Velleman - Sound & Light 2021 - EN

SOUND
& LIGHT
2021

Content
Cables
& Connectors
Effect
Machines
Lamps
4
8
10

Get to know our ‘Sound & light’ range and discover loads of
products such as lighting, sound products, effect machines, cables,
connectors and trusses. In this catalogue you will not only
find the newest products but also our absolute must-haves.
Discover the complete range on www.velleman.eu now and
offer your customers a versatile selection of products.
a must-have product
very interesting and essential product to
complement and broaden the range
a new product
recently added to the
product range
LED
& laser
Light
Sound
Stands
& Clamps
Truss
& Stages
12
16
19
27
30

Cables &
Connectors
Câble haut-Cca speaker wire
red/black - 2 x 1.50 Mm² - 300 m
colour: red - black • size: 2 x 1.50 mm² • inner
conductor: 0.19 mm x 48 x 2 • outer isolation: PVC
Ø 3.0 mm x 2 • conductor resistance: 20 Ohm/km
• voltage resistance: > 3 kV • isolation resistance: >
500 Mohm
HQLW12006
(!4BA32J-hcaaih!
Professional speaker wire
colour: red - black • size: 2 x 1.5 mm² • inner
conductor: 0.20 mm x 48 x 2 • outer isolation:
PVC Ø 2.8 mm x 2 • conductor resistance:
13 Ohm/km • voltage resistance: > 3 kV • isolation
resistance: > 500 Mohm • length: 100 m
2 x 1.50 mm² - HQPW10001
2 x 2.50 mm² - HQPW10002
2 x 4.00 mm² - HQPW10003
(!4BA32J-hcaijg!
Rean - phono plug (rca)
gold plated contacts
(!4BA32J-edcbhb!
NYS373-0 NYS373-2 NYS373-9
Neutrik - jack plug connector
male, 6.3 Mm, nickel
2-polig - NP2X • 3-polig - NP3X
(!4BA32J-dficgg!
Neutrik - 3.5 Mm plug
right angle
NTP3RC
(!4BA32J-dhdbjb!
Neutrik - jack plug connector
2-pin male, 6.3 Mm, 90°, nickel
NP2RCS
(!4BA32J-dgegej!
Neutrik - 3.5 Mm plug
right angle - black
NTP3RCB
(!4BA32J-dhdcah!
Rean - 3.5 Mm 3-pole plug
metal housing with crimp strain relief
NYS231
(!4BA32J-eedaeh!
4

Neutrik- xlr cable connector
silver plated, nickel
Code
NC3FXX
3-pin femalel
NC3MXX
NC5MX
3-pin male
5-pin male
Neutrik - speakon
2-pin female, black, >1000 w
NL2FX
(!4BA32J-dgedgg!
Neutrik - speakon
4-pin female, black, >1000 w
NL4FX
*!6B3B8H-aaaade!
Neutrik - speakon adapter
4-pin female - 4-pin female
NL4MXX
(!4BA32J-dgejga!
(!4BA32J-dficae!
Neutrik - xlr mounting connector
3-pin female, silver plated, nickel, d-size
NC3FD-LX
(!4BA32J-dfibib!
Neutrik - xlr mounting connector
3-pin male, silver plated, nickel, d-size
NC3MD-LX
Neutrik - reversible usb gender changer
(type usb a and usb b)
nickeled d housing
NA-USB
*!6B3B8H-aafaai!
Neutrik - xlr mounting connector
4-pin female, silver plated, nickel, d-size
NC4FD-LX
(!4BA32J-gibafa!
Neutrik - xlr
4-pin male, silver plated, d-size metal body
NC4MD-LX
(!4BA32J-dfideb!
Neutrik - powercon 3-pin mounting
blue, energized / power input
NAC3MPA
(!4BA32J-djdead!
Neutrik - ethercon
metal chassis housing with rear-mounted
standard rj45
NE-8-FD-P
(!4BA32J-dfidba!
Neutrik - speakon mounting plug
4-pin male, black, d-size
NL4MP
5

Patch cable
Code
info
PAC155
jack 6.35 mm
male
jack 6.35 mm
male
1 m
PAC156
PAC157
PAC158
jack 6.35 mm
male
jack 6.35 mm
male
jack 6.35 mm
male
jack 6.35 mm
male
jack 6.35 mm
male
jack 6.35 mm
male 90°
2 m
5 m
6 m
(!4BA32J-edhbah!
Jack cable
jack 6.35 Mm male to jack 6.35 Mm female -
mono - 5 m
PAC151
(!4BA32J-edghci!
Speaker cable
jack 6.35 Mm to jack 6.35 Mm - mono - 3 m - blue
3 m - PAC135 • 5 m - PAC136
Dmx cable
Code
info
Code
info
PAC105
PAC101
0,5 m
1 m
PAC103
PAC104
5 m
10 m
Neutrik - sealing cover
for xlr top female chassis nc3fdx-top
and nc5fdx-top
SCFDX-TOP
Patch cable set
jack 6.35 Mm male 90° to jack 6.35 Mm male 90°
- mono - 6 pcs
0,5 m - PAC125 • 1 m - PAC126
PAC102
2,5 m
Xlr cable
Code
info
PAC110
PAC111
PAC112
XLR female
XLR female
XLR female
Jack 6.35 mm
- mono
Jack 6.35 mm
- mono
Jack 6.35 mm
- mono
3 m
6 m
10 m
Xlr-rca cable
2 x xlr 3 pin to 2 x rca male - 1 m
PAC150
(!4BA32J-edhajb!
(!4BA32J-edgfhf!
Rca-jack cable
2 x rca male to jack 6.35 Mm - mono - 5 m
PAC118
PAC116-1
XLR male
Jack 6.35 mm
- mono
1,5 m
PAC116-2
XLR male
Jack 6.35 mm
- mono
3 m
PAC116
XLR male
Jack 6.35 mm
- mono
6 m
PAC120 XLR male XLR male 1 m
PAC121 XLR male XLR male 3 m
PAC122 XLR male XLR male 6 m
PAC123 XLR male XLR male 10 m
6
Jack cable
2 x jack 6.35 Mm to 2 x jack 6.35 Mm - mono - 5 m
PAC130
(!4BA32J-edgged!
Rca-jack cable
2 x rca male to jack 6.35 Mm - stereo - 6 m
PAC131

Disco
Lights
Mirror ball
individual mirrors: 10 x 10 mm • material: PVC and
mirror in real glass
Blacklight + holder
housing: metal • colour: black • power supply:
230 VAC 50 Hz
Code ø kg
VDL10MB2 ø 10 cm 0,19 kg
VDL20MB2 ø 20 cm 0,75 kg
VDL30MB2 ø 30 cm 1,40 kg
Code
VDL15UV
VDL20UV
VDL40UV
dimensions
15 W
500 x 110 x 60mm
20 W
670 x 110 x 60 mm
40 W
1250 x 145 x 60 mm
VDL50MB2 ø 50 cm 4,80 kg
(!4BA32J-gjfafh!
Coloured filter sheets
8 pcs
dimensions (per piece): 250 x 250 mm
HQCS00825
Mirror ball motor
220-240 v~ - black
max. 3 kg - 3 tpm - HQMB15001
max. 5 kg - 1.5 tpm - VDLMM8
max. 20 kg - 6 tpm- VDLMM9
(!4BA32J-hbhijg!
Pvc coated safety cable
max. Load 50 kg / 110 lb
(!4BA32J-eabggf!
max. 50 kg - VDLSC8N • max. 20 kg - VDLSC7N
Pin spot par36
blackpower supply: 230 Vac • lamp socket: G53 •
dimensions: Ø 120 x 165 mm • lamp: 4515 (not
incl.)
VLP36B
(!4BA32J-fhdcje!
7

Effect
Machines
Haze machine
power supply: 220-240 VAC 50/60 Hz • power
consumption: 600 W • fuse: F5A 250V • warmup
time: 3 min • output: ± 170 m³ / min • tank
capacity: 1.2 L • fluid consumption: 60 - 80 ml /
min • IP rating: IP20
HQHZ10001
(!4BA32J-gdhhed!
Haze machine
power supply: 220-240 VAC 50/60 Hz • power
consumption: 1000 W • fuse: F6A • warm-up time:
3 min • output: ± 225 m³ / min • tank capacity:
2.3 L • fluid consumption: 60 - 80 ml / min • IP
rating: IP20
HQHZ10002
(!4BA32J-gdhhfa!
Bubble machine
power supply: 3 VDC (adapter incl.) • battery: 2 x C
battery (not incl.) • motor: 5 rpm • capacity: 140 ml
• weight: 590 g • dimensions: 215 x 175 x 150 mm
HQPE10001
(!4BA32J-gdjeii!
Bubble machine 20 w
power supply: 12 VDC (adapter incl.) • motor:
5 rpm • capacity: 1 L • weight: 1.8 kg • dimensions:
235 x 253 x 244 mm
HQPE10002
(!4BA32J-ggeded!
Snow machine
power supply: 230 VAC 50 Hz • power
consumption: 800 W • output: 30 m³/min • tank
capacity: 1.2 L • dimensions: 310 x 175 x 238 mm •
weight: 2.85 kg
HQPE10003
(!4BA32J-ggcgeg!
Smoke and bubble machine
power supply: 230 VAC 50 Hz • power
consumption: 440 W • fuse: F7A • warm-up time:
± 2 min • output distance: ± 3 m • tank capacity:
0.8 L • IP rating: IP20
HQPE10015
(!4BA32J-haaeaj!
Wireless controller
power supply: •• transmitter: 1 x 12 V alkaline
A23 battery (incl.) • frequency: 433 Mhz • cable
length: 40 cm • weight: 0.1 kg • transmitter
distance: 30 m • dimensions: •• receiver: 90 x 50 x
28 mm •• transmitter: 63 x 39 x 16 mm
HQRC10001
(!4BA32J-gejggb!
Smoke machine
power supply: 220-240 VAC 50/60 Hz • power
consumption: 600 W • fuse: F4A • heating time:
3 min. • output: ± 283 m³ / min • tank capacity: 0.5 L
• fluid consumption: 60 - 80 ml / min • IP rating:
IP20
HQSM10001
(!4BA32J-gdhgic!
8

Smoke machine
power supply: 220-240 VAC 50/60 Hz • power
consumption: 1000 W • fuse: F6A • warm-up time:
3 min. • output: ± 424 m³ / min • tank capacity:
0.8 L • fluid consumption: 60 - 80 ml / min • IP
rating: IP20
HQSM10003
Smoke machine
power supply: 220-240 VAC 50/60 Hz • power
consumption: 1200 W • fuse: F7A • warm-up time:
6 min. • output: ± 849 m³ / min • tank capacity:
1.8 L • fluid consumption: 100 - 120 ml / min • IP
(!4BA32J-gdhhaf! rating: IP20 (!4BA32J-gdhhbc! rating: IP20 (!4BA32J-gggggi!
HQSM10004
Smoke machine
power supply: 230 VAC 50/60 Hz • power
consumption: 1200 W • fuse: F7A • warm-up time:
3 min • output: ± 3000 m³ / min • tank capacity:
1.8 L • fluid consumption: 450 - 600 ml / min • IP
HQSM10007
Low ice fog machine
power supply: 230 VAC 50 Hz • power
consumption: 420 W • warm-up time: 2 min
• tank capacity: 1.2 L • fluid consumption: 70 -
90 ml / min • output distance: 3 m • IP rating: IP20
HQSM10010
(!4BA32J-habbif!
Smoke machine
power supply: 230 VAC 50 Hz • fuse: F5AL 250 V
• power consumption: 400 W • output: ± 70 m³ /
min • tank capacity: 300 ml • fluid consumption:
60 - 80 ml / min
HQSM10011
(!4BA32J-gjibfh!
Smoke machine liquid
Code information l
VDLCL cleaning liquid 0.25 l
VDLSL1 Standard smoke liquid 1 l
VDLSL5 Standard smoke liquid 5 l
VDLSLH25 High-density smoke liquid 25 l
Disco light pack 3
(3 x VDLSL5 + 1 x VDLSL5 for free
+ 1 free bottle of cleaning liquid)
VDLPACK10
(!4BA32J-ehbjhc!
Promopack 3
(3 x VDLSL5 + 1 x VDLSL5 for free
+ 1 free bottle of fragrance)
VDLPACK3
(!4BA32J-dcdbad!
VDLSLH5 High-density smoke liquid 5 l
VDLSLHT5
Pro high-density smoke
liquid
5 l
Bubble liquid
1 l - VDLBL1 • 5 l - VDLBL5
(!4BA32J-ddeiea!
Standard snow liquid
content: 5 L
VDLSW5
(!4BA32J-dfhafe!
High-density hazer liquid
content: 5 l
VDLHLH5
(!4BA32J-ebadhh!
9

Lamps
Par spots
Code brand color
LAMPLRGB-SWS Sylvania PAR56 - for swimming pools 12 W 12 V RGB
LAMP36/2 HQ Power PAR36 30 W 6.4 V 3000 K
LAMP300/12SWPS Sylvania PAR56 - for swimming pools 300 W 12 V 2850 K
LAMP300P56MFL GE PAR56 300 W 240 V 3000 K
Halogen lamps
Code
brand
LAMPOS64627 Osram 100 W 12 V GZ6.35 50 h
LAMPOS64634 Osram 150 W 15 V GZ6.35 50 h
LAMP150/15 Philips 150 W 15 V G6.35 50 h
LAMP250/24ELC Philips 250 W 24 V GX5.3 50 h
LAMP250/24ELC5H Philips 250 W 24 V GX5.3 500 h
LAMP250ELC10HS Sylvania 250 W 24 V GX5.3 1000 h
10

Blacklight tubes
Code
LAMP04TBL 4 W 134 / 148 mm
LAMP06TBL 6 W 212 / 224 mm
LAMP08TBL 8 W 288 / 302 mm
LAMP20TBL 18/20 W 60 cm
LAMP40TBL/PH 36 W 120 cm
Mini led strobe lamp
e27 socket - 3 w
(!4BA32J-habicg!
HQPL11026 HQPL11027 HQPL11028
Code
Code
LAMP100/12
Halogen lamp philips 100w /
12v, fcr gy6.35, 3400K, 50h
LAMP500T/GE
Halogen lamp ge lighting
500w / 240v, gy9.5, T25 gcw
(88470)
LAMP1000T/GE
Halogen lamp tungsram
1000w / 230-240v, bi-plane
(ge 88457)
LAMP75ST2
Strobe lamp 75w for vdl75st
LAMP12GL
Spare bulb 12v/5w
LAMPOS64610 Hlx 50w / 12v, g6.35
LAMP250/24EHJ
Halogen lamp philips, 250w /
24v, ehj g6.35, 3400K, 50h
LAMPOS64625
Hlx 100w / 12v, gy6.35
LAMP300
Jdc 300w / 230v, gx6.35
LAMPOS64657
Evc 250w / 24v, g6.35, 300H
LAMP300/120OS
Jdc 300w / 120v, gx6.35
LAMP575HPL
Halogen lamp thungsram
hpl 575w / 240v long life
11

LED
Technology
Led bar
6 x 4 w rgbw 4-in-1 - dmx controlled
power supply: 100-240 VAC 50 Hz • power
consumption: 18 W • colour: black • light source:
6 x 4 W RGBW 4-in-1 LED • beam angle: 25° •
dimensions: 587 x 87 x 104 mm • weight: 1.7 kg
• power factor: 0.51 • max. linkout current: 10 A •
fuse: F1A 250 V
HQLB10001
(!4BA32J-gjchia!
Led bar- 6 x 3 w uv - dmx controlled
power supply: 100-240 VAC 50 Hz • power
consumption: 18 W • colour: black • light source:
6 x 3 W UV LED • beam angle: 25° • dimensions:
587 x 87 x 104 mm • weight: 1.6 kg • power factor:
0.48 • max. linkout current: 10 A • fuse: F1A 250 V
HQLB10002
(!4BA32J-gjciad!
Led bar- 6 x 6 w ww/cw - dmx controlled
power supply: 100-240 VAC 50/60 Hz • power
consumption: 28 W • colour: black • light source:
6 x 6 W 2700 K WW & 6500 K CW • beam angle:
25° • dimensions: 587 x 87 x 104 mm • weight:
1.7 kg • power factor: 0.46 • max. linkout current:
10 A • fuse: F1A 250 V
HQLB10003
(!4BA32J-gjciba!
Compact uv led par
54 x 10 mm
power supply: 100-240 VAC 50/60 Hz • power
consumption: 5 W • power factor: 0.4 • LEDs
in device: 54 x 10 mm • dimensions: 170 x 170 x
225 mm • weight: 750 g
HQLE10022
(!4BA32J-ghbcdf!
Mini mushroom 6 x 3 w rgbwa
power supply: 220-240 VAC 50/60Hz • power
consumption: 18 W • LEDs in device: 6 x 3 W
RGBWA • dimensions: 232 x 232 x 325 mm •
weight: 1.6 kg
HQLE10023
(!4BA32J-ghgiad!
Dual moonflower with wash effect
power supply: 100-240 VAC 50/60 Hz • power
consumption: 20 W • power factor: 0.49 • LEDs in
device: •• dual flower: 54 x 5 mm RGB (18 pcs red,
12 pcs green, 24 pcs blue) •• wash: 6 x 1 W RGB •
dimensions: 250 x 230 x 145 mm • weight: 1.3 kg
HQLE10025
(!4BA32J-ghbdeb!
Derby - laser - strobe effect
power supply: 100-240 VAC 50/60 Hz • power
consumption: 22 W • power factor: 0.51 • LEDs in
device: •• derby: 4 x 3 W RGBW •• strobe: 16 x 0.5 W
SMD white • laser in device: •• red: 112 mW •• green:
77.5 mW • DMX channel modes (4)
HQLE10026
(!4BA32J-ghbdij!
Derby - strobe dual effect
power supply: 100-240 VAC 50/60 Hz • power
consumption: 8 W • LEDs in device: •• derby:
3 x 3W RGB •• SMD LED: 14 x 0.5 W cold white •
dimensions: 230 x 195 x 130 mm • weight: 1.2 kg
HQLE10027
(!4BA32J-ghbdgf!
12

Quad led moonflower
in transparent housing
power supply: 12 VDC 1000 mA (adaptor incl.) •
power consumption: 30 W • LEDs in device: 128 x
5 mm 20 mA RGBA • dimensions: 300 x 240 x
120 mm
HQLE10030
Quatro fx
power supply: 100-240 VAC 50/60 Hz • power
consumption: 55 W • power factor: 0.47 • LEDs
in device: •• wash LED: 8 x 4 W RGBUV •• combo
LED: 6 x 3 W RGBWAUV •• SMD LED: 12 x 0.5 W
white • laser in device: •• red: 100 mW •• green:
(!4BA32J-ghbecg! 30 mW • dimensions: 315 x 250 (!4BA32J-gjaigb! x 328 mm
• weight: 1.2 kg (!4BA32J-gijghe!
HQLE10036
Led moonflower in transparent housing
power supply: 12 VDC 1000 mA (adaptor incl.) •
power consumption: 12 W • LEDs in device: 60 x
5 mm RGBWA • dimensions: 265 x 145 x 107 mm
HQLE10040
Dual led moonflower
in transparent housing
power supply: 12 VDC 1000 mA (adaptor incl.) •
power consumption: 12 W • LEDs in device: 114 x
5 mm RGBWA • dimensions: 300 x 240 x 120 mm
HQLE10045
Maxi mushroom 6 x 3 W RGBWA
power supply: 100-240 VAC 50/60 Hz • power
consumption: 15 W • LEDs in device: 6 x 3 W
RGBWA • dimensions: 279 x 282 x 304 mm •
(!4BA32J-gijggh! weight: 2.5 kg (!4BA32J-gjcddj! (without bracket) • weight: 0.3 (!4BA32J-gijhfj!
kg
HQLE10048
Compact 121
mini led par 9 x 1 w rgb + 3 x 1 w white
power supply: 12 VDC 1500 mA (adaptor incl.) •
power consumption: 15 W • colour: black • light
source: 12 x 1 W (3 x R, 3 x G, 3 x B, 3 x W) • beam
angle: 25° • dimensions: 120 x 120 x 90 mm
HQLP10001
Flat par - 6 X 3 W UV LED
power supply: 100-240 VAC 50/60 Hz • power
consumption: 20 W • colour: black • light source:
6 x 3 W UV LED • wavelength: 395 nm • beam
angle: 25° • dimensions: 250 x 240 x 150 mm
HQLP10006
Flat par - 5 X 3 W RGB + 1 UV LED
power supply: 100-240 VAC 50/60 Hz • power
consumption: 16 W • colour: black • light source: ••
5 x 3 W RGB 3-in-1 •• 1 x 3 W UV • beam angle: 25° •
(!4BA32J-gibfdb! dimensions: 250 x 240 x 150 (!4BA32J-gjcdbf! mm • weight: 1.2 kg
• dimensions: 300 x 280 x 160 (!4BA32J-gieihh!
mm • weight: 2 kg
HQLP10007
Showpar 12 x 12 RGBWAUV
power supply: 100-240 VAC 50/60 Hz • power
consumption: 50 W • colour: black • light source:
12 x 12 W RGBWAUV 6-in-1 LED • beam angle: 25°
HQLP10013
Showpar special fx - rgbw
power supply: 100-240 VAC 50/60 Hz • power
consumption: 65 W • power factor: 0.47 • colour:
black • light source: •• PAR: 9 x 4 W RGBW 4-in-
1 •• COB: 1 x 15 W RGBW •• SMD: 24 x 1 W white •
dimensions: 300 x 280 x 160 mm • weight: 2 kg
HQLP10014
Show pinpar rgbw
power supply: 100-240 VAC 50/60 Hz • power
consumption: 13.5 W • colour: black • light source:
1 x 15 W RGBW COB LED • beam angle: 5° •
dimensions: 250 x 163 x 101 mm • weight: 1.1 kg •
(!4BA32J-gidgde! power factor: 0.42 • fuse: F1A (!4BA32J-gjcihc! 250 V
• weight: 0.3 kg (!4BA32J-hahffc!
HQLP10021
Compact 110 - mini led par 10 W COB RGB
power supply: 12 VDC 1500 mA (adaptor incl.)
• power consumption: 10 W • colour: black •
light source: 1 x 10 W COB • beam angle: 25° •
dimensions: 120 x 120 x 90 mm (without bracket)
HQLP10026
13

Compact 111
mini led par 10 w cob uv
power supply: 12 VDC 1500 mA (adaptor incl.)
• power consumption: 16 W • colour: black •
light source: 1 x 16 W UV • beam angle: 25° •
dimensions: 120 x 120 x 90 mm (without bracket)
• weight: 0.3 kg
HQLP10027
Led battery uplighter 4 x RGBWA-UV
power supply: 100-240 VAC 50/60 Hz • power consumption:
18 W • beam angle: 20° • voltage: 12 VDC
(!4BA32J-hahfgj! • capacity: 4.4 Ah • dimensions: (!4BA32J-gjhfha! 144 x 144 x 185 mm 6x HQLP10031 - HQLP10031/6 (!4BA32J-hccgeh!
4 x 12 W - HQLP10031 • 6 x 12 W - HQLP10030
Flight-case with 6 x led battery uplighter
power supply: 100-240 VAC 50/60 Hz • beam
angle: 20° • voltage: 12 VDC •• capacity: 4.4 Ah •
dimensions case: 630 x 300 x 310 mm
6 x HQLP10030 - HQLP10030/6
Mini sniper - 60 w led moving head
power supply: 100-240 VAC 50/60 Hz • power
consumption: max. 40 W - pf 0.57 • dimensions:
215 x 205 x 290 mm
HQMH10005
Disco rgb fireball
power supply: 5 VDC 1 A (adaptor incl.) • LEDs in
device: 3 x 1 W RGB (3 in 1) • dimensions: Ø 215 x
(!4BA32J-gjaffh! 175 mm • weight: 820 g (!4BA32J-giicdd! dimensions: 220 x 140 x 100 mm (!4BA32J-giicea!
• weight: 400 g
HQPE10008
Multicolour led show projector
power supply: 5 VDC 1 A (adaptor incl.) • LEDs
in device: 41 pcs x 5 mm (9 x R, 16 x G, 16 x B) •
HQPE10009
Modular light organ with flower effect
power supply: 5 VDC 1000 mA (power supply
incl.) • LEDs: 1 x 20 mA LED per module (RGBY) •
dimensions: 345 x 130 x 245 mm • weight: 1.3 kg
HQPE11001
(!4BA32J-haedhh!
Modular light organ - 4 x 47 leds
power supply: 14 VDC 300 mA (PSU incl.) •
LEDs: 47 per module (1 x red, 1 x green, 1 x blue,
1 x yellow) • dimensions: 345 x 130 x 245 mm •
weight: 1.25 kg
VDLL4RL2
(!4BA32J-fjaehf!
Modular light organ - 6 x 47 leds
power supply: 14 VDC 300 mA (PSU incl.) •
LEDs: 47 per module (1 x red, 1 x green, 2 x blue,
1 x yellow, 1 x orange) • dimensions: 345 x 130 x
360 mm • weight: 1.8 kg
VDLL6RL2
(!4BA32J-fjaeic!
Mini white led strobe
24 leds - battery operated
power supply: 6 VDC (4 x AA battery, not incl.)
• working time: 5-7 h • dimensions: 125 x 85 x
55 mm (bracket not incl.) • weight: 218 g
HQPL10001
14
(!4BA32J-gdiaaj!
Home dj led dream magic ball
power supply: 5 VDC, 1A (adapter incl.) • power
consumption: 5 W • LEDs: 48 pcs 5 mm LEDs
(16 red, 16 green, 16 blue) • dimensions: Ø 130 x
42 mm • weight: 0.2 kg
VDLLUFCB
(!4BA32J-fjjjhd!
(!4BA32J-fjaeee!
Led beacon light
power supply: 14 VDC 300 mA (adaptor incl.) •
LEDs: 108 pcs • dimensions: Ø 143 x 182 mm
VDLLPLB1 VDLLPLO1 VDLLPLR1

Laser
Products
Laser module 1 mw
voltage: 3 V • current: 50 mA • wavelength:
650 nm • beam divergence: < 2 mrad • operating
temperature: -10 °C to +50 °C • dimensions: Ø
10.5 x 32.5 mm • weight: 15 g
DLU01
(!4BA32J-cibcgh!
Led water light
7 colours - 12 w (rgbw 4 in 1)
power supply: 5 VDC 1.2 A (adaptor incl.) • power
consumption: 6 W • light source: 4 x 3 W RGBW
LED • control range: < 10 m • dimensions: 117 x 91 x
51 mm • weight: 450 g
HQLE10028
(!4BA32J-gijfgi!
Mini laser light 100 mw
power supply: 5 V USB • laser class: 2 • laser power:
•• green: 0.3 mW (532 nm) •• red: 0.6 mW (663 nm)
• dimensions: 108 x 85 x 45 mm • weight: 0.18 kg
HQPE10007
(!4BA32J-gijhgg!
Mini pattern rg laser + 3 w led
power supply: 5 VDC 1A (adaptor incl.) • laser class:
3B • IP rating: IP20 • projection distance: 10-15 m
• LEDs in device: 1 x 3 W blue • laser power: ••
green: 175 mW (523 nm) •• red: 125 mW (658 nm) •
dimensions: 120 x 100 x 60 mm • weight: 325 g
HQPE10010
(!4BA32J-gjhfbi!
Super mini firefly laser
power supply: 5 VDC / 1A (adaptor incl.) • laser
class: 3B • laser power: •• green: 100 mW (532 nm)
•• red: 50 mW (660 nm) • dimensions: 95 x 90 x
80 mm • weight: 150 g
HQPE10011
(!4BA32J-hbgeig!
Laser pointer
abs - 1 mw - class 2
power supply: 2 x AAA-battery (incl.) • dimensions:
Ø 18 mm x 138 mm • weight: 24 g
MP1000
(!4BA32J-cibche!
15

Light
4-Way dmx splitter in compact housing
power supply: 100-240 VAC 50/60 Hz • power
consumption: 2 W • dimensions: 175 x 55 x
150 mm • weight: 1.3 kg
HQDB10001
(!4BA32J-gjjeee!
8-Way dmx splitter in compact housing
power supply: 100-240 VAC 50/60 Hz • power
consumption: 3.5 W • dimensions: 175 x 80 x
150 mm • weight: 1.6 kg
HQDB10002
(!4BA32J-haabea!
192-Channel dmx controller
MIDI signal: effective for memory banks and
chases • remote controls: blackout by MIDI input
signal • power supply: 9-12 VDC / 300 mA min.
(adapter incl.) • number of DMX channels: 192 •
maximum cable length: 100 m
VDPC145
(!4BA32J-dgijag!
192-Channel dmx controller with joystick
power supply: 9-12 VDC 500 mA • DMX in/out:
3-pin female/male XLR socket • MIDI in: 5-pin DIN
socket • dimensions: 19” x 134 mm (2U) x 85 mm •
weight: 2.7 kg
VDPC174
(!4BA32J-dgijca!
Daslight - dvc4 gold virtual dmx
controller with usb dmx interface
DMX connection: 1 x 3-pin XLR male socket
(input) and 1 x 3pin XLR female socket (output) •
standalone interface: HE10 connector
VDPDVC4GOLD
(!4BA32J-gecahf!
Daslight - dvc4 gzm virtual dmx
controller with usb-dmx interface
DMX connection: 1 x 3-pin XLR male socket
(input) and 1 x 3pin XLR female socket (output) •
standalone interface: HE10 connector
VDPDVC4GZM
(!4BA32J-gfgfjb!
Daslight - dvc fun controller
output channels: 128 • mode: limited • software:
DVC3, Daslight 4 • upgradable: yes • ethernet: no •
connector: mini usb • memory: 65 k • dry contact
ports: 8
VDPDVCFUN
(!4BA32J-gejfei!
Magic plasma light 8"
power supply: 12 VDC adaptor (incl.) • power
consumption: 24 W • dimensions: 200 x 200 x
280 mm
HQLE10019
16

Led party light chain
power supply: 230 VAC 50 Hz • socket type:
E27 (50 pcs) • IP rating: IP44
50 lampes / 25 m- HQPL11003
20 lampes / 10 m - HQPL11002
10 lampes / 5 m - HQPL11001
Led party light chain
with 20 coloured led lamps
power supply: 230 VAC 50 Hz • lamp
specifications: SMD 3528 - 7 LEDs - 0.6 W • total
(!4BA32J-gjhhcd! light chain length: 11 m (!4BA32J-gjhgaa! light chain length: 11 m (!4BA32J-gjhgbh!
HQPL11010
Led party light chain
with 20 warm white led lamps
power supply: 230 VAC 50 Hz • lamp
specifications: SMD 3528 - 7 LEDs - 0.6 W • total
HQPL11011
(!4BA32J-gjhgce!
Coloured led lamps (6pcs)
type: SMD 3528 • number of LEDs: 7 • power:
0.6 W (each lamp)
6 pièces - HQPL11020 • 10 pièces - HQPL11021
(!4BA32J-gjhgdb!
Warm white led lamps (6pcs)
type: SMD 3528 • number of LEDs: 7 • power (per
lamp): 0.6 W • colour: warm white
6 pièces - HQPL11022 • 10 pièces HQPL11023
Filament light bulb set
coloured glass - 4 pcs - red - green - blue - orange
• total nominal power: 4.5 W • nominal voltage
driver: 230 V~ • frequency: 50 Hz • fitting: E27
(!4BA32J-hcadbf!
type G45 - HQPL22033 • type A60 - HQPL22031
Filament light bulb set
clear glass - 4 pcs - red - green - blue • total
nominal power: 4.5 W • nominal voltage driver:
230 V~ • frequency: 50 Hz • fitting: E27
(!4BA32J-hcadcc!
type G45 - HQPL22032 • type A60 - HQPL22030
Led coaster
power supply: 2 x CR2032 lithium battery
(CR2032C, incl.) • LEDs: 2 x red, 2 x blue •
dimensions: 90 x 90 x 7mm
CLC7
(!4BA32J-ecieii!
Rgb led light ice bucket
LEDs: •• colour: RGB •• number: 12 •• size:
SMD5050 • power supply: 4 x 1.5 V AA batteries
(not incl.) • dimensions: Ø 230 x 240 mm • weight:
600 g
CLIB3
(!4BA32J-gbdaee!
Light stick pack ø 0.5 X 20 cm
mixed colours (50 pcs/box)
colour: blue - green - red - yellow
(!4BA32J-gjcdcc!
verschillende kleuren - HQLS10001 • groen - HQLS10004
Led garland
warm white - 20 leds - battery powered
power supply: 3 x AA / LR6 1.5 V batteries (not
incl.) • LEDs: 20 pcs • total length: 220 cm
XML19
(!4BA32J-fgggbg!
Led party gloves
power supply: 2 x CR2016 (incl.) • material: •• shell:
acrylic 77.1% - polyester 21.2% - elastodiene 1.0% -
elastane 0.7% •• lining: polyester 100%
HQPE15001
(!4BA32J-hcgfga!
17

Led rope light
single channel rope light for static effect • from
accent and task lighting to party and event lighting,
rope light is an easy and cost-effective solution
• each reel and retail pack comes with useful
accessories such as end caps and a power cord
Dual channel led rope light
multicolour + controller • power supply: 230 V~
50 Hz • power consumption: 15 W • power
consumption/m: 1.70 W/m • cutting distance: 3 m
• IP rating: IP44 • length: 9 m
HQRL09010
(!4BA32J-hacgej!
Dual channel led rope light
multicolour + controller (20 m) • power supply:
230 V~ 50 Hz • power consumption: 15 W • power
consumption/m: 1.70 W/m • colour: multi colour •
IP rating: IP44 • length: 20 m
HQRL09011
(!4BA32J-hbjibe!
Code
HQRL09001
HQRL45001
HQRL09002
HQRL45002
color
cold
white
cold
white
warm
white
warm
white
9 m 22 W
45 m 110 W
9 m 22 W
45 m 110 W
HQRL09003 red 9 m 22 W
HQRL45003 red 45 m 110 W
HQRL09004 green 9 m 22 W
Rope light
45 m - warm white • power supply: 230 V~
50 Hz • power consumption: 630 W • power
consumption/m: 14 W/m • IP rating: IP44 •
length: 45 m
HQRL45012
(!4BA32J-hacgdc!
Waterproof power cable
for led rope light
1 pc
length: 150 cm • voltage: 230 Vac
HQRL99001
(!4BA32J-hacgfg!
HQRL45004 green 45 m 110 W
HQRL09005 blue 9 m 22 W
HQRL45005 blue 45 m 110 W
HQRL09006 yellow 9 m 22 W
HQRL45006 yellow 45 m 110 W
HQRL09007 pink 9 m 22 W
HQRL45007 pink 45 m 110 W
(!4BA32J-hacggd!
Waterproof power cable for rope light
1 pc
length: 150 cm • voltage: 230 Vac
HQRL99002
Mounting clips for rope light and led
rope light
20 pcs
HQRL99003
(!4BA32J-hacgha!
End caps for rope light and led rope light
5 pcs
HQRL99004
18
Inline connectors for rope light and led
rope light
T-connector for rope light and led rope
(!4BA32J-hacgih! 5 pcs (!4BA32J-hacgje! (!4BA32J-hachaa!
light - 1 pc
HQRL99005
HQRL99006

Sound
Magnetic wireless earbuds
rated voltage: 3.7 VDC 1 A • battery: Li-Po 55 mAh
• frequency range: 2.402-2.480 MHz • radio
frequency: 20 Hz-20 kHz • sound power: 2 x
5 mW • Bluetooth connection range: 10 m
BP-4625
&!60JAC0-behbja!
*May only be sold in Belgium, Luxemburg and The Netherlands.
Wired earbuds
rated voltage: 50 mA • playback time: 2-3 hours •
charging time: 1 hour • standby time: 100 hours •
charging cable length: 70 cm
BP-4655
&!60JAC0-behcag!
*May only be sold in Belgium, Luxemburg and The Netherlands.
Wireless earbuds with charging case
rated voltage: •• base: 5 VDC 1 A •• earphones:
3.7 VDC 1 A • radio frequency: 2.402-2.480 MHz
• sound power: 5 mW • frequency range: 20 Hz-
20 kHz • Bluetooth connection range: 10 m
BP-4770
&!60JAC0-befbeb!
*May only be sold in Belgium, Luxemburg and The Netherlands.
Wireless earbuds with charging case
rated voltage: •• base: 5 VDC 1 A •• earphones:
3.7 VDC 1 A • radio frequency: 2.4 GHz • sound
power: 3 mW • frequency range: 500 Hz ± 20% •
Bluetooth connection range: 10 m
BP-4795.112
&!60JAC0-beajei!
*May only be sold in Belgium, Luxemburg and The Netherlands.
(!7AG75B-aeahhb!
Bte-110grey - bluetooth® earphones
power supply: rechargeable lithium polymer
battery 50 mAh • connection for charging: USB
DV-10806
Twe-36 - truly wireless bluetooth earbud
power supply: •• earbud (each): built-in 50 mAh
rechargeable battery •• charging case: 400 mAh
• Bluetooth version: V 5.0 • standby time: 130 h •
talk time: up to 3 h • music playback time: up to
1.8 h • speaker: 10 mm speaker unit - 32 Ohm
DV-10808
(!7AG75B-aegffb!
Wired headphone
driver diameter: 40 mm • impedance: 32 Ohm •
sensitivity: 102 ±3 dB/mW • frequency response:
20-22000 Hz • rated power: 10 mW
BP-4570.133
&!60JAC0-bdecdh!
*May only be sold in Belgium, Luxemburg and The Netherlands.
Wireless bluetooth headphone
rated voltage: 5 VDC 1 A • maximum
consumption: 5 W • radio frequency: 2.402 -
2.480 GHz • sound power: 0.5 W
BP-4100
&!60JAC0-aibjbd!
*May only be sold in Belgium, Luxemburg and The Netherlands.
19

Digital stereo headphones
speaker: Ø 40 mm dynamic type • impedance:
32 Ohm • maximum power: 600 mW •
frequency: 20-20000 Hz • sensitivity: 105 dB ±
3 dB (at 1 kHz) • input connection: gold-plated
3.5 mm stereo plug & 6.3 mm adapter
HPD13
Stereo wireless headphones
noise cancelling • DSP: CVC 6.0 noise and
echo reduction • RF range: 10 m • frequency
response: 20 Hz - 20 KHz • SN: 90 dB • THD: 3 % •
(!4BA32J-chhgjh! loudspeaker output: 20 mW (!4BA32J-gifgdi! • battery: LiPo 3.7 V length: 1.2 m (!4BA32J-cafied!
HPD30
Mono earphone
frequency response: 20-20 kHz • sensitivity: 103 ±
5 dB • impedance: 8 ohm • 3.5 mm plug • cable
HPSS2
Noise cancelling bluetooth headphone
rated voltage: 5 VDC 220 mA • maximum
consumption: 0.04 W • radio frequency: 2.402-
2.480 MHz • sound power: 10 mW
BP-4400
&!60JAC0-bdfhfd!
*May only be sold in Belgium, Luxemburg and The Netherlands.
Table speaker with wireless charging
rated voltage: 5 VDC 2 A • sound power: 10 W
• frequency range: 20 Hz-20 kHz • Bluetooth
connection range: 10 m
BP-0540
&!60JAC0-befchb!
*May only be sold in Belgium, Luxemburg and The Netherlands.
Bluetooth speaker with wireless charging
maximum consumption: 10 W • sound power:
3 W • connection range: 10 m
BP-3270
&!60JAC0-behddg!
*May only be sold in Belgium, Luxemburg and The Netherlands.
Speaker with wireless charging
maximum consumption: 10 W • radio frequency:
2.402-2.480 GHz • sound power: 5 W • Bluetooth
connection range: 10 m
BP-3260
&!60JAC0-behdcj!
*May only be sold in Belgium, Luxemburg and The Netherlands.
Bluetooth speaker with wireless charging
rated voltage: 5 VDC 2 A • maximum consumption:
10 W • radio frequency: 2.4 GHZ • sound power: 2 X
5 W • Bluetooth connection range: 10 m
BP-3250
&!60JAC0-bebbib!
*May only be sold in Belgium, Luxemburg and The Netherlands.
Bts-32black - bluetooth speaker with
rechargeable battery - black
power supply: 110-230 V~ 50 Hz, battery 300 mAh
• dimensions: 700 x 700 x 430 mm
DV-10720
*May only be sold in Belgium, Luxemburg and The Netherlands.
20
Bamboo bluetooth speaker
maximum consumption: 3 W • radio frequency:
2.402-2.480 MHz • sound power: 3 W • Bluetooth
connection range: 10 m
BP-3630
*May only be sold in Belgium, Luxemburg and The Netherlands.
Bluetooth party led speaker bluetooth
radio frequency: 87.5-108 MHz • sound power:
40 W (2 x 6.5”) • Bluetooth connection range: 10 m
BP-3910
&!60JAC0-begbaa!
*May only be sold in Belgium, Luxemburg and The Netherlands.

&!60JAC0-begaih!
Bts-53 - bluetooth speaker with microsd
card slot & aux
battery life: ± 8 hours per charge • power supply:
rechargeable lithium battery 3000 mAh •
dimensions: 250 x 138 x 138 mm • weight: 1.15 kg
DV-10714
(!7AG75B-adhdfb!
Bluetooth party led speaker
rated voltage: 5 VDC 1 A • maximum
consumption: 5 W • radio frequency: 2.4 GHz •
sound power: 20 W • compatible with Bluetooth
version: 4.2 • Bluetooth connection range: 10 m •
playback time: 4 hours • charging time: 5 hours
BP-3915
*May only be sold in Belgium, Luxemburg and The Netherlands.
Portable bluetooth speaker
rated voltage: 5 VDC 1 A • maximum
consumption: 5 W • radio frequency: 2.402-
2.480 MHz • sound power: 2 x 8 W • Bluetooth
connection range: 10 m • playback time:
2-5 hours • charging time: 3-5 hours
BP-3750
&!60JAC0-befdfg!
*May only be sold in Belgium, Luxemburg and The Netherlands.
Bluetooth sound bar
rated voltage: 5 VDC 500 mAh • maximum
consumption: 2.55 W • radio frequency: 87.5-
108 MHz • sound power: 2 x 5 W • Bluetooth
connection range: 10 m • playback time:
3-4 hours • charging time: 2-3 hours
BP-9630
&!60JAC0-beeehc!
*May only be sold in Belgium, Luxemburg and The Netherlands.
Bluetooth sound bar
with led & extra bass
rated voltage: 5 VDC 1 A • maximum
consumption: 5 W • radio frequency: 2.4GHz •
sound power: 2 x 8 W • Bluetooth connection
range: 10 m • playback time: 4-5 hours • charging
time: 4-5 hours
BP-9640
&!60JAC0-beeejg!
*May only be sold in Belgium, Luxemburg and The Netherlands.
(!4BA32J-hafbid!
Fluide 160
6.5" Wireless active speaker - battery powered
HQSA1020
Fluide bazooka xii
bluetooth® speaker 2 x 15 W
power supply: 5 VDC • battery capacity: • play
time: 3-5 h • frequency response: 80 Hz - 18 kHz •
speaker: 2 x 4” - 2 Ohm • USB/SD card: max. 32 Gb
• dimensions: 375 x 145 x 210 mm
HQSA1040
(!4BA32J-hbcihh!
Fluide bazooka xi
bluetooth® speaker 2 x 15 W
power supply: 5 VDC • battery capacity: play
time: 3-5 h • frequency response: 80 Hz - 18 kHz •
speaker: 2 x 4” - 2 Ohm • USB/SD card: max. 32 Gb
• dimensions: 360 x 147 x 210 mm
HQSA1041
(!4BA32J-hbciie!
Fluide bazooka
bluetooth® speaker
power supply: 5 VDC • battery capacity:
3600 mAh - 3.7 V • frequency response: 100 Hz-
20 kHz • power: 24 W • subwoofer: 4” - 2 x 10 W @
4 Ohm • tweeter: 1.6” - 2 x 2 W @ 4 Ohm • USB/SD
card: max. 32 Gb • dimensions: 420 x 191 x 189 mm
HQSA1009
(!4BA32J-hafchf!
Fluide bazooka x
bluetooth® speaker 2 x 8 w
power supply: 5 VDC • play time: 3-5 h • frequency
response: 80 Hz - 18 kHz • power: 2 x 8 W • S/N
ratio: > 85 dB • speaker: 2 x 4” - 2 Ohm • USB/
SD card: max. 32 Gb • dimensions: 372 x 146 x
207 mm
HQSA1042
(!4BA32J-hbcijb!
Party speaker with stand
maximum consumption: 5 W • radio frequency:
2.4 GHz • sound power: 15 W • Bluetooth
connection range: 10 m • playback time: 1-3 hours
• charging time: 3.5 hours • dimensions: 40 x 22.5 x
26 cm • supported audio formats: mp3 - wav - wma
BP-3975
&!60JAC0-behiig!
*May only be sold in Belgium, Luxemburg and The Netherlands.
(!4BA32J-cacaea!
2-Way speaker - 8" - full grid - 300 w -
black
VDSG8
21

Fluide
10" 2-Way active speaker - 70 w
Fluide 10.2 - 10” - 70 W - HQSA1024
(!4BA32J-hafdfa!
Fluide
2-Way active speaker - trolley system
Fluide 15.2 - 15” - 120 W - HQSA1026
Fluide 12.2 - 12” - 100 W - HQSA1025
(!4BA32J-hafdib!
Speaker handle with spring
dimensions: 140 x 40 mm • mounting type • load
capacity: ± 60 kg • heavy-duty • colour: black •
material: metal
HQAC1009
(!4BA32J-hbifad!
(!4BA32J-hceiha!
Speaker handle
dimensions: 137 x 87mm • material: plastic
HQAC1002
Heavy-duty speaker handle
dimensions: 210 x 160 mm • mounting
dimensions: •• height x width: 167 x 120 mm ••
depth: 47 mm • material: plastic
HQAC1003
(!4BA32J-hceiej!
(!4BA32J-hbieia!
Heavy-duty speaker handle
dimensions: 220 x 160mm • heavy-duty • material:
black metal
HQAC1004
Hinge
white metal - 58 x 46 mm - 10 pcs per package
dimensions: 58 x 46 mm • material: metal •
colour: white
HQAC1014
(!4BA32J-hbifde!
(!4BA32J-hbifba!
Lock
dimensions: 105 x 102mm • flush type • material:
white metal
105 x102mm - HQAC1011 • 171 x 126mm - HQAC1012
(!4BA32J-hcdahb!
Speaker strap handle
black - 250 x 25 mm
colour: black • dimensions: 250 x 25 mm
HQAC1010
22
(!4BA32J-hcehcg!
Speaker cabinet corner
8pcs • dimensions: 38 x 38mm x 90° • material:
black metal
HQAC1023
(!4BA32J-hccefg!
Speaker cabinet corner
8 pcs • dimensions: 55 x 35mm x 90° • material:
black plastic
HQAC1015
(!4BA32J-hcbbbe!
Speaker cabinet corner
8 pcs • dimensions: 80 x 50mm x 90° • material:
black plastic
HQAC1017

(!4BA32J-dhdifg!
Speaker wall bracket
max. load: 25 Kg • Ø tube: 35.6mm • weight: 1073g
VDLLB5
Wall bracket
max. angle: 180° • dimensions: •• plate: 100 x
100mm •• speaker holder: 80 x 40mm • max. load:
5 kg • weight: 0.7 kg
VDLWB1
(!4BA32J-cigffc!
Black metal speaker grille
material: metal + rubber ring
Code
HQAC1032 12,7 cm - 5” 10 pcs
VDAC33 20,3 cm - 8” 1 pc
VDAC34 25,4 cm - 10” 1 pc
HQAC1035 30,5 cm - 12” 1 pc
HQAC1036 38,1 cm - 15” 1 pc
VDAC36 38,1 cm - 15” 1 pc
(!4BA32J-ciehgd!
Loudspeaker bracket
material: black metal • interior diameter: 35.5mm
VDLLB1
(!4BA32J-cifbfj!
Fixing accessories for speaker grill
contents: 4 clamps + screws • screw length:
25 mm
VDAC37
Black subwoofer for speaker
Code
VDSSP6.5/8 6.5” 250 W
VDSSP8/8 8” 350 W
Double loudspeaker
connection terminal
gold-plated • dimensions: 92 x 78mm
LSC7G
(!4BA32J-ceaiee!
Double loudspeaker
connection terminal
gold-plated • dimensions: Ø 105mm
LSC6G
(!4BA32J-cbigbe!
VDSSP10/8 10” 350 W
Bass reflex tube
with protection grid
Code
dimensions
AH6
Ø 50 mm x 51 mm
(!4BA32J-eeahfg!
Dual 5" water-resistant cone speaker set
with grids - 80 w - 8 ohm (1 pair)
VDSWPS5N
(!4BA32J-eeahgd!
Dual 6.5" Water-resistant cone speaker
set with grids 120w / 8 ohm (1 pair)
VDSWPS6N
AH8
AH9
Ø 70 x 115 mm
Ø 95 x 113 mm
23

Sagira 150
power amplifier 2 x 100 w rms (2u - 19")
power supply: 100-115 / 220-230 V~ 50 Hz • output
power: •• @ 4ohm: 2 x 130W •• @ 8ohm: 2 x 90W
• frequency response: 20-20,000 Hz • input
sensitivity: 1 V • max. input level: 5.5 V
HQAA10010
Sagira 200
power amplifier 2 x 250 w rms (2u - 19")
power supply: 100-115 / 220-230V 50Hz • output
power: •• @ 4ohm: 2 x 250W •• @ 8ohm: 2 x
170W • frequency response: 20-20,000 Hz • input
(!4BA32J-hbfehc! sensitivity: 1 V • max. input level: (!4BA32J-hbfgab! 5.5 V
Wireless audio amplifier 2 x 15 w
(!4BA32J-giffga!
HQAA10011
BTR4
Eriana 100
power amplifier 2 x 100 w rms - bluetooth® &
usb port • power supply: 220-240 V~ 50/60 Hz •
power consumption: max. 1.5 A • output power:
2 x 100 W 4 Ohm min. • THD: < 0.5% • distortion: >
98 dB • signal to noise ratio: > 95 dB
HQDA10002
(!4BA32J-hbibhg!
Mixer
2 channels + usb input
power supply: 230 V~ 50 Hz • power
consumption: 5 W • audio inputs: •• mic: 20 mV,
unbalanced •• phono: 15 mV / 1 kHz, unbalanced ••
line: 0.8 V, unbalanced
PROMIX50U
(!4BA32J-ecedfa!
Dynamic microphone
MIC11B MIC11BL
(!4BA32J-gbdbdg!
Dynamic microphone
frequency: 100 Hz - 14 kHz • impedance:
600 Ohm • cable length: 4 m with 6.35 mm plug
and XLR plug • cable Ø: 6 mm
MICPRO8
(!4BA32J-dfbcib!
Microphone windscreen set
5 pcs
HQMC10010
(!4BA32J-gjfage!
Dynamic microphone with carry case
frequency: 50 Hz - 15 kHz • impedance: 600 Ohm
• output: XLR • cable length: 4.5 m with 6.35 mm
plug and XLR plug • dimensions: 245 x 165 x 70 mm
MICPRO9
24
(!4BA32J-fhaebf!
Dynamic microphone
frequency: 80 Hz - 12000 Hz • impedance: 600 +/-
30% Ohm • cable length: 3 m with 6.35 mm plug
and XLR plug
HQMC10005
HQMC10006
(!4BA32J-gjhihh!
(!4BA32J-dfbbgi!
Karaoke sound mixer
power supply: adapter 9-12 VDC (incl.) •
dimensions: 130 x 70 x 30 mm • weight: 0.145 kg
PROMIX02

Uhf wireless microphone
single channel
receiver: •• frequency range: 864.000 MHz ••
receiving system: PLL composed •• receiving
module: single (fixed) channel •• frequency
stability: ± 0.005 % •• S/N ratio: 100 dB
HQMC10011
(!4BA32J-hbdffd!
Uhf wireless microphone
dual channel
receiver: •• frequency range: 863.050 MHz &
854.00 MHz •• receiving system: PLL composed
•• receiving module: single (fixed) channel ••
frequency stability: ± 0.005 % •• S/N ratio: 100 dB
HQMC10012
(!4BA32J-hbhcgb!
Set of 3 dynamic black microphones in
plastic case
microphone: •• frequency: 80 Hz - 12000 Hz ••
impedance: 600 +/- 30% Ohm •• colour: black ••
weight: 210 g • case: •• colour: black •• dimensions:
310 x 215 x 70 mm •• weight: 1.2 kg
HQMC10007
(!4BA32J-gjhijb!
Basic karaoke set
power supply: 5 VDC 1000 mA • frequency
range: 20 Hz-20 kHz • line: •• input sensitivity:
380 mV / - 8.5 dB •• input impedance: 20 Kohm •
microphone: •• input sensitivity: 5 mV / - 46 dB
HQMC10050
(!4BA32J-gjjchh!
Karaoke set with hd connection
power supply: 5 VDC • frequency response: 30 Hz
- 18 Khz ± 3 dB • typical tone control: ± 15 dB @
10 kHz • mic input impedance: 22 Kohm • stereo
line input impedance: 10 Kohm
HQMC10051
(!4BA32J-gjjdfc!
Dual-channel wireless
microphone system
system: •• frequency range: UHF 863.500 -
865.000 MHz •• a licence may be required for
some frequency bands - please check your local
regulations
MICW81
(!4BA32J-gdbagc!
Stereo electret microphone
directivity: unidirectional • frequency response:
100-16000 Hz • output level: -48 dB ± 3 dB @ 1 kHz
(0 dB = 1 V/Pa) • output impedance: 600 Ohm ±
30% • max. SPL: 105 dB (1% distortion @ 1 kHz)
MIC2ST
(!4BA32J-cicgfd!
Lavalier microphone
for body-pack MICW43
pick-up pattern: cardioid • frequency response:
30Hz - 18kHz • impedance: 680 ohms ± 30% •
max. SPL @ 1% THD: 130dB • cable length: ± 1.1m
MICW45
(!4BA32J-diedea!
Usb microphone with table stand
microphone type: condensor • polar pattern:
omnidirectional • sensitivity: -38 ± 3 dB • cable
length: 1.35 m • dimensions: 150 x 55 x 45 mm
HQMC10002
(!4BA32J-gjhfje!
Portable public address system
power supply: 10 V 300 mA (adaptor incl.) •
operating voltage: 7.4 V • output: 5 W @ 4 Ohm •
dimensions: 85 x 85 x 50 mm •
HQPA10001
Spare headset for hqpa10001
HQPA10001/SP1
Portable public address system
with usb/sd and fm radio
power supply: 10 V 300 mA (adaptor incl.) •
operating voltage: 7.4 V • battery operating
time: ± 8-10 h • battery charging time: 4-5 h •
(!4BA32J-gjfchj! dimensions: 155 x 95 x 50 mm (!4BA32J-gjfcig! •
50 x 50 mm • weight: 228 g(!4BA32J-habeic!
HQPA10002
Condensor microphone set
colour: black • polar pattern: cardioid • sensitivity:
-46dB ±3dB • frequency response: 20 Hz - 16 kHz
• impedance: •• output: 150 Kohm ± 30% •• load:
1 Kohm • cable length: 1.7 m • dimensions: 180 x
HQMC10001
25

Megaphone
rated power: 10 W • range: 100 m depending on
conditions • power supply: 4 x 1.5 V D batteries
(LR20C, not incl.) • dimensions cone: Ø 155 mm •
length: 245 mm
MP10
Megaphone with record function
rated power: 10W Max. • range: 100m depending
on conditions • power supply: 4 x 1.5V D battery
(LR20C, not incl.) • dimensions cone: Ø 155 mm •
(!4BA32J-ebbdgh! length: 245 mm (!4BA32J-ebbdhe! length: 370 mm (!4BA32J-edhgge!
MP10SR
Megaphone
rated power: 25 W • digital sound level: max.
105 dB • range: 300-500 m depending on
conditions • power supply: 8 x 1.5V C battery
(LR14C, not incl.) • dimensions cone: Ø 230 mm •
MP25-VEL
Megaphone with sd card slot and usb
rated power: 25 W • digital sound level: max.
105 dB • range: 300-500 m depending on
conditions • impedance: 8 Ohm • dimensions
cone: Ø 230 mm • length: 335 mm
MP25FMU
Power megaphone
rated power: 25 W • digital sound level: max.
88 - 92 dB • range: 300-500 m depending on
conditions • impedance: 8 Ohm • dimensions
(!4BA32J-ehcgjg! cone: Ø 230 mm • length: 345 (!4BA32J-ebbdib! mm
300 mm • length: 470 mm (!4BA32J-ehcjff!
MP25SFM
Hi-power megaphone
rated power: peak power max. 45 W • range:
800 - 1000 m depending on surroundings
• impedance: 8 Ohm • dimensions cone: Ø
MP45S
26

Stands &
Clamps
Telescope microphone stand
normal type • plastic & steel joints • finish: chrome
• adjustable height: 92-158 cm • arm length:
75 cm (adjustable) • weight: 2.4 kg
HQMS10001
HQMS10002
(!4BA32J-ggifgd!
(!4BA32J-gfggdi!
One-hand telescope microphone stand
colour: black • adjustable height: 110-168 cm • arm
length: 48.5-86 cm • weight: 2.7 kg
HQMS10003
(!4BA32J-ehffdg!
Tripod microphone stand
colour: black • adjustable height: 90-145 cm • arm
length: 49-90 cm • weight: 1.6 kg
MICS6
(!4BA32J-ecgici!
Microphone stand
colour: black • adjustable height: 95-165 cm •
weight: 4.10 kg
MICS4
Mobile flexible stand
for smartphone or tablet
colour: black • dimensions: •• height: 400-
970 mm • weight: 1 kg
HQMS10006
(!4BA32J-ghbfdc!
Microphone stand
high-grade type • joints in high-grade ABS •
finish: black • adjustable height: 75-138 cm • arm
length: 50 cm-90 cm • weight: 1.6 kg
MICS1BN
(!4BA32J-eabhii!
Adjustable desk mic stand
with phone holder
dimensions: •• arm: 33 / 37 cm •• phone arm:
25 cm •• clip: 4 cm •• phone holder: 12 cm
HQMS10010
(!4BA32J-gibiah!
Table stand with holder
for microphone, smartphone and tablet
material: plastic
HQMS10011
(!4BA32J-hbbcbe!
27

Universal microphone holder 35 mm
with spring
material: plastic • Ø: 35 mm (1.38”) • mounting: Ø
5/8” (metal)
HQMS19004
(!4BA32J-ggjfeg!
(!4BA32J-ggjfcc!
Universal microphone holder 32 mm
material: plastic • Ø: 32 mm (1.26”) • mounting: Ø
5/8” (metal)
HQMS19002
(!4BA32J-ggjfdj!
Universal microphone holder 30 mm
dimensions: •• holder: Ø 30 mm (1.18”) •• mount: Ø
5/8” • material: •• holder: plastic •• mount: metal
HQMS19003
(!4BA32J-ghggaf!
Universal tablet holder for mic stand
height: 160 mm
HQMS10007
Table stand for microphone
gooseneck model • Ø of base: 13cm • finish:
chrome • 5/8” (for use with MICAS8) • length
gooseneck: 30cm • weight: 1.3kg
MICTS2
(!4BA32J-ciehej!
(!4BA32J-ecgibb!
Table stand for microphone
colour: black • base Ø: 105 mm • length: 150 mm •
weight: 390 g
MICTS4
(!4BA32J-efjbgb!
Table stand for microphone
colour: black • base Ø: 140 mm • length: 250-
400 mm • weight: 1260 g
MICTS5
(!4BA32J-ciehfg!
Table stand for microphone
height: 14 - 19 cm • black metal • 5/8” (for use with
MICAS3) • weight: 0.22 kg
MICTS3
(!4BA32J-ggifih!
2-Way microphone adapter
2-way microphone adapter • length: 200 mm •
mounting: 5/8”
HQMS19001
Adapter 3/8"
5/8"
3/8” - 5/8” mounting • material: metal
MICAS3
28
Adapter 3/8"
(!4BA32J-ciehha! 5/8"
Adapter for micas7
(!4BA32J-cifibe! (!4BA32J-cififc!
3/8” - 5/8” inner mounting • material: metal
for MICAS7 • inner thread: 5/8” • outer thread: 3/8”
MICAS4
MICAS8

Flange base for gooseneck microphone
Ø: 45 mm • outer thread: 5/8”
MICAS7
(!4BA32J-cifief! Mic gooseneck (!4BA32J-cdggab! Microphone gooseneck (!4BA32J-cieddg!
black xlr/xlr
20 cm - MICGS2 • 30 cm - MICGS3 • 50 cm - MICGS5
40 cm - MICGSX1 • 50 cm - MICGS5B
Quick trigger clamp
250 kg
max. load: 250 kg • max. diameter: 48-51 mm •
width: 30 mm • colour: black
VDLPCS21
(!4BA32J-fhbhac!
Heavy duty clamp
500 kg
max. load: 500 kg • max. diameter: 48-51 mm •
width: 50 mm • colour: silver
VDLPCS23
(!4BA32J-gdhggi!
Single lighting stand
max. load: 30 kg • height: 120-250 cm • T-bar
length: 100 cm • colour: black
VDL12LS
Lighting bridge with 2 extra t-bars
colour: black-hammered finish paint • max. load:
80 kg (175 lb) • adjustable height: 2.75-3.5 m (9-
11.5 ft) • width: 1.53 m or 3.05 m (5 or 10 ft)
VDL8LS
Black speaker stand
19" Rack stand
(!4BA32J-ecehje! max. load: 60 kg • tube diameter: (!4BA32J-gdhghf! Ø 35 mm •
max. load: 30 kg • dimensions: (!4BA32J-eabhjf!
1050 x 530 x
height: 100-160 cm • weight: 3 kg • colour: black
500 mm • weight: 9.65 kg
VDL8SS
VDLIS6
Speaker stand
max. load: 30 kg • tube: Ø 35 mm • height: 113-
200 cm • weight: 2.25 kg
HQSS10002
Single x quick-mount instrument stand Double x quick-mount instrument stand
(!4BA32J-ghgfca! max. load: 20 kg • colour: black (!4BA32J-ggiheh! • height: 17-92 cm max. load: 30 kg • colour: black (!4BA32J-ggihif!
• height: 17-92 cm
• weight: 2.4 kg
• weight: 3.4 kg
HQSS11001
HQSS11002
29

*Sixty82 may only
be sold in Belgium
Truss & Stages
Sixty82 - square
dimensions main tube: 48.3 x 3 mm • weight: 6.3 kg/m
Code dimensions color
Code dimensions color
M29S-L021 21 cm
M29S-L071R9005
71 cm
M29S-L021R9005
21 cm
M29S-L100
100 cm
M29S-L025
25 cm
M29S-L100R9005
100 cm
M29S-L025R9005
25 cm
M29S-L150
150 cm
M29S-L029
29 cm
M29S-L150R9005
150 cm
M29S-L029R9005
29 cm
M29S-L200
200 cm
M29S-L050
50 cm
M29S-L200R9005
200 cm
M29S-L050R9005
50 cm
M29S-L300
300 cm
M29S-L071
71 cm
M29S-L300R9005
300 cm
(!4BA32J-hcbcee!
Sixty82 - m29s box corner square
dimensions: 289 x 289 mm • weight: 8.5 kg
BOX-M29S
BOX-M29SR9005
(!4BA32J-hcbded!
Sixty82 - square corner 2-way 90°
dimensions: 500 x 500 mm • weight: 5.13 kg
M29S-C203
M29S-C203R9005
30

Sixty82 - square corner 3-way 90° + leg
dimensions: 500 x 500 x 500 mm • weight: 6.91 kg
M29S-C312
Sixty82 - square corner 3-way t-joint
Sixty82 - square corner 4-way cross
(!4BA32J-hcbdgh! (!4BA32J-hcbdib! (!4BA32J-hcbeae!
dimensions: 500 x 710 mm • weight: 7.82 kg
dimensions: 710 x 710 mm • weight: 9.59 kg
M29S-C312R9005
M29S-C317
M29S-C317R9005
M29S-C416
M29S-C416R9005
Sixty82 - square corner 4-way t-joint + leg
dimensions: 500 x 710 x 500 mm • weight: 9.57 kg
M29S-C420
Sixty82 - square corner 5-way cross + leg Sixty82 - hang-on82 truss
(!4BA32J-hcbeci! (!4BA32J-hcbefj! (!4BA32J-hcbhdc!
dimensions: 710 x 710 x 500 mm • weight: 11.33 kg m29 to m29s-t
M29S-C420R9005
M29S-C524
M29S-C524R9005
M29S-T-HO
M29S-T-HO-R9005
Sixty82 - receiver model m51
l=75 mm m12 locator pin
M29S-T-202009
(!4BA32J-hcbgjf!
(!4BA32J-hcbdcj!
Sixty82 - base plate 329 x 329 x 6
dimensions: 329 x 239 x 6 mm • weight: 1.65 kg
M29S-BASE
(!4BA32J-hcbddg!
Sixty82 - base plate 329 x 329 x 6
dimensions: 329 x 239 x 6 mm • weight: 1.65 kg •
colour: blackM29S-BASE-R9005
(!4BA32J-hcbdaf!
Sixty82 - pc-ral9005 ft wall adapter m29
maximum load: 500 kg • colour: black
M29-WAAD-R9005
Sixty82 - stick82 base
dimensions: 600 x 8 mm
STICK82-BASE
(!4BA32J-hcbjda!
(!4BA32J-hcbjeh!
Sixty82 - stick82 pole length 185 cm
STICK82-POLE185
31

Sixty82 - stage82 module - black
sealed gap between wood and extrusion avoids
water seepage • screwed top plate • frame design
makes it easy to handle and pick up by hand •
compatible with scaffolding beam • compatible
with existing brands • double painted plywood
topping • fully bolted for easy repair
Sixty82 - leg stage
diameter: 48.3 mm • thickness: 3 mm
Code
dimensions
Sixty82 - modular fixed stair
maximum load: 500 kg/m²
S82-MFSTAIR
(!4BA32J-hcbiig!
Code
dimensions
S82-L-020
20 cm
S82-100100-B
100 x 100 cm
S82-L-040
40 cm
S82-200050-B
200 x 50 cm
S82-L-080
80 cm
S82-200100-B
200 x 100 cm
S82-L-100
100 cm
Code
Sixty82
Code
Sixty82
M29S-M52S
connector model m52s
0 mm offset m12 locator pin
M29S-T-202005
r-spring model m05
M29S-T-202007
connector model m49 9 mm
offset m12
M29S-T-HO-S
hang-on82 spacer 30 mm
M29S-T-202010
connector model m50 0 mm
offset m12
S82-LTL-CLAMP
leg to leg etp clamp 2-way
M29S-T-202002
connector model
m02 19 mm offset m12
S82-STS-CLAMP
stage to stage clamp
M29S-T-202001
connector model m00
S82-STS-LEVELER
stage to stage leveler
M29S-T-202003
spigot model m03
M29S-817003
bolt m12x20 countersunk
din7991
M29S-T-202004
spigot model
m04 m8 thread
STICK82-817004
bolt m12x020 din933
M29S-T-HO-B
bolt m12x060 din7984 low
head
STICK82-817006
bolt m12x035 din933
M29S-T-202041
modular hinge set
BOX-M29S-BOLT
bolt m12x025 din7984 low
head
M29S-T-811003
cylindrical pin
3x8 din6325 m6
STICK82-817005
washer m12 spring din127b
32

Notes
33

35

n
Prices excl. VAT. Offer is only valid for retailers. Price per piece, only valid when ordering the minimum order quantity (MOQ)
mentioned. Subject to change. Misprints and errors excepted. Actual product appearance may differ from the shown
images. Do not throw on the public highway. Copyright Velleman nv
BE +32 (0)9 384 36 11
+32 (0)9 389 93 35
export@velleman.eu
