mm, SS. 33, 53, 59, 71<br />
NM-X7010 Motor Mount, Star-Hex 1.25mm, L35.0mm, SS. 33, 53, 59, 71<br />
NM-X7011 Driver Star-Hex 1.25mm, L20.0mm, SS. 33, 53, 59, 71<br />
NM-X7100 Stright Multi-Unit holder, Delrin 50<br />
NM-X7101 Angualted Multi-Unit holder, Delrin 50, 58<br />
NM-X7307 Star Hex. Ratchet Drivers, 1.25mm, L7mm, SS. 71<br />
NM-X7310 Star Hex. Ratchet Drivers, 1.25mm, L10mm, SS. 71<br />
NM-X7315 Star Hex. Ratchet Drivers, 1.25mm, L15mm, SS. 71<br />
NM-Z Description Page<br />
NM-Z1001 Ti. Base for Zirconia, Ti. 44<br />
NM-Z3400 Angulated, Anatomic Ti. Base Zirconia Abutment, 15°, L9mm, SH0.5mm 44<br />
NM-Z3401 Angulated, Anatomic Ti. Base Zirconia Abutment, 15°, L9.5mm, SH1mm 44<br />
NM-Z3402 Angulated, Anatomic Ti. Base Zirconia Abutment, 15°, L10.5mm, SH2mm 44<br />
NM-Z3403 Angulated, Anatomic Ti. Base Zirconia Abutment, 15°, L11.5mm, SH3mm 44<br />
NM-Z3600 Angulated, Anatomic Ti. Base Zirconia Abutment, 25°, L9mm, SH0.5mm 44<br />
NM-Z3601 Angulated, Anatomic Ti. Base Zirconia Abutment, 25°, L9.5mm, SH1mm 44<br />
NM-Z3602 Angulated, Anatomic Ti. Base Zirconia Abutment, 25°, L10.5mm, SH2mm 44<br />
NM-Z3603 Angulated, Anatomic Ti. Base Zirconia Abutment, 25°, L11.5mm, SH3mm 44<br />
NM-Z5600 Straight Anatomic Ti. Base Zirconia Abutment, L8.5mm, SH0.5mm 44<br />
NM-Z5601 Straight Anatomic Ti. Base Zirconia Abutment, L9mm, SH1mm 44<br />
NM-Z5602 Straight Anatomic Ti. Base Zirconia Abutment, L10mm, SH2mm 44<br />
NM-Z5603 Straight Anatomic Ti. Base Zirconia Abutment, L11mm, SH3mm 44<br />
NMAF Description<br />
Page<br />
NMAF3310 Tuff Pro Implant, ø3.3mm, L10.0mm, Ti. 11<br />
NMAF3311 Tuff Pro Implant, ø3.3mm, L11.5mm, Ti. 11<br />
NMAF3313 Tuff Pro Implant, ø3.3mm, L13.0mm, Ti. 11<br />
NMAF3316 Tuff Pro Implant, ø3.3mm, L16.0mm, Ti. 11<br />
/ 81 /
Index<br />
NMAF3710 Tuff Pro Implant, ø3.75mm, L10.0mm, Ti. 11<br />
NMAF3711 Tuff Pro Implant, ø3.75mm, L11.5mm, Ti. 11<br />
NMAF3713 Tuff Pro Implant, ø3.75mm, L13.0mm, Ti. 11<br />
NMAF3716 Tuff Pro Implant, ø3.75mm, L16.0mm, Ti. 11<br />
NMAF4210 Tuff Pro Implant, ø4.2mm, L10.0mm, Ti. 11<br />
NMAF4211 Tuff Pro Implant, ø4.2mm, L11.5mm, Ti. 11<br />
NMAF4213 Tuff Pro Implant, ø4.2mm, L13.0mm, Ti. 11<br />
NMAF4216 Tuff Pro Implant, ø4.2mm, L16.0mm, Ti. 11<br />
NMAF4218 PteryFit Implant, ø4.2mm, L18.0mm, Ti. 19<br />
NMAF4220 PteryFit Implant, ø4.2mm, L20.0mm, Ti. 19<br />
NMAF4222 PteryFit Implant, ø4.2mm, L22.0mm, Ti. 19<br />
NMAF4225 PteryFit Implant, ø4.2mm, L25.0mm, Ti. 19<br />
NMAF5010 Tuff Pro Implant, ø5.0mm, L10.0mm, Ti. 11<br />
NMAF5011 Tuff Pro Implant, ø5.0mm, L11.5mm, Ti. 11<br />
NMAF5013 Tuff Pro Implant, ø5.0mm, L13.0mm, Ti. 11<br />
NMAF5016 Tuff Pro Implant, ø5.0mm, L16.0mm, Ti. 11<br />
NMBV Description<br />
Page<br />
NMBV3711 Bendable Mono Implant, ø3.75mm, L11.5mm, Ti. 29<br />
NMBV3713 Bendable Mono Implant, ø3.75mm, L13.0mm, Ti. 29<br />
NMBV3716 Bendable Mono Implant, ø3.75mm, L16.0mm, Ti. 29<br />
NMBV4211 Bendable Mono Implant, ø4.2mm, L11.5mm, Ti. 29<br />
NMBV4213 Bendable Mono Implant, ø4.2mm, L13.0mm, Ti. 29<br />
NMBV3716 Bendable Mono Implant, ø4.2mm, L16.0mm, Ti. 29<br />
NMHX Description<br />
Page<br />
NMHX1014 Motor Mount, 2.4mm, L20mm, SS. 6, 69, 74<br />
NMHX1015 Motor Mount, 2.4mm, L28mm, SS. 6, 24, 69, 74, 75<br />
NMHX2607 Driver Hex 2.42mm, L7mm, Ti. 6, 69, 74<br />
NMHX2610 Driver Hex 2.42mm, L10mm, Ti. 6, 69<br />
NMHX2615 Driver Hex 2.42mm, L15mm, Ti. 6, 69, 74, 75<br />
NMHX2620 Driver Hex 2.42mm, L20mm, Ti. 6, 24, 69<br />
NMHX2640 Driver Hex 2.42mm, L40mm, Ti. 6, 69<br />
NMSF4216 Tuff Implant, Machined Neck, ø4.2mm, L16.0mm, Ti. 9<br />
NMSF4218 Tuff Implant, Machined Neck, ø4.2mm, L18.0mm, Ti. 9<br />
NMSF4220 Tuff Implant, Machined Neck, ø4.2mm, L20.0mm, Ti. 9<br />
NMSF4222 Tuff Implant, Machined Neck, ø4.2mm, L22.0mm, Ti. 9<br />
NMSF4225 Tuff Implant, Machined Neck, ø4.2mm, L25.0mm, Ti. 9<br />
NMSF5006 Tuff Implant, Machined Neck, ø5.0mm, L6.0mm, Ti. 9<br />
NMSF5008 Tuff Implant, Machined Neck, ø5.0mm, L8.0mm, Ti. 9<br />
NMSF5010 Tuff Implant, Machined Neck, ø5.0mm, L10.0mm, Ti. 9<br />
NMSF5011 Tuff Implant, Machined Neck, ø5.0mm, L11.5mm, Ti. 9<br />
NMSF5013 Tuff Implant, Machined Neck, ø5.0mm, L13.0mm, Ti. 9<br />
NMSF5016 Tuff Implant, Machined Neck, ø5.0mm, L16.0mm, Ti. 9<br />
NMSF6006 Tuff Implant, Machined Neck, ø6.0mm, L6.0mm, Ti. 9<br />
NMSF6008 Tuff Implant, Machined Neck, ø6.0mm, L8.0mm, Ti. 9<br />
NMSF6010 Tuff Implant, Machined Neck, ø6.0mm, L10.0mm, Ti. 9<br />
NMSF6011 Tuff Implant, Machined Neck, ø6.0mm, L11.5mm, Ti. 9<br />
NMSF6013 Tuff Implant, Machined Neck, ø6.0mm, L13.0mm, Ti. 9<br />
NMSF6016 Tuff Implant, Machined Neck, ø6.0mm, L16.0mm, Ti. 9<br />
NMTV Description<br />
Page<br />
NMTV2010 MBI NC Implant, ø2.0mm, L10mm, Ti. 27<br />
NMTV2013 MBI NC Implant, ø2.0mm, L13mm, Ti. 27<br />
NMTV2016 MBI NC Implant, ø2.0mm, L16mm, Ti. 27<br />
NMTV<strong>2018</strong> MBI NC Implant, ø2.0mm, L18mm, Ti. 27<br />
NMTV2410 MBI NC Implant, ø2.4mm, L10mm, Ti. 27<br />
NMTV2413 MBI NC Implant, ø2.4mm, L13mm, Ti. 27<br />
NMTV2416 MBI NC Implant, ø2.4mm, L16mm, Ti. 27<br />
NMTV2418 MBI NC Implant, ø2.4mm, L18mm, Ti. 27<br />
NMTV2910 MBI NC Implant, ø2.9mm, L10mm, Ti. 27<br />
NMTV2913 MBI NC Implant, ø2.9mm, L13mm, Ti. 27<br />
NMTV2916 MBI NC Implant, ø2.9mm, L16mm, Ti. 27<br />
NMTV2918 MBI NC Implant, ø2.9mm, L18mm, Ti. 27<br />
NMSF Description Page<br />
NMSF3308 Tuff Implant, Machined Neck, ø3.3mm, L8.0mm, Ti. 9<br />
NMSF3310 Tuff Implant, Machined Neck, ø3.3mm, L10.0mm, Ti. 9<br />
NMSF3311 Tuff Implant, Machined Neck, ø3.3mm, L11.5mm, Ti. 9<br />
NMSF3313 Tuff Implant, Machined Neck, ø3.3mm, L13.0mm, Ti. 9<br />
NMSF3316 Tuff Implant, Machined Neck, ø3.3mm, L16.0mm, Ti. 9<br />
NMSF3706 Tuff Implant, Machined Neck, ø3.75mm, L6.0mm, Ti. 9<br />
NMSF3708 Tuff Implant, Machined Neck, ø3.75mm, L8.0mm, Ti. 9<br />
NMSF3710 Tuff Implant, Machined Neck, ø3.75mm, L10.0mm, Ti. 9<br />
NMSF3711 Tuff Implant, Machined Neck, ø3.75mm, L11.5mm, Ti. 9<br />
NMSF3713 Tuff Implant, Machined Neck, ø3.75mm, L13.0mm, Ti. 9<br />
NMSF3716 Tuff Implant, Machined Neck, ø3.75mm, L16.0mm, Ti. 9<br />
NMSF3718 Tuff Implant, Machined Neck, ø3.75mm, L18.0mm, Ti. 9<br />
NMSF4206 Tuff Implant, Machined Neck, ø4.2mm, L6.0mm, Ti. 9<br />
NMSF4208 Tuff Implant, Machined Neck, ø4.2mm, L8.0mm, Ti. 9<br />
NMSF4210 Tuff Implant, Machined Neck, ø4.2mm, L10.0mm, Ti. 9<br />
NMSF4211 Tuff Implant, Machined Neck, ø4.2mm, L11.5mm, Ti. 9<br />
NMSF4213 Tuff Implant, Machined Neck, ø4.2mm, L13.0mm, Ti. 9<br />
/ 82 / Index
PRECISION<br />
DOWN TO THE SMALLEST DETAIL
LBL006 Rev. <strong>2018</strong>-3 EN | © <strong>2018</strong> NORIS MEDICAL<br />
www.norismedical.com
