Genesis, final project Workbook by Encarni Muñoz Cabello at Marbella Design Academy

A FUTURE

FOR MARBELLA

INT63_2FMP

Marbella Design Academy

By Encarni Muñoz Cabello

TABLE OF CONTENTS

01 02 03

07 08 09

BRIEF SITE LOCATION PROBLEM

INSPIRATION

BOARD

MATERIAL

BOARD

RENDERS

04 05 06

10 11

12

SOLUTION /

CONCEPT

CONCEPT

DEVELOPMENT

TECHNICAL

DRAWINGS

BRANDING

VIDEO

CONCLUSION

01

m a r b e l l a

The aim of this project was to design a future for Marbella to the original

project proposal from 2008 called ¨ La Bajadilla ¨.

Marbella´s fishing port ¨ La Bajadilla ¨ was planned to be transformed into

a new sleek, high-tech marina, which would expand the capacity of the

existing port, allowing luxury cruise liners as a higher class of society to

dock at what is considered one of the most luxurious places in the world.

Figure 1

The aim of this project was to design a future for Marbella to the original project proposal from

2008 called ¨ La Bajadilla ¨.

BRIEF

Marbella´s fishing port ¨ La Bajadilla ¨ was planned to be transformed into a new sleek, high-tech

marina, which would expand the capacity of the existing port, allowing luxury cruise liners as a

higher class of society to dock at what is considered one of the most luxurious places in the world.

1

A FUTURE FOR MARBELLA


2

02

Marbella remains one of the most luxurious cities in Spain, a place where every year millionaires

from around the world meet to spend their holidays and enjoy all the delights offered by

this beautiful city. Well-known is Puerto Banus, situated a few kilometres from Marbella.

The contract to enlarge Marbella´s La Bajadilla marina has been awarded to Nasir Bin Abdullah & Sons.

This temporary consortium was headed by Sheikh Abdullah Al-Thani, a member of the

Qatari royal family and owner of Malaga FC. With a cost of €84 million this would be the

first harbour development in Andalucía that is funded with both public and private money.

The main characteristic of this project was to reinterpret its goal, strengthening it

and qualifying it as a strategic “new centrality” both in its urban and territorial scale.

The construction of a spectacular exterior dyked formed in a circle

of a 911m and surrounding the whole area of the current port.

The plot I chose was the triangular plot because it is the one with the best access from the sea, it

has good views and it is the most interesting plot of the port because of its shape, with which I can

challenge myself, as it is not a simple square or rectangle.

My area to work with was 37m x 52m x 63m allowing me to have around 1355m2.

SITE LOCATION

LA BAJADILLA

Figure 2

3 A FUTURE FOR MARBELLA A FUTURE FOR MARBELLA

4

03

MENTAL HEALTH PROBLEMS

ANXIETY AND STRESS DISORDER: THE EVILS OF THE 21ST CENTURY

According to statistics from the World Health Organization (WHO) there were some

264 million people affected by anxiety and stress disorders worldwide, a pathology

that in Spain, the health authorities recognize has grown by 15% since 2005.

Also, after the pandemic anxiety and stress disorder have worsened, becoming as one of the

biggest problems in society nowadays. The figures have tripled compared to the previous year,

increasing to 22%. So, I asked myself:

Have you ever thought about all the time that we spend inside buildings?

The WHO calculated that it’is between 80% and 90% of the time that we are awake, which is why

it is so important that our emotional and physical health is considered when these places are

designed. Also, the pandemic has highlighted the environmental influence on emotional health.

80% 90%

problem

For this reason I wanted to focus on the design of the building because it is crucial to solve these

problems and the well being of the humans.

5 A FUTURE FOR MARBELLA


6

04

S P A C E N T E R

The idea to solve my problem was to create a Spa Center, in which people can relax and enjoy.

WHY A SPA CENTER ?

SOLUTION - CONCEPT

A Spa center is a perfect place in which you can relax, rest, clear your mind

and connect with your soul. As a function for my building this is the solution

but in terms of design the solution to my problem is neuroarchitecture.

N E U R O A R C H I T E C T U R E

THE FUTURE OF ARCHITECTURE

Neuroarchitecture is the application of neuroscience to architecture. This discipline allows us

to study the cognitive-emotional state of the users in architectural spaces and, therefore,

the effect that the different design variables have, in a more objective and exhaustive way ”.

A relationship that is based on the fact that the artificial element has a significant impact on the

mind and the entire psycho-emotional system. “Neuroscience analyzes the functioning and behavior

of the human brain and architecture creates spaces for the human being, that is the connection.

When design and architecture take into account the aspects with which the brain is

comfortable, a series of physiological reactions linked to well-being are triggered.



8

04

This new branch of architecture, in which it work hand in hand with

scientists, seeks to understand how the environment modifies our emotions,

thoughts or behaviors. It is closely linked to sustainable architecture.

Neuroarchitecture develops how built space affects cognitively. For this reason, natural

and sustainable spaces will always be more beneficial for our health and, of course for

the environment.

SOLUTION - CONCEPT

Neuroarchitecture establishes key aspects when configuring spaces to ensure that the mind

is relaxed. Lighting, green areas, colors and ceilings are the keys of neuroarchitecture.

-Lighting: Light attracts the human being, so it is a key element that will

guide the individual in his experience in the building. Natural light helps

people to concentrate and creates a kinder environment than artificial light.

-Green Spaces: Together with natural light, human contact with green

areas helps to open the mind, increase concentration and promote calm.

The views to the outside of the buildings improve the mood of the people.

-Colors: Colors influence and condition people's moods, so it is essential to study

the effect of different shades on our brain and thus use them in the most efficient

way. Green, blue, yellow and pink tones close to nature reduce stress, increase

the feeling of comfort and affect the perception of space as a healthy building.

-Ceilings: High ceilings reduce stress and the feeling of being enclosed. Also

the sharp angles of the buildings favor the appearance of stress or anxiety,

however, the curves or soft contours give us a feeling of security and comfort.

- Architectural Elements: The marked angles of the buildings favor the appearance of stress

or anxiety in the face of curves or soft contours that give us a feeling of security and comfort.

LIGHTING

CEILINGS

ARCHITECTURAL ELEMENTS

GREEN SPACES

COLORS

Figure 3 Figure 4


Healthy buildings are not only those that use materials that are beneficial to the natural

environment and human beings. It is also essential to achieve the best synergies between

the human and structural factors of buildings to build efficient and happy spaces.

For this reason, I chose neuroarchitecture as my concept and solution. It is perfect as concept and

solution because it is innovative, sustainable and futuristic in terms of the future of archirecture.



10

so

05

CONCEPT DEVELOPMENT

This is my plot, in

which I wanted to

take advantage as

much as possible.

After that, I added a

slope on the roof to

play with a sunlight

strategy, to get natural

light from anywhere

in the building.

I curved the edges to

avoid straight lines and

have curved lines as my

concept. Curved lines

reduce stress and give

safety and comfort.

Finally, I divided

the building into 3

differents

volumes,

to obtained more

natural ligth, more

open spaces and also

play with the sunlight

strategy and the

height of the ceilings.

Then I converted it

After, I designed an

in a volume, to see

open

space in the

better my design

middle, to obtained

and the building.

natural light inside

the building as

much as possible.

I chose this design, because it had connection with my concept, using different

strategies such as a slope to play with different heights of the ceilings, a volume

divided into 3 different buildings to obtained sunlight as much as possible

and

curved lines that it is one of the principles keys of neuroarchitecture.

11 11 A FUTURE FOR MARBELLA A FUTURE FOR MARBELLA

12

06

TECHNICAL DRAWINGS

L E G E N D

1. Spa Area

2. Zen Area

3. Beauty Area

3

1

2

This is the site plan, in which we can appreciate everything that surrounding the

building. Also , as you can see, we have the dimensions of the plot, 37m x 52m x

63m allowing me to have around 1355m2. The building is divided into 3 diferent parts.

The main part is the Spa Area, the second one is the Zen Area, then we have the

Beauty Area and finally the outdoor space, in which all the buildings are connected.



14

06

This is the floor plan of the ground

floor with all the dimensions.

The Spa has 501m2, the Zen Area

has 165 m2, the Beauty Area has

183m2 and the outdoor area has

493m2, in total we have 1355m2.


´

´



16

06

This is the floor plan of the ground floor

in which you can see the distribution

of all the differents areas. Also it is

visible the harmonic and curved lines

which I designed the different spaces to

obtained the feeling of well being, relax

and peace just looking at the building.

I divided into 3 different spaces to

have separated areas, in which you

can have different experiences.

In the main building we have

the spa, the sauna room, the

toilets and the changing rooms.

The Zen area, is more focus to connect

with your soul, doing meditation and yoga.


´

´

The third one, is the Beauty Area,

focus in beauty and aesthetic clinics.

Finally we have the connection between

the 3 different buildings in the middle

of the plot, the outdoor area, in

which people can meet and enjoy.



18

06

This is the floor plan of the first

floor

with all of the dimensions

of the different spaces.

In this case we have just first floor

in the main building the Spa Area and

the Beauty Area, because the Zen

space it doesn´t have enough heigh

ceilings to have the feeling that I

wanted to transmit so it has just

the ground floor with high ceilings.




20

06

This is the floor plan of the first floor,

in which we can appreciate the upper

floor. In the Spa building we have the

sauna room and the changing room. The

Zen building doesn´t have first floor

because of the heights of the ceilings,

in which I need high celings.The Beauty

Area, we havee the aesthetic clinic

room in which we have more privacy.




22

´

´

06

´


This is the section AA´ in which you can see with more details the inside

of the buildings, The Spa and the Zen Areas, also you can appreciate

the inclination of the slope, with which I wanted the sunlight strategy.

´



24

´

´

06

´


This is the section BB´, in which you can see with more details the

inside of the Zen building

and the Beauty building. Also, in this section

is more visible than in the section AA´

the inclination of the slope.

´



26

06


+ 10

+ 8,28

+ 7,11

This is the elevation A, in which you can see with details how

looks like the building with materials and all the surroundings.

Also is visible the inclination of the slope , as in the last sections.

+ 5,30



28

06


This is the section B, in which is visible the main facade of

the Genesis Spa Center with all the surroundings of the Port.

+ 5,30



30

so

07

inspiration board

Figure 7

Figure 8


I got inspired by harmonic shapes

with rhythm combined with green

spaces , open spaces and pink

pastel tones as my concept.



32

08

material board

ECOLOGICAL

CONCRETE

WOOD

PINK PASTEL

GLASS

The materials that I chose for my project were

the

ecological concrete, wood and pastel pink ecological paint.

Green concrete is a form of eco-friendly concrete that is

manufactured using waste or residual materials from different

industries, and requires less amount of energy for production.

Compared to traditional concrete, it produces less carbon

dioxide, and is considered cheap and more durable. The aim

of using green concrete is to lessen the burden on natural

resources, and increase dependency on recyclable materials.

There are numerous reasons why wood is an eco-friendly

option. From retaining heat to having a positive effect on our

mental health, and this is one of my principle goal of design.

I chose pink pastel tones because colors is a key of

neuroarchitecture and has influence in our menta health

depends of the tones and colors. The color pink is a relaxing

color that influences feelings, inviting them to be kind, soft and

deep, and thus inducing us to feel affection, love and protection.

Finally I used mirrored glass, in which if you are outside you can

not see the inside, but if you are inside you can enjoy the views.



34

s

09

The reception of Genesis Spa Center, is an environment in which you enter

in and you can feel peace and relax with its structure, harmonic shapes with

rhythm, materials, colors, green spaces, natural light and high ceilings.

It has all the principle keys of neuroarchitecure, so the goal of well being

is more than achieved .The ecological concrete simulating a natural rock in

the walls, the ecological concrete painted with pink pastel tones, creates

a beautiful contrast, in which the user feel good and relax. Also the green

spaces looks like if you are in the middle of the nature and breathe fresh air.

R E C E P T I O N

RENDERS



36

s

09

Genesis Spa, is the perfect place to well being. You can enjoy the views,

relax and feel the peace, reducing any type of stress and axiety.

It has natural light thanks to its mirrored

glass windows that has one part of the facade.

SPA

RENDERS



38

s

09

SAUNA

The sauna, is a

beautiful place, in which you can feel relax

looking to its harmonic shapes which have rhythm and elegance.

Also all the entire room is made by wood, which transmit

good feelings, having

positive effects in our mental health.

The massage room, is a beautiful place, in which you

can have the feeling of being surrounded by the nature

and enjoy the beuatiful sunsets while you are relaxing.

MASSAGE ROOM

RENDERS


40

s

09

The Beauty Salon is the perfect place to take care of yourself

and pamper yourself, being relaxed and enjoy the views.

The outdoor area, is the common space between all the 3

buildings, in which it is produced a connection between all of them.

Also is the perfect place to meet and enjoy with other people.

BEAUTY SALON

RENDERS

OUTDOOR



42

s

10

branding

Genesis Spa Center is the branding of this project. Genesis meaning

`` the origin or mode of formation of something´´ which that means that Genesis Spa

Center is the origin of the future of architecture, from which neuroarchitecture is

born, the fusion of the human mind and architecture to achieve human well-being.



44

11 12

To see the video, clik on the link: https://youtu.be/xcS9Yh_dqUY

In conclusion, I am really proud of what I have been able to achieve

during these three years. Also, the last one, it has been more difficult

than the rest of the years because I have been working while I have

been studing, but finally I am here, working and finshing my interior

architecture degree. Last but not least, thank my teachers for

the support and really helped me grow up and expand my learning

capacity to keep achieving the best. It has been a very nice experience

video

CONCLUSION


46

FIGURE 1: https://acortar.link/wrZdx

FIGURE 2: https://acortar.link/wrZdx

FIGURE 3: https://acortar.link/URxGV

FIGURE 4: https://acortar.link/GZkZX

FIGURE 5: https://acortar.link/KvWIf

FIGURE 6: https://acortar.link/y1zH1

FIGURE 7: https://acortar.link/l6Nr5

FIGURE 8: https://acortar.link/P535q

FIGURE 9: https://acortar.link/JbIgk

FIGURE 11: https://acortar.link/JbIgk

The rest of the document is made my Encarni Muñoz Cabello.

references

By encarni muñoz cabello


47

Genesis, final project Workbook by Encarni Muñoz Cabello at Marbella Design Academy

Create successful ePaper yourself

Delete template?

Save as template ?
