PRODUCT CATALOGUE 4a


WELCOME TO THE NEW

CATALOGUE

Trevor Gordon

Leigh Sadler

Here we are again, gracing the fourth edition of the Indifit catalogue! Our business may

have grown, but we still offer the same attentive, personal, efficient service upon which we

have built our company. “The customer comes first” may sound a cliché, but it is as true today

as it has ever been, and a mantra for we here at Indifit!

Since our last catalogue, we have moved from the wilds of the Essex countryside to a strategically

located industrial estate, moments from the M11 and 3 miles from Stansted Airport. For local customers

who may wish to collect, we are now very conveniently situated.

We have also implemented a new software system, offering the latest functionality and instant

information regarding product availability, pricing, customer purchasing history, quotations/

acknowledgements by email or direct fax. All our goods are labelled with your part number, order

number, description and quantity.

In the following pages you will find thousands of finishing products invaluable to manufacturers of

• Shopfitting and point of sale equipment

• Furniture – school, office, laboratory, contract, etc

• Medical apparatus

• General tubular and sheetmetal fabrications

....and many other industries

We understand the products we sell, and will be pleased to offer advice and information regarding any

requirement. You do not need a part number to order from Indifit!

Free of charge samples are available for evaluation or prototyping purposes, and we strongly advise you

take advantage of this service when colour, pattern, fit are crucial.

We are able to accept most major credit

or debit cards for non-account customers,

enabling immediate despatch of goods.

Credit accounts can usually be swiftly opened

with the minimum of fuss.

NEED AN EXTRA

COPY OF THIS

CATALOGUE?

Just call or email and it

will be in the post without delay.

Great care has been taken to ensure the data and information in this catalogue is correct at the time of publication. Indifit, however, assumes no responsibility for errors in, or misinterpretation of said information. This

catalogue and the content therein may not be reproduced, stored, or transmitted in any form or by any means without prior written consent of it’s owner.

2

01279 656 189 01279 658 891 sales@indifit.co.uk


Dealing with Indifit couldn’t be easier!

Phones answered by human beings (not machines) from

08.30-17.30 Monday-Thursday, 08:30-17:00 Friday.

T: 01279 656 189

F: 01279 658 891

E: sales@indifit.co.uk

Next day delivery for stock goods

NO MINIMUM ORDER CHARGE

NO MINIMUM ORDER QUANTITIES

ON STOCK/STANDARD ITEMS

NO PUNATIVE SMALL QUANTITY PRICES

All items shown in this catalogue are available at the time of

publication. Popular items are held in stock, delivered on a next day

service, and the usual special timed deliveries are offered at extra

cost. We use the most economical method of despatch for each

consignment – small packages can be sent first class post. Nonstock

items are available on short lead times – please enquire for

details.

Polly says:

“Still the best

customer service in

the business!”

01279 656 189 01279 658 891 sales@indifit.co.uk

3


PRODUCT INDEX

CASTORS AND WHEELS - all types

PAGES

6 - 19

DRAWER SLIDES

CABLE ACCESS GROMMETS

ADJUSTABLE FEET/GLIDES

light to heavy duty - static or tilt -

plastic, metal and chrome capped

PAGE

PAGE

20 21 - 26

TUBE INSERTS

TUBE CONNECTORS

threaded, non-threaded - plastic, plastic/metal, steel, aluminium

PAGE

27 - 33

PAGES

33 - 35

4

01279 656 189 01279 658 891 sales@indifit.co.uk


END TIPS - FERRULES - STAND OFF

FEET - BUFFER FEET - SADDLE FEET

HOLE PLUGS

HANDWHEELS - KNOBS -

THUMBSCREWS - BALLKNOBS

PRODUCT INDEX

PAGES

PAGE

36 - 39 40 - 41

HANDGRIPS - LEVERS - LOCKING

HANDLES - LATCHES - CAMLOCKS

HINGES - PULLS -

DEE HANDLES - PLUNGERS

v

age

PAGE

42 - 45

PAGE

46 - 49

FASTENERS

screws, bolts, nuts, washers, rivets, threaded insert nuts,

clevis pins, R clips, wire support hooks, protection caps etc.

NYLON WASHERS,

BUSHES, SPACERS

DO YOU NEED

SPECIAL SIZED

WASHERS OR

GASKETS?

PAGE

PAGES

50 - 56 56 - 58

PAGE

59

01279 656 189 01279 658 891 sales@indifit.co.uk

5


CASTORS - LIGHT DUTY / FURNITURE

CASTORS & WHEELS

We have many years of experience supplying castors and wheels and whether you are making an office chair or an industrial waste container, we can help

you to specify the product you need. In addition to the primary ranges shown in this catalogue, we can supply products suitable for every conceivable application.

Helpful and comprehensive advice is a phone call away - CALL OUR SALESLINE NOW ON 01279 656 189

EXPLANATION OF SYMBOLS

Wheel diameter

TWINWHEEL FURNITURE CASTORS

Braked

Tread width

of wheel

CWTRT

Static load

capacity

*Allowance must be made for pedal on braked versions

Unbraked

Round top twinwheel to suit 5 star

chair base with 10 or 11mm dia

circlip pin fittings—please enquire.

Swivel lead

(centre of pivot to

wheel centre)*

Bore size

of wheel

Threaded stud

Fitting M8 or M10

Hub width

of wheel

Many other patterns of twinwheel and furniture castors, with alternative fittings,

are available. Ask us about polyurethane tyres, anti-static castors, load dependent

brakes, circlip pin fittings etc…

4 Suitable for a wide range of

furniture, display units and light duty

applications

Square Plate Fitting

Overall height

FITTING

M8 Threaded Stud

M10 Threaded Stud

Square Plate

PART NO

UNBRAKED

Single bolthole

diameter

4 Available braked and unbraked

4 Standard material: black nylon

4 FIRA and BIFMA tested

PART NO

BRAKED

40mm CTW040B CTW040B/BR 50

50mm CTW050B CTW050B/BR 50

PART NO

CTWM0815

CTWM1015

CTWP

Threaded stud

size

CTW

SUPERIOR TWINWHEEL RANGE 35-100KG

4 Clean, modern aesthetics

4 Robust nylon construction

4 Wide range of fittings, colours and wheel options

CTX

PART NO

PART NO

UNBRAKED

BRAKED

50MM CTX050(COLOUR/FITTING) CTX050B(COLOUR/FITTING) 35

65MM CTX065(COLOUR/FITTING) CTX065B(COLOUR/FITTING) 50

75MM CTX075(COLOUR/FITTING) CTX075B(COLOUR/FITTING) 75*

100MM CTX100(COLOUR/FITTING) CTX100B(COLOUR/FITTING) 100*

*Highest capacity, dependent on fitting—please enquire

ALSO AVAILABLE

Braked castor

50 + 65mm - wheel brake only

75 + 100mm - total stop brake

on wheel and swivel

Un-braked castor in RAL9006 with black

polyurethane tyres

AVAILABLE

CTX

CTX050 CTX065 CTX075 CTX100

11 DIA X 22MM CIRCLIP PIN YES YES YES YES

10 DIA X 22MM CIRCLIP PIN YES YES YES NO

10 DIA X 30MM CIRCLIP PIN YES YES NO NO

M8 X 15 THREADED STUD YES NO NO NO

Hard wheel

(without tyre)

STANDARD FITTINGS

Other standard colour

combination: black /

RAL9006

Round top to suit standard bases.

Load dependent

brake also available.

M10 X 15 THREADED STUD YES YES YES YES

M10 X 20 THREADED STUD NO NO NO YES

M12 X 20 THREADED STUD NO YES YES YES

38 X 38 PLATE YES YES NO NO

42 X 42 PLATE YES YES YES NO

Circlip Pin

11mm dia x 22mm

10mm dia x 22mm

10mm dia x 30mm

Threaded stud

M8 x 15

M10 x 15

M10 x 20

M12 x 20

Square plate

38 x 38mm

42 x 42mm

6

01279 656 189 01279 658 891 sales@indifit.co.uk


FURNITURE ROLLER INSERT

TUBE SIZE WHEEL DIA EFFECTIVE HEIGHT PART NO

32 Dia x 1.5 20 7.0 CFR3215

32 Dia x 2.0 20 7.0 CFR3220

35 Dia x 1.5 20 7.0 CFR3515

35 Dia x 2.0 20 7.0 CFR3520

38 Dia x 1.5 25 10 CFR3815

38 Dia x 2.0 25 10 CFR3820

40 Dia x 1.5 25 10 CFR4015

40 Dia x 2.0 25 10 CFR4020

LIGHT DUTY INDUSTRIAL 20-35KG

4 Suitable for wide variety of light duty applications

4 Available braked and unbraked

Fixed plate

Makes easy work of moving tubular

furniture. Use in 2 legs and the unit

can lifted and moved “wheelbarrow”

style! Insert in black nylon, with

thermoplastic rubber roller.

4 Very economical prices PART NO PART NO BLACK PLATE HOLE

GREY TYRE PP WHEEL SIZE SPACING (DIA)

Swivel plate and brake

CFR

PLATE FITTING

50MM C050/DP/7 20 C050/DP 35 17 15 67.5 45 x 45 33 x 33 (5)

50MM BRAKED C050/DP/7/2 20 C050/DP/2 35 17 15 67.5 45 x 45 33 x 33 (5)

50MM FIXED C050/DSF/7 20 C050/DSF 35 17 - 67.5 45 x 45 33 x 33 (5)

PART NO

GREY TYRE

NEW

SINGLE BOLTHOLE FITTING

PART NO BLACK

PP WHEEL

50MM C050/DO/7 20 C050/DO 35 17 15 66 10.2

DP

DO

CASTORS - LIGHT / MEDIUM DUTY

50MM BRAKED C050/DO/7/2 20 C050/DO/2 35 17 15 66 10.2

THREADED STUD FITTING

DF

PART NO

GREY TYRE

PART NO BLACK

PP WHEEL

Single bolthole

Threaded stud

50MM C050/DF/7 20 C050/DF 35 17 15 66.5 M10 X 25

50MM BRAKED C050/DF/7/2 20 C050/DF/2 35 17 15 66.5 M10 X 25

DOUBLE WHEEL APPARATUS CASTORS 80KG

PLATE FITTING

TNP2

TBP2

PART NO PART NO BLACK PLATE HOLE SPACING

GREY TYRE PP WHEEL SIZE (DIA)

50MM C050/TBP2 C050/TNP2 70 39 14 79 60 x 60 43 x 43 (6.5)

50MM BRAKED C050/TBBP2 C050/TNBP2 70 39 14 79 60 x 60 43 x 43 (6.5)

4 50mm dia wheel - grey tyre or

solid black PP

4 80kg load capacity with low

overall height

4 Highly efficient “total stop”

brake mechanism locks wheel

and swivel action

4 Large contact area eases

rolling resistance

4 Very economical prices!

4 Standard stocked fittings -

plate and single bolthole.

Threaded stud to special

order

SINGLE BOLTHOLE FITTING

TNO2

TBO2

PART NO

GREY TYRE

PART NO BLACK

PP WHEEL

50MM C050/TBO2 C050/TNO2 70 39 14 79 12.2

50MM BRAKED C050/TBBO2 C050/TNBO2 70 39 14 79 12.2

TBBP2

TBP2

TNP2

TNBP2

TN02

TNB02

TBB02

TB02

01279 656 189 01279 658 891 sales@indifit.co.uk

7


CASTORS - LIGHT DUTY

SINGLE BOLTHOLE FITTING 40-70KG

TBO

TNO

4 High quality, yet low prices

4 Ideal for contract/educational furniture, shopfittings, portable apparatus etc etc

4 Highly efficient “total stop” brake mechanism locks wheel and swivel action

4 Grey synthetic rubber or white nylon wheel as standard

4 Threadguards, prime rubber tyre, anti-static tyres, stainless fork all available to special order

for all patterns

SINGLE BOLTHOLE FITTING

PART NO

GREY TYRE

PART NO WHITE

NYLON WHEEL

TBO

50MM C050/TBO C050/TNO* 18 40 26 70 12.2

50MM BRAKED C050/TBBO C050/TNBO* 18 40 26 70 12.2

60MM C060/TBO C060/TNO 22 40 26 89 12.2

60MM BRAKED C060/TBBO C060/TNBO 22 40 26 89 12.2

80MM C080/TBO C080/TNO 22 50 25 108 12.2

80MM BRAKED C080/TBBO C080/TNBO 22 50 25 108 12.2

100MM C100/TBO C100/TNO 27 60 36 132 12.2

100MM BRAKED C100/TBBO C100/TNBO 27 60 36 132 12.2

TNO

125MM C125/TBO C125/TNO 27 70 35 156 12.2

125MM BRAKED C125/TBBO C125/TNBO 27 70 35 156 12.2

ZAMAC REDUCER AVAILABLE TO CONVERT 12.2 BOLTHOLE TO 10.2MM

TBBO

TNBO

Weight Loadings - Important Information

The weight loadings quoted in this catalogue assume ideal working conditions, i.e:

Smooth floor in good condition. Equal distribution of weight over wheels / castors

We will be pleased to give advice in this regard just telephone our sales line 01279 656 189

FIXED VERSION TO

SPECIAL ORDER

PRIME RUBBER TYRE/THREADGUARDS

AS SPECIAL OPTION FOR ALL PATTERNS

THREADED STUD FITTING 40-70KG

THREADED STUD FITTING

TBF

TNF

PART NO

GREY TYRE

PART NO WHITE

NYLON WHEEL

TBF

TNF

50MM C050/TBF C050/TNF* 18 40 26 70 M10 x 25

50MM BRAKED C050/TBBF C050/TNBF* 18 40 26 70 M10 x 25

60MM C060/TBF C060/TNF 22 40 26 89 M10 x 25

60MM BRAKED C060/TBBF C060/TNBF 22 40 26 89 M10 x 25

80MM C080/TBF C080/TNF 22 50 25 108 M10 x 25

80MM BRAKED C080/TBBF C080/TNBF 22 50 25 108 M10 x 25

100MM C100/TBF C100/TNF 27 60 36 132 M10 x 25

100MM BRAKED C100/TBBF C100/TNBF 27 60 36 132 M10 x 25

125MM C125/TBF C125/TNF 27 70 35 157 M10 x 25

125MM BRAKED C125/TBBF C125/TNBF 27 70 35 157 M10 x 25

*50MM nylon wheel castors have load capacity of 55kg

Swivel Leads

Important Information

Dimension shown in table is for unbraked

castor. Additional room must be

allowed for extension of pedal on

braked versions

We will be pleased to give advice in this regard

just telephone our sales line 01279 656 189

TBBF

TNBF

FIXED VERSION TO

SPECIAL ORDER

8

01279 656 189 01279 658 891 sales@indifit.co.uk


PLATE FITTING 40-70KG

PLATE FITTING

TBP TNP TBBP TNBP

TBP

50MM C050/TBP C050/TNP* 18 40 26 70 60 x 60 45 x 45 (6.5)

50MM BRAKED C050/TBBP C050/TNBP* 18 40 26 70 60 x 60 45 x 45 (6.5)

50MM FIXED C050/TBFP C050/TNFP* 18 40 - 70 60 x 60 45 x 45 (6.5)

60MM C060/TBP C060/TNP 22 40 26 90 60 x 60 45 x 45 (6.5)

TNP

PART NO PART NO WHITE PLATE HOLE SPACING

GREY TYRE NYLON WHEEL SIZE (DIA)

CASTORS - LIGHT DUTY

60MM BRAKED C060/TBBP C060/TNBP 22 40 26 90 60 x 60 45 x 45 (6.5)

60MM FIXED C060/TBFP C060/TNFP 22 40 - 90 60 x 60 45 x 45 (6.5)

80MM C080/TBP C080/TNP 22 50 25 109 60 x 60 45 x 45 (6.5)

80MM BRAKED C080/TBBP C080/TNBP 22 50 25 109 60 x 60 45 x 45 (6.5)

80MM FIXED C080/TBFP C080/TNFP 22 50 - 109 60 x 60 45 x 45 (6.5)

TBFP

100MM C100/TBP C100/TNP 27 60 36 134 76 x 70 60 x 50 (8.5)

100MM BRAKED C100/TBBP C100/TNBP 27 60 36 134 76 x 70 60 x 50 (8.5)

100MM FIXED C100/TBFP C100/TNFP 27 60 - 134 76 x 70 60 x 50 (8.5)

125MM C125/TBP C125/TNP 27 70 35 159 76 x 70 60 x 50 (8.5)

TNFP

125MM BRAKED C125/TBBP C125/TNBP 27 70 35 159 76 x 70 60 x 50 (8.5)

125MM FIXED C125/TBFP C125/TNBP 27 70 - 159 76 x 70 60 x 50 (8.5)

TUBE EXPANDER FITTING 40-70KG

TUBE EXPANDER FITTING

TBE

TNE

PART NO

GREY TYRE

PART NO WHITE

NYLON WHEEL

50MM C050/TBE C050/TNE* 18 40 26 70

50MM BRAKED C050/TBBE C050/TNBE* 18 40 26 70

60MM C060/TBE C060/TNE 22 40 26 91

60MM BRAKED C060/TBBE C060/TNBE 22 40 26 91

80MM C080/TBE C080/TNE 22 50 25 110

80MM BRAKED C080/TBBE C080/TNBE 22 50 25 110

100MM C100/TBE C100/TNE 27 60 36 134

TNE

100MM BRAKED C100/TBBE C100/TNBE 27 60 36 134

125MM C125/TBE C125/TNE 27 70 35 159

125MM BRAKED C125/TBBE C125/TNBE 27 70 35 159

TBE

*50MM nylon wheel castors have load capacity of 55kg

EXPANDER SIZES

EXPANDER

FITS TUBE

EXPANDER

FITS TUBE

SIZE - ROUND

SIZE (OD)

SIZE - SQUARE

SIZE (OD)

17mm dia

19mm dia

21mm dia

24mm dia

26mm dia

3/4” / 20mm

7/8” / 22mm

1” / 25mm

1.1/8” / 28mm

30mm

15 x 15mm 3/4” x 3/4” / 19 x 19mm

17 x 17mm 7/8” x 7/8” / 22 x 22mm

22 x 22mm 1” x 1” / 25 x 25mm

27 x 27mm 1.1/4” x 1.1/4” / 30 x 30mm

37 x 37mm 40 x 40mm

Expanders provide a quick, easy and secure method of fitting castors to tubular apparatus.

Rubber body expands as hexagon underneath ballrace is tightened. We are able to supply

expanders of different sizes and materials - if your requirement is not covered by the

standard sizes shown in the adjacent table - PLEASE ASK!

TBBE

TNBE

01279 656 189 01279 658 891 sales@indifit.co.uk

9


CASTORS - MEDIUM DUTY

PLATE FITTING 50-350KG

EPRS

4 Bright zinc plated forks with

double ball bearing swivel

4 Suitable for medium duty

materials handling and

industrial applications

4 Efficient “total stop” brake

mechanism locks wheel and

swivel action

4 Highly competitive prices

EPRS/2

BLACK RUBBER TYRE ON ROLLER BEARING STEEL CENTRE

PART NO PART NO PART NO SWIVEL FIXED PLATE HOLE SPACING

UNBRAKED BRAKED FIXED PLATE SIZE SIZE (DIA)

80mm C080/EPRS C080/EPRS/2 C080/EFRS 50 25 32 107 99 x 80 100 x 84 80 x 60 (9)

100mm C100/EPRS C100/EPRS/2 C100/EFRS 70 30 33 127 99 x 80 100 x 84 80 x 60 (9)

125mm C125/EPRS C125/EPRS/2 C125/EFRS 110 37.5 46 155 99 x 80 100 x 84 80 x 60 (9)

150mm C150/EPRS C150/EPRS/2 C150/EFRS 150 40 47 185 129 x 106 134 x 110 105 x 80 (11)

160mm C160/EPRS - C160/EFRS 160 40 47 190 129 x 106 134 x 110 105 x 80 (11)

200mm C200/EPRS C200/EPRS/2 C200/EFRS 220 50 56 239 129 x 106 135 x 110 105 x 80 (11)

250mm C250/EPRS C250/EPRS/2 C250/EFRS 300 60 78 311 187 x 170 175 x 145 140 x 105 (14)

280mm C280/EPRS C280/EPRS/2 C280/EFRS 350 70 78 325 187 x 170 175 x 145 140 x 105 (14)

EFRS

EP

SCP

SCP/2

SCF

BLACK RUBBER TYRE ON PLAIN BEARING PLASTIC CENTRE

SC

Don’t see what you need...

CALL US

We can supply much more than is

shown in this catalogue!

?

PART NO PART NO PART NO SWIVEL FIXED PLATE HOLE SPACING

UNBRAKED BRAKED FIXED PLATE SIZE SIZE (DIA)

80mm C080/SCP C080/SCP/2 C080/SCF 50 25 32 107 99 x 80 100 x 84 80 x 60 (9)

100mm C100/SCP C100/SCP/2 C100/SCF 70 30 33 127 99 x 80 100 x 84 80 x 60 (9)

125mm C125/SCP C125/SCP/2 C125/SCF 100 37.5 46 155 99 x 80 100 x 84 80 x 60 (9)

150mm C150/SCP C150/SCP/2 C150/SCF 140 40 47 185 129 x 106 134 x 110 105 x 80 (11)

200mm C200/SCP C200/SCP/2 C200/SCF 205 50 56 239 129 x 109 135 x 110 105 x 80 (11)

NVPB NVPB/2 NVFB

NYLON WHEEL PLAIN BEARING (ALSO AVAILABLE WITH ROLLER BEARING)

NV

WEIGHT LOADINGS -

IMPORTANT INFORMATION

The weight loadings quoted in this catalogue

assume ideal working conditions, i.e:

Smooth floor in good condition.

Equal distribution of weight over wheels / castors.

WE WILL BE PLEASED TO GIVE ADVICE IN

THIS REGARD JUST TELEPHONE OUR SALES

LINE 01279 656 189

PART NO PART NO PART NO SWIVEL FIXED PLATE HOLE SPACING

UNBRAKED BRAKED FIXED PLATE SIZE SIZE (DIA)

80mm C080/NVPB C080/NVPB/2 C080/NVFB 100 30 32 107 99 x 80 100 x 84 80 x 60 (9)

100mm C100/NVPB C100/NVPB/2 C100/NVFB 120 30 33 127 99 x 80 100 x 84 80 x 60 (9)

125mm C125/NVPB C125/NVPB/2 C125/NVFB 120 39 46 155 99 x 80 116 x 84 80 x 60 (9)

150mm C150/NVPB C150/NVPB/2 C150/NVFB 180 40 47 185 129 x 106 134 x 110 105 x 80 (11)

200mm C200/NVPB C200/NVPB/2 C200/NVFB 260 50 56 239 129 x 109 135 x 110 105 x 80 (11)

10

01279 656 189 01279 658 891 sales@indifit.co.uk


PLATE FITTING 100-260KG

NYPB

POLYURETHANE TYRED NYLON PLAIN BEARING (also available with roller bearing)

PART NO PART NO PART NO SWIVEL FIXED HOLE SPACING

UNBRAKED BRAKED FIXED PLATE SIZE PLATE SIZE (DIA)

80mm C080/NYPB C080/NYPB/2 C080/NYFB 100 30 32 107 99 x 80 100 x 84 80 x 60 (9)

100mm C100/NYPB C100/NYPB/2 C100/NYFB 120 35 33 127 99 x 80 100 x 84 80 x 60 (9)

125mm C125/NYPB C125/NYPB/2 C125/NYFB 130 40 46 155 99 x 80 100 x 84 80 x 60 (9)

150mm C150/NYPB C150/NYPB/2 C150/NYFB 180 40 47 185 129 x 106 134 x 110 105 x 80 (11)

200mm C200/NYPB C200/NYPB/2 C200/NYFB 260 50 56 239 129 x 109 135 x 110 105 x 80 (11)

SINGLE BOLTHOLE FITTING 50-260KG

NYPB/2

NYFB

NY

CASTORS - MEDIUM DUTY

Our medium duty range as shown on these

pages is also available as a single bolthole

fitting. All weight loadings, wheel widths and

swivel leads are as shown in the preceding

tables for plate fitting. Differing specifications

are shown as follows:

WEIGHT LOADINGS - IMPORTANT INFORMATION

The weight loadings quoted in this catalogue

assume ideal working conditions, i.e:

Smooth floor in good condition.

Equal distribution of weight over wheels / castors.

WE WILL BE PLEASED TO GIVE ADVICE IN THIS REGARD

JUST TELEPHONE OUR SALES LINE 01279 656 189

BLACK RUBBER TYRE ON ROLLER BEARING STEEL CENTRE

EOR

PART NO

UNBRAKED

PART NO

BRAKED

80mm C080/EORS C080/EORS/2 107 12.2

100mm C100/EORS C100/EORS/2 127 12.2

125mm C125/EORS C125/EORS/2 155 12.2

150mm C150/EORS C150/EORS/2 192 12.2

200mm C200/EORS C200/EORS/2 240 12.2

EORS

EORS/2

BLACK RUBBER TYRE ON PLAIN BEARING PLASTIC CENTRE

SCO

PART NO

UNBRAKED

PART NO

BRAKED

80mm C080/SCO C080/SCO/2 107 12.2

100mm C100/SCO C100/SCO/2 127 12.2

125mm C125/SCO C125/SCO/2 155 12.2

150mm C150/SCO C150/SCO/2 192 12.2

200mm C200/SCO C200/SCO/2 240 12.2

SCO

SCO/2

NYLON WHEEL PLAIN BEARING

NVO

PART NO

UNBRAKED

PART NO

BRAKED

80mm C080/NVOB C080/NVOB/2 107 12.2

100mm C100/NVOB C100/NVOB/2 127 12.2

125mm C125/NVOB C125/NVOB/2 155 12.2

150mm C150/NVOB C150/NVOB/2 192 12.2

200mm C200/NVOB C200/NVOB/2 240 12.2

NVOB

NVOB/2

POLYURETHANE TYRED NYLON PLAIN BEARING

NYO

PART NO

UNBRAKED

PART NO

BRAKED

80mm C080/NYOB C080/NYOB/2 107 12.2

100mm C100/NYOB C100/NYOB/2 127 12.2

125mm C125/NYOB C125/NYOB/2 155 12.2

150mm C150/NYOB C150/NYOB/2 192 12.2

200mm C200/NYOB C200/NYOB/2 240 12.2

NYOB

NYOB/2

01279 656 189 01279 658 891 sales@indifit.co.uk

11


CASTORS - BUFFERS / SPECIAL CASTORS

CASTOR BUFFERS

SPECIAL CASTORS

4 Clean, modern aesthetics

4 Available in range of colours

4 Choice of fitting hole size/shape

4 Buffer rotates to prevent marking/scuffing

4 High quality UK manufactured product

The soft EVA foam tyre and rotating design of these buffers prevent contact damage both to the

equipment to which they are fitted and to walls, doors and general environment in which it is used.

Please note — both bore shapes, round and square, rotate when fitted.

Fitting can be either at the extremities of the apparatus, or on top of the castor ballrace.

CASTOR BUFFERS

OVERALL

DIA

BORE

SIZE

BORE

TYPE

TYRE

COLOUR

CENTRE

COLOUR

113MM 6MM ROUND BLACK GREY CB113/06/BLGR

113MM 6MM ROUND GREY WHITE CB113/06/GRWH

113MM 20MM ROUND GREY GREY CB113/20/GR

113MM 25MM ROUND BLACK BLACK CB113/20/BL

113MM 25MM ROUND BROWN BROWN CB113/25/BR

113MM 25MM ROUND GREY GREY CB113/25/GR

113MM 25MM ROUND IVORY IVORY CB113/25/IV

113MM 32MM ROUND GREY GREY CB113/32/GR

113MM 20 X 20MM SQUARE GREY GREY CB113/20Q/GR

113MM 25 X 25MM SQUARE BLACK BLACK CB113/25Q/BL

113MM 25 X 25MM SQUARE BROWN BROWN CB113/25Q/BR

113MM 25 X 25MM SQUARE GREY GREY C113/25Q/GR

113MM 30 X 30MM SQUARE GREY GREY CB113/30Q/GR

113MM 32 X 32MM SQUARE GREY GREY CB113/32Q/GR

This table shows standard colours and fitting hole sizes readily available. Other combinations can be

manufactured subject to minimum quantities. Please enquire.

PART

NO

CB

We have many years experience in the castor supply industry, and are able to source many unusual or specialised castors designed for

specific applications. A few examples are shown as follows:

Colour co-ordinated castor, with powder coated

steel frame and matching wheel and contrasting

brake. Many colour combinations available.

Superior quality construction—would suit the

highest specification shopfitting units in the

swankiest location!

Low level/high capacity adjustable

castor allowing full mobility

through swivel function, and static

anchorage by means of mounting

base which adjusts down by

rotating thumbwheel. Up to 2,600kg

loading over 4 castors catered for

Spring adaptor for bolthole castors.

Spring compresses under loading. Ideal

for mobile steps, etc

Three castor skates—specifically

designed for moving scenery

Truck locks - quickly secures a truck or trolley on

castors in static position for loading or unloading

CALL US WITH YOUR APPLICATION DETAILS -

WE WILL ALWAYS DO OUR BEST TO FIND A SOLUTION!

12

01279 656 189 01279 658 891 sales@indifit.co.uk


HEAVY DUTY PRESSED STEEL 250-500KG

4 BZP pressed steel frame with double ball bearing swivel

4 Five choices of wheel type

4 Available in fixed and swivel plate, and swivel single bolthole configurations

HEAVY DUTY PRESSED STEEL

NYLON

RED POLY-

URETHANE

ON WHITE

NYLON

PLATE SIZE: 105 X 86MM BOLTHOLE SPACING: 80 X 60 HOLE DIA: 8MM

100MM SWIVEL C100/HNY 250 32 C100/HNP 250 35 C100/HRN 250 C100/HCI 250 C100/HPTB 250 40 128 90 (116)

100MM FIXED C100/HFNY 250 32 C100/HFNP 250 35 C100/HFRN 250 C100/HFCI 250 C100/HFPTB 250 40 128

125MM SWIVEL C125/HNY 250 35 C125/HNP 250 35 C125/HRN 250 C125/HCI 250 C125/HPTB 250 40 155 93 (120)

125MM FIXED C125/HFNY 250 35 C125/HFNP 250 35 C125/HFRN 250 C125/HFCI 250 C125/HFPTB 250 40 155

PLATE SIZE: 135 X 110MM (SWIVEL) 135 X 115MM (FIXED) BOLTHOLE SPACING 105 X 75/80 HOLE DIA 10MM

100MM SWIVEL C100/PHNY 250 32 C100/PHNP 250 35 C100/PHRN 250 C100/PHCI 250 C100/PHPTB 250 40 129 90 (116)

100MM FIXED C100/PHFNY 250 32 C100/PHFNP 250 35 C100/PHFRN 250 C100/PHFCI 250 C100/PHFPTB 250 40 129

125MM SWIVEL C125/PHNY 250 35 C125/PHNP 250 35 C125/PHRN 250 C125/PHCI 250 C125/PHPTB 250 40 157 93 (120)

125MM FIXED C125/PHFNY 250 35 C125/PHFNP 250 35 C125/PHFRN 250 C125/PHFCI 250 C125/PHFPTB 250 40 157

150MM SWIVEL C150/PHNY 500 45 C150/PHNP 500 40 C150/PHRN 300 C150/PHCI 500 C150/PHPTB 500 50 188 128 (165)

150MM FIXED C150/PHFNY 500 45 C150/PHFNP 500 40 C150/PHFRN 300 C150/PHFCI 500 C150/PHFPTB 500 50 188

200MM SWIVEL C200/PHNY 500 50 C200/PHNP 500 50 C200/PHRN 400 C200/PHCI 500 C200/PHPTB 500 50 238 153 (165)

200MM FIXED C200/PHFNY 500 50 C200/PHFNP 500 50 C200/PHFRN 400 C200/PHFCI 500 C200/PHFPTB 500 50 238

WHEEL TYPES AVAILABLE IN THIS CASTOR RANGE

BLUE ELASTIC

RUBBER ON

BLACK NYLON

CAST

IRON

BROWN POLY-

URETHANE ON

CAST IRON

CP

CPH

CASTORS - HEAVY DUTY PRESSED STEEL

OPTIONS

NY white nylon

NP red polyurethane tyre on white nylon centre

WHEEL BEARINGS

Part number shown in the above table refer to plain bearing wheels

(except “PTB” which is unavailable in plain bearing)

For roller bearing wheel add “B” to end of part number

For ball bearing wheel add “BJ” to end of part number

(available on 150 + 200mm diameters, NY, NP, CI, PTB wheels

only)

PTB brown polyurethane tyre on

roller bearing cast iron centre

CI cast iron

SINGLE BOLTHOLE FITTING

12mm diameter. Available on 100 + 125mm

only - add “BH12” to end of part number

RN blue elastic rubber tyre on black nylon

SWIVEL + WHEEL BRAKE

Add “SWB” to end of part number

01279 656 189 01279 658 891 sales@indifit.co.uk

13


CASTORS - HEAVY DUTY FABRICATED

HEAVY DUTY FABRICATED 300-1400KG

4 Precision machined and induction hardened ballraces

4 Sealed head with grease nipple

4 Polymer-painted black finish

4 Choice of 4 wheel types

4 Swivel and wheel brake or directional lock options

HEAVY DUTY FABRICATED

WHEEL

BEARING

NYLON

BROWN POLY-

URETHANE ON

CAST IRON

BLACK

ELASTIC

RUBBER TYRE

ON CAST IRON

CAST IRON

PLATE SIZE: 150 X 110MM BOLTHOLE SPACING: 121/105 X 80/59 HOLE DIA: 12.2MM

K Pattern Single Wheel

150MM SWIVEL PLAIN C150/KNY 800 45 C150/KCR 300 50 C150/KCI 910 50 200 135 (135)

ROLLER C150/KNYB 800 45 C150/KPTB 750 50 C150/KCRB 300 50 C150/KCIB 910 50 200 135 (135)

BALL JOURNAL C150/KNYBJ 800 45 C150/KTPBJ 750 50 C150/KCRBJ 300 50 C150/KCIBJ 910 50 200 135 (135)

150MM FIXED PLAIN C150/KFNY 800 45 C150/KFCR 300 50 C150/KFCI` 910 50 200

ROLLER C150/KFNYB 800 45 C150/KFPTB 750 50 C150/KFCRB 300 50 C150/KFCIB 910 50 200

BALL JOURNAL C150/KFNYBJ 800 45 C150/KFPTBJ 750 50 C150/KFCRBJ 300 50 C150/KFCIBJ 910 50 200

200MM SWIVEL PLAIN C200/KNY 1000 50 C200/KCI 1000 50 250 165 (165)

ROLLER C200/KNYB 1000 50 C200/KPTB 1000 50 C200/KCIB 1000 50 250 165 (165)

BALL JOURNAL C200/KNYBJ 1000 50 C200/KPTBJ 1000 50 C150/KCRBJ 600 60 C200/KCIBJ 1000 50 250 165 (165)

200MM FIXED PLAIN C200/KFNY 1000 50 C200/KFCI 1000 50 250

ROLLER C200/KFNYB 1000 50 C200/KFPTB 1000 50 C200/KFCIB 1000 50 250

BALL JOURNAL C200/KFNYBJ 1000 50 C200/KPTBJ 1000 50 C150/KFCRBJ 600 60 C200/KFCIBJ 1000 50 250

250MM SWIVEL PLAIN C250/KNY 930 50 300 195 (195)

BALL JOURNAL C250/KNYBJ 1200 50 C250/KPTBJ 1400 60 C250/KCRBJ 500 50 C250/KCIBJ 1250 50 300 195 (195)

250MM FIXED PLAIN C250/KFNY 930 50 300

BALL JOURNAL C250/KFNYBJ 1200 50 C250/KFPTBJ 1400 60 C250/KFCRBJ 500 50 C250/KFCIBJ 1250 50 300

CK

WHEEL TYPES AVAILABLE IN THIS CASTOR RANGE

PTB brown polyurethane tyre on

roller bearing cast iron centre

CI cast iron

CR black elastic rubber

tyre on cast iron

NY white nylon

OPTIONS

SWIVEL + WHEEL BRAKE

Add “SWB” to end of part number

DIRECTIONAL LOCK

Locks plate on swivel castor to adapt

to fixed configuration

Add “DL” to end of part number

14

01279 656 189 01279 658 891 sales@indifit.co.uk


HEAVY DUTY FABRICATED 360-1500KG

4 Precision machined and induction hardened ballraces

4 Sealed head with grease nipple

4 Polymer-painted black finish

4 Choice of 4 wheel types

4 Wheel brake or directional lock options

HEAVY DUTY FABRICATED

WHEEL

BEARING

NYLON

BROWN POLY-

URETHANE ON

CAST IRON

BLACK

ELASTIC

RUBBER TYRE

ON CAST IRON

125MM SWIVEL PLAIN C125/2KNY 700 40

121/105 175 98

X

ROLLER C125/2KNYB 700 40 150 X 110 80/59 175 98

BALL JOURNAL C125/2KNYBJ 700 40 C125/2KPTBJ 800 40 C125/2KCRBJ 360 38 C125/2KCIBJ 900 38

(12)

175 98

125MM FIXED PLAIN C125/2KFNY 700 40

121/105 175

X

ROLLER C125/2KFNYB 700 40 175 X 150 80/59 175

BALL JOURNAL C125/2KFNYBJ 700 40 C125/2KFPTBJ 800 40 C125/2KFCRBJ 360 38 C125/2KFCIBJ 900 38

(12)

175

150MM SWIVEL PLAIN C150/2KNY 1500 45 C150/2KCR 600 50 C150/2KCI 1500 50

121/105 200 135

X

ROLLER C150/2KNYB 1500 45 C150/2KPTB 1500 50 C150/2KCRB 600 50 C150/2KCIB 1500 50 150 X 110 80/59 200 135

BALL JOURNAL C150/2KNYBJ 1500 45 C150/2KPTBJ 1500 50 C150/2KCRBJ 600 50 C150/2KCIBJ 1500 50

(12)

200 135

150MM FIXED PLAIN C150/2KFNY 1500 45 C150/2KFCR 600 50 C150/2KFCI 1500 50

121/105 200

X

ROLLER C150/2KFNYB 1500 45 C150/2KFPTB 1500 50 C150/2KFCRB 600 50 C150/2KFCIB 1500 50 175 X 150 80/59 200

BALL JOURNAL C150/2KFNYBJ 1500 45 C150/2KFPTBJ 1500 50 C150/2KFCRBJ 600 50 C150/2KFCIBJ 1500 50

(12)

200

200MM SWIVEL PLAIN C200/2KNY 1500 50 C200/2KCI 1500 50

121/105 250 165

X

ROLLER C200/2KNYB 1500 50 C200/2KPTB 1500 50 C200/2KCIB 1500 50 150 X 110 80/59 250 165

BALL JOURNAL C200/2KNYBJ 1500 50 C200/2KPTBJ 1500 50 C200/2KCRBJ 1200 60 C200/2KCIBJ 1500 50

(12)

250 165

CAST IRON

2K Pattern Double Wheel

PLATE SIZE

BOLTHOLE

SPACING

(DIA)

200MM FIXED PLAIN C200/2KFNY 1500 50 C200/2KFCI 1500 50

121/105 250

X

ROLLER C200/2KFNYB 1500 50 C200/2KFPTB 1500 50 C200/2KFCIB 1500 50 175 X 150 80/59 250

BALL JOURNAL C200/2KFNYBJ 1500 50 C200/2KFPTBJ 1500 50 C200/2KFCRBJ 1200 60 C200/2KFCIBJ 1500 50

(12)

250

C2K

CASTORS - HEAVY DUTY FABRICATED

WHEEL TYPES AVAILABLE IN THIS CASTOR RANGE

PTB brown polyurethane tyre on

roller bearing cast iron centre

CR black elastic rubber

tyre on cast iron

CI cast iron

NY white nylon

NOT HEAVY

ENOUGH?

We are able to supply

various patterns of

specialist castors to suit

load capacities to 7000kg

PLEASE CALL US WITH

YOUR REQUIREMENTS!

OPTIONS

WHEEL BRAKE

Add “BR” to end of part number.

(Note - brake is “trailing”)

DIRECTIONAL LOCK

Locks plate on swivel castor to adapt

to fixed configuration

Add “DL” to end of part number

01279 656 189 01279 658 891 sales@indifit.co.uk

15


CASTORS - PNEUMATIC TYRED WHEELS / GATE CASTOR

CASTORS WITH PNEUMATIC TYRED WHEELS

4 BZP pressed steel frame with double ball

bearing swivel and head seal

4 Swivel and fixed configurations

4 Wheels with roller bearing centres in

plastic or steel

PNEUMATIC TYRED WHEELS

Plastic centre with

diamond tread

PLASTIC

CENTRED

WHEEL

GATE CASTOR

TREAD

PATTERN

Steel centre with

ribbed tread

CPC Pressed steel frame

CPC PRESSED STEEL FRAME

STEEL

CENTRED

WHEEL

TREAD

PATTERN

CFPC FABRICATED STEEL FRAME

4 Specifically designed to help support wide gates.

4 Vertical plate fitting

4 Sprung loaded to compensate for uneven surfaces or gentle slopes

4 Fitted as standard with black elastic rubber tyred wheel on ball bearing cast iron centre

PLATE SIZE

BOLTHOLE

SPACING

(DIA)

200MM SWIVEL C200/PCPRB RIBBED 75 C200/PCMRB RIBBED 75 50 140 X 110 105 X 80/75 (10) 232 167

200MM FIXED C200/PCFPRB RIBBED 75 C200/PCFMRB RIBBED 75 50 140 X 110 105 X 80/75 (10) 232

260MM SWIVEL C260/PCPRB DIAMOND 120 C200/PCMRB DIAMOND 200 85 200 X 160 150 X 115 (14) 302 215

260MM FIXED C260/PCFPRB DIAMOND 120 C260/PCFMRB DIAMOND 200 85 200 X 160 150 X 115 (14) 302

260MM SWIVEL C260/FPCPRB DIAMOND 120 C260/FCPMRB DIAMOND 200 85 115 X 112 92/76 X 76/67 (10) 318 171

260MM FIXED C260/FPCFPRB DIAMOND 120 C260/FPCFMRB DIAMOND 200 85 115 X 112 92/76 X 76/67 (10) 318

GATE CASTOR

CPC

BLACK

ELASTIC TYRE

ON CAST

IRON CENTRE

CFPC Fabricated steel frame

CFPC

ALSO AVAILABLE

260mm dia also available with micro-cellular polyurethane

tyred wheel. Lightweight and puncture-proof!

PLEASE ENQUIRE FOR DETAILS

PLATE SIZE

100MM SWIVEL C100/GCBJ 40 75* 159 X 41 85 (8)

100MM FIXED C100/GCFBJ 40 75* 159 X 41 85 (8)

CGC

BOLTHOLE

SPACING

(DIA)

8

41

85 159

85

40

375

ALSO AVAILABLE

Wide range of jacking castors are also

available in diameters 75—100mm, with

load capacities ranging 120—1000kg. Wheel

types include nylon, polyurethane tyre on

nylon or cast iron centre, rubber tyred cast

iron and solid cast iron.

PLEASE ENQUIRE FOR DETAILS

100

16

01279 656 189 01279 658 891 sales@indifit.co.uk


WHEELS

Our standard range of wheels is detailed on this page, and is normally available from stock for immediate

despatch. We are also able to supply many other types of wheel, including light duty domestic, pneumatic,

phenolic (standard and high temperature), anti-static etc, etc.

GREY SYNTHETIC RUBBER TYRE - PLAIN BEARING PLASTIC CENTRE 40-70KG

PART NO

50MM CW050/TB 18 10 27 40

63MM CW060/TB 22 10 27 40

80MM CW080/TB 22 10 27 50

100MM CW100/TB 27 12 32 60

125MM CW125/TB 27 12 32 70

TB

WHEELS

LIGHT DUTY 55-100KG

TN

MEDIUM DUTY 100-380KG

NVB

PART NO

50MM CW050/TN 18 8 23 55

60MM CW060/TN 22 10 27 60

80MM CW080/TN 22 10 27 80

100MM CW100/TN 27 12 32 90

125MM CW125/TN 27 12 32 100

PART NO

80MM CW080/NVB 30 12 39 100

100MM CW100/NVB 30 12 39 130

125MM CW125/NVB 39 15 44 200

150MM CW150/NVB 40 20 45 250

200MM CW200/NVB 50 20 58 380

POLYURETHANE TYRE - PLAIN BEARING NYLON CENTRE 100-365KG

NY

PART NO

80MM CW080/NYB 29 12 40 100

100MM CW100/NYB 30 12 40 130

125MM CW125/NYB 34 15 44 200

150MM CW150/NYB 39 20 45 250

200MM CW200/NYB 49 20 58 365

BLACK RUBBER TYRE ON PLAIN BEARING PLASTIC CENTRE 50-240KG

SC

PART NO

80MM CW080/SC 25 12 39 50

100MM CW100/SC 30 12 39 70

125MM CW125/SC 37.5 15 44 100

150MM CW150/SC 40 20 45 140

200MM CW200/SC 50 20 58 205

250MM CW250/SC 60 25 78 240

Don’t see what you need...

CALL US

We can supply much more than is

shown in this catalogue!

?

BLACK RUBBER TYRE ON ROLLER BEARING STEEL CENTRE 50-300KG

ERS

PART NO

80MM CW080/ERS 25 12 39 50

100MM CW100/ERS 30 12 39 70

125MM CW125/ERS 37.5 15 44 110

150MM CW150/ERS 40 20 45 150

160MM CW160/ERS 40 20 45 160

200MM CW200/ERS 50 20 58 220

250MM CW250/ERS 60 25 77.5 300

01279 656 189 01279 658 891 sales@indifit.co.uk

17


WHEELS

WHEELS

BLUE ELASTIC RUBBER TYRE

ON BLACK NYLON CENTRE 40-500KG

PLAIN

BEARING

PART NO

50MM 22 6.4 24 CW050RN 40

65MM 35 12 40 CW065RN 80

75MM 35 12 40 CW075RN 90

80MM 35 12 40 CW080RN 100

ROLLER

BEARING

PART NO

100MM 32 12 40 CW100RN 160 CW100RNB 160

100MM 40 15 48 CW100RN15 250 CW100RN15B 250

125MM 36 15 45 CW125RN 200 CW125RNB 200

125MM 40 15 48 CW125RN40 250 CW125RN40B 250

125MM 50 20 60 CW125RN20B 275

150MM 50 20 60 CW150RN 300 CW150RNB 300

BALL

BEARING

PART NO

CWRN

160MM 50 20 50 CW160RNBJ 300

160MM 50 20 60 CW160RNB 300 CW160RNBJ/60 300

200MM 50 20 50 CW200RNBJ 400

200MM 50 20 60 CW200RN 400 CW200RNB 400 CW200RNBJ/60 400

250MM 50 25 60 CW250RNB 500

250MM 60 25 60 CW250RNBJ 500

BLACK RUBBER TYRE ON

BOLTED STEEL CENTRE 205-700KG

PLAIN

BEARING

PART NO

200MM 50 25.4 51 CW200MK254 205

250MM 60 25.4 51 CW250MK254 350

250MM 60 25 60 CW250MK250 350

300MM 60 25.4 51 CW300MK254 400

355MM 80 25.4 66 CW355MK254 400

ROLLER

BEARING

PART NO

CWMK

355MM 80 25 75 CW355MK250 400

355MM 80 25.4 75 CW355MK254/75 400

400MM 100 25.4 66 CW400MK254 700

400MM 100 25 75 CW400MK250B 700

400MM 100 25.4 75 CW400MK254/75 700

SOLID CAST IRON 100-1250KG

PLAIN

BEARING

PART NO

75MM 32 12 39 CW075CI 100

80MM 32 12 39 CW080CI 130

100MM 35 12 39 CW100CI 240

100MM 35 12.7 39 CW100CI127 240

ROLLER

BEARING

PART NO

100MM 38 12 45 CW100CIB/45 260

100MM 38 20 45 CW100CI/38 260

100MM 38 15 48 CW100CI150 270 CW100CI15B 270

100MM 38 23 48 CW100CI/48 270

BALL

BEARING

PART NO

CWCI

100MM 50 20 60 CW100CI200 400 CW100CI200B 400 CW100CI200BJ 400

125MM 35 12 44 CW125CI1200B 350

125MM 35 15 44 CW125CI150 350

125MM 38 20 44 CW125CI 350 CW125CIBJ 350

125MM 38 15 48 CW125CI/38 350 CW125CIB/38 350

125MM 38 23 48 CW125CI230 350

125MM 50 20 60 CW125CI/50 550 CW125CIB/50 550 CW125CIBJ/50 550

150MM 50 20 60 CW150CI 910 CW150CIB 910 CW150CIBJ 910

200MM 50 20 60 CW200CI 1000 CW200CIB 1000 CW200CIBJ 1000

250MM 50 20 60 CW250CIBJ 1250

BLACK RUBBER TYRE ON RED

POLYPROPYLENE CENTRE 120-350KG

PLAIN

BEARING

PART NO

160MM 40 20 51 CW160PK200 120

160MM 40 25.4 51 CW160PK254 120

ROLLER

BEARING

PART NO

CWPK

200MM 50 25.4 51 CW200PK254 205 CW200PK254B 205

250MM 60 25 60 CW250PK250B 275

250MM 60 25.4 51 CW250PK254 275 CW250PK254B 275

260MM 95 25.4 59 CW260PK254 125

300MM 60 25.4 51 CW300PK254 280 CW300PK254B 280

355MM 90 25.4 66 CW355PK254 280 CW355PK254B 300

400MM 100 25 66 CW400PK250B 350

400MM 100 25.4 66 CW400PK254 350 CW400PK254B 350

18

01279 656 189 01279 658 891 sales@indifit.co.uk


WHEELS

WHEELS

PNEUMATIC TYRED STEEL CENTRE 75-300KG

PSI

TREAD

PLAIN

BEARING

PART NO

200MM 50 20 60 36* R CW200PM 75

ROLLER

BEARING

PART NO

CWPM

260MM 85 25 65 36 D CW260PMB 200

260MM 85 25.4 65 36 D CW260PMB254 200

260MM 85 20 75 36 D CW260PM 200

260MM 85 25 75 36 D CW260PM250 200

260MM 85 25.4 75 36 D CW260PM254 200

300MM 100 25 65 36 D CW300PMB 250

300MM 100 25 65 36 D CW300PMB254 250

300MM 100 25 75 36 D CW300PM 250

300MM 100 25.4 75 36 D CW300PMB 250

400MM 105 25 65 30 R CW400PMB 250

400MM 105 25.4 65 30 R CW400PMB254 250

400MM 105 25 65 30 D CW400PMBD 300

400MM 105 25.4 65 30 D CW400PMB254D 300

400MM 105 25 75 30 R CW400PM 250

400MM 105 25.4 75 30 R CW400PM254 250

400MM 105 25 75 30 D CW400PMD 300

400MM 105 25.4 75 30 D CW400PM254D 300

PNEUMATIC TYRED PLASTIC CENTRE 75-200KG

*2 ply tyres. All others shown are 4-ply. 6 ply tyres are available in some sizes -

please enquire

PLEASE NOTE, These wheels are designed for manual propulsion at max speed of 4kph

TREAD PATTERNS

D - Diamond

PSI

TREAD

PLAIN

BEARING

PART NO

R - Ribbed

ROLLER

BEARING

PART NO

CWPP

200MM 50 20 60 30* R CW200PPB 75

260MM 85 20 75 30 D CW260PP 120 CW260PPB 120

260MM 85 25 75 30 D CW260PP250 120 CW260PPB250 120

260MM 85 25.4 75 30 D CW260PP254 120 CW260PPB254 120

300MM 100 25 75 30 D CW300PP 155 CW300PPB 155

300MM 100 25.4 75 30 D CW300PP254 155 CW300PPB254 155

370MM 85 25 75 30* R CW370PPB 120

400MM 105 25 75 30 R CW400PP 200 CW400PPB 200

400MM 105 25.4 75 30 R CW400PP254 200 CW400PPB254 200

400MM 105 25 75 30 D CW400PPB25D 200

400MM 105 25.4 75 30 D CW400PPB254D 200

ALSO AVAILABLE

PUNCTURE-PROOF MICROCELLULAR

TYRED WHEELS

Lightweight and resilient.

Plastic or steel centre.

Please call for details.

POLYURETHANE TYRED CAST IRON CENTRE 80-4500KG

PLAIN

BEARING

PART NO

ROLLER

BEARING

PART NO

BALL

BEARING

PART NO

ROLLER

BEARING

PART NO

BALL

BEARING

PART NO

50MM 14 12 17 CW050PT 80 150MM 40 20 40 CW150PTBJ/40 500

60MM 35 12 37 CW060PTBJ 180 150MM 50 20 50 CW150PTB 750 CW150PTBJ 750

75MM 30 12 40 CW075PT 150 150MM 50 25.4 60 CW150PTB254 750

75MM 40 15 40 CW075PTBJ 300 200MM 45 25 45 CW200PTBJ 1000

100MM 30 12 45 CW100PTB 250 200MM 45 20 60 CW200PTB 1000 CW200PTBJ 1000

100MM 30 15 30 CW100PTBJ 250 200MM 45 25.4 60 CW200PTB254 1000

100MM 30 20 45 CW100PT 250 200MM 75 30 82 CW200PTBJ/75 1600

100MM 40 15 50 270 CW100PT150B 300 200MM 100 50 100 CW200PTBJ/100 2000

100MM 40 23 50 CW100PT230 300 250MM 50 25 60 CW250PTBJ 1200

100MM 40 20 40 CW100PT200BJ 300 250MM 60 25 60 CW250PTBJ/60 1400

100MM 50 20 60 CW100PTBJ/50 400 250MM 75 30 82 CW250PTBJ/75 1800

125MM 30 12 45 CW125PTB 300 250MM 100 50 100 CW250PTBJ/100 2500

125MM 30 15 30 CW125PTBJ 300 300MM 75 30 82 CW300PTBJ 2200

125MM 30 20 45 CW125PT200 300 300MM 100 50 100 CW300PTBJ/100 3000

125MM 40 15 50 CW125PT150B 350 400MM 100 50 108 CW400PTBJ 3500

125MM 40 23 50 CW125PT230 350 450MM 85 35 75 CW450PTBJ 4000

125MM 40 20 50 CW125PT200BJ 400 500MM 85 35 75 CW500PTBJ 4500

125MM 50 20 60 CW125PTBJ/50 500

CWPT

01279 656 189 01279 658 891 sales@indifit.co.uk

19


DRAWER SLIDES - CABLE MANAGEMENT

DRAWER SLIDES

We can supply a wide variety of drawer slides for light to heavy duty applications. Our primary stock range is detailed below,

but please call should you require a different pattern - specifications of alternative ranges can be supplied.

4 45kg load rating in closed position

4 Slim profile

4 32mm Euro pattern hole spacing

4 Bright zinc plated finish as standard

Ø4.6 15 8.3x4.4(TYP)

Ø6.4(TYP)

Ø4.6 15 8.3x4.4(TYP)

Ø6.4(TYP)

16

32

16

12.732

45.5

F

G

G

12.7

F

12.7

J

E

J

12.7

E

A

12.7

A

16

32

4 Trigger disconnect facility

4 Cold rolled steel slide members

4 Carbon steel ball bearings

4 Nylon trigger / stops

A A

D

C D

B C

Ø6.2(TYP) Ø4.2(TYP)

64 B

32 35

Ø6.2(TYP) Ø4.2(TYP) Ø4.5

I

9.6

25.4

9.6

25.4

H

7

9.6

25.4

Double extension draw slide

PART NO A B C D E F G H I J K

DS45H/250/TS

64

250 250 160 32 43 163

32 35

DS45H/300/TS 300 300 208 16 53 203

Ø4.5

DS45H/350/TS 7 350 350 224 256 53 112 142

DS45H/400/TS 9.6 400 400 224 288 32 53 132 171

25.4

DS45H/450/TS 450 450 224 288 352 53 157 196

4.5x9.4(TYP)

Ø4.4(TYP) 9.4x4.5(TYP)

1.5

I

DS45H/500/TS H

500 500 224 288 416 64 53 182 221

16

4.5x9.4(TYP) 16

Ø4.4(TYP) 32

32

9.4x4.5(TYP)

DS45H/550/TS 1.5

550 550 224 288 416 64 32 64 53 212 242

DS45H/600/TS 600 600 224 320 480 32 53 222 281

16

32DS45H/700/TS 700 700 224 352 576 53 272 331

(All sizes in millimetres)

L

L

12.7

45.5

DS

12.7

45.5

CABLE ACCESS GROMMETS

4 Enables cables to be safely and neatly

channeled through panels

4 Slim, low profile liner with removable cap

4 Many other patterns, sizes and colours

available

PANEL OVERALL LINER SHAPE PART NO

APERTURE SIZE DIM (A) DEPTH (B)

PC

46.0mm Dia 55 18 ROUND PCD460

A

60.0mm Dia 69 18 ROUND PCD600

80.0mm Dia 96 18 ROUND PCD800

102.5 x 52.5mm 118 x 68 18 RECT PCL100500

102.5 x 52.5mm 150 x 75 18 OVAL PCV100500

B

COLOURS

Popular size/pattern/colour combinations are held in stock for immediate delivery.

Other colours are available to order - specials may be subject to minimum quantities.

PLEASE CONTACT OUR SALES DEPARTMENT FOR DETAILS.

20

01279 656 189 01279 658 891 sales@indifit.co.uk


ECONOMICAL LIGHT DUTY

4 Low priced range of standard adjustable feet suitable for furniture,

stands and light duty applications

4 Pozi/screwdriver slot in base for automated assembly

4 Stock colour black - can be colour matched subject to quantity

BASE DIA (MM) THREAD SIZE STEM LENGTH PART NO

25 M8 25 FSE25/0825

25 M8 38 FSE25/0838

25 M8 50 FSE25/0850

38 M8 25 FSE38/0825

38 M8 38 FSE38/0838

38 M8 50 FSE38/0850

PLASTIC BASE TILTGLIDE

4 Plastic base with BZP steel stud, pivoting on ball & socket

4 Ideal for uneven or sloping floors, or angled legs

BASE DIA

FSE

STUD SIZE 25MM 32.5MM 40MM 47.5MM 55MM

M6 X 12.5 FT25/0613 FT32/0613 FT40/0613 FT47/0613 FT55/0613

M6 X 25 FT25/0625 FT32/0625 FT40/0625 FT47/0625 FT55/0625

M8 X 12.5 FT25/0813 FT32/0813 FT40/0813 FT47/0813 FT55/0813

M8 X 25 FT25/0825 FT32/0825 FT40/0825 FT47/0825 FT55/0825

M8 X 37.5 FT25/0838 FT32/0838 FT40/0838 FT47/0838 FT55/0838

M8 X 50 FT25/0850 FT32/0850 FT40/0850 FT47/0850 FT55/0850

M8 X 60 FT25/0860 FT32/0860 FT40/0860 FT47/0860 FT55/0860

M8 X 75 FT25/0875 FT32/0875 FT40/0875 FT47/0875 FT55/0875

M8 X 100 FT25/08100 FT32/08100 FT40/08100 FT47/08100 FT55/08100

M10 X 15 FT25/1015 FT32/1015 FT40/1015 FT47/1015 FT55/1015

M10 X 25 FT25/1025 FT32/1025 FT40/1025 FT47/1025 FT55/1025

M10 X 37.5 FT25/1037 FT32/1037 FT40/1037 FT47/1037 FT55/1037

M10 X 50 FT25/1050 FT32/1050 FT40/1050 FT47/1050 FT55/1050

FT

AVAILABLE TO ORDER

Integral tube insert in nylon, with tilt base

in metric sizes. Options include base caps

in PTFE, felt, and metal. Please enquire for

full details

BASE DIA

STUD SIZE 25MM 32.5MM 40MM 47.5MM 55MM

M10 x 75 FT25/1075 FT32/1075 FT40/1075 FT47/1075 FT55/1075

M10 x 100 FT25/10100 FT32/10100 FT40/10100 FT47/10100 FT55/10100

M12 x 50 FT25/1250 FT32/1250 FT40/1250 FT47/1250 FT55/1250

M12 x 75 FT25/1275 FT32/1275 FT40/1275 FT47/1275 FT55/1275

M12 x 100 FT25/12100 FT32/12100 FT40/12100 FT47/12100 FT55/12100

FT

ADJUSTABLE FEET - STATIC - TILT

LOW PROFILE

4 Versatile range with low profile plastic base and BZP steel stud

4 Huge variety of base and stud sizes

4 Can be used as thumbscrews owing to knurled edge (not 15mm dia)

FSL

BASE DIA (MM) 15 20 25 29 32 38 44

BASE THICKNESS (MM) 6 6 6 7 9 9 10

BASE DIA (MM) 20 25 29 32 38 44 60

BASE THICKNESS (MM) 6 6 7 9 9 10 10

M5 x 13 A A A

M8 x 12 A A A A A

M5 x 17 A A A

M8 x 16 A A A A A A

M5 x 22 A A A

M8 x 21 A A A A A A

M5 X 27 A A A

M8 x 26 A A A A A A

M5 x 37 A A A

M8 X 36 A A A A A A

STUD SIZE

M6 x 9 A A

M6 x 11 A A A

M6 x 13 A A A

STUD SIZE

M8 x 46 A A A A A A

M8 x 71 A A A A A

M10 x 19 A A A A A A

M6 x 17 A A A A A A A

M10 x 24 A A A A A A

M6 x 22 A A A A A A A

M10 x 34 A A A A A A

M6 x 27 A A A A A A A

M10 x 44 A A A A A A

M6 x 37 A A A A A A A

M10 x 54 A A A A A A

M6 x 47 A A A

A = AVAILABLE

01279 656 189 01279 658 891 sales@indifit.co.uk

21


ADJUSTABLE FEET - STATIC

MEDIUM - HEAVY DUTY

OPTIONS - TO SPECIAL ORDER

Coloured bases.

Hexagon in stud end to enable adjustment from top when assembled.

Minimum quantities will apply - please enquire

FSB type

Articulating BZP steel

stud with hexagon

Base material:

polypropylene/nylon

FSA type

(38 and 48mm base)

Fixed BZP steel stud

with hexagon

Base material: polypropylene/

nylon

FSJ type

Articulating BZP steel

stud with hexagon

Base material:

polypropylene

FSA type (70mm)

Fixed BZP steel stud

Base material:

polypropylene

4 Economically priced range of medium duty adjusters

4 Vast range of base size / thread /stud length

4 Static load capacity 400 - 650kg according to pattern/size*

4 Steel pozi head in base for automated assembly*

(*not 70mm base)

ANTI SLIP BASE

To suit FSA and FSB series in 38 and 48 base diameters.

Manufactured in TPE shore 85. Thickness - 3.5mm

SCREW DOWN BASE

To suit FSA and FSB series in 38, 48 and 58mm base

diameters. Manufactured in nylon 6. Has centre hole (4mm) to

enable fixing to floor. Adjuster then locates onto the base.

BASE DIA NON SLIP SCREW DOWN

38mm FSA38/TPE FSA38/SD

48mm FSA48/TPE FSA48/SD

58mm

FSA

FSA58/SD

FSB

FSA

FSJ

STUD SIZE

A = AVAILABLE

BASE DIA (MM) 20 30 30 38 38 40 48 48 58 70

BASE TYPE FSJ FSB FSJ FSA FSB FSJ FSA FSB FSB FSA

BASE THICKNESS 11 10 10 10 10 10 10 10 19.5 14

M8 x 16 A A A A A A A A

M8 x 20 A A A A A A A A

M8 x 30 A A A A A A A A

M8 x 40 A A A A A A A A

M8 x 50 A A A A A A A A

M8 x 60 A A A A A A A A

M8 x 70 A A A A A A A A

M8 x 80 A A A A A A A A

M8 x 90 A A A A A A A A

M8 x 100 A A A A A A A A

M8 x 120 A A A A A A A A

M10 x 16 A A A A A A A A A

M10 x 20 A A A A A A A A A A

M10 x 30 A A A A A A A A A

M10 x 40 A A A A A A A A A A

M10 x 50 A A A A A A A A A

STUD SIZE

A = AVAILABLE

BASE DIA (MM) 20 30 30 38 38 40 48 48 58 70

BASE TYPE FSJ FSB FSJ FSA FSB FSJ FSA FSB FSB FSA

BASE THICKNESS 11 10 10 10 10 10 10 10 19.5 14

M10 x 60 A A A A A A A A A A

M10 x 70 A A A A A A A A A

M10 x 80 A A A A A A A A A

M10 x 90 A A A A A A A A A

M10 x 100 A A A A A A A A A

M10 x 120 A A A A A A A A A

M12 x 30 A A A A A A A A

M12 x 38

M12 x 40 A A A A A A A A

M12 x 50 A A A A A A A A

M12 x 60 A A A A A A A A

M12 x 70 A A A A A A A A

M12 x 80 A A A A A A A A A

M12 x 90 A A A A A A A A

M12 x 100 A A A A A A A A

M12 x 120 A A A A A A A A

A

STATIC ADJUSTER WITH HEX-END STUD

Static adjuster with nylon base, and BZP steel stud which turns independently of base. Hex form at stud

end to enable adjustment from above, or in situ by standard hexagon socket.

All sizes have 12mm A/F hexagon at base of stud for conventional adjustment and pozi slot in

underside of nylon base for automated assembly.

BASE DIA

(MM)

BASE THICKNESS

(TO TOP OF HEX NUT) MM M10 X 35 M10 X 45 M10 X 70

FSX

30 19 FSX30/1035 FSX30/1045 FSX30/1070

40 19 FSX40/1035 FSX40/1045 FSX40/1070

45 22 FSX45/1035 FSX45/1045 FSX45/1070

50 19 FSX50/1035 FSX50/1045 FSX50/1070

22

01279 656 189 01279 658 891 sales@indifit.co.uk


DECORATIVE - CHROME COLOUR CAPPED

4 Compliments chrome finished furniture or apparatus

4 Highly decorative finish

STUD SIZE

FSC

BASE DIA (MM) 20 25 30 35 40 40 40 45 50 50

BASE TYPE FSCA FSCA FSCA FSCA FSCA FSCB FSCA FSCD FSCA FSCB

BASE THICKNESS 7 10 11.5 12 12 18 17.5 22 15.5 19.5

M6 x 13

A

A = AVAILABLE

M8 x 20 A A A

M8 x 25

M10 x 20 A A A

M10 x 25

M10 x 30

M10 x 40 A A

M10 x 45

M10 x 60 A A

M12 x 30

M12 x 35

A

A

A

A

A

FSCB type

Articulating BZP

steel stud

Base material: black plastic

with chrome colour metal

cover cap

OPTIONS - TO SPECIAL ORDER

Brass colour cover cap and stud

Minimum quantities will apply - please enquire

FSCD type

Fixed BZP steel stud

Base material: natural nylon with

plated metal cover cap

FSCA type

Fixed BZP steel stud

Base material: black

plastic with chrome

colour metal cover cap

ADJUSTABLE FEET - STATIC

HEAVY DUTY

4 High quality range of adjusters

with static load capacity range

500 - 2000kg according to size/

pattern

4 Black nylon base, articulating BZP

steel stud with integral hexagon

FSF type

Flat Base

allows adjustment under load

4 Screwdriver slot in base for

automated assembly

4 Moulded pilot holes in base

enable permanent fixing to floor/

ceiling (not 47.5mm base)

FSH type

Conical Base

CONICAL BASE

BASE BASE PART NO

DIA (MM) THICKNESS* (***** = STUD SIZE)

47.5 19 FSH48/*****

*Dimension is from top of hexagon to floor

FSH

FLAT BASE

BASE BASE PART NO

DIA (MM) THICKNESS* (***** = STUD SIZE)

25 15 FSF25/*****

37.5 15 FSF38/*****

47.5 15 FSF48/*****

*Dimension is from top of hexagon to floor

FSF

STUD THREAD / LENGTH

(available with all diameters/patterns)

M10 x 25 M10 x 100

M10 x 35 M12 x 45

M10 X 45 M12 x 65

OPTIONS - TO SPECIAL ORDER

Coloured bases.

Screwdriver slot in stud end to enable

adjustment from top when assembled.

M10 x 70 M12 x 100

Minimum quantities will apply - please enquire

ALL STEEL ADJUSTER

4 Load capacities up to 650kg

4 Bright zinc plated mild steel base and stem

PLAIN BASE

FSM

FSM type

Articulating BZP steel

stud Plain base

Need a threaded insert

for your adjuster?

SEE PAGES 27-30

A = AVAILABLE

BASE STUD STUD LENGTHS

DIA (MM) THREAD 20 30 40 50 60 70 80 90 100 120

45 M8 A A A A A A A A A A

45 M10 A A A A A A A A A A

45 M12 A A A A A A A A

46 M10 A A

ALSO AVAILABLE

FSMB TYPE

With bolt-down base as standard.

Base dias 40 and 50mm, with M8,

M10 and M12 studs.

TO SPECIAL ORDER -PLEASE

ENQUIRE FOR AVAILABILITY

01279 656 189 01279 658 891 sales@indifit.co.uk

23


ADJUSTABLE FEET - HEAVY DUTY

NYLON BASE WITH STEEL STUD

Plain Base

Bolt-Down Base

20 o Articulation

(C1=82mm)

55 M8 30 57 400 FTM055/08030/S

55 M8 60 87 400 FTM055/08060/S

55 M10 75 102 500 FTM055/10075/S

4 Threaded studs rolled from hexagon bar to ensure integrity and strength

4 Studs available in 303 stainless steel (316L to special order on some sizes)

and BZP mild steel

4 Bases in plain or bolt-down style manufactured in re-inforced nylon

4 Strong ball and socket prevents base detachment even when equipment

is moved

4 Special options - non slip nitrile pad bonded to base - vibration

dampening pad bonded to base - hygienic plastic seal cover for ball

and socket joint

55 M12 75 102 600 FTM055/12075/S FTM055/12075/M

55 M12 125 152 600 FTM055/12125/S FTM055/12125/M

55 M12 150 177 600 FTM055/12150/S FTM055/12150/M

70 M12 75 108 1000 FTM070/12075/S FTM070/12075/M

70 M12 125 158 1000 FTM070/12125/S FTM070/12125/M

70 M12 150 183 1000 FTM070/12150/S FTM070/12150/M

70 M16 75 111 1500 FTM070/16075/S FTM070/16075/M

70 M16 125 161 1500 FTM070/16125/S FTM070/16125/M

70 M16 150 186 1500 FTM070/16150/S FTM070/16150/M

70 M16 200 236 1500 FTM070/16200/S FTM070/16200/M

5mm

Our primary range of heavy duty adjusters is manufactured from the highest

quality materials and to the finest tolerances to ensure premium quality for

demanding applications.

Popular combinations of base diameter and pattern, and stud size are held

in stock for immediate despatch with less popular items available on short

leadtimes.

BASE THREAD STUD OVERALL OVERALL HEIGHT MAX STAINLESS STUD STAINLESS STUD BZP MS STUD BZP MS STUD

DIA (D1) LENGTH HEIGHT BOLT-DOWN LOAD PLAIN BASE BOLT-DOWN BASE PLAIN BASE BOLT-DOWN BASE

(D2) (L) PLAIN (L) (H) (KG) PART NO PART NO PART NO PART NO

100 M12 75 117 1000 FTM100/12075/SB FTM100/12075/MB

100 M12 125 167 1000 FTM100/12125/SB FTM100/12125/MB

100 M12 150 192 1000 FTM100/12150/SB FTM100/12150/MB

100 M16 75 119 120 2000 FTM100/16075/S FTM100/16075/SB FTM100/16075/M FTM100/16075/MB

100 M16 125 169 170 2000 FTM100/16125/S FTM100/16125/SB FTM100/16125/M FTM100/16125/MB

100 M16 150 194 195 2000 FTM100/16150/S FTM100/16150/SB FTM100/16150/M FTM100/16150/MB

100 M16 200 244 245 2000 FTM100/16200/S FTM100/16200/SB FTM100/16200/M FTM100/16200/MB

100 M20 125 178 174 2000 FTM100/20125/S FTM100/20125/SB FTM100/20125/M FTM100/20125MB

100 M20 150 200 199 2000 FTM100/20150/S FTM100/20150/SB FTM100/20150/M FTM100/20150/MB

100 M20 200 250 249 2000 FTM100/20200/S FTM100/20200/SB FTM100/20200/M FTM100/20200/MB

100 M24 125 179 178 2000 FTM100/24125/S FTM100/24125/SB FTM100/24125/M FTM100/24125/MB

100 M24 150 204 203 2000 FTM100/24150/S FTM100/24150/SB FTM100/24150/M FTM100/24150/MB

100 M24 200 254 253 2000 FTM100/24200/S FTM100/24200/SB FTM100/24200/M FTM100/24200/MB

100 M24 250 304 303 2000 FTM100/24250/S FTM100/24250/SB FTM100/24250/M FTM100/24250/MB

FTM

OPTION

OPTION

OPTION

Hygienic seal. Prevents ingress of

matter into ball and socket joint.

Also resistant to range of industrial

chemicals.

Nitrile pad providing some resistance

to movement of apparatus and protection

to vulnerable floors. Can be supplied

separately.

Vibration absorbing pad. Mixture

of synthetic rubber and cork that

resists water, most oils, spirits and

cutting fluids.

24

01279 656 189 01279 658 891 sales@indifit.co.uk


LOW PROFILE BOLT-DOWN ALL STAINLESS RANGE

4 Base and stud in stainless steel type 303

4 Superior quality and strength

4 Ideal for hygienic environments such as pharmaceutical,

food preparation, medical and marine

4 Special options - non slip nitrile pad bonded to base

- vibration dampening pad bonded to base - hygienic

plastic seal cover for ball and socket joint

20 o Articulation

BASE THREAD STUD OVERALL HOLE FLANGE HOLE MAX PART

DIA (D) (T) LENGTH (L) HEIGHT (H) CENTRES (C) THICKNESS (t) DIA (d) LOAD (KG) NO

50 M8 60 82 40 4 5.5 300 FTM050/08060/SSB

50 M10 75 97 40 5 5.5 500 FTM050/10075/SSB

50 M12 75 100 40 4 5.5 750 FTM050/12075/SSB

60 M12 75 100 50 5 5.5 1250 FTM060/12075/SSB

60 M12 125 150 50 5 5.5 1250 FTM060/12125/SSB

80 M16 75 106 68 6 6.5 1750 FTM080/16075/SSB

80 M16 125 156 68 6 6.5 1750 FTM080/16125/SSB

80 M16 150 181 68 6 6.5 1750 FTM080/16150/SSB

100 M16 125 158 82 6.5 9 2500 FTM100/16125/SSB

100 M16 150 183 82 6.5 9 2500 FTM100/16150/SSB

100 M16 200 233 82 6.5 9 2500 FTM100/16200/SSB

100 M20 125 164 82 6.5 9 2500 FTM100/20125/SSB

100 M20 150 189 82 6.5 9 2500 FTM100/20150/SSB

100 M20 200 239 82 6.5 9 2500 FTM100/20200/SSB

120 M20 150 191 100 7.5 11 3750 FTM120/20150/SSB

120 M20 200 241 100 7.5 11 3750 FTM120/20200/SSB

120 M24 125 181 100 7.5 11 3750 FTM120/24125/SSB

120 M24 150 206 100 7.5 11 3750 FTM120/24150/SSB

120 M24 200 256 100 7.5 11 3750 FTM120/24200/SSB

5mm

Bolt-Down Base

FTM

ADJUSTABLE FEET - HEAVY DUTY

SPECIAL OPTIONS

Heavy duty threaded tube

inserts in reinforced

nylon with threads in

stainless, or brass

plated mild steel.

Tube sizes 30 x 30 x 1.5 to

50 x 50 x 2.0,

threads M10-M24

We welcome your enquiries for specially manufactured

adjusters to suit specific applications. Advice and design

assistance is available, and economically priced solutions

offered. Please call for details.

Low profile stainless steel adjuster with

standard nitrile pad

Standard Base all stainless adjuster

01279 656 189 01279 658 891 sales@indifit.co.uk

25


ANTI VIBRATION DAMPNERS

BLACK NATURAL RUBBER

FV10

FV20

FV30

FV40

FV50

BLACK NATURAL RUBBER HARDNESS A55, WITH ZINC PLATED STEEL INSERTS/THREAD

FV

D H G h t FV10 FV20 FV30 FV40 FV50 D H G h t FV10 FV20 FV30 FV40 FV50

10 10 M4 10 3 FV10/01010 FV20/01010 FV30/01010 FV40/01010 FV50/01010 40 20 M8 23 8 FV10/04020 FV20/04020 FV40/04020 FV50/04020

10 15 M4 10 3 FV10/01015 FV20/01015 FV30/01015 FV40/01015 FV50/01015 40 25 M8 23 8 FV10/04025 FV20/04025 FV30/04025 FV40/04025 FV50/04025

15 10 M4 10 3 FV10/01510 FV20/01510 FV30/01510 FV40/01510 FV50/01510 40 30 M8 23 8 FV10/04030 FV20/04030 FV30/04030 FV40/04030 FV50/04030

15 15 M4 10 3 FV10/01515 FV20/01515 FV30/01515 FV40/01515 FV50/01515 40 40 M8 23 8 FV10/04040 FV20/04040 FV30/04040 FV40/04040 FV50/04040

15 20 M4 10 3 FV10/01520 FV20/01520 FV30/01520 FV40/01520 FV50/01520 50 20 M10 28 10 FV10/05020 FV20/05020 FV40/05020 FV50/05020

15 30 M4 10 3 FV10/01530 FV20/01530 FV30/01530 FV40/01530 FV50/01530 50 30 M10 28 10 FV10/05030 FV20/05030 FV30/05030 FV40/05030 FV50/05030

20 10 M6 18 6 FV10/02010 FV40/02010 FV50/02010 50 40 M10 28 10 FV10/05040 FV20/05040 FV30/05040 FV40/05040 FV50/05040

20 15 M6 18 6 FV10/02015 FV20/02015 FV40/02015 FV50/02015 50 45 M10 28 10 FV10/05045 FV20/05045 FV30/05045 FV40/05045 FV50/05045

20 20 M6 18 6 FV10/02020 FV20/02020 FV30/02020 FV40/02020 FV50/02020 50 50 M10 28 10 FV10/05050 FV20/05050 FV30/05050 FV40/05050 FV50/05050

20 25 M6 18 6 FV10/02025 FV20/02025 FV30/02025 FV40/02025 FV50/02025 70 45 M12 37 12 FV10/07045 FV20/07045 FV30/07045 FV40/07045 FV50/07045

25 10 M6 18 6 FV10/02510 FV40/02510 FV50/02510 75 25 M12 37 12 FV10/07525 FV20/07525 FV40/07525 FV50/07525

25 15 M6 18 6 FV10/02515 FV20/02515 FV40/02515 FV50/02515 75 40 M12 37 12 FV10/07540 FV20/07540 FV30/07540 FV50/07540

25 20 M6 18 6 FV10/02520 FV20/02520 FV30/02520 FV40/02520 FV50/02520 75 50 M12 37 12 FV10/07550 FV20/07550 FV30/07550 FV50/07550

25 25 M6 18 6 FV10/02525 FV20/02525 FV30/02525 FV40/02525 FV50/02525 100 40 M16 41 16 FV10/10040 FV20/10040 FV30/10040 FV50/10040

25 30 M6 18 6 FV10/02530 FV20/02530 FV30/02530 FV40/02530 FV50/02530 100 55 M16 41 16 FV10/10055 FV20/10055 FV30/10055 FV50/10055

30 15 M8 20 8 FV10/03015 FV20/03015 FV40/03015 FV50/03015 100 75 M16 41 16 FV10/10075 FV20/10075 FV30/10075 FV40/10075 FV50/10075

30 20 M8 20 8 FV10/03020 FV20/03020 FV30/03020 FV40/03020 FV50/03020 150 40 M20 46 20 FV10/15040 FV20/15040 FV30/15040 FV40/15040 FV50/15040

30 25 M8 20 8 FV10/03025 FV20/03025 FV30/03025 FV40/03025 FV30/03025

30 30 M8 20 8 FV10/03030 FV20/03030 FV40/03030 FV50/03030

OTHER PATTERNS TO ORDER - PLEASE ENQUIRE

FV42

FV41

FV43

FV52

FV53

FV51

FV

D H G h t FV42 FV51

20 24 M6 18 6 FV51/02024

25 17 M6 18 6 FV42/02517

30 36 M8 20 8 FV51/03036

50 18 M10 28 10 FV42/05018

50 61 M10 28 10 FV51/05061

75 89 M12 37 12 FV51/07589

26

01279 656 189 01279 658 891 sales@indifit.co.uk


SQUARE

B TYPE-Imperial

Plain shank to

suit single gauge

4 Designed for use with adjustable glide feet

MANY

NEW SIZES!

Some items may be

subject to min quantity

METRIC

A TYPE – Metric

Ribbed shank to suit a

range of gauges

TUBE SIZE MM GAUGE THREAD PART NO TUBE SIZE MM GAUGE THREAD PART NO

15 x 15 1.0-2.0 M8 BFQ150/102008A

16 x 16 1.0-2.0 M8 BFQ160/102008A

18 x 18 1.0-2.0 M8 BFQ180/102008A

20 x 20 1.0-2.0 M8 BFQ200/102008A

22 x 22 1.0-2.0 M8 BFQ220/102008A

25 x 25 1.2-1.6 M8 BFQ250/121608A

25 x 25 1.5-2.0 M8 BFQ250/152008A

25 x 25 1.5-2.0 M10 BFQ250/152010A

30 x 30 1.0-2.0 M8 BFQ300/102008A

30 x 30 1.5-2.0 M8 BFQ300/152008A

30 x 30 1.0-2.0 M10 BFQ300/102010A

30 x 30 1.5-2.0 M10 BFQ300/152010A

30 x 30 2.5-3.0 M8 BFQ300/253008A

30 x 30 2.5-3.0 M10 BFQ300/253010A

30 x 30 2.5-3.0 M12 BFQ300/253012A

35 x 35 1.5-2.0 M8 BFQ350/152008A

IMPERIAL

TUBE SIZE INCHES GAUGE THREAD TYPE PART NO

3/4 x 3/4 18G M6 B BFQ190/1806B

3/4 x 3/4 18G M8 B BFQ190/1808B

3/4 x 3/4 16G M8 B BFQ190/1608B

1 x 1 18G M8 B BFQ254/1808B

1 x 1 16G M8 B BFQ254/1608B

1.1/8 x 1.1/8 18G M8 B BFQ286/1808B

1.1/4 x 1.1/4 18G M8 B BFQ317/1808B

1.1/4 x 1.1/4 18G M10 B BFQ317/1810B

1.1/4 x 1.1/4 16G M8 B BFQ317/1608B

1.1/4 x 1.1/4 16G M10 B BFQ317/1610B

1.1/2 x 1.1/2 18G M10 B BFQ381/1810B

1.1/2 x 1.1/2 16G M10 B BFQ381/1610B

1.1/2 x 1.1/2 12G M10 B BFQ381/1210B

1.1/2 x 1.1/2 12G M12 B BFQ381/1212B

35 x 35 1.5-2.0 M10 BFQ350/152010A

38 x 38 1.5-2.0 M8 BFQ380/152008A

38 x 38 1.5-2.0 M10 BFQ380/152010A

38 x 38 1.5-2.0 M12 BFQ380/152012A

40 x 40 1.5-2.0 M8 BFQ400/152008A

40 x 40 1.5-2.0 M10 BFQ400/152010A

40 x 40 2.5-3.0 M10 BFQ400/253010A

40 x 40 1.5-2.0 M12 BFQ400/152012A

40 x 40 2.5-3.0 M12 BFQ400/253012A

50 x 50 1.5-2.0 M8 BFQ500/152008A

50 x 50 2.5-3.0 M8 BFQ500/253008A

50 x 50 1.5-2.0 M10 BFQ500/152010A

50 x 50 2.5-3.0 M10 BFQ500/253010A

50 x 50 1.5-2.0 M12 BFQ500/152012A

50 x 50 2.5-3.0 M12 BFQ500/253012A

BFQ

BFQ

THREADED TUBE INSERTS - ALL PLASTIC

RECTANGULAR

A TYPE

Ribbed shank to suit

a range of gauges

B TYPE

Plain shank to

suit single gauge

METRIC

TUBE SIZE MM GAUGE THREAD PART NO TUBE SIZE MM GAUGE THREAD PART NO

30 x 20 1.0-2.0 M8 BFL300200/102008A

30 x 20 1.0-2.0 M10 BFL300200/102010A

40 x 20 1.0-2.0 M8 BFL400200/102008A

40 x 20 1.0-2.0 M10 BFL400200/102010A

40 x 25 1.5-2.0 M8 BFL400250/152008A

40 x 25 1.5-2.0 M10 BFL400250/152010A

40 x 30 1.5-2.0 M8 BFL400300/152008A

40 x 30 1.5-2.0 M10 BFL400300/152010A

50 x 25 1.0-2.0 M8 BFL500250/102008A

MANY

NEW SIZES!

Some sizes may be

subject to min quantity –

please enquire

50 x 25 1.0-2.0 M10 BFL500250/102010A

50 x 25 1.5-2.0 M8 BFL500250/152008A

50 x 25 1.5-2.0 M10 BFL500250/152010A

60 x 20 1.0-2.0 M8 BFL600200/102008A

60 x 20 1.0-2.0 M10 BFL600200/102010A

60 x 30 2.0* M10 BFL600300/2010

60 x 30 2.5* M10 BFL600300/2510

60 x 40 1.5-2.0 M8 BFL600400/152008A

60 x 40 1.5-2.0 M10 BFL600400/152010A

60 x 40 1.5-2.0 M12 BFL600400/152012A

IMPERIAL

TUBE SIZE INCHES GAUGE THREAD TYPE PART NO

1.1/2 x 3/4 16G M10 B BFL381190/1610B

*plain shank “B” pattern

BFL

BFL

01279 656 189 01279 658 891 sales@indifit.co.uk

27


THREADED TUBE INSERTS / INTEGRAL ADJUSTERS

ROUND

PLASTIC SHANK / METAL THREAD

4 Suitable for heavier duty applications

4 Material: HD Polyethylene with BZP steel thread

4 Long shank patterns can be used in conjunction with furniture castors

SQUARE

MANY

NEW SIZES!

Some items may be

subject to min quantity –

please enquire

TUBE SIZE MM GAUGE THREAD TYPE PART NO

BFMQ

16 x 16 1.0-2.0 M6 S BFMQ160/102006S

20 x 20 1.0-2.0 M8 S/P/L BFMQ200/102008*

25 x 25 1.0-2.0 M8 S/P/L BFMQ250/102008*

25 x 25 1.0-2.0 M10 S/P/L BFMQ250/102010*

30 x 30 1.0-2.0 M8 S/L BFMQ300/102008*

30 x 30 1.0-2.0 M10 S/P/L BFMQ300/102010*

35 x 35 1.0-2.0 M10 S BFMQ350/102010S

40 x 40 1.0-2.0 M10 S BFMQ400/102010S

*Last digit of part number S P or L according to pattern

METRIC

TUBE SIZE MM GAUGE THREAD PART NO

18 1.0-2.0 M8 BFD180/102008A

20 1.0-2.0 M8 BFD200/102010A

22 1.0-2.0 M8 BFD220/102008A

22 1.0-2.0 M10 BFD220/102010A

25 1.0-2.0 M8 BFD250/102008A

25 1.0-2.0 M10 BFD250/102010A

25 1.5-2.0 M8 BFD250/152008A

25 1.5-2.0 M10 BFD250/152010A

25 1.5-2.0 M12 BFD250/152012A

28 1.0-2.0 M8 BFD280/102008A

28 1.0-2.0 M10 BFD280/102010A

28 1.5-2.0 M8 BFD280/152008A

28 1.5-2.0 M10 BFD280/152010A

28 1.5-2.0 M12 BFD280/152012A

30 1.0-2.0 M8 BFD300/102008A

30 1.0-2.0 M10 BFD300/102010A

30 1.5-2.0 M8 BFD300/152008A

30 1.5-2.0 M10 BFD300/152010A

30 1.5-2.0 M12 BFD300/152012A

32 1.0-2.0 M8 BFD320/102008A

32 1.0-2.0 M10 BFD320/102010A

32 1.5-2.0 M8 BFD320/152008A

ROUND

BFD

TUBE SIZE MM GAUGE THREAD TYPE PART NO

BFMD

25 0.8 M8 S BFMD250/0808S

25 0.8 M10 S BFMD250/0810S

25 1.5 M8 S BFMD250/1508S

25 1.5 M10 S BFMD250/1510S

32 1.5 M8 S BFMD320/1508S

32 1.5 M10 S BFMD320/1510S

38 1.5 M8 S BFMD380/1508S

38 1.5 M10 S BFMD380/1510S

38 2.0 M8 S BFMD380/2008S

METRIC

TUBE SIZE MM GAUGE THREAD PART NO

32 1.5-2.0 M10 BFD320/152010A

32 1.5-2.0 M12 BFD320/152012A

35 1.0-2.0 M10 BFD350/102010A

38 1.5-2.0 M8 BFD380/152008A

38 1.5-2.0 M10 BFD380/152010A

38 1.5-2.0 M12 BFD380/152012A

40 1.0-2.0 M8 BFD400/102008A

40 1.0-2.0 M10 BFD400/102010A

40 1.5-2.0 M8 BFD400/152008A

40 1.5-2.0 M10 BFD400/152010A

40 1.5-2.0 M12 BFD400/152012A

45 1.0-2.0 M8 BFD450/102008A

45 1.0-2.0 M10 BFD450/102010A

50 1.0-2.0 M8 BFD500/102008A

50 1.0-2.0 M10 BFD500/102010A

50 1.5-2.0 M8 BFD500/152008A

50 1.5-2.0 M10 BFD500/152010A

50 1.5-2.0 M12 BFD500/152012A

50.8 1.0-1.6 M8 BFD508/101608A

50.8 1.0-1.6 M10 BFD508/101610A

50.8 1.0-1.6 M12 BFD508/101612A

BFD

S TYPE

Standard shank with standard

threaded bush

P TYPE

Long shank with standard

threaded bush

RECTANGULAR

BFML

TUBE SIZE MM GAUGE THREAD TYPE PART NO

30 x 15 1.0-2.0 M8 S BFML300150/102008S

30 x 20 1.0-2.0 M8 P/L BFML300200/102008*

30 x 20 1.0-2.0 M10 S BFML300200/102010S

40 x 20 1.0-2.0 M10 S BFML400200/102010S

40 x 30 1.0-2.0 M10 S BFML400300/102010S

50 x 25 1.0-2.0 M10 S BFML500250/102010S

50 x 40 1.0-2.0 M10 S BFML500400/102010S

*Last digit of part number S P or L according to pattern

38 2.0 M10 S BFMD380/2010S

40 2.0 M10 S BFMD400/2010S

44 2.0 M10 S BFMD440/2010S

S TYPE

Standard shank with standard

threaded bush

L TYPE

Long shank/long threaded bush

for extra stability

FLAT SIDED OVAL

MINIMUM ORDER QUANTITES

WILL APPLY TO OVAL PATTERNS

METRIC

TUBE SIZE MM GAUGE THREAD PART NO

BFV

36 x 18 1.0-2.0 M10 BFV360180/102010A

ALSO AVAILABLE TO SPECIAL ORDER

4 Integral all nylon

insert/static adjuster

in round and square

metric sizes.

40 x 20 1.0-2.0 M8 BFV400200/102008A

28

40 x 20 1.0-2.0 M10 BFV400200/102010A

FSIQ

Square tube fitting

FSID

Round tube fitting

01279 656 189 01279 658 891 sales@indifit.co.uk


NYLON SHANK WITH METAL NUT

4 High quality, strong nylon moulded insert with BZP metal nut

4 Most sizes supplied to order - min quantities may apply on

some items - please enquire

ROUND

TUBE SIZE MM GAUGE MM THREAD PART NO

16 0.75 M6 BFZD160/0706

16 1.0 M5 BFZD160/1005

16 1.5 M5 BFZD160/1505

16 1.5 M6 BFZD160/1506

18 1.25 M5 BFZD180/1205

19 1.5 M8 BFZD190/1508

20 0.5 M6 BFZD200/0506

20 0.75 M6 BFZD200/0706

20 1.0-1.5 M8 BFZD200/101508

20 1.0-1.5 M10 BFZD200/101510

20 1.5 M6 BFZD200/1506

20 2.0 M8 BFZD200/2008

22 1.0 M8 BFZD220/1008

22 1.5 M8 BFZD220/1508

22 2.0 M8 BFZD220/2008

25 1.5-2.0 M6 BFZD250/152006

25 1.5-2.0 M8 BFZD250/152008

25 1.5-2.0 M10 BFZD250/152010

25 2.5 M8 BFZD250/2508

28 1.5-2.0 M6 BFZD280/152006

28 10-1.5 M8 BFZD280/101508

28 1.0-1.5 M10 BFZD280/101510

28 2.0 M8 BFZD280/2008

28 2.0 M10 BFZD280/2010

28 3.0 M10 BFZD280/3010

30 1.0 M8 BFZD300/1008

30 1.0 M10 BFZD300/1010

30 1.5-2.0 M8 BFZD300/152008

30 1.5-2.0 M10 BFZD300/152010

30 3.0 M10 BFZD300/3010

30 4.0 M10 BFZD300/4010

32 1.5-2.0 M8 BFZD320/152008

32 1.5-2.0 M10 BFZD320/152010

35 1.5-2.0 M8 BFZD350/152008

35 1.5-2.0 M10 BFZD350/152010

38 1.2 M6 BFZD380/1206

38 1.5 M10 BFZD380/1510

38 2.0 M8 BFZD380/2008

38 2.0 M10 BFZD380/2010

38 2.5 M10 BFZD380/2510

40 1.5-2.0 M8 BFZD400/152008

40 1.5-2.0 M10 BFZD400/152010

40 1.5-2.0 M12 BFZD400/152012

45 1.5-2.0 M8 BFZD450/152008

45 1.5-2.0 M10 BFZD450/152010

50 1.5 M8 BFZD500/1508

50 1.5 M10 BFZD500/1510

50 2.0 M8 BFZD500/2008

50 2.0 M10 BFZD500/2010

TUBE SIZE MM GAUGE MM THREAD PART NO

BFZD

50 2.5 M12 BZFD500/2512

50 3.0 M8 BFZD500/3008

60 1.5 M10 BFZD600/1510

60 2.0 M8 BFZD600/2008

60 2.0 M10 BFZD600/2010

60 2.0 M12 BFZD600/2012

70 2.0 M12 BFZD700/2012

70 3.0 M10 BFZD700/3010

SQUARE

TUBE SIZE MM GAUGE MM THREAD PART NO

BFZQ

18 x 18 1.0-1.5 M8 BFZQ180/101508

20 x 20 1.5-2.0 M6 BFZQ200/152006

20 x 20 1.5-2.0 M8 BFZQ200/152008

20 x 20 1.5-2.0 M10 BFZQ200/152010

22 x 22 1.5-2.0 M8 BFZQ220/152008

25 X 25 1.0-1.5 M8 BFZQ250/101508

25 x 25 1.5 M10 BFZQ250/1510

25 x 25 2.0 M8 BFZQ250/2008

25 x 25 2.0 M10 BFZQ250/2010

25 x 25 3.0 M10 BFZQ250/3010

30 x 30 1.5-2.0 M8 BFZQ300/152008

30 x 30 1.5-2.0 M10 BFZQ300/152010

30 x 30 2.5 M10 BFZQ300/2510

35 x 35 1.0-1.5 M10 BFZQ350/101510

35 x 35 1.5-2.0 M8 BFZQ350/152008

35 x 35 1.5-2.0 M12 BFZQ350/152012

40 x 40 1.5-2.0 M8 BFZQ400/152008

40 x 40 1.5-2.0 M10 BFZQ400/152010

40 x 40 1.5-2.0 M12 BFZQ400/152012

40 x 40 1.5-2.0 M16 BFZQ400/152016

40 x 40 3.0 M10 BFZQ400/3010

50 x 50 2.0 M8 BFZQ500/2008

50 x 50 2.0 M10 BFZQ500/2010

50 x 50 2.5 M10 BFZQ500/2510

50 x 50 3.0 M12 BFZQ500/3012

60 x 60 1.5-2.0 M10 BFZQ600/152010

60 x 60 1.5-2.0 M12 BFZQ600/152012

RECTANGULAR

TUBE SIZE MM GAUGE MM THREAD PART NO

BFZL

25 x 20 1.5-2.0 M8 BFZL250200/152008

30 x 15* 1.0-2.0 M8 BFZL300150/102008

30 x 20* 1.0-2.0 M10 BFZL300200/102010

30 x 20 1.5 M8 BFZL300200/1508

30 x 25 1.0-2.0 M10 BFZL300250/102010

35 x 20* 1.0-2.0 M10 BFZL350200/102010

35 x 25 1.5-2.0 M10 BFZL350250/152010

40 x 20* 1.0-2.0 M10 BFZL400200/102010

40 x 20 1.5-2.0 M8 BFZL400200/152008

40 x 25 2.0 M8 BFZL400250/2008

40 x 30 1.5-2.0 M10 BFZL400300/152010

40 x 30 3.0 M10 BFZL400300/3010

45 x 25 1.5-2.0 M10 BFZL450250/152010

50 x 25 1.5-2.0 M10 BFZL500250/152010

50 x 30 1.5-2.0 M8 BFZL500300/152008

50 x 30 1.5-2.0 M10 BFZL500300/152010

50 x 30 2.5 M10 BFZL500300/2510

50 x 40 1.5-2.0 M10 BFZL500400/152010

60 X 30 1.5-2.0 M10 BFZL600300/152010

60 x 30 1.5-2.0 M12 BFZL600300/152012

60 x 30 3.0 M8 BFZL600300/3008

60 x 40 1.5-2.0 M10 BFZL600400/152010

60 x 40 3.0 M10 BFZL600400/3010

70 x 30 2.0 M10 BFZL700300/2010

80 x 30 1.5-2.0 M10 BFZL800300/152010

* material polyethylene

SIZE YOU NEED NOT SHOWN?

Custom sizes can be manufactured for

quantities 2000 - 5000 depending on size

WITH NO TOOLING CHARGE!

Contact us for a quotation

THREADED TUBE INSERTS - NYLON SHANK WITH METAL NUT

01279 656 189 01279 658 891 sales@indifit.co.uk

29


THREADED TUBE INSERTS - ALL METAL

CAST ALUMINIUM

4 Ideal for heavy duty applications such as shopfittings and catering equipment

STEEL

S TYPE

Standard pattern with thread

tapped into pressing

RECTANGULAR

TUBE SIZE MM GAUGE THREAD PART NO

50 x 25 2.0 M10 BFAL500250/2010

50 x 30 2.0 M10 BFAL500300/2010

50 x 30 2.5 M10 BFAL500300/2510

60 x 30 2.0 M10 BFAL600300/2010

60 x 30 2.5 M10 BFAL600300/2510

80 x 30 2.5 M10 BFAL800300/2510

120 x 30 2.5 M12 BFALH20300/2512

ROUND

BFAL

ROUND

TUBE SIZE MM GAUGE THREAD PART NO

32 1.5 M10 BFAD320/1510

32 2.0 M10 BFAD320/2010

38 1.5 M10 BFAD380/1510

38 2.0 M10 BFAD380/2010

SQUARE

TUBE SIZE MM GAUGE THREAD PART NO

25 x 25 1.5 M10 BFAQ250/1510

25 x 25 2.0 M10 BFAQ250/2010

30 x 30 1.5 M10 BFAQ300/1510

30 x 30 2.0 M10 BFAQ300/2010

30 x 30 2.5 M10 BFAQ300/2510

35 x 35 2.0 M10 BFAQ350/2010

40 x 40 1.5 M10 BFAQ400/1510

40 x 40 2.0 M10 BFAQ400/2010

40 x40 2.5 M10 BFAQ400/2510

BFAD

BFAQ

4 Material: Self colour mild steel (BZP available to order)

TUBE SIZE GAUGE THREAD TYPE PART NO

INCHES

1 18G M10 H BFSD254/1210

1 16G M10 H BFSD254/1610

1.1/8 16G M10 H BFSD286/1610

1.1/4 18G M10 H BFSD317/1210

1.1/4 16G M10 H BFSD317/1610

1.1/2 18G M10 H BFSD381/1210

1.1/2 16G M10 H BFSD381/1610

BFSD

H TYPE

Heavy duty pattern with

threaded bush

SQUARE

TUBE SIZE GAUGE THREAD TYPE PART NO

INCHES

1 x 1 18G M8 S BFSQ254/1208

1 x 1 16G M8 S BFSQ254/1608

1 x 1 18G M10 H BFHQ254/1210

1 x 1 16G M10 H BFHQ254/1610

BFSQ

DO YOU NEED SPECIAL SIZED

WASHERS OR GASKETS?

• SMALL QUANTITIES WELCOMED

• Delivery usually 7-10 days

• Wide choice of materials

• Self-adhesive available in some materials

SEE PAGE 59 FOR FULL DETAILS

30

01279 656 189 01279 658 891 sales@indifit.co.uk


SQUARE

METRIC

BQ

TUBE SIZE MM GAUGE RANGE PART NO

10 x 10 1.0-1.5 BQ100/1015

15 x 15 1.0-2.0 BQ150/1020

16 x 16 1.0-1.6 BQ158/1016

18 x 18 1.2-1.5 BQ180/1215

19 x 19 1.0-2.0 BQ190/1020

20 x 20 0.8-3.0 BQ200/0830

20 x 20 1.0-2.0 BQ200/1020

22 x 22 1.0-2.0 BQ222/1020

25 x 25 1.0-2.0 BQ254/1020

4 Vast range to suit every conceivable tube size

4 Standard material: LD Polyethylene

4 Standard stock colour black — many others

available either from stock or on short leadtimes

4 RAL colour matching available on most items

4 Popular sizes have “ribbed shank” to suit a

range of tube gauges

METRIC

TUBE SIZE MM GAUGE RANGE PART NO

40 x 40 2.6-4.0 BQ400/2640

50 x 50 1.2-2.0 BQ508/1020

50 x 50 2.0-3.2 BQ508/2032

50 x 50 2.6-5.0 BQ500/2650

60 x 60 1.5-3.5 BQ600/1535

60 x 60 2.6-5.0 BQ600/2640

70 x 70 1.5-2.5 BQ700/1525

70 x 70 2.5-5.0 BQ700/2550

75 x 75 2.0-4.5 BQ750/2045

BQ

WHAT WE NEED TO KNOW!

At least TWO of the following:

The OUTSIDE dimension of your tube. The INSIDE

dimension of your tube. The GAUGE (wall thickness)

All tube dimensions shown in the adjacent tables refer

to the OUTSIDE of the tube

IMPERIAL

TUBE SIZE INCHES GAUGE RANGE PART NO

1/2 x 1/2 16-20G BQ127/1016

5/8 x 5/8 16-20G BQ158/1016

3/4 x 3/4 14-20G BQ190/1020

7/8 x 7/8 14-20G BQ222/1020

1 x 1 14-20G BQ254/1020

1 x 1 10-14G BQ254/2032

1.1/8 x 1.1/8 14-20G BQ286/1020

1.1/4 x 1.1/4 14-20G BQ317/1020

1.3/8 x 1.3/8 14-20G BQ350/1020

BQ

PLASTIC TUBE INSERTS

25 x 25 2.0-3.2 BQ254/2032

80 x 80 2.6-4.0 BQ800/2640

1.1/2 x 1.1/2 14-20G BQ381/1020

30 x 30 1.0-2.5 BQ300/1025

80 x 80 3.0-5.0 BQ800/3050

1.1/2 x 1.1/2 12-14G BQ381/2026

30 x 30 2.0-3.0 BQ300/2030

90 x 90 3.6-6.3 BQ900/3663

1.1/2 x 1.1/2 10-18G BQ381/1232

32 x 32 1.0-2.0 BQ317/1020

100 x 100 2.0-5.0 BQH00/2050

1.3/4 x 1.3/4 10-20G BQ450/1030

35 x 35 2.0-3.2 BQ350/2032

120 x 120 2.5-5.0 BQH20/2550

2 x 2 14-18G BQ508/1020

38 x 38 1.0-2.0 BQ381/1020

150 x 150 3.6-6.3 BQH50/3663

2 x 2 10-14G BQ508/2032

38 x 38 2.0-3.2 BQ381/2032

2.1/2 x 2.1/2 10-14G BQ635/2032

40 x 40 1.0-2.0 BQ400/1020

4 x 4 4-8G BQH00/2550

40 X 40 2.0-3.2 BQ400/2032

RECTANGULAR

IMPERIAL

TUBE SIZE INCHES GAUGE RANGE PART NO

1 x 1/2 16-18G BL254127/1216

1.3/8 x 5/8 14-20G BL349158/1020

1.1/2 x 3/4 14-20G BL381190/1020

1.1/2 x 1 14-20G BL381254/1020

2 x 1 14-20G BL508254/1020

2 x 1 10-14G BL508254/2032

2.1/2 x 1 14-20G BL635254/1020

METRIC

TUBE SIZE MM GAUGE RANGE PART NO

20 x 10 1.0-2.0 BL200100/1020

25 x 10 1.0-1.5 BL250100/1015

25 x 12 1.0-2.0 BL250120/1020

25 x 15 1.0-2.0 BL250150/1020

30 x 10 1.0-1.5 BL300100/1015

30 x 20 1.0-2.0 BL300200/1020

40 x 20 1.2-2.0 BL400200/1220

40 x 25 1.5-2.5 BL400250/1525

50 x 25 1.0-2.0 BL508254/1020

FLAT SIDED OVAL

BL

TUBE SIZE MM GAUGE RANGE PART NO TUBE SIZE MM GAUGE RANGE PART NO

50 x 25 2.0-3.2 BL508254/2032

50 x 30 1.5-3.2 BL500300/1532

60 x 20 1.0-2.0 BL600200/1020

60 x 30 1.5-3.2 BL600300/1532

60 x 40 1.0-2.0 BL600400/1020

60 x 40 2.0-3.5 BL600400/2035

75 x 25 1.5-2.0 BL750250/1520

75 x 50 2.0-4.0 BL750500/2040

80 x 30 1.0-2.0 BL800300/1020

MANY MORE SIZES AVAILABLE

If you do not see the size you require -

ASK! We can probably supply it!

BL

80 x 40 2.5-4.0 BL800400/2540

80 x 40 3.2-5.0 BL800400/3250

90 x 50 2.5-4.0 BL900500/2540

100 x 40 1.5-4.0 BLH00400/1540

100 x 50 2.0-4.0 BLH00500/2040

100 x 80 5.0-8.0 BLH00800/5080

120 x 60 2.0-3.0 BLH20600/2030

120 x 80 5.0-8.0 BLH20800/5080

150 x 100 5.0-8.0 BLH50H00/5080

METRIC

BV

TUBE SIZE MM

20 x 10

GAUGE RANGE

1.0-2.0

PART NO

BV200100/1020

TUBE SIZE MM

60 x 30

GAUGE RANGE

1.0-2.0

PART NO

BV600300/1020

25 x 12 1.0-2.0 BV250120/1020 130 x 60 3.5-5.0 BVH30600/3550

30 x 15 1.0-2.5 BV300150/1025

IMPERIAL

BV

40 x 20 1.0-3.0 BV400200/1030

TUBE SIZE INCHES GAUGE RANGE PART NO

48 x 20 1.0-1.5 BV480200/1015

1.1/4 X 5/8 16-18G BV317158/1216

50 x 25 1.0-2.0 BV500250/1020

01279 656 189 01279 658 891 sales@indifit.co.uk

RAL9006 - silver available to special order in

most tube inserts

31


PLASTIC TUBE INSERTS

ROUND

MANY MORE SIZES AVAILABLE

If you do not see the size you require -

ASK! We can probably supply it!

IMPERIAL

BD

TUBE SIZE INCHES GAUGE RANGE PART NO TUBE SIZE INCHES GAUGE RANGE PART NO

1/2 16-20G BD127/1016

1.1/2 14-20G BD381/1220

5/8 16-20G BD158/1016

1.1/2 10-14G BD380/2032

3/4 14-20G BD190/1020

1.3/4 14-18G BD444/1220

7/8 14-20G BD222/1020

2 14-18G BD508/1220

1 14-20G BD254/1020

2 10-14G BD508/2032

1 10-14G BD254/2032

2.3/8 10-14G BD603/2032

1.1/8 14-20G BD286/1020

2.1/2 14-18G BD635/1220

1.1/4 14-20G BD317/1020

3 12-16G BD760/1525

1.1/4 10-14G BD317/2032

3 8-10G BD760/2940

1.3/8 14-20G BD350/1020

3 5-10G BD762/3250

METRIC

BD

TUBE SIZE MM GAUGE RANGE PART NO TUBE SIZE MM GAUGE RANGE PART NO

10 0.8-1.5 BD100/0815

35 1.0-2.0 BD350/1020

12 1.0-2.0 BD120/1020

40 1.0-2.0 BD400/1020

13 1.0-2.0 BD127/1020

42.4 2.6-4.0 BD424/2640

16 1.0-.2.0 BD158/1016

45 1.0-2.0 BD450/1020

18 1.0-2.0 BD180/1020

48.3 3.2-5.0 BD483/3250

19 1.0-2.0 BD190/1020

50 1.0-2.0 BD500/1020

20 1.0-2.0 BD200/1020

50 2.0-3.2 BD500/2032

22 1.0-2.0 BD220/1020

60.3 3.2-5.0 BD603/3250

25 1.0-2.0 BD254/1020

76 1.5-2.5 BD760/1525

28 1.0-2.0 BD286/1020

76 2.9-4.0 BD760/2940

30 1.0-2.0 BD300/1020

76 3.2-5.0 BD762/3250

32 1.0-2.0 BD320/1020

100 4.5-6.0 BDH00/4560

33.7 2.6-4.0 BD337/2640

110 4.5-6.0 BDH10/4560

PROFILED HEAD

ANGLED

TUBE O/D GAUGE PART NO TUBE O/D GAUGE PART NO

16mm dia 1.0-2.0mm BPD160

28mm dia 1.0-2.0mm BPD280

18mm dia 1.0-2.0mm BPD180

30mm dia 1.0-2.0mm BPD300

20mm dia 1.0-2.0mm BPD200

32mm dia 1.0-2.0mm BPD320

22mm dia 1.0-2.0mm BPD220

35mm dia 1.0-2.0mm BPD350

25mm dia 1.0-2.0mm BPD250

40mm dia 1.0-2.0mm BPD400

BPD

A comprehensive range of plastic tube

inserts with angled and shaped heads in

square, round, rectangular and oval sizes

is available.

Please contact us with your enquiry.

FELT BASE

Similar range of inserts with integral

non-slip base also available -

please enquire

Ideal for use on highly polished or vulnerable floor surfaces

(for example, gymnasia) these plastic inserts have a felt pad

vibration welded to the base, providing a protective interface.

A limited range of angled inserts with felt base is also

available - details on request.

Please note - felt base has a limited lifespan if under heavy use

TUBE O/D GAUGE PART NO TUBE O/D GAUGE PART NO

15mm dia 1.0-2.0mm BTD150

25mm dia 1.5-2.5mm BTD250

16mm dia 1.0-2.0mm BTD160

28mm dia 1.5-2.5mm BTD280

18mm dia 1.0-2.0mm BTD180

30mm dia 1.5-2.5mm BTD300

20mm dia 1.5-2.5mm BTD200

32mm dia 1.5-2.5mm BTD320

22mm dia 1.5-2.5mm BTD220

BT

32

01279 656 189 01279 658 891 sales@indifit.co.uk


CHROME COLOUR METAL CAPPED

FLAT SIDED OVAL

BSV ROUND

TUBE SIZE MM GAUGE RANGE PART NO

TUBE SIZE MM GAUGE RANGE PART NO

20 x 10 1.0-2.0 BSV200100

12 dia 1.0.2.0 BSD120

30 x 15 1.0-2.0 BSV300150

13 dia 1.0-.2.0 BSD130

40 x 20 1.0-2.0 BSV400200

16 dia 1.0-2.0 BSD160

19 dia 1.0-2.0 BSD190

RECTANGULAR

BSL 20 dia 1.0-2.0 BSD200

TUBE SIZE MM GAUGE RANGE PART NO

22 dia 1.0-2.0 BSD220

20 x 10 1.0-2.0 BSL200100

25 dia 1.0-2.0 BSD250

30 x 15 1.0-2.0 BSL300150

28 dia 1.0-2.0 BSD280

40 x 20 1.0-2.0 BSL400200

30 dia 1.0-2.0 BSD300

SQUARE

BSQ

32 dia 1.0-2.0 BSD320

38 dia 1.0-2.0 BSD380

TUBE SIZE MM GAUGE RANGE PART NO

18 x 18 1.0-2.0 BSQ180

50 dia 1.5 BSD500/15

20 x 20 1.0-2.0 BSQ200

50 dia 2.0 BSD500/20

25 x 25 1.0-2.0 BSQ250

30 x 30 1.0-2.0 BSQ300

40 x 40 1.0-2.0 BSQ400

HEAVY DUTY STEEL TUBE INSERT

ROUND

BMD

TUBE SIZE INCHES GAUGE RANGE PART NO

3/4 dia 18G BMD190/18

3/4 dia 16G BMD190/16

7/8 dia 18G BMD222/18

1 dia 18G BMD254/18

1 dia 16G BMD254/16

1.1/8 dia 16G BMD286/16

1.1/4 dia 16G BMD317/16

SQUARE

BMQ

TUBE SIZE INCHES GAUGE RANGE PART NO

1 x 1 18G BMQ254/18

1 x 1 16G BMQ254/16

EXPANDING CONNECTOR INSERT

BSD

4 Polyethylene insert with highly decorative chrome

colour metal cap

4 Neat low profile finish

4 Many metric sizes are suitable for imperial tubes

- we will be happy to advise

4 Other sizes available - please ask!

4 Gold/brass colour available, subject to min quantities

Light duty range in diameters

16 - 32mm also available -

please enquire

METALLIC FINISH TUBE INSERTS/CONNECTOR INSERTS

Manufactured in nylon, these inserts have a conical cavity to suit standard metric nuts. As the

thread is tightened, the grip within the tube is increased, giving a connection resistant to tension.

Suitable for tube lengthening, or for tee connections.

SIZE YOU NEED NOT SHOWN?

Custom sizes can be manufactured for

quantities 2000 - 5000 depending on size

Supplied to order - minimum quantities may apply

WITH NO TOOLING CHARGE!

Contact us for a quotation

SQUARE

Size range from

20 x 20 x 1.5mm to

70 x 70 x 2.0mm

ROUND

18 dia x 1.5mm to

80 dia x 2.0mm

RECTANGULAR

Size range from

30 x 20 x 1.5mm to

60 x 30 x 2.5mm

01279 656 189 01279 658 891 sales@indifit.co.uk

33


TUBE CONNECTORS

TUBE CONNECTORS (SQUARE)

Indifit offers the widest range of tube connectors in the UK. Popular sizes and patterns are held in stock

for immediate delivery - others are available on short lead-times and with modest minimum quantities.

Please call our salesline now for further advice and information.

TCH1

2-WAY STRAIGHT

TUBE

SIZE MM

PART NO WITH METAL CORE

(add “NC” for no core)

15 x 15 x 1.5 TCH1/150/15

20 x 20 x 1.5 TCH1/200/15

20 x 20 x 2.0 TCH1/200/20

25 x 25 x 1.5 TCH1/250/15

25 x 25 x 2.0 TCH1/250/20

30 x 30 x 1.5 TCH1/300/15

30 x 30 x 2.0 TCH1/300/20

35 x 35 x 2.0 TCH1/350/20

TCH2

4 Consists of two piece “clip together” nylon moulding

4 With or without steel reinforcing core

4 25 x 25 x 1.5 also available with stainless steel core

2-WAY CORNER

TUBE

SIZE MM

20 x 20 x 1.2 TCL2/200**

PART NO WITH METAL CORE

(add “NC” for no core)

20 x 20 x 1.5 TCH2/200/15

20 x 20 x 2.0 TCH2/200/20

25 x 25 x 1.2 TCL2**

25 x 25 x 1.5 TCH2

30 x 30 x 2.0 TCH2/300/20

** light duty hollow ABS pattern - no steel core

3-WAY CORNER

3-WAY TEE

TUBE

SIZE MM

PART NO WITH METAL CORE

(add “NC” for no core)

TUBE

SIZE MM

PART NO WITH METAL CORE

(add “NC” for no core)

20 x 20 x 1.2 TCL3/200**

20 x 20 x 1.2 TCL3C/200**

20 x 20 x 1.5 TCH3F/200/15

20 x 20 x 1.5 TCH3C/200/15

25 x 25 x 1.2 TCL3**

25 x 25 x 1.5 TCH3C

TCH3F

25 x 25 x 1.5 TCH3F

30 x 30 x 2.0 TCH3F/300/20

** light duty hollow ABS pattern - no steel core

TCH3C

30 x 30 x 2.0 TCH3C/300/20

** light duty hollow ABS pattern - no steel core

4-WAY FLAT

4-WAY VERTICAL

TUBE

SIZE MM

PART NO WITH METAL CORE

(add “NC” for no core)

TUBE

SIZE MM

PART NO WITH METAL CORE

(add “NC” for no core)

20 x 20 x 1.2 TCL4F/200**

20 x 20 x 1.2 TCL4C/200**

20 x 20 x 1.5 TCH4F/200/15

20 x 20 x 1.5 TCH4C/200/15

TCH4F

25 x 25 x 1.5 TCH4F

30 x 30 x 2.0 TCH4F/300/20

25 x 25 x 1.2 TCL4C**

25 x 25 x 1.5 TCH4C

** light duty hollow ABS pattern - no steel core

TCH4C

30 x 30 x 2.0 TCH4C/300/20

** light duty hollow ABS pattern - no steel core

5-WAY

6-WAY

TUBE

SIZE MM

PART NO WITH METAL CORE

(add “NC” for no core)

TUBE

SIZE MM

PART NO WITH METAL CORE

(add “NC” for no core)

20 x 20 x 1.2 TCL5/200**

20 X 20 X 1.2 TCL6/200**

20 x 20 x 1.5 TCH5/200/15

20 x 20 x 1.5 TCH6/200/15

25 x 25 x 1.2 TCL5**

25 x 25 x 1.5 TCH6C

25 x 25 x 1.5 TCH5

TCH6

30 x 30 x 2.0 TCH6C/300/20

TCH5

30 x 30 x 2.0 TCH5/300/20

** light duty hollow ABS pattern - no steel core

** light duty hollow ABS pattern - no steel core

SPECIAL PATTERNS - SELECTED SIZES ONLY

Radius corner

Two way elbow

25 x 25 x 1.5 only

Without raised head for mitred tubes

Two way elbow

25 x 25 x 1.5

30 x 30 x 2.0

With metal M8 or M10 bush in head

25 x 25 x 1.5

30 x 30 x 2.0

all patterns except

TCH4F and TCH6

34

01279 656 189 01279 658 891 sales@indifit.co.uk


TUBE CONNECTORS (ROUND)

TCH1D

TUBE

PART NO WITH METAL CORE

TUBE

PART NO WITH METAL CORE

SIZE MM

(add “NC” for no core)

SIZE MM

(add “NC” for no core)

18.0 Dia x 0.8 TCH1D/180/08

32.0 Dia x 2.0 TCH1D/320/20

18.0 Dia x1.5 TCH1D/180/15

32.0 Dia x 2.5 TCH1D/320/25

19.0 Dia x 1.0 TCH1D/190/10

33.7 Dia x 3.2 TCH1D/337/32

20.0 Dia x 1.1 TCH1D/200/11

35.0 Dia x 1.2 TCH1D/350/12

20.0 Dia x 1.5 TCH1D/200/15

38.0 Dia x 2.0 TCH1D/380/20

22.0 Dia x 1.0 TCH1D/220/10

40.0 Dia x 1.5 TCH1D/400/15

25.0 Dia x 1.5 TCH1D/250/15

40.0 Dia x 2.0 TCH1D/400/20

26.9 Dia x 2.6 TCH1D/269/26

48.0 Dia x 4.0 TCH1D/480/40

28.0 Dia x 1.5 TCH1D/280/15

48.3 Dia x 3.2 TCH1D/483/32

30.0 Dia x 1.0 TCH1D/300/10

50.0 Dia x 1.5 TCH1D/500/15

30.0 Dia x 1.5 TCH1D/300/15

50.0 Dia x 2.0 TCH1D/500/20

30.0 Dia x 2.0 TCH1D/300/20

60.0 Dia x 2.0 TCH1D/600/20

32.0 Dia x 1.5 TCH1D/320/15

4 Nylon moulding with or without steel reinforcement

TUBE CONNECTORS

SIZE YOU NEED

NOT SHOWN?

Connectors for sizes not shown can be manufactured

for quantities 2000-5000 (dependent on size)

WITHOUT TOOLING COSTS!

Call for details.

TCH2D

TUBE

PART NO WITH METAL CORE

SIZE MM

(add “NC” for no core)

25.0 Dia x 1.0 TCH2D/250/10

25.0 Dia x 2.0 TCH2D/250/20

32..0 Dia x 1.0 TCH2D/320/10

TUBE CONNECTORS (OVAL)

TCH1V

TUBE

PART NO WITHOUT

SIZE MM

METAL CORE

30 x 15 x 1.5 TCH1V/300150/15NC

40 x 20 x 2.0 TCH1V400200/20NC

TUBE

PART NO WITH

SIZE MM

METAL CORE

40 x 20 x 2.0 TCH1V/400200/20

TCH1V

PIVOTING TUBE CONNECTORS FOR 0 - 300 O

RADIUS

4 Robust nylon moulding

4 Range of angles available to suit different applications

4 Standard colour black

TUBE ANGLE SHANK PART

SIZE MM RANGE LENGTH NO

TCR2

25 x 25 x 1.5 60-300 ° 38 TCR2/250/15/300

25 x 25 x 1.5 45-195 ° (*) 38 TCR2/250/15/195

25 x 25 x 1.5 0 -190 ° 38 TCR2/250/15/190

30 x 30 x 2.0 45-200 ° 41 TCR2/300/20/200

(*) - angle adjusts in 15 ° increments

TUBE ANGLE SHANK PART

SIZE MM RANGE LENGTH NO

TCR3

25 x 25 x 1.5 60-300 ° 43 TCR3/250/15/300

25 x 25 x 1.5 45-195 ° (*) 43 TCR3/250/15/195

25 x 25 x 1.5 0 -190 ° 43 TCR3/250/15/190

30 x 30 x 2.0 45-200 ° 41 TCR3/300/20/200

(*) - angle adjusts in 15 ° increments

TUBE ANGLE SHANK PART

SIZE MM RANGE LENGTH NO

TCR4

25 x 25 x 1.5 60-300 ° 43 TCR4/250/15/300

25 x 25 x 1.5 45-195 ° (*) 43 TCR4/250/15/195

25 x 25 x 1.5 0 -190 ° 43 TCR4/250/15/190

30 x 30 x 2.0 45-200 ° 41 TCR4/300/20/200

(*) - angle adjusts in 15 ° increments

01279 656 189 01279 658 891 sales@indifit.co.uk

35


FERRULES / STAND-OFF FEET

RUBBER FERRULES

4 Rubber ferrules providing non-slip

qualities for medical and other

applications

4 Standard colour grey, others to order

OUTSIDE FITTING FERRULES

4 Suitable as closures, or as feet in light duty applications

4 Heavy or light duty patterns also available

4 Standard material: black LD polyethylene

4 Other colours available - please enquire

ROUND

TUBE SIZE INCHES

PART NO

1/2 RDD127

5/8 RDD158

3/4 RDD190

7/8 RDD222

1 RDD254

1.1/8 RDD286

1.1/4 RDD317

1.1/2 RDD381

1.3/4 RDD444

1.29/32 RDD483

3 RDD762

4 RDDH01

RDD

TUBE O/D MM

F S OVAL

TUBE SIZE INCHES / MM

SQUARE

TUBE SIZE INCHES / MM

PART NO

30 x 15mm RDV300150

1.1/4 x 5/8 RDV317158

40 x 20mm* RDV400200

* PVC

PART NO

13 RB130

16 RB160

19 RB190

22 RB220

25 RB250

32 RB320

PART NO

3/4 X 3/4 RDQ190

20 x 20mm RDQ200

25 x 25mm RDQ250

30 x 30mm RDQ300

RB

RDV

RDQ

A wide range of metric sizes and alternative patterns is also

available - please enquire

EXTERNAL FITTING STAND-OFF FEET

4 Provides neat closure to horizontal tube and lifts frame off floor

4 Ideal for signage, display stands etc

RECTANGULAR

SEL

SQUARE

SEQ

TUBE SIZE INCHES / MM

PART NO

TUBE SIZE INCHES

PART NO

1.1/2 x 3/4 SEL381190

3/4 x 3/4 SEQ190

40 x 20MM SEL400200

1 x 1 SEQ254

2 x 1 SEL508254

ROUND

SED

A wide range of metric sizes and alternative

patterns is also available - please enquire

TUBE SIZE MM

28MM DIA

PART NO

SED280

INTERNAL FITTING STAND-OFF FEET

RECTANGULAR

SIL

SQUARE

SIQ

TUBE GAUGE PART NO PART NO

SIZE MM VERTICAL HORIZONTAL

30 x 15 1.0-2.0 SILV300150 SILH300150

30 x 20 1.0-2.0 SILV300200 SILH300200

35 x 20 1.0-2.0 SILV350200

TUBE SIZE MM GAUGE PART NO

20 x 20 1.0-2.0 SIQ200

25 x 25 1.0-2.0 SIQ250

30 x 30 1.0-2.0 SIQ300

Vertical

35 x 25 1.0-2.0 SILV350250

40 x 20 1.0-2.0 SILV400200 SILH400200

ROUND

SID

40 x 25 1.0-2.0 SILV400250

TUBE SIZE MM GAUGE PART NO

40 x 30 1.0-2.0 SILV400300

20 dia 2.0 SID200/20

50 x 20 1.0-2.0 SILH500200

25 dia 2.0 SID250/20

50 x 25 1.0-2.0 SILV500250

28 dia 2.0 SID280/20

50 x 30 1.0-2.0 SILV500300

30 dia 2.0 SID300/20

32 dia 1.5 SID320/15

Horizontal

38 dia 2.0 SID380/20

36

01279 656 189 01279 658 891 sales@indifit.co.uk


PVC TIPS AND SLEEVES

ROUND

WIRE SIZE INCHES / MM

PART NO

3/16 (4.8mm) RW048

1/4 (6.3mm) RW065

5/16 (8.0mm) RW080

RW

4 TYPE 1 - injection moulded PVC

4 Ideal for wire displays, signage etc

4 Standard material: soft PVC

TIPS / SLEEVES

ROUND

WIRE / TUBE LENGTH PART NO

SIZE DIA MM

2.0 10.0 RW020/010

2.0 15.0 RW020/015

3.0 10.0 RW030/010

3.0 15.0 RW030/015

3.5 10.0 RW035/010

4.0 10.0 RW040/010

4.0 15.0 RW040/015

5.0 5.0 RW050/005

5.0 15.0 RW050/015

5.0 20.0 RW050/020

5.0 40.0 RW050/040

6.0 15.0 RW060/015

6.0 25.0 RW060/025

6.0 30.0 RW060/030

6.0 50.0 RW060/050

6.0 100.0 RW060/100

7.0 15.0 RW070/015

7.0 30.0 RW070/030

8.0 15.0 RW080/015

8.0 25.0 RW080/025

8.0 35.0 RW080/035

8.0 75.0 RW080/075

9.0 15.0 RW090/015

9.0 30.0 RW090/030

10.0 20.0 RW100/020

10.0 25.0 RW100/025

10.0 50.0 RW100/050

10.0 100.0 RW100/100

12.0 20.0 RW120/020

12.0 25.0 RW120/025

12.0 50.0 RW120/050

WIRE / TUBE LENGTH PART NO

SIZE DIA MM

12.0 75.0 RW120/075

12.0 100.0 RW120/100

15.0 30.0 RW150/030

15.0 40.0 RW150/040

15.0 50.0 RW150/050

16.0 25.0 RW160/025

16.0 32.0 RW160/032

16.0 60.0 RW160/060

16.0 100.0 RW160/100

19.0 30.0 RW190/030

19.0 45.0 RW190/045

20.0 15.0 RW200/015

20.0 25.0 RW200/025

20.0 45.0 RW200/045

25.0 40.0 RW250/040

25.0 75.0 RW250/075

25.0 100.0 RW250/100

25.0 130.0 RW250/130

28.0 25.0 RW280/025

28.0 45.0 RW280/045

30.0 25.0 RW300/025

30.0 130.0 RW300/130

32.0 25.0 RW320/025

32.0 45.0 RW320/045

32.0 130.0 RW320/130

35.0 45.0 RW350/045

38.0 45.0 RW380/045

48.0 45.0 RW480/045

48.0 180.0 RW480/180

60.0 90.0 RW600/090

RW

4 Type 2 - dip moulded PVC - high gloss finish

- in wide variety of diameters, sections and lengths.

4 Standard colour black - others available to order

- please enquire

Many other sizes and lengths

can be supplied. Special colours can be

manufactured with very modest minimum

quantity requirements.

Please call our sales department

for details

RECTANGULAR / SQUARE

BAR / TUBE LENGTH PART NO

SIZE MM

13 x 13 30.0 RW130130/030

20 x 4 30.0 RW200040/030

20 x 5 40.0 RW200050/040

20 x 6 25.0 RW200060/025

25 x 4 30.0 RW250040/030

25 x 4 40.0 RW250040/040

25 x 5 25.0 RW250050/025

BAR / TUBE LENGTH PART NO

SIZE MM

25 x 6 25.0 RW250060/025

30 x 4 30.0 RW300040/030

30 x 4 40.0 RW300040/040

30 x 8 25.0 RW300080/025

30 x 8 100.0 RW300080/100

30 x 15 25.0 RW300150/025

40 x 10 40.0 RW400100/040

RW

01279 656 189 01279 658 891 sales@indifit.co.uk

37


PUSH IN / SELF ADHESIVE BUFFER-FEET

SELF ADHESIVE BUFFER FEET

4 High quality polyurethane buffers with advanced

formula adhesive backing

MT2006

4 Minimum labour involved in application

4 Standard colours: black , grey and clear

4 Special colours to order: white, brown, red, blue,

green and beige

MT2008 MT2079 MT2010 MT2115 MT2150

DIA mm 6.4 8.0 7.9 10.0 11.1 16.0

HEIGHT mm 1.9 2.1 2.5 3.1 5.0 7.9

MT2014

MT2191 MT2204 MT2024 MT2019 MT2020

DIA mm 14.0 19.0 19.7 19.0 19.0 20.0

HEIGHT mm 4.5 1.9 3.0 4.0 6.0 6.2

MT2190

MT2075 MT2120 MT2122 MT2125 MT2104

DIA mm 19.0 7.5 10.1 12.7 12.7 10.0

HEIGHT mm 9.5 3.0 1.8 1.8 3.5 4.0

MT

MT

MT

MT

MT2100

MT2127 MT2126 MT2205 MT2210

DIA mm 10.1 x 10.1 12.7 x 12.7 12.6 x 12.6 20.5 x 20.5 22.3

HEIGHT mm 2.5 3.1 5.7 7.6 10.1

PUSH IN BUFFER FEET

4 Neat and easily fixed cushioned buffer feet for apparatus

4 Standard material: polyethylene (PE), PVC, EVA.

4 Standard colour: black (others available)

MANY MORE PATTERNS

/ SIZES ARE AVAILABLE

PLEASE ENQUIRE!

MP

d D H L TYPE MATERIAL PART NO d D H L TYPE MATERIAL PART NO

4 12 1.5 7.5 A PVC MPA040/12PV

6 14 8 15 B PE/PVC MPB060/14**

4.2 11 7 10 A PVC MPA042/11PC

6 16 11 12 A PE MPA060/16PE

5 9 4 6 B PE/PVC MPB050/09**

7.8 14 3 8.5 A PE MPA078/14PE

5.8 12 3 7 A PE MPA058/12PE

8 11 2.5 6 B PVC MPB080/11PC

6 12 3.8 9 A PE/PVC MPA060/12**

9 14 5 6 B PE/PVC MPB090/14**

All dims in MM

10 20 9 10 B PE/PVC MPB100/20PC

** - add material

TYPE A

TYPE B

38

01279 656 189 01279 658 891 sales@indifit.co.uk


SNAP-IN HOLE PLUGS

4 Spring mechanism in shank to lock

plug into aperture

D B C PART

MM MM MM NO

4.8 6.4 5.9 MH048

6.4 8.0 8.0 MH064

8.0 9.5 8.0 MH080

9.5 12.0 10.3 MH095

11.0 13.5 10.3 MH110

12.7 14.6 10.3 MH127

14.3 16.7 10.3 MH143

D B C PART

MM MM MM NO

15.9 18.2 10.3 MH159

17.5 20.0 10.3 MH175

19.0 23.2 10.3 MH190

20.6 22.6 10.3 MH206

22.2 25.8 11.5 MH222

25.4 30.5 11.5 MH254

28.5 31.0 11.5 MH285

SCREW IN BUFFER FEET

4 Standard material: Black or white

nylon

4 Low profile matt finish head

D B C PART

MM MM MM NO

MH

30.1 33.3 11.5 MH301

32.0 34.9 11.5 MH320

35.0 38.0 11.5 MH350

38.0 42.7 11.5 MH380

45.0 48.4 11.5 MH450

51.0 55.0 11.5 MH510

4 Standard colour: black (most EVA patterns also in white) 4 Standard material: PVC, EVA, polyethylene (PE) 4 Recessed hole for screw fixing.

D d H d1 h MATERIAL PART NO

13.0 3.0 6.0 6.0 4.0 PVC MS130/30/06PC

15.0 4.1 10.0 7.5 4.0 EVA MS150/41/10EV

18.0 2.0 8.0 7.0 5.0 PVC MS180/20/08PC

18.5 3.0 18.0 8.0 6.0 PVC MS185/30/18PC

19.0 3.0 10.0 8.5 5.0 PVC MS190/30/10PC

19.0 3.0 13.0 7.5 6.0 PVC MS190/30/13PC

20.0 4.6 10.0 10.1 4.0 EVA MS200/46/10EV

20.0 4.6 18.0 10.1 4.0 EVA MS200/46/18EV

All dims in MM

All dims in MM

D d H d1 h MATERIAL PART NO

MS

20.0 4.6 23.0 9.0 7.0 PVC MS200/46/23PC

22.0 4.6 10.0 10.1 4.0 EVA MS220/46/10EV

22.0 4.6 18.0 10.1 4.0 EVA MS220/46/18EV

25.0 4.6 8.0 10.1 4.0 EVA MS250/46/08EV

25.0 5.0 24.0 10.0 7.0 PVC MSA/25024

D

Many patterns of cheap and simple polyethylene hole plugs

are available for hole sizes 2.8 - 13.0mm. Please enquire!

B

Also available - PVC

screw on foot with

countersunk hole. Foot

diameters: 20 - 25

- 30 - 40mm

BUFFER FEET / HOLE PLUGS

TRANSPARENT GLASS BUFFERS

4 Ideal for supporting glass shelves and tops

4 Material: soft PVC

4 Provide slight suction action to locate glass securely

d D H L PART NO

MM MM MM MM (TYPE)

d D H L PART NO

MM MM MM MM (TYPE)

d D H L PART NO

MM MM MM MM (TYPE)

MT

MTK

MTVG

5 8 4 8 MTK08/0408

8 15 5 8 MTK15/0508

7 25 12 5 MTVS250/1207

5 15 5 5 MTK15/0505

6 20 6.5 10 MTVG20/0606

8 30 13 5 MTVS300/1308

6 20 10 4 MTVS200/1006

MTVS

EXTERNAL FITTING SADDLE FEET

TUBE SIZE INCHES / MM PART NO

14 - 16mm JDR140

TUBE SIZE INCHES / MM PART NO TUBE SIZE INCHES / MM PART NO

20 - 22mm JDR200

24 - 26mm JDR240

JDR

4 Integral peg locates

in pre-drilled hole to

provide secure location

16 - 18mm JDR160

7/8 - 1 JDR254

28 - 30mm JDR280

18 - 20mm JDR180

*No peg

7/8 - 1* JDR222254N

1.1/4 JDR317

JDR

SPECIAL ORDER ITEMS

Pin glides—plain nylon or with PTFE or felt base

Nylon saddle foot, also with PTFE glide, or PVC

non-slip base

Screw-on radius foot for flat or

curved tubular base

01279 656 189 01279 658 891 sales@indifit.co.uk

39


PLASTIC HANDWHEELS

THUMBSCREW

4 Versatile range of black plastic thumbscrews with BZP

or passivated steel threads

4 Offers attractive and discreet method of locking and

adjusting

4 Ideal for standing signs, displayboards, shopfittings

and many other applications

HITF type

Wing pattern giving

maximum purchase

(28 + 32mm)

HITF TYPE

GRIP/KNOB WIDTH THREADED BLIND BUSH MALE STUD MM

HITR TYPE

28mm - M5 x 10/15/20/25 M6 x 10/16/20/25/30

32mm M6 M8 M6 x 10/16/20/25 M8 x 15/20/35

68mm M6 M8 M6 x 10/16/20/25 M8 x 15/20/35

GRIP/KNOB WIDTH THREADED BLIND BUSH MALE STUD MM

14mm - M4 x 8/15/25

22mm M5 M6 M4 x 8/15/25 M5 x 10/15/20/30 M6 x 10/15/20/25/30/40/50

28mm M8 M8 x 20/25/30/40/50

HITF

HITR

OTHER THREAD SIZES

AND KNOB PATTERNS ARE

AVAILABLE - PLEASE ENQUIRE!

HITR type

Round pattern

with knurled edge

HITF Type (68mm)

LIGHT DUTY HANDWHEEL

4 Economically priced range of injection moulded

thermoplastic handwheels with BZP steel studs

and female threads

4 Standard colour: black. Others to special order

A

B

C

D

PART NO A B C D E F

(TYPE) MM MM MM MM MM MM

HLIS30/0612 30 10 8 12 M6 13.5

HLIS30/0617 30 10 8 17 M6 13.5

HLIS30/0622 30 10 8 22 M6 13.5

HLIS30/0820 30 10 8 20 M8 13.5

HLIS40/0820 40 11 7 20 M8 16

HLIS40/1020 40 11 7 20 M10 16

PART NO A B C D E F

(TYPE) MM MM MM MM MM MM

HLIS

HLIS50/1020 50 14 8.5 20 M10 18

HLIS50/1025 50 14 8.5 25 M10 18

HLIS50/1030 50 14 8.5 30 M10 18

HLIS60/1020 60 15 9 20 M10 18

HLIS60/1025 60 15 9 25 M10 18

HLIS60/1030 60 15 9 30 M10 18

E

F

HLIS

HLIB

PART NO A B C D E F

(TYPE) MM MM MM MM MM MM

HLIB30/06 30 10 8 M6 13.5 14

HLIB30/08 30 10 8 M8 13.5 14

HLIB40/06 40 12 6.5 M6 16 14

HLIB40/08 40 12 6.5 M8 16 14

HLIB

PART NO A B C D E F

(TYPE) MM MM MM MM MM MM

HLIB50/08 50 14 9.5 M8 18 18

HLIB50/10 50 14 9.5 M10 18 16

HLIB60/08 60 15 9 M8 18 18

HLIB60/10 60 15 9 M10 18 18

LIGHT DUTY HANDWHEEL

4 Very economically priced handwheel

4 Five lobe knob provides good grip/purchase

PART NO KNOB THREAD STUD

(TYPE) DIA MM LENGTH

HL5

HL5/44/0815 44 M8 15

HL5/44/0822 44 M8 22

HL5/44/0837 44 M8 37.5

HL5/60/0815 60 M8 15

HL5/60/0822 60 M8 22

HL5/60/0837 60 M8 37.5

40

01279 656 189 01279 658 891 sales@indifit.co.uk


LIGHT DUTY HANDWHEEL

Knob

Dia

Thread

(bush)

4 LOBE HANDWHEEL

4 Smart, matt finish nylon handwheel with modern

KNOB HL4S THREADED HL4T THRU’ HL4B BLIND

DIA MM STUD THREAD THREAD

21 M4 x 10/16/20/30 M4 M4

M5 x 10/16/20/30 M5 M5

M6 x 10/16/20/30/40 M6 M6

26 M4 x 10/16/20/30 M4 M4

M5 x 10/16/20/30/40 M5 M5

M6 x 10/16/20/30/40 M6 M6

M8 x 16/20/30/40 M8 M8

30 M5 x 10/16/20/30/40 M5 M5

M6 x 16/20/30/40/50 M6 M6

M8 x 16/20/30/40/50 M8 M8

M10 x 20/30/40/50/60 M10 M10

41 M6 x 16/20/30/40/50 M6 M5

M8 x 16/20/30/40/50 M8 M6

M10 x 16/20/30/40/50/60 M10 M8

M12 x 20/30/40 M12 M10

Male stud lengths

HL4

KNOB HL4S THREADED HL4T THRU’ HL4B BLIND

DIA MM STUD THREAD THREAD

52 M6 x 16/20/30/40/50 M6 M6

M8 x 16/20/30/40/50/60 M8 M8

M10 x 16/20/30/40/50/60 M10 M10

M12 x 20/30/40/50/60 M12 M12

59 M8 x 16/20/30/40/50/60 M8 M8

M10 x 16/20/30/40/50/60 M10 M10

M12 x 20/30/40/50/60 M12 M12

M14 x 30/40/50 M14 M14

79 M10 x 20/30/40/50/60 M8 M10

M12 x 20/30/40/50/60 M10 M12

M14 x 30/40/50 M12 M14

* BZP mild steel thread

M14 M16*

M16* M20*

HSTGR

12 16 26 36 46 56 66 76 86 96 116

40 M6 X X X X X X X X

40 M8 X X X X X X X X X X X

50 M6 X X X X X X X X

50 M8 X X X X X X X X X X X

50 M10 X X X X X X X X X X X

63 M8 X X X X X X X X X X X

63 M10 X X X X X X X X X X X

80 M10 X X X X X X X X X X

80 M12 X X X X X X X X

HSTGR female blind thread

4 2 part body in Nylon 6

aesthetics

4 Standard colour: black - available in wide range of colours

to order

HL4T

Threaded through

brass insert

HL4S

Male BZP steel stud

HSTGR male stud

4 Male and female threads in zinc plated steel

4 Very economical prices

4 Other RAL colours can be manufactured, including

2 colour (face/body) and/or embossed or printed

company logo (subject to minimum quantities)

4 Other options include: special stud lengths, stainless

steel threads, non-standard threads etc.

HL4B

Female blind threaded bush

PLASTIC HANDWHEELS

DUROPLAST HANDWHEEL

KNOB DIA MM

25 M5

32 M5/M6/M8

40 M6/M8

HH5

THREAD (MALE / FEMALE)

50 M8/M10/M12

63 M8/M10/M12

80 M10/M12/M16

HH4

4 Thermoset duroplast material provides excellent durability and heat resistance

4 Male and female threads in BZP mild steel.

4 Standard colour: black - other colours to order

HH4 TYPE

MALE STUD LENGTHS An almost infinite range of stud lengths

is available PLEASE ENQUIRE

HH5 TYPE

DUROPLAST BALLKNOB

4 Standard colour: black - other colours to order

(subject to min quantities)

4 Thermoset duroplast with moulded threads

SPECIAL OPTIONS

Patterns with steel threaded

insert, or with plain tapered hole

for push fit onto plain shaft are

available to order.

HB

BALL DIA MM

THREAD

BALL DIA MM

THREAD

10 M3

35 M6/M10

12 M4

40 M8/M10/M12

16 M4/M5/M6

45 M10/M12

20 M4/M5/M6/M8/M10

50 M8/M10/M12/M16

25 M5/M6/M8/M10

60 M10/M12/M16

32 M6/M8/M10/M12

01279 656 189 01279 658 891 sales@indifit.co.uk

41


CONTROL ELEMENTS / HANDGRIPS

PVC HANDGRIP

4 Dip moulded flexible PVC

4 Preferred colour: black, Other colours to order

TUBE GRIP PART

DIA MM LENGTH NO

16 100 HGS160/100

19 100 HGS190/100

22 100 HGS220/100

25 100 HGS250/100

TUBE GRIP PART

DIA MM LENGTH NO

19 110 HGB190/110

22 110 HGB220/110

25 110 HGB250/110

HGS

HGB

INDEXED (ADJUSTABLE) CLAMPING LEVER

4 Glass filled technopolymer - satin finish

4 Standard colour black with red button - other

combinations, including coloured handle, available

to order

4 Spring loaded handle allows adjustment in confined

area - locks into position on knurled boss

LEVER

LENGTH MM

HGS TYPE

Plain sleeve

TUBE GRIP PART

DIA MM LENGTH NO

19 110 HGP190/110

22 110 HGP220/110

25 110 HGP250/110

THREADED

BLIND BUSH

HGP

MANY OTHER TYPES/STYLES

OF CLAMPING LEVERS ARE AVAILABLE

SUCH AS: Stainless steel threads, Coloured

handles, Non- adjustable (fixed),

All metal construction

PLEASE ENQUIRE FOR DETAILS!

MALE STUD MM

HGB TYPE Bulbous

NB. stock colour: black

HGP TYPE Finger grip

HCL

Male threaded stud

51 M4 M5 M6 M4 x 10/15/20/25/30/40 M5 x 10/16/20/25/30/40 M6 x 10/16/20/25/30/35/40/50

63 M6 M8 M10 M6 x 16/20/25/30/35/40/50 M8 x 16/20/25/30/35/40/45/50 M10 x 20/25/30/35/40/50

76 M6 M8 M10 M6 x 16/20/25/30/35/40/45/50 M8 x 16/20/25/30/35/40/45/50/60

M10 x 20/25/30/35/40/50

93 M8 M10 M12 M8 x 20/25/30/35/40/45/50 M10 x 20/25/30/35/40/50/60/70

M12 x 20/25/30/35/40/45/50/60/70/80

Threaded blind bush

109 M8 M10 M12 M8 x 20/25/30/35/40/50 M10 x 20/25/30/35/40/50/60/70/80

M12 x 20/25/30/35/40/45/50/60/70/80

125 M12 M14 M16 M12 x 20/30/40/50/60/70/80 M14 x 30/40/50/60/70 M16 x 40/50/60

MISCELLANEOUS CONTROL ELEMENTS

We can supply handwheels

of all shapes and sizes!

Please ask for details!

REVOLVING + FIXED HANDLES

Male and female threads

CONTROL

HANDWHEELS

Plastic and aluminium,

with or without revolving

handles

CRANKED HANDLES

Plastic, steel and aluminium

42

01279 656 189 01279 658 891 sales@indifit.co.uk


1000 SERIES QUARTER TURN L HANDLE

4 Shown with handle in black nylon, also available black

powder coated or chrome plated die cast zinc

4 Lock or non-locking, with same or different keys

4 IP65 rated

PART NUMBER - BLACK NYLON HANDLE/ DIE CAST ZINC HOUSING + CYLINDER

GH Ts 1.5- H- range dependent

on cam specified NON-LOCK LOCKING LOCKING DIFF KEY

18mm 8mm 4 - 50mm E1000-U570 E1000-U572 E1000-U574

30mm 20mm 16 - 62mm E1000-U576 E1000-U578 E1000-U580

40mm 30mm 26 - 72mm E1000-U582 E1000-U584 E1000-U586

50mm 40mm 36 - 82mm E1000-U588 E1000-U590 E1000-U592

60mm 50mm 48 - 92mm E1000-U624 E1000-U626 E1000-U628

“GH”, “Ts” & “H” DIMENSIONS - NOTE

“Ts” equates to thickness of panel through which the body must pass.

Min dimension is 1.5mm - the further dimension shown above is the MAXIMUM panel thickness that can be accommodated by the body length (GH).

“GH” equates to the body length. The total door/panel locking thickness as shown by “H” dimension is dependent on cam specified. Please enquire.

LATCHES / HANDLES

Die cast zinc cylinder with stainless steel cap and shutter

on all models.

Screw and nut BZP mild steel.

Key removable in locked and unlocked positions.

Also available with earthing nut - please enquire.

1000 SERIES QUARTER TURN TEE HANDLE

PART NUMBER - BLACK NYLON HANDLE/ DIE CAST ZINC HOUSING + CYLINDER

GH Ts 1.5- H- range dependent

on cam specified NON-LOCK LOCKING LOCKING DIFF KEY

18mm 8mm 4 - 50mm E1000-U546 E1000-U548 E1000-U550

30mm 20mm 16 - 62mm E1000-U552 E1000-U554 E1000-U556

40mm 30mm 26 - 72mm E1000-U558 E1000-U560 E1000-U562

50mm 40mm 36 - 82mm E1000-U564 E1000-U566 E1000-U568

60mm 50mm 48 - 92mm E1000-U606 E1000-U608 E1000-U610

“GH”, “Ts” & “H” DIMENSIONS - NOTE

“Ts” equates to thickness of panel through which the body must pass.

Min dimension is 1.5mm - the further dimension shown above is the MAXIMUM panel thickness that can be accommodated by the body length (GH).

“GH” equates to the body length. The total door/panel locking thickness as shown by “H” dimension is dependent on cam specified. Please enquire.

Die cast zinc cylinder with stainless steel cap and shutter on all

models.

Screw and nut BZP mild steel.

Key removable in locked and unlocked positions.

Also available with earthing nut - please enquire.

01279 656 189 01279 658 891 sales@indifit.co.uk

43


LATCHES / HANDLES

1000 SERIES QUARTER TURN WING KNOB

Die cast zinc cylinder with stainless steel cap and shutter

on all models.

Screw and nut BZP mild steel.

Key removable in locked and unlocked positions.

4 Shown with handle in black nylon, also available black powder coated or chrome plated

die cast zinc

4 Lock or non-locking, with same or different keys

4 IP65 rated

Also available with

Earthing nut -

Please enquire!

PART NUMBER - BLACK NYLON HANDLE/ DIE CAST ZINC HOUSING + CYLINDER

GH Ts 1.5- H- range dependent

on cam specified NON-LOCK LOCKING LOCKING DIFF KEY

18mm 8mm 4 - 50mm E1000-U343 E1000-U345 E1000-U347

30mm 20mm 16 - 62mm E1000-U512 E1000-U514 E1000-U516

40mm 30mm 26 - 72mm E1000-U518 E1000-U520 E1000-U522

50mm 40mm 36 - 82mm E1000-U524 E1000-U526 E1000-U528

60mm 50mm 48 - 92mm E1000-U645 E1000-U647 E1000-U649

“GH”, “Ts” & “H” DIMENSIONS - NOTE

“Ts” equates to thickness of panel through which the body must pass.

Min dimension is 1.5mm - the further dimension shown above is the MAXIMUM panel thickness that can be accommodated by the body length (GH).

“GH” equates to the body length. The total door/panel locking thickness as shown by “H” dimension is dependent on cam specified. Please enquire.

Also available with earthing nut - please enquire

1000 SERIES QUARTER TURN KNOB

Head materials:

Head dims:

Insert materials:

Insert profile:

Chrome plated die-cast zinc - Black powder coated die-cast zinc

Black glass filled nylon - Stainless steel (304 or 316)

28mm dia x 4mm high - 30mm dia x 4mm high - 32mm dia x 6mm high

Chrome plated die-cast zinc - Black powder coated die-cast zinc

Black glass filled nylon - Stainless steel (304 or 316)

8mm square or triangular standard - many other patterns also available

Key to suit insert supplied separately

PLEASE CONTACT US FOR A FULL RANGE OF CAMS (H DIMENSIONS) AVAILABLE

Long housing

also available -

Please ask for

details.

“H” dimension - 4mm to 50mm

according to cam supplied.

Please enquire

44

01279 656 189 01279 658 891 sales@indifit.co.uk


1048 SERIES QUARTER TURN WITH CYLINDER

4 Standard with die-cast zinc housing (black or chrome) with stainless steel cap and shutter, BZP mild steel nut and washer

4 High quality construction

4 Supplied with one steel key (nylon grip), removable in locked and unlocked position

4 Available with same or different keys

PART N0 - CHROME PLATED DIE-CAST ZINC

PART N0 - BLACK POWDER COATED DIE-CAST ZINC

HEAD DIA SINGLE KEY DIFF KEY SINGLE KEY DIFF KEY

28mm E1048-U6 E1048-U7 E1048-U14 E1048-U15

32mm E1048-U1 E1048-U2 E1048-U10 E1048-U11

“H” dimension - 4mm to 50mm

according to cam supplied. Please

enquire

All nylon version

also available -

Please enquire!

LATCHES / HANDLES

7308 SERIES CAMLOCK

4 Highly economical prices

4 500 different key combinations

4 BZP mild steel with nut and cam in zinc/colour

KEY REMOVABLE

POSITION SHOWN

BY

PART NO E7308-A009B E7308-B009B E7308-C009B E7308-D009B

Screw and nut BZP mild steel.

Key removable in locked and unlocked positions.

ADDITIONAL ITEMS

In addition to the items shown in this catalogue, we can supply a vast range of access hardware including:

Plastic quarter turn Slam latches Lift & turn / swing handles

Multi-point latching

01279 656 189 01279 658 891 sales@indifit.co.uk

45


HINGES

0400 SERIES G/F NYLON HINGE

4 High quality reinforced nylon hinge in standard black RAL9011 or colours to order

4 Variety of fitting options

4 Options: stainless steel pin; mixed stud/bush pattern

THROUGH HOLE FITTING

0400

PART NO I C A/B h H d1 d d2 d3

E0400-20-M04 20 20 32 7.0 10.5 4.5 8 3 7

E0400-30-M06 30 30 48 10.5 15.5 6.5 13 5 10

E0400-40-M06 40 40 64 13.0 19.0 6.5 13 5 12

E0400-60-M08 60 63 96 16.0 24.0 8.5 16 8 16

E0400-60-M10 60 63 96 16.0 24.0 10.5 20 8 16

0400 - Through hole fitting

0430 - Threaded bush fitting

0431 - Threaded stud fitting

THREADED BUSH FITTING

0430

PART NO 1a 1b A/B h H d1 Q d2 d3

E0430-30-M05 30 30 48 10.5 15.5 M5 7 5 10

E0430-30-M06 30 30 48 10.5 15.5 M6 7 5 10

E0430-40-M06 40 40 64 13.0 19.0 M6 9 5 12

E0430-40-M08 40 40 64 13.0 19.0 M8 9 5 12

E0430-60-M08 60 63 95 19.0 28.5 M8 13 8 18

E0430-60-M10 60 63 95 19.0 28.5 M10 13 8 18

THREADED STUD FITTING

0431

PART NO 1a 1b A/B h H d1 Q d2 d3

E0431-30-M05 30 30 48 10.5 15.5 M5 15 5 10

E0431-30-M06 30 30 48 10.5 15.5 M6 15 5 10

E0431-40-M06 40 40 64 13.0 19.0 M6 20 5 12

E0431-40-M08 40 40 64 13.0 19.0 M8 20 5 12

E0431-60-M08 60 63 95 19.0 28.5 M8 20 8 18

E0431-60-M10 60 63 95 19.0 28.5 M10 20 8 18

PLASTIC ADJUSTABLE HINGE

4 Manufactured in white or black acetal polymer (POM)

4 Pin in clear acetal polymer

4 Friction / resistance of hinge can be adjusted by tightening of BZP pozi screw

4 All RAL colours can be produced subject to min quantity

PART NO

BLACK

PART NO

WHITE A MM B MM C MM D MM

EAH

HOLE

SIZE

EAH12824X EAH10896Y 43 36.5 32 25 5.2

DO YOU NEED SPECIAL SIZED

WASHERS OR GASKETS?

• SMALL QUANTITIES WELCOMED

• Delivery usually 7-10 days

• Wide choice of materials

• Self-adhesive available in some materials

SEE PAGE 59 FOR FULL DETAILS

46

01279 656 189 01279 658 891 sales@indifit.co.uk


1091 SERIES SLIDE LATCH (SPRING LOADED)

4 High quality black nylon moulding with stainless spring

4 Quick and easy snap-in installation

E1091-U114-01 E1091-U114 28 47 25 20.0 38 25.5

E1091-U115-01 E1091-U115 47 47 44 39.5 38 44.5

- E1091-U116 86 47 83 78.5 38 83.5

1091

PANEL THICKNESS PANEL THICKNESS A B C D DOOR CUT-OUT

1.2 - 1.6MM 1.75 - 2.2MM X Y

Lockable

(e.g. see “quarter turn latches”)

1091 SERIES SNAP-IN PULL

4 High quality black nylon moulding

4 Quick and easy snap-in installation

4 Your logo can be incorporated (subject to quantity)

PANEL THICKNESS PANEL THICKNESS PANEL THICKNESS

0.8 - 1.2MM 1.2 - 1.6MM 1.75 - 2.2MM

E1091-93 E1091-91 E1091-92

1016 SERIES SELF ADHESIVE CLOSED CELL NEOPRENE

1091

SLIDE LATCH / PULLS / SELF ADHESIVE NEOPRENE STRIP

1016

PART NO B D COIL LENGTH

E1016-61 10 3 10M

E1016-62 10 4 10M

E1016-63 10 5 10M

E1016-64 15 3 10M

E1016-65 15 4 10M

E1016-67 20 3 10M

Many other profiles and sizes of gasketing and self-adhesive strip are available

PLEASE ENQUIRE!

E1016-68 20 4 10M

E1016-69 20 5 10M

01279 656 189 01279 658 891 sales@indifit.co.uk

47


HANDLES / PULLS

REN.PRO#054

PRODUCT

Handle

CODE 2179/F

Glass filled nylon handle in black of elliptical section. Brass bush insert for fixing from behind

panel. Can be produced in a wide range of RAL colours to order in minimum quantities.

CONTACT Ben Bryant 01934 424594

DRAWING

B

Glass filled nylon handle in black with push-in red cap. Cap also available in wide range

of RAL colours in minimum quantities. Available with through-holes for frontal fixing by

socket head capscrew or with brass bush insert for concealed fixing from behind panel.

A

T PATTERN - with through-fixing holes

B PATTERN - with concealed brass bushes

C

D

PART NO “B”

PATTERN

NYLON DEE HANDLE / PULL

PART NO A B C D THREAD

HDR3/12550T 107 40.5 94 20 M5

HDR3/12551P 134 50 117 25 M6

HDR3/12552W 137 50 120 25 M6

HDR3/12553S 148 50 132 25 M6

HDR3/12554Z 168 58 150 29 M8

HDR3/12555V 197 58 179 29 M8

NYLON DEE HANDLE / PULL

THREAD

PART NO

“T” PATTERN

HOLE

DIA A MM B MM C MM D MM E MM

HDR1/7759VB M6 HDR1/7758ZT 6.5 119.5 35 93.4 29 26

HDR1/7760RB M8 119.5 35 93.4 29 26

HDR1/7762UB M6 145 40 117 34 29

HDR1/7761YB M8 HDR1/7733PT 8.5 145 40 117 34 29

HDR1/7798TB M6 163 45 132 38 31

HDR1/7800WB M8 HDR1/7765TT 8.5 163 45 132 38 31

HDR1/7999SB M8 HDR1/7797XT 8.5 213 50 179 42.5 35

HDR1/7799PB M10 213 50 179 42.5 35

HDR1/7801SB M12 213 50 179 42.5 35

HDR3

HDR1

4 Male threaded stud fitting—with locking nuts

FOLDING PULL CHROMED STEEL

HPR3

B

A

C

D

E

F

PART NO A B C D E F THREAD

HPR3/11801X 116 42 100 16 29 51 M10

HPR3/11802T 138 42 120 18 29 51 M10

HPR3/11803P 198 42 180 18 29 51 M10

Two piece glass filled nylon with base in orange or black, and cover in black. Other colours to

order in min quantities.

Fixes from front by two M6 bolts/screws (not included) - holes covered by black cover.

B

NYLON PULL

HPR1

PART NO A B C D E F

Orange base HPR1/12439X 116 35 95.5 40 20 24

Black base HPR1/12544V 116 35 95.5 40 20 24

Black cover HPR1/12440T

Pull in matt finish, anodised aluminium.

Fixing from behind panel into two integral female blind M6 threads

ALUMINIUM PULL

HPR2

PART NO A B C D E F THREAD

HPR2/11835T 110 32 90 10 33 9.5 M6

HPR2/11836P 140 32 120 10 33 9.5 M6

We are able to supply many other patterns of dee handles/pulls. Please call us for details.

Electro-polished, high quality

stainless steel pull two sizes 220 and 325mm long

Matt anodised aluminium in 6 sizes 63 — 243mm lengths

Heavy duty Duroplast in two sizes 140 and 185mm long

48

REN.PRO#058

PRODUCT Handle

CODE

MBH01

CONTACT Ben Bryant 01934 424594

DRAWING

01279 656 189 01279 658 891 sales@indifit.co.uk


Stainless steel

QUICK AND EASY FASTEN/RELEASE FOR SLIDING PANELS!

4 Matt zinc finish steel plate fixing with glass filled nylon pull knob

4 With or without 1/4 turn locking hold-open position

PLATE FITTING PLUNGER

PART NO WITH

1/4 TURN LOCK

PART NO

WITHOUT 1/4

TURN LOCK A B C D E F G

HPL1/11820Y HPL1/11819R 25 37 40 30 18 4.5 6 6

HPL1/11824T HPL1/11823X 31 44 46 34 20 5.5 8 8

4 Burnished or stainless stud/nut fixing with glass filled nylon pull knob

4 1/4 turn locking hold-open position as standard

THREAD FITTING PLUNGER

PART NO

BURNISHED

PART NO STAIN-

LESS A B C D E

THREAD

x PITCH

HPL2/11817Z HPL2/11818V 21 51 5 17 5 M10 x 1.0 5

HPL2/11821U HPL2/11822Q 25 61 6 20 6 M12 x 1.5 6

HPL2/11825P HPL2/11826W 31 75.5 8 26 7 M16 x 1.5 8

4 Burnished steel stud/nut fixing with glass filled nylon pull knob

4 With or without 1/4 turn locking hold-open position

THREAD FITTING PLUNGER

PART NO

WITHOUT

HOLD OPEN

PART NO WITH

HOLD OPEN A B C D E

THREAD x

PITCH

HPL3/12542S - 21 45 5 17 5 M10 x 1.0 5

HPL3/12672P - 21 51 5 17 5 M10 x 1.0 5

HPL3/11831Y - 25 45 5 10 6 M12 x 1.5 6

- HPL3/11832U 25 54 5 10 6 M12 x 1.5 6

HPL3/12673W - 25 61 6 20 6 M12 x 1.5 6

HPL3/11833Q HPL3/11834X 31 54 6 12 8 M16 x 1.5 8

HLP3/12674S - 31 75.5 8 26 7 M16 x 1.5 8

HPL1

PLUNGER

DIA

HPL2

PLUNGER

DIA

HPL3

PLUNGE

DIA

SPRING LOADED INDEX PLUNGERS

4 Stainless steel cam action plunger with plastic cap

4 Lever rests to hold open at extremity of travel

HPL4

CAM ACTION THREAD FITTING PLUNGER

PART NO A B C D

THREAD

x PITCH

HPL4/11794S 69 52 36 12 M20 x 1.5 6

HPL4/11795Z 69 52 36 12 M20 x 1.5 10

HPL4/11796V 69 52 36 12 M20 x 1.5 12

PLUNGER DIA

v

age

PART NO

STAINLESS/

ZINC WITH

LOCK POS

PART NO

STAINLESS/

ZINC WITHOUT

LOCK POS

PART NO

ZINC PLATED

WITH LOCK

POS

4 Plunger with zinc plated or stainless steel body with die cast zinc head

4 Standard colour - silver

4 NB: M12 option does not have hex body as shown in image - only with

12mm A/F flats to accept standard 12mm spanner

PART NO

ZINC PLATED

WITHOUT LOCK

POS A B C D E

THREAD x

PITCH

HPL5/12679U HPL5/12680Q HPL5/12676V HPL5/12675Z 18 30.4 18.2 4 7 M10 x 1.0 6

HPL5/12678Y HPL5/12677R 24 39.4 19.2 8 7 M12 x 1.75 7

HPL5

PLUNGER DIA

01279 656 189 01279 658 891 sales@indifit.co.uk

49


INDUSTRIAL FASTENERS

SOCKET SCREWS

We are able to supply every conceivable type of industrial fastener swiftly and economically. The entire list of products and sizes is too large

to list in detail here - the following ranges represent the most popular items together with the range of standard sizes available.

SOCKET CAPHEAD

SIZE RANGE

M3 x 6 to M12 x 80

1/8 x 1/4” to 1/2” x 3”

SOCKET FLANGE BUTTON HEAD

SIZE RANGE

1.5mm to 10mm

1/16” to 3/8”

SOCKET COUNTERSUNK

SIZE RANGE

M3 x 6 to M20 x 100

1/8 x 1/4” to 3/4” x 4”

HEXAGON HIGH TENSILE

SOCKET SHOULDER SCREW

SIZE RANGE

(M5)6x6 to (M20)24 x 120

(3/16”)1/4” x 1/4” to (3/4”)1” x 1”

SOCKET BUTTON

SIZE RANGE

M3 x 5 to M16 x 80

1/8 x 3/16” to 5/8” x 3”

Finishes: self colour - zinc & de-embrittle - stainless - nickel Threads: metric - UNF - UNC - BSW - BSF

SOCKET SET (GRUB) SCREW

SIZE RANGE

M2 x 2 to M24 x 70

1/16 x 1/8” to 1” x 3”

SOCKET WRENCH (ALLEN KEY)

SIZE RANGE

0.7mm to 27.0mm

1/16” to 3/4”

Cup point

Cone point

Don’t see what you need...

CALL US

Flat point

We can supply much more than is

shown in this catalogue!

?

HEX SETSCREW

SIZE RANGE

M3 x 6 to M36 x 100

1/8” x 1/4” to 1.1/2” x 4

HEX BOLT

SIZE RANGE

M4 x 25 to M64 x 400

5/32” x 1” to 2.1/2” x 16”

Finishes: self colour - zinc plated - zinc & colour - galvanised - stainless steel - nickel plated

MACHINE SCREWS

COUNTERSUNK POZI

SIZE RANGE

COUNTERSUNK SLOTTED

SIZE RANGE

PAN HEAD POZI

SIZE RANGE

PAN HEAD SLOTTED

SIZE RANGE

M3 x 5 to M8 x 50

M2 x 4 to M20 x 140

M2 x 4 to M10 x 60

M3 x 6 to M8 x 25

1/8” x 3/16” to 5/16” x 2”

3/32” x 3/16” to 3/4” x 6”

3/32” x 3/16” to 3/8” x 2.1/2”

1/8” x 1/4” to 5/16” x 2”

CHEESE HEAD SLOTTED

SIZE RANGE

M2 x 4 to M12 x 80

3/32” x 3/16” to 1/2” x 3”

Finishes: self colour - bright zinc plated - zinc & black - nickel plated - stainless steel Threads: Metric - UNF - UNC - BSW - BSF

SELF TAPPING SCREWS

COUNTERSUNK POZI

SIZE RANGE

COUNTERSUNK SLOT

SIZE RANGE

PAN HEAD POZI

SIZE RANGE

PAN HEAD SLOT

SIZE RANGE

No 4 x 1/4” to No 14 x 2.1/2”

No 4 x 1/4” to No 14 x 2”

No 4 x 1/4” to No 14 x 2”

No 4 x 1/4” to No 8 x 2”

Finishes: zinc & clear - zinc & colour - zinc & black - nickel plated - electrobrass - stainless steel Also available: Blunt end self tapping screws - self - drilling screws

WOODSCREWS

COUNTERSUNK POZI

SIZE RANGE

ROUND POZI

SIZE RANGE

COUNTERSUNK SLOT

SIZE RANGE

ROUND SLOT

SIZE RANGE

No 4 x 3/16” to No 12 x 4”

No 4 x 3/16” to No 12 x 4”

No 4 x 1/4” to No 14 x 4”

No 4 x 1/4” to No 14 x 4”

Finishes: zinc & clear - zinc & colour - zinc & black - electrobrass - brass - stainless steel Also available: chipboard screws - drywall screws

50

01279 656 189 01279 658 891 sales@indifit.co.uk


NUTS

FULL NUT

SIZE RANGE

M3 to M110 1/8” to 1”

WING NUT

SIZE RANGE

M3 to M24 1/8” to 1”

RIVET BUSHES

LOCK (HALF) NUT

SIZE RANGE

M2 to M60 3/32” to 2”

TEE NUT

SIZE RANGE

M3 to M10

pronged &

weld-on

WASHERS

NYLON INSERT LOCK NUT

SIZE RANGE

M3 to M64 1/8” to 2.1/2”

DOME NUT

SIZE RANGE

M3 to M24 1/8” to 1”

Finishes: Mild steel self colour, bright zinc plated and zinc black - electrobrass

- brass - nickel plated - stainless steel

Also available: Flange nuts - weld nuts - square nuts - cage nuts

Threads: Metric - UNF - UNC - BSW - BSF

WEIRD OR WONDERFUL SIZE OF WASHER / GASKET NEEDED? SEE PAGE 59!

INDUSTRIAL FASTENERS

HEXAGON

SIZE RANGE

M2 to M20

FLAT WASHER

SIZE RANGE

M1.6 to M64 1/16” to 2.1/2”

MUDGUARD WASHER

SIZE RANGE

M3 to M30 1/8” to 1.1/4”

single & double coil

SPRING WASHER

SIZE RANGE

M2 to M76 3/6” to 20”

ROUND

SIZE RANGE

M3 to M10

Finishes: self colour - zinc clear

- brass - stainless steel - zinc colour

PUSH-ON RETAINING WASHER

SIZE RANGE

1.5MM to 25MM 1/16” to 1”

SQUARE PLATE WASHER

SIZE RANGE

M8 to M30 5/16” to 1”

SHAKEPROOF WASHER

SIZE RANGE

M3 to M24 1/8” to 1”

Finishes: self colour - bright zinc plated - zinc & black - nickel plated - stainless steel - brass Also available: Crinkle washers

- fan disc washers - shim washers

BLIND RIVETS

DOME SEALED LARGE FLANGE COUNTERSUNK PEAL MULTIGRIP

Blind rivets are available in diameters 2.4mm to 8.0mm with grip ranges 0.5 - 2.0 to 23.0 - 27.0. Please enquire for full details

Finishes: aluminium - steel - stainless steel - nickel copper

01279 656 189 01279 658 891 sales@indifit.co.uk

51


CONNECTOR BOLTS AND NUTS / COVER CAPS

CONNECTOR BOLTS & CAP NUTS

4 Designed to be used with capnuts, connector bolts provide a neat, low profile finish.

Finishes: (steel) bronze - zinc plated - black - oil dipped

CONNECTOR BOLTS

AJCB CONNECTOR CAP NUT

AJCN

THREAD L L1 H THREAD L L1 H THREAD L L1 H THREAD L L1 D1 D2 D3 THREAD L L1 D1 D2 D3

M6 12.0 8.0 4 M6 50.0 40.0 4 M8 30.0 20.0 5 M6 9.0 5.0 14.8 8.9 5 M8 16.0 13.0 20.0 9.9 5

M6 16.0 10.0 4 M6 60.0 40.0 4 M8 35.0 30.0 5 M6 12.0 8.0 14.8 8.9 5 M8 17.0 13.0 17.0 11.0 5

M6 20.0 15.0 4 M6 70.0 40.0 4 M8 50.0 30.0 5 M6 17.0 13.0 14.8 8.9 5

M6 25.0 20.0 4 M6 80.0 40.0 4 M8 60.0 40.0 5

M6 30.0 25.0 4 M6 90.0 40.0 4 M8 70.0 40.0 5

M6 35.0 30.0 4 M6 100.0 40.0 4 M8 80.0 40.0 5

M6 40.0 30.0 4 M6 110.0 40.0 4 M8 100.0 40.0 5

M6 45.0 30.0 4 M6 120.0 40.0 4 M8 120.0 40.0 5

NUTCAPS

UC

4 Tight push fit onto standard metric hex bolts and nuts. 4 Standard material: black or white polyethylene

THREAD SIZE

PART NO

M6

UC06

M8

UC08

M10

UC10

M12

UC12

M16

UC16

Larger sizes also available to order - please enquire

52

01279 656 189 01279 658 891 sales@indifit.co.uk


THREADED INSERT NUTS FOR METAL

4 Quick and easy application with hand or power tool

4 Provides permanent thread in sheet metal

4 Standard finish—zinc/clear.

4 Stainless or aluminium to order.

“THINSHEET” REDUCED COUNTERSUNK PATTERN

PART NO THREAD PITCH

THREADED INSERT NUTS FOR WOOD

4 Insert nuts provide a quick, neat and permanent thread in wooden panels

D TYPE

A

(-.15)

B

(+/- 0.3)

C

(+/- 0.3)

D

(+/- 0.2)

APR

GRIP

RANGE

APR03ZC M3 0.5 4.75 8.8 5.3 0.4 0.3-1.5

APRO4ZC M4 0.7 6.3 10.4 7.2 0.45 0.5-2.0

APRO5ZC M5 0.8 7.1 12.0 8.1 0.50 0.5-2.5

APR06ZC M6 1.0 9.5 15.0 10.5 0.50 0.7-3.0

APR08ZC M8 1.25 10.5 16.0 11.5 0.50 0.8-3.0

APR10ZC M10 1.5 12.7 21.5 13.8 0.80 1.0-4.0

“D” TYPE & “E” TYPE

External thread ensures secure location in panel by thread-in operation.

D Type head flange prevents over-insertion and splitting of panel,

whilst E Type can be inserted to below panel surface, or on curved surfaces.

Material: zinc alloy die cast Finish: zinc and yellow

E-TYPE

LARGE FLANGE PATTERN

PART NO THREAD PITCH

A

(-.15)

B

(+/- 0.3)

ANIE

C

(+/- 0.3)

D

(+/- 0.2)

E TYPE

AFTT

GRIP

RANGE

AFTTC03 M3 0.5 5.0 10.5 8.0 0.7 0.5-2.0

AFTTC04 M4 0.7 6.0 11.0 9.0 0.8 0.5-2.5

AFTTC05 M5 0.8 7.0 13.0 10.0 1.0 0.7-3.0

AFTTC06 M6 1.0 9.0 16.5 13.0 1.5 0.8-3.0

AFTTC08 M8 1.25 11.0 17.5 16.0 1.5 1.0-3.0

AFTTC10 M10 1.5 13.0 21.0 17.0 2.0 1.0-3.5

AFTTC12 M12 1.75 16.0 25.2 21.7 2.0 1.0-4.0

THREADED INSERT NUTS FOR WOOD AND METAL

D-TYPE

THREAD L L1 d1 d2 d3 H

ANID

PANEL HOLE

M4 10.0 3.1 8.5 8.0 5.5 4 5.6-6.0

M5 10.0 2.9 11.5 10.6 7.1 5 7.5-7.9

M5 13.0 3.4 11.5 10.6 6.6 5 7.5-7.9

M5 20.0 3.8 11.5 10.8 7.0 5 7.9-8.7

M6 10.0 3.3 12.5 11.6 8.0 6 8.7-9.1

M6 13.0 3.4 12.5 11.7 7.8 6 8.7-9.1

M6 16.0 3.6 12.5 11.7 7.6 6 8.7-9.1

M6 20.0 3.4 12.5 12.0 7.5 6 8.7-9.1

M6 25.0 4.0 12.5 11.9 8.0 6 8.7-9.5

M8 13.0 4.4 14.5 13.5 9.6 8 11.1-11.5

M8 20.0 5.5 14.5 13.5 9.6 8 11.1-11.5

M8 25.0 4.6 14.5 13.8 9.5 8 11.1-12.7

M10 13.0 4.4 16.0 15.1 11.7 10 12.7-13.1

M10 25.0 4.6 15.9 15.1 11.7 10 12.7-13.1

THREAD L L1 d2 d3 H PANEL HOLE

M4 10.0 3.4 7.3 5.5 4 5.6-6.0

M5 13.0 3.4 10.9 6.7 5 7.5-7.9

M6 13.0 3.4 11.5 7.5 6 8.7-9.1

M6 20.0 3.6 11.7 7.7 6 8.7-9.1

M8 13.0 3.4 14.2 9.5 8 11.1-11.5

M8 20.0 4.2 14.3 9.5 8 11.1-11.5

“B” TYPE

External barbs ensures secure location in panel by knock-in operation.

Flange prevents over-insertion and splitting of panel.

B-TYPE

THREAD L L1 d1 d2 d3 H PANEL HOLE

M4 8.0 5.7 10.4 7.6 6 1.5 5.6-6.0

M5 10.0 8.1 12.5 9.8 7.4 2.0 7.1-7.5

M5 13.0 9.5 12.5 10.0 7.5 2.0 7.1-7.5

M6 8.5 7.0 16.0 11.8 9.0 2.0 8.7-9.1

M8 11.5 9.2 19.0 12.4 10.0 2.0 9.5-9.9

M8 14.0 9.9 18.7 12.2 9.9 1.7 9.5-9.9

M8 18.5 16.0 25.0 13.0 10.0 2.0 9.5-9.9

M8 23.0 17.7 18.7 12.2 9.9 0.9 9.5-9.9

ANIB

B TYPE

01279 656 189 01279 658 891 sales@indifit.co.uk

53


SECURITY FASTENERS

SECURITY FASTENERS

2 HOLE

Designed for low-medium torque applications, with two drilled holes in head requiring

unique 2-pin driver to install and remove. Standard in machine and self tapping screws.

Manufactured in A2 stainless steel

SIZE RANGE

CSK self

tapper.

AB type

thread

2.9mm x 9.5mm

to

6.3mm x 50mm

SIZE RANGE

2.9mm x 9.5mm

to

6.3mm x 50mm

Pan head

self tapper.

AB type

thread

Requires insert bit for installation/removal

SIZE RANGE

M3 x 8

to

M6 x 40

CSK

machine

screw

SIZE RANGE

M3 x 10/

M4 X 6

to

M6 x 40

Pan

head

machine

screw

All sizes - box quantity

100 pieces

PIN HEX

Designed for medium torque applications, these screws have internal pin within

standard hex aperture. Very hard to remove without the special insert bit as shown.

Standard in machine and self tapping screws. Manufactured in A2 stainless steel

SIZE RANGE

CSK self

tapper.

AB type

thread

3.5mm x 9.5mm

to

6.3mm x 50mm

SIZE RANGE

3.5mm x 9.5mm

to

6.3mm x 50mm

Pan head

self tapper.

AB type

thread

Requires insert bit for installation/removal

Key wrench

SIZE RANGE

M3 x 10/

M4 x 8

to

M12 x 50

CSK

machine

screw

SIZE RANGE

M3 x 10/

M4 x 8

to

M12 x 60

Pan

head

machine

screw

All sizes - box quantity

100 pieces

6 LOBE PIN

Suitable for higher torque applications, these have a central pin within the 6 lobe recess.

Requires matching insert bit for installation and removal. Standard in machine and self

tapping screws. Manufactured in A2 stainless steel.

CLUTCH HEAD

Operates in a clockwise motion only, using standard slotted screwdriver. No specialist

tools required. Manufactured in BZP hardened steel (woodscrews) or A2 stainless

(self tappers).

CSK self

tapper.

AB type

thread

Button head

self tapper.

AB type

thread

CSK

machine

screw

Button

head

machine

screw

CSK

woodscrew.

Twinthread

CSK self

tapper.

AB type

thread

Round

head self

tapper.

AB type

thread

SIZE RANGE

SIZE RANGE

SIZE RANGE

SIZE RANGE

SIZE RANGE

SIZE RANGE

SIZE RANGE

2.9mm x 13mm

to

5.5mm x 75mm/

6.3mm x 50mm

3.5mm x 13mm/

4.2mm x 9.5mm

To

5.5mm x 75mm/

6.3mm x 50mm

M3 x 6

to

M10 x 80

M3 x 6

to

M8 x 100/

M10 x 80

No 6 x 3/4”

to

No 12 x 3”

3.5mm x 19mm/

4.2mm x 13mm

To

4.8mm x 50mm

3.5mm x 25mm

to

6.3mm x 75mm

Requires insert bit for installation/removal

Key wrench

All sizes - box quantity

100 pieces

All sizes - box quantity

100 pieces

ONE WAY POZIDRIVE

One way motion only, using standard pozi screwdriver or bit.

Manufactured in BZP hardened steel

CSK

woodscrew.

Twinthread

CSK

machine

screw

Button

head

machine

screw

SHEAR NUT

High security permanent nut fastening. Hex part of nut shears off at predetermined

torque (only cone part is threaded) leaving tamper resistant cone.

No specialist tool required—use standard spanner or socket. Manufactured in

galvanised mild steel, BZP mild steel or stainless steel. See tables.

Size M6 M8 M10 M12 M16 M20

Shear

Torque

lb/ft 5-9 10-15 23-28 38-44 54-60 72-82

nm 7-14 14-20 31-38 52-60 74-82 100-113

SIZE RANGE

SIZE RANGE

SIZE RANGE

BZP mild steel

A/F (mm) 14 16 19 22 27 32

M4 x 12

to

M6 x 40

All sizes - box quantity 100 pieces

3.5mm x 19mm/

4.2mm x 13mm

To

5.5mm x 75mm

M4 x 12

to

M8 x 50

Size M8 M10 M12 M16 M20

Shear

Torque

lb/ft 10-15 23-28 38-44 54-60 72-82

nm 14-20 31-38 52-60 74-82 100-113

PERMANENT NUT

Unique, patented high torque security drive nut. Can be re-torqued but not removed.

Removable version also available. Requires matching tool for installation.

Material as shown in table

M5 M6 M8 M10 M12

BZP Steel x x x x x

Galvanised Steel x x x x

A2 Stainles Steel x x x x x

Galvanised mild steel

A2 stainless steel

A/F (mm) 16 19 22 27 32

Size M6 M8 M10 M12 M16 M20

Shear

Torque

lb/ft 5-9 10-15 23-28 38-44 54-60 72-82

nm 7-14 14-20 31-38 52-60 74-82 100-113

A/F (mm) 14 16 19 22 27 32

Tool required for installation

All sizes - box quantity

100 pieces

All sizes - box quantity

100 pieces

54

01279 656 189 01279 658 891 sales@indifit.co.uk


BUTTON CLIPS

4 Quick and easy locking of sliding, adjusting tubes. Button clip locates in inner tube,

button “clicks” into hole in outer tube.

4 Manufactured from BS1449 CS70 heat treated and chemically blacked steel

STRIP

WIDTH

STRIP

THICKNESS A B C BUTTON DIA PART NO

6.3mm 0.5mm 32.8mm 32.8mm 8.9mm 5.7mm ABC063

9.5mm 0.7mm 41.0mm 41.4mm 8.9mm 7.9mm ABC095

A

CIRCLIPS

4 Circlips—internal and external in many patterns to suit shaft diameters

from 1.0mm to 48mm.

B

C

ACIR

ABC

R CLIPS

4 “R” retaining clips manufactured from zinc plated steel

ACR

WIRE DIA OVERALL LENGTH PART NO

1.2mm 21.0mm ACR012

2.0mm 43.0mm ACR200

2.5mm 45.0mm ACR250

3.0mm 54.0mm ACR300

3.5mm 67.0mm ACR350

4.0mm 75.0mm ACR400

BUTTON CLIPS - CIRCLIPS - R CLIPS - CLEVIS PINS

4 Min quantities may apply—please call for details.

5.0mm 107.0mm ACR500

4 Boxes of assorted sizes can be supplied to order.

6.0mm 117.0mm ACR600

7.0mm 170.0mm ACR700

CLEVIS PINS

These provide a simple and effective method of connecting drives and linkages where a

certain amount of angular rotation is required. Being comparatively simple and sturdy,

and requiring no special tooling for insertion, they lend themselves readily to both manual

and automatic assemblies.

APCL

A Clevis Pin is a solid metal cylinder, with or without a head, with or without a drilled cross

hole (to take a Split Cotter Pin), or a groove (for a Retaining Pin or Circlip).

Standard pattern (as shown) size range from imperial 3/16 ” dia x 1/2” to 5/8” dia x 1.3/8”

or metric 5mm dia x 40mm to 10mm dia x 50mm.

BOX QUANTITIES NORMALLY 100 PIECES.

01279 656 189 01279 658 891 sales@indifit.co.uk

55


TOOL CLIPS / LINCH PINS / WIRE HOOKS / NYLON BUSHES

LINCH, PIPE AND SHAFT LOCKING PINS

“Apple” pattern

Mild steel pin with spring steel ring.

Pin size range 4.5mm dia x 32 to 12mm dia x 45.

Box quantities 100 per size

WIRE SUPPORT HOOKS

V HOOK

S HOOK

“Pear” pattern

4 For suspending of product whilst powder coating, spray painting or finishing

4 Manufactured from copper drawn wire, and can be re-used time and time again

C HOOK

90 DEG HOOK

NYLON FLANGED BUSHES

4 Suitable for use as bearings in pivoting applications and for

fastener insulators

4 Standard material nylon 6, which is “self lubricating” and highly

resistant to aggressive environments and most chemicals

d1

d2

APLI

TOOL CLIP

Narrow base

PART NO d1 D d2 H h

NB029/016/052030 2.9 5.2 1.6 3.0 1.0

NB029/021/052030 2.9 5.2 2.1 3.0 1.0

NB029/016/063030 2.9 6.3 1.6 3.0 1.0

NB029/021/063020 2.9 6.3 2.1 2.0 0.8

NB032/016/052030 3.2 5.2 1.6 3.0 1.0

NB032/021/052030 3.2 5.2 2.1 3.0 1.0

NB033/021/060025 3.3 6.0 2.1 2.5 1.0

NB033/016/060030 3.3 6.0 1.6 3.0 1.0

NB033/021/060030 3.3 6.0 2.1 3.0 1.0

NB033/024/060030 3.3 6.0 2.4 3.0 1.0

NB033/026/060030 3.3 6.0 2.6 3.0 1.0

NB035/028/051020 3.5 5.1 2.8 2.0 0.8

NB035/016/051020 3.5 5.1 1.6 2.0 0.8

NB035/021/051020 3.5 5.1 2.1 2.0 0.8

NB035/024/051020 3.5 5.1 2.4 2.0 0.8

NB035/026/051020 3.5 5.1 2.6 2.0 0.8

NB035/021/061020 3.5 6.1 2.1 2.0 0.8

NB035/024/061020 3.5 6.1 2.4 2.0 0.8

NB035/026/061020 3.5 6.1 2.6 2.0 0.8

NB035/028/061020 3.5 6.1 2.8 2.0 0.8

NB038/021/061020 3.8 6.1 2.1 2.0 0.8

NB038/024/061020 3.8 6.1 2.4 2.0 0.8

NB038/026/061020 3.8 6.1 2.6 2.0 0.8

Wide base

Manufactured from high carbon spring steel with standard finish BZP.

Other finishes to order.

To suit shaft diameters 6mm to 76mm dia. 6—16mm box qty 250

19-32mm box qty 100 38—76mm box qty 50.

AWH

LENGTH 1.2 dia 1.5 dia 2.0 dia 2.5 dia 3.0 dia 4.0 dia 5.0 dia 6.0 dia 8.0 dia 10.0 dia

50mm X X X X X X X X

75mm X X X X X X X X

100mm X X X X X X X X X X

150mm X X X X X X X X X X

200mm X X X X X X X X X X

250mm X X X X X X X X X X

300mm X X X X X X X X X X

350mm X X X X X X X X X X

400mm X X X X X X X X X X

450mm X X X X X X X X X X

500mm X X X X X X X X X

550mm X X X X X X X X X

600mm X X X X X X X X X

700mm X X X X X X X X X

800mm X X X X X X X X X

900mm X X X X X X X X X

Minimum pack—1,000 per size

ATO

NB

PART NO d1 D d2 H h

NB038/028/061020 3.8 6.1 2.8 2.0 0.8

NB038/031/061020 3.8 6.1 3.1 2.0 0.8

NB039/021/100030 3.9 10.0 2.1 3.0 1.3

NB039/024/100030 3.9 10.0 2.4 3.0 1.3

NB039/026/100030 3.9 10.0 2.6 3.0 1.3

NB039/028/100030 3.9 10.0 2.8 3.0 1.3

NB039/031/100030 3.9 10.0 3.1 3.0 1.3

NB040/021/062030 4.0 6.2 2.1 3.0 1.3

NB040/024/062030 4.0 6.2 2.4 3.0 1.3

NB040/026/062030 4.0 6.2 2.6 3.0 1.3

NB040/031/062030 4.0 6.2 3.1 3.0 1.3

NB043/021/074030 4.3 7.4 2.1 3.0 1.3

NB043/024/074030 4.3 7.4 2.4 3.0 1.3

NB043/026/074030 4.3 7.4 2.6 3.0 1.3

NB043/028/074030 4.3 7.4 2.8 3.0 1.3

NB043/031/074030 4.3 7.4 3.1 3.0 1.3

NB043/036/074030 4.3 7.4 3.6 3.0 1.3

NB047/021/079030 4.7 7.9 2.1 3.0 1.3

NB047/024/079030 4.7 7.9 2.4 3.0 1.3

NB047/026/079030 4.7 7.9 2.6 3.0 1.3

NB047/028/079030 4.7 7.9 2.8 3.0 1.3

NB047/031/079030 4.7 7.9 3.1 3.0 1.3

NB047/036/079030 4.7 7.9 3.6 3.0 1.3

56

01279 656 189 01279 658 891 sales@indifit.co.uk


NYLON FLANGED BUSHES CONTINUED...

d1

d2

SIZE YOU

NEED NOT

SHOWN?

Other

intermediate

sizes are

available

- PLEASE

ENQUIRE

TOLERANCES (items in italics only)

PART NO d1 D d2 H h

NB049/021/100030 4.9 10.0 2.1 3.0 1.3

NB049/024/100030 4.9 10.0 2.4 3.0 1.3

NB049/026/100030 4.9 10.0 2.6 3.0 1.3

NB049/028/100030 4.9 10.0 2.8 3.0 1.3

NB049/036/100030 4.9 10.0 3.6 3.0 1.3

NB049/042/100030 4.9 10.0 4.2 3.0 1.3

NB059/021/100030 5.9 10.0 2.1 3.0 1.3

NB059/024/100030 5.9 10.0 2.4 3.0 1.3

NB059/026/100030 5.9 10.0 2.6 3.0 1.3

NB059/028/100030 5.9 10.0 2.8 3.0 1.3

NB059/031/100030 5.9 10.0 3.1 3.0 1.3

NB059/036/100030 5.9 10.0 3.6 3.0 1.3

NB059/042/100030 5.9 10.0 4.2 3.0 1.3

NB059/052/100030 5.9 10.0 5.2 3.0 1.3

NB063/031/095030 6.3 9.5 3.1 3.0 1.3

NB063/036/095030 6.3 9.5 3.6 3.0 1.3

NB063/052/095030 6.3 9.5 5.2 3.0 1.3

NB063/031/130030 6.3 13.0 3.1 3.0 1.3

NB063/036/130030 6.3 13.0 3.6 3.0 1.3

NB063/042/130030 6.3 13.0 4.2 3.0 1.3

NB063/052/130030 6.3 13.0 5.2 3.0 1.3

NB069/031/150035 6.9 15.0 3.1 3.5 1.5

NB069/036/150035 6.9 15.0 3.6 3.5 1.5

NB069/042/150035 6.9 15.0 4.2 3.5 1.5

NB069/062/150035 6.9 15.0 6.2 3.5 1.5

NB079/031/150035 7.9 15.0 3.1 3.5 1.5

NB079/036/150035 7.9 15.0 3.6 3.5 1.5

NB079/052/150035 7.9 15.0 5.2 3.5 1.5

NB079/062/150035 7.9 15.0 6.2 3.5 1.5

NB080/060/100100 8.0 10.0 6.0 10.0 2.0

NB089/036/150035 8.9 15.0 3.6 3.5 1.5

NB089/042/150035 8.9 15.0 4.2 3.5 1.5

NB089/052/150035 8.9 15.0 5.2 3.5 1.5

NB089/062/150035 8.9 15.0 6.2 3.5 1.5

NB089/082/150035 8.9 15.0 8.2 3.5 1.5

NB099/031/150035 9.9 15.0 3.1 3.5 1.5

d2 min/max d2 min/max d1 min/max d1 min/max

6.0 +0.05/+0.30 26.0 +0.05/+0.61 8.0 +0.16/+0.20 30.0 +0.00/+0.06

8.0 +0.07/+0.32 28.0 +0.29/+0.93 10.0 +0.07/+0.26 32.0 +0.00/+0.87

10.0 +0.14/+0.40 30.0 +0.27/+1.05 12.0 +0.14/+0.28 33.0 -0.2/+0.72

12.0 +0.21/+0.45 32.0 +0.23/+1.22 14.0 +0.03/+0.37 36.0 -0.12/+0.75

13.0 +0.08/+0.23 33.0 +0.39/+0.74 16.0 +0.07/+0.23 38.0 +0.05/+0.56

14.0 +0.04/+0.31 36.0 +0.25/+0.89 17.0 +0.16/+0.32 40.0 +0.10/+0.60

15.0 +0.00/+0.34 38.0 +0.04/+0.68 18.0 +0.11/+0.30 44.0 +0.40/+0.92

16.0 +0.12/+0.41 40.0 +0.23/+0.94 20.0 -0.01/+0.31 45.0 +0.30/+0.70

18.0 +0.21/+0.29 42.0 +0.21/+0.74 22.0 +0.05/+0.57 48.0 +0.00/+0.90

20.0 +0.16/+0.56 45.0 +0.16/+1.08 24.0 -0.01/-0.09 50.0 +0.10/+0.80

22.0 +0.26/+0.63 48.0 +0.58/+0.95 25.0 -0.10/+0.56 56.0 -0.37/+0.81

24.0 +0.24/+0.59 50.0 +0.53/+1.03 26.0 +0.05/+0.81 60.0 +0.14/+1.22

25.0 +0.21/+0.85 28.0 -0.01/+0.12

PART NO d1 D d2 H h

NB099/036/150035 9.9 15.0 3.6 3.5 1.5

NB100/060/150080 10.0 15.0 6.0 8.0 1.5

NB100/060/150100 10.0 15.0 6.0 10.0 1.5

NB101/081/142125 10.1 14.2 8.1 12.5 2.5

NB104/082/180050 10.4 18.0 8.2 5.0 1.0

NB109/031/180040 10.9 18.0 3.1 4.0 1.5

NB109/036/180040 10.9 18.0 3.6 4.0 1.5

NB109/042/180040 10.9 18.0 4.2 4.0 1.5

NB109/052/180040 10.9 18.0 5.2 4.0 1.5

NB109/062/180040 10.9 18.0 6.2 4.0 1.5

NB109/082/180040 10.9 18.0 8.2 4.0 1.5

NB109/102/180040 10.9 18.0 10.2 4.0 1.5

NB110/080/160070 11.0 16.0 8.0 7.0 2.0

NB119/042/180040 11.9 18.0 4.2 4.0 1.5

NB119/052/180040 11.9 18.0 5.2 4.0 1.5

NB119/082/180040 11.9 18.0 8.2 4.0 1.5

NB119/102/180040 11.9 18.0 10.2 4.0 1.5

NB125/102/210050 12.5 21.0 10.2 5.0 1.0

NB120/080/160060 12.0 16.0 8.0 6.0 2.0

NB120/080/160120 12.0 16.0 8.0 12.0 2.0

NB120/100/160060 12.0 16.0 10.0 6.0 2.0

NB120/100/160120 12.0 16.0 10.0 12.0 2.0

NB129/102/190035 12.9 19.0 10.2 3.5 1.5

NB138/122/250040 13.8 25.0 12.2 4.0 2.0

NB140/080/200100 14.0 20.0 8.0 10.0 2.0

NB140/080/200120 14.0 20.0 8.0 12.0 2.0

NB140/100/200100 14.0 20.0 10.0 10.0 2.0

NB140/100/200120 14.0 20.0 10.0 12.0 2.0

NB140/120/200100 14.0 20.0 12.0 10.0 2.0

NB140/120/200120 14.0 20.0 12.0 12.0 2.0

NB148/122/250040 14.8 25.0 12.2 4.0 2.0

NB150/122/240050 15.0 24.0 12.2 5.0 1.2

NB158/142/250040 15.8 25.0 14.2 4.0 2.0

NB159/112/222127 15.9 22.2 11.2 12.7 3.2

NB160/100/200100 16.0 20.0 10.0 10.0 2.0

NB160/100/200120 16.0 20.0 10.0 12.0 2.0

NB160/120/200100 16.0 20.0 12.0 10.0 2.0

NB160/120/200120 16.0 20.0 12.0 12.0 2.0

NB170/130/240200 17.0 24.0 13.0 20.0 4.0

NB170/140/240200 17.0 24.0 14.0 20.0 4.0

NB178/142/250040 17.8 25.0 14.2 4.0 2.0

NB178/162/250040 17.8 25.0 16.2 4.0 2.0

NB180/100/240200 18.0 24.0 10.0 20.0 4.0

NB180/120/240200 18.0 24.0 12.0 20.0 4.0

NB190/100/220400 19.0 22.0 10.0 40.0 5.5

NB190/100/220340 19.0 22.0 10.0 34.0 5.0

NB190/162/230250 19.0 23.0 16.2 25.0 1.0

NB190/162/230250 19.0 23.0 16.2 25.0 1.0

NB200/130/280200 20.0 28.0 13.0 20.0 4.0

NB200/140/280200 20.0 28.0 14.0 20.0 4.0

NB200/150/280200 20.0 28.0 15.0 20.0 4.0

NB200/160/280150 20.0 28.0 16.0 15.0 2.0

NB200/160/280200 20.0 28.0 16.0 20.0 4.0

NB200/140/300200 20.0 30.0 14.0 20.0 4.0

NB200/140/300240 20.0 30.0 14.0 24.0 2.0

NB200/150/300200 20.0 30.0 15.0 20.0 4.0

NB200/160/300200 20.0 30.0 16.0 20.0 4.0

NB

PART NO d1 D d2 H h

NB220/120/300200 22.0 30.0 12.0 20.0 4.0

NB220/140/300200 22.0 30.0 14.0 20.0 4.0

NB220/160/300150 22.0 30.0 16.0 15.0 2.0

NB220/160/300200 22.0 30.0 16.0 20.0 4.0

NB240/200/300150 24.0 30.0 20.0 15.0 2.0

NB250/150/300200 25.0 30.0 15.0 20.0 4.0

NB250/160/300200 25.0 30.0 16.0 20.0 4.0

NB250/180/300200 25.0 30.0 18.0 20.0 4.0

NB250/200/300150 25.0 30.0 20.0 15.0 2.0

NB250/200/300200 25.0 30.0 20.0 20.0 4.0

NB280/200/300570 28.0 30.0 20.0 57.0 4.0

NB280/200/340200 28.0 34.0 20.0 20.0 4.0

NB280/220/340200 28.0 34.0 22.0 20.0 3.0

NB300/200/360200 30.0 36.0 20.0 20.0 3.0

NB300/220/360240 30.0 36.0 22.0 24.0 4.0

NB300/250/360200 30.0 36.0 25.0 20.0 3.0

NB320/220/400240 32.0 40.0 22.0 24.0 4.0

NB320/250/400240 32.0 40.0 25.0 24.0 4.0

NB320/280/400300 32.0 40.0 28.0 30.0 4.0

NB320/300/400300 32.0 40.0 30.0 30.0 4.0

NB350/240/450240 35.0 45.0 24.0 24.0 4.0

NB350/250/450300 35.0 45.0 25.0 30.0 4.0

NB350/280/450300 35.0 45.0 28.0 30.0 4.0

NB350/320/450300 35.0 45.0 32.0 30.0 4.0

NB360/260/450240 36.0 45.0 26.0 24.0 4.0

NB360/320/450240 36.0 45.0 32.0 24.0 4.0

NB380/260/480240 38.0 48.0 26.0 24.0 4.0

NB380/300/480240 38.0 48.0 30.0 24.0 4.0

NB380/320/480240 38.0 48.0 32.0 24.0 4.0

NB400/280/500240 40.0 50.0 28.0 24.0 4.0

NB400/300/500240 40.0 50.0 30.0 24.0 4.0

NB400/320/500240 40.0 50.0 32.0 24.0 4.0

NB400/320/500300 40.0 50.0 32.0 30.0 4.0

NB400/330/500240 40.0 50.0 33.0 24.0 4.0

NB400/330/500300 40.0 50.0 33.0 30.0 4.0

NB400/360/500240 40.0 50.0 36.0 24.0 4.0

NB440/320/540400 44.0 54.0 32.0 40.0 5.0

NB440/360/540400 44.0 54.0 36.0 40.0 5.0

NB440/380/540400 44.0 54.0 38.0 40.0 5.0

NB440/400/540400 44.0 54.0 40.0 40.0 5.0

NB480/360/580400 48.0 58.0 36.0 40.0 5.0

NB480/380/580400 48.0 58.0 38.0 40.0 5.0

NB480/400/580400 48.0 58.0 40.0 40.0 5.0

NB480/420/580400 48.0 58.0 42.0 40.0 5.0

NB500/380/600400 50.0 60.0 38.0 40.0 5.0

NB500/400/600400 50.0 60.0 40.0 40.0 5.0

NB500/420/600400 50.0 60.0 42.0 40.0 5.0

NB560/400/700400 56.0 70.0 40.0 40.0 5.0

NB560/420/700400 56.0 70.0 42.0 40.0 5.0

NB560/450/700400 56.0 70.0 45.0 40.0 5.0

NB560/480/700400 56.0 70.0 48.0 40.0 5.0

NB560/500/700400 56.0 70.0 50.0 40.0 5.0

NB560/500/700500 56.0 70.0 50.0 50.0 5.0

NB600/450/700400 60.0 70.0 45.0 40.0 5.0

NB600/480/700400 60.0 70.0 48.0 40.0 5.0

NB600/500/700400 60.0 70.0 50.0 40.0 5.0

NB600/500/700500 60.0 70.0 50.0 50.0 5.0

NYLON BUSHES

01279 656 189 01279 658 891 sales@indifit.co.uk

57


PLASTIC WASHERS / SPACERS

PLASTIC SPACERS - NYLON / HDPE

Nylon 66 parts ideal as self-lubricating bearings

Black high density polyethylene (HDPE) ideal for spacers/packing

PART NAT BLACK “A” “B” “C”

NO NYLON HDPE MM MM MM

NS032/08030 X 3.2 8.0 3.0

NS043/08025 X 4.3 8.0 2.5

NS043/08030 X 4.3 8.0 3.0

NS043/08050 X 4.3 8.0 5.0

NS043/08100 X 4.3 8.0 10.0

NS043/08125 X X 4.3 8.0 12.5

NS043/08150 X 4.3 8.0 15.0

NS043/08175 X X 4.3 8.0 17.5

NS043/08200 X 4.3 8.0 20.0

NS052/08050 X 5.2 8.0 5.0

NS053/08175 X 5.3 8.0 17.5

NS053/10030 X 5.3 10.0 3.0

NS053/10075 X X 5.3 10.0 7.5

NS053/10100 X X 5.3 10.0 10.0

NS052/10200 X 5.2 10.0 20.0

NS052/10250 X 5.2 10.0 25.0

NS063/10050 X X 6.3 10.0 5.0

NS063/10075 X 6.3 10.0 7.5

NS062/10100 X X 6.2 10.0 10.0

NS063/10125 X X 6.3 10.0 12.5

NS062/10150 X 6.2 10.0 15.0

NS062/10175 X 6.2 10.0 17.5

NS063/10200 X X 6.3 10.0 20.0

NS062/10300 X 6.2 10.0 30.0

NS064/12150 X 6.4 12.0 15.0

NS064/12175 X 6.2 12.0 17.5

PART NAT BLACK “A” “B” “C”

NO NYLON HDPE MM MM MM

NS064/12300 X 6.4 12.0 30.0

NS062/15025 X 6.2 15.0 2.5

NS064/15030 X 6.4 15.0 3.0

NS062/15040 X 6.2 15.0 4.0

NS062/15050 X 6.2 15.0 5.0

NS062/15075 X 6.2 15.0 7.5

NS062/15100 X 6.2 15.0 10.0

NS062/15125 X 6.2 15.0 12.5

NS064/15150 X X 6.4 15.0 15.0

NS062/15175 X 6.2 15.0 17.5

NS062/15200 X 6.2 15.0 20.0

NS082/12030 X X 8.2 12.0 3.0

NS082/12050 X X 8.2 12.0 5.0

NS082/12075 X 8.2 12.0 7.5

NS082/12100 X 8.2 12.0 10.0

NS082/12125 X X 8.2 12.0 12.5

NS082/12150 X 8.2 12.0 15.0

NS082/12175 X 8.2 12.0 17.5

NS082/12250 X 8.2 12.0 25.0

NS082/20025 X 8.2 20.0 2.5

NS082/20030 X 8.2 20.0 3.0

NS082/20050 X 8.2 20.0 5.0

NS082/20075 X 8.2 20.0 7.5

NS082/20100 X 8.2 20.0 10.0

NS082/20125 X 8.2 20.0 12.5

NS082/20150 X X 8.2 20.0 15.0

NS082/20200 X 8.2 20.0 20.0

NS104/20025 X X 10.4 20.0 2.5

NS102/20050 X 10.2 20.0 5.0

NS102/20075 X 10.2 20.0 7.5

NS102/20100 X 10.2 20.0 10.0

PART NAT BLACK “A” “B” “C”

NO NYLON HDPE MM MM MM

NS102/20125 X 10.2 20.0 12.5

NS102/20250 X X 10.2 20.0 25.0

NS102/20300 X 10.2 20.0 30.0

NS102/25025 X 10.2 25.0 2.5

NS102/25050 X 10.2 25.0 5.0

NS102/25075 X 10.2 25.0 7.5

NS104/25100 X X 10.4 25.0 10.0

NS102/25125 X 10.2 25.0 12.5

NS102/25150 X 10.2 25.0 15.0

NS102/25250 X 10.2 25.0 25.0

NS102/25300 X 10.2 25.0 30.0

NS128/25050 X 12.8 25.0 5.0

NS128/25075 X 12.8 25.0 7.5

NS128/25100 X 12.8 25.0 10.0

NS128/25150 X 12.8 25.0 15.0

NS128/25175 X 12.8 25.0 17.5

NS128/25200 X 12.8 25.0 20.0

NS128/25250 X 12.8 25.0 25.0

NS130/25050 X 13.0 25.0 5.0

MANY MORE SIZES

AVAILABLE

WE CAN SUPPLY MANY MORE

COMBINATIONS OF ID, OD

AND LENGTH IN NYLON AND/

OR HDPE—PLEASE ENQUIRE

FOR DETAILS. PLEASE NOTE -

NON-PREFERRED ITEMS MAY

BE SUBJECT TO MINIMUM

QUANTITIES

NYLON WASHERS

4 Ideal for use as spacers, to cushion or insulate

4 Standard material: Nylon 66 natural / black - some sizes HDPE black

PART A B C

NO MM MM MM

PART A B C

NO MM MM MM

PART A B C

NO MM MM MM

NW022/05003 2.2 5.0 0.3

NW064/12016 6.4 12.0 1.6

NW130/37030 13.0 37.0 3.0

NW027/06005 2.7 6.0 0.5

NW064/18015 6.4 18.0 1.5

NW150/28025 15.0 28.0 2.5

NW032/07005 3.2 7.0 0.5

NW074/14016 7.4 14.0 1.6

NW170/30030 17.0 30.0 3.0

NW043/08005 4.3 8.0 0.5

NW084/15016 8.4 15.0 1.6

NW170/50030 17.0 50.0 3.0

NW043/09008 4.3 9.0 0.8

NW084/16016 8.4 16.0 1.6

NW190/30025 19.0 30.0 2.5

NW043/12010 4.3 12.0 1.0

NW084/24020 8.4 24.0 2.0

NW200/56040 20.0 56.0 4.0

NW053/10010 5.3 10.0 1.0

NW105/18016 10.5 18.0 1.6

NW210/34030 21.0 34.0 3.0

NW053/15012 5.3 15.0 1.2

NW054/12015 5.4 12.0 1.5

NW064/11016 6.4 11.0 1.6

NW105/20020 10.5 20.0 2.0

NW105/30025 10.5 30.0 2.5

NW130/24025 13.0 24.0 2.5

NW210/37030 21.0 37.0 3.0

NW230/39030 23.0 39.0 3.0

NW250/44040 25.0 44.0 4.0

NW280/50040 28.0 50.0 4.0

MANY MORE

INTERMEDIATE SIZES AVAILABLE

If you do not see the size you require -

ASK! We can probably supply it!

NW310/56040 31.0 56.0 4.0

58

01279 656 189 01279 658 891 sales@indifit.co.uk


DO YOU NEED SPECIAL SIZED

WASHERS OR GASKETS?

By ingenious yet simple tooling methods,

special sizes of washers, discs and gaskets can

be produced exactly to your specification in a

multiple of materials.

Hundreds of sizes are already available from

previous tooling—if we cannot cater for the

exact size needed, then specific tooling can

usually be produced within 7-10 days, with

production immediately after.

Small runs are no problem—and are made

economical by our low part-tool-charges.

All we need in order to quote is a rough sketch

of the part needed, or for simple washers/discs,

purely the dimensions, thickness and material

required.

The following materials are available

(gaskets in non-metallic only):

• SMALL QUANTITIES WELCOMED

• Delivery usually 7-10 days

• Wide choice of materials

• Self-adhesive available in some materials

ACETAL

ALUMINIUM

BRASS

BUTYL

CNAF

COPPER

CORK

DELRIN

ELEPHANTIDE

EPDM

FELT

FIBREBOARD

GASKET PAPER

LEAD

LEATHER

MELINEX

MILD STEEL

MILLBOARD

NEOPRENE

NITRILE

NYLON

NYLATRON

PHOSPHUR BRONZE

POLYESTER

POLYPROPYLENE

POLYTHENE

POLYURETHANE

PRESSPAHN

PTFE

PVC

RUBBER

SILICONE

SPONGE

SRBF

SRBP

VITON

VULCANISED FIBRE

Fax your drawing for special

gaskets or washers to

01279 658 891

or email

sales@indifit.co.uk

Assortment kits

also available...

Imperial copper washers

Imperial fibre washers

Metric copper washers

Metric fibre washers

01279 656 189 01279 658 891 sales@indifit.co.uk

59


THE INDEPENDENT COMPONENTS COMPANY

T 01279 656 189 F 01279 658 891

E sales@indifit.co.uk W www.indifit.co.uk

Indifit Limited, 36-37 Raynham Road Industrial Estate, Bishop’s Stortford, Hertfordshire, CM23 5PE

Designed and produced by i Designs Ltd • 01268 206123 • www.idesigns.ltd.uk

Hooray! Your file is uploaded and ready to be published.

Saved successfully!

Ooh no, something went wrong!
