On the Road, Get Set – The Solved Challenge

for Handling Radioactive Waste

Sooner or later in discussions about nuclear energy, the question is raised, “What should be done with the radioactive

waste?” Opponents of nuclear power have been very active here over the years and have, in part, successfully

created a distorted picture of the facts. Above all, the phrase “airplane without a runway for landing” attributed to

nuclear energy clearly shows this. The situation is different from the point of view of nuclear and nuclear technology

and the other disciplines responsible for dismantling and final disposal of the waste. Good solutions are known and

applicable for the challenges of handling and long-term storage of radioactive waste as well as for decommissioning.

However, due to societal and political constellations, their actual implementation is sometimes stymied.

Worldwide, the countries using nuclear energy today also

started dealing with questions of handling radioactive

residues, the “nuclear waste”, about 60 years ago when

they commissioned their first nuclear power plants.

Today, the picture is very different in terms of concepts

and progress. Certainly and obviously, the two Nordic

countries, Sweden and Finland, are clearly leading both

from a technical point of view, i.e. with regard to the

questions of implementing long-term storage, and with

regard to the socio-political framework.

Finland will be the first country in the world to have a

repository for spent fuel elements available at the Olkiluoto

Baltic Sea site on its west coast from around the mid-

2020s, in addition to the VLJ repository, which has been

available for the storage of low and intermediate level

radio active waste since 1992.

This repository is the result of a political and societal

selection and decision-making process on how to deal with

the long-lived radioactive waste from nuclear power, which

has provided about 35 % of the nation's electricity needs

quasi-emission-free for years. Even if situational criticism is

generated primarily from the German-speaking world, the

transparency and implementation of the final disposal

strategy are exemplary. The project for handling radio active

waste in Finland started in 1983, i.e. after the country's four

nuclear power plants, which are still in operation today, four

decades after the start of the plants, went into operation at

the two sites Olkiluoto and Loviisa. Originally, export of

spent fuel was an option, with the possibility of reprocessing

of nuclear fuel. In 1987, geo logical disposal was added, and

the Nuclear Energy Act of 1994 prioritised the national

solution, i.e., disposal only. With future tasks in mind, the

Finnish private sector therefore established Posiva Oy, a

company focused on radioactive waste disposal issues and

implementation. In the first nationwide step, the repository

strategy included a site search with accompanying environmental

impact assessment. Four sites that were excellent

from a technical or geological point of view were identified,

and Posiva selected the Eurajoki region as the preferred site.

Further parliamentary steps were then taken with this site,

and in May 2001 the Finnish Parliament ratified the

corresponding government bill. As local shareholders were

given extensive rights in the site selection process, local

politicians also had the opportunity to veto the proposal.

However, the Eurajoki Council voted 20 : 7 in favour of

establishing the repository.

In 2004, the closer site exploration began with the first

facilities of the site designated ONKALO. At a depth of 400

to 430 meters, the repository is to be emplaced in the

bedrock of the Finnish granite. In December 2012, Posiva

applied for construction of the repository and associated

additional facilities for packaging the fuel assemblies.

In 2015, the Finnish government granted the permit. Currently,

Posiva plans to submit the permit for the operation

of the ONKALO repository to the government by the end of

2021, so the stated time horizon for the first emplacement

seems realistic.

Technical figures for the project to date indicate the

spiral access tunnel from the surface to the deepest part of

the mine, plus four vertical shafts for personnel, the eventual

emplacement canister transport, and ventilation. By 2020,

some 10 km of tunnel systems will have been excavated

from the granite, with a further 40 km to be added during

the emplacement operation. The radioactive waste will be

stored using the Swedish KBS-3V method. This system

ensures, on the one hand, the multi-barrier system for

sealing the repository canisters; the fuel assemblies are enclosed

in canisters which are sunk into vertical boreholes

and sealed with bentonite. A special feature of the overall

concept is also that a possible retrieval of the stored repository

canisters is envisaged from the outset; this is intended

to include the option that materials regarded as “waste”

today may be regarded as valuable materials for new

reactors or fuel concepts in the future. Fuel assemblies are to

be disposed about 40 years after discharge from the reactor

and appropriate interim storage. By then, heat generation

will have decreased significantly and radioactivity will have

dropped to about one-thousandth of its original value. The

final storage canisters are also to be loaded at the site.

Construction of the “Encapsulation Plant” began in 2019.

Certainly, these are all largely known facts, which have

also been summarised here before. The endless expanses

of today's media provision and discussions in the so-called

“social media” of the World-Wide-Web leave doubts about

the balance of one or the other “fact finder”.

The topic of plant decommissioning in nuclear

technology almost got lost in the background here. This is

also part of the “natural” operating cycle of a plant. After

the political termination of the peaceful use of nuclear

energy in 2022, 36 power reactors in Germany will be

decommissioned. At three sites, Kahl, Großwelzheim and

Niederaichbach, the status of “greenfield sites” has already

been reached, i.e. no facilities of the former plants are left –

what more can be said about the feasibility of an allencompassing

dismantling? However, dismantling also

offers a still possible potential for new technologies, even if

it often involves disassembling, cleaning and separating.

When it comes to “waste”, the journey certainly began

with the operation of the first nuclear power plants. But it

was by no means a journey into the unknown, and nuclear

power was and is the only large-scale form of energy

generation that offers solutions for all its wastes and has

also priced in the associated costs.

Christopher Weßelmann

– Editor in Chief –
