the project

Simplicity, robustness and elements performing
multiple functions. These along with a simple
response to the site and urban context are the
underlying principles of the Cylinders House,
a discreet yet powerful addition to the urban
landscape of the suburb of Salt in Northern NSW.
The mass of the building has been withdrawn
from the street edge, creating light, promoting
breezes, and consciously reducing the scale of the
streetscape. The carefully considered landscape,
rather than the building mass, becomes the
dominant element bordering the public realm.
The ‘U’ shaped plan and elevated floor level
relative to the street gives the occupants
substantial privacy whilst allowing a broad
outlook. The home uses courtyards to enhance
privacy and allow natural light and ventilation
and celebrates vibrancy of movement through
the visual connection of circulation around the
home with hallways and living areas bounding
and looking through the main external courtyard
space. This also increases the separation to the
homes opposite adding to the feeling of space
and openness within a tight urban context.
The simplicity extends to the building shape,
with a series of perforated boxes forming the
mass of the home. Each box is connected
to the other, with glazing typically providing
a lightness between elements. The glazing
also allows the expression of the edge - the
edge between internal and external and the
sharp edge of the cantilevered concrete roof.
The concrete roof performs multiple functions
from the practical of keeping out the rain,
allowing shading from the sun and providing
insulation, through to the aesthetic of the robust
industrial formed concrete ceiling, and allowing
the absolute simplicity of the edge. Similarly, the
filigree aluminium screens provide filtered light and
sun shading whilst providing privacy to the upper
level of the home. Selectively used timber along
with natural travertine flooring internally provides
a warmth and homeliness to this simple design.
Restraint was critical in the design and is
clearly evident in this finished home. It is seen
in the planning and massing, the materials
selections and detailing and through to the
highly considered and integrated landscape.
The home allows the family to feel connected
both with each other and with the surrounding
suburbs, but always on their own terms.
