A step towards a more sustainable future.<br />
<strong>MASTER</strong> <strong>BAG</strong> <strong>F150</strong>
1.<br />
2.<br />
3.<br />
4.<br />
5.<br />
6.<br />
7.<br />
8.
Environmentally friendly biodegradable materials<br />
are used in the production of <strong>bags</strong><br />
Model<br />
Max bag width<br />
Max bag length (depth)<br />
Max unwinding diameter<br />
Max speed (pcs/min)<br />
Suitable film<br />
Weight<br />
Dimension(L*W*H)<br />
Voltage<br />
<strong>MASTER</strong> <strong>BAG</strong> F 150<br />
ECOM <strong>BAG</strong><br />
950mm<br />
900mm<br />
φ1000mm<br />
40-150 pcs/min(depend on<br />
the bag size)<br />
Paper<br />
5000kg<br />
8000*1700*2000mm<br />
380V, 50Hz<br />
Inverter control speed, easy to operate, reduce electric consumption.<br />
Feed wheel and pull device controlled by servo motor, high efficiency<br />
output.<br />
Computer control full automatically, touch screen and human-<strong>machine</strong><br />
interface, easy for correction and fine adjustment.<br />
Unwinding adopts shaft feeding, equipped with 3 raised key type air<br />
expansion shaft<br />
Unwinding with 2.5kg magnetic powder brake<br />
The deviation rectifying device is push-type photoelectric automatic<br />
deviation<br />
rectifying device.<br />
8.Glue scraping and merging function part<br />
1) Longitudinal Z-axis servo motor: 1 piece<br />
2) Glue scraping of transverse X-axis servo motor: 2piece<br />
3) Centrifugal membrane glue gun: 1 piece<br />
4) Rubber scraping can be moved left and right: 1 set<br />
5) Bottom scraping can move left and right: 1 set<br />
6) Glue storage barrel
Photocell<br />
Servo motor & driver<br />
Inverter<br />
PLC with program<br />
Touch screen<br />
Tension controller<br />
Button<br />
Bearing<br />
SSR<br />
Intermediate relay<br />
Datalogic – Italy<br />
Mitsubishi – Japan<br />
Delta –Taiwan<br />
Mitsubishi – Japan<br />
MCGS– Taiwan<br />
Automatic<br />
Schneider – France<br />
NSK--Japan<br />
Fotek - Taiwan<br />
Schneider – France
Phone: 00 31 023 5689139<br />
Mobile: 00 31 6 21673554<br />
WhatsApp:0031 630 07 44 07<br />
email:info@gutenberg<strong>machine</strong>s.com<br />
SIRIUSDREEF 17-27 2132 WT<br />
HOOFDDORP – THE NETHERLANDS
