THE KNEIDINGER

CATALOGUE 2024

valid from 01.01.2024

innovation

the whole range

CONTENT

• Content

• Contact

• Reverse Drive Description

• Forestry Protection Description

• Panoramic roof Description

• Pneumatic Cab Suspension Description

• mounted crane Description

REVERSE DRIVE PRICES

• New Holland T5 AC DC

• New Holland T6 EC

• New Holland T6 AD AC with Sidewender II

• New Holland T7 SWB Stage V

• New Holland T7 LWB Stage V PLM

• New Holland T7 HD Stage V PLM

• New Holland T8 Genesis

FORESTRY PROTECTION

• New Holland T5 80-120 Dual Command

• New Holland T7 HD

• New Holland T8 Genesis

• Orderform Reverse Drive

• Orderform Forestry Protection

1

2

3 4

5 6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

TERMS OF SERVICE

delivery terms

Delivery dates and deadlines are none-binding

Warranty terms

Warranty conditions are listed on our website and are available in the download area on our website under the following link:

http://reversedrive.at/downloads/

Copyright

Construction plans and drawings are the property of Kneidinger 1880 GmbH and are protected by copyright. They may not - in whatever way - be passed on

to third parties.

general provisions

Oral side agreements are not valid. Changes and additions has to be in written form. the order is only valid after the order confirmation has been issued by

Kneidinger 1880 to the customer.

Payment terms

The goods are property of Kneidinger 1880 GmbH until full payment is received. Payment has to be made before delivery.

Transport

In case of warehouse and customer vehicles, the customer must always provide for transport.

For new vehicles ex works St. Valentin please always note VAN No. in the order form. Assembly by Kneidinger 1880 before delivery to the dealer.

Pricelist is valid from January 2024

All prices are excl. VAT, with the publication of this pricelist all previous pricelists lose theire validity, all information is none binding, price and construction

changes are reserved.

1

Kneidinger 1880 GmbH

Streinesberg 12

4134 Putzleinsdorf

Tel.: +43 (0) 59 1880 301

Kontakt: forsttechnik@kneidinger.at

www.reversedrive.at

Johannes Leitner

Service / Offer

forsttechnik@kneidinger.at

Tel.: +43 (0) 59 1880 301

Martin Traxler

Development

martin.traxler@kneidinger.at

Tel.: +43 (0) 59 1880 602

Helmut Hötzendorfer

Customer Service/Technician

technik@kneidinger.at

2

REVERSE

Efficiency

a buzzword that is implemented with a reversing device

in agriculture and forestry as well as in the municipal

sector and in industry.

Our reversing devices are used all over the world and

have continuously established themselves and proven

themselves many times.

DRIVE

We have been dealing with the conversion of Steyr and

CaseIH tractors since 1998 and have raised and continuously

developed our qualities in this area over the years

of experience.

Large glass areas offer the driver excellent all-round visibility.

Changing from forward operation to reverse position

works without switching off the engine.

The controls for the pedals and the steering as well as

the display switch over automatically during the 180° rotation

process. Standing up during the turning process is

not necessary. All functions are equally available in both

directions of travel thanks to the operating armrest.

The engine performance of the environmentally friendly,

economical SCR engines with full thrust is retained even

when reversing. The steering wheel at the rear can be adjusted

laterally and in terms of inclination - on the Steyr

Terrus and CaseIH Optum, the original steering wheel is

converted and modified in a removable manner.

A reversing device for maximum ease of use for the models

Steyr Profi to Terrus as well as CaseIH Maxxum to

Optum, and thus for a performance range from 115 - 300

hp is a clear advantage for all customers who are working

with a trailer or a forestry cutter. All controls, including

the armrest, can be switched from normal forward

travel to reverse work in seconds. By turning the seat, the

controls switch over, offering significantly more relaxed

and safer work.

3

Conversion

The cab floor, cab rear wall, additional control units and

the air ducts for the air conditioning system are moved

to the rear. The footwell is extended for the turning process

on the right and a protective cover is installed in the

turning area.

A display is used at the rear and the foldable armrest is

installed.

For the installation of the swivel seat, only the necessary

elements for the swiveling process and operation are

assembled. Pedals and controls as well as the steering

wheel for reversing are omitted here.

The full power of the rear PTO shaft can be used with

a reversing device. Many tractor attachments work best

with full engine power on the rear PTO and can be optimally

controlled by the driver in the reverse position.

For customers who do not need a complete reversing

device, we offer the pure swivel seat, which can be rotated

180° in the right direction into the rear seat position

and significantly optimizes and facilitates work in

the rear area.

ARGUMENTS

• comfortable seat position

• Steering wheel adjustable laterally and in inclination

• best view on wide devices

• fast and comfortable change from forward to

backward operation

• operation switches automatically

• excellent all-around visibility throught large glass

surfaces

• within the operation armrest all functions are available

in both directions

• high engine performance, economical engin

• full thrust even in reverse position

• spacious cabin

4

FORESTRY

Efficiency

PROTECTION

Applications in forestry require the technology. With the

protection and tailor-made additional equipment for

New Holland tractors, you increase the value of your machine

and are completely safe.

A massive forest frame, consisting of a 4-pillar system for

the cabin, as well as protective grilles on the roof and in

front of the rear window, offers protection for man and

machine.

Optionally, we also install a tested polycarbonate rear

window for the best visibility.

The solid floor protection plate and side panels protect

the engine, transmission, rear axle, fuel and hydraulic

tanks.

The floor protection plate has all the necessary service

access.

From „light to heavy“

Dedication is not always the same - a principle that also

applies to work in the forest. We offer different forest packages

for this.

The basic protection „light“ consists of a continuous floor

protection plate up to the front axle and side protection

in the area of the engine.

5

Our Forestry Protection is available for:

New Holland T5 DC

New Holland T7 HD

New Holland T8 Genesis

Conversion

The forest body „light including side paneling“ also offers

protective paneling for the fuel tank, gearbox, SCR

Cat and the battery.

With a „heavy“ forest body, your machine is equipped

with a 4-pillar forest frame, a polycarbonate safety rear

window and a branch deflector for the hood in addition

to the components mentioned. TÜV acceptance and

OPS - and FOPS test guarantee you safety for man and

machine with the quality from our house.

ARGUMENTS

• tested according to the official forest

protecion standard DIN ISO 8083/DIN ISO 8084

• protection and security increases the value of

the machine

• individual solution for every customer

• well prepared for any mission in the forest

• high quality processing - parts sandblasted and

primed and painted

6

PANORAMIC

Overview

This is what matters in many everyday jobs and it is precisely

this that is unsurpassed with our panorama roof.

Our conversion gives the driver an unrestricted view

of all work equipment that is moved at or above cabin

height, ideal for working with cranes, embankment mulchers,

pruning shears, ...

In combination with our reversing device and the joystick

installation, a workplace is created here that no driver

would want to be without. Above all, the ergonomic, relaxed

sitting position, which can be maintained throughout

the working time due to the large window areas,

is praised by our customers. This prevents fatigue and

protects both the driver and the machine. A separate

windscreen wiper and a sun blind for the skylight round

off the overall package and enable use in almost any weather.

ROOF

Of course, safety must not be neglected, that‘s why we

use 12mm thick polycarbonate for the roof pane in addition,

the complete roof shell can be equipped with an

optional branch deflectors are protected.

7

PNEUMATIC

CAB

Efficiency

• higher driving comfort

• easy retrofit

• relief of the spine

SUSPENSION

Think about your health - with a pneumatic cab suspension

you increase the driving comfort of your machine

and thus ensure your well-being.

During a season, a driver sits in the cab for many hours.

Often on bumpy terrain and at high driving speeds. Our

pneumatic cab suspension creates significantly better

driving conditions for the driver while working.

Thanks to the improved suspension, driving comfort is

increased and the driver can concentrate better on the

journey and on the work.

The spine is relieved and consequential damage is counteracted.

Automatic level control by the air pressure dampers ensures

stress-free cabin damping.

After approx. 4 hours of assembly time, the retrofit kit is

installed in an uncomplicated and simple design.

8

MOUNTED

Overview

QUiCK CHANGING SYSTEM

CRANE

• Quick change system with hydraulic or mechanical

locking

• Rear attachment and lifting gear remain intact

• Crane body frame on the tractor with additional support

up to the front axle support

• Various crane supports available on request

• PERMANENT ATTACHMENT

Mounting position near the rear axle

Additional equipment such as cable winch, stacking

shield etc. possible.

Crane assembly for all tractor models on request!

9

New Holland T5

AC & DC

Ordernr. Conversion Rotation Seat and Reverse Drive EUR excl. VAT

N-EX1-DR

N-EX1-RF

Rotation Seat

Conversion of rotating seat, direction of rotation to the right 180°, lateral protective

covering in the rotating area, extended footwell on the right for the rotating

process, conversion of the cabin floor, conversion of air ducts and air conditioning,

rear wall of the cabin and additional control units moved to the rear, complete

with assembly 8.430,00

Reverse Drive

Incl. conversion of rotating seat, extended foot space on the right for the rotating

process, conversion of the cabin floor, conversion of air ducts and air conditioning,

rear wall of the cabin and additional control units moved to the rear, operation

switches automatically by rotating the seat,

Operation: steering, clutch, shuttle lever, brake and accelerator pedal 18.890,00

N-HD1-LVS Removable original front steering wheel optional, incl. bracket 980,00

Ordernr.

N-EX-DW

N-EX-PNV

N-EX-HSM

N-EX-JSM

N-EX-HF

EUR excl. VAT

Double-acting hoist

operation via additional control unit 1.850,00

Pneumatic cab suspension parts kit

with integrated level control, incl. shipping costs

(Original cabin suspension and compressed air system must already be present.) 2.830,00

Safety rear window polycarbonate

12mm incl. mounting (shipping on request) 2.670,00

Joystick operation crane control, armrest assembly incl.

Armrest adjustable on the left, modification of the control panel on the right 2.050,00

ear panorama roof

Ideal for crane operation (incl. individual approval)

wipers, sunblind,

12mm polycarbonate disc,

Steyr roof shell is replaced by CASE roof shell,

(only for high-roof design) Skylight front. omitted

including assembly 14.780,00

N-EX-HF-AD Branch deflector for roof shell 1.930,00

10

Click to picture >>>>


EC


N-PC-DR

N-PC-RF

Rotation Seat

Modification of swivel seat, direction of rotation right 180°, side protective

paneling in the rotating area, extended footwell on the right for the

rotating process, modification of the cabin floor, modification of air ducts

and air conditioning, complete including assembly,

Requirement 90mm original cylinder rear linkage! 8.400,00

Reverse Drive

Incl. conversion of rotating seat, extended foot space on the right for the

rotating process, conversion of the cabin floor, conversion of air ducts and

air conditioning, rear wall of the cabin and additional control units moved

to the rear, operation switches automatically by rotating the seat,

Operation: steering, clutch, shuttle lever, brake and accelerator pedal,

Requirement 90mm original cylinder rear linkage! 17.800,00

N-HD1-LVS Removable original steering wheel in front optional, incl. bracket 980,00

Ordernr.

N-PC-DW

N-PC-PNV

N-PC-HSM

N-PC-HF

EUR excl. VAT

Double-acting lifting gear, original lifting cylinders are replaced,




(Original cabin suspension and compressed air system must already be present.)

2.680,00



Rear panorama roof





(only for high-roof design) Front skylight omitted,


PC-HF-AD Branch deflector for roof shell 1.930,00

11



AC & AD with Side Wender II


N-PMC-DR

N-PMC-RF

Rotation Seat

Conversion of rotary seat, rotation to the right 180°, lateral protective paneling

in the rotary area, extended footwell on the right for the rotary process,

conversion of the cabin floor, conversion of air ducts and air conditioning,

MC armrests can be folded up *

complete incl. assembly 8.690,00

Reverse Drive




to the rear, display at the rear, MC armrest can be folded up*, operation


Operation: steering, clutch, shuttle lever, brake and accelerator pedal, 20.200,00


Ordernr.

N-PMC-DW

EUR excl. VAT

Double-acting lifting gear, original lifting cylinders are replaced,


N-PMC-PNV



(Original cabin suspension and compressed air system must already be

present.) 2.680,00

N-PMC-S8-PNV Pneumatic cab suspension parts kit Dynamic Command 2.680,00

N-PMC-HSM



N-PMC-JSM

N-PMC-HF

Joystickoperation of crane control, armrest assembly incl. armrest adjustable

on the left, modification of the control panel on the right




2.080,00



(only for high-roof design) Skylight at the front is omitted.


PMC-HF-AD Branch deflector for roof shell 1.930,00

12

*el. Height adjustment not possible/not applicable


New Holland T7 SWB

Stage V


N-SWB-DR Rotation Seat

Conversion of rotating seat, direction of rotation 180° to the right, lateral

protective covering in the rotating area, extended footwell on the

right for the rotating process, armrest can be folded up*, conversion of

the cabin floor, conversion of the air duct and air conditioning system, 8.690,00

complete with assembly

N-SWB-RF Reverse Drive

Incl. conversion of swivel seat, extended footwell on the right, side protective

paneling in the swivel area, conversion of the cabin floor, conversion

of air ducts and air conditioning, rear wall of the cabin and additional

control units moved to the rear, display at the rear, operation

switches automatically by rotating the seat, *

20.200,00

Operation: steering, clutch, shuttle lever, brake and accelerator pedal


Ordernr.

N-SWB-DW

N-SWB-PNV

N-SWB-HSM

N-SWB-JSM

N-SWB-HF

EUR excl.VAT



Pneumatic cabin suspension parts kit, not possible for Puma FPS transmission!



present.) 2.680,00



Joystick operation of crane control, armrest assembly incl. armrest adjustable

on the left, modification of the control panel on the right 2.080,00






(only for high-roof design) Skylight at the front is omitted


N-SWB-HF-AD Branch deflector for roof shell 1.930,00


13


New Holland T7 LWB

Stage V PLM


N-LWB-DR

N-LWB-RF

Ordernr.

N-LWB-DW

N-LWB-PNV

N-LWB-HSM

N-LWB-JSM

N-LWB-HF

Rotation Seat

Conversion of rotating seat, direction of rotation to the right 180°, lateral

protective covering in the rotating area, extended footwell on the right for

the rotating process, conversion of the cabin floor, conversion of air ducts

and air conditioning, MC armrests can be folded up*

removable original steering wheel incl. bracket

complete incl. assembly 9.780,00

Reverse Drive




to the rear, display at the rear, MC armrest can be folded up*, operation


removable original steering wheel incl. bracket

Operation: steering, clutch, shuttle lever, brake and accelerator pedal, 21.150,00

EUR excl. VAT



Pneumatic cabin suspension parts kit, not possible for Puma FPS transmission!



present.) 2.680,00








IN PREPARATION



including assembly

on request

N-LWB-HF-AD Branch deflector for roof shell 1.980,00


14



Stage V PLM


N-HD2-DR

N-HD2-RF

Rotation Seat

Conversion of swivel seat, rotation to the right 180°, lateral protective

covering in the rotation area, armrests can be folded up, extended foot

space at the rear, conversion of the cabin floor, removable steering wheel, 9.950,00

complete with assembly

Reverse Drive

Including conversion of swivel seat, extended foot space on the right,

lateral protective covering in the rotating area, conversion of the cabin

floor, conversion of ventilation and air conditioning, operation switches

over automatically by turning. Detachable original steering wheel in front

Operation: steering, clutch, shuttle lever, brake and accelerator pedal 21.900,00

Ordernr.

N-HD-DW

N-HD-PNV

N-HD-HSM

N-HD-JSM

N-HD-HF

EUR excl. VAT






present.) 2.680,00









auf Anfrage



N-HD-HF-AD Branch deflector for roof shell 1.980,00

15



Genesis


N-MA2-DR

N-MA2-RF

Rotation Seat

Conversion of rotary seat, rotation to the right 180°, lateral protective covering

in the rotary area, armrest can be folded up*, extended footwell on the

right in the rotary area and at the rear, conversion of the cabin floor, conversion

of air ducts and air conditioning, complete with assembly 9.980,00

Reverse Drive

Incl. conversion of swivel seat, extended footwell on the right, side protective

paneling in the rotating area, conversion of the cabin floor, conversion

of air ducts and air conditioning,

Operation: steering, clutch, shuttle lever, brake and accelerator pedal 24.150,00

Ordernr.

N-MA-JSM

N-MA-PNV

EUR excl. VAT

Joystick operation crane control, armrest assembly incl. armrest adjustable

on the left 1.350,00

Pneumatic cab suspension parts set instead of mechanical suspension



present.)

2.780,00

16



New Holland T5 80-120 Dual Command

Ordernr. Variants EUR excl. VAT

N-K3-L

N-K3-L-TS

N-K3-H

N-K3-MHS

Forest protection equipment light

consisting of:

Floor protection plate continuous to the front axle, material thickness:

6mm, service accesses,

incl. assembly or free delivery 4.690,00

Forest protection equipment light incl. side panels


Forest light + side panel for gearbox; fuel tank (up to cab suspension),

battery box, material thickness: 3 mm,

service accesses,

incl. assembly or free delivery 9.800,00

Forest protection equipment heavy


Floor protection plate, tank protection below (material thickness

6mm), side paneling for engine, transmission and fuel tank (material

thickness 3mm) service accesses,

Cab protection - 4 pillar forest frame, rear window 12 mm polycarbonate,

branch deflector for engine by means of 2 ropes from forest

frame, mirror removable, side fender protection rear left and right,

Tested according to DIN ISO 8083 and DIN ISO 8084


Motor hood protection plate incl. holder

(heavy version) 400,00

N-K3-H-FM

N-K3-DW

Surcharge for mounting the loosely provided front loader console

(Stoll, Quicke, Hydrac)

Double-acting linkage, only in connection with EHR, (limited pressure

force)


570,00

4.630,00

17





N-HD2-H

N-HD2-HSM

N-HD2-MS

forest protection equipment


Floor protection plate continuous to the front axle (material thickness

6mm), side paneling for engine, transmission, fuel tank and SCR catalytic

converter (material thickness 3mm) service access, including bonnet protector,



12mm, including mounting (shipping on request) 2.550,00

Motor hood protector

Front grid (also available separately) incl. shipping 1.220,00

18



T8 Genesis


N-MA2-H

forest protection equipment


Floor protection plate continuous to the front axle (material thickness

6mm and 10mm), side panel for engine, gearbox including bonnet protector,

Fuel tank and SCR-Kat (material thickness 3mm),


N-MA2-HG Protective grid for rear window (also available separately) 1.490,00

N-MA2-MS

Motor hood protector

Front grid incl. shipping 1.220,00

19


Reverse Drive and innovation

ORDER




email.: forsttechnik@kneidinger.at

company

vehicle/type

contact person

serial number

street

Van Number

cipcode/city

telephone

Email

another Remark:

VAT number

Transport of warehouse or customer vehicles is always to be organized by the customer. For

new orders ex works CNH = in each case agreement with CNH required.

Retention of title: The object of purchase remains the property of Kneidinger 1880 GmbH

until full payment has been made.

Terms of payment: partial payment 50% 4 weeks before planned delivery,

Final invoice: 50% upon delivery

Date: (stamp and sign)

Ordernr. description EUR excl. VAT

20

Forestry Protection

ORDER




email.: forsttechnik@kneidinger.at

company

vehicle / type

contact person

serial number

Street

Van Number

cipcode/city

telephone

Email

VAT number

zusätzliche Angaben zum Fahrzeug

Frontendloader Typ

Cab suspension

air pressure system

front axle suspended

another remark:

Transport of warehouse or customer vehicles is always to be organized by the customer.

For new orders ex works CNH = in each case agreement with CNH required.

Retention of title: The object of purchase remains the property of Kneidinger 1880 GmbH

until full payment has been made.

Terms of payment: partial payment 50% 4 weeks before planned delivery,

Final invoice: 50% upon delivery

Date: (stamp and sign)

Ordernr. description EUR excl. VAT

21

Gesamtkatalog_NewHolland_engl_24

You also want an ePaper? Increase the reach of your titles

Delete template?

Save as template ?
