EDITORIAL
Castings –produced as sustainably
aspossible
The business climate in the industrial nations has improved with the
expectation that rising vaccination rates will make lockdowns athing of
the past. In addition to digitalization and e-mobility, climate change is
high on the agenda again –and thus sustainability and the possibility of
climate neutrality in the foundry industry.
Robert Piterek
e-mail: robert.piterek@bdguss.de
The highly infectious delta variant
of Covid-19 is on the rampage in
Germany and worldwide. Governments
are therefore wary of lifting
measures combatting the spread of the
virus –also because the vaccination rate
in many countries is only rising hesitantly.
The business climate, on the
other hand, is good enough to bring
topics that were deferred by the pandemic
back to the fore again.
One ofthese topics is sustainability,
which we examine in our interview with
Clemens Küpper, Managing Director of
the iron foundry Baumgarte and President
of the German Foundry Association.
He expects that sustainability will
sooner or later become adecision criterion
for customers, and supports casting
production that is assustainable as possible.
More on this from P. 6.
Prices for input materials, particularly
metals, are another important subject
for foundries. Prof. Rüdiger Deike
of the University of Duisburg-Essen has
written adetailed background article
on this, enabling predictions on the
development of metal prices and showing
how they are influenced by the situation
in producer countries as well as
public statements (from P. 32).
Other interesting highlights in this
issue include the production ofcasting
cores using slurry-based additive manufacturing.
This enables the production
of mechanically stable, complex and filigree
cores with low surface roughness
for investment casting (from P. 18), and
an article by foundry engineers at
Gemco in the Netherlands. Using bestpractice
examples, they show how logistics
can improve foundry efficiency
(from P. 13).
Important future topics can be
found in our News Review, including
very interesting facts about the hydrogen-induced
formation of cracks in steel
components and how they can be prevented.
After all, aclimate-neutral
industry –asdemanded by the EU by
2050 at the latest –will depend on the
use of hydrogen. Moreover, the first
foundries in Germany are already
announcing climate-neutral production.
Have agood read!
CASTING PLANT &TECHNOLOGY 3/2021 3

CONTENTS
FEATURES
6 INTERVIEW
„Sustainability is becoming adecision criterion
for customers“
Clemens Küpper is Managing Director of aGerman
iron foundry and President of the German Foundry
Association. Atalk on aspirations and realities of
sustainability in the sector. Robert Piterek
8 COMPANY
From family-run company to lean machine
constructor
Machine constructor Wöhr is an indispensable supplier
for hand-molding foundries. The eventful history
of the company goes back 150 years.
Robert Piterek
13 FOUNDRY CONSTRUCTION
COMPANY
Wöhr‘s plant technology
and handmolding
foundries
belong together.
METALLURGY
ASK Chemicals Metallurgy
produces master
alloys and inoculants.
Logistics as basis for an optimally functioning
foundry
The efficiency of afoundry is not solely determined
by installations and production processes. Asuitable
layout and good logistics are prerequisites.
Huub van der Weiden
18 COREMAKING
Slurry-based 3-D-printing of casting cores
An alternative for manufacturing investment casting
cores. Joachim Vogt, Marina Stepanyan, Patricia
Erhard, Daniel Günther, Sebastian Schmalzl and Sven
Gläser
Cover-Photo:
JASPER Gesellschaft für Energiewirtschaft und Kybernetik
mbH, Bönninghauser Strasse 10, 59590 Geseke, Germany
info@jasper-gmbh.de
www.jasper-gmbh.de
HEAT RECOVERY
Climate neutral production
will become
more important in
the future. Sustainable
heat recovery
offers potential.
Jasper develops solutions for the aluminium and steel industry
and local authorities. The focus of activities is in industrial
furnace engineering and firing systems, energy engineering
and control systems and process control technology.
4

CONTENTS
INTERVIEW
Sustainability –lofty
wish or competitive
advantage?
24 METALLURGY
Where metallurgical additives in foundries
come from
The production facility for metallurgical products
of ASK Chemicals is located in Southern Germany,
Verena Sander
27 HEAT RECOVERY
Sustainable heating solution for magnesium
die caster
With anew heat recovery system Stihl Magnesium
Druckguss lowers CO 2
emissions, Lena Arenz
30 SIMULATION
Aring for eternity
With acasting simulation aThai jewelry caster optimized
his investment casting process, Pia Sonntag
32 METAL MARKETS
What is happening on the commodities
market –and what the future holds?
Global market analysis which provides astrategic
basis for future purchase prices, Rüdiger Deike
43 PRESSURE DIE CASTING
Bohai Trimet banks on GDK and Kseries
Die casting machine manufacturer Oskar Frech successfully
sells new series to automotive supplier,
Jürgen Lamparter
COLUMNS
SIMULATION
Aring accompanies
its wearer often for a
lifetime. Afoundry
optimized its production
by simulation.
3 EDITORIAL
48 NEWS IN BRIEF
58 SUPPLIERS GUIDE
65 FAIRS AND KONGRESSES/AD INDEX
66 PREVIEW/IMPRINT
METAL MARKETS
Metal expert Prof.
Rüdiger Deike has
analyzed the markets
and gives aglobal
overview.
CASTING PLANT &TECHNOLOGY 3/2021 5
