cpp – Process technology for the chemical industry 02.2019

02-2019
10 COVER
CLEAR SIGNALS
FOR LNG
20 INDUSTRIAL INTERNET
WHEN EVERYONE SPEAKS
ETHERNET
38 FERTILISER
FLUIDISED BED SPRAY
GRANULATION
52 IN-LINE MEASUREMENT
NO DEAD SPACES AND
NO BLOCKAGES
PROCESS TECHNOLOGY FOR THE CHEMICAL INDUSTRY
WWW.CPP-NET.COM

SEPARATION
HOW CAN A CONTROL
SYSTEM ADD INTELLIGENCE
TO YOUR OPERATIONS?
METRIS addIQ CONTROL SYSTEMS
Metris addIQ control systems, part of
the ANDRITZ digital solutions offered
under the Metris technology brand,
enable users to maximize availability,
capacity, and quality while minimizing
costs for both new and existing
processes. The portfolio ranges from
smart sensors to collect all relevant
operational data, to sophisticated
data analytics to turn data into
relevant information, to augmented
reality that visualizes the information
for the operator. Whatever you
demand, may it be predictive
maintenance, process monitoring,
troubleshooting, long-term trending,
or any other automation challenge,
your ANDRITZ specialist will help you
to find the perfect solution.
Visit us at AchemAsia in Shanghai,
May 21-23, hall 7.1, booth F95!
Want to learn more?
Open the photo app on
your mobile, focus in the
QR code, click on the link
and get deeper insights.
ANDRITZ AG / Stattegger Strasse 18 / 8045 Graz / Austria / andritz.com/separation

cpp
EDITORIAL
First time in
Shanghai
Achemasia 2019 is setting new standards. Long before the event
opens on 21 May 2019 for three days in Shanghai, the booked
exhibition space already exceeds the final count for the 2016 event.
With about 400 exhibitors from some 20 countries, it will focus on
an exchange of experience between scientists and engineers as well
as between equipment suppliers and users. Achemasia is a prime
opportunity to discover more about current trends in the Chinese
market and see what the Chinese industry has to offer. Especially in
the area of digitalization, China is seen as a global leader and that
will soon show in the process industry as well.
Apart from the move to Shanghai, where Achemasia will take place
at the NECC for the first time, participants can look forward to a
couple more novelties: the International Expo and Innovation
Forum for Sustainable Chemical Production will cast a spotlight on
the latest technologies in this field. Making the process industry
more sustainable means using less resources and less energy; efficiency
in production processes is increased by implementing energy
recovery measures and by using better catalysts and optimized
equipment. It means designing processes from a holistic perspective
while making use of new digitalization and modelling approaches.
Our preview of Achemasia starts on page 30 with a very interesting
article from Andritz dealing with the so-called Metris technology,
an IIoT solution for solid / liquid separation equipment and systems
featuring advanced digital control. Thanks to this technology,
proactive measures to prevent shutdowns and improve monitoring
can become reality by applying smart sensors, big data analytics and
visualisation using both virtual and augmented reality.
CMX 2000
/// Inline mixer for rapid
and homogeneous
incorporation of powders
into liquids
IKA-Werke GmbH & Co. KG
Phone: +49 7633 831-0, Fax: +49 7633 831-98
eMail: process@ika.de
www.ikaprocess.com // IKAworldwide
Günter Eckhardt, Editor-in-Chief
cpp 02-2019 3

cpp CONTENTS 02-2019
10 Cover Linde is
building a medium-sized
natural gas liquefaction
plant near the Russian
Baltic Sea town of Portovaya.
Vegaflex 86 and
Ve gaswing 66 are ideal
for level measurement in
this application.
22 Every operator wants
to benefit from the added
value of cloud-based
evaluations. The Namur
NOA concept explains
how this is possible.
38 The waste-free production
of fertiliser from
phosphorus-containing
ashes using fluidised bed
spray granulation.
INSTRUMENTATION, CONTROL, AUTOMATION
10 COVER Clear signals for LNG
Vegaflex 86 – robust guided radar sensors ensure
measurement accuracy in LNG production
14 Get the most from your level measurement
Selecting the right measurement technology to
maximise operational efficiency
18 In-line sensors for bio processes
Monitoring critical process parameters in upstream
processes
FOCUS: IIOT IN CHEMICAL INDUSTRY
20 When everyone speaks Ethernet
Seamless communication from field to enterprise level
22 Implementation of the NOA concept
Security by design is mandatory
25 PRODUCTS
28 Valve island 4.0
High availability and safe shutdown in the
pharmaceutical industry
30 How separation processes profit from IIoT solutions
Intelligence for machine and process control
PROCESS ENGINEERING
36 Design software for mass transfer columns
Packings and trays
ENVIRONMENTAL ENGINEERING
38 Fertiliser from phosphorus-containing ashes
Waste-free process using fluidised bed spray
granulation
PLANTS, APPARATUS, COMPONENTS
44 Efficiency throughout the line
Dry vacuum systems for the centralisation
of vacuum supplies
46 More efficiency for asset management
Predictive and preventive maintenance
PHARMACEUTICAL ENGINEERING
48 Goodbye manual work
Automated particle measurement in the hot air tunnel
50 Modular mills adapted without specification sheets
From laboratory to process
52 No dead spaces and no blockages
In-line measurement technology instead of
instrumentation with tees
54 Microencapsulation of active ingredients
Electrostatic spray drying combines drying
and agglomeration
4 cpp 02-2019

46 The availability of
digital technologies
which enable predictive
maintenance brings
more efficiency in asset
management.
54 Using an electro -
static spray drying process,
sensitive pharmaceutical
ingredients can
be microencapsulated
especially gently.
OUR ENGINEERING IS
YOUR SYSTEM SOLUTION
Rapid delivery
Made in Germany
ISO 9001
COLUMNS
3 Editorial
4 Contents
6 News
33 Trade Fair Preview Achemasia 2019
40 Trade Fair Review Powtech 2019
57 PRODUCTS
58 Advertisers
58 Contact the Editors
58 Imprint
WWW.CPP-NET.COM
More news, facts, products and
solutions for the process technology
in the chemical industry can be found
on our Internet page!
www.cpp-net.com
